HP M430f Data sheet

Data sheet
HP LaserJet Enterprise MFP M430f
HPs entry-level Enterprise-class MFP with speeds up to 40 ppm and strongest security.
Easy to use, simple to manage
HP FutureSmart firmware can be updated with the latest features to optimize your investment for years to come. Centralize control of your printing environment with HP Web Jetadmin—and help build business efficiency. Easily enable workflows across your fleet with a consistent user experience and intuitive, tablet-like icons. Set up this MFP fast, and easily manage device settings to help increase efficiency.
The operating code (BIOS) is automatically checked duringstartupand repairs itself if compromised. Common Criteriacertified to continually monitor memory activity to detect and stop attacks in real time. Firmware is automatically checked duringstartupto determine if it’s authentic code—digitally signed by HP. The printer’s outgoing network connections are inspected to stop suspicious requests and thwart malware.
Enhanced productivity to empower work teams
Give workgroups what they need to succeed with hundreds of HP and third-party solutions and card reader support. Optimize workflows,reduce steps and errors, and support mobile workers with optional MFP apps that meet your specific business needs. Help ensure the security of confidential information with PIN/Pull printing to retrieve print jobs. Stay connected with an optional accessory for wireless, Bluetooth® Low Energy, and NFC touch-to-print.
Sustainability is smart business
Help save paper right out of the box. Two-sided (duplex) printing is set at default for automatic savings. Help reduce wasted paper and toner by only printing jobs that are truly needed, using HP Roam for Business. , Save energy without sacrificing performance—this MFP is ENERGY STAR® and Blue Angel certified. Leverage HP End of Life Solutions to ensure your Hardware and Supplies are sustainably retired.
This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges. More at: Learn more at http://www.hp.com/learn/ds
9 1
2
3
1
4
6
7
8
Data sheet | HP LaserJet Enterprise MFP M430f
Technical specifications
Product name HP LaserJet Enterprise MFP M430f Product number 3PZ55A Functions Print, copy, scan, fax Print Duplex printing Automatic (default)
Print speed
Black (A4, normal) Up to 38 ppm (default); Up to 40 ppm (HP high speed mode); Black (A4, duplex): Up to 31 ipm; Black (letter, normal): Up to 40 ppm (default); Up to 42 ppm (HP high speed
mode); Black (letter, duplex): Up to 33 ipm; First page out Black (A4, ready): As fast as 6.5 sec; Black (A4, sleep): As fast as 8.8 sec Print technology Laser Print resolution Black (best): Up to 1200 x 1200 dpi; Black (normal): Up to 600 x 600 dpi Print resolution technology 300 dpi, 600 dpi, HP FastRes 1200, HP ProRes 1200 Print cartridges number 1 (black) Standard print languages HP PCL 6, HP PCL 5, HP PostScript level 3 emulation, native PDF printing (v 1.7), Apple AirPrint™
Printer management
HP Printer Assistant, HP Web JetAdmin Software, HP JetAdvantage Security Manager, HP SNMP Proxy Agent (Part of HP WebJetAdmin), HP WS Pro Proxy Agent (Part of HP WebJetAdmin), Printer
Administrator Resource Kit for HP Universal Print Driver (Driver Configuration Utility - Driver Deployment Utility - Managed Printing Administrator); Scan Scan speed Normal (A4): Up to 29 ppm/46 ipm (b&w), up to 20 ppm/35 ipm (color); Duplex (A4): Up to 46 ipm (b&w), up to 35 ipm (color)
Scanner specifications
Scanner type Flatbed, ADF; Scan technology: Contact Image Sensor (CIS); Duplex ADF scanning: Yes, single pass duplexing ADF; Scan size maximum (ADF): 216 x 356 mm; Scan size maximum
(flatbed): 216 x 297 mm; Optical scan resolution: Up to 600 dpi; Enhanced Scan Resolution: Up to 600 dpi; Hardware resolution: Up to 600 x 600 dpi
Scanner advanced features
