QuickSpecs
HP ProLiant ML350 Generation 6

Overview

The HP ProLiant ML350 G6 is the best price performance DP Tower server that delivers excellence with performance, expandability and availability. The G6 server has more memory capacity and HDD expandability than previous generations. It combines the latest Intel Xeon 5600 processors with QPI technology, best-in-class availability features, and unsurpassed flexibility in a system ideal for growing businesses and especially well suited to meet the needs of remote branch offices.
Front View:
SATA DVD ROM or DVD RW optical drive
Four (4) removable media bays
Eight (8) SFF (2.5") (shown) or six (6) LFF (3.5") SAS or SATA hot plug drive bays
Two (2) USB ports
LEDs: System power, Health, Power cap, NIC 1&2, UID
Six (6) expansion slots
Nine (9) DIMM slots (Processor 2): DDR3 Registered (RDIMM) or Unbuffered (UDIMM) memory
Processor heatsink
System fans
10.
Nine (9) DIMM slots (Processor 1): DDR3 Registered (RDIMM) or Unbuffered (UDIMM) memory
What's New
Support for Intel's latest 5600 series processors
Rear View:
PS/2 mouse port
Serial port
Dedicated remote management port
Six (6) expansion slots
Two (2) network ports
Two (2) USB ports
Video port
Power supply bay 1
PS/2 keyboard port
10.
Power supply bay 2
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 1
QuickSpecs

Standard Features

NOTE:
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information
- Factory Integrated Models" section.
Processor
One of the following depending on Model
Six-Core Processors
Intel® Xeon® Processor X5675 (3.06 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor X5670 (2.93 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor X5660 (2.80 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor E5649 (2.53 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor E5645 (2.40 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Quad-Core Processors
Intel® Xeon® Processor X5672 (3.20 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor E5640 (2.66 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo (1/1/2/2)
Intel® Xeon® Processor E5630 (2.53 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo
Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo
Intel® Xeon® Processor E5607 (2.26 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor E5606 (2.13 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® Processor E5603 (1.60 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
Intel® Xeon® processor X5570 (2.93 GHz, 8MB L3 cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® processor X5560 (2.80 GHz, 8MB L3 cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® processor X5550 (2.66 GHz, 8MB L3 cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® processor E5540 (2.53 GHz, 8MB L3 cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® processor E5530 (2.40 GHz, 8MB L3 cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® processor E5520 (2.26 GHz, 8MB L3 cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5507 (2.26 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® processor E5506 (2.13 GHz, 4MB L3 cache, 80W, DDR3-800)
Intel® Xeon® processor E5504 (2.00 GHz, 4MB L3 cache, 80W, DDR3-800)
Intel® Xeon® Processor L5630 (2.13 GHz, 12MB L3 Cache, 40W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® processor L5520 (2.26 GHz, 8MB L3 cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2)
Quad-Core Intel® Xeon® Processor L5506 (2.13 GHz, 4MB cache, QPI 4.8GT/s)
HP ProLiant ML350 Generation 6
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 2
QuickSpecs
Standard Features
Dual-Core Processors
Intel® Xeon® Processor E5503 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® processor E5502 (1.86 GHz, 4MB L3 cache, 80W, DDR3-800)
NOTE:
HT indicates that the processor model supports Intel® Hyper-Threading Technology.
NOTE:
Turbo indicates the maximum potential frequency increment when using Intel® Turbo
Boost Technology, with 4, 3, 2, and 1 cores active.
NOTE:
DDR3 speed is the maximum memory speed of the processor. Actual memory speed
may depend on the quantity and type of DIMMs installed.
NOTE:
For the Intel 5600 and 5500 Series, the letter preceding the model number indicates the performance/wattage of the processor. "X" denotes High Performance/Wattage; "E" denotes Enterprise Performance/Wattage (Mainstream); and "L" denotes Lower Wattage.
NOTE:
Customers transitioning from 5500 series processors to 5600 series processors must include a third fan along with the two fans present on the server
HP ProLiant ML350 Generation 6
Cache Memory
One of the following depending on Model
Chipset
Upgradeability
Memory Protection
12MB (1 x 12MB) Level 3 cache
NOTE:
For 5600 series processors
8MB (1 x 8MB) Level 3 cache
NOTE:
For X5570/X5560/X5550/E5540/E5530/E5520/L5520 processors
4MB (1 x 4MB) Level 3 cache
NOTE:
For E5507/E5506/E5504/E5503/E5502/L5506 processors
Intel® 5520 Chipset
NOTE:
For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/
Upgradeable to two processors
NOTE:
total 4, 8 or 12 cores
Advanced ECC
Mirroring mode
Lock-step mode
Online Spare (Requires X5600 or E5600 processor family)
.
Memory
One of the following depending on model
Type
Standard (Performance Models)
Standard (Base Models)
Standard (Entry Models)
Standard (Entry Models)
Maximum (RDIMM)
Maximum (UDIMM
Maximum (RDIMM)
NOTE:
Depending on the memory configuration and processor model, the memory speed may run at 1333MHz, 1066MHz, or 800MHz. Please see the Online Memory Configuration Tool at:
www.hp.com/go/ddr3memory-configurator
NOTE:
The 16 GB memory module is a quad ranked 800MHz DDR3 memory.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
DDR3 Registered (RDIMM) or Unbuffered (UDIMM)
12 GB (6 x 2 GB) RDIMM
6 GB (3 x 2 GB) RDIMM
4 GB (2 x 2 GB) RDIMM
4 GB (1 x 4 GB) RDIMM
192 GB (12 x 16 GB)
48 GB (12 x 4 GB)
144 GB (18 x 8 GB) for Registered Memory configurations
.
Page 3
QuickSpecs
Standard Features
HP ProLiant ML350 Generation 6
Network Controller
Expansion Slots
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Expansion
Slot #
6
5
4
3
2
1
NOTE:
Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may
alter the actual bus assignment number
NOTE:
Indicates the number of physical electrical lanes running to the connector.
NOTE:
Six total expansion slots. One PCI-Express x16 Gen2 (x8 speed); One PCI-Express x8 Gen2 (x8 speed); Four PCI-Express x8 Gen2 (x4 speed). Optional PCI-X Expander provides additional two 64-bit/100-MHz PCI-X slots by using a single PCI Express slot.
Technology
PCI Express
Gen2
PCI Express
Gen2
PCI Express
Gen2
PCI Express
Gen2
PCI Express
Gen2
PCI Express
Gen2
Bus Width
x4 x8
x4 x8
x8
x8 x8
x4 x8
x4 x8
Connector
Width
x16
Bus
Number
5
8
11
14
17
20
Form Factor
Standard
Height/Length
Standard
Height/Length
Standard
Height/Length
Standard
Height/Length
Standard
Height/Length
Standard
Height/Length
Notes
Storage Controller
One of the following depending on model
Internal Storage Devices
Maximum Internal Storage
One of the following depending on model
Entry Models
Base Models
Performance Models
Available upgrades: 256MB, 512MB with BBWC, Battery kit upgrade (for BBWC), and Smart Array Advanced Pack (SAAP)
Diskette Drive
Optical Drives
Hard Drives
Hot Plug LFF SAS
Hot Plug LFF SATA
Hot Plug SFF SAS
Hot Plug SFF SATA
Embedded HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
Embedded HP Smart Array P410i/256MB Controller (RAID 0/1/1+0/5/5+0)
Embedded HP Smart Array P410i/512 MB BBWC Controller (RAID 0/1/1+0/5/5+0)
Embedded HP Smart Array P410i/1GB FBWC Controller
None included standard (not supported)
HP Half-Height SATA DVD-ROM Optical Drive
None standard
16TB
16TB
8TB
8TB
8 x 2TB
8 x 2TB
16 x 500GB
16 x 500GB
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 4
QuickSpecs
Standard Features
HP ProLiant ML350 Generation 6
Interfaces
Industry Standard Compliance
Serial
Pointing Device (Mouse)
Graphics
Keyboard
Network RJ-45
USB 2.0 Ports
ACPI V2.0 Compliant PCI-Express Gen2 PXE Support WOL Support PCI-X 1.0a Compliant Novell Certified Microsoft® Logo certifications USB 2.0 Support SMBIOS 2.6.1
1
1
1
1
3 (1 dedicated for iLO)
6 (2 front, 2 rear, 2 internal)
NOTE:
regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb­support.html
Please see the following URL for additional information
.
Server Power Cords
Power Supply
ProLiant ML servers in a rack-mount configuration no longer ship standard with NEMA power cords that allow connection to 110V US wall outlets in a home or office. These servers are primarily connected to PDU's in data center racks so they now ship standard with only a PDU power cord (416151-B21). If a user wishes to power a ProLiant ML rack-mount server using a 110V receptacle (NEMA-15), the NEMA power cord must be ordered separately. The 12' cord (AF556A) or 6' cord (187335-001) can be purchased online at HP.COM. In a tower configuration, the servers ship standard with a 6' country specific NEMA power cord. If customers require a local power cord, they can check the power cord matrix for the appropriate country specific sku. Please see the following power cord matrix:
http://www.hp.com/go/powercordmatrix
HP 750W CS HE Gold Power Supply (standard on some models) HP 460W CS HE Gold Power Supply (standard on some models)
.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 5
QuickSpecs
Standard Features
HP ProLiant ML350 Generation 6
Common Slot Power Supplies
HP has a new design for ProLiant power- the new Common Slot Power Supply bay. This design provides the customer with commonality in power supplies across multiple platforms to save on the cost of spares and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers come with Common Slot, High Efficiency and Right-Size Power Supplies. The new HP Common Slot power supplies are designed for the highest power efficiency without degrading performance of the ProLiant server. Power Supplies have efficiency ratings up to 92%. There are three Right Size power options available depending on the configuration of your server. To make sure you select the correct power supply to meet your configuration, please use the HP Power Advisor at:
www.hp.com/go/hppoweradvisor
Compliant, Hot Plug and Redundant.
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your needs.
The HP ProLiant Common Slot Power supplies meet multiple Energy Efficiency Initiatives: Climate Savers Computing Initiative GOLD and ECOS Consulting 80PLUS GOLD for the 460w and 750w Power Supplies and Climate Savers Computing Initiative Silver, ECOS Consulting 80PLUS Silver for 1200w Power Supply. HP has also been working with the EPA on developing an ENERGY STAR? Computer Server specification and plans on offering models that meet the requirements when they are published. Please visit the ENERGY STAR website at www.energystar.gov for updates on the specification development process and approved platforms. The HP Power Advisor is located at:
www.hp.com/go/hppoweradvisor
. All HP Common Slot power sources are UL, CE Mark
www.hp.com/go/proliant-energy-efficient
www.hp.com/go/proliant-energy-efficient
or
or
System Fans
Required Cabling
Operating Systems and Virtualization Software Support for ProLiant Servers
3 system fans ship standard
NOTE:
Does not include power supply or processor heat sink fans. Processor heat sink fans packed in processor kit.
N+1 fan redundancy standard
For required cabling information, refer to the HP ProLiant ML350 G6 cabling matrix at:
http://www.hp.com/servers/proliantML350
NOTE:
Please see the "Storage" section of this QuickSpecs for important information on controllers and cables required to support SAS or SATA hard drives as well as storage management software available for SATA hard drives.
Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) NetWare
NOTE:
NetWare support on Intel Xeon 5500 family only.
VMware HP Citrix Essentials for XenServer
NOTE:
For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
www.hp.com/support/ML350G6
http://www.hp.com/go/ossupport
.
.
and our driver download page
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 6
QuickSpecs
Standard Features
HP ProLiant ML350 Generation 6
Graphics
Form Factor
HP Insight Management Control Software
Integrated ATI RN50, 64MB video standard
16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024
NOTE:
Maximum resolution available via iLO remote console is 1280 x 1024.
Tower or Rack (5U)
NOTE:
Rack models (with a Tower to Rack conversion kit) support:
Square or round hole racks 24"- 36" deep, including HP Rack System /E and HP Systems Telco racks with 3rd part option kit from Rack Solutions
http://www.racksolutions.com/hp
HP Insight Foundation
Managing the growing number of servers can be complex and expensive for your organization. IT managers need to address changing business needs with tools that meet the challenges of managing today's complex Datacenters.
HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server lifecycle. This provides the customer with higher levels of operational efficiency and highly reliable systems:
http://www.hp.com/go/foundation
HP Integrated Lights­Out (iLO)
The foundation pack includes:
HP SmartStart HP Management DVD HP ProLiant Smart Update Firmware DVD
NOTE:
In an effort to support reducing our environmental impact, the HP Insight Foundation Suite for ProLiant media will be available as a selectable option for this server at time of order of a CTO SKU. This will allow customers to order the number of media kits that best meet their needs and eliminate receiving unnecessary duplicate media.
HP Integrated Lights-Out (iLO) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration of ProLiant ML, DL, and BL servers. HP iLO functions without additional software and can be accessed from any location via a web browser. HP iLO works hand-in-hand with HP Systems Insight Manager, Insight Control suites, and Insight Dynamics for ProLiant, helping customers unleash the value of the ProLiant platform and deliver the highest possible quality of IT service. For more information, visit:
www.hp.com/go/iLO
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 7
QuickSpecs
Standard Features
HP ProLiant ML350 Generation 6
Intelligent Manageability
Security
Warranty
HP Systems Insight Manager SmartStart Redundant ROM System Firmware Update ROMPaq ProLiant RBSU (ROM-Based Setup Utility) Automatic Server Recovery-2 (ASR-2) Dynamic Sector Repairing (with Smart Array Controller) Drive Parameter Tracking (with Smart Array Controller) Pre-Failure Warranty (covers processors, memory, and SAS hard drives)
Power-on password Setup password Serial interface control Disk configuration lock Power switch security
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE:
business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 8
QuickSpecs

