QuickSpecs

Overview

ProLiant BL30p Server Blades Installed in Server Blade Enclosure

ProLiant BL30p Server Blades Installed in Server Blade EnclosureProLiant BL30p Server Blades Installed in Server Blade Enclosure

ProLiant BL30p

ProLiant BL30pProLiant BL30p

ProLiant BL30p server blades (16)

ProLiant BL p-Class interconnects (2) (patch panel 2 shown)

What's New

What's NewWhat's New

ProLiant BL30p -- A new high density, dual-processor capable server blade for the ProLiant BL p-Class An enhanced, fully backwards-compatible server blade enclosure featuring support for the new BL30p series server blades and all current and future BL20p series and BL40p series blades New enclosure with enhanced backplane components features Integrated Light-Out (iLO) management cable consolidation iLO provides new feature for automatically assigning static IP addresses for blades New dual power input option kit allows support for two power enclosures on mini bus bars

DA - 11958 Canada — Version 2 — June 29, 2004

Page 1

QuickSpecs

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Overview

At A Glance

At A GlanceAt A Glance

Maximum density ProLiant BL30p server blade

Maximum density ProLiant BL30p server bladeMaximum density ProLiant BL30p server blade

Up to two Intel Xeon 3.2-GHz/533-MHz with 2MB L3 cache processors with Hyper-Threading Technology ServerWorks GC-LE chipset 1024-MB PC2100-MHz Registered ECC DDR memory (1 x 1-GB), expandable to 4-GB, flex memory supports interleaved and non-interleaved memory configurations Integrated Lights-Out (iLO) Advanced Pack with new static IP bay configuration feature Two (2) NC7781 PCI-X Gigabit NICs (embedded) One 10/100T NIC (embedded) dedicated to iLO management Supports up to two optional small form factor EIDE 60-GB hard drives BIOS-Enhanced RAID for Linux enables both primary and secondary hard drives to be bootable Dual-Port Fibre Channel Adapter (2-Gb) option for SAN connectivity BL30p plugs vertically into blade sleeve and sleeve plugs into 6U blade enclosure Local I/O cable attaches to front of blade and provides two USB ports, one video port, one iLO port and serial port Integrated Access Tool for blade management and enhanced server blade documentation including Best Practices and Common Procedures guides Up to 96 BL30p blades fit in 42U rack in non-redundant power configuration; up to 80 BL30p blades fit in 42U in full power redundant configuration

ProLiant BL p-Class Server Blade Enclosure with Enhanced Backplane Components

ProLiant BL p-Class Server Blade Enclosure with Enhanced Backplane ComponentsProLiant BL p-Class Server Blade Enclosure with Enhanced Backplane Components

Updated to support the new BL30p blade and be fully compatible with all current and future BL20p series and BL40p series blades Blade iLO signals are physically consolidated to an RJ-45 port on the server blade management module Option kit available for field upgrade of backplanes to existing, deployed blade enclosures Each server blade enclosure is 6U and holds up to 16 ProLiant BL30p server blades (BL30p blade sleeve is required for each pair of BL30p blades installed) Interconnect options for network signal routing include GbE Interconnect Switches, GbE2 Interconnect Switches with optional Fibre Channel pass through, Patch Panels or Patch Panel 2 with Fibre Channel pass through

ProLiant BL p-Class Power Enclosure

ProLiant BL p-Class Power EnclosureProLiant BL p-Class Power Enclosure

BL p-Class rack-centralized power enclosure holds hot-plug power supplies Use BL p-Class sizing tool to determine power and cooling requirements based on your desired configuration:

http://h30099.www3.hp.com/configurator/calc/Power%20Calculator%20Catalog.xls

3 phase power enclosure highly recommended for BL30p deployments BL p-Class power enclosure not needed if using facility -48VDC ± 10% (DC option kit required)

ProLiant BL p-Class Power Distribution

ProLiant BL p-Class Power DistributionProLiant BL p-Class Power Distribution

Carries power from the power enclosure(s) to the server blade enclosures Three power distribution choices: mini bus bars (support up to 3 blade enclosures) scalable bus bars (support up to 5 blade enclosures) power bus box (supports a single blade enclosure)

New dual power input option kit allows support for two power enclosures on mini bus bars BL p-Class server blades, server blade enclosures, interconnects and power enclosures protected by a limited three year warranty with optional service uplifts available.

NOTE:

Power requirements for a ProLiant BL p-Class system: 200V - 240V AC, 30 amp or facility DC -48V ± 10%.

NOTE:NOTE:

NOTE:

NOTE: NOTE:

All ATA hard drives offered by HP carry a one year warranty regardless of the base system in which they are installed.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 2

QuickSpecs

Overview

ProLiant BL30p Server Blade

ProLiant BL30p Server BladeProLiant BL30p Server Blade

++++

ProLiant BL30p

ProLiant BL30pProLiant BL30p

ProLiant BL30p Blade Sleeve (holds 2 BL30p blades)

ProLiant BL30p Blade Sleeve (holds 2 BL30p blades)ProLiant BL30p Blade Sleeve (holds 2 BL30p blades)

++++

DA - 11958 Canada — Version 2 — June 29, 2004

Page 3

QuickSpecs

Overview

BL p-Class Server Blade Enclosure with enhanced backplane components

BL p-Class Server Blade Enclosure with enhanced backplane componentsBL p-Class Server Blade Enclosure with enhanced backplane components

++++

ProLiant BL30p

ProLiant BL30pProLiant BL30p

OROR

Patch Panel (shown) or

Patch Panel 2

BL p-Class Interconnects

BL p-Class InterconnectsBL p-Class Interconnects

GbE Interconnect Switch (shown) or GbE2 Interconnect Switch

++++

BL p-Class power enclosure(s) and power supplies (three phase recommended)

BL p-Class power enclosure(s) and power supplies (three phase recommended)BL p-Class power enclosure(s) and power supplies (three phase recommended)

++++

OROR

Facility DC

Facility DCFacility DC

(fiber- or copper-based)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 4

QuickSpecs

Overview

OR OR

OROR

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Mini bus bars

Scalable bus bars

BL p-Class power distribution

BL p-Class power distributionBL p-Class power distribution

Bus boxes

DA - 11958 Canada — Version 2 — June 29, 2004

Page 5

QuickSpecs

Overview

Configuration Steps

Configuration StepsConfiguration Steps

For a complete ProLiant BL30p blade solution, do the following:

Select desired model, configuration and quantity of ProLiant BL30p server blades

PLUS

PLUSPLUS

Determine how many BL30p blade sleeves are required. Each BL30p blade sleeve holds two BL30p server blades and one server blade enclosure

2. holds up to eight sleeves.

PLUS

PLUSPLUS

3. Determine how many BL p-Class Server Blade Enclosures with enhanced backplanes are required. Each blade enclosure with enhanced

3. backplanes can hold up to 16 ProLiant BL30p server blades.

NOTE:

NOTE: NOTE:

Server blade enclosures with enhanced backplanes can be purchased with licenses for Rapid Deployment Pack: BL p-Class server blade enclosure with enhanced backplanes with 8 Rapid Deployment Pack licenses (281404-B22) or BL p-Class server blade enclosure with enhanced backplanes with Rapid Deployment Pack trial (243564-B22)

ProLiant BL p-Class server blade enclosures with enhanced backplane components are required to support BL30p server blades.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

PLUS

PLUSPLUS

Select an Interconnect Kit. Each Interconnect Kit contains a pair of interconnects. One interconnect kit is required with each server blade enclosure:

4. RJ-45 Patch Panel 2 with Fibre Channel pass through. This is the required patch panel model for Fibre Channel connectivity on BL30p (306465B21). or RJ-45 Patch Panel (230766-B21) or BL p-Class C-GbE2 Interconnect Kit (with 12 RJ-45 10/100/1000 T/TX/T external ports) (283192-B21) with or without optional ProLiant BL p-Class GbE2 Storage Connectivity Kit (with 16 Fibre Channel connectors) (321745 -B21) (required for BL30p Fibre Channel connectivity when using the GbE2 Interconnect Switch) or BL p-Class F-GbE2 Interconnect (with 8 LC 1000 SX and 4 RJ-45 10/100/1000 T/TX/T external ports) (283193-B21) with or without optional ProLiant BL p-Class GbE2 Storage Connectivity Kit (with 16 Fibre Channel connectors) (321745 -B21) (required for BL30p Fibre Channel connectivity when using the GbE2 Interconnect Switch) or BL p-Class C-GbE Interconnect Kit (with 4 RJ-45 10/100/1000 T/TX/T and 8 RJ-45 10/100 T/TX external ports (249655-B21) or BL p-Class F-GbE Interconnect Kit (with 4 LC 1000 SX and 8 RJ-45 10/100 T/TX external ports) (279720-B21)

PLUS

PLUSPLUS

Select BL p-Class power enclosure(s) and power supplies based on configuration.

NOTE:

NOTE: NOTE: Use the ProLiant BL p-Class sizing utility to help determine power configuration:

http://h30099.www3.hp.com/configurator/calc/Power%20Calculator%20Catalog.xls .

NOTE:

NOTE:NOTE:

3 phase power enclosure options are highly recommended for deployments of BL30p server blades.

Power enclosures and supplies are not needed if using facility DC (-48V ± 10%).

3 phase power enclosure with six power supplies (3 phase power enclosure holds six power supplies) (NA/JPN- 230769-001) (INTL - 230769-421) (Power enclosures and supplies can also be purchased separately see options list)

PLUS

PLUSPLUS

Select power distribution option:

6. Mini bus bars (support up to 3 server blade enclosures) (240559-B21). Note that two mini-bar configurations can be stacked to fill a 42U rack. or Scalable bus bars (support up to 5 server blade enclosures) (240560-B21) or Power Bus Box (supports a single server blade enclosure) (240562-B21)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 6

QuickSpecs

Overview

ProLiant BL p-Class Server Blade Enclosures with Enhanced Backplanes Installed in 42U Rack

ProLiant BL p-Class Server Blade Enclosures with Enhanced Backplanes Installed in 42U RackProLiant BL p-Class Server Blade Enclosures with Enhanced Backplanes Installed in 42U Rack

Redundant Power Configuration (left) and Non-Redundant Power Configurations (right)

Redundant Power Configuration (left) and Non-Redundant Power Configurations (right)Redundant Power Configuration (left) and Non-Redundant Power Configurations (right)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

1. Power Enclosure

DA - 11958 Canada — Version 2 — June 29, 2004

Page 7

QuickSpecs

Standard Features (Server Blade)

Processor

ProcessorProcessor

Upgradability

UpgradabilityUpgradability

Cache Memory

Cache MemoryCache Memory

One of the following depending on Model

Chipset

ChipsetChipset

Memory

MemoryMemory

Intel Xeon Processor 3.2-GHz/533-MHz with 2MB L3 cache Intel Xeon Processor 3.2-GHz/533-MHz with 1MB L3 cache Intel Xeon Processor 3.06-GHz/533-MHz with 512KB L2 cache

BL30p server blade is dual-processor capable

2-MB Level 3 cache 1-MB Level 3 cache 512-KB Level 2 cache

ServerWorks GC-LE chipset

NOTE:

NOTE: NOTE:

http://www.serverworks.com/products/overview.html

Standard

Maximum Flex Memory

For more information regarding the ServerWorks chipset, see the following website:

ProLiant BL30p

ProLiant BL30pProLiant BL30p

1024-MB (1 x 1-GB) PC2100 DDR SDRAM running at 266MHz; non-interleaved unless a second DIMM option installed 287497-B21

4-GB BL30p blade supports memory interleaving when an identical pair of DIMMs is installed

Network Adapter

Network AdapterNetwork Adapter

Integrated Manageability

Integrated ManageabilityIntegrated Manageability

Internal Storage

Internal StorageInternal Storage

Three (3) network adapters total: Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE One 10/100T NIC (embedded) dedicated to iLO management

