QuickSpecs

Overview

HP ProLiant DL380 Generation 6
Front View:
1.
Quick removal access panel
2.
Intel Quad-Core Processor (Performance models include two processors)
3.
Second Intel Quad-Core Processor
4.
5.
Hot-plug fans, full N+1 redundancy
6.
Slim Optical Bay (SATA DVD-RW Optical Drive included on Performance models)
7.
UID LED button
8.
Health LED
9.
Power On/Standby button and system power LED
10.
USB connectors (2)
11.
Video connector
12.
Systems Insight Display
Rear View:
1.
PCI slot 5
2.
PCI slot 6
3.
PCI slot 4
4.
PCI slot 2
5.
PCI slot 3
6.
PCI slot 1
7.
Power supply 2
8.
Power supply 1
9.
USB connectors (2)
10.
Video connector
11.
NIC 1 connector
12.
NIC 2 connector
13.
Mouse connector
14.
Keyboard connector
15.
Serial connector
16.
iLO2 connector
17.
NIC 3 connector
18.
NIC 4 connector
At A Glance
The HP ProLiant DL380 G6 Server continues to deliver on its heritage of engineering excellence with increased flexibility and performance, enterprise-class uptime and manageability, 2-socket Intel Xeon performance, and 2U density for a variety of applications.
Processors
Memory
Storage Controller
: Up to 2 Quad-Core or Dual-Core Intel® Xeon® processor 5500 sequence) Intel® 5520 Chipset
: Up to 192GB, using PC3-8500R DDR3 Registered (RDIMM) memory, operating at 800MHz when fully populated at 2 DIMMs per Channel in 12 slots
NOTE:
If only one processor is installed, only half the DIMM slots are available
Up to 24GB, using PC3-10600E DDR3 Unbuffered (UDIMM) memory, operating at 1066MHz when fully populated at 2 DIMMs per Channel in 12 slots Two DIMMs Per Channel at 1333MHz supported with ROM update via ROM Based Setup Utility (RBSU) for 1333MHz RDIMMs. UDIMM support is only on 12-slot servers.
: Entry Models: HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0) Base Models: HP Smart Array P410i/256 MB Controller (RAID 0/1/1+0/5/5+0)
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 1
Page 2
QuickSpecs
Overview
Performance Models: HP Smart Array P410i/512 MB BBWC Controller (RAID 0/1/1+0/5/5+0) High Efficiency: HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0) Available upgrades: 256MB, 512MB with BBWC, Battery kit upgrade (for BBWC), and Smart Array Advanced Pack (SAAP)
Internal Drive Support
Standard (8) small form factor (SFF) hot-plug drive bays to support Serial-attached SCSI (SAS) and Serial ATA (SATA) drives
Optional second drive cage for additional (8) SFF drive bays (total 16) Optional cage for (6) Large Form Factor SAS/SATA hard drive bays
Slimline media bay supporting Optical Drive (ships standard on performance models)
Network Controller
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) with TCP/IP Offload Engine, including support for Accelerated iSCSI
Expansion Slots
Six available PCI-Express Gen2 slots, optional mixed PCI-X / PCI-Express or x16 PCI configurations available (see "Standard Features -Expansion Slots" section for more details)
Ports
:
USB 2.0 support 5 total ports: (2) ports up front; (2) ports in back; (1) port internal 1 internal Secure Digital (SD) slot
Integrated Hypervisors
VMware 3i virtualization technology Citrix XenServer virtualization technology
Redundancy
Fully redundant hot plug fans (N+1) Hot plug power supply with optional redundancy (Included in Performance models)
Power Sources
Dual Common Slot Bay for Right Sized, Hot plug and Redundant Power options
Infrastructure Management:
Convenient slide-out Systems Insight Display for quick and easy front view server diagnostics, along with status LEDs, Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU) HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) for simplified server setup, health monitoring and recovery, power and thermal control, and lights-out remote administration. HP Insight Control (ICE) suites, as product options, deliver essential infrastructure management that can help save time and money by making it easy to deploy, monitor, control and optimize your IT infrastructure through a single, simple management console. ICE suites support both Windows and Linux-based servers and management consoles HP Insight Dynamics - VSE suite for ProLiant servers, a product option, is an integrated command center that enables you to continuously analyze and optimize your adaptive infrastructure. This advanced infrastructure management software lets you reduce the cost of common data center tasks by as much as 40 percent while keeping pace with your changing business.
Form Factor
Rack (2U), (3.5-inch); Depth 27.25 inches (69.98 cm)
Operating Systems and Virtualization Software Support for ProLiant Servers
Supports Windows, RHEL, SLES, OEL, Solaris, NetWare, VMware, and HP Citrix Essentials for XenServer
Deployment/Serviceability
System Insight Display on the front bezel for quick and easy server diagnostics Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick release levers for fast and easy serviceability Tool-less access to all system components for easy in rack serviceability Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for greater flexibility in performing defective parts replacement
Warranty
:
:
HP 1200W CS HE Silver Power Supply (optional) HP 750W CS HE Gold Power Supply (standard on some models) HP 460W CS HE Gold Power Supply (standard on some models) HP 48V DC Power Supply (optional)
:
:
:
:
:
(Optional):
:
HP ProLiant DL380 Generation 6
:
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 2
Page 3
QuickSpecs
Overview
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. SATA hard drives have a one-year warranty. SAS Enterprise drives have a three-year warranty.
NOTE:
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:
HP ProLiant DL380 Generation 6
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 3
Page 4
QuickSpecs

