HP m1005 Datasheet

HP LaserJet M1005 MFP

Move up to a versatile HP LaserJet MFP and you can easily handle printing, copying, and scanning with a single, compact device at a very attractive price.

HP LaserJet M1005 MFP

Ideal for personal users in small offices, home offices, or microbusinesses who need reliable printing, copying, and scanning in a single, compact device.

Get more functionality at a great price – print, copy and scan with this affordable HP LaserJet MFP.

●

Make multitasking easier – print, copy and scan with just one device

●

Work faster and more efficiently: output speed of up to 14 ppm and printing with 1200 dpi effective output quality

●

No time wasted as Instant-on Technology delivers a first printed page out from Powersave mode in under 10 seconds

●

Produce quality colour scans with up to 19.200 dpi resolution

●

The flatbed scanner lets you conveniently copy various materials including bound documents like magazines, books and

reports.

Save space on your desktop, and accomplish more with the compact, versatile HP LaserJet M1005 MFP.

●

Increase your workspace as this LaserJet MFP’s compact size is an ideal fit for any desktop, shelf or small surface area

●

Convert your documents to digital format for archiving or transform hardcopies into editable electronic documents using OCR2software

●

Make a great impression by producing professional, laser-quality documents using original HP LaserJet print cartridges

●

Enjoy flexible paper-handling with a 150-sheet input tray, a 10-sheet priority input tray and a 50-sheet output tray.

The intuitive features make work simpler – and printing, copying and scanning easier than ever.

●

Easy to use and maintain with an intuitive, 2-line, 16-character front-panel display

●

Count on Hi-Speed USB connectivity for fast, easy installation and use

●

The HP LaserJet print cartridge is designed for simple operation and incorporates all wear and tear components in just one supply

●

HP print cartridges are clean and convenient to install and replace

●

Robust 5,000 page per month duty cycle and proven HP LaserJet quality.

600 x 600 dpi with HP Resolution Enhancement technology (REt) and FastRes 1200 technology.

Optical Character Recognition software.

Print technology Print speed

Processor Memory Print

Scan

Copy

Media handling Input: Capacity Weight Size

Media types Interface and connectivity Operating systems compatibility

Minimum system requirements

Standard software

Control panel Power

Dimensions (w x d x h) Weight Operating environment

Certifications

Warranty

Monochrome Laser Up to 14 ppm. First page out black: < 10 sec for printing (Instant-on Technology virtually eliminating warm-up time – from cold or

warm start). Exact speed varies depending on the system configuration, software program, and document complexity. 230 MHz. Tensilica® 32 MB Quality 1200 dpi effective output quality (600 x 600 dpi with HP Resolution Enhancement technology

Resolution Up to 600 x 600 dpi Printer languages Host-based Economical printing Economode print quality settings prints text with less toner, N-up printing (multiple pages per sheet)

Typefaces/fonts None (Host-based) Duty cycle Up to 5000 pages per month Print margins (mm) Top: 4 mm. Left: 4 mm. Right: 4 mm. Bottom: 4 mm

Type Flatbed. Colour scanning: Yes Scan resolution Optical: Up to 1200 dpi. Enhanced: Up to 19200 dpi Bit depth 24 bit Grey scale levels 256 Twain version TWAIN compatible Version 1.9 Scannable area Minimum media size: 25 x 25 mm. Maximum media size: 216 x 297 mm Margins for scanned items Left: 4 mm. Top: 4 mm. Right: 4 mm. Bottom: 4 mm

Copy speed Up to 14 cpm Copy resolution Up to 600 x 600 dpi Multiple copies Up to 99 Reduce/enlarge 25 to 400%

Tray 1 Sheets: up to 10;

Tray 2 Sheets: up to 150;

Output: Duplex printing:

Paper (plain, laser), envelopes, transparencies, labels, cardstock, postcards Hi-Speed USB (compatible with USB 2.0 specifications) Microsoft® Windows® 2000, XP Professional, Server 2003; Mac OX v10.3 and higher. Latest drivers available from

http://www.hp.com Microsoft® Windows® 2000, XP, Server 2003: Pentium® II processor, 233 MHz; 64 MB RAM; 35 MB available hard disk

space; SVGA 800 x 600 16-bit colour monitor; USB port; CD-ROM drive. Mac OS X v10.3 and higher; G3, G4, or G5 PowerPC processor; 128 MB RAM; 30 to 50 MB available hard disk space; USB port; CD-ROM drive

