HP ML310 User Manual

QuickSpecs

Overview

HP ProLiant ML310 Generation 5
Front View:
1.
SATA DVD-ROM
2.
Removable Media Bays
3.
LED Indicators and Power Button
4.
Upfront USB Ports
5.
Four DIMM Sockets for up to 8GB DDR2 memory
6.
Processor Socket (Intel® Xeon®, Core™2, Pentium® or Celeron®)
7.
System Fan
8.
410W Non-Hot Plug Non-Redundant Power Supply or 430W Hot Plug Redundant Power Supplies
Rear View:
1.
Power cord connections for Non-Redundant Power Supply
2.
3.
Keyboard connector
4.
Embedded Gigabit NIC / Shared iLO 2 Management Port
5.
Dedicated Integrated Lights-Out 2 (iLO 2) Management Port
6.
USB 2.0 (qty 2)
7.
Video Port
8.
Serial Port
9.
Up to Five Expansion Slots (Four PCI Express and One PCI-X (Optional))
What's New
Quad-Core Intel® Xeon® processor X3360 (2.83GHz, 12MB L2 cache, 95 Watts, 1333MHz Front Side Bus (FSB)) Single-Core Intel® Celeron® processor 440 (2.0GHz, 512KB L2 cache, 800MHz FSB)
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 1
QuickSpecs
HP ProLiant ML310 Generation 5
Overview
At A Glance
The HP ProLiant ML310 G5 is an affordable, single processor tower server designed to provide the solid network foundation essential to fuel thriving small offices. Processing power ranging from single-core Celeron to quad-core Xeon combines with industry-leading management and essential data protection features for a secure, affordable platform that helps you run your business efficiently.
Processors:
Quad-Core Intel® Xeon® 3200 processor sequence Dual-Core Intel® Xeon® 3100 processor sequence Dual-Core Intel® Xeon® 3000 processor sequence Dual-Core Intel® Core™2 E4600 processor Dual-Core Intel® Pentium® E2160 processor Single-Core Intel® Celeron® 420 processor 1333 MHz Front Side Bus (FSB) Intel® 3210 Chipset
Memory:
Up to 8 GB of PC2-6400 800MHz unbuffered DDR2 SDRAM with ECC capabilities and optional interleaving
Storage Controller:
SAS Models: HP SC40Ge SAS HBA with RAID 0,1 in a PCI Express slot SATA Models: Embedded SATA with integrated SATA RAID 0,1
Internal Drive Support:
Supports up to four hot plug SAS or SATA hard drives for up to 3TB internal storage Models support SAS and SATA hard drives
Network Controller:
Embedded NC326i Gigabit Server Adapter
Expansion Slots:
Up to 5 Total: (1) PCI Express x8, (3) PCI Express x1, Optional Extender Board for (1) 64-bit/100MHz PCI-X
USB 2.0 Ports:
6 Total: (2) front; (2) rear; (1) internal; (1) dedicated internal for tape
Management:
HP Insight Control Environment server management software Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared network access ROM Based Setup Utility (RBSU) and PXE support
Form Factor:
Tower Optional Tower-to-Rack Enabling Kit available, system & tray occupy 6U
Warranty:
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year, with 1 year Next Business Day and year on-site support from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Expanded support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. SATA hard drives have a one-year warranty. (3-1-1 warranty offered in AP only).
NOTE:
Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.htm
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 2
QuickSpecs

