QuickSpecs
Overview
Ultra-slim Desktop
Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
HP recommends
HP recommends
HP recommendsHP recommends
Windows Vista® Business
Windows Vista® Business
Windows Vista® BusinessWindows Vista® Business
1.
Rear I/O: (6) USB 2.0, (1) DisplayPort, (2) PS/2, (1) RJ-45, (1)
VGA port, (1) audio in, (1) audio out
2.
(1) 2.5” internal hard disk drive bay
3.
Front I/O: (2) USB 2.0, headphone and microphone
4.
135W 87% efficient external power adapter
5.
Tower stand (sold separately)
DA - 13029 North America — Version 15 — March 30, 2009
6.
7.
8.
9.
(1) Optical disk drive (slimline)
HP 2-button optical scroll mouse
HP keyboard
HP Monitor (sold separately)
Page 1
QuickSpecs
Overview
Small Form Factor
Small Form Factor
Small Form FactorSmall Form Factor
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
1.
HP Monitor (sold separately)
2.
Rear I/O: (6) USB 2.0, (1) serial port, (2) PS/2, (1) RJ-45, (1)
VGA port, (1) DisplayPort, (1) audio in, (1) audio out
Optional: 2nd serial port, (1) parallel port, (1) eSATA port
3.
(1) low profile PCI slot, (1) low profile PCI Express x1 slot, (2)
low profile PCI Express x16 slots
(
NOTE:
NOTE:
2nd x16 slot has x4 connectivity.
NOTE:NOTE:
4.
Front I/O: (2) USB 2.0, headphone and microphone
5.
HP 2-button optical scroll mouse
)
6.
7.
8.
9.
10.
HP keyboard
(1) 3.5-inch external drive bay supporting media card
reader, diskette drive, or secondary hard disk drive
(1) Optical disk drive
(1) 3.5-inch internal drive bay supporting primary hard disk
drive
240-watt standard efficiency power supply
Optional: 85% efficient energy saving power supply
DA - 13029 North America — Version 15 — March 30, 2009
Page 2
QuickSpecs
Overview
Convertible Minitower
Convertible Minitower
Convertible MinitowerConvertible Minitower
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
1.
(2) Optical disk drives
(2) 3.5” internal hard disk drive bays
2.
365-watt standard efficiency power supply, Active Power
Factor Correction (PFC)
Optional: 85% efficient energy saving power supply
3.
(1) 5.25” removable media drive bay
4.
Rear I/O: (6) USB 2.0, (1) serial port, (2) PS/2, (1) RJ-45, (1)
VGA, (1) DisplayPort, (1) audio in, (1) audio out
Optional: 2nd serial port, (1) parallel port, (1) eSATA port
5.
Media card reader or Floppy disk drive
6.
Front I/O: (2) USB 2.0, headphone and microphone
7.
(3) full-height PCI slots, (1) full-height PCI Express x1 slot, (2)
full-height PCI Express x16 slots
(
NOTE:
NOTE:
2nd x16 slot has x4 connectivity.
NOTE:NOTE:
8.
HP 2-button optical scroll mouse
9.
HP keyboard
10.
HP Monitor (sold separately)
)
DA - 13029 North America — Version 15 — March 30, 2009
Page 3
QuickSpecs
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Overview
At A Glance
At A Glance
At A GlanceAt A Glance
Designed for long-term deployment within commercial and institutional organizations
Guaranteed lengthy purchase lifecycles and image stability
Integrated dual monitor support via both a VGA and DisplayPort monitor interface
Optional 85% efficient power supplies
ENERGY STAR qualification for dc7900e models
Intel® Q45 Express chipset featuring Intel's Graphics Media Accelerator 4500
Software image fully compatible across all models and form factors
BIOS developed and engineered by HP for better security, manageability and software image stability
Created using industry leading Design for Environment standards
Supports industry standard management protocols including DASH, Intel Standard Manageability, and Intel Core 2 Processor
with vPro Technology (on select models)
CMT and SFF models can be configured with multiple hard disk drives in a RAID array
Selected configurations with global availability easily set up and ordered through HP.com Business to Business portals
(
http://h10019.www1.hp.com/business-site/index.html
Tailored HP Factory Express deployment and lifecycle services available
(
http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx
Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions
and exclusions apply)
Tool-less serviceability features for easier upgrades and repairs
Choice of professional chassis form factors to accommodate the desired mix between expandability and size
)
)
* TPM module and cryptographic software disabled where use is restricted by law; for example, Russia and China.
DA - 13029 North America — Version 15 — March 30, 2009
Page 4
QuickSpecs
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Configurable Components - Select Models (localized by Regions)
Model Key and Example
Model Key and Example
Model Key and ExampleModel Key and Example
NOTE:
NOTE:
This diagram is an example that illustrates how to read the model number. It is not intended to give every available
NOTE:NOTE:
configuration choice specified in the body of this document and may include references to modules that are out of date and no
longer available.
DA - 13029 North America — Version 15 — March 30, 2009
Page 5
QuickSpecs
Standard Features and Configurable Components
Operating System -
Operating System -
Operating System -Operating System One of the following
Preinstalled
Preinstalled
PreinstalledPreinstalled
Supported
Supported
SupportedSupported
Certified
Certified
CertifiedCertified
* Certain Windows Vista product features require advanced or additional hardware. See:
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
www.microsoft.com/windowsvista/getready/capable.mspx
can help you determine which features of Windows Vista will run on your computer. To download the
tool, visit:
+ Windows Vista Business disk may be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions) and is
expected to order at least 25 customer systems with the same custom image.