Optional Features

HP ProLiant ML350 Generation 6
HP Insight Management Software
HP Insight Control
HP Insight Dynamics
HP Insight Control, a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.
Two versions of Insight Control are available, to serve environments requiring either a Linux-based or a Windows-based central management server: HP Insight Control for Linux, and HP Insight Control. See
HP Insight Control includes one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:
HP Insight Dynamics for ProLiant, a product option, is advanced infrastructure management software that enables IT staff to instantly adjust their environments to meet dynamic business demands by provisioning, optimizing and protecting complex infrastructure in minutes. It's a powerful toolkit, integrated-by-design, that accelerates complex technology projects and simplifies daily operations, transforming data center economics. With Insight Dynamics IT professionals can plan capacity and power continuously, balance workloads across physical and virtual resources, and ensure cost­effective high availability. It also enables IT organizations to provision infrastructure consistently and automatically from pools of shared resources using a self-service portal. Resources provisioned can range from a single virtual machine to complex multi-tier environments and their associated physical and virtual resource requirements. In addition to the previous functional benefits, it also provides a cost­effective disaster recovery for physical and virtual environments that works with HP StorageWorks Continuous Access software for both the Enterprise Virtual Array and the XP storage array allowing application environments to be reactivated in minutes with the touch of a button to a remote location.
NOTE:
http://www.hp.com/go/insightdynamics
www.hp.com/go/insightcontrol
http://www.hp.com/services/insight
For more information, visit:
.
High Performance Clusters
HP Cluster Platforms
HPC Interconnects
HP Cluster Management Utility
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
HP Cluster Platforms are specifically engineered, factory-integrated large-scale ProLiant clusters optimized for High Performance Computing, with a choice of servers, networks and software. Operating system options include specially priced offerings for Red Hat Enterprise Linux and Novell SLES, as well as Microsoft Windows HPC Server. A Cluster Platform Configurator simplifies ordering.
http://www.hp.com/go/clusters
High Performance Computing (HPC) interconnect technologies are available for this server as part of the HP Cluster Platform portfolio. These high-speed InfiniBand and Gigabit interconnects are fully supported by HP when integrated within an HP cluster. Flexible, validated solutions can be defined with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
HP Cluster Management Utility (CMU) is an HP-licensed and HP­supported suite of tools that are used to manage large-scale Linux ProLiant systems. CMU includes software for the centralized provisioning, management and monitoring of nodes. CMU makes the administration of clusters user friendly, efficient, and effective.
http://www.hp.com/go/cmu
.
Page 9
QuickSpecs
Optional Features
HP ProLiant ML350 Generation 6
Factory Express Portfolio for Servers and Storage
HP Enterprise Configurator
HP HPC Linux Value Pack
HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.
For more information on Factory Express services for your specific server model please contact your sales representative or go to:
The HP eConfigure Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance. For additional information please visit:
HP HPC Linux Value Pack (Value Pack) is an HP-licensed and HP­supported specially priced software bundle for the development and deployment of applications on HPC Cluster Platforms. Value Pack includes the Platform LSF workload scheduler, the HP-MPI parallelization library, the HP Unified Parallel C compiler and the HP Shmem library, as well as the execution environments for the libraries and compiler.
http://www.hp.com/products/configurator
HP HPC Linux Value Pack
http://www.hp.com/go/factory-express
.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 10
QuickSpecs

Service and Support

HP ProLiant ML350 Generation 6
Service and Support
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROI
When you buy HP server and storage products and solutions, it's also a good time to think about what levels of support you may need. Our portfolio of service options reduce deployment and management worries while helping you get the most out of your server and storage investments. We take a holistic approach to your environment, bridging servers, blades, storage, software and network infrastructures with our packaged HP Care Pack Services for servers and storage.
Protect your business beyond warranty
When it comes to robustness and reliability, standard computing equipment warranties have matured along with technology. Good news that can also create problems stemming from depending on standard warranties designed to only protect against product defects and some downtime causes. Using a standard approach to warranty uplifts, such as HP Care Pack Services, helps reduce downtime risks and provides operational consistency for mission-critical and standard business computing.
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost effectively
HP Care Pack Services offer a standard reactive hardware and software support services suite sold separately, or combined with our Support Plus and Support Plus 24 services. The portfolio also provides a combination of integrated proactive and reactive services, such as Proactive 24 Service and Critical Service. In addition with HP Proactive Select, you can acquire the specific proactive constancy and technical services. HP Proactive Select menu offers a broad set of service options that you can mix and match depending on your specific requirements. Proactive service options include offers for server, storage, network, SAN device, software, environment and education services.
HP server and storage lifecycle support services offers a full spectrum of customer care-from technology support to complex migrations to complete managed services. HP Factory Express provides customization, integration and deployment services for turnkey solutions. HP Education Services offer flexible, comprehensive training on to help your IT staff get the most out of your server and storage investments. HP Financial solutions extend innovative financing and cost-effective asset management programs-from purchase to equipment retirement.
Learn more:
NOTE:
HP Care Pack Services are sold by HP and HP Authorized Service Partners: Services for customers purchasing from HP or an enterprise reseller are quoted using HP order configuration tools. Customers purchasing from a commercial reseller can find HP Care Pack Services at
http://www.hp.com/go/lookuptool
www.hp.com/services/servers
Care Pack Services availability may vary by product and country.
and
www.hp.com/services/storage
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 11
QuickSpecs
HP ProLiant ML350 Generation 6
Service and Support
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services
3-Year HP Hardware Support Onsite Call-to-Repair (CTR) Service, 6- or 24-hour
Provides your IT manager with a team of support specialists who will quickly begin troubleshooting the system to help return the hardware to operating condition within 6 or 24 hours of the initial service request to the HP Global Solution Center.
HP is committed to repairing your hardware within a maximum of six or twenty four hours. The benefits include:
Improved system uptime Predictable repair times More effective IT resource planning Consistent level of hardware support across your multi-technology systems
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6636ENN
3-Year HP Hardware Support Onsite Service, 4-hour response, 24x7
Provides you with rapid remote support and if required an HP authorized representative who will arrive on site any time and day of the year to begin hardware maintenance service within 4 hours of the service request being logged.
This service provides a trained HP service specialist to perform an installation that meets HP quality standards, for:
Help improve or maintain system uptime Convenient onsite support Committed response time
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.
Expedited installation, with all service prerequisites met before the installation is performed Installation in accordance with manufacturer's specifications, enhancing the supportability of your HP-installed hardware and software Service delivery at a mutually scheduled time Allows your IT resources to stay focused on their core tasks and priorities Availability of an HP service specialist to answer questions during the onsite delivery of this service
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 12
QuickSpecs
HP ProLiant ML350 Generation 6
Service and Support
Optional HP Care Pack Services that will enhance your HP product experience
Optional Services
3-Year HP Support Plus 24
As an alternative to our recommended support level, for customers who need access to responsive 24x7 hardware and software support plus software updates on HP and selected third party products:
For a higher return on your server and storage technology, our 3-year combined reactive support service delivers integrated onsite hardware/software support services available 24x7x365, including access to HP technical resources, 4-hour response onsite hardware support and software updates.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EEE
3-Year HP Proactive 24
As an alternative to our recommended support level, for customers who want enhanced operational effectiveness and proactive problem identification:
Provides improved stability, availability and operational effectiveness with an integrated hardware and software support service that combines industry-leading reactive technical assistance with proactive account services, giving your IT manage support from a team of service specialists.
eSupport
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA0-1614ENUC
HP Proactive Select Service
Customer needs on demand access to consulting, technical proactive services and education courses
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy Proactive Select Service Credits when you purchase your hardware and then use the credits over the next 12 months.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN
HP eSupport is a portfolio of technology-based services that assist you with managing your business environment - from the desktop to the data center.
Support Portal
The HP support portal provides one-stop access to the information, tools and services you need to manage the daily operations of your IT environment.
Features include
Access to self-solve tools (including search technical knowledge base) Efficient logging and tracking of support cases Collaboration with other business and IT professionals Download of patches and drivers Access to diagnostic tools Proactive notification of relevant information
:
Access to certain features of the support portal requires an HP service agreement. To access the support portal, visit:
HP Insight Remote Support software delivers secure remote support for your HP Servers and Storage, 24 X 7, so you can spend less time solving problems and more time focused on your business. You can have your systems remotely monitored for hardware failure using secure
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
http://www.hp.com/support
Page 13
QuickSpecs
Service and Support
technology that's been proven at thousands of companies around the world. In many cases, you can avoid problems before they occur.
HP ProLiant ML350 Generation 6
Customer Technical Training
HP Services Awards
Additional Services Information
In today's cost-conscious business environment, IT professionals, developers, consultants and users face an interesting challenge: how to keep up with the latest technologies and expand important skills while delivering profitable results on current projects. To help address this challenge, HP offers innovative training solutions that help keep you up-to-date on virtualization, server, storage, Insight Control, Citrix, Microsoft® and open source/Linux-related topics-while spending less time away from business-critical activities.
HP Technology Services continues to be recognized for service and support excellence by customers, partners, industry organizations and publications around the world. Recent honors and award reflect our services team's dedications, technical expertise, professionalism and uncompromising commitment to customer satisfaction.
To learn more on HP ProLiant servers, HP BladeSystem servers and HP StorageWorks storage products, please contact your HP sales representative or HP Authorized Channel Partner. Or visit:
http://www.hp.com/hps/storage
www.hp.com/services/proliant
or
www.hp.com/services/bladesystem
or
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 14
QuickSpecs

