QuickSpecs

Overview

HP ProLiant ML330 Generation 6

Front View:

Power supply

Expansion slots

1st Processor socket

Nine DIMM slots (for 1st processor)

Rear System Fan

Hard drive bays 5-8

Hard drive bays 1-4

LED indicators and power button

USB connectors (2)

10.

Removable Media Bays

11.

Optical drive bays

12.

Front System Fans

Rear View:

Power supply 1

Power supply (blank) (for Redundant Optional)

Expansion slots

UID button/LED

Video ports

Four USB ports

Keyboard port

Mouse port

Network port 1(shared iLO management port)

10.

Network port 2

11.

Serial port

12.

Dedicated iLO management port (optional)

What's New

Supports the new Intel Xeon processors X5600/E5600 family with up to 2.66GHz at 6 cores turbo mode and latest E5500 series.

At A Glance

Performance and manageability to scale your business. The HP ProLiant ML330 G6 is a new dual processor tower platform which built on the latest Intel Xeon processors with QPI technology to create a unique system architecture. This unique architecture enables you to scale your business as needed and allows you to improve the efficiency of how you spend your IT dollars. ML330 G6 not only delivers excellent performance with the latest technology but it also incorporates the industry's most powerful embedded management technology with the HP Integrated Lights-Out 2 (iLO 2) for ProLiant controller, allowing you to manage servers anytime and anywhere.

Processors

: Two Six Core/Quad core Intel® Xeon® X5600/E5600 processors Two Quad-Core/Dual-Core Intel® Xeon® E5500 processors

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 1

QuickSpecs

Overview

One Quad-Core/Dual Core Intel® Xeon® W3500 processors Intel® 5500 chipset

Memory

Storage Controllers

Internal Drive Support

Network Controller

Expansion Slots

Ports

Power Supply

Redundancy

Infrastructure Management

Deployment/Serviceability

Operating Systems and Virtualization Software Support for ProLiant Servers

: 18 DIMM slots Up to 192GB, using PC3-8500R DDR3 Registered (RDIMM) memory, operating at 800MHz when fully populated at 3 DIMMs per Channel in 18 slots. Up to 48GB, using PC3-10600E DDR3 Unbuffered (UDIMM) memory, operating at 1066MHz when fully populated at 2 DIMMs per Channel in 12 slots.

NOTE:

If only one processor is installed, only half the DIMM slots are available

: Entry Models: Non hot plug model with embedded HP Smart Array B110i SATA RAID Controller (RAID 0/1/1+0) o Base Models: Hot plug SAS/SATA model (SAS model integrated HP Smart Array P410/Zero memory SAS Controller (RAID 0/1/1+0) Performance Models: Hot plug SATA model integrated HP Smart Array B110i SATA RAID controller hot plug advanced key Available upgrades: 256MB, 512MB/1G with write back, Battery kit upgrade (for FB/BBWC), and Smart Array Advanced Pack (SAAP)

: Up to eight (8) LFF (3.5") Hot Plug or four (4) Non Hot Plug Serial Attached SCSI (SAS) or Serial-ATA (SATA) hard drives Maximum of 16TB of internal storage capacity

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

: Four total expansion slots One (1) PCI-Express x8 Gen1 (x1 speed); One (1) PCI-Express x16 Gen2 (x16 speed); Two (2) PCI-Express x8 Gen2 (x4 speed) Optional PCI-X Expander provides additional two (2) 64-bit/100-MHz PCI-X slots by using a single PCI Express slot (only on slot 5)

USB 2.0 support Eight total ports: (2) front; (4) rear; (2) internal (1 for Tape) 1 internal Secure Digital (SD) slot

: One 460 W Non-Hot Plug, Non-redundant Power Supply Optional 750W Hot Plug redundant power supply

NOTE:

The 750W power supply requires RPS Enablement kit.

: Optional Hot plug redundant power supply Optional for optional redundant fan

: HP Integrated Lights-Out 2 (iLO 2) management processor for simplified server setup, health monitoring and recovery, power and thermal control, and lights-out remote administration. HP Insight Control a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, control and optimize your IT infrastructure through a single, simple management console. Insight Control supports both Windows and Linux-based central management servers. HP Insight Dynamics for ProLiant, a product option, is an integrated command center that enables IT Staff personnel to continuously analyze and optimize a converged infrastructure, while automating and reducing the cost of common data center tasks by as much as 40 percent. This ultimately enables them to dynamically keep pace with the organization's changing business requirements.

: Easy chassis entry and component access Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for greater flexibility in performing defective parts replacement HP Smart Start Tool

Supports Windows, RHEL, SLES, OEL, VMware, and HP Citrix Essentials for XenServer

HP ProLiant ML330 Generation 6

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 2

QuickSpecs

Overview

HP ProLiant ML330 Generation 6

Security - Trusted Platform Module

One (1) internal TPM 1.2 module connector

Warranty

: This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 3

QuickSpecs

Standard Features

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -

Factory Integrated Models" section.

Processor

One of the following depending on Model

Six-Core Processors

Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W,DDR3-1333, HT, Turbo 1/1/2/2/3/3)

Quad-Core Processors

Intel® Xeon® Processor E5640 (2.66 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo NA/1/1/2/2)

Intel® Xeon® Processor E5630 (2.53 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo NA/1/1/2/2)

Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo NA/1/1/2/2)

Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)

Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)

Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)

Intel® Xeon® Processor E5507 (2.26 GHz, 4MB L3 Cache, 80W, DDR3-800)

Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800)

Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)

Intel® Xeon® Processor W3540 (2.93 GHz, 8MB L3 Cache, 130W, DDR3-1066, HT, Turbo 1/1/1/2)

Intel® Xeon® Processor W3520 (2.66 GHz, 8MB L3 Cache, 130W, DDR3-1066, HT, Turbo 1/1/1/2)

Dual-Core Processors

Intel® Xeon® Processor E5503 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)

Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)

Intel® Xeon® Processor W3505 (2.53 GHz, 4MB L3 Cache, 130W, DDR3-1066)

Intel® Xeon® Processor W3503 (2.40 GHz, 4MB L3 Cache, 130W, DDR3-1066)

NOTE:

HT indicates that the processor model supports Intel® Hyper-Threading Technology.

NOTE:

Turbo indicates the maximum potential frequency increment when using Intel® Turbo

Boost Technology, with 4, 3, 2, and 1 cores active.

NOTE:

DDR3 speed is the maximum memory speed of the processor. Actual memory speed may

depend on the quantity and type of DIMMs installed.

NOTE:

For the Intel 5500 Series, the letter preceding the model number indicates the performance/wattage of the processor. "X" denotes High Performance/Wattage; "E" denotes Enterprise Performance/Wattage (Mainstream); and "L" denotes Lower Wattage.

HP ProLiant ML330 Generation 6

Cache Memory

One of the following depending on Model

Chipset

12MB (1x 12MB) level 3 cache

NOTE:

For processors X5600 and E5600.

8MB (1 x 8MB) Level 3 cache

NOTE:

For processors E5540/E5530/E5520/W3540/W3520.

4MB (1 x 4MB) Level 3 cache

NOTE:

For processors E5506/E5504/E5502/W3505/W3503.

Intel® 5500 Chipset

NOTE:

For more information regarding Intel® chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 4

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

Upgradeability

Memory Protection

Memory

One of the following depending on model

Upgradeable to 2 processors (4 or 8 or 12 cores)

Mirroring

Lock-step mode

Advanced ECC

Online Spare (Requires X5600 or E5600 processor family)

NOTE:

Xeon W3500 processor family does not support any of above advanced features.

Type

Standard (Performance)

Standard (Base Models)

Standard (Entry Models)

Maximum (RDIMM)

Maximum (UDIMM)

NOTE:

Depending on the memory configuration and processor model, the memory speed may run at 1333MHz, 1066MHz, or 800MHz. Please see the Online Memory Configuration Tool at:

www.hp.com/go/ddr3memory-configurator

DDR3 Registered (RDIMM) and Unbuffered (UDIMM)

6GB (3 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs

4GB (2 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs

2GB (1 x 2GB) PC3-10600E (DDR3-1333) Registered DIMMs

192GB (18 x 8GB) for Registered Memory configurations

48GB (12x 2GB) for Unbuffered Memory configurations

Network Controller

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 5

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

Expansion Slots

Storage Controller

Expansion

Slot #

* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.

Entry Models

Base Models

Performance Models

Available upgrades: 256MB, 512MB/1GB with FB/BBWC, Battery kit upgrade (for FB/BBWC), and Smart Array Advanced Pack (SAAP)

Technology

PCI Express

Gen2

PCI Express

Gen2

PCI Express

Gen2

PCI Express

Gen1

Bus Width**Connector

Width

x4 x8

x16 x16

x1 x8

Non hot plug model with HP Smart Array B110i SATA RAID Controller (RAID 0/1/1+0)

Hot plug SAS model integrated HP Smart Array P410/Zero memory SAS Controller (RAID 0/1/1+0) Hot plug SATA model integrated HP Smart Array B110i SATA RAID controller hot plug advanced key

Hot plug SATA model integrated HP Smart Array B110i SATA RAID controller hot plug advanced key

Bus

Number

Form Factor

Standard

Height/ Half

Length

Standard

Height/ Half

Length

Standard

Height/Length

Standard

Height/Length

Notes

Storage

Maximum Internal Storage

Interfaces

Optical Drive

Hard Drives

Hot Plug LFF SATA

Hot Plug LFF SAS

Serial

Pointing Device (Mouse)

Graphics

Keyboard

Network RJ-45

SD Slot

USB 2.0 Ports

HP Half-Height SATA DVD-ROM Optical Drive

Hot Plug Model: None ship standard

HP 250GB 3G SATA 7.2K NHP 3.5" MDL HDD

16TB

3 (1 dedicated for HP Integrated Lights-Out 2 (iLO 2)

1 (internal)

8 (2 front, 4 rear, 2 internal)

NOTE:

Please see the following URL for additional information regarding USB support:

http://h18004.www1.hp.com/products/servers/platforms/usbsupport.html

8 x 2TB

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 6

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

Graphics

Form Factor

HP Insight management software

Integrated ATI RN50, 64MB video standard

16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024

NOTE:

Maximum resolution available via HP Integrated Lights-Out 2 (iLO 2) remote console is

1280 x 1024.