† The following features are not supported on Linux certified systems:
www.windowsvista.com/upgradeadvisor
Genuine Windows Vista Business 32
Genuine Windows Vista Business 64
Genuine Windows Vista Home Basic 32
Genuine Windows Vista Ultimate 32
Genuine Windows Vista Business with downgrade to Windows XP
Professional custom installed
FreeDOS
Genuine Windows XP Home Edition
Genuine Windows XP Professional
SUSE Linux Enterprise Desktop
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
*
*
*
*
*+
†
†
and
for details. WindowsVista Upgrade Advisor
.
HP 22-in-1 Media Card Reader
HP 1.44-MB External USB Diskette Drive
TPM 1.2 Security Chip
Intel Pro 1000 PT PCIe x1 Gigabit NIC
Broadcom NetXtreme Gigabit Ethernet Plus PCIe NIC
HP 802.11b/g/n Wireless PCIe x1 Card (SFF and MT)
Intel WiFi Link 5100 a/b/g/n (USDT) Wireless NIC
Agere PCI 56K International SoftModem
LSI PCIe x1 56K International SoftModem
ATI Radeon 3470 256MB SH PCIe x16 graphics card
ATI Radeon HD 2400XT 256MB DH PCIe x16 graphics card
ATI Radeon HD 3650 512MB DH PCIe x16 graphics card
NVIDIA Quadro NVS 290 256MB dual head graphics adapter
HP USB Smartcard Keyboard
HP 2nd Serial Port
Parallel port adapter
eSATA port adapter
HP FireWire / IEEE 1394 PCI Card
DA - 13029 North America — Version 15 — March 30, 2009
Page 6
QuickSpecs
Standard Features and Configurable Components
Value-added Software
Value-added Software
Value-added SoftwareValue-added Software
(included with all models;
not included with
FreeDOS)
Value-added Software
Value-added Software
Value-added SoftwareValue-added Software
(included with select
models; not included with
FreeDOS)
HP ProtectTools Security Suite
HP Backup and Recovery Manager
HP Insight Diagnostics
† Not included on models configured with less than 1 GB system memory.
* Computrace agent is in HP BIOS. For tracking and tracing services, available in select countries,
separate software and purchase of a subscription is required.
Computer Setup Utility
McAfee Total Protection Anti-Virus
Sonic/Roxio Easy Media Creator 9
or
Roxio Business Creator 10
HP Power Manager v2.0
HP Total Care Advisor
Microsoft Office 2007 Basic
† Not included on models configured with less than 1 GB system memory.
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
†
†*
†
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
HP Software Management Agent
PDF Complete
Computrace for Desktops (in the HP BIOS)
Microsoft Office 2007 Personal
Microsoft Office 2007 Professional
Microsoft Office 2007 Small Business
Microsoft Works 8.5
Firefox-HP Virtual Browser
Corel WinDVD 8
*
HP Client Management
HP Client Management
HP Client ManagementHP Client Management
Solutions
Solutions
SolutionsSolutions
(available for free
download from the Web
http://www.hp.com/go/
easydeploy
Value-added Services and
Value-added Services and
Value-added Services andValue-added Services and
Features
Features
FeaturesFeatures
)
HP Client Configuration Manager Basic Edition
HP Client Manager for Altiris
HP SoftPaq Download Manager
HP Client Catalog for Microsoft SMS
HP Stable Platform Program
Business-to-Business Portals
HP Global Series Services
TPM 1.2 security module
* TPM module disabled where use is restricted by law; for example, Russia.
*
HP Out-of-Band Management Console
(for Intel management technology enabled models)
Altiris Out-of-Band Management Solution (for Intel
AMT enabled models)
HP Systems Software Manager
Factory Express Deployment and Lifecycle Services
Intel Standard Manageability
Intel Core 2 processor with vPro Technology
DA - 13029 North America — Version 15 — March 30, 2009
Page 7
QuickSpecs
Standard Features and Configurable Components
Service and Support
Service and Support
Service and SupportService and Support
On-site Warranty and Service1: This three-year (3-3-3), limited warranty and service offering delivers
three years of parts, labor and on-site repair. Response time is next business-day2 and includes free
telephone support3 24 x 7. Global coverage2 ensures that any product purchased in one country and
transferred to another non-restricted country will remain fully covered under the original warranty and
service offering. Some countries/regions do not offer one year onsite and labor.
1
Terms and conditions may vary by country. Certain restrictions and exclusions apply.
2
On-site service may be provided pursuant to a service contract between HP and an authorized HP
third-party provider, and is not available in certain countries. Global service response times are based on
commercially reasonable best effort and may vary by country.
3
Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party hardware
and software. Toll-free calling and 24 x 7 support may not be available in some countries.