Integrated Lights-Out (iLO) Management Advanced Pack with new static IP bay configuration feature

Hard Drives Maximum Internal Storage

None ship standard 120-GB (2 x 60-GB small form factor EIDE, 5400rpm hard drives)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 8

QuickSpecs

Standard Features (Server Blade)

Fiber Channel on the

Fiber Channel on theFiber Channel on the ProLiant BL30p

ProLiant BL30p

ProLiant BL30pProLiant BL30p

The following items are needed to connect the ProLiant BL30p to a SAN via Fibre Channel:

1. ProLiant BL30p blade with Dual-Port Fibre Channel Adapter (option) installed The Dual-Port Fibre Channel Adapter option 354054-B21 is compatible with the ProLiant BL30p blade (not

compatible with ProLiant BL20p series blades) Two ports on each configured blade provide redundant Fibre Channel connections Supports up to 2 Gb/s and backward compatible with existing 1 Gb/s Fibre Channel equipment Based on the QLogic ISP2312 chipset Kit includes two small form factor pluggable transceivers with LC connectors for installation into the interconnect option kit (see 2A and 2B below)

AND

ANDAND

2A. RJ-45 Patch Panel 2 (with Fibre Channel pass through) interconnect option

Enables pass through of both Ethernet and Fibre Channel signals Ethernet signals exit the rear of the RJ-45 Patch Panel 2 interconnects Fibre Channel signals exit the front of the RJ-5 Patch Panel 2 interconnects

8 Fibre Channel small form factor pluggable (SPF) transceiver cages on the front of each Patch Panel 2 interconnect (16 Fibre Channel SPF transceiver cages per server blade enclosure) SPF transceivers are included with the BL30p Dual-Port Fibre Channel Adapter kit (option)

OROR

2B. C-GbE2 or F-GbE2 Interconnect Kit plus the GbE2 Storage Connectivity Kit (option)

Enables Ethernet signal consolidation and pass through of Fibre Channel signals Both Ethernet and Fibre Channel signals exit the rear of the GbE2 Interconnect Switch (with the GbE2 Storage Connectivity Kit option)

8 Fibre Channel small form factor pluggable (SPF) transceiver slots on the back of each GbE2 Interconnect Switch (16 Fibre Channel SPF transceiver cages per server blade enclosure) SPF transceivers included with the BL30p Dual-Port Fibre Channel Adapter kit (option)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Local I/O Cable

Local I/O CableLocal I/O Cable

AND

ANDAND

3. Compatible SAN Optimized for StorageWorks arrays:

Modular Smart Array 1000 Enterprise Virtual Array 5000 (EVA5000) V2; Enterprise Virtual Array 3000 (EVA3000)

XP48, 128, 512, 1024; Compatible with select 3rd party SANs. Refer to blade storage website for details:

http://h18000.www1.hp.com/products/servers/proliant-bl/p-class/storage.html

Connects to the front of BL30p server blade for local management and aid in first server blade configuration Two (2) USB ports, one (1) video port, one (1) iLO port and one (1) serial port Two (2) Local I/O cables ship with each server blade enclosure with enhanced backplane components (281404-B22 and

243564-B22)

NOTE:

NOTE: NOTE:

Tested USB devices (keyboard, mouse, floppy) are listed in options section below.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 9

QuickSpecs

Standard Features (Server Blade Enclosure and Interconnects)

ProLiant BL p-Class Server Blade Enclosure and Interconnects

ProLiant BL p-Class Server Blade Enclosure and InterconnectsProLiant BL p-Class Server Blade Enclosure and Interconnects

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Server Blade Enclosure

Server Blade Enclosure

Server Blade EnclosureServer Blade Enclosure

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Power Requirements

Power Requirements

Power RequirementsPower Requirements

6U (10.5-inch), 19-inch wide Holds up to:

Eight (8) ProLiant BL20p series server blades Sixteen (16) ProLiant BL30p series server blades (BL30p blade sleeves required) Two (2) ProLiant BL40p series server blades A combination of the above

NOTE:

NOTE: NOTE: server blades. NOTE:

NOTE:

NOTE: NOTE: upgrade of a blade enclosure to support BL30p series blades and provide a single, physical iLO port for the enclosure.

Two (2) outside bays for interconnects (Patch Panel, Patch Panel 2, GbE Interconnect Switch, or GbE2 Interconnect Switch) Server blade management module on the rear of the server blade enclosure is hot-plug, has a centralized 10/100T iLO port

for all installed blades, reports events of all installed blades and provides asset and inventory information via SNMP.

Redundant 208V 30amp 3-phase 4 wire

NOTE:

NOTE:NOTE:

Redundant 200V - 240V AC, 30 amp single-phase

ProLiant BL p-Class server blade enclosures with enhanced backplane components are required to support BL30p

Server Blade Enclosure Upgrade Kit (354100-B21) contains enhanced backplane components and enables a field

3 phase power highly recommended for BL30p deployments.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

DA - 11958 Canada — Version 2 — June 29, 2004

Page 10

QuickSpecs

Standard Features (Server Blade Enclosure and Interconnects)

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Interconnect Switch

Interconnect Switch

Interconnect SwitchInterconnect Switch Option

Option

OptionOption

(A pair of switches per kit)

(Each server blade enclosure requires a pair of interconnects

- patch panels or interconnect switches)

Interconnect Switch interconnects consolidate the Ethernet signals from the server blades to a smaller set of external copperbased or fiber-based uplink ports for connection to the network infrastructure. Like the Patch Panel interconnects, an option is also available to pass through individual BL20p G2 and BL30p Fibre Channel signals.

The interconnect switches provide up to a 32-to-1 server network cable reduction per server enclosure depending on the mix of BL20p series, BL30p series, and BL40p series blades. Each interconnect switch pair reduces up to sixteen internal server network (NIC) ports to one to six external ports (four on a modular rear mounting interconnect and two on the switch front panel). This provides a total of twelve external ports per server blade enclosure.

The GbE2 Interconnect Kits (C-GbE2 and F-GbE2) provide NIC consolidation to 1000 Mbps (Gigabit Ethernet), advanced network feature support including layer 3-7 switching, Fibre Channel pass-through (for BL20p series and BL30p series blades), and 10 Gigabit Ethernet bandwidth connectivity to the network. Expandability of both layer 3-7 switching and 10 Gigabit Ethernet is planned with future GbE2 Interconnect Switch upgrade options available through Nortel Networks.

The ProLiant BL p-Class F-GbE2 Interconnect Kit includes two GbE2 Interconnect Switches and two QuadSX Interconnect Modules that provide eight (8) LC 1000 SX and four (4) RJ-45 10/100/1000 T/TX/T external ports per server blade enclosure. The ProLiant BL p-Class C-GbE2 Interconnect Kit includes two GbE2 Interconnect Switches and two QuadT2 Interconnect Modules that provide twelve (12) RJ-45 10/100/1000 T/TX/T external ports per server blade enclosure. The optional ProLiant BL p-Class GbE2 Storage Connectivity Kit (321745 -B21) is required for Fibre Channel passthrough when using either the C-GbE2 or F-GbE2 Interconnect Kit.

The GbE Interconnect Kits (C-GbE and F-GbE) provide NIC consolidation to 100 Mbps (Fast Ethernet).

The ProLiant BL p-Class F-GbE Interconnect Kit includes two GbE Interconnect Switches and two DualTSX Interconnect Modules that provide four (4) LC 1000 SX and eight (8) RJ-45 10/100 T/TX external ports per server blade enclosure. The ProLiant BL p-Class C-GbE Interconnect Kit includes two GbE Interconnect Switches and two QuadT Interconnect Modules that provide four (4) RJ-45 10/100/1000 T/TX/T and eight (8) RJ-45 10/100 T/TX external ports per server blade enclosure.

Also included (per Interconnect Switch):

One (1) RS-232 DB-9 front panel out-of-band management port Redundant crosslink ports connecting the two interconnect switches Redundant power inputs and on-board redundant fans Hot-plug and hot- remove with configuration retention and no need to cable/re-cable Power ON, management, and per port status and speed LED indicators Reset/power momentary push-button switch HP ProLiant BL Interconnect Switch Management Utilities and User Documentation CD Fully pre-configured for rapid deployment and immediate operation

The GbE Interconnect Kits (C-GbE and F-GbE) are for applications that require network adapter consolidation to 100 Mbps (Fast Ethernet).

ProLiant BL30p

ProLiant BL30pProLiant BL30p

ProLiant BL Interconnect Switch Management System and Utilities: Full featured web-based and scriptable command line (CLI) interfaces, password protected multi-level user accounts,

Telnet, SNMP, BootP client, port mirroring, port-based VLANs and VLAN tagging, EtherChannel compatible multi-port trunking, network time protocol, spanning tree protocol, broadcast/multicast storm control, flow control, human readable/writeable configuration file, TFTP client, IP address security restrictions, auto-MDI/MDIX, auto-negotiation and auto-sensing of speed and duplex mode, and more.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 11

QuickSpecs

Standard Features (Server Blade Enclosure and Interconnects)

ProLiant BL p-Class GbE2

ProLiant BL p-Class GbE2ProLiant BL p-Class GbE2 Storage Connectivity Kit

Storage Connectivity Kit

Storage Connectivity KitStorage Connectivity Kit Option

Option

OptionOption (supports a pair of GbE2 switches)

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class RJ-45 Patch Panel

RJ-45 Patch Panel

RJ-45 Patch PanelRJ-45 Patch Panel (A pair of patch panels provided per kit)

(Each server blade enclosure requires a pair of interconnects

- patch panels or interconnect switches)

ProLiant BL p-Class RJ-45

ProLiant BL p-Class RJ-45ProLiant BL p-Class RJ-45 Patch Panel 2

Patch Panel 2

Patch Panel 2 Patch Panel 2 Channel pass through)

(A pair of patch panels provided per kit)

(Each server blade enclosure requires a pair of interconnects

- patch panels or interconnect switches)

NOTE:

NOTE: NOTE: a GbE2 Interconnect Kit is required for SAN connectivity with BL20p series and BL30p series blades.

(with Fibre

Either Patch Panel 2 or

The GbE2 Storage Connectivity Kit (option) is required for Fibre Channel signal pass-through when using a GbE2 Interconnect Switch Kit. Both Ethernet cable consolidation and Fibre Channel connectivity is possible using a single interconnect option. Order one GbE2 Storage Connectivity Kit per server blade enclosure for Fibre Channel pass through of BL20p and BL30p series blades. The GbE2 Storage Connectivity Kit includes two OctalFC Interconnect Modules that provide sixteen open transceiver cages for the pluggable small form factor transceivers that come with each BL30p Dual-Port Fibre Channel Adapter (option) and each BL20p Dual Port Fibre Channel Adapter. The GbE2 Storage Connectivity Kit supports up to eight BL20p series, up to sixteen BL30p series blades or combinations thereof.

6U (10.5-inch), plugs into BL p-Class 6U server blade enclosures. Passes through Ethernet NIC signals, from all installed server blades, individually out as RJ-45 connections. Supports Gigabit Ethernet network adapters. 16 RJ-45 connectors on the back of each RJ-45 Patch Panel (32 RJ-45 connections per server blade enclosure). The benefits to the RJ-45 Patch Panel are that it:

- Allows the customer to connect signals to their own LAN infrastructure components.

- Provides very economical option enabling the lowest cost blade solution.

- Is completely passive and requires no software or management.