Standard Features

NOTE:
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
Processor
One of the following depending on Model
Quad-Core Processors
Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800)
Dual-Core Processors
Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)
NOTE: NOTE:
Turbo indicates the maximum potential frequency increment when using Intel® Turbo
Boost Technology, with 4, 3, 2, and 1 cores active.
NOTE:
depend on the quantity and type of DIMMs installed.
NOTE:
For the Intel 5500 Series, the letter preceding the model number indicates the performance/wattage of the processor. "X" denotes High Performance/Wattage; "E" denotes Enterprise Performance/Wattage (Mainstream); and "L" denotes Lower Wattage.
NOTE:
Up to 2 processors supported. Performance configurations include two processors. Mixing different processor models is not supported.
HP ProLiant DL380 Generation 6
HT indicates that the processor model supports Intel® Hyper-Threading Technology.
DDR3 speed is the maximum memory speed of the processor. Actual memory speed may
Cache Memory
One of the following depending on Model
Chipset
Upgradeability
Memory Protection
8MB (1 x 8MB) Level 3 cache
NOTE:
All processor models except for those identified below.
4MB (1 x 4MB) Level 3 cache
NOTE:
For processors E5506/L5506/E5504/E5502.
Intel® 5520 Chipset
NOTE:
For more information regarding Intel chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/
Upgradeable to 2 processors (8 cores)
Advanced ECC (multi-bit error protection)
Mirroring mode
Lockstep mode
.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 4
Page 5
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Memory
Type
Standard (Performance Models)
Standard (Base Models)
Standard (Entry Models)
Standard (High Efficiency Models)
Maximum (RDIMM)
Maximum (UDIMM)
NOTE: NOTE:
at 1333MHz, 1066MHz, or 800MHz. Please see the Online Memory Configuration Tool at:
www.hp.com/go/ddr3memory-configurator
If only one processor is installed, only half the DIMM slots are available
Depending on the memory configuration and processor model, the memory speed may run
DDR3 Registered (RDIMM) and Unbuffered (UDIMM)
12 GB (6 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
6 GB (3 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
4 GB (2 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
4 GB (2 x 2 GB) PC3-10600E (DDR3-1333) Unbuffered DIMMs
192 GB (12 x 16 GB) for Registered Memory configurations
24 GB (12 x 2 GB) for Unbuffered Memory configurations
.
DDR3 memory options part number decoder
Network Controller
Expansion Slots
NOTE:
The system board has 2 PCI connectors, but the below riser cards have the actual PCI slots, to which PCI cards
attach.
Primary Riser
(Standard)
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) with TCP/IP Offload Engine, including support for Accelerated iSCSI
Expansion
Slots #
1
2
3
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Technology
PCIe Gen2
PCIe Gen2
PCIe Gen2
Bus
Width
**
X8
X4 X8
X4 X8
Connector
Width
X16
Bus
Number
7
10
13
Form Factor
*
Full Length,
Full Height
Slot
Half Length,
Full Height
Slot
Half Length,
Full Height
Slot
PCIe Riser
Expansion
Technology
Bus
Connector
Bus
Form Factor
Notes
Notes
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 5
Page 6
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
(Optional Secondary)
PCIe/PCI-X Riser
(Optional Primary)
PCIe/PCI-X Riser
(Optional Secondary)
x16 PCIe Riser
(Optional Primary)
x16 PCIe Riser
(Optional Secondary)
Slots #
4
5
6
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Expansion
Slots #
1
2
3
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Expansion
Slots #
4
5
6
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Expansion
Slots #
1
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Expansion
Slots #
PCIe Gen2
PCIe Gen2
PCIe Gen2
Technology
PCI-X
(133MHz)
PCI-E Gen2
PCI-E Gen2
Technology
PCI-X
(133MHz)
PCI-E Gen2
PCI-E Gen2
Technology
PCIe Gen2
Technology
Width
**
X8
X4 X8
X4 X8
Bus
Width
64-bit
X8
X4 X8
Bus
Width
64-bit
X8
X4 X8
Bus
Width
x16 x16
Bus
Width
Connector
**
Connector
**
applicable
Connector
**
Connector
**
Width
X16
Width
N/A
X16
Width
Not
X16
Width
Width
Number
16
20
23
Bus
Number
7
11
15
Bus
Number
19
23
27
Bus
Number
13
Bus
Number
*
Full length,
full height
Half length,
half height
Half length,
half height
Form Factor
*
Full length,
Full Height
Half Length,
Full Height
Half Length,
Full Height
Form Factor
*
Full length,
Full height
Half Length,
Half Height
Half Length,
Half Height
Form Factor
*
Full Length,
Full Height
Form Factor
*
slot
slot
slot
slot
slot
Notes
Notes
Notes
Supports up
to 225W;
single wide
cards only
Notes
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 6
Page 7
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Storage Controller
One of the following depending on Model
Storage
4
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment number ** Indicates the number of physical electrical lanes running to the connector.
Entry Models
Base Models
Performance Models
High Efficiency Models
Available upgrades: 256MB, 512MB with BBWC, Battery kit upgrade (for BBWC), and Smart Array Advanced Pack (SAAP which allows for RAID 6 support)
Diskette Drive
Optical Drive
One of the following depending on Model
Hard Drives
PCIe Gen2
x16 x16
HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
HP Smart Array P410i/256 MB Controller (RAID 0/1/1+0/5/5+0)
HP Smart Array P410i/512 MB BBWC Controller (RAID 0/1/1+0/5/5+0)
HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
None Standard
None Standard on Entry, High Efficiency, and Base Models
NOTE:
HP Slim SATA DVD RW Optical Drive Standard on Performance Models
NOTE:
sections below contact HP for details.
None Standard
No support on LFF HD Models.
HP 64GB SSD Optical Drive Option Kit available. See options
16
Full Length,
Full Height
slot
Supports up
to 225W;
single wide
cards only
Maximum Internal Storage
Interfaces
Hot Plug SFF SAS
Hot Plug LFF SAS
Serial
Pointing Device (Mouse)
Graphics
Keyboard
VGA
Network RJ-45
iLO remote management port
SD slot
USB 2.0 Ports
4.80TB
6.0TB
1
1
1
1
2 (1 front, 1 back)
2
1
1
5 total: 2 front, 2 back, 1 internal
NOTE:
Please see the following URL for additional information regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb­support.html
.
16 x 300GB
6 x 1TB
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 7
Page 8
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Graphics
Form Factor
Core Infrastructure Management
Integrated ATI ES1000, 32MB video standard
16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024
NOTE:
Maximum resolution available via iLO 2 remote console is 1280 x 1024.
Rack (2U); Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth: 27.25 inches (69.98 cm)
HP Insight Foundation
Managing the growing number of servers can be complex and expensive for your organization. IT managers need to address changing business needs with tools that meet the challenges of managing today's complex Datacenters. HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server lifecyle. This provides the customer with higher levels of operational efficiency and highly reliable systems:
www.hp.com/go/foundation
The foundation pack includes:
HP SmartStart HP Management HP ProLiant Firmware Maintenance
.
ProLiant Onboard Administrator
HP Insight Control (ICE) suites
SmartStart version supported (minimum): SmartStart 8.20
http://www.hp.com/servers/smartstart
NOTE:
In an effort to support reducing our environmental impact, the HP ProLiant Essentials Foundation Pack media will be available as a selectable option for this server at time of order of a CTO SKU. This will allow customers to order the number of media kits that best meet their needs and eliminate receiving unnecessary duplicate media.
HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration of ProLiant ML, DL, and BL servers. HP ProLiant Onboard Administrator functions without additional software, and can be accessed from any location via a web browser. It works hand-in-hand with HP Systems Insight Manager, Insight Control suites, and the Insight Dynamics-VSE suite helping customers unlock the value of the ProLiant platform and deliver the highest possible quality of IT service to the business. See
HP Insight Control (ICE) suites, as product options, deliver essential infrastructure management that can help save time and money by making it easy to deploy, monitor, remote control, and optimize your IT infrastructure through a single, simple management console. ICE suites install and license software modules that are integrated into HP System Insight Manager.
www.hp.com/go/onboardadministrator
Two Insight Control suites are available, to serve environments requiring either Linux-based or Windows-based management consoles: HP Insight Control suite for Linux (ICE-LX), and HP Insight Control suite (ICE). See
HP Insight Control suites include one year of 24 x 7 HP Software
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
www.hp.com/go/insightcontrol
Page 8
Page 9
QuickSpecs
Standard Features
HP Insight Dynamics ­VSE suite
HP ProLiant DL380 Generation 6
Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight
The HP Insight Dynamics - VSE suite for ProLiant, a product option, is an integrated command center that enables you to continuously analyze and optimize your adaptive infrastructure. This advanced infrastructure management software that allows you to analyze and optimize your adaptive infrastructure to manage physical and virtual resources in the same way. HP Insight Dynamics - VSE gives you a powerful toolkit to accelerate complex technology projects and simplify daily operations. It enables you to plan capacity and power continuously, balance across physical and virtual resources, ensure cost-effective high availability, and provision infrastructure consistently.
HP Insight Orchestration, an optional extension to Insight Dynamics ­VSE, enables IT organizations to provision infrastructure consistently and automatically from pools of shared resources using a self-service portal. Resources provisioned can range from a single virtual machine to complex multi-tier environments and their associated physical and virtual resource requirements.
.
Industry Standard Compliance
Security
HP Insight Recovery, also an optional extension for Insight Dynamics ­VSE, enables cost-effective disaster recovery for physical and virtual environments. Application environments can be reactivated in minutes with the touch of a button to a remote location
NOTE:
For more information, visit:
http://www.hp.com/go/insightdynamics http://www.hp.com/go/insightorchestration http://www.hp.com/go/insightrecovery
ACPI 2.0 Compliant PCI 2.2 Compliant WOL Support Microsoft® Logo certifications USB 2.0 Support
Power-on password Keyboard password Diskette drive control Diskette boot control QuickLock, Network Server Mode Parallel and serial interface control Administrator's password
,
,
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 9
Page 10
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Security - Trusted Platform Module
Server Power Cords
Trusted Platform Module option kit
The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker leverages the enhanced security capabilities of a Trusted Platform Module (TPM) version 1.2. The TPM works with BitLocker to help protect user data and to ensure that a server running Windows Server 2008 has not been tampered with while the system was offline. For more information about TPM, including a white paper, go to
www.hp.com/go/TPM
NOTE:
ProLiant OS pre-installed units will come with the partition required for TPM deployment.
NOTE:
The TPM key is unique to every TPM deployed server and must be retained. Misplacing or
losing the key could result in data loss.
High voltage power cord ships standard with all part numbers.
NOTE:
HP ProLiant DL servers no longer ship standard with a 12-foot NEMA 5-15P to C13 power cords (227099-001) that allow connection to 110V US wall outlets in a home or office. ProLiant DL servers are primarily connected to PDU's in data center racks so they now ship standard with only a PDU 6-foot C-14 to C13 power cord (142258-001). If a user wishes to power a ProLiant DL server using a110V receptacle (NEMA-15), the 12-foot NEMA 5-15 to C13 power cord (227099-
001) must be ordered separately. Also available: 110 volt 6-Foot NEMA 5-15p to C13 (AF556A).
UPS and PDU Power Cord Matrix
Power Supply
Please see the UPS and PDU cable matrix's on the HP Power Protection and Management page. Under Power Cords, click on the "HP Power Cord Matrix" link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link:
www.hp.com/products/powercords
HP has a new design for ProLiant power. The new Common Slot Power Supply bay. This design provides the customer with commonality in power supplies across multiple platforms to save on the cost of spares and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers come with Common Slot, High Efficiency and Right-Size Power Supplies. Common Slot (CS) designates commonality of the power supply across multiple ProLiant servers. HP's new Common Slot power supplies are designed for highest efficiency to provide power efficiency without degrading performance of the ProLiant. Power Supplies will have efficiency ratings up to 92%. There are three Right Size power options available, depending on the configuration of your server. To make sure you select the correct power supply to meet your configuration, we suggest that you use the HP configuration. All HP Common Slot power sources are UL, CE Mark Compliant, Hot Plug and Redundant.
.
Power Advisor
to decide the "Right-Size" for your
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 10
Page 11
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Common Slot ProLiant
System Fans
It is highly recommended that you use the HP supply for your needs. HP offers four Power Supply Options:
460Watts, Common Slot,92% Efficiency 750Watts, Common Slot, 92% Efficiency 1200Watts, Common Slot, 90% Efficiency 1200Watts, -48V DC, Common Slot
HP's ProLiant Common Slot Power supplies (460W & 750W) meet multiple Energy Efficiency Initiatives. Climate Savers Computing Initiative GOLD, ECOS Consulting 80PLUS GOLD and plans on offering models that meet the Energy Star for Server requirements when they are published.
HP's ProLiant Common Slot Power supplies (1200W) meet multiple Energy Efficiency Initiatives. Climate Savers Computing Initiative Bronze, ECOS Consulting 80PLUS Bronze Power Supply requirements.
Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power supply option kits (see Redundant Options for part numbers).
Fully redundant hot plug fans ship standard (N+1).
NOTE:
One processor models include four fans. Two processor models include six fans.
Power Advisor
in defining the "Right-Size" power
Operating Systems and Virtualization Software Support for ProLiant Servers
Microsoft Windows Server Microsoft Windows Server Hyper-V Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Enterprise Linux (OEL) Solaris 10 for x86/x64 based Systems NetWare VMware HP Citrix Essentials for XenServer
NOTE:
For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
www.hp.com/support/DL380G6
http://www.hp.com/go/ossupport
.
and our driver download page
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 11
Page 12
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
Rack Airflow Requirements
Rack Kit
Rack 10000 G2 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The 10000 G2 Series Racks provide enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION:
adequate airflow and to prevent damage to the equipment:
CAUTION:
This arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.
NOTE:
CD provided with the server, or to the server documentation located in the Support section at the following URL:
Quick deploy rail system provides tool-free support for racks with square or round mounting holes (including Compaq/HP 7000, 9000, 10000 G2 and HP series), with an adjustment range of 24" ­36". The ambidextrous cable management arm can be mounted on either the left or right side for improved cable management.
If a third-party rack is used, observe the following additional requirements to ensure
Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of 2.75 inches (7 cm).
Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.
For additional information, refer to the Setup and Installation Guide or the Documentation
www.hp.com/servers/dl380
.
Telco Rack Support
Factory Express Portfolio for Servers and Storage
NOTE:
327281-B21; or High Air Flow Rack Door Insert for the 7142 Rack (6-pack) - PN: 327281-B22) are required to support the HP ProLiant DL380 in 7000 series racks. The DL380 Cable Management Arm is not supported on 7000 series racks.
NOTE:
cable management arm is mounted on the right.
Support for all 2-post Telco racks requires the use of the standard rack kit and an additional option kit from Rack Solutions at:
HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, EVA7xxx,,EVA, XP, rackable tape libraries and configurable network switches.
For more information on Factory Express services for your specific server model please contact your sales representative or go to:
High Airflow Inserts (High Air Flow Rack Door Insert for the 7142 Rack (single) - PN:
Cable management arm must be removed to access hot-plug power supplies when the
http://www.racksolutions.com/hp/
http://www.hp.com/go/factory-express
.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 12
Page 13
QuickSpecs
Standard Features
HP ProLiant DL380 Generation 6
HP Enterprise Configurator
Service and Support
The HP eConfigure-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.
http://www.hp.com/products/configurator
HP Care Pack services include coverage for the HP branded hardware options qualified for the server and purchased at the same time or afterward that are internal to the enclosure. This also includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.
To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions, provides a range of support services designed to meet the varying needs of your business. Whether an SMB, or large global corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.
Recommended Service
management.
- simplify ProLiant solution implementation, maintenance, and
.
Support Deployment Service
Enhanced Service
Support
Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.
NOTE:
For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices http://www.hp.com/go/proliant/carepack
: 3-Year 4-Hour response 24x7 Same Business Day Coverage only
: Installation and Start up only
- optimize service level to increase IT performance and availability.
: 3-Year Support Plus 24 only
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 13
Page 14
QuickSpecs
HP ProLiant DL380 Generation 6

HPC Interconnects

NOTE:
High Performance Computing (HPC) interconnect technologies are available for the DL380 under the Cluster Platform product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following URL to configure HPC Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects:
http://www.hp.com/techservers/clusters/ucp/index.html
HPC Interconnect
InfiniBand
Gigabit Ethernet
Myrinet XP
PCI-X and PCI-Express adapters
Use embedded ports
PCI-X Rev D and Rev E adapters
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 14
Page 15
QuickSpecs

