HP Compaq 8710p, Compaq 8710w Service Manual

HP Compaq 8710p Notebook PC and HP Compaq 8710w Mobile Workstation
Maintenance and Service Guide
© Copyright 2007, 2008 Hewlett-Packard Development Company, L.P.
AMD, the AMD Arrow logo, and combinations thereof, are trademarks of Advanced Micro Devices, Inc. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Java is a US trademark of Sun Microsystems, Inc. Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. SD Logo is a trademark of its proprietor.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Third Edition: July 2008
First Edition: June 2007
Document Part Number: 453579-003
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Product description
2 External component identification
Display components ............................................................................................................................. 7
Top components ................................................................................................................................... 8
Buttons, switches, and fingerprint reader ............................................................................ 8
Keys ..................................................................................................................................... 9
Lights ................................................................................................................................. 10
Pointing devices ................................................................................................................. 12
Front components .............................................................................................................................. 13
Left-side components ......................................................................................................................... 14
Rear component ................................................................................................................................. 15
Right-side components ....................................................................................................................... 15
Bottom components ........................................................................................................................... 16
3 Illustrated parts catalog
Serial number location ........................................................................................................................ 17
Computer major components ............................................................................................................. 18
Plastics Kit .......................................................................................................................................... 26
Cable Kit ............................................................................................................................................. 27
Mass storage devices ......................................................................................................................... 28
Miscellaneous parts ............................................................................................................................ 28
Sequential part number listing ............................................................................................................ 30
4 Removal and replacement procedures
Preliminary replacement requirements ............................................................................................... 37
Tools required .................................................................................................................... 37
Service considerations ....................................................................................................... 37
Plastic parts ....................................................................................................... 37
Cables and and pointing stick connectors ......................................................... 38
Drive handling ................................................................................................... 38
Grounding guidelines ......................................................................................................... 39
Electrostatic discharge damage ........................................................................ 39
v
Packaging and transporting guidelines ............................................. 40
Workstation guidelines ..................................................................... 40
Equipment guidelines ....................................................................... 41
Unknown user password ................................................................................................... 42
Component replacement procedures ................................................................................................. 43
Serial number .................................................................................................................... 43
Computer feet .................................................................................................................... 43
Battery ............................................................................................................................... 44
Display inverter and ambient light sensor board ................................................................ 45
Hard drive .......................................................................................................................... 48
Bluetooth module ............................................................................................................... 51
Primary memory module .................................................................................................... 52
WLAN module .................................................................................................................... 54
RTC battery ....................................................................................................................... 57
Optical drive ....................................................................................................................... 58
Keyboard ........................................................................................................................... 60
Expansion memory module ............................................................................................... 63
TouchPad .......................................................................................................................... 64
Modem module .................................................................................................................. 66
Switch cover ...................................................................................................................... 67
Power button board ........................................................................................................... 69
Fan/heat sink assembly ..................................................................................................... 70
Graphics card .................................................................................................................... 72
Heat sink ............................................................................................................................ 74
Processor ........................................................................................................................... 75
Display assembly ............................................................................................................... 77
Top cover ........................................................................................................................... 83
Speaker assembly ............................................................................................................. 85
System board ..................................................................................................................... 87
USB/audio board ............................................................................................................... 91
PC Card assembly ............................................................................................................. 92
5 Computer Setup
Starting Computer Setup .................................................................................................................... 94
Using Computer Setup ....................................................................................................................... 95
Computer Setup menus ..................................................................................................................... 96
vi
Navigating and selecting in Computer Setup ..................................................................... 95
Restoring factory settings in Computer Setup ................................................................... 95
File menu ........................................................................................................................... 96
Security menu .................................................................................................................... 97
Diagnostics menu .............................................................................................................. 97
System Configuration menu .............................................................................................. 98
6 Specifications
Computer specifications ................................................................................................................... 100
17.0-inch, WUXGA+WVA display specifications .............................................................................. 101
17.0-inch, WSXGA+WVA display specifications .............................................................................. 102
17.0-inch, WXGA+WVA display specifications ................................................................................ 103
Hard drive specifications .................................................................................................................. 104
DVD±RW and CD-RW Double-Layer Combo Drive specifications .................................................. 105
DVD/CD-RW Combo Drive specifications ........................................................................................ 106
DVD-ROM Drive ............................................................................................................................... 107
System DMA specifications .............................................................................................................. 108
System memory map specifications ................................................................................................. 108
System interrupt specifications ......................................................................................................... 109
System I/O address specifications ................................................................................................... 110
7 Screw listing
Phillips PM2.0×17.0 captive screw ................................................................................................... 113
Phillips PM2.5×13.0 captive screw ................................................................................................... 114
Phillips PM3.0×4.0 screw ................................................................................................................. 115
Phillips PM2.5×5.0 captive screw ..................................................................................................... 116
Phillips PM2.0×4.0 screw ................................................................................................................. 117
Torx TM2.5×9.0 screw ..................................................................................................................... 119
Torx TM2.5×4.0 screw ..................................................................................................................... 121
Phillips PM2.5×9.0 captive screw ..................................................................................................... 124
Torx T8M2.5×7.0 screw ................................................................................................................... 125
Phillips PM2.5×7.0 screw ................................................................................................................. 127
Torx T8M2.0×10.0 captive screw ..................................................................................................... 128
Hex Metric HM5.0×10.0 standoff ...................................................................................................... 129
Phillips PM2.5×7.0 captive screw ..................................................................................................... 130
Phillips PM2.0×6.0 screw ................................................................................................................. 131
8 Backup and recovery
Backup and recovery using Windows Vista ..................................................................................... 132
Creating recovery discs ................................................................................................... 132
Backing up your information ............................................................................................ 132
Performing a recovery ..................................................................................................... 135
When to back up ............................................................................................. 133
Backup suggestions ........................................................................................ 133
Backing up specific files or folders .................................................................. 133
Backing up the entire hard drive ..................................................................... 134
Creating recovery points ................................................................................. 135
Scheduling backups ........................................................................................ 135
Performing a recovery from the recovery discs ............................................... 136
Performing a recovery from the hard drive ...................................................... 136
vii
Backup and recovery using Windows XP ......................................................................................... 138
Creating recovery discs ................................................................................................... 138
Backing up your information ............................................................................................ 138
Performing a recovery ..................................................................................................... 141
9 Connector pin assignments
1394 ................................................................................................................................................. 144
Audio-out (headphone) ..................................................................................................................... 144
Audio-in (microphone) ...................................................................................................................... 145
External monitor ............................................................................................................................... 145
HDMI ................................................................................................................................................ 146
RJ-11 (modem) ................................................................................................................................ 147
RJ-45 (network) ................................................................................................................................ 148
Universal Serial Bus ......................................................................................................................... 149
Initiating a recovery in Windows ..................................................... 137
Initiating a recovery from the hard drive recovery partition ............. 137
When to back up ............................................................................................. 139
Backup suggestions ........................................................................................ 139
Backing up specific files or folders .................................................................. 139
Backing up the entire hard drive ..................................................................... 140
Creating recovery points ................................................................................. 141
Scheduling backups ........................................................................................ 141
Performing a recovery from the recovery discs ............................................... 142
Performing a recovery from the hard drive ...................................................... 142
Initiating a recovery in Windows ..................................................... 143
Initiating a recovery from the hard drive recovery partition ............. 143
10 Power cord set requirements
Requirements for all countries and regions ...................................................................................... 150
Requirements for specific countries and regions ............................................................................. 151
11 Recycling
Battery .............................................................................................................................................. 152
Display .............................................................................................................................................. 152
Index ................................................................................................................................................................. 158
viii

