QuickSpecs

Overview

Front View:

Quick removal access panel

AMD Six-Core Processor (Performance models include two processors)

Second AMD Six-Core Processor

Sixteen sockets for PC2-6400 DIMMs (800MHz) with Advanced ECC

Hot-plug fans, full redundancy

Slim SATA DVD-RW Optical Drive included on Performance models

UID LED button

Health LED

Power On/Standby button and system power LED

10.

USB connectors (2)

11.

Video connector

12.

Systems Insight Display

Rear View:

PCI slot 5

PCI slot 6

PCI slot 4

PCI slot 2

PCI slot 3

PCI slot 1

Power supply 2

Power supply 1

USB connectors (2)

10.

Video connector

11.

NIC 1 connector

12.

NIC 2 connector

13.

Mouse connector

14.

Keyboard connector

15.

Serial connector

16.

iLO2 connector

17.

NIC 3 connector

18.

NIC 4 connector

HP ProLiant DL385 Generation 6

What's New

Deploy more virtual machines with confidence with the new HP ProLiant DL385 G6 that offers 16 DIMM slots, two (2) dualport NICs, and up to 16 SFF hard drives. Offering new AMD Opteron® six-core processors and modular Smart Arrays.

Up to two (2) AMD Opteron™ 2400 Series Six-Core Processors with 6MB L3 cache 16 DIMMs sockets for up to 128GB of DDR2-800MHz Two HP NC382i Integrated Dual Port Multifunction Gigabit Server Adapters (four ports total)

At A Glance

As the leading 2P 2U AMD rack server, the HP ProLiant DL385 G6 is designed with virtualization in mind, yet flexible to support any business need in many environments from corporate datacenters to sophisticated SMBs.

Processors

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 1

QuickSpecs

Overview

AMD Six-Core, 2400 series processors with 6MB Level 3 cache for blazing performance; systems support up to 2 processors (2 processors standard on all Performance models) Preconfigured Performance models save valuable deployment time at a discounted bundle price Serverworks HT-2100 Northbridge and HT-1000 Southbridge chipset

Memory

Storage Controller

Internal Drive Support

Network Controller

Expansion Slots

USB 2.0 Ports

Redundancy

Power Supply

Infrastructure Management:

Operating Systems and Virtualization Software Support for ProLiant Servers

Form Factor

Deployment/Serviceability

: Up to 128 GB (with PC2-5300 8GB DIMMs). PC2-6400 800MHz DDR2 Standard models support 2:1 Bank Interleaving. 4:1 Bank Interleaving (Data saved across 2 pairs of DIMMs) and Node interleaving support (data saved across 2 processors memory sets) also available

: Performance Models: HP Smart Array P410/512MB with BBWC Base Models: HP Smart Array P410/256MB Controller Entry Models: HP Smart Array P410/Zero Memory Controller

Upgrade to 256MB cache with optional battery for BBWC, or 512MB BBWC option

: Up to 16 small form factor (SFF) or up to 6 large form factor (LFF) hot-plug drive bays to support Serial-attached SCSI (SAS) and Serial ATA (SATA) drives (with optional drive cages)

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

: Up to 6 PCI slots (one occupied by controller) Standard BTO riser with PCIe (1) x8 FL/FH, (2) x4 HL/FH Optional second risers with PCIe (1) x8, (2) x4; or a PCIe/PCI-X mixed riser with (1) PCI-X, (1) x8, (1) x4; or a x16 225w PCIe riser with (1) x16; or a (2) x8 Dual Port 10GbE riser

5 total ports: (2) ports in front; (2) ports in back; (1) port internal

: Fully redundant hot plug fans (Entry/Base four fans; Performance six fans) Hot plug power supply with optional redundancy (Included in Performance models)

Dual Common Slot Bay for Right Sized, Hot plug and Redundant Power options

HP 1200W CS HE Silver Power Supply HP 750W CS HE Gold Power Supply HP 460W CS HE Gold Power Supply HP 1200W -48V DC CS Power Supply

Convenient slide-out Systems Insight Display for quick and easy front view server diagnostics, along with status LEDs, Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU) HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) for simplified server setup, health monitoring and recovery, power and thermal control, and lights-out remote administration. HP Insight Control (ICE) suites, as product options, deliver essential infrastructure management that can help save time and money by making it easy to deploy, monitor, control and optimize your IT infrastructure through a single, simple management console. ICE suites support both Windows and Linux-based servers and management consoles HP Insight Dynamics - VSE suite for ProLiant servers, a product option, is an integrated command center that enables you to continuously analyze and optimize your adaptive infrastructure. This advanced infrastructure management software lets you reduce the cost of common data center tasks by as much as 40 percent while keeping pace with your changing business.

Supports Windows, RHEL, SLES, OEL, Solaris, NetWare, VMware

Rack (2U), (3.5-inch)

: Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick release levers for fast and easy serviceability Tool-less access to all system components for easy in rack serviceability Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for greater flexibility in performing defective parts replacement

HP ProLiant DL385 Generation 6

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 2

QuickSpecs

Overview

HP ProLiant DL385 Generation 6

Warranty

: This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 3

QuickSpecs

Standard Features

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -

Factory Integrated Models" section.

Processor

One of the following depending on Model

Six-Core Processors

AMD Opteron™ Processor Model 2435 (2.6 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2431 (2.4 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2427 (2.2 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2425HE (2.1 GHz, 6MB Level 3 Cache, 55W)

NOTE:

Processor wattage references reflect Average CPU Power (ACP). For more information on

ACP visit:

NOTE:

Up to 2 processors supported. High Performance Model configurations include two processors, 16 GB system memory, 512MB storage controller memory, BBWC, DVDRW, Redundant 750W Power Supplies, and 6 hot plug redundant fans.

http://www.amd.com/powernow

HP ProLiant DL385 Generation 6

Cache Memory

Upgradeability

Chipset

Memory Protection

Memory

One of the following depending on Model

6MB Level 3 cache memory

Upgradeable to two processors

Serverworks HT-2100 Northbridge and HT-1000 Southbridge Chipset

Advanced ECC

Type

Standard (Entry Models)

Standard (Base Models)

Standard (Performance Models)

Maximum

REG PC2-6400 DIMMs (DDR2-800) Standard models support 2:1 Bank Interleaving, with 4:1 Bank Interleaving (Data saved across 2 pairs of DIMMs) and Node interleaving support (data saved across 2 processors memory sets) available.

NOTE:

If only one processor is installed, only half of the DIMM slots are

available.

4 GB (2 x 2 GB)

8 GB (2 x 4 GB)

16 GB (4 x 4 GB)

128 GB (16 x 8 GB) (PC2-5300)

Network Controller

Expansion Slots

Primary Riser

(Standard)

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

NOTE:

1GB of memory is sufficient to support up to eight Total Ports. 2GB of memory is required if nine or more Total Ports have been selected.

Expansion

Slots #

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Technology

PCI-Express

Bus

Width

Connector

Width

x16

Bus Number

Form Factor

Full

Length/Full

Height

Notes

Page 4

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

PCIe Riser

(Optional Secondary)

PCIe/PCI-X Riser

(Optional Primary)

PCIe/PCI-X

Secondary)

x16 PCIe Riser

(Optional Primary)

Dual Port 10GbE Riser

(Optional Primary)

(Optional

NOTE:

alter the actual bus assignment number

NOTE:

alter the actual bus assignment number

NOTE:

alter the actual bus assignment number

NOTE:

alter the actual bus assignment number

NOTE:

alter the actual bus assignment number

NOTE:

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

Expansion

Slots #

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the

Expansion

Slots #

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

Expansion

Slots #

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

Expansion

Slots #

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

Expansion

Slots #

PCI-Express

Technology

PCI-Express

Technology

PCI-Express

Technology

PCI-X

PCI-Express

Technology

PCI-Express

Technology

PCI-Express

x4 x8

Bus

Width

x4 x8

Bus

Width

64-bit

x4 x8

Bus

Width

64-bit

x4 x8

Bus

Width

x16 x16

Bus

Width

Connector

Width

Connector

Width

Connector

Width

Connector

Width

Connector

Width

x16

N/A

x16

N/A

x16

Bus Number

Half length,

full height

Half length,

full height

Form Factor

Full

Length/Full

Height

Low Profile

Form Factor

Full length,

Half height

Half Length,

Full Height

Half Length,

Full Height

Form Factor

Full

Length/Full

Height

Low Profile

Form Factor

Full

Length/Full

Height

Form Factor

Full

Length/Full

Height

Occupied by

P410

controller

Notes

Supports up

to 225W;

single wide

cards only

Notes

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 5

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

Dual Port 10GbE Riser

(Optional Secondary)

Storage Controller

One of the following depending on Model

NOTE:

alter the actual bus assignment number

NOTE:

alter the actual bus assignment number

NOTE:

Entry Models:

Base Models:

High Performance Models:

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

Expansion

Slots #

Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may

Bus width - Indicates the number of physical electrical lanes running to the connector

PCI-Express

Technology

PCI-Express

Bus

Width

HP Smart Array P410/Zero Memory Controller

HP Smart Array P410/256 MB Controller

Available upgrades

0/1/1+0/5/6, battery for battery-backed write cache (BBWC).

