QuickSpecs

Overview

What's New

•

Intel Xeon™ Processors MP at

2.0 GHz/2MB or 1.5 GHz/1MB.

At A Glance

•

Next generation D L580 G2

maximum performance and unprecedented availability in a flexible, rack optimized form factor

•

Intel Xeon Processors MP at 2.0 GHz/2M, 1.9GHz/1M, 1.5GHz/1M,

1.60 GHz/1MB or 1.40 GHz/512KB

•

ServerWorks Grand Champi onHE chipset

•

4x1 interleaved memory, 200MHz DDR SDRAM Memory (PC1600 Registered S DRAM with Advanced ECC functionality)

•

2048 MB (2P Mod els) or 1024 MB (1P Model) st andard memory , expandable to 32 GB

•

HP Advanced Memory Protect ion (Online Spare, Single Board Mirrored Memory, Hot Plug Mirrored Memory)

•

Six, full length 64-bit/1 00 MHz PCI-X slots, 4 Hot Pluggable

•

Integrated Lights-Out Standard Management (iLO) on system board

•

Integrated Compaq NC7770 PCIX Gigabit Server Adapter in a slot

•

Integrated Smart Array 5i Plus Controller (Dual Channel, Ultra3) with 64-MB total memory on 5i Plus Memory Mod ule

•

Battery-Backed Write Cache Enabler module on all 2P models (optional on 1P model )

•

Internal Hot Plug Drive Storage of up to 587.2 GB (4 x 146.8-GB 1″ Wide Ultra3 SCSI hard driv es )

•

Redundant Cooling Zones for major subsystems (Memory, I/O, CPUs) assure 7x24 cooling

•

Toolless and virtually c able-less internal des ign

•

Innovative diagnostic lighting (QuickFind Diagnostic Display) for rapid response to service events

•

Rapid Deployment rack i ng solution (r ack rails and cable management)

•

Protected by HP Services, including a t hree-year, N ext Business Day on-site, limited, Global warra nty and extend ed Pre-Failure Warranty that covers processors, memory and dis k drives — Certain restrict ions and exclusions apply. Consult the HP Customer Su pport Center at 1-800-345-1518 for details.

delivers

hp ProLiant DL580 Generation 2 (G2)

DA-11372 World Wide — Version 25 — March 20, 2003 1

QuickSpecs

Standard Features

hp ProLiant DL580 Generation 2 (G2)

Processor

One or more of the following depending on Model

Cache Memory

One of the following depending on Model

Upgradabili ty

Chipset

Memory

One of the following depending on Model

Intel Xeon Processor MP at 2.00 GHz\2MB Intel Xeon Processor MP 1.90 GHz\1MB Intel Xeon Processor MP at 1.50 GHz\1MB Intel Xeon Processor MP at 1.60 GHz\1MB

Intel Xeon Processor MP at 1.40 GHz\512KB

2-MB Integrated Level 3 Cache

NOTE: 2.0 GHz Models only.

1-MB Integrated Level 3 Cache

NOTE: 1.9GHz, 1.6GHz and 1.5GHz Models only.

512-KB Integrated Level 3 Cache

NOTE: 1.40 MHz Models only.

Upgradable to quad processing

ServerWorks Grand Champion-HE chipset

NOTE: For more information regarding ServerWorks, please see the following URL:

http://www.serverworks.com/products/overview.html.

Standard 2048 MB 200-MHz Double Data Rate (DDR) SDRAM (PC1600 Registered

SDRAM Memory with Advanced ECC functionality) (2P Models) Maximum 32 GB Standard 1024 MB 200-MHz Double Data Rate (DDR) SDRAM (PC1600-MHz Registered

SDRAM Memory with Advanced ECC functionality) (1P Model) Maximum 32 GB

NOTE: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component

failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered DIMMs.

NOTE: 32 GB achieved with use of 2nd, optional memory board and 2GB Registered DIMM sticks.

Network Con troller

Expansion Slots

Manageability Integrated Lights-Out (iLO) Standard Management (ASIC on the System Board)

Storage Con troller

Storage Data Pro tection

Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot

I/O (6 Total, 5 Available) PCI Voltage:

64-bit/100-MHz PCI-X Hot Plug

64-bit/100-MHz PCI-X Non-Hot Plug

Smart Array 5i Plus Controller (integrated on system board), Dual Channel, Ultra3 (supports RAID 0, 1, 1+0, and 5 across internal hard disk drives) with 64 MB of memory.

• 64-MB total memory for code, transfer buffers, and read/write cache on the 5i Plus Memory Module

• Connector for Battery Backed Write Cache (BBWC) Enabler

NOTE: The Smart Array 5i Plus Controller is integrated on the system board and is designed to support the

duplex/simplex drive cage. An external SCSI port is not available on the DL580 G2. External SCSI solutions require the addition of a PCI or PCI-X option card.

NOTE: For complete list of devices supported the Smart Array 5i Controller see the following:

http://www5.hp.com/products/quickspecs/10890_div/10890_div.HTML (Divis ion/Worl d Wide) http://www5.hp.com/products/quickspecs/10890_na/10890_na.HTML (North America)

The Battery-Backed Write Cache (BBWC) Enabler protects up to 64-MB write cache memory from hard boot, power, controller, or system board failures.

• Standard on DL580 G2 2P Models, optional on DL580 G2 1P Models

• Battery charge/life: Up to 72 hours/ 3 years

• Transportable data protection

• Increases overall controller performance

NOTE: Safely transport your write cache data to another DL580 G2 in the data center be removing the BBWC

Enabler and 5i Plus Memory Module simultaneously (connected by short cable).

3, 4, 5 and 6 available 3.3 Volt or Universal cards (3.3/5.0V) only

1, 2 (NIC in slot 1) 3.3 Volt or Universal (3.3/5.0V) cards only

DA-11372 World Wide — Version 25 — March 20, 2003 2

QuickSpecs

Standard Features

hp ProLiant DL580 Generation 2 (G2)

Storage

Interfaces

Graphics

Form Factor

ProLiant™ Essentials Foundation Pack Software

Diskette Drive 1.44 MB (slim line) – ejectable for security and se rviceability CD-ROM 24x IDE CD-ROM Drive (slim line) – ejectable for security and serviceability Hard Drives None Maximum Internal Storage 587.2 GB (4 x 146.8 GB Wide Ultra 320 1″ drives) (internal hot plug Ultra3 drive

Hard Disk Drive Backplane Internal Wide Ultra3 backplane supports up to four 1″ hard disk drives and is

Serial 1 Pointing Device (Mouse) 1 Graphics 1 Keyboard 1 Rear USB Ports 2 iLO Remote Management 1 Network RJ-4 5 1

Integrated 1280 x 1024, 16M color on PCI local bus, 8-MB of SDRAM video memory

Rack (4U = 7 inches), ships with sliding rails and cable management system Space saving form factor (4U) provides space efficiencies while providing maximum deployment flexibility

Insight Manager™ 7 Insight Manager 7 helps maximize system uptime and performance and reduces

SmartStart™ SmartStart is a tool that simplifies server setup, providing a rapid way to deploy

Management Agents The Management Agents form the foundation for HP’s Intelligent Manageability

ActiveUpdate ActiveUpdate is a web-based application that keeps IT managers directly

ROMPaq, support software,

and configuration utilities Survey Utility and diagnostics

utilities

cage)

easily configurable to support simplex (4x1) or duplex mode (2x2) Standard

shipping configuration is the duplex mode.

NOTE: Optional SCSI cable assembly 288874-B21 is required for connecting

Smart Array Controller in a PCI slot to internal hard drive backplane. Duplex configuration requires two such kits.

the cost of maintaining the IT infrastructure by providing proactive notification of

problems before those problems result in costly downtime and reduced

productivity. Insight Manager 7 is easy to set up and provides rapid access to

detailed fault and performance information

One-click-access to the Remote Insight Lights Out Edition board allows systems

administrators to take full graphical control of ProLiant servers in remote

locations or lights-out data centers. Finally, Insight Manager 7 in concert with the

Version Control Agents and Version Control Repository Manager enables

systems administrators to version manage and update system software across

groups of ProLiant servers.

reliable and consistent server configurations. For more information, please visit

the SmartStart website at http://www.hp.com/servers/smartstart.

SmartStart version supported (minimum): SmartStart 5.40.

strategy. They provide direct, browser-based access to in-depth instrumentation

built into HP servers, workstations, desktops, and portables, and send alerts to

Insight Manager 7 and other enterprise management applications in case of

subsystem or environmental failures. For additional information about the

Management Agents and other management products from HP, please visit the

management website at http://www.hp.com/servers/manage.

connected to HP for proactive notification and delivery of the latest software

updates.

The latest software, drivers, and firmware fully optimized and tested for your

ProLiant server and options.

The most advanced configuration analysis, reporting and troubleshooting utilities

used by HP and at your fingertips.

athered by the Management Agents.

DA-11372 World Wide — Version 25 — March 20, 2003 3

QuickSpecs

Standard Features

hp ProLiant DL580 Generation 2 (G2)

ProLiant Essentials Foundation Pack Software (continued)

Industry Standard Compliance

Optional ProLiant Essentials Value Packs

NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to

http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product

QuickSpecs for more information.

NOTE: For more information regarding ProLiant Essentials Software, please see the following URL:

http://www.hp.com/servers/proliantessentials.

NOTE: These Web sites are available in English only.

ACPI 2.0 Compliant PCI 2.2 Compliant

PXE Support WOL Support Physical Address Extension (PAE) Support



Microsoft

Logo certifications

Optional software offerin

Infrastructure to address specific business problems and needs:

• Rapid Deployment Pack – an automated solution for multi-server deployment and provisioning, enabling companies to quickly and easily adapt to changing business demands.

• Workload Management Pack – provides easier management of complex environments, improving overall server utilization and enabling Windows 2000 customers for the first time to confidently deploy multiple applications on a single multiprocessor ProLiant Server.

• Integrated Lights-Out Advanced Pack – upgrades the Integrated Lights-Out processor to full virtual presence and control with graphical console and virtual media.

• Integrated Lights-Out Advanced Pack – upgrades the Integrated Lights-Out processor to full virtual presence and control with graphical console and virtual media

• Recovery Server Option Pack – entry-level high availability software that will provide reliab le protection and increased uptime against server hardware and operating system failures.

• Performance Management Pack – a performance management solution that identifies and explains hardware performance bottlenecks on ProLiant servers and attached options enabling users to better utilize their valuable resources.

s that selectively extend the functionality of an Adaptive



Intelligent M anageability

DA-11372 World Wide — Version 25 — March 20, 2003 4

Integrated Lights-Out (iLO) Standard Management

• Virtual Text Remote Console

• Virtual Power Button Control

• Dedicated LAN Connectivity

• Automatic IP Configuration via DHCP/DNS/WINS

• Industry Standard 128-bit Secure Sockets Layer (SSL) Security

• IML and iLO Event Logging

• Support for 12 user accounts with customizable access privileges

Integrated Lights-Out (iLO) Advanced Pack (supports Advanced features such as Graphical Remote Console and Virtual Floppy − available as a separate option)

Automatic Server Recovery-2 (ASR-2) Insight Manager 7 Redundant ROM Remote Flash ROM ROM-Based Setup Utility (RBSU) Integrated Management Log (IML) Hot Spare Boot (NOTE: Upon the event of a failed processor or VRM in a multi-processing environment, the

system will automatically reboot and use the remaining good processor(s).)

Dynamic sector repairing and drive parameter tracking (with Smart Array controllers) Redundant/adaptive load balancing NIC Support

QuickSpecs

Standard Features

hp ProLiant DL580 Generation 2 (G2)

Availability

• Standard Advanced ECC functionality detects and corrects single bit and specific multi-bit memory errors (4bit and 8bit) while using industry standard registered DIMMS. Functionality is embedded in the chipset design.

• HP Advanced Memory Protection Technology – delivers unsurpassed memory protection and server availability:

• Online Spare Memory

Offers a higher level of memory protection than Advanced ECC alone. If the number of single-bit correctable errors on a bank exceeds the pre-defined error threshold, that bank will fail over to the online spare bank without intervention or server interruption. Online spare memory can be configured across one or two memory cards. The failed memory can then be replaced at the user’s convenience during a scheduled maintenance window.

• Single-Board Mirrored Memory

Single-board mirrored memory provides a higher level of availability than Advanced ECC and Online Spare Memory because it protects against multi-bit errors. Single-board Mirrored Memory uses mirrored banks on a single memory board that is configured with one redundant bank of memory. The system writes to both banks, but reads from one. If a DIMM(s) has a multi-bit error, the system simply reads from the mirrored bank instead. This process occurs without intervention or server interruption, and the failed DIMM can be replaced during a regularly scheduled shutdown.

• Hot Plug Mirrored Memory

Hot Plug Mirrored Memory is a fault-tolerant memory feature that provides a higher level of availability than Advanced ECC, Online Spare Memory, or Single-Board Mirrored Memory because it protects against multi-bit errors and does not require any server downtime to replace failed DIMMs. Hot Plug Mirrored Memory requires that two memory boards be installed, one an exact mirror of the other, which run in parallel and provide protection against multi-bit memory errors. When configured for Hot Plug Mirrored Memory, the system writes to both memory boards, but reads from one. If a read error occurs, the system fails over to the redundant memory board. At that point the memory board containing the failed DIMMs can be hot replaced. Once the failed DIMMs are replaced and the memory board re-installed into the server, the system goes back to full mirrored status. All this occurs without bringing the server down.

NOTE: Hot Plug Mirrored Memory and Dual-Board Online Spare Memory require the use of two memory cards. All DL580 G2 servers ship standard with a single memory board. The second memory board is optional (P/N 203320-B21). NOTE: All HP Advanced Memory Protection modes are user configurable through the ROM-Based Setup Utility (RBSU) and viewable through Insight Manager 7 and the Integrated Management Log (IML.).

• PCI-X Hot Plug Technology (Four 64bit/100-MHz PCI-X hot plug slots available)

• Smart Array 5i Plus Controller with standard Battery Backed Write Cache (BBWC) Enabler provides

transportable data protection and increases overall controller performance. Up to 64MB Battery Backed Write Cache protection available on 2P DL580 G2 models (BBWC Enabler is optional on 1P model.)

• Redundant Cooling Zones across major server subsystems (Memory, I/O, CPU) provide 7x24 cooling. Each zone is independent of each other and is able to support n+1 redundancy, as indicated below:

• PCI-X expansion zone is 1+1 redundant (fans 1 and 2)

• Memory zone is 1+1 redundant (fans 3 and 4)

• CPU zone is 2+1 redundant (fans 5, 6, and 7)

This zone configuration enables the server to withstand up to three fan failures, provided that they are not within the same zone. Each fan is hot plug redundant and individually removable.

• Up to four Hot Plug Ultra3 Drive Bays

• Duplex or Simplex SCSI Backplane (Duplex configuration is standard)

• Dual Hot Plug Redundant Power Supplies (standard on 2P Models, one ships standard on 1P Models.)

