HP E23 G4 User Manual

Datasheet

HP E23 G4 FHD Monitor

Enhance your entire viewing experience

Work comfortably and stay focused with the
optimized ergonomics and Full HD resolution
of the HP E23 G4 FHD Monitor with HP Eye
Ease that is designed around you. Make life
easy for IT with remote manageability.

Total comfort begins with HP Eye Ease

Keep your eyes comfortable through the work day with HP Eye Ease, our first built-in, always-on blue light filter
that presents your vivid content with zero impact on your color accuracy, no OSD required.

Personalize your view

Never lose a moment of productivity with 4-way monitor adjustability that lets you find your sweet spot, a 3-sided
micro-edge, flicker-free 23" diagonal screen that reveals more of your work, and Full HD resolution for crisp visuals
from any angle.

Responsibly made

Energy efficiency is built into every ENERGY STAR® certified, EPEAT® 2020 registered , and low halogen display.
We go one step further with 100% recyclable packaging that’s easily accepted by recycling facilities.

Featuring

Connect to your most frequently-used devices with VGA, HDMI, and DisplayPort™. Add up to four of your USB
accessories right at the monitor with the integrated USB 3.2 hub.

Work comfortably with adjustable tilt, height, and swivel settings. Use pivot rotation to conveniently customize
portrait or landscape views on multiple monitors.

Create an efficient, compact, solution when you mount your HP Desktop Mini PC directly on the column stand using
the optional HP B300 PC Mounting Bracket.

Customize your monitor and help deter its theft with easy, intuitive HP Display Center software that lets you tailor
your settings, partition screens, and even dim the screen if your monitor is disconnected without approval—all
through the host PC.

Customize a total solution with options like the HP S101 Speaker Bar, which attaches easily to the lower bezel to
add stereo audio on the monitor.

Rest assured that this monitor has been vigorously tested for compatibility across HP PCs and workstations. It’s
also supported by our three-year standard limited warranty. Extend your protection to cover accidents, next­business day needs, and more with optional HP Care Pack services.

3 4

2

5

6

5

7

Data sheet | HP E23 G4 FHD Monitor

HP E23 G4 FHD Monitor Specifications Table

Display type IPS

Panel Active Area 20.04 x 11.27 in 50.91 x 28.64 cm

Display size (diagonal) 23"

Brightness 250 nits

Contrast ratio 1000:1 static

Response Ratio 5ms on/off (with overdrive)

Product color Black bezel, silver stand

Aspect ratio 16:9

Native resolution FHD (1920 x 1080)

Resolutions supported

1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1440 x 900; 1600 x 900; 1680 x 1050; 1920 x 1080; 640 x 480; 720 x 400;
800 x 600

Display features Low blue light mode; Anti-glare

User controls Brightness; Exit; Information; Management; Power control; Input control; Menu control; Image; Color

Input signal 1 VGA; 1 USB Type-B; 1 HDMI 1.4; 1 DisplayPort™ 1.2; 4 USB-A 3.2 Gen 1
Display
Environmental Operating temperature: 5 to 35°C; Operating humidity: 20 to 80% non-condensing

Power Input voltage 100 to 240 VAC

Power consumption 51 W (maximum), 26 W (typical), 0.5 W (standby)

Dimensions 20.54 x 1.85 x 12.33 in; 52.16 x 4.7 x 31.31 cm

Weight 11.9 lb; 5.4 kg

Physical security features Security lock-ready

Energy efficiency compliance ENERGY STAR® certified; EPEAT® 2019 registered

Certification and compliance

Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; ENERGY STAR®; FCC; GS Mark; ISE for Cambodia;
ISO 9241-307; KC/KCC; NOM; PSB; SEPA; TCO Certified; TCO Certified Edge; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; Low blue
light; WW application; ICE; UAE

What's in the box Monitor; DisplayPort™ 1.2 cable; HDMI cable; USB cable; VGA cable; AC power cable


