QuickSpecs

Overview

HP Compaq 8100 Elite PC

Small Form Factor

1. Rear I/O includes (6) USB 2.0 ports, serial port, PS/2 mouse and keyboard ports, RJ-45 network interface, DisplayPort and VGA video interfaces, and audio in/out jacks

2. Low profile expansion slots include (1) PCI slot, (1) PCI Express x1 slots and (2) PCI Express x16 graphics slot

NOTE:

3. Front I/O includes (4) USB 2.0 ports, dedicated headphone output, and a microphone/headphone jack

4. HP Optical Mouse

5. HP Keyboard

2nd PCIe x16 slot has x4 connectivity.

6. 3.5” external drive bay supporting a media card reader or a secondary hard disk drive

7. 5.25” external drive bay supporting an optical disk drive

8. 3.5” internal drive bay supporting primary hard disk drive

9. 240W standard or high efficiency Power Supply

10. HP Monitor (sold separately)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 1

QuickSpecs

Overview

HP Compaq 8100 Elite PC

Convertible Minitower

1. (3) 5.25”external drive bays supporting optical disk drives, removable hard disk drives, or the HP Media Card Reader

2. 320W standard or high efficiency Power Supply

3. Rear I/O includes (6) USB 2.0 ports, serial port, PS/2 mouse and keyboard ports, RJ-45 network interface, DisplayPort and VGA video interfaces, and audio in/out jacks

4. Front I/O includes (4) USB 2.0 ports, dedicated headphone output, and a microphone/headphone jack

5. (3) 3.5” internal drive bays supporting multiple hard disk drives

6. Full height expansion slots include (3) full-length PCI slots, (1) PCI Express x1 slot, and (2) full-length PCI Express x16 graphics slots

NOTE:

7. HP Optical Mouse

8. HP Keyboard

9. HP Monitor (sold separately)

2nd PCIe x16 slot has x4 connectivity.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 2

QuickSpecs

HP Compaq 8100 Elite PC

Overview

At A Glance

Designed for long-term deployment within medium to large commercial and institutional organizations Guaranteed lengthy purchase lifecycles and image stability Standard efficiency or 89% high efficiency energy saving power supplies; high efficiency power supplies certified 80 PLUS® Gold by Ecos Consulting ENERGY STAR qualified models available; all ENERGY STAR qualified models are certified EPEAT Gold Intel® Q57 Express chipset Intel® Core™ and Pentium® processors DDR3 Synchronous Dynamic Random Access Memory (SDRAM) Software image fully compatible across all models and form factors BIOS developed and engineered by HP for better security, manageability and software image stability Integrated dual independent monitor support via both a VGA and DisplayPort video/audio interface Created using industry leading Design for Environment standards Intel® Core™ Processor with vPro™ Technology (on select models) Supports industry standard management protocols including DASH and Intel® Standard Manageability Models can be configured with multiple hard disk drives in a RAID array Selected configurations with global availability easily set up and ordered through HP.com Business to Business portals ( Tailored HP Factory Express deployment and lifecycle services available (

http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx

Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions and exclusions apply) Tool-less serviceability features for easier upgrades and repairs Choice of professional chassis form factors to accommodate the desired mix between expandability and size HP unique Convertible Minitower chassis delivers true expandability, and is easily configured for vertical or horizontal orientation

http://h10019.www1.hp.com/business-site/index.html

)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 3

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Operating Systems

Preinstalled

Supported

Certified

Certain Windows Vista product features require advanced or additional hardware. See

www.microsoft.com/windowsvista/getready/hardwarereqs.mspx www.microsoft.com/windowsvista/getready/capable.mspx

determine which features of Windows Vista will run on your computer. To download the tool, visit:

www.windowsvista.com/upgradeadvisor

System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See

Windows 7 Professional disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to order at least 25 customer systems with the same custom image.

The following features are not supported on Linux certified systems:

HP 22-in-1 media card reader Trusted Platform Module (TPM) 1.2 Security Chip Intel Gigabit CT Desktop NIC Card Broadcom NetXtreme GbE Ethernet Plus NIC HP 802.11b/g/n wireless NIC LSI 56K Int'l SoftModem HP USB Smartcard keyboard HP Serial port adapter HP Parallel port adapter HP eSATA port adapter HP FireWire/IEEE 1394 I/O card RAID Media Card Reader (22-in-1) with 1394 port NVIDIA NVS G310 SH Graphics Card NVIDIA Quadro NVS 290 Graphics Card NVIDIA Quadro NVS 295 Graphics Card ATI Radeon HD 4550 Graphics Card ATI Radeon HD 4650 DP Graphics Card SATA Blu-Ray Writer Drive NVIDIA GeForce 310 DP PCIe x16 Graphics Card

Genuine Windows Vista Business (32-bit) Genuine Windows Vista Home Basic (32-bit)1 Genuine Windows 7 Professional Edition (32-bit) Genuine Windows 7 Professional Edition (64-bit) Genuine Windows XP Professional (available through downgrade rights from Genuine Windows 7 Professional) Genuine Windows 7 Home Premium Edition (32-bit or 64-bit) Genuine Windows 7 Home Basic Edition (32-bit) FreeDOS

Genuine Windows Vista Enterprise Edition Genuine Windows 7 Enterprise Edition Genuine Windows 7 Ultimate Edition Novell SUSE Linux Enterprise Desktop 11

Certified Red Hat Enterprise Linux 64

2,3

and

for details. Windows Vista Upgrade Advisor can help you

http://www.microsoft.com/windows/windows-7/

for details.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 4

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Value Added Software

HP ProtectTools Security Suite HP Software Management Agent Computrace for Desktops agent (optional)

* Computrace available as an optional aftermarket service; separate software and subscription are required

Value Added Software

Computer Setup Utility McAfee Total Protection Anti-Virus* Roxio Creator Business HP Power Assistant

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to receive updates. First update included. Subscription required for updates thereafter

HP Client Management Solutions

http://www.hp.com/go/easydeploy

HP Client Automation Starter HP SoftPaq Download Manager

* Available from your HP Sales Representative or HP Channel Partner

(included with all models; not included when configured with FreeDOS)

HP Insight Diagnostics PDF Complete

(included with select models; not included when configured with FreeDOS)

Microsoft Office Trial Version Mozilla Firefox for HP Virtual Browser Corel WinDVD

(available for free download from the Internet)

)

HP Client Catalog for Microsoft SMS HP Systems Software Manag

Value Added Services and Features

HP Stable Platform Program Intel Stable Platform Program Business-to-Business Portals HP Global Series Services

Factory Express Deployment and Lifecycle Services Intel Standard Manageability Intel® Core™ processor with vPro™ technology Trusted Platform Module (TPM) v1.2

TPM module disabled where restricted by law; for example, Russia.

Service and Support

On-site warranty and service¹: three year (3/3/3) limited warranty and service offering delivers three years of parts, labor and on-site repair. Response time is next business day² and includes free telephone support³ 24 x 7. Global coverage² ensures any product purchased in one country and transferred to another non-restricted country will remain fully covered under the original warranty and service offering. Some countries/regions do not offer one year onsite and labor.

Terms and conditions may vary by country. Certain restrictions and exclusions apply.

On-site services may be provided pursuant to a service contract between HP and an authorized HP third party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

Technical telephone support applies only to HP configured, HP and HP qualified third party hardware and software. Tollfree calling and 24 x 7 support may not be available in some countries.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 5

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Power Supply

Standard Efficiency High Efficiency

Operating Voltage Range

Ports

USB 2.0

Serial Parallel eSATA PS/2 Video DVI output Audio

NIC

Slots

Type and quantity

Slot specifications

Chipset

Small Form Factor

240W active PFC 320W active PFC 240W active PFC

87/89/85% efficient at 20/50/100% load 90 – 264 VAC 90 – 264 VAC

Front – four (4) ports Rear – six (6) ports

One port standard; second port available optionally One port available optionally One port available optionally Color coded support for keyboard (purple) and mouse (green) VGA and DisplayPort provide integrated dual independent monitor support Available via optional DisplayPort to DVI Adapter Front – microphone & headphone

Rear – line input (supports microphone or line input), line out

NOTE:

also supports audio.

Industry standard RJ-45 port accesses the integrated network interface controller

Low Profile 25W max. cards

Intel Q57 Express supporting Intel® Core™ processor with vPro™ technology

See Audio/Visual section for information on re-taskable audio ports. DisplayPort

(1) PCI

(1) PCI Express x1

(2) PCI Express x16

320W active PFC 87/89/85% efficient at 20/50/100% load

Full height 75W max. for cards in both x16 slots Primary x16 slot supports 75W or 35W card Secondary x16 slot supports 35W card when primary slot is limited to 35W card Secondary slot functions electrically as an x4 slot

Convertible Minitower

(3) PCI

(1) PCI Express x1 (half-length)

(2) PCI Express x16

Processors

NOTE:

all models configured with Intel® Core™ processors with 4 cores require a discrete graphics solution

Intel Pentium Processors:

Intel Pentium G6950 Processor

2.80 GHz, 3M total cache 2 cores/2 threads Integrated Intel® HD Graphics

Intel Core i3 Processors:

Intel Core i3-530 Processor

2.93 GHz, 4M total cache 2 cores/4 threads Integrated Intel® HD Graphics

Intel Core i3-540 Processor

3.06 GHz, 4M total cache 2 cores/4 threads Integrated Intel® HD Graphics

Intel Core i5 Processors:

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 6

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Intel Core i5-650 Processor

3.2 GHz, 4M total cache 2 cores/4 threads Integrated Intel® HD Graphics Intel® Core™ processor with vPro™ technology Intel® Stable Image Platform Program (SIPP)

Intel Core i5-660 Processor

3.33 GHz, 4M total cache 2 cores/4 threads Integrated Intel® HD Graphics Intel® Core™ processor with vPro™ technology Intel® Stable Image Platform Program (SIPP)

Intel Core i5-670 Processor

3.46 GHz, 4M total cache 2 cores/4 threads Integrated Intel® HD Graphics Intel® Core™ processor with vPro™ technology Intel® Stable Image Platform Program (SIPP)

Intel Core i5-750 Processor

2.66 GHz, 8M total cache 4 cores/4 threads Requires a discrete graphics solution

Intel Core i5-750S (low power) Processor

2.40 GHz, 8M total cache 4 cores/4 threads Requires a discrete graphics solution

Intel Core i7 Processors:

Intel Core i7-860 Processor

2.80 GHz, 8M total cache 4 cores/8 threads Requires a discrete graphics solution Intel® Core™ processor with vPro™ technology Intel® Stable Image Platform Program (SIPP)

Intel Core i7-870 Processor

2.93 GHz, 8M total cache 4 cores/8 threads Requires a discrete graphics solution Intel® Core™ processor with vPro™ technology Intel® Stable Image Platform Program (SIPP)

Redundant Array of Independent Drives (RAID)

DriveLock is supported while in RAID mode. Users can manage the DriveLock password from within F10 Setup. Locked drives will be displayed as such in the RAID option ROM interface. Hard drive information can be viewed within F10 Setup while in RAID mode. Previously, the hard drives will not appear in Drive Configuration when switching to RAID mode. DPS Self Test can be executed on physical hard drives while in RAID mode. The RAID Setup Utility (accessed through CTRL-I) can be protected by the F10 Setup password.

