HP F2S90EA User guide

User Guide

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel is a trademark of Intel Corporation in the U.S. and other countries. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: July 2012

Document Part Number: 695858-001

Product notice

This guide describes features that are common to most models. Some features may not be available on your computer.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a refund subject to the refund policy of your place of purchase.

For any further information or to request a full refund of the computer, please contact your local point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Starting right ................................................................................................................................................... 1

Best practices ....................................................................................................................................... 1

Fun things to do .................................................................................................................................... 1

More HP resources .............................................................................................................................. 1

2 Getting to know your computer ..................................................................................................................... 3

Finding your hardware and software information ................................................................................. 3

Front ..................................................................................................................................................... 3

Right side ............................................................................................................................................. 3

Left side ................................................................................................................................................ 4

Display .................................................................................................................................................. 6

Top ....................................................................................................................................................... 7

TouchPad ............................................................................................................................ 7

Lights ................................................................................................................................... 8

Buttons and speakers .......................................................................................................... 9

Keys ................................................................................................................................... 10

Bottom ................................................................................................................................................ 11

Labels ................................................................................................................................................. 12

3 Connecting to a network .............................................................................................................................. 14

Connecting to a wireless network ....................................................................................................... 14

Using the wireless controls ................................................................................................ 14

Using the wireless button .................................................................................. 14

Using operating system controls ....................................................................... 15

Using a WLAN ................................................................................................................... 15

Using an Internet service provider .................................................................... 15

Setting up a WLAN ............................................................................................ 16

Configuring a wireless router ............................................................................ 16

Protecting your WLAN ....................................................................................... 16

Connecting to a WLAN ...................................................................................... 17

Using Bluetooth wireless devices (select models only) ..................................................... 17

Connecting to a wired network ........................................................................................................... 17

Connecting to a local area network (LAN) ......................................................................... 18

4 Enjoying entertainment features ................................................................................................................. 19

Using the webcam .............................................................................................................................. 20

Using audio ........................................................................................................................................ 20

Connecting speakers ......................................................................................................... 20

Connecting headphones .................................................................................................... 20

Connecting a microphone .................................................................................................. 21

Checking the sound ........................................................................................................... 21

Using video ......................................................................................................................................... 21

Connecting a VGA monitor or projector ............................................................................. 21

Connecting an HDMI TV or monitor ................................................................................... 22

Configuring audio settings (with HDMI TV) ....................................................... 23

Managing your audio and video files .................................................................................................. 24

5 Navigating using touch gestures, pointing devices and the keyboard ................................................... 25

Using the TouchPad ........................................................................................................................... 25

Using TouchPad gestures .................................................................................................................. 25

Scrolling ............................................................................................................................. 26

Pinching/zooming .............................................................................................................. 26

Edge swipes ...................................................................................................................... 27

Right-edge swipe .............................................................................................. 27

Top-edge swipe ................................................................................................. 27

Left-edge swipe ................................................................................................. 28

Using the keyboard and mouse .......................................................................................................... 28

Using ALT GR key combinations ....................................................................................... 29

Using the keys ................................................................................................................... 29

Using the action keys ........................................................................................ 29

Using Microsoft Windows 8 shortcut keys ......................................................... 30

Using the hot keys ............................................................................................. 31

6 Managing power ............................................................................................................................................ 32

Initiating Sleep and Hibernation ......................................................................................................... 32

Initiating and exiting Sleep ................................................................................................. 32

Enabling and Exiting User-Initiated Hibernation ................................................................ 33

Setting password protection on wakeup ............................................................................ 33

Using the power meter and power settings ........................................................................................ 33

Selecting a power plan ....................................................................................................................... 34

Running on battery power .................................................................................................................. 34

Removing a user-replaceable battery ................................................................................ 34

Finding battery information ................................................................................................ 35

Conserving battery power .................................................................................................. 35

Identifying low battery levels .............................................................................................. 36

Resolving a low battery level ............................................................................................. 36

Resolving a low battery level when external power is available ........................ 36

Resolving a low battery level when no power source is available ..................... 36

Resolving a low battery level when the computer cannot exit Hibernation ....... 36

Storing a user-replaceable battery ..................................................................................... 36

Disposing of a user-replaceable battery ............................................................................ 36

Replacing a user-replaceable battery ................................................................................ 37

Running on external AC power .......................................................................................................... 37

Troubleshooting an AC adapter ......................................................................................... 37

Shutting down (turning off) the computer ........................................................................................... 38

7 Managing and sharing information ............................................................................................................. 39

Using a USB device ........................................................................................................................... 39

Connecting a USB device .................................................................................................. 39

Removing a USB device .................................................................................................... 40

Connecting a powered USB device ................................................................................... 40

Inserting and removing a digital storage card .................................................................................... 40

Using optical drives ............................................................................................................................ 41

Inserting an optical disc ..................................................................................................... 42

Removing an optical disc ................................................................................................... 43

Sharing data and drives and accessing software .............................................................. 44

8 Maintaining your computer .......................................................................................................................... 46

Improving performance ...................................................................................................................... 46

Handling drives .................................................................................................................. 46

Replacing a hard drive ....................................................................................................... 46

Using Disk Defragmenter ................................................................................................... 48

Using Disk Cleanup ........................................................................................................... 49

Adding or replacing memory modules ............................................................................... 49

Updating programs and drivers .......................................................................................................... 51

Cleaning your computer ..................................................................................................................... 52

Cleaning the display, sides, and cover .............................................................................. 52

Cleaning the TouchPad and keyboard .............................................................................. 52

Traveling with or shipping your computer ........................................................................................... 52

9 Securing your computer and information .................................................................................................. 54

Locating your security software .......................................................................................................... 54

Using passwords ................................................................................................................................ 54

Setting Windows passwords .............................................................................................. 55

Setting Setup Utility (BIOS) passwords ............................................................................. 55

Using Internet security software ......................................................................................................... 56

Using antivirus software ..................................................................................................... 56

vii

Using firewall software ....................................................................................................... 56

Installing software updates ................................................................................................................. 56

Installing Windows security updates .................................................................................. 56

Installing HP and third-party software updates .................................................................. 57

Securing your wireless network .......................................................................................................... 57

Backing up your software applications and information ..................................................................... 57

Using an optional security cable lock ................................................................................................. 57

10 Using Setup Utility (BIOS) and System Diagnostics ............................................................................... 59

Starting Setup Utility (BIOS) ............................................................................................................... 59

Updating the BIOS ............................................................................................................................. 59

Determining the BIOS version ........................................................................................... 59

Downloading a BIOS update ............................................................................................. 60

Using System Diagnostics .................................................................................................................. 60

11 Backing up, restoring, and recovering ..................................................................................................... 62

Creating recovery media and backups ............................................................................................... 62

Creating HP Recovery media ............................................................................................ 63

What you need to know ..................................................................................... 63

To create HP Recovery media: ......................................................................... 63

Restore and recovery ......................................................................................................................... 64

Using Windows Refresh for quick and easy recovery ....................................................... 65

Remove everything and reinstall Windows ........................................................................ 65

How to remove everything and reinstall Windows on your computer ............... 65

Recovering using HP Recovery Manager .......................................................................... 66

What you need to know ..................................................................................... 66

Using the HP Recovery partition to recover a minimized image (select

models only) ...................................................................................................... 66

Using HP Recovery media to recover ............................................................... 67

Changing the computer boot order ................................................................... 67

Removing the HP Recovery partition ................................................................................. 67

12 Specifications .............................................................................................................................................. 68

Input power ......................................................................................................................................... 68

Operating environment ....................................................................................................................... 68

13 Electrostatic Discharge .............................................................................................................................. 69

Index ................................................................................................................................................................... 70

viii

1 Starting right

This computer is a powerful tool designed to enhance your work and entertainment. Read this chapter to learn about best practices after setup, fun things to do with your computer, and where to get more HP resources.

Best practices

To get the most out of your smart investment, after you set up and register the computer, we recommend the following steps:

Take a minute to browse the printed Windows 8 Basics guide to explore the new Windows®

●

features.

TIP: To quickly return to the computer Start screen from an open app or the Windows Desktop,

press the Windows logo key

return you to the previous screen.

If you haven’t already done so, connect to a wired or wireless network. See details in

●

to a network on page 14.

Become familiar with the computer hardware and software. Go to

●

on page 3 and Enjoying entertainment features on page 19 for information.

Update or purchase antivirus software. Learn more at

●

Back up your hard drive by creating recovery discs or a recovery flash drive. See

●

restoring, and recovering on page 62.

Fun things to do

You know that you can watch a YouTube video on the computer. But did you know that you can

●

also connect your computer to a TV or gaming console? For more information, see Connecting an HDMI device.

You know you can listen to music on the computer. But did you know that you can also stream

●

live radio to the computer and listen to music or talk radio from all over the world? See Using audio.

You know you can create a powerful presentation with Microsoft applications. But did you know

●

you can also connect to a projector to share your ideas with a group? See

monitor or projector on page 21.

on your keyboard. Pressing the Windows logo key again will

Connecting

Getting to know your computer

Using antivirus software on page 56.

Backing up,

Connecting a VGA

Use the TouchPad and the new Windows 8 touch gestures for smooth control of images and

●

pages of text. See Using touch gestures.

More HP resources

You have already used Setup Instructions to turn on the computer and locate this guide. To locate product details, how-to information, and more, use this table.

Best practices 1

Resource Contents

Setup Instructions

Windows 8 Basics guide ● Overview of using and navigating with Windows® 8.

Help and Support

To access Help and Support, from the Start screen, type h, and then select Help and Support. For U.S. support, go to worldwide support, go to

country/us/en/wwcontact_us.html.

Safety & Comfort Guide

To access this guide, select the HP Support Assistant app on the Start screen, select My computer, and then select User guides, or go to

http://www.hp.com/ergo.

Worldwide support web page

To get support in your language, go to

http://welcome.hp.com/country/us/en/ wwcontact_us.html.

Regulatory, Safety and Environmental Notices

To access this guide, select the HP Support Assistant app on the Start screen, select My computer, and then select User guides.

http://www.hp.com/go/contactHP. For

http://welcome.hp.com/

Overview of computer setup and features.

●

A broad range of how-to information and troubleshooting tips.

●

● Proper workstation setup.

Guidelines for posture and work habits that increase your

●

comfort and decrease your risk of injury.

● Electrical and mechanical safety information.

Online chat with an HP technician.

●

Email support.

●

Find support telephone numbers.

●

Locate HP service center locations.

●

● Important regulatory notices, including proper battery disposal

information.

Limited Warranty*

To access this guide, select the HP Support

Assistant app, select My computer, and then select Warranty and User Guides, or go to

http://www.hp.com/go/orderdocuments.

*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited Warranty in the box. For countries/regions where the warranty is not provided in printed format, you may request a printed copy from

●

When you request a printed copy of your warranty, please include your product number, warranty period (found on your service label), name, and postal address.

IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to

contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.

http://www.hp.com/go/orderdocuments or write to:

North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA

Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

● Specific warranty information about this computer.

http://www.hp.com/go/

2 Chapter 1 Starting right

2 Getting to know your computer

Finding your hardware and software information

Locating hardware

To find out what hardware is installed on your computer:

1. From the Start screen, type c, and then select Control Panel.

2. Select System and Security, and then in the System area, click Device Manager.

A list displays all the devices installed in your computer.

Locating software

To find out what software is installed on your computer, from the Start screen, right-click using

▲

the mouse or swipe from the top of the TouchPad to display the Apps, and then select the All apps icon.

Front

Component Description

Speakers Produce sound.

Right side

Component Description

(1) Optical drive Reads and writes (select models only) to an optical

(2) Optical drive light

disk.

Green: The optical drive is being accessed.

●

Off: The optical drive is idle.

●

Finding your hardware and software information 3

Component Description

(3) Optical drive eject button Releases the disc tray.

(4) USB 2.0 ports (2) Connect optional USB devices.

(5)

(6) Power connector Connects an AC adapter.

(7) Security cable slot Attaches an optional security cable to the computer.

Left side

NOTE: For details about different types of USB

ports, see

AC adapter light ● White: The AC adapter is connected and the

●

● Off: The computer is using DC power.

NOTE: The security cable is designed to act as a

deterrent, but it may not prevent the computer from being mishandled or stolen.

Using a USB device on page 39.

battery is charged.

Amber: The AC adapter is connected and the battery is charging.

Component Description

(1)

(2) Vents (2) Enable airflow to cool internal components.

