HP DL580 User Manual

HP ProLiant DL580 Generation 5 Server User Guide

Part Number 453878-002
September 2008 (Second Edition)

© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP
shall not be liable for technical or editorial errors or omissions contained herein.

Microsoft, Windows, Windows Server 2003, and Windows NT are U.S. registered trademarks of Microsoft Corporation.

Intended audience

This document is for the person who installs, administers, and troubleshoots servers and storage systems.
HP assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards
in products with hazardous energy levels.

Contents

Component identification............................................................................................................... 7

Front panel components ............................................................................................................................. 7

Front panel LEDs and buttons ......................................................................................................................8

Systems Insight Display ..............................................................................................................................9

Rear panel components............................................................................................................................ 10

Rear panel LEDs and buttons..................................................................................................................... 11

Power supply LED.................................................................................................................................... 12

System board components........................................................................................................................ 13

SPI board components ................................................................................................................... 14

System maintenance switch............................................................................................................. 14

FBDIMM slot locations ............................................................................................................................. 15

SAS device numbers................................................................................................................................ 16

SAS hard drive LEDs ......................................................................................................................17

SAS hard drive LED combinations.................................................................................................... 17

Battery pack LEDs.................................................................................................................................... 18

Fan locations ..........................................................................................................................................20

Operations................................................................................................................................. 21

Power up the server................................................................................................................................. 21

Power down the server............................................................................................................................. 21

Extending the server from the rack............................................................................................................. 21

Removing the access panel....................................................................................................................... 23

Accessing the Systems Insight Display ........................................................................................................ 24

Removing the system battery .....................................................................................................................24

Setup......................................................................................................................................... 26

Optional installation services .................................................................................................................... 26

Rack planning resources........................................................................................................................... 26

Optimum environment.............................................................................................................................. 27

Space and airflow requirements ...................................................................................................... 27

Temperature requirements............................................................................................................... 27

Power requirements .......................................................................................................................28

Electrical grounding requirements .................................................................................................... 28

Rack warnings ........................................................................................................................................ 29

Identifying the contents of the server shipping carton.................................................................................... 29

Installing hardware options....................................................................................................................... 29

Setting up a tower model server ................................................................................................................ 30

Installing the server into the rack................................................................................................................ 31

Powering up and configuring the server .....................................................................................................31

Installing the operating system................................................................................................................... 32

Registering the server............................................................................................................................... 32

Hardware options installation....................................................................................................... 33

Introduction ............................................................................................................................................ 33

Processor options .................................................................................................................................... 33

Removing the processor memory module .......................................................................................... 33

Installing a processor ..................................................................................................................... 35

Contents 3

Memory options...................................................................................................................................... 39

Memory configurations................................................................................................................... 39

Advanced ECC memory ................................................................................................................. 40

Online spare memory configuration ................................................................................................. 41

Mirrored memory configuration....................................................................................................... 42

Installing FBDIMMs ........................................................................................................................ 42

Installing optional memory expansion boards.................................................................................... 43

Hot-plug SAS hard drive options ............................................................................................................... 44

Installing a hot-plug SAS hard drive ................................................................................................. 44

Installing the drive cage ................................................................................................................. 45

Tape drive.............................................................................................................................................. 49

Redundant hot-plug power supply option.................................................................................................... 52

Battery-backed write cache....................................................................................................................... 53

Fans ...................................................................................................................................................... 56

Expansion board options.......................................................................................................................... 57

Installing non-hot-plug expansion boards .......................................................................................... 57

Installing the PCI Express x8 3 Slot Option Card ............................................................................... 58

Installing the PCI-X 3 Slot Option Card ............................................................................................. 59

Cabling ..................................................................................................................................... 61

BBWC cabling........................................................................................................................................ 61

Hard drive cabling .................................................................................................................................. 62

Tape drive cabling ..................................................................................................................................63

SATA DVD drive cabling.......................................................................................................................... 63

DVD drive cabling................................................................................................................................... 63

Server software and configuration utilities...................................................................................... 65

Configuration tools.................................................................................................................................. 65

SmartStart software........................................................................................................................ 65

SmartStart Scripting Toolkit ............................................................................................................. 65

HP ROM-Based Setup Utility ..................................................................................................................... 66

Using RBSU .................................................................................................................................. 66

Configuring online spare memory.................................................................................................... 66