NOTE:

RAID 1 is the only RAID configuration offered via factory configurations. The pre-configured systems:

Are complete RAID systems and have both drives installed. If the CMT is configured with three hard disk drives, the third drive is would be unpartitioned and not part of the RAID array Have the necessary Option ROM configuration. Are pre-loaded and pre-installed with all required Intel software. Include a preinstalled operating system that is mirrored mode out of the box.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 7

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Please refer to the HP White Paper titled "Advanced Host Controller Interface (AHCI) and Redundant Array of Independent Disks (RAID) on HP Compaq 8100 Elite Series PCs" at:

http://www.hp.com

for more information and instructions.

DDR3 Synchronous DRAM NON-ECC System Memory

Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible memory configurations. The HP Compaq 8100 Elite Series PC supports non-ECC DDR3 PC3-10600 (1333 MHz)* and PC3-8500 (1066 MHz)* memory.

CAUTION:

Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.

Supports up to 16 GB of DDR3 SDRAM using DIMM modules. Slot 1 is black and must always be populated. Not all memory configurations possible are represented below.

NOTE:

available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.

(single channel)

* The Intel Q57 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability functions. Management Engine memory is shared with system memory. If the PC contains a single DIMM, 16 MB of memory is pre-allocated for it at system startup. If the PC contains two DIMMs, 32 MB of memory is pre-allocated. This memory is not made available to the operating system, just as pre-allocated video memory is not available.

You must shut down the computer and disconnect the power cord before adding or removing memory modules.

For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be

Total Memory

1GB

2 GB

(dual channel)

4 GB

(dual channel)

8 GB

(dual channel)

16 GB

(dual channel)

Channel A Channel B

(black)

1 GB

1 GB 1 GB 1 GB 1 GB

2 GB 2 GB 2 GB 2 GB

4 GB 4 GB 4 GB 4 GB

2 (white) 3 (white) 4 (white)

Slot

1 GB

Memory Configurations

1GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (1 x 1GB)

2GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (1 x 2GB)

3GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (1GB + 2GB)

4GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (1 x 4GB)

4GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (2 x 2GB)

8GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (2 x 4GB)

8GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (4 x 2GB)

16GB DDR3 SDRAM PC3-10600 (1333MHz) non ECC (4 x 4GB)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 8

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Expandability

PCI slot

PCI Express x16 slot

PCI Express x1 slot

External Drive Bays

3.5"

5.25"

Internal Drive Bays

Small Form Factor

(1) slot Low profile (2.5”); Half length (6.6”) 25W max. power

(2) slots Low profile (2.5”); Half length (6.6”) 25W max. power Secondary slot functions electrically as an x4 slot

(1) slot Low profile (2.5”); Half length (6.6”) 10W max. power

(1) bay available for Media Card Reader unless used for a secondary hard drive

1 bay (8.19" depth)

1 bay for primary hard disk drive

Convertible Minitower

(3) slots Full height (4.2”); Full length 25W max. power

Full height (4.2”); Full length 75W max. for cards in both x16 slots Primary x16 slot supports 75W or 35W card Secondary x16 slot supports 35W card when primary slot is limited to 35W card Secondary slot functions electrically as an x4 slot

(1) slot Half height; Half length 10W max. power

N/A

NOTE

Top two bays accept drives up to 8.19”

Bottom bay accepts drives up to 5.7”depth

: A 3.5”device can be used in

5.25” bay with an adapter.

3 bays

depth

3 bays for 3.5” hard disk drives

Hard Drive Controller SATA Interfaces

Host SATA Controller

Small Form Factor

A secondary HDD can be installed in 3.5” external bay if not used for an external device

Serial ATA with support for SATA 1.5-Gb/s and 3.0-Gb/s hard drives

(4) Serial ATA interfaces

NOTE

one that can optionally be used for eSATA

: Three common SATA ports and

Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a

description

of the hardware/software interface between system software and the host controller

hardware.

2.5" SSD can be installed with an adapter bracket

(5) Serial ATA interfaces

NOTE

one that can optionally be used for eSATA

: Four common SATA ports and

Convertible Minitower

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 9

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Storage – Drive Support

Quantity Supported

Position

MCR

1 1 2 1 2 3 1 3

Hard Disk Drives

160GB Hard Disk Drive 7,200 rpm, 8MB cache, 3.0 GB/s, 3.5” drive

160GB Hard Disk Drive 10,000 rpm, 16MB cache, 3.0 GB/s, 2.5” drive (includes 3.5” adapter)

160GB Removable Hard Disk Drive 7,200 rpm, 8MB cache, 3.0 GB/s

250GB Hard Disk Drive 7,200 rpm, 8MB cache, 3.0 GB/s, 3.5” drive

250GB Removable Hard Disk Drive 7,200 rpm, 8MB cache, 3.0 GB/s

SFF

ODD

HDD

SSD

2,1

MCR

CMT

ODD

1,2

HDD

SSD

4,5,6

320GB Hard Disk Drive 7,200 rpm, 8MB cache, 3.0 GB/s, 3.5” drive

500GB Hard Disk Drive 7,200 rpm, 16MB cache, 3.0 GB/s, 3.5” drive

1 TB Hard Disk Drive 7,200 rpm, 16MB cache, 3.0 GB/s, 3.5” drive

Solid State Drives

64GB Solid State Drive

2.5" drive (includes 3.5” adapter)

Optical Disc Drives (5.25”)

DVD-ROM Drive

SuperMulti LightScribe DVD Writer Drive

Blu-Ray Writer Drive

For playing DVDs, Corel WinDVD 8

For writing CDs, choice of Sonic/Roxio Easy Media Creator 9 orRoxio Business Creator 10

For writing CDs and DVDs, video editing and authoring DVDs, choice of Sonic/Roxio Easy Media Creator 9 or Roxio

Business Creator 10

1,2,3

Media Card Readers

Media Card Reader (22-in-1)

Media Card Reader (22-in-1) with 1394 port

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 10

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Security

Trusted Platform Module (TPM) 1.2

Stringent Security (via BIOS)

SATA Port Disablement (via BIOS)

Drive Lock

RAID Configurations

HP ProtectTools security software

Serial, Parallel, USB enable/disable (via BIOS)

Optional USB Port Disable at factory (user configurable via BIOS)

Removable Media Write/Boot Control

Power-On Password (via BIOS)

Setup Password (via BIOS)

Solenoid Hood Lock / Sensor

Support for chassis padlocks and cable lock devices

TPM module disabled where use is restricted by law; for example, Russia.

This setting is defaulted to disable, but when enabled, the PW jumper will not clear the BIOS pre-boot authentication

passwords.

Network Interface Connection

Intel 82578 GbE Network Connection (integrated)

Intel Gigabit CT Desktop NIC Card

Broadcom NetXtreme GbE Ethernet Plus NIC (PCIe x1)

NOTE:

The integrated network connection is required to support the vPro Technology features.

HP 802.11 b/g/n Wireless NIC (PCIe x1)

NOTE:

These wireless network interface solutions will disable the vPro Technology features.

Modem

LSI Hi-Speed 56K International Soft Modem (PCIe x1)

Graphics

Integrated graphics with Intel Pentium processor, Intel Core i3 processors, and select Intel Core i5 processors:

Intel HD Graphics (integrated) on selected models

Available discrete graphics cards:

NVIDIA GeForce 310 DP PCIe x16 Graphics Card

Nvidia Quadro NVS 290 Graphics Card

Nvidia Quadro NVS 295 Graphics Card

ATI Radeon HD 4550 Graphics Card

ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card (CMT only)

HP ADD2 SDVO + DVI-D Video Adapter

HP DisplayPort to DVI-D Adapter

HP DisplayPort to VGA Adapter

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 11

QuickSpecs

HP Compaq 8100 Elite PC

Standard Features and Configurable Components (availability may vary by country)

Audio/Visual

High Definition Audio with Realtek ALC261 codec (all ports are stereo)

Microphone/Headphone* and dedicated headphone front ports

Line-out and Line-In rear Ports*

Multi-streaming capable*

Internal Speaker (standard)

HP Thin USB Powered Speakers

HP TV Tuner (Americas) PCIe x1 Card

* The front microphone port is re-taskable as a Line-in, Microphone-in or Headphone . Rear audio input ports are retaskable as Line-in or Microphone-in. External speakers must be powered externally. Multistreaming can be enabled in the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks. This allows for different audio applications to use separate audio ports on the system. For example, the front jacks could be used with a headset for a communications application while the rear jacks are being used with external speakers and a multimedia application.

Input Devices

HP PS/2 Standard Keyboard

HP USB Standard Keyboard

HP USB SmartCard Keyboard

HP USB Mini Keyboard

HP USB & PS/2 Washable Keyboard

PS/2 Optical Scroll Mouse

USB Optical Scroll Mouse

USB Laser Scroll Mouse

Miscellaneous

HP FireWire (IEEE 1394) Card

HP Serial Port Adapter

HP Parallel Port Adapter

HP eSATA Port Adapter

HP Small Form Factor PC Tower Stand

Configure CMT in desktop orientation

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 12

QuickSpecs

After-Market Options (availability may vary by region)

HP Compaq 8100 Elite PC

Communications

HP Wireless 802.11 b/g/n NIC Card

Broadcom NetXtreme GbE Ethernet Plus NIC Card

Intel Gigabit CT Desktop NIC Card

LSI Hi-Speed 56K Int'l Soft Modem Card

RJ11 Modem Adapter Kit

NOTE:

The use of a NIC Card (wired or wireless) will disable the vPro Technology features.

Graphics

ATI Radeon HD 4550 Graphics Card

ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card

Nvidia Quadro NVS 290 Graphics Card

Nvidia Quadro NVS 295 Graphics Card

Nvidia GeForce 310 DP PCIe x16 Graphics Card

DMS59 DVI Dual-head Connector Cable

HP DVI to DVI cable

HP DisplayPort To DVI-D adapter

HP DisplayPort To DL DVI-D adapter

HP DisplayPort to VGA Adapter

HP DisplayPort Cable Kit

Part Number

FH971AA

FS215AA

FH969AA

FH970AA

DC131C

Part Number

AT042AA

VN566AA

KG748AA

FY943AA

VG885AA

DL139A

DC198A

FH973AA

NR078AA

AS615AA

VN567AA

Hard Disk Drives

HP 160GB SATA NCQ SMART IV Hard Disk Drive

HP 250GB SATA NCQ SMART IV Hard Disk Drive

HP 500GB SATA NCQ SMART IV Hard Disk Drive

HP eSATA Adapter

HP Removable SATA Hard Drive Enclosure (frame & carrier)

HP Removable SATA Hard Drive Enclosure (Carrier Only)

Input/Output Devices

HP PS/2 Standard Keyboard

HP USB Standard Keyboard

HP USB Gray Keyboard

HP 2.4GHz Wireless Keyboard & Mouse

HP USB Mini Keyboard

HP USB Washable Keyboard

HP PS/2 Optical Scroll Mouse

HP USB Optical Scroll Mouse

HP USB Laser Mouse

Part Number

PY277AT

PY278AA

KW347AA

FH966AA

RY102AA

RY103AA

Part Number

DT527A

DT528A

DT529A

NB896AA#xxx

AS601AA

VF097AA

EY703AA

DC172B

GW405AA

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 13

QuickSpecs

After-Market Options (availability may vary by region)

HP Compaq 8100 Elite PC

DDR3 SDRAM System Memory

1 GB DIMM

2 GB DIMM

HP 4-GB PC3-10600 (DDR3-1333 MHz) DIMM

HP Monitors

All HP monitors are supported that accept a graphics output provided by this PC.