Optimize text/picture; Image adjustments; Job build; Output quality setting; Selectable scan resolution 75 to 600 dpi; Auto detect color; Edge Erase; Job notification; Blank page suppression; HP
Quick Sets Copy Copy speed Black (A4, normal): Up to 38 cpm; Black (letter, normal): Up to 40 cpm; Black (A4, duplex): Up to 31 cpm; Black (letter, duplex): Up to 33 cpm First copy out Black (A4, ready): As fast as 7.2 sec; Black (A4, sleep): As fast as 9.5 sec; Black (letter, ready): As fast as 6.8 sec Fax Fax speed 33.6 kbps (maximum); 14.4 kbps (default) / 3 sec per page
Fax specifications
Fax memory: Dependent on the amount of available disk space; Fax resolution: Up to 300 x 300 dpi; Auto fax reduction supported: Yes; Auto-redialing: Yes; Fax delayed sending: No; Distinctive
ring detection supported: No; Fax forwarding supported: Yes; Junk barrier supported: Yes, as blocked fax numbers; Maximum speed dialing numbers: Up to 1000 numbers; PC interface
supported: Yes, software not included; Fax polling supported: Yes (poll to receive only) Fax smart software features Stored faxes; Fax archiving; Fax forwarding; Scale to fit; Fax address book; LAN/Internet fax; Fax number confirmation; Holiday fax schedule Connectivity Standard connectivity 2 Hi-Speed USB 2.0 Host; 1 Hi-Speed USB 2.0 Device; 1 Gigabit Ethernet 10/100/1000T network; 1 Fax Mobile printing capability HP ePrint; Apple AirPrint™; Mopria™ Certified; Wi-Fi® Direct Printing; NFC Touch-to-print (optional); Roam capable for easy printing; PrinterOn Print
Wireless capability
Optional, enabled with purchase of a wireless hardware accessory. Dual band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3100w BLE/NFC/Wireless Accessory
3JN69A
Network capabilities
Yes, via HP Jetdirect Ethernet embedded print server (standard) which supports: 10Base-T, 100Base-Tx, 1000Base-T; 802.3az (EEE) support on Fast Ethernet and Gig Links; IPsec (standard);
802.11a/b/g/n wireless networking (Optional); second Ethernet port (Optional). Memory Standard: 2 GB; Maximum: 2 GB Storage capacity 16 GB eMMC Hard disk Not available on this product Processor speed 800 MHz Warm-up time 180 sec Paper handling Duty cycle (monthly) Duty cycle (monthly, A4): Up to 100,000 pages; Recommended monthly page volume: 900 to 4,800 Pages Input capacity 100-sheet tray 1, 250-sheet input tray 2; 50-sheet Automatic Document Feeder (ADF); Optional third 550-sheet tray Output capacity 150-sheet output bin Number of paper trays Standard: 2; Maximum: 3 Media types Paper (plain, ecoefficient, light, heavy, bond, colored, letterhead, pre-printed, pre-punched, recycled, rough); envelopes; labels Media weight Tray 1: 60 to 175 g/m²; tray 2, optional 550-sheet tray 3: 60 to 120 g/m²
Media size
Custom (metric): Tray 1: 76 x 127 to 216 x 356 mm; Tray 2: 105 x 148 to 216 x 356mm; Optional Tray: 105x 148 to 216 x 356 mm; Supported (metric): Tray 1: A4, RA4, A5, B5 (JIS), B6 (JIS), 10 x 15 cm, A6, 16K, envelopes (B5, C5 ISO, C6, DL ISO); Custom: 76 x 127 to 216 x 356 mm; Tray 2:A4; RA4;A5; B5 (JIS); B6 (JIS); A6; 16K; 105 x 148 to 216 x 356 mm; Optional Tray 3:A4;
RA4;A5; B5 (JIS); B6 (JIS); A6; 16K; 105 x 148 to 216 x 356 mm; ADF: letter; legal; oficio; executive; statement; A4; RA4; A5;B5; 5 x 7 in; 5 x 8 in Printer dimensions (W x D x H) 420 x 390 x 323 mm Printer weight 13.01 kg Software included No software solutions are included in the Box only on http://hp.com or http://123.hp.com What's in the box HP LaserJet Enterprise MFP M430f printer; HP Black Original LaserJet Toner Cartridge (~3,000 pages); Getting started Guide; 1 Power cord Warranty One-year, On-site Repair 24-hour / 7 day a week phone support Systems
Compatible operating systems
Windows Client OS (32/64 bit)-, Win10, Win8.1, Win7 Ultimate, Mobile OS-, iOS, Android, Mac-, Apple® MacOS High Sierra v10.13, Apple® MacOS Mojave v10.14, Apple® MacOS Catalina v10.15,
Discrete PCL6 Printer Driver-, For more information on the supported operating systems go to http://support.hp.com, Enter your product name and search, Click on User Guides and enter your