1 Product description

Category Description HP Compaq 8710w
Mobile Workstation
Product Name HP Compaq 8710w Mobile
Workstation
HP Compaq 8710p Notebook PC
Processors Intel® Core™ 2 Duo processors
T9300 2.5-GHz processor 6-MB L2
T8300 2.4-GHz processor 3-MB L2
T8100 2.1-GHz processor 3-MB L2
T7800 2.5-GHz processor 4-MB L2
T7700 2.4-GHz processor 4-MB L2
T7500 2.2-GHz processor 4-MB L2
T9500 2.6-GHz processor 6-MB L2 cache, 800-MHz FSB
cache, 800-MHz FSB
cache, 800-MHz FSB
cache, 800-MHz FSB
cache, 800-MHz FSB
cache, 800-MHz FSB
cache, 800-MHz FSB
HP Compaq 8710p Notebook PC
T7300 2.0-GHz processor 4-MB L2
cache, 800-MHz FSB
T7250 2.0-GHz processor 2-MB L2
cache, 800-MHz FSB
T7100 1.8-GHz processor 2-MB L2
cache, 800-MHz FSB
Chipset Northbridge: Intel 965PM with iAMT
support
Southbridge: Intel ICH8M-enhanced
Graphics nVidia NB8E-GLM (G84GLM-UU)
graphics card with 512-MB graphics subsystem memory operating at 800 MHz
nVidia NB8P-NVS2 (G84M-GT)
graphics card with 256-MB graphics
1
Category Description HP Compaq 8710w
Mobile Workstation
subsystem memory operating at 700 MHz (supports TurboCache)
OpenGL driver support
HP Compaq 8710p Notebook PC
Panel All display assemblies include 3 wireless
local area network (WLAN) antennae
17.0-inch WUXGA WVA AntiGlare
17.0-inch WSXGA+ WVA AntiGlare
17.0-inch WXGA+ AntiGlare
17.0-inch WSXGA+ Bright View
Supports privacy film
Memory 2 customer-accessible/upgradable
memory module slots
Supports dual-channel memory
Supports up to 8 GB of system RAM
PC2-5300, 667-MHz, DDR2
Supports the following configurations:
8192-MB total system memory
(4096 × 2, dual-channel)
6144-MB total system memory
(4096 + 2048)
5120-MB total system memory
(4096 + 1024)
√√
4608-MB total system memory
(4096 + 512)
4096-MB total system memory
(2048 × 2, dual channel
4096-MB total system memory
(4096 × 1)
3072-MB total system memory
(2048 + 1024)
2560-MB total system memory
(2048 + 512)
2048-MB total system memory
(1024 × 2, dual-channel)
2048-MB total system memory
(2048 × 1)
1536-MB total system memory
(1024 + 512)
1024-MB total system memory
(512 × 2, dual-channel)
2 Chapter 1 Product description
Category Description HP Compaq 8710w
Mobile Workstation
1024-MB total system memory
(1024 × 1)
512-MB total system memory (512
× 1)
Hard drives Supports 9.5-mm, 2.5-inch hard drives
Customer-accessible
Serial ATA
HP Compaq 8710p Notebook PC
Supports the following drives:
250-GB, 5400-rpm
200-GB, 7200--rpm
160-GB, 7200- and 5400-rpm
120-GB, 7200- and 5400-rpm
100-GB, 7200-rpm
80-GB, 7200- and 5400-rpm
HP 3D DriveGuard
Optical drives Fixed (removal of 1 screw required)
Customer-accessible
Parallel ATA
12.7-mm tray load
Supports the following drives:
DVD±RW and CD-RW Super Multi
Double-Layer Combo Drive with LightScribe
DVD±RW and CD-RW Super Multi
Double-Layer Combo Drive
DVD-CD/RW Combo Drive
Blu-Ray DVD-RW Combo Drive
DVD-ROM Drive
Diskette drive Supports external USB diskette drive
only
Supports boot from external USB
diskette drive
Supports 3-mode diskette drive
Microphone Integrated microphone
Audio HD audio - ADI1981
Modem 56K V.92 1.5-inch data/fax modem with
digital line guard
√√
3
Category Description HP Compaq 8710w
Mobile Workstation
HD audio interface
HP Compaq 8710p Notebook PC
Modem cable included in Brazil, the
Czech Republic, Europe, France, Greece, Hungary, Israel, Latin America, Poland, Russia, Saudi Arabia, Slovakia, Slovenia, South Africa, Turkey, and the United Kingdom
Ethernet Intel 82566MM 10/100/1000 network
S3/S4/S5 wake on LAN: DC - no
S3/S4/S5 wake on LAN: AC - yes
NIC power-down technology
Wireless Integrated WLAN options by way of wireless module:
Support for no-WLAN option
Support for the following WLAN formats:
interface card (NIC) with iAMT
Three WLAN antennae built into display assembly
Intel 802.11a/b/g/n with iAMT
support
Broadcom 802.11a/b/g
Intel 802.11a/b/g with iAMT
support
Broadcom 802.11b/g
Integrated personal area network (PAN) options by way of Bluetooth® module:
Broadcom Bluetooth
External media card One Type I/II PC Card slot, supporting
Media Card Reader slot supporting SD,
Ports Audio-in (mono microphone)
Audio-out (stereo headphone)
High-Definition Multimedia Interface
RJ-11 (modem)
RJ-45 (Ethernet, includes link and
USB (6) √√
Support for no-WPAN option
16-bit and 32-bit (Cardbus) PC Card modules
MMC, MS, MSP, xD, and Memory Stick Duo
(HDMI)
activity lights)
4 Chapter 1 Product description
Category Description HP Compaq 8710w
Mobile Workstation
HP Compaq 8710p Notebook PC
VGA (Dsub 15-pin) supporting 1600 ×
3-pin AC power
Docking HP 3-in-1 NAS Docking Station, HP
Keyboard/pointing devices
Dual point (pointing stick and
TouchPad only, with 2 TouchPad
Windows Vista™ Hardware Start Button
Power requirements The following AC adapters with localized
1200 external resolution at 75-GHz (hot plug/unplug with auto-detect)
Advanced Docking Station, and HP Docking Station
14.4-inch keyboard with separate numeric keypad
TouchPad) with 3 pointing stick buttons and 3 TouchPad buttons and vertical scrolling (taps enabled as default)
buttons and vertical scrolling (taps enabled as default)
cable plug support (3-wire plug with ground pin, supports 3-pin DC connector):
180-W PFC AC adapter
135-W PFC AC adapter
120-W non-PFC and PFC AC
adapters
90-W non-PFC and PFC AC
adapters
8-cell, 2.55-Ah (73-Wh) Li-ion battery
Support for 8-cell Extended Life Battery
Support for 12-cell Ultra Capacity
Security Full volume encryption
Integrated fingerprint reader
Integrated smart card reader
Preboot authentication (password,
Security cable slot
Trusted platform module (TPM) V.1.2
Operating system Preinstalled:
Battery
smart card)
Windows Vista Business 32/64
Windows Vista Home Basic 32 √√
5
Category Description HP Compaq 8710w
Mobile Workstation
Windows® XP Professional
FreeDOS
Preinstalled with Microsoft® Office:
HP Compaq 8710p Notebook PC
Windows Vista Business 32/64 with
Windows XP Professional with Office
Windows XP Professional with Office
Restore media:
Windows Vista Home Basic 32
Windows XP Professional
DRDVD XP
DRDVD Vista
Supported:
Certified:
Windows Vista Business 32/64 with Office 2007 Ready
Office 2007 Personal
2007 Ready
2007 Personal
Windows Vista Business 32/64
Windows® 2000
Linux
Serviceability End-user replaceable parts:
Battery (system)
Battery (RTC)
Hard drive
Memory module
Modem module
Optical drive
WLAN module √√
AC adapter
6 Chapter 1 Product description

2 External component identification

Display components

Item Component Function
(1) Ambient light sensor When activated, the sensor automatically adjusts the
display brightness based on the surrounding lighting conditions.
(2) Wireless antenna locations Send and receive wireless signals to communicate with
WLANs.
(3) Internal microphone Records sound.
Display components 7

Top components

Buttons, switches, and fingerprint reader

Item Component Function
(1) Power button
(2) Info button Launches Info Center, which enables you to open various
(3) Wireless button Turns the wireless feature on or off, but does not establish
When the computer is off, press the button to turn on
the computer.
When the computer is on, press the button to shut
down the computer.
When the computer is in the Sleep state (Windows
Vista) or in Standby (Windows XP), press the button briefly to exit the Sleep state or Standby.
When the computer is in Hibernation, press the button
briefly to exit Hibernation.
If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button for at least 5 seconds to turn off the computer.
To learn more about power settings, follow these steps:
In Windows Vista, select Start > Control Panel >
System and Maintenance > Power Options.
In Windows XP, select Start > Control Panel >
Performance and Maintenance > Power Options.
software solutions.
a wireless connection.
(4) Presentation button Starts the presentation feature.
(5) Volume mute button Mutes and restores speaker sound.
8 Chapter 2 External component identification
NOTE: A wireless network must be set up in order to
establish a wireless connection.

Keys

Item Component Function
(6) Volume scroll zone Adjusts speaker volume. Slide your finger to the left to
decrease volume and to the right to increase volume. You can also press the left side of the volume slider to decrease volume, or press the right side of the volume slider to increase volume.
(7) Calculator button Turns on the Windows calculator function.
(8) HP Fingerprint Sensor (fingerprint reader) Allows a fingerprint logon to Windows, instead of a
password logon.
NOTE: Your computer may look slightly different from the illustration in this section.
Item Component Function
(1) esc key Displays system information when pressed in combination
(2) fn key Executes frequently used system functions when pressed
(3) Windows logo key Displays the Windows Start menu.
(4) Windows applications key Displays a shortcut menu for items beneath the pointer.
(5) Integrated numeric keypad Can be used like the keys on an external numeric keypad.
(6) Function keys Execute frequently used system functions when pressed
with the fn key.
in combination with a function key or the esc key.
in combination with the fn key.
Top components 9

Lights

Item Component Function
(1) Wireless lights (2)*
(2) Power lights (2)†
(3) Battery light
(4) Drive light
On: An integrated wireless device, such as a WLAN
device and/or a Bluetooth® device, is on.
Off: All wireless devices are off.
On: The computer is on.
Blinking: The computer is in the Sleep state (Windows
Vista) or Standby (Windows XP).
Blinking rapidly: An AC adapter with a higher power
rating should be connected.
Off: The computer is off or in Hibernation.
Amber: A battery is charging.
Green: A battery is close to full charge capacity.
Blinking amber: A battery that is the only available
power source has reached a low battery level. When the battery reaches a critical battery level, the battery light begins blinking rapidly.
Off: If the computer is plugged into an external power
source, the light turns off when all batteries in the computer are fully charged. If the computer is not plugged into an external power source, the light stays off until the battery reaches a low battery level.
Blinking green: The hard drive or optical drive is being
accessed.
(5) Caps lock light On: Caps lock is on.
(6) Num lock light On: Num lock is on or the integrated numeric keypad is
10 Chapter 2 External component identification
Amber: HP 3D DriveGuard has temporarily parked the
internal hard drive.
enabled.
Item Component Function
(7) Volume mute light
(8) Volume down light On: The volume scroll zone is being used to decrease
(9) Volume up light On: The volume scroll zone is being used to increase
*The 2 wireless lights display the same information. The light on the wireless button is visible only when the computer is open. The wireless light on the front of the computer is visible whether the computer is open or closed.
†The 2 power lights display the same information. The light on the power button is visible only when the computer is open. The power light on the front of the computer is visible whether the computer is open or closed.
Amber: Computer sound is turned off.
On: Computer sound is turned on.
speaker volume.
speaker volume.
Top components 11

Pointing devices

Item Component Function
(1) Pointing stick* Moves the pointer and selects or activates items on the
screen.
(2) Left pointing stick button* Functions like the left button on an external mouse.
(3) TouchPad* Moves the pointer and selects or activates items on the
screen.
(4) Left TouchPad button* Functions like the left button on an external mouse.
(5) Center TouchPad button* Functions like the center button on an external mouse.
(6) Right TouchPad button* Functions like the right button on an external mouse.
(7) TouchPad scroll zone Scrolls up or down.
(8) Right pointing stick button* Functions like the right button on an external mouse.
(9) Center pointing stick button* Functions like the center button on an external mouse.
*This table describes factory settings. View or change pointing device preferences as follows:
In Windows Vista, select Start > Control Panel > Hardware and Sound > Mouse.
In Windows XP, select Start > Control Panel > Printers and Other Hardware > Mouse.
12 Chapter 2 External component identification

Front components

Item Component Function
(1) Wireless light
(2) Power light
(3) Battery light
(4) Drive light
On: An integrated wireless device, such as a WLAN
device and/or a Bluetooth device, is on.
Off: All wireless devices are off.
On: The computer is on.
Blinking: The computer is in the Sleep state (Windows
Vista) or in Standby (Windows XP).
Blinking rapidly: An AC adapter with a higher power
rating should be connected.
Off: The computer is off or in Hibernation.
Amber: A battery is charging.
Green: A battery is close to full charge capacity.
Blinking amber: A battery that is the only available
power source has reached a low battery level. When the battery reaches a critical battery level, the battery light begins blinking rapidly.
Off: If the computer is plugged into an external power
source, the light turns off when all batteries in the computer are fully charged. If the computer is not plugged into an external power source, the light stays off until the battery reaches a low battery level.
Blinking green: The hard drive or optical drive is being
accessed.
Amber: HP 3D DriveGuard has temporarily parked the
hard drive.
(5) Speakers (2) Produce sound.
(6) Display release latch Opens the computer.
(7) Media Card Reader Supports the following optional digital card formats: Secure
Digital (SD) Memory Card, Memory Stick Pro, Memory Stick Duo, xD-Picture Card, and MultiMediaCard (MMC).
Front components 13

Left-side components

Item Component Function
(1) Security cable slot Attaches an optional security cable to the computer.
(2) Vent Enables airflow to cool internal components.
(3) Power connector Connects an AC adapter.
(4) HDMI port Connects an optional HDMI device.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being mishandled or stolen.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.
(5) External monitor port Connects an external VGA monitor or projector.
(6) USB ports (2) Connect optional USB devices.
(7) 1394 port Connects an optional IEEE 1394 or 1394a device, such as
a camcorder.
(8) Smart card reader Supports smart cards and Java™ cards.
(9) PC Card slot Supports optional Type I or Type II 32–bit (CardBus) or 16–
bit PC Cards.
(10) PC Card eject button Ejects a PC Card from the PC Card slot.
14 Chapter 2 External component identification

Rear component

Component Function
Vent Enables airflow to cool internal components.