Multimedia Devices

HP Thin USB Powered Speakers

DVD-ROM Drive

SuperMulti LightScribe Drive

Blu-Ray Writer Drive

Removable Media Storage

HP USB External Diskette Drive

HP Media Card Reader (22-in-1)

HP Media Card Reader (22-in-1) with FireWire (IEEE 1394)

Part Number

AT023AA

AT024AA

VH638AA

Part Number

KK912AA

AR629AA

AR630AA

AR482AA

Part Number

DC141B

AR941AA

AR942AA

Security Devices

HP/Kensington MicroSaver Cable Lock

HP Business PC Security Lock

HP (2009) SFF Wall Mount/Security Sleeve

HP 2009 (SFF) Solenoid Lock and Hood Sensor

HP (CMT) Solenoid Lock and Hood

HP ProtectTools Version 5.0 (1 User) Software

HP USB SmartCard Keyboard

Software Solutions

HP Client Automation Standard

Stands and Accessories

HP (2009) SFF Tower Stand

HP Serial Port Adapter

HP Parallel Port Adapter

HP 5.25” Blank Bezel Kit (50 pack)

HP FireWire (IEEE 1394) Card

Part Number

PC766A

PV606AA

VN570AA

BP428AA

DE618A

VR893AA

ED707AA

Part Number

T3488AA (qty 1)

TA599AA (qty 10) TA600AA (qty 100) TA601AA (qty 500)

T3489AA (qty

1000)

Part Number

VN568AA

PA716A

KD061AA

DC177B

PA997A

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 14

QuickSpecs

Technical Specifications

HP Compaq 8100 Elite PC

Dimensions

Chassis (H x W x D)

System Volume

Tower Stand (H x W x D)

Packaging (H x W x D)

System Weight

Shipping Weight

Max Supported Weight (desktop orientation)

*Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.

3.95 x 13.30 x 14.9 in 100 x 338 x 378.5 mm

790.26 cu in

12.95 L

1.12 x 7.01 x 7.87 in

28.5 x 178 x 200 mm

9.00 x 19.68 x 23.38 in

228.6 x 499.9 x 593.85 mm

16.72 lbs

7.6 kg

17.86 lbs

8.1 kg 77 lb

35 kg

Small Form Factor

Convertible Minitower

17.63 x 7.00 x 17.5 in

447.8 x 177.8 x 444.5 mm 2160 cu in

35.4 L N/A

22.64 x 12.72 x 24.41 in

575.0 x 323 x 620 mm

24.54 lbs

11.15 kg

34.0 lbs

15.42 kg 77 lbs

35 kg

Unit Environment and Operating Conditions

General Unit Operating Guidelines

Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is operated within the specified operating range. Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow. Never restrict airflow into the computer by blocking any vents or air intakes. Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-circulated or preheated air. Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign matter can block the vents and limit the airflow. If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure, and the same operating guidelines listed above will still apply.

Temperature Range

Relative Humidity

Maximum Altitude (unpressurized)

*Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.

Operating: 10% to 90% (non-condensing at ambient)

Non-operating: 5% to 95% (non-condensing at ambient)

Operating: 50° to 95° F (10° to 35° C)

Non-operating: –22° to 140° F(–30° to 60° C)

Operating: 10,000 ft (3048 m)

Non-operating: 30,000 ft (9144 m)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 15

QuickSpecs

Technical Specifications

HP Compaq 8100 Elite PC

Power Supply

Standard Efficiency

High Efficiency

Operating Voltage Range Rated Voltage Range Rated Line Frequency Operating Line Frequency

Range Rated Input Current Rated Input Current with

Energy Efficient Supply

Current Leakage (NFPA 99)

System Heat Dissipation

System Heat Dissipation with Energy Efficient Supply

Power Supply Fan External Power Adapter Dimensions Total Cord Length

*High efficiency power supply is a requirement for ENERGY STAR qualification in conjunction with a select range of processors and modules

* Power

240W standard efficiency active PFC

240W 89% efficient active PFC

90 – 264 VAC 90 – 264 VAC 100 – 240 VAC 100 – 240 VAC 50/60 Hz 50/60 Hz 47 – 63 Hz 47 – 63 Hz

4A 4A

< 275 µA < 450 µA

Typical 198 btu/hr (50 kg-cal/hr) Maximum 818 btu/hr (204 kg-cal/hr)

Typical 150 btu/hr (38 kg-cal/hr) Maximum 818 btu/hr (204 kg-cal/hr)

92mm variable speed

N/A N/A

SFF

320W standard efficiency active PFC

320W 89% efficient active PFC

5.5A

Typical 222 btu/hr (56 kg-cal/hr) Maximum 1091 btu/hr (272 kg-cal/hr)

Typical 171 btu/hr (43 kg-cal/hr) Maximum 1091 btu/hr (272 kg-cal/hr)

92mm variable speed

N/A N/A

CMT

ROM BIOS Information

Key features of the HP BIOS include:

Deployment and manageability – HP BIOS provides several technologies that help integrate the HP Elite PC into the enterprise, such as PXE, remote configuration, remote control, and F10 Setup support for 12 languages. Select models feature either Intel Standard Manageability or Core 2 processor with vPro Technology. Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification. Computrace agent – For tracking and tracing services, available in select countries, separate software and purchase of a subscription is required. Thermal and power management – The HP BIOS provides and enables thermal and power management technologies so component temperatures are managed for high reliability and to assist in operating the HP Business Desktop computer in any enterprise environment. Acoustic performance – Industry leading acoustic emissions across the range of operating conditions. Serviceability – HP BIOS provides diagnostic and detailed service information. Upgrades and recovery – HP BIOS provides numerous ways to upgrade HP Business Desktop computers, including BIOS updates from within DOS (Flashbin), BIOS updates from within Windows (HPQFlash), HP Client Manager, and fail-safe recovery. In addition, the HP Business Desktop BIOS Utilities tool enables replicated BIOS setup throughout the Enterprise; it is available from within the BIOS software and from the support website.

Additional HP BIOS Features

Power-On password – Helps prevent an unauthorized user from powering on the system. Administrator password – Also known as the setup password, this helps prevent unauthorized changes to the system configuration. If the administrator password is not known, the BIOS version cannot be changed and changes cannot

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 16

QuickSpecs

HP Compaq 8100 Elite PC

Technical Specifications

be made to BIOS settings using F10 setup or under the OS. Advanced Configuration and Power Interface (ACPI) – Represents a significant innovation in power and configuration management, allowing operating systems and applications to manage power based on activity and usage. HP Elite models use ACPI to provide power conservation features. S5 Max Power Savings setting supports EU Lot6 requirement and allows the computer to power down below 1W is S5 (when turned off). When S5 Max Power Savings feature is enabled power to slots is turned off along with WOL functionality.

Other Features

Advanced Configuration and Power Management Interface (ACPI). Allows the system to wake from a low power mode. Controls system power consumption, making it possible to place individual cards and peripherals in a lowpower or powered-off state without affecting other elements of the system. System Management BIOS v2.6 Intel Wired for Management support; industry wide initiative to make Intel architecture based PCs, servers and mobile computers more inherently manageable out-of-the-box and over the network Dual State Power Button; acts as both an on/off button and a suspend-to-sleep button

Serviceability Features

Dual colored power LED on front of computer to indicate either normal or fault condition Diagnostic LED Explanation Table:

Number of 1-second red LED blinks followed by a 2-second pause, then repeats:

2 – processor thermal protection activated 3 – processor not installed 4 – power supply failure 5 – memory error 6 – video error 7 – PCA failure (ROM detected failure prior to video) 8 – invalid ROM, bootblock recovery mode 9 – system not fetching code

10 – system hang while loading an option ROM System/Emergency ROM Flash ROM CMOS Battery Holder for easy replacement Flash Recovery with Video Configuration Record Software 5 Aux Power LED on System PCA Processor ZIF Socket for easy Upgrade Over-Temp Warning on Screen (Requires IM Agents) Clear Password Jumper DIMM Connectors for easy Upgrade Clear CMOS Button NIC LEDs (integrated) (Green & Amber) Dual Color Power and HD LED - To Indicate Normal Operations and Fault Conditions Color coordinated cables and connectors Tool-less Hood Removal Front power switch System memory can be upgraded without removing the system board or any internal components Tool-less Hard Drive, CD & Diskette Removal Green Pull Tabs, and Quick Release Latches for easy Identification

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 17

QuickSpecs

Technical Specifications

HP Compaq 8100 Elite PC

Additional Features

Computrace DT or MT Orientation Drive Lock

Drive Protection System

SMART Technology (Self-Monitoring, Analysis and Reporting Technology)

SMART I – Drive Failure Prediction

SMART II – Off-Line Data Collection

SMART III – Off-Line Read Scanning with Defect Reallocation

SMART IV – End-to-End CRC for hard drives

Description

Computrace agent included; separate software and subscription required Product can be oriented in either a tower or desktop orientation Implementation of the industry standard ATA Security feature set. When enabled,

it prevents software access to user data on the drive until one or two user-defined passwords are provided.

DPS Access through F10 Setup during Boot

A diagnostic hard drive self test. It scans critical physical components and every sector of the hard drive for physical faults and then reports any faults to the user. Running independently of the operating system, it can be accessed through a Windows-based diagnostics utility or through the computer's setup procedure. It produces an evaluation on whether the hard drive is the source of the problem and needs to be replaced.

The system expands on the Self-Monitoring, Analysis, and Reporting Technology (SMART), a continuously running systems diagnostic that alerts the user to certain types of failures.

Allows hard drives to monitor their own health and to raise flags if imminent failures were predicted

Predicts failures before they occur. Tracks fault prediction and failure indication parameters such as re-allocated sector count, spin retry count, calibration retry count By avoiding actual hard drive failures, SMART hard drives act as "insurance" against unplanned user downtime and potential data loss from hard drive failure IOEDC: I/O Error Detection Circuitry Detects errors in Read/Write buffers on HDD cache RAM

Interface in F10 setup provides confirmation of SMART IV support.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 18

QuickSpecs

Technical Specifications - Audio

HP Compaq 8100 Elite PC

High Definition Audio

Type

High Definition Stereo Codec

Audio Jacks

Internal Speaker Amplifier is for the internal speaker only. External speakers need to be powered externally. Rear Line-In audio port is re-task able as Line-In or Microphone-In.