Pre-configured Models

NOTE:
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information
- Factory Integrated Models" section.
NOTE:
Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional
options section of this QuickSpecs.
NOTE:
HP does not allow factory integration of options into pre-configured models. Any additional options purchased will
be shipped separately.
NOTE:
If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section
of this QuickSpecs.
NOTE:
Not all models are available in all regions. Check with your local country HP offices for availability.
Entry Tower
HP ML350T06 E5606 LFF Entry AU Svr
638180-xx1
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
HP ProLiant ML350 Generation 6
(1) Intel® Xeon® Processor E5606 (2.13 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
12MB (1 x 12MB) L3 cache
(4 GB (1 x 4 GB) RDIMM)
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/Zero Memory Controller
None ship standard
6.0 TB LFF (3.5-inch) SAS
6.0 TB LFF (3.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(1) 460 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
HP ProLiant ML350 G6 E5504 1P 4GB-R P410i/ZM 460W RPS Tower Server
487932-xx1
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
1 Intel® Xeon® processor E5504 (2.00 GHz, 4MB L3 cache, 80W, DDR3-800)
4MB (1 x 4MB) L3 cache
4GB (2 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/Zero Memory Controller
None ship standard
6.0 TB LFF (3.5-inch) SAS
6.0 TB LFF (3.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(1) 460 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 15
QuickSpecs
Pre-configured Models
Base Models
HP ML350T06 E5645 SFF Base AU Svr
638181-xx1
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
HP ProLiant ML350 Generation 6
(1) Intel® Xeon® Processor E5645 (2.40 GHz, 12MB L3 Cache, 80W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
12MB (1 x 12MB) L3 cache
6GB (3 x 2GB) PC3-10600 (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/256MB Controller
None ship standard
2.4 TB SFF(2.5") SAS 2.0 TB SFF(2.5") SATA
HP Half-Height SATA DVD-ROM Optical Drive
(1) 750 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
HP ProLiant ML350 G6 E5520 1P 6GB-R P410i/256 750W RPS Tower Server
487930-xx1
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
1 Intel® Xeon® processor E5520 (2.26 GHz, 8MB L3 cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) L3 cache
6GB (3 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/256MB Controller
None ship standard
2.4 TB SFF(2.5-inch) SAS
2.0 TB SFF(2.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(1) 750 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Tower or Rack (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 16
QuickSpecs
Pre-configured Models
HP ProLiant ML350 Generation 6
HP ProLiant ML350 G6 E5520 1P 6GB-R P410i/256 750W RPS Rack Server
487931-xx1
HP ProLiant ML350 G6 E5620 1P 6GB-R P410i/256 460W RPS Tower Server
594869-xx1
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
Processor
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
Intel® Xeon® processor E5520 (2.26 GHz, 8MB L3 cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) L3 cache
6GB (3 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/256MB Controller
None ship standard
2.4 TB SFF(2.5-inch) SAS
2.0 TB SFF(2.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(1) 750 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Rack (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
(1) Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo (1/1/2/2)
12MB (1 x 12MB) L3 cache
6GB (3 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/256MB Controller
None ship standard
(8) SFF SAS/SATA HDD Bays; upgradeable to (16)
SATA DVD ROM
(1) 460 Watt Hot-Plug (Redundancy enabled) power supply
3 fans ship standard
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Performance Models
HP ProLiant ML350 G6 E5530 2P 12GB-R P410i/512 BBWC 750W RPS Tower Server
487928-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
(2) Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) L3 cache
12GB (6 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/512MB with BBWC
None ship standard
2.4 TB SFF(2.5-inch) SAS
2.0 TB SFF(2.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(2) 750 Watt Hot-Plug Redundant power supplies
4 fans ship standard
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Page 17
QuickSpecs
Pre-configured Models
HP ProLiant ML350 Generation 6
HP ProLiant ML350 G6 E5530 2P 12GB-R P410i/512 BBWC 750W RPS Rack Server
576778-xx1
HP ProLiant ML350 G6 X5650 2P 12GB-R P410i/1GB FBWC 750W RPS Tower Server
594874-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Insight Control
Form Factor
Warranty
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Warranty
(2) Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) L3 cache
12GB (6 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/512MB with BBWC
None ship standard
2.4 TB SFF(2.5-inch) SAS
2.0 TB SFF(2.5-inch) SATA
HP Half-Height SATA DVD-ROM Optical Drive
(2) 750 Watt Hot-Plug Redundant power supplies
4 full Redundant fans
HP Insight Control Environment No Media single server license, including 1 year of 24x7 Technical Support and Updates
Rack (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
(2) Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)
12MB (1 x 12MB) L3 cache
12GB (6 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Embedded HP Smart Array P410i/1G FBWC Controller
None ship standard
(8) SFF SAS/SATA HDD Bays; upgradeable to (16)
SATA DVD ROM
(2) 750 Watt Hot-Plug Redundant power supplies
4 full Redundant fans
Tower (5U)
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Country Code Key
xx=00
xx=01
xx=03
xx=04
xx=05
xx=20
xx=29
xx=37
xx=42
xx=AA
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Tower Code Key
US US
Australia
UK
Germany
France
Brazil
Japan Japan
ADP ADP
Europe Europe
PRC PRC
Rack Code Key
N/A
N/A
N/A
N/A
N/A
Page 18
QuickSpecs
HP ProLiant ML350 Generation 6

Configuration Information - Factory Integrated Models

NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.
NOTE:
Configure-to-order (CTO) servers must start with a CTO Chassis.
NOTE:
FIO indicates that this option is only available as a factory installable option.
Step 1: Base Configuration (choose one of the following configurable models)
HP Models
ML350G6 Tower Models
HP ProLiant ML350 G6 SFF Configure-to-order Tower Chassis
Includes:
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter Embedded Smart Array P410i Controller Eight (8) Hot-Plug (SFF) SAS/SATA Drive Bays Seven (7) HDD blanks Six (6) Expansion slots: One Express x16 Gen2 (x8 speed); One PCI-Express x8 Gen2 (x8 speed); Four PCI-Express x8 Gen2 (x4 speed) Six (6) USB ports PS/2 Keyboard & Mouse (2-button) Tower Form Factor
HP ProLiant ML350 G6 LFF Configure-to-order Tower Chassis
Includes:
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter Embedded Smart Array P410i Controller Six (6) Hot-Plug (LFF) SAS/SATA Drive Bays Five (5) HDD blanks Six (6) Expansion slots: One Express x16 Gen2 (x8 speed); One PCI-Express x8 Gen2(x8 speed); Four PCI-Express x8 Gen2 (x4 speed) Six (6) USB ports P/S 2 Keyboard & Mouse (2-button) Tower Form Factor
ML350G6 Rack Models
HP ProLiant ML350 G6 SFF Configure-to-order Rack Server
Includes:
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter Embedded Smart Array P410i Controller Eight (8) Hot-Plug (SFF) SAS/SATA Drive Bays Seven (7) HDD blanks Six (6) Expansion slots: One Express x16 Gen2 (x8 speed); One PCI-Express x8 Gen2 (x8 speed); Four PCI-Express x8 Gen2 (x4 speed) Six (6) USB ports Rack (5U) Form Factor
HP ProLiant ML350 G6 LFF Configure-to-order Rack Server
Includes:
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter Embedded Smart Array P410i Controller Six (6) Hot-Plug (LFF) SAS/SATA Drive Bays Six (6) Expansion slots: One Express x16 Gen2 (x8 speed); One PCI-Express x8 Gen2 (x8 speed); Four PCI-Express x8 Gen2 (x4 speed) Six (6) USB ports Rack (5U) Form Factor
483447-B21
483448-B21
483443-B21
483444-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 19
QuickSpecs
HP ProLiant ML350 Generation 6
Configuration Information - Factory Integrated Models
Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)
HP Processors
Six-Core Processors
HP ML350 G6 Intel® Xeon® X5675 (3.06GHz/6-core/12MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5670 (2.93GHz/6-core/12MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5660 (2.80GHz/6-core/12MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5650 (2.66GHz/6-core/12MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5649 (2.53GHz/6-core/12MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5645 (2.40GHz/6-core/12MB/80W) FIO Processor Kit
Quad-Core Processors
HP ML350 G6 Intel® Xeon® X5672 (3.20GHz/4-core/12MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5640 (2.66GHz/4-core/12MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5630 (2.53GHz/4-core/12MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5620 (2.40GHz/4-core/12MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5607 (2.26GHz/4-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5606 (2.13GHz/4-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5603 (2.00GHz/2-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5570 (2.93GHz/4-core/8MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5560 (2.80GHz/4-core/8MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® X5550 (2.66GHz/4-core/8MB/95W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5540 (2.53GHz/4-core/8MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5530 (2.40GHz/4-core/8MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5520 (2.26GHz/4-core/8MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5507 (2.26 GHz/4-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5506 (2.13GHz/4-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5504 (2.00GHz/4-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® L5630 (2.13GHz/4-core/12MB/40W) FIO Processor Kit
638315-L21
601236-L21
601238-L21
601240-L21
638316-L21
638317-L21
638314-L21
601242-L21
601244-L21
601246-L21
638318-L21
638319-L21
638320-L21
495904-L21
495906-L21
495908-L21
495910-L21
495912-L21
495914-L21
601248-L21
495916-L21
495918-L21
601252-L21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 20
QuickSpecs
Configuration Information - Factory Integrated Models
HP ProLiant ML350 Generation 6
HP Memory
HP Power Supplies
HP ML350 G6 Intel® Xeon® L5520 (2.26GHz/4-core/8MB/60W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® L5506 (2.13GHz/4-core/4MB/60W) FIO Processor Kit
Dual-Core Processors
HP ML350 G6 Intel® Xeon® E5503 (2.0GHz/2-core/4MB/80W) FIO Processor Kit
HP ML350 G6 Intel® Xeon® E5502 (1.86GHz/2-core/4MB/80W) FIO Processor Kit
Registered DIMMs (RDIMMs)
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered CAS-7 Memory Kit
HP 4GB (1x4GB) Quad Rank x8 PC3-8500 (DDR3-1066) Registered CAS-7 Low Power Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit
HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP Memory Kit
NOTE:
Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600
series processors
Unbuffered with ECC DIMMs (UDIMMs)
HP 1GB (1x1GB) Single Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600 (DDR3-1333) Unbuffered CAS-9 Low Power Memory Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see:
http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
NOTE:
Prior to making a power supply selection it is highly recommended that the HP Power Advisor is run to determine the right size power supply for your server configuration. The HP Power Advisor is located at:
www.hp.com/go/hppoweradvisor
HP 460W HE Hot Plug AC Power Supply Kit
HP 750W Common Slot High Efficiency Power Supply Kit
HP 1200W 12V Hot Plug AC Power Supply
www.hp.com/go/ddr3memory-configurator
.
505513-L21
495902-L21
601250-L21
495920-L21
500656-B21
593339-B21
500658-B21
500662-B21
500666-B21
500660-B21
604504-B21
604506-B21
627812-B21
500668-B21
500670-B21
500672-B21
619488-B21
503296-B21
512327-B21
500172-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 21
QuickSpecs
HP ProLiant ML350 Generation 6
Configuration Information - Factory Integrated Models
NOTE:
Option Kits contain optional power supply, an IEC power cable and PDU IEC cables.
Step 3: Choose Additional Factory Integratable Options
HP Storage Controllers
HP Performance Packs
HP Insight Software
HP Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 FIO SAS Controller
NOTE:
SAS Controller supporting RAID 0/1/1+0/5.
HP Smart Array P411/256 2-ports Ext PCIe x8 FIO SAS Controller
NOTE:
SAS Controller supporting RAID 0/1/1+0/5.
Upgrade Options
HP 256MB Factory Integrated P-Series Cache Module
NOTE:
Available for P410i only.
Performance Packs are necessary to configure a HP ProLiant ML350 G6 to a High Performance Model which includes the latest performance technologies and enterprise class availability features pre-installed for convenience and value. The Performance Pack includes a 2nd processor, 512MB cache with BBWC for P410i (650 mAh P-Series Battery), redundant fan, and (1) 750W CS HE Power supply kit.
NOTE:
Must also select 447326-B21 (SATA DVD ROM) to achieve parity to ML350 G6 High Performance Models.
HP ML350G6 E5530 HPM FIO Kit
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Single Server FIO License
HP Insight Control for Linux including 1yr 24x7 Support ML/DL Bundle 1 Server FIO License
491191-B21
491193-B21
534108-B21
530547-B21
582765-B21
TC203A
Step 4: Choose Additional Options for Factory Integration
NOTE:
For additional options, please refer to the "Core Options" and "Additional Options" section below.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 22
QuickSpecs
HP ProLiant ML350 Generation 6