Standard Features

HP ProLiant ML310 Generation 5
NOTE:
specifications, please visit:
NOTE:
Factory Integrated Models" section.
Processor
One of the following depending on Model
For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
http://h71028.www7.hp.com/ERC/downloads/4AA1-5499ENW.pdf
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information –
Quad-Core Intel® Xeon® processor X3360 (2.83GHz, 12MB L2 Cache, 95 Watts, 1333MHz Front Side Bus (FSB))
Quad-Core Intel® Xeon® processor X3350 (2.66GHz, 12MB L2 Cache, 95 Watts, 1333MHz FSB)
Quad-Core Intel® Xeon® processor X3320 (2.5GHz, 6MB L2 Cache, 95 Watts, 1333MHz FSB)
Quad-Core Intel® Xeon® processor X3220 (2.4GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
NOTE:
Dual-Core Intel® Core™2 processor E4600 (2.4GHz, 2MB L2 Cache, 800MHz FSB)
Dual-Core Intel® Pentium processor E2160 (1.8GHz, 1MB L2 Cache, 800MHz FSB)
Single-Core Intel® Celeron® processor 440 (2.0GHz, 512KB L2 Cache, 800MHz FSB)
Single-Core Intel® Celeron® processor 420 (1.60GHz, 512KB L2 Cache, 800MHz FSB)
NOTE:
"Configuration Information - Factory Integrated Models" section of this QuickSpecs.
Quad-Core Intel® Xeon® processor X3210 (2.13 GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
Dual-Core Intel® Xeon® processor E3110 (3.0GHz, 6MB L2 Cache, 65 Watts, 1333MHz FSB)
Dual-Core Intel® Xeon® processor 3075 (2.66GHz, 4MB L2 Cache, 65 Watts, 1333MHz FSB)
Dual-Core Intel® Xeon® processor 3065 (2.33 GHz, 4MB L2 Cache, 65 Watts, 1333MHz FSB)
Not available in Asia Pacific
The processors listed above available via Configure to Order only. Please see
.
Cache Memory
One of the following depending on Model
Memory Protection
Memory
One of the following depending on Model
12 MB L2 Cache
NOTE:
8 MB L2 Cache
NOTE:
6 MB L2 Cache
NOTE:
4 MB L2 Cache
NOTE:
2 MB L2 Cache
NOTE:
1 MB L2 Cache
NOTE:
512 KB L2 Cache
NOTE:
ECC
Type
Standard - Xeon 3075 and Xeon 3065 Models
Standard - Xeon X3210 and Xeon E3110 Models
Maximum
For Models with Intel Xeon processor X3350 and X3360.
For Models with Intel Xeon processor X3220 and X3210.
For Models with Intel Xeon processor X3320 and E3110.
For Models with the Intel Xeon processor 3075 and 3065.
For Models with the Intel Core2 processor E4600.
For Models with the Intel Pentium processor E2160
For Models with the Intel Celeron processor 420.
.
PC2-6400 unbuffered DDR2 SDRAM (800MHz)
512 MB (1 x 512 MB)
1 GB (1 x 1 GB)
8 GB
Network Controller
Embedded NC326i Gigabit Server Adapter
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 3
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Expansion Slots
Storage Controllers
Expansion
Slots #
7
6
5
3
1
(Optional)
The HP ProLiant ML310 G5 supports Serial ATA (SATA) and Serial Attached SCSI (SAS) hard drives. Models described as SAS models include an 8 port HBA that supports both SATA and SAS hard drives in non-RAID, RAID 0, or RAID 1 configurations. Models described as SATA/SAS support SATA hard drives standard and require the installation of an HBA or controller to support SAS.
HP SC40Ge SAS HBA with RAID (in PCIe slot) (SAS Models)
Embedded SATA with integrated SATA RAID 0,1 (SATA/SAS Models)
NOTE:
installation of a driver from a floppy drive. The supported floppy drive can be a USB drive key, USB floppy drive, half-height internal floppy drive, or virtual floppy via Integrated Lights-Out 2 (iLO
2).
NOTE:
the ML310 G5.
NOTE:
SATA and SAS hard drive configurations.
Technology
PCIe
PCIe
PCIe
PCIe
PCI-X
(100MHz,
3.3V)
Use of the embedded SATA RAID feature with a Linux operating system requires
Any Smart Array Controller or SAS HBA requires the purchase of the HP SAS Cable for
See the "Storage" section of these QuickSpecs for information on required to support
Bus
Width
***
x1 x8
x1 x8
x1 x8
x8 x8
64-bit
Connector
Width
Not
applicable
Bus
Number
4 0
7 0
10 0
18 0
14 2
*
Device
No.
**
Form
Factor
Half length,
full height
slot
Half length,
full height
slot
Full length,
full height
slot
Full length,
full height
slot
Full length,
full height
slot
Notes
Storage
Maximum Internal Storage
Optical Drive
Diskette Drive
Hot Plug SAS (3.5")
Hot Plug SATA (3.5")
NOTE:
See the "Storage" section of these QuickSpecs for information on controllers required to
support SATA and SAS hard drive configurations.
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
SATA DVD-ROM Drive Standard
Optional 1.44 MB Diskette Drive
NOTE:
Use of the embedded SATA RAID feature with a Linux operating system requires installation of a driver from a floppy drive. The supported floppy drive can be a USB drive key, USB floppy drive, half­height internal floppy drive, or virtual floppy via Integrated Lights-Out 2 (iLO 2).
1.2TB
3.0TB
4 x 300 GB SAS
4 x 750 GB SATA
Page 4
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Interfaces
Graphics
Parallel
Serial
Pointing Device (Mouse)
Graphics
Keyboard
USB Ports
Dedicated USB Port
Network RJ-45 (Ethernet)
iLO 2 Remote Management port
Integrated ATI ES1000, 32 MB video standard
16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024
NOTE:
Maximum resolution available via iLO 2 remote console is 1280 x 1024.
1 (Optional)
1 (Optional second serial port available)
1
1
1
5 (2 front; 2 rear; 1 internal)
NOTE:
Please see the following URL for additional information regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb­support.html
1 (available for USB tape connectivity)
1 (Shared iLO 2 port)
1
.
Form Factor
HP Insight Control Management Suites
Tower (5U) Optional Tower-to-Rack Enabling Kit available (system & tray occupy 6U)
HP Insight Control Environment delivers foundation management, including remote monitoring, hardware resource deployment, health monitoring, software version control, performance monitoring, vulnerability scanning and patch management, and power management. HP Insight Control Environment installs and licenses the following components by default using a wizard-based integrated installer:
HP Systems Insight Manager HP iLO Advanced Pack HP Rapid Deployment Pack HP Insight Power Manager HP Performance Management Pack HP Vulnerability and Patch Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control Management kit can be installed manually
HP Server Migration Pack - Universal Edition HP Open Service Event Manager HP Instant Support Enterprise Edition
NOTE:
included in the Insight Control Management media kit.
NOTE:
visit:
Server Migration Pack - Universal Edition can be installed from the SMP Universal CD
For additional product and licensing information about HP Insight Control Environment,
http://www.hp.com/go/ice
.
HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
.
Page 5
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Server Management Stand Alone Software Product - ProLiant Essentials
HP Systems Insight Manager
ProLiant Essentials Server Migration Pack ­Universal Edition
ProLiant Essentials Performance Management Pack
Integrated Lights-Out Advanced Pack
HP Insight Power Manager (IPM)
NOTE:
Packs. Refer to: Value Pack product QuickSpecs for more information.
Flexible and volume quantity license kits are available for ProLiant Essentials Value
http://www.hp.com/servers/proliantessentials
HP Systems Insight Manager (HP SIM) provides a unified, secure and extensible standards-based environment to centrally manage servers, storage and other infrastructure devices, (both HP and non-HP) across multiple operating system platforms.
Upgrading, replacing, or virtualizing your existing server? Effortlessly transition to new virtual or physical HP ProLiant servers or BladeSystem with automated, accurate and affordable migration of OS, application and data. SMP Universal automates the manual processes required for migrating servers between physical or virtual platforms, whether migrating to VMware or Microsoft virtual machines. SMP Universal allows all of the following migrations:
physical to ProLiant physical to virtual virtual to virtual virtual to ProLiant
NOTE:
Performance Management Pack (offered exclusively through the Insight Control suites) - a performance management solution that identifies and explains hardware performance bottlenecks on ProLiant servers and attached options enabling users to better utilize their valuable resources
Upgrades the iLO 2 processor with comprehensive remote control including Virtual KVM remote graphical console, enhanced console sharing and replay, virtual media (floppy, CD/DVD, USB key), virtual folders, and enterprise security (directory services and two-factor authentication).
Upgrades the single-server remote management capabilities of iLO Select/Advanced to include centralized reporting and policy-based management of power consumption and thermal output provided by the Insight Power Manager. IPM unifies all of this functionality within a single user interface - HP Systems Insight Manager.
For more information, visit:
http://www.hp.com/go/migrate
or the various ProLiant Essentials
.
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 6
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Core Infrastructure Management
SmartStart
Insight Management Agents
Subscriber's Choice
ProLiant Support Packs and ROMPaq, software
SmartStart is a tool that simplifies server setup, providing a rapid way to deploy reliable and consistent server configurations. For more information, please visit the SmartStart Web site at:
http://www.hp.com/servers/smartstart
SmartStart version supported (minimum): SmartStart 7.51.
The Insight Management Agents should be installed on all HP servers to present system instrumentation, health and configuration information into HP Systems Insight Manager and the HP System Management Homepage. The HP System Management Homepage aggregates systems data from Insight Management Agents and other HP management tools, providing a consolidated browser-based interface for managing individual servers.
Insight Management Agents and The HP System Management Homepage are included on ProLiant Support Packs, and can also be installed using the server profiles provided with the ProLiant Essentials Rapid Deployment Pack.
For additional information about the Management Agents and the HP System Management Homepage please visit the management Web site at:
http://www.hp.com/servers/manage
Subscriber's Choice Driver and Support Alerts/Notifications is a web­based email subscription service that provides software and driver change notifications for ProLiant products. Sign up at:
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become available, on a weekly or monthly basis.
The latest software, drivers, and firmware fully optimized and tested for your ProLiant server and options, available through ProLiant Support Packs the ProLiant Essentials Rapid Deployment Pack, SmartStart or downloaded from software and drivers download pages website at:
http://www.hp.com/go/support
.
.
.
Industry Standard Compliance
ACPI V1.0b and 2.0 Compliant PCI 3.0 Compliant PCI-X 3.0 Compliant PCI-Express 3.0 Compliant PXE Support WOL Support Microsoft Logo certifications Novell Logo certifications USB 2.0
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 7
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Remote Management
Manageability
Integrated Lights-Out (iLO 2) Management 2
Virtual Text Remote Console (pre-OS only) Remote Serial Console Virtual Power Button Control Virtual Unit ID control Integrated Remote Console Dedicated & full function shared network connectivity Embedded system health Present power consumption Browser, command line and scripted access Automatic IP Configuration via DHCP/DNS/WINS Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH) Advanced Encryption Standard (AES)/Triple Data Encryption Standard (3DES) OS independent hardware health status IML and iLO Event Logging Support for 12 user accounts with customizable access privilege
HP Systems Insight Manager Online ROM Flash Utility Drive Parameter Tracking (with Smart Array Controller) Dynamic Sector Repairing (with Smart Array Controller) Pre-Failure Warranty (covers processors, memory and SAS hard drives) BIOS Serial Console
Security
Server Power Cords
Power Specifications
Power Supply
UPS and PDU Power Cord Matrix
Power-on password Setup password Diskette boot control Power switch security
All models ship with one 1.8m (6 foot) standard low-line, country specific power cord. Localized cables included with geographic specific models in other world regions.
NOTE:
local power cord, they can check the power cord matrix for the appropriate country specific sku. Please see the following power cord matrix:
To review typical system power ratings use the Active Answers Power Calculator at:
http://h30099.www3.hp.com/configurator/powercalcs.asp
410 Watt PFC (Power Factor Correcting) non-hot plug non-redundant power supply or 430 Watt PFC hot plug redundant power supplies (ships with two power supplies)
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications for UPS and PDU units:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
HP ProLiant ML310 a C13 to C14 2.8M jumper cord ships standard. If customers require a
http://www.hp.com/go/powercordmatrix
.
System Fans
1 - Non-hot plug, Non-redundant system fans; 1 optional fan for PCI-X Extender Board
NOTE:
Does not include fan in power supply.
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 8
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
OS Support
Factory Express Portfolio for Servers and Storage
Microsoft Windows Server 2003 Microsoft Small Business Server 2003 Microsoft Windows Server 2008 Novell NetWare Red Hat Enterprise Linux SUSE Enterprise Linux Server SCO OpenServer
NOTE:
operating systems.
NOTE:
OS Support Matrix at:
NOTE:
select your server:
lang=en&cc=us&taskId=135&prodTypeId=15351&prodCatId=241435
NOTE:
BladeSystem Server Linux matrix
http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE:
from HP please visit the OS product site at:
http://h18004.www1.hp.com/products/servers/software/OEM.html
HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.
The ML310 Embedded SATA RAID feature is not available for use with Netware or SCO
For a more complete and up-to-date listing of supported OSs and versions, please visit our
http://www.hp.com/go/supportos
For an up-to-date listing of the latest software and drivers available for your server, please
http://h20000.www2.hp.com/bizsupport/TechSupport/Product.jsp?
.
For more Linux OS support & certification information, please visit our the ProLiant &
For more complete and up-to-date information on how to buy server operating systems
Rack and Rack Options
HP Enterprise Configurator
Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.
For more information on Factory Express services for your specific server model please contact your sales representative or go to:
Rack Cabinets:
For information regarding Rack Cabinets, please see the following URL:
http://www.hp.com/go/rackandpower
KVM Switches, Serial Console Servers, Rackmount Monitors, Keyboards:
For additional information regarding KVM switches, Serial Console servers, rack mount monitors, keyboards and all related options please see the following URL:
http://www.hp.com/go/kvm
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.
http://www.hp.com/products/configurator
http://www.hp.com/go/factory-express
.
.
.
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 9
QuickSpecs
Standard Features
HP ProLiant ML310 Generation 5
Service and Support
HP Care Pack Services provide total care and support expertise with committed response times designed to meet your IT and business needs.
HP Care Pack services include coverage for the HP branded hardware options qualified for the server that are purchased at the same time or afterward and internal to the enclosure. It also includes the 22-inch and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of support solutions provides a range of support services designed to meet the varying needs of your business. Whether an SMB, or large global corporation, HP has ProLiant server support offers to help you speedily deploy and maximize system uptime.
Recommended Service
management.
Support Deployment Service
Enhanced Service
– 3-Year 9x5 Next Business Day coverage, excluding HP holidays only
– simplify ProLiant solution implementation, maintenance, and
– HW Installation only
– optimize service level to increase IT performance and availability.
Support Deployment Service
Refer to the information on the Installation of a ProLiant on the ProLiant Data Sheet; to be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.
NOTE:
http://www.hp.com/services/proliantservices http://www.hp.com/go/proliant/carepack
For a complete listing of service offerings and information visit:
– 3-Yyear 13x5 Same Business Day, 4-Hour response coverage only
– Installation and Start up only
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 10
QuickSpecs