Multistreaming Capable

Sampling

Wavetable Syntheses

(software)

Analog Audio

Number of Channels on Line-Out

(mono/stereo)

Internal Audio Speaker Power Rating

Internal Speaker

External Speaker Jack

(Line-Out)

Integrated

Yes - Realtek 4-channel ALC261 codec

Front microphone-In (150-K ohm Input Impedance)

Rear Line-In/Microphone input (150-K ohm Input Impedance, function is configurable by audio driver)

Rear Line-Out* (190 ohms Output Impedance, expects at least a 10-K ohm load)

Front Headphone-Out (0.5 Ohm Output Impedance, expects at least a 32 ohm load) Front Microphone/Headphone jack is re-task able to provide Microphone input, line-in or Headphone output to support connecting two headphones to the front of the system. When configured as a second front headphone output, both front headphone outputs are always driven with the same signal.

Multistreaming can be enabled in the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks.

8 kHz - 192 kHz

Yes - Uses OS soft wavetable

Yes

Stereo (Left & Right channels)

1.5 W

Yes

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 19

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

Intel 82578 Gigabit Network Connection (integrated)

Connector

Controller

Memory

Data rates supported

Compliance

Bus architecture

Data transfer mode

Hardware certifications

Power requirement

Boot ROM support

Network transfer mode

Network transfer rate

Environmental

Management capabilities

Alerting

RJ-45

Intel 82578 Gigabit platform LAN Connect Networking Controller

24 KB FIFO packet buffer memory

10/100/1000 Mbps

IEEE 802.3i (10Base-T) IEEE 802.3u (100Base-TX) IEEE 802.3ab (1000Base-T) IEEE 802.3u (Auto-negotiation) IEEE 802.3af (Power over Ethernet) IEEE 1588 (Time Sync) IEEE 802.1ae (MacSec)

PCIe-based MAC to PHY interface

PCIe-like interface for 1000 speed, SMBus interface for lower 10/100 speeds.

FCC B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for European Union

Requires 3.3V & 1.2V. Power consumption 761 Milliwatts

Yes

Full-duplex

Half-duplex (not supported for the 1000BASE-T transceiver)

10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps

100BASE-TX (half-duplex) 100 Mbps

100BASE-TX (full-duplex) 200 Mbps

1000BASE-T (full-duplex) 2000 Mbps

Operating temperature

WOL, auto MDI crossover, PXE, Muti-port teaming, RSS, Advanced cable diagnostic.

AMT 6.0 support

0° to 85° C

Broadcom NetXtreme GbE Ethernet Plus NIC

Connector

Controller

Memory

Data rates supported

Compliance

Bus architecture

Data path width

Data transfer mode

Hardware certifications

Power requirement

Boot ROM support

Network transfer mode

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

RJ-45

Broadcom 5761 PCI-Express LAN Controller

8 MB NVRAM serial Flash

10/100/1000 Mbps

IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3AB, 802.3u, and 802.3x

PCI-Express

Single Channel PCI-Express

Bus Master DMA

FCC class B, Canada and US NRTL Mark, C-Tick for Australia, BSMI for Taiwan, VCCI for Japan, MIC for Korea, GOST for Russia, UL listed (E212044), European Union Notice (CE 0682)

1.8W @ 3.3V

Yes

Full-duplex

Half-duplex (not available for the 1000BASE-T transceiver)

Page 20

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

Intel Gigabit CT Desktop NIC

Network transfer rate

Environmental

Dimensions

Operating system driver support

Management capabilities

Connector

Controller

Memory

Data rates supported

Compliance

Bus architecture

Data path width

Data transfer mode

Hardware certifications

Power requirement

Boot ROM support

Network transfer rate

Environmental

Dimensions

10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps

100BASE-TX (half-duplex) 100 Mbps

100BASE-TX (full-duplex) 200 Mbps

1000BASE-T (full-duplex) 2000 Mbps

Operating temperature

Operating humidity

2.75 in x 4.13 in (7 cm x 10.5 cm), low profile compatible

Windows Vista 32-bit SP1, Windows Vista x64 SP1, Windows XP 32 bit professional

ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility, ASF2.0, DASH 1.0 and DASH 1.1 profiles

RJ-45

Intel 82574L Gigabit Ethernet Controller

40KB configurable transmit/receive FIFO Buffers

10/100/1000 Mbps

IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,

802.3x flow control, 802.1as Time synch offload

PCIe Base 1.1 (2.5 GT/s) x1

X1, 250 MB/s, Bi-directional interface

Bus-master DMA

(see EPS for more certification details) EMI: FCC Class B Intel 25-GS3000 Environmental Specification. EN-55024: 1998 specification (see EPS for details) EN-55022: Class A 1998 specification. EN-60950-1 first Edition specification. C-Tick specification, Class A VCCI Class 1 specification. CE specification and CE Mark. UL 60950-1 first Edition specification. CSA 60950-1 first Edition specification. BSMI CNS13438 Class A specification Korean MIC Class A specification. European RoHS directive China RoHS directive

3.3V and 3.3V Aux, 2.1 Watts max in 1000Base-T (D0)

Yes

10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps

100BASE-TX (half-duplex) 100 Mbps

100BASE-TX (full-duplex) 200 Mbps

1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)

Operating temperature

Operating humidity

Low-profile, half-length form factor conforming to PCIe* CEM v1.1 (55 mm x 119 mm)

32° to 131°F (0° to 55° C)

131° F (55° C) with 5% to 95% noncondensing humidity

0 °C to 55 °C (operating)

-40 to 70 °C (non-operating)

85% at 131° F (55° C)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 21

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

HP Wireless

802.11b/g/n (PCIe)

Management capabilities

Dimensions

Weight

Controller

System interface

Network standard

Frequency band

Operating temperature

Storage temperature

Humidity

Operating voltage

Power consumption

Output power

(approximately)

Receive sensitivity

(L x H)

SMBus, WOL, PXE

3.3 x 4.7 inches (8.5 x 12 cm)

0.08 pounds (40 g)

Ralink RT2790

PCIExpress x1

802.11 b/g/n

2.400 - 2.497 GHz

14° to 149°F, operating (-10° to 65°C, operating)

-40° to 176°F, non-operating (-40° to 80°C, non-operating)

10-90% operating 5-95% non-operating

3.3V +/- 9% 12V +/- 8%

Platform/WLAN Mode

Maximum Power Consumption

Transmit Only

Transmit Packet or Active Scanning

Receive Only Mode or Idle without IEEE PSP mode enabled

Idle, with IEEE PSP mode enabled

Transmit Disabled (turned off in software)

Platform in S3 or S4 (power removed from Low Profile PCI Express Card)

802.11b modes 802.11g modes

+19 dBm +/- 1.0 dB maximum

Mode

802.11b

802.11g

EWC (2.4 GHz)

Power Consumption

10 Watts

4 Watts maximum averaged power over 1 second

1000 mA peak current for 100 microseconds or longer

3 Watts maximum averaged over 1 second

1.0 Watts maximum averaged over 1 second

50 mW maximum, averaged over 1 second

5 mW maximum, averaged over 1 second

EWC modes

+17 dBm +/- 1.0 dB maximum

Data rate

1 Mbps

11 Mbps

6 Mbps

18 Mbps

48 Mbps

54 Mbps

6.5 Mbps

54 Mbps

81 Mbps

162 Mbps

270 Mbps

+17 dBm +/- 1.0 dB maximum (total power in all transmit chains)

Sensitivity

-94 dBm

-85 dBm

-91 dBm

-85 dBm

-75 dBm

-72 dBm

-87 dBm

-82 dBm

-78 dBm

-74 dBm

-68 dBm

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 22

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

Data transfer rate

Security

EWC (2.4 GHz)

Data Rate (MCS)

1 Mbps (802.11 b)

2 Mbps (802.11 b)

5.5 Mbps (802.11 b)

11 Mbps (802.11 b)

12 Mbps (802.11 g)

18 Mbps (802.11 g)

24 Mbps (802.11 g)

36 Mbps (802.11 g)

48 Mbps (802.11 g)

54 Mbps (802.11 g)

6.5 Mbps (20 MHz EWC)

13 Mbps (20 MHz EWC)

19.5 Mbps (20 MHz EWC)

26 Mbps (20 MHz EWC)

39 Mbps (20 MHz EWC)

52 Mbps (20 MHz EWC)

58.5 Mbps (20 MHz EWC)

65 Mbps (20 MHz EWC)

78 Mbps (20 MHz EWC)

104 Mbps (20 MHz EWC)

117 Mbps (20 MHz EWC)

130 Mbps (20 MHz EWC)

13.5 Mbps (40 MHz EWC)

27 Mbps (40 MHz EWC)

40.5 Mbps (40 MHz EWC)

54 Mbps (40 MHz EWC)

81 Mbps (40 MHz EWC)

108 Mbps (40 MHz EWC)

121.5 Mbps (40 MHz EWC)

135 Mbps (40 MHz EWC)

IEEE and WiFi compliant 64 / 128 bit WEP encryption AES: CCM

802.1x authentication WPA: 802.1x. WPA-PSK and TKIP WPA2 certification IEEE 802.11i Cisco Certified Extensions, all versions through V5

300 Mbps

Minimum Throughput

700 kbps

1.4 Mbps

3.5 Mbps

5.9 Mbps

6 Mbps

9 Mbps

12 Mbps

18 Mbps

21 Mbps

22.5 Mbps

4.5 Mbps

9 Mbps

13.5 Mbps

18 Mbps

27 Mbps

36 Mbps

40 Mbps

45 Mbps

54 Mbps

72 Mbps

81 Mbps

91 Mbps

8 Mbps

16 Mbps

24 Mbps

32 Mbps

48 Mbps

64 Mbps

72 Mbps

81 Mbps

-64 dBm

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 23

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

LSI PCIe x1 56K International SoftModem

Antenna

Certifications

Certifications for use by country

Data Transmission

Data Speeds

Data Standards

Fax Speeds

Fax Mode Capabilities

Error Correction and Data Compression

Power Management

Upgradeability

Video

Other

Operating Temperature

Operating Humidity

Power

Chipset

Dimensions

Connection

Other Features

Safety

EMC

Telecom

(L X H)

HP part number 497792-001

Wi-Fi certified

United States, Canada, Peru, Taiwan

Technology speeds: 56,000 Kbps maximum downstream data, controllerless

NOTE:

56 Kbps technology refers to download speeds only and requires compatible modems at server sites. Other conditions may limit modem speed. FCC limitations allow a maximum of 53 Kbps during download transmissions.

(Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/ 16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300

ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A, and Bell 103

14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s

ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2

V.44, 42bis, V.42 and MNP2-5

PCI Bus Power Management Interface Specification (PCI-PM) Revision

1.2, Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in D3cold. If the power management event (PME) feature is enabled in D3cold, a modem can wake the system via WAKE# (WAKEN) or beacon. Meets PCI Express 1.1 standard.