Core Options

NOTE:
Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP
recommends the use of an HP approved configurator. Contact your local sales representative for additional information.
HP Unique Options
HP ML350 G6 Redundant Fan/Baffle Kit
HP ML350 G6 2 Slot PCI-X Riser Kit
NOTE:
into two full height, full length 64-bit 100MHz PCI-X slots. The PCI-X Expander Kit can only be plug in Slot 1.
HP ML350G6 Tower to Rack Conversion Kit
NOTE:
Power supplies.
HP 2.5 Hard Disk Drive Blank Kit
The HP PCI-X Expander kit converts a single PCI Express slot (Slot 1)
See "Redundant Options" section below for Hot Plug Redundant
515081-B21
488413-B21
534534-B21
503771-B21
HP Processors
Six-Core Processors
HP ML350 G6 Intel® Xeon® X5675 (3.06GHz/6-core/12MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® X5670 (2.93GHz/6-core/12MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® X5660 (2.80GHz/6-core/12MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® X5650 (2.66GHz/6-core/12MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® E5649 (2.53GHz/6-core/12MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5645 (2.40GHz/6-core/12MB/80W) Processor Kit
Quad-Core Processors
HP ML350 G6 Intel® Xeon® X5672 (3.20GHz/4-core/12MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® E5640 (2.66GHz/4-core/12MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5630 (2.53GHz/4-core/12MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5620 (2.40GHz/4-core/12MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5607 (2.26GHz/4-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5606 (2.13GHz/4-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5603 (2.00GHz/2-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® X5570 (2.93GHz/4-core/8MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® X5560 (2.80GHz/4-core/8MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® X5550 (2.66GHz/4-core/8MB/95W) Processor Kit
HP ML350 G6 Intel® Xeon® E5540 (2.53GHz/4-core/8MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5530 (2.40GHz/4-core/8MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5520 (2.26GHz/4-core/8MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5507 (2.26 GHz/4-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5506 (2.13GHz/4-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5504 (2.00GHz/4-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® L5630 (2.13GHz/4-core/12MB/40W) Processor Kit
638315-B21
601236-B21
601238-B21
601240-B21
638316-B21
638317-B21
638314-B21
601242-B21
601244-B21
601246-B21
638318-B21
638319-B21
638320-B21
495904-B21
495906-B21
495908-B21
495910-B21
495912-B21
495914-B21
601248-B21
495916-B21
495918-B21
601252-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 23
QuickSpecs
Core Options
HP ProLiant ML350 Generation 6
HP Memory
HP ML350 G6 Intel® Xeon® L5520 (2.26GHz/4-core/8MB/60W) Processor Kit
HP ML350 G6 Intel® Xeon® L5506 (2.13GHz/4-core/4MB/60W) Processor Kit
Dual-Core Processors
HP ML350 G6 Intel® Xeon® E5503 (2.0GHz/2-core/4MB/80W) Processor Kit
HP ML350 G6 Intel® Xeon® E5502 (1.86GHz/2-core/4MB/80W) Processor Kit
Registered RDIMMs
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered CAS-7 Memory Kit
HP 4GB (1x4GB) Quad Rank x8 PC3-8500 (DDR3-1066) Registered CAS-7 Low Power Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3L-10600 (DDR3-1333) Registered CAS­9 Low Power Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit
NOTE:
Low Voltage DIMMs can only be used with Intel® Xeon® processor
5600 series processors
HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP Memory Kit
Unregistered with ECC UDIMMs
HP 1GB (1x1GB) Single Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600 (DDR3-1333) Unbuffered CAS-9 Low Power Memory Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see:
efficient
.
www.hp.com/go/ddr3memory-configurator
www.hp.com/go/proliant-energy-
.
505513-B21
495902-B21
601250-B21
495920-B21
500656-B21
593339-B21
500658-B21
500662-B21
500666-B21
500660-B21
604504-B21
604506-B21
627812-B21
500668-B21
500670-B21
500672-B21
619488-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 24
QuickSpecs
Core Options
HP ProLiant ML350 Generation 6
HP Drive Cage Options
HP Optical Drives
HP Hard Drives
HP ML350/370 G6 8 Small Form Factor (SFF) 2nd Drive Cage Kit
NOTE:
is required to purchase a SAS RAID controller or SAS Expander Card to support over 8 HDD
NOTE:
drive blank spare kit: 392613-001
HP ML350/ML/DL370G6 2 Large Form Factor Drive Kit
NOTE: NOTE:
drive blank spare kit: 389015-001
HP Half-Height SATA DVD-ROM Optical Drive
HP Half-Height SATA DVD-RW Optical Drive
NOTE:
adding SATA Optical Drives. To ensure compatibility of the SATA Optical Drives, please add additional optical drives only on models with Quad-Core 5400 Series.
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 146GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 450GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
HP 300GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 2TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive
HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide)
SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 500GB 6G SAS 7.2K rpm SFF (2.5-inch) Dual Port Midline 1yr Warranty Hard Drive
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
The Second drive cage installation replaces 2 internal optical bays. It
To cover a empty SFF HDD slot, please order the following SFF hard
The Second drive cage installation replaces 2 internal optical bays.
To cover a empty LFF HDD slot, please order the following LFF hard
Please note that some of the earlier BTO models may not support
Please see the QuickSpecs for Technical Specifications and additional
507803-B21
487936-B21
447326-B21
447328-B21
581286-B21
581284-B21
507127-B21
512547-B21
507125-B21
512545-B21
516828-B21
516816-B21
516814-B21
507616-B21
507614-B21
507610-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 25
QuickSpecs
Core Options
HP ProLiant ML350 Generation 6
HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1yr Warranty Hard Drive
HP 160GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1yr Warranty Hard Drive
SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 2TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
HP 1TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives
HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive
HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive
NOTE:
SATA hard drives have a 1-year warranty. Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/13021_div/13021_div.html
(Worldwide)
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
HP 120GB 3G SATA LFF (3.5-inch) Midline 1yr Warranty Solid State Drive
HP 60GB 3G SATA LFF (3.5-inch) Midline 1yr Warranty Solid State Drive
SATA Hot Plug Midline (MDL) Solid State Drives
HP 120GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive
HP 60GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13415_div/13415_div.html
(Worldwide)
NOTE:
HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
NOTE:
specific hard drive QuickSpecs for details.
Please see the QuickSpecs for Technical Specifications and additional
The components of a storage subsystem (e.g. the drive, the
Hard drives have either a one year or three year warranty; refer to the
507750-B21
530888-B21
507632-B21
454146-B21
458928-B21
571230-B21
458945-B21
570763-B21
570761-B21
572073-B21
572071-B21
HP Networking
Gigabit Ethernet adapters
HP NC112T PCI Express Gigabit Server Adapter
HP NC360T PCI-E Dual Port Gigabit Server Adapter
HP NC364T PCI-E Quad Port Gigabit Server Adapter
NOTE:
Does not support Windows 2000.
NOTE:
There is a maximum of five NC364T PCI Express Quad Port Gigabit Server Adapter NICs allowed in this server.
HP NC365T 4-port Ethernet Server Adapter
HP NC373F PCI-E Multifunction 1000SX Gigabit Svr Adapter
HP NC373T PCI-E Multifunction Gigabit Server Adapter
HP NC375T PCI Express Quad Port Gigabit Server Adapter
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter
10 Gigabit Ethernet adapters
NOTE:
A minimum of two gigabytes (2 GB) of server memory is required per each adapter.
NOTE:
Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.
HP NC522SFP Dual Port 10GbE Server Adapter
HP NC523SFP 10Gb 2-port Server Adapter
503746-B21
412648-B21
435508-B21
593722-B21
394793-B21
394791-B21
538696-B21
458492-B21
468332-B21
593717-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 26
QuickSpecs
Core Options
HP ProLiant ML350 Generation 6
HP I/O Expansion Options
HP Power Supplies
HP Cooling Options
HP NC550SFP Dual Port 10GbE Server Adapter
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
HP ML350 G6 2 Slot PCI-X Riser Kit
NOTE:
the HP Power Advisor is run to determine the right size power supply for your server configuration. The HP Power Advisor is located at:
www.hp.com/go/hppoweradvisor
Power Supplies
HP 460W HE Hot Plug AC Power Supply Kit
HP 750W Common Slot High Efficiency Power Supply Kit
HP 1200W 12V Hot Plug AC Power Supply
NOTE:
PDU IEC cables.
HP ML350 G6 Redundant Fan/Baffle Kit
www.hp.com/go/ProLiantNICs
Prior to making a power supply selection it is highly recommended that
.
Option Kits contain optional power supply, an IEC power cable and
581201-B21
488413-B21
503296-B21
512327-B21
500172-B21
515081-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 27
QuickSpecs

