Practical considerations for imaging and printing security
Overview.................................................................................................................................................. 3
Imaging and printing security............................................................................................................... 3
Common Criteria Certification ..................................................................................................................... 3
IEEE p2600 ....................................................................................................................................... 4
Security checklists............................................................................................................................... 4
Conclusion: look beyond Common Criteria Certification .......................................................................... 4
HP’s imaging and printing security framework ............................................................................................... 4
Secure the Imaging and Printing Device ................................................................................................ 5
MFP walk-up authentication.......................................................................................................... 5
Network printing authentication.................................................................................................... 5
Physical document access control.................................................................................................. 5
HP Secure Erase ......................................................................................................................... 6
Vulnerabilities, viruses, and worms ................................................................................................ 6
Protect Information on the Network ....................................................................................................... 6
Network connectivity with HP Jetdirect devices................................................................................ 6
HP Digital Sending Software (DSS)................................................................................................ 7
Fax/LAN bridging ...................................................................................................................... 7
Effectively Monitor and Manage........................................................................................................... 7
HP Web Jetadmin for fleet management ........................................................................................ 7
Device and service control ........................................................................................................... 7
Firmware updates ....................................................................................................................... 7
Logging device activity ................................................................................................................ 8
Common Criteria Certification ...................................................................................................... 8
The future of imaging and printing security .................................................................................................... 8
Document security and Digital Rights Management ................................................................................. 8
Trusted Computing Group.................................................................................................................... 8
Conclusion ................................................................................................................................................ 9
Appendix A—Access controls..................................................................................................................... 10
HP Digital Sending Software 4.0.........................................................................................................10
HP Job Retention and PIN Printing ....................................................................................................... 10
Capella Technologies VeriUser Authentication ....................................................................................... 10
Jetmobile SecureJet-PS Secure Print Product ...........................................................................................10
Jetmobile Technologies SecureJet Authenticator Products......................................................................... 11
SafeCom .......................................................................................................................................... 11
Appendix B—HP Secure Erase.................................................................................................................... 12
For more information .................................................................................................................................13
Overview
The IT security climate has changed. While in the past the challenge has been to convince customers
of the need for security, the current need is to show how a product’s security capabilities complement
a customer’s existing security environment.
Security measures have evolved through the years, from firewalls that kept intruders out, to
sophisticated virus throttling systems that detect viruses before they take hold and prevent them from
spreading. Attacks now often originate from inside the network, for example: employees take
advantage of access, wireless networks are improperly secured, and unaware users introduce viruses
or worms to the secure network.
As attacks increase in sophistication, hardening the internal network’s security—from clients and
servers to the imaging and printing infrastructure—becomes critical. Further, regulatory requirements,
including Sarbanes-Oxley and the Health Insurance Portability Protection Act, are mandating
protection accountability.
Imaging and printing security
Security of the imaging and printing environment has long been ignored by IT administrators. Printers
and scanners have been considered little more than network appliances, posing none of the risks of
client and server PCs. Recent publications by hacker groups have raised the awareness that imaging
and printing devices are more than simple appliances, and that these devices have capabilities
beyond printing and scanning.
This whitepaper explains the threats and risks unique to imaging and printing environments and
provides recommendations and strategies to prevent their effects. Parallels to common security
capabilities are drawn to aid in explaining hardcopy-specific needs. Imaging and printing devices
are put into the context of regulatory requirements, although—as will be seen—there is no simple
solution.
Common Criteria Certification
While Common Criteria Certification provides a valuable means for assessing the security capabilities
of a product, it is important to understand the true significance of Certification, what Common Criteria
is and is not, and the role Common Criteria Certification plays in imaging and printing manufacturer’s
marketing differentiation claims.
Common Criteria Certification provides no credible means for assessing the true security capabilities
of hardcopy products today, and should not be used as a measure for purchasing requirements.
Common Criteria does not dictate necessary security functionality, it merely provides a means to
assess the correctness of a manufacturer’s implementation claims.
The varying levels of EAL (Evaluation Assurance Level) certification foster further confusion. Higher
certification levels are assumed to provide greater levels of security. However, as certification reflects
only the manufacturer’s functional claims, the higher levels of certification are frequently meaningless.