Models

NOTE:
For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
HP DL380 G6 Performance Models
Quad-Core Models HP DL380G6 X5560
491315-xx1
HP DL380G6 X5550
491316-xx1
Processor(s)
Two of the following depending on Model
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
HP ProLiant DL380 Generation 6
(2) Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) (2) Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
8MB (1 x 8MB) Level 3 cache
12 GB (6 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters
HP Smart Array P410i/512MB with BBWC
None ship standard
Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays
HP Slim SATA DVD RW drive
(2) 750W Hot Plug Power Supplies
(6) (N+1 redundancy standard)
Rack (2U), Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth:
27.25 inches (69.98 cm)
HP DL380 G6 Performance Models with ICE standard
Quad-Core Models HP DL380G6 X5560
470065-067 US 470065-071 APJ 470065-072 EURO
HP DL380G6 X5550
470065-068 APJ 470065-069 EURO
Processor(s)
Two of the following depending on Model
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Insight Control Environment (ICE)
Form Factor
(2) Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) (2) Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
8MB (1 x 8MB) Level 3 cache
12 GB (6 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters
HP Smart Array P410i/512MB with BBWC
None ship standard
Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays
HP Slim SATA DVD RW drive
(2) 750W Hot Plug Power Supplies
(6) (N+1 redundancy standard)
ICE 24x7 support
Rack (2U), Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth:
27.25 inches (69.98 cm)
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 15
Page 16
QuickSpecs
Models
HP ProLiant DL380 Generation 6
HP DL380 G6 Base Models
Quad-Core Models HP DL380G6 E5540
491332-xx1
HP DL380G6 E5530
491324-xx1
HP DL380G6 E5520
491325-xx1
HP DL380 G6 High Efficiency Models
Quad-Core Models HP DL380G6 L5520
491335-xx1
Processor(s)
One of the following depending on Model
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
(1) Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) (1) Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) (1) Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) Level 3 cache
6 GB (3 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters
HP Smart Array P410i/256MB Controller
None ship standard
Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays
None ship standard
(1) 460W Hot Plug Power Supply
(4) (N+1 redundancy standard)
Rack (2U), Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth:
27.25 inches (69.98 cm)
(1) Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB (1 x 8MB) Level 3 cache
4 GB (2 x 2 GB) PC3-10600E (DDR3-1333) Unbuffered DIMMs
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters
HP Smart Array P410i/Zero Memory Controller
None ship standard
Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays
None ship standard
(1) 460W Hot Plug Power Supply
(4) (N+1 redundancy standard)
Rack (2U), Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth:
27.25 inches (69.98 cm)
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 16
Page 17
QuickSpecs
Models
HP ProLiant DL380 Generation 6
HP DL380 G6 Entry Models
Quad-Core Models HP DL380G6 E5504
491505-xx1
Country Code Key
Processor(s)
Cache Memory
Memory
Network Controller
Storage Controller
Hard Drive
Internal Storage
Optical Drive
Power Supply
Fans
Form Factor
XX=00
XX=20
XX=29
XX=37
XX=42
XX=AA
(1) Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)
4MB (1 x 4MB) Level 3 cache
4 GB (2 x 2 GB) PC3-10600R (DDR3-1333) Registered DIMMs
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters
HP Smart Array P410i/Zero Memory Controller
None ship standard
Standard: 8 SFF SAS/SATA HDD Bays Optional: 16 SFF SAS/SATA HDD Bays
None ship standard
(1) 460W Hot Plug Power Supply
(4) (N+1 redundancy standard)
Rack (2U), Height 3.38-inch (8.59 cm); Width: 17.25 (44.54 cm); Depth:
27.25 inches (69.98 cm)
U.S.
Brazil
Japan
APD
Euro
PRC
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 17
Page 18
QuickSpecs
HP ProLiant DL380 Generation 6

Configuration Information - Factory Integrated Models

NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
NOTE:
HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start with a CTO Chassis.
NOTE:
FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Models
HP DL380R06 CTO Chassis
Factory Integrated Model ships with:
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters Smart Array P410i Controller I/O slots - 3 Slots come standard:
Slot 1 - FL/FH x8 PCIE (x16 connector) Slot 2 - HL/FH x4 PCIE (x8 connector) Slot 3 - HL/FH x4 PCIE (x8 connector)
Additional Slots may be added via selections from the PCI Information and Options subsection
494329-B21
System Fans - 4 (2 additional fans included with second processor) Drive Cage - 8-SFF (Second SFF drive cage optional) USB - 2 Rear, 2 Front, 1 Internal, 1 SD slot Server Management - (iLO2) (embedded)
NOTE:
HP DL380R06 LFF CTO Chassis
Factory Integrated Model ships with:
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters Smart Array P410i Controller I/O slots - 3 Slots come standard:
Drive Cage - 6-LFF System Fans - 4 (2 additional fans included with second processor) USB - 2 Rear, 2 Front, 1 Internal, 1 SD slot Server Management - (iLO2) (embedded)
NOTE:
Power Supply not included - choose from Options section
Slot 1 - FL/FH x8 PCIE (x16 connector) Slot 2 - HL/FH x4 PCIE (x8 connector) Slot 3 - HL/FH x4 PCIE (x8 connector)
Additional Slots may be added via selections from the PCI Information and Options subsection
Power Supply not included - choose from Options section
516919-B21
Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)
Processors
Quad-Core Processors
Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800), FIO
Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800), FIO
Intel® Xeon® Processor L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800), FIO
Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2), FIO
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
492136-L21
492131-L21
500089-L21
492239-L21
Page 18
Page 19
QuickSpecs
Configuration Information - Factory Integrated Models
HP ProLiant DL380 Generation 6
Base Memory
Power Supplies
Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2), FIO
Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2), FIO
Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2), FIO
Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3), FIO
Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3), FIO
Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3), FIO
Dual-Core Processors
Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800), FIO
Registered DIMMs (RDIMMs)
HP 2GB 2Rx8 PC3-10600R-9 Kit
HP 4GB 2Rx4 PC3-10600R-9 Kit
HP 4GB 4Rx8 PC3-8500R-7 LP Kit
HP 8GB 2Rx4 PC3-8500R-7 Kit
HP 8GB 2Rx4 PC3-10600R-9 Kit
HP 16GB 4Rx4 PC3-8500R-7 Kit
Unbuffered with ECC DIMMs (UDIMMs)
HP 1GB 1Rx8 PC3-10600E-9 Kit
HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see:
efficient
NOTE:
configuration, offer new power options, including Common Slot Power Supplies. These power supplies come in multiple power ratings and higher efficiency levels to offer the Right Size solution to fit your configuration. This provides improved power delivery and the advantage of reclaiming lost power. Prior to making a power supply selection it is "highly recommended" that the "HP Power Advisor" is run to determine the right size power supply for your server configuration. The HP Power Advisor is located at "
www.hp.com/go/hppoweradvisor
HP 460W CS HE Power Supply Kit
HP 750W CS HE Power Supply Kit
HP 1200W CS HE Power Supply Kit
HP 1200W-48V DC Common Slot Power Supply
NOTE:
DC power rectifiers.
NOTE:
IEC cables.
.
Refer to HP Power Advisor when selecting a power supply for your
www.hp.com/go/hppoweradvisor
DC power supplies contain a -48V DC power cord designed for in rack
Option Kits contain optional power supply, an IEC power cable and PDU
www.hp.com/go/ddr3memory-configurator
www.hp.com/go/proliant-energy-
. Many HP ProLiant Servers now
www.hp.com/go/proliant-energy-efficient
" or
.
500087-L21
492237-L21
492244-L21
492234-L21
492232-L21
500094-L21
500085-L21
500656-B21
500658-B21
500660-B21
516423-B21
500662-B21
500666-B21
500668-B21
500670-B21
516914-B21
503296-B21
512327-B21
500172-B21
437573-B21
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 19
Page 20
QuickSpecs
HP ProLiant DL380 Generation 6
Configuration Information - Factory Integrated Models
Step 3: Choose Additional Factory Integratable Options (only one of the following from each list unless otherwise noted)
Controllers
Integrated hypervisor (iHV)
Performance Packs
NOTE:
one of the following:
HP 256 MB P-series cache module FIO
NOTE:
standard integrated controller).
Battery Option Kit Upgrade
NOTE:
standard integrated controller).
NOTE:
512MB BBWC
NOTE:
standard integrated controller).
NOTE:
controller.
HP Smart Array P212/256 MB w/ Battery FIO
HP Smart Array P410/256 MB w/ Battery FIO
HP Smart Array P411/256 MB w/ Battery FIO
NOTE:
Virtualization
HP VMware 3i Enterprise 2p Lic SW
NOTE:
at:
NOTE:
http://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do? productNumber=HPXS
HP Essentials -XenServer Platinum Nm Lic
HP ProLiant Virtual Console Full License
XenServer HP Ent Upg iSW Lic
HP Citrix Essentials for XenServer Enterprise Edition
NOTE:
Essentials for XenServer QuickSpecs at
The HP ProLiant DL380 performance packs are necessary to configure a HP ProLiant DL380 Performance Model. HP ProLiant DL380 Performance model includes the latest performance technologies and enterprise class availability features pre-installed for convenience and value.
If Additional Memory Cache Module or Controller is Required please pick
This is an option for the HP Smart Array P410i Controller (P410i is
This is an option for the HP Smart Array P410i Controller (P410i is
To enable BBWC on the 256MB cache on P410i).
This is an option for the HP Smart Array P410i Controller (P410i is
Battery included. When used with the embedded HP Smart Array P410i
HP VMware ESXi free download from
For additional information and options kits, please see the QuickSpecs
www.hp.com/go/vmware
HP XenServer Select Edition free Download from:
For additional information and options kits, please see the HP Citrix
.
www.software.hp.com
www.hp.com/go/citrix
- select
534108-B21
462969-B21
462967-B21
491191-B21
491195-B21
491193-B21
430341-B21
530753-B21
508293-B21
464676-B21
508294-B21
The performance pack includes:
2nd processor 750-watt redundant power supply 512MB cache module for P410i 650 mAh P-Series Battery 15P 24in SFP Battery Cable Assy One DL380 G6 HP Fan kit (contains qty of 2)
NOTE:
Must also select Slimline SATA DVD RW Optical Drive (481043-B21) to achieve parity to DL380 High Performance Models.
HP DL380G6 2.6 HPM FIO Perf Pack
HP DL380G6 2.8 HPM FIO Perf Pack
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
500583-B21
500584-B21
Page 20
Page 21
QuickSpecs
Configuration Information - Factory Integrated Models
HP ProLiant DL380 Generation 6
Step 4: Choose Additional Options for Factory Integration
NOTE:
For additional options, please refer to the "Core Options and Additional Options" section below.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 21
Page 22
QuickSpecs