Models

NOTE:
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
Models with SAS Support Standard
ML310T05 3210 HP SAS/SATA
445336-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drives
Internal Storage
Optical Drive
Diskette Drive
Power Supply
Form Factor
HP ProLiant ML310 Generation 5
Quad-Core Intel® Xeon® processor 3210 (2.13 GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
8MB L2
1 GB (1 x 1GB)
Embedded NC326i Gigabit Server Adapter
HP SC40Ge SAS HBA with RAID 0, 1 in a PCIe slot
None ship standard (up to 4 hot plug SAS or SATA 3.5" drives supported)
SAS: 1.2TB maximum; SATA: 3TB maximum
SATA DVD-ROM Drive
None ship standard (Optional 1.44 MB Diskette Drive available)
410W non-hot plug non-redundant power supply
Tower (5U) (Optional Tower to Rack Enabling Kit available, system & tray occupy 6U)
Models with SATA Support Standard
ML310T05 3065 HP SATA
445333-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drives
Internal Storage
Optical Drive
Diskette Drive
Power Supply
Form Factor
Dual-Core Intel® Xeon® processor 3065 (2.33 GHz, 4MB L2 Cache, 65 Watts, 1333MHz FSB)
4MB L2
512 MB (1 x 512 MB)
Embedded NC326i Gigabit Server Adapter
Embedded SATA with integrated SATA RAID 0, 1
None ship standard (Up to 4 hot plug SATA 3.5" drives supported standard. SAS 3.5" drives supported with optional HBA or controller)
SATA: 3 TB maximum; SAS: 1.2TB maximum
SATA DVD-ROM Drive
None ship standard (Optional 1.44 MB Diskette Drive)
410W non-hot plug non-redundant power supply
Tower (5U) (Optional Tower to Rack Enabling Kit available, system & tray occupy 6U)
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 11
QuickSpecs
Models
HP ProLiant ML310 Generation 5
ML310T05 3075 HP SATA
445334-xx1
ML310T05 E3110 HP SATA
460383-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drives
Internal Storage
Optical Drive
Diskette Drive
Power Supply
Form Factor
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drives
Internal Storage
Optical Drive
Diskette Drive
Power Supply
Form Factor
Dual-Core Intel® Xeon® processor 3075 (2.66GHz, 4MB L2 cache, 65 Watts, 1333MHz FSB)
4MB L2
512 MB (1 x 512 MB)
Embedded NC326i Gigabit Server Adapter
Embedded SATA with integrated SATA RAID 0, 1
None ship standard (Up to 4 hot plug SATA 3.5" drives supported standard. SAS 3.5" drives supported with optional HBA or controller)
SATA: 3 TB maximum; SAS: 1.2TB maximum
SATA DVD-ROM Drive
None ship standard (Optional 1.44 MB Diskette Drive available)
410W non-hot plug non-redundant power supply
Tower (5U) (Optional Tower to Rack Enabling Kit available, system & tray occupy 6U)
Dual-Core Intel® Xeon® processor E3110 (3.0GHz, 6MB L2 cache, 65 Watts, 1333MHz FSB)
6MB L2
1 GB (1 x 1 GB)
Embedded NC326i Gigabit Server Adapter
Embedded SATA with integrated SATA RAID 0, 1
None ship standard (Up to 4 hot plug SATA 3.5" drives supported standard. SAS 3.5" drives supported with optional HBA or controller)
SATA: 3 TB maximum; SAS: 1.2TB maximum
SATA DVD-ROM Drive
None ship standard (Optional 1.44 MB Diskette Drive available)
410W non-hot plug non-redundant power supply
Tower (5U) (Optional Tower to Rack Enabling Kit available, system & tray occupy 6U)
ML310T05 3210 HP SATA/SAS RPS
445335-xx1
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drives
Internal Storage
Optical Drive
Diskette Drive
Power Supply
Form Factor
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Quad-Core Intel® Xeon® processor 3210 (2.13 GHz, 8MB L2 Cache, 95 Watts, 1066MHz FSB)
8MB L2
1 GB (1 x 1 GB)
Embedded NC326i Gigabit Server Adapter
Embedded SATA with integrated SATA RAID 0, 1
None ship standard (Up to 4 hot plug SATA 3.5" drives supported standard. SAS 3.5" drives supported with optional HBA or controller)
SATA: 3 TB maximum; SAS: 1.2TB maximum
SATA DVD-ROM Drive
None ship standard (Optional 1.44 MB Diskette Drive available)
430W hot plug redundant power supplies
Tower (5U) (Optional Tower to Rack Enabling Kit available, system & tray occupy 6U)
Page 12
QuickSpecs
Models
HP ProLiant ML310 Generation 5
Country Code Key
XX=00
XX=01
XX=03
XX=04
XX=05
XX=29
XX=37
XX=42
NA
Australia
UK
Germany
France
Japan
AP
EURO
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 13
QuickSpecs
HP ProLiant ML310 Generation 5