Right-side components

NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.
Item Component Function
(1) Audio-out (headphone) jack Produces sound when connected to optional powered
stereo speakers, headphones, ear buds, a headset, or television audio.
(2) Audio-in (microphone) jack Connects an optional computer headset microphone,
stereo array microphone, or monaural microphone.
(3) USB ports (4) Connects up to 4 optional USB devices.
(4) Optical drive Reads an optical disc.
(5) Optical drive button Releases the media tray.
(6) RJ-11 (modem) jack Connects a modem cable.
(7) RJ-45 (network) jack Connects a network cable.
Rear component 15

Bottom components

Item Component Function
(1) Battery bay Holds the battery.
(2) Battery release latches (2) Release the battery from the battery bay.
(3) Docking connector Connects an optional docking device.
(4) Accessory battery connector (slide open to expose) Connects an optional accessory battery.
(5) Hard drive bay Contains the hard drive and the Bluetooth module.
(6) Vents (3) Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.
(7) Memory module/WLAN module compartment Contains the expansion memory module slot, the WLAN
module slot, and the RTC battery.
CAUTION: To prevent an unresponsive system, replace
the wireless module only with a wireless module authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region. If you replace the module and then receive a warning message, remove the module to restore computer functionality, and then contact technical support through Help and Support.
16 Chapter 2 External component identification

3 Illustrated parts catalog

Serial number location

When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer.
Serial number location 17

Computer major components

Item Description Spare part number
(1) Display assemblies (include 3 WLAN antenna transceivers and cables)
17.0-inch, WUXGA WVA AntiGlare
18 Chapter 3 Illustrated parts catalog
450582-001
Item Description Spare part number
17.0-inch, WSXGA+ WVA AntiGlare 450580-001
17.0-inch, WSXGA+ WVA BrightView 450581-001
17.0-inch, WXGA+ AnitGlare 450583-001
Display internal components (not illustrated):
Display bezel 450500-001
Display inverter 450498-001
Display Bracket Kit (includes left and right display hinges) 450570-001
Display panel cable 450571-001
Wireless Antenna Kit (includes 3 WLAN antenna transceivers and cables) 450475-001
Display enclosure for use with WUXGA display assemblies (includes 3 WLAN antenna
Display enclosure for use with WSXGA+ and WXGA+ display assemblies (includes 3 WLAN
Display Rubber Kit (includes display bezel rubber screw covers) 450573-001
Display Screw Kit 450574-001
(2) Switch cover (includes LED board and cable) 450479-001
(3) Power button board (includes cable) 450481-001
(4) Keyboards with pointing stick (include pointing stick cable)
For use in Brazil 450471-201
Ambient light sensor board 450480-001
456223-001
transceivers and cables)
450572-001
antenna transceivers and cables)
For use in Belgium 450471-A41
For use in the Czech Republic 450471-221
For use in Denmark 450471-081
For use in France 450471-051
For use in French Canada 450471-121
For use in Germany 450471-041
For use in Greece 450471-151
For use in Hungary 450471-211
For use in Iceland 450471-DD1
For use in Israel 450471-BB1
For use in Italy 450471-061
For use in Japan 450471-291
For use in Latin America 450471-161
For use in the Netherlands and Europe 450471-021
For use in Norway 450471-091
Computer major components 19
Item Description Spare part number
For use in Portugal 450471-131
For use in Russia 450471-251
For use in Saudi Arabia 450471-171
For use in Slovakia 450471-231
For use in Slovenia 450471-BA1
For use in South Korea 450471-AD1
For use in Spain 450471-071
For use in Sweden and Finland 450471-B71
For use in Switzerland 450471-111
For use in Taiwan 450471-AB1
For use in Thailand 450471-281
For use in Turkey 450471-141
For use in the United Kingdom 450471-031
For use in the United States 450471-001
Keyboards without pointing stick
For use in Brazil 450472-201
For use in the Czech Republic 450472-221
For use in Denmark 450472-081
For use in France 450472-051
For use in French Canada 450472-121
For use in Germany 450472-041
For use in Greece 450472-151
For use in Hungary 450472-211
For use in Iceland 450472-DD1
For use in Israel 450472-BB1
For use in Italy 450472-061
For use in Japan 450472-291
For use in Latin America 450472-161
For use in the Netherlands and Europe 450472-021
For use in Norway 450472-091
For use in Belgium 450472-A41
For use in Portugal 450472-131
For use in Russia 450472-251
For use in Saudi Arabia 450472-171
20 Chapter 3 Illustrated parts catalog
Item Description Spare part number
For use in Slovakia 450472-231
For use in Slovenia 450472-BA1
For use in South Korea 450472-AD1
For use in Spain 450472-071
For use in Sweden and Finland 450472-B71
For use in Switzerland 450472-111
For use in Taiwan 450472-AB1
For use in Thailand 450472-281
For use in Turkey 450472-141
For use in the United Kingdom 450472-031
For use in the United States 450472-001
(5) TouchPads (include TouchPad cable)
For use with keyboards without a pointing stick, includes 2 TouchPad buttons 450596-001
(6) Top covers (include fingerprint reader board and cable )
For use with HP Compaq 8710p computer models 450595-001
(7) Graphics card fan/heat sink (includes replacement thermal material) 450594-001
(8) Heat sink assemblies (include replacement thermal material)
For use only with computer models equipped with processors with 2- or 4-MB L2 cache 450593-001
Plastics Kit (see Plastics Kit on page 26 for more Plastics Kit spare part information): 450585-001
(9a) PC Card slot bezel
(9b) Memory module/WLAN module compartment cover (includes 3 captive screws, secured by C-clips)
Computer feet (not illustrated; 9 feet in 4 different sizes)
(9c) Hard drive cover (includes 2 captive screws, secured by C-clips)
(10)
(11) Intel Core 2 Duo processors (include replacement thermal material)
For use with keyboards with a pointing stick, includes 3 pointing stick buttons and 3 TouchPad buttons
For use with HP Compaq 8710w computer models 451379-001
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468593-001
PC Card assembly 450584-001
450597-001
T9300 2.5-GHz processor (6-MB L2 cache, 800-MHz FSB) 463050-001
T8300 2.4-GHz processor (3-MB L2 cache, 800-MHz FSB) 463049-001
T8100 2.1-GHz processor (3-MB L2 cache, 800-MHz FSB) 463048-001
T7800 2.6-GHz processor (4-MB L2 cache, 800-MHz FSB) 458218-001
T7700 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB) 450589-001
T9500 2.6-GHz processor (6-MB L2 cache, 800-MHz FSB) 463051-001
Computer major components 21
Item Description Spare part number
T7500 2.2-GHz processor (4-MB L2 cache, 800-MHz FSB) 450588-001
T7300 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB) 450587-001
T7250 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB) 460283-001
T7100 1.8-GHz processor (2-MB L2 cache, 800-MHz FSB) 450586-001
(12) Graphics cards (include replacement thermal material)
For use only with HP Compaq 8710w computer models (nVidia NB8E-GLM graphics card with
For use only with HP Compaq 8710p computer models (nVidia NB8P-NVS2 graphics card
(13) USB/audio board (includes 2-into-1 USB board cable and audio board cable) 450483-001
(14) Bluetooth module (includes Bluetooth module cable) 450485-001
(15) System boards (include replacement thermal material)
For use only with computer models equipped with processors with 2- or 4-MB L2 cache 450482-001
(16) Modem module 443899-001
(17) Speaker assembly 450592-001
(18) Base enclosure (includes rubber feet) 450476-001
Rubber Kit (includes 9 feet in 4 different sizes) 450590-001
(19) RTC battery 450478-001
(20) 8-cell, 5.1-Ah, Li-ion battery 450477-001
(21) Memory modules
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468592-001
451377-001
512-MB graphics subsystem memory operating at 800 MHz)
450484-001
with 256-MB graphics subsystem memory operating at 700 MHz; supports TurboCache)
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468591-001
2048-MB memory module (PC2-5300, 667-MHz, DDR2) 450576-001
1024-MB memory module (PC2-5300, 667-MHz, DDR2) 450575-001
512-MB memory module (PC2-5300, 667-MHz, DDR2) 450577-001
(22) WLAN modules
Intel 802.11a/b/g/n WLAN modules:
4096-MB memory module (PC2-5300, 667-MHz, DDR2) 469650-001
For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda,
Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam
For use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia, Cyprus, the
Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
22 Chapter 3 Illustrated parts catalog
441086-001
441086-002
Item Description Spare part number
Broadcom 802.11a/b/g WLAN modules:
For use in Australia, New Zealand, Pakistan, the People's Republic of China, and South
Korea
For use in Japan
For use in South Korea
For use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and
the United States
For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda,
Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441086-003
441086-291
441086-AD1
441075-001
441075-002
Intel 802.11a/b/g WLAN modules:
Broadcom 802.11b/g WLAN modules:
For use in Japan
For use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda,
Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, the United States, Uruguay, Venezuela, and Vietnam
For use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia, Cyprus, the
Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
For use in Australia, New Zealand, Pakistan, the People's Republic of China, and South
Korea
For use in Japan
441075-291
441082-001
441082-002
441082-003
441082-291 and 441082-292
Computer major components 23
Item Description Spare part number
For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and
the United States
For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua & Barbuda, Argentina,
Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia & Herzegovina Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Palau, Panama, Papua New Guinea, Paraguay, the People's Republic of China, Peru, the Philippines, Poland, Portugal, Qatar, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Thailand, Togo, Tonga, Trinidad & Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441090-001
441090-002
Intel 802.11b/g WLAN module for use in Japan 448675-004
(23) Hard drives (include hard drive bracket)
200-GB, 7200-rpm 461876-001
160-GB, 7200-rpm 460282-001
160-GB, 5400-rpm 450495-001
120-GB, 7200-rpm 454487-001
120-GB, 5400-rpm 450494-001
100-GB, 7200-rpm 450493-001
80-GB, 7200-rpm 450497-001
80-GB, 5400-rpm 450496-001
(24) Optical drives
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 450491-001
DVD/CD-RW Combo Drive 450492-001
For use in Japan
250-GB, 5400-rpm 458219-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 450490-001
441090-291
Blu-ray DVD-RW Drive 450489-001
24 Chapter 3 Illustrated parts catalog
Item Description Spare part number
DVD-ROM Drive 450488-001
Cable Kit (not illustrated; see Cable Kit on page 27 for more Cable Kit spare part number
information)
450486-001
Computer major components 25

