Overview

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

At a Glance

At a GlanceAt a Glance

1.0-GHz Transmeta Efficeon TM8000 40-GB Ultra ATA/100 5400 rpm hard drive 512-MB DDR SDRAM PC2700 (333-MHz) expandable to 1024 MB (2 SODIMM slots)

(

NOTE:

32 MB of system RAM is reserved for processor usage.)

NOTE:NOTE:

Two Broadcom 5705F 10/100 Integrated Network Controllers. NIC 1 is compliant with PXE (Pre-boot execution Environment) Connector for graphics diagnostics card Blade PCs protected by HP Services, including a limited three-year parts warranty with optional service uplifts available

DA - 11903 North America — Version 5 — May 20, 2005

Page 1

QuickSpecs

Overview

Configuration Steps

Configuration StepsConfiguration Steps

For a complete configuration of the HP bc1000 blade PC system, you need:

1. HP bc1000 blade PC (sold in a single-pack or 10-pack)

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

2. HP e-Class Blade PC Enclosure (each can hold up to 20 blade PCs). The enclosure comes bundled with 20 licenses for the ProLiant Essentials Rapid Deployment Pack.

3. C-GbE Interconnect Switch (with 4 10/100/1000T Gigabit Ethernet RJ45 uplinks for up to 40-to-1 network cable reduction).

DA - 11903 North America — Version 5 — May 20, 2005

Page 2

QuickSpecs

Standard Features

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Processor

ProcessorProcessor

Cache Memory

Cache MemoryCache Memory

Chipset

ChipsetChipset

Memory

MemoryMemory

Network Controller

Network ControllerNetwork Controller

One Transmeta Efficeon TM8000 1.0-GHz processor, integrated North Bridge with 400-MHz Hyper Transport South Bridge interface

1024K L2

ALi M1563M South Bridge

NOTE:

For more information regarding Acer Labs Inc, please see the following URL:

NOTE:NOTE:

http://www.ali.com.tw/

Standard

Maximum

Two 5705F 10/100 Integrated Network Controllers. NIC 1is compliant with PXE

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

.

512-MB DDR SDRAM PC2700 (333-MHz) (1x512 MB SODIMM)

(

NOTE:

32 MB of system RAM is reserved for processor usage.)

NOTE:NOTE:

1024 MB (2 SODIMM slots total)

Internal Storage

Internal StorageInternal Storage

Industry Standard

Industry StandardIndustry Standard Compliance

Compliance

ComplianceCompliance

Manageability

ManageabilityManageability

High Availability

High AvailabilityHigh Availability

Security

SecuritySecurity

OS Support

OS SupportOS Support

One 40-GB Ultra ATA/100 5400 rpm hard drive

ACPI 1.0b; ANSI C63.4 - 1992; C.I.S.P.R. Pub 22; CFR 47, Part 15; EN 55022; EN 55024; EN 60950: 2000; ICES-003; IEC 61000-4, Section 2-6, 8, 11; IEC 730-1; IEC 801, Part 2; IPC-A-610; PC2700; PCI 2.3; PXE 2.1; SPD 1.2B; UL 94; UL 796; USB 1.1

HP Systems Insight Manager ROM Based Setup Utility (RBSU) Automatic System Recovery (ASR) System Software Manager (SSM) DOS-based replicated setup utility (REPSET) Unit ID LED

Robust boot block recovery ROM F5 auto roll over to new blade Dual network communication paths

Administrator's password

Microsoft® Windows® XP Pro with Service Pack 1a

DA - 11903 North America — Version 5 — May 20, 2005

Page 3

QuickSpecs

Standard Features

HP e-Class Blade PC Enclosure (sold separately)

HP e-Class Blade PC Enclosure (sold separately)HP e-Class Blade PC Enclosure (sold separately)

Rack Capability

Rack CapabilityRack Capability

Rack Airflow

Rack AirflowRack Airflow Requirements

Requirements

RequirementsRequirements

Mounts in HP 10000 and 9000 series, HP System-E, as well as third-party, and Telco racks. Rack mounting hardware for HP and third-party racks ships standard with each blade enclosure. Telco rackmounting hardware is a separately available option kit.

The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted blade PCs. The HP 10000 Series Racks provide enhanced airflow for maximum cooling, allowing these racks to be fully loaded with blade PCs using the latest processors.

CAUTION:

CAUTION:CAUTION: adequate airflow and to prevent damage to the equipment:

CAUTION:

CAUTION:CAUTION: arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage. NOTE:

NOTE:

NOTE:NOTE:

If a third-party rack is used, observe the following additional requirements to ensure

Front and rear doors: If your 42U rack includes closing front and rear doors, you must allow 5,350 square cm (830 square inches) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of 7 cm (2.75 inches).

Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This

Please consult the Setup & Installation Guide for the blade PC for additional details.

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Enclosure includes

Enclosure includesEnclosure includes

Diagnostic Adapter

Diagnostic AdapterDiagnostic Adapter Interfaces

Interfaces

InterfacesInterfaces

3U high rack-mountable chassis with 20 blade PC bays Rack mounting hardware for HP, Compaq-branded and third-party racks Rear bay for Interconnect Switch for network cable management Two (2) Diagnostic Adapters (see features following) for connecting keyboard, video, mouse and other devices locally to individual blade PCs ProLiant Essentials Foundation Pack licenses for 20 Blade PCs (see features following), includes the HP Systems Insight Manager and ProLiant Essentials Rapid Deployment Pack CD Four hot-plug fans Dual hot-plug power supplies (600 watts each), power cords Blade PC blanks (to fill 19 of the 20 blade PC bays) Null-modem cable for serial connection to the Integrated Administrator serial "Console" connector HP Documentation CD

NOTE:

Two Diagnostic Adapters are included with every enclosure.

NOTE:NOTE:

Blade PC LEDs (6) PS/2 Mouse PS/2 Keyboard VGA monitor (functional only when graphics diagnostics card installed) Serial RS-232 port USB 1.1 ports (2)

DA - 11903 North America — Version 5 — May 20, 2005

Page 4

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Standard Features

ProLiant Essentials

ProLiant EssentialsProLiant Essentials Foundation Pack Software

Foundation Pack Software

Foundation Pack SoftwareFoundation Pack Software

C-GbE Interconnect Switch Features (sold separately)

C-GbE Interconnect Switch Features (sold separately)C-GbE Interconnect Switch Features (sold separately)

Provides up to a 40-to-1 reduction in network cables for each blade enclosure using a pair of non-blocking layer 2 switch modules Four RJ-45 10/100/1000T Gigabit Ethernet uplinks Forty 10/100T Ethernet ports dedicated to blade-to-interconnect switch network communications Communicate with all 40 blade PC network controllers through any one uplink connector and the management connector Includes Integrated Administrator module (see features following) Spanning tree protocol for loop-free path redundancy Browser, scriptable CLI, and console-based interfaces for local and remote interconnect switch management Manage entire interconnect switch through the Integrated Administrator connectors or any uplink connector Telnet, RMON and SNMP support; SNMP-based scripting utility with example scripts IGMP (internet group management protocol) multicasting and quality of service (QoS) packet prioritization TFTP support for rapid deployment of multiple interconnect switches and to provide backup and restore capabilities Industry-standard design compatible with industry-standard network components from leading network manufacturers Fully pre-configured for rapid deployment and immediate operation in HP e-Class Blade PC Enclosure

HP Systems Insight

HP Systems InsightHP Systems Insight Manager

Manager

ManagerManager

ProLiant Essentials Rapid

ProLiant Essentials RapidProLiant Essentials Rapid Deployment Pack

Deployment Pack

Deployment PackDeployment Pack

Interconnect Switch

Interconnect SwitchInterconnect Switch Management System and

Management System and

Management System andManagement System and Utilities

Utilities

UtilitiesUtilities

Systems Insight Manager helps maximize system uptime and performance and reduces the cost of maintaining the IT infrastructure by providing proactive notification of problems before those problems result in costly downtime and reduced productivity. Insight Manager is easy to set up and provides rapid access to inventory information.

http://www.hp.com/go/hpsim/

An automated solution for deployment and provisioning, enabling companies to quickly and easily adapt to changing business demands.

NOTE:

For more information regarding ProLiant Essentials Software, please

NOTE:NOTE: see the following URL:

Full featured web-based interface, menu-driven console interface, SNMPbased scripting utility and example scripts, SNMP and RMON MIBs, and TFTP utilities for management of interconnect switch.

http://www.hp.com/servers/proliantessentials

.

For more information on the C-GbE Interconnect Switch, please visit the Web site at:

http://h18000.www1.hp.com/products/servers/proliant-bl/e-class/interconnect-switch.html

DA - 11903 North America — Version 5 — May 20, 2005

.

Page 5

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Standard Features

HP Integrated Administrator Features

HP Integrated Administrator FeaturesHP Integrated Administrator Features

Out-of-band local console and remote network access to the blade enclosure and all 20 blade PCs via (one) RJ-45 10/100BaseT Fast Ethernet and (one) RS-232 management connectors Provides local and remote access to the C-GbE Interconnect Switch command console Remotely power on/off/reboot blade PCs and enclosures Remotely toggle on/off unit identification (UID) LEDs of blade PCs and enclosures Monitors and controls the enclosure fans, temperature sensors, power supplies, interconnect switch and blade PC status Connect to each blade PC's serial text console for enabling full control over blade PC's Power-On Self Test (POST) and boot process, including the ROM-Based Setup Utility (RBSU). User administration for up to 25 users. Blade PC bay privileges can be set on a per-user basis Virtual NMI button generates non-maskable interrupt for crash debug and analysis More than 100 scriptable commands enable automated management Selective enabling of all protocols, such as Telnet Logging of operating system console, blade PC and enclosure hardware events, user actions and invalid login attempts Administrator notification that a blade is warm Enclosure controller blade shutdown (graceful Windows shutdown) if blade overheats Emergency blade shutdown in the event of a critical temperature fault Enclosure Link (2) connectors reserved for future use.