The majority of the hardcopy industry currently certifies Disk Erase and Analog Fax functions, but this
certification does not accurately portray a product’s security capabilities or vulnerabilities. A product
may advertise certification of these capabilities while providing no, or rudimentary, protection for the
remaining system.
To ensure Common Criteria Certification provides value, it is important to understand the product’s
complete range of capabilities versus those for which certification is claimed. While certification can
prove what a product does properly, it says nothing of what a product does not do, and to what
degree that omission represents a security risk.
3
e
IEEE p2600
The IEEE p2600 working group is defining a security standard for hardcopy devices, as well as
recommendations for the security capabilities of devices when deployed in various environments,
including enterprise, high-security, small office/home office, and public spaces.
The p2600 working group has broad industry participation, including Hewlett-Packard, Lexmark,
Canon, Xerox, Sharp, Ricoh, IBM, Epson, Okidata, Equitrac, and Oce.
The p2600 standard will provide a means for credibly measuring the security capabilities of individual
manufacturers. HP is actively participating within the working group, and will Common Criteria-certify
products to the standard when complete. As of this time, HP devices support the majority of capabilities
specified in the draft documents.
Security checklists
The National Institute of Standards and Technologies (NIST) has been tasked by U.S. legislation to
develop checklists that facilitate security configuration of devices likely to be used by the U.S. Federal
Government. NIST has requested IT equipment manufacturers to develop these security checklists for
their products. Details of the checklist program are available at
NIST will review manufacturer’s checklists for relevance and correctness and publish those checklists
on a searchable NIST website.
HP considers security checklists as a means to significantly improve the security capabilities’ ease of
configuration for imaging and printing products. A security checklist for the HP LaserJet 4345mfp is
available for public review at
http://checklists.nist.gov/repository/, and is currently the only available
hardcopy product checklist available from any manufacturer. HP plans to develop additional checklists
for hardcopy devices in the future.
http://csrc.nist.gov/checklists.
Conclusion: look beyond Common Criteria Certification
Ultimately, individuals must look carefully at their requirements and not be swayed by manufacturer
advertising claims. Common Criteria Certification adds significant cost and development time to
products, while providing limited assurance to the product’s actual capabilities and potential
vulnerabilities. Products that are not certified may actually provide more robust security capabilities than
products that are certified. NIST security checklists simplify the complex process of enabling security
functions, and better illustrate the product’s capabilities
HP’s imaging and printing security framework
To simplify the presentation of security concepts, HP developed an imaging and printing security
framework with three categories of security functions:
Secure the Device Includes elements that protect the function of the physical device, including access controls for
Protect Information on
the Network management, scanning, and printing protocols.
Effectively Monitor and
Manage
The categories within HP’s imaging and printing security framework are built from traditional network
security theory, which identifies the four elements that compose a secure system: confidentiality, access
control, integrity, and non-repudiation.
management and use, secure deletion of files, and physical security.
Includes network communications, including media access protocols such as 802.1x and secur
Includes the capabilities to securely manage fleets of imaging and printing devices and audit
devices for compliance to security policies and regulatory requirements
4
In addition to directly implementing extensive security capabilities in the device, HP strategically
partners with companies through the Global Solutions Catalog (
imaging and printing security, as well as solutions tailored to individual customers and environments.
The breadth and depth of the capabilities provided by HP and its partners uniquely poises HP as the
leader in imaging and printing security.
www.hpgsc.com) to provide enhanced
Secure the Imaging and Printing Device
Secure the Imaging and Printing Device includes capabilities that provide access controls to the
functions of the device and ensure the integrity of its operations.
Access controls limit MFP and printer functions to authorized users and include:
• Walk-up
• Network printing
• Physical access to printed documents
Authentication requirements vary by environment, as do integration requirements to existing
authorization mechanisms.
MFP walk-up authentication
MFPs can require users to be authenticated before accessing MFP functions via the device control
panel. MFPs can restrict access to digital sending functions and restrict digital sending email
destinations based on user. MFPs can control access to installed functions and installed applications
(e.g. HP Autostore) based on user. Device usage may also be tracked with associated users.