Plastics Kit

Item Description Spare part number
Plastics Kit: 450585-001
(1) Memory module/WLAN module compartment cover (includes 3 captive screws, secured by C-clips)
(2) Hard drive cover (includes 2 captive screws, secured by C-clips)
(3) PC Card slot bezel
26 Chapter 3 Illustrated parts catalog

Cable Kit

Item Description Spare part number
Cable Kit: 450486-001
(1) RJ-45 jack cable
(2) RJ-11 jack cable
(3) TouchPad cable
(4) Bluetooth module cable
(5) USB/audio board cable
(6) Microphone extension cable
(7) Power button board cable
Cable Kit 27

Mass storage devices

Item Description Spare part number
(1) Hard drives (include frame)
250-GB, 5400-rpm 458219-001
200-GB, 7200-rpm 461876-001
160-GB, 7200-rpm 460282-001
160-GB, 5400-rpm 450495-001
120-GB, 7200-rpm 454987-001
120-GB, 5400-rpm 450494-001
100-GB, 7200-rpm 450493-001
80-GB, 7200-rpm 450497-001
80-GB, 5400-rpm 450496-001
(2) Optical drives (include bezel)
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 450490-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 450491-001
DVD/CD-RW Combo Drive 450492-001
Blu-ray DVD-RW Drive 450489-001
DVD-ROM Drive 450488-001

Miscellaneous parts

Description Spare part number
AC adapters
180-W PFC AC adapter
135-W PFC AC adapter 468590-001
28 Chapter 3 Illustrated parts catalog
463952-001
Description Spare part number
120-W non-PFC AC adapter 416391-001
120-W PFC AC adapter 391174-001
90-W non-PFC AC adapter 418873-001
90-W PFC AC adapter 418875-001
External MultiBay II 366143-001
External MultiBay II power cable and stand 366144-001
HP Extended Life Battery 367456-001
Label Kit 450499-001
MultiBay 8X DVD-ROM Drive 373314-001
MultiBay 24X DVD/CD-RW Combo Drive 373315-001
Nylon carrying case 325814-001
USB 1.1 diskette drive 359118-001
Power cords:
For use in Australia
For use in Brazil 403811-201
For use in Denmark 403811-081
For use in Europe, the Middle East, and Africa 403811-021
For use in India 403811-D61
For use in Israel 403811-BB1
For use in Italy 403811-061
For use in Japan 403811-291
For use in the People's Republic of China 403811-AA1
For use in South Korea 403811-AD1
For use in Switzerland 403811-111
For use in Taiwan 403811-AB1
For use in the United Kingdom 403811-031
For use the United States 403811-001
Screw Kit
Phillips PM2.5×4.0 screw
403811-011
450591-001
Phillips PM2.0×10.0 screw
Phillips PM2.0×5.0 captive screw
Phillips PM2.0×5.0 screw
Phillips PM2.0×4.0 screw
Phillips PM2.0×3.0 screw
Miscellaneous parts 29
Description Spare part number
Phillips PM2.0×2.0 broad-head screw
Phillips PM2.0×2.0 screw
Phillips PM1.5×3.0 screw
Torx T8M2.5×7.0 screw
Torx T8M2.5×4.0 screw
Torx T6M2.0×5.0 screw

Sequential part number listing

Spare part number
391174-001 120-W PFC AC adapter
325814-001 Nylon carrying case
359118-001 USB 1.1 diskette drive
366143-001 External MultiBay II
366144-001 External MultiBay II power cable and stand
367456-001 HP Extended Life Battery
373314-001 MultiBay 8X DVD-ROM Drive
373315-001 MultiBay 24X DVD/CD-RW Combo Drive
403811-001 Power cord (3-wire) for use in North America
403811-011 Power cord (3-wire) for use in Australia
403811-021 Power cord (3-wire) for use in Europe, the Middle East, and Africa
403811-031 Power cord (3-wire) for use in the United Kingdom
403811-061 Power cord (3-wire) for use in Italy
403811-081 Power cord (3-wire) for use in Denmark
403811-111 Power cord (3-wire) for use in Switzerland
Description
403811-291 Power cord (3-wire) for use in Japan
403811-AA1 Power cord (3-wire) for use in the People's Republic of China
403811-AB1 Power cord (3-wire) for use in Taiwan
403811-AD1 Power cord (3-wire) for use in South Korea
403811-BB1 Power cord (3-wire) for use in Israel
403811-D61 Power cord (3-wire) for use in India
416931-001 120-W non-PFC AC adapter
418873-001 90-W non-PFC AC adapter
30 Chapter 3 Illustrated parts catalog
Spare part number
418875-001 90-W PFC AC adapter
441075-001 Broadcom 802.11a/b/g WLAN module for use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin
441075-002 Broadcom 802.11a/b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and
Description
Islands, and the United States
Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441075-291 Broadcom 802.11a/b/g WLAN module for use in Japan
441082-001 Intel 802.11a/b/g WLAN module for use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados,
Bermuda, Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, the United States, Uruguay, Venezuela, and Vietnam
441082-002 Intel 802.11a/b/g WLAN module for use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia,
Cyprus, the Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
441082-003 Intel 802.11a/b/g WLAN module for use in Australia, New Zealand, Pakistan, the People's Republic of China,
and South Korea
441082-291 Intel 802.11a/b/g WLAN module for use in Japan
441082-292 Intel 802.11a/b/g WLAN module for use in Japan
441086-001 Intel 802.11a/b/g/n WLAN module for use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados,
441086-002 Intel 802.11a/b/g/n WLAN module for use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia,
Bermuda, Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam
Cyprus, the Czech Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
441086-003 Intel 802.11a/b/g/n WLAN module for use in Australia, New Zealand, Pakistan, the People's Republic of China,
and South Korea
Sequential part number listing 31
Spare part number
441086-291 Intel 802.11a/b/g/n WLAN module for use in Japan
441086-AD1 Intel 802.11a/b/g/n WLAN module for use in South Korea
441090-001 Broadcom 802.11b/g WLAN module for use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S.
441090-002 Broadcom 802.11b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua &
Description
Virgin Islands, and the United States
Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia & Herzegovina Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Palau, Panama, Papua New Guinea, Paraguay, the People's Republic of China, Peru, the Philippines, Poland, Portugal, Qatar, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Thailand, Togo, Tonga, Trinidad & Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441090-291 Broadcom 802.11b/g WLAN module for use in Japan
443899-001 Modem module
448675-004 Intel 802.11b/g WLAN module for use in Japan
450471-001 Keyboard with pointing stick for use in the United States (includes keyboard and pointing stick cable)
450471-021 Keyboard with pointing stick for use in Europe (includes keyboard and pointing stick cable)
450471-031 Keyboard with pointing stick for use in the United Kingdom (includes keyboard and pointing stick cable)
450471-041 Keyboard with pointing stick for use in Germany (includes keyboard and pointing stick cable)
450471-051 Keyboard with pointing stick for use in France (includes keyboard and pointing stick cable)
450471-061 Keyboard with pointing stick for use in Italy (includes keyboard and pointing stick cable)
450471-071 Keyboard with pointing stick for use in Spain (includes keyboard and pointing stick cable)
450471-081 Keyboard with pointing stick for use in Denmark (includes keyboard and pointing stick cable)
450471-091 Keyboard with pointing stick for use in Norway (includes keyboard and pointing stick cable)
450471-111 Keyboard with pointing stick for use in Switzerland (includes keyboard and pointing stick cable)
450471-121 Keyboard with pointing stick for use in French Canada (includes keyboard and pointing stick cable)
450471-131 Keyboard with pointing stick for use in Portugal (includes keyboard and pointing stick cable)
450471-141 Keyboard with pointing stick for use in Turkey (includes keyboard and pointing stick cable)
450471-151 Keyboard with pointing stick for use in Greece (includes keyboard and pointing stick cable)
450471-161 Keyboard with pointing stick for use in Latin America (includes keyboard and pointing stick cable)
32 Chapter 3 Illustrated parts catalog
Spare part number
450471-171 Keyboard with pointing stick for use in Saudi Arabia (includes keyboard and pointing stick cable)
450471-201 Keyboard with pointing stick for use in Brazil (includes keyboard and pointing stick cable)
450471-211 Keyboard with pointing stick for use in Hungary (includes keyboard and pointing stick cable)
450471-221 Keyboard with pointing stick for use in the Czech Republic (includes keyboard and pointing stick cable)
450471-231 Keyboard with pointing stick for use in Slovakia (includes keyboard and pointing stick cable)
450471-251 Keyboard with pointing stick for use in Russia (includes keyboard and pointing stick cable)
450471-281 Keyboard with pointing stick for use in Thailand (includes keyboard and pointing stick cable)
450471-291 Keyboard with pointing stick for use in Japan (includes keyboard and pointing stick cable)
450471-A41 Keyboard with pointing stick for use in Belgium (includes keyboard and pointing stick cable)
450471-AB1 Keyboard with pointing stick for use in Taiwan (includes keyboard and pointing stick cable)
450471-AD1 Keyboard with pointing stick for use in South Korea (includes keyboard and pointing stick cable)
450471-B71 Keyboard with pointing stick for use in Sweden and Finland (includes keyboard and pointing stick cable)
450471-BA1 Keyboard with pointing stick for use in Slovenia (includes keyboard and pointing stick cable)
450471-BB1 Keyboard with pointing stick for use in Israel (includes keyboard and pointing stick cable)
450471-DD1 Keyboard with pointing stick for use in Iceland (includes keyboard and pointing stick cable)
Description
450472-001 Keyboard without pointing stick for use in the United States (includes keyboard cable)
450472-021 Keyboard without pointing stick for use in Europe (includes keyboard cable)
450472-031 Keyboard without pointing stick for use in the United Kingdom (includes keyboard cable)
450472-041 Keyboard without pointing stick for use in Germany (includes keyboard cable)
450472-051 Keyboard without pointing stick for use in France (includes keyboard cable)
450472-061 Keyboard without pointing stick for use in Italy (includes keyboard cable)
450472-071 Keyboard without pointing stick for use in Spain (includes keyboard cable)
450472-081 Keyboard without pointing stick for use in Denmark (includes keyboard cable)
450472-091 Keyboard without pointing stick for use in Norway (includes keyboard cable)
450472-111 Keyboard without pointing stick for use in Switzerland (includes keyboard cable)
450472-121 Keyboard without pointing stick for use in French Canada (includes keyboard cable)
450472-131 Keyboard without pointing stick for use in Portugal (includes keyboard cable)
450472-141 Keyboard without pointing stick for use in Turkey (includes keyboard cable)
450472-151 Keyboard without pointing stick for use in Greece (includes keyboard cable)
450472-161 Keyboard without pointing stick for use in Latin America (includes keyboard cable)
450472-171 Keyboard without pointing stick for use in Saudi Arabia (includes keyboard cable)
450472-201 Keyboard without pointing stick for use in Brazil (includes keyboard cable)
450472-211 Keyboard without pointing stick for use in Hungary (includes keyboard cable)
450472-221 Keyboard without pointing stick for use in the Czech Republic (includes keyboard cable)
Sequential part number listing 33
Spare part number
450472-231 Keyboard without pointing stick for use in Slovakia (includes keyboard cable)
450472-251 Keyboard without pointing stick for use in Russia (includes keyboard cable)
450472-281 Keyboard without pointing stick for use in Thailand (includes keyboard cable)
450472-291 Keyboard without pointing stick for use in Japan (includes keyboard cable)
450472-A41 Keyboard without pointing stick for use in Belgium (includes keyboard cable)
450472-AB1 Keyboard without pointing stick for use in Taiwan (includes keyboard cable)
450472-AD1 Keyboard without pointing stick for use in South Korea (includes keyboard cable)
450472-B71 Keyboard without pointing stick for use in Sweden (includes keyboard cable)
450472-BA1 Keyboard without pointing stick for use in Slovenia (includes keyboard cable)
450472-BB1 Keyboard without pointing stick for use in Israel (includes keyboard cable)
450472-DD1 Keyboard without pointing stick for use in Iceland (includes keyboard cable)
450475-001 Wireless Antenna Kit (includes 3 WLAN antenna transceivers and cables)
450476-001 Base enclosure (includes rubber computer feet)
450477-001 8-cell, 5.1-Ah battery
450478-001 RTC battery
Description
450479-001 Switch cover (includes LED board and cable)
450480-001 Ambient light sensor board
450481-001 Power button board (includes cable)
450482-001 System board for use only with computer models equipped with processors with 2- or 4-MB L2 cache (includes
replacement thermal material)
450483-001 USB/audio board (includes 2-into-1 USB board cable and audio board cable)
450484-001 Graphics card for use only with HP Compaq 8710p computer models (nVidia NB8P-NVS2 with 256 MB of
graphics subsystem memory operating at 700 MHz, supporting TurboCache; includes replacement thermal material)
450485-001 Bluetooth module (includes Bluetooth module cable)
450486-001 Cable Kit (see Cable Kit on page 27 for more Cable Kit spare part information
450488-001 DVD-ROM Drive
450489-001 Blu-ray DVD-RW Drive
450490-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe
450491-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive
450492-001 DVD/CD-RW Combo Drive
450493-001 100-GB, 7200-rpm hard drive
450494-001 120-GB, 5400-rpm hard drive
450495-001 160-GB, 5400-rpm hard drive
450496-001 80-GB, 5400-rpm hard drive
34 Chapter 3 Illustrated parts catalog
Spare part number
450497-001 80-GB, 7200-rpm hard drive
450498-001 Display inverter
450499-001 Label Kit
450500-001 Display bezel
450570-001 Display Bracket Kit (includes left and right display hinges)
450571-001 Display cable
Description
450572-001 Display enclosure for use with WSXGA+ and WXGA+ display assemblies (includes 3 WLAN antenna
450573-001 Display Rubber Kit (includes display bezel rubber screw covers)
450574-001 Display Screw Kit
450575-001 1024-MB memory module (PC-5300, 667-GHz, DDR2)
450576-001 2048-MB memory module (PC-5300, 667-GHz, DDR2)
450577-001 512-MB memory module (PC-5300, 667-GHz, DDR2)
450578-001 Microphone extension cable
450580-001 17.0-inch, WSXGA+ WVA AntiGlare display assembly (includes 3 WLAN antenna transceivers and cables)
450581-001 17.0-inch, WSXGA+ WVA BrightView display assembly (includes 3 WLAN antenna transceivers and cables)
450582-001 17.0-inch, WUXGA+ WVA AntiGlare display assembly (includes 3 WLAN antenna transceivers and cables)
450583-001 17.0-inch, WXGA+ AntiGlare display assembly (includes 3 WLAN antenna transceivers and cables)
450584-001 PC Card assembly
450585-001 Plastics Kit (see Plastics Kit on page 26 for more Plastics Kit spare part information)
450586-001 Intel Core 2 Duo T7100 1.8-GHz processor (2-MB L2 cache, 800-MHz FSB; includes replacement thermal
450587-001 Intel Core 2 Duo T7300 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
transceivers and cables)
material)
material)
450588-001 Intel Core 2 Duo T7500 2.2-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
450589-001 Intel Core 2 Duo T7700 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
450590-001 Rubber Kit (includes base enclosure rubber feet
450591-001 Screw Kit
450592-001 Speaker assembly
450593-001 Heat sink for use only with computer models equipped with processors with 2- or 4-MB L2 cache (includes
450594-001 Fan/heat sink assembly (includes replacement thermal material)
450595-001 Top cover for use with 8710p computer models (includes fingerprint reader board and cable)
450596-001 TouchPad with 2 TouchPad buttons (for use with keyboards without a pointing stick; includes TouchPad
material)
replacement thermal material)
cable)
Sequential part number listing 35
Spare part number
Description
450597-001 TouchPad with 3 pointing stick buttons and 3 TouchPad buttons (for use with keyboards with a pointing stick;
451377-001 Graphics card for use only with HP Compaq 8710w computer models (nVidia NB8E-GLM with 512 MB graphics
451379-001 Top cover for use with 8710w computer models (includes fingerprint reader board and cable)
416931-001 120-W non-PFC AC adapter
391174-001 120-W PFC AC adapter
454987-001 120-GB, 7200-rpm hard drive
456223-001 Display enclosure for use with WUXGA display assemblies (includes 3 WLAN antenna transceivers and
458218-001 Intel Core 2 Duo T7800 2.6-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
458219-001 250-GB, 5400-rpm hard drive
460282-001 160-GB, 7200-rpm hard drive
460283-001 Intel Core 2 Duo T7250 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
461876-001 200-GB, 7200-rpm hard drive
463048-001 Intel Core 2 Duo T8100 2.1-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
includes TouchPad cable)
subsystem memory operating at 800 MHz; includes replacement thermal material)
cables)
material)
material)
material)
463049-001 Intel Core 2 Duo T8300 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
463050-001 Intel Core 2 Duo T9300 2.8-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
463051-001 Intel Core 2 Duo T9500 2.6-GHz processor (4-MB L2 cache, 800-MHz FSB; includes replacement thermal
material)
463952-001 180-W PFC AC adapter
468590-001 135-W PFC AC adapter
468591-001 System board for use only with computer models equipped with processors with 3- or 6-MB L2 cache (includes
replacement thermal material)
468592-001 Graphics card for use only with computer models equipped with processors with 3- or 6-MB L2 cache
468593-001 Heat sink for use only with computer models equipped with processors with 3- or 6-MB L2 cache (includes
replacement thermal material)
469650-001 4096-MB memory module (PC-5300, 667-GHz, DDR2)
36 Chapter 3 Illustrated parts catalog

