QuickSpecs
HP EliteDisplay E273m 27-inch Monitor
Technical Specifications
c05689688 DA 16077 Worldwide Version 2 November 6, 2017
Page 1
HP EliteDisplay E273m 27-inch Monitor
1.
Webcam
2.
Volume Up and Down
3.
Start Call
4.
Mute Mic
5.
Mute Speakers
6.
End Call
7.
Power light
LED: fully powered = white sleep mode = amber sleep timer mode = flashing amber
8.
Menu
Press to open the OSD menu, select a menu item from the OSD, or close the OSD menu.
9-11.
Function buttons
Use these buttons to navigate through the OSD menu based on the indicators next to the buttons that are activated while the OSD menu is open.
12.
Power button
Turns the monitor on or off.
QuickSpecs
HP EliteDisplay E273m 27-inch Monitor
Technical Specifications
c05689688 DA 16077 Worldwide Version 2 November 6, 2017
Page 2
1.
Power Connector
2.
Security Lock Slot
3.
DisplayPort 1.2
4.
HDMI 1.4
5.
VGA 6.
Audio Line In
7.
USB Type-C™ upstream port
8.
USB 3.0 Downstream
9.
Audio out (Headphone) Jack
QuickSpecs
HP EliteDisplay E273m 27-inch Monitor
Technical Specifications
c05689688 DA 16077 Worldwide Version 2 November 6, 2017
Page 3
Models
1FH51AA, 1FH51AC, 1FH51A8, 1FH51AS, 1FH51AT
Panel*
Type
27-inch IPS, Micro Edge LED Backlit
Viewable Image Area (diagonal)
68,5 cm (27 in) widescreen; diagonally measured
Panel Active Area (W x H)
59,79 x 33,63 cm (23.54 × 13.24 in.) Panel Type
IPS
Resolution
1920 x 1080 @ 60 Hz
Aspect Ratio
16:9
Viewing Angle (typical)
Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)
Brightness (typical)
250 cd/m²
Contrast Ratio (typical)
1,000:1
Dynamic Contrast Ratio (typical)
5,000,000:1
Response Time (typical)***
5 ms
Pixel Pitch*
0.3114 mm
Pixel Per Inch (PPI)
81.59
Backlight Lamp Life (to half brightness)
30,000 hours minimum
Color Support**
Up to 16.7 million colors with the use of FRC technology (8 bit)
Color Gamut
NTSC 72%, 94% sRGB
Surface Hardness
3H
Flicker Free
Yes
Low Blue Light Capable
Yes, user selectable in OSD menu
Anti-Glare
Yes
*All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology. ***Product default is 14ms response time and can be adjusted to as low as 5ms in the display menu. See user guide for more information.
User Controls
On Screen Display (OSD) User Controls
Brightness, Contrast, Color Control, Input Control, Image Control, Power Control, OSD Menu Control, Management, Language, Information
Monitor Control Buttons or Switches
Menu, Information/Auto-Adjust (assignable), Viewing Mode (assignable), Next Active Input (assignable)
User-Assignable Function Buttons
Yes, 12
Skype for Business and Audio Controls
Volume Down/Up, Answer call, Mute microphone, Mute volume, Hang-up call
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese)
Signal Interface/ Performance
Horizontal Frequency
30 - 80 kHz
Vertical Frequency
50 - 60 Hz
Native Resolution
1920 x 1080 @ 60 Hz
Preset VESA Graphic Modes (non­interlaced)
640 x 480 @ 60Hz 720 x 400 @ 70 Hz 800 x 600 @ 60 Hz 1024 x 768 @ 60 Hz 1280 x 720 @ 60 Hz 1280 x 800 @ 60 Hz 1280 x 1024 @ 60 Hz 1440 x 900 @ 60 Hz 1600 x 900 @ 60 Hz