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Dimensions
Dimensions
DimensionsDimensions
Chassis Dimensions
(H x W x D)
Optional Tower Stand
Dimensions (H x W x D)
System weight
System volume
Shipping weight
Maximum supported
weight (desktop orientation)
Shipping box dimensions
(H x W x D)
* Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
Standard Efficiency Power
Standard Efficiency Power
Standard Efficiency PowerStandard Efficiency Power
Supply
Supply
SupplySupply
Energy Efficient Power
Energy Efficient Power
Energy Efficient PowerEnergy Efficient Power
Supply
Supply
SupplySupply
Ports
Ports
PortsPorts
USB 2.0
Serial
Parallel
eSATA
PS/2
Video
DVI output
*
*
External power supply dimensions:
Ultra-slim Desktop
Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
2.60 x 9.90 x 10 in
(66.0 x 251.5 x 254 mm)
1.26 x 4.82 x 6.69 in
(32.0 x122.3 x 170.0 mm)
7.0 lb (3.18 kg)
4.21 liters
14.34 lb (6.52 kg)
77.1 lb (35 kg) 77.1 lb (35 kg) 77.1 lb (35 kg)
8.60 x 15.68 x 19.68 in
(218.4 x 398.3 x 499.9 mm)
Ultra-slim Desktop
Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
N/A
135W active PFC
87% efficient
6.7 x 2.6 x 1.5 in
Total length of external power
supply and power cord:
12 feet 8 inches
N/A
N/A
N/A
available via ADD2 card or optional DisplayPort to DVI adapterr
Small Form Factor
Small Form Factor
Small Form FactorSmall Form Factor
3.95 x 13.3 x 14.9 in
(100.3 x 337.8 x 378.5)
1.05 x 6.95 x 7.83 in
(26.75 x 176.46 x 198.87 mm)
18.75 lb (8.50 kg) 26.2 lb (11.89 kg)
13 liters 36 liters
26.10 lb (11.86 kg) 34.60 lb (15.72 kg)
9.00 x 19.68 x 23.38 in
(228.6 x 499.9 x 593.85 mm)
Small Form Factor
Small Form Factor
Small Form FactorSmall Form Factor
240W active PFC 365W active PFC
240W active PFC
85% efficient
(8) Total
(2) front, (6) rear
(1) keyboard; (1) mouse
(1) VGA; (1) DisplayPort
Convertible Minitower
Convertible Minitower
Convertible MinitowerConvertible Minitower
17.63 x 7.0 x 17.8 in
(447.8 x 177.8 x 452.12 mm)
24.25 x 12.33 x 22.13 in
(616.0 x 313.2 x 562.1 mm)
Convertible Minitower
Convertible Minitower
Convertible MinitowerConvertible Minitower
365W active PFC
85% efficient
(1) Standard
Optional 2nd port available
Optional (1)
Optional (1)
N/A
DA - 13029 North America — Version 15 — March 30, 2009
Page 8
QuickSpecs
Standard Features and Configurable Components
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Support for Multi-Monitor
Audio
NIC (RJ-45)
Slots
Slots
SlotsSlots
Type and quantity
Slot specifications
Chipset
Chipset
ChipsetChipset
Processor and Speed
Processor and Speed
Processor and SpeedProcessor and Speed
One of the following
*
Dual monitor support standard
Rear – input (supports microphone or line input), line out
Integrated Intel 82567LM GbE Network Connection
(1) mini PCI Express
Intel Q45 Express chipset featuring Intel GMA 4500 DirectX 10 graphics
Intel Celeron Dual-Core Processors:
Intel Celeron Dual-Core Processors:
Intel Celeron Dual-Core Processors:Intel Celeron Dual-Core Processors:
Intel Celeron dual-core E1200 processor
1.6 GHz, 512 KB L2 cache, 800 MHz FSB
Intel Celeron dual-core E1400 processor
2.0 GHz, 512 KB L2 cache, 800 MHz FSB
Intel Pentium dual-core Processors:
Intel Pentium dual-core Processors:
Intel Pentium dual-core Processors:Intel Pentium dual-core Processors:
Intel Pentium dual-core E5200 processor
2.5 GHz, 2 MB L2 cache, 800 MHz FSB
Intel Core 2 Duo Processors:
Intel Core 2 Duo Processors:
Intel Core 2 Duo Processors:Intel Core 2 Duo Processors:
Intel Core 2 Duo E7200 processor
2.53 GHz, 3 MB L2 cache, 1066 MHz FSB
Intel Core 2 Duo E7300 processor
2.66 GHz, 3 MB L2 cache, 1066 MHz FSB
Intel Core 2 Duo E8400 processor
3.0 GHz, 6 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
Intel Core 2 Duo E8500 processor
3.16 GHz, 6 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
Intel Core 2 Duo E8600 processor
3.33 GHz, 6 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
Intel Core 2 Quad Processors:
Intel Core 2 Quad Processors:
Intel Core 2 Quad Processors:Intel Core 2 Quad Processors:
Intel Core 2 Quad Q8200 processor
2.33 GHz, 4 MB L2 cache, 1333 MHz FSB
Dual monitor support standard; >
2 via ADD2 card or optional
graphics cards
Front – mic and headphone
(1) PCI
(1) PCI Express x1
(2) PCI Express x16
Accommodates low profile
cards only
Graphics slots support 35W
cards
2nd PCIe x16 slot functions
electrically as a x4
Dual monitor support standard; >
2 via ADD2 card or optional
graphics cards
(3) PCI
(1) PCI Express x1
(2) PCI Express x16
Accommodates full height
cards
1st graphics slot supports
75W card; 2nd graphics
slot support 35W card
2nd PCIe x16 slot functions
electrically as a x4
USDT
USDT
USDTUSDT
SFF
SFF
CMT
CMT
SFFSFF
CMTCMT
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X
DA - 13029 North America — Version 15 — March 30, 2009
Page 9
QuickSpecs
Standard Features and Configurable Components
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Intel Core 2 Processor
Intel Core 2 Processor
Intel Core 2 ProcessorIntel Core 2 Processor
with vPro Technology
with vPro Technology
with vPro Technologywith vPro Technology
Intel Core 2 Quad Q9400 processor
2.66 GHz, 6 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
Intel Core 2 Quad Q9550 processor
2.83 GHz, 12 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
Intel Core 2 Quad Q9650 processor
3.0 GHz, 12 MB L2 cache, 1333 MHz FSB
Featuring Core 2 Processor with vPro Technology
All dc7900 Series models featuring this technology include processors which are
part of the Intel 2008 Stable Image Platform Program (SIPP) designed to ensure
the stability promise inherent in the value proposition of the HP Compaq dc7900
Series business desktop, thus making these model the most stable, secure, and
manageable platforms available to enterprises today.