Additional Options

HP ProLiant ML350 Generation 6
HP Insight Software
HP Insight Control for Linux
HP Insight Control for Linux including 1yr 24x7 Support Electronic License
HP Insight Control for Linux including 1yr 24x7 Support Single Server License
HP Insight Control for Linux Media Kit
NOTE:
Media pack DVD contains the ISO image for HP Insight Control for Linux, HP Systems Insight Manager, HP Insight Control power management, HP Insight Control virtual machine management, and an integrated installer. Servers must be acquired separately.
NOTE:
Licenses ship without media. The Media Kit for Insight Control for Linux can be ordered separately, or can be downloaded at:
http://www.hp.com/go/ic-linux
NOTE:
Electronic software is available in all countries except China and Japan. Customers in China and Japan should order the physical equivalent.
NOTE:
Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single set of activation keys.
NOTE:
For additional License Kits, including electronic licensing options, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/13019_div/13019_div.html
HP Insight Control
HP Insight Software Media Kit
NOTE:
Manager and Essentials software products and components licensed by Insight Control Environment suite. Uses an integrated installer to perform quick and accurate software installation and updates.
HP Insight Control including 1yr 24x7 Technical Support and Updates Single Server License
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Electronic License
NOTE:
multiple licenses with a single activation key.
NOTE:
Japan. Customers in China and Japan should order the physical equivalent.
NOTE:
entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
NOTE:
ordered separately, or can be downloaded at:
http://www.hp.com/go/insightupdates
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html
HP Integrated Lights-Out (iLO) Advanced
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Single Server License
NOTE:
Advanced. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service
NOTE:
Japan. Customers in China and Japan should order the physical equivalent.
NOTE:
see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html
Insight Software DVD media without licenses. Contains Insight
Electronic and Flexible-Quantity licenses can be used to purchase
Electronic software is available in all countries except China and
Customer will receive a license entitlement certificate. The license
Licenses ship without media. The HP Insight Control Media Kit can be
For additional License Kits, please see the QuickSpecs at:
This license allows 1 server to be deployed and managed via HP iLO
Electronic software is available in all countries except China and
For additional license kits, including electronic delivery options, please
(click on Download button).
.
TC213AAE
TC209A
TC208A
436222-B21
452148-B22
TC278AAE
512485-B21
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 28
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP I/O Accelerator Options
HP Graphics Options
HP Security - TPM
HP 160GB SLC PCIe ioDrive
NOTE:
A low-profile PCI bracket is included for use in low-profile slots.
HP 320GB MLC PCIe ioDrive
NOTE:
A low-profile PCI bracket is included for use in low-profile slots.
HP 320GB SLC PCIe ioDrive Duo
HP 640GB MLC PCIe ioDrive Duo
HP 1.28TB MLC PCIe ioDrive Duo
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/13587_div/13587_div.html
(Worldwide)
HP 350/370G6 Graphic Card Cable Kit
HP Trusted Platform Module Option
NOTE:
The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker leverages the enhanced security capabilities of a Trusted Platform Module (TPM) version 1.2. The TPM works with BitLocker to help protect user data and to ensure that a server running Windows Server 2008 has not been tampered with while the system was offline. For more information about TPM, including a white paper, go to:
www.hp.com/go/TPM
NOTE:
TPM deployment.
NOTE:
retained. Misplacing or loosing the key could result in data loss.
ProLiant OS pre-installed units will come with the partition required for
The TPM key is unique to every TPM deployed server and must be
.
600278-B21
600279-B21
600281-B21
600282-B21
641027-B21
537721-B21
488069-B21
HP Storage Controllers
SAS Controllers
HP Smart Array P212 Controller
HP Smart Array P212/ZM 1-ports Int/1-ports Ext PCIe x8 SAS Controller
HP Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 SAS Controller
HP Smart Array P410 Controller
HP Smart Array P410/256 2-ports Int PCIe x8 SAS Controller
HP Smart Array P410/512 BBWC 2-ports Int PCIe x8 SAS Controller
HP Smart Array P410/512 FBWC 2-ports Int PCIe x8 SAS Controller
HP Smart Array P410/1G FBWC 2-ports Int PCIe x8 SAS Controller
NOTE:
HP NHP Internal SAS/SATA 4 Port Cable Kit (487734-B21) is required when adding Smart Array P410 Controller on Non-Hot Plug SATA/SAS server models.
HP Smart Array P411 Controller
HP Smart Array P411/256 2-ports Ext PCIe x8 SAS Controller
HP Smart Array P411/512 BBWC 2-ports Ext PCIe x8 SAS Controller
HP Smart Array P411/512 FBWC 2-ports Ext PCIe x8 SAS Controller
HP Smart Array P411/1G FBWC 2-ports Ext PCIe x8 SAS Controller
Smart Array P812 Controller
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
462828-B21
462834-B21
462862-B21
462864-B21
578230-B21
572532-B21
462830-B21
462832-B21
578229-B21
572531-B21
Page 29
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP Smart Array P812/1G FBWC 2-ports Int/4-ports Ext PCIe x8 SAS Controller
Optional Upgrades
HP 256MB P-series Cache Upgrade
NOTE:
Controller only.
HP 512MB P-Series Battery Backed Write Cache Upgrade
NOTE:
P411 Controller only.
HP 650 mAh P-Series Battery
NOTE:
Controller, and HP Smart Array P411 Controller only.
HP 15 Position 24in SFP Battery Cable Assembly
NOTE:
Controller, and HP Smart Array P411 Controller only.
HP 512MB Flash Backed Write Cache
NOTE:
HP 1GB Flash Backed Cache
NOTE:
HP Smart Array Advanced Pack including 1yr 24x7 Technical Support and Updates Single Server License
NOTE:
multiple licenses with a single activation key. Customers will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Include one year of 24x7 HP Software Technical Support Services.
HP 24 Bay 3Gb SAS Expander Card
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13203_div/13203_div.html
(Smart Array P212 Controller)
http://h18000.www1.hp.com/products/quickspecs/13201_div/13201_div.html
(Smart Array P410 Controller)
http://h18000.www1.hp.com/products/quickspecs/13202_div/13202_div.html
(Smart Array P411 Controller)
http://h18000.www1.hp.com/products/quickspecs/13558_div/13558_div.html
(Smart Array P812 Controller)
http://h18000.www1.hp.com/products/quickspecs/13200_div/13200_div.html
(Smart Array Advanced Pack)
SAS HBA
HP SC08Ge 2-ports Ext PCIe x8 SAS Host Bus Adapter
HP Modular Smart Array SC08e 2-ports Ext PCIe x8 SAS Host Bus Adapter
NOTE:
http://h18004.www1.hp.com/products/quickspecs/13082_div/13082_div.html
SCSI HBA
HP SC11Xe Ultra320 Single Channel/ PCIe x4 SCSI Host Bus Adapter
NOTE:
HP StorageWorks U320e SCSI Dual Channel Host Bus Adapter
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12566_div/12566_div.html
Supported on HP Smart Array P212 & HP Smart Array P410/ZM
Supported on HP Smart Array P410 Controller, and HP Smart Array
Supported on HP Smart Array P212 Controller, HP Smart Array P410
Supported on HP Smart Array P212 Controller, HP Smart Array P410
Supported on the Smart Array P410i Controller only.
Supported on the Smart Array P410i Controller only.
This part number can be used to purchase a single license or to order
Please see the QuickSpecs for Technical Specifications and additional
Please see the QuickSpecs for additional information:
Supports external drive attach.
Please see the following QuickSpecs for additional information:
487204-B21
462968-B21
462967-B21
462969-B21
496029-B21
534916-B21
534562-B21
516471-B21
468406-B21
488765-B21
614988-B21
412911-B21
AH627A
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 30
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP Tape Backup
NOTE:
For the complete range of StorageWorks tape drives, autoloaders, libraries and media see: software compatibility of HP StorageWorks tape backup products see:
http://www.hp.com/go/connect
HP StorageWorks DAT 160 SAS Internal Tape Drive
HP StorageWorks DAT 160 USB Internal Tape Drive
HP StorageWorks DAT 320 USB Internal Tape Drive
HP StorageWorks DAT 320 SAS Internal Tape Drive
NOTE:
recommended.
HP StorageWorks Ultrium 448 SAS Internal Drive
HP StorageWorks LTO-4 Ultrium 1760 SAS Internal WW Tape Drive
NOTE:
recommended.
HP StorageWorks LTO-4 Ultrium 1840 SAS External WW Drive
NOTE:
recommended.
HP StorageWorks LTO-5 Ultrium 3000 SAS Internal Tape Drive
HP StorageWorks LTO-5 Ultrium 3000 SAS External Tape Drive
NOTE:
recommended.
HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader
NOTE:
installation. Connection using HP SC44Ge SAS Host Bus Adapter (416096­B21) recommended.
HP StorageWorks MSL2024 1 LTO-5 Ultrium 3000 SAS Tape Library
HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Tape Library
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Tape Library
Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21)
Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21)
Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21)
Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21)
Requires HP 1U Tape Autoloader Rack Kit (AH166A) for rack
http://www.hp.com/go/tape
.
. For hardware and
Q1587A
Q1580A
AJ825A
AJ830A
DW085A
EH919A
EH861A
EH957A
EH958A
AK377A
BL537A
AK380A
AK378A
HP Disk Backup
NOTE:
http://www.hp.com/go/d2d
drives and media see: compatibility of HP StorageWorks disk backup products see:
http://www.hp.com/go/connect
HP StorageWorks RDX Removable Disk Backup Systems USB
HP StorageWorks RDX320 Internal Removable Disk Backup System
NOTE:
bay available for drive installation into the server. 320GB of disk capacity per data cartridge.
HP StorageWorks RDX500 Internal Removable Disk Backup System
NOTE:
bay available for drive installation into the server. 500GB of disk capacity per data cartridge.
HP StorageWorks RDX160 Internal Removable Disk Backup System
HP StorageWorks RDX 1TB Internal Removable Disk Backup System
For the complete range of StorageWorks D2D Backup Systems see:
. For the complete range of StorageWorks RDX
http://www.hp.com/go/rdx
.
For installation into 1U USB Rack-Mount Kit (A8007A). No peripheral