Tower (5U)

NOTE:

Rack mounting available via HP Tower to Rack Conversion Tray, Universal Kit. Please see

the options section in this QuickSpecs:

Square or round hole racks 24"- 36" deep, including HP Rack System /E and HP Systems Telco racks with 3rd part option kit from Rack Solutions

HP Insight Foundation

Managing the growing number of servers can be complex and expensive for your organization. IT managers need to address changing business needs with tools that meet the challenges of managing today's complex Datacenters.

HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server lifecycle. This provides the customer with higher levels of operational efficiency and highly reliable systems:

www.hp.com/go/foundation

www.hp.com/go/rackandpower

HP Integrated Lights-Out (iLO)

HP Insight Control

The foundation pack includes:

HP SmartStart HP Management HP ProLiant Firmware Maintenance

SmartStart version supported (minimum): SmartStart 8.25

http://www.hp.com/servers/smartstart

NOTE:

In an effort to support reducing our environmental impact, the HP ProLiant Essentials Foundation Pack media will be available as a selectable option for this server at time of order of a Factory Integrated Model. This will allow customers to order the number of media kits that best meet their needs and eliminate receiving unnecessary duplicate media.

HP Integrated Lights-Out (iLO) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration of ProLiant ML, DL, and BL servers. HP iLO functions without additional software and can be accessed from any location via a web browser. HP iLO works hand-in-hand with HP Systems Insight Manager, Insight Control suites, and Insight Dynamics for ProLiant, helping customers unleash the value of the ProLiant platform and deliver the highest possible quality of IT service. For more information, visit:

www.hp.com/go/iLO

HP Insight Control, a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.

Two versions of Insight Control are available, to serve environments

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 7

QuickSpecs

Standard Features

HP Insight Dynamics for ProLiant

HP ProLiant ML330 Generation 6

requiring either a Linux-based or a Windows-based central management server: HP Insight Control for Linux, and HP Insight Control. See

www.hp.com/go/insightcontrol

HP Insight Control includes one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:

HP Insight Dynamics for ProLiant, a product option, is advanced infrastructure management software that enables IT staff to instantly adjust their environments to meet dynamic business demands by provisioning, optimizing and protecting complex infrastructure in minutes. It's a powerful toolkit, integrated-by-design, that accelerates complex technology projects and simplifies daily operations, transforming data center economics. With Insight Dynamics IT professionals can plan capacity and power continuously, balance workloads across physical and virtual resources, and ensure costeffective high availability. It also enables IT organizations to provision infrastructure consistently and automatically from pools of shared resources using a self-service portal. Resources provisioned can range from a single virtual machine to complex multi-tier environments and their associated physical and virtual resource requirements. In addition to the previous functional benefits, it also provides a cost-effective disaster recovery for physical and virtual environments that works with HP StorageWorks Continuous Access software for both the Enterprise Virtual Array and the XP storage array allowing application environments to be reactivated in minutes with the touch of a button to a remote location.

http://www.hp.com/services/insight

Industry Standard Compliance

System Management

NOTE:

For more information, visit:

http://www.hp.com/go/insightdynamics

ACPI V2.0 Compliant PCI-Express Gen2 PXE Support WOL Support PCI-X 1.0a Compliant Microsoft® Logo certifications USB 2.0

HP Systems Insight Manager SmartStart Redundant ROM System Firmware Update ROMPaq ProLiant RBSU (ROM-Based Setup Utility) Automatic Server Recovery-2 (ASR-2) Dynamic Sector Repairing (with Smart Array Controller) Drive Parameter Tracking (with Smart Array Controller) Pre-Failure Warranty (covers processors, memory, and SAS hard drives) Dynamic power capping (with 750W PSU)

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 8

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

Security

Security - Trusted Platform Module

Power-on password Setup password Serial interface control Power switch security Front bezel/side access panel Lock Padlock and Kensington lock available Keyboard/Mouse/USB port lock

Trusted Platform Module option kit

The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker leverages the enhanced security capabilities of a Trusted Platform Module (TPM) version 1.2. The TPM works with BitLocker to help protect user data and to ensure that a server running Windows Server 2008 has not been tampered with while the system was offline. For more information about TPM, including a white paper, go to:

www.hp.com/go/TPM

NOTE:

ProLiant OS pre-installed units will come with the partition required for TPM deployment.

NOTE:

The TPM key is unique to every TPM deployed server and must be retained. Misplacing or

loosing the key could result in data loss.

UPS and PDU Power Cord Matrix

Power Supply

Please see the UPS and PDU cable matrix's on the HP Power Protection and Management page. Under Power Cords, click on the "HP Power Cord Matrix" link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link:

www.hp.com/products/powercords

460W Non-Redundant Power Supply, Non-hot plug 750W Hot plug, Redundant Power supply

NOTE:

The 750W power supply requires RPS Enablement kit.

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your need. The HP Power Advisor is located at "

efficient

HP has a new design for ProLiant power. The new Common Slot Power Supply bay. This design provides the customer with commonality in power supplies across multiple platforms to save on the cost of spares and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers come with Common Slot, High Efficiency and Right-Size Power Supplies. Common Slot (CS) designates commonality of the power supply across multiple ProLiant servers. HP's new Common Slot power supplies are designed for highest efficiency to provide power efficiency without degrading performance of the ProLiant. Power Supplies will have efficiency ratings up to 92%. There are three Right Size power options available, depending on the configuration of your server. To make sure you select the correct power supply to meet your configuration, we suggest that you use the HP Power Calculator to decide the "Right-Size" for your configuration. All HP Common Slot power sources are UL, CE Mark Compliant, Hot Plug and Redundant.

www.hp.com/go/hppoweradvisor

www.hp.com/go/proliant-energy-

HP's ProLiant Common Slot Power supplies (750W) meet multiple Energy Efficiency Initiatives. Climate Savers Computing Initiative GOLD, ECOS Consulting 80PLUS GOLD and they meet the standard specifications for Energy Star for Servers Power Supply requirements.

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 9

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

System Fans

Operating Systems and Virtualization Software Support for ProLiant Servers

Factory Express Portfolio for Servers and Storage

3 fans ship standard, 4 fans total supported (optional (1) redundant fan)

NOTE:

Does not include power supply or processor heat sink fans. Processor heat sink fans

packed in processor kit.

NOTE:

There are two fans packed in the Redundant Fan Kit, only 1 is required for system

redundant function. The other one can be saved as a spare part.

Microsoft Windows Server Microsoft Windows Server Hyper V Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Enterprise Linux (OEL) VMware Citrix Essentials for XenServer

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at:

www.hp.com/support/ML330G6

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

http://www.hp.com/go/ossupport

and our driver download page

HP Enterprise Configurator

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to:

The HP eConfigure-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.

http://www.hp.com/products/configurator

http://www.hp.com/go/factory-express

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 10

QuickSpecs

Standard Features

HP ProLiant ML330 Generation 6

Service and Support

HP Care Pack services provide total care and support expertise with committed response designed to meet your IT and business needs.

HP Care Pack services include coverage for the HP branded hardware options qualified for the server and purchased at the same time or afterward that are internal to the enclosure. This also includes the 22" and smaller external monitors and tower UPS options up to 12kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions, provides a range of support services designed to meet the varying needs of your business. Whether an SMB, or large global corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Recommended Service

management.

Support Deployment Service

Enhanced Service

- 3-Year 4-Hour response 24x7 Same Business Day Coverage only

- simplify ProLiant solution implementation, maintenance, and

- Installation and Start up only

- optimize service level to increase IT performance and availability.

Support

Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.

NOTE:

For a complete listing of service offerings and information visit:

http://www.hp.com/services/proliantservices http://www.hp.com/services/carepack

- 3-Year Support Plus 24 only

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 11

QuickSpecs

Models

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -

Factory Integrated Models" section.

HP ML330 G6 Entry Model

Quad-Core Models HP ML330T06 E5504 LFF Non Hot Plug

504055-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

PCI-Express Slots

Power Supply

Fans

Form Factor

HP ProLiant ML330 Generation 6

(1) Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800

4MB (1 x 4MB) Level 3 cache

2 GB (1 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

Embedded HP Smart Array B110i SATA RAID Controller (RAID 0/1/0+1)

HP 250GB 3G SATA 7.2K NHP 3.5" MDL HDD

8TB LFF SAS 8TB LFF SATA

HP Half-Height SATA DVD-ROM Optical Drive

Four expansion slots (four PCI-Express)

460 Watt power supply (NHP, Non Redundant)

3 fans ship standard

Tower (5U)

HP ML330 G6 Base Models

Quad-Core Models HP ML330T06 E5506 LFF Hot Plug

504056-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

PCI-Express Slots

Power Supply

Fans

Form Factor

(1) Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800)

4MB (1 x 4MB) Level 3 cache

4 GB (2 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

HP Smart Array P410/Zero memory Controller (RAID 0/1/0+1)

None ship standard

4TB LFF SAS 8TB LFF SATA

HP Half-Height SATA DVD-ROM Optical Drive

Four expansion slots (four PCI-Express)

460 Watt power supply (NHP, Non Redundant)

3 fans ship standard

Tower (5U)

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 12

QuickSpecs

Models

HP ProLiant ML330 Generation 6

HP ML330 G6 Base Models

Quad-Core Models HP ML330T06 E5507 LFF Hot Plug

600910-xx1

HP ML330 G6 Performance Models

Quad-Core Models HP ML330T06 E5620 LFF Hot Plug

600910-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

PCI-Express Slots

Power Supply

Fans

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

PCI-Express Slots

Power Supply

Fans

Form Factor

(1) Intel® Xeon® Processor E5507 (2.26 GHz, 4MB L3 Cache, 80W, DDR3-800)

4MB (1 x 4MB) Level 3 cache

4 GB (2 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

Embedded HP Smart Array B110i SATA RAID Controller Hot plug advanced key (RAID 0/1/0+1)

None ship standard

8TB LFF SAS 8TB LFF SATA

HP Half-Height SATA DVD-ROM Optical Drive

Four expansion slots (four PCI-Express)

460 Watt power supply (NHP, Non Redundant)

3 fans ship standard

Tower (5U)

(1) Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066)

12MB (1 x 12MB) Level 3 cache

6 GB (3 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

Embedded HP Smart Array B110i SATA RAID Controller Hot plug advanced key (RAID 0/1/0+1)

None ship standard

8TB LFF SAS 8TB LFF SATA

HP Half-Height SATA DVD-ROM Optical Drive

Four expansion slots (four PCI-Express)

460 Watt power supply (NHP, Non Redundant)

3 fans ship standard

Tower (5U)

Country Code Key

xx=00

xx=01

xx=03

xx=04

xx=05

xx=20

xx=29

xx=37

xx=42

xx=AA

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Tower Code Key

U.S. English U.S. English

Australia

Germany

France

Brazil

Japan Japan

APD APD

Europe Europe

PRC PRC

Rack Code Key

N/A

Page 13

QuickSpecs

HP ProLiant ML330 Generation 6

Configuration Information - Factory Integrated Models

NOTE:

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.