DA-11372 World Wide — Version 25 — March 20, 2003 5

QuickSpecs

)

Standard Features

hp ProLiant DL580 Generation 2 (G2)

Serviceability

Security

• Innovative Diagnostic Lighting

• QuickFind Diagnostic Display – precisely depicts all major subsystems of the server (PCI-X I/O, Memory,

CPU, Redundant Cooling, Interlock, Thermtrip) and gives instant visual indication of fault status. Located on top front of server.

• LED display on front panel indicates power, internal health, external health, Unit ID light.

• LED display on Memory board indicates Memory status, health, and protection mode.

• Tool-less, virtually cable-less interior design

• Tool-less access to interior of server

• Two ejectable, slim line media drives (diskette and CD-ROM standard with support for optional DVD-

ROM drives) are removable without the use of tools

• Front access power supplies

• Spring-loaded memory board release latches prevent unseating incidents

• PCI Card Guides locks full length PCI cards in place during transit

• SCSI Duplex/Simplex Drive Cage connects directly to system board – no cables.

NOTE: Confi located on the cage itself. System ships standard in Duplex mode.

• Seven individually removable fans connect without cables to the system board

• Processor/VRM Retention Cage securely locks both processor and VRM into their respective sockets

• Tool-less removal of system board

• Quick Deploy Rails

• Tool-less design “snap in” rail

Power-on password Keyboard password Diskette drive control Diskette boot control Network Server Mode Security Provision Serial interface control Administrator’s password Disk configuration lock Hot plug access security Removable Diskette drive Removable CD-ROM drive

ure your SCSI Duplex/Simplex Drive Cage by means of simple switch (duplex to simplex

Power Supply

System Fans

Required Cabl ing

DA-11372 World Wide — Version 25 — March 20, 2003 6

800-Watt (low line or high line) Hot Plug Power Supply

NOTE: One 800-Watt Hot Plug Power Supply ships standard with 1P Models (optional Redundant Hot Plug

Power Supply Option Kit).

NOTE: Two 800-Watt Hot Plug Power Supplies ship standard with 2P Models.

Standard 7 Hot plug, redundant fans (individually removable) Maximum 7 Hot plug, redundant fans (individually removable)

• Redundant Cooling Zones across major server subsystems (Memory, I/O, CPU) provide 7x24 cooling. Each zone is independent of each other and is able to support n+1 redundancy, as indicated below:

- PCI-X expansion zone is 1+1 redundant (fans 1 and 2)

- Memory zone is 1+1 redundant (fans 3 and 4)

- CPU zone is 2+1 redundant (fans 5, 6, and 7)

• This zone configuration enables the server to withstand up to three fan failures, provided that they are not within the same zone. Each fan is hot plug redundant and individually removable.

For required cabling information, refer to the HP Web site at

http://www.compaq.com/products/servers/proliantDL580/.

QuickSpecs

Standard Features

OS Support

hp ProLiant DL580 Generation 2 (G2)



Microsoft Windows NT Microsoft Windows 2000



Novell

NetWare LINUX (Red Hat, SuSE) Sun Solaris 8 Intel Platform Edition

NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS Support

Matrix at: ftp://ftp.HP.com/pub/products/servers/os-support-matrix-310.pdf.

NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant DL580 G2, please see:

http://www.HP.com/support/files/server/us/index.html.

Server



Rack Airflow Req uirements

Rack Kit

• Rack 9000 and 10000 series Cabinets

The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The Compaq 9000 Series Rack and the 10000 Series Racks provides enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

• Rack 7000 series Cabinets

When installing a server with processors running at speeds of 550 MHz or greater in Compaq Rack 7000 series racks with glass doors (165753-001 (42U), and 163747-001 (22U)), the new processor technology requires the installation of Compaq’s High Airflow Rack Door Inserts (327281-B21 (42U), 327281-B22 (42U 6 pack), or 157847-B21 (22U)) to promote enhanced airflow for maximum cooling.

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow

and to prevent damage to the equipment:

- Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).

- Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of 7 cm (2.75 inches).

CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This

arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with

the server, or to the server documentation located in the Support section at the following URL:

http://www5.HP.com/products/servers/proliantdl580/index.html.

DL580 G2 rack models provide tool-free support for square hole racks (including Compaq/HP 7000, 9000, 10000

and H9 series) with an adjustment range from 28″ – 29″ in depth

Service and Support

DA-11372 World Wide — Version 25 — March 20, 2003 7

HP Services provides a three-year, limited warranty, including Pre-Failure Warranty (coverage of hard drives, memory and processors) fully supported by a worldwide network of resellers and service providers. HP technical assistance is available 7x24, toll free in the United States and Canada. Telephone support services may be covered under warranty or available for an additional fee.

NOTE: Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support.

A full range of CarePaq packaged hardware and software services:

• Installation and start up

• Extended coverage hours and enhanced response times

• System management and performance services

• Availability and recovery services

NOTE: For more information, customer/resellers can contact http://www.compaq.com/services. Please see the following URL regarding Warranty Information For Your HP Products:

http://www.compaq.com/support/warranty_upgrades/web_statements/176738.html

For additional information regarding Worldwide Limited Warranty and Technical Support, please see the following URL: ftp://ftp.compaq.com/pub/supportinformation/ejourney/176738.pdf

NOTE: Certain restrictions and exclusions apply. Consult the Customer Support Center at 1-800-345-1518 for

details.

QuickSpecs

Models

hp ProLiant DL580 Generation 2 (G2)

DL580R02 X2.0 GHz-2MB, 2048MB (2P )

202176-xx1

DL580R02 X1900-1MB, 2048MB

(2P)

202175-xx1

Processor Cache Memory Memory

Network Controller Storage Controller Smart Array 5i Plus Controller (Dual Channel, Ultra3) with Battery-Backed Write

Manageability Hard Drive Internal Storage

Power Supply Optical Drive Form Factor

Processor Cache Memory Memory

Network Controller Storage Controller Smart Array 5i Plus Controller (Dual Channel, Ultra3) with Battery-Backed Write

Manageability Hard Drive Internal Storage

Power Supply Optical Drive Form Factor

(2) Intel Xeon Processors MP at 2.0 GHz standard (up to 4 supported) 2-MB Integrated Level 3 Cache

2048 MB PC1600 registered ECC SDRAM (Standard) to 32 GB (Maximum) (4x1 interleaved memory and HP Advanced Memory Protection Technology) Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot

Cache Enabler (integrated on system board) Integrated Lights-Out (iLO) Standard management (integrated on system board)

None ship standard

587.2 GB maximum (with optional hard drives) Two 800W Hot Plug Redundant Power Supplies (low line or high line)

24x IDE slim-line CD-ROM Drive Rack 4U

(2) Intel Xeon Processors MP at 1.90 GHz standard (up to 4 supported) 1-MB Integrated Level 3 Cache

2048 MB PC1600 registered ECC SDRAM (Standard) to 32 GB (Maximum) (4x1 interleaved memory and HP Advanced Memory Protection Technology) Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot

Cache Enabler (integrated on system board) Integrated Lights-Out (iLO) Standard management (integrated on system board)

None ship standard

587.2 GB maximum (with optional hard drives) Two 800W Hot Plug Redundant Power Supplies (low line or high line)

24x IDE slim-line CD-ROM Drive Rack 4U

DL580R02 X1600-1MB, 2048MB

(2P)

201203-xx1

Processor Cache Memory Memory

Network Controller Storage Controller Smart Array 5i Plus Controller (Dual Channel, Ultra3) with Battery-Backed Write

Manageability Hard Drive Internal Storage

Power Supply Optical Drive Form Factor

(2) Intel Xeon Processors MP at 1.60 GHz standard (up to 4 supported) 1-MB Integrated Level 3 Cache

2048 MB PC1600 registered ECC SDRAM (Standard) to 32 GB (Maximum) (4x1 interleaved memory and HP Advanced Memory Protection Technology) Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot

Cache Enabler (integrated on system board) Integrated Lights-Out (iLO) Standard management (integrated on system board)

None ship standard

587.2 GB maximum (with optional hard drives) Two 800W Hot Plug Redundant Power Supplies (low line or high line)

24x IDE slim-line CD-ROM Drive Rack 4U

DA-11372 World Wide — Version 25 — March 20, 2003 8

QuickSpecs

Models

hp ProLiant DL580 Generation 2 (G2)

DL580R02 X1400-512KB, 2048MB (2P )

201202-xx1

DL580R02 X1500-1MB, 1024MB

(1P)

202174-xx1

Processor Cache Memory Memory

Network Controller Storage Controller Smart Array 5i Plus Controller (Dual channel, Ultra3) with Battery-Backed Write

Manageability Hard Drive Internal Storage

Power Supply Optical Drive Form Factor

Processor Cache Memory Memory

Network Controller Storage Controller

Manageability Hard Drive Internal Storage Power Supply Optical Drive Form Factor

(2) Intel Xeon Processors MP at 1.40 GHz standard (up to 4 supported) 512-KB Integrated Level 3 Cache

2048 MB PC1600 registered ECC SDRAM (Standard) to 32 GB (Maximum) (4x1 interleaved memory and HP Advanced Memory Protection Technology) Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot

Cache Enabler (integrated on system board) Integrated Lights-Out (iLO) Standard management (integrated on system board)

None ship standard

587.2 GB maximum (with optional hard drives) Two 800W Hot Plug Power Supplies (low line or high line)

24x IDE slim-line CD-ROM Drive Rack 4U

(1) Intel Xeon Processor MP at 1.50 GHz standard (up to 4 supported) 1MB Integrated Level 3 Cache

1024 MB PC1600 registered ECC SDRAM (Standard) to 32 GB (Maximum) (4x1 interleaved memory and HP Advanced Memory Protection Technology) Integrated Compaq NC7770 PCI-X Gigabit Server Adapter in a slot Smart Array 5i Plus Controller (Dual channel, Ultra3) (integrated on system

board) Integrated Lights-Out (iLO) Standard management (integrated on system board) None ship standard

587.2 GB maximum (with optional hard drives) One 800W Power Supply (low line or high line) 24x IDE slim-line CD-ROM Drive Rack 4U

DL580R02 X1400-512KB, 1024MB (1P )

201201-xx1

Country Code Key

Processor Cache Memory Memory

Network Controller Storage Controller

Manageability Hard Drive Internal Storage Power Supply Optical Drive Form Factor

XX=00 U.S. XX=01 Australia

XX=42 Int’l, Europe, Germany, France XX=03 UK XX=37 APD XX=29 Japan XX=AA PRC

(1) Intel Xeon Processor MP at 1.40 GHz standard (up to 4 supported) 512-KB Integrated Level 3 Cache

board) Integrated Lights-Out (iLO) Standard management (integrated on system board) None ship standard

587.2 GB maximum (with optional hard drives) One 800W Power Supply (low line or high line) 24x IDE slim-line CD-ROM Drive Rack 4U

DA-11372 World Wide — Version 25 — March 20, 2003 9

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

ProLiant DL580 Unique Options

8192MB PC1600 Registered ECC SDRAM Memory Kit (4 x 2048 MB) 202173-B21 4096MB PC1600 Registered ECC SDRAM Memory Kit (4 x 1024 MB) 202172-B21 2048MB PC1600 Registered ECC SDRAM Memory Kit (4 x 512 MB) 202171-B21 1024MB PC1600 Registered ECC SDRAM Memory Kit (4 x 256 MB) 202170-B21 Hot Plug Memory Expansion Board

NOTE: The Hot Plug Memory Expansion Board provides 8 additional DIMM slots for

powering memory-intensive applications.

800W Hot Plug Redundant Power Supply US 278535-001 800W Hot Plug Redundant Power Supply AUST 278535-011 800W Hot Plug Redundant Power Supply EURO 278535-021 800W Hot Plug Redundant Power Supply UK 278535-031 800W Hot Plug Redundant Power Supply JPN2 278535-291 800W Hot Plug Redundant Power Supply -inc IEC 278535-B21 DL580 G2 Third Party Racking Kit 287528-B21 DL580 G2 Folding Cable Management Arm 289294-B21 DL580 G2 Cable Assembly, SCSI, Ultra3, LVDS

NOTE: All DL580 G2 models ship standard with the integrated Smart Array 5i Plus

Controller, which has been designed to deliver maximum performance and

availability across the internal SCSI Duplex backplane.

• The Ultra3 SCSI cable is required onl Smart Array 5i Plus Controller and connect slot-based SCSI adapters or RAID controllers to the internal SCSI Duplex backplane.

• Two cables are required to maintain the standard, duplexed configuration of the backplane.

• One cable is required if the simplex configuration is chosen.

The backplane is easily configured to simplex mode by means of a simple switch

duplex to simplex) located on the top of the backplane itself.

Cord, AC Line, 20A, 250V, US 235604-001 Cable, 16A, IEC320-C20 to IEC320-C19

NOTE: Power cord (295633-B21) connects ProLiant servers to PDUs or UPSs with

IEC320-C19 output connections.

Cable, 10A, IEC320-C14 to IEC320-C19

NOTE: Power cord (291034-B21) connects ProLiant DL580 G2 servers to PDUs or

UPSs with IEC320-C13 output connections. This power cord has been

specifically designed to work with the ProLiant DL580 G2 server. Please NOTE

the following important precautions when deploying this power cord:

• Use the cord only in conjunction with the ProLiant DL580 G2 server.

• Use the cord to connect the ProLiant DL580 G2 server only to PDUs or

UPSs with IEC320-C13 output connections.

• Do not use the cord with any other ProLiant or third party server.

• Do not use the cord with any other office equipment or computers.

• Do not use the cord as an extension cord.

• Do not plug the cord into a wall outlet.

Failure to adhere to these precautions may invalidate the server warranty.

if the customer chooses to bypass the

203320-B21

288874-B21

295633-B21

291034-B21

ProLiant Essentials Value Pack Software

DA-11372 World Wide — Version 25 — March 20, 2003 10

Rapid Deployment Pack, 1 User, V1.x

NOTE: This license allows 1 server to be managed and deployed via the Deployment

Server.

Rapid Deployment Pack, 1 User, V1.x (Japan)

NOTE: This license allows 1 server to be managed and deployed via the Deployment

Server.

Rapid Deployment Pack, 10 Users, V1.x

NOTE: This license allows 10 servers to be managed and deployed via the Deployment

Server.

Rapid Deployment Pack, 10 Users, V1.x (Japan)

NOTE: This license allows 10 servers to be managed and deployed via the Deployment

Server.

ProLiant Essentials Workload Management Pack (Featuring HP Resource Partitioning Manager version 2.0)

267196-B21

267196-291

269817-B21

269817-291

303284-B21

QuickSpecs

(

Options

hp ProLiant DL580 Generation 2 (G2)

ProLiant Essentials Value Pack Software (continued)

Software HP digital asset protection 302316-001

Processor Intel Xeon MP X2.0 GHz-2MB Processor Option Kit

ProLiant Essentials Recovery Server Option Pack Integrated Lights-Out (iLO) Advanced Pack ProLiant Essentials Performance Management Pack v2.0, Single License

NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials

Value Packs. Refer to http://www.hp.com/servers/proliantessentials or the

various ProLiant Essentials Value Pack product QuickSpecs for more

information. NOTE: For more information regarding ProLiant Essentials Software, please see the

following URL: http://www.hp.com/servers/proliantessentials.

