HP Compaq 6000, Compaq 6000 Pro Quickspecs

1.

Dual microphone array

8.

Drive activity LED

2.

Webcam (optional)

9.

Power button and LED

3.

21.5-inch diagonal 16:9 widescreen LED-backlit
full HD LCD display

10.

High-performance stereo speakers

4.

Tray-load optical drive (optional)

11.

IR Receiver and LED (select models only)

5.

Optical drive eject button

12.

Adjustable tilt and swivel stand

6.

Brightness increase button

13.

HP low-profile keyboard* with numeric keypad

7.

Brightness decrease button

14.

HP optical mouse

*

* Wired or optional wireless

QuickSpecs

HP Compaq 6000 Pro All-in-One Business PC

Overview

DA - 13627 North America — Version 19 — September 30, 2011

Page 1

1.

HP 6-in-1 Media Card Reader

13.

Stereo audio line out

2.

IEEE 1394 port

14.

(4) USB 2.0 ports

3.

(2) USB 2.0 ports

15.

PS/2 mouse port

4.

Microphone/line in jack

16.

PS/2 keyboard port

5.

Headphone jack

17.

USB 2.0 port (used for optional wireless keyboard/mouse
transmitter/receiver)

6.

Hard drive access

18.

RJ-45 Gigabit Ethernet port

7.

Optical drive access

19.

Power connector with LED indicator

8.

Removable access panels

20.

VESA-compliant mounting holes (4)

9.

Memory access

21.

Adjustable tilt and swivel stand

10.

DisplayPort

22.

Access cover panel

11.

TV tuner coax jacks (optional)

23.

Lock slot

12.

IR Emitter (Blaster) output (optional)

24.

Lockable port cover

QuickSpecs

HP Compaq 6000 Pro All-in-One Business PC

Overview

DA - 13627 North America — Version 19 — September 30, 2011

Page 2

At A Glance

Genuine Windows 7 Professional Edition, SUSE Linux Enterprise Desktop 11, or FreeDOS

21.5-inch diagonal widescreen Full HD WLED anti-glare display (1080p)
Integrated All-in-One form factor
Adjustable tilt and swivel stand
Integrated VESA-compliant mounting hole pattern of 100mm x 100mm for attaching the All-in-One system directly to a wall
mount or articulating arm
Intel® Core™ 2 Duo, Pentium, or Celeron processor
Intel Q43 Express chipset
Integrated Intel Graphics Media Accelerator 4500 HD, or optional NVIDIA GeForce GT230 discrete graphics
Integrated Gigabit Network Connection (10/100/1000 NIC)
Integrated HD webcam* with dual microphone array; premium stereo speakers
Optional wireless connectivity:

802.11 b/g/n wireless LAN module

Bluetooth® 2.1
Optional TV Tuner
Up to 8 GB of DDR3 SDRAM supported, dual channel memory support
Up to 1 TB hard drive, or 80 GB Solid State Drive
Tray-load SuperMulti DVD Burner
6-in-1 Media Card Reader
HP SkyRoom** full version for professional quality visual collaboration built on HP Video and Image processing engines for hi-fi
audio, hi-def video, and hi-performance 3D application sharing
HP MediaSmart software for photos, music, video, DVD, and webcam
Microsoft Office Communicator certification

***

Face Recognition

****

for HP ProtectTools for auto-logon
Choice of wired or wireless keyboard and mouse
ENERGY STAR®
BFR/CFR/PVC-free (except for power supply and cord)

* The webcam is deselectable at customer request.
** HP Skyroom requires the webcam, a Microsoft Windows operating system, and a minimum of 2 GB memory.
*** Submitted to Microsoft and pending approval
**** Face Recognition for HP ProtectTools requires the webcam and a Microsoft Windows operating system.