Driver upgradeable for future enhancements

ITU-T V.80 video ready interface

TIA/EIA 602 standard AT command set

Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a UART-compatible interface

Optional ring wakeup signal

32° to 158° F (0° to 70° C)

20% to 90%, non-condensing

Requires a 3.3-V auxiliary power rail on PCI express bus

Uses only one PCI express load (i.e., one grant/request pair), one shared IRQ, one electrical load

LSI SV92EX - Integrated PCI interface with 3.3-V tolerant buffers and CardBus support

Complies with PCI express low profile specifications-6.7 x 2.3 in (17.0 x

5.8 cm) and supports high- and low-profile brackets

Single RJ-11 connector

Digital line protection, call progress monitoring via on-board piezo device, support for high profile and low profile brackets, PnP ID support

UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO, SEMKO, CE mark

FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN 61000-4-6, EN 61000-4-8

FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals Not available in Korea or the Republic of South Africa.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 24

QuickSpecs

Technical Specifications - Communications

HP Compaq 8100 Elite PC

Other

The SV92EX device is packaged in a 32-pin micro leadless chip carrier (MLCC). The SV92EX is fully compliant with the PCI Express revision

1.1 specification. WHQL approved; ASPM compliant.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 25

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Intel® HD Graphics

3D/2D Controller

VGA Controller

DisplayPort

Bus Type

RAMDAC

Memory

Microsoft DirectX® 10 based with support for Pixel Shader 3.0

Integrated

Integrated, Multimode capable; supports HDCP

PCI Express™ x16

Integrated, 350 MHz

Graphics memory is shared with system memory. Graphics memory usage varies depending on the amount of system memory installed, BIOS settings, operating system, and system load. 32 MB is pre-allocated for graphics use at system boot time. Additional memory can be allocated at boot time by the BIOS for PAVP (Protected Audio Video Playback) support for playback of protected video content. For Vista, use of PAVP heavy mode preallocates an additional 96MB.

Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an optimal balance between graphics and system memory use.

Windows XP Memory Usage

Total System Memory

.5GB

1.0GB

1.5GB

2GB & more

Windows Vista Memory Usage

(Assumes Management Engine , VT-d enabled and other memory allocated for other BIOS usage)

System

Memory

1 GB

2 GB

4 GB

6 GB

8 GB

Total Available GFX Memory

reported by the OS.

PVAP

Lite Heavy Lite Heavy Lite Heavy Lite Heavy Lite Heavy

Pre-Allocated (MB)

32 128 32 512 32 768 32 1024

Avail

System

Memory

(MB)

952 252 32 96 124

856 294 122 6 166 1976 764 32 96 636 1880 806 122 6 678 4024 1759 32 96 1631 3928 1759 122 6 1631 6072 1759 32 96 1631 5976 1759 122 6 1631 8120 1759 32 96 1631 8024 1759 122 6 1631

Total Avail

GFX

Memory

(MB)

: Total graphics memory available to the system as

Dedicated

Video

Memory

(MB)

DVMT (MB)

System

Video

Memory

(MB)

Shared System

Memory

(MB)

HW Video Decode

Maximum Color Depth

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Dedicated Video Memory

reported by the OS. (Preallocated)

System Video Memory

Shared System Memory

Hardware Accelerated decode for MPEG2 encrypted video; support for PAVP Lite (default) and Heavy ( or Paranoid) modes

32 bits/pixel

: Memory owned and locked for graphics use as

: System memory locked and dedicated for graphics use.

: Memory dynamically allocated for Graphics use

Page 26

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Maximum Vertical Refresh Rate

Multi-display Support

Graphics/Video API Support

NOTE:

Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.

Resolution

640x480

800x600 1024x768 1280x720

1280x1024

1440x900

1600x1200 1680x1050 1920x1080 1920x1200 1920x1440 2048x1536 2560x1600

* Only supported when using a DisplayPort connection

NOTE:

60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital

connections.

85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and configuration. See table below.

Integrated dual independent monitor support facilitated via one VGA port and one DisplayPort integrated on the back plane of the system board and presented as part of the rear I/O set of interfaces. DVI supported via optional HP DisplayPort to DVI-D adapter.

Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver update)

Resolutions Supported

Maximum Refresh Rate (Hz)

Analog Connection

85 60 85 60 85 60 85 60 85 60 75 60 85 60 75 60 85 85 85 75

N/A

Digital Connection

60-R 60-R

N/A N/A

NVIDIA Quadro NVS 290 256MB PCIe Dual Head

Form Factor

Bus Type

Memory

Connector

Display resolution support

RAMDAC

Color planes

Overlay planes

nView architecture

Multi-Monitor support

DVI support

High-definition Video Processor

(HDVP)

Low Profile

PCIe x16

256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and Texture storage

DMS-59; includes one DMS-59 to Dual VGA cable. A DMS-59 to Dual DVI-I cable is available as an option.

Dual integrated analog display controllers supporting up to two analog displays at 2048x1536 @ 85Hz on both displays or dual digital displays at 1920x1200 (single-link). NVIEW advanced multi-display desktop and application management seamlessly integrated into Microsoft Windows

Integrated dual 400MHz

32-bit color buffer

Hardware supported

Advanced multi-display desktop & application management seamlessly integrated into Microsoft Windows.

Dual monitor support

DMS-59 (to dual DVI-SL)

Full-screen, full-frame video playback of HDTV and DVD content DVD-ready motion compensation for MPEG-2 Independent hardware color controls for video overlay Hardware color-space conversion (YUV 4:2:2 and 4:2:0)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 27

QuickSpecs

Technical Specifications - Graphics

Supported graphics APIs

HP Compaq 8100 Elite PC

IDCT motion compensation 5-tap horizontal by 3-tap vertical filtering 8:1 up/down scaling

OGL 2.1 & DX10 Support; Shader Model 4.0

NVIDIA Quadro NVS 295 Graphics Card

NVIDIA GeForce 310 DP PCIe x16 Graphics Card

NVIDIA GeForce 310 DP PCIe x16 Graphics Card display resolutions and refresh rates

NOTE:

Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.

Resolution

640x480

800x600 1024x768 1280x720

1280x1024

1440x900

1600x1200 1680x1050 1920x1080 1920x1200 1920x1440 2048x1536 2560x1600

* Only supported when using a dual-link DVI or DP connection.

NOTE:

60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital

connections.

Form Factor

Graphics Controller

Bus Type

Memory

Connectors

Maximum Resolution

Display Output

Supported Graphics APIs

Bus type

Maximum vertical refresh rate

Display support

Display max resolution

Board display options

2.731 inches (H) × 6.600 inches (L), Half-Height

NVIDIA Quadro NVS 295 Graphics Board

PCI Express x16, Generation 2.0

256 MB GDDR3 SDRAM unified graphics memory

2 DisplayPort Comes with 2 DisplayPort to VGA Adapters

NOTE:

with 2 DisplayPort to DVI-D adapters.

Two DisplayPort outputs drive two digital displays up to 2560 x 1600

OpenGL 3.0 DirectX 10.0

PCI Express (x16 lanes)

85 Hz

Integrated 400 MHz RAMDAC

2560x1600 digital, 2048 x 1536 analog

Analog Connection

Supports two displays via the DisplayPort and DVI connectors

When purchased as an after-market option, this comes instead

Drives DisplayPort enabled digital displays at resolutions up to 2560 × 1600 at 60 Hz with reduced blanking Drives DVI enabled digital displays at resolutions up to 1920 × 1200 at 60 Hz with reduced blanking (through DisplayPort to DVID (single link) cable)

85 60 85 60 85 60 85 60 85 60 75 60 85 60 75 60 85 85 85 75

N/A

Maximum Refresh Rate

(Hz)

Digital Connection

60-R 60-R

N/A N/A

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 28

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Board configuration

Audio Support

(through HDMI only)

Operating systems support

Specification

Graphics Chip

Core clock

Memory clock

Frame buffer

Integrated HD Audio codec supports linear PCM and Dolby® Digital (7.1) audio formats for HDMI output

Windows 7 Home Basic*, Windows 7 Home Premium*, Windows 7 Professional Edition 32*, Windows 7 Professional Edition 64*, Windows 7 Ultimate Edition 32*, Windows 7 Ultimate Edition 64*, Windows Vista Business 32†, Windows Vista Business 64†, Windows Vista Home Basic 32†, Windows Vista Home Basic 64†, Windows XP Professional or Windows XP Home 32†.

*This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See details.

Windows 7 Business disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to order at least 25 customer systems with the same custom image

Description

RV620

750 MHz

500 MHz

512 MB DDR3, 64 bit wide

http://www.microsoft.com/windows/windows-7/

for

Core power

Dimensions

Weight

Option kit contents

Compliance standards

(H x D)

† Certain Windows Vista product features require advanced or additional hardware. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:

http://www.windowsvista.com/upgradeadvisor

requirements, visit:

Linux x86 and x86_64 distributions using XFree86 or X.Org

‡Linux drivers are available from ATI's website and may be available in a Linux distribution. Refer to the Open Source and Linux from HP website:

http://www.hp.com/wwsolutions/linux/products/clients/

22 W (max)

2.71 in x 6.60 in (68.90 mm x 167.65 mm)

0.30 lb (134.3 g)

NVIDIA GeForce 310 DP PCIe x16 Graphics Cardwith full height bracket attached DVI to VGA adapter Software CD with graphics drivers Low profile bracket to convert the card for using in a low profile chassis Warranty documentation

EMC Emissions a) FCC Part 15, Subpart B - Unintentional Radiators, Class B Computing Devices for Home & Office Use b) CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods of measurement of radio disturbance characteristics of Information Technology Equipment c) Canadian Standard ICES-003 is equivalent to CISPR22 d) Taiwanese Standard BSMI e) Japanese VCCI f) Australian C-Tick g) Korean (MIC)

http://www.windowsvista.com/systemrequirements

. For Windows Vista system

‡.

for support information.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 29

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

ATI Radeon HD 4550 Dual Head PCIe x16 Graphics Card

EMC Immunity CISPR 24:1997/EN 55024:1998 - Information Technology Equipment Immunity Characteristics - Limits and Methods of Measurement.

Bus type

Maximum vertical refresh rate

Display support

Display max resolution

Board display options

Board configuration

Languages supported

Compliance standards

PCI Express (x16 lanes)

85 Hz

Integrated 400 MHz RAMDAC

1900 x 1200 digital, 2048 x 1536 analog

Supports two displays via included DMS-59 to dual VGA cable or 2 DVI monitors via optional DMS-59 to dual DVI cable kit part number: DL139A. 4-pin mini-DIN S-video connector for TV output

Specification

Graphics Chip

Core clock

Memory clock

Frame buffer

24 languages: English, Arabic, Chinese Simplified, Chinese Traditional, Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish

Description

RV710

600MHz

800 MHz

512 MB DDR3, 64 bit wide

EMC Immunity CISPR 24:1997/EN 55024:1998 - Information Technology Equipment - Immunity Characteristics - Limits and Methods of Measurement.

ATI Radeon HD 4550 DH PCIe x16 Graphics Card display resolutions and refresh rates

NOTE:

Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 30

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Resolution

Analog Connection

640x480

800x600 1024x768 1280x720

1280x1024

1440x900

1600x1200 1680x1050 1920x1080 1920x1200 1920x1440 2048x1536 2560x1600

NOTE:

60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital

connections.

ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card

ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card display resolutions and refresh rates

NOTE:

Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP

* Only supported when using a dual-link DVI or DP connection

NOTE:

60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital

connections

Bus type

Maximum vertical refresh rate

Display support

Display max resolution

Resolution

640x480

800x600 1024x768 1280x720

1280x1024

1440x900

1600x1200 1680x1050 1920x1080 1920x1200 1920x1440 2048x1536 2560x1600

Board display options

PCI Express (x16 lanes)

85 Hz

Integrated 400 MHz RAMDAC

2560 x 1600 digital, 2048 x 1536 analog

Analog Connection

Supports two displays via included two DisplayPort and one Dual Link DVI-I connectors.

85 60 85 60 85 60 85 60 85 60 75 60 85 60 75 60 85 85 85 75

N/A N/A

85 60 85 60 85 60 85 60 85 60 75 60 85 60 75 60 85 85 85 75

N/A

Maximum Refresh Rate (Hz)

Digital Connection

Maximum Refresh Rate

(Hz)

Digital Connection

60-R 60-R

N/A N/A

60-R 60-R

N/A N/A

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 31

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Board configuration

Languages supported

Operating systems support

Specification

Graphics Chip

Core clock

Memory clock

Frame buffer

Windows 7 Home Basic*, Windows 7 Home Premium*, Windows 7 Professional Edition 32*, Windows 7 Professional Edition 64*, Windows 7 Ultimate Edition 32*, Windows 7 Ultimate Edition 64*, Windows Vista Business 64**, Windows Vista Business 32**, Windows Vista Home Basic 32**, Windows XP Professional or Windows XP Home 32**.

*This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See details.

** Certain Windows Vista product features require advanced or additional hardware. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:

http://www.windowsvista.com/upgradeadvisor

requirements, visit:

http://www.windowsvista.com/systemrequirements

Description

RV635

725 MHz

500 MHz

1 GB DDR3, 128 bit wide

http://www.microsoft.com/windows/windows-7/

. For Windows Vista system

for

Core power

Option kit contents

Compliance standards

Linux x86 and x86_64 distributions using XFree86 or X.Org

*** Linux drivers are available from ATI's website and may be available in a Linux distribution. Refer to the Open Source and Linux from HP website:

http://www.hp.com/wwsolutions/linux/products/clients/

56 W

ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card with full height bracket attached DVI to VGA adapter DisplayPort to DVI-D adapter Software CD with graphics drivers Warranty documentation

***

for support information.

EMC Immunity CISPR 24:1997/EN 55024:1998 - Information Technology Equipment Immunity Characteristics - Limits and Methods of Measurement.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 32

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

HP ADD2 SDVO PCIe DVI-D Adapter

Resolution

Blanking

640 x 480 800 x 600

1024 x 768 1280 x 1024 1600 x 1200

Models

Form Factor

DVI-D Connector

Dual Head Support

Display Devices Supported

NOTE:

These graphics adapters offer optimal performance with any display that meets

applicable VESA standards.

Color Depth

Host Interface Connector

Dot Clock

Display Modes

VGA

SVGA

XGA SXGA UXGA

HP ADD2 SDVO DVI-D Out Adapter

Low-profile card

Digital connection only

Yes, when used with the integrated VGA connector

HP L1740 HP L1940T HP L2045W HP LP1965

All modes support 8-bpp, 16-bpp, and 24-bpp color depths

Mechanically compliant with PCI-E standard Complies with the Intel ADD2 and Intel Serial Digital Video Output (SDVO) specifications

165 MHz maximum

Supports display modes that require up to 165-MHz bandwidth on the link, as shown in the following table.

60-Hz LCD

5% reduced

Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

60-Hz 75-Hz 85-Hz

GTF GTF GTF

No No No No

HP DisplayPort to DVID Adapter

HP DisplayPort to VGA Adapter

NOTE:

Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.

Using the HP DisplayPort to VGA Adapter may require an update to the graphics driver installed on your system. To install

Connectors

Adapter length

Adapter weight

Connectors

Adapter length

Adapter weight

Maximum vertical refresh rate

Display support

Display max resolution

HP DisplayPort to VGA adapter display resolutions and refresh rates

the most up-to-date graphics driver go to:

DisplayPort and DVI-D single link connector

7.5 in (19.0 cm)

.10 lbs (.05 kg)

DisplayPort and VGA connector

8 in (20 cm)

.1 lbs (.06 kg)

85 Hz

162 MHz RAMDAC

1600x1200

www.hp.com.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 33

QuickSpecs

Technical Specifications - Graphics

HP Compaq 8100 Elite PC

Resolution

640x480

800x600 1024x768 1280x720

1280x1024

1440x900

1600x1200 1680x1050 1920x1080 1920x1200

NOTE:

60-R denotes reduced blanking timings are used. Not all monitors support reduced blanking timing.

Max refresh rate

85 85 85 85 85 75 60

60 60-R 60-R

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 34

QuickSpecs

Technical Specifications - Hard Drives

HP Compaq 8100 Elite PC

3.5” 7200 RPM Serial ATA Hard Drives

500 GB

320 GB

250 GB

Capacity

Height

Width

Interface

Synchronous Transfer Rate

(Maximum)

Buffer

Seek Time

reads, includes controller overhead, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer Rate

Buffer

Seek Time

reads, includes controller overhead, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer Rate

Buffer

Seek Time

reads, includes controller overhead, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

(typical

(Maximum)

(typical

(Maximum)

(typical

500,107,862,016 bytes

1 in (2.54 cm)

Media diameter: 3.5 in (8.89 cm)

Physical size: 4 in (10.2 cm)

Serial ATA (3.0 Gb/s)

Up to 3 Gb/s

16 MB

Single Track

Average

Full-Stroke

7,200 rpm

976,773,168

41° to 131° F (5° to 55° C)

320,069,031,690 bytes

1 in (2.54 cm)

Media diameter: 3.5 in (8.89 cm)

Physical size: 4 in (10.2 cm)

Serial ATA (3.0 Gb/s)

Up to 3 Gb/s

8 MB

Single Track

Average

Full-Stroke

7,200 rpm

625,142,448

41° to 131° F (5° to 55° C)

250,059,350,016 bytes

1 in (2.54 cm)

Media diameter: 3.5 in (8.89 cm)

Physical size: 4 in (10.2 cm)

Serial ATA (3.0 Gb/s)

Up to 3 Gb/s

8 MB

Single Track

Average

Full-Stroke

7,200 rpm

488,397,168

41° to 131° F (5° to 55° C)

2.0 ms

11 ms

21 ms

1.0 ms

8.5 ms

18 ms

1.0 ms

8.5 ms

18 ms

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 35

QuickSpecs

Technical Specifications - Hard Drives

HP Compaq 8100 Elite PC

10,000 RPM Serial ATA Hard Drives

160 GB

Capacity

Height

Width

Interface

Synchronous Transfer Rate

(Maximum)

Buffer

Seek Time

reads, includes controller overhead, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Capacity

Height

Width

Interface

Synchronous Transfer Rate

Cache

Seek Time

reads, includes controller overhead, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

(typical

(Maximum)

(typical

160,041,885,696 bytes

1 in (2.54 cm)

Media diameter: 3.5 in (8.89 cm)

Physical size: 4 in (10.2 cm)

Serial ATA (3.0 Gb/s)

Up to 3 Gb/s

8 MB

Single Track

Average

Full-Stroke

7,200 rpm

312,581,808

41° to 131° F (5° to 55° C)

160,041,885,696 bytes

1 in (2.54 cm)

Media diameter: 3.0 in (7.62 cm)

Physical size: 4 in (10.2 cm)

Serial ATA (1.5 Gb/s), Native Command Queuing enabled

Up to 3.0 Gb/s

16 Mbytes

Single Track

Average

Full-Stroke

10,000 rpm

312,581,808

41° to 131° F (5° to 55° C)

0.9 ms

9.3 ms

18 ms

0.3 ms

4.6 ms

10.2 ms

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 36

QuickSpecs

Technical Specifications - Hard Drives

HP Compaq 8100 Elite PC

Solid State Drive

64 GB

Capacity

NAND Flash Memory

Interface type

Dimensions-external

(W x H x D)

Weight

Internal transfer rate

Host transfer rate

Power

Environmental

(all conditions, noncondensing)

Regulations

NOTE:

For solid state disk drives, GB means 1 billion bytes. 16GB is the unformatted capacity of this drive before a portion of the drive is reserved for flash management features. Actual capacity varies by content and will be less than 15.8GB.

64 GB

Multi Level Cell (MLC) with wear leveling controller

SATA 3Gb/sec

2.74 x 0.37 x 4 in (6.98 x 0.95 x 10.2 cm)

0.14 lb (65 g)

Write speed

Read speed

Ultra DMA mode

DC power requirement

Total power consumption

Temperature

(operating)

Relative Humidity

(operating)

Maximum Wet Bulb Temperature

(operating)

UL, CSA, EN 60950-2000, CISPR Pub 22 Class B, CNS 13438, AS/NZS CISPR 22:2002 Class B, R1113 and C1172 Class B

Up to 220 MB/s

Up to 120 MB/s

Up to 150 MB/s

5 VDC 5%-100 mV ripple pp

<1.12Watt

32° to 158° F (0° to 70° C)

5% to 95%

84° F (29° C)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 37

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

USB Standard Keyboard

Physical characteristics

Electrical

Mechanical

Environmental

Approvals

Ergonomic compliance

Kit contents

Keys

Dimensions

Weight

Operating voltage

Power consumption

System interface

ESD

EMI - RFI

Microsoft® PC 99 2001

Languages

Keycaps

Switch actuation

Switch life

Switch type

Key-leveling mechanisms

Cable length

Microsoft PC 99 - 2001

Acoustics

Operating temperature

Non-operating temperature

Operating humidity

Non-operating humidity

Operating shock

Non-operating shock

Operating vibration

Non-operating vibration

Drop

(out of box)

Drop

(in box)

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC

ANSI HFS 100, ISO 9241-4, and TUVGS

Keyboard, installation guide, warranty card, safety and comfort guide

(L x W x H)

104, 105, 106, 107, 109 layout (depending upon country)

18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)

2 lb (0.9 kg) minimum

+ 5VDC ± 5%

50-mA maximum (with three LEDs ON)

USB Type A plug connector

CE level 4, 15-kV air discharge

Conforms to FCC rules for a Class B computing device

Functionally compliant

38 available

Low-profile design

55-g nominal peak force with tactile feedback

20 million keystrokes (using Hasco modified tester)

Contamination-resistant switch membrane

For all double-wide and greater-length keys

6 ft (1.8 m)

Mechanically compliant

43-dBA maximum sound pressure level

50° to 122° F (10° to 50° C)

-22° to 140° F (-30° to 60° C)

10% to 90% (non-condensing at ambient)

20% to 80% (non-condensing at ambient)

40 g, six surfaces

80 g, six surfaces

2-g peak acceleration

4-g peak acceleration

26 in (66 cm) on carpet, six-drop sequence

42 in (107 cm) on concrete, 16-drop sequence

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 38

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

PS/2 Standard Keyboard

Physical characteristics

Electrical

Mechanical

Environmental

Approvals

Ergonomic compliance

Keys

Dimensions

Weight

Operating voltage

Power consumption

System interface

ESD

EMI - RFI

Microsoft PC 99 - 2001

Languages

Keycaps

Switch actuation

Switch life

Switch type

Key-leveling mechanisms

Cable length

Microsoft PC 99 - 2001

Acoustics

Operating temperature

Non-operating temperature

Operating humidity

Non-operating humidity

Operating shock

Non-operating shock

Operating vibration

Non-operating vibration

Drop

(out of box)