NOTE:

RAID 6 requires purchase of HP Smart Array Advanced Pack

(516471-B21).

HP Smart Array P410/512 MB BBWC Controller

x16

Connector

Width

x16

: 512MB memory module with BBWC for RAID

Bus Number

Half length,

full height

Form Factor

Full

Length/Full

Height

Low Profile

Notes

Storage

Maximum Internal Storage

Interfaces

Diskette Drive

Optical Drive

Hard Drives

Hot Plug SFF SAS

Hot Plug LFF SAS

Serial

Pointing Device (Mouse)

Graphics

Keyboard

VGA

Network RJ-45 (Ethernet)

iLO 2 remote management port

USB 2.0 Ports

None Standard

HP Slim SATA DVD RW Optical Drive Standard on Performance Models

None Standard

8TB

6TB

2 (1 front, 1 back)

5 (2 front, 2 back, 1 inside)

NOTE:

Please see the following URL for additional information regarding USB support:

http://h18004.www1.hp.com/products/servers/platforms/usbsupport.html

16 x 500GB with standard internal hot plug SFF SAS (with optional drive cage)

6 x 1TB (with optional drive cage)

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 6

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

Graphics

Form Factor

HP Insight Software

Integrated ATI ES1000, 32MB video standard

16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024

NOTE:

Maximum resolution available via iLO remote console is 1280 x 1024.

Rack (2U), (3.5-inch)

HP Insight Foundation

Managing the growing number of servers can be complex and expensive for your organization. IT managers need to address changing business needs with tools that meet the challenges of managing today's complex Datacenters.

HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server lifecyle. This provides the customer with higher levels of operational efficiency and highly reliable systems:

http://www.hp.com/go/foundation

The foundation pack includes:

HP SmartStart HP Management HP ProLiant Firmware Maintenance

ProLiant Onboard Administrator

HP Insight Control suites

HP Insight Dynamics – VSE suite

SmartStart version supported (minimum): SmartStart 8.25.

http://www.hp.com/servers/smartstart

HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration of ProLiant ML, DL, and BL servers. HP ProLiant Onboard Administrator functions without additional software, and can be accessed from any location via a web browser. It works hand-in-hand with HP Systems Insight Manager, Insight Control suites, and the Insight Dynamics-VSE suite helping customers unlock the value of the ProLiant platform and deliver the highest possible quality of IT service to the business. See

HP Insight Control suites, as product options, deliver essential infrastructure management that can help save time and money by making it easy to deploy, monitor, remote control, and optimize your IT infrastructure through a single, simple management console. Insight Control suites install and license software modules that are integrated into HP System Insight Manager. Two Insight Control suites are available, to serve environments requiring either Linux-based or Windows-based central management servers: HP Insight Control suite for Linux, and HP Insight Control suite. See

www.hp.com/go/insightcontrol

HP Insight Control suites include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:

http://www.hp.com/services/insight

The HP Insight Dynamics - VSE suite for ProLiant, a product option, is an integrated command center that enables you to continuously analyze and optimize your adaptive infrastructure. This advanced infrastructure

www.hp.com/go/ProLiantOA

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 7

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

management software that allows you to analyze and optimize your adaptive infrastructure to manage physical and virtual resources in the same way. HP Insight Dynamics - VSE gives you a powerful toolkit to accelerate complex technology projects and simplify daily operations. It enables you to plan capacity and power continuously, balance across physical and virtual resources, ensure cost-effective high availability, and provision infrastructure consistently.

HP Insight Orchestration, an optional extension to Insight Dynamics VSE, enables IT organizations to provision infrastructure consistently and automatically from pools of shared resources using a self-service portal. Resources provisioned can range from a single virtual machine to complex multi-tier environments and their associated physical and virtual resource requirements.

HP Insight Recovery, also an optional extension for Insight Dynamics VSE, enables cost-effective disaster recovery for physical and virtual environments. Application environments can be reactivated in minutes with the touch of a button to a remote location.

NOTE:

For more information, visit:

http://www.hp.com/go/insightdynamics http://www.hp.com/go/insightorchestration http://www.hp.com/go/insightrecovery

Industry Standard Compliance

Intelligent Manageability

Security

ACPI 2.0 Compliant PCIe 1.1 Compliant PCI 2.2 Compliant PCI-X 2.0a Compliant WOL Support Microsoft® Logo certifications USB 2.0 Support

HP Systems Insight Manager software SmartStart Management Agent Redundant ROM Remote Flash ROM ROM-Based Setup Utility (RBSU) Integrated Management Log Automatic Server Recovery (ASR) Dynamic Sector Repairing (with Smart Array controller) Drive Parameter Tracking (with Smart Array controller) Pre-Failure Warranty (covers processors, SAS hard drives and memory)

Power-on password Keyboard password Diskette drive control Diskette boot control QuickLock, Network Server Mode Parallel and serial interface control Administrator's password

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 8

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

Security - Trusted Platform Module

UPS and PDU Power Cord Matrix

Power Supply

Trusted Platform Module option kit

The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker leverages the enhanced security capabilities of a Trusted Platform Module (TPM) version 1.2. The TPM works with BitLocker to help protect user data and to ensure that a server running Windows Server 2008 has not been tampered with while the system was offline. For more information about TPM, including a white paper, go to:

NOTE:

ProLiant OS pre-installed units will come with the partition required for TPM deployment.

NOTE:

The TPM key is unique to every TPM deployed server and must be retained. Misplacing or

losing the key could result in data loss.

Please see the UPS and PDU cable matrix's on the HP Power Protection and Management page. Under Power Cords, click on the “HP Power Cord Matrix” link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link:

www.hp.com/products/powercords

HP has a new design for ProLiant power. The new Common Slot Power Supply bay. This design provides the customer with commonality in power supplies across multiple platforms to save on the cost of spares and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers come with Common Slot, High Efficiency and Right-Size Power Supplies. Common Slot (CS) designates commonality of the power supply across multiple ProLiant servers. HP's new Common Slot power supplies are designed for highest efficiency to provide power efficiency without degrading performance of the ProLiant. Power Supplies will have efficiency ratings up to 92%. There are three Right Size power options available, depending on the configuration of your server. To make sure you select the correct power supply to meet your configuration, we suggest that you use the HP Power Advisor ( to decide the "Right-Size" for your configuration. All HP Common Slot power sources are UL, CE Mark Compliant, Hot Plug and Redundant.

www.hp.com/go/TPM

www.hp.com/go/hppoweradvisor

)

Common Slot ProLiant

It is highly recommended that you use the HP Power Calculator in defining the "Right-Size" power supply for your needs. HP offers the following Power Supply Options:

HP 460Watts, Common Slot, 92% Efficiency HP 750Watts, Common Slot, 92% Efficiency HP 1200Watts, Common Slot, 90% Efficiency HP 1200W -48V DC CS Power Supply

HP's ProLiant Common Slot Power supplies (460W & 750W) meet multiple Energy Efficiency Initiatives. Climate Savers Computing Initiative GOLD, ECOS Consulting 80PLUS GOLD and plans on offering models that meet the Energy Star for Server requirements when they are published.

HP's ProLiant Common Slot Power supplies (1200W) meet multiple Energy Efficiency Initiatives. Climate Savers Computing Initiative Bronze, ECOS Consulting 80PLUS Bronze Power Supply requirements.

Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power supply option kits (see Redundant Options for part numbers).

NOTE:

BTO Performance models include two power supplies; BTO Base and Entry models

include one power supply. On CTO models, power supply must be selected from available

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 9

QuickSpecs

Standard Features

options.

HP ProLiant DL385 Generation 6

System Fans

Operating Systems and Virtualization Software Support for ProLiant Servers

Rack Airflow Requirements

Hot plug fans ship standard, N+1 fully redundant (3+1) for 1 processor, (5+1) for 2 processors

NOTE:

Processor option kits include 2 additional fans when upgrading to 2 processors.

Microsoft Windows Server Microsoft Windows Server Hyper-V Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Enterprise Linux (OEL) Solaris 10 for x86/x64 based Systems VMware

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at:

www.hp.com/support/DL385G6

Rack 10000 G2 series Cabinets

The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The 10000 G2 Series Racks provide enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

CAUTION:

adequate airflow and to prevent damage to the equipment:

If a third-party rack is used, observe the following additional requirements to ensure

http://www.hp.com/go/ossupport

and our driver download page

Rack Kit

Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 830 square inches (5,350 sq cm) of holes evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of 2.75 inches (7 cm).

CAUTION:

This arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE:

CD provided with the server, or to the server documentation located in the Support section at the following URL:

Quick deploy rail system provides tool-free support for racks with square or round mounting holes (including Compaq/HP 7000, 9000, 10000 G2 and HP series), with an adjustment range of 24" 36". The ambidextrous cable management arm can be mounted on either the left or right side for improved cable management.

NOTE:

cable management arm is mounted on the right.