NOTE: These Web sites are available in English only.

NOTE: This processor option kit

the DL580 G2.

Intel Xeon MP X1.9 GHz-1MB Processor Option Kit

NOTE: This processor option kit

the ProLiant DL580 G2.

Intel Xeon MP X1.50 GHz-1MB Processor Option Kit

NOTE: This processor option kit (PN 191220-B21) supports the ProLiant ML570 G2 and

the ProLiant DL580 G2.

Intel Xeon MP X1.60 GHz-1MB Processor Option Kit

NOTE: This processor option kit (PN 226776-B21) supports the ProLiant DL580 G2

only.

Intel Xeon MP X1.40 GHz-512KB Processor Option Kit

NOTE: This processor option kit (PN 226775-B21) supports the ProLiant ML570 G2 and

the ProLiant DL580 G2.

PN 307276-B21) supports the ProLiant ML570 G2 and

PN 311228-B21) supports the ProLiant ML570 G2 and

280189-B21 263825-B21 306696-B21

307276-B21

311228-B21

191220-B21

226776-B21

226775-B21

Memory (DIMMs) 8192 MB PC1600 Registered ECC SDRAM Memory Kit (4 x 2048 MB)

4096 MB PC1600 Registered ECC SDRAM Memory Kit (4 x 1024 MB) 2048 MB PC1600 Registered ECC SDRAM Memory Kit (4 x 512 MB) 1024 MB PC1600 Registered ECC SDRAM Memory Kit (4 x 256 MB)

Hot Plug Memory Expansion Board

NOTE: The Hot Plug Memory Expansion Board provides 8 additional DIMM slots for

powering memory-intensive applications.

Optical Drives Slimline DVD-ROM Drive (8X/24X) Option Kit

Hard Drives

Ultra320 – Universal Hot Plug

146.8-GB 10,000 rpm U320 Universal Hard Drive (1″)

72.8-GB 10,000 rpm U320 Universal Hard Drive (1″)

36.4-GB 10,000 rpm U320 Universal Hard Drive (1″)

72.8-GB 15,000 rpm U320 Universal Hard Drive (1″)

36.4-GB 15,000 rpm U320 Universal Hard Drive (1″)

18.2-GB 15,000 rpm U320 Universal Hard Drive (1″)

NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds.

U320 drives require an optional U320 Smart Array Controller or U320 SCSI

HBA to support U320 transfer rates. NOTE: Please see the Hard Drive QuickSpecs for Technical Specifications such as capacity, height, width,

interface, transfer rate, seek time, physical configuration, and operating temperature:

U320 Hard Drive QS:

http://www5.compaq.com/products/quickspecs/11531_div/11531_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11531_na/11531_na.HTML (North America)

202173-B21 202172-B21 202171-B21 202170-B21

203320-B21

264007-B21

286716-B22 286714-B22 286713-B22 286778-B22 286776-B22 286775-B22

DA-11372 World Wide — Version 25 — March 20, 2003 11

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Storage Controllers Smart Array 532 Controller

Smart Array 532 Controller (Japan) Smart Array 5302/128 Controller Smart Array 5302/128 Controller (Japan) Smart Array 5304/256 Controller Smart Array 5304/256 Controller (Japan) Smart Array 5312 Controller Smart Array 5312 Controller (Japan)

Smart Array 641 Controller 291966-B21 Smart Array 642 Controller 291967-B21

Ultra3 Channel Expansion Module for Smart Array 5300 Controller 128-MB Cache Module for Smart Array 5302 Controller 256-MB Battery-Backed Cache Module

NOTE: This 256-MB Battery-Backed Cache Module supports the Smart Array 5300

series controllers, MSA 1000 and the Smart Array Cluster Storage.

RAID ADG Upgrade for Smart Array 5302 Battery-Backed Write Cache Enabler Option Kit

NOTE: This Battery-Backed Write Cache Enable Option Kit (PN 255514-xx1) is optional

for the DL580 G2 1P Model only.

Battery-Backed Write Cache Enabler Option Kit (Japan)

NOTE: This Battery-Backed Write Cache Enable Option Kit (PN 255514-xx1) is optional

for the DL580 G2 1P Model only.

64 MB Battery Backed Write Cache Enabler

NOTE: This 64 MB BBWC supports the Smart Array 641 Controller and Smart Array

642 Controller.

DL580 G2 Cable Assembly, SCSI, Ultra3, LVDS

NOTE: All DL580 G2 models ship standard with the integrated Smart Array 5i Plus

Controller, which has been designed to deliver maximum performance and

availability across the internal SCSI Duplex backplane.

• The Ultra3 SCSI cable is required onl Smart Array 5i Plus Controller and connect slot-based SCSI adapters or RAID controllers to the internal SCSI Duplex backplane.

• Two cables are required to maintain the standard, duplexed configuration of the backplane.

• One cable is required if the simplex configuration is chosen.

The backplane is easily configured to simplex mode by means of a simple switch

duplex to simplex) located on the top of the backplane itself.

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 154457-B21 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 129803-B21 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter 268351-B21

64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter, Alternate OS 284688-B21

NOTE: Please see the following Controller or SCSI Adapter QuickSpecs for Technical Specifications such as PCI

Bus, PCI Peak Data Transfer Rate, SCSI Protocols supported, SCSI Peak Data Transfer Rate, Channels, SCSI Ports, Drives supported, Cache, RAID support, and additional information:

http://www5.compaq.com/products/quickspecs/11063_div/11063_div.HTML (Smart Array 5i Plus) http://www5.compaq.com/products/quickspecs/10851_div/10851_div.HTML (Smart Array 532) http://www5.compaq.com/products/quickspecs/10640_div/10640_div.HTML (Smart Array 5300 Series) http://www5.compaq.com/products/quickspecs/11328_div/11328_div.HTML (Smart Array 5312) http://www5.compaq.com/products/quickspecs/11563_div/11563_div.HTML (Smart Array 641) http://www5.compaq.com/products/quickspecs/11563_div/11563_div.HTML (Smart Array 642) http://www5.compaq.com/products/quickspecs/10429_div/10429_div.HTML (SCSI Adapter) http://www5.compaq.com/products/quickspecs/11555_div/11555_div.HTML (U320 Adapter)

225338-B21

225338-291

283552-B21

283552-291

283551-B21

283551-291

238633-B21

238633-291

153507-B21 153506-B21 254786-B21

288601-B21 255514-B21

255514-291

291969-B21

288874-B21

if the customer chooses to bypass the

DA-11372 World Wide — Version 25 — March 20, 2003 12

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Communications

Redundant Options 800W Hot Plug Redundant Power Supply US 278535-001

Management Options

Security HP/Atalla AXL600L SSL Accelerator Card for ProLiant Servers

Monitors Essential Series

Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Port 10/100 Compaq NC3135 Fast Ethernet Module Dual 10/100 Upgrade Module for NC3134 Compaq NC6132 Gigabit Module 1000 SX Upgrade Module for NC3134 Compaq NC6136 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 1000 SX Compaq NC7131 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 10/100/1000-T Compaq NC7132 10/100/1000-T Upgrade Module for NC3134 and NC3131 Compaq NC7770 PCI-X Gigabit Server Adapter

800W Hot Plug Redundant Power Supply AUST 800W Hot Plug Redundant Power Supply EURO 800W Hot Plug Redundant Power Supply UK 800W Hot Plug Redundant Power Supply JPN2 800W Hot Plug Redundant Power Supply -inc IEC

Remote Insight Lights-Out Edition II (NA, LA) 227251-001 Remote Insight Lights-Out Edition II (EMEA) 227251-021 Remote Insight Lights-Out Edition II (ROW) 227251-371

Compaq AXL300 Accelerator PCI Card for ProLiant Servers 227933-B21

Compaq S9500 CRT Monitor (19-inch, Carbon/Silver) 261615-XX Compaq S7500 CRT Monitor (17-inch, Carbon/Silver) 261606-XX Compaq S5500 CRT Monitor (15-inch Carbon/Silver) 261602-XX Compaq TFT1501 Flat Panel Monitor (15-inch, Carbon/Silver, North America) 301042-003 Compaq TFT1501 Flat Panel Monitor (15-inch, Carbon/Silver, Outside North America) P4825D-XX Compaq TFT1701 Flat Panel Monitor (17-inch, Carbon/Silver, North America) 292847-003 Compaq TFT1701 Flat Panel Monitor (17-inch, Carbon/Silver, Outside North America) P9019A-XX

Advantage Series

Compaq V7550 CRT Color Monitor (17-inch, Carbon/Silver) 261611-XX Compaq TFT1720 Flat Panel Monitor (17-inch, Carbon/Silver, North America) 295926-003 Compaq TFT1720 Flat Panel Monitor (17-inch, Carbon/Silver, outside North America) D5064D-XX Compaq FT1720M Flat Panel Monitor (17-inch, (Carbon/Silver, includes speaker, USB

port, headphone, North America) Compaq TFT1720M Flat Panel Monitor (17-inch, (Carbon/Silver, includes speaker, USB

port, headphone, outside North America) Compaq TFT1520 Flat Panel Monitor (15-inch, Carbon/Silver, North America) 295925-003 Compaq TFT1520 Flat Panel Monitor (15-inch, Carbon/Silver, outside North America) D5063D-XX Compaq TFT1520M Flat Panel Monitor (15-inch, (Carbon/Silver includes speaker, USB

port, headphone, North America) Compaq TFT1520M Flat Panel Monitor (15-inch, (Carbon/Silver includes speaker, USB

port, headphone, outside North America)

138603-B21 138604-B21 338456-B23 203539-B21 158575-B21 153543-B21 244948-B21

278535-011 278535-021 278535-031 278535-291

278535-B21

524545-B21

301958-003

D5064P-XX

301957-003

D5063P-XX

DA-11372 World Wide — Version 25 — March 20, 2003 13

QuickSpecs

Options

Monitors (continued) Performance Series

HP P930 CRT Monitor (19-inch, Flat-screen, Carbon/Silver, North America) 302268-003 HP P930 CRT Monitor (19-inch, Flat-screen, Carbon/Silver, Outside North America) P909W-XX HP P1130 CRT Monitor (21-inch, Flat-screen, Carbon/Silver, North America) 302270-003 HP P1130 CRT Monitor (21-inch, Flat-screen, Carbon/Silver, Outside North America)

HP L1825 Flat Panel Monitor (18-inch, Carbon/Silver, North America) 303486-003 HP L1825 Flat Panel Monitor (18-inch, Carbon/Silver, Outside North America) P9021W-XX HP L2025 Flat Panel Monitor (20-inch, Carbon/Silver, North America) 303102-003 HP L2025 Flat Panel Monitor (20-inch, Carbon/Silver, Outside North America) P4831W-XX Compaq TFT1825 Flat Panel Monitor (18-inch, Carbon/Silver, North America) 296751-003 Compaq TFT1825 Flat Panel Monitor (18-inch, Carbon/Silver, Outside North America) P9021A-XX Compaq TFT2025 Flat Panel Monitor (20-inch, Carbon/Silver, North America) 285550-003 Compaq TFT2025 Flat Panel Monitor (20-inch, Carbon/Silver, Outside North America) P4831D-XX

Rackmount Flat Panel Monitors

TFT5110R Flat Panel Monitor (Carbon) TFT5010R Flat Panel Monitor (NA) TFT5010R Flat Panel Monitor (Int’l) TFT5010R Flat Panel Monitor (Japan)

hp ProLiant DL580 Generation 2 (G2)

P4819-XX

281683-B21

217248-001

217248-B31

217248-291

Tape Drives Internal and External DAT Tape Drives

HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Carbon) (NA) HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Int’l) (Carbon) HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Japan) (Carbon) HP StorageWorks Internal 20/40-GB DAT, Hot Plug (Carbon) HP StorageWorks 3U Rackmount Tape Drive Kit

NOTE: Please see the 20/40-GB DAT Tape Drive QuickSpecs for additional options such as host bus adapters,

controllers, cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/10426_div/10426_div.HTML (Division/World Wide) http://www5.compaq.com/products/quickspecs/10426_na/10426_na.HTML (North America)

Internal and External AIT Tape Drives

HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) (Int’l) HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) (Japan) HP StorageWorks Internal AIT 35-GB, LVD, Hot Plug (Carbon)

NOTE: Please see the AIT 35 GB, LVD Tape Drive QuickSpecs for additional options such as adapters,

controllers, and cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/10712_div/10712_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10712_na/10712_na.HTML (North America)

HP StorageWorks AIT 50-GB Tape Drive, External (Carbon) (NA) HP StorageWorks AIT 50-GB Tape Drive, External (Int’l) (Carbon) HP StorageWorks AIT 50-GB Tape Drive, External (Japan) (Carbon) Internal AIT 50-GB, Hot Plug (Carbon) HP StorageWorks Rackmount AIT 50-GB, 3U (Single Drive) HP StorageWorks 3U Rackmount Tape Drive Kit

NOTE: Please see the AIT 50-GB Tape Drive QuickSpecs for additional options such as adapters, controllers, and

cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/10425_div/10425_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10425_na/10425_na.HTML (North America)

157770-002

157770-B32

157770-292 215488-B21 274338-B21

216885-001 216885-B31

216885-291 216886-B21

157767-002 157767-B32

157767-292 215487-B21 274333-B21 274338-B21

DA-11372 World Wide — Version 25 — March 20, 2003 14

QuickSpecs

hp ProLiant DL580 Generation 2 (G2)

Options

Tape Drives (continued) Internal and External AIT Tape Drives (continued)

HP StorageWorks External AIT 100-GB Tape Drive (Carbon) 249160-001 HP StorageWorks External AIT 100-GB Tape Drive (Carbon) (Int’l) 249160-B31 HP StorageWorks Internal AIT 100-GB, Hot-Plug (Carbon) 249161-B21

NOTE: Please see the AIT 100-GB Tape Drive QuickSpecs for additional options such as adapters, controllers,

and cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/11062_div/11062_div.HTML (Division/World Wide) http://www5.compaq.com/products/quickspecs/11062_na/11062_na.HTML (North America)

NOTE: Internal Hot Plug AIT drives can be supported by the integrated Smart Array 5i Plus Controller.