For installation into 1U USB Rack-Mount Kit (A8007A). No peripheral
. For hardware and software
AJ767A
AJ934A
AJ765A
BV847A
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 31
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP StorageWorks Options
NOTE:
The following is a list of all Fibre Channel Host Bus Adapters for Windows and Linux. For detailed compatibility information please see:
http://h18006.www1.hp.com/storage/saninfrastructure/hba.html
StorageWorks Fibre Channel HBA
Brocade Fibre Channel HBAs
HP StorageWorks 81B PCIe 8Gb Fibre Channel Single Port Host Bus Adapter
HP StorageWorks 82B PCIe 8Gb Fibre Channel Dual Port Host Bus Adapter
HP StorageWorks 41B PCIe 4Gb Fibre Channel Single Port Host Bus Adapter
HP StorageWorks 42B PCIe 4Gb Fibre Channel Dual Port Host Bus Adapter
Emulex Fibre Channel HBAs
HP StorageWorks 81E 8Gb Single Port PCI-e Fibre Channel Host Bus Adapter
HP StorageWorks 82E 8Gb Dual Port PCI-e Fibre Channel Host Bus Adapter
HP StorageWorks FC2142SR 4Gb PCIe Host Bus Adapter
HP StorageWorks FC2242SR 4Gb PCIe DC Host Bus Adapter
QLogic Fibre Channel HBAs
HP StorageWorks 81Q PCI-e Fibre Channel Host Bus Adapter
HP StorageWorks 82Q 8Gb Dual Port PCI-e Fibre Channel Host Bus Adapter
HP StorageWorks FC1142SR 4Gb PCIe Host Bus Adapter
HP StorageWorks FC1242SR 4Gb PCIe DC Host Bus Adapter
StorageWorks Converged Network Adapter
HP StorageWorks CN1000E Dual Port Converged Network Adapter
HP StorageWorks CN1000Q Dual Port Converged Network Adapter
AP769A
AP770A
AP767A
AP768A
AJ762A
AJ763A
A8002A
A8003A
AK344A
AJ764A
AE311A
AE312A
AW520A
BS668A
HP Disk Storage Systems
MSA SAN Storage Arrays
HP StorageWorks MSA60 Array
NOTE:
configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12627_div/12627_div.html
(Worldwide)
HP StorageWorks MSA70 Array
NOTE:
configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12652_div/12652_div.html
(Worldwide)
HP StorageWorks 2012sa Dual Controller Modular Smart Array
HP StorageWorks 2012sa Single Controller Modular Smart Array
NOTE:
information at:
http://h18000.www1.hp.com/products/quickspecs/13045_div/13045_div.html
(Worldwide)
Disk Enclosures
HP StorageWorks D2600 Disk Enclosure
HP StorageWorks D2700 Disk Enclosure
NOTE:
information at:
http://h18000.www1.hp.com/products/quickspecs/13404_div/13404_div.html
(Worldwide)
Please see the QuickSpecs for additional information including
Please see the QuickSpecs for additional information including
Please see the QuickSpecs for additional options and configuration
Please see the QuickSpecs for additional options and configuration
418408-B21
418800-B21
AJ753A
AJ752A
AJ940A
AJ941A
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 32
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP Uninterruptible Power Systems
HP Tower UPS
HP T1500 G3 UPS Models
HP T1500 G3 1400VA INTL Tower Uninterruptible Power System
HP T1500 G3 1400VA NA Tower Uninterruptible Power System
HP T1500J JP Uninterruptible Power System
NOTE:
Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/13160_div/13160_div.html
(Worldwide)
HP T1000 G3 UPS Models
HP T1000 G3 1000VA INTL Tower Uninterruptible Power System
HP T1000 G3 1000VA NA Tower Uninterruptible Power System
HP T1000J JP Uninterruptible Power System
HP Rack-mountable UPS
HP R1500 G2 UPS
HP R1500 G2 1440VA Low Voltage NA 1U Rackmount Uninterruptible Power System
HP R1500 G2 1440VA INTL 1U Rackmount Uninterruptible Power System
HP R1500 G2 1200kVA Low Voltage JP 1U Rackmount Uninterruptible Power System
NOTE:
Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/12507_div/12507_div.html
(Worldwide)
HP R/T3000 Uninterruptible Power System (UPS)
HP R/T3000 3300VA INTL 2U Rackmount Uninterruptible Power System
HP R/T3000 2880VA Low Voltage NA/JPN 2U Rackmount Uninterruptible Power System
HP R/T3000 3300VA High Voltage NA/JPN 2U Rackmount Uninterruptible Power System
NOTE:
For additional information on HP Uninterruptable Power Systems please go to:
NOTE:
Protection and Management page. Under Power Cords, click on the “HP Power Cord Matrix” link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link:
www.hp.com/products/powercords
www.hp.com/servers/rackups
Please see the UPS and PDU cable matrix's on the HP Power
.
.
AF451A
AF450A
AF458A
AF449A
AF448A
AF457A
AF419A
AF418A
AF421A
AF454A
AF452A
AF453A
HP Rack Series
HP Rack Options
Rack 10000 G2 series
HP 10642 G2 Pallet Universal Rack
HP 10642 G2 Shock Universal Rack
HP 10642 G2 1200mm deep Shock Rack
HP 10647 G2 1200mm deep Shock Rack
Keyboards and Monitors
HP TFT7600 G2 KVM Console Rackmount Keyboard BE Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard DK Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard FR Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard DE Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard Intl Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard IT Monitor
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
AF001A
AF002A
AF092A
AF094A
AZ881A
AZ876A
AZ873A
AZ872A
AZ884A
AZ874A
Page 33
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP TFT7600 G2 KVM Console Rackmount Keyboard JP Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard NO Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard PT Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard RU Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard SE/FI Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard ES Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard CH Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard UK Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard US Monitor
HP TFT7600 G2 KVM Console Rackmount Keyboard US TAA Monitor
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13731_div/13731_div.html
(Worldwide)
HP 1U IT Rackmount Keyboard with USB
HP 1U US Rackmount Keyboard with USB
HP 1U BE Rackmount Keyboard with USB
HP 1U DK Rackmount Keyboard with USB
HP 1U FR Rackmount Keyboard with USB
HP 1U DE Rackmount Keyboard with USB
HP 1U INT Rackmount Keyboard with USB
HP 1U NO Rackmount Keyboard with USB
HP 1U PT Rackmount Keyboard with USB
HP 1U RU Rackmount Keyboard with USB
HP 1U ES Rackmount Keyboard with USB
HP 1U SE/FI Rackmount Keyboard with USB
HP 1U Rackmount Keyboard with USB
HP 1U UK Rackmount Keyboard with USB
HP 1U JP Rackmount Keyboard with USB
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/12465_div/12465_div.html
(Worldwide)
HP TAA TFT7600 Rackmount Keyboard 17in US Monitor
HP TFT7600 Rackmount Keyboard 17in BE Monitor
HP TFT7600 Rackmount Keyboard 17in DK Monitor
HP TFT7600 Rackmount Keyboard 17in IT Monitor
HP TFT7600 Rackmount Keyboard 17in CH Monitor
HP TFT7600 Rackmount Keyboard 17in FR Monitor
HP TFT7600 Rackmount Keyboard 17in DE Monitor
HP TFT7600 Rackmount Keyboard 17in JP Monitor
HP TFT7600 Rackmount Keyboard 17in NO Monitor
HP TFT7600 Rackmount Keyboard 17in RU Monitor
HP TFT7600 Rackmount Keyboard 17in ES Monitor
HP TFT7600 Rackmount Keyboard 17in UK Monitor
HP TFT7600 Rackmount Keyboard 17in SE/FI Monitor
HP TFT7600 Rackmount Keyboard 17in Intl Monitor
HP TFT7600 Rackmount Keyboard 17in PT Monitor
Please see the QuickSpecs for Technical Specifications and additional
Please see the QuickSpecs for Technical Specifications and additional
AZ882A
AZ877A
AZ880A
AZ883A
AZ878A
AZ875A
AZ879A
AZ871A
AZ870A
AZ885A
AG076A
AG072A
AG083A
AG078A
AG075A
AG074A
AG086A
AG079A
AG082A
AG085A
AG077A
AG080A
AG081A
AG073A
AG084A
AG067A
AG063A
AG058A
AG056A
AG061A
AG055A
AG054A
AG064A
AG059A
AG065A
AG057A
AG053A
AG060A
AG066A
AG062A
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 34
QuickSpecs
Additional Options
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12417_div/12417_div.html
(Worldwide)
NOTE:
For additional information regarding Rack Options, please see the following URL:
HP Server Console Switches
HP Server Console 0x2x8 Port Analog Switch
HP Server Console 0x2x16 Port Analog Switch
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/11834_div/11834_div.html
(Worldwide)
HP Server Console Switch G2 with Virtual Media & CAC
HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software
HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13475_div/13475_div.html
(Worldwide)
HP IP Console Switch G2 with Virtual Media & CAC
HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software
HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software
HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13474_div/13474_div.html
(Worldwide)
Rack Kits
HP ML350G6 Tower to Rack Conversion Kit
Please see the QuickSpecs for Technical Specifications and additional
Please see the QuickSpecs for Technical Specifications and additional
http://www.hp.com/go/rackandpower
HP ProLiant ML350 Generation 6
.
AF616A
AF617A
AF618A
AF619A
AF620A
AF621A
AF622A
534534-B21
HP USB and SD Options
HP 1.44MB USB External Floppy Drive
HP 2GB USB Flash Media Drive Key Kit
NOTE:
HP qualified blank USB key for use with HP ProLiant servers that support the VMware virtualization environment and other HP value-add software like SmartStart. HP recommends this industry standard USB flash device for use with VMware ESXi. USB device must be installed in the internal slot of the ProLiant server for use with VMware ESXi. Refer to
Getting Started Guide
HP 4GB Secure Digital Flash Media Kit
NOTE:
SD media must be installed in the internal slot of the ProLiant server. Learn more at
HP USB 2-Button Optical Scroll Mouse
HP USB Standard Keyboard US
Blank SD media device is supported for use with VMware and Citrix.
http://www.hp.com/go/proliantvirtualization
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
for installation instructions.
.
HP VMware
DC141B
608447-B21
580387-B21
DC172B
DT528A#ABA
Page 35
QuickSpecs
Additional Options
HP ProLiant ML350 Generation 6
HP Care Pack Services
Hardware Services On-site Service
HP 3 year 4 hour 13x5 ProLiant ML350 Hardware Support
HP 3 year 4 hour 24x7 ProLiant ML350 Hardware Support
HP 3 year 6 hour 24x7 Call to Repair ProLiant ML350 Hardware Support
Installation & Start-up Services
HP Install ProLiant ML350 Service
HP Startup ProLiant ML350 Service
Support Plus
HP 3 year Support Plus Microsoft ProLiant ML350 Service
Support Plus 24
HP 3 year Support Plus 24 Microsoft ProLiant ML350 Service
HP 3 year Support Plus 24 SuSE ProLiant ML350 Service
U4512E
U4513E
U4514E
U4522E
U4523E
U4524E
U4525E
U6308E
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 36
QuickSpecs
HP ProLiant ML350 Generation 6