4 Removal and replacement procedures

Preliminary replacement requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:
Flat-bladed screwdriver
Magnetic screwdriver
Phillips P0 and P1 screwdrivers
Torx T8 screwdriver

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.
NOTE: As you remove each subassembly from the computer, place the subassembly (and all
accompanying screws) away from the work area to prevent damage.
Plastic parts
Using excessive force during disassembly and reassembly can damage plastic parts. Use care when handling the plastic parts. Apply pressure only at the points designated in the maintenance instructions.
Preliminary replacement requirements 37
Cables and and pointing stick connectors
CAUTION: When servicing the computer, be sure that cables are placed in their proper locations
during the reassembly process. Improper cable placement can damage the computer.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables tear easily.
Drive handling
CAUTION: Drives are fragile components that must be handled with care. To prevent damage to the
computer, damage to a drive, or loss of information, observe these precautions:
Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
Before handling a drive, be sure that you are discharged of static electricity. While handling a drive, avoid touching the connector.
Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be sure that the optical drive tray is closed.
Handle drives on surfaces covered with at least one inch of shock-proof foam.
Avoid dropping drives from any height onto any surface.
After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.
Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.
Avoid exposing a drive to temperature extremes or liquids.
If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective packaging and label the package “FRAGILE.”
38 Chapter 4 Removal and replacement procedures

Grounding guidelines

Electrostatic discharge damage
Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated and pointing stick circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.
A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.
An electronic device exposed to ESD may not be affected at all and and pointing stick can work perfectly throughout a normal cycle. Or the device may function normally for a while, then degrade in the internal layers, reducing its life expectancy.
CAUTION: To prevent damage to the computer when you are removing or installing internal
components, observe these precautions:
Keep components in their electrostatic-safe containers until you area ready to install them.
Use nonmagnetic tools.
Before touching an electronic component, discharge static electricity by using the guidelines described in this section.
Avoid touching pins, leads, and and pointing stick circuitry. Handle electronic components as little as possible.
If you remove a component, place it in an electrostatic-safe container.
The following table shows how humidity affects the electrostatic voltage levels generated by different activities.
CAUTION: A product can be degraded by as little as 700 V.
Typical electrostatic voltage levels
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl floor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tube 2,000 V 700 V 400 V
Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
Relative humidity
Preliminary replacement requirements 39
Packaging and transporting guidelines
Follow these grounding guidelines when packaging and transporting equipment:
To avoid hand and pointing stick contact, transport products in static-safe tubes, bags, or boxes.
Protect ESD-sensitive parts and assemblies with conductive or approved and pointing stick
containers or packaging.
Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
Place items on a grounded surface before removing items from their containers.
Always be properly grounded when touching a component or assembly.
Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive
foam.
Use transporters and and pointing stick conveyors made of antistatic belts and roller bushings. Be
sure that mechanized equipment used for moving materials is wired to ground and that proper materials are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate electric charges.
Workstation guidelines
Follow these grounding workstation guidelines:
Cover the workstation with approved static-shielding material.
Use a wrist strap connected to a properly grounded work surface and use properly grounded tools
and equipment.
Use conductive field service tools, such as cutters, screwdrivers, and vacuums.
When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe
materials.
Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and
Styrofoam.
Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle
these items only at static-free workstations.
Avoid and pointing stick contact with pins, leads, or circuitry.
Turn off power and input signals before inserting or removing connectors or test equipment.
40 Chapter 4 Removal and replacement procedures
Equipment guidelines
Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.
When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps
with a minimum of one megohm ±10% resistance in the ground and pointing stick cords. To provide proper ground, wear a strap snugly against the skin at all times. On grounded mats with banana­plug connectors, use alligator clips to connect a wrist strap.
When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps)
can be used at standing workstations and are compatible with most types of shoes or boots. On conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm resistance between the operator and ground. To be effective, the conductive strips must be worn in contact with the skin.
The following grounding equipment is recommended to prevent electrostatic damage:
Antistatic tape
Antistatic smocks, aprons, and sleeve protectors
Conductive bins and other assembly or soldering aids
Nonconductive foam
Conductive tabletop workstations with ground and pointing stick cords of one megohm resistance
Static-dissipative tables or floor mats with hard ties to the ground
Field service kits
Static awareness labels
Material-handling packages
Nonconductive plastic bags, tubes, or boxes
Metal tote boxes
Electrostatic voltage levels and protective materials
The following table lists the shielding protection provided by antistatic bags and floor mats.
Material Use Voltage protection level
Antistatic plastic Bags 1,500 V
Carbon-loaded plastic Floor mats 7,500 V
Metallized laminate Floor mats 5,000 V
Preliminary replacement requirements 41

Unknown user password

NOTE: This process will not work if Stringent Security is enabled in F10 Setup. Stringent Security
installs passwords into the ROM so that it is not affected when the RTC battery is removed.
If the computer you are servicing has an unknown user password, follow these steps to clear the password:
NOTE: These steps also clear CMOS.
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the real-time clock (RTC) battery (see
6. Wait approximately 5 minutes.
7. Replace the RTC battery and reassemble the computer.
8. Connect AC power to the computer. Do not reinsert any batteries at this time.
9. Turn on the computer.
All passwords and all CMOS settings have been cleared.
Battery on page 44).
RTC battery on page 57).
42 Chapter 4 Removal and replacement procedures

Component replacement procedures

This chapter provides removal and replacement procedures.
There are as many as 97 screws and screw locks, in 18 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw and screw lock size and location during removal and replacement.