Configuring mirrored memory ......................................................................................................... 67

Auto-configuration process.............................................................................................................. 67

Boot options ................................................................................................................................. 68

BIOS Serial Console ...................................................................................................................... 68

HP ProLiant Essentials Rapid Deployment Pack ............................................................................................ 68

Option ROM Configuration for Arrays ....................................................................................................... 68

Array Configuration Utility........................................................................................................................ 69

Re-entering the server serial number and product ID..................................................................................... 69

Management tools................................................................................................................................... 70

Automatic Server Recovery .............................................................................................................70

ROMPaq utility.............................................................................................................................. 70

System Online ROM flash component utility ......................................................................................70

Remote Insight Lights-Out Edition II................................................................................................... 70

Integrated Lights-Out 2 technology................................................................................................... 71

StorageWorks library and tape tools................................................................................................ 71

HP Systems Insight Manager........................................................................................................... 71

Management Agents...................................................................................................................... 71

Redundant ROM support ................................................................................................................ 72

USB support.................................................................................................................................. 72

Diagnostic tools ...................................................................................................................................... 72

HP Insight Diagnostics.................................................................................................................... 72

Contents 4

Integrated Management Log ...........................................................................................................73

Array Diagnostic Utility ..................................................................................................................73

Remote support and analysis tools............................................................................................................. 73

HP Instant Support Enterprise Edition................................................................................................ 73

Keeping the system current ....................................................................................................................... 74

Drivers ......................................................................................................................................... 74

ProLiant Support Packs ................................................................................................................... 74

Operating system version support.................................................................................................... 74

Change control and proactive notification ........................................................................................ 74

Care Pack ....................................................................................................................................74

Troubleshooting.......................................................................................................................... 75

Troubleshooting resources ........................................................................................................................75

Pre-diagnostic steps ................................................................................................................................. 75

Important safety information............................................................................................................ 75

Symptom information ..................................................................................................................... 77

Prepare the server for diagnosis ......................................................................................................78

Loose connections ...................................................................................................................................78

Service notifications................................................................................................................................. 79

Troubleshooting flowcharts .......................................................................................................................79

Start diagnosis flowchart ................................................................................................................79

General diagnosis flowchart ........................................................................................................... 80

Server power-on problems flowchart ................................................................................................82

POST problems flowchart ............................................................................................................... 85

OS boot problems flowchart ...........................................................................................................86

Server fault indications flowchart ..................................................................................................... 88

POST error messages and beep codes....................................................................................................... 90

Regulatory compliance notices ..................................................................................................... 91

Regulatory compliance identification numbers............................................................................................. 91

Federal Communications Commission notice............................................................................................... 91

FCC rating label............................................................................................................................ 91

Class A equipment......................................................................................................................... 91

Class B equipment......................................................................................................................... 91

Declaration of conformity for products marked with the FCC logo, United States only....................................... 92

Modifications.......................................................................................................................................... 92

Cables................................................................................................................................................... 92

Canadian notice (Avis Canadien).............................................................................................................. 93

European Union regulatory notice .............................................................................................................93

Disposal of waste equipment by users in private households in the European Union......................................... 93

Japanese notice ...................................................................................................................................... 94

BSMI notice............................................................................................................................................ 94

Korean notice ......................................................................................................................................... 94

Laser compliance .................................................................................................................................... 95

Battery replacement notice........................................................................................................................ 95

Taiwan battery recycling notice................................................................................................................. 96

Power cord statement for Japan................................................................................................................. 96

Acoustics statement for Germany (Geräuschemission) .................................................................................. 96

Electrostatic discharge................................................................................................................. 97

Preventing electrostatic discharge.............................................................................................................. 97

Grounding methods to prevent electrostatic discharge.................................................................................. 97

Specifications............................................................................................................................. 98

Environmental specifications ..................................................................................................................... 98

Contents 5

Server specifications................................................................................................................................ 98

Technical support...................................................................................................................... 100

Before you contact HP............................................................................................................................ 100

HP contact information........................................................................................................................... 100

Acronyms and abbreviations...................................................................................................... 101

Index....................................................................................................................................... 105

Contents 6

Component identification

Front panel components

Item Description

1 USB connectors
2 Video connector
3 Systems Insight Display
4 DVD drive bay
5 Optional tape drive or blank
6 Optional hard drive bay or blank
7 Hard drive bay
8 Processor memory module