Core Options

NOTE:
Some options may not be integrated at the factory. Contact your local sales representative for additional information.
HP ProLiant DL380 Generation 6
HP ProLiant DL380 G6 Unique Options
Processors
HP StorageWorks RDX160 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 second drive cage slot (160GB of Disk Storage)
HP StorageWorks RDX320 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 second drive cage slot (320GB of Disk Storage)
HP StorageWorks RDX500 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 second drive cage slot (500GB of Disk Storage)
HP 8SFF CAGE 380G6
NOTE:
Second drive cage installation replaces internal optical bay.
NOTE:
Second drive cage requires second controller or HP SAS Expander Card (468406-B21).
HP DL380G6 3 Slot PCI-E Riser Kit
Quad-Core Processors
Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800)
Intel® Xeon® Processor L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800)
Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3)
Dual-Core Processors
Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)
AP724A
AP725A
AP726A
516914-B21
500579-B21
492136-B21
492131-B21
500089-B21
492239-B21
500087-B21
492237-B21
492244-B21
492234-B21
492232-B21
500094-B21
500085-B21
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 22
Page 23
QuickSpecs
Core Options
HP ProLiant DL380 Generation 6
Memory
Optical Drives
Registered DIMMs (RDIMMs)
HP 2GB 2Rx8 PC3-10600R-9 Kit
HP 4GB 2Rx4 PC3-10600R-9 Kit
HP 4GB 4Rx8 PC3-8500R-7 LP Kit
HP 8GB 2Rx4 PC3-8500R-7 Kit
HP 8GB 2Rx4 PC3-10600R-9 Kit
HP 16GB 4Rx4 PC3-8500R-7 Kit
Unbuffered with ECC DIMMs (UDIMMs)
HP 1GB 1Rx8 PC3-10600E-9 Kit
HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see:
HP Slim SATA DVD RW Optical Drive
NOTE:
Included in performance models.
HP Slim SATA DVD-ROM Optical Drive
HP 64GB SSD Drive option for Optical Drive Bay
www.hp.com/go/ddr3memory-configurator
www.hp.com/go/proliant-energy-efficient
.
500656-B21
500658-B21
500660-B21
516423-B21
500662-B21
500666-B21
500668-B21
500670-B21
481043-B21
481041-B21
575489-B21
Hard Drives
NOTE:
The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
SAS Hot Plug SFF Enterprise (ENT) Drives
HP 300GB 6G SAS 10K SFF DP ENT HDD
HP 300GB 3G SAS 10K SFF DP ENT HDD
HP 146GB 6G SAS 10K SFF DP ENT HDD
HP 146GB 3G SAS 10K SFF DP ENT HDD
HP 146GB 3G SAS 15K SFF DP ENT HDD
HP 72GB 3G SAS 15K SFF DP ENT HDD
HP 72GB 3G SAS 10K SFF DP ENT HDD
SAS Hot Plug 3.5" Enterprise (ENT) Drives
HP 450GB 3G SAS 15K 3.5" DP ENT HDD
HP 400GB 3G SAS 10K 3.5" DP ENT HDD
HP 300GB 3G SAS 15K 3.5" DP ENT HDD
HP 146GB 3G SAS 15K 3.5" DP ENT HDD
HP 72GB 3G SAS 15K 3.5" DP ENT HDD
SAS Hot Plug SFF Midline (MDL) Drives
HP 500GB 6G SAS 7.2K SFF DP MDL HDD
SAS Hot Plug 3.5" Midline (MDL) Drives
HP 1TB 3G SAS 7.2K 3.5" DP MDL HDD
HP 750GB 3G SAS 7.2K 3.5" DP MDL HDD
NOTE:
SAS Enterprise drives have a 3-year warranty. Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide)
507127-B21
492620-B21
507125-B21
418367-B21
504062-B21
418371-B21
384842-B21
454232-B21
459508-B21
416127-B21
384854-B21
384852-B21
507610-B21
461137-B21
461135-B21
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 23
Page 24
QuickSpecs
Core Options
HP ProLiant DL380 Generation 6
Communications
SATA Hot Plug SFF Midline (MDL) Drives
HP 500GB 3G SATA 7.2K 2.5in MDL HDD
HP 160GB 3G SATA 7.2K 2.5in MDL HDD
SATA Hot Plug 3.5" Midline (MDL) Drives
HP 1TB 3G SATA 7.2K 3.5" MDL HDD
HP 750GB 3G SATA 7.2K 3.5" MDL HDD
HP 500GB 3G SATA 7.2K 3.5" MDL HDD
HP 250GB 3G SATA 7.2K 3.5" MDL HDD
SATA Hot Plug 3.5" Entry (ETY) Drives
HP 160GB 3G SATA 7.2K 3.5" ETY HDD
SATA Hot Plug SFF Entry (ETY) Drives
HP 250GB 3G SATA 5.4K SFF ETY HDD
HP 120GB 1.5G SATA 5.4K SFF ETY HDD
NOTE:
SATA drives have a 1 year warranty. Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/13021_div/13021_div.html
(Worldwide)
HP NC112T PCIe Gigabit Server Adapter
HP NC360T PCI Express Dual Port Gigabit Server Adapter
HP NC364T PCI Express Quad Port Gigabit Server Adapter
NOTE:
Does not support Windows 2000.
HP NC373F PCI Express Multifunction Gigabit Server Adapter
HP NC373T PCI Express Multifunction Gigabit Server Adapter
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter
HP NC522SFP Dual Port 10GbE Server Adapter
NOTE:
A minimum of two gigabyte (2 GB) of server memory is required per each NC522SFP adapter.
NOTE:
Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
www.hp.com/go/ProLiantNICs
507750-B21
530888-B21
454146-B21
458930-B21
458928-B21
458926-B21
458945-B21
460355-B21
458924-B21
503746-B21
412648-B21
435508-B21
394793-B21
394791-B21
458492-B21
468332-B21
Riser Cage Options
HP DL380G6 3 Slot PCI-E Riser Kit
HP DL385G5p PCI-X Riser Kit
HP PCI x16 Riser Kit
HP DL38X (2) x8 Dual Port 10GbE Riser Kit
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
500579-B21
494322-B21
494323-B21
494326-B21
Page 24
Page 25
QuickSpecs
Core Options
HP ProLiant DL380 Generation 6
Power Supplies
CAUTION:
same size power supplies are recommended. If non-matched power supplies are inserted you will get errors and operation will fail.
HP 460W CS HE Power Supply Kit
HP 750W CS HE Power Supply Kit
HP 1200W CS HE Power Supply Kit
HP 1200W-48V DC Common Slot Power Supply
NOTE:
DC power rectifiers.
NOTE:
IEC cables.
In ProLiant Servers that have more than one power slot (bay), only
DC power supplies contain a -48V DC power cord designed for in rack
Option Kits contain optional power supply, an IEC power cable and PDU
503296-B21
512327-B21
500172-B21
437573-B21
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 25
Page 26
QuickSpecs