CAUTION:

CAUTION:CAUTION: these enclosure link (RJ-45) connecters may damage your external device.

For more information on the Integrated Administrator, please visit the Web site at:

http://h18000.www1.hp.com/products/servers/proliant-bl/e-class/integrated-admin.html

The enclosure link (RJ-45) connectors on the interconnect tray are not to be used. Connecting an external device to

.

Service and Support

Service and SupportService and Support

HP Services provides a wide range of service offerings, including a three-year, limited parts warranty on the HP bc1000 blade PC.

CAUTION:

CAUTION:CAUTION: Class Enclosure Shipping Bracket (part number PH555A). Failure to use the shipping bracket may cause damage to the blade PC and/or enclosure, thereby voiding the warranty.

The HP e-Class Blade PC Enclosure has a three-year, limited warranty on parts, labor and on-site support.

Warranties are fully supported by a network of resellers and service providers in over 160 countries. HP warranty assistance is available 7x24, toll free in the United States and Canada. Other additional support services may be covered under warranty or available for an additional fee.

A full range of HP Care Pack packaged hardware and software services:

NOTE:

NOTE:NOTE: NOTE:

NOTE:

NOTE:NOTE: 1616 for details.

Do not ship the blade PCs and enclosure while inside the rack without first installing the e-

Add labor or on-site service for the blade PC Installation and start up Extended coverage hours and enhanced response times System management and performance services Availability and recovery services

For more information, customer/resellers can contact Certain restrictions and exclusions apply. Consult the Customer Support Center at 1-800-567-

http://www.hp.com/services/carepack

.

DA - 11903 North America — Version 5 — May 20, 2005

Page 6

QuickSpecs

Models

bc1000 blade PC

bc1000 blade PCbc1000 blade PC

DS658A (1 pack)

bc1000 blade PC

bc1000 blade PCbc1000 blade PC

DS659A (10 pack)

Processor

ProcessorProcessor Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory Network Controller

Network Controller

Network ControllerNetwork Controller Hard Drive

Hard Drive

Hard DriveHard Drive Form Factor

Form Factor

Form FactorForm Factor

Processor

ProcessorProcessor Cache Memory

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory Network Controller

Network Controller

Network ControllerNetwork Controller Hard Drive

Hard Drive

Hard DriveHard Drive Form Factor

Form Factor

Form FactorForm Factor

1.0-GHz Transmeta Efficeon TM8000 1024K L2 512-MB DDR SDRAM PC2700 (333-MHz) Two Broadcom 5705F 10/100 Integrated NICs 40-GB Ultra ATA/100 5400 rpm Plugs vertically into HP e-Class Blade PC Enclosure

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

DA - 11903 North America — Version 5 — May 20, 2005

Page 7

QuickSpecs

Options

Enclosure and Switch

Enclosure and SwitchEnclosure and Switch

Memory

MemoryMemory

Miscellaneous

MiscellaneousMiscellaneous

HP e-Class Blade PC Enclosure (includes 20 licenses for ProLiant Essentials Rapid Deployment Pack at 50% of the standard per-node license list price)

Enclosure Shipping Bracket Kit

NOTE:

When shipping an enclosure in a rack, shipping brackets must be installed to

NOTE:NOTE: the rack.

C-GbE Interconnect Switch (includes Integrated Administrator module)

512-MB DDR SDRAM PC2700 (333-MHz) Option Kit (1 x 512 MB)

PS/2 Mouse PS/2 Keyboard TFT5600 Rackmount Keyboard and Monitor TFT721OR 17-inch Rackmount Monitor Integrated Keyboard and Drawer External USB MultiBay Caddy Third-party Rail Kit for HP Input Devices Telco Rail Kit for HP Input Devices MultiBay 24X CD-ROM Graphics Diagnostics Card (5 pack)

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

DW366A

DW367A

PA715A

DD440B

DT527A 221546-001 348373-B21 257054-001

DC373A#ABA

287139-B21 287138-B21 217396-930

DV300C

UPS and PDU Power

UPS and PDU PowerUPS and PDU Power Cord Matrix

Cord Matrix

Cord MatrixCord Matrix

Uninterruptible Power

Uninterruptible PowerUninterruptible Power Systems – Rack

Systems – Rack

Systems – RackSystems – Rack

Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and

Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, andPlease see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications for UPS and PDU units:

specifications for UPS and PDU units:

specifications for UPS and PDU units:specifications for UPS and PDU units:

ftp://ftp.compaq.com/pub/products/servers/ProLiantstorage/power-protection/powercordmatrix.pdf.