Memory

NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
DDR3 memory population guidelines
For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
Some DIMM installation guidelines are summarized below:
For servers with eighteen (18) memory slots:
There are three (3) channels per processor; six (6) channels per server There are three (3) DIMM slots for each memory channel; eighteen (18) total slots Memory channel 1 consists of the three (3) DIMMs that are closest to the processor
Memory channel 3 consists of the three (3) DIMMs that are furthest from the processor DIMM slots that are white should be populated first Do not mix Unbuffered memory (UDIMMs) with Registered memory (RDIMMs) Do not install DIMMs if the corresponding processor is not installed If only one processor is installed in a 2CPU system, only half of the DIMM slots are available To maximize performance, balance the total memory capacity between all installed processors I
t is not required, but it is recommended to load the channels similarly if possible If any Quad rank DIMMs are installed, all channels are limited to only 2 DIMMs per channel You can only install two quad-rank DIMMs per channel You can only install two UDIMMs per channel; if available, the third slot in the channel must remain empty Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel Heaviest load (DIMM with most ranks) within a channel goes furthest from the chipset For memory mirroring mode, channel 3 must be unpopulated. Channels 1 and 2 are populated identically For lock-step mode, channel 3 must be unpopulated. DIMMs in channels 1 and 2 will be installed in pairs. The paired slots will be 1,4; 2,5; 3;6 on a 3DPC system or 1,4; 2,5; on a 2DPC system Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600 series processors If mixing DIMM voltage is a requirement, please note that the DIMMs will run at 1.5V since all 1.35V are capable of supporting 1.5V operations
DIMM slot/capacity/populated speed table
DIMM Type
-> DIMM Rank->Single
Rank (1R)
DIMM Capacity ->
DIMM Native Speed (MHz) ->
Voltage
SLOTS THAT CAN BE POPULATED
18 slot servers
MAXIMUM CAPACITY (GB)
18 slot servers
POPULATED DIMM SPEED (MHz)
1 DIMM Per Channel
2 DIMM Per Channel
4GB 2GB 4GB 8GB 8GB 4GB
1333 1333 1333 1067 1333 1067 1067 1333 1333 1333
LV/Reg
18 18 18 18 18 12 12 12 12 12
72 36 72 144 144 48 192 12 24 48
1333 1333 1333 1067 1333 1067 1067 1333 1333 1333
1333
Reg Reg Reg
*
1333
Registered DIMMS (RDIMMs)
Dual Rank (2R)
*
1333
*
1067 1333
LV/Reg
*
Quad Rank (4R)
16GB
Reg Reg Reg Reg Reg
800 800 1333 1333 1333
Unbuffered with ECC DIMMs
(UDIMMs)
Single
Rank (1R)
1GB 2GB 4GB
Dual Rank (2R)
*
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 37
QuickSpecs
Memory
HP ProLiant ML350 Generation 6
3 DIMM Per Channel
* - supported with ROM update via ROM Based Setup Utility (RBSU). UDIMM support is only on 12-slot servers.
NOTES:
PC3-10600 DIMMs have a maximum speed of 1333MHz. PC3-8500 DIMMs have a maximum speed of 1066MHz Mixing DIMM speeds is allowed, but the system processor speed rules always override the DIMM capabilities If you do mix DIMM speeds, the memory bus will default to the minimum clock rate of all DIMMs in the system - even if the slower DIMM is on the other processor If you install 1x 1066MHz DIMM in channel 1 and 1x 1333MHz DIMM in channel 2, the maximum speed will be 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other channels, the maximum speed will be 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other channels, you run at 1066MHz If you install 3DPC in one channel (if applicable) and 1DPC in all other channels, you run at 800MHz Maximum memory speed will also depend on the processor installed References to the above MHz speeds are for the various speeds of DDR3 DIMMs; 1333 refers to DDR3-1333, etc.
DIMM slot and configuration diagrams
Basic memory slot & population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
Chnl 1
Chnl 2
Chnl 3
Standard memory configuration (1 CPU model)
800 800 800 800 800
18 DIMM SLOTS (9 per CPU node)
CPU1 CPU2
slot #
1 2 3
4 5 6
7 8 9
population order
G
D A
H E B
I F C
n/a n/a n/a n/a n/a
slot #
1 2 3
4 5 6
7 8 9
population order
G
D A
H E B
I F C
Chnl 1
Chnl 2
Chnl 3
6GB, consisting of three (3) 2GB dual-rank PC3-10600 RDIMMs (Base Model)
Chnl 1
Chnl 2
Chnl 3
slot #
1 2 3
4 5 6
7 8 9
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
CPU1 CPU2
population order
G; empty D; empty
A; 2GB DIMM
H; empty
E; empty
B; 2GB DIMM
I; empty
F; empty
C; 2GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; empty
A; empty
H; empty
E; empty B; empty
I; empty
F; empty
C; empty
Chnl 1
Chnl 2
Chnl 3
Page 38
QuickSpecs
HP ProLiant ML350 Generation 6
Memory
Standard memory plus optional memory (1 CPU model)
54GB, consisting of three (3) 2GB RDIMMs plus six (6) 8GB RDIMMs (Base Model)
3x 2GB dual-rank PC3-10600 RDIMMs 6x 8GB dual-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
Chnl 3
Standard memory replaced with optional memory (1 CPU model) RDIMM maximum configuration (1 CPU model)
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; 8GB DIMM D; 8GB DIMM A; 2GB DIMM
H; 8GB DIMM E; 8GB DIMM B; 2GB DIMM
I; 8GB DIMM
F; 8GB DIMM
C; 2GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; empty
A; empty
H; empty
E; empty B; empty
I; empty
F; empty
C; empty
Chnl 1
Chnl 2
Chnl 3
96GB, consisting of six (6) 16GB quad-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
Chnl 3
UDIMM maximum configuration (1 CPU model)
24GB, consisting of six (6) 4GB dual-rank PC3-10600 UDIMMs
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; empty
D; 16GB DIMM
A; 16GB DIMM
H; empty E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; empty
A; empty
H; empty
E; empty B; empty
I; empty
F; empty
C; empty
Chnl 1
Chnl 2
Chnl 3
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 39
QuickSpecs
Memory
HP ProLiant ML350 Generation 6
Chnl 1
Chnl 2
Chnl 3
Standard memory replaced with optional memory (2 CPU model) RDIMM maximum configuration (2 CPU model)
192GB, consisting of twelve (12) 16GB quad-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
Chnl 3
UDIMM maximum configuration (2 CPU model)
slot #
1 2 3
4 5 6
7 8 9
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; empty
D; 4GB DIMM A; 4GB DIMM
H; empty
E; 4GB DIMM B; 4GB DIMM
I; empty
F; 4GB DIMM
C; 4GB DIMM
CPU1 CPU2
population order
G; empty
D; 16GB DIMM
A; 16GB DIMM
H; empty E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
slot #
1 2 3
4 5 6
7 8 9
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; empty
A; empty
H; empty
E; empty B; empty
I; empty
F; empty
C; empty
population order
G; empty
D; 16GB DIMM
A; 16GB DIMM
H; empty E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
Chnl 1
Chnl 2
Chnl 3
Chnl 1
Chnl 2
Chnl 3
48GB, consisting of twelve (12) 4GB dual-rank PC3-10600 UDIMMs
Chnl 1
Chnl 2
Chnl 3
NOTE:
Capacity references are rounded to the common Gigabyte values.
slot #
1 2 3
4 5 6
7 8 9
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
CPU1 CPU2
population order
G; empty D; 4GB DIMM A; 4GB DIMM
H; empty E; 4GB DIMM B; 4GB DIMM
I; empty
F; 4GB DIMM
C; 4GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; 4GB DIMM A; 4GB DIMM
H; empty E; 4GB DIMM B; 4GB DIMM
I; empty
F; 4GB DIMM
C; 4GB DIMM
Chnl 1
Chnl 2
Chnl 3
Page 40
QuickSpecs
Memory
1GB = 1024MB 2GB = 2048MB 4GB = 4096MB 8GB = 8192MB 16GB = 16384MB
Following are memory options available from HP:
Memory
Registered DIMMs (RDIMMs)
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit
HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered CAS-7 Memory Kit
HP 4GB (1x4GB) Quad Rank x8 PC3-8500 (DDR3-1066) Registered CAS-7 Low Power Memory Kit
HP 4GB (1x4GB) Single Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit
NOTE:
Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600
series processors
HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP Memory Kit
Unbuffered with ECC DIMMs (UDIMMs)
HP 1GB (1x1GB) Single Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600 (DDR3-1333) Unbuffered CAS-9 Low Power Memory Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
ProLiant Energy Efficient Features, see:
http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
Kits described as LP include Low Power DIMMs. For more information on
HP ProLiant ML350 Generation 6
www.hp.com/go/ddr3memory-configurator
500656-B21
593339-B21
500658-B21
500662-B21
500666-B21
500660-B21
604504-B21
604506-B21
627812-B21
500668-B21
500670-B21
500672-B21
619488-B21
.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 41
QuickSpecs

Storage

HP ProLiant ML350 Generation 6
Drive Support
Removable Media
HP Half-Height SATA DVD-ROM Optical Drive
HP Half-Height SATA DVD RW Optical Drive
Quantity
Supported
Up to 1
Up to 1
Position
Supported
A-E
A-E
1 - 6
1 - 8
B,C,D,E
Controller
Integrated SATA Controller
Integrated SATA Controller
Or
A-E
D+E
6 x 3.5" (LFF) Hot-Plug SAS/SATA hard drive bays
8 x 2.5" (SFF) Hot-Plug SAS/SATA hard drive bays
Available half height media bays
Removable Optical Drive
8 x 2.5" (SFF) Hot-Plug SAS/SATA hard drive bays or 2 x 3.5" (LFF) Hot-Plug SAS/SATA hard drive bays
Hard Drives
NOTE:
The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
NOTE:
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
600GB 6G SAS 10K DP 450GB 6G SAS 10K DP 300GB 6G SAS 10K DP 146GB 6G SAS 15K DP 146GB 6G SAS 10K DP 72GB 6G SAS 15K DP
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.
Quantity
Supported
Up to 16 SFF
Position
Supported
1-8 and D+E
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 42
QuickSpecs
Storage
HP ProLiant ML350 Generation 6
600GB 6G SAS 15K DP 450GB 6G SAS 15K DP 300GB 6G SAS 15K DP
SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives
2TB 6G SAS 2.7K DP 1TB 6G SAS 2.7K DP 1TB 3G SAS 7.2K DP 750GB 3G SAS 7.2K DP
Quantity
Supported
Up to 8 LFF
Quantity
Supported
Up to 6 LFF
Position
Supported
1-6 and D+E
Position
Supported
1-6 and D+E
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
500GB 6G SAS 7.2K DP
SATA Hot Plug SFF (2.5-inch) Entry (ETY) Drives
250GB 3G SATA 5.4K 120GB 1.5G SATA 5.4K
Quantity
Supported
Up to 16 SFF
Quantity
Supported
Up to 16
Position
Supported
1-8 and D+E
Position
Supported
1-8 and D+E
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 43
QuickSpecs
Storage
NOTE:
HP Systems Insight Manager should not be used to view the status of SATA hard drives and SATA RAID configurations.
SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives
250GB 3G SATA 7.2K 160GB 3G SATA 7.2K
Quantity
Supported
Up to 8
Position
Supported
1-6 and D+E
HP ProLiant ML350 Generation 6
HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
500GB 3G SATA 7.2K 160GB 3G SATA 7.2K
SATA Hot Plug 3.5" Midline (MDL) Drives
2TB 3G SATA 7.2K 1TB 3G SATA 7.2K 750GB 3G SATA 7.2K 500GB 3G SATA 7.2K 250GB 3G SATA 7.2K
Quantity
Supported
Up to 16
Quantity
Supported
Up to 8
Position
Supported
1-8 and D+E
Position
Supported
1-6 and D+E
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 44
QuickSpecs
Storage
SATA Hot Plug Midline (MDL) Solid State Drives
60GB 3.0G SATA SSD 120GB 3.0G SATA SSD
Quantity
Supported
Up to 16
Position
Supported
1-8 and D+E
HP ProLiant ML350 Generation 6
HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Controller
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
60GB 3.0G SATA SSD 120GB 3.0G SATA SSD
External Storage
60 Modular Smart Array
70 Modular Smart Array
Quantity
Supported
Up to 8
Quantity
Supported
Up to 4
Up to 8
Up to 2
Position
Supported
1-6 and D+E
Position
Supported
External
External
External
Controller
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
Host Controller or Adapter
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/256 MB Controller
HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller HP Smart Array P800 Controller
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/256 MB Controller
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 45
QuickSpecs
Storage
HP ProLiant ML350 Generation 6
Up to 4
HP 2000sa Modular Smart Array Controller
D2700 Disk Enclosure
Tape and Disk-Based Backup
NOTE:
For the complete range of StorageWorks tape drives, autoloaders, libraries and media, including the internal fitting models, see:
http://www.hp.com/go/d2d
For hardware and software compatibility of HP StorageWorks disk and tape backup products see:
http://www.hp.com/go/connect
HP StorageWorks SCSI Tape Drives
LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-3 Ultrium 960 LTO4 Ultrium 1760 LTO-4 Ultrium 1840 DAT 40 DAT 72 DAT 160
HP StorageWorks SCSI Rack Mount Kits
1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks USB Tape Drives
DAT 40 DAT 72 DAT 160 DAT 320
HP StorageWorks USB Rack Mount Kits
1U USB Rack-Mount Kit
HP StorageWorks SAS Tape Drives
DAT 160
http://www.hp.com/go/tape
Up to 4
Up to 2 Up to 4
. For the complete range of StorageWorks RDX drives and media see:
.
Position
Supported
Internal or
External
External
Internal or
External
External
Internal or
External
External
External
External
. For the complete range of StorageWorks D2D Backup Systems see:
Controller
HP SC11Xe Host Bus Adapter HP U320e SCSI Dual Channel Controller
NOTE:
Please check the full compatibility information at:
http://www.hp.com/go/connect
HP SC11Xe Ultra320 Single Channel/ PCIe x4 SCSI Host Bus Adapter
USB 2.0 Port
USB 2.0 Port
HP Modular Smart Array SC44Ge 1-ports Int/1-ports Ext PCIe x8 SAS Host Bus Adapter
NOTE:
Please check the full compatibility information at:
HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller HP Smart Array P800 Controller
HP SC08Ge Host Bus Adapter
HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Backed Cache Controller
http://www.hp.com/go/rdx
Controller/HBA
Option Kit Part
Number
412911-B21
AH627A
412911-B21
N/A
416096-B21
.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 46
QuickSpecs
Storage
HP ProLiant ML350 Generation 6
DAT 320 LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-4 Ultrium 1760 LTO-4 Ultrium 1840 LTO-5 Ultrium 3000 LTO-5 Ultrium 3280
HP StorageWorks SAS Rack Mount Kits
1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks SCSI Tape Autoloaders
DAT 72x10 Autoloader 1/8 G2 Autoloader
HP StorageWorks SCSI Tape Libraries
MSL2024 MSL4048 MSL8096 MSL6000
HP StorageWorks SAS Tape Autoloaders and Libraries
1/8 G2 Autoloader MSL2024 MSL4048 MSL8096
HP StorageWorks Fibre Channel Tape Libraries
MSL2024 MSL4048 MSL8096 MSL6000
HP StorageWorks USB RDX Removable Disk Backup System
RDX160 RDX320 RDX500 RDX750 RDX1TB
HP StorageWorks D2D Backup Systems, iSCSI
D2D2500i D2D4000i
External
External
External
External
External
Internal or
External
External
http://www.hp.com/go/connect
HP Modular Smart Array SC44Ge 1-ports Int/1-ports Ext PCIe x8 SAS Host Bus Adapter
NOTE:
http://www.hp.com/go/connect
HP SC11Xe Host Bus Adapter HP U320e SCSI Dual Channel Controller
HP StorageWorks U320e SCSI Dual Channel Host Bus Adapter
NOTE:
http://www.hp.com/go/connect
HP Modular Smart Array SC44Ge 1-ports Int/1-ports Ext PCIe x8 SAS Host Bus Adapter
NOTE:
http://www.hp.com/go/connect
Please consult the EBS connectivity matrix at:
http://www.hp.com/go/ebs
supported Fibre Channel HBAs shown in this QuickSpec.
USB 2.0 port
Embedded Network Controller. If the server requires a hardware iSCSI initiator, the QLogic QLA4050 Host Bus Adapter is recommended.
Please check the full compatibility information at:
Please check the full compatibility information at:
Please check the full compatibility information at:
for connectivity information and the
416096-B21
412911-B21
AH627A
AH627A
416096-B21
N/A
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 47
QuickSpecs
Storage
HP ProLiant ML350 Generation 6
HP StorageWorks D2D Backup Systems, Fibre Channel
D2D4000fc
External
Direct server attach is not supported, requires connection via SAN fabric. See:
http://www.hp.com/go/connect
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 48
QuickSpecs