Additional Options

HP ProLiant DL380 Generation 6
HP Insight Control (ICE) suites
HP Insight Control suite (ICE)
HP Insight Control suite, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates
NOTE:
Advanced.
NOTE:
licenses with a single activation key. Customer will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service. Only available directly from HP and select resellers in the Americas region.
HP Insight Control Management Software Media Kit
NOTE:
and Essentials software products and components licensed by Insight Control Environment suite. Uses an integrated installer to perform quick and accurate software installation and updates.
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html
HP Insight Control suite for Linux (ICE-LX)
HP Insight Control suite for Linux, Media pack (DVD) - No licenses included
NOTE:
Control Environment for Linux, HP System Insight Manager, HP Insight Power Manager, HP Virtual Machine Management Pack, and an integrated installer. Servers must be acquired separately.
NOTE:
updates may be downloaded at no cost from: (click on Download button).
HP Insight Control suite for Linux, No Media, 1-Server license, including one year of 24x7 Technical Support and Updates
NOTE:
activation key. Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
NOTE:
NOTE:
http://h18000.www1.hp.com/products/quickspecs/13019_div/13019_div.html
Contains 1 license for each of RDP, PMP, VMM, VPM, IPM and iLO
This part number can be purchased as a single license or as multiple
Insight Software DVD media without licenses. Contains Insight Manager
For additional License Kits, please see the QuickSpecs at:
This optional Media pack DVD contains the ISO image for HP Insight
This Media pack is optional because the latest ISO image and latest
http://www.hp.com/go/ice-linux
This part number can be used to purchase one (1) license with a single
One certificate is shipped for each license.
For additional License Kits, please see the QuickSpecs at:
452148-B22
436222-B21
464422-B22
464423-B22
Drive Cage Options
Secure Digital (SD) Memory Cards
Security
Storage Controllers
HP 8SFF CAGE 380G6
NOTE:
Second drive cage installation replaces internal optical bay.
NOTE:
Second drive cage requires second controller or HP SAS Expander Card (468406-B21).
HP Photosmart 2GB Secure Digital (SD) Card
HP Photosmart 4GB Secure Digital High Speed Card (SDHC)
HP Trusted Platform Module Option Kit
SAS Controllers
Smart Array P800 Controller
HP Smart Array P800/512 BBWC Controller
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
516914-B21
L1877A
L1878A#707
488069-B21
381513-B21
Page 26
Page 27
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
Smart Array P212 Controller
HP Smart Array P212/Zero Memory Controller
HP Smart Array P212/256 MB Controller
Smart Array P410 Controller
HP Smart Array P410/256 MB Controller
HP Smart Array P410/512 MB with BBWC Controller
Smart Array P411 Controller
HP Smart Array P411/256 MB Controller
HP Smart Array P411/512 MB with BBWC Controller
Optional Upgrades
256 MB Cache Module
NOTE:
Supported on HP Smart Array P212 Controller only.
512MB BBWC
NOTE:
When used with the embedded HP Smart Array P410i controller, this battery module also requires a 24 inch SFP Battery Cable (496029-B21).
Battery Kit upgrade
NOTE:
To enable BBWC on the 256MB cache.
NOTE:
Controller, HP Smart Array P410 Controller, and HP Smart Array P411 Controller only.
HP Smart Array Advanced Pack No Media 1-Server license including 1yr 24x7 Technical Support
NOTE:
multiple licenses with a single activation key. Customers will receive a license entitlement certificate via e-mail. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Include one year of 24x7 HP Software Technical Support Services.
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/12616_div/12616_div.html
(Smart Array P800 Controller)
http://h18000.www1.hp.com/products/quickspecs/13203_div/13203_div.html
(Smart Array P212 Controller)
http://h18000.www1.hp.com/products/quickspecs/13201_div/13201_div.html
(Smart Array P410 Controller)
http://h18000.www1.hp.com/products/quickspecs/13202_div/13202_div.html
(Smart Array P411 Controller)
http://h18000.www1.hp.com/products/quickspecs/13200_div/13200_div.html
(Smart Array Advanced Pack)
SAS Controller Options
HP SAS Expander Card
NOTE:
information:
http://h18004.www1.hp.com/products/quickspecs/13232_div/13232_div.html
(SAS Expander Card)
SAS HBA
HP SC08Ge Host Bus Adapter
NOTE:
NOTE:
information:
http://h18004.www1.hp.com/products/quickspecs/13082_div/13082_div.html
(SC08Ge HBA)
SCSI HBA
Supported on HP P410i Smart Array (integrated), HP Smart Array P212
This part number can be used to purchase a single license or to order
Please see the QuickSpecs for Technical Specifications and additional
Please see the QuickSpecs for Technical Specifications and additional
For use with additional 8 SFF drive cage (516914-B21).
Please see the QuickSpecs for Technical Specifications and additional
462828-B21
462834-B21
462862-B21
462864-B21
462830-B21
462832-B21
462968-B21
462967-B21
462969-B21
516471-B21
468406-B21
488765-B21
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 27
Page 28
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
Power Cords
HPC Specific Options
HP SC11Xe Host Bus Adapter
NOTE:
Recommended HBA for SCSI tape drive connect.
NOTE:
Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/12566_div/12566_div.html
(SC11Xe HBA)
NOTE:
HP ProLiant servers ships with an IEC-IEC power cord used for rack mounting with Power Distribution Units (PDUs).
Nema 5-15P to IEC320-C13, North America low voltage (6 ft/2 m)
Power Cord, Euro, 10A 250 V Straight (6 ft/1.83 m)
Power Cord, UK, 10A 250 V Straight (6 ft/1.83 m)
Power Cord, Danish, 10A 250 V Straight (6 ft/1.83 m)
Power Cord, Swiss, 10A 250 V Straight (6 ft/1.83 m)
Power Cord, Italian, 10A 250 V Straight (6 ft/1.83 m)
Power Cord, South Africa, 10A 250 V Straight (8.2 ft/2.5 m)
HP IB 4X QDR PCI-e G2 Dual Port HCA
NOTE:
Please see the QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/13078_div/13078_div.html
412911-B21
AF556A
AF568A
AF570A
AF566A
AF565A
AF571A
AF567A
517721-B21
Tape Storage
NOTE:
For the complete listing of Tape Drive offerings, please see:
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
For recommended tape drive offerings for this ProLiant server see the following:
Tape Drives
USB Rack-Mount Tape Solutions
HP StorageWorks 1U USB Rack-Mount Kit with one DAT 160 USB Tape Drive
NOTE:
Pre-configured with one DAT 160 USB tape drive.
SAS Rack-Mount Tape Solutions
NOTE:
HP recommends purchasing the HP Smart Array P212 Controller (462828-B21) for a dedicated SAS HBA for tape.
HP StorageWorks 1U SAS Rack-Mount Kit with one LTO-4 Ultrium 1760
NOTE:
Pre-configured with one LTO-4 Ultrium 1760 SAS tape drive.
HP StorageWorks 1U SAS Rack-Mount Kit
NOTE:
Supports up to (2) half-height SAS tape drives.
HP StorageWorks LTO-2 Ultrium 448 SAS Internal Tape Drive
NOTE:
Mounts inside the 1U SAS Rack-Mount Kit (AE459A).
HP StorageWorks LTO-3 Ultrium 920 SAS Internal Tape Drive
NOTE:
Mounts inside the 1U SAS Rack-Mount Kit (AE459A).
NOTE:
For an up-to-date listing of the latest O/S and software support details for HP tape drives, please visit:
HP StorageWorks 1/8 G2 Tape Autoloader
HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader
HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 SAS Autoloader
HP StorageWorks 1/8 G2 Tape Autoloader Rack Kit
NOTE:
includes rails and rackmount instructions.
Required to install the 1/8 G2 Autoloaders in a standard 19-inch rack;
http://www.hp.com/go/connect
.
AG703A
EH946A
AE459A
DW085A
EH847A
AK377A
AH558A
AH166A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 28
Page 29
QuickSpecs
Additional Options
NOTE:
Please reference the Tape Autoloader QuickSpecs at:
http://www.hp.com/go/automation
complete solution.
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Drive Library
HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Drive Library
HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library
NOTE:
Please reference the MSL Tape Library QuickSpecs at:
http://www.hp.com/go/automation
complete solution; reference current compatibility information at:
http://www.hp.com/go/ebs
HP ProLiant DL380 Generation 6
for additional information needed to create a
AK378A
AH559A
AK380A
AH560A
for additional information needed to create a
.
Disk-Based Backup
StorageWorks Options
RDX Removable Disk Backup
HP StorageWorks RDX160 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 media bay (160GB of Disk Storage)
HP StorageWorks RDX320 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 media bay (320GB of Disk Storage)
HP StorageWorks RDX500 Removable Disk Backup System DL Server Module
NOTE:
Mounts in DL380 G6 media bay (500GB of Disk Storage)
NOTE:
Please see the HP RDX Removable Disk Backup System QuickSpecs for additional information:
http://h18000.www1.hp.com/products/quickspecs/13036_div/13036_div.html
D2D Backup
HP StorageWorks D2D2502i Backup System
NOTE:
2 TB raw capacity/1.5 TB useable capacity.
HP StorageWorks D2D2504i Backup System
NOTE:
4 TB raw capacity/3 TB useable capacity.
NOTE:
Please see the HP D2D Backup Systems QuickSpecs for additional information:
StorageWorks Fibre Channel HBA
NOTE:
2000, Windows Server 2003 and Linux, please see:
http://h18006.www1.hp.com/storage/saninfrastructure/hba.html
HP StorageWorks FC2142SR 4Gb PCI-e HBA
HP StorageWorks FC2242SR Dual Channel 4Gb PCI-e HBA
HP StorageWorks FC1142SR 4Gb PCI-e HBA
HP StorageWorks FC1242SR Dual Channel 4Gb PCI-e HBA
HP StorageWorks 81Q 8Gb PCI-e FC HBA
HP StorageWorks 81E 8Gb PCI-e FC HBA
HP StorageWorks 82E 8Gb Dual-port PCI-e FC HBA
HP StorageWorks 82Q 8Gb Dual Port PCI-e FC HBA
http://www.hp.com/go/d2d
For the complete listing of Fibre Channel Host Bus Adapters for Windows
AP724A
AP725A
AP726A
EJ001A
EJ002A
A8002A
A8003A
AE311A
AE312A
AK344A
AJ762A
AJ763A
AJ764A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 29
Page 30
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
HP StorageWorks Modular Smart Array
MSA SAN Storage Arrays
HP StorageWorks 50 Modular Smart Array
NOTE:
Please see the Modular Smart Array 50 QuickSpecs for additional information including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12245_div/12245_div.html
(Worldwide)
HP StorageWorks 60 Modular Smart Array
NOTE:
information including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12627_div/12627_div.html
(Worldwide)
HP StorageWorks 70 Modular Smart Array
NOTE:
information including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/12652_div/12652_div.html
(Worldwide)
HP 2012sa Single Controller Modular Smart Array
HP 2012sa Dual Controller Modular Smart Array
NOTE:
options and configuration information at:
http://h18000.www1.hp.com/products/quickspecs/13045_div/13045_div.html
(Worldwide)
Please see the Modular Smart Array 60 QuickSpecs for additional
Please see the Modular Smart Array 70 QuickSpecs for additional
Please see the Modular Smart Array 2000sa QuickSpecs for additional
364430-B21
418408-B21
418800-B21
AJ752A
AJ753A
Uninterruptible Power Systems
HP Rack-mountable UPS
HP R1500 G2 UPS
HP, R1.5kVA UPS, 1U, NA
HP, R1.5kVA UPS, 1U, INTL
HP, R1.5kVA UPS, 1U, JPN/TW
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12507_div/12507_div.html
(Worldwide)
HP R3000v Uninterruptible Power System
HP R3000v UPS
NOTE:
NOTE:
information:
http://h18000.www1.hp.com/products/quickspecs/13129_div/13129_div.html
NOTE:
go to:
The R3000v is available in China and India only.
Please see the QuickSpecs for Technical Specifications and additional
For additional information on HP Uninterruptable Power Systems please
www.hp.com/servers/rackups
.
AF419A
AF418A
AF421A
AF444A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 30
Page 31
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
Power Distribution Units
HP Rack 5000 Series
(Graphite Metallic)
Monitored PDUs
HP Monitored Power Distribution Unit: Full Rack Version
HP 17.3 kVA S2324 Monitored PDU- dual input, 3Ø24A (NA/JPN)
HP 8.6 kVA S1324 Monitored PDU- single input, 3Ø, 24A (NA/JPN)
HP 16.6 kVA S2140 Monitored PDU- dual input, 1Ø, 40A (NA/JPN)
HP 8.3 S1140 Monitored PDU- single input, 1Ø, 40A (NA/JPN)
HP 22.1 kVA S2316 Monitored PDU- dual input, 3Ø, 16A (INTL)
HP 11 kVA S1316 Monitored PDU- single input, 3Ø, 16A (INTL)
HP 14.7 kVA S2132 Monitored PDU- dual input, 1Ø, 32A (INTL)
HP 7.3 kVA S1132 Monitored PDU- single input, 1Ø, 32A (INTL)
HP Monitored Power Distribution Unit: Half Rack Version
HP 4.9 kVA S124 Monitored PDU- single input, 1Ø, 24A (NA/JPN)
HP 7.3 kVA S132 Monitored PDU- single input, 1Ø, 32A (INTL)
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12118_div/12118_div.html
(Worldwide)
HP 5642 Rack-Unassembled
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12074_div/12074_div.html
(Worldwide)
NOTE:
For additional information regarding Rack Cabinets, please see the following URL:
http://www.hp.com/go/rackandpower
.
AF503A
AF504A
AF505A
AF506A
AF507A
AF508A
AF509A
AF510A
AF914A
AF915A
358254-B21
HP Rack Series
HP Rack 5000 Series
HP 5642 Rack-Unassembled
NOTE:
http://h18000.www1.hp.com/products/quickspecs/12074_div/12074_div.html
(Worldwide)
HP Rack 10000 G2 Series
10642 G2 (42U) Rack Cabinet - Pallet
10642 G2 (42U) Rack Cabinet - Shock Pallet
10642 G2 (42U) Rack Cabinet - Crated
10642 G2 (42U) Rack Cabinet, with Extension - Shock Pallet
10636 G2 (36U) Rack Cabinet - Pallet
10636 G2 (36U) Rack Cabinet - Shock Pallet
10636 G2 (36U) Rack Cabinet - Crated
10636 G2 (36U) Rack Cabinet, with Extension - Shock Pallet
10622 G2 (22U) Rack Cabinet - Pallet
10622 G2 (22U) Rack Cabinet - Shock Pallet
10642 G2 (42U) Rack Cabinet 1200mm Deep - Shock Pallet
10642 G2 (42U) Rack Cabinet 1200mm Deep - Pallet
10842 G2 (42U) 800mm Wide Rack Cabinet - Pallet
10842 G2 (42U) 800mm Wide Rack Cabinet - Shock Pallet
10647 G2 (47U) Rack Cabinet - Pallet
HP S10614 (14U) Rack Cabinet - Shock Pallet
Please see the QuickSpecs for additional information:
(Graphite Metallic)
(Carbon/Graphite Metallic)
358254-B21
AF001A
AF002A
AF003A
AF004A
AF011A
AF012A
AF013A
AF014A
AF021A
AF022A
AF034A
AF038A
AF041A
AF042A
AF031A
292302-B22
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 31
Page 32
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
HP Rack Options
10647 G2 (47U) Rack Cabinet 1200mm Deep - Shock Pallet
NOTE:
Due to handling and shipping requirements, AF044A is only orderable through HP Factory Express. It is not for direct sales. Customer site surveys are required before an order is approved. CTO orders may require additional lead time.
10647 G2 (47U) Rack Cabinet 1200mm Deep - Pallet
NOTE:
It is mandatory to use a shock pallet when shipping racks with equipment installed.
NOTE:
xxxxxx-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels).
NOTE:
Please see the QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12402_div/12402_div.html
(Worldwide)
NOTE:
For additional information regarding Rack Cabinets, please see the following URL:
Keyboards and Monitors
TFT7600 Rackmount Keyboard Monitor US
TFT7600 Rackmount Keyboard Monitor UK
TFT7600 Rackmount Keyboard Monitor GR
TFT7600 Rackmount Keyboard Monitor FR
TFT7600 Rackmount Keyboard Monitor IT
TFT7600 Rackmount Keyboard Monitor SP
TFT7600 Rackmount Keyboard Monitor DEN
TFT7600 Rackmount Keyboard Monitor NOR
TFT7600 Rackmount Keyboard Monitor SE/FI
TFT7600 Rackmount Keyboard Monitor SWI
TFT7600 Rackmount Keyboard Monitor PORT
TFT7600 Rackmount Keyboard Monitor BEL
TFT7600 Rackmount Keyboard Monitor JPN2
TFT7600 Rackmount Keyboard Monitor RUS
TFT7600 Rackmount Keyboard Monitor INTL
1U Rackmount Keyboard with USB, US
1U Rackmount Keyboard with USB, UK
1U Rackmount Keyboard with USB, GR
1U Rackmount Keyboard with USB, FR
1U Rackmount Keyboard with USB, ITL
1U Rackmount Keyboard with USB, SP
1U Rackmount Keyboard with USB, DEN
1U Rackmount Keyboard with USB, NOR
1U Rackmount Keyboard with USB, SE/FI
1U Rackmount Keyboard with USB, SWI
1U Rackmount Keyboard with USB, PORT
1U Rackmount Keyboard with USB, BEL
1U Rackmount Keyboard with USB, JPN2
1U Rackmount Keyboard with USB, RUS
1U Rackmount Keyboard with USB, INTL
http://www.hp.com/go/rackandpower
.
AF044A
AF045A
AG052A
AG053A
AG054A
AG055A
AG056A
AG057A
AG058A
AG059A
AG060A
AG061A
AG062A
AG063A
AG064A
AG065A
AG066A
AG072A
AG073A
AG074A
AG075A
AG076A
AG077A
AG078A
AG079A
AG080A
AG081A
AG082A
AG083A
AG084A
AG085A
AG086A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 32
Page 33
QuickSpecs
Additional Options
NOTE:
For additional information regarding Rack Options, please see the following URL:
HP KVM Switch Options
2x1x16 IP Console Switch with Virtual Media
4x1x16 IP Console Switch with Virtual Media
2x16 Server Console Switch with Virtual Media
PS/2 Virtual Media Interface Adapter, 1 pack
NOTE:
Requires PS/2 and one USB port on server.
Server console switch 0x2x8
Server console switch 0x2x16
PS/2 Interface Adapter, 1 pack
PS/2 Interface Adapter, 8 pack
NOTE:
Cat5e cables are required to connect Interface Adapters to Console Switches. Cat5e cables can be found at the following URL:
http://www.hp.com/go/kvm
HP 1x4 Console Switch
HP PS2 Server Console Cable, 6 foot, 2-Pack
HP USB Server Console Cable, 6 foot, 2-Pack
NOTE:
Required for supporting USB peripherals.
NOTE:
For additional information regarding KVM switches, Serial Console servers, rack mount monitors, keyboards and all related options please see the following URL:
HP Serial Console Server Options
HP 16 Port Serial Console Server (worldwide)
HP 48 Port Serial Console Server (worldwide)
Serial Adapter, RJ45-DB9 DCE Female, 1 Pack
Serial Adapter, RJ45-DB9 DCE Female, 8 Pack
NOTE:
Cat5e cables are required to connect Serial Adapters to Serial Console Servers. Additional Serial Adapters and Cat5e cables can be found at the following URL:
NOTE:
For additional information regarding KVM switches, Serial Console servers, rack mount monitors, keyboards and all related options please see the following URL:
http://www.hp.com/go/rackandpower
.
http://www.hp.com/go/kvm
http://www.hp.com/go/kvm
http://www.hp.com/go/kvm
.
.
.
HP ProLiant DL380 Generation 6
.
AF601A
AF602A
AF600A
AF604A
AF616A
AF617A
262588-B21
262587-B21
AF611A
AF612A
AF613A
AF101A
AF102A
AF103A
AF110A
USB Options
HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)
1.44MB External USB Floppy Drive
HP USB 04 Standard Keyboard
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
DC172B
DC141B
DT528A#ABA
Page 33
Page 34
QuickSpecs
Additional Options
HP ProLiant DL380 Generation 6
Service and Support Offerings
(HP Care Pack Services)
Hardware Services On-site Service
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic
Hardware Services 6-Hour Call to Repair On-site Service
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic
Installation & Start-up Services
Hardware Installation, Electronic
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic
Installation and Startup for Essentials Rapid Deployment Pack, Electronic
Support Plus
Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic
Support Plus 24
Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
Onsite HW support 24x7, 4hr response and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
Onsite HW support 24x7, 4hr response and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
NOTE:
For more information, customer/resellers can contact:
http://www.hp.com/services/carepack
U4544E
U4545E
U4546E
U4554E
U4555E
U5683E
U4556E
U4557E
U6312E
U8334E
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 34
Page 35
QuickSpecs
HP ProLiant DL380 Generation 6