NOTE:

327281-B21; or High Air Flow Rack Door Insert for the 7142 Rack (6-pack) - PN: 327281-B22) are required to support the HP ProLiant DL385 in 7000 series racks. The DL385 Cable Management Arm is not supported on 7000 series racks.

Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.

For additional information, refer to the Setup and Installation Guide or the Documentation

www.hp.com/servers/proliantdl385G6

Cable management arm must be removed to access hot-plug power supplies when the

High Airflow Inserts (High Air Flow Rack Door Insert for the 7142 Rack (single) - PN:

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 10

QuickSpecs

Standard Features

HP ProLiant DL385 Generation 6

Telco Rack Support

Factory Express Portfolio for Servers and Storage

HP Enterprise Configurator

Support for all 2-post Telco racks requires the use of the standard rack kit and an additional option kit from Rack Solutions (

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to:

The HP eConfigure-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.

http://www.hp.com/products/configurator

http://www.racksolutions.com/hp/

http://www.hp.com/go/factory-express

)

Service and Support

HP Care Pack services provide total care and support expertise with committed response designed to meet your IT and business needs.

HP Care Pack services include coverage for the HP branded hardware options qualified for the server and purchased at the same time or afterward that are internal to the enclosure. This also includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions, provides a range of support services designed to meet the varying needs of your business. Whether an SMB, or large global corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Recommended Service

management.

Support: Service:

Enhanced Service

3-Year 4-Hour response 24x7 Same Business Day Coverage only

Installation and Start up only

- simplify ProLiant solution implementation, maintenance, and

- optimize service level to increase IT performance and availability.

Support:

Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft, or Linux O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.

NOTE:

For a complete listing of service offerings and information visit:

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

3-Year Support Plus 24 only

Page 11

QuickSpecs

Standard Features

http://www.hp.com/services/proliantservices http://www.hp.com/go/proliant/carepack

HP ProLiant DL385 Generation 6

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 12

QuickSpecs

HP ProLiant DL385 Generation 6

HPC Interconnects

NOTE:

High Performance Computing (HPC) interconnect technologies are available for this server under the Cluster Platform product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following URL to configure HPC Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects:

http://www.hp.com/techservers/clusters/ucp/index.html

HPC Interconnect

InfiniBand

Gigabit Ethernet

Myrinet XP

PCI-X and PCI-Express adapters

Use embedded ports

PCI-X Rev D and Rev E adapters

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 13

QuickSpecs

Models

Performance Models

HP ProLiant DL385 G6 2435 2.6GHz Six Core Performance Rack Server

570102-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

Power Supply

Fans

Form Factor

(s)

HP ProLiant DL385 Generation 6

(2) Six-Core AMD Opteron™ Processor Model 2435 (2.6 GHz, 75W)

6MB L3 cache

16GB (4 x 4GB) of 2:1 interleaved PC2-6400 DIMMs (DDR2-800MHz) with Advanced ECC capabilities

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

HP Smart Array P410/512MB BBWC Controller

None ship standard

Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays

Slim SATA DVD-RW Optical Drive

(2) 750W power supplies

6 Hot Plug Fully Redundant Fans

Rack (2U), (3.5-inch)

HP ProLiant DL385 G6 2435 2.6GHz Six Core ICE Performance Rack Server

575381-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

Power Supply

Insight Control Environment (ICE)

Fans

Form Factor

(s)

(2) Six-Core AMD Opteron™ Processor Model 2435 (2.6 GHz, 75W)

6MB L3 cache

16GB (4 x 4GB) of 2:1 interleaved PC2-6400 DIMMs (DDR2-800MHz) with Advanced ECC capabilities

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

HP Smart Array P410/512MB BBWC Controller

None ship standard

Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays

Slim SATA DVD-RW Optical Drive

(2) 750W power supplies

HP Insight Control Environment No Media single server license, including 1 year of 24x7 Technical Support and Updates

6 hot plug redundant fans

Rack (2U), (3.5-inch)

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 14

QuickSpecs

Models

Base Models

HP ProLiant DL385 G6 2431 2.4GHz Six Core Base Rack Server

570103-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

Power Supply

Fans

Form Factor

(s)

HP ProLiant DL385 Generation 6

(1) Six-Core AMD Opteron™ Processor Model 2431 (2.4 GHz, 75W)

6MB L3 cache

8GB (2 x 4GB) of 2:1 interleaved PC2-6400 DIMMs (DDR2-800MHz) with Advanced ECC capabilities

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

HP Smart Array P410/256MB Controller

None ship standard

Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays

Not included on Base Model

(1) 460W power supply

4 hot plug redundant fans

Rack (2U), (3.5-inch)

Entry Models

HP ProLiant DL385 G6 2427 2.2GHz Six Core Entry Rack Server

570108-xx1

HP ProLiant DL385 G6 2425HE 2.1GHz Six Core Rack Server

570109-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

Power Supply

Fans

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Optical Drive

Power Supply

Fans

Form Factor

(s)

(1) Six-Core AMD Opteron™ Processor Model 2427 (2.2 GHz, 75W)

6MB L3 cache

4GB (2 x 2GB) of 2:1 interleaved PC2-6400 DIMMs (DDR2-800MHz) with Advanced ECC capabilities

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

HP Smart Array P410/Zero Memory Controller

None ship standard

Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays

Not Included on entry model

(1) 460W power supply

4 hot plug redundant fans

Rack (2U), (3.5-inch)

(1) Six-Core AMD Opteron™ Processor Model 2425HE (2.1 GHz, 55W)

6MB L3 cache

4GB (2 x 2GB) of 2:1 interleaved PC2-6400 DIMMs (DDR2-800MHz) with Advanced ECC capabilities

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)

HP Smart Array P410/Zero Memory Controller

None ship standard

Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays

Not Included on entry model

(1) 460W power supply

4 hot plug redundant fans

Rack (2U), (3.5-inch)

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 15

QuickSpecs

Models

HP ProLiant DL385 Generation 6

Country Code Key

XX=00

XX=20

XX=29

XX=37

XX=42

XX=AA

U.S.

Brazil

Japan

A/P

Europe

PRC

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 16

QuickSpecs

HP ProLiant DL385 Generation 6

Configuration Information - Factory Integrated Models

NOTE:

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.

NOTE:

HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start with a CTO Chassis.

NOTE:

FIO indicates that this option only available as a Factory Installable Option.

Step 1: Base Configuration (choose one of the following configurable models)

Models

HP ProLiant DL385G6 Rack CTO Chassis

Factory Integrated Model ships with:

(8) SFF Serial Attached SCSI (SAS) Drive Bays Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) PCI-Express Riser Cage One IEC Power cord Hot plug fans (fully redundant)

NOTE:

4 fans one processor models; 6 fans two processor models

Rack (2U), (3.5-inch)

NOTE:

this option removes the optical media bay and 8 SFF drive bays

HP ProLiant DL385G6 Rack LFF CTO Chassis

Factory Integrated Model ships with:

(6) LFF Serial Attached SCSI (SAS) Drive Bays

NOTE:

LFF configuration does not support internal optical drive

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) PCI-Express Riser Cage One IEC Power cord Hot plug fans (fully redundant)

NOTE:

(4 fans one processor models; 6 fans two processor models)

Rack (2U), (3.5-inch)

572431-B21

573104-B21

Step 1A: Choose Storage Controller (must choose only one of the following)

Storage Controllers

NOTE:

RAID 6 requires purchase of HP Smart Array Advanced Pack (516471B21).

HP Smart Array P800/512 BBWC Controller

NOTE:

PCI Express.

HP Smart Array P212/256MB Controller

NOTE:

PCI Express.

HP Smart Array P212/Zero Memory Controller

NOTE:

PCI Express.

HP Smart Array P410/256MB Controller

NOTE:

PCI Express.

HP Smart Array P410/512MB with BBWC

NOTE:

PCI Express.

HP Smart Array P411/256MB Controller

NOTE:

PCI Express.

HP Smart Array P411/512MB BBWC

NOTE:

PCI Express.

381513-B21

462834-B21

462828-B21

462862-B21

462864-B21

462830-B21

462832-B21

Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)

Processors

Six-Core Processors

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 17

QuickSpecs

Configuration Information - Factory Integrated Models

HP ProLiant DL385 Generation 6

Base Memory

Power Supply Options

(Single or Redundant)

Storage Controllers

AMD Opteron™ Processor Model 2435 (2.6 GHz, 6MB Level 3 Cache, 75W), FIO

AMD Opteron™ Processor Model 2431 (2.4 GHz, 6MB Level 3 Cache, 75W), FIO

AMD Opteron™ Processor Model 2427 (2.2 GHz, 6MB Level 3 Cache, 75W), FIO

AMD Opteron™ Processor Model 2425HE (2.1 GHz, 6MB Level 3 Cache, 55W), FIO

NOTE:

If two processors are desired, select one xxxxxx-L21 and one xxxxxxB21. If selecting 570113-L21 and high performance features are desired, select High Performance Pack in Step 3 below.

NOTE:

DIMM banks are active only when the corresponding processor socket is populated.