NOTE:

HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start with a CTO Chassis.

NOTE:

FIO indicates that this option only available as a Factory Installable Option.

Step 1: Base Configuration (choose one of the following configurable models)

HP Models

HP ML330G6 CTO Chassis

Includes:

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter Integrated Smart Array B110i SATA RAID Controller One PCI-Express x8 Gen1 (x1 speed); One PCI-Express x16 Gen2 (x16 speed); Two PCI-Express x8 Gen2 (x4 speed) Eight USB ports Tower Form Factor Keyboard 2-button Mouse

504271-B21

Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)

HP Processors

Six-Core Processors

Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3/4/4) FIO

Quad-Core Processors

Intel® Xeon® Processor E5640 (2.66 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) FIO

Intel® Xeon® Processor E5630 (2.53 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) FIO

Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) FIO

Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 FIO Kit

Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 FIO Kit

Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 FIO Kit

Intel® Xeon® Processor E5507 (2.26 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 FIO Kit

Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 FIO Kit

Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800 ML330G6 FIO Kit

Intel® Xeon® Processor W3540 (2.93 GHz, 8MB L3 Cache, 130W, DDR3-1066, HT, Turbo 1/1/1/2) ML330G6 FIO Kit

Intel® Xeon® Processor W3520 (2.66 GHz, 8MB L3 Cache, 130W, DDR3-1066, HT, Turbo 1/1/1/2) ML330G6 FIO Kit

Dual-Core Processors

Intel® Xeon® Processor E5503 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 FIO Kit

601054-L21

607120-L21

601053-L21

601052-L21

535585-L21

535584-L21

535583-L21

601051-L21

535582-L21

535581-L21

512718-L21

512717-L21

601050-L21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 14

QuickSpecs

Configuration Information - Factory Integrated Models

HP ProLiant ML330 Generation 6

HP Memory

HP Drive Cage Options

HP Hard Drives

Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 FIO Kit

Intel® Xeon® Processor W3505 (2.53 GHz, 4MB L3 Cache, 130W, DDR3-1066) ML330G6 FIO Kit

Intel® Xeon® Processor W3503 (2.40 GHz, 4MB L3 Cache, 130W, DDR3-1066) ML330G6 FIO Kit

NOTE:

Xeon E5500 DP family supports both Registered DIMMs and Unbuffered

DIMMs. Xeon W3500 UP family supports only Unbuffered DIMMs.

Registered DIMMs (RDIMMs)

HP 2GB 2Rx8 PC3-10600R-9 Kit

HP 4GB 2Rx4 PC3-10600R-9 Kit

HP 4GB 4Rx8 PC3-8500R-7 LP Kit

HP 4GB 1Rx4 PC3-10600R-9 Kit

HP 4GB 1Rx4 PC3L-10600R-9 Kit

NOTE:

Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600

series processors.

HP 8GB 2Rx4 PC3-8500R-7 Kit

HP 8GB 2Rx4 PC3-10600R-9 Kit

HP 8GB 2Rx4 PC3L-10600R-9 Kit

NOTE:

Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600

series processors.

HP 16GB 4Rx4 PC3-8500R-7 Kit

Unbuffered with ECC DIMMs (UDIMMs)

HP 1GB 1Rx8 PC3-10600E-9 Kit

HP 2GB 2Rx8 PC3-10600E-9 Kit

HP 4GB 2Rx8 PC3-10600E-9 Kit

NOTE:

For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:

configurator

NOTE:

Non-Hot Plug HDD Model

HP SATA 5U G6 Module FIO Kit

Hot Plug HDD Model

HP Hot Plug HDD Drive Cage Kit

NOTE:

SATA or SAS RAID Controller.

NOTE: NOTE:

controller hot plug advanced key (515471-B21)

NOTE:

Plug HDD Drive Cage kit and Smart Array controller 8 ports or 2x 4 ports.

NOTE:

HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.

NOTE:

specific hard drive QuickSpecs for details.

SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

HP 600GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

PC3L is a low voltage memory.

Hot Plug SATA/SAS model and Non-hot plug SAS model requires a HP

Non-Hot Plug Model only supports up to total 4 drives.

Hot plug SATA model requires HP Smart Array B110i SATA RAID

To reach maximum 8 LFF Drive support, it is required to purchase 2 Hot

The components of a storage subsystem (e.g. the drive, the

Hard drives have either a one year or three year warranty; refer to the

www.hp.com/go/ddr3memory-

535580-L21

573362-L21

573363-L21

500656-B21

500658-B21

500660-B21

593339-B21

604504-B21

516423-B21

500662-B21

604506-B21

500666-B21

500668-B21

500670-B21

500672-B21

500448-B21

487737-B21

516830-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 15

QuickSpecs

Configuration Information - Factory Integrated Models

HP ProLiant ML330 Generation 6

HP Power supplies

HP 450GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 450GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 300GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 300GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 146GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 600GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

NOTE:

SAS non-hot plug drives require the Non-Hot Plug Internal SAS/SATA 4 port Cable kit (P/N 487734-B21) and a HP SAS/Smart Array Controller.

SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives

HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Entry 1y Wty Hard Drive

SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HP 750GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your need. The HP Power Advisor is located at:

www.hp.com/go/proliant-energy-efficient

HP 460W Power Supply, FIO Kit

HP 750W CS HE Power Supply

NOTE:

The HP 750W power supply requires purchasing the Redundant Power Supply Enablement Kit (P/N 508544-B21).

HP Redundant Power Supply Enablement Kit

NOTE:

The Redundant Power Supply Enablement kit does not integrate any power supply. To enable full Redundancy, it requires 2 units of 750W Power supply.

www.hp.com/go/hppoweradvisor

516826-B21

454234-B21

516824-B21

417950-B21

417855-B21

516830-B21

458947-B21

462595-B21

458941-B21

458939-B21

500447-B21

512327-B21

508544-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 16

QuickSpecs

HP ProLiant ML330 Generation 6

Configuration Information - Factory Integrated Models

Step 3: Choose Additional Factory Integratable Options

HP Storage Controllers

HP Insight Software

HP P212 /256 FIO SA Cntrlr w/Battery

HP P410/ZM FIO Smart Array Controller

HP P410/256 FIO SA Cntrlr w/Battery

HP P411/256MB BBWC Smart Array Controller FIO Kit

NOTE:

SAS Controller supporting RAID 0/1/1+0/5.

Optional Upgrades

256 MB Cache Upgrade

NOTE:

Supported HP Smart Array P212 and P410/ZM Controllers only.

512MB BBWC

NOTE:

Supported on HP Smart Array P410 Controller and HP Smart Array P411 Controller only.

Battery Kit upgrade

NOTE:

To enable BBWC on the 256MB cache.

NOTE:

Supported on HP Smart Array P212 Controller, HP Smart Array P410 Controller, and HP Smart Array P411 Controller only.

NOTE:

To support RAID 5, HP P410 requires at least 256MB Cache

NOTE:

To support RAID 6, HP P410 requires at least 256MB Cache + Battery + SAAP or 512MB BBWC + Smart Array Advanced Pack (SAAP) license key. Smart Array P411 Controller.

HP Smart Array Advanced Pack No Media 1-Server license including 1yr 24x7

NOTE:

This part number can be used to purchase a single license or to order multiple licenses with a single activation key. Customers will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Include one year of 24x7 HP Software Technical Support Services.

HP Smart Array Hot Plug Advance Pack for B110i w/1yr 24x7 Supp Physical 1 Svr LTU

HP Insight Control suite, No Media 1-Server License Factory-Integratable Option (FIO) including 1 year of 24x7 Technical Support and Updates

HP Insight Control for Linux, No Media 1-Server License Factory-Integratable Option (FIO) including 1 year of 24x7 Technical Support and Updates

491191-B21

462860-B21

491195-B21

491193-B21

462968-B21

462967-B21

462969-B21

516471-B21

TC421A

582765-B21

TC203A

Step 4: Choose Additional Options for Factory Integration

NOTE:

For additional options, please refer to the "Core Options" or "Additional Options" section below.

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 17

QuickSpecs

Core Options

NOTE:

Some options may not be factory configurable. Please contact your local sales representative for additional

information.

HP Processors

Six-Core Processors

Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3/4/4) ML330G6 Processor Kit

Quad-Core Processors

Intel® Xeon® Processor E5640 (2.66 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5630 (2.53 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) ML330G6 Processor Kit

Intel® Xeon® Processor E5507 (2.26 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 Processor Kit

Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 Processor Kit

Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800 ML330G6 Processor Kit

Dual-Core Processors

Intel® Xeon® Processor E5503 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 Processor Kit

Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800) ML330G6 Processor Kit

NOTE:

Each Processor Kit includes (1) processor/(1) heatsink/ (1) Processor board. The Processor board integrated (1) processor socket and (9) DIMM slots.

NOTE:

When two (2) Xeon E5500 processors are installed, the system QPI will be locked at 4.8 GT/s.