(3)

4 Chapter 2 Getting to know your computer

External monitor port Connects an external VGA monitor or

projector.

NOTE: The computer fan starts up

automatically to cool internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

RJ-45 (network) jack Connects a network cable.

Component Description

(4)

(5) USB 2.0 port Connects an optional USB device.

(6)

(7)

(8)

HDMI port Connects an optional video or audio device,

Audio-in (microphone) jack Connects an optional computer headset

Audio-out (headphone) jack Connects optional powered stereo speakers,

Digital Media Slot Supports the following digital card formats:

such as a high-definition television, or any compatible digital or audio device.

NOTE: For details about different types of

USB ports, see

on page 39.

microphone, stereo array microphone, or monaural microphone.

headphones, earbuds, a headset, or a television audio cable.

WARNING! To reduce the risk of personal

injury, adjust the volume before using headphones, earbuds, or a headset. For additional safety information, see the

Regulatory, Safety and Environmental Notices.

NOTE: When a device is connected to a

headphone jack, the computer speakers are disabled.

Secure Digital (SD) Memory Card

●

Secure Digital High Capacity (SDHC)

●

Memory Card

Using a USB device

(9)

(10)

● Secure Digital Extended Capacity

(SDxC) Memory Card

MultiMediaCard (MMC)

●

Hard drive light Blinking white: The hard drive is being

Power light ● White: The AC adapter is connected and

accessed.

the battery is charged.

Blinking white: The computer is in the

●

Sleep state, which is an energy-saving mode. The computer shuts off power to the display and other unneeded components.

Off: The computer is off or in

●

Hibernation.

Left side 5

Display

Component Description

(1) WLAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless

(2) Internal microphone Records sound.

(3) Webcam Records video, captures still photographs, and allows video

(4) Webcam light On: The webcam is in use.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and

Environmental Notices that applies to your country or region. To access this guide, from the Start screen, select the HP Support Assistant app on the Start screen, select My computer, and then select User guides.

local area networks (WLANs).

conferences and online chat by means of streaming video.

To use the webcam, from the Start screen, type c, and then select CyberLink YouCam from the list of applications.

6 Chapter 2 Getting to know your computer

Top

TouchPad

Component Description

(1) TouchPad on/off button Turns the TouchPad on or off.

(2) TouchPad light ● On: The TouchPad is off.

Off: The TouchPad is on.

●

(3) TouchPad zone Moves the on-screen pointer and selects or activates

items on the screen.

(4) Left TouchPad button Functions like the left button on an external mouse.

(5) Right TouchPad button Functions like the right button on an external mouse.

Top 7

Lights

Component Description

(1) Caps lock light On: Caps lock is on, which switches the keys to all capital

(2)

(3)

Power light ● White: The computer is on.

Wireless light

letters.

Blinking white: The computer is in the Sleep state,

●

which is an energy-saving mode. The computer shuts off power to the display and other unneeded components.

Off: The computer is off or in Hibernation.

●

Hibernation is an energy-saving mode that uses the least amount of power.

White: An integrated wireless device, such as a

●

wireless local area network (WLAN) device and/or a Bluetooth® device, is on.

● Amber: All wireless devices are off.

8 Chapter 2 Getting to know your computer

Buttons and speakers

Component Description

(1)

Power button ● When the computer is off, press the button to turn on

the computer.

When the computer is in the Sleep state, press the

●

button briefly to exit Sleep.(default enabled)

● When the computer is in Hibernation, press the button

down briefly to exit Hibernation. (default enabled)

CAUTION: Pressing and holding down the power button

will result in the loss of unsaved information.

If the computer has stopped responding and Microsoft® Windows® shutdown procedures are ineffective, press and hold the power button down for at least 5 seconds to turn off the computer.

To learn more about your power settings:

From the Start screen type power.

●

Select Settings, and then select Power options. See

●

Managing power on page 32 for more information.

Top 9

Keys

Component Description

(1) esc key Displays system information when pressed in

(2) fn key Executes the following functions:

(3)

(4) Action keys Execute frequently used system functions.

(5)

Windows logo key Displays the Windows Start screen.

Windows applications key Displays a shortcut menu for a selected object.

combination with the fn key.

Displays system information when pressed in

●

combination with the esc key.

10 Chapter 2 Getting to know your computer

Bottom

Component Description

(1) Battery bay Holds the battery.

(2) Vents (4) Enable airflow to cool internal components.

NOTE: The computer fan starts up

automatically to cool internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

(3)

Battery release latch Releases the battery from the battery bay.

Bottom 11

Component Description

Labels

The labels affixed to the computer provide information you may need when you troubleshoot system problems or travel internationally with the computer. The labels are in easily accessible locations.

(4)

(5)

Service door The service door provides access to the

wireless compartment, memory module compartment, keyboard access screw, and optical drive bay,

CAUTION: To prevent an unresponsive

system, replace the wireless module only with a wireless module authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region. If you replace the module and then receive a warning message, remove the module to restore computer functionality, and then contact customer support through Help and Support. To access Help and Support, from the Start screen, type h, and then select Help and Support from the list of applications.

Hard drive cover The hard drive cover provides access to

the hard drive bay.

Service label—Provides important information, including the following:

●

Component

(1) Product name

(2) Serial number

(3) Product part number

(4) Warranty period

(5) Model description

12 Chapter 2 Getting to know your computer

Have this information available when you contact technical support. The serial number label is affixed to the bottom of the computer.

Regulatory label—Provides regulatory information about the computer. The regulatory label is

●

affixed inside the battery bay.

● Wireless certification label or labels—Provide information about optional wireless devices and

the approval markings of some of the countries or regions in which the devices have been approved for use. If your computer model includes one or more wireless devices, one or more certification labels are included with your computer. You may need this information when traveling internationally. Wireless certification labels are affixed inside the battery bay.

Labels 13

3 Connecting to a network

Your computer can travel with you wherever you go. But even at home, you can explore the globe and access information from millions of websites using your computer and a wired or wireless network connection. This chapter will help you get connected to that world.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your computer may be equipped with one or more of the following wireless devices:

Wireless local area network (WLAN) device—Connects the computer to wireless local area

●

networks (commonly referred to as Wi-Fi networks, wireless LANs, or WLANs) in corporate offices, your home, and public places such as airports, restaurants, coffee shops, hotels, and universities. In a WLAN, the mobile wireless device in your computer communicates with a wireless router or a wireless access point.

HP Mobile Broadband Module (select models only)—A wireless wide area network (WWAN)

●

device that gives you wireless connectivity over a much larger area. Mobile network operators install base stations (similar to cell phone towers) throughout large geographic areas, effectively providing coverage across entire states, regions, or even countries.

Bluetooth device (select models only)—Creates a personal area network (PAN) to connect to

●

other Bluetooth-enabled devices such as computers, phones, printers, headsets, speakers, and cameras. In a PAN, each device communicates directly with other devices, and devices must be relatively close together—typically within 10 meters (approximately 33 feet) of each other.

For more information about wireless technology, see the information and website links provided in Help and Support. From the Start screen, type h, and then select Help and Support.

Using the wireless controls

You can control the wireless devices in your computer using these features:

Wireless button, wireless switch, or wireless key (referred to in this chapter as the wireless

●

button)

Operating system controls

●

Using the wireless button

The computer has a wireless button, one or more wireless devices, and one or two wireless lights, depending on the model. All of the wireless devices on your computer are enabled at the factory, so the wireless light is on (white) when you turn on the computer.

The wireless light indicates the overall power state of your wireless devices, not the status of individual devices. If the wireless light is white, at least one wireless device is on. If the wireless light is off, all wireless devices are off.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

Because the wireless devices are enabled at the factory, you can use the wireless button to turn on or turn off the wireless devices simultaneously.

14 Chapter 3 Connecting to a network

Using operating system controls

The Network and Sharing Center allows you to set up a connection or network, connect to a network, manage wireless networks, and diagnose and repair network problems.

To use operating system controls:

1. From the Start screen, type n, and then select Settings.

2. Type network and sharing in the search box, and then select Network and Sharing

Center.

For more information, from the Start screen, type h, and then select Help and Support.

Using a WLAN

With a WLAN device, you can access a wireless local area network (WLAN), which is composed of other computers and accessories that are linked by a wireless router or a wireless access point.

NOTE: The terms wireless router and wireless access point are often used interchangeably.

A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points

●

that can accommodate a large number of computers and accessories and can separate critical network functions.

A home or small office WLAN typically uses a wireless router, which allows several wireless and

●

wired computers to share an Internet connection, a printer, and files without requiring additional pieces of hardware or software.

To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided through a service provider or a public or corporate network).

Using an Internet service provider

When you are setting up Internet access in your home, you must establish an account with an Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The ISP will help set up the modem, install a network cable to connect your wireless router to the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this

information and store it in a safe place.

Connecting to a wireless network 15

Setting up a WLAN

To set up a WLAN and connect to the Internet, you need the following equipment:

● A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from

an Internet service provider

A wireless router (2) (purchased separately)

●

A wireless computer (3)

●

NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type

of modem you have.

The illustration below shows an example of a wireless network installation that is connected to the Internet.

As your network grows, additional wireless and wired computers can be connected to the network to access the Internet.

For help in setting up your WLAN, see the information provided by your router manufacturer or your ISP.

Configuring a wireless router

For help in setting up a WLAN, see the information provided by your router manufacturer or your ISP.

NOTE: It is recommended that you initially connect your new wireless computer to the router by

using the network cable provided with the router. When the computer successfully connects to the Internet, disconnect the cable, and access the Internet through your wireless network.

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and airports may not provide any security. If you are concerned about the security of your computer when connected to a hotspot, limit your network activities to email that is not confidential and basic Internet surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected signals. Take the following precautions to protect your WLAN:

● Use a firewall.

A firewall checks both data and requests for data that are sent to your network, and discards any suspicious items. Firewalls are available in both software and hardware. Some networks use a combination of both types.

Use wireless encryption.

●

Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over the network. For more information, from the Start screen, type h, and then select Help and Support.

16 Chapter 3 Connecting to a network

Connecting to a WLAN

To connect to the WLAN, follow these steps:

1. Be sure that the WLAN device is on. If the device is on, the wireless light is on. If the wireless

light is off, press the wireless button.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

2. From the Windows Desktop, tap and hold, or click the network status icon in the notification

area, at the far right of the taskbar.

3. Select your WLAN from the list.

4. Click Connect.

If the WLAN is a security-enabled WLAN, you are prompted to enter a security code. Type the code, and then click OK to complete the connection.

NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.

NOTE: If you do not see the WLAN you want to connect to, from the Windows Desktop, right-

click the network status icon, and then select Open Network and Sharing Center. Click Set up a new connection or network. A list of options is displayed, allowing you to manually search

for and connect to a network or to create a new network connection.

After the connection is made, place the mouse pointer over the network status icon in the notification area, at the far right of the taskbar, to verify the name and status of the connection.

NOTE: The functional range (how far your wireless signals travel) depends on WLAN

implementation, router manufacturer, and interference from other electronic devices or structural barriers such as walls and floors.

Using Bluetooth wireless devices (select models only)

A Bluetooth device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as the following:

Computers (desktop, notebook, PDA)

●

● Phones (cellular, cordless, smart phone)

Imaging devices (printer, camera)

●

Audio devices (headset, speakers)

●

Mouse

●

Bluetooth devices provide peer-to-peer capability that allows you to set up a personal area network (PAN) of Bluetooth devices. For information about configuring and using Bluetooth devices, see the Bluetooth software Help.

Connecting to a wired network

There are 2 kinds of wired connections: local area network (LAN) and modem connection. A LAN connection uses a network cable and is much faster than a modem, which uses a telephone cable. Both cables are sold separately.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not plug a

modem cable or telephone cable into an RJ-45 (network) jack.

Connecting to a wired network 17

Connecting to a local area network (LAN)

Use a LAN connection if you want to connect the computer directly to a router in your home (instead of working wirelessly), or if you want to connect to an existing network at your office.

Connecting to a LAN requires an 8-pin, RJ-45 (network) cable.

To connect the network cable, follow these steps:

1. Plug the network cable into the network jack (1) on the computer.

2. Plug the other end of the network cable into a network wall jack (2) or router.

NOTE: If the network cable contains noise suppression circuitry (3), which prevents

interference from TV and radio reception, orient the circuitry end of the cable toward the computer.