6U (10.5-inch), plugs into BL p-Class 6U server blade enclosures. Passes through Ethernet NIC signals, from all installed server blades, individually out as RJ-45 connections. Supports Gigabit Ethernet network adapters. 16 RJ-45 connectors on the back of each RJ-45 Patch Panel 2 (32 RJ-45 connections per server blade enclosure). Passes through Fibre Channel signals, from all installed BL20p and BL30p series server blades, individually out through

small form factor pluggable (SPF) transceiver cages. Supports 2 Gb/s Fibre Channel signals and backward compatible with existing 1 Gb/s Fibre Channel equipment. 8 Fibre Channel small form factor pluggable (SPF) transceiver cages on the front of each Patch Panel 2 (16 Fibre Channel

SPF transceiver cages per server blade enclosure). The benefits to the RJ-45 Patch Panel 2 are that it:

- Allows the customer to connect signals to their own LAN and SAN infrastructure components.

- Provides a very economical option enabling the lowest cost blade solution.

- Is completely passive and requires no software or management.

- Electrically isolates the Ethernet and Fibre Channel signals from each other.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

ProLiant BL p-Class Fibre

ProLiant BL p-Class FibreProLiant BL p-Class Fibre Channel pass through

Channel pass through

Channel pass throughChannel pass through

Fibre Channel signals travel from a ProLiant BL20p series and/or BL30p series blades through the server blade enclosure backplane. Fibre Channel signals are terminated through the RJ-45 Patch Panel 2 or GbE2 Interconnect Switch (with GbE2 Storage Connectivity Kit) in the interconnect bays. To provide redundancy each server blade has two Fibre Channel signals; one Fibre Channel signal terminates through the right interconnect, the other Fibre Channel signal terminates through the left interconnect.

Eight Fibre Channel small form factor pluggable (SPF) transceiver cages exist on the front of each RJ-45 Patch Panel 2 and rear of each GbE2 Interconnect Switch (16 Fibre Channel connections per server blade enclosure). The SPF cages are used for insertion of SPF transceivers included with the BL20p G2 Dual-port Fibre Channel Mezzanine Card and the BL30p Dual-Port Fibre Channel Adapter.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 12

QuickSpecs

Standard Features (Server Blade Enclosure and Interconnects)

Required Network Cabling

Required Network CablingRequired Network Cabling

10Base-T

100Base-TX

1000Base-T

1000Base-SX

NOTE:

For cabling information, refer to the website at:

NOTE:NOTE:

Categories 3, 4 or 5 UTP (100 metres) EIA/TIA-568 100-ohm STP (100 metres)

Category 5 UTP (100 metres) EIA/TIA-568 100-ohm STP (100 metres)

50/125 µm Multimode Fiber, 400 MHz/Km (500 metres) 50/125 µm Multimode Fiber, 500 MHz/Km (550 metres)

62.5/125 µm Multimode Fiber, 160 MHz/Km (220 metres)

62.5/125 µm Multimode Fiber, 200 MHz/Km (275 metres)

http://www.hp.com/go/servers/

ProLiant BL30p

ProLiant BL30pProLiant BL30p

DA - 11958 Canada — Version 2 — June 29, 2004

Page 13

QuickSpecs

Standard Features (Power System and Rack Information)

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Power System and

Power System and

Power System andPower System and Rack Information

Rack Information

Rack InformationRack Information

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Power Enclosure

Power Enclosure

Power EnclosurePower Enclosure

BL p-Class Power

BL p-Class PowerBL p-Class Power Distribution

Distribution

DistributionDistribution

Scalable Bus Bar

Scalable Bus BarScalable Bus Bar Mini Bus Bar

Mini Bus Bar

Mini Bus BarMini Bus Bar Power Bus Box

Power Bus Box

Power Bus BoxPower Bus Box

Required Power Source

Required Power SourceRequired Power Source

NOTE:

To determine power configuration, please refer to the ProLiant BL p-Class Overview and Planning Whitepaper and

NOTE:NOTE: sizing utility at

3U (5.25-inch), 19-inch wide, 29-inch deep (0.48-metre wide, 0.74-metre deep), dual input single phase and three phase models available.

BL p-Class power enclosure provides scalable rack-centralized, hot-plug power without the need for PDUs. Each 3 phase power enclosure houses six hot-plug power supplies Each single-phase power enclosure holds four hot-plug power supplies Please use the sizing utility to determine the power needed for each configuration

http://h30099.www3.hp.com/configurator/powercalcs.asp

NOTE:

NOTE:NOTE:

Power enclosures and power supplies are not needed if using facility DC (-48V DC ± 10%). If using facility DC, Facility DC Power Connection kit (240563-B21) is needed.

-48 VDC power (from the power enclosures or facility DC power) is carried from the power enclosures to the server blade enclosures through bus bars (for multiple enclosures) or power bus boxes (for a single enclosure). Hinges attach the bus bars to the rack rails and provide easy rear access to the blade enclosures and interconnects. Power is distributed through independent A- and B-sided bus bars.

Three power distribution solutions are available depending on the size of the intended deployment (see table).

Power Enclosures Supported

Power Enclosures SupportedPower Enclosures Supported

NOTE*:

NOTE*:NOTE*: NOTE:

NOTE:

NOTE:NOTE:

Two 30-Amp redundant power feeds per power enclosure Connectors:

http://www.hp.com/products/servers/proliant-bl/p-class/info/

3 phase power enclosure options highly recommended for BL30p deployments.

Server Blade Enclosures

Server Blade EnclosuresServer Blade Enclosures

1 or 2

1 or 2*

1 1

Dual power input kit for mini bus bar option (364565-B21) required to support two power enclosures.

To support a full 42U rack of BL p-Class server blades, use two stacked pairs of mini bus bars.

Supported

SupportedSupported

up to 5 up to 3

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Max. Rack Space Occupied

Max. Rack Space OccupiedMax. Rack Space Occupied

36U 24U

NEMA receptacles

1. NA 1-phase L6-30, 250v, 30A 3-wire NA 3-phase L15-30, 250V, 30A, 4-wire

For cabling information, refer to the website at:

http://www.hp.com/go/servers/

DA - 11958 Canada — Version 2 — June 29, 2004

Page 14

QuickSpecs

Standard Features (Manageability)

ProLiant Essentials

ProLiant EssentialsProLiant Essentials Foundation Pack

Foundation Pack

Foundation PackFoundation Pack Software for the ProLiant

Software for the ProLiant

Software for the ProLiantSoftware for the ProLiant BL Server

BL Server

BL ServerBL Server

ProLiant Essentials Rapid Deployment Pack

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Rapid Deployment Pack (RDP) is an automated deployment and provisioning solution for all ProLiant servers. RDP includes the Altiris Deployment Solution and ProLiant Integration Module featuring ProLiant server pre-configured events for OS installation, and optimized software drivers, firmware and management agents. Every RDP CD includes 10-node trial licenses for evaluation purposes. RDP requires a license for each server deployed and are available for purchase with blade servers. For more information, visit

http://www.hp.com/servers/rdp

HP Systems Insight Manger

Management Agents

Subscriber's Choice

ROMPaq, support software, and configuration utilities

HP Systems Insight Manager (HP SIM) help maximize system uptime and performance and reduce system maintenance costs by providing proactive notification of problems before those problems result in unplanned downtime or reduced productivity. HP SIM is easy to set up to work with the Insight Management Agents, integrated Light-Out and Remote Insight Light-Out Edition, and Version Control Agents to deliver robust fault, configuration, and asset management as well as remote administration. With HP Systems Insight Manager customers will also be able to take advantage of role-based security; the ability to manage ProLiant, Integrity, and HP9000 systems; and plug-ins for storage, client, printer, and power management as well as server rapid deployment, performance management, and workload management. For more details on HP Systems Insight Manager visit

http://www.hp.com/go/hpsim

The Management Agents form the foundation for HP's Intelligent Manageability strategy. They provide direct, browser-based access to in-depth instrumentation built into HP servers, workstations, desktops, and portables, and send alerts to HP Systems Insight Manager and other enterprise management applications in case of subsystem or environmental failures. For additional information about the Management Agents and other management products from HP, please visit the management Web site at

http://www.hp.com/servers/manage

Subscriber's Choice Driver and Support Alerts/Notifications is a web-based email subscription service that provides software and driver change notifications for ProLiant products. Sign up at and customize your profile to receive various new alerts as they become available, on a weekly or monthly basis.

The latest software, drivers, and firmware fully optimized and tested for your ProLiant server and options, available in the RDP CD, SmartStart or downloadable from Software and Drivers download pages, linked from the SmartStart website at

http://www.hp.com/servers/smartstart

http://www.hp.com/go/subscriberschoice

Optional ProLiant

Optional ProLiantOptional ProLiant Essentials Value Packs

Essentials Value Packs

Essentials Value PacksEssentials Value Packs

Survey Utility and diagnostics utilities

NOTE:

For more information regarding ProLiant Essentials Software, please see the following URL:

NOTE:NOTE:

http://www.hp.com/servers/proliantessentials

Optional software offerings that selectively extend the functionality of an Adaptive Infrastructure to address specific business problems and needs:

Workload Management Pack - provides easier management of complex environments, improving overall server utilization and enabling customers for the first time to confidently deploy multiple applications on a single multiprocessor ProLiant Server. Performance Management Pack - identifies and explains hardware performance bottlenecks on ProLiant servers and attached options enabling users to better utilize their valuable resources.

NOTE:

NOTE: NOTE:

http://www.hp.com/servers/proliantessentials

information.

Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to

The most advanced configuration analysis, reporting and troubleshooting utilities used by HP and at your fingertips, available in SmartStart.

or the various ProLiant Essentials Value Pack product QuickSpecs for more

DA - 11958 Canada — Version 2 — June 29, 2004

Page 15

QuickSpecs

Standard Features (Manageability)

SmartStart

SmartStartSmartStart

OS Support

OS SupportOS Support

Intelligent Manageability

Intelligent ManageabilityIntelligent Manageability

SmartStart is a tool that simplifies single server setup, providing a rapid way to deploy reliable and consistent server configurations. SmartStart 7.00 and later can now deploy the ProLiant BL20P G3 and ProLiant BL40P servers, using the I/O port with an attached USB CD-ROM device. To obtain a copy of SmartStart for your blade server, redeem the coupon that is included with your Blade server or order your copy from the SmartStart web site. For more information, please visit the SmartStart Web site at SmartStart version supported (minimum): SmartStart 6.20

Microsoft® Windows® LINUX

NOTE:

NOTE: NOTE: Support Matrices website: NOTE:

NOTE:

NOTE:NOTE:

http://www.hp.com/products/servers/proliant-bl/p-class/info/

Integrated Lights-Out (iLO) Advanced Pack

For a more complete and up-to-date listing of supported operating systems and versions, please visit our OS

For an up-to-date listing of the latest drivers available for the ProLiant BL p-Class, please visit the support website:

Static IP bay configuration -- new feature for ProLiant BL p-Class blades Virtual Text and Graphical Remote Console Virtual CD-ROM and Virtual Floppy Virtual Power Button Control Dedicated LAN Connectivity Automatic IP Configuration via DHCP/DNS/WINS Industry Standard 128-bit Secure Sockets Layer (SSL) Security IML and iLO Event Logging Support for 12 user accounts with customizable access privileges

http://www.hp.com/servers/smartstart

http://www.hp.com/go/ossupport

ProLiant BL30p

ProLiant BL30pProLiant BL30p

NOTE:

For more information on iLO Advanced visit the website:

NOTE:NOTE:

Automatic Server Recovery-2 (ASR-2) Redundant ROM Remote Flash ROM ROM Based Setup Utility (RBSU) Advanced Configuration and Power Interface Specification Ready (ACPI) Server and Interconnect Switch Health Logs Redundant Power Supply Utility Pre-Failure Warranty (covers processors, as well as hard drives and memory) Interconnect Switch Management System and Utilities (Interconnect Switch option) Integrated Management Log (IML) Off-Line Backup Processor capability Dynamic sector repairing and drive parameter tracking (with Smart Array controllers) Network adapter teaming set-up utility

http://www.hp.com/servers/ilo/

DA - 11958 Canada — Version 2 — June 29, 2004

Page 16

QuickSpecs

Standard Features (Manageability)