Component identification 7

Front panel LEDs and buttons

Item Description Status

1 UID switch and LED Blue—Activated

Blue (flashing)—Server being managed remotely
Off—Deactivated

2 Internal system health LED Green—Normal (system on)

Amber (flashing)—Internal system health degraded
Red (flashing)—Internal system health critical
Off—Normal (system off)

3 External system health LED Green—Normal (system on)

Amber (flashing)—External system health degraded
Red (flashing)—External system health critical
Off—Normal (system off)

4 NIC 1 link/activity LED Green—Linked to network

Green (flashing)—Linked with activity on the network
Off—No network connection

5 NIC 2 link/activity LED Green—Linked to network

Green (flashing)—Linked with activity on the network
Off—No network connection

6 Power on/Standby button and

LED

Amber—System has AC power and is in standby mode.
Green—System has AC power and is turned on.
Off—System has no AC power.

Component identification 8

Systems Insight Display

The Systems Insight Display LEDs represent the server and component layout.

LED Description

ONLINE SPARE Off—No protection

Green—Protection enabled
Amber—Memory failure occurred
Amber (flashing)—Memory configuration error

MIRROR Off—No protection

Green—Protection enabled
Amber—Memory failure occurred
Amber (flashing)—Memory configuration error

All other LEDs Off—Normal

Amber—Failed or missing component

Component identification 9

Rear panel components

Item Description Item Description

1 Power supply bay 4 (optional) 13 PCI-X non-hot-plug for PCI Express x8 non-hot-

plug expansion slot 3 (optional)
2 Power supply bay 3 (optional) 14 PCI Express x8 non-hot-plug expansion slot 4
3 Power supply bay 2 15 PCI Express x8 non-hot-plug expansion slot 5
4 Power supply bay 1 16 PCI Express x8 non-hot-plug expansion slot 6
5 Keyboard connector 17 PCI Express x8 non-hot-plug expansion slot 7
6 USB connectors 18 PCI Express x4 non-hot-plug expansion slot 8
7 Video connector 19 PCI Express x4 non-hot-plug expansion slot 9
8 Serial connector 20 PCI Express x4 non-hot-plug expansion slot

10
9 iLO 2 NIC connector 21 PCI Express x4 non-hot-plug expansion slot

11
10 Mouse connector 22 NIC 2 connector
11 PCI-X non-hot-plug or PCI Express x8

non-hot-plug expansion slot 1
(optional)

12 PCI-X non-hot-plug or PCI Express x8

non-hot-plug expansion slot 2
(optional)

23 NIC 1 connector

24 Torx T-15 tool

Component identification 10

Rear panel LEDs and buttons

Item Description LED color Status

1 NIC 2 Activity LED Green On or flashing—Network activity

Off—No network activity

2 NIC 2 Link LED Green On—Linked to network

Off—Not linked to network

3 UID Blue On—Front UID button activated

Off—Normal

4 iLO 2 NIC Activity LED Green On or flashing—Network activity

Off—No network activity

5 iLO 2 NIC Link LED Green On—Linked to network

Off—Not linked to network

6 NIC 1 Link LED Green On—Linked to network

Off—Not linked to network

7 NIC 1 Activity LED Green On or flashing—Network activity

Off—No network activity

Component identification 11

Power supply LED

Power LED
(green)

Off Off No AC power to power supply units
On Off AC present. Standby output on. Power supply DC output on and OK
Off On Power supply failure (includes overvoltage and overtemperature)

Failure LED
(amber)

Status

Component identification 12

System board components

Item Description

1 Fan 1
2 Fan 2
3 Connector for:

• PCI Express x8 3 Slot Option Card (optional)

• PCI-X 3 Slot Option Card (optional)

4 Fan 3
5 Fan 5
6 Fan 4
7 Fan 6
8 PCI Express x8 non-hot-plug expansion slot 4
9 PCI Express x8 non-hot-plug expansion slot 5
10 PCI Express x8 non-hot-plug expansion slot 6
11 PCI Express x8 non-hot-plug expansion slot 7
12 PCI Express x4 non-hot-plug expansion slot 8
13 PCI Express x4 non-hot-plug expansion slot 9
14 PCI Express x4 non-hot-plug expansion slot 10
15 PCI Express x4 non-hot-plug expansion slot 11

Component identification 13

Item Description

16 System maintenance switch
17 SPI board

SPI board components

Item Description

1 BBWC cache module connectors
2 Battery

System maintenance switch

The system maintenance switch (SW1) is an eight-position switch that is used for system configuration. The
default position for all eight positions is Off.