The 2008 SIPP processors are:
Core 2 Duo E8400, E8500, E8600
Core 2 Quad Q9400, Q9550, Q9650
Intel's Core 2 Processor with vPro Technology suite of features includes:
Intel Active Management Technology
Intel Active Management Technology
Intel Active Management TechnologyIntel Active Management Technology
an advanced set of remote management features and functionality which
provides network administrators the latest and most effective tools to
remotely discover, heal, and protect networked client systems regardless of
the system's health or power state. Intel Active Management Technology
includes all features described as part of Intel Standard Manageability plus
the following advanced management functions:
Fast Call for Help
Fast Call for Help
Fast Call for HelpFast Call for Help
a call for help via BIOS screen, periodic connections, or alert
triggered connection
Remote Scheduled Maintenance
Remote Scheduled Maintenance
Remote Scheduled MaintenanceRemote Scheduled Maintenance
connects to the IT or service provider console for maintenance.
Remote PCs can get required patches, be inventoried, etc by
connecting to their IT console or Service Provider when it's convenient
Remote Alerts
Remote Alerts
Remote AlertsRemote Alerts
arise
Access Monitor
Access Monitor
Access MonitorAccess Monitor
support security requirements
Microsoft NAP Support
Microsoft NAP Support
Microsoft NAP SupportMicrosoft NAP Support
Allows Intel Active Management Technology to gain access to a Microsoft
NAP enabled 802.1x network OOB to enable OOB SW updates,
inventories, remote diagnostics, etc. NAP is a new platform and solution
that controls access to network resources based on a client computer's
identity and compliance with corporate governance policy. NAP allows
network administrators to define granular levels of network access based on
who a client is, the groups to which the client belongs, and the degree to
which that client is compliant with corporate governance policy. If a client is
– a client inside or outside the firewall may initiate
– pre-schedule when the PC
– automatically alert IT or service provider if issues
– Provides oversight into Intel® AMT actions to
X X
X X
X X
X X X
DA - 13029 North America — Version 15 — March 30, 2009
Page 10
QuickSpecs
Standard Features and Configurable Components
not compliant, NAP provides a mechanism to automatically bring the client
back into compliance and then dynamically increase its level of network
access.
When a client attempts to access the network or communicate on the
network, it must present its system health state or proof of health
compliance. If a client cannot prove it is compliant with system health
requirements (for example, that it has the latest operating system and
antivirus updates installed), its access to the network or communication on
the network can be limited to a restricted network containing server
resources so that health compliance issues can be remedied. After the
updates are installed, the client requests access to the network or attempts
the communication again. If compliant, the client is granted unlimited
access to the network or the communication is allowed.
Memory
Memory
MemoryMemory
DDR2 SYNCH DRAM NON-ECC MEMORY
DDR2 SYNCH DRAM NON-ECC MEMORY
DDR2 SYNCH DRAM NON-ECC MEMORYDDR2 SYNCH DRAM NON-ECC MEMORY
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes.
This chart does not represent all possible memory configurations. The HP Compaq dc7900 business
desktop supports non-ECC DDR2 PC2-5300 (667-MHz) and PC2-6400 (800-MHz) memory.
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
RAID
RAID
RAIDRAID
CAUTION:
CAUTION:
CAUTION:CAUTION:
removing memory modules. Regardless of the power-on state, voltage is always supplied to the memory
modules as long as the computer is plugged in to an active AC outlet. Adding or removing memory
modules while voltage is present may cause irreparable damage to the memory modules or system
board.
HP recommends dual-channel symmetric configurations for maximum performance.
HP recommends dual-channel symmetric configurations for maximum performance.
HP recommends dual-channel symmetric configurations for maximum performance.HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds.
For dual-channel symmetric performance, the total amount of memory in each channel must be equal. If
speeds are mixed, speed will default to the slowest DIMM.
Redundant Array of Independent Drives
Redundant Array of Independent Drives
Redundant Array of Independent DrivesRedundant Array of Independent Drives
Fl
exible implementation:
NOTE:
NOTE:
NOTE: NOTE:
factory configurations. The pre-configured systems:
You must shut down the computer and disconnect the power cord before adding or
DriveLock is supported while in RAID mode. Users can manage DriveLock password from within
F10 Setup. Locked drives will be displayed as such in the RAID option ROM interface.
Hard drive information can be viewed within F10 Setup while in RAID mode. Previously, the hard
drives will not appear in Drive Configuration when switching to RAID mode.
DPS Self Test can be executed on physical hard drives while in RAID mode.
The RAID Setup Utility (accessed through CTRL-I) can be protected by the F10 Setup password.
RAID 1 is the only RAID configuration that HP Compaq dc7900 Business PC products offer as
Are only available on the CMT and SFF form factors. The USDT does not support RAID as it does
not allow for more than one hard disk drive.
Are complete RAID systems and have both drives installed.
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is mirrored mode out of the box.
DA - 13029 North America — Version 15 — March 30, 2009
Page 11
QuickSpecs
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Standard Features and Configurable Components
Please refer to the HP White Paper titled "Advanced Host Controller Interface (AHCI) and Redundant
Array of Independent Disks (RAID) on HP Compaq dc7900 Business PCs" at
information and instructions.