2 GB REG PC2-6400 2 x 1 GB Kit

4 GB REG PC2-6400 2 x 2 GB Kit

8 GB REG PC2-6400 2 x 4 GB Kit

8 GB REG PC2-6400 2 x 4 GB Low Power Kit

16 GB REG PC2-5300 2 x 8 GB Dual Rank Kit

64 GB REG PC2-5300 8 x 8 GB Dual Rank Kit

NOTE:

P/N: 495605-B21 includes 8 DIMMs instead of 2. It is counted as 4 kits instead of 1.

NOTE:

Refer to HP Power Advisor when selecting a power supply for your configuration, offer new power options, including Common Slot Power Supplies. These power supplies come in multiple power ratings and higher efficiency levels to offer the Right Size solution to fit your configuration. This provides improved power delivery and the advantage of reclaiming lost power. Prior to making a power supply selection it is "highly recommended" that the "HP Power Advisor" is run to determine the right size power supply for your server configuration. The HP Power Advisor is located at: "

www.hp.com/go/hppoweradvisor

HP 460W CS HE Gold Power Supply

HP 750W CS HE Gold Power Supply

HP 1200W CS HE Silver Power Supply

HP 1200W-48V DC Common Slot Power Supply

NOTE:

DC power supplies contain a -48V DC power cord designed for in rack DC power rectifiers.

NOTE:

3 below.

256MB Cache Module FIO

NOTE:

Supported on HP Smart Array P410/Zero Memory Controller only.

512MB BBWC

Battery Kit upgrade

NOTE:

To enable BBWC on the 256MB Cache.

HP Smart Array P410/256 FIO Controller w/Battery

HP Smart Array P410/256MB Controller

HP Smart Array P410/512MB with BBWC

HP Smart Array P410/Zero Memory FIO Controller

HP Smart Array Advanced Pack No Media 1-Server license including 1yr 24x7 Technical Support

NOTE:

This part number can be used to purchase a single license or to order multiple licenses with a single activation key. Customers will receive a license

www.hp.co/go/hppoweradvisor

www.hp.com/go/proliant-energy-efficient

Storage Controller is NOT required if selecting P/N: 570121-B21 in Step

. Many HP ProLiant Servers now

" or

570113-L21

570115-L21

570117-L21

570119-L21

497763-B21

497765-B21

497767-B21

504351-B21

408855-B21

495605-B21

503296-B21

512327-B21

500172-B21

437573-B21

534108-B21

462967-B21

462969-B21

491195-B21

462862-B21

462864-B21

462860-B21

516471-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 18

QuickSpecs

HP ProLiant DL385 Generation 6

Configuration Information - Factory Integrated Models

entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Include one year of 24x7 HP Software Technical Support Services.

NOTE:

RAID 6 requires purchase of HP Smart Array Advanced Pack (516471B21).

Step 3: Choose Additional Factory Integratable Options

Insight Control suite

Performance Packs

HP Insight Control suite, No Media 1-Server License Factory-Integratable Option (FIO) including 1 year of 24x7 Technical Support and Updates

The HP ProLiant DL385 G6 performance packs are necessary to configure a HP ProLiant DL385 G6 Performance Model. HP ProLiant DL385 G6 Performance model includes the latest performance technologies and enterprise class availability features pre-installed for convenience and value. The performance pack includes a 2nd processor, two additional fans, HP Smart Array P410/512MB with BBWC, and a second 750W CS HE power supply. To complete the configuration of a Performance model, select the Slim SATA DVDRW Optical Drive Kit (481043-B21).

HP DL385G6 O2435 HPM FIO PERF PACK

582765-B21

570121-B21

Step 4: Choose Additional Options for Factory Integration

NOTE:

For additional options, please refer to the "Core Options" and "Additional Options" section below.

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 19

QuickSpecs

Core Options

NOTE:

Some options may not be available for factory integration. Please contact an HP sales representative for additional

information.

HP ProLiant DL385 G6 Unique Options

HP StorageWorks RDX160 Removable Disk Backup System DL Server Module

NOTE:

Mounts in DL385 G6 second drive cage slot (160GB of Disk Storage)

HP StorageWorks RDX320 Removable Disk Backup System DL Server Module

NOTE:

Mounts in DL385 G6 second drive cage slot (320GB of Disk Storage)

HP StorageWorks RDX500 Removable Disk Backup System DL Server Module

NOTE:

Mounts in DL385 G6 second drive cage slot (500GB of Disk Storage)

HP 8SFF CAGE 385 G6

NOTE:

Second drive cage installation replaces internal optical bay.

NOTE:

Second drive cage requires second controller or HP SAS Expander Card (468406-B21).

HP ProLiant DL385 Generation 6

AP724A

AP725A

AP726A

516914-B21

Processors

Memory

Optical Drives

Six-Core Processors

AMD Opteron™ Processor Model 2435 (2.6 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2431 (2.4 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2427 (2.2 GHz, 6MB Level 3 Cache, 75W)

AMD Opteron™ Processor Model 2425HE (2.1 GHz, 6MB Level 3 Cache, 55W)

NOTE:

Second processor kits include additional two fans.

2 GB REG PC2-6400 2 x 1 GB Kit

4 GB REG PC2-6400 2 x 2 GB Kit

8 GB REG PC2-6400 2 x 4 GB Kit

8 GB REG PC2-6400 2 x 4 GB Low Power Kit

16 GB REG PC2-5300 2 x 8 GB Dual Rank Kit

64 GB REG PC2-5300 8 x 8 GB Dual Rank Kit

HP Slim SATA DVD-ROM Optical Drive

HP Slim SATA DVD-RW Optical Drive

NOTE:

Included in performance models.

HP External USB CD/DVD R/RW Optical Drive

570113-B21

570115-B21

570117-B21

570119-B21

497763-B21

497765-B21

497767-B21

504351-B21

408855-B21

495605-B21

481041-B21

481043-B21

FS943AA

Hard Drives

NOTE:

The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.

NOTE:

Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

6G drives will run at 3G speed on the DL385 G6.

SAS Hot Plug SFF Enterprise (ENT) Drives

HP 300GB 6G SAS 10K SFF DP ENT HDD

HP 300GB 3G SAS 10K SFF DP ENT HDD

HP 146GB 6G SAS 15K SFF DP ENT HDD

HP 146GB 3G SAS 15K SFF DP ENT HDD

HP 146GB 6G SAS 10K SFF DP ENT HDD

HP 146GB 3G SAS 10K SFF DP ENT HDD

HP 72GB 6G SAS 15K SFF DP ENT HDD

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

507127-B21

492620-B21

512547-B21

504062-B21

507125-B21

418367-B21

512545-B21

Page 20

QuickSpecs

Core Options

HP ProLiant DL385 Generation 6

HP 72GB 3G SAS 15K SFF DP ENT HDD

HP 72GB 3G SAS 10K SFF DP ENT HDD

SAS Hot Plug 3.5" Enterprise (ENT) Drives

HP 600GB 6G SAS 15K 3.5" DP ENT HDD

HP 450GB 6G SAS 15K 3.5" DP ENT HDD

HP 450GB 3G SAS 15K 3.5" DP ENT HDD

HP 300GB 6G SAS 15K 3.5" DP ENT HDD

HP 300GB 3G SAS 15K 3.5" DP ENT HDD

HP 146GB 3G SAS 15K 3.5" DP ENT HDD

SAS Hot Plug SFF Midline (MDL) Drives

HP 500GB 6G SAS 7.2K SFF DP MDL HDD

SAS Hot Plug 3.5" Midline (MDL) Drives

HP 1TB 3G SAS 7.2K 3.5" DP MDL HDD

HP 750GB 3G SAS 7.2K 3.5" DP MDL HDD

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html

(Worldwide)

SATA Hot Plug SFF Midline (MDL) Drives

HP 500GB 3G SATA 7.2K 2.5in MDL HDD

HP 160GB 3G SATA 7.2K 2.5in MDL HDD

SATA Hot Plug 3.5” Midline (MDL) Drives

HP 1TB 3G SATA 7.2K 3.5" MDL HDD

HP 750GB 3G SATA 7.2K 3.5" MDL HDD

HP 500GB 3G SATA 7.2K 3.5" MDL HDD

HP 250GB 3G SATA 7.2K 3.5" MDL HDD

SATA Hot Plug SFF Entry (ETY) Drives

HP 250GB 3G SATA 5.4K SFF ETY HDD

HP 120GB 1.5G SATA 5.4K SFF ETY HDD

SATA Hot Plug 3.5" Entry (ETY) Drives

HP 160GB 3G SATA 7.2K 3.5" ETY HDD

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13021_div/13021_div.html

(Worldwide)

SATA Hot Plug Midline (MDL) Solid State Drives

HP 60GB 3G SATA 2.5in MDL 1y Wty SSD

HP 120GB 3G SATA 2.5in MDL 1y Wty SSD

SATA Hot Plug 3.5" Midline (MDL) Solid State Drives

HP 60GB 3G SATA 3.5in MDL 1y Wty SSD

HP 120GB 3G SATA 3.5in MDL 1y Wty SSD

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/13415_div/13415_div.html

(Worldwide)

418371-B21

384842-B21

516828-B21

516816-B21

454232-B21

516814-B21

416127-B21

384854-B21

507610-B21

461137-B21

461135-B21

507750-B21

530888-B21

454146-B21

458930-B21

458928-B21

458926-B21

460355-B21

458924-B21

458945-B21

572071-B21

572073-B21

570761-B21

570763-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 21

QuickSpecs

Core Options

HP ProLiant DL385 Generation 6

Communications

Riser Cage Options

Gigabit Ethernet adapters

HP NC112T PCIe Gigabit Server Adapter

HP NC360T PCI Express Dual Port Gigabit Server Adapter

HP NC364T PCI Express Quad Port Gigabit Server Adapter

HP NC373F PCI Express Multifunction Gigabit Server Adapter

HP NC373T PCI Express Multifunction Gigabit Server Adapter

HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter

10 Gigabit Ethernet adapters

HP NC522SFP Dual Port 10GbE Server Adapter

NOTE:

A minimum of 2 gigabytes (2 GB) of server memory is required per each NC522SFP adapter.

