Data sheet | HP LaserJet Pro MFP M428 series
Model HP LaserJet Pro MFP M428fdn HP LaserJet Pro MFP M428fdw
Product number W1A29A W1A30A
Compatible network operating systems
Windows Server 2008 R2 64-bit, Windows Server 2008 R2 64-bit (SP1), Windows Server 2012 64-bit, Windows Server 2012 R2 64-bit, Windows
Server 2016 64-bit, Failover Cluster 2008 R2, Failover Cluster 2012 R2, Terminal server 2008 R2, Remote Desktop server 2012 R2, Citrix Server 6.5,
Citrix XenApp & XenDesktop 7.6, Novell iPrint server, Citrix Ready Kit Certification - up to Citrix Server 7.18 for more information see
http://www.citrixready.citrix.com, Linux - for more information see http://www.developers.hp.com/hp-linux-imaging-and-printing, Unix - for more
information see http://www.hp.com/go/unixmodelscripts, UPD PCL6 / PS Printer Drivers, Supported for Compatible Network Operating systems
please see http://www.hp.com/go/upd
Minimum system requirements
Windows: 2 GB available hard disk space, Internet connection, USB port, Internet browser, for additional OS hardware requirements see
http://www.microsoft.com;
Mac: 2 GB available hard disk space, Internet connection or USB port, for additional OS hardware requirements see http://www.apple.com
Software included No software solutions are included in the Box, only on http://www.hp.com, http://www.123.hp.com/laserjet
Security management
Secure Boot, Secure Firmware Integrity, Runtime Code Integrity, password
protected EWS, secure browsing via SSL/TLS 1.0, TLS 1.1, TLS 1.2, IPP
over TLS; Network: enable/disable network ports and features, unused
protocol and service disablement, SNMPv1, SNMPv2, and SNMPv3,
community password change; HP ePrint: HTTPS with certificate validation,
HTTP Basic Access Authentication, SASL authentication, LDAP
authentication and authorization, firewall and ACL, control panel lock,
certificates configuration, UPD PIN printing, Syslog, signed firmware,
administrator settings, access control, 802.1x authentication (EAP-TLS,
and PEAP), Encrypted data storage, Secure data erase, automatic
firmware updates, Secure Encrypted Print via optional job storage,
compatible with optional HP JetAdvantage Security Manager
Secure Boot, secure firmware integrity, runtime code integrity, password
protect EWS, secure browsing via SSL/TLS 1.0, TLS 1.1, TLS 1.2; IPP over
TLS; Network: enable/disable network ports and features, unused
protocol and service disablement, SNMPv1 & SNMPv2 community
password change; HP ePrint: HTTPS with certificate validation, HTTP Basic
Access Authentication, SASL authentication, LDAP authentication and
authorization, firewall and ACL, control panel lock, certificates
configuration, UPD PIN printing, Syslog, signed firmware, administrator
settings, access control SNMPv3, 802.1x wireless authentication (EAPTLS, LEAP, and PEAP), authentication via WEP, WPA/WPA2 Personal,
WPA2-enterprise wired, encryption via AES or TKIP, Encrypted data
storage, Secure data erase, automatic firmware updates, Secure
Encrypted Print via optional job storage, compatible with optional HP
JetAdvantage Security Manager, IPPS
Printer management
HP Printer Assistant, HP Utility (Mac), HP Device Toolbox, HP Web JetAdmin Software, HP JetAdvantage Security Manager, HP SNMP Proxy Agent, HP
WS Pro Proxy Agent, Printer Administrator Resource Kit for HP Universal Print Driver (Driver Configuration Utility - Driver Deployment Utility -
Managed Printing Administrator)
Dimensions and weight
Printer dimensions (W x D x H) Minimum 420 x 390 x 323 mm; Maximum: 430 x 634 x 325 mm;
Package dimensions (W x D x H) 497 x 398 x 490 mm
Printer weight 12.6 kg
Package weight 15.5 kg
Operating environment Temperature: 10 to 32.5°C; Humidity: 30 to 70% RH
Storage conditions Temperature: -20 to 40°C;
Acoustics Acoustic power emissions: 6.7 Bel(A) (Printing at 38 ppm); Acoustic pressure emissions: 53 dB(A)
Power
Requirements: 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz);
Consumption: 510 watts (Active Printing), 7.5 watts (Ready), 0.9 watts (Sleep), 0.9 watts (Auto Off/Wake on LAN, enabled at shipment), 0.06 watts
(Auto Off/Manual On), 0.06 (Manual Off);
Typical Electricity Consumption (TEC) : Blue Angel: 1.144 kWh/Week; Energy Star 3.0: 0.4125 kWh/Week;
Power supply type: Internal (Built-in) power supply;
Energy savings feature technology HP Auto-On/Auto-Off Technology; Instant-on Technology
Certifications
CISPR 32:2012/EN 55032:2012 - Class B, CISPR 32:2015/EN 55032:2015 - Class B, EN 61000-3-2:2014, EN 61000-3-3:2013, EN
55024:2010+A1:2015
CECP; ENERGY STAR® qualified; EPEAT® Silver
Blue Angel compliant Yes, Blue Angel DE-UZ 205—only ensured when using Original HP supplies
Country of origin Made in China
What's in the box
HP LaserJet Pro M428fdn; Preinstalled HP 59A Black LaserJet Toner
Cartridge (yield: 3,000 pages); Getting started guide; Support flyer;
Warranty guide; Regulatory flyer; Power cord; Phone cord; HP printer
software is available at http://www.hp.com/support
HP LaserJet Pro M428fdw; Preinstalled HP 59A Black LaserJet Toner
Cartridge (yield: 3,000 pages); Getting started guide; Support flyer;
Warranty guide; Regulatory flyer; Power cord; Phone cord; USB cable; HP
printer software is available at http://www.hp.com/support
Warranty
One-year Bench/Depot Repair warranty. Warranty and support options vary by product, country and local legal requirements. Contact your
Contractual Vendor or go to http://www.hp.com/support to learn about HP award winning service and support options in your region. (wty code 4E;
wty ID A033)