QuickSpecs

HP Compaq 6000 Pro All-in-One Business PC

Overview

DA - 13627 North America — Version 19 — September 30, 2011

Page 3

Processor and Speed

*

One of the following

Intel Celeron Dual-Core Processors:

Intel Celeron E3300 Processor (2.5-GHz, 2 MB L2 cache, 800-MHz FSB)

Intel Pentium Dual-Core Processors:

Intel Pentium E5400 Processor (2.70-GHz, 2MB L2 cache, 800-MHz FSB)
Intel Pentium E5500 Processor (2.80-GHz, 2MB L2 cache, 800-MHz FSB)
Intel Pentium E6600 Processor (3.06-GHz, 2MB L2 cache, 1066-MHz FSB)
Intel Pentium E6700 Processor (3.20-GHz, 2MB L2 cache, 1066-MHz FSB)

Intel Core 2 Duo Processors:

Intel Core 2 Duo E7500 Processor (2.93-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E7600 Processor (3.06-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E8400 Processor (3.0-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8500 Processor (3.16-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8600 Processor (3.33-GHz, 6 MB L2 cache, 1333-MHz FSB)

* Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families.

Operating System

Preinstalled

Genuine Windows 7 Professional Edition 32

*

Genuine Windows 7 Professional Edition 64

*

SUSE Linux Enterprise Desktop 11

†

FreeDOS

Supported

Genuine Windows Vista Business 32

**

Genuine Windows Vista Business 64

**

Genuine Windows Vista Business 32

**

Genuine Windows 7 Enterprise 32

*

Genuine Windows 7 Enterprise 64

*

Certified

SUSE Linux Enterprise Desktop 11

†

NOTE:

Windows XP Mode, available as a separate download for Windows 7 Professional, works with
virtualization software such as Windows Virtual PC to run older Windows XP business software on the
Windows 7 desktop.

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality.
See:

http://www.microsoft.com/windows/windows-7/

for details.

** Certain Windows Vista product features require advanced or additional hardware. See:

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and:

http://www.microsoft.com/windowsvista/getready/capable.mspx

for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit:

http://www.windowsvista.com/upgradeadvisor

.

† The following features are not supported by SUSE Linux Enterprise Desktop 11:

Integrated 1.2 TPM Embedded Security Chip
HP USB Smartcard Keyboard
Array microphone
Optional Infrared Remote Control for Media Center (with TV Tuner)

QuickSpecs

HP Compaq 6000 Pro All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 13627 North America — Version 19 — September 30, 2011

Page 4

Chipset

Intel Q43 Express chipset

Graphics

Integrated Intel Graphics Media Accelerator 4500 HD
Shared system memory
DirectX 10 capable

-- or -­Discrete NVIDIA GeForce GT230 (internal MXM 3.0 connector)
1 GB GDDR3 800 MHz dedicated video memory
DirectX 10.1 capable

-- or -­Discrete ATI Radeon HD 5570 card (internal MXM 3.0 connector)
1 GB GDDR3 800 MHz dedicated video memory
DirectX 11 capable

Display

21.5-inch diagonal widescreen Full HD WLED anti-glare display,
tilt and swivel adjustments

Resolution

1920 x 1080 resolution (16:9)

Contrast ratio

1000:1 typical

Image brightness

250 nits typical

Viewing angle (typical)

Up to 160º horizontal/160º vertical (10:1 minimum contract ratio)

Adjustable Tilt and Swivel
Stand

Tilt range of motion is -5 degrees forward to +30 degrees backward.
Swivel wheel under base of stand allows it to swivel on the desk.

Memory

Standard

PC3-10600 DDR3 non-ECC SDRAM (runs at 1333 MHz)
Two 204-pin SODIMM slots supporting dual channel memory
2 GB (1 GB x 2)
2 GB (2 GB x 1)
4 GB (2 GB x 2)
4 GB (4 GB x 1)
8 GB (4 GB x 2)

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.

NOTE:

Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-bit
operating systems, the amount of usable memory is dependent upon your configuration, so that above 3
GB all memory may not be available due to system resource requirements.

QuickSpecs

HP Compaq 6000 Pro All-in-One Business PC

Standard Features and Configurable Components (availability may vary by country)

DA - 13627 North America — Version 19 — September 30, 2011

Page 5
