Page 1
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 1
HP EliteDisplay E223d 21.5-inch Docking Monitor Front
1.
Function Buttons
2.
Power Button
Page 2
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 2
HP EliteDisplay E223d 21.5-inch Docking Monitor Back
1.
DC Power IN Connector
7.
Network Jack
2.
Security Cable Slot
8.
USB Type-A port
3.
HDMI Port
9.
USB Type-A Port
4.
DisplayPort™ 1.2 OUT Port
10.
USB Type-A Ports (2)
5.
USB Type-C™ Port
11.
Headset Port
6.
USB Type-B™ Port
Page 3
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 3
Models: 5VT82A8/5VT82U9/5VT82AA/5VT82A7/5VT82AS/5VT82AT
Panel Specifications
Display Size (Diagonal)
21.5 in
Display Panel Type
IPS w/LED backlight
Micro-Edge Bezel
Yes, 3-sided
Native Resolution*
1920 x 1080 @60 Hz
Native Resolution Note
The video card of the connected PC must be capable of
supporting 1920 x 1080 at 60 Hz and include 1 HDMI or 1DP
outputs or USB TYPC DP ALT MODE to drive the monitor at
the Preferred Mode.
Panel Bit Depth
8 Bit (6 Bit + A-FRC)
Aspect Ratio
16:9
Brightness Typical
250 cd/m²
Static Contrast Ratio - Typical
1000:1
Static Contrast Ratio - Minimum
700:1
Dynamic Contrast Ratio (DCR)
5,000,000:1
Pixel Pitch
0.27495 x 0.27495 mm
Pixels Per Inch (PPI)
102.46
Backlight Lamp Life
(to half brightness - in hours)
30k minimum
Anti-Glare Panel
Yes Response Time - Typical
5ms (GTG)
Horizontal Viewing Angle
(typical CR>10)
178°
Vertical Viewing Angle
(typical CR>10)
178°
Panel Active Area (w x h)
476.064(H)x 267.786(V)
Preset Graphic Modes/Supported
Resolutions
640×480 @59.940Hz
720×400 @70.087Hz
800×600 @60.317Hz
1024×768 @60.004Hz
1280×720 @60Hz
1280×800 @59.810Hz
1280×1024 @60.020Hz
1440×900 @59.887Hz
1600×900 @60Hz
1680×1050 @59.954Hz
1920×1080 @60Hz
Maximum Resolution
1920×1080 @ 60HZ
Recommended Resolution
1920×1080 @ 60HZ
Vertical Scan Range
50 - 60 Hz
Horizontal Scan Range
30 - 80 kHz
Default Color Temperature
Neutral (6500 K)
Maximum Pixel Clock Speed
170 MHz
*DisplayPort™ 1.2 or HDMI 1.4 required to drive panel at its native resolution
NOTE: Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Page 4
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 4
Color Gamut Coverage
NTSC
72%
sRGB
>94% sRGB
Color Management
Color Space / Subsampling Support
RGB 4:4:4, YCBCR 4:4:4, YCBCR 4:2:2
Default Color Temperature
Neutral (6500 K)
Low Blue Light Modes
Yes RGB Channel Adjust
Yes, Gain
Monitor Specifications
Exterior Color of Monitor Bezel and
Stand
Asteroid in bezel and bucket frame and black in stand
Plug & Play
Yes Tilt
-5 TO +23 DEGREES
Swivel
Yes, 45°
Pivot
Pivot (CW & counter CW). Detent at 0 degrees
Height Adjustment Range
Yes,150 mm
VESA Mounting
Yes, 100 mm with integrated mount or with included
bracket
Security Lock Ready
Yes Detachable Base
Yes, ships detached
Warranty
3-3-0 NA/TW/EMEA/ANZ/JPN/VIET/THAI
3-3-3 INDIA/PRC
On Screen Display
(OSD)
On Screen Display User Controls
Brightness, Contrast, Color Control, Input Control, Image
Control, Power control, Menu Control, Management, USB
Host Selection, Information, EXIT
User Programmable Modes
Yes, 10
Monitor Control Buttons or Switches
Menu, Minus ("-")/Information, Plus ("+")/Viewing Modes,
Back/Next Active Input, Power
User-Assignable Function Buttons
Yes, 3 (8 options)
Languages
10 (English, Spanish, German, French, Italian, Netherlands,
Portuguese, Japanese, T-Chinese and S-Chinese)
Connector Types
DisplayPort™
1 DisplayPort 1.2 out
HDMI
1 HDMI 1.4
USB Type-C™
1 USB3.1 Type C upstream ports
HDCP support
Yes, (USB-C Video and HDMI)
Audio Output
1, Analog
Ethernet
Yes
USB Port
Specifications
USB Version
3.1
USB Hub
Yes Downstream Ports
4 Ports
Upstream Ports
1 USB-C
Fast Charging USB Ports
1 Port (Upper in side BD)
Power Output Maximum
Fast Charging: 7.5W; Standard 4.5W
USB-Type C™ Port
Specifications
USB-Type C™ Version