product name and search for User Guide, Search for your (Product Name) - User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers, Supported Operating
systems, For more information on the supported operating systems see www.hp.com/go/upd
Minimum system requirements
Windows: 2 GB available hard disk space Internet connection or USB port Internet browser. For additional OS hardware requirements see microsoft.com; Mac: 2 GB available hard drive space
Internet connection or USB port Internet browser. For additional OS hardware requirements see apple.com
Security management
Identity management: Kerberos authentication, LDAP authentication, 1000 user PIN codes, Optional HP and 3rd party advanced authentication solutions (e.g., badge readers); Network:
IPsec/firewall with Certificate, Pre-shared Key, Kerberos authentication, Supports WJA-10 IPsec configuration Plug-in, 802.1X authentication (EAP-PEAP; EAP-TLS), SNMPv3, HTTPS, Certificates,
Access Control List; Data: Storage Encryption, Encrypted PDF & Email (uses FIPS 140 validated cryptographic libraries from Microsoft), SSL/TLS (HTTPS), Encrypted Credentials; Device: HP Sure
Start Secure Boot (BIOS Integrity Checking with self-healing capability), Intrusion Detection (Constant in-device monitoring for attacks), Whitelisting (loads only known good code), Embedded
Trusted Platform Module, HP Connection Inspector, Security lock slot, USB port disablement; Security management: Compatible with HP JetAdvantage Security Manager, Device Security Syslog
Messages processed and accessible in Arcsight and Splunk SIEMs
Fonts and typefaces
105 internal TrueType fonts scalable in HP PCL, 92 internal scalable fonts in HP PostScript Level 3 emulation (Euro symbol built-in); 1 internal Unicode Fonts (Andale Mono World Type); 2
Internal Windows Vista 8 Fonts (Calibri, Cambria);additional font solutions available via third-party flash memory cards; HP LaserJet Fonts and IPDS Emulation available at
Http://www.hp.com/go/laserjetfonts Control panel 4.3” Color Capacitive Touch Control Panel Display 4.3” diagonal Color TFT-LCD back-lit 480 RGB (H) x 272 (V)
Power
Requirements: 110-volt input voltage: 110 to 127 VAC (+/- 10%), 60 Hz (+/- 3 Hz); 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50/60Hz (+/- 3 Hz) (Not dual voltage, power supply varies
by part number with # Option code identifier); Consumption: 525 watts (active printing), 10.1 watts (ready), 1.2 watts (sleep), 0.08 watts (auto-off/manual-on), 0.08 watts (manual off); Typical
Electricity Consumption (TEC) : 1.222 kWh/week (Blue Angel); 0.463 kWh/week (Energy Star 3.0); Power supply type: Internal (Built-in) power supply
Operating environment
Operating temperature range: 15 to 32.5°C; Recommended operating temperature range: 15 to 27°C
Operating humidity range: 10 to 90% RH; Recommended operating humidity range: 30 to 70% RH Ecolabels EPEAT® Silver; CECP; ENERGY STAR® certified Sustainable impact specifications Mercury-free
Acoustics
Acoustic power emissions: 6.4 B(A) @ 38 ipm; Acoustic power emissions (ready): Inaudible; Acoustic pressure emissions: 54 dB(A) @ 38 ipm; Acoustic pressure emissions bystander (ready):
Inaudible
Safety approvals and requirements
IEC 60950-1:2005 +A1:2009 +A2:2013 (International); EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 (EU); EN 60825-1:2014/IEC 60825-1:2014 (Class 1 Laser Product); EN
62479:2010/IEC 62479:2010; IEC 62471:2006 / EN 62471:2008;IEC 62368-1:2014;EN 62368-1:2014Low Voltage Directive 2014/35/EU with CE Mark (Europe); GS Certificate (Germany,
Europe); UL/cUL Listed and UC CoC (US/Canada); CAN/CSA C22.2 No. 60950-1-07 2nd Ed. 2011-12; Compliance with Laser safety standards 21 CFR 1040.10 and 1040.11 except for deviations
pursuant to Laser notice No. 50, Dated June 24, 2007; Other safety approvals as required by individual countries.
