QuickSpecs
Overview
HP L1908w 19-inch Widescreen LCD Monitor
1.
Menu/select
2.
"-"/Auto
and decreases adjustment levels; when the OSD menu is
inactive, activates the auto adjustment feature to optimize
the screen image.
3.
"+"
: Navigates forward through the OSD menu and
increases adjustment levels.
: Opens, selects or exits the OSD menu.
: Navigates backward through the OSD menu
Model
GP536AA
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
4.
Power LED
sleep timer mode = flashing amber.
5.
Power
: fully powered = green; sleep mode = amber;
: Turns the monitor on or off.
Page 1
QuickSpecs
Technical Specifications
HP L1908w 19-inch Widescreen LCD Monitor
Panel
On Screen Display
(OSD)
Controls
Signal Interface/
Performance
Video Input
Type
Viewable Image Area
(diagonal)
Screen Opening
(W x H)
Viewing Angle
Brightness
Contrast Ratio
Response Rate
Pixel Pitch
Backlight Lamp Life
(to half brightness)
* All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Buttons or Switches
Languages
User Controls
Horizontal Frequency
Vertical Frequency
Native Resolution
Preset VESA Graphic
Modes
Text Mode
Mac Mode
Sun Mode
Maximum Pixel Clock
Speed
User Programmable
Modes
Anti-Glare
Anti-Static
Default Color
Temperature
Plug and Play
Self Powered USB 2.0
Hub
Input Signal
Input Impedance
Sync Input
VGA Cable
VGA Cable Length
(non-interlaced)
(typical)
(typical)
(typical)*1000:1
19-in (48.25-cm) Wide-Aspect Active Matrix TFT (thin film transistor)
19 in (48.25 cm) wide (WXGA+); diagonally measured
16.1 x 10.1 in (40.98 x 25.67 cm)
Up to 160° horizontal/160° vertical (10:1 minimum contrast ratio)
*
300 nits (cd/m2)
≤5 ms (on/off)
0.285 mm
50 K hours
Auto adjust/OSD down, OSD UP, OSD menu select, power
English, French, German, Spanish, Italian, Dutch, and Japanese, S.
Chinese
Brightness, contrast, positioning, color temperature (6500k, 9300k,
custom), individual color control, serial number, display, clock, clock
phase, monitor management, factory reset, zoom
24 to 83 kHz
50 to 76 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz and 75 Hz
1024 x 768 @ 60 Hz and 75 Hz
800 x 600 @ 60 Hz and 75 Hz
640 x 480 @ 60 Hz and 75 Hz
720 x 400 @ 70 Hz
1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz
1152 x 900 @ 66 Hz
140 MHz (analog input)
Yes, 10
Yes
Yes
6500 K
Yes
No
VGA
75 ohms ± 10%
TTL separate synch or Composite Sync
15 pin D-sub VGA
5.9 ft (1.8 m)
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
Page 2
QuickSpecs
Technical Specifications
HP L1908w 19-inch Widescreen LCD Monitor
Power
Mechanical
Environmental
Environmental Data
Input Power
Frequency
Typical Power
Consumption
Maximum
Power Saving
Power Cable Length
Dimensions
Weight
Tilt Range
Swivel Range
Height Adjustable
Pivot Rotation
Base and Stand
Temperature –
Operating
Temperature –
Non-operating
Humidity – Operating
Humidity –
Non-operating
Altitude – Operating
Altitude –
Non-operating
Eco-Label
Certifications and
Declarations
(H x W x D)
Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
45 to 63 Hz
37 watts
50 watts
2 watts standby;1 watt off
6.2 ft (1.9 m)
Unpacked w/stand
Unpacked w/o stand
(head only)
Packaged
Unpacked
Head only
Packaged
-5° to + 30° vertical
No
No
No
Detachable, ships attached
41° to 104° F (5° to 40° C)
-29° to 140° F (-34° to 60° C)
20% to 80% non-condensing
5% to 95%, 38.7° C max wet-bulb
+12,000 ft (3,658 m)
+40,000 ft (12,192 m)
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
14.6 x 17.6 x 7.3 in (37.0 x 44.6 x 18.7 cm)
11.9 x 17.6 x 2.3 in (30.1 x 44.6 x 5.9 cm)
16.7 x 21.2 x 6.9in (42.3 x 53.6 x 17.4 cm)
11.2 lb (5.1 kg)
9.3 lb (4.2 kg)
14.2 lb (6.45 kg)
ENERGY STAR®
US Federal Energy Management Program (FEMP)
IT ECO declaration
TCO 03
Taiwan Green Mark
CECP
EU Flower (2001/686/EC & 2001/687/EC)
GEEA
Energy Consumption
(in accordance with
ENERGY STAR® test
method)
Normal Operation
Sleep
Off
Heat Dissipation*
Normal Operation
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
AC Input Voltage at
100 VAC +/- 5 VAC,
50 Hz +/- 3 Hz
36 watts 37 watts 37 watts
2 watts 2 watts 2 watts
1 watt 1 watt 1 watt
100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
123 BTU/hr 123 BTU/hr 123 BTU/hr
AC Input Voltage at
115 VAC +/- 5 VAC,
60 Hz +/- 3 Hz
AC Input Voltage at
230 VAC +/- 5 VAC,
50 Hz +/- 3 Hz
Page 3
QuickSpecs
Technical Specifications
HP L1908w 19-inch Widescreen LCD Monitor
Sleep
Off
*
Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Longevity and
Upgrading
Ergonomics
Additional Information
Material Usage
6.82 BTU/hr 6.82 BTU/hr 6.82 BTU/hr
3.41 BTU/hr 3.41 BTU/hr 3.41 BTU/hr
Upgradeability features contained in the product include:
One upstream and two downstream USB ports
The monitor meets the ergonomic requirement of EN-ISO 13406-2 for
flat panel displays.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive, 2002/96/EC.