Serial number

Report the computer serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the computer.

Computer feet

The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 450590-001. There are 9 rubber feet, in 4 different sizes, that attach to the base enclosure in the locations illustrated below.
Component replacement procedures 43

Battery

Description Spare part number
8-cell, 5.1-Ah, Li-ion battery 450477-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
Remove the battery:
1. Turn the computer upside down on a flat surface, with the battery bay toward you.
2. Slide the battery release latches (1) to release the battery.
3. Remove the battery (2) from the computer.
Install the battery by inserting it into the battery bay until you hear a click.
44 Chapter 4 Removal and replacement procedures

Display inverter and ambient light sensor board

NOTE: If it has been determined that the display inverter or the ambient light sensor board are the
components that must be replaced to complete the computer repair, the display assembly does not have to be removed. Follow the procedures in this section to replace the display inverter or ambient light sensor board . For information on replacing the display assembly, the display hinges, or the display bezel, see
Description Spare part number
Display inverter 450498-001
Ambient light sensor board 450480-001
Before removing the display inverter, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
Display assembly on page 77.
computer on, and then shut it down through the operating system.
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the display inverter:
1. Turn the computer right-side up, with the front toward you.
2. Open the computer as far as possible.
Component replacement procedures 45
3. Remove the screw covers, screws, and stabilizer clips listed below. All rubber screw covers are
included in the Display Rubber Kit, spare part number 450573-001.
(1) Two flat rubber screw covers
(2) Two small oblong rubber screw covers
(3) Four Phillips PM2.0×6.0 screws
(4) Two stabilizer clips
4. Flex the inside edges of the left and right sides (1) and the display bezel bottom edge (2) until the
bezel disengages from the display assembly.
5. Release the display bezel bottom edge (3) from the display assembly.
6. Remove the Torx T8M2.5×4.0 screw (1) that secures the ambient light sensor board to the display
enclosure.
7. Release the ambient light sensor board (2) from the display enclosure as far as the ambient light
sensor board cable allows.
46 Chapter 4 Removal and replacement procedures
8. Disconnect the ambient light sensor board cable (3) from the ambient light sensor board.
9. Remove the Torx T8M2.5×4.0 screw (1) that secures the display inverter to the display enclosure.
10. Release the inverter (2) from the display enclosure as far as the display panel cable and backlight
cable allow.
11. Disconnect the display panel cable (3) and the backlight cable (4) from the display inverter.
12. Remove the display inverter.
Reverse this procedure to install the display inverter.
Component replacement procedures 47

Hard drive

Description Spare part number
250-GB, 5400-rpm hard drive 458219-001
200-GB, 7200-rpm hard drive 461876-001
160-GB, 7200-rpm hard drive 460282-001
160-GB, 5400-rpm hard drive 450495-001
120-GB, 7200-rpm hard drive 454987-001
120-GB, 5400-rpm hard drive 450494-001
100-GB, 7200-rpm hard drive 450493-001
80-GB, 7200-rpm hard drive 450497-001
80-GB, 5400-rpm hard drive 450496-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
computer on, and then shut it down through the operating system.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the hard drive:
1. Position the computer with the front toward you.
2. Loosen the two Phillips PM2.0×17.0 captive screws (1) that secure the hard drive cover to the
computer.
48 Chapter 4 Removal and replacement procedures
3. Lift the right side of the hard drive cover (2), swing it to left, and remove the cover. The hard drive
cover is included in the Plastics Kit, spare part number 450585-001.
4. Loosen the Phillips PM2.5×13.0 captive screw (1) that secures the hard drive to the computer.
5. Grasp the Mylar tab (2) on the hard drive and slide the hard drive (3) to the left to disconnect it from
the system board.
6. Remove the hard drive (4) from the hard drive bay.
7. If it is necessary to replace the hard drive bracket, remove the two Phillips PM3.0×4.0 hard drive
bracket screws (1) from each side of the hard drive.
Component replacement procedures 49
8. Lift the bracket (2) straight up to remove it from the hard drive.
Reverse this procedure to reassemble and install the hard drive.
50 Chapter 4 Removal and replacement procedures

Bluetooth module

Description Spare part number
Bluetooth module (includes Bluetooth module cable) 450485-001
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the hard drive (see
Battery on page 44).
Hard drive on page 48).
Remove the Bluetooth® module:
1. Position the computer with the rear panel toward you.
2. Release the Bluetooth module (1) from the clip in the hard drive bay by sliding it forward.
3. Remove the Bluetooth module (2) from the hard drive bay by lifting it straight up.
4. Disconnect the Bluetooth module cable (3) from the Bluetooth module.
Reverse this procedure to reassemble and install the Bluetooth module.
Component replacement procedures 51

Primary memory module

Description Spare part number
4096-MB (PC2-5300, 667-MHz, DDR2) 469650-001
2048-MB (PC2-5300, 667-MHz, DDR2) 450576-001
1024-MB (PC2-5300, 667-MHz, DDR2) 450575-001
512-MB (PC2-5300, 667-MHz, DDR2) 450577-001
Before removing the primary memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the primary memory module:
1. Loosen the three Phillips PM2.5×5.0 captive screws (1) that secure the memory module/WLAN
module compartment cover to the computer.
2. Lift the front edge of the cover (2), swing it up and forward, and remove the cover. The memory
module/WLAN module compartment cover is included in the Plastics Kit, spare part number 450585-001.
3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
52 Chapter 4 Removal and replacement procedures
4. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the
memory module slot.
Reverse this procedure to install the primary memory module.
Component replacement procedures 53

WLAN module

Description Spare part number
Intel 802.11a/b/g/n WLAN modules:
For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei,
Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam
For use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia, Cyprus, the Czech
Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
For use in Australia, New Zealand, Pakistan, the People's Republic of China, and South Korea
For use in Japan
For use in South Korea
Broadcom 802.11a/b/g WLAN modules:
For use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United
States
For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina,
Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441086-001
441086-002
441086-003
441086-291
441086-AD1
441075-001
441075-002
For use in Japan
Intel 802.11a/b/g WLAN modules:
For use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei,
Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, the United States, Uruguay, Venezuela, and Vietnam
54 Chapter 4 Removal and replacement procedures
441075-291
441082-001
Description Spare part number
For use in Austria, Azerbaijan, Bahrain, Belgium, Brazil, Bulgaria, Croatia, Cyprus, the Czech
Republic, Denmark, Egypt, Estonia, Finland, France, Georgia, Germany, Greece, Hungary, Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan
For use in Australia, New Zealand, Pakistan, the People's Republic of China, and South Korea
For use in Japan
802.11b/g Broadcom WLAN modules:
For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the
United States
For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua & Barbuda, Argentina,
Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia & Herzegovina Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissa, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Palau, Panama, Papua New Guinea, Paraguay, the People's Republic of China, Peru, the Philippines, Poland, Portugal, Qatar, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome & Principe, Saudi Arabia, Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts & Nevis, St. Lucia, St. Vincent & Grenada, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Thailand, Togo, Tonga, Trinidad & Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
441082-002
441082-003
441082-291 and 441082-292
441090-001
441090-002
For use in Japan
802.11b/g Intel WLAN module for use in Thailand 448675-004
441090-291
Before removing the WLAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the memory module/WLAN module compartment cover (see
Battery on page 44).
Primary memory module
on page 52).
Component replacement procedures 55
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The
white WLAN antenna cable is connected to the WLAN module “Aux” terminal. If the computer is equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable (2) is connected to the middle terminal on the WLAN module.
2. Remove the two Phillips PM2.0×3.0 screws (3) that secure the WLAN module to the computer.
(The edge of the module opposite the slot rises away from the computer.)
3. Remove the WLAN module (4) by pulling the module away from the slot at an angle.
NOTE: WLAN modules are designed with a notch (5) to prevent incorrect installation.
Reverse this procedure to install the WLAN module.
56 Chapter 4 Removal and replacement procedures

RTC battery

NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all
passwords and CMOS settings to be cleared.
Description Spare part number
RTC battery 450478-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the memory module/WLAN module compartment cover (see
on page 52).
Remove the RTC battery:
1. Disconnect the RTC battery cable (1) from the system board.
2. Remove the RTC battery (2) from the clip built into the base enclosure.
Primary memory module
Reverse this procedure to install the RTC battery.
Component replacement procedures 57

Optical drive

Description Spare part number
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 450490-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 450491-001
DVD/CD-RW Combo Drive 450492-001
Blu-ray DVD-RW Drive 450489-001
DVD-ROM Drive 450488-001
Before removing the optical drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the optical drive:
1. Position the computer with the left side toward you.
2. Remove the Phillips PM2.5×9.0 screw (1) that secures the optical drive to the computer.
3. Insert a flat-bladed screwdriver or similar tool into the optical drive tab access (2) and press the
tab to the left to release the optical drive from the computer.
4. Remove the optical drive (3).
5. If it is necessary to replace the optical drive bracket, position the optical drive with the rear toward
you.
58 Chapter 4 Removal and replacement procedures
6. Remove the two Phillips PM2.0×4.0 screws (1) that secure the optical drive bracket to the optical
drive.
7. Remove the optical drive bracket (2).
Reverse this procedure to install an optical drive.
Component replacement procedures 59