Supported network protocols
Via built-in networking solution: TCP/IP, IPv4, IPv6; Print: TCP-IP port 9100 Direct Mode, LPD, Web Services Printing, IPP 2.0, Apple AirPrint™, HP ePrint; Discovery: SLP, Bonjour, Web Services
Discovery; IP Config: IPv4 (BootP, DHCP, AutoIP, Manual), IPv6 (Stateless Link-Local and via Router, Statefull via DHCPv6); Management: SNMPv2/v3, HTTP/HTTPS, Syslog; Security: SNMPv3, SSL
Cert Management, IPSec(IKEv1 and IKEv2), Firewall, 802.1x
8
9
12
6
5
1
11
4
Data sheet | HP LaserJet Enterprise MFP M430f
Ordering information
Accessories
Number Description 3JN69A HP Jetdirect 3100w BLE/NFC/Wireless Accessory 4QL32A HP Legic Secure USB Reader 8FP31A HP Jetdirect LAN Accessory 8ZN00A HP HIP2 Card Reader Accessory Kit B5L31A HP Foreign Interface Harness D9P29A HP LaserJet Pro 550-sheet Feeder Tray X3D03A HP Universal USB Proximity Card Reader Y7C05A HP HIP2 Keystroke Reader
Supplies and Media
Number Description 4WM80A HP CHP113 Office Paper-2500 sht/A4/210 x 297 mm 4WM81A HP CHP150 Home and Office Paper-500 sht/A4/210 x 297 mm 4WM82A HP CHP650 Everyday Paper 75 gsm-500 sht/A4/210 x 297 mm 4WM83A HP CHP755 Color Choice Paper 200 gsm-250 sht/A4/210 x 297 mm 4WM84A HP CHP855 Premium Paper 80 gsm-250 sht/A4/210 x 297 mm 4WM85A HP CHP910 Copy Paper 80 gsm-500 sht/A4/210 x 297 mm 4WN07A HP Everyday Laser Glossy FSC Paper 120 gsm-150 sht/Tabloid/11 x 17 in 4WN08A HP Everyday Laser Glossy FSC Paper 120 gsm-150 sht/Letter 8.5 x 11 in 7MV81A HP Everyday Laser Glossy FSC Paper 120 gsm-150 sht/A3/297 x 420 mm 7MV82A HP Everyday Laser Glossy FSC Paper 120 gsm-150 sht/A4/210 x 297 mm CF276A HP 76A Black Original LaserJet Toner Cartridge (~3,000 pages) CF276X HP 76X High Yield Black Original LaserJet Toner Cartridge (~10,000 pages)
Contact HP via phone: Asia: 65 6253 8500
HP Care Packs
Number Description U11D7E HP 3 year Next Business Day Service for LaserJet Enterprise MFP M43x U11D8E HP 4 year Next Business Day Service for LaserJet Enterprise MFP M43x U11D9E HP 5 year Next Business Day Service for LaserJet Enterprise MFP M43x U11DBE HP 3 year 4 hour 9x5 Service for LaserJet Enterprise MFP M43x U11DCE HP 4 year 4 hour 9x5 Service for LaserJet Enterprise MFP M43x U11DDE HP 5 year 4 hour 9x5 Service for LaserJet Enterprise MFP M43x
U11DME
HP 3 year Parts Exchange Service for LaserJet Enterprise MFP M43x (Managed Component Only)
U11DNE
HP 4 year Parts Exchange Service for LaserJet Enterprise MFP M43x (Managed Component Only)
U11DQE
HP 5 year Parts Exchange Service for LaserJet Enterprise MFP M43x (Managed Component
Only) U11DRPE HP 1 year Post Warranty Next Business Day Service for LaserJet Enterprise MFP M43x U11DSPE HP 2 year Post Warranty Next Business Day Service for LaserJet Enterprise MFP M43x U11DTPE HP 1 year Post Warranty 4 hour 9x5 Service for LaserJet Enterprise MFP M43x U11DVPE HP 2 year Post Warranty 4 hour 9x5 Service for LaserJet Enterprise MFP M43x
U11DZPE
HP 1 year Post Wty Parts Exchange Service for LaserJet Enterprise MFP M43x (Managed
Component Only)
U11E0PE
HP 2 year Post Wty Parts Exchange Service for LaserJet Enterprise MFP M43x (Managed
Component Only)
Protect your investment with HP Care Pack. Let HP certified engineers resolve your technical issues. For more details on HP Care Pack, go to hp.com/go/cpc
HP Inc. offices
Australia 13 10 47 hp.com.au China (010) 6564 3888 hp.com.cn Hong Kong (852) 3077 2688 hp.com.hk India (80) 2612 9000 hp.com/in Indonesia (62-21) 5799 1088 hp.com/idw Korea (02) 2199 0114 hp.co.kr Malaysia (603) 2332 3333 hp.com.my New Zealand (09) 0800 449 553 hp.co.nz Philippines (632) 888 5900 hp.com/ph Singapore (65) 6275 3888 hp.com.sg Taiwan (02) 3789 9900 hp.com.tw Thailand (662) 353 9500 hp.com/th Vietnam (848) 3823 4151 hp.com/vn
Solutions
For more solutions information, please visit hp.com/go/gsc
Footnotes