NOTE:

Xeon E5500 DP family supports both Registered DIMMs and Unbuffered DIMMs. Xeon W3500 UP family supports only Unbuffered DIMMs.

HP ProLiant ML330 Generation 6

603978-B21

607122-B21

603977-B21

603976-B21

512716-B21

512715-B21

512714-B21

603975-B21

512713-B21

512712-B21

603974-B21

512711-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 18

QuickSpecs

Core Options

HP ProLiant ML330 Generation 6

HP Memory

Registered DIMMs (RDIMMs)

HP 2GB 2Rx8 PC3-10600R-9 Kit

HP 4GB 2Rx4 PC3-10600R-9 Kit

HP 4GB 4Rx8 PC3-8500R-7 LP Kit

HP 4GB 1Rx4 PC3-10600R-9 Kit

HP 4GB 1Rx4 PC3L-10600R-9 Kit

NOTE:

series processors.

HP 8GB 2Rx4 PC3-8500R-7 Kit

HP 8GB 2Rx4 PC3-10600R-9 Kit

HP 8GB 2Rx4 PC3L-10600R-9 Kit

NOTE:

series processors.

HP 16GB 4Rx4 PC3-8500R-7 Kit

Unbuffered with ECC DIMMs (UDIMMs)

HP 1GB 1Rx8 PC3-10600E-9 Kit

HP 2GB 2Rx8 PC3-10600E-9 Kit

NOTE:

Online DDR3 Memory Configuration Tool:

configurator

NOTE:

Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600

For detailed memory configuration rules and guidelines, please use the

www.hp.com/go/ddr3memory-

PC3L is a low voltage memory.

500656-B21

500658-B21

500660-B21

593339-B21

604504-B21

516423-B21

500662-B21

604506-B21

500666-B21

500668-B21

500670-B21

HP Optical Drives

HP Drive Cage Options

HP Hard Drives

HP Half-Height SATA DVD-ROM Optical Drive

HP Half-Height SATA DVD RW Optical Drive

HP 5U Hot Plug HDD Drive Cage Kit

NOTE:

To reach maximum 8 LFF Drive support, it is required to purchase 2 Hot Plug HDD Drive Cage kit and Smart Array controller 8 ports or 2x 4 ports.

NOTE:

The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.

NOTE:

Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

SATA Hot Plug models require HP SAS Smart Array Controller.

NOTE:

SAS Non-Hot Plug and SAS Hot Plug Models require HP SAS Smart Array Controller.

SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

HP 600GB 6G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

HP 450GB 6G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

HP 450GB 3G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

HP 300GB 6G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

HP 300GB 3G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

447326-B21

447328-B21

487737-B21

516828-B21

516816-B21

454232-B21

516814-B21

416127-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 19

QuickSpecs

Core Options

HP ProLiant ML330 Generation 6

HP 146GB 3G SAS 15K LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive

SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

HP 600GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 450GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 450GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 300GB 6G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 300GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

HP 146GB 3G SAS 15K LFF (3.5-inch) Non-hot Plug Dual Port ENT 3y Wty Hard Drive

SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HP 2TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive

HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive

HP 1TB 3G SAS 7.2K rpm LFF(3.5-inch) Dual Port Midline 1yr Warranty Hard Drive

HP 750GB 3G SAS 7.2K rpm LFF(3.5-inch) Dual Port Midline 1yr Warranty Hard Drive

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html

(Worldwide)

SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HP 2TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive

HP 1TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive

HP 750GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive

HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive

HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive

SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HP 2TB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 1TB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 750GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1y Wty Hard Drive

SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives

HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive

HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive

SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives

HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Entry 1y Wty Hard Drive

384854-B21

516830-B21

516826-B21

454234-B21

516824-B21

417950-B21

417855-B21

507616-B21

507614-B21

461137-B21

461135-B21

507632-B21

454146-B21

458930-B21

458928-B21

458926-B21

507774-B21

507772-B21

462595-B21

458941-B21

458939-B21

571230-B21

458945-B21

571232-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 20

QuickSpecs

Core Options

HP ProLiant ML330 Generation 6

HP Networking

HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Entry 1y Wty Hard Drive

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13021_div/13021_div.html

(Worldwide)

SATA Hot Plug 3.5" Midline (MDL) Solid State Drives

HP 60GB 3G SATA 3.5in MDL 1y Wty SSD

HP 120GB 3G SATA 3.5in MDL 1y Wty SSD

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13415_div/13415_div.html

(Worldwide)

Gigabit Ethernet Adapters

HP NC112T PCIe Gigabit Server Adapter

HP NC360T PCI Express Dual Port Gigabit Server Adapter

HP NC364T PCI Express Quad Port Gigabit Server Adapter

HP NC373F PCI Express Multifunction Gigabit Server Adapter

HP NC373T PCI Express Multifunction Gigabit Server Adapter

HP NC375T PCI Express Quad Port Gigabit Server Adapter

HP NC382T PCIe Dual Port Multifunction Gigabit Server Adapter

10 Gigabit Ethernet Adapters

HP NC522SFP Dual Port 10GbE Server Adapter

NOTE:

A minimum of 2 GB of server memory is required per each NC522SFP adapter.

NOTE:

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.

HP NC550SFP Dual Port 10GbE Server Adapter

NOTE:

A minimum of two Gigabytes (2 GB) of server memory is required per each NC550SFP adapter.

NOTE:

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

www.hp.com/go/ProLiantNICs

458947-B21

570761-B21

570763-B21

503746-B21

412648-B21

435508-B21

394793-B21

394791-B21

538696-B21

458492-B21

468332-B21

581201-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 21

QuickSpecs

Core Options

HP ProLiant ML330 Generation 6

HP Power Supplies

HP Cooling Options

NOTE:

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your need. The HP Power Advisor is located at:

www.hp.com/go/proliant-energy-efficient

CAUTION:

original supplied power supply. Upgrades for more power headroom, when replacing the original power supplies must match if purchased for redundancy. Option Kits contain optional power supply, an IEC power cable and PDU IEC cables. In ProLiant Servers that have more than one power slot (bay), only same size power supplies are recommended. If non-matched power supplies are inserted you will get errors and operation will fail.

HP 750W CS HE Power Supply

NOTE:

Supply Enablement Kit (P/N 508544-B21).

HP Redundant Power Supply Enablement Kit

NOTE:

power supply. To enable full Redundancy, it requires 2 units of 750W Power supply.

HP 5U G6 Redundant fan kit

NOTE:

IEC cables.

Optional Power Supplies used for Redundancy "must" match the

The HP 750W power supply requires purchasing the Redundant Power

The Redundant Power Supply Enablement kit does not integrate any

Option Kits contain optional power supply, an IEC power cable and PDU

www.hp.com/go/hppoweradvisor

512327-B21

508544-B21

513927-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 22

QuickSpecs

Additional Options

HP ProLiant ML330 Generation 6

HP Insight Software

HP Insight Control

HP Insight Control, Single-Server License including 1 year of 24x7 Technical Support and Updates

HP Insight Control suite, No Media, Electronic License including 1 year of 24x7 Technical Support and Updates

HP Insight Control, Electronic License for bundling with ProLiant ML/DL server, including 1 year of 24x7 Technical Support and Updates

HP Insight Control, Tracking License for bundling with ProLiant ML/DL server, including 1 year of 24x7 Technical Support and Updates

NOTE:

Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single activation key.

NOTE:

Electronic software is available in all countries except China and Japan. Customers in China and Japan should order the physical equivalent.

NOTE:

Customer will receive a license entitlement certificate. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.

NOTE:

Licenses ship without media. The HP Insight Control Media Kit can be ordered separately, or can be downloaded at:

http://www.hp.com/go/insightupdates

NOTE:

For additional license options please see the Insight Control QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html

HP Insight Control for Linux

HP Insight Control for Linux, 1-server license, including one year of 24x7 Technical Support and Updates, Electronic

HP Insight Control for Linux, No Media, 1-Server license, including one year of 24x7 Technical Support and Updates

HP Insight Control for Linux, Media pack (DVD) - No licenses included

NOTE:

Media pack DVD contains the ISO image for HP Insight Control for Linux, HP Systems Insight Manager, HP Insight Control power management, HP Insight Control virtual machine management, and an integrated installer. Servers must be acquired separately.

NOTE:

Licenses ship without media. The Media Kit for Insight Control for Linux can be ordered separately, or can be downloaded at:

linux

(click on Download button).

NOTE:

Electronic software is available in all countries except China and Japan. Customers in China and Japan should order the physical equivalent.

NOTE:

Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single set of activation keys.

NOTE:

For additional License Kits, including electronic licensing options, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/13019_div/13019_div.html

HP Integrated Lights-Out (iLO) Advanced

HP Integrated Lights-Out Advanced, No Media, 1-Server License, including 1 year of 24x7 Technical Support and Updates

HP ProLiant Essentials Integrated Lights-Out Advanced Pack, Electronic, including 1 year of 24x7 Technical Support and Updates

HP Insight Software Media Kit

NOTE:

Insight Software DVD media without licenses. Contains HP Systems Insight Manager, HP Insight Control, HP Insight Dynamics, HP Insight Control for Microsoft System Center, and Virtual Connect Enterprise Manager software. Uses an integrated installer to perform quick and accurate software installation and updates.

NOTE:

This license allows 1 server to be deployed and managed via HP iLO

http://www.hp.com/go/ic-

452148-B22

T9074BAE

TC278AAE

TC275A

TC213AAE

TC209A

TC208A

512485-B21

TA850AAE

436222-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 23

QuickSpecs

Additional Options

Advanced. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service

NOTE:

For additional license kits, including electronic delivery options, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html

HP Insight Control server deployment

HP Insight Control server deployment Electronic License including 1 year 24x7 Technical Support and Updates

HP Insight Control server deployment 1-Server License including 1 year 24x7 Technical Support and Updates

NOTE:

Licenses ship without media. The Insight Control Media Kit can be ordered separately, or can be downloaded at:

http://www.hp.com/go/insightupdates

NOTE:

Electronic licenses can be used to purchase multiple licenses with a single activation key, and is available in all countries except China and Japan. Customers in China and Japan should order the physical equivalent.