Integrating MFP access controls with existing enterprise access controls reduces complexity and
minimizes administration requirements. HP and its partners support a wide variety of authentication
mechanisms, including Windows® Domain accounts, proximity cards, and Smartcards.
HP’s Digital Sending Software (DSS) enables Windows and Netware authentication using an
intermediary server, while Capella Technologies’ VeriUser provides Windows authentication
embedded in the MFP. Jetmobile’s SecureJet, Ringdale’s FollowMe, and SafeCom external
authentication each provide Smartcard, swipe card, and proximity card capabilities.
Network printing authentication
Printers and MFPs may enforce access controls for network printing to restrict usage of devices and
the use of high-value consumables. Auditing systems may also use the access controls to log user
activity, such as dates and times of documents printed.
capabilities such as copying and digital sending
The HP Output Server and the Microsoft® Print Spooler provide direct integration of Domain accounts
with printing access controls, which allows control of individual users and groups, including access
rights to network printers.
Physical document access control
Documents in the output bin of a network printer are at risk for unauthorized access. PIN and Pull
Printing allow print jobs to be saved electronically in the device, or on an external server, until the
authorized user is ready to print them. The user provides a simple PIN code, or uses an authentication
method supported for other MFP walk-up operations, to release the print job. HP printers and MFPs
provide native support for PIN printing, while Jetmobile, Capella Technologies, Ringdale, and SafeCom
each provide solutions integral to their authentication products.
For more information on Access Controls, including HP and partner solutions, see Appendix A,
“Access controls,” on page 10.
5
HP Secure Erase
HP Secure Erase implements the Department of Defense (DoD) 5220-22m specification for the
deletion of data from hard disk storage. DoD 5220-22m specifies an algorithm to repetitively
overwrite hard disk data sectors to remove all trace magnetic information.
For more information on HP Secure Erase, see Appendix B, “HP Secure Erase,” on page 12.
Vulnerabilities, viruses, and worms
Vulnerability assessments are an integral step in HP’s imaging and printing product development, and
as a result these devices have been affected little by the viruses and worms that afflict enterprise
networks. While the ingenuity of hackers continues to evolve, HP ensures its products meet the threat
posed by hostile network environments.
• Chai
HP’s Chai provides a means to extend an imaging and printing device’s functionality. For example,
Capella Technologies’ VeriUser Authentication is implemented as a Chailet. Access controls restrict
installation of Chailets to authorized administrators, however, as it is important to avoid installing
malware on PCs, Chailets should only be installed from known and trusted sources, such as HP and
its partners.
Protect Information on the Network
Protecting Information on the Network insures that network communications between users,
administrators, the imaging and printing device, and the workflow are confidential and prevent
unauthorized modification by maintaining their integrity.
Network connectivity with HP Jetdirect devices
Network connectivity for HP imaging and printing devices is provided by the HP Jetdirect family of
products, including internal cards, external boxes, and embedded networking. HP Jetdirect provides
many secure network protocols and services, including:
802.1x for Wired Provides access control to the Ethernet network. Network devices that are unable to authenticate
Networks to the 802.1x authorization server have all network access denied. 802.1x can prevent
unauthorized users from attaching devices to the network as well as insure that only IT deployed
and trusted devices, such as those with virus protection software, are allowed access.
IPsec Allows for strong authentication, confidentiality, and integrity of communications, and can secure
network printing and scanning protocols. The HP Jetdirect 635n IPv6/IPsec and Gigabit Ethernet
internal print server, available November 2005, uses a cryptographic accelerator to provide
click-to-clunk performance that rivals unsecured protocols, and supports the IPsec implementations
available in all current major operating systems, including Windows, Unix®, and Linux®.
SNMPv3 and HTTPS Provide secure management of the imaging and printing device. SNMPv3 provides strong
authentication and encryption of management communications and is used by HP Web Jetadmin
to provide fleet management of HP imaging and printing devices. HTTPS using SSL/TLS provides
security of web protocols and is used for secure management using the device’s embedded web
server, as well as security of web services such as consumable reordering.