18 Chapter 3 Connecting to a network

4 Enjoying entertainment features

Use your HP computer as an entertainment hub to socialize via the webcam, enjoy and manage your music, and download and watch movies. Or, to make your computer an even more powerful entertainment center, connect external devices like speakers, headphones, monitor, projector, TV, and, on select models, high-definition devices.

Multimedia Features

Here are some of the entertainment features on your computer.

Component Description

(1) Internal microphone Records sound.

(2) Webcam (select models only) Records video and captures still photographs.

To use the webcam, from the Start screen, type c, and then select CyberLink YouCam from the list of applications.

(3) Webcam light (select models only) On: The webcam is in use.

(4)

(5) Optical drive Reads and writes (select models only) to an optical

(6) Speakers (2) Produce sound.

USB ports Connect optional USB devices.

disc.

Component Description

(7)

(8)

(9)

(10)

Using the webcam

Your computer has an integrated webcam, a powerful social networking tool that allows you to communicate up close with friends and colleagues next door or on the other side of the world. With the webcam, you can stream video with your instant messaging software, capture and share video, and take still photos.

Audio-out (headphone) jack Connects optional powered stereo speakers,

headphones, earbuds, a headset, or a television audio cable.

WARNING! To reduce the risk of personal injury,

adjust the volume before putting on headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices.

NOTE: When a device is connected to a

headphone jack, the computer speakers are disabled.

Audio-in (microphone) jack Connects an optional computer headset

microphone, stereo array microphone, or monaural microphone.

HDMI port Connects an optional video or audio device, such as

a high-definition television, any compatible digital or audio component, or a high-speed HDMI device.

External monitor port Connects an external VGA monitor or projector.

To use the webcam, from the computer Start screen, type c, and then select CyberLink YouCam from the list of applications.

For details about using the webcam go to Help and Support. From the Start screen, type h, and then select Help and Support.

Using audio

On your HP computer, you can play music CDs, download and listen to music, stream audio content from the web (including radio), record audio, or mix audio and video to create multimedia. To enhance your listening enjoyment, attach external audio devices such as speakers or headphones.

Connecting speakers

You can attach wired speakers to your computer by connecting them to USB ports (or the audio-out jack) on your computer or on a docking station.

To connect wireless speakers to your computer, follow the device manufacturer's instructions. To connect high-definition speakers to the computer, see

on page 23. Before connecting audio devices, be sure to adjust the volume.

Connecting headphones

You can connect wired headphones to the headphone jack on your computer.

Configuring audio settings (with HDMI TV)

20 Chapter 4 Enjoying entertainment features

To connect wireless headphones to your computer, follow the device manufacturer's instructions.

WARNING! To reduce the risk of personal injury, adjust the volume before putting on headphones,

earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices.

Connecting a microphone

To record audio, connect a microphone to the microphone jack on the computer. For best results when recording, speak directly into the microphone and record sound in a setting free of background noise.

Checking the sound

To check the audio functions on your computer, follow these steps:

1. From the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound > Sound.

3. When the Sound window opens, select the Sounds tab. Under Program Events, select any

sound event, such as a beep or alarm, and then click Test.

You should hear sound through the speakers or through connected headphones.

To check the recording functions on your computer, follow these steps:

1. From the Start screen, type s, and then select Sound Recorder.

2. Click Start Recording and speak into the microphone. Save the file to your desktop.

3. Open a multimedia program and play the recording.

To confirm or change the audio settings on your computer:

1. From the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound > Sound.

Using video

Your HP computer is a powerful video device that enables you to watch streaming video from your favorite websites and download video and movies to watch on your computer, without needing to access a network.

To enhance your viewing enjoyment, use one of the video ports on the computer to connect an external monitor, projector, or TV. Most computers have a video graphics array (VGA) port, which connects analog video devices. Some computers also have an high-definition multimedia interface (HDMI) port, which allows you to connect a high-definition monitor or TV.

IMPORTANT: Be sure that the external device is connected to the correct port on the computer,

using the correct cable. Check the device manufacturer's instructions if you have questions.

Connecting a VGA monitor or projector

To see the computer screen image on an external VGA monitor or projected for a presentation, connect a monitor or projector to the computer's VGA port.

Using video 21

To connect a monitor or projector:

1. Connect the VGA cable from the monitor or projector to the VGA port on the computer as

shown.

2. Press f4 to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and external

●

device.

Extend: View the screen image extended across both the computer and external device.

●

Second screen only: View the screen image on the external device only.

●

Each time you press f4, the display state changes.

NOTE: Adjust the screen resolution of the external device, especially if you choose the Extend

option. From the Start screen, type c, and then select Control Panel. Select Appearance and Personalization. Under Display, select Adjust screen resolution for best results.

Connecting an HDMI TV or monitor

To see the computer screen image on a high-definition TV or monitor, connect the high-definition device according to the following instructions.

To connect an HDMI device to your computer, you need an HDMI cable, sold separately.

22 Chapter 4 Enjoying entertainment features

To connect a high-definition TV or monitor to your computer:

1. Connect one end of the HDMI cable to the HDMI port on the computer.

2. Connect the other end of the cable to the high-definition TV or monitor.

3. Press f4 to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and external

●

device.

Extend: View the screen image extended across both the computer and external device.

●

Projector only: View the screen image on the external device only.

●

Each time you press f4, the display state changes.

NOTE: Adjust the screen resolution of the external device, especially if you choose the Extend

option. From the Start screen, type c, and then select Control Panel. Select Appearance and Personalization. Under Display, select Adjust screen resolution for best results.

Configuring audio settings (with HDMI TV)

HDMI is the only video interface that supports high-definition video and audio. After you connect an HDMI TV to the computer, if the HDMI sound does not configure itself automatically, you can turn on HDMI audio by following these steps:

1. On the Windows Desktop, right-click the Speakers and Headphones icon in the notification

area, at the far right of the taskbar, and then click Playback devices.

2. On the Playback tab, click the name of the digital output device.

3. Click Set Default, and then click OK.

To return the audio stream to the computer speakers, follow these steps:

1. On the Windows Desktop, right-click the Speakers icon in the notification area, at the far right of

the taskbar, and then click Playback devices.

2. On the Playback tab, click Speakers.

3. Click Set Default, and then click OK.

Using video 23

Managing your audio and video files

CyberLink PowerDVD helps you manage and edit your photo and video collections.

To start CyberLink PowerDVD, from the Start screen, type c, and then select CyberLink

▲

PowerDVD from the list of applications.

For more information about using CyberLink PowerDVD, see the PowerDVD software Help.

24 Chapter 4 Enjoying entertainment features

5 Navigating using touch gestures,

pointing devices and the keyboard

Your computer allows navigation using touch gestures (select models only) in addition to the keyboard and mouse. Touch gestures can be used on your computer TouchPad or on a touch screen (select models only).

NOTE: An external USB mouse (purchased separately) can be connected to one of the USB ports

on the computer.

Review the Windows 8 Basics guide included with your computer. The guide provides information on common tasks using the TouchPad, touch screen, or the keyboard.

Select computer models have special action keys or hot key functions on the keyboard to perform routine tasks.

Some computer models may also have an integrated numeric keypad.

Using the TouchPad

The TouchPad allows you to navigate the computer with simple finger movements.

You can customize the touch gestures by changing settings, button configurations, click speed, and pointer options. From the Start screen, type c to display the Apps list. Select Control Panel, and then select Hardware and Sound. Under Devices and Printers, select Mouse.

Turning the TouchPad off or on

To turn the TouchPad off or on, quickly double-tap the TouchPad on/off button.

The TouchPad light is off when the TouchPad is on.

The TouchPad supports a variety of gestures that let your fingers scroll, swipe, pinch, and rotate to manipulate items on the screen.

Using TouchPad gestures

A TouchPad allows you to control the pointing device on the screen using your fingers.

TIP: Use the left and right buttons on the TouchPad as you would use the corresponding buttons on

an external mouse.

Using the TouchPad 25

NOTE: TouchPad gestures are not supported in all apps.

To view a demonstration of each gesture:

1. From the Start screen, type c to display the Apps list. Select Control Panel, and then select

2. Select Synaptics TouchPad.

3. Click a gesture to activate the demonstration.

To turn a gesture off or on:

1. From the Synaptics TouchPad screen, select or clear the check box next to the gesture that

2. Click Apply, and then click OK.

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image.

●

Hardware and Sound.

you want to turn on or off.

Place two fingers slightly apart on the TouchPad zone and then drag them up, down, left, or right.

Pinching/zooming

Pinching and zooming allow you to zoom out or in on images or text.

Zoom in or out by placing two fingers together on the TouchPad zone and then moving your

●

fingers apart.

● Zoom in by placing two fingers apart on the TouchPad zone and then moving your fingers

together.

26 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Edge swipes

Edge swipes allow you perform tasks such as changing settings and finding or using apps.

Right-edge swipe

The right-edge swipe reveals the charms, which let you search, share, start apps, access devices, or change settings.

Slide your finger gently from the right edge to display the charms.

●

Top-edge swipe

The top-edge swipe allows you to open apps available on the Start screen.

IMPORTANT: When an app is active, the top-edge gesture varies depending on the app.

Slide your finger gently from the top edge to display available apps.

●

Using TouchPad gestures 27

Left-edge swipe

The left-edge swipe reveals your open apps so that you can switch to them quickly.

Swipe from the left edge of the TouchPad to switch between apps.

●

Using the keyboard and mouse

The keyboard and mouse allow you to type, select items, scroll and to perform the same functions as you do by using touch gestures. The keyboard also allows you to use action keys and hot keys to perform specific functions.

28 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

TIP: The Windows logo key on the keyboard allows you to quickly return to the Start screen

from an open app or the Windows Desktop. Pressing the Windows logo key again will return you to the previous screen.

NOTE: Depending on the country or region, your keyboard may have different keys and keyboard

functions than those discussed in this section.

Using ALT GR key combinations

Some countries have keyboards with an ALT GR key that is used for special key combinations. To type the rupee symbol on a keyboard that includes this key, use the alt gr+4 key combination. Region-specific keyboards in India can use the ctrl+shift+4 keys for the rupee symbol.

To learn about ALT GR key combinations, go to the Microsoft Office website,

http://www.office.microsoft.com, and search for ALT GR.

Using the keys

Your computer has different ways to quickly access information or perform functions with certain keys and key combinations.

Using the action keys

An action key performs an assigned function. The icon on each of the f1 through f4 keys and f6 through f12 keys illustrates the assigned function for that key.

To use an action key function, press and hold the key.

The action key feature is enabled at the factory. You can disable this feature in Setup Utility (BIOS).

Using Setup Utility (BIOS) and System Diagnostics on page 59 for instructions on opening

See Setup Utility (BIOS), and then follow the instructions at the bottom of the screen.

To activate the assigned function after you have disabled the action key feature, you must press the

fn key in combination with the appropriate action key.

CAUTION: Use extreme care when making changes in Setup Utility. Errors can prevent the

computer from operating properly.

Icon Key Description

f1 Opens Help and Support, which provides tutorials, information about the Windows

operating system and your computer, answers to questions, and updates to your computer.

Help and Support also provides automated troubleshooting tools and access to support.

f2 Decreases the screen brightness incrementally as long as you hold down the key.

f3 Increases the screen brightness incrementally as long as you hold down the key.

Using the keyboard and mouse 29

Icon Key Description

f4 Switches the screen image between display devices connected to the system. For

f6 Plays the previous track of an audio CD or the previous section of a DVD or a BD.

f7 Begins, pauses, or resumes playback of an audio CD, a DVD, or a BD.

f8 Plays the next track of an audio CD or the next section of a DVD or a BD.

f9 Decreases speaker volume incrementally as long as you hold down the key.

f10 Increases speaker volume incrementally as long as you hold down the key.

f11 Mutes or restores speaker sound.

f12 Turns the wireless feature on or off.

example, if a monitor is connected to the computer, pressing this key alternates the screen image from the computer display to the monitor display to a simultaneous display on both the computer and the monitor.

Most external monitors receive video information from the computer using the external VGA video standard. This action key can also alternate images among other devices that are receiving video information from the computer.

NOTE: A wireless network must be set up before a wireless connection is possible.

Using Microsoft Windows 8 shortcut keys

Microsoft Windows 8 provides shortcuts to perform actions quickly. Several shortcuts will help you with Windows 8 functions. Press the Windows logo key in combination with the key to perform the

action.

For additional information on Windows 8 shortcut keys, go to Help and Support. From the Start screen, type h, and then select Help and Support.

Shortcut key

in combination with the key to perform the action.