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
Display meets the requirement for low frequency electromagnetic fields
per MPR-II, TCO, and prEN50279 A/B/C.
This product contains 0% recycled materials (by wt.)
This product is 95% recyclable when properly disposed of at end of life.
Packaging Materials
Corrugated Carton – 0.96 kg
HDPE Bag – 0.09 kg
Polystyrene – 0.55 kg
This product does not contain any of the following substances in excess
of regulatory limits (refer to the HP General Specification for the
Environment at:
supplychain/gen_specifications.html
www.hp.com/hpinfo/globalcitizenship/environment/
)
Packaging
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
HP follows these guidelines to decrease the environmental impact of
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
Page 4
QuickSpecs
Technical Specifications
End-of-life
Management and
Recycling
Hewlett-Packard
Corporate
Environmental
Information
Options
Other
HP Silver LCD Speaker
Bar – Part number:
EE418AA
HP LCD Monitor Quick
Release – Part number
EM870AA*
* The HP Flat Panel Monitor Quick Release has been designed to support a maximum of up to 24
lbs (10.9 kg) depending upon the mounting configuration used. Please note this is a total weight
limit for all devices mounted, i.e. the combined weight of the monitor and a second device such an
HP Thin Client cannot exceed 24 pounds. Because mounting surfaces vary widely and the final
mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering,
architectural or construction professional to determine the appropriate type and quantity of
mounting fasteners required for your application and to ensure that your mounting solution is
properly installed to support applied loads.
Accessories Included
Software
HP L1908w 19-inch Widescreen LCD Monitor
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
Hewlett-Packard offers end-of-life HP product return and recycling
programs in many geographic areas. To recycle your product, please go
to:
www.hp.com/recycle
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
For more information about HP's commitment to the environment:
Global Citizenship Report
www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html
Powered directly by the connected PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to select
HP flat panel monitors. Features include dual speakers with full sound
range and external jack for headphones. Sold separately. For more
information, refer to the product's QuickSpecs.
An easy-to-use, VESA-compliant, LCD monitor mounting solution that
allows you to quickly and securely attach a flat panel monitor to a variety
of stands, brackets, arms or wall mounts. For more information, refer to
this product's QuickSpecs document.
VGA cable – connects the graphic card's VGA connector to the
monitor's VGA input
HP Display Assistant is a software utility that allows monitor adjustment
and color calibration using the Display Data Channel Command
Interface (DDC/CI) protocol of the connected PC.
HP Display LiteSaver allows you to schedule Sleep mode at preset
times to help protect the monitor against image retention, drastically
lower power consumption and energy costs, and extend the lifespan of
the monitor.
or contact your nearest HP sales office.
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
Page 5
QuickSpecs
Technical Specifications
HP L1908w 19-inch Widescreen LCD Monitor
Certification and
Compliance
Compatibility
Service and Warranty
User Guide Languages
Warranty Languages
Color
VESA External
Mounting
Kensington Lock-ready
TCO'03, ISO 13406-2 VDT Guidelines Approval, MPR-II Compliant, CISPR Requirements, VCCI
Approvals, MIC (Korean) Requirements, CSA, Australian ACA Approval, "GS" Mark, TUV
Approvals, CE Marking, FCC Approval, ENERGY STAR® Qualified, PC-2001 Certified,
Microsoft® Windows® Certification (Microsoft® Windows® 98, Microsoft Windows 2000,
Microsoft Windows XP, and Windows Vista®)
Compatible with platforms using the VESA standard video modes. Recommended for use with HP
products.
Three years parts, labor, and on-site service. 24-hour, 90-day, toll-free technical support.
Replacement options may include second business day on-site service, or next business day
direct replacement, at HP's sole discretion1. With direct replacement, HP will ship a replacement
display product directly to you. Using the prepaid shipping labels provided, return your failed
display to HP in the same packaging as the replacement. Certain restrictions and exclusions
apply. For details see your product warranty or contact HP Customer Support.
1
The HP Flat Panel Monitor Quick Release has been designed to support a maximum of up to 24
lbs (10.9 kg) depending upon the mounting configuration used. Please note this is a total weight
limit for all devices mounted, i.e. the combined weight of the monitor and a second device such an
HP Thin Client cannot exceed 24 pounds. Because mounting surfaces vary widely and the final
mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering,
architectural or construction professional to determine the appropriate type and quantity of
mounting fasteners required for your application and to ensure that your mounting solution is
properly installed to support applied loads.
English, B. Portuguese, French, LA Spanish, Korean, S. Chinese, T.
Chinese, Bahasa, Japanese, Danish, Finnish, German, Norwegian,
Spanish, Swedish, Greek, Polish, Russian, Slovenian, Turkish
English, Canadian French, LA Spanish, Brazilian Portuguese, Danish,
German, Castilian Spanish, French, Italian, Dutch, Norwegian, Finnish,
Swedish, Bahasa Indonesian, Korean, T. Chinese, S. Chinese
All carbonite
Yes (Two sets of Standard 4 hole pattern, 100 mm) Use of the top
VESA 4 hole pattern will allow the user to set monitor head lower to the
desk surface
Yes
© Copyright 2007 Hewlett-Packard Development Company, L.P.
Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the U.S. and other countries.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other
countries. ENERGY STAR is a registered mark owned by the U.S. government.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
DA - 12826 Worldwide QuickSpecs — Version 3 — 12/17/2007
Page 6
Loading...