Drop

(in box)

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC

ANSI HFS 100, ISO 9241-4, and TUVGS

(L x W x H)

104, 105, 106, 107, 109 layout (depending upon country)

18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)

2 lb (0.9 kg) minimum

+ 5VDC ± 5%

50-mA maximum (with three LEDs ON)

PS/2 6-pin mini din connector

CE level 4, 15-kV air discharge

Conforms to FCC rules for a Class B computing device

Functionally compliant

38 available

Low-profile design

55-g nominal peak force with tactile feedback

20 million keystrokes (using Hasco modified tester)

Contamination-resistant switch membrane

For all double-wide and greater-length keys

6 ft (1.8 m)

Mechanically compliant

43-dBA maximum sound pressure level

50° to 122° F (10° to 50° C)

-22° to 140° F (-30° to 60° C)

10% to 90% (non-condensing at ambient)

20% to 80% (non-condensing at ambient)

40 g, six surfaces

80 g, six surfaces

2-g peak acceleration

4-g peak acceleration

26 in (66 cm) on carpet, six-drop sequence

42 in (107 cm) on concrete, 16-drop sequence

HP USB Smartcard Keyboard

Physical characteristics

Electrical

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Keys

Form factor

Colors

Dimensions

Weight

Operating voltage

Power consumption

System interface

(H x W x D)

104, 105, 106, 107, 109 layout (depending upon country)

USB basic Smart Card keyboard

Carbonite/Silver

18.2 x 6.3 x 1.3 in (46.3 x 16.1 x 3.3 cm)

2 lb (0.9 kg) minimum

+ 5VDC ± 5%

100-mA maximum (with four LEDs ON)

USB Type A plug connector

Page 39

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

Mechanical

Environmental

SMARTCARD function

ESD

EMI - RFI

Microsoft PC 99 - 2001

Languages

Keycaps

Switch actuation

Switch life

Switch type

Key-leveling mechanisms

Cable length

Microsoft PC 99 - 2001

Acoustics

Operating temperature

Non-operating temperature

Operating humidity

Non-operating humidity

Operating shock

Non-operating shock

Operating vibration

Non-operating vibration

Drop

(out of box)

Drop

(in box)

Support

Interface

Chipset

Standard APIs supported

Power

Power consumption

Communication

CE level 4, 15-kV air discharge

Conforms to FCC rules for a Class B computing device

Functionally compliant

30+ available

Low-profile design

55 g nominal peak force with tactile feedback

20 million keystrokes (using Hasco modified tester)

Contamination-resistant membrane

For all double-wide and greater-length keys

6 ft (1.8 m)

Mechanically compliant

43-dBA maximum sound pressure level

50° to 122° F (10° to 50° C)

-22° to 140° F (-30° to 60° C)

10% to 90% (non-condensing at ambient)

20% to 80% (non-condensing at ambient)

40 g, six surfaces

80 g, six surfaces

2-g peak acceleration

4-g peak acceleration

26 in (66 cm) on carpet, six-drop sequence

42 in (107 cm) on concrete, 16-drop sequence

All ISO 7816 smart cards

Reads from and writes to all ISO7816-1, 2, 3, 4 memory and microprocessor smart cards (T=0, T=1)

SCM STCII

PC/SC, EMV2000, SET

USB Port Short circuit detection (protects smart card and reader) Power supply compliant with ISO7816 and EMV (5V, 60 mA) Supports 3-V and 5-V cards

250-mA maximum draw (50 mA for the keyboard with three LEDs ON and 200-mA maximum startup current using a highcurrent, 60-mA smart card)

From card

From computer

Programmable from 9,600 baud to 115,200 baud

Up to 38,400 baud

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 40

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

HP PS/2 Optical Scroll Mouse

Dimensions

Weight

Environmental

Electrical

Mechanical

Scroll wheel

(H x L x W)

Landing mechanism

Interface modes

Reader performance interface

Electro-magnetic standards

3.95 x 6.21 x 11.7 cm (1.56 x 2.44 x 4.61 in)

4.44 oz (126 g)

Operating temperature

Non-operating temperature

Operating humidity

Non-operating humidity

Operating shock

Non-operating shock

Operating vibration

Non-operating vibration

Drop

(out of box)

Operating voltage

Power consumption

System consumption

ESD

EMI-RFI

Microsoft PC99 - 2001

Resolution

Tracking speed

Acceleration

Switch actuation

Switch life

Switch type

Tracking mechanism life

Cable length

Microsoft PC99 - 2001

Width

Diameter

Maximum rotation speed

Contact device

Card insertions rating

USB communications through USB port SCM protocol Automatic card insertion/removal detection

USB connection

Europe

USA

-32° to 104°F (0° to 40° C)

-4° to 140°F ( -20° to 60° C)

10% to 90% (non condensing at ambient)

10% to 90% non condensing

40 g, 6 surfaces

80 g, 6 surfaces

2 g peak acceleration

4 g peak acceleration

80 cm height onto asphalt tile over concrete or equivalent, 5-drop in 5 direction except the cable face

5 VDC ± 10%

100mA

PS/2 mini-din connector

CE level 4, 15 kV air discharge

Conforms to FCC rules for a Class B computing device

Functionally compliant

400 ± 20% DPI

10 in/s (25.4 cm/s) maximum

100 in/s/s (2.54 m/s/s)

61 g nominal peak force

3,000,000 operations (using Hasco modified tester)

Low force micro-switches

155 mi (250 km) at average speed of 10 in/s

6 ft (1.8 m)

Mechanically compliant

8 mm

1.01 in (25.6 mm)

48 rats/sec

Friction contact

Up to 100,000 insertion cycles

89/336/CEE guideline

USAFCC part 15

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 41

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

HP USB Optical Scroll Mouse

HP USB 2-Button Laser Mouse

Regulatory approvals

Dimensions

Weight

Cable length

System requirements

Scroll Wheel

Maximum Rotation Speed

Switch Type

Switch Life

Environmental

Electrical

Mechanical

(H x L x W)

Switch type

Switch life

Mechanical life

Compliant

1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)

0.27 lb (0.12 kg)

72.8 in (185 cm)

Microsoft Windows 95, 98, 2000, Me, XP and Vista Available USB port

48 rats/sec

wheel

Button - 3,000,000 Wheel - 1,000,000 times Tilt switch - 500,000 times

Operating Temperature

Non-operating Temperature

Operating Humidity

Non-operating Humidity

Operating Shock

Non-operating Shock

Operating Vibration

Non-operating Vibration

Operating Voltage

Power Consumption

MTBF

ESD

EMI-RFI

PC98

Resolution

Tracking Speed

Acceleration

Switch Actuation

Switch Life

Cable Length

PC98-99

Light force micro-switch

1 million operations

Minimum 200,000 revolutions

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC

32° to 104° F (0° to 40° C)

-4° to 140° F (-20° to 60° C)

10% to 90% (non-condensing at ambient)

20% to 80% (non-condensing at ambient)

40 g, six surfaces

80 g, six surfaces

2-g peak acceleration

4-g peak acceleration

+ 5VDC ± 5%

> 150,000 hrs

IEC-61000-4-2 criteria B, Contact discharge: +/- 4kV, Air discharge: +/- 8kV

FCC Class B

PC 99 Compliant

800dpi

25 cm/sec

0.5mm

0.6N (60gf)

Button - 3,000,000 Wheel - 1,000,000 times Tilt switch - 500,000 times

1850mm

PC99 compliant

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 42

QuickSpecs

Technical Specifications - Input/Output Devices

HP Compaq 8100 Elite PC

Regulatory Approvals

UL60950-1, UL 94, UL 746 (A-E), UL 796 TUV/GS: EN 60950-1, EN 60825-1 FCC Class B, UL 1950, cUL, TUV GS, CE, C-tick, VCCI, BSMI, RRL

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 43

QuickSpecs

Technical Specifications - Optical Storage

HP Compaq 8100 Elite PC

HP Blu-ray Writer Drive

Height

Orientation

Interface type

Disc capacity

Dimensions

Weight

Write speed

Read speeds

Sustained Transfer rate

Burst Transfer rate

Multimedia MPC-3 compliant

Access times

(typical reads, including setting)

(W x H x D)

(max)

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA/ATAPI

50 GB DL or 25 GB standard

5.9 x 1.7 x 7.5 in (15.0 x 4.4 x 19.0 cm)

2.0 lb (907g)

Single-layer

BD-R

BD-RE

DVD-R

DVD-RW

DVD+R

DVD+RW

DVD-RAM

CD-R

CD-RW

BD-ROM

BD-R

BD-RE

(SL/DL)

DVD-ROM

DVD-R

DVD-RW

DVD+R

DVD+RW

BDMV

(AACS Compliant

Disc)

DVD-RAM

DVD-Video

Compliant Disc)

CD-R/RW/ROM

CD-DA

80 mm CD

BD-ROM

DVD-ROM

CD-ROM

Random

Full Stroke

(CSS

(DAE)

2x, 4x CLV, 6x CAV

2.3x

2x, 4x CLV, 8x ZCLV, 8x, 12x PCAV, 16x CAV

1x, 2x, 4x, 6x CLV

2.4x, 4x CLV, 8x ZCLV, 8x, 12x PCAV, 16x CAV

2.4x, 4x, 6x CLV, 8x ZCLV

2x, 3x CLV, 3-5x PCAV

8x,16x CLV, 24x, 32x PCAV, 40x CAV

4x, 10x, 16x CLV, 24x ZCLV

Single-layer

6x CAV

4.8x CAV 4.8x CAV

16x CAV

12x CAV

10x CAV

12x CAV

10x CAV

4.8x CAV

2x, 3x CLV, 3x-5x PCAV

8x CAV

40x / 40x / 40x CAV

32x CAV

16x CAV

26.97 MB/s (6x) max

16.62 MB/s (16x) max.

6,000 KB/s (40x) max.