Position Description Function

S1 iLO 2 Security Off = iLO 2 security is enabled

On = iLO 2 security is disabled

S2 Configuration

lock

S3 Reserved Reserved
S4 Reserved Reserved
S5 Password

protection
override

Off = System configuration can
be changed

On = System configuration is
locked

Off = No function
On = Clears power-on

password and administrator
password

Component identification 14

Position Description Function

S6 Invalidate

configuration

S7 Reserved Reserved

S8 Reserved Reserved

Off = Normal
On = Clears NVRAM

FBDIMM slot locations

The server contains 16 FBDIMM slots on the processor-memory board, which are numbered sequentially
from 1 to 16. The paired banks are identified by the letters A through H.

Four FBDIMM slots located on each optional memory board are numbered from 1 to 4. The paired banks
are identified by the letters A through D.

Component identification 15

SAS device numbers

Component identification 16

SAS hard drive LEDs

Item Description

1 Fault/UID LED (amber/blue)
2 Online LED (green)

SAS hard drive LED combinations

Online/activity
LED (green)

On, off, or
flashing

On, off, or
flashing

On Amber, flashing

On Off The drive is online, but it is not active currently.
Flashing regularly

(1 Hz)

Flashing regularly
(1 Hz)

Flashing
irregularly

Fault/UID LED

Interpretation

(amber/blue)

Alternating amber and
blue

Steadily blue The drive is operating normally, and it has been selected by a

regularly (1 Hz)

Amber, flashing
regularly (1 Hz)

Off Do not remove the drive. Removing a drive may terminate the

Amber, flashing
regularly (1 Hz)

The drive has failed, or a predictive failure alert has been
received for this drive; it also has been selected by a
management application.

management application.
A predictive failure alert has been received for this drive.
Replace the drive as soon as possible.

Do not remove the drive. Removing a drive may terminate the
current operation and cause data loss.

The drive is part of an array that is undergoing capacity
expansion or stripe migration, but a predictive failure alert has
been received for this drive. To minimize the risk of data loss,
do not replace the drive until the expansion or migration is
complete.

current operation and cause data loss.
The drive is rebuilding, or it is part of an array that is

undergoing capacity expansion or stripe migration.
The drive is active, but a predictive failure alert has been

received for this drive. Replace the drive as soon as possible.

Component identification 17

Online/activity
LED (green)

Flashing

Fault/UID LED
(amber/blue)

Off The drive is active, and it is operating normally.

irregularly
Off Steadily amber A critical fault condition has been identified for this drive, and

Off Amber, flashing

regularly (1 Hz)

Off Off The drive is offline, a spare, or not configured as part of an

Battery pack LEDs

Interpretation

the controller has placed it offline. Replace the drive as soon as
possible.

A predictive failure alert has been received for this drive.
Replace the drive as soon as possible.

array.

Item ID Color Description

1 Green System Power LED. This LED glows steadily when the

system is powered up and 12 V system power is
available. This power supply is used to maintain the
battery charge and provide supplementary power to the
cache microcontroller.

2 Green Auxiliary Power LED. This LED glows steadily when 3.3V

auxiliary voltage is detected. The auxiliary voltage is used
to preserve BBWC data and is available any time that the
system power cords are connected to a power supply.

3 Amber Battery Health LED. To interpret the illumination patterns of

this LED, see the following table.

4 Green BBWC Status LED. To interpret the illumination patterns of

this LED, see the following table.

Component identification 18

LED3 pattern LED4 pattern Interpretation

— One blink every

two seconds

— Double blink,

then pause

— One blink per

second

— Steady glow The battery pack is fully charged, and posted write data is stored in

— Off The battery pack is fully charged, and there is no posted write data

One blink per
second

One blink per
second

Steady glow — There is a short circuit across the battery terminals or within the

One blink per

— There is an open circuit across the battery terminals or within the

second

The system is powered down, and the cache contains data that has
not yet been written to the drives. Restore system power as soon as
possible to prevent data loss.

Data preservation time is extended any time that 3.3 V auxiliary
power is available, as indicated by LED 2. In the absence of
auxiliary power, battery power alone preserves the data. A fully­charged battery can normally preserve data for at least two days.