Ultra-slim Desktop
Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
Maximum Memory
Maximum Memory
Maximum MemoryMaximum Memory
2-GB
2-GB
2-GB2-GB
4-GB
4-GB
4-GB4-GB
8-GB maximum
8-GB maximum
8-GB maximum8-GB maximum
* The Intel Q45 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability functions.
Management Engine memory is shared with system memory. If the PC contains a single SO-DIMM, 16 MB of memory is preallocated for it at system startup. If the PC contains two SO-DIMMs, 32 MB of memory is pre-allocated. This memory is not made
available to the operating system, just as pre-allocated video memory is not available.
Small Form Factor and Convertible Minitower
Small Form Factor and Convertible Minitower
Small Form Factor and Convertible MinitowerSmall Form Factor and Convertible Minitower
Maximum Memory
Maximum Memory
Maximum MemoryMaximum Memory
DIMM Size
DIMM Size
DIMM SizeDIMM Size
512-MB
512-MB
512-MB512-MB
1-GB
1-GB 1-GB
1-GB1-GB
2-GB
2-GB
(dual-channel
2-GB2-GB
symmetric)
4-GB
4-GB
(dual-channel
4-GB4-GB
symmetric)
8-GB
8-GB
(dual-channel
8-GB8-GB
symmetric)
16-GB maximum
16-GB maximum
16-GB maximum16-GB maximum
(dual-channel symmetric)
*
SO-DIMM Size
SO-DIMM Size
SO-DIMM SizeSO-DIMM Size
512-MB
512-MB
512-MB512-MB
1-GB
1-GB 1-GB
1-GB1-GB
(dual-channel symmetric)
(dual channel symmetric)
(dual channel symmetric)
*
1111
Supports up to 8 GB of DDR2 SYNCH DRAM using SO-DIMM modules. Slot 1 is black and must always
be populated. Not all memory configurations possible are represented below.
NOTE:
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
NOTE:NOTE:
memory may not be available due to system resource requirements.
Slot
Slot
SlotSlot
1111
Supports up to 16 GB of DDR2 SYNCH DRAM using DIMM modules. Slot 1 is black and must
always be populated. Not all memory configurations possible are represented below.
NOTE:
NOTE:
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
NOTE:NOTE:
memory may not be available due to system resource requirements. Addressing memory above 4
GB requires a 64-bit operating system.
Channel A
Channel A
Channel AChannel A
(black)
512-MB
1-GB
1-GB 1-GB 1-GB 1-GB
2-GB 2-GB 2-GB 2-GB
4-GB 4-GB 4-GB 4-GB
Channel A
Channel A
Channel AChannel A
(black)
512-MB
1-GB 1-GB
2-GB 2-GB
4-GB 4-GB
Slot
Slot
SlotSlot
2222
(white)
3333
(white)
1-GB
http://www.hp.com
Channel B
Channel B
Channel BChannel B
2222
(white)
Channel B
Channel B
Channel BChannel B
4444
for more
(white)
DA - 13029 North America — Version 15 — March 30, 2009
Page 12
QuickSpecs
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Standard Features and Configurable Components
* The Intel Q45 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability functions.
Management Engine memory is shared with system memory. If the PC contains a single DIMM, 16 MB of memory is pre-allocated for
it at system startup. If the PC contains two DIMMs, 32 MB of memory is pre-allocated. This memory is not made available to the
operating system, just as pre-allocated video memory is not available.
Memory Configurations –
Memory Configurations –
Memory Configurations –Memory Configurations –
One of the following
Expandability
Expandability
ExpandabilityExpandability
PCI slots
Max power per slot
PCI Express x16 slot (Also
functions as SDVO/ADD2
Slot)
Max power per slot
PCI Express x1 slot
Max power per slot
External Bays
3.5”
5.25”
Slimline
Internal 2.5” HDD Bays
Internal 3.5” HDD Bays
512-MB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 512)
1-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 1GB)
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (1 x 2GB)
2-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 1GB)
3-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (3 x 1GB)
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 1GB)
4-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (2 x 2GB)
8-GB DDR2 Synch Dram PC2-6400 (800-MHz) Non ECC (4 x 2GB)
16-GB DDR2 Synch Dram PC2-6400 (800-Mhz) Non ECC (4 x 4GB)
USDT
USDT
USDTUSDT
N/A
N/A
N/A
N/A
N/A
N/A
(1) Total (2) Total (4) Total
N/A
N/A
128w x 127d x 12.7h mm
(1)
N/A
(1) LP (2.5”), length (6.6”)
(2) FH (4.2”), length (6.875”) via
optional riser card.
NOTE:
NOTE:
NOTE:NOTE:
PCIe x1 and PCIe x16 slots are
(2) LP (2.5”), length (6.6”)
(1) LP (2.5”), length (6.6”)
unless used for a secondary hard
(1) for primary hard drive
NOTE:
NOTE:
NOTE: NOTE:
be installed in 3.5”
external bay if not used for
SFF
SFF
SFFSFF
standard;
With optional riser card,
not accessible.
25W 25W
35W
10W 10W
(1)
drive
(1) 8.189” length (2) 8.189” length
N/A N/A
N/A N/A
Secondary hard drive can
external device.
(3) FH (4.2"), length (10.5”)
(2) FH (4.2”), full-length
75W max if 1 16x slot,
35W each if both PCIe 16 slots
(1) FH (4.2”), full-length
(2) dedicated for HDDs
NOTE:
NOTE:
NOTE: NOTE:
can be installed in 3.5”
external bay if not used for
USDT
USDT
USDTUSDT
(1) 5.71” length
A third hard drive
external device.