Power Specifications

HP 460W CS HE Power Supply Kit Part Number Input Voltage Range (Vrms) Frequency Range (Nominal)
(Hz) Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Rating
Nominal Input Current (A rms) Maximum Rated Input Wattage
Rating (Watts) Maximum Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A
peak) Maximum Inrush Current
duration (mS) Maximum British Thermal Unit
Rating (BTU-Hr)
HP 750W CS HE Power Supply Kit Part Number Input Voltage Range (Vrms) Frequency Range (Nominal)
(Hz) Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Rating
Nominal Input Current (A rms) Maximum Rated Input Wattage
Rating (Watts) Maximum Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A
peak) Maximum Inrush Current
duration (mS) Maximum British Thermal Unit
Rating (BTU-Hr)
503296-B21 100 to 240 50/60
512327-B21 100 to 240 50/60
HP ProLiant ML350 Generation 6
100 120 200 208 220 230 240
460 460 460 460 460 460 460
5.5 4.5 2.6 2.5 2.4 2.3 2.2
526 520 505 505 503 503 503
548 542 527 527 524 524 524
87.5 88.5
0.42 0.50 0.83 0.87 0.92 0.96 1.00
1794 1773 1725 1725 1715 1715 1715
100 120 200 208 220 230 240
750 750 750 750 750 750 750
8.9 7.4 4.3 4.1 3.9 3.7 3.6
857 847 824 825 820 820 820
894 884 859 859 854 854 854
87.5 88.5
0.42 0.50 0.83 0.87 0.92 0.96 1.00
2925 2892 2812 2812 2797 2797 2797
91 91
0.97
30
20
91 91
0.97
30
20
91.5 91.5 91.5
91.5 91.5 91.5
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 49
QuickSpecs
Power Specifications
HP 1200W CS HE Power Supply Kit Part Number Input Voltage Range (Vrms) Frequency Range (Nominal)
(Hz) Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Rating
Nominal Input Current (A rms) Maximum Rated Input Wattage
Rating Maximum Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A
peak) Maximum Inrush Current
duration (mS) Maximum British Thermal Unit
Rating (BTU-Hr)
500172-B21 100 to 240 50/60
HP ProLiant ML350 Generation 6
100 120 200 208 220 230 240
800 900 1200 1200 1200 1200 1200
9.7 9.0 7.0 6.8 6.4 6.1 5.9
930 1034 1348 1348 1348 1348 1348
970 1079 1406 1406 1406 1406 1406
86 87 89 89 89 89 89
0.97
0.42 0.50 0.83 0.87 0.92 0.96 1.00 30
20
3174 3530 4600 4600 4600 4600 4600
NOTE:
To review typical system power ratings use the HP Power Advisor which is available online located at url:
www.hp.com/go/proliant-energy-efficient
NOTE:
Option Kits contain optional power supply, an IEC power cable and PDU IEC cables.
or
www.hp.com/go/hppoweradvisor
.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 50
QuickSpecs

Technical Specifications

HP ProLiant ML350 Generation 6
System Unit
Tower Dimensions
(H x W x D) (with feet/bezel)
Rack Dimensions
(H x W x D) (with feet/bezel)
Tower Weight
(approximate)
Rack Weight
(approximate)
Input Requirements
(per power supply)
BTU Rating
Power Specifications
18.5 x 8.59 x 23.46 in (47 x 21.8 x 59.6 cm)
8.54 x 17.5 x 21.9 in. (21.7 x 44.5 x 55.7cm)
Maximum (all hard drives, power supplies, and processors installed)
Minimum (one hard drive, power supply, and processor installed)
Maximum (all hard drives, power supplies, and processors installed)
Minimum (one hard drive, power supply, and processor installed)
Rated Line Voltage
Rated Input Current
Rated Input Frequency
Rated Input Power
Maximum
To review typical system power ratings use the HP Power Advisor which is available via the online tool located at URL:
www.hp.com/go/proliant-energy-efficient
70 lb (31.8 kg)
54 lb (24.5 kg)
66 lb (29.9 kg)
48 lb (21.8 kg)
100 to 240 VAC
7.1 Amps (at 120VAC) to 3.5 Amps (at 240 VAC)
50 to 60 Hz
852 W
460W - 1773 BTU / hr (at 120 VAC), 1715 (at 240 VAC) 750W - 2892 BTU / hr (at 120 VAC), 2797 (at 240 VAC) 1200W - 3530 BTU / hr (at 120 VAC), 4600 (at 240 VAC)
- Click on the system of interest. Example: ML350 G6
- Follow the instructions of the next screens.
Power Supply Output
(per power supply)
System Inlet Temperature
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Rated Steady-State Power
Maximum Peak Power
Operating
460(750) W (at 100 VAC), 460(750) W (at 200 VAC)
460(750) W (at 100 VAC), 460(750) W (at 200 VAC)
NOTE:
See Power Supply Specifications tables for complete details on 460W PSU and optional 750W and 1200W Power Supply Options.
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options
Page 51
QuickSpecs
Technical Specifications
Relative Humidity
(non-condensing)
Altitude
Acoustic Noise
Emissions Classification (EMC)
HP ProLiant ML350 Generation 6
installed. System performance may be reduced if operating with a fan fault or above 30°C (86°F).
Non-operating
Operating
Non-operating
Operating
Non-operating
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA
74) and declared in accordance with ISO 9296 (ECMA 109).
Idle
L
WAd
L
pAm
Operating
L
WAd
L
pAm
NOTE:
The Listed sound levels apply to standard shipping
configurations. Additional options may result in increased sound levels.
FCC Rating
Normative Standards
NOTE:
Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non­condensing.
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing.
3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
4.7 B (1P Non-Redundant)
4.6 B (2P Redundant)
32.48dB (1P Non-Redundant)
31.18dB (2P Redundant)
4.8 B (1P Non-Redundant)
4.7 B (2P Redundant)
32.39dB (1P Non-Redundant)
31.62dB (2P Redundant)
Class B
CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 52
QuickSpecs
Technical Specifications
HP ProLiant ML350 Generation 6
Smart Array P410i Controller
Dimensions
Disk Drive and Enclosure Interface ­Transfer rate
SAS Connectors
Cache Memory Speed
Server Interface
SAS Speed
Cache Memory
Logical Drives Supported
Host Memory Addressing
RAID Support
Embedded
6Gb/s SAS (Serial Attached SCSI) 3Gb/s SATA (Serial ATA)
2 internal 4X connectors
DDR2-800MHz with 40 or 72-bit wide bus
x4 PCIe 2.0 provides 2GB/s maximum bandwidth
8 6Gb/s SAS links provide 4.8GB/s maximum bandwidth
Zero Memory RAID has no cache memory 40-bit 256MB ECC protected cache (battery upgrade available) 72-bit 512MB BBWC or 72-bit 512MB and 1G FBWC
Zero Memory, Up to 2 logical volumes (8 physical drives) Up to 64 logical drives with cache
64-bit, supporting greater than 4GB server memory space
RAID 6, 6+0 (Advanced Data Guarding)
NOTE:
RAID 6, 6+0 can be enabled with one of the following
combinations:
256 MB cache, Battery kit and Smart Array Advanced Pack License key option upgrades 512 MB BBWC/FBWC and Smart Array Advanced Pack License key option upgrades 1G FBWC and Smart Array Advanced Pack License key option upgrades
RAID 5, 5+0 (Distributed Data Guarding)
NOTE:
A minimum or 256 MB cache is required to enable RAID 5, 5+0
support
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping), RAID 1 (Mirroring)
Embedded NC326i PCI Express Dual Port Gigabit Server Adapter
Network Interface
Compatibility
Data Transfer Method
Controller
Network Transfer Rate
Connector
Cable Support
10Base-T/100Base-TX/1000Base-TX
IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
PCI Express, four lanes (x4)
BCM5715
10Base-T (Half-Duplex)
10Base-T (Full-Duplex)
100Base-TX (Half­Duplex)
100Base-TX (Full­Duplex)
1000Base-TX (Half and Full-Duplex)
RJ-45
10Base-T
10/100/1000Base-TX
10 Mb/s
20 Mb/s
100 Mb/s
200 Mb/s
2000Mb/s
Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
Category 5 UTP; up to 328 ft (100 m)
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 53
QuickSpecs
Technical Specifications
HP ProLiant ML350 Generation 6
Environment-friendly Products and Approach
© Copyright 2011 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
http://www.hp.com/go/green http://www.hp.com/go/green
http://www.hp.com/go/green
. To recycle your product, or contact your nearest HP
. These
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
DA - 13241 Worldwide QuickSpecs — Version 38 — 3/16/2011
Page 54
Loading...