Keyboard

For use in: Spare part number For use in: Spare part number
Keyboards with pointing stick (includes pointing stick cable):
Belgium
Brazil
The Czech Republic
Denmark
France
French Canada
Germany
Greece
Hungary
Iceland
Israel
Italy
Japan
Latin America
The Netherlands and Europe
Keyboards without pointing stick:
450471-A41
450471-201
450471-221
450471-081
450471-051
450471-121
450471-041
450471-151
450471-211
450471-DD1
450471-BB1
450471-061
450471-291
450471-161
450471-021
Norway
Portugal
Russia
Saudi Arabia
Slovakia
Slovenia
South Korea
Spain
Sweden and Finland
Switzerland
Taiwan
Thailand
Turkey
The United Kingdom
The United States
450471-091
450471-131
450471-251
450471-171
450471-231
450471-AD1
450471-BA1
450471-071
450471-B71
450471-111
450471-AB1
450471-281
450471-141
450471-031
450471-001
Belgium
Brazil
The Czech Republic
Denmark
France
French Canada
Germany
Greece
Hungary
Iceland
Israel
Italy
Japan
Latin America
The Netherlands and Europe
450472-A41
450472-201
450472-221
450472-081
450472-051
450472-121
450472-041
450472-151
450472-211
450472-DD1
450472-BB1
450472-061
450472-291
450472-161
450472-021
Norway
Portugal
Russia
Saudi Arabia
Slovakia
Slovenia
South Korea
Spain
Sweden and Finland
Switzerland
Taiwan
Thailand
Turkey
The United Kingdom
The United States
450472-091
450472-131
450472-251
450472-171
450472-231
450472-AD1
450472-BA1
450472-071
450472-B71
450472-111
450472-AB1
450472-281
450472-141
450472-031
450472-001
60 Chapter 4 Removal and replacement procedures
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the keyboard:
1. Position the computer with the front toward you.
2. Loosen the four Phillips PM2.5×9.0 captive screws that secure the keyboard to the computer.
3. Open the computer, and rest it on its right side.
Component replacement procedures 61
4. Lift the upper left corner of the keyboard (1) and swing the left side of the keyboard (2) forward.
5. Turn the computer right-side up, with the front toward you.
6. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and
disconnect the keyboard cable (2) from the system board.
7. Release the ZIF connector (3) to which the pointing stick cable is attached, and disconnect the
pointing stick cable (4) from the system board.
8. Remove the keyboard.
Reverse this procedure to install the keyboard.
62 Chapter 4 Removal and replacement procedures

Expansion memory module

Description Spare part number
4096-MB (PC2-5300, 667-MHz, DDR2) 469650-001
2048-MB (PC2-5300, 667-MHz, DDR2) 450576-001
1024-MB (PC2-5300, 667-MHz, DDR2) 450575-001
512-MB (PC2-5300, 667-MHz, DDR2) 450577-001
Before removing the expansion memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
Battery on page 44).
Keyboard on page 60).
Remove the expansion memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
2. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the
memory module slot.
Reverse this procedure to install the expansion memory module.
Component replacement procedures 63

TouchPad

NOTE: All TouchPad spare part kits include a TouchPad cable.
Description Spare part number
For use with keyboards with a pointing stick, includes 3 pointing stick buttons and 3 TouchPad buttons
For use with keyboards without a pointing stick, includes 2 TouchPad buttons 450596-001
450597-001
Before removing the TouchPad, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
Battery on page 44).
Keyboard on page 60).
Remove the TouchPad:
1. Turn the computer upside down, with the front toward you.
2. Remove the Torx T8M2.5×9.0 screw that secures the TouchPad to the computer.
3. Turn the computer right-side up, with the front toward you.
4. Disconnect the TouchPad cable (1) from the system board.
64 Chapter 4 Removal and replacement procedures
5. Lift the rear edge of the TouchPad (2) until it disengages from the top cover.
6. Remove the TouchPad.
Reverse this procedure to install the TouchPad.
Component replacement procedures 65

Modem module

Description Spare part number
Modem module 443899-001
Before removing the modem module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
6. Remove the TouchPad (see
Battery on page 44).
Keyboard on page 60).
TouchPad on page 64).
Remove the modem module:
1. Remove the two Phillips PM2.0×4.0 screws (1) that secure the modem module to the system board.
2. Disconnect the modem module (2) from the system board by lifting it straight up.
3. Disconnect the modem module cable (3) from the modem module.
4. Remove the modem module.
Reverse this procedure to install the modem module.
66 Chapter 4 Removal and replacement procedures

Switch cover

Description Spare part number
Switch cover (includes LED board and cable) 450479-001
Before removing the switch cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
Battery on page 44).
Keyboard on page 60).
Remove the switch cover:
1. Turn the computer upside down, with the rear panel toward you.
2. Remove the four Torx T8M2.5×4.0 screws that secure the switch cover to the computer.
3. Turn the computer right-side up, with the front toward you.
4. Open the computer as far as possible.
5. Disconnect the power button board cable (1) from the system board.
Component replacement procedures 67
6. Lift the front edge of the switch cover (2) until it disengages from the computer.
7. Release the ZIF connector (1) to which the LED board cable is connected and disconnect the cable
from the system board.
8. Remove the switch cover (2).
Reverse this procedure to install the switch cover.
68 Chapter 4 Removal and replacement procedures

Power button board

Description Spare part number
Power button board (includes cable) 450481-001
Before removing the power button board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
6. Remove the switch cover (see
Battery on page 44).
Keyboard on page 60).
Switch cover on page 67).
Remove the power button board:
1. Turn the switch cover upside down, with the front toward you.
2. Remove the Torx T8M2.5×4.0 screw (1) that secures the power button board to the switch cover.
3. Remove the power button board (2).
Reverse this procedure to install the power button board.
Component replacement procedures 69

Fan/heat sink assembly

Description Spare part number
Fan/heat sink assembly (includes replacement thermal material) 450594-001
Before removing the fan/heat sink assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
6. Remove the switch cover (see
Battery on page 44).
Keyboard on page 60).
Switch cover on page 67).
Remove the fan/heat sink assembly:
1. Disconnect the fan cable (1) from the system board.
2. Remove the Torx T8M2.5×7.0 screw (2) that secures the fan/heat sink assembly to the computer.
3. Loosen the four Torx T8M2.0×10.0 screws (3) that secure the fan/heat sink assembly to the
computer.
4. Lift the front edge of the fan/heat sink assembly (1) to disengage it from the system board and
graphics card.
70 Chapter 4 Removal and replacement procedures
5. Remove the fan/heat sink assembly (2) by sliding it forward.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the graphics card (1)
and fan/heat sink assembly(2) each time the fan/heat sink assembly is removed. Thermal material is included with all fan/heat sink assembly and graphics card spare part kits.
Reverse this procedure to reassemble and install the fan/heat sink assembly.
Component replacement procedures 71

Graphics card

NOTE: All graphics card spare part kits include replacement thermal material.
Description Spare part number
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468952-001
For use only with HP Compaq 8710w computer models with processors with 2- or 4-MB L2 cache (nVidia NB8E-GLM graphics card with 512 MB graphics subsystem memory operating at 800 MHz)
For use only with HP Compaq 8710p computer models with processors with 2- or 4-MB L2 cache (nVidia NB8P-NVS2 graphics card with 256 MB of graphics subsystem memory operating at 700 MHz; supports TurboCache)
451377-001
450484-001
Before removing the graphics card, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the following components:
a. Keyboard (see
b. Switch cover (see
c. Fan/heat sink assembly (see
Keyboard on page 60)
Switch cover on page 67)
Fan/heat sink assembly on page 70)
Remove the graphics card:
1. Remove the two HM5.0×10.0 standoffs (1) that secure the graphics card to the system board.
2. Lift the front edge of the graphics card (2) until it clears the adjacent edge of the top cover.
72 Chapter 4 Removal and replacement procedures
3. Remove the graphics card (3) by sliding it away from the graphics card slot at an angle.
NOTE: The graphics card is designed with a notch (4) to prevent incorrect installation.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the graphics
card (1) and fan/heat sink assembly(2) each time the fan/heat sink assembly is removed. Thermal material is included with all fan/heat sink assembly and graphics card spare part kits.
Reverse this procedure to install the graphics card.
Component replacement procedures 73

Heat sink

NOTE: Replacement thermal material is included with all heat sink spare part kits.
Description Spare part number
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468593-001
For use only with computer models equipped with processors with 2- or 4-MB L2 cache 450593-001
Before removing the processor heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
computer on, and then shut it down through the operating system.
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the following components:
a. Keyboard (see
b. Switch cover (see
c. Fan/heat sink assembly (see
Keyboard on page 60)
Switch cover on page 67)
Fan/heat sink assembly on page 70)
Remove the processor heat sink:
1. Loosen the four Phillips PM2.5×7.0 screws (1) that secure the processor heat sink to the base
enclosure.
2. Lift the right side of the processor heat sink (2) until it disengages from the processor.
3. Release the processor heat sink (3) by sliding it to the right until it clears the base enclosure.
4. Remove the processor heat sink.
74 Chapter 4 Removal and replacement procedures
Reverse this procedure to install the processor heat sink.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the processor heat
sink (1) and the processor (2) each time the processor heat sink is removed. Thermal material is included with all processor heat sink and processor spare part kits.

Processor

NOTE: Replacement thermal material is included with all processor spare part kits.
Description Spare part number
Intel Core 2 Duo T9500 2.6-GHz processor (6-MB L2 cache, 800-MHz FSB) 463051-001
Intel Core 2 Duo T9300 2.5-GHz processor (6-MB L2 cache, 800-MHz FSB) 463050-001
Intel Core 2 Duo T8300 2.4-GHz processor (3-MB L2 cache, 800-MHz FSB) 463049-001
Intel Core 2 Duo T8100 2.1-GHz processor (3-MB L2 cache, 800-MHz FSB) 463048-001
Intel Core 2 Duo T7800 2.6-GHz processor (4-MB L2 cache, 800-MHz FSB) 458218-001
Intel Core 2 Duo T7700 2.4-GHz processor (4-MB L2 cache, 800-MHz FSB) 450589-001
Intel Core 2 Duo T7500 2.2-GHz processor (4-MB L2 cache, 800-MHz FSB) 450588-001
Intel Core 2 Duo T7300 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB) 450587-001
Intel Core 2 Duo T7250 2.0-GHz processor (4-MB L2 cache, 800-MHz FSB) 460283-001
Intel Core 2 Duo T7100 1.8-GHz processor (2-MB L2 cache, 800-MHz FSB) 450586-001
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
Component replacement procedures 75
4. Remove the battery (see Battery on page 44).
5. Remove the following components:
a. Keyboard (see
b. Switch cover (see
c. Fan/heat sink assembly (see
d. Processor heat sink (see
Remove the processor:
1. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn counterclockwise
until you hear a click.
2. Lift the processor (2) straight up and remove it.
NOTE: The gold triangle (3) on the processor must be aligned with the triangle (4) embossed on
the processor socket when you install the processor.
Keyboard on page 60)
Switch cover on page 67)
Fan/heat sink assembly on page 70)
Heat sink on page 74)
Reverse this procedure to install the processor.
76 Chapter 4 Removal and replacement procedures