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Availability Features

Availability Features

Availability FeaturesAvailability Features

Power redundancy:

hot-plug power supplies redundant AC feeds (requires two power enclosures when using blade enclosures with enhanced backplane components) interconnects options and server blade management module share power from both A- and B- side power buses

Dual-Port Fibre Channel Mezzanine Card for redundant SAN connections Redundant ROM on each server blade ECC Memory Network adapter teaming (network fault tolerance, transmit load balancing, switch-assisted load balancing)

Interconnect Switch availability features:

Hot-plug and hot- remove with configuration retention and no need to cable/re-cable Two network connections per BL30p server blade routed to independent interconnect switches Redundant Ethernet inter-switch communication with two sets of redundant Ethernet uplink ports per each interconnect switch Redundant front panel ports per each interconnect switch for diagnostics, management, and additional uplinks Redundant serial ports Compatibility with PVST+ (GbE2 switch) and 802.1D Spanning tree protocol support for loop-free path redundancy Static IEEE 802.3ad (EtherChannel compatible) trunking with automatic port load balancing and failover Redundant configuration files and operating system firmware images in memory (GbE2 switch) Redundant fans per each interconnect switch Redundant power to each interconnect switch Support for ProLiant network adapter teaming Redundant configurable community strings and SNMP trap manager hosts Redundant configurable syslog server, DNS server, and default gateways (GbE2 switch)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Security

SecuritySecurity

Minimum Rack

Minimum RackMinimum Rack Requirements

Requirements

RequirementsRequirements

Power-on password Administrator's password Integrated Lights-Out has 12 customizable user accounts and SSL encryption Integrated Lights-Out can be disabled via a Global Setting Interconnect switch multilevel user names and passwords, management interface time out period setting, SSH*, SCP secure copy protocol*, port-based IEEE 802.1Q tagged VLANs, RADIUS user authentication and authorization*, and IP address restriction

NOTE*:

NOTE*: NOTE*:

Mounts in ProLiant, and Telco racks and Third Party racks that meet the following criteria:

NOTE:

NOTE:NOTE:

GbE2 Interconnect Switch only

Compatible with 19-inch Standard EIA rail sets EIA rail-to-rail depth is 29 - 30" Cabinet depth must be at least 36-inch deep overall (Additional min. 3.5-inch clearance from rear RETMA rail to rear door, inclusive in the 36-inch overall depth) Ample room for top and bottom cable egress (approximately 8 square inches for full rack configuration with patch panel) Must be capable of supporting 1600 lb (for full rack configuration) Perforated front and rear doors to accommodate front-to-back cooling Must have 65% open perforation on server blade enclosure doors to support airflow requirements Optimized for use with the HP 10000 Series racks

If using Compaq 7000 Series rack, Rack Extension Kit and High Air Flow Rack Door options are required.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 17

QuickSpecs

Standard Features (Manageability)

Rack Airflow Requirements

Rack Airflow RequirementsRack Airflow Requirements

Service and Support

Service and SupportService and Support

HP 10000 series racks provide enhanced airflow for maximum cooling, allowing racks to be fully loaded with servers and server blades using the latest server technologies.

CAUTION:

CAUTION:CAUTION: prevent damage to the equipment:

CAUTION:

CAUTION:CAUTION: ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE:

NOTE:NOTE: server, or to the server documentation located in the Support section on the ProLiant BL30p website:

Three-year limited warranty, including hardware diagnostic support, pre-failure warranty (coverage of hard drives, memory and processors). The warranty is fully supported by HP Services and a worldwide network of resellers and service providers. In addition 90-day's getting started software telephone support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services.

If a third-party rack is used, observe the following additional requirements to ensure adequate airflow and to

Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of

2.75 inches (7 cm).

Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This arrangement

For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with the

http://www.hp.com/servers/bl30p

ProLiant BL30p

ProLiant BL30pProLiant BL30p

NOTE:

Sever Blade Limited Warranty includes 3 year Parts, 3 year Labour, 3-year on-site support.

NOTE:NOTE: NOTE:

NOTE:

NOTE: NOTE: support.

Care Pack services provide a range of life cycle support options that let you choose the service levels that meet your business requirements, from basic to mission-critical.

A full range of HP Care Pack hardware and software services are available including:

HP Care Pack services for ProLiant BL p-Class server blades, cover the server blade and the p-Class blade enclosure that the server blade is installed in as well as interconnects, power enclosure with power supplies and power distribution.

NOTE:

NOTE:NOTE: worldwide Web site on the internet at: NOTE:

NOTE:

NOTE:NOTE:

http://www.hp.com/hps

NOTE:

NOTE:NOTE:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

Server Blade Enclosure and Interconnects Limited Warranty includes 3 year Parts, 3 year Labour, 3-year on-site

Installation and start up Education courses Extended onsite hardware coverage hours from same business day 13 hours, 5 day to 24 hours, 7 days call window with options including 4-hour response or 6-hour Call To Repair Comprehensive range of software technical support for Microsoft, Linux, ProLiant Essentials and VMWare-based IT solutions helping to deliver high level of application availability. Response times range from 30 mins for critical problems to 2 hours. System Management, Performance Services and Mission Critical Support Solution

For more information on HP Care Pack services, contact any of our worldwide sales offices or resellers or visit our

http://www.hp.com/hps/carepack

For more complete information on HP Services offerings, customers and resellers, please visit us at:

Additional information regarding worldwide limited warranty and technical support is available at:

DA - 11958 Canada — Version 2 — June 29, 2004

Page 18

QuickSpecs

Models

ProLiant BL30p X3.2-2MB,

ProLiant BL30p X3.2-2MB,ProLiant BL30p X3.2-2MB, 1GB (2P)

1GB (2P)

1GB (2P)1GB (2P) 360329-B21

ProLiant BL30p X3.2-1MB,

ProLiant BL30p X3.2-1MB,ProLiant BL30p X3.2-1MB, 1GB (2P)

1GB (2P)

1GB (2P)1GB (2P) 368271-B21

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage Optical Drive

Optical Drive

Optical DriveOptical Drive I/O cable

I/O cable

I/O cableI/O cable Form Factor

Form Factor

Form FactorForm Factor

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage Optical Drive

Optical Drive

Optical DriveOptical Drive Form Factor

Form Factor

Form FactorForm Factor

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Two (2) Intel Xeon 3.2-GHz standard (up to 2 supported) 2-MB Level 3 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266-MHz (1

x 1-GB); 2-way interleaved when an identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

One (1) 10/100T NIC (embedded) dedicated to iLO management None ship standard Up to 120-GB maximum (with optional hard drives) None Included Plugs vertically into BL30p blade sleeve. Blade sleeve supports 1 or 2 BL30p blades. Blade

sleeve plugs vertically into ProLiant BL p-Class Server Blade Enclosure with enhanced backplane components.

Two (2) Intel Xeon 3.2-GHz standard (up to 2 supported) 1-MB Level 3 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266-MHz (1

x 1-GB); 2-way interleaved when an identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

One (1) 10/100T NIC (embedded) dedicated to iLO management None ship standard Up to 120-GB maximum (with optional hard drives) None Plugs vertically into BL30p blade sleeve. Blade sleeve supports 1 or 2 BL30p blades. Blade

sleeve plugs vertically into ProLiant BL p-Class Server Blade Enclosure with enhanced backplane components.

ProLiant BL30p

ProLiant BL30pProLiant BL30p X3.06/533MHz-512KB,

X3.06/533MHz-512KB,

X3.06/533MHz-512KB,X3.06/533MHz-512KB, 1GB (2P)

1GB (2P)

1GB (2P)1GB (2P) 354566-B21

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage Optical Drive

Optical Drive

Optical DriveOptical Drive Form Factor

Form Factor

Form FactorForm Factor

Two (2) Intel Xeon 3.06-GHz standard (up to 2 supported) 512-KB Level 2 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266MHz (1 x

1-GB), 2-way interleaved when an identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

One (1) 10/100T NIC (embedded) dedicated to iLO management None ship standard Up to 120-GB maximum (with optional hard drives) 2 x 60-GB None Plugs vertically into BL30p blade sleeve. Blade sleeve supports 1 or 2 BL30p blades. Blade

sleeve plugs vertically into ProLiant BL p-Class Server Blade Enclosure with enhanced backplane components.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 19

QuickSpecs

Models

ProLiant BL30p

ProLiant BL30pProLiant BL30p X3.06/533MHz-512KB,

X3.06/533MHz-512KB,

X3.06/533MHz-512KB,X3.06/533MHz-512KB, 1GB (1P)

1GB (1P)

1GB (1P)1GB (1P) 354050-B21

ProLiant 3.2-GHz BL30p

ProLiant 3.2-GHz BL30pProLiant 3.2-GHz BL30p Server Blade Multi-Pack

Server Blade Multi-Pack

Server Blade Multi-PackServer Blade Multi-Pack 368272-B21

NOTE:

Multi-pack contains 8

NOTE:NOTE: BL30p server blades, 4 BL30p blade sleeves and 8 licenses for Rapid Deployment Pack.

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage Optical Drive

Optical Drive

Optical DriveOptical Drive Form Factor

Form Factor

Form FactorForm Factor

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage

ProLiant BL30p

ProLiant BL30pProLiant BL30p

One (1) Intel Xeon 3.06-GHz standard (up to 2 supported) 512-KB Level 2 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266-MHz (1

x 1-GB), 2-way interleaved when an identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

sleeve plugs vertically into ProLiant BL p-Class Server Blade Enclosure with enhanced backplane components.

Each blade is configured with Two (2) Intel Xeon 3.2-GHz standard (up to 2 supported) 2-MB Level 3 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266-MHz (1

x 1-GB), 2-way interleaved when identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

One (1) 10/100T NIC (embedded) dedicated to iLO management None ship standard Up to 120-GB maximum (with optional hard drives) 2 x 60-GB

ProLiant 3.06-GHz BL30p

ProLiant 3.06-GHz BL30pProLiant 3.06-GHz BL30p Server Blade Multi-Pack

Server Blade Multi-Pack

Server Blade Multi-PackServer Blade Multi-Pack 354051-B21

NOTE:

NOTE: NOTE: BL30p server blades, 4 BL30p blade sleeves and 8 licenses for Rapid Deployment Pack.

Multi-pack contains 8

Processor(s)

Processor(s)Processor(s) Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory

Network Adapter

Network AdapterNetwork Adapter

Hard Drives

Hard DrivesHard Drives Internal Storage

Internal Storage

Internal StorageInternal Storage

Each blade is configured with Two (2) Intel Xeon 3.06-GHz standard (up to 2 supported) 512-KB Level 2 writeback per processor 1024-MB (standard) to 4-GB (maximum) of PC2100 DDR SDRAM running at 266-MHz (1

x 1-GB), 2-way interleaved when identical pair installed Two (2) NC7781 PCI-X Gigabit NICs (embedded) with WOL and PXE

One (1) 10/100T NIC (embedded) dedicated to iLO management None ship standard Up to 120-GB maximum (with optional hard drives) 2 x 60-GB

DA - 11958 Canada — Version 2 — June 29, 2004

Page 20

QuickSpecs

Options

Unique Options

Unique OptionsUnique Options

ProLiant BL30p Dual-Port

ProLiant BL30p Dual-PortProLiant BL30p Dual-Port Fibre Channel Adapter

Fibre Channel Adapter

Fibre Channel AdapterFibre Channel Adapter

ProLiant Essentials Value

ProLiant Essentials ValueProLiant Essentials Value Pack Software

Pack Software

Pack SoftwarePack Software

ATA Hard Drive Kit for ProLiant BL30p, 2.5" parallel ATA drive, 60GB, 5400 rpm (option) ProLiant BL30p Blade Sleeve Kit (option)

NOTE:

Each blade sleeve supports one or two BL30p server blades.