Key Description

Returns you to the Start screen from an open app or the Windows

+ c Opens the charms.

+ d Opens the Windows Desktop.

Desktop. Pressing the key again returns you to the previous screen.

30 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Shortcut key

alt + f4 Closes an active app.

Key Description

+ tab Switches between open apps.

Using the hot keys

A hot key is a combination of the fn key and the esc key, the b key, or the spacebar.

To use a hot key:

Briefly press the fn key, and then briefly press the second key of the combination.

▲

Function Hot key Description

NOTE: Continue to press this key combination until the app you

want displays.

Display system information. fn+esc Displays information about system hardware components and the

system BIOS version number.

Using the keyboard and mouse 31

6 Managing power

Your computer can operate on either battery power or external power. When the computer is only running on battery power and an AC power source is not available to charge the battery, it is important to monitor and conserve the battery charge. Your computer supports power plans to manage how your computer uses and conserves power so that you can balance computer performance with power conservation.

Initiating Sleep and Hibernation

Microsoft® Windows has two power-saving states, Sleep and Hibernation.

Sleep–The Sleep state is automatically initiated after a period of inactivity when running on

●

battery power or on external power. Your work is saved to memory, allowing you to resume your work very quickly. You can also initiate Sleep manually. For more information, see

exiting Sleep on page 32.

● Hibernation–The Hibernation state is automatically initiated if the battery reaches a critical level.

NOTE: If you want to initiate Hibernation manually, you must enable Hibernation using Power

Options in Windows Control Panel. For more information, see

Initiated Hibernation on page 33.

Initiating and

Enabling and Exiting User-

CAUTION: To reduce the risk of possible audio and video degradation, loss of audio or video

playback functionality, or loss of information, do not initiate Sleep while reading from or writing to a disc or an external media card.

NOTE: You cannot initiate any type of networking connection or perform any computer functions

while the computer is in the Sleep state or in Hibernation.

Initiating and exiting Sleep

With the computer on, you can initiate Sleep in any of the following ways:

● Close the display.

From the Start screen, point to the upper-right or lower-right side of the screen. When the

●

charms list displays, click Settings, click the Power icon, and the click Sleep.

To exit Sleep:

● Briefly press the power button.

If the display is closed, open the display.

●

Press a key on the keyboard.

●

● Tap or swipe the TouchPad.

When the computer exits Sleep, the power lights turn on and the computer returns to the screen where you stopped working.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before the computer will return to the screen.

32 Chapter 6 Managing power

Enabling and Exiting User-Initiated Hibernation

You can enable user-initiated Hibernation and change other power settings and timeouts using Power Options in Windows Control Panel. as follows:

1. From the Start screen, type power, then select Settings, and then select Power Options from

the list of applications.

2. Click Hardware and Sound, and then click Power Options.

3. In the left pane, click Choose what the power button does.

4. Click Change Settings that are currently unavailable.

5. In the When I press the power button area, select Hibernate.

6. Click Save changes.

To exit Hibernation, briefly press the power button. The power lights turn on and your work returns to the screen where you stopped working.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before your work will return to the screen.

Setting password protection on wakeup

To set the computer to prompt for a password when the computer exits Sleep or Hibernation, follow these steps:

1. From the Start screen, type power, then select Settings, and then select Power Options.

2. Click Hardware and Sound, and then click Power Options.

3. In the left pane, click Require a password on wakeup.

4. Click Change Settings that are currently unavailable.

5. Click Require a password (recommended).

NOTE: If you need to create a user account password or change your current user account

password, click Create or change your user account password, and then follow the on- screen instructions. If you do not need to create or change a user account password, go to step

6. Click Save changes.

Using the power meter and power settings

The power meter is located on the Windows Desktop. The power meter allows you to quickly access power settings and view the remaining battery charge.

To display the percentage of remaining battery charge and the current power plan, on the

●

Windows Desktop, point over the power meter icon.

To use Power Options, or to change the power plan, click the power meter icon and select an

●

item from the list. From the Start screen, you can also type power, then select Settings, and then select Power Options.

Different power meter icons indicate whether the computer is running on battery or external power. The icon also displays a message if the battery has reached a low or critical battery level.

Using the power meter and power settings 33

Selecting a power plan

A power plan manages how the computer uses power and helps you conserve power and maximize performance. To change the power plan, from the Start screen, type power, then select Settings, and then select Power Options.

The following power plans are available:

HP Recommended (recommended). Automatically balances performance with energy

●

consumption on capable hardware.

● Power saver. Saves power by reducing system performance and screen brightness where

possible.

High performance. Favors performance, but may use more energy. Your battery will not last as

●

long between charges using this power plan. Click Show additional plans to select this power plan.

You can also create your own power plan and customize it to how you use the computer for your needs.

To use Power Options in the Control Panel, from the Start screen, type c, and then select Control

Panel. Click Hardware and Sound, and then click Power Options.

Running on battery power

When a charged battery is in the computer and the computer is not plugged into external power, the computer runs on battery power. If the computer has a charged battery installed and the AC adapter is disconnected from the computer, the computer automatically switches to battery power and the display brightness decreases to conserve battery life. The battery in the computer slowly discharges when the computer is off and unplugged from external power.

Computer battery life varies, depending on power management settings, programs running on the computer, display brightness, external devices connected to the computer, and other factors.

Removing a user-replaceable battery

WARNING! To reduce potential safety issues, use only the user-replaceable battery provided with

the computer, a replacement battery provided by HP, or a compatible battery purchased from HP.

CAUTION: Removing a user-replaceable battery that is the sole power source for the computer can

cause loss of information. To prevent loss of information, save your work or shut down the computer through Windows before removing the battery.

1. Turn the computer upside down on a flat surface.

2. Slide the battery release latch (1) to release the battery.

NOTE: The battery release latch automatically returns to its original position.

34 Chapter 6 Managing power

3. Pivot the battery (2) upward and remove it from the computer.

Finding battery information

To monitor the status of your battery, or if the battery is no longer holding a charge, run Battery Check in HP Support Assistant. To access battery information, select the HP Support Assistant app on the Start screen, and then select Battery and performance.

HP Support Assistant provides the following tools and information about the battery:

Battery test

●

Information on battery types, specifications, life cycles, and capacity

●

To access battery information, select the HP Support Assistant app on the Start screen, and then select Battery and performance. If Battery Check indicates that your battery should be replaced, contact support.

Conserving battery power

Tips for conserving battery power and maximizing battery life:

Lower the brightness on the display.

●

Select the Power saver setting in Power Options.

●

Remove a user-replaceable battery from the computer when it is not being used or charged.

●

Turn off wireless when you are not using them.

●

Disconnect unused external devices that are not plugged into an external power source, such as

●

an external hard drive connected to a USB port.

Stop, disable, or remove any external media cards that you are not using.

●

Before you leave your work, initiate Sleep or shut down the computer.

●

Running on battery power 35

Identifying low battery levels

When a battery that is the sole power source for the computer reaches a low or critical battery level, the following behavior occurs:

The battery light (select models only) indicates a low or critical battery level.

●

– or –

The power meter icon on the Windows Desktop shows a low or critical battery notification.

●

NOTE: For additional information about the power meter, refer to “Using the power meter”

section.

The computer takes the following actions for a critical battery level:

If Hibernation is disabled and the computer is on or in the Sleep state, the computer remains

●

briefly in the Sleep state, and then shuts down and loses any unsaved information.

If Hibernation is enabled and the computer is on or in the Sleep state, the computer initiates

●

Hibernation.

Resolving a low battery level

Resolving a low battery level when external power is available

Connect an AC adapter.

●

● Connect an optional docking or expansion device.

Connect an optional power adapter purchased as an accessory from HP.

●

Resolving a low battery level when no power source is available

Save your work and shut down the computer.

Resolving a low battery level when the computer cannot exit Hibernation

When the computer lacks sufficient power to exit Hibernation, follow these steps:

1. Replace the discharged user-replaceable battery with a charged battery, or connect the AC

adapter to the computer and to external power.

2. Exit Hibernation by pressing the power button.

Storing a user-replaceable battery

CAUTION: To reduce the risk of damage to a battery, do not expose it to high temperatures for

extended periods of time.

If a computer will be unused and unplugged from external power for more than 2 weeks, remove the battery and store it separately in a cool, dry place to prolong the battery charge.

A stored battery should be checked every 6 months. If the capacity is less than 50 percent, recharge the battery before returning it to storage.

Disposing of a user-replaceable battery

WARNING! To reduce the risk of fire or burns, do not disassemble, crush, or puncture; do not short

external contacts; do not dispose of in fire or water.

36 Chapter 6 Managing power

See the Regulatory, Safety and Environmental Notices for proper battery disposal. To access battery information, select the HP Support Assistant app on the Start screen, and then select Battery and

performance.

Replacing a user-replaceable battery

Battery Check in Help and Support notifies you to replace the battery when an internal cell is not charging properly or when the battery storage capacity has reached a weak condition. If the battery is possibly covered by an HP warranty, instructions include a warranty ID. A message refers you to the HP Web site for more information about ordering a replacement battery.

Running on external AC power

For information on connecting to AC power, refer to the Setup Instructions poster provided in the computer box.

The computer does not use battery power when the computer is connected to AC external power with an approved AC adapter or an optional docking/expansion device.

WARNING! To reduce potential safety issues, use only the AC adapter provided with the computer,

a replacement AC adapter provided by HP, or a compatible AC adapter purchased from HP.

Connect the computer to external AC power under any of the following conditions:

WARNING! Do not charge the computer battery while you are onboard aircraft.

When charging or calibrating a battery

●

● When installing or modifying system software

When writing information to a disc (select models only)

●

When running Disk Defragmenter on computers with internal hard drives

●

When performing a backup or recovery

●

When you connect the computer to external AC power:

The battery begins to charge.

●

The display brightness increases.

●

The power meter icon on the Windows Desktop changes appearance.

●

When you disconnect external AC power, the following events occur:

The computer switches to battery power.

●

The display brightness automatically decreases to save battery life.

●

The power meter icon on the Windows Desktop changes appearance.

●

Troubleshooting an AC adapter

Test the AC adapter if the computer exhibits any of the following symptoms when it is connected to AC power:

The computer does not turn on.

●

● The display does not turn on.

The power lights are off.

●

Running on external AC power 37

To test the AC adapter:

1. Shut down the computer.

2. Remove the battery from the computer.

3. Connect the AC adapter to the computer, and then plug it into an AC outlet.

4. Turn on the computer.

● If the power lights turn on, the AC adapter is working properly.

If the power lights remain off, check the connection from the AC adapter to the computer

●

and the connection from the AC adapter to the AC outlet to make sure the connections are secure.

If the connections are secure and the power lights remain off, the AC adapter is not

●

functioning and should be replaced.

Contact customer support for information on obtaining a replacement AC power adapter.

Shutting down (turning off) the computer

CAUTION: Unsaved information is lost when the computer shuts down. Be sure to save your work

before shutting down the computer.

The Shut down command closes all open programs, including the operating system, and then turns off the display and computer.

Shut down the computer under any of the following conditions:

When you need to replace the battery or access components inside the computer

●

When you are connecting an external hardware device that does not connect to a USB or video

●

port

When the computer will be unused and disconnected from external power for an extended

●

period

Although you can shut down the computer with the power button, the recommended procedure is to use the Windows Shut down command:

NOTE: If the computer is in the Sleep state or in Hibernation, you must first exit Sleep or

Hibernation before shutdown is possible by briefly pressing the power button.

1. Save your work and close all open programs.

2. From the Start screen, point to the upper-right or lower-right corner of the screen.

3. When the charms list opens, click Settings. Click the Power icon, and then click Shut down.

If the computer is unresponsive and you are unable to use the preceding shutdown procedures, try the following emergency procedures in the sequence provided:

Press ctrl+alt+delete, and then click the Power icon, and then select Shut Down.

●

Press and hold the power button for at least 5 seconds.

●

Disconnect the computer from external power.

●

On models with a user-replaceable battery, remove the battery.

●

38 Chapter 6 Managing power

7 Managing and sharing information

Drives are digital storage devices or solid-state drives that help you store, manage, share, and access information. Your computer has an internal hard drive that stores your computer's software, operating system, as well as providing storage for all of your personal files. Some computers also have a built-in optical drive that allows you to read or write to a CD, DVD, or (on select models) Bluray Disc (BD), to play and record audio and video.