NOTE:

Customer will receive a license entitlement certificate, which must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service.

NOTE:

For additional license kits please see the Insight Control QuickSpecs at:

http://h18004.www1.hp.com/products/quickspecs/12631_div/12631_div.html

HP ProLiant ML330 Generation 6

T9082AAE

452151-B21

HP Port Options

HP PCI-X Expander Kit

HP Security - TPM

HP Storage Controllers

HP iLO 2 PORT OPT KIT

HP NHP Internal SAS/SATA 4 port cable kit

NOTE:

SAS non-hot plug drives require the Non-Hot Plug Internal SAS/SATA 4 port Cable kit (P/N 487734-B21) and a HP SAS/Smart Array Controller.

HP Hot plug internal SATA to mini SAS cable kit

NOTE:

This cable needed when upgrade from non-hot plug SATA to hot plug SATA.

HP PCI-X Expander Kit (2 x 64-bit 100MHz PCI-X slots)

HP Trusted Platform Module Option Kit

SAS Controllers

Smart Array P212 Controller

HP Smart Array P212/Zero Memory Controller

HP Smart Array P212/256MB Controller

Smart Array P410 Controller

HP Smart Array P410/256MB Controller

HP Smart Array P410/512MB with BBWC

HP Smart Array P410/512MB with FBWC

HP Smart Array P410/1G with FBWC

Smart Array P411 Controller

HP Smart Array P411/256MB Controller

HP Smart Array P411/512MB BBWC

HP Smart Array P411/512MB Flash Backed Write Cache

HP Smart Array P411/1G Flash Backed Write Cache

514206-B21

487734-B21

600732-B21

488413-B21

488069-B21

462828-B21

462834-B21

462862-B21

462864-B21

578230-B21

572532-B21

462830-B21

462832-B21

578229-B21

572531-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 24

QuickSpecs

Additional Options

HP ProLiant ML330 Generation 6

Smart Array P812 Controller

HP Smart Array P812/1G Flash Backed Cache Controller

Upgrade Options

256 MB Cache Module

NOTE:

Supported on HP Smart Array P212 and P410/ZM Controllers only.

512MB BBWC

Battery Kit upgrade

NOTE:

To enable BBWC on the 256MB cache.

NOTE:

Supported on HP Smart Array P212 Controller, HP Smart Array P410 Controller, and HP Smart Array P411 Controller only.

HP 8484 to Mini SAS 33in Cable Assy

NOTE:

Needed to support internal drives on the HP ProLiant ML330 G6 when using a Smart Array P800.

512MB Flash Backed Write Cache

1G Flash Backed Write Cache

HP Smart Array Advanced Pack No Media 1-Server license including 1yr 24x7 Technical Support

NOTE:

HP Smart Array Hot Plug Advance Pack for B110i w/1yr 24x7 Supp Physical 1 Svr LTU

NOTE:

Please see the following QuickSpecs additional information:

http://h18000.www1.hp.com/products/quickspecs/12616_div/12616_div.html

(Smart Array P800 Controller)

http://h18000.www1.hp.com/products/quickspecs/13203_div/13203_div.html

(Smart Array P212 Controller)

http://h18000.www1.hp.com/products/quickspecs/13201_div/13201_div.html

(Smart Array P410 Controller)

http://h18000.www1.hp.com/products/quickspecs/13202_div/13202_div.html

(Smart Array P411 Controller)

http://h18000.www1.hp.com/products/quickspecs/13558_div/13558_div.html

(Smart Array P812 Controller)

SAS HBA

HP SC08Ge Host Bus Adapter

NOTE:

Please see the HBA QuickSpecs for additional information:

http://h18004.www1.hp.com/products/quickspecs/13082_div/13082_div.html

(SC08Ge HBA)

SCSI HBA

HP SC11Xe Host Bus Adapter

NOTE:

Recommended HBA for SCSI tape drive connect.

NOTE:

Please see the following QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/12566_div/12566_div.html

(SC11Xe HBA)

487204-B21

462968-B21

462967-B21

462969-B21

591734-B21

534916-B21

534562-B21

516471-B21

TC421A

488765-B21

412911-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 25

QuickSpecs

Additional Options

HP ProLiant ML330 Generation 6

Backup & Recovery Software

Tape Backup

HP Data Protector Express

HP Data Protector Express 4.0 SP1 Backup Server

HP Data Protector Express 4.0 SP1 for Microsoft Small Business Server

HP Data Protector Express Backup Server 4.0 SP1Upgrade from Data Protector Express Single Server Edition

NOTE:

One of these Data Protector Express base products is required. To see available options:

NOTE:

For the complete range of StorageWorks tape drives, autoloaders, libraries and media see: compatibility of HP StorageWorks tape backup products see:

http://www.hp.com/go/connect

Rack-Mount Tape Solutions

HP StorageWorks DAT 320 USB Internal Tape Drive

HP StorageWorks DAT 320 SAS Internal Tape Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks LTO-3 Ultrium 920 SAS Internal Tape Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks LTO-4 Ultrium 1760 SAS Internal Tape Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks LTO-4 Ultrium 1840 SAS Internal Tape Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks LTO-5 Ultrium 3000 SAS Internal Tape Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader

NOTE:

Requires HP 1U Tape Autoloader Rack Kit (AH166A) for rack installation. Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks MSL2024 Tape Library with one LTO-4 Ultrium 1760 SAS Drive

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

HP StorageWorks MSL4048 Tape Library with two LTO-4 Ultrium 1760 SAS Drives

NOTE:

Connection using HP SC44Ge SAS Host Bus Adapter (416096-B21) recommended.

http://www.hp.com/go/dataprotectorexpress

http://www.hp.com/go/tape

. For hardware and software

BB117BA

BB118BA

BB117BT

AJ825A

AJ830A

EH847A

EH919A

EH861A

EH958A

AK377A

AK378A

AK380A

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 26

QuickSpecs

Additional Options

HP ProLiant ML330 Generation 6

Disk Backup

NOTE:

For the complete range of StorageWorks D2D Backup Systems see:

http://www.hp.com/go/d2d

and media see: compatibility of HP StorageWorks disk backup products see:

http://www.hp.com/go/connect

HP StorageWorks D2D Backup Systems with Backup Data Deduplication

HP StorageWorks D2D2502i Backup System

NOTE:

1.5TB of useable network disk backup capacity. Network connected appliance with connectivity using the iSCSI protocol. If the server requires a hardware iSCSI initiator, the QLogic QLA4050 Host Bus Adapter is recommended.

HP StorageWorks D2D2503i Backup System

NOTE:

2.25TB of useable network disk backup capacity. Network connected appliance with connectivity using the iSCSI protocol. If the server requires a hardware iSCSI initiator, the QLogic QLA4050 Host Bus Adapter is recommended.

HP StorageWorks D2D4004i Backup System

NOTE:

3.0TB (expandable to 7.5TB) of useable network disk backup capacity. Network connected appliance with connectivity using the iSCSI protocol. If the server requires a hardware iSCSI initiator, the QLogic QLA4050 Host Bus Adapter is recommended.

HP StorageWorks D2D4112fc Backup System

NOTE:

9.0TB (expandable to 18.0TB) of useable network disk backup capacity. Fibre Channel SAN connected appliance. Direct server attach is not supported, requires connection via SAN fabric.

HP StorageWorks RDX Removable Disk Backup Systems USB

HP StorageWorks RDX320 Internal Removable Disk Backup System

NOTE:

For installation into 1U USB Rack-Mount Kit (A8007A). No peripheral bay available for drive installation into the server. 320GB of disk capacity per data cartridge.

HP StorageWorks RDX500 Internal Removable Disk Backup System

NOTE:

For installation into 1U USB Rack-Mount Kit (A8007A). No peripheral bay available for drive installation into the server. 500GB of disk capacity per data cartridge.

HP StorageWorks RDX750 Internal Removable Disk Backup System

NOTE:

For installation into 1U USB Rack-Mount Kit (A8007A). No peripheral bay available for drive installation into the server. 750GB of disk capacity per data cartridge.

http://www.hp.com/go/rdx

. For the complete range of StorageWorks RDX drives

. For hardware and software

EJ001A

EH954A

EH938A

EH993A

AJ767A

AJ934A

AW577A

HP StorageWorks Options

HP Disk Storage Systems

StorageWorks SCSI HBA

HP U320e SCSI Host Bus Adapter

NOTE:

Recommended HBA for MSL SCSI Tape Library connect.

Disk Enclosures

HP StorageWorks D2700 Disk Enclosure

NOTE:

Please see the QuickSpecs for additional information including configuration steps and additional options needed for a complete solution at:

http://h18000.www1.hp.com/products/quickspecs/13404_div/13404_div.html

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

AH627A

AJ941A

Page 27

QuickSpecs

Additional Options

HP ProLiant ML330 Generation 6

HP Uninterruptible Power Systems

HP Rack Series

HP Tower UPS

HP T1000 G3 UPS Models

HP T1000 G3 UPS, NA

HP T1000 G3 UPS, INTL

HP T1000J UPS, Japan

HP T1500 G3 UPS Models

HP T1500 G3 UPS, NA

HP T1500 G3 UPS, INTL

HP T1500J UPS, Japan

NOTE:

Please see the QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/13160_div/13160_div.html

(Worldwide)

NOTE:

For additional information on HP Uninterruptible Power Systems please go to:

www.hp.com/products/ups

NOTE:

For additional information on sizing your server, please reference:

http://www.upssizer.com

HP Rack 10000 G2 Series

10642 G2 (42U) Rack Cabinet - Pallet

10642 G2 (42U) Rack Cabinet - Shock Pallet

NOTE:

It is mandatory to use a shock pallet when shipping racks with equipment installed.