Secure IPP (IPP-S) The secure form of the IPP protocol using SSL/TLS, secure IPP requires no additional configuration
and is primarily intended for small networks lacking sophisticated IT administration. While Secure
IPP may be used in large enterprise environments, IPsec is the recommended protocol for securing
printing and scanning functions.
6
HP Digital Sending Software (DSS)
HP Digital Sending Software 4.0 can encrypt scanned documents between the MFP and the DSS
Server. The DSS Server may then use the “Secondary email” function to store the encrypted document
in a location accessible to third-party applications, such as Omtool, that then securely retransmit the
document to its final destination via email. In addition to the secondary email function, secure sending
to email, fax, and network folders may be achieved by securing the network communications between
the DSS Server and the remote server using IPsec.
To control email distribution, the SMTP server used by the DSS Server may be configured to enforce
internal security policies. Such policies may prevent digital sending to email addresses outside of the
internal network or analyzing the content of digitally sent documents to prevent breaches of
confidentiality.
Fax/LAN bridging
The analog fax port of an HP imaging and printing device is isolated from the digital network
connectivity of the device. Communications to the analog fax are routed directly to the device
formatter and cannot be bridged to the digital network, preventing the threat of an attacker
connecting to the analog fax through a telephone line and then gaining access to an internal network.
HP is currently in the process of receiving Common Criteria Certification to validate this behavior in
the HP LaserJet 4345mfp and 4730mfp.
Effectively Monitor and Manage
Effectively Monitor and Manage allows for imaging and printing infrastructure maintenance and
enables auditing to facilitate compliance with policy and regulatory requirements. Effectively
managing network resources is critical to maintaining a secure network.
HP Web Jetadmin for fleet management
HP Web Jetadmin (WJA) is the backbone for the administration and maintenance of imaging and
printing products, for both HP and its competitors, deployed on enterprise networks. Fleet or batch
management enables consistent management and security policy enforcement across a large number
of imaging and printing devices. WJA can manage any device that supports the SNMP Printer MIB
and allow manufacturers to develop device-specific extensions using plug-ins.
WJA uses SNMPv3 to ensure authenticated and confidential management of networked devices. WJA
allows devices to be manually administered and can automatically discover and configure newly
installed devices.
Device and service control
Imaging and printing devices support many network protocols and services. Protocols and services
that are unused often go ignored, resulting in unintended vulnerabilities, such as unsecured
management interfaces or printing protocols that circumvent job accounting controls. HP imaging and
printing devices allow individual control over these protocols and services and let administrators
enable only the functionality required.
Firmware updates
Firmware updates can correct product defects and enhance product functionality, and they are an
important means for preventing the exploitation of security vulnerabilities. It is important for IT and
security administrators to monitor the availability of firmware updates and apply as necessary. HP
releases firmware updates based on the severity of the defect and provides administrators the ability
to receive automatic email notifications of releases.
HP Web Jetadmin allows an administrator to discover devices using out-of-date firmware and update
those devices automatically over the network.
7
Logging device activity
Logging device activities ensures compliance to security and access policies. HP DSS, Capella,
SafeCom, and Ringdale each allow device activity, including user, document, and destination, to be
monitored. Logging functions can also include configuration and management actions.
Common Criteria Certification
HP is currently in process of receiving Common Criteria Certification for Disk Erase and analog fax
capabilities for the HP LaserJet 4345mfp, 4730mfp.
HP supports the IEEE p2600’s development of an imaging and printing security standard that will
allow credible industry-wide Common Criteria Certification and expects to certify products to the
standard when available.
The future of imaging and printing security
Document security and Digital Rights Management
Document security is evolving. Driven by Digital Rights Management, developers are focusing on the
security of the content, rather than the security of the application that transports it. Current,
rudimentary, examples include document password protection by application (e.g., Excel
spreadsheets and Word documents). Passwords provide basic, limited capabilities.
Adobe® Systems (PDF) and Microsoft (Metro) have both introduced content protection capabilities in
their respective document formats, allowing control over individual access to documents, limits on
document redistribution, and automatic expiration of content after a defined date.
As content protection evolves, the enforcement of controls will move from PC-based applications that
render documents for devices, to the devices themselves. Likewise, content originating at a device
(e.g., scanned documents) will immediately receive content protections, rather than rely on attached
PC-devices to provide it.