External DLT Tape Drives

HP StorageWorks External 20/40-GB DLT Drive (opal) (WW) 340744-B22 HP StorageWorks External 20/40-GB DLT Drive (opal) (Japan) 340744-292

NOTE: Please see the 20/40-GB DLT Drive QuickSpecs for additional options such as data and cleaning

cartridges, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/10234_div/10234_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10234_na/10234_na.HTML (North America)

HP StorageWorks 40/80-GB DLT Tape Drive, External (Carbon) (NA) 146197-B22 HP StorageWorks 40/80-GB DLT Tape Drive, External (Carbon) (Japan) 146197-293 HP StorageWorks Rackmount DLT 40/80, 3U (Single Drive) 274332-B21 HP StorageWorks Rackmount DLT 40/80, Dual-Drive, 3U (Two Drives) 274335-B21 HP StorageWorks Rackmount DLT 40/80 Tape Array III, 5U (Four Drives) 274337-B21

NOTE: Please see the 40/80-GB DLT Drive QuickSpecs for additional options such as host bus adapters,

controllers, cassettes, and for an up-to-date listing of the latest O/S Support details, please see the

following:

http://www5.compaq.com/products/quickspecs/10658_div/10658_div.HTML (Division/World Wide)

http://www5.compaqcom/products/quickspecs/10658_na/10658_na.HTML (North America)

External DLT VS Tape Drives

HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) All HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) (WW) HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) (Japan)

NOTE: Please see the DLT VS 40/80 Tape Drive QuickSpecs for additional options such as host bus adapters,

controllers, cassettes, and for an up-to-date listing of the latest O/S Support details, please see the

following:

http://www5.compaq.com/products/quickspecs/11403_div/11403_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11403_na/11403_na.HTML (North America)

External SDLT Tape Drives

HP StorageWorks SDLT 110/220, External NA (carbon) HP StorageWorks SDLT 110/220, External WW (carbon) HP StorageWorks SDLT 110/220, External Japan (carbon)

NOTE: Please see the SDLT 110/220-GB Tape Drive QuickSpecs for additional options such as adapters,

controllers, and media, and for an up-to-date listing of the latest O/S Support details, please see the

following:

http://www5.compaq.com/products/quickspecs/10772_div/10772_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10772_na/10772_na.HTML (North America)

HP StorageWorks SDLT 160/320, External NA (carbon) HP StorageWorks SDLT 160/320, External WW (carbon) HP StorageWorks SDLT 160/320, External Japan (carbon)

NOTE: Please see the SDLT 160/320-GB Tape Drive QuickSpecs for additional options such as adapters,

controllers, and media, and for an up-to-date listing of the latest O/S Support details, please see the

following:

http://www5.compaq.com/products/quickspecs/11406_div/11406_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11406_na/11406_na.HTML (North America)

280129-B22 280129-B31

280129-291

192103-002

192103-B32

192103-292

257319-001

257319-B31

257319-291

DA-11372 World Wide — Version 25 — March 20, 2003 15

QuickSpecs

Options

Tape Drives (continued) External SDLT Tape Drives (continued)

HP StorageWorks Rackmount SDLT 110/220, 3U (Single Drive) 274331-B21 HP StorageWorks Rackmount SDLT 110/220, Dual-Drive, 3U (Two Drives) 274334-B21 HP StorageWorks Rackmount SDLT 110/220 Tape Array III, 5U (Four Drives) 274336-B21

NOTE: Please see the SDLT 110/220-GB Tape Drive QuickSpecs for additional options such as adapters,

controllers, and media, and for an up-to-date listing of the latest O/S Support details, please see the

following:

http://www5.compaq.com/products/quickspecs/10772_div/10772_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10772_na/10772_na.HTML (North America)

External SuperLoader

DLT1 1280 SuperLoader

NOTE: Please see the StorageWorks DLT1 1280 SuperLoader QuickSpecs for additional options and for an up-

to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/11330_div/11330_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11330_na/11330_na.HTML (North America)

External LTO Ult rium Tape Drives

HP StorageWorks LTO Ultrium 230 Tape Drive, External (Carbon) NA HP StorageWorks LTO Ultrium 230 Tape Drive, External (Carbon) Int’l

NOTE: Please see the HP StorageWorks LTO Ultrium Tape Drive QuickSpecs for additional options such as

controllers, and other related items, and for an up-to-date listing of the latest O/S Support details, please

see the following:

http://www5.compaq.com/products/quickspecs/11415_div/11415_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11415_na/11415_na.HTML (North America)

hp ProLiant DL580 Generation 2 (G2)

268664-B21

Q1516A Q1517A

External HP StorageWorks Ultrium 460 tape drive for ProLiant

HP StorageWorks Ultrium 460 tape drive for ProLiant, external (Carbon) NA HP StorageWorks Ultrium 460 tape drive for ProLiant, external (Carbon) Int’l

NOTE: Please see the HP StorageWorks Ultrium 460 Tape Drive QuickSpecs for additional options such as

controllers, and other related items, and for an up-to-date listing of the latest O/S Support details, please

see the following:

http://www5.compaq.com/products/quickspecs/11530_div/11530_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11530_na/11530_na.HTML (North America)

1/8 Autoloader

HP Storage Works 1/8 Autoloader, DLT vs 80 HP Storage Works 1/8 Autoloader, Ultrium 230 Rackmount Kit for 1/8 Autoloader

NOTE: Please see the 1/8 Autoloader QuickSpecs for additional options such as adapters, controllers, and

cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/11496_div/11496_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11496_na/11496_na.HTML (North America)

Internal and External AIT Autoloader

HP StorageWorks AIT 35 GB Autoloader, Rackmount (Carbon) (NA) HP StorageWorks AIT 35 GB Autoloader, Rackmount (Carbon) (Int’l)

NOTE: Please see the AIT 35-GB Autoloader QuickSpecs for additional options such as adapters, controllers, and

cassettes, and for an up-to-date listing of the latest O/S Support details, please see the following:

http://www5.compaq.com/products/quickspecs/11404_div/11404_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/11404_na/11404_na.HTML (North America)

Q1519 Q1520

C9264CB C9572CB

C9268R

280349-001

280349-B31

DA-11372 World Wide — Version 25 — March 20, 2003 16

QuickSpecs

Options

Tape Drives (continued) Rackmount Tape Drive Kits

3U Rackmount Kit

NOTE: The 3U Rackmount Kit (PN 274338-B21) can support up to (2) full-height or (4)

half-height tape drives and compatible with multiple Single-Ended and LVD

SCSI Tape Drives including the 12/24-GB DAT, 20/40-GB DAT, 20/40-GB DAT

DDS-4 8 Cassette Autoloader, AIT 35-GB LVD, AIT 50 GB, 20/40-GB DLT,

40/80-GB DLT, SDLT 110/220-GB, and Ultrium 230 Tape Drives.

5U Rackmount Kit

NOTE: The 5U Rackmount Kit (PN 274339-B21) can support up to (4) full-height tape

drives and is compatible with all DLT/SDLT tape drives including the 20/40-GB

DLT, 35/70-GB DLT, 40/80-GB DLT, and SDLT 110/220-GB, and Ultrium 230

Tape Drives. NOTE: Please see the Rackmount Tape Drive Kits QuickSpecs for additional information regarding these kits,

please see the following:

http://www5.compaq.com/products/quickspecs/10854_div/10854_div.HTML (Division/World Wide)

http://www5.compaq.com/products/quickspecs/10854_na/10854_na.HTML (North America)

Rackmount Tape Drive Cable Kits

LVD Cable Kit, VHDCI/HD68

NOTE: For use with the 3U RM Storage Enclosure and DLT Tape Array III only.

LVD Cable Kit, HD68/HD68

NOTE: For use with the 3U RM Storage Enclosure and DLT Tape Array III only.

hp ProLiant DL580 Generation 2 (G2)

274338-B21

274339-B21

168048-B21

242381-B21

Tape Automation

StorageWorks ESL9000 Enterprise System Library

ESL9322L1 – LTO Ultrium based enterprise library with up to 8 drives and 222, 322 slots

ESL9322L1 222 slot 2 DRV LTO1 ESL9322L1 222 slot 8 DRV LTO1 ESL9322L1 322 slot 2 DRV LTO1 ESL9322L1 322 slot 8 DRV LTO1

ESL9322S2 – SDLT160 based enterprise library with up to 8 drives and 222, 322 slots

ESL9322S2 222 slot 2 DRV SDLT2 ESL9322S2 222 slot 8 DRV SDLT2 ESL9322S2 322 slot 2 DRV SDLT2 ESL9322S2 322 slot 8 DRV SDLT2

NOTE: Please see the StorageWorks ESL9322S2 Enterprise Library QuickSpecs for additional information

including Tape Drives, Cartridges, Controllers, and SCSI Cables and additional options needed for a

complete solution at:

http://www5.compaq.com/proudcts/quickspecs/11437_na/11437_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11437_div/11437_div.HTML (World Wide)

ESL9322: Common Options

ESL9322, slot upgrade 222 to 322 slots

ESL9595L1 – LTO Ultrium based enterprise library with up to 16 drives and 400, 500, 595 slots

ESL9595L1 400 slot 2 DRV LTO1 ESL9595L1 400 slot 16 DRV LTO1 ESL9595L1 500 slot 2 DRV LTO1 ESL9595L1 500 slot 16 DRV LTO1 ESL9595L1 595 slot 2 DRV LTO1 ESL9595L1 595 slot 16 DRV LTO1

NOTE: Please see the StorageWorks ESL9595L1 Enterprise Library QuickSpecs for additional information

including Tape Drives, Cartridges, Controllers, and SCSI Cables and additional options needed for a

complete solution at:

http://www5.compaq.com/products/quickspecs/11435_na/11435_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11435_div/11435_div.HTML (World Wide)

301927-B22 301927-B28 301928-B22 301928-B28

293409-B22 293409-B28 293410-B22 293410-B28

293588-B21

301929-B22 301929-B28 301931-B22 301931-B28 301932-B22 301932-B28

DA-11372 World Wide — Version 25 — March 20, 2003 17

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Tape Automation (continued)

StorageWorks ESL9000 Enterprise System Library (continued)

ESL9595S2 – SDLT160 based enterprise library with up to 16 drives and 400, 500, 595 slots

ESL9595S2 400 slot 2 DRV SDLT 160/320 ESL9595S2 400 slot 16 DRV SDLT 160/320 ESL9595S2 500 slot 2 DRV SDLT 160/320 ESL9595S2 500 slot 16 DRV SDLT 160/320 ESL9595S2 595 slot 2 DRV SDLT 160/320 ESL9595S2 595 slot 16 DRV SDLT 160/320

NOTE: Please see the StorageWorks ESL9595S2 Enterprise Library QuickSpecs for additional information

including Tape Drives, Cartridges, Controllers, and SCSI Cables and additional options needed for a

complete solution at:

http://www5.compaq.com/products/quickspecs/11436_na/11436_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11436_div/11436_div.HTML (World Wide)

ESL9595SL – SDLT110 based enterprise library with up to 16 drives and 400, 500, 595 slots

ESL9595SL 400 slots, 2 DRV SDLT110/220 274672-B22 ESL9595SL 400 slots, 16 DRV SDLT110/220 274672-B28 ESL9595SL 500 slots, 2 DRV SDLT110/220 281627-B22 ESL9595SL 500 slots, 16 DRV SDLT110/220 281627-B28 ESL9595SL 595 slots, 2 DRV SDLT110/220 281628-B22 ESL9595SL 595 slots, 16 DRV SDLT110/220 281628-B28

NOTE: Please see the StorageWorks ESL9595SL Enterprise Library QuickSpecs for additional information

including Tape Drives, Cartridges, Controllers, and SCSI Cables and additional options needed for a

complete solution at:

http://www5.compaq.com/products/quickspecs/11332_na/11332_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11332_div/11332_div.HTML (World Wide)

293411-B22 293411-B28 293412-B22 293412-B28 293413-B22 293413-B28

ESL9595: Common Options

ESL9595SL 400 to 500 slot upgrade ESL9595SL 500 to 595 slot upgrade ESL9595SL 400 to 595 slot upgrade

Add-on drives & Accessories

ESL9000 LVD SDLT 160/320 Drive upgrade (ESL9595S2 and ESL9322S2 only) ESL9000 LTO1 drive upgrade (ESL9322L1 and ESL9595L1 only) ESL9000 Universal Load Port (support both LTO & SDLT cartridges) Not removable ESL9000 Pass-thru kit (graphite)

Add-on drives & Accessories

ESL9000 Field Upgrade SDLT 110/220, LVD Drive (ESL9198SL, ESL9326SL, ESL9595SL only) ESL9000 Field Upgrade SDLT 110/220, HVD Drive (for existing ESL9326D/DX customers) LVD Extender Kit for ESL9198DLX, ESL9198SL, ESL9326SL

ESL 9000 Pass Through Kit for Multi Unit Connectivity 64-Bit/66Mhz Dual Channel Wide Ultra3 SCSI Adapter

NOTE: 64-Bit/66Mhz Dual Channel Wide Ultra3 SCSI Adapter is required to support

the LVD based libraries.

274674-B21 274674-B22 274674-B23

293414-B21 301930-B21 302254-B21 161268-B23

234617-B21 234617-B22 221249-B21

161268-B21 129803-B21

DA-11372 World Wide — Version 25 — March 20, 2003 18

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Tape Automation (continued)

StorageWorks MSL5000 departmental libraries

MSL5060L1 – LTO Ultrium 1 based departmental library up to 4 drives and 60 slots

MSL5060L1, 0 DRV LTO1 RM Library MSL5060L1, 2 DRV LTO1 RM Library MSL5060L1, 2 DRV LTO1 TT Library MSL5060L1FC, 2 DRV LTO1 RM-with integrated FC router

NOTE: Please see the StorageWorks MSL5060 LTO Library QuickSpecs for additional information including

Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete solution at:

http://www5.compaq.com/products/quickspecs/11438_na/11438_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11438_div/11438_div.HTML (Division/World Wide)

MSL5052S2 – SDLT160 based departmental library up to 4 drives and 52 slots

MSL5052S2, RM 0 DRV SDLT ALL MSL5052S2, 2 DRV SDLT2 TT LIB MSL5052S2, 2 DRV SDLT2 RM LIB MSL5052S2FC 2 DRV SDLT2 RM- with integrated FC router

NOTE: Please see the StorageWorks MSL5052S2 Library QuickSpecs for additional information including

Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete solution at:

http://www5.compaq.com/products/quickspecs/11442_na/11442_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11442_div/11442_div.HTML (Division/World Wide)

MSL5030L1 – LTO Ultrium 1 mid-range library up to 2 drives and 30 slots

MSL5030L1, 0 DRV LTO1 RM Library MSL5030L1, 1 DRV LTO1 RM Library MSL5030L1, 2 DRV LTO1 RM Library MSL5030L1, 1 DRV LTO1 TT Library MSL5030L1, 2 DRV LTO1 TT Library MSL5030L1FC, 1 DRV LTO1 RM- with integrated FC router MSL5030L1FC, 2 DRV LTO1 RM- with integrated FC router

NOTE: Please see the StorageWorks MSL5030 LTO Library QuickSpecs for additional information including

Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete solution at:

http://www5.compaq.com/products/quickspecs/11439_na/11439_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11439_div/11439_div.HTML (Division/World Wide)