NOTE:

Please see the QuickSpecs for Technical Specifications such as height, width, depth, weight, and color:

http://h18000.www1.hp.com/products/quickspecs/12402_div/12402_div.html

(Worldwide)

NOTE:

For additional information regarding Rack Cabinets, please see the following URL:

http://www.hp.com/go/rackandpower

(Carbon/Graphite Metallic)

AF448A

AF449A

AF457A

AF450A

AF451A

AF458A

AF001A

AF002A

HP Rack Options

HP Server Console Switches

HP Server console switch 0x2x8

HP Server console switch 0x2x16

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/11834_div/11834_div.html

(Worldwide)

HP Server Console Switch G2 with Virtual Media & CAC

0x2x16 KVM Server Console G2 Switch with Virtual Media and CAC

0x2x32 KVM Server Console G2 Switch with Virtual Media and CAC

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13475_div/13475_div.html

(Worldwide)

HP IP Console Switch G2 with Virtual Media & CAC

1x1Ex8 KVM IP Console Switch G2 with Virtual Media and CAC

2x1Ex16 KVM IP Console Switch G2 with Virtual Media and CAC

4x1Ex32 KVM IP Console Switch G2 with Virtual Media and CAC

AF616A

AF617A

AF618A

AF619A

AF620A

AF621A

AF622A

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 28

QuickSpecs

Additional Options

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13474_div/13474_div.html

(Worldwide)

Rack Kit

HP Tower to Rack Conversion Tray, Universal Kit

HP ProLiant ML330 Generation 6

417705-B21

HP USB and SD Options

HP Care Pack Services

HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)

USB 1.44-MB External Diskette Drive (Carbonite)

HP USB 04 Standard Keyboard

HP 4GB SD Flash Media Kit

NOTE:

Blank SD media device is supported for use with VMware and Citrix.SD media must be installed in the internal slot of the ProLiant server. Learn more at:

http://www.hp.com/go/proliantvirtualization

HP 2GB USB Flash Media Drive Key

NOTE:

HP qualified blank USB key for use with HP ProLiant servers that support the VMware virtualization environment and other HP value-add software like SmartStart. HP recommends this industry standard USB flash device for use with VMware ESXi. USB device must be installed in the internal slot of the ProLiant server for use with VMware ESXi. Refer to

Started Guide

Hardware Services On-site Service

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 1Year

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 1 Year

Hardware Services

Next Day Service, 3 Year

4-Hour Service, 5-Day x 13-Hour Coverage, 3 Years

4-Hour Service, 7-Day x 24-Hour Coverage, 3Years

6-Hour Call to Repair, Service, 7-Day x 24-Hour Coverage, 3 Year

Other Services

4-Hour Service, 5-Day x 13-Hour Coverage, 4 Years

4-Hour Service, 7-Day x 24-Hour Coverage, 4Years

4-Hour Service, 5-Day x 13-Hour Coverage, 5 Years

4-Hour Service, 7-Day x 24-Hour Coverage, 5Years

Support Plus

Support Plus, MS, 3Years

NOTE:

For more information, customer/resellers can contact:

http://www.hp.com/services/carepack

for installation instructions.

HP VMware Getting

DC172B

DC141B

DT528A#ABA

580387-B21

608447-B21

UM868E

UM869E

UM870E

UM872E

UM874E

UM876E

UM880E

UM882E

UM888E

UM890E

UM894E

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 29

QuickSpecs

HP ProLiant ML330 Generation 6

Memory

NOTE:

Memory configurations listed do not apply to "Factory Integrated Models".

DDR3 memory population guidelines

For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:

www.hp.com/go/ddr3memory-configurator

Some DIMM installation guidelines are summarized below:

For servers with eighteen (18) memory slots:

There are three (3) channels per processor; six (6) channels per server There are three (3) DIMM slots for each memory channel; eighteen (18) total slots Memory channel 1 consists of the three (3) DIMMs that are closest to the processor

Memory channel 3 consists of the three (3) DIMMs that are furthest from the processor DIMM slots that are white should be populated first Do not mix Unbuffered memory (UDIMMs) with Registered memory (RDIMMs) Do not install DIMMs if the corresponding processor is not installed If only one processor is installed in a 2CPU system, only half of the DIMM slots are available To maximize performance, balance the total memory capacity between all installed processors It is not required, but it is recommended to load the channels similarly if possible If any Quad rank DIMMs are installed, all channels are limited to only 2 DIMMs per channel. You can only install two quad-rank DIMMs per channel You can only install two UDIMMs per channel; if available, the third slot in the channel must remain empty Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel Heaviest load (DIMM with most ranks) within a channel goes furthest from the chipset For memory mirroring mode, channel 3 must be unpopulated. Channels 1 and 2 are populated identically For lock-step mode, channel 3 must be unpopulated. DIMMs in channels 1 and 2 will be installed in pairs. The paired slots will be 1,4; 2,5; 3;6 on a 3DPC system or 1,4; 2,5; on a 2DPC system Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600 series processors If mixing DIMM voltage is a requirement, please note that the DIMMs will run at 1.5V since all 1.35V are capable of supporting 1.5V operations

DIMM slot/capacity/populated speed table

DIMM Type DIMM Rank

DIMM Capacity DIMM Native Speed

(MHz) Voltage

18 slot servers

1 DIMM Per Channel

2 DIMM Per Channel

3 DIMM Per Channel

NOTES:

Registered DIMMS

(RDIMMs)

Single

Rank

(1R)

4GB 2GB 4GB 8GB 8GB 4GB

1333 1333 1333 1066 1333 1066 1066 1333 1333 1333

LV/Reg

SLOTS THAT CAN BE POPULATED

18 18 18 18 18 12 12 12 12 12

MAXIMUM CAPACITY (GB)

72 36 72 144 144 48 192 12 24 48

POPULATED DIMM SPEED (MHz)

1333 1333 1333 1066 1333 1066 1066 1333 1333 1333

1333

800 800 800 800 800

Reg Reg Reg

1333

Dual Rank (2R)

1333

1066 1333

LV/Reg

Quad Rank (4R)

16GB

Reg Reg Reg Reg Reg

800 800 1333 1333 1333

n/a n/a n/a n/a n/a

Unbuffered with ECC DIMMs

(UDIMMs)

Single

Rank

(1R)

1GB 2GB 4GB

Dual Rank (2R)

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 30

QuickSpecs

HP ProLiant ML330 Generation 6

Memory

PC3-10600 DIMMs have a maximum speed of 1333MHz. PC3-8500 DIMMs have a maximum speed of 1066MHz Mixing DIMM speeds is allowed, but the system processor speed rules always override the DIMM capabilities If you do mix DIMM speeds, the memory bus will default to the minimum clock rate of all DIMMs in the system - even if the slower DIMM is on the other processor If you install 1x 1066MHz DIMM in channel 1 and 1x 1333MHz DIMM in channel 2, the maximum speed will be 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other channels, the maximum speed will be 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other channels, you run at 1066MHz If you install 3DPC in one channel (if applicable) and 1DPC in all other channels, you run at 800MHz Maximum memory speed will also depend on the processor installed. References to the above MHz speeds are for the various speeds of DDR3 DIMMs; 1333 refers to DDR3-1333, etc.

DIMM slot and configuration diagrams

Basic memory slot & population diagram

Population order; start with "A" first, "B" second, "C" third, etc.

18 DIMM SLOTS (9 per CPU node)

Chnl 0

Chnl 1

Chnl 2

Standard memory configuration (1 CPU model)

slot #

1 2 3

4 5 6

7 8 9

CPU1 CPU2

population order

G D A

H E B

slot #

1 2 3

4 5 6

7 8 9

population order

G D A

H E B

Chnl 0

Chnl 1

Chnl 2

4GB, consisting of three (2) 2GB dual-rank PC3-10600 RDIMMs (Base model)

Chnl 1

Chnl 2

Chnl 3

slot #

1 2 3

4 5 6

7 8 9

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

CPU1 CPU2

population order

G; empty D; empty

A; 2GB DIMM

H; empty E; empty

B; 2GB DIMM

I; empty

F; empty

C; empty

slot #

1 2 3

4 5 6

7 8 9

population order

G; empty D; empty A; empty

H; empty E; empty B; empty

I; empty

F; empty

C; empty

Chnl 1

Chnl 2

Chnl 3

Page 31

QuickSpecs

HP ProLiant ML330 Generation 6

Memory

Standard memory plus optional memory (1 CPU model)

60GB, consisting of two (2) 2GB RDIMMs plus seven (7) 8GB RDIMMs

2x 2GB dual-rank PC3-10600 RDIMMs 7x 8GB dual-rank PC3-8500 RDIMMs

Chnl 1

Chnl 2

Chnl 3

Standard memory replaced with optional memory (1 CPU model) RDIMM maximum configuration

slot #

1 2 3

4 5 6

7 8 9

CPU1 CPU2

population order

G; 8GB DIMM D; 8GB DIMM

A; 2GB DIMM

H; 8GB DIMM

E; 8GB DIMM B; 2GB DIMM

I; 8GB DIMM

F; 8GB DIMM

C; 8GB DIMM

slot #

1 2 3

4 5 6

7 8 9

population order

G; empty D; empty A; empty

H; empty E; empty B; empty

I; empty

F; empty

C; empty

Chnl 1

Chnl 2

Chnl 3

96GB, consisting of nine (6) 16GB dual-rank PC3-8500 RDIMMs

Chnl 1

Chnl 2

Chnl 3

UDIMM maximum configuration (1 CPU model)

24GB, consisting of six (6) 4GB dual-rank PC3-10600 UDIMMs

slot #

1 2 3

4 5 6

7 8 9

CPU1 CPU2

population order

G; empty D; 16GB DIMM A; 16GB DIMM

H; empty E; 16GB DIMM B; 16GB DIMM

I; empty

F; 16GB DIMM

C; 16GB DIMM

slot #

1 2 3

4 5 6

7 8 9

population order

G; empty D; empty A; empty

H; empty E; empty B; empty

I; empty

F; empty

C; empty

Chnl 1

Chnl 2

Chnl 3

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 32

QuickSpecs

Memory

HP ProLiant ML330 Generation 6

Chnl 1

Chnl 2

Chnl 3

Standard memory replaced with optional memory (2 CPU model) RDIMM maximum configuration