1.5Gbps bits/s (10b side)

1.2Gbps bits/s (8b side)

Yes

DVD: < 140 ms (typical), CD: < 125 ms (typical)

DVD: < 250 ms (seek), CD: < 210 ms (seek)

Double-layer

2x, 4x CLV

2x CLV

2x, 4x CLV

Not supported

2.4x, 4x CLV

Not supported

Double-layer

4.8x CAV

8x CAV

Not support

8x CAV

Not support

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 44

QuickSpecs

Technical Specifications - Optical Storage

HP Compaq 8100 Elite PC

HP SuperMulti LightScribe DVD Writer Drive

Power

Environmental

(all conditions non-condensing)

Height

Orientation

Interface type

Disc capacity

Dimensions

Weight

Write speeds

Read speeds

Access time

(typical reads, including settling)

Power

(W x H x D)

(max)

Source

DC Power Requirement

DC Current

Temperature

(operating)

Relative Humidity

(operating)

Maximum Wet Bulb Temperature

(operating)

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA/ATAPI

8.5 GB DL or 4.7 GB standard

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)

2.6 lb (1.2 kg)

DVD-RAM

DVD+R

DVD+RW

DVD+R DL

DVD-R DL

DVD-R

DVD-RW

CD-R

CD-RW

DVD-RAM

DVD+RW, DVD-RW, DVD+R DL, DVD-R DL

DVD-ROM DL

DVD-ROM, DVD+R, DVD-R

CD-ROM, CD-R

CD-RW

Random

Full Stroke

Source

DC Power Requirement

DC Current

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p

5 VDC -1000 mA typical, 1600 mA maximum 12 VDC -600 mA typical, 1400 mA maximum

41° to 122° F (5° to 50° C)

10% to 90%

86° F (30° C)

Up to 12X

Up to 16X

Up to 8X

Up to 16X

Up to 6X

Up to 48X

Up to 32X

Up to 12X

Up to 8X

Up to 16X

Up to 48X

Up to 32X

DVD: < 140 ms (typical), CD: < 125 ms (typical)

DVD: < 250 ms (seek), CD: < 210 ms (seek)

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p

12 VDC ± 5%-200 mV ripple p-p

5 VDC (< 1000 mA typical, 1600 mA maximum)

12 VDC (< 600 mA typical, 1400 mA maximum)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 45

QuickSpecs

Technical Specifications - Optical Storage

HP Compaq 8100 Elite PC

HP DVD-ROM Drive

Environmental conditions

non-condensing)

Height

Orientation

Interface type

Disc capacity

Dimensions

Weight

Read speeds

Removable Storage Media Compatibility DVD-ROM

Access times

(typical reads, including setting)

Power

(operating -

(W x H x D)

(max)

Temperature

Relative Humidity

Maximum Wet Bulb Temperature

5.25-inch, half-height, tray-load

Either horizontal or vertical

SATA/ATAPI

Single layer: Up to 4.7 GB (6 times capacity of CD-ROM) Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)

2.6 lb (1.2 kg)

DVD+R/-R/+RW/

-RW/+R DL /-R DL

DVD-ROM

DVD-RAM

CD-ROM, CD-R

CD-RW

Media

CD-ROM

CD-R

CD-RW

DVD-ROM

DVD-ROM DL

DVD-RAM

DVD+R

DVD+R DL

DVD+RW

DVD-R

DVD-RW

DVD-R DL

Random

Full Stroke

Cache Buffer

Data Transfer Modes

Source

DC Power Requirement

DC Current

41° to 122° F (5° to 50° C)

10% to 90%

86° F (30° C)

Up to 8X

Up to 16X

Up to 4X

Up to 40X

Up to 32X

Read

Yes

DVD: < 140 ms (typical), CD: < 125 ms (typical)

DVD: < 250 ms (seek), CD: < 210 ms (seek)

2 MB (minimum)

ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA mode 2 (16.7 MB/s); ATA UltraDMA Mode 3 (44.4 MB/s -default)

SATA DC power receptacle

5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p

5 VDC - <1000 mA typical, < 1600 mA maximum 12 VDC -< 600 mA typical, < 1400 mA maximum

Write

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 46

QuickSpecs

Technical Specifications - Optical Storage

HP Compaq 8100 Elite PC

Environmental

(all conditions non-condensing)

Temperature

Relative Humidity

Maximum Wet Bulb Temperature

41° to 122° F (5° to 50° C)

10% to 90%

86° F (30° C)

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 47

QuickSpecs

Technical Specifications - Removable Storage

HP Compaq 8100 Elite PC

HP 22-in-1 Media Card Reader (with 1394)

USB Interface

1394 Interface

Advance protocol support

Supported media type

Supported media type with card adapter

Environmental

USB 2.0 High-speed interface

NOTE:

USB 2.0 port or a USB 2.0 PCI card.

Two IEEE-1394a external ports; 1 IEEE-1394a internal port (connects to the pass through cable on the media card reader)

Supports hardware ECC (Error Correction Code) function Supports hardware CRC (Cyclic Redundancy Check) function Supports MS 4-bit parallel transfer mode Supports MS-PRO 4-bit parallel transfer mode Supports MS PRO-HG Duo 4-bit parallel transfer mode Supports SD 4-bit parallel transfer mode Supports high-speed 50Mhz SD 4-bit card (version 2.0) Supports high-speed 52Mhz MMC 8-bit card (version 4.2) Supports CF v4.0 with PIO mode 6 and Ultra DMA mode

CompactFlash Type I CompactFlash Type II Microdrive MultiMediaCard (MMC) Reduced Size MultiMediaCard (RS MMC) MultiMediaCard 4.2 (MMC Plus, including MMC Plus HC) Reduced Size MultiMediaCard 4.2 (MMC Mobile, including MMC Mobile HC) Secure Digital Card (SD) Secure Digital High Capacity (SDHC) miniSD miniSD High Capacity Micro SD (T-Flash) Micro SD HC Memory Stick Memory Stick Select Memory Stick Duo (MS Duo) Memory Stick PRO (MS PRO) Memory Stick PRO Duo (MS PRO Duo) Memory Stick PRO-HG Duo MagicGate Memory Stick (MG) MagicGate Memory Stick Duo xD-Picture Card

Memory Stick Micro (M2) MMC Micro

Operational Environmental Extremes

Storage Environmental Extremes

Requires the USB cable to be connected to the internal

Test Parameters/Conditions - Power applied, unit operating on system ±5% nominal supply voltage. 10°C 10% R.H. ≥ 24 hours 10°C 90% R.H. ≥ 24 hours 20°C 90% R.H. ≥ 24 hours 30°C 90% R.H. ≥ 24 hours 40°C 90% R.H. ≥ 24 hours 50°C 90% R.H. ≥ 24 hours 50°C 10% R.H. ≥ 24 hours

Test Parameters/Conditions 140°F (60°C) @ 80% R.H. for 96 hours

-22°F (-30°C) @ 20% R.H. for 48 hours No power applied Delta °C < 1.0°C/min Delta % R.H. < 1.5% R.H./min

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 48

QuickSpecs

Technical Specifications - Removable Storage

HP Compaq 8100 Elite PC

Approvals

USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.3 FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUV-T

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 49

QuickSpecs

Technical Specifications - Environmental Data

HP Compaq 8100 Elite PC

Eco-Label Certifications & declarations

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

US ENERGY STAR ® IT ECO declaration EPEAT Gold where HP registers commercial desktop products. See for registration status in your country.

http://www.epeat.net

Convertible Minitower

Energy Consumption

(typically configured)

Normal Operation

Sleep (Energy Star low power mode)

Off

Heat Dissipation

(typically configured)

Normal Operation

Sleep

Off

* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

System Fan Off

Idle

Fixed Disk (random writes)

Batteries

115 VAC 230 VAC 100 VAC

46.9450 W 47.0125 W 46.5123 W

3.7745 W 3.7250 W 3.6882 W

0.7562 W 0.8895 W 0.7751 W

115 VAC 230 VAC 100 VAC

161 BTU/hr 161 BTU/hr 159 BTU/hr

13 BTU/hr 13 BTU/hr 13 BTU/hr

3 BTU/hr 3 BTU/hr 3 BTU/hr

Sound Power

(LWAd, bels)

3.8

This battery(s) in this product comply with EU Directive 2006/66/EC

Sound Pressure

(LpAm, decibels)

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight Cadmium greater than 10ppm by weight

Battery size: CR2032 (coin cell) Battery type: Li-Ion

Additional Information

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of

1986). This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold where HP registers commercial desktop products. See country. Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.

http://www.epeat.net

for registration status in your

Page 50

QuickSpecs

HP Compaq 8100 Elite PC

Technical Specifications - Environmental Data

This product contains 0% post consumer recycled plastic (by wt.) This product is 90% recyclable when properly disposed of at end of life.

Packaging Materials

External:

Corrugated 2550 g

Internal:

Polyethylene high density 160 g The corrugated packaging material is made from 37% recycled content. The Polyethylene high density packaging material is made from 100% recycled content.

Small Form Factor

Energy Consumption

(typically configured)

Normal Operation

Sleep (Energy Star low power mode)

Off

Heat Dissipation

(typically configured)

Normal Operation

Sleep

Off

* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Declared Noise Emissions (in accordance with ISO 7779 and ISO

9296)

System Fan Off

Idle

Fixed Disk (random writes)

Batteries

115 VAC 230 VAC 100 VAC

39.787 W 39.547 W 39.865 W

3.2283 W 3.4659 W 3.2186 W

1.0477 W 1.2128 W 1.0345 W

115 VAC 230 VAC 100 VAC

161 BTU/hr 161 BTU/hr 136 BTU/hr

13 BTU/hr 13 BTU/hr 11 BTU/hr

3 BTU/hr 3 BTU/hr 4 BTU/hr

Sound Power

(LWAd, bels)

3.7

This battery(s) in this product comply with EU Directive 2006/66/EC

Sound Pressure

(LpAm, decibels)

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight Cadmium greater than 10ppm by weight

Battery size: BR-2032 Battery type: Lithium

Additional Information

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 51

QuickSpecs

Technical Specifications - Environmental Data

This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of

1986). This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold where HP registers commercial desktop products. See http://www.epeat.net for registration status in your country. Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043. This product contains 0% post consumer recycled plastic (by wt.) This product is 95.1% recyclable when properly disposed of at end of life.

Packaging Materials

External:

Internal:

The Corrugated Carton packaging material is made from 100% recycled content. The EPE – Expanded Polyethylene packaging material is made from 100% recycled content The Polyethylene low density foam packaging material is made from 100% recycled content

HP Compaq 8100 Elite PC

Corrugated – 1700 g

EPE - Expanded Polyethylene – 160 g Polyethylene low density foam – 160 g

Convertible Minitower and Small Form Factor

RoHS Compliance

Material Usage

Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).

This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at:

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/ gen_specifications.html

Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be frequently handled or carried by the user. Ozone Depleting Substances

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 52

QuickSpecs

Technical Specifications - Environmental Data

Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Packaging

End-of-life Management and Recycling

HP follows these guidelines to decrease the environmental impact of product packaging:

Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:

http://www.hp.com/go/reuse-recycle

sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

HP Compaq 8100 Elite PC

or contact your nearest HP

Hewlett-Packard Corporate Environmental Information

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at:

http://www.hp.com/go/recyclers

recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

For more information about HP's commitment to the environment: Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/ envmanagement.html

. These instructions may be used by

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 53

QuickSpecs

HP Compaq 8100 Elite PC

Technical Specifications - Environmental Data

All rights reserved. Microsoft, Windows, Windows 7, and Windows Vista are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel, Core, and Pentium are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 13524 Worldwide QuickSpecs — Version 14 — 6/24/2010

Page 54

HP ELITE 8100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features and Configurable Components (availability may vary by country)

After-Market Options (availability may vary by region)

Technical Specifications

Technical Specifications - Audio

Technical Specifications - Communications

Technical Specifications - Graphics

Technical Specifications - Hard Drives

Technical Specifications - Input/Output Devices

Technical Specifications - Optical Storage

Technical Specifications - Removable Storage

Technical Specifications - Environmental Data