USB 3.1 Gen1 / 5 G bps
Upstream USB-Type C™ Ports
1 Port
Video Support
USB-C Alt mode – DisplayPort™ 1.2
Power Output
5V/9V/10V/12V/15V/20V
Power Output Maximum
65W Max
Special Features
Remote Manageability
No User Presets
Yes
Page 5
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 5
Power & Operating
Specs
Power Supply
External
Power Source
100 – 240 VAC 50/60 Hz
Power Consumption - Maximum
138 W (Without DC power out, with power delivery)
Energy Saving/Standby Mode
0.5W
Power Consumption - Typical
35 W
Power cable length
1830mm: 398062-001,150304-008,130627-008,121565001,285052-001,100613-008,286496-001,109197008,653326-001,438723-001,393312-001
2500mm: 187487-001,100661-001,401328-001
1800mm: 100614-009
2000mm: 403440-001
EU Energy Efficiency
Class (EC1062)
Visible Screen Size
21,5"/55cm
Operating Conditions
Operating Temperature - Celsius
5° - 35°C
Operating Temperature - Fahrenheit
41° - 95°F
Non-operating Temperature - Celsius
-20° - 60°C
Non-operating Temperature Fahrenheit
-4° - 140°F
Operating Humidity
20% - 80% (non-condensing)
Non-operating Humidity
5% - 95%
Operating Altitude
0 - 5,000 m (16,400 ft.)
Non-operating Altitude
0 - 12.192 m (40,000 ft.)
Environmental
Features and
Certifications
Mercury-free LED display backlighting
Yes, Mercury-free LED backlights
Arsenic-Free Display Glass
Yes
Low Halogen**
GSE HP-00011-01B, table 2 defines low-halogen (BFR, CFR,
PVC)
Agency Approvals and Certifications
WW application
CE,CB,KC/KCC/NOM/ICE/ISO 9241-307/ EAC/TUVGS/cTUVus/PSB/CCC/CEL/ISC/VCCI/FCC/BSMI/Vietnam
MEPS/Australian-New Zealand MEPS/WEEE/BIS
Microsoft WHQL Certification
Win 10, Win 8.1, Win 7
SmartWay Transport Partnership - NA
only
Yes (NA SKU)
**External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after
purchase may not be Low Halogen.
Note: DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards
Association (VESA®) in the United States and other countries.
Contains Recycled
Plastics
Contains Recycled Plastics in Back
Cover
0.85
Contains Recycled Plastics in
Base/Stand
0.85
Contains Recycled Plastics in Other
Parts
85% (Deco, Middle Frame)
Recyclable Packaging
(Box, packing materials)
0% recyclable Plastics content by total weight of packing
materials
Recyclable Plastics
All
Recyclable Packaging (Box, packing
materials)
All
Page 6
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 6
Metric
Imperial
Unit Product/Package
Specifications
Product Dimensions
(Unpacked with stand) (W x D x H)
48.83 x 20.5 x 44.865 cm
19.22 x 8.07 x 17.66 in
Product Dimensions
(Packed) (W x D x H)
58.9 x 27.3 x 36.5 cm
23.19 x 10.75 x 14.37 in
Display Head Dimensions
(Unpacked without stand) (W x D x H)
48.83 x 4.483 x 29.33 cm
19.22 x 1.765 x 11.55 in
Base Area Footprint
(w x d mm)
236.99 x 205.00 mm
9.33 x 8.07 in
Bezel Measurements
Top 1.36 mm
Side 1.36 mm
Bottom 18.4 mm
Top 0.0535 in
Side 0.0535 in
Bottom 0.724 in
Product Weight
(Unpacked with stand)
5.08 kg
11.2 lb
Product Weight
(Packed)
8.06 kg
17.77 lb
Product Weight
(Head Only)
2.75 kg
6.06 lb
Pallet Information
Pallet Dimensions
(L x W x H)
G-1:1190L x 1100W x
125H mm
G-2:1100L x 620W x 125H
mm
G-1:46.85L x 43.31W x 4.92H
inch
G-2:43.31L x 24.41W x 4.92H
inch Pallet Layers
20/40" Wooden- 5 layers
Pallet Product per Layer
G-1: 8 sets
G-2: 4 sets
Total Products per Pallet
G-1: 40 sets
G-2: 20 sets
Container Load, 20-Foot
360 units
Container Load, 40-Foot
800 units
Container Load, 40-Foot HighQ
960 units
Software Included
Install Monitor INF/ICM Software
Install HP Display Assistant
Recommended
Accessories*
Description
Part Number
HP B300 PC Mounting Bracket
2DW53AA
HP Quick Release Bracket 2
6KD15AA
HP S101 Speaker Bar
5UU40AA
HP Hot Desk Stand
W2Z73AA
HP Executive 15.6 Backpack
6KD07AA
HP Sure Key Cable Lock
6UW42AA
*Sold separately and availability may vary by country
What's in the box?