NOTE:NOTE:

Dual-Port Fibre Channel Adapter (2-Gb) Kit (option) for ProLiant BL30p

NOTE:

When using this card, Patch Panel 2 or a GbE2 Interconnect Switch Kit (with GbE2 Storage

NOTE:NOTE: Connectivity Kit) must be used to provide pass through of the Fibre Channel signals.

Rapid Deployment Pack, 10 User, V1.x

NOTE:

The above licenses allows 10 servers to be managed and deployed via the Deployment

NOTE:NOTE: Server.

NOTE:

Not necessary if you purchase the BL30p Multi-Pack (354051-B21) or server blade enclosure

NOTE:NOTE: with 8 Rapid Deployment Pack licenses 281404-B22.

NOTE:

Rapid Deployment pack is now available in a Linux Edition for Linux-only environments.

NOTE:NOTE:

Rapid Deployment Pack, 1 User, V1.x

NOTE:

The above licenses allows 1 server to be managed and deployed via the Deployment Server.

NOTE:NOTE:

NOTE:

Not necessary if you purchase the BL30p Multi-Pack (354051-B21) or server blade enclosure

NOTE:NOTE: with 8 Rapid Deployment Pack licenses 281404-B22.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

354052-B21 354101-B21

354054-B21

269817-B21

267196-B21

Processor

ProcessorProcessor

Memory

MemoryMemory (SDRAM DIMMs)

NOTE:

Rapid Deployment pack is now available in a Linux Edition for Linux-only environments.

NOTE:NOTE:

Flexible Quantity License Kit

License-Only - for use with a Master License Agreement

ProLiant Essentials Workload Management Pack (Featuring Resource Partitioning Manager version

2.0)

NOTE:

For more information regarding ProLiant Essentials Software, please see the following URL:

NOTE:NOTE:

http://www.compaq.ca/english/productinfo/servers/ proliant/essentials/essentials_index.htm

NOTE:

Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs.

NOTE:NOTE: Refer to URL

proliant/essentials/essentials_index.htm

QuickSpecs for more information.

Intel Xeon 3.06-GHz / 512-KB cache Processor Kit (option)

NOTE:

NOTE:NOTE: because all models ship with two processors installed.

4096-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (2 x 2-GB) 1024-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (1 x 1-GB)

NOTE:

NOTE: NOTE: and therefore provides 2-way interleaving when installed on a base model BL30p blade.

1024-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (2 x 512-MB)

http://www.compaq.ca/english/productinfo/servers/

There is no option kit offered for the ProLiant BL30p with Intel Xeon 3.2GHz processor

This DIMM option is an identical match to the DIMM installed on the BL30p base model

or the various ProLiant Essentials Value Pack product

302127-B21

302128-B21

303284-B21

354053-B21

300682-B21 287497-B21

300679-B21

DA - 11958 Canada — Version 2 — June 29, 2004

Page 21

QuickSpecs

Options

BL p-Class Server

BL p-Class ServerBL p-Class Server Blade Enclosures with

Blade Enclosures with

Blade Enclosures withBlade Enclosures with enhanced backplane

enhanced backplane

enhanced backplaneenhanced backplane components

components

componentscomponents

BL p-Class Interconnects

BL p-Class InterconnectsBL p-Class Interconnects

ProLiant BL p-Class Server Blade Enclosure (includes enhanced backplane components) ProLiant BL p-Class Server Blade Enclosure with eight (8) ProLiant Essentials Rapid Deployment Pack

Licenses (includes enhanced backplane components)

NOTE:

ProLiant BL p-Class server blade enclosures with enhanced backplane components are

NOTE:NOTE: required to support BL30p server blades.

ProLiant BL p-Class Server Blade Enclosure Upgrade Kit (option)

NOTE:

Server Blade Enclosure Upgrade Kit (354100-B21) contains enhanced backplane

NOTE:NOTE: components and enables a field upgrade of a blade enclosure to support BL30p series blades and provide a single, physical iLO port for the enclosure.

ProLiant BL p-Class Patch Panel 2 Kit with Fibre Channel pass-through (pair)

NOTE:

NOTE: NOTE:

ProLiant BL p-Class Patch Panel (pair)

NOTE:

NOTE:NOTE:

ProLiant BL p-Class C-GbE2 Interconnect Kit (with pair of GbE2 Interconnect Switches and two QuadT2 Interconnect Modules)

NOTE:

NOTE:NOTE:

ProLiant BL p-Class F-GbE2 Interconnect Kit (with pair of GbE2 Interconnect Switches and two QuadSX Interconnect Modules)

NOTE:

NOTE:NOTE:

ProLiant BL p-Class GbE2 Storage Connectivity Kit (with pair of OctalFC Interconnect Modules and two Fibre Channel signal conditioning cards)

NOTE:

NOTE:NOTE: Switch. NOTE:

NOTE:

NOTE: NOTE:

ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches and two QuadT Interconnect Modules)

NOTE:

NOTE:NOTE: NOTE:

NOTE:

NOTE:NOTE: that a Patch Panel Kit or GbE2 Interconnect Switch Kit option be used if server NIC speeds to 1000 Mbps are required. NOTE:

NOTE:

NOTE:NOTE: any individual rack or a series of coupled racks and the front and rear doors must be installed in any racks containing more than one ProLiant BL p-Class GbE Interconnect Kit.

ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches and two DualTSX Interconnect Modules)

NOTE:

NOTE:NOTE: NOTE:

NOTE:

NOTE: NOTE: that a Patch Panel Kit option be used if server NIC speeds to 1000 Mbps are required. NOTE:

NOTE:

NOTE:NOTE: any individual rack or a series of coupled racks and the front and rear doors must be installed in any racks containing more than one ProLiant BL p-Class GbE Interconnect Kit.

Only one interconnect kit required per server blade enclosure.

Required for BL30p Fibre Channel signal pass through when using the GbE2 Interconnect

Only one Storage Connectivity Kit required per each GbE2 Interconnect Kit.

Only one interconnect kit required per server blade enclosure. The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is recommended

To meet applicable radio frequency (RF) emission limits, the sidewall panels on the ends of

Only one interconnect kit required per server blade enclosure.

The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is recommended

To meet applicable radio frequency (RF) emission limits, the sidewall panels on the ends of

ProLiant BL30p

ProLiant BL30pProLiant BL30p

243564-B22 281404-B22

354100-B21

306465-B21

230766-B21

283192-B21

283193-B21

321745 -B21

249655-B21

279720-B21

DA - 11958 Canada — Version 2 — June 29, 2004

Page 22

QuickSpecs

Options

BL p-Class Power Options

BL p-Class Power OptionsBL p-Class Power Options

ProLiant BL p-Class Power

ProLiant BL p-Class PowerProLiant BL p-Class Power Distribution

Distribution

DistributionDistribution

NOTE:

NOTE: NOTE:

http://h30099.www3.hp.com/configurator/powercalcs.asp

Single Phase Redundant Power Enclosure with 4 power supplies (Single Phase Power Enclosure holds a maximum of 4 power supplies; no need to order additional power supplies with this option kit)

3 Phase Redundant Power Enclosure with 6 power supplies (3 Phase Power Enclosure holds a maximum of 6 power supplies; no need to order additional power supplies with this option kit)

Single Phase Power Enclosure (empty) (Holds up to 4 power supplies; power supplies are not included in this kit)

3 Phase Power Enclosure (empty) (Holds up to 6 power supplies; power supplies are not included in this kit)

Single Power Supply Facility DC Power Connection

Scalable Bus Bar Mini Bus Bar Dual Power Input Kit for Mini Bus Bar Power Bus Box

Use p-Class sizing tool to help determine power configuration:

ProLiant BL30p

ProLiant BL30pProLiant BL30p

239162-001

230769-001

231710-001

231709-001

239161-B21 240563-B21

240560-B21 240559-B21 364565-B21 240562-B21

ProLiant BL p-Class Other

ProLiant BL p-Class OtherProLiant BL p-Class Other Options

Options

OptionsOptions

Tape Libraries

Tape LibrariesTape Libraries

Diagnostic Station ProLiant BL p-Class Server Enclosure Shipping Bracket Option Kit

NOTE:

Used to secure one server blade enclosure in a rack when moving.

NOTE:NOTE:

ProLiant BL p-Class Power Enclosure Shipping Bracket Option Kit

NOTE:

Used to secure one power enclosure in a rack when moving.

NOTE:NOTE:

Bus Bar Telco Rack Kit Enclosure Telco Rack Kit

HP StorageWorks MSL6000 Tape Library

HP StorageWorks MSL6000 Tape LibraryHP StorageWorks MSL6000 Tape Library MSL6030, 1 drive, 30 slots, Ultrium 460, rackmount

MSL6030, 2 drive, 30 slots, Ultrium 460, rackmount

MSL6030, 1 drive, 30 slots, Ultrium 460, rackmount with embedded FC router

MSL6030, 2 drive, 30 slots, Ultrium 460, rackmount with embedded FC router

MSL6030, 1 drive, 30 slots, Ultrium 460, tabletop

MSL6030, 2 drive, 30 slots, Ultrium 460, tabletop

MSL6060, 2 drive, 60 slot, Ultrium 460, rackmount

MSL6060, 2 drive, 60 slot, Ultrium 460, rackmount with embedded FC router

MSL6060, 2 drive, 60 slot, Ultrium 460, tabletop

NOTE:

NOTE: NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

HP StorageWorks MSL5026S2 Tape Library

HP StorageWorks MSL5026S2 Tape LibraryHP StorageWorks MSL5026S2 Tape Library

MSL5026S2, 1 drive, 26 slots, SDLT 320, rackmount

MSL5026S2, 2 drive, 26 slots, SDLT 320, rackmount

Please reference the MSL6000 Tape Library QuickSpecs at

for additional information needed to create a complete solution;

http://www.hp.com/go/ebs

230743-B21 293121-B21

365044-B21

245249-B21 266076-B21

330731-B22

330731-B23

330731-B24

330731-B25

330788-B21

330788-B22

331196-B21

331196-B22

331195-B21

293472-B22

293472-B23

DA - 11958 Canada — Version 2 — June 29, 2004

Page 23

QuickSpecs

Options

ProLiant BL30p

ProLiant BL30pProLiant BL30p

MSL5026S2, 1 drive, 26 slots, SDLT 320, rackmount with embedded FC router

MSL5026S2, 2 drive, 26 slots, SDLT 320, rackmount with embedded FC router

MSL5026S2, 1 drive, 26 slots, SDLT 320, tabletop

MSL5026S2, 2 drive, 26 slots, SDLT 320, tabletop

NOTE:

Please reference the MSL5026S2 Tape Library QuickSpecs at

NOTE:NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

HP StorageWorks MSL5052S2 Tape Library

HP StorageWorks MSL5052S2 Tape LibraryHP StorageWorks MSL5052S2 Tape Library

MSL5052S2, 2 drive, 52 slots, SDLT 320, rackmount

MSL5052S2, 2 drive, 52 slots, SDLT 320, rackmount with embedded FC router

MSL5052S2, 2 drive, 52 slots, SDLT 320, tabletop

NOTE:

NOTE: NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

HP StorageWorks MSL5030 Tape Library

HP StorageWorks MSL5030 Tape LibraryHP StorageWorks MSL5030 Tape Library

MSL5030, 1 drive, 30 slots, Ultrium 230, rackmount

MSL5030, 2 drive, 30 slots, Ultrium 230, rackmount

MSL5030, 1 drive, 30 slots, Ultrium 230, rackmount with embedded FC router

MSL5030, 2 drive, 30 slots, Ultrium 230, rackmount with embedded FC router

MSL5030, 1 drive, 30 slots, Ultrium 230, tabletop

MSL5030, 2 drive, 30 slots, Ultrium 230, tabletop

NOTE:

NOTE: NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

HP StorageWorks MSL5060 Tape Library

HP StorageWorks MSL5060 Tape LibraryHP StorageWorks MSL5060 Tape Library

MSL5060, 2 drive, 60 slots, Ultrium 230, rackmount

MSL5060, 2 drive, 60 slots, Ultrium 230, rackmount with embedded FC router

MSL5060, 2 drive, 60 slots, Ultrium 230, tabletop

NOTE:

NOTE:NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

HP StorageWorks ESL9000 Series Tape Libraries

HP StorageWorks ESL9000 Series Tape LibrariesHP StorageWorks ESL9000 Series Tape Libraries

ESL9595 Extended Tape Library, 0 drive, 400 slots (card cage, Interface Mgr card, Command View license)

ESL9322 Extended Tape Library, 0 drive, 222 slots (card cage, Interface Mgr card, Command View license)

ESL9000 Ultrium 460 drive kit

ESL9000 Ultrium 230 drive kit

ESL9000 SDLT 320 drive kit

NOTE:

NOTE:NOTE:

http://www.hp.com/go/automation

reference current compatibility information at

Please reference the MSL5052S2 Tape Library QuickSpecs at

Please reference the MSL5030 Tape Library QuickSpecs at

Please reference the MSL5060 Tape Library QuickSpecs at

Please reference the ESL9000 Series Tape Libraries QuickSpecs at

for additional information needed to create a complete solution;

http://www.hp.com/go/ebs

for additional information needed to create a complete solution;

http:/www.hp.com/go/ebs

for additional information needed to create a complete solution;

http://www.hp.com/go/ebs

for additional information needed to create a complete solution;

http://www.hp.com/go/ebs

for additional information needed to create a complete solution;

http://www.hp.com/go/ebs

293472-B24

293472-B25

293473-B21

293473-B22

293474-B21

293474-B24

293476-B21

301897-B22

301897-B23

301897-B24

301897-B25

301898-B21

301898-B22

301899-B22

301899-B23

301900-B21

343378-B21

343377-B21

330834-B21

301930-B21

293414-B21

DA - 11958 Canada — Version 2 — June 29, 2004

Page 24

QuickSpecs

Options

Magneto-Optical

Magneto-OpticalMagneto-Optical Jukeboxes

Jukeboxes

JukeboxesJukeboxes

HP StorageWorks 9.1 GB Mid-range Optical Jukeboxes

HP StorageWorks 9.1 GB Mid-range Optical JukeboxesHP StorageWorks 9.1 GB Mid-range Optical Jukeboxes 300mx, 2 drive, 32 slot jukebox 600mx, 4 drive, 64 slot jukebox

700mx, 2 drive, 76 slot jukebox

NOTE:

Please reference the Magneto-Optical Jukebox data sheets at

NOTE:NOTE: for additional information needed to create a complete solution

HP StorageWorks 9.1 GB High-end Optical Jukeboxes

HP StorageWorks 9.1 GB High-end Optical JukeboxesHP StorageWorks 9.1 GB High-end Optical Jukeboxes

1200mx, 4 drive, up to 128 slots

1200mx, 6 drive, up to 128 slots

2200mx, 4 drive, up to 238 slots

2200mx, 6 drive, up to 238 slots

2200mx, 10 drive, up to 238 slots

NOTE:

NOTE: NOTE: for additional information needed to create a complete solution

Please reference the Magneto-Optical Jukebox data sheets at

http://www.hp.com/go/optical

ProLiant BL30p

ProLiant BL30pProLiant BL30p

C1150M C1160M

C1170M

C1104M

C1105M

C1111M

C1107M

C1110M

HP StorageWorks Modular

HP StorageWorks ModularHP StorageWorks Modular Smart Array 1000

Smart Array 1000

Smart Array 1000Smart Array 1000

HP StorageWorks Modular Smart Array 1000 Modular Smart Array 1000 Controller Modular Smart Array Fibre Channel I/O Module Modular Smart Array hub 2/3 HP StorageWorks Modular Smart Array 1000

NOTE:

Please see the StorageWorks Modular Smart Array 1000 QuickSpecs for additional options

NOTE:NOTE: and configuration information at:

http://h18000.www1.hp.com/products/quickspecs/11033_ca/11033_ca.HTML

201723-B22 218231-B22 218960-B21 286763-B21 201723-B22

DA - 11958 Canada — Version 2 — June 29, 2004

Page 25

QuickSpecs

Options

Cluster Options

Cluster OptionsCluster Options

ProLiant Cluster HA/F200 for Modular Smart Arrary 1000

NOTE:

NOTE: NOTE: Modular Smart Arrary 1000 please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11035_ca/11035_ca.html

ProLiant Cluster HA/F500 Enhanced Kit for Enterprise Virtual Array

ProLiant Cluster HA/F500 Basic Kit for Enterprise Virtual Array

NOTE:

NOTE:NOTE: for Enterprise Virtual Array please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11055_ca/11055_ca.html

NOTE:

NOTE: NOTE: following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/10232_ca/10232_ca.html

HP Serviceguard for Linux ProLiant Cluster A.11.14 for Red Hat EL 2.1 (2 node license cluster kit)

NOTE:

NOTE:NOTE:

HP Serviceguard for Linux ProLiant Cluster (2 node license cluster kit) A.11.15

NOTE:

NOTE:NOTE:

HP Serviceguard for Linux (single license version for ordering flexibility and to ease ordering for larger cluster for Red Hat AS 2.1) A.11.14

NOTE:

NOTE:NOTE:

HP Serviceguard for Linux (single license version for ordering flexibility and to ease ordering for larger cluster) A.11.15

NOTE:

NOTE:NOTE:

NOTE:

NOTE: NOTE: following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11518_ca/11518_ca.html

For additional information regarding the ProLiant Cluster for HA/F100, HA/F200 for

For additional information regarding the HP ProLiant Cluster for ProLiant Cluster HA/F500

For additional information regarding the HP ProLiant Cluster for HA/F500 please see the

Kit includes 2 licenses, documentation and an Ethernet crossover cable.

Kit includes single license version and documentation.

For additional information regarding the HP Serviceguard for Linux License, please see the

ProLiant BL30p

ProLiant BL30pProLiant BL30p

252409-B24

254623-B24

313047-B23

305199-B22

305199-B24

307754-B22

307754-B24

USB Options

USB OptionsUSB Options

USB 1.44-MB External Diskette Drive (Carbonite) USB Optical Scroll Mouse (Carbonite) USB Easy Access Keyboard (Carbonite/Silver)

DC141B DD441B

DC168B-ABA

DA - 11958 Canada — Version 2 — June 29, 2004

Page 26

QuickSpecs

Options

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Rack 10000 Series

Rack 10000 SeriesRack 10000 Series (Graphite Metallic)

HP S10614 (14U) Rack Cabinet - Shock Pallet HP Rack 10647 (47U) Cabinet - Pallet HP Rack 10647 (47U) Cabinet - Crated HP Rack 10642 (42U) Cabinet - Pallet HP Rack 10642 (42U) Cabinet - Shock Pallet HP Rack 10642 (42U) Cabinet - Crated HP Rack 10636 (36U) Cabinet - Pallet HP Rack 10636 (36U) Cabinet - Shock Pallet HP Rack 10636 (36U) Cabinet - Crate HP Rack 10622 (22U) Cabinet - Pallet HP Rack 10622 (22U) Cabinet - Shock Pallet HP Rack 10622 (22U) Cabinet - Crated

NOTE:

-B21 (pallet) used to ship empty racks shipped on a truck

NOTE:NOTE:

-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels)

-B23 (crated) used for air shipments of empty racks Not all HP equipment is qualified to be shipped in the Rack 10000 series.

NOTE:

Please see the Rack 10000 QuickSpecs for Technical Specifications such as height, width,

NOTE:NOTE: depth, weight, and colour:

http://h18000.www1.hp.com/products/quickspecs/10995_ca/10995_ca.HTML

NOTE:

For additional information regarding Rack Cabinets, please see the following URL:

NOTE:NOTE:

http://h18000.www1.hp.com/products/servers/proliantstorage/rack-options/index.html

292302-B22 245160-B21 245160-B23 245161-B21 245161-B22 245161-B23 245162-B21 245162-B22 245162-B23 245163-B21 245163-B22 245163-B23

Rack Options for HP

Rack Options for HPRack Options for HP Rack 10000 Series

Rack 10000 Series

Rack 10000 SeriesRack 10000 Series

42U Side Panel – Graphite Metallic 36U Side Panel – Graphite Metallic 47U Side Panel – Graphite Metallic

NOTE:

NOTE: For additional information regarding Rack Options, please see the following URL:

NOTE:NOTE:

http://h18000.www1.hp.com/products/servers/proliantstorage/rack-options/index.html

Server Console Switch 1 x 4 port (100-230 VAC) IP Console Switch Box, 1 x 1 x 16 IP Console Switch Box, 3 x 1 x 16 CPU to Server Console Cable, 12’ CPU to Server Console Cable, 3’ CPU to Server Console Cable, 7’ IP CAT5 Cable 3’, 4 pack IP CAT5 Cable 6’, 8 pack IP CAT5 Cable 12’, 8 pack IP CAT5 Cable 20’, 4 pack IP CAT5 Cable 40’, 1 pack TFT5600 Rack Keyboard Monitor TFT7210R Rack Mounted 17" Monitor

NOTE:

For a complete list of Monitors please view the following URL:

NOTE:NOTE:

http://h18004.www1.hp.com/products/monitors/

1U Rack Keyboard & Drawer (Carbon)

NOTE:

NOTE: NOTE:

http://h18000.www1.hp.com/products/servers/proliantstorage/rack-options/index.html

For additional information regarding Rack Options, please see the following URL:

246099-B21 246102-B21 255486-B21

400336-001 262585-B21 262586-B21 110936-B21 110936-B24 110936-B25 263474-B21 263474-B22 263474-B23 263474-B24 263474-B25 221546-001 348373-B21

257054-001

DA - 11958 Canada — Version 2 — June 29, 2004

Page 27

QuickSpecs

Options

Service and Support

Service and SupportService and Support Offerings

Offerings

Offerings Offerings Services)

(HP Care Pack

NOTE:

The HP Care Pack services for ProLiant BL p-Class server blades, cover the server blade and

NOTE:NOTE: the p-Class blade enclosure that the server blade is installed in as well as interconnects, power enclosure with power supplies and power distribution.

Hardware Services On-site Service

Hardware Services On-site ServiceHardware Services On-site Service Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years

Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years, Electronic 4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years 4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic 6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years 6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

Installation & Start-up Services

Installation & Start-up ServicesInstallation & Start-up Services

ProLiant BL p-Class Blade Server Hardware Installation ProLiant BL p-Class Blade Server Hardware Installation, Electronic ProLiant BL p-Class Enclosure and Server Blade Hardware Installation ProLiant BL p-Class Enclosure and Server Blade Hardware Installation, Electronic Provides for the Installation and Start-up of Compaq's Rapid Deployment Pack on a Customer

supplied server designated as a Deployment Server. Includes the deployment of a single server. This new server will be deployed using either one of the pre-configured scripts or an image. In addition, the service will provide for the capture and storage of the configuration of the newly deployed server and orientation on product usage. To be delivered during standard office ours, standard office days.

Provides for the Installation and Start-up of Compaq's Rapid Deployment Pack on a Customer supplied server designated as a Deployment Server. Includes the deployment of a single server. This new server will be deployed using either one of the pre-configured scripts or an image. In addition, the service will provide for the capture and storage of the configuration of the newly deployed server and orientation on product usage. To be delivered during standard office ours, standard office days. Electronic.