Configuration Information - Factory Integrated Models

NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
NOTE:
start with a CTO Chassis.
NOTE: NOTE:
HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must
This product offering does not support HP Factory Express Server Configuration Level 1. FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration
Models
HP ProLiant ML310 G5 CTO Chassis
Factory Integrated Models ship with:
Embedded NC326i Gigabit Server Adapter
Integrated Four Port SATA Controller (HP-SATA/SAS chassis only)
Keyboard and Mouse
445343-B21
Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)
Processors
Base Memory
Optical Drive
Power Supply
HP C420 ML310G5 FIO Kit
HP E2160 ML310G5 FIO Kit
HP E3110 ML310G5 FIO Kit
HP E4600 ML310G5 FIO Kit
HP X3065 ML310G5 FIO Kit
HP X3075 ML310G5 FIO Kit
HP X3210 ML310G5 FIO Kit
HP X3220 ML310G5 FIO Kit
HP X3320 ML310G5 FIO Kit
HP X3350 ML310G5 FIO Kit
HP X3360 ML310G5 FIO Kit
2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB)
1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB)
512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB)
HP Half-Height SATA DVD-ROM Optical Drive
HP Half-Height SATA DVD RW Optical Drive
430W Hot-plug Redundant Power Supply, FIO
NOTE:
Hot plug redundant power supply (PN 431652-B21) ships with two power
supplies.
410W Non-hot-plug Power Supply, FIO
NOTE:
supply.
Non-hot plug power supply (PN 459902-B21) ships with one power
450134-L21
450133-L21
463430-L21
482108-L21
450130-L21
450131-L21
454631-L21
451245-L21
463428-L21
464790-L21
489907-L21
450260-B21
450259-B21
450258-B21
447326-B21
447328-B21
431652-B21
459902-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 14
QuickSpecs
HP ProLiant ML310 Generation 5
Configuration Information - Factory Integrated Models
Step 3: Choose Additional Factory Integratable Options
PCI-X Slot
SAS HBAs
Controllers
Modems
HP ML310 G5 PCI-X Extender Board Kit
HP SAS Cable ML310 G5
HP SC40Ge SAS HBA, FIO
NOTE:
RAID 0, 1.
HP SC44Ge Host Bus Adapter
NOTE:
RAID 0, 1.
NOTE:
SATA hot-plug capability are not supported with the embedded controller. For full LED and hot-plug support, an optional SAS RAID controller must be installed.
NOTE:
and full SATA hot-plug capability are not supported with the embedded controller. For full LED and hot-plug support, an optional SATA RAID or SAS controller must be installed. SAS Controllers support both SAS and SATA hard drives. Some SAS Controllers also have SAS tape support. Please refer to the "Tape Drives, Tape Autoloader & Tape Libraries" table in the Storage section for a list of SAS Controllers with tape support.
HP Smart Array E200/128 BBWC Controller
NOTE:
HP Smart Array P400/256MB Controller
NOTE:
HP Smart Array P400/512MB BBWC Controller
NOTE:
HP Smart Array E500/256MB Controller
NOTE:
HP Smart Array P800/512MB BBWC Controller
NOTE:
HP SAS Cable ML310 G5
NOTE:
ML310 G5 (460310-B21).
Agere 06 PCI Hi-Speed 56K SftMd, FIO
NOTE:
integration (or as an additional "ship along" option) choose EK694AA.
When SATA hard drives are installed, SATA LED functionality and full
When hot-plug SATA hard drives are installed, SATA LED functionality
RAID 0, 1, 1+0, 5.
RAID 0, 1, 1+0, 5.
RAID 0, 1, 1+0, 5, 6.
RAID 0, 1, 1+0 standard, 5 optional
RAID 0, 1, 1+0, 5, 6.
Any Smart Array Controller requires the purchase of the HP SAS Cable
This part number must be used for factory integration. For field
451778-B21
460310-B21
449176-B21
416096-B21
411508-B21
405132-B21
411064-B21
435129-B21
381513-B21
460310-B21
440519-B21
Step 4: Choose Additional Options for Factory Integration
NOTE:
For additional options, please refer to the "Options" section below.
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 15
QuickSpecs