Trusted Computing Group
The Trusted Computing Group (TCG, www.trustedcomputinggroup.org) is a standards organization
with over 100 member companies developing standards to enhance the trustworthiness of computing
equipment. HP chairs the Hardcopy Work Group, which is responsible for standards related to imaging
and printing devices. Trusted Computing will ensure devices operate with a greater level of integrity.
Trusted imaging and printing platforms will allow both IT administrators and users to validate the
trustworthiness of a device prior to its use. Such trusted capabilities could ensure that only authorized
MFPs are allowed access to the network, that designated MFPs are the actual originators of documents,
and that printers cannot replicate print jobs without user permission.
8
Conclusion
HP imaging and printing has evolved with enterprise security needs. HP offers imaging and printing
devices with a broad range of security capabilities, including high-security products that allow
operations in the most demanding environments and the tools to effectively manage large-scale
deployments of those devices.
While it would be impossible to prescribe all of the security requirements for an enterprise’s imaging
and printing environment, the following recommendations may be used as a starting point for
enabling that security.
1. Assess Common Criteria Certification needs
Today, features being certified by the hardcopy industry are not representative of the true risks that
face imaging and printing devices. It is critical to scrutinize certification and assess the capabilities
of the device against actual needs.
2. Fleet/batch manage using HP Web Jetadmin
HP Web Jetadmin provides consistent management of enterprise-deployed imaging and printing
devices and is critical for maintaining a secure environment. Fleet management aids in the
consistency of policy enforcement and assists in audit and regulatory compliance.
Update firmware images
3.
Firmware updates protect against product defects and vulnerabilities. HP provides automated
firmware update notification services, and HP Web Jetadmin aids in deploying updates across
enterprise environments.
4. Disable unused ports and services
Frequently, imaging and printing devices have unused capabilities that are enabled. In some cases,
these capabilities may enable functionality counter to the intent of the administrator, such as leaving
insecure management protocols accessible, when only encrypted management is desired.
Implement access controls
5.
HP printers and MFPs allow a variety of user-level authentication mechanisms, including passwords,
proximity cards, and Smartcards. Access controls can ensure that only authorized users utilize the
imaging and printing infrastructure, while authentication capabilities provide assurances of who is
using the environment, and how they are using it, which aids in audit and regulatory compliance.
Implement secure protocols
6.
The sophistication necessary to sniff network traffic has been reduced by the distribution of hacking
tools, as well as by legitimate network analyzers. IPsec secures existing printing and scanning
applications with strong encryption, while SNMPv3 and HTTPS secures management functions.
9
Appendix A—Access controls
HP Digital Sending Software 4.0
HP Digital Sending Software allows MFPs to digitally send documents to a variety of destinations,
including email, fax, and network folders.
DSS allows the MFP to authenticate a user prior to allowing access to MFP functions. DSS allows
integration of authentication functions with Microsoft Windows (using NTLM or Kerberos) and Novell
Netware (using Bindery or NDS) operating systems. If authentication is enabled, users are prompted
for their username, password, and domain/tree by the MFP. The MFP then transmits these credentials
to the DSS server, and the DSS server authenticates the user to the Windows or Novell system as
appropriate.
If a remote network folder requires authentication for access, the user’s previously provided credentials
are used. If the user has not previously provided their user credentials, they are prompted to enter
them to access the network folder.
HP Job Retention and PIN Printing
HP provides support for PIN printing on a variety of HP LaserJet platforms, including the HP LaserJet
2300, 2400, 4250, 4350, and LJ 5500 printers in conjunction with current PCL print drivers.
Capella Technologies VeriUser Authentication
Capella Technologies offers authenticated user access to MFP and digital sender functions in Windows
environments through the VeriUser Authentication Solution. VeriUser consists of VuLDAP and VuNTLM,
available as either a hardware module or software update, that can be installed on a wide range of
existing MFP devices.
The printer administrator may specify which MFP and digital sender functions require authenticated
access. As necessary, users are prompted for their user credentials, and the MFP authenticates access
with the local Windows server using LDAP or NTLM.