192GB, consisting of eighteen (12) 16GB dual-rank PC3-8500 RDIMMs

Chnl 1

Chnl 2

Chnl 3

UDIMM maximum configuration (2 CPU model)

slot #

1 2 3

4 5 6

7 8 9

slot #

1 2 3

4 5 6

7 8 9

CPU1 CPU2

population order

G; empty

D; 4GB DIMM

A; 4GB DIMM

H; empty

E; 4GB DIMM B; 4GB DIMM

I; empty

F; 4GB DIMM

C; 4GB DIMM

CPU1 CPU2

population order

G; empty D; 16GB DIMM A; 16GB DIMM

H; empty E; 16GB DIMM B; 16GB DIMM

I; empty

F; 16GB DIMM

C; 16GB DIMM

slot #

1 2 3

4 5 6

7 8 9

slot #

1 2 3

4 5 6

7 8 9

population order

G; empty D; empty A; empty

H; empty E; empty B; empty

I; empty

F; empty

C; empty

population order

G; empty D; 16GB DIMM A; 16GB DIMM

H; empty E; 16GB DIMM B; 16GB DIMM

I; empty

F; 16GB DIMM

C; 16GB DIMM

Chnl 1

Chnl 2

Chnl 3

Chnl 1

Chnl 2

Chnl 3

48GB, consisting of twelve (12) 2GB dual-rank PC3-10600 UDIMMs

Chnl 1

Chnl 2

Chnl 3

slot #

1 2 3

4 5 6

7 8 9

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

CPU1 CPU2

population order

G; empty

D; 4GB DIMM

A; 4GB DIMM

H; empty E; 4GB DIMM B; 4GB DIMM

I; empty

F; 4GB DIMM

C; 4GB DIMM

slot #

1 2 3

4 5 6

7 8 9

population order

G; empty

D; 4GB DIMM

A; 4GB DIMM

H; empty E; 4GB DIMM B; 4GB DIMM

I; empty

F; 4GB DIMM

C; 4GB DIMM

Chnl 1

Chnl 2

Chnl 3

Page 33

QuickSpecs

Memory

NOTE:

Capacity references are rounded to the common Gigabyte values.

1GB = 1024MB 2GB = 2048MB 4GB = 4096MB 8GB = 8192MB

Following are memory options available from HP:

HP Memory

Registered DIMMs (RDIMMs)

HP 2GB 2Rx8 PC3-10600R-9 Kit

HP 4GB 2Rx4 PC3-10600R-9 Kit

HP 4GB 4Rx8 PC3-8500R-7 LP Kit

HP 4GB 1Rx4 PC3-10600R-9 Kit

HP 4GB 1Rx4 PC3L-10600R-9 Kit

NOTE:

Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600

series processors.

HP 8GB 2Rx4 PC3-8500R-7 Kit

HP 8GB 2Rx4 PC3-10600R-9 Kit

HP 8GB 2Rx4 PC3L-10600R-9 Kit

NOTE:

Low Voltage DIMMs can only be used with Intel® Xeon® processor 5600

series processors.

HP 16GB 4Rx4 PC3-8500R-7 Kit

Unbuffered with ECC DIMMs (UDIMMs)

HP 1GB 1Rx8 PC3-10600E-9 Kit

HP 2GB 2Rx8 PC3-10600E-9 Kit

NOTE:

For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:

configurator

NOTE:

PC3L is a low voltage memory.

HP ProLiant ML330 Generation 6

500656-B21

500658-B21

500660-B21

593339-B21

604504-B21

516423-B21

500662-B21

604506-B21

500666-B21

500668-B21

500670-B21

www.hp.com/go/ddr3memory-

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 34

QuickSpecs

Storage

HP ProLiant ML330 Generation 6

Optical Drive

B,C

Removable Media Bays- 1 full-height drive or 2 halfheight drives

1-4

4 x 3.5" (LFF) Hot plug or Non hot-plug SATA/SAS hard drive bays (Standard)

5-8

4 x 3.5" (LFF) Hot plug SATA/SAS hard drive bays (Optional)

Drive Support

Removable Media

SATA DVD-ROM Drive

HP Half-Height SATA DVD RW Optical Drive

Hard Drives

NOTE:

Transfer rates of drives are dependent on the maximum transfer rate supported by the HBA or Controller. Refer to

the HBA or Controller technical specifications for details.

NOTE:

Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

Supports up to Eight (8) SAS/SATA hard drives via 2nd Hot plug Hard Disk Drive module option kit and HP Smart

Array P410 Controller.

SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

600GB 6G SAS 15K DP 450GB 6G SAS 15K DP 450GB 3G SAS 15K DP 300GB 6G SAS 15K DP 300GB 3G SAS 15K DP 146GB 3G SAS 15K DP

Quantity

Supported

Up to 1

Quantity

Supported

Up to 8

Position

Supported

Position

Supported

1-8

Controller

Integrated SAS Controller

Integrated SATA Controller

Controller

HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller

SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

Quantity

Supported

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Position

Supported

Controller

Page 35

QuickSpecs

Storage

HP ProLiant ML330 Generation 6

600GB 6G SAS 15K DP 450GB 6G SAS 15K DP 450GB 3G SAS 15K DP 300GB 6G SAS 15K DP 300GB 3G SAS 15K DP 146GB 3G SAS 15K DP

SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives

2TB 6G SAS 7.2K DP 1TB 3G SAS 7.2K DP 750GB 3G SAS 7.2K DP

NOTE:

Transfer rates of drives are dependent on the maximum transfer rate supported by the HBA or Controller. Refer to

the HBA or Controller technical specifications for details.

SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives

2TB 3G SATA 7.2K 1TB 3G SATA 7.2K 750GB 3G SATA 7.2K 500GB 3G SATA 7.2K 250GB 3G SATA 7.2K

Up to 8

Quantity

Supported

Up to 8

Quantity

Supported

Up to 8

1-8

Position

Supported

1-8

Position

Supported

1-8

HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller

Controller

HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller

Controller

HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array Hot Plug Advance Pack for B110i

SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives

750GB 3G SATA15K 500GB 3G SATA 15K 250GB 3G SATA 15K

SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives

250GB 3G SATA 7.2K 160GB 3G SATA 7.2K

SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives

Quantity

Supported

Up to 4

Quantity

Supported

Up to 8

Quantity

Supported

Position

Supported

1-4

Position

Supported

1-8

Position

Supported

Controller

Embedded Smart Array B110i SATA RAID Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array B110i SATA RAID controller

Controller

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 36

QuickSpecs

Storage

HP ProLiant ML330 Generation 6

250GB 3G SATA 15K 160GB 3G SATA 15K

SATA Hot Plug 3.5" Midline (MDL) Solid State Drives

60GB 3.0G SATA SSD 120GB 3.0G SATA SSD

NOTE:

To support 8 drives, the purchase of the optional HP HDD cage and possibly purchase a second SATA/SAS

controller are required.

NOTE:

SAS non-hot plug drives require the Non-Hot Plug Internal SAS/SATA 4 port Cable kit (P/N 487734-B21) and a HP

SAS/Smart Array Controller.

NOTE:

Hot Plug SATA/SAS model and Non-hot plug SAS model requires A HP SAS Controller.

Maximum Storage Capacity

Internal

Total

Maximum Storage Capacity

Internal

Total

Up to 4

Quantity

Supported

Up to 8

- SAS Models

16.0TB (8 x 2TB SAS hard drives)

- SATA Models

16.0TB (8 x 2TB SATA drives)

1-4

Position

Supported

1-8

Controller

External Storage

D2700 Disk Enclosure

Tape and Disk Backup

NOTE:

For the complete range of StorageWorks tape drives, autoloaders, libraries and media, including the internal fitting models, see:

http://www.hp.com/go/d2d

For hardware and software compatibility of HP StorageWorks disk and tape backup products see:

http://www.hp.com/go/connect

HP StorageWorks SCSI Tape Drives

LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-3 Ultrium 960

http://www.hp.com/go/tape

Quantity

Supported

Up to 2

Up to 4

. For the complete range of StorageWorks RDX drives and media see:

Position

Supported

Internal or

External

Position

Supported

External

. For the complete range of StorageWorks D2D Backup Systems see:

Controller

HP SC11Xe Host Bus Adapter

Host Controller or Adapter

HP Smart Array P212/ 256 MB Controller

HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller

http://www.hp.com/go/rdx

Controller/HBA

Option Kit Part

Number

412911-B21

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 37

QuickSpecs

HP ProLiant ML330 Generation 6

Storage

LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-3 Ultrium 960 LTO4 Ultrium 1760 LTO-4 Ultrium 1840 DAT 40 DAT 72 DAT 160

HP StorageWorks SCSI Rack Mount Kits

1U Rack-Mount Kit 3U Rack-Mount Kit

HP StorageWorks USB Tape Drives

DAT 40 DAT 72 DAT 160 DAT 320

HP StorageWorks USB Rack Mount Kits

1U USB Rack-Mount Kit

HP StorageWorks SAS Tape Drives

DAT 160 DAT 320 LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-4 Ultrium 1760 LTO-4 Ultrium 1840 LTO-5 Ultrium 3000 LTO-5 Ultrium 3280

HP StorageWorks SAS Rack Mount Kits

1U Rack-Mount Kit 3U Rack-Mount Kit

HP StorageWorks SCSI Tape Autoloaders, External

DAT 72x10 Autoloader 1/8 G2 Autoloader

HP StorageWorks SCSI Tape Libraries, External

MSL2024 MSL4048 MSL8096 MSL6000

External

Internal or

External

Internal or

External

HP U320e SCSI Dual Channel Controller

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

HP SC11Xe Host Bus Adapter

USB 2.0 Port

HP SC44Ge SAS Host Bus Adapter

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

HP SC44Ge SAS Host Bus Adapter

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

HP SC11Xe Host Bus Adapter

HP U320e SCSI Dual Channel Controller

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

HP U320e SCSI Dual Channel Controller

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

AH627A

412911-B21

N/A

416096-B21

412911-B21

AH627A

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 38

QuickSpecs

Storage

HP ProLiant ML330 Generation 6

HP StorageWorks SAS Tape Autoloaders and Libraries, External

1/8 G2 Autoloader MSL2024 MSL4048 MSL8096

HP StorageWorks Fibre Channel Tape Libraries

MSL2024 MSL4048 MSL8096 MSL6000

HP StorageWorks USB RDX Removable Disk Backup System

RDX160 RDX320 RDX500 RDX750

HP StorageWorks D2D Backup Systems, iSCSI

D2D2500i D2D4000i

HP StorageWorks D2D Backup Systems, Fibre Channel

D2D4000fc

External

Internal or

External

HP SC44Ge SAS Host Bus Adapter

NOTE:

Please check the full compatibility information at:

http://www.hp.com/go/connect

Please consult the EBS connectivity matrix at:

http://www.hp.com/go/ebs

supported Fibre Channel HBAs shown in this QuickSpec.