NOTE:

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.

NOTE:

Please see the QuickSpecs for additional information:

www.hp.com/go/ProLiantNICs

HP DL38X (1) x16 PCI-E riser kit

HP DL38X (1) x8, (2) x4 PCI-E riser kit

HP DL38X PCI-X riser kit (1) PCI-X, (1) x8, (1) x4)

HP DL38X (2) x8 Dual Port 10GbE Riser Kit

NOTE:

This riser card will support Qty 2 of 10Gbe NICs.

503746-B21

412648-B21

435508-B21

394793-B21

394791-B21

458492-B21

468332-B21

494323-B21

500580-B21

494322-B21

494326-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 22

QuickSpecs

Additional Options

HP ProLiant DL385 Generation 6

Power Supplies

HP Insight Control suites

HP 460W CS HE Gold Power Supply

HP 750W CS HE Gold Power Supply

HP 1200W CS HE Silver Power Supply

HP 1200W-48V DC Common Slot Power Supply

NOTE:

DC power supplies contain a -48V DC power cord designed for in rack DC power rectifiers.

HP Insight Control suite

HP Insight Control Environment, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates

NOTE:

Customer will receive a license entitlement certificate, which must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.

HP Insight Control Management Software Media Kit

NOTE:

Insight Software DVD media without licenses. Contains HP Systems Insight Manager and Insight software products and components licensed by the Insight Control suite. Uses an integrated installer to perform quick and accurate software installation and updates.

NOTE:

For additional license kits please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html

HP Insight Control suite for Linux (ICE-LX)

HP Insight Control suite for Linux, Media pack (DVD) - No licenses included

NOTE:

This optional Media pack DVD contains the ISO image for HP Insight Control Environment for Linux, HP System Insight Manager, HP Insight Power Manager, HP Insight Virtual Machine Management software, and an integrated installer. Servers must be acquired separately.

NOTE:

This Media pack is optional because the latest ISO image and latest updates may be downloaded at no cost from: (click on Download button).

HP Insight Control suite for Linux, No Media, 1-Server license, including one year of 24x7 Technical Support and Updates

NOTE:

This part number can be used to purchase one (1) license with a single activation key. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.

NOTE:

One certificate is shipped for each license.

NOTE:

For additional License Kits, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/13019_div/13019_div.html

HP Integrated Lights-Out Advanced

HP Integrated Lights-Out Advanced, No Media, 1-Server License, including 1 year of 24x7 Technical Support and Updates

NOTE:

This license allows 1 server to be deployed and managed via HP iLO Advanced. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service

NOTE:

For additional license kits, including electronic delivery options, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html

HP Insight Rapid Deployment software

HP Insight Rapid Deployment software No Media 1-Server License including 1 year of 24x7 Technical Support and Updates

http://www.hp.com/go/ice-linux

503296-B21

512327-B21

500172-B21

437573-B21

452148-B22

436222-B21

464422-B22

464423-B22

512485-B21

452151-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 23

QuickSpecs

Additional Options

NOTE:

This license allows 1 server to be deployed and managed via RDP. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support Service

NOTE:

For additional license kits, including electronic delivery options, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.html

HP ProLiant DL385 Generation 6

Drive Cage Options

Security

Storage Controllers

HP 8SFF CAGE 380G6

HP Trusted Platform Module Option Kit

SAS Controllers

HP Smart Array P800 Controller

HP Smart Array P800/512 BBWC Controller

HP Smart Array P212 Controller

HP Smart Array P212/Zero Memory Controller

HP Smart Array P212/256 MB Controller

HP Smart Array P411 Controller

HP Smart Array P411/256 MB Controller

HP Smart Array P411/512 MB with BBWC Controller

Optional Upgrades

256 MB Cache Module

NOTE:

Supported on HP Smart Array P212 Controller and HP Smart Array P410/Zero Memory Controller only.

512MB BBWC

Battery Kit upgrade

NOTE:

To enable BBWC on the 256MB cache.

HP Smart Array Advanced Pack No Media 1-Server license including 1yr 24x7 Technical Support

NOTE:

This part number can be used to purchase a single license or to order multiple licenses with a single activation key. Customers will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Include one year of 24x7 HP Software Technical Support Services.

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18000.www1.hp.com/products/quickspecs/12616_div/12616_div.html

(Smart Array P800 Controller)

http://h18000.www1.hp.com/products/quickspecs/13203_div/13203_div.html

(Smart Array P212 Controller)

http://h18000.www1.hp.com/products/quickspecs/13202_div/13202_div.html

(Smart Array P411 Controller)

http://h18000.www1.hp.com/products/quickspecs/13200_div/13200_div.html

(Smart Array Advanced Pack)

SAS Controller Options

HP SAS Expander Card

Mini SAS 4i to Mini SAS 4i, 8.00"

NOTE:

BTO Models will require Mini SAS 4i to Mini SAS 4i, 8.00" (496012-B21), included on CTO built models.

516914-B21

488069-B21

381513-B21

462828-B21

462834-B21

462830-B21

462832-B21

462968-B21

462967-B21

462969-B21

516471-B21

468406-B21

496012-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 24

QuickSpecs

Additional Options

NOTE:

Please see the QuickSpecs for Technical Specifications and additional information:

http://h18004.www1.hp.com/products/quickspecs/13232_div/13232_div.html

(SAS Expander Card)

SAS HBA

HP SC08Ge Host Bus Adapter

NOTE:

Please see the following QuickSpecs for additional information:

http://h18004.www1.hp.com/products/quickspecs/13082_div/13082_div.html

(SC08Ge HBA)

SCSI HBA

HP SC11Xe Host Bus Adapter

NOTE:

Recommended HBA for SCSI tape drive connect.

NOTE:

Please see the following QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/12566_div/12566_div.html

(SC11Xe HBA)

HP ProLiant DL385 Generation 6

488765-B21

412911-B21

HPC Specific Options

Tape Storage

HP InfiniBand 4X DDR Conn-X PCI-E G2 Dual Port HCA

HP InfiniBand 4X DDR PCI-E 0 Memory Dual Port HCA

HP InfiniBand 4X DDR PCI-E Dual Port HCA

HP InfiniBand 4X DDR PCI-E Dual Port Host Adapter

Tape Drives

USB Rack-Mount Tape Solutions

HP StorageWorks 1U USB Rack-Mount Kit with one DAT 160 USB Tape Drive

NOTE:

Pre-configured with one DAT 160 USB tape drive.

SAS Rack-Mount Tape Solutions

NOTE:

HP recommends purchasing the HP Smart Array P212 (462828-B21) for a dedicated SAS HBA for tape.

HP StorageWorks 1U SAS Rack-Mount Kit with one LTO-4 Ultrium 1760

NOTE:

Pre-configured with one LTO-4 Ultrium 1760 SAS tape drive.

HP StorageWorks 1U SAS Rack Mount Kit

NOTE:

Supports up to (2) half-height SAS tape drives.

HP StorageWorks LTO-2 Ultrium 448 SAS Internal Tape Drive

NOTE:

Mounts inside the 1U SAS Rack-Mount Kit (AE459A).

HP StorageWorks LTO-3 Ultrium 920 SAS Internal Tape Drive

NOTE:

Mounts inside the 1U SAS Rack-Mount Kit (AE459A).

NOTE:

For an up-to-date listing of the latest O/S and software support details for HP tape drives, please visit:

HP StorageWorks 1/8 G2 Tape Autoloader

HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader

HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 SAS Autoloader

HP StorageWorks 1/8 G2 Tape Autoloader Rack Kit

NOTE:

Required to install the 1/8 G2 Autoloaders in a standard 19-inch rack; includes rails and rackmount instructions.

NOTE:

Please reference the Tape Autoloader QuickSpecs at:

http://www.hp.com/go/automation

complete solution.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Tape Library

HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library

http://www.hp.com/go/connect

for additional information needed to create a

483514-B21

483513-B21

448397-B21

409376-B21

AG703A

EH946A

AE459A

DW085A

EH847A

AK377A

AH558A

AH166A

AK378A

AH559A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 25

QuickSpecs

Additional Options

HP ProLiant DL385 Generation 6

Disk-Based Backup

HP StorageWorks MSL4048 Tape Library

HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Tape Library

HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library

NOTE:

Please reference the MSL Tape Library QuickSpecs at:

http://www.hp.com/go/automation

complete solution.