VuLDAP authenticates users via the LDAP protocol and supports:
• HP LaserJet 4100mfp, 9000mfp
VuNTLM authenticates users via Microsoft’s NTLM protocol, which provides encryption of account
credentials, and supports:
• HP LaserJet 4100mfp, 4345mfp, 9000mfp, 9040mfp 9050mfp
• HP Color LaserJet 9500mfp, 4730mfp
• HP Digital Sender 9200c
Jetmobile SecureJet-PS Secure Print Product
SecureJet PS supports a variety of authentication mechanisms for retrieving print jobs. A basic PIN
may be used for job retrieval, using either the MFPs control panel or an add-on terminal, or a more
advanced swipe card, proximity badge, or Smartcard can be used. Authentication provided by
SecureJet may be integrated with Capella’s MegaTrack software tool for job accounting.
10
Jetmobile Technologies SecureJet Authenticator Products
Jetmobile have a series of authentication products including user pin (SecureJet FP), Smart Card
(SecureJet SC), Proximity Card (SecureJet PX), or Swipe Card (SecureJet SW). These authentication
products can be used to authenticate MFP functions and supported applications. Authentication
provided by these SecureJet products may be integrated with Capella’s MegaTrack software tool for
job accounting.
SafeCom
SafeCom provides a suite of security capabilities, including Pull Printing and authenticated MFP device
access. As with Jetmobile, SafeCom supports a variety of hardware authentication devices, including
magnetic swipe cards and proximity badges. SafeCom provides optional encryption for
communications and allows the authentication to be integrated with job tracking and billing tools.
SafeCom is deployed using the DIMM module on HP LaserJet 4100, 4200, 4300, 9000, 9055, and
9065 devices, and HP Color LaserJet 4600, 5500, and 9500 devices. Other printers and MFPs are
supported by external SafeCom equipment that attaches via a parallel or network port.
Ringdale FollowMe printing
Ringdale provides Pull Printing, as well as access controls to printing and scanning functionality. Jobs
are stored on the FollowMe Q-Server and users may be authenticated using a variety of hardware
authentication mechanisms, including proximity cards and Smartcards. FollowMe Hardware for job
release is an external hardware component, allowing compatibility with a large range of printers and
MFPs.
11
Appendix B—HP Secure Erase
HP Secure Erase implements the Department of Defense (DoD) specification 5220-22m algorithm for
the deletion of data from hard disk storage. Typically when files are erased from a disk, they are simply
marked as removed, however the data remains on the drive and can be recovered with undelete tools.
The DoD 5220-22m algorithm specifies the repetitive overwriting of the disk data to ensure no trace
magnetic data remains. Data erased using the DoD 5220-22m algorithm is considered unrecoverable.
Secure Erase can occur continuously as files are deleted, or erase the entire disk when triggered by an
administrator or a regularly scheduled event configured by HP Web Jetadmin.
HP Secure Erase is available on the following devices:
• HP LaserJet 2400, 4250, 4350 printers
• HP LaserJet 4100mfp, 4345mfp, 4730mfp, 9000mfp, 9000Lmfp, 9040mfp, 9050, 9050mfp,
9055mfp, 9065mfp
• HP Color LaserJet 5550 printer
• HP Color LaserJet 9500mfp
12
For more information
• Please see the “HP Secure Erase for Imaging and Printing” whitepaper
www.hp.com/sbso/security/secure_disk_erase.pdf) for complete details of algorithms implemented
(
and devices supported.
• Capella Technologies:
• Global Solutions Catalog:
• Jetmobile:
www.jetmobile.com
• National Institute of Standards and Technologies checklist:
• Ringdale:
• SafeCom:
www.ringdale.com
www.safecom.dk
• Trusted Computer Group:
© 2003 Hewlett-Packard Development Company, L.P. The information
contained herein is subject to change without notice. The only warranties for
HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
Linux is a U.S. registered trademark of Linus Torvalds. Microsoft and Windows
are U.S. registered trademarks of Microsoft Corporation. UNIX is a registered
trademark of the Open Group.
XXXX-XXXXEN, 09/2005
www.capellatech.com
www.hpgsc.com
www.trustedcomputinggroup.org
http://csrc.nist.gov/checklists
Loading...