Options

HP ProLiant ML310 Generation 5
NOTE:
information.
HP Insight Control Management Suites
Some options may not be factory integrated. Please contact your local sales representative for additional
NOTE:
software products. Please see the appropriate Insight Control QuickSpecs for additional information.
HP Insight Control Environment
HP Insight Control Environment, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates
NOTE:
licenses with a single activation key. Customer will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service. Only available directly from HP and select resellers in the Americas region.
HP Insight Control Management Software Media Kit
NOTE:
Insight Manager and Essentials software products and components licensed by Insight Control Management suites. Uses an integrated installer to perform quick and accurate software installation and updates.
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html
Electronic licensing options are available for Insight Control suites
This part number can be purchased as a single license or as multiple
Insight Control Management DVD media without licenses. Contains
For additional License Kits, please see the QuickSpecs at:
452148-B22
436222-B21
Server Management Stand Alone Software Product - ProLiant Essentials
NOTE:
software products. Please see the appropriate ProLiant Essentials QuickSpecs for additional information.
Deploy
HP Server Migration Pack - Universal Edition
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to ProLiant Single Migration License, including 1 year of 24x7 Technical Support and Updates
NOTE:
Customer will receive a printed license entitlement certificate and documentation via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to Virtual Single Migration License, including 1 year of 24x7 Technical Support and Updates
NOTE:
Customer will receive a printed license entitlement certificate and documentation via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
HP Server Migration Pack - Universal Edition, No Media, 1-Year Unlimited Migration License, including 1 year of 24x7 Technical Support
NOTE:
virtual, virtual to virtual, and virtual to ProLiant) for one year. Customer will receive a printed license entitlement certificate and documentation via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service.
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12855_div/12855_div.html
Electronic licensing options are available for select ProLiant Essentials
This license allows 1 physical to ProLiant or virtual to ProLiant migration.
This license allows 1 physical to virtual or virtual to virtual migration.
This license allows unlimited migrations (physical to ProLiant, physical to
For additional License Kits, please see the QuickSpecs at:
460750-B21
460753-B21
460756-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 16
QuickSpecs
Options
HP ProLiant ML310 Generation 5
Memory
(SDRAM DIMMs)
Optical Drives
Control
Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select Pack, No Media, 1-Server License
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html
Integrated Lights-Out Advanced Pack
Integrated Lights-Out Advanced Pack, No Media ,1 Server License
NOTE:
http://h18000.www1.hp.com/products/quickspecs/10861_div/10861_div.html
NOTE:
Essentials Value Packs. Refer to: or the various ProLiant Essentials QuickSpecs for more information.
2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB)
1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB)
512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB)
HP Half-Height SATA DVD-ROM Optical Drive
HP Half-Height SATA DVD RW Optical Drive
For additional License Kits, please see the QuickSpecs at
For additional License Kits, please see the QuickSpecs at:
Flexible and volume quantity license kits are available for ProLiant
http://www.hp.com/servers/proliantessentials
:
452158-B21
452141-B21
450260-B21
450259-B21
450258-B21
447326-B21
447328-B21
Diskette Drives
Serial / Parallel Port Kit
Hard Drives
1.44MB Diskette Drive Option Kit
HP ProLiant Second Serial /Parallel port option kit
Serial-Attached SCSI (SAS) Hot Plug Hard Drive
NOTE:
SAS HBA or array controller is required.
HP 300GB 3G SAS 15K 3.5" DP HDD
HP 300GB 3G SAS 15K 3.5" SP HDD
HP 146GB 3G SAS 15K 3.5" DP HDD
HP 146GB 3G SAS 15K 3.5" SP HDD
HP 72GB 3G SAS 15K 3.5" DP HDD
HP 72GB 3G SAS 15K 3.5" SP HDD
Serial-ATA (SATA) Hot Plug Hard Drive
HP 750GB 1.5G SATA 7.2K 3.5" HDD
HP 500GB 1.5G SATA 7.2K 3.5" HDD
HP 250GB 1.5G SATA 7.2K 3.5" HDD
HP 160GB 1.5G SATA 7.2K 3.5" HDD
HP 80GB 1.5G SATA 7.2K 3.5" HDD
NOTE:
SATA drives have a 1 year warranty. Please see the QuickSpecs for Technical Specifications such as capacity, height, width, interface, transfer rate, seek time, physical configuration, and operating temperature:
http://h18000.www1.hp.com/products/quickspecs/11940_div/11940_div.html
(Worldwide)
379257-B21
401222-B21
416127-B21
431944-B21
384854-B21
375872-B21
384852-B21
375870-B21
432341-B21
395473-B21
349239-B21
349238-B21
349237-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 17
QuickSpecs
Options
HP ProLiant ML310 Generation 5
PCI-X Slot
Storage Controllers
HP ML310 G5 PCI-X Extender Board Kit
NOTE:
included in the HP ML310 G5 PCI-X Extender Board Kit.
SAS Cable
NOTE: A SAS HBA or Controller is required if SAS hard drives are selected.
SAS HBAs support both SAS and SATA hard drives. Some SAS HBAs also have SAS tape support. Please refer to the "Tape Drives, Tape Autoloader & Tape Libraries" table in the Storage section for a list of SAS HBAs with tape support.
HP SAS Cable ML310 G5
NOTE:
SAS Cable ML310 G5 (460310-B21).
SAS Controllers
Smart Array E200 Controller
HP Smart Array E200/128 BBWC Controller
Smart Array E500 Controller
HP Smart Array E500/256MB Controller
Smart Array P400 Controller
HP Smart Array P400/256MB Controller
HP Smart Array P400/512MB BBWC Controller
Battery-backed write cache upgrade
NOTE:
512MB Battery-backed cache upgrade
NOTE:
Smart Array P800 Controller
HP Smart Array P800/512 BBWC Controller
NOTE:
additional information:
http://h18000.www1.hp.com/products/quickspecs/12460_div/12460_div.html
(Smart Array E200 Controller)
http://h18000.www1.hp.com/products/quickspecs/12700_div/12700_div.
(Smart Array E500 Controller)
http://h18000.www1.hp.com/products/quickspecs/12400_div/12400_div.
(Smart Array P400 Controller)
http://h18000.www1.hp.com/products/quickspecs/12616_div/12616_div.
(Smart Array P800 Controller)
SAS HBA
HP SC44Ge Host Bus Adapter
HP 8 Internal Port SAS HBA with RAID
NOTE:
http://h18004.www1.hp.com/products/quickspecs/12617_div/12617_div.html
(SC44Ge HBA)
http://h18004.www1.hp.com/products/quickspecs/12332_div/12332_div.html
(8 Internal Port SAS HBA)
SCSI Controllers for External Drive/Storage Support
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
NOTE:
customer must add either 374654-B21 or 412911-B21.
SCSI HBA
An additional fan is required with PCI-X Extender Board. This fan is
Any SAS HBA or Smart Array Controller requires the purchase of the HP
For Smart Array P400 Controller only.
For Smart Array P400 Controller only.
Please see the following QuickSpecs for Technical Specifications and
html
html
html
Please see the HBA QuickSpecs for additional information:
If a Non-Hot Plug SCSI Tape Drive is selected in any model, then
451778-B21
460310-B21
411508-B21
435129-B21
405132-B21
411064-B21
383280-B21
405148-B21
381513-B21
416096-B21
347786-B21
374654-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 18
QuickSpecs
Options
HP ProLiant ML310 Generation 5
Communications
Tape Drives
HP SC11Xe Host Bus Adapter
NOTE:
If a Non-Hot Plug SCSI Tape Drive is selected in any model, then customer must add either 374654-B21 or 412911-B21.
NOTE:
http://h18004.www1.hp.com/products/quickspecs/11943_div/11943_div.html
(SCSI HBA)
http://h18000.www1.hp.com/products/quickspecs/12566_div/12566_div.
(SC11Xe HBA)
HP NC110T PCI Express Gigabit Server Adapter
HP NC360T PCI Express Dual Port Gigabit Server Adapter
HP NC364T PCI Express Quad Port Gigabit Server Adapter
HP NC373F PCI Express Multifunction Gigabit Server Adapter
HP NC373T PCI Express Multifunction Gigabit Server Adapter
HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter
2006 Agere PCI high-speed international soft modem
NOTE:
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
USB Tape Drives
HP DAT 160 USB Internal Tape Drive
SAS Tape Drives
NOTE:
(416096-B21) for a dedicated SAS HBA for tape.