Memory

NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
DDR3 memory population guidelines
For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
Some DIMM installation guidelines are summarized below:
For servers with eighteen (18) memory slots:
There are three (3) channels per processor; six (6) channels per server There are three (3) DIMM slots for each memory channel; eighteen (18) total slots Memory channel 1 consists of the three (3) DIMMs that are closest to the processor
Memory channel 3 consists of the three (3) DIMMs that are furthest from the processor DIMM slots that are white should be populated first Do not mix Unbuffered memory (UDIMMs) with Registered memory (RDIMMs) Do not install DIMMs if the corresponding processor is not installed If only one processor is installed in a 2CPU system, only half of the DIMM slots are available To maximize performance, balance the total memory capacity between all installed processors It is not required, but it is recommended to load the channels similarly if possible You can only have up to eight (8) ranks installed per channel You can only install two quad-rank DIMMs per channel You can only install two UDIMMs per channel; if available, the third slot in the channel must remain empty Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel Heaviest load (DIMM with most ranks) within a channel goes furthest from the chipset For memory mirroring mode, channel 3 must be unpopulated. Channels 1 and 2 are populated identically For lock-step mode, channel 3 must be unpopulated. DIMMs in channels 1 and 2 will be installed in pairs. The paired slots will be 1,4; 2,5; 3;6 on a 3DPC system or 1,4; 2,5; on a 2DPC system No mixing DIMM voltage; all DIMMs must be the same voltage
DIMM Type -> DIMM Rank -> DIMM Capacity -> DIMM Native Speed
(MHz) ->
SLOTS THAT CAN BE POPULATED
18 slot servers
MAXIMUM CAPACITY (GB)
18 slot servers
POPULATED DIMM SPEED (MHz)
1 DIMM Per Channel
2 DIMM Per Channel
3 DIMM Per Channel
* - supported with ROM update via ROM Based Setup Utility (RBSU). UDIMM support is only on 12-slot servers
NOTES:
2GB 4GB 8GB 8GB 4GB
1333 1333 1067 1333 1067 1067 1333 1333
18 18 18 18 12 12 12 12
36 72 144 144 48 192 12 24
1333 1333 1067 1333 1067 1067 1333 1333
1333
*
800 800 800 800
Registered Dimms (RDIMMs)
Dual Rank (2R)
1333
*
1067 1333
*
Unbuffered with ECC DIMMs (UDIMMs)
Quad Rank (4R)
16GB
800 800 1067 1067
*
n/a n/a n/a
Single Rank (1R)
1GB 2GB
Dual Rank (2R)
Mixing DIMM speeds is allowed, but the system processor speed rules always override the DIMM capabilities If you do mix DIMM speeds, the memory bus will default to the minimum clock rate of all DIMMs in the system - even if the slower DIMM is on the other processor If you install 1x 1066MHz DIMM in channel 1 and 1x 1333MHz DIMM in channel 2, you still run at 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 35
Page 36
QuickSpecs
HP ProLiant DL380 Generation 6
Memory
other channels, you run at 1066MHz If you install 3DPC in one channel (if applicable) and 1DPC in all other channels, you run at 800MHz 95 Watt CPU's are required for 1333MHz DIMM speeds. All other CPU's are capable of up to 1067MHz References to the above MHz speeds are for the various speeds of DDR3 DIMMs; 1333 refers to DDR3-1333, etc.
DIMM slot and configuration diagrams Basic memory slot & population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
18 DIMM SLOTS (9 per CPU node)
Chnl 1
Chnl 2
Chnl 3
Standard memory configuration (1 CPU model)
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G D A
H E B
I
F
C
slot #
1 2 3
4 5 6
7 8 9
population order
G D A
H E B
I
F
C
Chnl 1
Chnl 2
Chnl 3
6GB, consisting of three (3) 2GB dual-rank PC3-10600 RDIMMs
Chnl 1
Chnl 2
Chnl 3
Standard memory plus optional memory (1 CPU model)
54GB, consisting of three (3) 2GB RDIMMs plus six (6) 8GB RDIMMs
3x 2GB dual-rank PC3-10600 RDIMMs 6x 8GB dual-rank PC3-8500 RDIMMs
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; empty D; empty
A; 2GB DIMM
H; empty E; empty
B; 2GB DIMM
I; empty
F; empty
C; 2GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; empty A; empty
H; empty E; empty B; empty
I; empty
F; empty
C; empty
Chnl 1
Chnl 2
Chnl 3
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 36
Page 37
QuickSpecs
Memory
HP ProLiant DL380 Generation 6
Chnl 1
Chnl 2
Chnl 3
Standard memory replaced with optional memory (1 CPU model) RDIMM maximum configuration (1 CPU model)
96GB, consisting of six (6) 16GB quad-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
slot #
1 2 3
4 5 6
7 8 9
slot #
1 2 3
4
CPU1 CPU2
population order
G; 8GB DIMM D; 8GB DIMM
A; 2GB DIMM
H; 8GB DIMM
E; 8GB DIMM B; 2GB DIMM
I; 8GB DIMM
F; 8GB DIMM
C; 2GB DIMM
CPU1 CPU2
population order
G; empty D; 16GB DIMM A; 16GB DIMM
H; empty
slot #
1 2 3
4 5 6
7 8 9
slot #
1 2 3
4
population order
G; empty D; empty A; empty
H; empty E; empty B; empty
I; empty
F; empty
C; empty
population order
G; empty D; empty A; empty
H; empty
Chnl 1
Chnl 2
Chnl 3
Chnl 1
Chnl 2
5 6
Chnl 3
UDIMM maximum configuration (1 CPU model)
12GB, consisting of six (6) 2GB dual-rank PC3-10600 UDIMMs
Chnl 1
Chnl 2
Chnl 3
7 8 9
slot #
1 2 3
4 5 6
7 8 9
E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
CPU1 CPU2
population order
G; empty
D; 2GB DIMM
A; 2GB DIMM
H; empty
E; 2GB DIMM B; 2GB DIMM
I; empty
F; 2GB DIMM
C; 2GB DIMM
5 6
7 8 9
slot #
1 2 3
4 5 6
7 8 9
E; empty B; empty
I; empty
F; empty
C; empty
population order
G; empty D; empty A; empty
H; empty E; empty B; empty
I; empty
F; empty
C; empty
Chnl 3
Chnl 1
Chnl 2
Chnl 3
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 37
Page 38
QuickSpecs
HP ProLiant DL380 Generation 6
Memory
Standard memory replaced with optional memory (2 CPU model) RDIMM maximum configuration (2 CPU model)
192GB, consisting of twelve (12) 16GB quad-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
Chnl 3
UDIMM maximum configuration
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; empty D; 16GB DIMM A; 16GB DIMM
H; empty E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty D; 16GB DIMM A; 16GB DIMM
H; empty E; 16GB DIMM B; 16GB DIMM
I; empty
F; 16GB DIMM
C; 16GB DIMM
Chnl 1
Chnl 2
Chnl 3
24GB, consisting of twelve (12) 2GB dual-rank PC3-10600 UDIMMs
Chnl 1
Chnl 2
Chnl 3
NOTE:
Capacity references are rounded to the common Gigabyte values.
1GB = 1024MB 2GB = 2048MB 4GB = 4096MB 8GB = 8192MB 16GB = 16384MB
slot #
1 2 3
4 5 6
7 8 9
CPU1 CPU2
population order
G; empty
D; 2GB DIMM
A; 2GB DIMM
H; empty E; 2GB DIMM B; 2GB DIMM
I; empty
F; 2GB DIMM
C; 2GB DIMM
slot #
1 2 3
4 5 6
7 8 9
population order
G; empty
D; 2GB DIMM
A; 2GB DIMM
H; empty E; 2GB DIMM B; 2GB DIMM
I; empty
F; 2GB DIMM
C; 2GB DIMM
Chnl 1
Chnl 2
Chnl 3
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 38
Page 39
QuickSpecs
Memory
Following are memory options available from HP:
Memory
Registered DIMMs (RDIMMs)
HP 2GB 2Rx8 PC3-10600R-9 Kit
HP 4GB 2Rx4 PC3-10600R-9 Kit
HP 4GB 4Rx8 PC3-8500R-7 LP Kit
HP 8GB 2Rx4 PC3-8500R-7 Kit
HP 8GB 2Rx4 PC3-10600R-9 Kit
HP 16GB 4Rx4 PC3-8500R-7 Kit
Unbuffered with ECC DIMMs (UDIMMs)
HP 1GB 1Rx8 PC3-10600E-9 Kit
HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE:
All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE:
ProLiant Energy Efficient Features, see:
Kits described as LP include Low Power DIMMs. For more information on
HP ProLiant DL380 Generation 6
www.hp.com/go/ddr3memory-configurator
www.hp.com/go/proliant-energy-efficient
500656-B21
500658-B21
500660-B21
516423-B21
500662-B21
500666-B21
500668-B21
500670-B21
.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 39
Page 40
QuickSpecs