RDX Removable Disk Backup

HP StorageWorks RDX500 External Removable Disk Backup System

NOTE:

Please see the HP RDX Removable Disk Backup System QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/13036_div/13036_div.html

D2D Backup

HP StorageWorks D2D2502i Backup System

NOTE:

2 TB raw capacity/1.5 TB useable capacity.

HP StorageWorks D2D2504i Backup System

NOTE:

4 TB raw capacity/3 TB useable capacity.

NOTE:

Please see the HP D2D Backup Systems QuickSpecs for additional information:

http://www.hp.com/go/d2d

for additional information needed to create a

AK380A

AH560A

AJ935A

EJ001A

EJ002A

StorageWorks Options

StorageWorks Fibre Channel HBA

NOTE:

For the complete listing of Fibre Channel Host Bus Adapters for Windows 2000, Windows Server 2003 and Linux, please see:

http://h18006.www1.hp.com/storage/saninfrastructure/hba.html

Brocade Fibre Channel HBAs

HP StorageWorks 81B PCI-e FC HBA Single Port

HP StorageWorks 82B PCI-e FC HBA Dual Port

HP StorageWorks 41B 4Gb PCI-e FC HBA

HP StorageWorks 42B 4Gb Dual-Port PCI-e FC HBA

Emulex Fibre Channel HBAs

HP StorageWorks 81E PCI-e FC HBA Single Port

HP StorageWorks 82E PCI-e FC HBA Dual Port

HP StorageWorks FC2142 4Gb PCI-e HBA

HP StorageWorks FC2242 Dual Channel 4Gb PCI-e HBA

QLogic Fibre Channel HBAs

HP StorageWorks 81Q PCI-e FC HBA Single Port

HP StorageWorks 82Q PCI-e FC HBA Dual Port

HP StorageWorks FC1142 4Gb PCI-e HBA

HP StorageWorks FC1242 Dual Channel 4Gb PCI-e HBA

AP769A

AP770A

AP767A

AP768A

AJ762A

AJ763A

A8002A

A8003A

AK344A

AJ764A

AE311A

AE312A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 26

QuickSpecs

Additional Options

HP ProLiant DL385 Generation 6

HP StorageWorks Modular Smart Array

MSA SAN Storage Arrays

HP StorageWorks 50 Modular Smart Array

NOTE:

Please see the Modular Smart Array 50 QuickSpecs for additional information including configuration steps and additional options needed for a complete solution at:

http://h18000.www1.hp.com/products/quickspecs/12245_div/12245_div.html

(Worldwide)

HP StorageWorks 60 Modular Smart Array

NOTE:

information including configuration steps and additional options needed for a complete solution at:

http://h18000.www1.hp.com/products/quickspecs/12627_div/12627_div.html

HP StorageWorks 70 Modular Smart Array

NOTE:

information including configuration steps and additional options needed for a complete solution at:

http://h18000.www1.hp.com/products/quickspecs/12652_div/12652_div.html

(Worldwide)

HP 2012sa Single Controller Modular Smart Array

HP 2012sa Dual Controller Modular Smart Array

NOTE:

options and configuration information at:

http://h18000.www1.hp.com/products/quickspecs/13045_div/13045_div.html

(Worldwide)

Please see the Modular Smart Array 60 QuickSpecs for additional

Please see the Modular Smart Array 70 QuickSpecs for additional

Please see the Modular Smart Array 2000sa QuickSpecs for additional

364430-B21

418408-B21

418800-B21

AJ753A

AJ752A

Uninterruptible Power Systems - Rack

HP Rack and Rack Options

HP Rack-mountable UPS

HP R1500 G2 UPS

HP, R1.5kVA UPS, 1U, NA

HP, R1.5kVA UPS, 1U, INTL

HP, R1.5kVA UPS, 1U, JPN/TW

NOTE:

Please see the QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/12507_div/12507_div.html

(Worldwide)

Rack 5000 series

HP 5642 Rack-Unassembled

NOTE:

Please see the QuickSpecs for additional information:

http://h18000.www1.hp.com/products/quickspecs/12074_div/12074_div.html

(Worldwide)

NOTE:

For additional information regarding Rack Cabinets, please see the following URL:

Rack Options

Console switches (KVM)

Server console switch 0x2x8

(Graphite Metallic)

http://www.hp.com/go/rackandpower

AF419A

AF418A

AF421A

358254-B21

AF616A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 27

QuickSpecs

Additional Options

HP ProLiant DL385 Generation 6

USB Options

Service and Support Offerings

(HP Care Pack Services)

HP USB 04 Standard Keyboard

HP 4GB USB Flash Media Key Kit

NOTE:

Blank USB media device is supported for use with ProLiant iVirtualization. USB media must be installed in the internal slot of the ProLiant server. Learn more at:

Hardware Services On-site Service

4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

Hardware Services 6-Hour Call to Repair On-site Service

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

Installation & Start-up Services

Hardware Installation, Electronic

Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic

Installation and Startup for Essentials Rapid Deployment Pack, Electronic

Support Plus

Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic

Support Plus 24

Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

Onsite HW support 24x7, 4hr response and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

Onsite HW support 24x7, 4hr response and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

NOTE:

For more information, customer/resellers can contact:

http://www.hp.com/services/carepack

http://www.hp.com/go/proliantvirtualization

DT528A#ABA

580385-B21

U4544E

U4545E

U4546E

U4554E

U4555E

U5683E

U4556E

U4557E

U6312E

U8334E

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 28

QuickSpecs

HP ProLiant DL385 Generation 6

Memory

NOTE:

Memory configurations listed do not apply to "Factory Integrated Models".

HP ProLiant DL385 G6 Base Models

Standard Memory

8 GB REG PC2-6400 2 x 4 GB installed (Base Model)

Upgrading Memory and Memory Interleaving

DIMMs must be installed in identical pairs. Bank interleaving is automatically enabled on a processor node under the following conditions:

Four single ranked DIMMs populated per node (4 x 1 GB or 4 x 2 GB for example) yields 2-way bank interleaving. Two dual ranked DIMMs populated per node (2 x 4 GB or 2 x 8 GB for example) yields 2-way bank interleaving. Four dual ranked DIMMs populated per node (4 x 4 GB or 4 x 8 GB for example) yields 4-way bank interleaving. If single and dual ranked DIMMs are mixed on the same node, bank interleaving will not be enabled. If single and dual ranked DIMMs are mixed on the same node, bank interleaving will not be enabled.

Node interleaving can be configured via RBSU if both processors have the same memory footprint and it is independent of bank interleaving.

DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the banks furthest away from each processor.

Standard Memory Plus Optional Memory

Up to 56 GB memory is available with the standard memory and the optional installation of 6 x 8GB PC2-5300 DIMMs.

Standard Memory Replaced with Optional Memory

Up to 64 GB of memory is available with the removal of the standard memory and the optional installation of 8 x 8 GB PC2-5300 DIMMs.

NOTE:

Chart does not represent all possible configurations.

NOTE:

DIMM banks are active only when the corresponding processor socket is populated.

Slot

Bank A

Config

Standard

Optional

Maximum

HP ProLiant DL385 G6 Performance Models

Standard Memory

16 GB REG PC2-6400 4 x 4 GB installed

Upgrading Memory and Memory Interleaving

DIMMs must be installed in identical pairs. Bank interleaving is automatically enabled on a processor node under the following conditions:

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 4GB 4GB 8GB 8GB 8GB 8GB 8GB 8GB 4GB 4GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB

Bank

Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty

Bank C Bank D

Bank E

Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty

Bank F

Bank G

Bank H

Total

8GB 56GB 64GB

Four single ranked DIMMs populated per node (4 x 1 GB or 4 x 2 GB for example) yields 2-way bank interleaving.

1. Two dual ranked DIMMs populated per node (2 x 4 GB or 2 x 8 GB for example) yields 2-way bank interleaving.

2. Four dual ranked DIMMs populated per node (4 x 4 GB or 4 x 8 GB for example) yields 4-way bank interleaving.

3. If single and dual ranked DIMMs are mixed on the same node, bank interleaving will not be enabled.

Node interleaving can be configured via RBSU if both processors have the same memory footprint and it is independent of bank interleaving.

DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the banks furthest away from each processor.

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 29

QuickSpecs

HP ProLiant DL385 Generation 6

Memory

Standard Memory Plus Optional Memory

Up to 112 GB memory is available with the standard memory and the optional installation of 12 x 8GB PC2-5300 DIMMs.

Standard Memory Replaced with Optional Memory

Up to 128 GB of memory is available with the removal of the standard memory and the optional installation of 16 x 8 GB PC2-5300 DIMMs.

NOTE:

Chart does not represent all possible configurations.