NOTE:

For more information, customer/resellers can contact

NOTE:NOTE:

http://www.hp.com/hps/

ProLiant BL30p

ProLiant BL30pProLiant BL30p

UA203A

UA203E

UA204A

UA204E

UA205A

UA205E

UA206A

UA206E

UA219A

UA219E U4971A

U4971E

U5683A

U5683E

DA - 11958 Canada — Version 2 — June 29, 2004

Page 28

QuickSpecs

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Memory

ProLiant BL30p Server Blade (all models)

ProLiant BL30p Server Blade (all models)ProLiant BL30p Server Blade (all models) Standard Memory

Standard Memory

Standard MemoryStandard Memory 1024-MB PC2100 MHz Registered DDR SDRAM DIMM installed (1 x 1-GB SDRAM DIMM)

Standard Memory Replaced with Optional Memory

Standard Memory Replaced with Optional MemoryStandard Memory Replaced with Optional Memory Up to 4096-MB of DDR SDRAM DIMM memory is available with the removal of standard memory and the installation of optional SDRAM DDR DIMM memory expansion kits.

Memory

MemoryMemory

Standard

StandardStandard Optional

Optional

OptionalOptional Optional

Optional

OptionalOptional Maximum

Maximum

MaximumMaximum

1024 MB

1024 MB 1024 MB

1024 MB1024 MB 1024 MB

1024 MB

1024 MB1024 MB 2048 MB

2048 MB 1024 MB

2048 MB2048 MB 4096 MB

4096 MB 2048 MB

4096 MB4096 MB

1111 2222

1024 MB

1024 MB1024 MB

512 KB

512 KB 512 KB

512 KB512 KB

1024 MB 1024 MB

1024 MB1024 MB 2048 MB 2048 MB

2048 MB2048 MB

Following are memory options available from HP:

4096-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (2 x 2 GB) 1024-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (1 x 1 GB) 1024-MB of Advanced ECC PC2100 DDR SDRAM DIMM Memory Kit (2 x 512 MB)

Slot

SlotSlot

512 KB

512 KB512 KB

1024 MB

1024 MB1024 MB 2048 MB

2048 MB2048 MB

300682-B21 287497-B21 257974-B21

DA - 11958 Canada — Version 2 — June 29, 2004

Page 29

QuickSpecs

TechSpecs

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Server Blade Enclosure

Server Blade Enclosure

Server Blade EnclosureServer Blade Enclosure with enhanced backplane

with enhanced backplane

with enhanced backplanewith enhanced backplane components

components

componentscomponents

Dimensions

DimensionsDimensions

Input Specifications

Input SpecificationsInput Specifications

Individual Server Blade

Individual Server BladeIndividual Server Blade Bay Ratings

Bay Ratings

Bay RatingsBay Ratings

Temperature Range

Temperature RangeTemperature Range

Relative Humidity

Relative HumidityRelative Humidity (non-condensing)

(non-condensing)

(non-condensing)(non-condensing)

Wet Bulb Temperature

Wet Bulb TemperatureWet Bulb Temperature

NOTE:

NOTE: NOTE: operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or

30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper

Height Width Depth Rated input voltage Rated input current Rated input Power Rated input voltage Rated input current Rated input Power Operating Non-Operating Operating Non-Operating Operating Non-Operating

10.5 in (26.67 cm)

17.60 in (44.70 cm)

28.86 in (73.30 cm)

-43 VDC to -53 VDC 125 A at -48 VDC 6000 W

-43 VDC to -53 VDC

14.6 A at -48 VDC 700 W 50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C) 20% to 80% 5% to 95%

82.4° F (28° C)

101.7° F (38.7° C)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Nominal -48 VDC

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for ProLiant BLp-Class RJ-45

ProLiant BLp-Class RJ-45

ProLiant BLp-Class RJ-45ProLiant BLp-Class RJ-45 Patch Panel 2 with Fiber

Patch Panel 2 with Fiber

Patch Panel 2 with FiberPatch Panel 2 with Fiber Channel pass through

Channel pass through

Channel pass throughChannel pass through

Dimensions

DimensionsDimensions

Capability

CapabilityCapability Network Transfer Rate

Network Transfer Rate

Network Transfer RateNetwork Transfer Rate

Fiber Channel SAN

Fiber Channel SANFiber Channel SAN Connector

Connector

ConnectorConnector

Cable Support

Cable SupportCable Support

EMI

EMIEMI

NOTE:

NOTE: NOTE: operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or

30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper

Height Width Depth IEEE 802.2, 802.3, 802.3u 10 Base-T (half-duplex) 10 Base-T (full-duplex) 100 Base-TX (half-duplex) 100 Base-TX (full-duplex) 1000 Base-TX (full-duplex) Velio VC1070 re-timer Network Fiber Channel SAN 10 Base-TX

100 Base-TX 1000 Base-TX Fiber Channel FCC Class A ICES-003 Class A AS/NZS 3548 Class A VCCI Class A

10.405 in (26.43 cm)

1.535 in (3.899 cm)

27.697 in (70.35 cm)

10 Mbps 20 Mbps 100 Mbps 200 Mbps 1000 Mbps Auto-rate negotiate between 2G and 1G 32 RJ-45 in the back. 16 Pluggable SFP optical cages in the front Categories 3, 4, or 5 UTP (2 or 4 pair);

up to 328 ft (100 m) Category 5 UTP (2 pair); up to 328 ft/100 m Category 5E (4 pair); up to 328 ft (100 m) SFP optical cable

DA - 11958 Canada — Version 2 — June 29, 2004

Page 30

QuickSpecs

TechSpecs

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for ProLiant BL p-Class RJ-45

ProLiant BL p-Class RJ-45

ProLiant BL p-Class RJ-45ProLiant BL p-Class RJ-45 Patch Panel

Patch Panel

Patch PanelPatch Panel

Dimensions

DimensionsDimensions

Capability

CapabilityCapability Network Transfer Rate

Network Transfer Rate

Network Transfer RateNetwork Transfer Rate

Connector

ConnectorConnector Cable Support

Cable Support

Cable SupportCable Support

Power Requirements

Power RequirementsPower Requirements Temperature Range

Temperature Range

Temperature RangeTemperature Range

Relative Humidity

Relative HumidityRelative Humidity (non-condensing)

(non-condensing)

(non-condensing)(non-condensing)

Wet Bulb Temperature

Wet Bulb TemperatureWet Bulb Temperature

NOTE:

NOTE: NOTE: operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or

30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper

Height Width Depth IEEE 802.2, 802.3, 802.3u 10 Base-T (half-duplex) 10 Base-T (full-duplex) 100 Base-TX (half-duplex) 100 Base-TX (full-duplex) 1000 Base-TX (full-duplex) Network 10 Base-TX

100 Base-TX 1000 Base-TX 200 mA at + 5V DC; 500 mA at -48V Operating Non-operating Operating Non-operating Operating Non-operating

10.405 in (26.43 cm)

1.535 in (3.899 cm)

27.697 in (70.35 cm)

10 Mbps 20 Mbps 100 Mbps 200 Mbps 1000 Mbps 16 RJ-45 in the back Categories 3, 4, or 5 UTP (2 or 4 pair);

up to 328 ft (100 m) Category 5 UTP (2 pair); up to 328 ft (100 m) Category 5E (4 pair); up to 328 ft (100 m)

50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C) 20% to 80% 5% to 95%

82.4° F (28° C)

101.7° F (38.7° C)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for ProLiant

Specifications for ProLiant

Specifications for ProLiantSpecifications for ProLiant BL p-Class GbE

BL p-Class GbE

BL p-Class GbEBL p-Class GbE Interconnect Switch

Interconnect Switch

Interconnect SwitchInterconnect Switch

Dimensions

DimensionsDimensions

Weight

WeightWeight Performance

Performance

PerformancePerformance

Forwarding Mode

Forwarding ModeForwarding Mode MAC Addresses

MAC Addresses

MAC AddressesMAC Addresses

Forwarding Table

Forwarding TableForwarding Table Age Time

Age Time

Age TimeAge Time Memory

Memory

MemoryMemory Compliance

Compliance

ComplianceCompliance

Height Width Depth

11.5 lb/5.2 kg per interconnect switch

9.6 Gbps external port bandwidth per server blade enclosure (full duplex) Forwarding rate 0.15 million pps per 10/100 port, 1.5 million pps per gigabit port, (64-

byte packets) Non-blocking, full-wire speed for all connections Auto-MDI/MDIX, auto-negotiation and auto-sensing with full-duplex support Store and forward 8,191 per interconnect switch; MAC address based filtering and MAC address packet

priority configuring Maximum age: 1 to 1,000,000 seconds; default: 300 seconds

32MB Main, 6MB flash and 16MB packet buffer per interconnect switch IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z (F-GbE only), 802.1D, 802.1p, 802.3ac,

802.3ad (Static), and 802.1Q SNMP v1 (RFC 1157) and RMON v1 (RFC 1757) groups 1, 2, 3, and 9 MIB-II (RFC 1213), Bridge MIB (RFC 1493), Interface Group MIB (RFC 2863), Ethernet MIB

(RFC 1643), 802.1Q Extended Bridge MIB (RFC 2674), Entity MIB (RFC 2037), SNMP Trap Convention (RFC 1215), Bridge Trap (RFC 1493), Remote Monitoring Traps (RFC 1757), and HP Enterprise Switch MIBs and Environmental Traps

IGMP v1 (RFC 1112), IGMP v2 (RFC 2236), SNTP (RFC 1361), Telnet (RFC 854), TFTP client (RFC 783), BootP client, (RFC 2132), DHCP client, (RFC 2131) and ZModem,

10.405 in (26.43 cm)

1.535 in (3.899 cm)

27.697 in (70.35 cm)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 31

QuickSpecs

TechSpecs

Network Transfer

Network TransferNetwork Transfer Rate

Rate

RateRate

Connector

ConnectorConnector

EMI

EMIEMI

Safety

SafetySafety

Power

PowerPower Requirements

Requirements

RequirementsRequirements Temperature

Temperature

TemperatureTemperature R range

R range

R rangeR range

Relative Humidity

Relative HumidityRelative Humidity (non-condensing)

(non-condensing)

(non-condensing)(non-condensing)

Wet Bulb

Wet BulbWet Bulb Temperature

Temperature

TemperatureTemperature

NOTE:

NOTE: NOTE: operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or

30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper

10 Base-T (half-duplex) 10 Base-T (full-duplex) 100 Base-TX (half-duplex) 100 Base-TX (full-duplex) 1000 Base-TX (half-duplex) 1000 Base-TX (full-duplex) 1000 Base-SX (full-duplex) 12 RJ-45, 2 DB-9 (C-GbE Interconnect Kit)

4 LC fiber, 8 RJ-45, 2 DB-9 (F-GbE Interconnect Kit) FCC Class A ICES-003 Class A AS/NZS 3548 Class A VCCI Class A UL/CUL Listed Accessory CE

-48VDC: 1050 mA, 50 W maximum (per interconnect switch)

Operating Non-operating Operating Non-operating Operating Non-operating

10 Mbps 20 Mbps 100 Mbps 200 Mbps 1000 Mbps 2000 Mbps 2000 Mbps

50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C) 20% to 80% 5% to 95%

82.4° F (28° C)

101.7° F (38.7° C)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

DA - 11958 Canada — Version 2 — June 29, 2004

Page 32

QuickSpecs

TechSpecs

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for ProLiant BL p-Class GbE2