Storage

Drive Support
1-8
1-16
1-6
HP ProLiant DL380 Generation 6
Eight SFF SAS hot plug hard drive bays
Sixteen SFF SAS hot plug hard drive bays
NOTE:
This configuration does not support optical
drive.
Six LFF SAS hot plug hard drive bays
NOTE:
This configuration does not support optical
drive.
Removable Media
HP Slim SATA DVD RW Optical Drive
NOTE:
Included in
performance models.
HP Slim SATA DVD­ROM Optical Drive
Hard Drives
NOTE:
The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
SAS Hot Plug SFF Enterprise (ENT) Drives
300GB 3G SAS 10K DP 300GB 6G SAS 10K DP 146GB 6G SAS 10K DP 146GB 6G SAS 15K DP 146GB 3G SAS 15K DP 146GB 3G SAS 10K DP 72GB 6G SAS 15K DP 72GB 3G SAS 10K DP 72GB 3G SAS 15K DP
NOTE:
Second SFF drive cage requires second controller or HP SAS Expander Card (PN 468406-B21).
SAS Hot Plug 3.5" Enterprise (ENT) Drives
450GB 3G SAS 15K DP 400GB 3G SAS 10K DP 300GB 3G SAS 15K DP 146GB 3G SAS 15K DP 72GB 3G SAS 15K DP
Quantity
Supported
Only 1 available
removable media bay
Only 1 available
removable media bay
Quantity
Supported
Up to 8
Quantity
Supported
Up to 6
Position
Supported
Slimline bay
Slimline bay
Position
Supported
1-8
Position
Supported
1-6
Controller
Integrated SATA
NOTE:
Optional
Integrated SATA
NOTE:
Optional
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 40
Page 41
QuickSpecs
Storage
SAS Hot Plug SFF Midline (MDL) Drives
500GB 6G SAS 7.2K DP
SAS Hot Plug 3.5" Midline (MDL) Drives
1TB 3G SAS 7.2K DP 750GB 3G SAS 7.2K DP
SATA Hot Plug SFF Midline (MDL) Drives
500GB 3G SATA 7.2K 160GB 3G SATA 7.2K
SATA Hot Plug 3.5" Midline (MDL) Drives
1TB 3G SATA 7.2K 750GB 3G SATA 7.2K 500GB 3G SATA 7.2K 250GB 3G SATA 7.2K
SATA Hot Plug 3.5" Entry (ETY) Drives
160GB 3G SATA 7.2K
SATA Hot Plug SFF Entry (ETY) Drives
Quantity
Supported
Up to 8
Quantity
Supported
Up to 6
Quantity
Supported
Up to 8
Quantity
Supported
Up to 6
Quantity
Supported
Up to 6
Position
Supported
1-8
Position
Supported
1-6
Position
Supported
1-8
Position
Supported
1-6
Position
Supported
1-6
HP ProLiant DL380 Generation 6
HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 41
Page 42
QuickSpecs
Storage
HP ProLiant DL380 Generation 6
250GB 3G SATA 5.4K 120GB 1.5G SATA 5.4K
NOTE:
External Storage
50 Modular Smart Array
60 Modular Smart Array
70 Modular Smart Array
HP 2000sa Modular Smart Array Controller
Second SFF drive cage requires second controller or HP SAS Expander Card (PN 468406-B21).
Quantity
Supported
Up to 8
Quantity
Supported
Up to 4
Up to 4
Up to 8
Up to 2
Up to 4
Up to 4
Position
Supported
1-8
Position
Supported
External
External
External
External
External
External
Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller HP Smart Array P410/256 MB Controller HP Smart Array P410/512 MB BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
Host Controller or Adapter
HP Smart Array P800/512 BBWC Controller
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
HP Smart Array P212/Zero Memory Controller HP Smart Array P212/ 256 MB Controller
HP Smart Array P800/512 BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 MB BBWC Controller
HP SC08Ge Host Bus Adapter
Maximum Storage Capacity
Internal
External
Total
Maximum Storage Capacity
Internal
External
Total
Tape and Disk-Based Backup
NOTE:
For a complete listing of compatible tape and disk-based backup offerings, please visit:
HP StorageWorks SCSI Tape Drives, External
LTO-1 Ultrium 232 LTO-2 Ultrium 448 LTO-3 Ultrium 960 LTO-3 Ultrium 920 LTO-4 Ultrium 1760 LTO-4 Ultrium 1840
- (with MSA50, SAS HDD)
2.4TB (16 x 300GB SAS SFF with addition 8 SFF drive cage)
6.720TB (20 x 300GB SAS SFF)
4.088TB
- (with MSA50, SATA HDD)
4.0TB (16 x 250GB SAS SFF with additional 8 SFF drive cage)
5.0TB (20 x 250GB SAS SFF)
9.0TB
Position
Supported
External
Controller
HP SC11Xe Host Bus Adapter
www.hp.com/go/connect
Part Number
412911-B21
.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 42
Page 43
QuickSpecs
HP ProLiant DL380 Generation 6
Storage
DAT 40 DAT 72 DAT 160 1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks USB Tape Drives, External
DAT 40 USB DAT 72 USB DAT 160 USB 1U Rack-Mount Kit
HP StorageWorks SAS Tape Drives, External
DAT 160 SAS LTO-2 Ultrium 448 SAS LTO-3 Ultrium 920 SAS LTO-4 Ultrium 1760 SAS LTO-4 Ultrium 1840 SAS 1U Rack-Mount Kit 3U Rack-Mount Kit
HP StorageWorks SCSI Tape Automation, External
DAT 72x10 Autoloader 1/8 G2 Autoloader MSL2024 MSL4048 MSL8096 MSL6000
HP StorageWorks SAS Tape Automation, External
1/8 G2 Autoloader MSL2024 MSL4048 MSL8096
HP StorageWorks Fibre Tape Automation, External
MSL2024 MSL4048 MSL8096 MSL6000
HP StorageWorks RDX Removable Disk Backup System
RDX160 RDX320 RDX500
External
External
External
External
External
Internal
USB 2.0 Port
HP Smart Array P212/Zero Memory Controller
HP SC11Xe Host Bus Adapter
HP Smart Array P212/Zero Memory Controller
NOTE:
Please visit: about minimum SAS controller firmware version and SAS cabling requirements.
Please consult the EBS connectivity matrix at:
http://www.hp.com/go/ebs
USB 2.0
NOTE:
RDX160 (AP724A), RDX320 (AP725A), or RDX500 (AP726A) are the required SKUs for mounting inside a HP ProLiant DL380 G6.
http://www.hp.com/go/connect
for detailed connectivity information.
for details
N/A
462828-B21
412911-B21
462828-B21
N/A
N/A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 43
Page 44
QuickSpecs
HP ProLiant DL380 Generation 6
Storage
HP StorageWorks D2D Backup Systems
D2D120 D2D130 D2D2500i D2D4000i
External
Embedded Network Controller
N/A
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 44
Page 45
QuickSpecs