AC power cord (1.83m) 6.0 ft
USB C-C cable (1.8m) 5.9 ft
USB A-B Cable (1.8m) 5.9 ft
HDMI Cable
External power supplier (150W)
QSP
Product notice
NOTE: Included cables may vary by country.
User Guide and
Warranty Languages
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish,
Dutch, Finnish, French, German, Greek, Hungarian, Italian,
Page 7
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 7
Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian
Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish,
Dutch, Finnish, French, German, Greek, Hungarian, Italian,
Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian
Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish.
Environmental
Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
• IT ECO declaration
• EPEAT® N/A registered in the United States. See http://www.epeat.net
for registration status in your country.
• US Federal Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
17 W
17 W
N/A
Sleep
0.33 W
0.35 W
N/A
Off
0.28 W
0.31 W
N/A
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
58 BTU/hr
58 BTU/hr
N/A
Sleep
1 BTU/hr
1 BTU/hr
N/A
Off
1 BTU/hr
1 BTU/hr
N/A
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information
• This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
• This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard at the
<N/A> level, see http://www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
• This product contains 44.5% post-consumer recycled plastic (by wt.)
according to IEEE 1680.1-2018 standard, criterion 4.2.1.1.
• This product is 98.9% recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
PAPER/Corrugated
923 g
PAPER/Paper
280 g
COMPOSITE/paper/carton+plastic
3 g
Page 8
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 8
Internal:
PLASTIC/Other
1 g
PLASTIC/Polyethylene high density - HDPE
16 g
PLASTIC/EPS (Expanded Polystyrene)
537 g
PLASTIC/Polyethylene low density- LDPE
9 g
RoHS Compliance
HP Inc. complies fully with materials regulations. We were among the first
companies to extend the restrictions in the European Union (EU) Restriction of
Hazardous Substances (RoHS) Directive to our products worldwide through the
HP GSE. HP has contributed to the development of related legislation in Europe,
as well as China, India, and Vietnam.
We believe the RoHS directive and similar laws play an important role in
promoting industry-wide elimination of substances of concern. We have
supported the inclusion of additional substances—including PVC, BFRs, and
certain phthalates—in future RoHS legislation that pertains to electrical and
electronics products.
We met our voluntary objective to achieve worldwide compliance with the new EU
RoHS requirements for virtually all relevant products by July 2013, and we will
continue to extend the scope of the commitment to include further restricted
substances as regulations continue to evolve.
To obtain a copy of the HP RoHS Compliance Statement, see HP RoHS position
statement.
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_spe
cifications.html):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Bis(2-Ethylhexyl) phthalate (DEHP)
• Benzyl butyl phthalate (BBP)
• Dibutyl phthalate (DBP)
• Diisobutyl phthalate (DIBP)
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
Page 9
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 9
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product
packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in
packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated
materials.
• Reduce size and weight of packages to improve transportation fuel
efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in
many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities. This
information (product disassembly instructions) is posted on the Hewlett Packard
web site at: http://www.hp.com/go/recyclers. These instructions may be used
Page 10
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 10
by recyclers and other WEEE treatment facilities as well as HP OEM customers
who integrate and re-sell HP equipment.
HP, Inc. Corporate
Environmental
Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesi
gn/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755
842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
Page 11
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Technical Specifications
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 11
Copyright © 2019 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries.
ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency.
Page 12
QuickSpecs
HP EliteDisplay E223d 21.5-inch Docking Monitor
Summary
c06314765 — DA16472 — Worldwide — Version 1 — July 22, 2019
Page 12
Change Log
V1 to V2
Loading...