ProLiant BL p-Class GbE2

ProLiant BL p-Class GbE2ProLiant BL p-Class GbE2 Interconnect Switch

Interconnect Switch

Interconnect SwitchInterconnect Switch

Dimensions

DimensionsDimensions

Weight

WeightWeight Performance

Performance

PerformancePerformance

Forwarding Mode

Forwarding ModeForwarding Mode MAC Addresses

MAC Addresses

MAC AddressesMAC Addresses Forwarding Table

Forwarding Table

Forwarding TableForwarding Table Age Time

Age Time

Age TimeAge Time Memory

Memory

MemoryMemory Compliance

Compliance

ComplianceCompliance

Network Transfer

Network TransferNetwork Transfer Rate

Rate

RateRate

Connector

ConnectorConnector

EMI

EMIEMI

Safety

SafetySafety

Power

PowerPower Requirements

Requirements

RequirementsRequirements

Temperature

TemperatureTemperature Range

Range

RangeRange

Relative Humidity

Relative HumidityRelative Humidity (non-condensing)

(non-condensing)

(non-condensing)(non-condensing)

Wet Bulb

Wet BulbWet Bulb Temperature

Temperature

TemperatureTemperature

NOTE:

NOTE: NOTE: operating limit is 10,000 ft/3,048 m or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft/9,144 m or 30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F/45° C. Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F/1° C per 1,000 ft/304.8 m. No direct sunlight. Upper

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Height Width Depth

12.0 lb/5.4 kg per interconnect switch 24 Gbps External port bandwidth per server blade enclosure (full duplex) Forwarding rate 1.5 million pps per gigabit port (64-byte packets) Auto-MDI/MDIX, auto-negotiation and auto-sensing with full-duplex support Store and forward 2,048 per interconnect switch Maximum age: 1 to 65535 seconds; default: 300 seconds

128MB Main, 32MB flash and 2MB packet buffer per interconnect switch IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z (F-GbE2 only), 802.1D, 802.3ac, 802.3ad

(Static), and 802.1Q SNMP v1 (RFC 1157), MIB-II (RFC 1213), Bridge MIB (RFC 1493), Interface Group MIB

(RFC 2863), Ethernet MIB (RFC 1643), 802.1Q Extended Bridge MIB , Entity MIB (RFC

2037), RADIUS Authentication MIB, 802.3-2002 MIB, SNMP Trap Convention (RFC

1215), Bridge Trap (RFC 1493), Remote Monitoring Traps (RFC 1757) and HP Enterprise Switch MIBs and Environmental Traps

RADIUS (RFC 2138), Telnet (RFC 854), TFTP client (RFC 783), SSH v1.5, SCP v1.5, NTP v2 (RFC 1119), BootP client (RFC 2132), and XModem

8 LC fiber, 4 RJ-45, 2 DB-9 (F-GbE2 Interconnect Kit) FCC Class A ICES-003 Class A AS/NZS 3548 Class A VCCI Class A UL/CUL Listed Accessory CE 48VDC: 2040 mA, 98 W maximum (per interconnect switch without GbE2 Storage

Connectivity Kit) 48VDC: 2355 mA, 113 W maximum (per interconnect switch with GbE2 Storage Connectivity Kit)

Operating Non-operating Operating Non-operating Operating Non-operating

10.405 in (26.43 cm)

1.535 in (3.899 cm)

27.697 in (70.35 cm)

10 Mbps 20 Mbps 100 Mbps 200 Mbps 1000 Mbps 2000 Mbps 2000 Mbps

50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C) 20% to 80% 5% to 95%

82.4° F (28° C)

101.7° F (38.7° C)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 33

QuickSpecs

TechSpecs

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for ProLiant BL p-Class

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Power Enclosures

Power Enclosures

Power EnclosuresPower Enclosures

Dimensions

DimensionsDimensions

Weights

WeightsWeights

Input Requirements

Input RequirementsInput Requirements

Output Voltage

Output VoltageOutput Voltage Specifications

Specifications

SpecificationsSpecifications

Ambient Temperature

Ambient TemperatureAmbient Temperature Range

Range (See

RangeRange

Relative humidity,

Relative humidity,Relative humidity, non-condensing

non-condensing

non-condensingnon-condensing

(See

NOTE

NOTENOTE

Wet Bulb

Wet BulbWet Bulb Temperature

Temperature

TemperatureTemperature

NOTE:

NOTE: NOTE: operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or

30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper

NOTE

NOTENOTE

)

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Height Width Depth No Hot-Plug

Power Supplies All Hot-Plug

Power Supplies Rated input voltage

Rated input frequency Rated input current

per side Rated input power

per side Power cord Rated output voltage Rated output current Rated output power Nominal power Operating

)

Shipping

Operating

Non-operating

Operating Non-operating

Single-Phase Model

Single-Phase ModelSingle-Phase Model

5.25 in (13.34 cm) 5.25 in (13.34 cm)

27.15 in (68.96 cm) 27.15 in (68.96 cm)

17.60 in (44.7 cm) 17.60 in (44.7 cm)

47.5 lb (21.55 kg) 47.5 lb (21.55 kg)

99.5 lb (45.13 kg)

200 VAC to 240 VAC

50 Hz to 60 Hz 50 Hz to 60 Hz 24A

5760 W 9976 W

1 NEMA L6-30P per side

-48.8 VDC to -54 VDC -48.8 VDC to -54 VDC 99A 4298 W 8310 W 4158 W at 208 VAC 7202 W at 208 VAC 50° to 95° F

(10° to 35° C)

-22° to 140° F (-30° to 60° C)

20% to 80% 20% to 80%

5% to 95% 5% to 95%

82.4° F (28° C) 82.4° F (28° C)

101.7° F (38.7° C) 101.7° F (38.7° C)

3-Phase Model

3-Phase Model3-Phase Model

125.5 lb (56.93 kg)

200 VAC to 240 VAC line to line

24A per phase

1 NEMA L15-30 per side

170A

50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C)

DA - 11958 Canada — Version 2 — June 29, 2004

Page 34

QuickSpecs

TechSpecs

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for ProLiant BL p-Class

ProLiant BL p-Class

ProLiant BL p-ClassProLiant BL p-Class Power Distribution

Power Distribution

Power DistributionPower Distribution Devices

Devices

DevicesDevices

Power

PowerPower Enclosures or facility DC

Enclosures or facility DC

Enclosures or facility DCEnclosures or facility DC feeds Supported

feeds Supported

feeds Supportedfeeds Supported (3U each)

Server blade enclosures

Server blade enclosuresServer blade enclosures supported

supported

supportedsupported (6U each)

Total rack height of

Total rack height ofTotal rack height of supported enclosures

supported enclosures

supported enclosuressupported enclosures Dimensions

Dimensions

DimensionsDimensions Height Width Depth Weight

Weight

WeightWeight Rated Operating

Rated Operating

Rated OperatingRated Operating Voltage

Voltage

VoltageVoltage Max Total Power

Max Total Power

Max Total PowerMax Total Power Supported

Supported

SupportedSupported Total Max Input Current

Total Max Input Current

Total Max Input CurrentTotal Max Input Current At Minimum Voltage

At Minimum Voltage

At Minimum VoltageAt Minimum Voltage

Total Max Input Current

Total Max Input CurrentTotal Max Input Current At Nominal Voltage

At Nominal Voltage

At Nominal VoltageAt Nominal Voltage

Max Current Per Power

Max Current Per PowerMax Current Per Power Feed

Feed

FeedFeed Max Local Ambient

Max Local Ambient

Max Local AmbientMax Local Ambient Temperature

Temperature

TemperatureTemperature

NOTE:

NOTE: NOTE:

All systems support redundant A & B feeds. Scalable bus bar supports dual A and dual B feeds.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Power Bus Box

Power Bus BoxPower Bus Box

5.1 in (12.95 cm)

3.6 in (9.14 cm) each

3.25 in (8.26 cm)

3.62 lb (1.64 kg)

-43.2 VDC to -54 VDC -43.2 VDC to -54 VDC -43.2 VDC to -54 VDC

3000 W 9000 W

69.44 A at -43.2VDC

62.5 A at -48VDC

70A 70A

149° F (65° C) 149° F (65° C) 149° F (65° C)

Mini Bus Bar

Mini Bus BarMini Bus Bar

1 or 2 1 or 2

up to 3 up to 5

24U 36U

19.45 in (49.40 cm)

19.74 in (50.14 cm) 19.74 in (50.14 cm)

2.2 in (5.59 cm) 2.2 in (5.59 cm)

13.2 lb (5.9 kg)

208.32 A at -43.2 VDC

187.5 A at -48 VDC 312.5 A at -48 VDC

Scalable Bus Bar

Scalable Bus BarScalable Bus Bar

48.57 in (123.37 cm)

26 lb (11.79 kg)

15000 W

347.2 A at -43.2 VDC (equivalent of 175A per feed)

(equivalent of 175A per feed)

210A

DA - 11958 Canada — Version 2 — June 29, 2004

Page 35

QuickSpecs

TechSpecs

Operating and

Operating andOperating and Performance

Performance

PerformancePerformance Specifications for

Specifications for

Specifications forSpecifications for Facility DC

Facility DC

Facility DCFacility DC

Voltage

VoltageVoltage

Current

CurrentCurrent

In-rush current

In-rush currentIn-rush current

Input over-current

Input over-currentInput over-current

Max Input Current Slew

Max Input Current SlewMax Input Current Slew Rate

Rate

RateRate Max Rated Power

Max Rated Power

Max Rated PowerMax Rated Power Connections and Cables

Connections and Cables

Connections and CablesConnections and Cables

NOTE:

NOTE: NOTE: ** Periodic and random noise (PARD). Maximum allowable peak-to-peak ripple and noise (as measured at the load on any

output channel). The ripple and noise is measured over a 20 Hz to 100 MHz frequency band. A resistive load (nonelectronic) is used for this measurement. Each output is by-passed to return by a 10uF tantalum capacitor with an ESR less than 100 milli-Ohms in parallel with a 0.47 uF ceramic capacitor, at the point of load. The load cable is 12 feet of twisted wire capable of carrying the current. The printed wiring board assembly is installed in its enclosure for this measurement, or the measurement leads are properly shielded with Earth grounds applied to the insert.

*All systems support redundant A and B feeds. Scalable bus bars support dual A and dual B feeds.

ProLiant BL30p

ProLiant BL30pProLiant BL30p

Nominal input voltage Operating voltage range Max Input voltage slew rate Redundant feed voltages*

(A & B) Ripple/Noise Overshoot

Voltage transients Max steady state input current Max steady state current per

feed/total

Power bus boxes Mini bus bars Scalable bus bars

Must support up to 2X the maximum operating current per server blade enclosure (125 A) for up to 1.0 mS

Customer provided fusing for facility DC feeds that protects the system from catastrophic over-current within 20 uS. Fuse should sustain all in-rush and operating currents.

1A/uS

3000W per server blade enclosure HP provided facility DC cable connection kit:

The facility DC connection kit supports the connection of up to four -48VDC, RETURN pairs and ground

The power cable assemblies consist of 1/0AWG, colour-coded, flexible cable rated at 105° C, terminated with bus mating connectors at one end and unterminated at the other end. The cable length provided enables the customer to route to a fuse panel within or adjacent to the rack.

-48 VDC

-48VDC ± 10% or -43.2 VDC to -52.8 VDC

0.5V/uS *A and B feeds must differ by no more than 5VDC during

steady state operation 480 mV PARD** Must remain within regulation limits on all feeds during

startup or shutdown Must not exceed -60 VDC

62.5A per server blade enclosure installed at -48VDC

70 A/70A 210 A/210A 210 A/350A or equivalent of 175A per feed*

The information contained herein is subject to change without notice.

Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 11958 Canada — Version 2 — June 29, 2004

Page 36

HP BL30p User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features (Server Blade)

Standard Features (Server Blade Enclosure and Interconnects)

Standard Features (Power System and Rack Information)

Standard Features (Manageability)

Models

Options

Memory

TechSpecs