301899-B21 301899-B22 301900-B21 301899-B23

255102-B21 293476-B21 293474-B21 293474-B24

301897-B21 301897-B22 301897-B23 301898-B21 301898-B22 301897-B24 301897-B25

MSL5026S2 – SDLT160 based mid-range library up to 2 drives and 26 slots

MSL5026S2, 0 DRV SDLT2 RM Library MSL5026S2, 1 DRV SDLT2 RM Library MSL5026S2, 2 DRV SDLT2 RM Library MSL5026S2, 1 DRV SDLT2 TT Library MSL5026S2, 2 DRV SDLT2 TT Library MSL5026S2FC, 1 DRV SDLT2 RM- with integrated FC router MSL5026S2FC, 2 DRV SDLT2 RM- with integrated FC router

NOTE: Please see the StorageWorks MSL5026SL Library QuickSpecs for additional information including

Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete solution at:

http://www5.compaq.com/products/quickspecs/11453_na/11453_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11453_div/11453_div.HTML (Division/World Wide)

MSL5026SL Graphite – SDLT110 based mid-range library up to 2 drives and 26 slots

MSL5026SL, 1 DRV SDLT TT, graphite MSL5026SL, 2 DRV SDLT TT, graphite MSL5026SL, 1 DRV SDLT RM, graphite MSL5026SL, 2 DRV SDLT RM, graphite

NOTE: Please see the StorageWorks MSL5026SL Graphite Library QuickSpecs for additional information

including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete

solution at:

http://www5.compaq.com/products/quickspecs/11440_na/11440_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11440_div/11440_div.HTML (Division/World Wide)

DA-11372 World Wide — Version 25 — March 20, 2003 19

293472-B21 293472-B22 293472-B23 293473-B21 293473-B22 293472-B24 293472-B25

302511-B21 302511-B22 302512-B21 302512-B22

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Tape Automation (continued)

StorageWorks MSL5000 departmental libraries (continued)

MSL5026SL Opal – SDLT110 based mid-range library up to 2 drives and 26 slots

MSL5026, 0 DR, LVD, RM

MSL5026DLX– 40/80GB DLT based mid-range library up to 2 drives and 26 slots

MSL5026DLX, 1 40/80GB DLT, LVD, TT 231821-B21 MSL5026DLX, 2 40/80GB DLT, LVD, TT 231821-B22 MSL5026DLX, 1 40/80GB DLT, LVD, RM 231891-B21 MSL5026DLX, 2 40/80GB DLT, LVD, RM 231891-B22

NOTE: Please see the StorageWorks MSL5026DLX Library QuickSpecs for additional information including

Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete solution at:

http://www5.compaq.com/products/quickspecs/10860_na/10860_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/10860_div/10860_div.HTML (Division/World Wide)

MSL5000 Add-on drives & accessories

MSL5000 SDLT 160/320 Upgrade DRV (MSL5052S2 & MSL5026S2 only) MSL5000 LTO Ultrium 1 Upgrade DRV (MSL5060L1 & MSL5030L1 only) MSL5000 SDLT 110/220 Upgrade DRV 231823-B22

MSL5000 40/80GB DLT Upgrade DRV 231823-B21 MSL5000 Dual Magazine LTO (2 X 15 slot magazines) 301902-B21 MSL5000 Dual Magazine DLT (2 X 13 slot magazines)

MSL5000 pass through mechanism 10 U (required for multi-unit scalability) MSL5000, Pass through mechanism 10U (includes elevator mechanism and router,

required to connect first two units in a stack) MSL5026, 5U Pass through extender (required one for each unit connected to the

stack, for third and additional units) – for MSL5026 & MSL5030 MSL5052, 10U Pass-Through Extender (required one for each unit connected to the

stack, for third and additional units) – for MSL5052 & MSL5060

231979-B21

293475-B21 301901-B21

232136-B21 231824-B21

231824-B21 231824-B22

231824-B23

StorageWorks SSL2000 small system library

SSL2020 – AIT50 based library with up to 2 drives and 20 slots

SSL2020 AIT Mini-Library 1 drive, 20 slot Table Top SSL2020 AIT Mini-Library 2 drive, 20 slot Table Top SSL2020 AIT Mini-Library 1 drive, 20 slot Rackmount SSL2020 AIT Mini-Library 2 drive, 20 slot Rackmount SSL2020 AIT Library Pass Thru with Transport

Add-on drives and accessories

SSL2020 AIT Library Pass Thru Extender AIT 50GB Drive Add-On LVD Drive for SSL2020 AIT Library 19 Slot Magazine for SSL2020 AIT Library AIT 50-GB Data Cassette (5 pack) AIT Cleaning Cassette

NOTE: Please see the SSL2020 Automated AIT Tape Library Solution QuickSpecs for additional information

including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a complete

solution at:

http://www5.compaq.com/products/quickspecs/10580_na/10580_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/10580_div/10580_div.HTML (Division/World Wide)

175195-B21 175195-B22 175196-B21 175196-B22 175312-B21

175312-B22 175197-B21 175198-B21

152841-001

402374-B21

DA-11372 World Wide — Version 25 — March 20, 2003 20

QuickSpecs

hp ProLiant DL580 Generation 2 (G2)

Options

Cluster Options ProLiant Cluster HA/F100 for MSA1000 v2 252408-B22

ProLiant Cluster HA/F100 for MSA1000 v2 (Japan) 252408-292 ProLiant Cluster HA/F200 for MSA1000 v2 252409-B22 ProLiant Cluster HA/F200 for MSA1000 v2 (Japan) 252409-292

NOTE: For additional information regarding the ProLiant Cluster for HA/F100, HA/F200 for MSA1000 please see

the following QuickSpecs at:

http://www5.compaq.com/products/quickspecs/11035_na/11035_na.html (North America)

http://www5.compaq.com/products/quickspecs/11035_div/11035_div.html (Division/World Wide)

ProLiant Cluster HA/F100 for Windows NT and 2000 Advanced Server 309816-B21 ProLiant Cluster HA/F200 Upgrade Kit (NT 4.0EE to W2K AS) 176848-B22 ProLiant Cluster HA/F200 for Windows NT and 2000 Advanced Server 380357-B23 ProLiant Cluster HA/F200 for Windows NT and 2000 Advanced Server (Japan) 380357-293

NOTE: For additional information regarding the ProLiant Cluster for HA/F100, HA/F200 for Windows NT and 2000

Advanced Server please see the following QuickSpecs at:

http://www5.compaq.com/products/quickspecs/10777_na/10777_na.html (North America)

http://www5.compaq.com/products/quickspecs/10777_div/10777_div.html (Division/World Wide)

ProLiant Cluster HA/F500 Basic Kit 103250-B24 ProLiant Cluster HA/F500 Enhanced Kit 379937-B24 ProLiant Cluster HA/F500 Enhanced DT Kit 164227-B22

NOTE: For additional information regarding the ProLiant Cluster for HA/F500 please see the following QuickSpecs

at:

http://www5.compaq.com/products/quickspecs/10232_na/10232_na.html (North America)

http://www5.compaq.com/products/quickspecs/10232_div/10232_div.html (Division/World Wide)

ProLiant Cluster HA/F500 for Enterprise Virtual Array 254623-B21

NOTE: For additional information regarding the ProLiant Cluster HA/F500 for Enterprise Virtual Array please see

the following QuickSpecs at:

http://www5.compaq.com/products/quickspecs/11055_na/11055_na.html (North America)

http://www5.HP.com/products/quickspecs/11055_div/11055_div.html (Division/World Wide)

ProLiant Cluster HA/L100 LifeKeeper for Linux 303523-B21

NOTE: For additional information regarding the ProLiant Cluster HA/L100 LifeKeeper for Linux, please see the

following QuickSpecs at:

http://www5.compaq.com/products/quickspecs/11533_na/11533_na.html (North America)

http://www5.compaq.com/products/quickspecs/11533_div/11533_div.html (Division/World Wide)

HP Serviceguard for Linux ProLiant Cluster

NOTE: Kit includes 2 licenses, documentation and an Ethernet crossover cable.

HP Serviceguard for Linux License

NOTE: Kit includes single license version and documentation. NOTE: For additional information regarding the HP Serviceguard for Linux License, please see the following

QuickSpecs at:

http://www5.compaq.com/products/quickspecs/11518_na/11518_na.html (North America)

http://www5.compaq.com/products/quickspecs/11518_div/11518_div.html (Division/World Wide)

305199-B21

307554-B21

External Storage - Rack StorageWorks Enclosure Model 4314R (rack-mountable)

StorageWorks Enclosure Model 4314R (rack-mount abl e) (Int’l ) StorageWorks Enclosure Model 4314R (rack-mounta bl e) (Japan) StorageWorks Enclosure Model 4354R (rack-mountable) StorageWorks Enclosure Model 4354R (rack-mount abl e) (Int’l ) StorageWorks Enclosure Model 4354R (rack-mount abl e) (Japan )

NOTE: The StorageWorks Enclosure 4300 Family supports the Wide Ultra3, Ultra320 1″ Hot Plug Hard Drives.

StorageWorks Enclosure 4200 Redundant Power Supply Option StorageWorks Enclosure 4200 Ultra3 Single Bus I/O Module Option StorageWorks Enclosure 4200 Ultra3 Dual Bus I/O Module Option StorageWorks Enclosure Tower to Rack Conversion Kit

DA-11372 World Wide — Version 25 — March 20, 2003 21

190209-001

190209-B31

190209-291 190211-001

190211-B31

190211-291

119826-B21 190212-B21 190213-B21 150213-B21

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

MSA1000 MSA 1000

MSA 1000 Controller MSA Fibre Channel I/O Module MSA1000 Fabric Switch MSA 1000 Fibre Channel Adapter (FCA) 2101 HP StorageWorks msa hub 2/3 286763-B21

NOTE: Please see the HP StorageWorks modular SAN array 1000 QuickSpecs for additional

options and configuration information at:

http://www5.compaq.com/products/quickspecs/11033_na/11033_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11033_div/11033_div.HTML (Division/World Wide)

StorageWorks Modular Array 8000/Enterprise Modular Array 12000

EMA12000 D14 60 Hz EMA12000 D14 50 Hz EMA12000 S14 60 Hz EMA12000 S14 50 Hz MA8000 60 Hz MA8000 50 Hz EMA12000 Blue 60 Hz EMA12000 Blue 50 Hz

NOTE: Options include controller, solution kits, ACS. MA8000/EMA12000 includes controller shelf, drive shelves

and cabinet. Packaging upgrade to RA8000/ESA12000. NOTE: Please see the StorageWorks MA8000/EMA12000 QuickSpecs for FC Hubs, FC switches, platform

software, host adapters, disks and options for complete solutions at:

http://www5.compaq.com/products/quickspecs/10545_na/10545_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/10545_div/10545_div.HTML (Division/World Wide)

201723-B22 218231-B22 218960-B21 218232-B21 245299-B21

175990-B21 175990-B22 175991-B21 175991-B22 175992-B21 175992-B22 175993-B21 175993-B22

StorageWorks Enterprise Modular Array 16000 FC

StorageWorks Options StorageWorks SAN Switch 2/8-EL

EMA16000 D14 50Hz (opal) EMA16000 D14 60Hz (opal) EMA16000 S14 50Hz (opal) EMA16000 S14 60Hz (opal)

NOTE: Models include: Dual HSG80 controllers in each Model 2200 enclosure (2 pairs per single bus

configuration, 4 pairs per dual bus configuration) with 1GB cache per controller pair, and 12 14-bay drive

enclosures with redundant power supplies. Confi

ACS, platform kits and software by HP. NOTE: Please see the StorageWorks EMA16000 QuickSpecs for FC switches, platform software, host adapters,

disks and options for complete solutions at:

http://www5.compaq.com/products/quickspecs/10812_na/10812_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/10812_div/10812_div.HTML (Division/World Wide)

StorageWorks SAN Switch 2/16-EL StorageWorks SAN Switch 2/8-EL Upgrade Kit StorageWorks SAN Switch 2/16-EL Upgrade Kit StorageWorks SAN Director 64

NOTE: Please see the StorageWorks SAN Director 64 QuickSpecs for additional information:

http://www5.compaq.com/products/quickspecs/11003_na/11003_na.HTML (North America)

http://www5.compaq.com/products/quickspecs/11003_div/11003_div.HTML (Division/World Wide)

238792-B22 238792-B21 238791-B22

238791-B21

ure-to-Order (CTO) builds are available. Options include

258707-B21 283056-B21 288162-B21 288250-B21 254512-B21

DA-11372 World Wide — Version 25 — March 20, 2003 22

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

UPS and PDU Power Cord Matrix

Uninterruptible Power Systems – Rack

Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications for UPS and PDU units.that lists c able descriptions, requirements, and specifications for UPS units.

ftp://ftp.compaq.com/pub/products/servers/ProLiantstorage/power-protection/powercordmatrix.pdf.

Compaq UPS R1500 XR (1440VA, 1340 Watt), Low Voltage (NA) Compaq UPS R1500 XR (1500VA, 1340 Watt), High Voltage (Int’l) Compaq UPS R1500 XR (1500VA, 1340 Watt), Low Voltage (Japan) Compaq UPS R3000 XR (2880VA, 2700 Watt), Low Voltage (NA) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (NA) Compaq UPS R3000 XR (2400VA, 2250 Watt), Low Voltage (Japan) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (Japan) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (Int’l - detachable cord) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (16A IEC309 Plug) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (16A CEE 7/7 SCHUKO

Plug) Compaq UPS R3000 XR (3000VA, 2700 Watt), High Voltage (16A BS-546 Plug)

Rack-Mountable UPS R6000 (6000VA, 6000 Watt) High Voltage (NA) Rack-Mountable UPS R6000 (6000VA, 6000 Watt) High Voltage (Int'l) Rack-Mountable UPS R6000 (6000VA, 6000 Watt) High Voltage (Japan) Compaq UPS R12000 XR, N+x (12KVA, 12KW) High Voltage (WW)

NOTE: UPS R6000 has a hardwired input; and the UPS R12000 XR has a hardwired

input and output connection.

204404-001

204404-B31

204404-291 192186-001 192186-002 192186-291

192186-292 192186-B31 192186-B32 192186-B33

192186-AR1

347207-001 347207-B31

347207-291 207552-B22

UPS Options SNMP Serial Port Card

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

Six Port Card

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

High to Low Voltage Transformer (250VA)

NOTE: Supports R6000 UPS series onl

NEMA 5-15.

Extended Runtime Module, R1500 XR

NOTE: 2U each, two ERM maximum.

Extended Runtime Module, R3000 XR

NOTE: 2U each, one ERM maximum.

Extended Runtime Module, R6000

NOTE: 3U each, two ERM maximum.

Extended Runtime Module, R12000 XR, 4U

NOTE: 4U each, two ERM maximum.

SNMP-EN Adapter

NOTE: Supports R6000 UPS series only.

Multi-Server UPS Card

NOTE: Supports R6000 UPS series only.

Scalable UPS Card

NOTE: Supports R6000 UPS series only.