The battery lifetime also depends on the cache module size. For
further information, refer to the controller QuickSpecs on the HP
website (http://www.hp.com

).

The cache microcontroller is waiting for the host controller to
communicate.

The battery pack is below the minimum charge level and is being
charged. Features that require a battery (such as write cache,
capacity expansion, stripe size migration, and RAID migration) are
temporarily unavailable until charging is complete. The recharge
process takes between 15 minutes and two hours, depending on the
initial capacity of the battery.

the cache.

in the cache.
An alternating green and amber blink pattern indicates that the

cache microcontroller is executing from within its boot loader and
receiving new flash code from the host controller.

battery pack. BBWC features are disabled until the battery pack is
replaced. The life expectancy of a battery pack is typically more
than three years.

battery pack. BBWC features are disabled until the battery pack is
replaced. The life expectancy of a battery pack is typically more
than three years.

Component identification 19

Fan locations

Component identification 20

Operations

Power up the server

To power up the server, press the Power On/Standby button.

Power down the server

WARNING: To reduce the risk of personal injury, electric shock, or damage to the equipment,

remove the power cord to remove power from the server. The front panel Power On/Standby
button does not completely shut off system power. Portions of the power supply and some

1. Back up the server data.

2. Shut down the operating system as directed by the operating system documentation.

3. Press the Power On/Standby button to place the server in Standby mode. When the server activates

internal circuitry remain active until AC power is removed.

IMPORTANT: If installing a hot-plug device, it is not necessary to power down the server.

NOTE: If the operating system automatically places the server in Standby mode, omit the next

step.

Standby power mode, the system power LED changes to amber.

IMPORTANT: Pressing the UID button illuminates the blue UID LEDs on the front and rear

panels. In a rack environment, this feature facilitates locating a server when moving between
the front and rear of the rack.

4. Disconnect the power cords.

The system is now without power.

Extending the server from the rack

The design of the server enables you to access several components through the front of the server. You do
not need to extend the server from the rack to install or access the following components:

• Processors

• PPMs

• Memory

• Processor memory module

• DVD drive

Operations 21

• Hard drives

• Systems Insight Display

WARNING: To reduce the risk of personal injury or equipment damage, be sure that the rack

To extend the server from the rack:

1. Pull down the quick-release levers on each side of the server to release the server from the rack.

2. Extend the server on the rack rails until the server rail-release latches engage.

is adequately stabilized before extending a component from the rack.

WARNING: To reduce the risk of personal injury, be careful when pressing the server rail-

release latches and sliding the server into the rack. The sliding rails could pinch your fingers.

3. After performing the installation or maintenance procedure, slide the server into the rack by pressing

the server rail-release latches.

Operations 22

Removing the access panel

WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the

1. Extend the server from the rack, if applicable ("Extending the server from the rack" on page 21).

2. Unlock the latch using a T-15 Torx screwdriver.

3. Lift up on the hood latch, and remove the access panel.

internal system components to cool before touching them.

CAUTION: Do not operate the server for long periods with the access panel open or removed.

Operating the server in this manner results in improper airflow and improper cooling that can
lead to thermal damage.

NOTE: The T-15 Torx screwdriver is shipped with the server and can be located on the rear

panel ("Rear panel components" on page 10).

4. After installing hardware options, replace the access panel. Be sure that the panel is securely locked

into place before powering up the server.

Operations 23

Accessing the Systems Insight Display

To access the Systems Insight Display:

1. Press and release the panel.

2. After the display fully ejects, rotate the display downward to view the LEDs.

Removing the system battery

If the server no longer automatically displays the correct date and time, you may need to replace the
battery that provides power to the real-time clock. Under normal use, battery life is 5 to 10 years.

WARNING: The computer contains an internal lithium manganese dioxide, a vanadium

pentoxide, or an alkaline battery pack. A risk of fire and burns exists if the battery pack is not
properly handled. To reduce the risk of personal injury:

• Do not attempt to recharge the battery.

• Do not expose the battery to temperatures higher than 60°C (140°F).

• Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water.

To remove the battery:

1. Power down the server (on page 21).

2. Extend or remove the server from the rack ("Extending the server from the rack" on page 21).

3. Remove the access panel ("Removing the access panel" on page 23).

• Replace only with the spare designated for this product.