HP StorageWorks LTO-2 Ultrium 448 SAS Internal Tape Drive
HP LTO-3 Ultrium 920 SAS Internal Tape Drive
HP StorageWorks LTO-4 Ultrium 1760 SAS Internal Tape Drive
NOTE:
table in the Storage section of this document for a list of SAS controllers with tape support.
Ultrium Tape Drives
HP StorageWorks LTO-1 Ultrium 232 Internal Tape Drive (Carbonite)
HP StorageWorks LTO-2 Ultrium 448 SCSI Internal Tape Drive (Carbonite)
HP LTO-3 Ultrium 920 SCSI Internal Tape Drive
NOTE:
for additional options such as controllers, media, and other related items:
http://h18006.www1.hp.com/products/quickspecs/11739_div/11739_div.html
(Worldwide)
http://h18006.www1.hp.com/products/quickspecs/12128_div/12128_div.html
(Worldwide)
For an up-to-date listing of the latest O/S and software support details for HP Ultrium tape drives, please visit:
Rack-Mount Tape Drive Enclosures
HP StorageWorks 1U SCSI Rack-Mount kit
NOTE:
and is compatible with multiple Single-Ended and LVD SCSI tape drives including the DAT 40, DAT 72, DAT 160, LTO-1 Ultrium 232, LTO-2 Ultrium 448 and LTO-3 Ultrium 920 tape drives.
Please see the following QuickSpecs for additional information:
html
For the complete listing of Tape Drive offerings, please see:
For the ML310 G5, HP recommends purchasing the HP SC44Ge HBA
Please refer to the "Tape Drives, Tape Autoloaders & Tape Libraries"
Please see the HP StorageWorks LTO Ultrium Tape Drive QuickSpecs
http://www.hp.com/go/connect
TThe 1U Rack-Mount Kit can support up to (2) half-height tape drives
412911-B21
434905-B21
412648-B21
435508-B21
394793-B21
394791-B21
394795-B21
EK694AA
EH976A
DW085A
EH978A
EH919A
DW064A
DW016A
EH977A
A7445B
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 19
QuickSpecs
Options
HP ProLiant ML310 Generation 5
HP D2D Backup System
HP StorageWorks 1U USB Rack-Mount Kit
NOTE:
and is compatible with the DAT 40 USB, DAT 72 USB and DAT 160 tape drives.
HP StorageWorks 1U SAS Rack-Mount Kit
NOTE:
and is compatible with the DAT 160 SAS, LTO-2 Ultrium 448 SAS, LTO-3 Ultrium 920 SAS and LTO-4 Ultrium 1760 SAS tape drives.
HP StorageWorks 3U SCSI Rack-mount kit
NOTE:
tape drives and compatible with multiple LVD SCSI tape drives including DAT 40, DAT 72, LTO-1 Ultrium 232, LTO-2 Ultrium 448, LTO-3 Ultrium 920, LTO-3 Ultrium 960 and LTO-4 Ultrium 1840 tape drives.
NOTE:
information regarding these kits:
http://h18000.www1.hp.com/products/quickspecs/10854_div/10854_div.html
(Worldwide)
HP StorageWorks D2D110 Backup System
NOTE:
HP StorageWorks D2D110 Backup System with Data Protector Express Software Kit
NOTE:
HP StorageWorks D2D120 Backup System
NOTE:
HP StorageWorks D2D120 Backup System with Data Protector Express Software Kit
NOTE:
HP StorageWorks D2D130 Backup System
NOTE:
HP StorageWorks D2D130 Backup System with Data Protector Express Software Kit
NOTE:
HP StorageWorks D2D130 Backup System with LTO-3 Ultrium 920 SAS Tape Drive
NOTE:
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/12651_div/12651_div.html
(Worldwide)
The 1U USB Rack-Mount Kit can support up to (2) half-height tape drives
The 1U SAS Rack-Mount Kit can support up to (2) half-height tape drives
The 3U Rack-mount Kit can support up to (2) full-height or (4) half-height
Please see the Rack-Mount Tape Drive Kits QuickSpecs for additional
1TB of Disk Storage.
1TB of Disk Storage.
2TB of Disk Storage.
2TB of Disk Storage
3TB of Disk Storage.
3TB of Disk Storage.
3TB of Disk Storage.
Please see the HP D2D Backup Systems QuickSpecs for additional
.
A8007A
AE459A
274338-B22
EH880A
EH923A
EH884A
EH924A
EH950A
EH951A
EH952A
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 20
QuickSpecs
Options
HP ProLiant ML310 Generation 5
Tape Autoloaders
Tape Libraries
HP StorageWorks DAT Autoloader
HP StorageWorks DAT 72x10 tape autoloader
HP StorageWorks 1/8 Tape Autoloader
HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader
HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 Tape Autoloader
HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 SAS Autoloader
HP StorageWorks 1/8 G2 LTO-2 Ultrium 448 Tape Autoloader
HP StorageWorks 1/8 G2 LTO-1 Ultrium 232 Tape Autoloader
HP StorageWorks 1/8 G2 Tape Autoloader Rack Kit
NOTE:
includes rails and rackmount instructions
NOTE:
http://www.hp.com/go/automation
complete solution; reference current compatibility information at:
http://www.hp.com/go/ebs
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1840 SCSI Drive Library HP StorageWorks MSL2024 1 LTO-4 Ultrium 1840 4GB FC Library HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Drive Library HP StorageWorks MSL2024 1 LTO-3 Ultrium 960 SCSI Drive Library HP StorageWorks MSL2024 1 LTO-3 Ultrium 960 4GB FC Library HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SCSI Drive Library HP StorageWorks MSL2024 1 LTO-2 Ultrium 448 SCSI Drive Library
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 1 LTO-4 Ultrium 1840 SCSI Drive Library HP StorageWorks MSL4048 1 LTO-4 Ultrium 1840 4GB FC Library HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Drive Library HP StorageWorks MSL4048 1 LTO-3 Ultrium 960 SCSI Drive Library HP StorageWorks MSL4048 1 LTO-3 Ultrium 960 4GB FC Library HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SCSI Drive Library HP StorageWorks MSL4048 1 LTO-2 Ultrium 448 SCSI Drive Library
NOTE:
http://www.hp.com/go/automation
complete solution; reference current compatibility information at:
http://www.hp.com/go/ebs
Required to install the 1/8 G2 Autoloaders in a standard 19-inch rack;
Please reference the Tape Autoloader QuickSpecs at:
for additional information needed to create a
Please reference the MSL Tape Library QuickSpecs at:
for additional information needed to create a
.
AE313B
AK377A
AH165A
AH558A
AH164A
AH163A
AH166A
AJ033A AJ034A
AK378A AG115A AG326B
AH559A
AH169A AG116A
AJ035A AJ036A
AK380A AG322A AG324B
AH560A
AH171A AG320A
HP StorageWorks Modular Smart Array 60
HP StorageWorks 60 Modular Smart Array Enclosure
NOTE:
Please see the Modular Smart Array 60 QuickSpecs for additional information including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12627_div/12627_div.html
(Worldwide)
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
418408-B21
Page 21
QuickSpecs
Options
HP ProLiant ML310 Generation 5
HP StorageWorks Modular Smart Array 70
Uninterruptible Power Systems – Tower
HP StorageWorks 70 Modular Smart Array Enclosure
NOTE:
information including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12652_div/12652_div.html
(Worldwide)
HP T500 UPS 120 V (US)
HP T750 UPS, Low Voltage (NA/JPN)
HP T750 UPS, High Voltage (INTL)
HP, T1000 UPS NA
HP, T1000 UPS JPN
HP, T1000 UPS INTL
HP, T1500 UPS NA
HP, T1500 UPS JPN
HP, T1500 UPS INTL
HP, R/T 2200 UPS NA
HP, R/T 2200 UPS JPN
HP, R/T 2200 UPS INTL
Please see the Modular Smart Array 70 QuickSpecs for additional
418800-B21
361475-001
378439-D71
378439-B31
AF403A
AF404A
AF405A
AF406A
AF407A
AF408A
AF409A
AF410A
AF411A
Rack Kits
USB Options
ProLiant Rack Enabling Kit (RoHS Compliant)
NOTE:
ProLiant ML310 servers (system & tray occupy 6U).
NOTE:
Compaq and HP Rack System /E and HP Systems), with an adjustment range of 24" - 36".
HP USB-P/S2 Optical Mouse
USB 1.44-MB External Diskette Drive (Carbonite)
HP USB 04 Standard Keyboard
HP 1GB USB 2.0 Floppy Drive Key
HP 256MB USB 2.0 Floppy Drive Key
This is a Rack Enabling Kit that supports the HP ProLiant ML110 and HP
Support for racks with round or square mounting holes (including all
417705-B21
DC369A
DC141B
DT528A#ABA
442085-B21
442084-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 22
QuickSpecs
Options
HP ProLiant ML310 Generation 5
Service and Support Offerings
(HP Care Pack Services)
Hardware Services On-site Service
Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years, Electronic
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic
Installation & Start-up Services
Hardware Installation, Electronic
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic
Support Plus
Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic
Support Plus 24
Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
Onsite HW support 24x7, 4hr response and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
Onsite HW support 24x7, 4hr response and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
NOTE:
http://www.hp.com/services/carepack
For more information, customer/resellers can contact:
.
U4445E
U4446E
U4447E
U4448E
U4456E
U4457E
U4458E
U4459E
U6306E
U8328E
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 23
QuickSpecs