For added capacity or functionality, connect an external drive (purchased separately), such as an optical drive or hard drive, or insert a digital storage card to import information directly from your phone or camera. A USB flash drive, connected to the Universal Serial Bus (USB) port on your computer, also allows quick data transfer. Some devices use the computer's power to run; others have their own power source. Some devices come with software that must be installed.

NOTE: For information about connecting external wireless devices, see Connecting to a network

on page 14.

NOTE: For more information about required software and drivers, or to learn which computer port to

use, see the manufacturer's instructions.

Using a USB device

Most computers have more than one USB port, because this versatile interface allows you to connect to numerous kinds of external devices to your computer, such as a USB keyboard, mouse, external drive, printer, scanner, or USB hub.

Your computer may have more than one type of USB port. See

on page 3 for the types of USB ports you have on this computer. Be sure to purchase devices that

are compatible with your computer.

Type Description

USB 2.0 Transfers data at 60 MB/s.

Connecting a USB device

CAUTION: To reduce the risk of damage to a USB connector, use minimal force to connect the

device.

Getting to know your computer

Using a USB device 39

Connect the USB cable for the device to the USB port.

▲

NOTE: The USB port on your computer may look slightly different from the illustration in this

section.

NOTE: The first time you connect a USB device, a message in the notification area lets you know

that the device is recognized by the computer.

Removing a USB device

CAUTION: To reduce the risk of damage to a USB connector, do not pull on the cable to remove

the USB device.

CAUTION: To reduce the risk of loss of information or an unresponsive system, use the following

procedure to safely remove the USB device.

1. To remove a USB device, save your information and close all programs associated with the device.

2. From the Windows Desktop, click the remove hardware icon in the notification area, at the far right of the taskbar. Then, follow the on-screen instructions.

3. Remove the device.

Connecting a powered USB device

CAUTION: To reduce the risk of damage to the equipment when connecting a powered device, be

sure that the device is turned off and its AC power cord is unplugged.

1. Connect the device to the computer.

2. Plug the device power cord into a grounded AC outlet.

3. Turn on the device.

To disconnect an unpowered external device, stop the device, and then disconnect it from the computer. To disconnect a powered external device, turn off the device, disconnect it from the computer, and then unplug the AC power cord.

Inserting and removing a digital storage card

To insert a digital storage card:

40 Chapter 7 Managing and sharing information

CAUTION: To reduce the risk of damage to the digital card connectors, use minimal force to insert

a digital card.

1. Hold the card label-side up, with the connectors facing the computer.

2. Insert the card into the digital storage slot, and then press in on the card until it is firmly seated.

To remove a digital storage card:

CAUTION: To reduce the risk of loss of data or an unresponsive system, use the following

procedure to safely remove the digital card.

1. Save your information and close all programs associated with the digital card.

2. From the Windows Desktop, click the remove hardware icon in the notification area, at the far

right of the taskbar. Then, follow the on-screen instructions.

3. Press in on the card (1), and then remove it from the slot (2).

NOTE: If the card is not ejected, pull the card out of the slot.

Using optical drives

An optical disc drive uses laser light to read or store large amounts of information. Some drives can only read information, but others can also write (burn) information onto a blank disc.

Using optical drives 41

Use these tips for best performance of your optical drive:

● When the battery is the only source of power, be sure the battery is sufficiently charged before

writing to media.

Do not type on the keyboard or move the computer while an optical drive is writing to a disc. The

●

write process is sensitive to vibration.

Make sure you have installed the latest software updates for the drive.

●

If the disc you are using is not clean, wipe it with a dry, lint-free, soft cloth.

●

Your computer may include an optical drive that supports one or more of the following disc technologies:

CD—A compact disc stores data that is read by a laser from the optical disc drive. The following

●

CD formats are available:

◦ CD-Recordable (CD-R), which allows the computer to read information and to record

information one time on the CD. Once the information is recorded on the CD-R disc, it cannot be changed or erased; it is permanent.

◦ CD-Re-Writable (CD-RW), which allows you to read information and record information

many times to the CD. Information on the CD can be erased.

DVD—A digital video disc is a high-capacity optical disc. It can store more information than a

●

CD. A double-sided DVD can store up to 17 GB. The following DVD formats are available:

DVD-Recordable (DVD-R or DVD+R), which allow the computer to read information and to

◦

record information one time on the DVD. After the information is recorded on the disc, it cannot be changed or erased; it is permanent. The DVDs can be used in DVD±R drives.

◦ DVD-Re-Writable (DVD-RW or DVD+RW), which allow to read information and record

information many times to the disc. Information on the disc can be erased. The DVDs can be used in DVD±R drives.

Note the following when using BDs:

CyberLink PowerDVD is installed on the computer to play BD movies.

●

Playing most BD movie titles on an external display requires an HDMI digital connection. The

●

computer can support up to 1080p resolution on an external display, which requires a 1080pcapable HDTV or monitor.

Attempting to play a BD movie simultaneously on both the internal and an external display may

●

cause an error, so choose only one.

For copy protection purposes, Advanced Access Content System (AACS) keys are integrated

●

into the computer. AACS keys require occasional renewal to support playback of new BD movie releases. The CyberLink PowerDVD program will request an update to continue playback when such a BD movie release is inserted in the drive. Follow the on-screen instructions to install the update.

If lines appear on the display when viewing a BD, they may be caused by interference from the

●

wireless network. To resolve the issue, close any open applications and turn off your wireless feature.

Inserting an optical disc

1. Turn on the computer.

2. Press the release button (1) on the drive bezel to release the disc tray.

42 Chapter 7 Managing and sharing information

3. Pull out the tray (2).

4. Hold the disc by the edges to avoid touching the flat surfaces and position the disc label-side up

over the tray spindle.

NOTE: If the tray is not fully accessible, tilt the disc carefully to position it over the spindle.

5. Gently press the disc (3) down onto the tray spindle until the disc snaps into place.

NOTE: If the tray is not fully accessible, tilt the disc carefully as you remove it.

6. Close the disc tray.

NOTE: After you insert a disc, a short pause is normal. If you have not selected a media player, an

AutoPlay dialog box opens. It prompts you to select how you want to use the media content.

Removing an optical disc

1. Press the release button (1) on the drive bezel to release the disc tray, and then gently pull out

the tray (2) until it stops.

Using optical drives 43

2. Remove the disc (3) from the tray by gently pressing down on the spindle while lifting the outer

edges of the disc. Hold the disc by the edges and avoid touching the flat surfaces.

NOTE: If the tray is not fully accessible, tilt the disc carefully as you remove it.

3. Close the disc tray and place the disc in a protective case.

Sharing data and drives and accessing software

When your computer is part of a network, you are not limited to using only the information that is stored in your computer. Network computers can exchange software and data with each other.

NOTE: When a disc like a DVD movie or game is copy-protected, it cannot be shared.

To share on the same network:

1. From the Windows Desktop, select File Explorer.

2. Click the Share tab on the Libraries window, and then click Specific people.

3. Type a name in the File Sharing box, and then click Add.

4. Click Share.

To share information from your Local Disk:

1. On the Windows Desktop, open File Explorer.

2. Click Local Disk (C:) on the Libraries window.

3. Click the Share tab, and then click Advanced sharing.

4. On the Local Disk (C:) Properties window, select Advanced sharing.

5. Check Share this folder.

To share drives on the same network:

On the Windows Desktop, right-click the Wireless Icon

2. Select Open Network and Sharing Center.

44 Chapter 7 Managing and sharing information

in the notification area.

3. Under View your active networks, select an active network.

4. Select Change advanced sharing settings to set sharing options for privacy, network

discovery, file and printer sharing or other network options.

Using optical drives 45

8 Maintaining your computer

It is important to perform regular maintenance to keep your computer in optimal condition. This chapter provides information about improving the performance of your computer by running tools such as Disk Defragmenter and Disk Cleanup and by replacing a hard drive or adding memory. It also provides information about updating your programs and drivers, instructions for cleaning your computer, and tips for travelling with your computer.

Improving performance

Everyone wants a fast computer and by performing regular maintenance tasks, using tools such as Disk Defragmenter and Disk Cleanup, you can drastically improve the performance of your computer. Also, as your computer gets older, you might consider installing larger drives and adding more memory.

Handling drives

Observe these precautions when handling drives:

Before removing or installing a drive, shut down the computer. If you are unsure whether the

●

computer is off or in the Sleep state, turn the computer on, and then shut it down through the operating system.

Before handling a drive, discharge static electricity by touching the unpainted metal surface of

●

the drive.

Do not touch the connector pins on a removable drive or on the computer.

●

Do not use excessive force when inserting a drive into a drive bay.

●

When the battery is the only source of power, be sure that the battery is sufficiently charged

●

before writing to media.

If a drive must be mailed, place the drive in a bubble-pack mailer or other suitable protective

●

packaging and label the package “FRAGILE.”

● Avoid exposing a drive to magnetic fields. Security devices with magnetic fields include airport

walk-through devices and security wands. Airport conveyer belts and similar security devices that check carry-on baggage use X-rays instead of magnetism and do not damage drives.

● Remove media from a drive before removing the drive from the drive bay, or traveling with,

shipping, or storing a drive.

Do not type on the keyboard or move the computer while an optical drive is writing to a disc. The

●

write process is sensitive to vibration.

Before you move a computer that is connected to an external hard drive, initiate Sleep and allow

●

the screen to clear, or properly disconnect the external hard drive.

Replacing a hard drive

CAUTION: Drives are fragile computer components that must be handled with care. Do not drop a

drive, place items on it, or expose it to liquids, or temperature or humidity extremes. See

drives on page 46 for specific precautions when handling drives.

46 Chapter 8 Maintaining your computer

Handling

CAUTION: To prevent information loss or an unresponsive system:

Before removing or installing a drive, shut down the computer. If you are unsure whether the computer is off or in the Sleep state turn the computer on, and then shut it down through the operating system.

1. Save your work and shut down the computer.

2. Disconnect all external devices connected to the computer.

3. Unplug the power cord from the AC outlet.

4. Turn the computer upside down on a flat surface.

5. Remove the battery.

Remove the hard drive:

1. Remove the service door.

2. Loosen the hard drive cover screw (1) and then lift up the cover (2) and remove it (3).

Improving performance 47

3. Disconnect the hard drive cable (1).

4. Remove the four screws (2), which hold the hard drive in place. Lift the hard drive out of the hard

drive bay (3).

5. Remove the screws (1) from the bracket.

Remove the brackets from the hard drive (2). Disconnect the hard drive cable (3) from the hard drive.

To install a hard drive, reverse this procedure.

Using Disk Defragmenter

As you use your computer over time, the files on the hard drive become fragmented. A fragmented drive means data on your drive is not contiguous (sequential) and, because of this, the hard drive works harder to locate files, thus slowing down the computer. Disk Defragmenter consolidates (or

48 Chapter 8 Maintaining your computer

physically reorganizes) the fragmented files and folders on the hard drive so that the system can run more efficiently.

NOTE: It is not necessary to run Disk Defragmenter on solid-state drives.

After you start Disk Defragmenter, it works without supervision. However, depending on the size of your hard drive and the number of fragmented files, Disk Defragmenter may take more than an hour to complete.

HP recommends defragmenting your hard drive at least once a month. You may set Disk Defragmenter to run on a monthly schedule, but you can defragment your computer manually at any time.

To run Disk Defragmenter:

1. Connect the computer to AC power.

2. From the Start screen, type d and then type disk in the search box. Click Settings, and then

click Defragment your hard drive to optimize your drives.

3. Follow the on-screen instructions.

For additional information, access the Disk Defragmenter software Help.

Using Disk Cleanup

Disk Cleanup searches the hard drive for unnecessary files that you can safely delete to free up disk space and help the computer run more efficiently.

To run Disk Cleanup:

1. From the Start screen, type d and then type disk in the search box. Click Settings, and then

click Free up disk space by deleting unnecessary files.

2. Follow the on-screen instructions.

Adding or replacing memory modules

Adding memory can help improve your computer's performance. Your computer is like your physical work area. The hard drive is the filing cabinet where you store your work and the memory is the desk where you work. When your memory isn’t big enough to hold all your work easily, like a desk overflowing with work, your productivity slows down. A great solution to improve performance is to expand the amount of memory you have in your computer.

The computer has two memory module slots. The memory module slots are located on the bottom of the computer under the service door. The memory capacity of the computer can be upgraded by adding a memory module or replacing the existing memory module in one of the memory module slots.

WARNING! To reduce the risk of electric shock and damage to the equipment, unplug the power

cord and remove all batteries before installing a memory module.