Cable, 16A, IEC320-C20 to IEC320-C19

NOTE: Power cord (295633-B21) connects ProLiant servers to PDUs or UPSs with

IEC320-C19 output connections.

192189-B21

192185-B21

388643-B21

. 2.5 amps @ 125 Volts max output across two

218971-B21

192188-B21

347224-B21

217800-B21

347225-B21

123508-B21

123509-B21 295633-B21

DA-11372 World Wide — Version 25 — March 20, 2003 23

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

UPS Options (continued)

Rack-Mountable PDUs – 1U/0U

(Up to 12 outlets)

NOTE: 0U mounting brackets shipped with

the unit (separate option kit for 1U mounting).

Cable, 10A, IEC320-C14 to IEC320-C19

NOTE: Power cord (291034-B21) connects ProLiant DL580 G2 servers to PDUs or

UPSs with IEC320-C13 output connections. This power cord has been specifically designed to work with the ProLiant DL580 G2 server. Please NOTE the following important precautions when deploying this power cord:

• Use the cord only in conjunction with the ProLiant DL580 G2 server.

• Use the cord to connect the ProLiant DL580 G2 server only to PDUs or

UPSs with IEC320-C13 output connections.

• Do not use the cord with any other ProLiant or third party server.

• Do not use the cord with any other office equipment or computers.

• Do not use the cord as an extension cord.

• Do not plug the cord into a wall outlet.

Failure to adhere to these precautions may invalidate the server warranty.

Compaq Power Distribution Unit-16A (200 to 240V) (WW)

NOTE: The 16A PDU also connects to the high volt models of the UPS R3000 XR

(need cable P/N 340653-001 for North America) and the UPS R6000 models. Cable P/N 340653-001 required if connecting to UPS R3000 XR (192186-002 NA-High Volt model only).

Compaq Power Distribution Unit-24A (200 to 240V) (NA, Japan, LA)

NOTE: This PDU may also be used to connect to the low volt UPS R3000 XR model.

Compaq Power Distribution Unit-32A (200 to 240V) (Int’l) Compaq Power Distribution Unit-40A (200 to 240V) (WW)

NOTE: Hardwire input required.

Compaq Power Distribution Unit-24A (100 to 127V) (NA, Japan, LA)

NOTE: L5-30 input.

1U PDU Mounting Brackets Kit

NOTE: Please see the following Power Distribution Unit (Zero-U/1U PDU) QuickSpecs for additional options

including cables:

http://www5.compaq.com/products/quickspecs/10838_na/10838_na.HTML (North America) http://www5.compaq.com/products/quickspecs/10838_div/10838_div.HTML (Division/World Wide)

291034-B21

207590-B21

207590-D72 207590-B31

207590-B23 207590-D71 215852-B21

Modular PDUs 1U/0U

(Up to 32 outlets)

NOTE: 1U/0U mounting brackets shipped

with the unit (optimized for 10000 and 9000 series racks)

Rack Builder Rack Builder for configuration assistance at

Modular Power Distribution Units (mPDU), High Volt Model, 16A (200-240 VAC) (WW)

NOTE: This model has a detachable input power cord and is adaptable to country

specific requirements. The 16A PDU also connects to the high volt models of the UPS R3000 XR and R6000 models. Cable P/N 340653-001 required if connecting to UPS R3000 XR (192186-002 NA -High Volt model only).

Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC) (NA, Japan)

NOTE: This model has a detachable input power cord and is adaptable to country

Modular Power Distribution Units (mPDU), High Volt Model, 24A (200-240 VAC) (NA, Japan)

NOTE: L6-30 input.

Modular Power Distribution Units (mPDU), High Volt Model, 32A (200-240 VAC) (Int'l) Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC) (WW)

NOTE: The 40A model has a hardwired input. NOTE: Please see the following Modular Power Distribution Unit (Zero-U/1U Modular PDUs) QuickSpecs for

additional options including cables:

http://www5.compaq.com/products/quickspecs/11041_na/11041_na.HTML (North America) http://www5.compaq.com/products/quickspecs/11041_div/11041_div.HTML (Division/World Wide)

http://www.compaq.com/rackbuilder/.

252663-B24

252663-D71

252663-D72

252663-B31 252663-B21

DA-11372 World Wide — Version 25 — March 20, 2003 24

QuickSpecs

)

Options

hp ProLiant DL580 Generation 2 (G2)

Third Party Rack Kit DL580 G2 rack model support:

The DL580 G2 Third Party rack kit 287528-B21 provides support for any rack, square hole or round hole, (including HP Rack System /E and HP Systems), with an adjustment range from 23 1/2″– 34″ deep.

NOTE: The Third party rack kit is required for round hole racks or for square hole racks

that do not conform to the adjustment range of the standard rail that ships with the server.

Telco Rack Support

HP Rack 10000 Series

(Graphite Metallic)

DL580 G2 rack model support: Support for all 2-post Telco racks requires the Third Party option kit 287528-B21, plus

an additional option kit from Rack Solutions. The Rack Solutions brackets can be purchased at:

http://www.racksolutions.com/hp

HP Rack 10842 (42U, 800mm wide) – Pallet HP Rack 10842 (42U, 800mm wide) – Shock Pallet HP Rack 10647 (47U) – Pallet HP Rack 10647 (47U) – Shock Pallet HP Rack 10642 (42U) – Pallet HP Rack 10642 (42U) – Shock Pallet HP Rack 10642 (42U) – Crated HP Rack 10636 (36U) – Pallet HP Rack 10636 (36U) - Shock Pallet HP Rack 10636 (36U) – Crated HP Rack 10622 (22U) – Pallet HP Rack 10622 (22U) – Shock Pallet HP Rack 10622 (22U) – Crated

NOTE: -B21 (pallet) used to ship empty racks shipped on a truck

-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels

-B23 (crated) used for air shipments of empty racks

NOTE: Please see the Rack 10000 QuickSpecs for Technical Specifications such as height, width, depth, weight,

and color:

http://www5.compaq.com/products/quickspecs/10995_div/10995_div.HTML (Division/World Wide) http://www5.compaq.com/products/quickspecs/10995_na/10995_na.HTML (North America)

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

http://www.compaq.com/racks

287528-B21

257415-B21 257415-B22 245160-B21 245160-B23 245161-B21 245161-B22 245161-B23 245162-B21 245162-B22 245162-B23 245163-B21 245163-B22 245163-B23

DA-11372 World Wide — Version 25 — March 20, 2003 25

QuickSpecs

)

Options

hp ProLiant DL580 Generation 2 (G2)

Compaq Rack 9000 Series (opal)

Series

Compaq Rack 9142 (42U) – Pallet Compaq Rack 9142 (42U) – Shock Pallet Compaq Rack 9142 (42U) – Crated Compaq Rack 9136 (36U) – Pallet Compaq Rack 9136 (36U) – Shock Pallet Compaq Rack 9136 (36U) – Crated Compaq Rack 9122 (22U) – Pallet Compaq Rack 9122 (22U) – Shock Pallet Compaq Rack 9122 (22U) – Crated Compaq Rack 9842 (800mm wide, 42U) – Pallet

NOTE: -B21 (pallet) used to ship empty racks shipped on a truck

-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels

-B23 (crated) used for air shipments of empty racks

NOTE: Please see the Rack 9000 QuickSpecs for Technical Specifications such as height, width, depth, weight,

and color:

http://www5.compaq.com/products/quickspecs/10366_div/10366_div.HTML (Division/World Wide) http://www5.compaq.com/products/quickspecs/10366_na/10366_na.HTML (North America)

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

http://www.compaq.com/racks

Rack Blanking Panels – Graphite (Multi)

NOTE: Contains one each of 1U, 2U, 3U, and 4U panel.

Rack Blanking Panels – Graphite (1U)

NOTE: The Rack Blanking Panels (PN 253214-B21) contains 10 each of (1U).

Rack Blanking Panels – Graphite (2U)

NOTE: The Rack Blanking Panels (PN 253214-B21) contains 10 each of (2U).

Rack Blanking Panels – Graphite (3U)

NOTE: The Rack Blanking Panels (PN 253214-B21) contains 10 each of (3U).

Rack Blanking Panels – Graphite (4U)

NOTE: The Rack Blanking Panels (PN 253214-B21) contains 10 each of (4U).

Rack Blanking Panels – Graphite (5U)

NOTE: The Rack Blanking Panels (PN 253214-B21) contains 10 each of (5U).

800mm Wide Stabilizer Kit (Graphite)

NOTE: Supported by the Rack 10842 cabinet only.

600mm Stabilizer Kit – Graphite 246107-B21 Baying Kit for Rack 10000 series (Carbon) 248929-B21 42U Side Panel – Graphite Metallic 246099-B21 110V Fan Kit (Graphite)

NOTE: Roof Mount Includes power cord with IEC320-C13 to Nema 5-15P.

220V Fan Kit (Graphite)

NOTE: Roof Mount Includes power cord with IEC320-C13 to Nema 6-15P.

36U Side Panel - Graphite Metallic (for 10636 Rack only) 246102-B21 47U Side Panel - Graphite Metallic (for 10647 Rack only) 255486-B21 9000/10000 Series 42U Offset Baying Kit

NOTE: This kit can be used to connect 9000 and 10000 series racks of the same U

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

ht together. Kit contents include hardware for connecting racks and a panel

hei to cover the 100mm gap at the rear of the two racks.

http://www.compaq.com/rackoptions

120663-B21 120663-B22 120663-B23 120664-B21 120664-B22 120664-B23 120665-B21 120665-B22 120665-B23 222192-B21

253214-B26Rack Options for HP Rack 10000

253214-B21

253214-B22

253214-B23

253214-B24

253214-B25

255488-B21

257413-B21

257414-B21

248931-B21

DA-11372 World Wide — Version 25 — March 20, 2003 26

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Rack Options for Compaq Rack 9000 Series

Baying/Coupling Kit 42U Side Panel

NOTE: The 42U Side Panel (PN 120670-B21) supports the Compaq Rack 9142 and

Compaq Rack 9842.

36U Side Panel

NOTE: The 36U Side Panel (PN 120671-B21) supports the Compaq Rack 9136.

9142 Extension Kit

NOTE: The 9142 Extension Kit (PN 120679-B21) supports the Compaq Rack 9142

only.

9142 Split Rear Door

NOTE: The 9142 Split Rear Door (PN 254045-B21) supports the 600 mm wide, 42U

9000 series rack.

9136 Extension Kit 9142 Short Rear Door

NOTE: The 9142 Short Rear Door (PN 218217-B21) supports the Compaq Rack 9142

only.

9136 Short Rear Door 9122 Short Rear Door (Opal) 218219-B21 800mm Stabilizer Option Kit (Opal)

NOTE: The 800mm Stabilizer Kit (PN 234493-B21) supports the Rack 9842 only.

600mm Stabilizer Option Kit Rack Blanking Panel (Multi)

NOTE: Kit includes four panels in 1U, 2U, 4U, and 8U.

Rack Blanking Panels (1U)

NOTE: The Rack Blanking Panels (PN 189453-B21) contains 10 each of (1U).

Rack Blanking Panels (2U)

NOTE: The Rack Blanking Panels (PN 189453-B22) contains 10 each of (2U).

Rack Blanking Panels (3U)

NOTE: The Rack Blanking Panels (PN 189453-B23) contains 10 each of (3U).

Rack Blanking Panels (4U)

NOTE: The Rack Blanking Panels (PN 189453-B24) contains 10 each of (4U).

Rack Blanking Panels (5U)

NOTE: The Rack Blanking Panels (PN 189453-B25) contains 10 each of (5U).

9000/10000 Series 42U Offset Baying Kit

NOTE: This kit can be used to connect 9000 and 10000 series racks of the same U

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

ht together. Kit contents include hardware for connecting racks and a panel

hei

to cover the 100mm gap at the rear of the two racks.

http://www.compaq.com/rackoptions

120669-B21 120670-B21

120671-B21

120679-B21

254045-B21

218216-B21 218217-B21

218218-B21

234493-B21

120673-B21 169940-B21

189453-B21

189453-B22

189453-B23

189453-B24

189453-B25

248931-B21

Rack Options for Compaq Rack 7000 Series

DA-11372 World Wide — Version 25 — March 20, 2003 27

High Air Flow Rack Door Insert for 7122 High Air Flow Rack Door Insert for 7142 High Air Flow Rack Door Insert for 7142 (six pack) Compaq Networking Cable Management Kit Compaq Rack Extension Kit for 7142

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

http://www.compaq.com/rackoptions

157847-B21 327281-B21 327281-B22 292407-B21 154392-B21

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Rack Options for Rack 7000, 9000 and 100000 Series

Ballast Option Kit Rack Rail Adapter Kit (25-inch depth) Cable Management D-Rings Kit Monitor/Utility Shelf - Graphite Depth Adjustable Fixed Rail Input Device Adjustable Rails

NOTE: Input Device Adjustable Rails (287139-B21) are for use ONLY with the

TFT5110R, TFT5600RKM and integrated keyboard/drawer which is used in

mounting into third party racks.

Input Device Telco Rails

NOTE: Input Device Telco Rails (287138-B21) are for use ONLY with the TFT5110R,

TFT5600RKM and integrated keyboard/drawer which is used in mounting into

third party racks.