Slot

Config

Standard

Optional

Maximum

Bank A

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 4GB 4GB 8GB 8GB 8GB 8GB 8GB 8GB 4GB 4GB 8GB 8GB 8GB 8GB 8GB 8GB 4GB 4GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB

Bank

Empty Empty Empty Empty Empty Empty

Bank C Bank D

Bank E

4GB 4GB

Bank F

Empty Empty Empty Empty Empty Empty

Bank G

Bank H

Total

16GB 112GB 128GB

Following are memory options available from HP:

2 GB REG PC2-6400 2 x 1 GB Kit

4 GB REG PC2-6400 2 x 2 GB Kit

8 GB REG PC2-6400 2 x 4 GB Kit

8 GB REG PC2-6400 2 x 4 GB Low Power Kit

16 GB REG PC2-5300 2 x 8 GB Dual Rank Kit

497763-B21

497765-B21

497767-B21

504351-B21

408855-B21

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 30

QuickSpecs

Storage

1-8

1-16

HP ProLiant DL385 Generation 6

Eight SFF SAS hot plug hard drive bays

Sixteen SFF SAS hot plug hard drive bays

Drive Support

Removable Media

Slim SATA DVD RW Optical Drive

NOTE:

Included in

performance models.

Slim SATA DVD-ROM Optical Drive

Quantity

Supported

Only 1 available

removable media bay

Only 1 available

removable media bay

Position

Supported

Slimline bay

Controller

Integrated SATA

NOTE:

drive.

1-6

Six LFF SAS hot plug hard drive bays

NOTE:

drive.

This configuration does not support optical

Hard Drives

NOTE:

Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

6G drives will run at 3G speed on the DL385 G6.

SAS Hot Plug SFF Enterprise (ENT) Drives

300GB 6G SAS 10K DP 300GB 3G SAS 10K DP 146GB 6G SAS 15K DP 146GB 6G SAS 10K DP 146GB 3G SAS 15K DP 146GB 3G SAS 10K DP 72GB 6G SAS 15K DP 72GB 3G SAS 15K DP 72GB 3G SAS 10K DP

SAS Hot Plug 3.5" Enterprise (ENT) Drives

600GB 6G SAS 15K DP 450GB 6G SAS 15K DP 450GB 3G SAS 15K DP

Quantity

Supported

Up to 16

Quantity

Supported

Up to 6

Position

Supported

1-8

1-16

NOTE:

Depending on

Model

Position

Supported

1-6

Controller

HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller

Controller

HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/256 MB Controller

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 31

QuickSpecs

Storage

HP ProLiant DL385 Generation 6

300GB 6G SAS 15K DP 300GB 3G SAS 15K DP 146GB 3G SAS 15K DP

SAS Hot Plug SFF Midline (MDL) Drives

500GB 6G SAS 7.2K DP

SAS Hot Plug 3.5" Midline (MDL) Drives

1TB 3G SAS 7.2K DP 750GB 3G SAS 7.2K DP

Quantity

Supported

Up to 16

Quantity

Supported

Up to 6

Position

Supported

1-8

1-16

NOTE:

Depending on

Model

Position

Supported

1-6

HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller

Controller

SATA Hot Plug SFF Midline (MDL) Drives

500GB 3G SATA 7.2K 160GB 3G SATA 7.2K

SATA Hot Plug 3.5" Midline (MDL) Drives

1TB 3G SATA 7.2K 750GB 3G SATA 7.2K 500GB 3G SATA 7.2K 250GB 3G SATA 7.2K

Quantity

Supported

Up to 16

Quantity

Supported

Up to 6

Position

Supported

1-8

1-16

NOTE:

Depending on

Model

Position

Supported

1-6

Controller

SATA Hot Plug SFF Entry (ETY) Drives

Quantity

Supported

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Position

Supported

Controller

Page 32

QuickSpecs

Storage

HP ProLiant DL385 Generation 6

250GB 3G SATA 5.4K 120GB 1.5G SATA 5.4K

SATA Hot Plug 3.5" Entry (ETY) Drives

160GB 3G SATA 7.2K

SATA Hot Plug Midline (MDL) Solid State Drives

60GB 3.0G SATA SSD 120GB 3.0G SATA SSD

Up to 16

Quantity

Supported

Up to 6

Quantity

Supported

Up to 16

1-8

1-16

NOTE:

Depending on

Model

Position

Supported

1-6

Position

Supported

1-8

1-16

Controller

SATA Hot Plug 3.5" Midline (MDL) Solid State Drives

60GB 3.0G SATA SSD 120GB 3.0G SATA SSD

Quantity

Supported

Up to 6

Position

Supported

1-6

Controller

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 33

QuickSpecs

Storage

External Storage

Quantity

Supported

50 Modular Smart Array

60 Modular Smart Array

70 Modular Smart Array

HP 2000sa Modular Smart Array Controller

Up to 4

Up to 8

Up to 4

Position

Supported

External

HP ProLiant DL385 Generation 6

Host Controller or Adapter

HP Smart Array P800/512 BBWC Controller

HP Smart Array P800/512 BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 BBWC Controller

HP Smart Array P212/Zero Memory Controller HP Smart Array P212/256 MB Controller

HP Smart Array P800/512 BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller

HP SC08Ge Host Bus Adapter

Maximum Storage Capacity

Internal

External

Total

Tape and Disk-Based Backup

NOTE:

For a complete listing of compatible tape and disk-based backup offerings, please visit:

HP StorageWorks SCSI Tape Drives, External

LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 960 LTO-3 Ultrium 920 LTO-4 Ultrium 1760 LTO-4 Ultrium 1840 DAT 40 DAT 72 DAT 160 1U Rack-Mount Kit 3U Rack-Mount Kit

HP StorageWorks USB Tape Drives, External

DAT 40 USB DAT 72 USB DAT 160 USB 1U Rack-Mount Kit

HP StorageWorks SAS Tape Drives, External

DAT 160 SAS LTO-2 Ultrium 448 SAS LTO-3 Ultrium 920 SAS LTO-4 Ultrium 1760 SAS LTO-4 Ultrium 1840 SAS

- (with MSA70)

8.0TB (16x 500GB SAS/SATA)

12.5TB (250 x 500GB SAS/SATA SFF)

20.5TB

Position

Supported

External

Controller

HP SC11Xe Host Bus Adapter

USB 2.0 Port

HP Smart Array P212/Zero Memory Controller

www.hp.com/go/connect

Controller Part

Number

412911-B21

462828-B21

N/A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 34

QuickSpecs

HP ProLiant DL385 Generation 6

Storage

1U Rack-Mount Kit 3U Rack-Mount Kit

HP StorageWorks SCSI Tape Automation, External

DAT 72x10 Autoloader 1/8 G2 Tape Autoloader MSL2024 MSL4048 MSL8096 MSL6000

HP StorageWorks SAS Tape Automation, External

1/8 G2 Autoloader MSL2024 MSL4048

HP StorageWorks Fibre Tape Automation, External

MSL2024 MSL4048 MSL8096 MSL6000

HP StorageWorks RDX Removable Disk Backup System, External

RDX160 RDX320 RDX500

HP StorageWorks D2D Backup Systems

D2D120 D2D130 D2D2500i D2D4000i

External

HP SC11Xe Host Bus Adapter

HP Smart Array P212/Zero Memory Controller

Please consult the EBS connectivity matrix at:

http://www.hp.com/go/ebs

USB 2.0 Port

Embedded Network Controller

for detailed connectivity information.

412911-B21

462828-B21

N/A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 35

QuickSpecs

Power Specifications

HP ProLiant DL385 Generation 6

HP 460W Power Supply Part Number - AC 460W PSU

Input Voltage Range (Vrms)

Frequency Range (Nominal) (Hz)

Nominal Input Voltage (Vrms)

Maximum Rated Output Wattage

Nominal Input Current (A rms)

Maximum Rated Input Wattage Rating (Watts)

Maximum Rated VA (Volt-Amp)

Efficiency (%) at Max. Rated Output Wattage

Power Factor Leakage Current (mA) Maximum Inrush Current

(A peak) Maximum Inrush Current

duration (mS) Maximum British

Thermal Unit Rating (BTU-Hr)

HP 750W Power Supply Part Number - AC 750W PSU

Input Voltage Range (Vrms)

Frequency Range (Nominal) (Hz)

Nominal Input Voltage (Vrms)

Maximum Rated Output Wattage

Nominal Input Current (A rms)

Max Rated Input Wattage Rating (Watts)

Max. Rated VA (VoltAmp)

Efficiency (%)at Max. Rated Output Wattage

Power Factor Leakage Current (mA) Max. Inrush Current

(A peak) Max. Inrush Current

duration (mS)

503296-B21

100 to 240

50/60

100 120 208 200 220 230 240

460 460 460 460 460 460 460

5.5 4.5 2.6 2.5 2.4 2.3 2.2

526 520 505 505 503 503 503

548 542 527 527 524 524 524

87.5 88.5

0.97 0.97 0.97 0.97 0.97 0.97 0.97

0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30

20 20 20 20 20 20 20

1794 1773 1725 1725 1715 1715 1715

512327-B21

100 to 240

50/60

100 120 208 200 220 230 240

750 750 750 750 750 750 750

8.9 7.4 4.3 4.1 3.9 3.7 3.6

857 847 824 825 820 820 820

894 884 859 859 854 854 854

87.5 88.5

0.97 0.97 0.97 0.97 0.97 0.97 0.97

0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30

20 20 20 20 20 20 20

91 91

91.5 91.5 91.5

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 36

QuickSpecs

Power Specifications

HP ProLiant DL385 Generation 6

Maximum British Thermal Unit Rating (BTU-Hr)