Memory

HP ProLiant ML310 Generation 5
NOTE:
HP ProLiant ML310 G5 Memory Configuration Standard Memory
All HP ProLiant ML310 G5 models ship with unbuffered, ECC PC2-6400 DDR2 SDRAM running at 800MHz. Dual-core models include a single 512 MB DIMM. Quad-core models include a single 1GB DIMM. Factory Integrated Models include the memory capacity of your choice.
Standard Memory Replaced with Optional Memory
Up to 8 GB memory is available with the optional installation of four 2 GB PC2-6400 Unbuffered ECC DDR2 SDRAM DIMM kits.
DIMM upgrades do not need to be installed in pairs although installation of pairs (an equal size DIMM for each channel) provides the best performance. The BIOS will detect the DIMM population and initialize the system accordingly as follows:
The first DIMM should be installed in Socket 1. A DIMM should not be installed in Socket 2 without a DIMM in Socket 1. Likewise a DIMM should not be installed in Socket 4 without a DIMM in Socket 3. A DIMM need not be installed in Socket 2 in order to install a DIMM in Socket 3.
Table 3-1 shows some of the suggested memory configurations for these systems.
NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
Single-channel mode – DIMMs installed for one channel only Dual-channel asymmetric mode – DIMMs installed for both channels but of unequal channel capacities. Dual-channel interleaved mode (recommended) – DIMMs installed for both channels and offering equal channel capacities, providing the highest performance.
Table 3-1 does not list all possible configurations. Balanced-capacity, dual-channel loading yields best performance.
Channel A Channel B
Socket 1 Socket 2 Socket 3 Socket 4
512 MB 512 MB
1 GB 1 GB
1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB 4 GB
1 GB 2 GB 1 GB 2 GB 6 GB
2 GB 2 GB 2 GB 2 GB 8 GB
none none none none
none none none none
512 MB
1 GB
none
none
none
Total
512 MB
1 GB
1 GB 2 GB
3 GB
Mode
Single-channel Single-channel
interleaved Single-channel Single-channel
interleaved
Dual-channel
asymmetric
Dual-channel
interleaved
Dual-channel
interleaved
Dual-channel
interleaved
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 24
QuickSpecs

Storage

Drive Support
Removable Media
1.44-MB Diskette Drive
HP Half-Height SATA DVD-ROM Optical Drive
HP Half-Height SATA DVD RW Optical Drive
Quantity
Supported
Up to 1
Up to 2
Up to 2
Position
Supported
A, B, or C
A, B, or C
A, B, or C
B, C
Removable Media Bays (1.6" each)
A
SATA DVD-ROM
1 - 4
Four Hot Plug Hard Drive Bays
Controller
Integrated
Integrated SATA
Integrated SATA
HP ProLiant ML310 Generation 5
Hard Drives
Hot Plug SAS
300GB 3G SAS 15K SP 300GB 3G SAS 15K DP 146GB 3G SAS 15K SP 146GB 3G SAS 15K DP 72GB 3G SAS 10K SP 72GB 3G SAS 15K DP
NOTE:
Use of SAS hard drives in SATA/SAS models requires installation of one of the controllers or HBAs listed above.
Quantity
Supported
Up to 4
Position
Supported
1-4
Controller
HP SC40Ge SAS HBA with RAID HP 8 Internal Port SAS HBA with RAID HP Smart Array E200/128 BBWC Controller HP Smart Array E500/256 MB Controller HP Smart Array P400/256 MB Controller HP Smart Array P400/512 MB BBWC Controller HP Smart Array P800/512 BBWC Controller
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 25
QuickSpecs
Storage
Hot Plug SATA
750GB 1.5G SATA 7.2K 500GB 1.5G SATA 7.2K 250GB 1.5G SATA 7.2K 160GB 1.5G SATA 7.2K 80GB 1.5G SATA 7.2K
NOTE:
Hot plug capability and drive LED status support requires installation of one of the controllers or HBAs listed above.
External Storage
Modular Smart Array 60 Enclosure
Modular Smart Array 70 Enclosure
Quantity
Supported
Up to 4
Quantity
Supported
Up to 8
Up to 4
Position
Supported
1-4
Position
Supported
External
External
HP ProLiant ML310 Generation 5
Controller
Embedded SATA with integrated SATA RAID 0,1 HP SC40Ge SAS HBA with RAID HP 8 Internal Port SAS HBA with RAID HP Smart Array E200/128 BBWC Controller HP Smart Array E500/256 MB Controller HP Smart Array P400/256 MB Controller HP Smart Array P400/512 MB BBWC Controller HP Smart Array P800/512 BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array E500/256 MB Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array E500/256 MB Controller
Tape Drives, Tape Autoloaders, Tape Libraries & D2D Backup
NOTE:
For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the following:
http://h18000.www1.hp.com/products/quickspecs/division/10233.html
NOTE:
below, please see the following:
NOTE:
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
NOTE:
with tape drive) deactivates 1 of the hard drive bays. Actual hard drive bay deactivated depends on where split cable plugs into SAS drive connector. Example: 3x SAS cable connector plugged into SAS drive connector (5-8) on the back of the hard drive cage would mean drive bay 8 is deactivated.
HP StorageWorks SCSI Tape Drives, Internal
LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 920 DAT 40 DAT 72 DAT 160
HP StorageWorks SCSI Tape Drives, Internal
LTO-3 Ultrium 960 LTO-4 Ultrium 1840
For an up-to-date listing of the latest O/S Support details for each of the Tape Autoloaders and Tape Libraries listed
http://h18000.www1.hp.com/products/quickspecs/division/10809.html
For complete listing of tape drive offerings see
SAS Tape Drives: Connecting hard drive cage and SAS tape to the same SAS Controller using split cable (supplied
Position
Supported
B,C
B+C
Controller
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
(Worldwide)
(Worldwide)
Controller/HBA
Option Kit Part
Number
374654-B21
374654-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 26
QuickSpecs
Storage
HP ProLiant ML310 Generation 5
HP StorageWorks SCSI Tape Drives, External
LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-3 Ultrium 960 LTO-4 Ultrium 1840 DAT 40 DAT 72 DAT 160 1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks USB Tape Drives, Internal
DAT 40 USB DAT 72 USB DAT 160 USB
HP StorageWorks USB Tape Drives, External
DAT 40 USB DAT 72 USB DAT 160 USB 1U USB Rack-Mount Kit
HP StorageWorks SAS Tape Drives, Internal
DAT160 SAS LTO-2 Ultrium 448 SAS LTO-3 Ultrium 920 SAS LTO-4 Ultrium 1760 SAS
Internal
B,C
External
Internal
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
USB 2.0 Port on motherboard
USB 2.0 Port
HP SC44Ge Host Bus Adapter
NOTE:
Recommended.
374654-B21
N/A
N/A
416096-B21
HP StorageWorks SAS Tape Drives, External
DAT 160 SAS LTO-2 Ultrium 448 SAS LTO-3 Ultrium 920 SAS LTO-4 Ultrium 1760 SAS LTO-4 Ultrium 1840 SAS 1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks SCSI Tape Automation, External
DAT 72x10 Autoloader 1/8 G2 Autoloader MSL2024 MSL4048 MSL8096 MSL6000
HP StorageWorks SAS Tape Automation, External
1/8 G2 Autoloader
External
External
External
HP SC44Ge Host Bus Adapter
NOTE:
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
HP U320e SCSI Host Bus Adapter
NOTE:
HP SC44Ge Host Bus Adapter
NOTE:
about minimum SAS controller firmware version and SAS cabling requirements.
Recommended.
Recommended for MSL tape libraries.
Please visit:
http://www.hp.com/go/connect
for details
416096-B21
374654-B21
AH627A
416096-B21
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 27
QuickSpecs
HP ProLiant ML310 Generation 5
Storage
MSL2024 MSL4048 MSL8096
HP StorageWorks Fibre Tape Automation, External
MSL2024 MSL4048 MSL6000
HP StorageWorks D2D Backup Systems
D2D110 D2D120 D2D130
External
External
Please consult the EBS connectivity matrix at:
http://www.hp.com/go/ebs
Embedded Network Controller
for detailed connectivity information.
N/A
N/A
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 28
QuickSpecs