Display assembly

NOTE: All display assembly spare part kits include 3 WLAN antenna transceivers and cables.
Description Spare part number
17.0-inch, WUXGA+ WVA AntiGlare display assembly 450582-001
17.0-inch, WSXGA+ WVA AntiGlare display assembly 450580-001
17.0-inch, WSXGA+ WVA BrightView display assembly 450581-001
17.0-inch, WXGA+ AntiGlare display assembly 450583-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the keyboard (see
6. Remove the switch cover (see
Battery on page 44).
Keyboard on page 60).
Switch cover on page 67).
Remove the display assembly:
1. Turn the computer upside down, with the rear panel toward you.
2. Remove the two Torx T8M2.5×9.0 screws (1) from the rear panel that secure the display assembly
to the computer.
3. Remove the three Torx T8M2.5×9.0 screws (2) from the base enclosure that secure the display
assembly to the computer.
4. Turn the computer right-side up, with the front toward you.
Component replacement procedures 77
5. Disconnect the display panel cable (1) from the system board.
6. Remove the wireless antenna cables, the microphone cable, and the microphone extension cable
from the clips (2) and routing channels built into the top cover.
7. Disconnect the microphone cable (3) from the microphone extension cable.
8. Open the computer as far as possible.
9. Remove the two Torx T8M2.5×4.0 screws (1) that secure the display assembly to the computer.
10. Lift the display assembly (2) straight up and remove it.
78 Chapter 4 Removal and replacement procedures
11. If it is necessary to replace the display bezel or display hinges, remove the rubber screw covers
listed below. All rubber screw covers are included in the Display Rubber Kit, spare part number 450573-001.
NOTE: See Display inverter and ambient light sensor board on page 45 for display inverter and
ambient light sensor board replacement instructions.
(1) Two rounded rubber screw covers on the display bezel top edge corners
(2) Two flat rubber screw covers on the display bezel bottom edge corners
(3) Two small oblong rubber screw covers on the display bezel top edge
(4) Two large oblong rubber screw covers on the display bezel top edge
12. Remove the following screws:
(1) Six Phillips PM2.5×7.0 screws
(2) Two Phillips PM2.0×6.0 screws
(3) Two stabilizer clips
Component replacement procedures 79
13. Flex the inside edges of the left and right sides (1) and the top and bottom sides (2) of the display
bezel until the bezel disengages from the display enclosure.
14. Remove the display bezel (3). The display bezel is available using spare part number 450500-001.
15. Remove the four mylar screw covers (1) from the left and right sides of the display enclosure.
16. Remove the four Torx T8M2.5×4.0 screws (2) that secure the display panel to the display enclosure.
80 Chapter 4 Removal and replacement procedures
17. Remove the following screws:
(1) Two Torx T8M2.5×4.0 screws on the display panel top edge
(2) Two Torx T8M2.5×7.0 screws on the display panel bottom edge
(3) One Torx T8M2.5×4.0 screw that secures the ambient light sensor to the display enclosure
(4) One Torx T8M2.5×4.0 screw that secures the display inverter to the display enclosure
18. Remove the display panel from the display enclosure.
19. Remove the four Phillips PM2.0×4.0 screws (1) that secure each display hinge to the display
panel.
Component replacement procedures 81
20. Remove the display hinges (2). The left and right display hinges are included in the Display Bracket
Kit, spare part number 450570-001.
Reverse this procedure to reassemble and install the display assembly.
82 Chapter 4 Removal and replacement procedures

Top cover

NOTE: All top cover spare part kits include a fingerprint reader board and cable.
Description Spare part number
For use only with HP Compaq 8710w computer models 451379-001
For use only with HP Compaq 8710p computer models 450595-001
Before removing the top cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
4. Remove the following components:
computer on, and then shut it down through the operating system.
then unplugging the AC adapter from the computer.
a. Battery (see
b. Keyboard (see
c. Switch cover (see
d. Display assembly (see
Battery on page 44)
Keyboard on page 60)
Switch cover on page 67)
Display assembly on page 77)
Remove the top cover:
1. Turn the computer upside down, with the front toward you.
2. Remove the fourteen Torx T8M2.5×9.0 screws that secure the top cover to the base enclosure.
3. Turn the computer right-side up, with the front toward you.
Component replacement procedures 83
4. Disconnect the fingerprint reader board cable from the system board.
5. Remove the three Torx T8M2.5×7.0 screws that secure the top cover to the computer.
6. Lift the rear edge of the top cover (1) until it rests at an angle.
7. Swing the rear edge of the top cover (2) up and forward until it disengages from the base enclosure.
84 Chapter 4 Removal and replacement procedures
8. Remove the top cover (3).
Reverse this procedure to install the top cover.

Speaker assembly

Description Spare part number
Speaker assembly 450592-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the following components:
a. Battery (see
b. Keyboard (see
c. Switch cover (see
d. Display assembly (see
e. Top cover (see
Battery on page 44)
Keyboard on page 60)
Switch cover on page 67)
Display assembly on page 77)
Top cover on page 83)
Remove the speaker assembly:
1. Disconnect the speaker cable (1) from the system board.
Component replacement procedures 85
2. Remove the speaker assembly (2) from the base enclosure.
Reverse this procedure to install the speaker assembly.
86 Chapter 4 Removal and replacement procedures

System board

NOTE: Replacement thermal material is included with all system board spare part kits.
Description Spare part number
For use only with computer models equipped with processors with 3- or 6-MB L2 cache 468591-001
For use only with computer models equipped with processors with 2- or 4-MB L2 cache 450482-001
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the following components:
a. Battery (see
b. Hard drive (see
c. Bluetooth module (see
d. Optical drive (see
e. Keyboard (see
f. TouchPad (see
g. Switch cover (see
h. Fan/heat sink assembly (see
i. Graphics card (see
j. Processor heat sink (see
k. Display assembly (see
l. Top cover (see
m. Speaker assembly (see
Battery on page 44)
Hard drive on page 48)
Bluetooth module on page 51)
Optical drive on page 58)
Keyboard on page 60)
TouchPad on page 64)
Switch cover on page 67)
Fan/heat sink assembly on page 70)
Graphics card on page 72)
Heat sink on page 74)
Display assembly on page 77)
Top cover on page 83)
Speaker assembly on page 85)
When replacing the system board, be sure that the following components are removed from the defective system board and installed on the replacement system board:
Memory modules (see
on page 63)
WLAN module (see
RTC battery (see
Modem module (see
Primary memory module on page 52 and Expansion memory module
WLAN module on page 54)
RTC battery on page 57)
Modem module on page 66)
Component replacement procedures 87
Processor (see
Processor on page 75)
PC Card assembly (see
PC Card assembly on page 92)
Remove the system board:
1. Turn the computer upside down, with the front toward you.
2. Remove the Torx T8M2.5×4.0 screw that secures the system board to the base enclosure.
3. Turn the computer right-side up, with the front toward you.
4. Disconnect the following cables from the system board:
(1) RJ-45 connector cable
(2) Modem module cable
(3) Bluetooth module cable
(4) USB/audio board cable
5. Remove the modem module cable (5) from the clip in the system board.
88 Chapter 4 Removal and replacement procedures
6. Remove the two Torx T8M2.5×7.0 screws (1) that secure the system board to the base enclosure.
7. Use the optical drive connector (2) to lift the right side of the system board (3) until it rests at an
angle.
8. Remove the system board (4) by sliding it away from the base enclosure at an angle.
9. If it is necessary to replace the Bluetooth module cable, remove the cable (1) from the clips (2)
and (3) built into the base enclosure. The Bluetooth module cable is included in the Cable Kit, spare part number 450486-001.
Component replacement procedures 89
10. If it is necessary to replace the microphone extension cable, disconnect the cable (1), push the
cable from the clips (2), and remove the cable(3). The microphone extension cable is available using spare part number 450578-001.
11. If it is necessary to replace the RJ-11 connector cable, remove the RJ-11 connector (1) from the
clip built into the base enclosure.
12. Remove the RJ-11 connector cable (2) from the clips and routing channel built into the base
enclosure. The RJ-11 connector cable is included in the Cable Kit, spare part number 450486-001.
13. If it is necessary to replace the RJ-45 connector cable, remove the RJ-45 connector (1) from the
clip built into the base enclosure. The RJ-45 connector cable is included in the Cable Kit, spare part number 450486-001
90 Chapter 4 Removal and replacement procedures
14. Remove the RJ-45 connector cable (2) from the clips and routing channel built into the base
enclosure.
Reverse the preceding procedure to install the system board, Bluetooth module cable, microphone extension cable, RJ-11 cable, and RJ-45 cable.

USB/audio board

Description Spare part number
USB/audio board (includes 2-into-1 USB board cable and audio board cable) 450483-001
Before removing the USB/audio board, follow these steps:
1. Battery (see
2. Hard drive (see
3. Bluetooth module (see
4. Optical drive (see
5. Keyboard (see
6. TouchPad (see
7. Switch cover (see
8. Fan/heat sink assembly (see
9. Graphics card (see
10. Processor heat sink (see
Battery on page 44)
Hard drive on page 48)
Bluetooth module on page 51)
Optical drive on page 58)
Keyboard on page 60)
TouchPad on page 64)
Switch cover on page 67)
Fan/heat sink assembly on page 70)
Graphics card on page 72)
Heat sink on page 74)
11. Display assembly (see
12. Top cover (see
Top cover on page 83)
Display assembly on page 77)
Component replacement procedures 91
13. Speaker assembly (see Speaker assembly on page 85)
14. System board (see
System board on page 87)
Remove the USB/audio board:
1. Remove the USB/audio board cables (1) from the clips (2) built into the base enclosure.
2. Remove the Torx T8M2.5×4.0 screw (3) that secures the USB/audio board to the base enclosure.
3. Lift the left side of the USB/audio board (4) until the USB and audio connectors disengage from
the openings in the base enclosure.
4. Remove the USB/audio board and cables from the base enclosure.
Reverse this procedure to install the USB/audio board.

PC Card assembly

Description Spare part number
PC Card assembly 450584-001
Before removing the PC Card assembly, follow these steps:
1. Battery (see
2. Hard drive (see
3. Bluetooth module (see
4. Optical drive (see
5. Keyboard (see
6. TouchPad (see
7. Switch cover (see
Battery on page 44)
Hard drive on page 48)
Bluetooth module on page 51)
Optical drive on page 58)
Keyboard on page 60)
TouchPad on page 64)
Switch cover on page 67)
8. Fan/heat sink assembly (see
Fan/heat sink assembly on page 70)
92 Chapter 4 Removal and replacement procedures
Loading...