HP 1200W Power Supply Part Number - AC

Operational Input Voltage Range (Vrms)

Frequency Range (Nominal) (Hz)

Nominal Input Voltage (Vrms)

Maximum Rated Output Wattage

Nominal Input Current (A rms)

Max Rated Input Wattage Rating (Watts)

Max. Rated VA (VoltAmp)

Efficiency (%)at Max. Rated Output Wattage

Power Factor Leakage Current (mA) Max. Inrush Current

(A peak) Max. Inrush Current

duration (mS) Maximum British

Thermal Unit Rating (BTU-Hr)

HP 1200W PSU 48VDC Input Part Number

Input Voltage Range (DCV)

Frequency Range (Nominal) (Hz)

Nominal Input Voltage (Vrms)

Maximum Rated Output Wattage

Nominal Input Current (A rms)

Max Rated Input Wattage Rating (Watts)

Max. Rated VA (VoltAmp)

Efficiency (%)at Max. Rated Output Wattage

Power Factor Leakage Current (mA)

2925 2892 2812 2812 2797 2797 2797

500172-B21

100 to 240

50/60

100 120 208 200 220 230 240

800 900 1200 1200 1200 1200 1200

9.7 9.0 7.0 6.8 6.4 9.1 5.9

930 1034 1348 1348 1348 1348 1348

970 1079 1406 1406 1406 1406 1406

86 87 89 89 89 89 89

0.97 0.97 0.97 0.97 0.97 0.97 0.97

0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30

20 20 20 20 20 20 20

3174 3530 4600 4600 4600 4600 4600

437573-B21

36-72

36 48 72

1200 1200 1200

38 28 19

1380 1350 1365

87 89 88

N/A N/A N/A N/A N/A N/A

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 37

QuickSpecs

Power Specifications

HP ProLiant DL385 Generation 6

Max. Inrush Current (A peak)

Max. Inrush Current duration (mS)

Maximum British Thermal Unit Rating (BTU-Hr)

NOTE:

To review typical system power ratings use the HP Power Advisor which is available online located at url:

www.hp.com/go/proliant-energy-efficient

Click on "ProLiant Servers" Click on the Server of interest. Example: DL385 G6 Click on: "Power Calculator" link. (You may need to scroll down to see it)

20 25 35

1 1 3

4713 4610 4662

www.hp.com/go/hppoweradvisor

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 38

QuickSpecs

Technical Specifications

HP ProLiant DL385 Generation 6

System Unit

Dimensions

(with bezel)

Weight

Input Requirements

(per power supply)

BTU Rating

Power Specifications

Power Supply Output

(per power supply)

(H x W x D)

(approximate)

3.38 x 17.54 x 27.25 in (8.59 x 44.54 x 69.98 cm)

Maximum (all hard drives, power supply, and processor installed)

Minimum (one hard drive, power supply, and processor installed)

Rated Line Voltage

Rated Input Current

Rated Input Frequency

Rated Input Power

Maximum

NOTE:

To review typical system power ratings use the HP Power Advisor which is available online located at url:

energy-efficient

Rated Steady-State Power

Maximum Peak Power

www.hp.com/go/hppoweradvisor

60 lb (27.22 kg)

47.18 lb (20.41 kg)

100 to 120 VAC 200 to 240 VAC

For 1200 W Power Supply: 10 A (at 100 VAC),

4.9 A (at 200 VAC) For 750 W Power Supply:

8.9 A (at 100 VAC),

4.3 A (at 200 VAC) For 460 W Power Supply:

5.5 A (at 100 VAC),

2.6 A (at 200 VAC)

50 to 60 Hz

For 1200 W Power Supply: 930 W (at 100 VAC), 1348 W (at 200 VAC) For 750 W Power Supply: 857 W (at 100 VAC), 824 W (at 200 VAC) For 460 W Power Supply: 526 W (at 100 VAC), 505 W (at 200 VAC)

For 1200 W Power Supply: 3530 BTU/hr (at 100 VAC), 4600 BTU/hr (at 200 VAC) For 750 W Power Supply: 2925 BTU/hr (at 100 VAC), 2812 BTU/hr (at 200 VAC) For 460 W Power Supply: 1794 BTU/hr (at 100 VAC), 1725 BTU/hr (at 200 VAC)

www.hp.com/go/proliant-

For 1200 W Power Supply: 800 W (at 100 VAC), 900 W (at 120 VAC), 1200 W (at 200 to 240 VAC) For 750 W Power Supply: 750 W (at 100 to 120 VAC), 750 W (at 200 to 240 VAC) For 460 W Power Supply: 460 W (at 100 to 120 VAC), 460 W (at 200 to 240 VAC)

For 1200 W Power Supply:

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 39

QuickSpecs

Technical Specifications

System Inlet Temperature

Relative Humidity

(non-condensing)

Altitude

Acoustic Noise

Emissions Classification (EMC)

HP ProLiant DL385 Generation 6

800 W (at 100 VAC),

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA

74) and declared in accordance with ISO 9296 (ECMA 109).

Idle

LWAd

LpAm

Operating

LWAd

LpAm

FCC Rating

Normative Standards

900 W (at 120 VAC), 1200 W (at 200 to 240 VAC) For 750 W Power Supply: 750 W (at 100 to 120 VAC), 750 W (at 200 to 240 VAC) For 460 W Power Supply: 460 W (at 100 to 120 VAC), 460 W (at 200 to 240 VAC)

10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed. System performance may be reduced if operating with a fan fault or above 30°C (86°F).

-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).

10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, noncondensing.

5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing.

3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

6.3 B

47 dBA

6.3 B

47 dBA

Class A

CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 40

QuickSpecs

Technical Specifications

HP ProLiant DL385 Generation 6

NOTE:

Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.

Smart Array P410 Controller

Disk Drive and Enclosure Interface Transfer rate

SAS Connectors

Cache Memory Speed

Server Interface

SAS Speed

Cache Memory

Logical Drives Supported

Maximum Logical Drive Capacity

Host Memory Addressing

RAID Support

6Gb/s SAS (Serial Attached SCSI)

3Gb/s SATA (Serial ATA)

2 internal (Mini-SAS) x8 wide port connectors

DDR2-800MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum bandwidth.

x8 5G PCIe 2.0 provides 4GB/s maximum bandwidth

x8 6G SAS provides 4.8GB/s maximum bandwidth

40-bit 256MB ECC protected cache (72-bit 512MB BBWC module upgrades available); transportable with battery-backed upgrade

Up to 64 logical drives

Greater than 2TB

64-bit, supporting greater than 4GB server memory space

RAID 6, 6+0 (Advanced Data Guarding)

NOTE:

The minimum of 256 MB cache, battery kit, and Smart Array

Advanced Pack License Key upgrade is required to enable RAID 6, 6+0

RAID 5, 5+0 (Distributed Data Guarding)

NOTE:

The 256 MB is required to enable RAID 5, 5+0 support of the

Smart Array P410i

RAID 1+0 (Striping & Mirroring)

RAID 0 (Striping)

Two HP NC382i Dual Port Multifunction Gigabit Server Adapters

Network Interface

Compatibility

Data Transfer Method

Network Transfer Rate

Connector

Cable Support

10Base-T/100Base-TX/1000Base-TX

IEEE 802.3 10Base-T

IEEE 802.3ab 1000Base-T

IEEE 802.3u 100Base-TX

PCI Express, four lanes (x4)

10Base-T (Half-Duplex)

10Base-T (Full-Duplex)

100Base-TX (HalfDuplex)

100Base-TX (FullDuplex)

1000Base-TX (Half and Full-Duplex)

Two RJ-45

10Base-T

100Base-TX

1000BaseTX

10 Mb/s

20 Mb/s

100 Mb/s

200 Mb/s

2000Mb/s

Categories 3, 4 or 5 UTP; up to 328 ft (100 m)

Category 5 or higher UTP; up to 328 ft (100 m)

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 41

QuickSpecs

Technical Specifications

HP ProLiant DL385 Generation 6

Environment-friendly Products and Approach

The information contained herein is subject to change without notice. Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. AMD, the AMD Arrow logo, AMD Opteron™, and combinations thereof, are trademarks of Advanced Micro Devices, Inc.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

End-of-life Management and Recycling

Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

http://www.hp.com/go/green http://www.hp.com/go/green

http://www.hp.com/go/green

. To recycle your product, or contact your nearest HP

. These

For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.

DA - 13360 Worldwide QuickSpecs — Version 9 — 10.23.2009

Page 42

HP DL385 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

HPC Interconnects

Models

Configuration Information - Factory Integrated Models

Core Options

Additional Options

Memory

Storage

Power Specifications

Technical Specifications