Technical Specifications

HP ProLiant ML310 Generation 5
System Unit
Dimensions
(with bezel)
Tower Weight
(approximate)
Input Requirements
(per power supply)
BTU Rating
Power Specifications
Power Supply Output
(per power supply)
System Inlet Temperature
Relative Humidity
(non-condensing)
Altitude
(H x W x D)
17.0 x 7.9 x 24.0 in (43.2 x 20.0 x 61.0 cm)
Maximum (two hard drives, power supply, and processor installed)
Minimum (one hard drive, power supply, and processor installed)
Rated Line Voltage
Rated Input Current
Rated Input Frequency
Rated Input Power
Maximum
To review typical system power ratings use the Power Calculator which is available via the online tool located at URL:
http://h30099.www3.hp.com/configurator/calc/ Power%20Calculator%20Catalog.xls
- Click on the system of interest. Example: ML310 G5
- Follow the instructions of the next screens.
Rated Steady-State Power
Maximum Peak Power
Operating
Non-operating
Operating
Non-operating
Operating
50 lb (22.7 kg)
33.1 lb (15.0 kg)
90 VAC – 264 VAC
6.5 A (at 100 VAC), 3 A (at 230 VAC)
47 to 63 Hz
<527W @115/230 VRMS
1836 BTU/hr (at 100 VAC), 1706 BTU/hr (at 200 VAC)
400 W (at 100 VAC), 400 W (at 200 VAC)
400 W (at 100 VAC), 400 W (at 200 VAC)
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed. System performance may be reduced if operating with a fan fault or above 30°C (86°F).
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non­condensing.
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing.
3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 29
QuickSpecs
Technical Specifications
HP ProLiant ML310 Generation 5
HP SATA DVD-ROM Optical Drive
Acoustic Noise
Applicable Disk
Capacity
Block Size
Diameter
Loading Mechanism
Interface
Non-operating
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA
74) and declared in accordance with ISO 9296 (ECMA 109).
Idle
L
WAd (BELS)
L
pAm (dBA)
Operating
L
WAd (BELS)
L
pAm (dBA)
DVD-ROM
DVD-R /-RW (Read Only) DVD+R /+RW (Read Only)
2.6 GB/side DVD-RAM (Read Only)
5.2 GB/side DVD-RAM (Read Only)
CD-ROM Mode-1 data disc
CD-ROM Mode-2 data disc
CD Audio disc
CD-Extra
CD-RW (Read Only)
CD-R (Read Only)
CD Text
PhotoCD
CD-I (mode 2)
CD-I Ready
CD-Bridge
DVD-ROM
DVD-R/-RW
DVD-RAM
DVD+R/+RW
CD-ROM
DVD CD
120 mm, 80 mm (with adapter at vertical mounting mode)
Tray type Auto Loading
SATA 1.5
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
5.0 B
32 dBA
5.0 B
32 dBA
DVD-SL
DVD-DL
Double Sided
Mode-1
Mode-2
4.7 GB/side
8.5 GB/side
9.40 GB/side
4.7 GB/side
2.6 GB/5.2 GB/side
4.7 GB
650 (700 MB)
742 MB (640 MB)
2,048 bytes 2,352 (Mode-0) 2352, 2340, 2336, 2048 bytes (Mode-1) 2352, 2340, 2336, 2048 bytes (Mode-2)
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 30
QuickSpecs
Technical Specifications
HP ProLiant ML310 Generation 5
HP SC40Ge SAS Host Bus Adapter with RAID
Access Times
Data Transfer Rate
(sustained)
Cache Buffer
Spin-up Time
MTBF
Ambient Temperature
Relative Humidity
Drive Dimensions
(HxWxD, maximum)
RAID Support
Logical Drives Supported
Maximum Capacity
Data Transfer Method
Port Transfer Rate
Simultaneous Drive Transfer Ports
Protocols
External SAS Connectors
Internal SAS Connectors
Upgradeable Firmware
(typical)
(typical)
Random
Full-Stroke
DVD-ROM
CD-ROM
2 MB
less than 10 seconds
125,000 Power On Hours (POH)
Operating
Storage/Transportation
Operating
Storage/Transportation
1.62 x 5.75 x 7.87 in (41.3 x 146 x 200 mm)
RAID 1 (Mirroring) RAID 0 (Striping)
Up to 2 Logical Volumes Up to 10 drives total in all RAID volumes Up to 2 Drives per RAID 1 Up to 8 Drives per RAID 0
576GB (8 x 72GB)
64-bit wide, PCI-X 133 MHz (1 GB/s maximum bandwidth)
12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
2 x4 Wide SAS Connectors
3 Gbps SAS (Serial Attached SCSI)
1.5 Gbps SATA (Serial Advanced Technology Attachment)
None
2 internal SFF8484 x4 SAS Connectors
4MB flashable ROM
DVD-ROM < 140 ms, CD-ROM < 125 ms
DVD-ROM < 250 ms, CD-ROM < 210 ms
21.6 MB/sec. Max.
6 MB/sec. Max.
41° to 122° F (5° to 50° C)
-40° to 120° F (-40° to 60° C)
10% to 90%
5% to 95%
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 31
QuickSpecs
Technical Specifications
HP ProLiant ML310 Generation 5
Embedded NC326i Gigabit Server Adapter
Environment-friendly Products and Approach
Network Interface
Compatibility
Data Transfer Method
Network Transfer Rate
Connector
Cable Support
End-of-life Management and Recycling
10Base-T/100Base-TX/1000Base-TX
IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
Four lane (x4), 100MHz PCI Express Reference Clock
10Base-T (Half-Duplex)
10Base-T (Full-Duplex)
100Base-TX (Half­Duplex)
100Base-TX (Full­Duplex)
1000Base-TX (Half and Full-Duplex)
RJ-45
10Base-T
10/100/1000Base-TX
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
http://www.hp.com/go/green
http://www.hp.com/go/green
10 Mb/s
20 Mb/s
100 Mb/s
200 Mb/s
2000Mb/s
Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
Category 5 UTP; up to 328 ft (100 m)
. To recycle your product,
or contact your nearest HP
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
© Copyright 2008 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation.
Intel, the Intel logo, Xeon and Xeon Inside are trademarks of Intel Corporation in the U.S. and other countries.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
http://www.hp.com/go/green
. These
DA - 12858 Worldwide QuickSpecs — Version 17 — 6.10.2008
Page 32
Loading...