Console Management Controller (CMC) Option Kit Console Management Controller (CMC) Sensors Option Kit Console Management Controller (CMC) Locking Option Kit Console Management Controller (CMC) Smoke Sensors Option Kit Server Console Switch 1 x 2 port (100 to 230 VAC) Server Console Switch 1 x 2 port (100 to 230 VAC) (Int’l) Server Console Switch 1 x 2 port (100 to 230 VAC) (Japan)

Server Console Switch 1 x 4 port (100 to 230 VAC) Server Console Switch 1 x 4 port (100 to 230 VAC) (Int’l) Server Console Switch 1 x 4 port (100 to 230 VAC) (Japan) Server Console Switch 1 x 8 port (100 to 230 VAC) Server Console Switch 1 x 8 port (100 to 230 VAC) (Int’l) Server Console Switch 1 x 8 port (100 to 230 VAC) (Japan) Server Console Switch 1 x 2 port (100 to 230 VAC) Server Console Switch 1 x 2 port (100 to 230 VAC) (Int’l) Server Console Switch 1 x 2 port (100 to 230 VAC) (Japan) Server Console Switch 2 x 8 port (48 VDC) KVM 9 PIN Adapter (4 Pack) CPU to Server Console Cable, 12′ CPU to Server Console Cable, 20′ CPU to Server Console Cable, 40′ CPU to Server Console Cable, 3′ CPU to Server Console Cable, 7′ CPU to Server Console Cable (Plenum Rated) 20′ CPU to Server Console Cable (Plenum Rated) 40′ Switch Box Connector Kit (115 V) Switch Box Connector Kit (230 V) Switch Box Connector Kit (high voltage) (Int’l) TFT5600 RKM (Rack-mount Keyboard Monitor) Country Code Key (for TFT5600 RKM Rack Keyboard Monitor (PN 221546-xx1)) XX = 001 US XX = 091 Norway

XX = 031 UK XX = 101 Sweden/Finland XX = 041 Germany XX = 111 Switzerland XX = 051 France XX = 131 Portugal XX = 061 Italy XX = 181 Belgium XX = 071 Spain XX = 291 Japan XX = 081 Denmark XX = B31 International

120672-B21 120675-B21 168233-B21 253449-B21 332558-B21

287139-B21

287138-B21

203039-B21 203039-B22 203039-B23 203039-B24

120206-001

120206-B31

120206-291 400336-001

400336-B31

400336-291 400337-001

400337-B31

400337-291 400338-001

400338-B31

400338-291 400542-B21 149361-B21 110936-B21 110936-B22 110936-B23 110936-B24 110936-B25 149363-B21 149364-B21

144007-001

144007-002 144007-B33

221546-xx1

DA-11372 World Wide — Version 25 — March 20, 2003 28

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Rack Options for Rack 7000, 9000 and 10000 Series (continued)

Service and Support Offerings

(CarePaq Services)

Keyboard with Hot Keys and Trackball Country Code Key (for 1U Rack Keyboard & Drawer (PN 257054-xxx)) XX = 001 US XX = 091 Norway XX = 031 UK XX = 101 Sweden/Finland XX = 041 Germany XX = 111 Switzerland XX = 051 France XX = 131 Portugal XX = 061 Italy XX = 181 Belgium XX = 071 Spain XX = 291 Japan XX = 081 Denmark XX = B31 International

NOTE: For additional information regarding Rack Cabinets, please see the following URL:

http://www.compaq.com/rackoptions

Hardware Services 4-Hour On-site Service

4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for U.S.) 4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for

Canada) 4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for

EMEA) 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (6-3 Part Number for U.S.) 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (6-3 Part Number for

Canada) 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years (6-3 Part Number for

EMEA) 4-Hour On-site Service, 5-Day x 9-Hour Coverage, 3 Years (6-3 Part Number for U.S.)

Installation & Start-up Services

Hardware Installation (2-5-2 Part Number for Canada) Hardware Installation (6-3 Part Number for US) Hardware Installation (6-3 Part Number for EMEA) Pre-installation planning; unpack equipment, install most current Compaq HW options

internal to server at same time of server installation; assemble & test; basic user information provided; Install & configure basic functionality of Win NT Operating System plus up to I day start-up activity, configure print & network access services, and orientation (2-5-2 Part Number for Canada.) Pre-installation planning; unpack equipment, install most current Compaq HW options internal to server at same time of server installation; assemble & test; basic user information provided; Install & configure basic functionality of Win NT Operating System plus up to I day start-up activity, configure print & network access services, and orientation (6-3 Part Number for U.S.) Pre-installation planning; unpack equipment, install most current Compaq HW options internal to server at same time of server installation; assemble & test; basic user information provided; Install & configure basic functionality of Novell NetWare Operating System plus up to I day start-up activity, configure print & network access services, and orientation (2-5-2 Part Number for Canada) Pre-installation planning; unpack equipment, install most current Compaq HW options internal to server at same time of server installation; assemble & test; basic user information provided; Install & configure basic functionality of Novell NetWare Operating System plus up to I day start-up activity, configure print & network access services, and orientation (6-3 Part Number for U.S.) Server Installation and Set-Up (Installation of the server, installation of the appropriate service tools, check to ensure device SW and firmware is loaded and installation of the operating system software (6-3 Part Number for EMEA.)

158649-xx1

401783-002

401783-122

324418-002

401782-002

401782-122

376911-022

401783-002

FP-MIINS-IN

401793-002

Quote

FM-MSTEC-03

240015-002

FM-NSTEC-03

240010-002

204564-022

DA-11372 World Wide — Version 25 — March 20, 2003 29

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Service and Support Offerings

(CarePaq Services) (continued)

CarePaq Priority Services for ProLiant Servers – Priority Level

9x5 4-hour H/W, 9x5 2-hour O/S (NT & NetWare), 3 Years (6-3 Part Number for EMEA) 9 x 5 HW, 4-hr response, Next Available HW engineer; 9 x 5 Bronze Software Support

2-hr response for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Next Available Specialist (2-5-2 Part Number for Canada)

9 x 5 HW, 4-hr response, Next Available HW engineer; 9 x 5 Bronze Software Support 2-hr response for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Next Available Specialist (6-3 Part Number for U.S.)

9 x 5 HW, 4-hr response, Next Available HW engineer; 9 x 5 Bronze Software Support 2-hr response for Novell NetWare Operating System, Next Available Specialist (2-5-2 Part Number for Canada)

9 x 5 HW, 4-hr response, Next Available HW engineer; 9 x 5 Bronze Software Support 2-hr response for Novell NetWare Operating System, Next Available Specialist (6-3 Part Number for U.S.)

CarePaq Priority Services for ProLiant Servers – Priority 24 Level

24x7 4-hour H/W, 24x7 2-hour O/S (NT & NetWare), 3 years (6-3 Part Number for EMEA)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Bronze Software Support, 2-hr response for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Next Available Specialist (6-3 Part Number for U.S.)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Bronze Software Support, 2-hr response for Novell NetWare Operating System, Next Available Specialist (6-3 Part Number for U.S.)

CarePaq Priority Services for ProLiant Servers - Priority Silver

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Software Support, 1-hr response, Monday – Friday, 8AM – 5PM local time, 2-hr response after hours for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Technical Account Manager, Technical Newsletter, SW activity review (2-5-2 Part Number for Canada)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Software Support, 1-hr response, Monday – Friday, 8AM – 5PM local time, 2-hr response after hours for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System Operating System, Technical Account Manager, Technical Newsletter, SW activity review (6-3 Part Number for U.S.)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (6-3 Part Number for U.S.)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (2-5-2 Part Number for Canada)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Software Support, 1-hr response, Monday – Friday, 8AM – 5PM local time, 2-hr response after hours for Novell NetWare Operating System, Technical Account Manager, Technical Newsletter, SW activity review (2-5-2 Part Number for Canada)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Subsequent System Support for Novell NetWare Operating System (2-5-2 Part Number for Canada.)

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Silver Subsequent System Support for Novell NetWare Operating System (6-3 Part Number for U.S.)

179836-022

FM-M01E3-36

239936-002

FM-N01E3-36

239976-002

179841-002

239938-002

239978-002

FM-M04E3-36

239940-002

239942-002

FM-M24E3-36

FM-N04E3-36

239980-002

FM-N24E3-36

239982-002

DA-11372 World Wide — Version 25 — March 20, 2003 30

QuickSpecs

Options

hp ProLiant DL580 Generation 2 (G2)

Service and Support Offerings

(CarePaq Services) (continued)

CarePaq Priority Services for ProLiant Servers – Priority Gold

24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Technical Account Manager, Technical Newsletter, SW activity review, proactive revision management, Upgrade impact planning, 2 System Healthcheck per year (2-5-2 Part Number for Canada) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Technical Account Manager, Technical Newsletter, SW activity review, proactive revision management, Upgrade impact planning, 2 System Healthcheck per year (6-3 Part Number for U.S.) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (2-5-2 Part Number for Canada) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (6-3 Part Number for U.S.) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Novell NetWare Operating System, Technical Account Manager, Technical Newsletter, SW activity review, Upgrade impact planning (2-5-2 Part Number for Canada) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Novell NetWare Operating System, Technical Account Manager, Technical Newsletter, SW activity review, Upgrade impact planning (6-3 Part Number for U.S.) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Novell NetWare Operating System (2-5-2 Part Number for Canada) 24 x 7 HW, 4-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Novell NetWare Operating System (6-3 Part Number for U.S.)

CarePaq Priority Services for ProLiant Servers – Priority Gold Executive

24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Technical Account Manager, Technical Newsletter, SW activity review, proactive revision management, Upgrade impact planning, 2 System Healthcheck per year (2-5-2 Part Number for Canada) 24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System, Technical Account Manager, Technical Newsletter, SW activity review, proactive revision management, Upgrade impact planning, 2 System Healthcheck per year (6-3 Part Number for U.S.)

24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (2-5-2 Part Number for Canada) 24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Windows NT, Windows 2000, Professional, Server or Advanced Server Operating System (6-3 Part Number for U.S.)

24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Novell NetWare Operating System, Technical Account Manager, Technical Newsletter, SW activity review, Upgrade impact planning (2-5-2 Part Number for Canada.) 24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Software Support, 30 minute response (critical), 1-hr response (non-critical), for Novell NetWare Operating System, Technical Account Manager, Technical Newsletter, SW activity review, Upgrade impact planning (6-3 Part Number for U.S.)

24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Novell NetWare Operating System (2-5-2 Part Number for Canada)

24 x 7 HW, 2-hr response, Named HW engineer; 24 x 7 Gold Subsequent System Support for Novell NetWare Operating System (6-3 Part Number for U.S.)

NOTE: For more information, customer/resellers can contact http://www.compaq.com/services.

FM-M08E3-36

239944-002

FM-M28E3-36

239946-002

FM-N08E3-36

239984-002

FM-N28E3-36

239986-002

FM-M09E3-36

239948-002

FM-M29E3-36

239950-002

FM-N09E3-36

239988-002

FM-N29E3-36

239990-002

DA-11372 World Wide — Version 25 — March 20, 2003 31

QuickSpecs

hp ProLiant DL580 Generation 2 (G2)

Memory

HP ProLiant DL580 G2 1.60 GHz 2P Models and 1.40 GHz 2P Models

TANDARD MEMORY

2048 MB 200MHz Double Data Rate (DDR) SDRAM (PC1600 Registered SDRAM Memory with Advanced ECC functionality)

TANDARD MEMORY PLUS OPTIONAL MEMORY AND OPTIONAL MEMORY BOARD

Up to 26,624-MB memory is available with the optional installation of PC1600 Registered ECC SDRAM Memory kits and a second, optional memory board.

TANDARD MEMORY REPLACED WITH OPTIONAL MEMORY AND OPTIONAL MEMORY BOARD

Up to 32,768-MB of memory is available with the removal of the standard 2048-MB of memory, the optional installation of PC1600 Registered ECC SDRAM Memory kits, and a second, optional memory board.

NOTE: Memory must be added in banks of four DIMMS. This chart does not represent all possible memory configurations.

Memory Standard Memory Board (Slots) Optional 2

Standard 2048MB Optional 26,624 MB

Maximum 32,768 MB

The following memory options are available from HP:

 1024-MB PC1600 Registered ECC SDRAM Memory Kit (4 x 256 MB) 202170-B21  2048-MB PC1600 Registered ECC SDRAM Memory Kit (4 x 512 MB) 202171-B21  4096-MB PC1600 Registered ECC SDRAM Memory Kit (4 x 1024 MB) 202172-B21  8192-MB PC1600 Registered ECC SDRAM Memory Kit (4 x 2048 MB) 202173-B21

Expand your memory capacity with the DL580 G2 Hot Plug Memory Expansion Board. Provides 8 additional DIMM slots for powering memoryintensive applications.

 Hot Plug Memory Expansion Board 203320-B21

1234567812345678

512 MB 512 MB 512 MB 512 MB Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty 512 MB 512 MB 512 MB 512 MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB

Memory Board (Slots)

DA-11372 World Wide — Version 25 — March 20, 2003 32

QuickSpecs

hp ProLiant DL580 Generation 2 (G2)

Memory

HP ProLiant DL580 G2 1.40 GHz 1P Model

TANDARD MEMORY

1024 MB 200MHz Double Data Rate (DDR) SDRAM (PC1600 Registered SDRAM Memory with Advanced ECC functionality

TANDARD MEMORY PLUS OPTIONAL MEMORY AND OPTIONAL MEMORY BOARD

Up to 25,600-MB memory is available with the optional installation of PC1600 Registered ECC SDRAM Memory kits and a second, optional memory board.

TANDARD MEMORY REPLACED WITH OPTIONAL MEMORY AND OPTIONAL MEMORY BOARD

Up to 32,768-MB of memory is available with the removal of the standard 1024-MB of memory, the optional installation PC1600 Registered ECC SDRAM Memory kits, and a second, optional memory board.

NOTE: Memory must be added in banks of four DIMMS. This chart does not represent all possible memory configurations.

Memory Standard Memory Board (Slots) Optional 2

Standard 1024MB Optional 25,600 MB

Maximum 32,768 MB

The following memory options are available from HP:

1234567812345678

256 MB 256 MB 256 MB 256 MB Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty 256 MB 256 MB 256 MB 256 MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB 2048MB

Memory Board (Slots)

Expand your memory capacity with the DL580 G2 Hot Plug Memory Expansion Board. Provides 8 additional DIMM slots for powering memoryintensive applications.

 Hot Plug Memory Expansion Board 203320-B21

DA-11372 World Wide — Version 25 — March 20, 2003 33

QuickSpecs

hp ProLiant DL580 Generation 2 (G2)

Storage

A Diskette Drive eject button B Ejectable: 24x IDE CD-ROM (Slimline) C Ejectable: 1.44-MB Diskette Drive (Slimline) D E 800-Watt (low line or high line) Redundant Hot Plug Power Supply F 800-Watt (low line or high line) Primary Hot Plug Power Supply

0-3

DRIVE SUPPORT

Quantity Supported

Ejectable Slim Line Drives

1.44-MB slim-line Diskette Drive Up to 1 C Integrated IDE slim-line CD-ROM Drive Up to 1 B Integrated IDE Slimline DVD-ROM Drive (8X/24X) Option

Kit

Hard Drive s

Ultra320 Hot Pluggable Drives

1-inch

146.8-GB 10,000 rpm

72.8-GB 10,000 rpm

36.4-GB 10,000 rpm

72.8-GB 15,000 rpm

36.4-GB 15,000 rpm

18.2-GB 15,000 rpm

NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives require an optional U320 Smart Array Controller or U320

SCSI HBA to support U320 transfer rates.