HP’s most advanced embedded security features are available on HP Managed and Enterprise devices with HP FutureSmart firmware 4.5 or above. Claim based on HP review of 2019 published features of competitive in-class printers. Only HP offers a combination of security features to automatically detect, stop, and recover from attacks with a self-healing reboot, in alignment with NIST SP 800-193 guidelines for device cyber resiliency. For a list of compatible products, visit hp.com/go/PrintersThatProtect. For more information, visit hp.com/go/PrinterSecurityClaims
Some features enabled by future HP FutureSmart firmware upgrades may not be available on older devices, if forexample, physical product characteristics limit the functionality of the new feature.
HP Web Jetadmin is free and available for download at hp.com/go/webjetadmin
Third-party certification based on Common Criteria Information Technology Security Evaluation ISO/IEC 15408 Standard requirements as of May 2019. Certification applicable to HP Managed and Enterprise devices running HP FutureSmart Firmware version 4.5.1 and later. For more information: https://www.commoncriteriaportal.org/files/epfiles/Certification%20Report%20-%20HP%20Intrusion%20Detection.pdf
Use of the HP Trusted Platform Module may require a firmware upgrade.
Wireless performance is dependent on physical environment and distance from access point and may be limited during active VPN connections.
Dependent upon country setup specifications.
To enable HP Roam, some devices may require firmware to be upgraded and an optional accessory to addBluetooth® Low Energy (BLE) beaconing capabilities. Subscription may be required. For more information, visit hp.com/go/roam
Measured using ISO/IEC 24734, excludes first set of test documents. For more information, see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Technical specifications disclaimers
For yield information on the cartridge included with your printer, see http://www.hp.com/go/toneryield. Yield values measured in accordance with ISO/IEC 19752 and continuous printing. Actual yields vary considerably based on images printed and other factors.
Declared yields based on ISO/IEC 19752 and continuous printing. Actual yields vary considerably based on images printed and other factors. For details see http://www.hp.com/go/toneryield
Declared yield value in accordance with ISO/IEC 19752. Actual yields vary considerably based on images printed and other factors. For more information, visit: http://www.hp.com/go/learnaboutsupplies
EPEAT® registered where applicable. EPEAT registration varies by country. See http://ww w.epeat.net for registration status by country.
To enable HP Roam, some devices may require firmware to be upgraded and an optional accessory to add Bluetooth® Low Energy (BLE) beaconing capabilities. Customer can purchase the HP Jetdirect 3100w BLE/NFC/Wireless accessory or the RadBeacon USB. Subscription may be required. For more information, visit http://www.hp.com/go/roam
Based on standard ITU-T test image #1 at standard resolution. More complicated pages or higher resolution will take longer and use more memory.
Measured using ISO/IEC 24734 Feature Performance Test, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Measured using ISO/IEC 24734, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
First Copy Out from Ready and Simplex Copy Speed measured using ISO/IEC 29183, Duplex Copy Speed measured using ISO/IEC 24735, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, document complexity, media size, media orientation and media type.
Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Energy Star value typically based on measurement of 115V
device and 230V for Blue Angel.
Sample Data: Typical Electricity Consumption (TEC) rating represents the typical electricity consumed by a product during 1 week, measured in kilowatt-hours (kWh). Scan speeds measured from ADF. Actual processing speeds may vary depending on scan resolution, network conditions, computer performance, and application software.
To learn more, visit hp.com
© Copyright 2021 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
ap-en July 2021