CAUTION: Electrostatic discharge (ESD) can damage electronic components. Before beginning

any procedure, ensure that you are discharged of static electricity by touching a grounded metal object.

NOTE: To use a dual-channel configuration with a second memory module, be sure that both

memory modules are identical.

To add or replace a memory module:

Improving performance 49

CAUTION: To prevent information loss or an unresponsive system:

Shut down the computer before adding or replacing memory modules. Do not remove a memory module while the computer is on or in the Sleep state.

If you are not sure whether the computer is off or in Sleep state, turn the computer on by pressing the power button. Then shut down the computer through the operating system.

1. Save your work and shut down the computer.

2. Disconnect all external devices connected to the computer.

3. Unplug the power cord from the AC outlet.

4. Turn the computer upside down on a flat surface.

5. Remove the battery from the computer.

6. Remove the service door from the computer.

7. If you are replacing a memory module, remove the existing memory module:

a. Pull away the retention clips (1) on each side of the memory module.

The memory module tilts up.

b. Grasp the edge of the memory module (2), and then gently pull the module out of the

memory module slot.

CAUTION: To prevent damage to the memory module, hold the memory module by the

edges only. Do not touch the components on the memory module.

To protect a memory module after removal, place it in an electrostatic-safe container.

50 Chapter 8 Maintaining your computer

8. Insert a new memory module:

CAUTION: To prevent damage to the memory module, hold the memory module by the edges

only. Do not touch the components on the memory module.

a. Align the notched edge (1) of the memory module with the tab in the memory module slot.

b. With the memory module at a 45-degree angle from the surface of the memory module

compartment, press the module into the memory module slot (2) until it is seated.

c. Gently press the memory module (3) down, applying pressure to both the left and right

edges of the module, until the retention clips snap into place.

CAUTION: To prevent damage to the memory module, be sure that you do not bend the

module.

9. Replace the service door.

10. Replace the battery.

11. Turn the computer right-side up, and then reconnect external power and external devices.

12. Turn on the computer.

Updating programs and drivers

HP recommends that you update your programs and drivers on a regular basis to the latest versions. Updates can resolve issues and bring new features and options to your computer. Technology is always changing, and updating programs and drivers allows your computer to run the latest technology available. For example, older graphics components might not work well with the most

Updating programs and drivers 51

recent gaming software. Without the latest driver, you would not be getting the most out of your equipment.

http://www.hp.com/support to download the latest versions of HP programs and drivers. In

Go to addition, register to receive automatic update notifications when they become available.

Cleaning your computer

Cleaning your computer and external devices helps keep them in good working condition. If you don't clean your computer, dust and dirt particles can build up.

CAUTION: Avoid using the following cleaning products to clean your computer:

Strong solvents, such as alcohol, acetone, ammonium chloride, methylene chloride, and hydrocarbons, which can permanently damage the surface of the computer.

Cleaning the display, sides, and cover

Gently wipe the display using a soft, lint-free cloth moistened with an alcohol-free glass cleaner. Allow the display to dry before closing the computer cover.

Use a pre-moistened germicidal wipe to clean the sides and cover. Fibrous materials, such as paper towels, can scratch the computer.

NOTE: When cleaning the cover of the computer, use a circular motion to aid in removing dirt and

debris.

Cleaning the TouchPad and keyboard

CAUTION: Never allow liquids to drip between the keys on the keyboard, even when you are

cleaning the computer. This can permanently damage internal components.

To clean and disinfect the TouchPad and keyboard, use a soft microfiber cloth or a static-free

●

cloth without oil (such as a chamois cloth) moistened with an alcohol-free glass cleaner or use an acceptable germicidal disposable wipe.

● To prevent keys from sticking and to remove dust, lint, and particles from the keyboard, use a

can of compressed air with a straw extension.

WARNING! To reduce the risk of electric shock or damage to internal components, do not use

a vacuum cleaner attachment to clean the keyboard. A vacuum cleaner can deposit household debris on the keyboard surface.

Traveling with or shipping your computer

If you have to travel with or ship your computer, here are some tips to keep in mind to keep your equipment safe.

Prepare the computer for traveling or shipping:

●

◦ Back up your information to an external drive.

◦ Remove all discs and all external media cards, such as digital storage cards, from the

computer.

Turn off, and then disconnect all external devices.

◦

◦ Remove any media from the drive before removing the drive from a drive bay.

52 Chapter 8 Maintaining your computer

CAUTION: Perform this action before shipping, storing, or traveling with a drive. This will

help reduce the risk of damage to the computer, damage to a drive, or loss of information.

Shut down the computer.

◦

Take along a backup of your information. Keep the backup separate from the computer.

●

When traveling by air, carry the computer as hand luggage; do not check it in with the rest of

●

your luggage.

CAUTION: Avoid exposing a drive to magnetic fields. Security devices with magnetic fields

include airport walk-through devices and security wands. Airport conveyer belts and similar security devices that check carry-on baggage use X-rays instead of magnetism and do not damage drives.

If you plan to use the computer during a flight, listen for the in-flight announcement that tells you

●

when you are allowed to use your computer. In-flight computer use is at the discretion of the airline.

● If the computer will be unused and disconnected from external power for more than 2 weeks,

remove the battery and store it separately.

If you are shipping the computer or a drive, use suitable protective packaging and label the

●

package “FRAGILE.”

If the computer has a wireless device installed, the use of these devices may be restricted in

●

some environments. Such restrictions may apply onboard aircraft, in hospitals, near explosives, and in hazardous locations. If you are uncertain of the policy that applies to the use of a particular device, ask for authorization to use your computer before you turn it on.

If you are traveling internationally, follow these suggestions:

●

Check the computer-related customs regulations for each country or region on your

◦

itinerary.

Check the power cord and adapter requirements for each location in which you plan to use

◦

the computer. Voltage, frequency, and plug configurations vary.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not

attempt to power the computer with a voltage converter kit sold for appliances.

Traveling with or shipping your computer 53

9 Securing your computer and

information

Computer security is essential for protecting the confidentiality, integrity, and availability of your information. Standard security solutions provided by the Windows operating system, HP applications, the non-Windows Setup Utility (BIOS), and other third-party software can help protect your computer from a variety of risks, such as viruses, worms, and other types of malicious code.

IMPORTANT: Some security features listed in this chapter may not be available on your computer.

Computer risk Security feature

Unauthorized use of the computer Power-on password

Computer viruses Antivirus software

Unauthorized access to data Firewall software

Unauthorized access to Setup Utility (BIOS) settings and other system identification information

Ongoing or future threats to the computer Software updates

Unauthorized access to a Windows user account User password

Unauthorized removal of the computer Security cable lock

Locating your security software

HP Security Assistant provides a starting location for quick access to a collection of security software applications that are organized by task. Instead of searching for each application through the Control Panel, HP Security Assistant allows you to access the applications for the following security tasks:

Setting up Internet and antivirus security.

●

Backing up and recovering files.

●

Managing passwords, user accounts, and parental controls.

●

Maintaining your computer and installing the latest HP and Windows updates.

●

Using passwords

A password is a group of characters that you choose to secure your computer information and to protect online transactions. Several types of passwords can be set. For example, when you set up your computer for the first time, you were asked to create a user password to secure your computer. Additional passwords can be set in Windows or in the HP Setup Utility (BIOS) that is preinstalled on your computer.

Administrator password

You may find it helpful to use the same password for a Setup Utility (BIOS) feature and for a Windows security feature.

54 Chapter 9 Securing your computer and information

Use the following tips for creating and saving passwords:

● To reduce the risk of being locked out of the computer, record each password and store it in a

secure place away from the computer. Do not store passwords in a file on the computer.

When creating passwords, follow requirements set by the program.

●

Change your passwords at least every three months.

●

An ideal password is long and has letters, punctuation, symbols, and numbers.

●

Before you send your computer for service, back up your files, delete confidential files, and then

●

remove all password settings.

For additional information about Windows passwords, such as screen-saver passwords, from the Start screen, type h, and then select Help and Support from the list of applications.

Setting Windows passwords

Password Function

User password Protects access to a Windows user account. You may also

Administrator password Protects administrator-level access to computer contents.

set up your computer to require the user password to exit Sleep. See

on page 33 for more information.

NOTE: This password cannot be used to access Setup

Utility (BIOS) contents.

Setting password protection on wakeup

Setting Setup Utility (BIOS) passwords

Password Function

Administrator password ● Must be entered each time you access Setup Utility

Power-on password

(BIOS).

If you forget your administrator password, you cannot

●

access Setup Utility (BIOS).

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: Your administrator password is not interchangeable

with an administrator password set in Windows, nor is it displayed as it is set, entered, changed, or deleted.

NOTE: If you enter the power-on password at the first

password check before the “Press the ESC key for Startup Menu” message is displayed, you must enter the administrator password to access Setup Utility (BIOS).

Must be entered each time you turn on or restart the

●

computer.

If you forget your power-on password, you cannot turn

●

on or restart the computer.

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: A power-on password is not displayed as it is set,

entered, changed, or deleted.

Using passwords 55

To set, change, or delete an administrator or power-on password in Setup Utility (BIOS):

1. To start Setup Utility (BIOS), turn on or restart the computer, and then quickly press f10.

2. Select Security, and then follow the on-screen instructions.

Your changes take effect when the computer restarts.

Using Internet security software

When you use your computer to access email, a network, or the Internet, you potentially expose your computer to computer viruses, spyware, and other online threats. To help protect your computer, Internet security software that includes antivirus and firewall features may be preinstalled on your computer as a trial offer. To provide ongoing protection against newly discovered viruses and other security risks, security software must be kept up to date. It is strongly recommended that you upgrade the security software trial offer or purchase the software of your choice in order to fully protect your computer.

Using antivirus software

Computer viruses can disable programs, utilities, or the operating system, or cause them to function abnormally. Antivirus software can detect most viruses, destroy them, and in most cases, repair any damage they have caused.

For more information about computer viruses, from the Start screen, type h, and then select Help

and Support from the list of applications.

Using firewall software

Firewalls are designed to prevent unauthorized access to a system or network. A firewall can be software you install on your computer and/or network, or it can be a combination of both hardware and software.

There are two types of firewalls to consider:

● Host-based firewalls—Software that protects only the computer it is installed on.

Network-based firewalls—Installed between your DSL or cable modem and your home network

●

to protect all the computers on the network.

When a firewall is installed on a system, all data sent to and from the system is monitored and compared with a set of user-defined security criteria. Any data that does not meet those criteria is blocked.

Installing software updates

HP, Microsoft Windows, and third-party software installed on your computer should be regularly updated to correct security problems and improve software performance. For more information, see

Updating programs and drivers on page 51.

Installing Windows security updates

Updates to the operating system and other software may have become available after the computer left the factory. Microsoft sends out alerts regarding critical updates. To protect the computer from security breaches and computer viruses, install all critical updates from Microsoft as soon as you receive an alert.

56 Chapter 9 Securing your computer and information

To be sure that all available updates are installed on the computer, observe these guidelines:

● Run Windows Update as soon as possible after you set up your computer. From the Start

screen, type w, and then type Windows update in the search box. Select Windows Update from the list of applications.

Run Windows Update monthly thereafter.

●

● Obtain updates to Windows and other Microsoft programs, as they are released, from the

Microsoft website and through the updates link in Help and Support.

Installing HP and third-party software updates

HP recommends that you regularly update the software and drivers that were originally installed on your computer. To download the latest versions, go to the HP website. For U.S. support, go to

http://www.hp.com/go/contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/ wwcontact_us.html. At this location, you can also register to receive automatic update notifications

when they become available.

If you have installed third-party software after you purchased your computer, regularly update the software. Software companies provide software updates to their products to correct security problems and improve functionality of the software.

Securing your wireless network

When you set up your wireless network, always enable security features. For more information, see

Protecting your WLAN on page 16.

Backing up your software applications and information

Regularly back up your software applications and information to protect them from being permanently lost or damaged through a virus attack or a software or hardware failure. For more information, see

Backing up, restoring, and recovering on page 62.

Using an optional security cable lock

A security cable lock, which is purchased separately, is designed to act as a deterrent, but it may not prevent the computer from being mishandled or stolen. Security cable locks are only one of several methods that should be employed as part of a complete security solution to help maximize theft protection.

The security cable slot on your computer may look slightly different from the illustration in this section. For the location of the security cable slot on your computer, see

on page 3.