USB 2.0 port

Embedded Network Controller. If the server requires a hardware iSCSI initiator, the QLogic QLA4050 Host Bus Adapter is recommended.

Direct server attach is not supported, requires connection via SAN fabric. See:

http://www.hp.com/go/connect

for connectivity information and the

416096-B21

N/A

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 39

QuickSpecs

Power Specifications

HP ProLiant ML330 Generation 6

460W PSU Part Number Operational Input Voltage Range

(Vrms) Frequency Range (Nominal) (Hz) Nominal Input Voltage (Vrms)

Max Rated Output Wattage Rating Nominal Input Current (A rms) Max Rated Input Wattage Rating (Watts) Max. Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A peak) Maximum Inrush Current duration (mS)

HP 750W Power Supply Part Number - AC 750W PSU

Input Voltage Range (Vrms) Frequency Range (Nominal)

(Hz) Nominal Input Voltage (Vrms)

Maximum Rated Output Wattage Nominal Input Current (A rms) Max Rated Input Wattage Rating

(Watts) Max. Rated VA (Volt-Amp) Efficiency (%) at Max. Rated

Output Wattage Power Factor Leakage Current (mA) Max. Inrush Current (A peak) Max. Inrush Current duration

(mS) Maximum British Thermal Unit

Rating (BTU-Hr)

512327-B21 100 to 240 50/60

100 120 200 208 220 230 240

750 750 750 750 750 750 750

8.9 7.4 4.3 4.1 3.9 3.7 3.6

857 847 824 825 820 820 820

894 884 859 859 854 854 854

87.5 88.5

0.97 0.97 0.97 0.97 0.97 0.97 0.97

0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30 20 20 20 20 20 20 20

2925 2892 2812 2812 2797 2797 2797

500447-B21 90 to 135

47 to 66 Hz

100 115 208 220 230 240

460 460 460 460 460 460

10 10 5 5 5 5 760 760 700 700 700 700 850 850 830 830 830 830

65 65 65 65 65 65

0.9 0.9 0.9 0.9 0.9 0.9

3.5 3.5 3.5 3.5 3.5 3.5

450 450 450 450 450 450

91 91

91.5 91.5 91.5

NOTE:

It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your need.

The HP Power Advisor is located at:

www.hp.com/go/proliant-energy-efficient

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

www.hp.com/go/hppoweradvisor

Page 40

QuickSpecs

Technical Specifications

HP ProLiant ML330 Generation 6

System Unit

Tower Dimensions

(H x W x D) (W/O foot stand)

Tower Weight

(approximate)

Input Requirements

(per power supply)

BTU Rating

Power Specifications

7.87 x 16.81 x 24.13 in (200 x 427 x 613 mm)

Maximum: (All hard drives, power supplies and processors installed)

Minimum: (One hard drive, power supply and processor installed)

Rated Line Voltage

Rated Input Current

Rated Input Frequency

Rated Input Power

Maximum

To review typical system power ratings use the Power Calculator which is available via the online tool located at URL:

energy-efficient

www.hp.com/go/hppoweradvisor

30 kg

16 Kg

100 to 240 VAC

7.1 Amps (at 120VAC) to 3.5 Amps (at 240 VAC)

50 to 60 Hz

852 W

460W - 1773 BTU / hr (at 120 VAC), 1715 (at 240 VAC) 750W - 2892 BTU / hr (at 120 VAC), 2797 (at 240 VAC) 1200W - 3530 BTU / hr (at 120 VAC), 4600 (at 240 VAC)

www.hp.com/go/proliant-

Power Supply Output

(per power supply)

System Inlet Temperature

Relative Humidity

(non-condensing)

- Click on the system of interest. Example: ML330 G6

- Follow the instructions of the next screens.

Rated Steady-State Power

Maximum Peak Power

Operating

Non-Operating

Operating

Non-operating

460 (750) W (at 100 VAC), 460 (750) W (at 200 VAC)

NOTE:

See Power Supply Specifications tables for complete details on 460W PSU and optional 750W.

50° to 95° F (10° to 35° C) at sea level with an altitude derating of 1.8°F per 1,000 ft (1.0° C per every 305 m) above seal level to a maximum of 10,000 ft (3050 m) no direct sustained sunlight . Maximum rate of change is 18°F/hr (10°C/hr). The upper limit may be limited by the type and number of options installed. System performance may be reduced if operating with a fan fault or above 86°F (30°C).

-22° to 140° F (-30° to 60° C)

10% to 90% relative humidity (Rh), 82.4°F (28°C) maximum wet bulb temperature, noncondensing.

10% to 95% relative humidity (Rh), 101.7°F (38.7°C) maximum wet bulb temperature, non-condensing.

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 41

QuickSpecs

Technical Specifications

HP ProLiant ML330 Generation 6

Altitude

Acoustic Noise

Emissions Classification (EMC)

Operating

Non-Operating

Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA

74) and declared in accordance with ISO 9296 (ECMA 109).

Idle (Fixed Disk Drives Spinning)

L WAd (BELS)

L-pAm

Operating (Random Seeks to Fixed Disks)

L WAd (BELS)

FCC Rating

Normative Standards

NOTE:

Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.

10,000 ft (3000m). Maximum allowable altitude change rate is 1°C per 300m.

30,000 ft (9144m). Maximum allowable altitude change rate is 1°C per 300m.

460W SPS (w/ non-redundant fan): 4.9B 460W SPS (w/ redundant fan): 5.1B 750W RPS (w/ non-redundant fan): 5.1B 750W RPS (w/ redundant fan): 5.3B

460W SPS (w/ non-redundant fan): 31.4 dBA 460W SPS (w/ redundant fan): 33.7 dBA 750W RPS (w/ non-redundant fan): 33.4 dBA 750W RPS (w/ redundant fan): 33.8 dBA

460W SPS (w/ non-redundant fan): 4.9B 460W SPS (w/ redundant fan): 5.2B 750W RPS (w/ non-redundant fan): 5.3B 750W RPS (w/ redundant fan): 5.4B

460W SPS (w/ non-redundant fan): 31.4 dBA 460W SPS (w/ redundant fan): 33.9 dBA 750W RPS (w/ non-redundant fan): 34.6 dBA 750W RPS (w/ redundant fan): 35.2 dBA

NOTE:

The listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels.

Class B

CISPR 22; EN55022; EN55024; 47 CFR, FCC Rules and Regulations Part 15 Subpart B;VCCI Class B ITE; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 610003-3.

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 42

QuickSpecs

Technical Specifications

HP ProLiant ML330 Generation 6

HP Smart Array B110i SATA RAID Controller (RAID 0,1,10)

HP 250GB 3G SATA

7.2K NHP 3.5" MDL HDD

Dimensions

Disk Drive and Enclosure Protocol Support Architecture

SAS Connectors

Software Upgradeable Firmware

Maximum Capacity

Memory Addressing

Logical Drives Supported

RAID Support

Capacity

Height

Width

Depth

Interface

Transfer Rate

(Maximum)

Native Command Queuing

Seek Time

(typical reads, including settling)

Physical Configuration

Operating Temperature

* Maximum drive dimension

N/A (embedded)

3.0 Gbps SATA

64-bit

4 internal x1 SATA connectors

Yes. HP Smart Array hot plug Advanced Pack No Media 1-Server license including 1yr 24x7 Technical Support

2TB

6GB (maximum)

2 (maximum)

RAID 1 (Mirroring) RAID 0 (Striping) RAID 10

250,059MB

1.028 in (26.1 mm)

4.00 in (101.6 mm)

5.787 in (147.0 mm)

Serial ATA

3Gb/s

N/A

Single Track

Average

Full-Stroke

Rotational Speed

Bytes/Sector

Logical Blocks

41° to 131° F (5° to 55° C)

1.0 ms

<8.5 ms

17.0 ms

7,200 rpm

512

488,397,168

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 43

QuickSpecs

Technical Specifications

HP ProLiant ML330 Generation 6

Embedded NC326i PCI Express Dual Port Gigabit Server Adapter

Environment-friendly Products and Approach

Network Interface

Compatibility

Data Transfer Method

Controller

Network Transfer Rate

Connector

Cable Support

End-of-life Management and Recycling

10Base-T/100Base-TX/1000Base-TX

IEEE 802.3 10Base-T

IEEE 802.3ab 1000Base-T

IEEE 802.3u 100Base-TX

PCI Express, four lanes (x4)

BCM5715C

10Base-T (Half-Duplex)

10Base-T (Full-Duplex)

100Base-TX (HalfDuplex)

100Base-TX (FullDuplex)

1000Base-TX (Half and Full-Duplex)

RJ-45

10Base-T

10/100/1000Base-TX

Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

http://www.hp.com/go/green http://www.hp.com/go/green

10 Mb/s

20 Mb/s

100 Mb/s

200 Mb/s

2000Mb/s

Categories 3, 4 or 5 UTP; up to 328 ft (100 m)

Category 5 UTP; up to 328 ft (100 m)

. To recycle your product, or contact your nearest HP

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

The information contained herein is subject to change without notice.

Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.

http://www.hp.com/go/green

. These

DA - 13361 Worldwide QuickSpecs — Version 17 — 3-31-2010

Page 44

HP ML330 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Models

Configuration Information - Factory Integrated Models

Core Options

Additional Options

Memory

Storage

Power Specifications

Technical Specifications