Operations 24

4.

If the bracket is installed, remove the bracket.

5. Locate the battery ("SPI board components" on page 14).

6. Remove the battery.

To replace the component, reverse the removal procedure.
Run the RBSU to configure the server after replacing the battery. See the HP ROM-Based Setup Utility User

Guide on the Documentation CD for more detailed information.

Operations 25

Setup

Optional installation services

Delivered by experienced, certified engineers, HP Care Pack services help you keep your servers up and
running with support packages tailored specifically for HP ProLiant systems. HP Care Packs let you
integrate both hardware and software support into a single package. A number of service level options
are available to meet your needs.

HP Care Pack Services offer upgraded service levels to expand your standard product warranty with easy­to-buy, easy-to-use support packages that help you make the most of your server investments. Some of the
Care Pack services are:

• Hardware support

o 6-Hour Call-to-Repair
o 4-Hour 24x7 Same Day
o 4-Hour Same Business Day

• Software support

o Microsoft®
o Linux
o HP ProLiant Essentials (HP SIM and RDP)
o VMWare

• Integrated hardware and software support

o Critical Service
o Proactive 24
o Support Plus
o Support Plus 24

• Startup and implementation services for both hardware and software

For more information on Care Packs, refer to the HP website
(http://www.hp.com/hps/carepack/servers/cp_proliant.html

Rack planning resources

).

The rack resource kit ships with all HP branded or Compaq branded 9000, 10000, and H9 series racks.
For more information on the content of each resource, refer to the rack resource kit documentation.

If you intend to deploy and configure multiple servers in a single rack, refer to the white paper on high­density deployment at the HP website (http://www.hp.com/products/servers/platforms

).

Setup 26

Optimum environment

When installing the server, select a location that meets the environmental standards described in this

Space and airflow requirements

section.

To allow for servicing and adequate airflow, observe the following space and airflow requirements when
deciding where to install a rack:

• Leave a minimum clearance of 63.5 cm (25 in) in front of the rack.

• Leave a minimum clearance of 76.2 cm (30 in) behind the rack.

• Leave a minimum clearance of 121.9 cm (48 in) from the back of the rack to the back of another

rack or row of racks.

HP servers draw in cool air through the front door and expel warm air through the rear door. Therefore,
the front and rear rack doors must be adequately ventilated to allow ambient room air to enter the
cabinet, and the rear door must be adequately ventilated to allow the warm air to escape from the
cabinet.

CAUTION: To prevent improper cooling and damage to the equipment, do not block the

ventilation openings.

When vertical space in the rack is not filled by a server or rack component, the gaps between the
components cause changes in airflow through the rack and across the servers. Cover all gaps with
blanking panels to maintain proper airflow.

CAUTION: Always use blanking panels to fill empty vertical spaces in the rack. This

arrangement ensures proper airflow. Using a rack without blanking panels results in improper
cooling that can lead to thermal damage.

The 9000 and 10000 Series Racks provide proper server cooling from flow-through perforations in the
front and rear doors that provide 64 percent open area for ventilation.

CAUTION: When using a Compaq branded 7000 Series rack, you must install the high

airflow rack door insert [P/N 327281-B21 (42U) or P/N 157847-B21 (22U)] to provide
proper front-to-back airflow and cooling.

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure

adequate airflow and to prevent damage to the equipment:

• Front and rear doors—If the 42U rack includes closing front and rear doors, you must allow

5,350 sq cm (830 sq in) of holes evenly distributed from top to bottom to permit adequate
airflow (equivalent to the required 64 percent open area for ventilation).

• Side—The clearance between the installed rack component and the side panels of the rack

must be a minimum of 7 cm (2.75 in).

Temperature requirements

To ensure continued safe and reliable equipment operation, install or position the system in a well­ventilated, climate-controlled environment.

Setup 27

The maximum recommended ambient operating temperature (TMRA) for most server products is 35°C
(95°F). The temperature in the room where the rack is located must not exceed 35°C (95°F).

CAUTION: To reduce the risk of damage to the equipment when installing third-party options:

• Do not permit optional equipment to impede airflow around the server or to increase the

internal rack temperature beyond the maximum allowable limits.

• Do not exceed the manufacturer’s TMRA.