Host-based print drivers, TWAIN 1.9 or WIA scanner drivers, scan application, installer/uninstaller, HP MARS/Pony Express usage tracking software, HP Order Reminder, screen fonts, I.R.I.S. Readiris PRO text recognition software (not installed with other software, separate installation required), Mac print drivers and scan drivers.

Intuitive control panel with 2-line, 16-character display, menu and navigation buttons, copy control buttons Requirements: Input voltage: 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 1.5 amp. Consumption: 0 watt (off), 7 watts

(powersave and standby), 230 watts (active) Out of package: 437 x 363 x 308 mm. Packaged: 600 x 400 x 390 mm Out of package: 8.5 kg. Packaged: 11.7 kg Operating temperature: 15 to 32.5° C. Recommended operating temperature: 20 to 27° C. Operating humidity: 20 to 80% RH.

Operating humidity recommended: 20 to 70% RH. Storage temperature: 0 to 40° C. Storage humidity: 10 to 80% RH. Noise level per ISO 9296: sound power: LwAd 6.3 B(A). Sound pressure: LpAm 49 dB(A)

CISPR 22: 2003/EN 55022: 2005 - Class B; EN 61000-3-2: 2000; EN 61000-3-3: 1995+A1; EN 55024: 1998+A1+A2; FCC Title 47 CFR, Part 15 Class B 2/ICES-003, Issue 4; GB9254-1998. Regulatory standards: IEC 60950-1: 2001/EN 60950-1: 2001+A11; IEC 60825-1: 1993 + A1:1997 + A2: 2001/EN 60825-1: 1994 + A1: 2002 + A2: 2001 (Class 1 Laser/LED Product); GB4943-1995. ENERGY STAR: Yes

One-year limited warranty

(REt) and FastRes 1200 technology)

saves paper

transparencies: 1; envelopes: 1

transparencies: up to 100; envelopes: up to 10 Sheets: Up to 100. Envelopes: Up to 10. Transparencies: Up to 65 Manual (driver support provided)

42 to 260 g/m² A4, A5, B5, C5, C6, DL, postcards, 76

60 to 163 g/m² A4, A5, B5, C5, C6, DL, postcards, 76

x 127 to 216 x 356 mm

Ordering informationTechnical specifications

CB376A

Q2612A

CHP210

CHP910

Q6616A

U9809A/E HP Care Pack, Return to HP,

3 years U9810A/E HP Care Pack, Next business day exchange, 3 years U9811A/E HP Care Pack, Next business day on-site response, 3 years U9813PA/PE HP Care Pack, Post Warranty, Next business day on-site response, 1 year UA152PA/PE HP Care Pack, Post Warranty, Return to HP, 1 year

For a complete list of supplies, accessories and services, please refer to http://www.hp.com

HP LaserJet M1005 multifunction product, HP LaserJet Introductory Print

Cartridge (1,000 standard

pages in accordance with

ISO/IEC 19752), getting

started guide, support flyer,

CDs containing device

software and electronics

user's guide, I.R.I.S. Readiris

PRO text recognition

software, 150-sheet media

input tray, output bin

support, power cord(s),

one-year limited warranty

Supplies

HP LaserJet Q2612A Black

Print Cartridge with

Ultraprecise Toner

2,000 standard pages in

accordance with ISO/IEC

19752

Media supplies

HP Printing Paper 80 g/m²-A4/210 x 297

mm/500 sht

HP Copy Paper 80

g/m²-A4/210 x 297

mm/500 sht

HP Superior Laser Paper

160 Glossy-160

g/m²/A4/210 x 297

mm/150 sht

Service & support

http://www.hp.com/uk/

© Copyright Hewlett Packard Development Company LP 2006. The information contained herein is subject to change without notice. The only warranties for HP Products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Published in EMEA 07/06 4AA0 -5296EEE