1. Loop the security cable lock around a secured object.

2. Insert the key (1) into the security cable lock (2).

Getting to know your computer

Securing your wireless network 57

3. Insert the security cable lock into the security cable slot on the computer (3), and then lock the

security cable lock with the key.

4. Remove the key and keep it in a safe place.

58 Chapter 9 Securing your computer and information

10 Using Setup Utility (BIOS) and System

Diagnostics

Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS) includes settings for the types of devices installed, the startup sequence of the computer, and the amount of system and extended memory.

Starting Setup Utility (BIOS)

To start Setup Utility (BIOS), turn on or restart the computer, and quickly press f10.

Information about how to navigate in Setup Utility (BIOS) is located at the bottom of the screen.

NOTE: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the

computer from operating properly.

Updating the BIOS

Updated versions of the BIOS may be available on the HP website.

Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding installing and troubleshooting the file.

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently installed on the computer, you need to know the version of the system BIOS currently installed.

BIOS version information (also known as ROM date and System BIOS) can be displayed by pressing

fn+esc (if you are already in Windows) or by using Setup Utility (BIOS).

1. Start Setup Utility (BIOS).

2. Use the arrow keys to select Main.

3. To exit Setup Utility (BIOS) without saving your changes, use the arrow keys to select Exit >

Exit Discarding Changes, and then press enter.

Starting Setup Utility (BIOS) 59

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download

and install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do not download or install a BIOS update while the computer is running on battery power, docked in an optional docking device, or connected to an optional power source. During the download and installation, follow these instructions:

Do not disconnect power from the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. From the Start screen, select HP Support Assistant.

2. Click Updates and tune-ups, and then click Check for HP updates now.

At the download area, follow these steps:

a. Identify the most recent BIOS update and compare it to the BIOS version currently installed

on your computer. Make a note of the date, name, or other identifier. You may need this information to locate the update later, after it has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive.

If the update is more recent than your BIOS, make a note of the path to the location on your hard drive where the BIOS update is downloaded. You will need to access this path when you are ready to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before

installing any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the download is complete. If no instructions are displayed, follow these steps:

1. From the Start screen, type e, and then select File Explorer.

2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).

3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains

the update.

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

NOTE: After a message on the screen reports a successful installation, you can delete the

downloaded file from your hard drive.

Using System Diagnostics

System Diagnostics allows you to run diagnostic tests to determine if the computer hardware is functioning properly.

To start System Diagnostics:

1. Turn on or restart the computer, and then quickly press f2.

2. Click the diagnostic test you want to run, and then follow the on-screen instructions.

60 Chapter 10 Using Setup Utility (BIOS) and System Diagnostics

NOTE: If you need to stop a diagnostic test while it is running, press esc.

Using System Diagnostics 61

11 Backing up, restoring, and recovering

Your computer includes tools provided by HP and the operating system to help you safeguard your information and retrieve it if ever needed. These tools will help you return your computer to a proper working state or even back to the original factory state, all with simple steps.

This chapter provides information about:

Creating recovery media and backups

●

Restoring and recovering your system

●

NOTE: This guide describes an overview of backing up, restoring and recovering options. For more

details about the tools provided, see Help and Support. From the Start screen, type h, and then select

Help and Support.

Creating recovery media and backups

Recovery after a system failure is only as good as your most recent backup.

1. After you successfully set up the computer, create HP Recovery media. HP Recovery media is a

backup of the HP Recovery partition on the computer. It can be used to reinstall the original operating system in cases where the hard drive is corrupted or has been replaced.

HP Recovery media you create will provide the following recovery options:

System Recovery—reinstalls the original operating system, and then configures the

●

settings for the default programs.

Minimized Image Recovery—reinstalls all hardware-related drivers and software, but not

●

other software applications.

Factory Reset—restores the computer to the state it originally came in from the factory. All

●

hard drive data is wiped out and all of the partitions are re-created.

Creating HP Recovery media on page 63.

See

2. As you add hardware and software programs, create system restore points. A system restore

point is a snapshot of certain hard drive contents saved by Windows System Restore at a specific time. A system restore point contains information that Windows uses, such as registry settings. Windows creates a system restore point for you automatically during a Windows update and during other system maintenance (such as a software update, security scanning, or system diagnostics). You can also create a system restore point manually at any time. For more information and steps for creating specific system restore points, see Windows Help and Support. From the Start screen, type h, and then select Help and Support.

3. As you add photos, video, music, and other personal files, create a backup of your personal

information. Windows File History can be set to regularly and automatically back up libraries, Contacts, Favorites, and the Windows Desktop. If files are accidentally deleted from the hard drive and they can no longer be restored from the Recycle Bin, or if files become corrupt, you can restore the files that you backed up using File History. Restoring files is also useful if you ever choose to reset the computer by reinstalling Windows or choose to recover using HP Recovery Manager.

NOTE: File History is not enabled by default, so you will need to turn it on.

62 Chapter 11 Backing up, restoring, and recovering

For more information and steps for enabling Windows File History, see Windows Help and Support. From the Start screen, type h, and then select Help and Support.

Creating HP Recovery media

HP Recovery Manager is a software program that offers a way to create recovery media after you successfully set up the computer. HP Recovery media can be used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the original operating system and the software programs installed at the factory, and then configures the settings for the programs. HP Recovery media can also be used to customize the system or aid in the replacement of a hard drive.

What you need to know

Only one set of HP Recovery media can be created. Handle these recovery tools carefully, and

●

keep them in a safe place.

HP Recovery Manager examines the computer and determines the required storage capacity for

●

the blank USB flash drive or the number of blank DVD discs that will be required.

● To create recovery discs, your computer must have an optical drive with DVD writer capability,

and you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, DVD+R DL discs. Do not use rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray) discs; they are not compatible with HP Recovery Manager software. Or instead you can use a high-quality blank USB flash drive.

If your computer does not include an integrated optical drive with DVD writer capability, but you

●

would like DVD recovery media, you can use an optional external optical drive (purchased separately) to create recovery discs, or you can obtain recovery discs for your computer from the HP website. For U.S. support, go to

http://welcome.hp.com/country/us/en/wwcontact_us.html. If you use an external optical drive,

to it must be connected directly to a USB port on the computer; the drive cannot be connected to a USB port on an external device, such as a USB hub.

http://www.hp.com/go/contactHP. For worldwide support, go

● Be sure that the computer is connected to AC power before you begin creating the recovery

media.

The creation process can take up to an hour or more. Do not interrupt the creation process.

●

If necessary, you can exit the program before you have finished creating all of the recovery

●

DVDs. HP Recovery Manager will finish burning the current DVD. The next time you start HP Recovery Manager, you will be prompted to continue, and the remaining discs will be burned.

To create HP Recovery media:

1. From the Start screen, type recovery, and then select HP Recovery Manager.

2. Select Recovery Media Creation, and follow the on-screen instructions to continue.

Should you ever need to recover the system, see

on page 66.

Recovering using HP Recovery Manager

Creating recovery media and backups 63

Restore and recovery

There are several options for recovering from potential problems. The method used depends on your situation and level of expertise:

● If you need to restore your personal files and data, you can use Windows File History to restore

the backups you created. For more information and steps for using File History, see Windows Help and Support. From the Start screen, type h, and then select Help and Support.

If you need to correct a problem with a preinstalled application or driver, use the Drivers and

●

Applications Reinstall option of HP Recovery Manager to reinstall the individual application or driver.

From the Start screen, type recovery, select HP Recovery Manager, and then select Drivers and Applications Reinstall, and follow the on-screen instructions.

If you want to restore the system to a previous state without losing any personal data, Windows

●

System Restore is an option. System Restore allows you to restore without the requirements of Windows Refresh or a reinstallation. Windows creates system restore points automatically during a Windows update and other system maintenance events. Even if you did not manually create a restore point, you can choose to restore to a previous point. For more information and steps for using Windows System Restore, see Windows Help and Support. From the Start screen, type h, and then select Help and Support.

● If you want a quick and easy way to recover the system without losing your personal data,

settings, or apps that came pre-installed on your computer or were purchased from the Windows Store, consider using Windows Refresh. This option does not require backing up data to another drive. See

Using Windows Refresh for quick and easy recovery on page 65.

Should you choose to reset your computer to its original state, Windows provides an easy way to

●

remove all personal data, apps, and settings, and reinstall Windows.

For more information, see

If you wish to reset your computer using a minimized image, you can choose the HP Minimized

●

Image Recovery option from the HP Recovery partition (select models only) or HP Recovery media. Minimized Image Recovery installs only drivers and hardware-enabling applications. Other applications included in the image continue to be available for installation through the Drivers and Applications Reinstall option in HP Recovery Manager.

For more information, see

● If you wish to recover the computer's original factory partitioning and content, you can choose

the System Recovery option from the HP Recovery media. For more information, see

Recovering using HP Recovery Manager on page 66.

● If you are replacing the hard drive, you can use the Factory Reset option of HP Recovery media

to restore the factory image to the replacement drive. For more information, see

using HP Recovery Manager on page 66.

If you wish to remove the recovery partition to reclaim hard drive space, HP Recovery Manager

●

offers the Remove Recovery Partition option.

For more information, see

Remove everything and reinstall Windows on page 65.

Recovering using HP Recovery Manager on page 66.

Recovering

Removing the HP Recovery partition on page 67.

64 Chapter 11 Backing up, restoring, and recovering

Using Windows Refresh for quick and easy recovery

When your computer is not working properly and you need to regain system stability, the Windows Refresh option allows you to start fresh and keep what is important to you.

IMPORTANT: Refresh removes any Windows Desktop apps that were not originally installed on the

system at the factory.

NOTE: During Refresh, a list of removed Windows Desktop apps will be saved to your Windows

Desktop so you have a quick way to see what you might need to reinstall. See Help and Support for instructions on reinstalling. From the Start screen, type h, and then select Help and Support.

NOTE: You may be prompted for your permission or password when using Refresh. See Windows

Help and Support for more information. From the Start screen, type h, and then select Help and Support.

To start Refresh:

1. On the Start screen, point to the far-right upper or lower corner of the screen to display charms.

2. Click Settings.

3. Click Change PC settings in the bottom right corner of the screen, and then select General

from the PC settings screen.

4. Under Refresh your PC without affecting your files, select Get started, and follow the on-

screen instructions.

Remove everything and reinstall Windows

Sometimes you want to perform detailed reformatting of your computer, or you want to remove personal information before you give away or recycle your computer. The Remove everything and reinstall Windows option provides a speedy, simple way to return the computer to its original state. This option removes all personal data, apps, and settings from your computer, and reinstalls Windows.

IMPORTANT: This option does not provide backups of your information. Before using this option,

back up any personal data you wish to retain.

How to remove everything and reinstall Windows on your computer

You can select to remove everything and reinstall Windows on your computer using the f11 key or from the Start screen.

To remove everything and reinstall Windows using the f11 key:

1. Press f11 while the computer boots.

—Or—

Press and hold f11 as you press the power button.

2. Select Troubleshoot from the boot options menu.

3. Select Reset your PC, and follow the on-screen instructions.

To remove everything and reinstall Windows from the Start screen:

1. On the Start screen, point to the far-right upper or lower corner of the screen to display charms.

2. Click Settings.

Restore and recovery 65

3. Click Change PC settings in the bottom right corner of the screen, and then select General

from the PC settings screen.

4. Under Remove everything and reinstall Windows, select Get started, and follow the on-

screen instructions.

Recovering using HP Recovery Manager

HP Recovery Manager software allows you to recover the computer to its original factory state. Using the HP Recovery media you created, you can choose from one of the following recovery options:

System Recovery—reinstalls the original operating system, and then configures the settings for

●

the default programs.

● Minimized Image Recovery—reinstalls all hardware-related drivers and software, but not other

software applications.

Factory Reset—restores the computer to the state it originally came in from the factory. All hard

●

drive data is wiped out and all of the partitions are re-created.

The HP Recovery partition (select models only) allows Minimized Image Recovery.

What you need to know

HP Recovery Manager recovers only software that was installed at the factory. For software not

●

provided with this computer, you must either download the software from the manufacturer's website or reinstall the software from the media provided by the manufacturer.

Recovery through HP Recovery Manager should be used as a final attempt to correct computer

●

issues.

HP Recovery media must be used if the computer hard drive fails or if all attempts to correct any

●

functional computer issues fail.

● To use the Factory Reset or System Recovery options, you must use HP Recovery media.

● If the HP Recovery media do not work, you can obtain recovery media for your system from the

HP website. For U.S. support, go to

http://welcome.hp.com/country/us/en/wwcontact_us.html.

IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal

data. Before beginning recovery, back up any personal data you wish to retain.

http://www.hp.com/go/contactHP. For worldwide support, go

Using the HP Recovery partition to recover a minimized image (select models only)

The HP Recovery partition (select models only) allows you to perform a minimized image recovery without the need for recovery discs or a recovery USB flash drive. This type of recovery can only be used if the hard drive is still working.

To start HP Recovery Manager from the HP Recovery partition:

1. Press f11 while the computer boots.

—Or—

Press and hold f11 as you press the power button.

2. Select Troubleshoot from the boot options menu.

3. Select HP Recovery Manager, and follow the on-screen instructions.

66 Chapter 11 Backing up, restoring, and recovering

Using HP Recovery media to recover

You can use HP Recovery media to recover the original system. This method can be used if your system does not have an HP Recovery partition or if the hard drive is not working properly.

1. If possible, back up all personal files.

2. Insert the first HP Recovery disc you created into the optical drive on your computer or into an

optional external optical drive, and then restart the computer.

—Or—

Insert the HP Recovery USB flash drive you created into a USB port on your computer, and then restart the computer.

NOTE: If the computer does not automatically restart in HP Recovery Manager, change the

computer boot order. See

3. Follow the on-screen instructions.

Changing the computer boot order on page 67.

Changing the computer boot order

If computer does not restart in HP Recovery Manager, you can change the computer boot order, which is the order of devices listed in BIOS where the computer looks for startup information. You can change the selection for an optical drive or a USB flash drive.

To change the boot order:

1. Make sure the HP Recovery media you created is inserted.

2. Restart the computer.

3. Press and hold esc while the computer is restarting, and then press f9 for boot options.

4. Select the optical drive or USB flash drive you want to boot from.

5. Follow the on-screen instructions.

Removing the HP Recovery partition

HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive space.

IMPORTANT: Removing the HP Recovery partition means you can no longer use Windows

Refresh, the Windows Remove everything and reinstall Windows option, or the HP Recovery Manager option for minimized image recovery. Create HP Recovery media before removing the Recovery partition to ensure you have recovery options; see

on page 63.

Follow these steps to remove the HP Recovery partition:

1. From the Start screen, type recovery, and then select HP Recovery Manager.

2. Select Remove Recovery Partition, and follow the on-screen instructions to continue.

Creating HP Recovery media

Restore and recovery 67

12 Specifications

Input power

The power information in this section may be helpful if you plan to travel internationally with the computer.

The computer operates on DC power, which can be supplied by an AC or a DC power source. The AC power source must be rated at 100–240 V, 50–60 Hz. Although the computer can be powered from a standalone DC power source, it should be powered only with an AC adapter or a DC power source supplied and approved by HP for use with this computer.

The computer can operate on DC power within the following specifications. Operating voltage and current varies by platform.

Input power Rating

Operating voltage and current 18.5 V dc @ 3.5 A or 19.5 V dc @ 3.33 A – 65 W

DC plug of external HP power supply

19 V dc @ 4.74 A or 19.5 V dc @ 4.62 A – 90 W

NOTE: This product is designed for IT power systems in Norway with phase-to-phase voltage not

exceeding 240 V rms.

NOTE: The computer operating voltage and current can be found on the system regulatory label.

Operating environment

Factor Metric U.S.

Temperature

Operating 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

Operating 10% to 90% 10% to 90%

Nonoperating 5% to 95% 5% to 95%

Maximum altitude (unpressurized)

Operating -15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

68 Chapter 12 Specifications

13 Electrostatic Discharge

Electrostatic discharge is the release of static electricity when two objects come into contact—for example, the shock you receive when you walk across the carpet and touch a metal door knob.

A discharge of static electricity from fingers or other electrostatic conductors may damage electronic components. To prevent damage to the computer, damage to a drive, or loss of information, observe these precautions:

If removal or installation instructions direct you to unplug the computer, unplug it after being

●

properly grounded and before removing a cover.

Keep components in their electrostatic-safe containers until you are ready to install them.

●

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

●

Use nonmagnetic tools.

●

● Before handling components, discharge static electricity by touching an unpainted metal surface

of the component.

If you remove a component, place it in an electrostatic-safe container.

●

If you need more information about static electricity or assistance with component removal or installation, contact customer support.

Index

AC adapter 4 AC adapter, testing 37 action keys

decrease screen brightness

29 Help and Support 29 identifying 10 increase screen brightness 29 next track or section 30 play, pause, resume 30 previous track or section 30 switch screen image 30 volume down 30 volume mute 30 volume up 30 wireless 30

airport security devices 46 antivirus software, using 56 audio functions, checking 21 audio-in (microphone) jack 5 audio-out (headphone) jacks 5

back up

personal files 62

backing up software and

information 57 backups 62 battery

discharging 35 disposing 36 low battery levels 36 replacing 37

storing 36 battery bay 11, 13 battery information, finding 35 battery power 34 battery release latch 11 battery temperature 36 best practices 1 BIOS

determining version 59

downloading an update 60

updating 59

Bluetooth device 14, 17 Bluetooth label 13 boot order

changing HP Recovery

Manager 67

buttons

left TouchPad 7 optical drive eject 4 power 9 right TouchPad 7 TouchPad on/off 7

cables

USB 40 caps lock light, identifying 8 caring for your computer 52 checking audio functions 21 cleaning your computer 52 components

bottom 11

display 6

front 3

left side 4

right side 3

top 7 computer reset 65 computer, traveling 36 configuring audio for HDMI 23 connecting to a WLAN 17 connector, power 4 corporate WLAN connection 17 critical battery level 36 CyberLink PowerDVD 24

deleted files

restoring 64 digital card

inserting 41 Digital Media Slot, identifying 5 Disk Cleanup software 49 Disk Defragmenter software 48

electrostatic discharge 69 esc key, identifying 10 external AC power, using 37 external devices 40 external monitor port 4, 21 external monitor port, identifying

firewall software 56 fn key, identifying 31 fun things to do 1 Function key, identifying 10

hard drive light 5 HDMI

configuring audio 23 HDMI port, connecting 22 HDMI port, identifying 5, 20 Hibernation

exiting 33

initiated during critical battery

level 36

initiating 33 high-definition devices,

connecting 22

hot keys

description 31

display system information 31

using 31 HP and third-party software

updates, installing 57

HP Recovery Manager 66

correcting boot problems 67

starting 66 HP Recovery media

creating 63

recovery 67 HP Recovery partition 66

recovery 66

removing 67 hubs 39

70 Index

input power 68 installing

critical security updates 56 optional security cable lock 57

integrated webcam light,

identifying 6, 19

internal microphone, identifying

6, 19 Internet connection setup 16 Internet security software, using

jacks

audio-in (microphone) 5 audio-out (headphone) 5 network 4 RJ-45 (network) 4

keyboard hot keys, identifying 31 keys

action 10 esc 10 Windows applications 10 Windows system logo 10

labels

Bluetooth 13 regulatory 13 serial number 12 service 12 wireless certification 13

WLAN 13 latch, battery release 11 lights

AC adapter 4

caps lock 8

hard drive 5

optical drive 3

power 8

TouchPad 7

webcam 6, 19

wireless 8 low battery level 36

maintenance

Disk Cleanup 49 Disk Defragmenter 48

memory module

inserting 51 removing 50 replacing 49

memory module compartment,

identifying 12

minimized image

creating 66 minimized image recovery 66 mouse, external

setting preferences 25

network jack, identifying 4

operating environment 68 optical disc

inserting 42

removing 43 optical drive bay, identifying 12 optical drive eject button,

identifying 4 optical drive light, identifying 3 optical drive, identifying 3, 19 optional external devices, using

40 original system recovery 66

passwords

Setup Utility (BIOS) 55

Windows 55 pinching TouchPad gesture 26 ports

external monitor 4, 20, 21

HDMI 5, 20, 22

USB 4, 5, 19

VGA 21 power

battery 34 power button, identifying 9 power connector, identifying 4 power lights, identifying 8 PowerDVD 24 product name and number,

computer 12

public WLAN connection 17

recovery 64, 65

discs 63, 67 HP Recovery Manager 66 media 67 starting 66 supported discs 63 system 66 USB flash drive 67 using HP Recovery media 63

recovery media

creating 63 creating using HP Recovery

Manager 63

recovery partition 66

removing 67

recycle

computer 64, 65

refresh 65

computer 64

regulatory information

regulatory label 13 wireless certification labels 13

remove everything and reinstall

Windows 65

reset

computer 64, 65 steps 65

restore

Windows File History 64

RJ-45 (network) jack, identifying

scrolling TouchPad gesture 26 security cable lock, installing 57 security cable slot, identifying 4 security, wireless 16 serial number 12 serial number, computer 12 service door 50 service labels

locating 12

setting password protection on

wakeup 33 setup of WLAN 16 Setup Utility (BIOS) passwords

Index 71

shipping the computer 52 shutdown 38 Sleep

exiting 32 initiating 32

slots

Digital Media 5 security cable 4

software

CyberLink PowerDVD 24 Disk Cleanup 49

Disk Defragmenter 48 software updates, installing 56 speakers, identifying 3, 19 storing a battery 36 supported discs

recovery 63 system information hot key 31 system recovery 66 system restore point

creating 62

restoring 64

temperature 36 testing an AC adapter 37 TouchPad

buttons 7 TouchPad gestures

pinching 26

scrolling 26

zooming 26 TouchPad light 7 TouchPad on/off button 7 TouchPad zone, identifying 7 traveling with the computer 13,

36, 52

turning off the computer 38

unresponsive system 38 USB cable, connecting 40 USB devices

connecting 39

description 39

removing 40 USB hubs 39 USB ports, identifying 4, 5, 19 using external AC power 37 using passwords 54

vents, identifying 4, 11 VGA port, connecting 21 video 21

webcam 20 webcam light, identifying 6, 19 webcam, identifying 6, 19 Windows

backup 62 File History 62, 64 Refresh 64, 65 reinstall 64, 65 remove everything and reinstall

option 65 reset 65 restoring files 64 system restore point 62, 64

Windows applications key,

identifying 10 Windows logo key, identifying 10 Windows passwords 55 Windows security updates,

installing 56 wireless button 14 wireless certification label 13 wireless controls

button 14

operating system 14 wireless light 8, 14 wireless module compartment,

identifying 12

wireless network (WLAN)

connecting 17

corporate WLAN connection

17 equipment needed 16 functional range 17 public WLAN connection 17 security 16 using 15

wireless network, securing 57 WLAN antennas, identifying 6 WLAN device 13, 15 WLAN label 13 WWAN device 14

zooming TouchPad gesture 26

72 Index

HP F2S90EA User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Starting right

Best practices

Fun things to do

More HP resources

2 Getting to know your computer

Finding your hardware and software information

Front

Right side

Left side

Display

TouchPad

Lights

Buttons and speakers

Keys

Bottom

Labels

3 Connecting to a network

Connecting to a wireless network

Using the wireless controls

Using the wireless button

Using operating system controls

Using a WLAN

Using an Internet service provider

Setting up a WLAN

Configuring a wireless router

Protecting your WLAN

Connecting to a WLAN

Using Bluetooth wireless devices (select models only)

Connecting to a wired network

Connecting to a local area network (LAN)

4 Enjoying entertainment features

Using the webcam

Using audio

Connecting speakers

Connecting headphones

Connecting a microphone

Checking the sound

Using video

Connecting a VGA monitor or projector

Connecting an HDMI TV or monitor

Configuring audio settings (with HDMI TV)

Managing your audio and video files

Using the TouchPad

Using TouchPad gestures

Scrolling

Pinching/zooming

Edge swipes

Right-edge swipe

Top-edge swipe

Left-edge swipe

Using the keyboard and mouse

Using ALT GR key combinations

Using the keys

Using the action keys

Using Microsoft Windows 8 shortcut keys

Using the hot keys

6 Managing power

Initiating Sleep and Hibernation

Initiating and exiting Sleep

Enabling and Exiting User-Initiated Hibernation

Setting password protection on wakeup

Using the power meter and power settings

Selecting a power plan

Running on battery power

Removing a user-replaceable battery

Finding battery information

Conserving battery power

Identifying low battery levels

Resolving a low battery level

Resolving a low battery level when external power is available

Resolving a low battery level when no power source is available

Resolving a low battery level when the computer cannot exit Hibernation

Storing a user-replaceable battery

Disposing of a user-replaceable battery

Replacing a user-replaceable battery

Running on external AC power