Power requirements

Installation of this equipment must comply with local and regional electrical regulations governing the
installation of information technology equipment by licensed electricians. This equipment is designed to
operate in installations covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992
(code for Protection of Electronic Computer/Data Processing Equipment). For electrical power ratings on
options, refer to the product rating label or the user documentation supplied with that option.

WARNING: To reduce the risk of personal injury, fire, or damage to the equipment, do not

overload the AC supply branch circuit that provides power to the rack. Consult the electrical

When installing more than one server, you may need to use additional power distribution devices to
safely provide power to all devices. Observe the following guidelines:

• Balance the server power load between available AC supply branch circuits.

authority having jurisdiction over wiring and installation requirements of your facility.

CAUTION: Protect the server from power fluctuations and temporary interruptions with a

regulating uninterruptible power supply (UPS). This device protects the hardware from damage
caused by power surges and voltage spikes and keeps the system in operation during a power
failure.

• Do not allow the overall system AC current load to exceed 80 percent of the branch circuit AC

current rating.

• Do not use common power outlet strips for this equipment.

• Provide a separate electrical circuit for the server.

Electrical grounding requirements

The server must be grounded properly for proper operation and safety. In the United States, you must
install the equipment in accordance with NFPA 70, 1999 Edition (National Electric Code), Article 250,
as well as any local and regional building codes. In Canada, you must install the equipment in
accordance with Canadian Standards Association, CSA C22.1, Canadian Electrical Code. In all other
countries, you must install the equipment in accordance with any regional or national electrical wiring
codes, such as the International Electrotechnical Commission (IEC) Code 364, parts 1 through 7.
Furthermore, you must be sure that all power distribution devices used in the installation, such as branch
wiring and receptacles, are listed or certified grounding-type devices.

Because of the high ground-leakage currents associated with multiple servers connected to the same
power source, HP recommends the use of a PDU that is either permanently wired to the building’s branch
circuit or includes a nondetachable cord that is wired to an industrial-style plug. NEMA locking-style plugs
or those complying with IEC 60309 are considered suitable for this purpose. Using common power outlet
strips for the server is not recommended.

Setup 28

Rack warnings

WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:

• The leveling jacks are extended to the floor.

• The full weight of the rack rests on the leveling jacks.

• The stabilizing feet are attached to the rack if it is a single-rack installation.

• The racks are coupled together in multiple-rack installations.

• Only one component is extended at a time. A rack may become unstable if more than one

component is extended for any reason.

WARNING: To reduce the risk of personal injury or equipment damage when unloading a

rack:

• At least two people are needed to safely unload the rack from the pallet. An empty 42U

rack can weigh as much as 115 kg (253 lb), can stand more than 2.1 m (7 ft) tall, and
may become unstable when being moved on its casters.

• Never stand in front of the rack when it is rolling down the ramp from the pallet. Always

handle the rack from both sides.

Identifying the contents of the server shipping carton

Unpack the server shipping carton and locate the materials and documentation necessary for installing the
server. All the rack mounting hardware necessary for installing the server into the rack is included with the
rack or the server.

The contents of the server shipping carton include:

• Server

• Power cord

• Hardware documentation, Documentation CD, and software products

• Rack-mounting hardware

In addition to the supplied items, you may need:

• Operating system or application software

• Hardware options

Installing hardware options

Install any hardware options before initializing the server. For options installation information, refer to the
option documentation. For server-specific information, refer to "Hardware options installation (on page

33)."

Setup 29

Setting up a tower model server

Follow these steps to set up a tower model server. If you are going to install the server into a rack, see the
rack installation section ("Installing the server into the rack" on page 31).

1. Connect the peripheral devices to the server.

Item Description Item Description

1 Power supply bay 4 (optional) 13 PCI-X non-hot-plug for PCI Express x8 non-

hot-plug expansion slot 3 (optional)

2 Power supply bay 3 (optional) 14 PCI Express x8 non-hot-plug expansion slot

4

3 Power supply bay 2 15 PCI Express x8 non-hot-plug expansion slot

5

4 Power supply bay 1 16 PCI Express x8 non-hot-plug expansion slot

6

5 Keyboard connector 17 PCI Express x8 non-hot-plug expansion slot

7

6 USB connectors 18 PCI Express x4 non-hot-plug expansion slot

8

7 Video connector 19 PCI Express x4 non-hot-plug expansion slot

9

8 Serial connector 20 PCI Express x4 non-hot-plug expansion slot

10

Setup 30