Up to 1 B or C Integrated IDE

Up to 4 0-3 Smart Array 5i Controller (integrated on system board)

CD-ROM Drive eject button

Wide Ultra3 Drive Cage (Duplex or Simplex configurable). Duplex is standard shipping configuration

Position Supported Controller

Smart Array 532 Controller Smart Array 5302/128 Controller Smart Array 5304/256 Controller Smart Array 5312 Controller Smart Array 641 Controller Smart Array 642 Controller 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

External Storage

StorageWorks Enclosure 4300 Family

(supports Ultra2/Ultra3 drives only)

MSA 1000

MSA 1000: http://www5.compaq.com/products/quickspecs/11033_div/11033_div.HTML

DA-11372 World Wide — Version 25 — March 20, 2003 34

Up to 20

(using Smart Array 5300 Controller)

Please see the MSA 1000 QuickSpecs below to determine configuration requirements

External Smart Array 532 Controller

Smart Array 5302/128 Controller Smart Array 5304/256 Controller Smart Array 5312 Controller Smart Array 642 Controller 64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

External Please see the MSA 1000 QuickSpecs (URL below) for the latest list

of supported HBAs

QuickSpecs

Storage

hp ProLiant DL580 Generation 2 (G2)

DRIVE SUPPORT

Maximum Sto rage Capaci ty – (External StorageWorks Enclosure Attached) Internal External 41.104 TB (20 x (14 x 146.8-GB 1″ Ultra320 SCSI Drives)) Total 41.691 TB

Tape Drives

NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the following:

http://www5.compaq.com/products/quickspecs/North_America/10233.html (North America) http://www5.compaq.com/products/quickspecs/Division/10233.html (Division/World Wide)

NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Storage Systems listed below, please see the following:

http://www5.compaq.com/products/quickspecs/North_America/10809.html (North America) http://www5.compaq.com/products/quickspecs/Division/10809.html (Division/World Wide)

Internal AIT 100-GB, Hot Plug Internal AIT 50-GB, Hot Plug Internal AIT 35-GB, LVD, Hot Plug Internal 20/40-GB DAT, Hot Plug

External AIT 50-GB Tape Drive External AIT 35-GB, LVD Tape Drive

SDLT 110/220-GB, External SDLT 160/320-GB, External

DLT VS 40/80-GB, External External 40/80-GB DLT Enhanced External 20/40-GB DLT

HP StorageWorks AIT 35 GB Autoloader

SSL2020 AIT Mini-Library

MSL5026DLX (40/80-GB DLT-based) and MSL5026SL (SDLT-based) Library

ESL9198SL ESL9326SL ESL9595SL

ESL9198SL: http://www5.compaq.com/products/quickspecs/10867_div/10867_div.HTML ESL9326SL: http://www5.compaq.com/products/quickspecs/10868_div/10868_div.HTML ESL9595SL: http://www5.compaq.com/products/quickspecs/11332_div/11332_div.HTML

(continued)

587.2 GB (4 x 146.8-GB Ultra320 SCSI 1″ Driv es)

Quantity Supported

Position Supported Controller

Up to 1 0 & 1 or 2 & 3 Smart Array 5i Controller (integrated on system board)

Smart Array 532

*NOTE: The Smart Array 532 Controller does not support the AIT

100-GB Hot Plug Tape Drive.

Smart Array 5302/128 Controller Smart Array 5304/256 Controller Smart Array 5312 Controller Smart Array 641 Controller Smart Array 642 Controller 64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 64-Bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

Up to 2 External 64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Up to 2 External 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Up to 3 External 64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

Up to 1 (for a single HBA) Up to 2 (for a dual HBA) 2 drives per SCSI channel

2 drives per SCSI channel

Please see the ESL Library QuickSpecs below to determine configuration requirements

External 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

External 64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

External 64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

64-Bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

64-Bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

SAN Access Module for Smart Array 5302 Controller 64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter

DA-11372 World Wide — Version 25 — March 20, 2003 35

QuickSpecs

Power Specifications

POWER SPECIFICATIONS

Part Number 278535-001 Spare Kit 192201-001

Operational Input Voltage Range (V rms) Frequency Range (Nominal) (Hz)

90 to 264 47 to 63 (50/60)

hp ProLiant DL580 Generation 2 (G2)

Nominal Input Voltage (Vrms)

Max Rated Output Wattage Rating Nominal Input Current (A rms) Max Rated Input Wattage Rating (Watts) Max. Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A peak) Maximum Inrush Current duration (mS)

100 115 208 220 230 240

800 800 800 800 800 800

11.7 9.9 5.2 4.9 4.7 4.5 1143 1111 1067 1067 1067 1053 1166 1134 1088 1088 1088 1074

70 72 75 75 75 76

0.98 0.98 0.98 0.98 0.98 0.98

0.43 0.50 .90 .96 1.00 1.04

25 25 25 25 25 25 20 20 20 20 20 20

SY STEM SPECIFICATIONS

DL580 G2 Fully Configured

Up to 4 Processors, 16 Memory Slots, 4 Hard Drives, 6 PCI Slots, and 2 Hot Plug Power Supplies

Nominal Input Voltage (Vrms)

Fully Loaded System Input Wattage (W) Fully Loaded System Input AMPs (A rms) Fully Loaded System Thermal (BTU-Hr) Fully Loaded System VA (Volt-Amp) System Leakage with all power supplies loaded (mA)

System Inrush Current with all power supplies loaded (A)

Power cord requirements

100 115 208 220 230 240

954 928 890 890 890 879

10 8.5 4.4 4.1 4.0 3.7 3253 3163 3063 3063 3063 2996 1004 976 909 909 909 897

.87 1.00 1.81 1.91 2.00 2.09

50 50 50 50 50 50

Nema 5-15P to IEC320-C19 Option no./Spare no: 235603-001/237457-001 PDU Jumper Cord IEC320-C19 to

IEC320-C20 PDU Jumper Cord IEC320-C14 to

IEC320-C19

Option no./Spare no: 295633-B21/295508-001 Option no./Spare no: 291034-B21/ 292241-001

NOTES: ActiveAnswers Power Calculation Power calculator is LIVE on ActiveAnswers website. This is an external link. Follow this link:

http://activeanswers.HP.com/aaconfiguratorcode/configurationUi.asp?HTMLFilename=Mainselections&UiLocalization= UnitedStates&DisplayCountry=United%20States

To drill down to calculators:

- Click on: “ProLiant Servers”

- Click on the Server of interest. Example: DL580 G2

- Click on: “Power Calculator” link (You may need to scroll down to see it.)

DA-11372 World Wide — Version 25 — March 20, 2003 36

QuickSpecs

Technical Specifications

hp ProLiant DL580 Generation 2 (G2)

System Unit Rack

Chassis Footprint (HxWxD) 6.94 x 19 x 26.5 in/17.6 x 48.3 x 67.3 cm Weight

No hard drives installed, one power supply

Input Requirements

Max BTU Rating

(per power supply)

Temperature Range

Relative Humidity

(non-condensing)

Maximum Wet Bulb Temperature

Acoustic Noise

66 lb/29.9 kg

Rated Input Voltage 100 to 120 VAC/200 to 240 VAC Rated Input Frequency 50 to 60 Hz Input Power 1135W @ 110 VAC/1125W @ 220 VAC Rated Input Current

4000 BTU Rated Steady-State Power 800W/800W (lowline/highline)Power Supply Output Power Maximum Peak Power 800W/800W (lowline/highline) Operating 50° to 95° F/10° to 35° C Non-operating -20° to 140° F/-29° to 60° C Shipping -22° to 122° F/-30° to 50° C Operating Non-operating

101.7°F/38.7°C

NOTE: Listed are the declared A-weighted sound power levels LWAd and the

declared average bystander position sound pressure levels LpAm when operating in a 23° C ambient environment. Noise emissions were measured in accordance with ECMA 74 and declared in accordance with ECMA 109.

Idle (Steady State)

(BELS)

WAd

(dBA)

pAm

NOTE: These values apply to 4U rack configuration. Configuration tested

included 2 processors, one 10, 000 rpm hard drive, 2 power supplies, 4 memory/IO fans and 3 CPU fans.

12A (100 VAC), 9.8A (120 VAC), 4.9A (220 VAC)

10% to 70% 5% to 95%

7.0 54

1.44-MB Diskette Drive

DA-11372 World Wide — Version 25 — March 20, 2003 37

Diskette Size LED Indicators (front panel) Read/Write Capacity per

Diskette (high/low density) Drive Supported

Drive Height Drive Rotation Transfer Rate (high/low) Bytes/Sector Sectors/Track (high/low) Tracks/Side (high/low) Access Times

Cylinders (high/low) Read/Write Heads

3.5 in Green

1.44 MB/720 KB

One One-third 300 rpm 500/250 Kb/s 512 18/9 80/80 Track-to-Track (high/low) 3/6 ms Average (high/low) 169/94 ms Settling Time 15 ms Latency Average 100 ms 80/80 Two

QuickSpecs

Technical Specifications

hp ProLiant DL580 Generation 2 (G2)

24X Max (or higher) IDE CD-ROM Drive Slim Line

Disk

Block Size Mode 1 2,048

Interface IDE (ATAPI) Access Times (typical) Random 100 ms

Audio Output Level Line-Out 0.7 VRMS at 47 kOhms

Data Transfer Rate Sustained 150 KB/s (single)

Cache Buffer 128 KB Start-up Time (typical) < 7 seconds Stop Time < 4 seconds Laser Parameters T ype Semiconductor Laser GaA1As

Operating Conditions Temperature 41° to 113°F/5° to 45°C

Dimensions (HxWxD, maximum) 1.69 x 5.75 x 8.19 in/4.29 x 15 x 20.8 cm

Applicable Disk CD-ROM (Mode 1 and 2)

CD-DA, CD-XA (Mode 2, Form 1 and 2) Photo CD (Single and Multi-session) Mixed Mode (Audio and Data combined)

Capacity 540 MB (Mode 1, 12 cm)

650 MB (Mode 2, 12 cm) Diameter 4.7 in, 3.15 in/12 cm, 8 cm Rotational Speed 4200 rpm maximum Center Hole 0.6 in/15 mm diameter Thickness 1.2 mm Track Pitch 1.6 µm

Mode 2 2,340, 2,336, 1,024 bytes CD-DA 2,352 bytes CD-XA 2,328 bytes

Full-Stroke 2000 ms

Headphone 0.6 VRMS at 32 kOhms (maximum volume)

Burst 2100 to 3600 KB/s

Wave Length 780 ± 25 nm Divergence Angle 53.5° ± 1.5° Output Power 0.14 mW

Humidity 10% to 80%

Weight 2.66 lb/1.2 kg

DA-11372 World Wide — Version 25 — March 20, 2003 38

QuickSpecs

Technical Specifications

hp ProLiant DL580 Generation 2 (G2)

Integrated Lights-Out Standard

(integrated on system board)

Architecture 32-bit PCI-based health and remote management ASIC (Application Specific

Processor 32-bit RISC processor core running at 66 MHz Upgradability Option firmware upgradable via flash ROM. Video Support Utilizes the host server’s embedded video chip. Supports VGA/SVGA, 640 x 480

Interfaces One Ethernet network connection (10/100 Mb/s)

Operating System Support

Client Browser Support Microsoft Internet Explorer 5.5 or later. iLO Standard Features

iLO Advanced Features

(optional)

Integrated Circuit)

(256 to 16.7M colors), 800 x 600 (256 to 16.7M colors), 1024 x 768 (256 to 65K colors), 1280 x 1024 (256 colors)

2-MB Flash ROMMemory 8-MB SDRAM Microsoft Windows NT 4.0 Server Windows NT 4.0 Enterprise Edition Windows 2000 Server Windows 2000 Advanced Server Red Hat 7.x, SuSE 7.0, Novell NetWare 5.x, 6.x

Virtual Text Remote Console Virtual Power Button Control Dedicated LAN Connectivity Automatic IP Configuration via DHCP/DNS/WINS Industry Standard 128-bit Secure Sockets Layer (SSL) Security IML and iLO Event Logging Support for up to 12 user accounts with customizable access privileges Virtual Graphical Remote Console Virtual Floppy Drive

DA-11372 World Wide — Version 25 — March 20, 2003 39

QuickSpecs

Technical Specifications

hp ProLiant DL580 Generation 2 (G2)

Integrated Smart Array 5i Plus Controller

Data Compatible with all Smart Array Controllers

Instant Upgrades to other Smart Array Controllers

Consistent S oftware Manageability Tools

PCI-X Bus 64-bit, 100 MHz (integrated on system board) PCI-X Peak Data Transfer Rate 800 MB/s SCSI Protocols Supported Ultra3, Ultra2 SCSI Peak Data Transfer Rate 160 MB/s per channel

NOTE: For ProLiant servers having TWO internal drive bays on separate SCSI ports: SCSI Peak Data Transfer

Rate is 320 MB/s total; 160 MB/s per channel and Channels is 2.

Channels 2

NOTE: For ProLiant servers having two internal drive bays on separate SCSI ports: SCSI Peak Data Transfer

Rate is 320 MB/s total; 160 MB/s per channel and Channels is 2.

SCSI Ports (external/internal) 0/2

NOTE: For ProLiant servers having two internal drive bays on separate SCSI ports: SCSI Peak Data Transfer

Rate is 320 MB/s total; 160 MB/s per channel and Channels is 2.

Drives Supported (maximum) Maximum = total number of drives

NOTE: Maximum is the total number of internal drives on each specific ProLiant server.

Cache 64 MB Read and/or Write Cache Battery-Backed Write Cache Yes, with installation of Battery-Backed Write Cache Enabler, up to 64MB RAID Support 0, 1, 1+0, 5 Logical Drives (maximum) Maximum = total number of drives Online Configuration Yes Online Capacity Expansion Yes Logical Drive Capacity

Extension Online Stripe Size Migration Yes Online RAID Level Migration Yes Online Spare Support Yes

Automatic Data Recovery Yes Drive Roaming Yes Redundant Controllers No

Yes

DA-11372 World Wide — Version 25 — March 20, 2003 40

QuickSpecs

Technical Specifications

hp ProLiant DL580 Generation 2 (G2)

Server Adapter

Hewlett-Packard Company in the U.S. and/or other countries. Microsoft and Windows NT are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Novell and NetWare are registered trademarks or trademarks of Novell, Inc in the U.S. and/or other countries. Intel and Xeon are registered trademarks or trademarks of the Intel Corporation in the U.S. and/or other countries. Solaris is a registered trademark or trademark of Sun Microsystems, Inc., in the U.S. and/or other countries. Linux is a registered trademark or trademark of Linus Torvalds in the U.S. and/or other countries. Red Hat is a registered trademark or trademark of Red Hat, Inc., in the U.S. and/or other countries. SuSE and its logo are registered trademarks or trademarks of SuSE AG in the U.S. and/or other countries. UNIX is a registered trademark of The Open Group in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

Network Interface 10/100/1000-TCompaq NC7770 PCI-X Gigabit Compatibility IEEE 802.3 10Base-T

IEEE 802.3ab 1000Base-T IEEE 802.3u 100Base-TX

Data Transfer Method 64-bit/133MHz PCI-X Network Transfer Rate

Connector RJ-45 Cable Support 10Base-T Category 3,4 or 5 UTP up to 328 ft/100 m

10Base-T (Half-Duplex) 10 Mb/s 10Base-T (Full-Duplex) 20 Mb/s 100Base-TX (Half-Duplex) 100 Mb/s 100Base-TX (Full-Duplex) 200 Mb/s 1000Base-T (Half-Duplex) 1000 Mb/s 1000Base-T (Full-Duplex) 2000 Mb/s

10/100/1000Base-T Category 5 UTP (2 pair); up to 328 ft/100 m

Hewlett-Packard shall not be liable for technical or editorial errors or omissions contained herein. The information is provided "as is" without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

DA-11372 World Wide — Version 25 — March 20, 2003 41

HP (Hewlett-Packard) DL580 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Models

Options

Memory

Storage

Power Specifications

Technical Specifications