Power Specifications

HP 460W Power Supply Part Number - AC 460W PSU
Input Voltage Range (Vrms) Frequency Range (Nominal)
(Hz) Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Nominal Input Current (A rms) Max Rated Input Wattage Rating
(Watts) Max. Rated VA (Volt-Amp) Efficiency (%) at Max. Rated
Output Wattage Power Factor Leakage Current (mA) Max. Inrush Current (A peak) Max. Inrush Current duration
(mS) Maximum British Thermal Unit
Rating (BTU-Hr)
HP 750W Power Supply Part Number - AC 750W PSU
Input Voltage Range (Vrms) Frequency Range (Nominal)
(Hz) Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Nominal Input Current (A rms) Max Rated Input Wattage Rating
(Watts) Max. Rated VA (Volt-Amp) Efficiency (%) at Max. Rated
Output Wattage Power Factor Leakage Current (mA) Max. Inrush Current (A peak) Max. Inrush Current duration
(mS) Maximum British Thermal Unit
Rating (BTU-Hr)
HP ProLiant DL380 Generation 6
503296-B21 100 to 240 50/60
100 120 208 200 220 230 240
460 460 460 460 460 460 460
5.5 4.5 2.6 2.5 2.4 2.3 2.2
526 520 505 505 503 503 503
548 542 527 527 524 524 524
87.5 88.5
0.97 0.97 0.97 0.97 0.97 0.97 0.97
0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30 20 20 20 20 20 20 20
1794 1773 1725 1725 1715 1715 1715
512327-B21 100 to 240 50/60
100 120 208 200 220 230 240
750 750 750 750 750 750 750
8.9 7.4 4.3 4.1 3.9 3.7 3.6
857 847 824 825 820 820 820
894 884 859 859 854 854 854
87.5 88.5
0.97 0.97 0.97 0.97 0.97 0.97 0.97
0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30 20 20 20 20 20 20 20
2925 2892 2812 2812 2797 2797 2797
91 91
91 91
91.5 91.5 91.5
91.5 91.5 91.5
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 45
Page 46
QuickSpecs
Power Specifications
HP 1200W Power Supply Part Number - AC
Operational Input Voltage Range (Vrms)
Frequency Range (Nominal) (Hz)
Nominal Input Voltage (Vrms)
Maximum Rated Output Wattage Nominal Input Current (A rms) Max Rated Input Wattage Rating
(Watts) Max. Rated VA (Volt-Amp) Efficiency (%) at Max. Rated
Output Wattage Power Factor Leakage Current (mA) Max. Inrush Current (A peak) Max. Inrush Current duration
(mS) Maximum British Thermal Unit
Rating (BTU-Hr)
HP 1200W PSU 48VDC Input Part Number Input Voltage Range (DCV) Frequency Range (Nominal) (Hz) Nominal Input Voltage (VDC)
Maximum Rated Output Wattage Nominal Input Current (ACD) Max Rated Input Wattage Rating (Watts) Max. Rated VA (Volt-Amp) Efficiency (%) at Max. Rated Output Wattage Power Factor Leakage Current (mA) Max. Inrush Current (A peak) Max. Inrush Current duration (mS) Maximum British Thermal Unit Rating (BTU-Hr)
500172-B21 100 to 240
50/60
100 120 208 200 220 230 240
800 900 1200 1200 1200 1200 1200
9.7 9.0 7.0 6.8 6.4 9.1 5.9
930 1034 1348 1348 1348 1348 1348
970 1079 1406 1406 1406 1406 1406
86 87 89 89 89 89 89
0.97 0.97 0.97 0.97 0.97 0.97 0.97
0.42 0.50 0.83 0.87 0.92 0.96 1.00 30 30 30 30 30 30 30 20 20 20 20 20 20 20
3174 3530 4600 4600 4600 4600 4600
HP ProLiant DL380 Generation 6
437573-B21 36-72 DC
36 48 72
1200 1200 1200
38 28 19 1380 1350 1365 1380 1350 1365
87 89 88
N/A N/A N/A N/A N/A N/A
20 25 35
1 1 3
4713 4610 4662
NOTES:
www.hp.com/go/proliant-energy-efficient
To review typical system power ratings use the HP Power Advisor which is available online located at url:
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
or
www.hp.com/go/hppoweradvisor
Page 46
Page 47
QuickSpecs

Technical Specifications

HP ProLiant DL380 Generation 6
System Unit
Dimensions
(with bezel)
Weight
Input Requirements
(per power supply)
BTU Rating
Power Specifications
Power Supply Output
(per power supply)
(H x W x D)
(approximate)
SFF Drives: 3.38 x 17.54 x 27.25 in (8.59 x 44.55 x 69.22 cm) LFF Drives: 3.38 x 17.54 x 29.25 in (8.59 x 44.55 x 74.30 cm)
Maximum (all hard drives, power supply, and processor installed)
Minimum (one hard drive, power supply, and processor installed)
Rated Line Voltage
Rated Input Current
Rated Input Frequency
Rated Input Power
Maximum
NOTE:
To review typical system power ratings use the HP Power Advisor which is available online located at url:
energy-efficient
Rated Steady-State Power
Maximum Peak Power
or
www.hp.com/go/hppoweradvisor
60.00 lb (27.27 kg)
47.18 lb (21.45 kg)
100 to 120 VAC 200 to 240 VAC
For 1200 W Power Supply: 10 A (at 100 VAC),
4.9 A (at 200 VAC) For 750 W Power Supply:
8.9 A (at 100 VAC),
4.3 A (at 200 VAC) For 460 W Power Supply:
5.5 A (at 100 VAC),
2.6 A (at 200 VAC)
50 to 60 Hz
For 1200 W Power Supply: 930 W (at 100 VAC), 1348 W (at 200 VAC) For 750 W Power Supply: 857 W (at 100 VAC), 824 W (at 200 VAC) For 460 W Power Supply: 526 W (at 100 VAC), 505 W (at 200 VAC)
For 1200 W Power Supply: 3530 BTU/hr (at 100 VAC), 4600 BTU/hr (at 200 VAC) For 750 W Power Supply: 2925 BTU/hr (at 100 VAC), 2812 BTU/hr (at 200 VAC) For 460 W Power Supply: 1794 BTU/hr (at 100 VAC), 1725 BTU/hr (at 200 VAC)
www.hp.com/go/proliant-
For 1200 W Power Supply: 800 W (at 100 VAC), 900 W (at 120 VAC), 1200 W (at 200 to 240 VAC) For 750 W Power Supply: 750 W (at 100 to 120 VAC), 750 W (at 200 to 240 VAC) For 460 W Power Supply: 460 W (at 100 to 120 VAC), 460 W (at 200 to 240 VAC)
For 1200 W Power Supply: 800 W (at 100 VAC),
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 47
Page 48
QuickSpecs
Technical Specifications
System Inlet Temperature
Relative Humidity
(non-condensing)
Altitude
Acoustic Noise
Emissions Classification (EMC)
HP ProLiant DL380 Generation 6
900 W (at 120 VAC), 1200 W (at 200 to 240 VAC) For 750 W Power Supply: 750 W (at 100 to 120 VAC), 750 W (at 200 to 240 VAC) For 460 W Power Supply: 460 W (at 100 to 120 VAC), 460 W (at 200 to 240 VAC)
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA
74) and declared in accordance with ISO 9296 (ECMA 109).
NOTE:
configurations. Additional options may result in increased sound levels.
Idle
Operating
FCC Rating
Normative Standards
The Listed sound levels apply to standard shipping
LWAd
LpAm
LWAd
LpAm
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed. System performance may be reduced if operating with a fan fault or above 30°C (86°F).
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non­condensing.
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing.
3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
1P SKU 2P SKU
4.1 B 4.7 B
22 dBA 28 dBA
1P SKU 2P SKU
4.1 B 4.7 B
22 dBA 28 dBA
Class A
CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 48
Page 49
QuickSpecs
Technical Specifications
HP ProLiant DL380 Generation 6
NOTE:
Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.
NOTE:
configurations. Additional options may result in increased sound levels.
The Listed sound levels apply to standard shipping
Smart Array P410i Controller
Dimensions
including bracket)
Disk Drive and Enclosure Interface ­transfer rate
SAS Connectors
Cache Memory Speed
Server Interface
SAS Speed
Cache Memory
Logical Drives Supported
Maximum Logical Drive Capacity
Host Memory Addressing
RAID Support
Upgradeable Firmware
(not
Low Profile PCIe Form Factor
7.5 in x 9.5 in x 2.25 in (19.05 cm x 24.13 cm x 5.72 cm)
3G SAS (Serial Attached SCSI)
1.5G SATA (Serial ATA)
2 internal (Mini-SAS) x8 wide port connectors
DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum bandwidth.
x8 2.5G PCIe 2.0 provides 2GB/s maximum bandwidth
x8 3G SAS provides 2.4GB/s maximum bandwidth
40-bit 256MB ECC protected cache (72-bit 512MB BBWC module upgrades available); transportable with battery-backed upgrade
Up to 32 logical drives
Greater than 2TB
64-bit, supporting greater than 4GB server memory space
RAID 6, 6+0 (Advanced Data Guarding)
NOTE:
The minimum of 256 MB cache, battery kit, and Smart Array
Advanced Pack License Key upgrade is required to enable RAID 6, 6+0
RAID 5, 5+0 (Distributed Data Guarding)
NOTE:
The 256 MB & Battery Kit upgrade is required to enable RAID 5,
5+0 support of the Smart Array P410i.
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware with Recovery ROM feature
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 49
Page 50
QuickSpecs
Technical Specifications
HP ProLiant DL380 Generation 6
HP NC382i Dual Port Multifunction Gigabit Server Adapters
Network Interface
Compatibility
Data Transfer Method
Network Transfer Rate
Connector
Cable Support
10Base-T/100Base-TX/1000Base-TX
EEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ad 1000Base-TX
IEEE 802.1p 100Base-TX
IEEE 802.1q 100Base-TX
PCI Express, four lanes (x4)
10Base-T (Half-Duplex)
10Base-T (Full-Duplex)
100Base-TX (Half­Duplex)
100Base-TX (Full­Duplex)
1000Base-TX (Half and Full-Duplex)
Two RJ-45
10Base-T
100Base-TX
1000BaseTX
10 Mb/s
20 Mb/s
100 Mb/s
200 Mb/s
2000Mb/s
Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
Category 5 or higher UTP; up to 328 ft (100 m)
Category 5 or higher UTP; up to 328 ft (100 m)
Environment-friendly Products and Approach
© Copyright 2009 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation.
Intel, the Intel logo, Xeon and Xeon Inside are trademarks of Intel Corporation in the U.S. and other countries.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
http://www.hp.com/go/green http://www.hp.com/go/green
http://www.hp.com/go/green
. To recycle your product, or contact your nearest HP
. These
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009
Page 50
Loading...