SFF
SFF
SFFSFF
X X X
X X X
X X X
X X X
X X
CMT
CMT
CMTCMT
X X
X X X
X X
X X
(1)
CMT
CMT
CMTCMT
DA - 13029 North America — Version 15 — March 30, 2009
Page 13
QuickSpecs
Standard Features and Configurable Components
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Hard Drive Controller (PCI)
Supported
Hard Drive and Optical
SATA Interfaces Supported
Host Controller for SATA
Ultra-slim Desktop
Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
Serial ATA
support for SATA 1.5-Gb/s and 3.0-Gb/s hard drives
(1) Serial ATA interface
Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description of the
hardware/software interface between system software and the host controller hardware.
Small Form Factor
Small Form Factor
Small Form FactorSmall Form Factor
(3) Serial ATA interfaces
(1) Serial ATA for eSATA
(4) Serial ATA interfaces
(1) Serial ATA for eSATA
Convertible Minitower
Convertible Minitower
Convertible MinitowerConvertible Minitower
Storage - Drive Support
Storage - Drive Support
Storage - Drive SupportStorage - Drive Support
Quantity Supported
Quantity Supported
Quantity SupportedQuantity Supported
Position Supported
Position Supported
Position SupportedPosition Supported
Controller
Controller
ControllerController
USDT
USDT
USDTUSDT
Slimline
Slimline
SlimlineSlimline
Optical
Optical
OpticalOptical
Drives
Drives
DrivesDrives
1111 1111 1111 1111 2222 1111 2222 3333
SATA
SATA SATA
SATASATA
2.5” Hard
2.5” Hard
2.5” Hard2.5” Hard
Disk Drive
Disk Drive
Disk DriveDisk Drive
or Solid
or Solid
or Solidor Solid
State Drive
State Drive
State DriveState Drive
(right angle,
(right angle,
(right angle,(right angle,
no cable)
no cable)
no cable)no cable)
SATA
SATASATA
DA - 13029 North America — Version 15 — March 30, 2009
Diskette
Diskette
DisketteDiskette
Drive or
Drive or
Drive orDrive or
Media Card
Media Card
Media CardMedia Card
Reader
Reader
ReaderReader
Diskette
Diskette
DisketteDiskette
Controller
Controller
ControllerController
or
or
oror
USB header
USB header
USB headerUSB header
on PCA
on PCA
on PCAon PCA
SFF
SFF
SFFSFF
5.25”
5.25”
5.25”5.25”
Optical
Optical
OpticalOptical
Drives
Drives
DrivesDrives
SATA
SATA SATA
SATASATA
Hard Disk
Hard Disk
Hard DiskHard Disk
Drives
Drives
DrivesDrives
SATA
SATASATA
CMT
CMT
CMTCMT
Diskette
Diskette
DisketteDiskette
Drive or
Drive or
Drive orDrive or
Media Card
Media Card
Media CardMedia Card
Reader
Reader
*
ReaderReader
,
, ,
, ,
Diskette
Diskette
DisketteDiskette
Controller
Controller
ControllerController
or
or
oror
USB header
USB header
USB headerUSB header
on PCA
on PCA
on PCAon PCA
5.25”
5.25”
5.25”5.25”
Optical
Optical
OpticalOptical
Drives
Drives
DrivesDrives
SATA
SATA SATA
SATASATA
, ,
, ,
Hard Disk
Hard Disk
Hard DiskHard Disk
Drives
Drives
DrivesDrives
, ,,,,
, ,
SATA
SATASATA
Page 14
QuickSpecs
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Standard Features and Configurable Components
* To have both a diskette drive and a media card reader in the Convertible Minitower, it is necessary to order it with a diskette drive
in position 4 and then purchase a media card reader as an after-market option kit (which contains a 5.25" bracket) and install it in
position 3.
Hard Drives (SATA)
Hard Drives (SATA)
Hard Drives (SATA)Hard Drives (SATA)
80 GB Hard Drive (2.5”)
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
160 GB Hard Drive (2.5”)
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
250 GB Hard Drive (2.5”)
8MB cache, 7200 RPM, 3.0 GB/s, NCQ, Smart IV
80 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
80 GB Hard Drive
16MB cache, 10,000 RPM, 3.0 GB/s, NCQ, Smart III
80 GB Hard Drive (removable)
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
160 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
160 GB Hard Drive
16MB cache, 10,000 RPM, 3.0 GB/s, NCQ, Smart III
160 GB Hard Drive (removable)
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
250 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
250 GB Hard Drive (removable)
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
500 GB Hard Drive
16MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
USDT
USDT
USDTUSDT
X
X
X
SFF
SFF
SFFSFF
X X
X X
X X
X X
X X
X X
X X
X X
X X
CMT
CMT
CMTCMT
DA - 13029 North America — Version 15 — March 30, 2009
Page 15
QuickSpecs
Standard Features and Configurable Components
Removable Storage
Removable Storage
Removable Storage Removable Storage
One or more of the
following depending on
form factor (see Storage –
Drive Support section
above)
Media Card Reader –
Media Card Reader –
Media Card Reader –Media Card Reader –
One of the following
–
Diskette Drives
Diskette Drives
Diskette DrivesDiskette Drives
1.44-MB Diskette Drive
5.25” Optical Drives (SATA)
5.25” Optical Drives (SATA)
5.25” Optical Drives (SATA)5.25” Optical Drives (SATA)
DVD-ROM Drive
SuperMulti LightScribe DVD Writer Drive
Slimline Optical Drives (SATA)
Slimline Optical Drives (SATA)
Slimline Optical Drives (SATA)Slimline Optical Drives (SATA)
DVD-ROM Drive
SuperMulti LightScribe DVD Writer Drive
1
For playing DVDs, Corel WinDVD 8
2
For writing CDs, choice of Sonic/Roxio Easy Media Creator 9 or
Roxio Business Creator 10
3
For writing CDs and DVDs, video editing and authoring DVDs, choice of
Sonic/Roxio Easy Media Creator 9
or
Roxio Business Creator 10
HP 22-in-1 Media Card Reader
HP 22-in-1 Media Card Reader with 1394 port
1
1,2,3
1,2,3
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
X X
X X
X X
X
X
X X
X X
Security
Security
SecuritySecurity
TPM 1.2 TPM Security Chip
TPM Pre-Boot Authentication (via BIOS)
Smartcard Pre-boot Authentication (via BIOS)
Stringent Security** (via BIOS)
SATA port disablement (via BIOS)
Drive Lock
RAID configurations
HP ProtectTools Embedded Security Software
Serial, Parallel, USB Enable/Disable (via BIOS)
Optional USB Port Disable at factory (user configurable via BIOS)
Removable Media Write/Boot Control
Power-On Password (via BIOS)
Setup Password (via BIOS)
Solenoid Hood Lock / Sensor
HP Security Lock Kit
Support for chassis padlocks and cable lock devices
* TPM module disabled where use is restricted by law; for example, Russia.
** This setting is defaulted to disable, but when enabled, the PW jumper will not
clear the BIOS pre-boot authentication passwords.
*
X X X
X X X
X X X
X X X
X X X
X X X
X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
DA - 13029 North America — Version 15 — March 30, 2009
Page 16
QuickSpecs
Standard Features and Configurable Components
NIC
NIC
NICNIC
Wireless
Wireless
WirelessWireless
Modem
Modem
ModemModem
Graphics
Graphics
GraphicsGraphics
Intel 82567LM GbE Network Connection (integrated on system board)
Intel Gigabit CT Desktop NIC
Broadcom NetXtreme Gigab Ethernet + NIC AV FS601AV
NOTE:
NOTE:
The integrated network connection is required to support the vPro
NOTE:NOTE:
technology features.
* Available after initial product release; use of this network card disables the vPro
technology features.
HP 802.11 b/g/n PCIe x1 Wireless card
Intel WiFi Link 5100 a/b/g/n (USDT) Wireless NIC
NOTE:
NOTE:
These wireless network solutions disable the vPro technology features.
NOTE:NOTE:
Agere 2006 PCI 56K International SoftModem
LSI PCIe x1 Hi-Speed 56K International SoftModem
Intel Graphics Media Accelerator 4500 (integrated on chipset)
ATI Radeon 3470 256MB SH PCIe x16 graphics card
ATI Radeon HD 2400XT 256MB DH PCIe x16 graphics card
ATI Radeon HD 3650 512MB DH PCIe x16 graphics card
NVIDIA Quadro NVS 290 256MB DH PCIe x16 graphics card
HP ADD2 SDVO PCIe DVI-D adapter
HP DisplayPort to VGA Adapter
*
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
X X X
X X
X X
X
X X X
X X X
X X
X X
X X
X X
X
X X
X X
Audio
Audio
AudioAudio
Integrated HD audio with AD1884A codec (all ports are stereo)
Microphone and Headphone front ports
Line-out and Line-In rear ports
Multistreaming capable
Internal Speaker (standard)
HP Thin USB Powered Speakers
* Rear audio input ports are re-taskable as Line-in or Microphone-in. External
speakers must be powered externally. Multistreaming can be enabled in the ADI
control panel to allow independent audio streams to be sent to/from the front and
rear jacks. This allows for different audio applications to use separate audio ports
on the system. For example, the front jacks could be used with a headset for a
communications application while the rear jacks are being used with external
speakers and a multimedia application.
DA - 13029 North America — Version 15 — March 30, 2009
*
*
X X X
X X X
X X X
X X X
X X X
X X X
Page 17
QuickSpecs
Standard Features and Configurable Components
Input Devices
Input Devices
Input DevicesInput Devices
Miscellaneous
Miscellaneous
MiscellaneousMiscellaneous
Keyboard
Keyboard
KeyboardKeyboard
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
HP USB Smartcard Keyboard
Mouse
Mouse
- One of the following
MouseMouse
HP PS/2 2-button Optical Scroll Mouse
HP USB 2-button Optical Scroll Mouse
HP USB 2-Button Laser Scroll Mouse
HP FireWire (IEEE 1394) PCI Card
PCI riser card for SFF - adds 2 full-height PCI slots
NOTE:
NOTE:
Low profile slots are unusable with riser card installed.
NOTE:NOTE:
Serial port adapter
Parallel port adapter
eSATA port adapter
Tower stand
Configure dc7900 CMT in desktop orientation
Rear Port Control Cover
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
X X X
X X X
X X X
X X X
X X X
X X X
X X
X
X X
X X
X X
X X
X
X
DA - 13029 North America — Version 15 — March 30, 2009
Page 18
QuickSpecs
After-Market Options (availability may vary by region)
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
Office 2007 Media-less
Office 2007 Media-less
Office 2007 Media-lessOffice 2007 Media-less
License Kits (MLKs)
License Kits (MLKs)
License Kits (MLKs)License Kits (MLKs)
Communications
Communications
CommunicationsCommunications
USDT
USDT
USDTUSDT
MS Office Basic Edition 2007 – Media-less License Kit
MS Office Small Business Edition 2007 – Media-less License Kit
MS Office Professional Edition 2007 – Media-less License Kit
Wireless
Wireless
WirelessWireless
HP Wireless 802.11 b/g/n PCIe x1
NICs
NICs
NICsNICs
Broadcom NetXtreme Gigabit Ethernet Plus PCIe NIC
Intel PRO/1000 CT Network Connection (GbE PCIe x1 NIC)
Modem
Modem
ModemModem
LSI PCIe x1 Hi-Speed 56K International SoftModem
Connectivity
Connectivity
ConnectivityConnectivity
Bundle Connectivity Starter Kit – Surge Protector/LAN
cable/Printer cable
* available after initial product release
NOTE:
NOTE:
The use of a PCI Express network card (wired or wireless) will disable the vPro
NOTE:NOTE:
technology features.
X X X
X X X
X X X
SFF
SFF
SFFSFF
X X
X X
X X
X X
X X
CMT
CMT
CMTCMT
After-Market
After-Market
After-MarketAfter-Market
Options Part
Options Part
Options PartOptions Part
Number
Number
NumberNumber
RZ361A#ABA
RZ365A#ABA
RZ363A#ABA
FH971AA
FS215AA
FH969AA
(launching
3/30/09)
FH970AA
RT174AA
Graphics
Graphics
GraphicsGraphics
Single head solutions
Single head solutions
Single head solutionsSingle head solutions
ATI Radeon 3470 256MB SH PCIe x16
Multi head solutions
Multi head solutions
Multi head solutionsMulti head solutions
ATI Radeon HD 2400XT 256MB DH PCIe x16
ATI Radeon HD 3650 512MB DH PCIe x16
ATI HD 4550 PCIe x16 (256GB/DDR3) Dual Head Graphics
Card
X X
X X
X X
X
(launching May
FH972AA
KD060AA
KS505AA
AT042AA
09)
DA - 13029 North America — Version 15 — March 30, 2009
Page 19
QuickSpecs
After-Market Options (availability may vary by region)
Hard Disk Drives
Hard Disk Drives
Hard Disk DrivesHard Disk Drives
Input/Output Devices
Input/Output Devices
Input/Output DevicesInput/Output Devices
Serial ATA Hard Drives
Serial ATA Hard Drives
Serial ATA Hard DrivesSerial ATA Hard Drives
HP 80-GB SATA (NCQ/Smart IV) 3.0-Gb/s HDD
HP 160-GB SATA (NCQ/Smart IV) 3.0-Gb/s HDD
HP 250-GB SATA (NCQ/Smart IV) 3.0-Gb/s HDD
HP 320-GB SATA (NCQ/Smart IV) 3.0-GB/s HDD
HP 500-GB SATA (NCQ/Smart IV) 3.0-GB/s HDD
HP eSATA Adapter
HP Removable SATA Hard Drive Enclosure (Frame & Carrier)
HP Removable SATA Hard Drive Enclosure (Carrier Only)
Wirelss Keyboard and Mouse
Wirelss Keyboard and Mouse
Wirelss Keyboard and MouseWirelss Keyboard and Mouse
2.4 GHz Wireless Keyboard and Mouse
Keyboards
Keyboards
KeyboardsKeyboards
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
HP USB Mini Keyboard
Pointing Devices
Pointing Devices
Pointing DevicesPointing Devices
HP PS/2 2-Button Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
HP USB 2-Button Laser Mouse
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PC
HP Compaq dc7900 Business PCHP Compaq dc7900 Business PC
X X
X X
X X
X X
X X
X X
X X
X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
PY276AA
PY277AA
PY278AA
FH963AA
KW347AA
FH966AA
RY102AA
RY103AA
NB896AA
DT527A
DT528A
AS601AA
(launching
3/30/09)
EY703AA
DC172B
GW405AA
Memory (non-ECC)
Memory (non-ECC)
Memory (non-ECC)Memory (non-ECC)
Monitors
Monitors
MonitorsMonitors
PC2-6400 (DDR2, 800 MHz) DIMM
PC2-6400 (DDR2, 800 MHz) DIMM
PC2-6400 (DDR2, 800 MHz) DIMMPC2-6400 (DDR2, 800 MHz) DIMM
Promo - 2GB (2 x 1GB) PC2-6400 DDR2-800
Promo - 4GB (2 x 2GB) PC2-6400 DDR2-800
HP 1 GB PC2-6400 (DDR2 800 MHz) DIMM
HP 2 GB PC2-6400 (DDR2 800 MHz) DIMM
HP 4 GB PC2-6400 (DDR2 800) DIMM
PC2-6400 (DDR2, 800 MHz) SODIMM
PC2-6400 (DDR2, 800 MHz) SODIMM
PC2-6400 (DDR2, 800 MHz) SODIMMPC2-6400 (DDR2, 800 MHz) SODIMM
HP 1 GB PC2-6400 (DDR2 800 MHz) SODIMM
HP 2 GB PC2-6400 (DDR2 800 MHz) SODIMM
HP 4 GB PC2-6400 (DDR2 800 MHz) SODIMM
CRTs
CRTs
CRTsCRTs
Business LCD Monitors
Business LCD Monitors
Business LCD MonitorsBusiness LCD Monitors
HP L1506 15-inch LCD Monitor
HP w15v 15-inch Widescreen LCD Monitor
HP w17e 17-inch LCD Monitor
HP L1710 17-inch LCD Monitor
DA - 13029 North America — Version 15 — March 30, 2009
X X X
X X X
X X
X X
X X
X
X
X
NQ604AT
NQ605AT
AH058AA
AH060AA
FH977AA
GM254AA
GV576AA
FH978AA
3PO Offering
PX848AA#ABA
FM745AA#ABA
GV537AA#ABA
GS917AA#ABA
Page 20
Loading...