HP UPS R1500 XR (1440VA, 1340 Watt), Low Voltage HP UPS R3000 XR (2880VA, 2700 Watt), Low Voltage HP UPS R3000 XR (3000VA, 2700 Watt), High Voltage Rack-Mountable UPS R6000 (6000VA, 6000 Watt) High Voltage

NOTE:

The UPS R6000 has a hardwired input.

NOTE:NOTE:

UPS R12000 XR N+ x (200-240V) (hardwired)

NOTE:

The UPS R12000 XR has a hardwired input and output.

NOTE:NOTE:

204404-001 192186-001 192186-002 347207-001

207552-B22

DA - 11903 North America — Version 5 — May 20, 2005

Page 8

QuickSpecs

Options

UPS Options

UPS OptionsUPS Options

SNMP Serial Port Card

NOTE:

Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

NOTE:NOTE:

Six Port Card

NOTE:

Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

NOTE:NOTE:

High to Low Voltage Transformer (250VA)

NOTE:

Supports R6000 UPS series only. 2.5 amps @ 125 Volts max output across

NOTE:NOTE: two NEMA 5-15.

Extended Runtime Module, R1500 XR

NOTE:

2U each, two ERM maximum.

NOTE:NOTE:

Extended Runtime Module, R3000 XR

NOTE:

2U each, one ERM maximum.

NOTE:NOTE:

Extended Runtime Module, R5500 XR

NOTE:

3U each, two ERM maximum.

NOTE:NOTE:

Extended Runtime Module, R6000

NOTE:

3U each, two ERM maximum.

NOTE:NOTE:

Extended Runtime Module, R12000 XR, 4U

NOTE:

4U each, two ERM maximum.

NOTE:NOTE:

R12000 XR BackPlate Receptacle Kit, (2) L6-30R

NOTE:

The R12000 XR BackPlate Kit has a hardwired input.

NOTE:NOTE:

R12000 XR BackPlate Receptacle Kit, (2) IEC-309R

NOTE:

The R12000 XR BackPlate Kit has a hardwired input.

NOTE:NOTE:

SNMP-EN Adapter

NOTE:

Supports R6000 UPS series only.

NOTE:NOTE:

Multi-Server UPS Card

NOTE:

Supports R6000 UPS series only.

NOTE:NOTE:

Scalable UPS Card

NOTE:

Supports R6000 UPS series only.

NOTE:NOTE:

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

192189-B21

192185-B21

388643-B21

218971-B21

192188-B21

326564-B21

347224-B21

217800-B21

325361-001

325361-B21

347225-B21

123508-B21

123509-B21

Rack-Mountable PDUs –

Rack-Mountable PDUs –Rack-Mountable PDUs – 1U/0U

1U/0U

(Up to 12 outlets)

1U/0U1U/0U

NOTE:

0U mounting

NOTE:NOTE: brackets shipped with the unit (separate option kit for 1U mounting).

HP Power Distribution Unit-16A (200 to 240V)

NOTE:

The 16A PDU also connects to the high volt models of the UPS R3000 XR

NOTE:NOTE: (need cable PN 340653-001) and the UPS R6000 models. Cable PN 340653-001 required if connecting to UPS R3000 XR (192186-002-High Volt model only).

HP Power Distribution Unit-40A (200 to 240V)

NOTE:

Please see the following Power Distribution Unit (Zero-U/1U PDU)

NOTE:NOTE: QuickSpecs for additional options, including cables:

http://h18000.www1.hp.com/products/quickspecs/10838_na/10838_na.HTML

DA - 11903 North America — Version 5 — May 20, 2005

207590-B21

207590-B23

Page 9

QuickSpecs

Options

Modular PDUs 1U/0U

Modular PDUs 1U/0UModular PDUs 1U/0U (Up to 32 outlets)

PDU Options

PDU OptionsPDU Options

Modular Power Distribution Units (mPDU), High Volt Model, 16A (200-240 VAC)

NOTE:

This model has a detachable input power cord and is adaptable to country

NOTE:NOTE: specific requirements. The 16A PDU also connects to the high volt models of the UPS R3000 XR and R6000 models. Cable P/N 340653-001 required if connecting to UPS R3000 XR (192186-002-High Volt model only).

Modular Power Distribution Units (mPDU), High Volt Model, 24A (200-240 VAC) Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC) Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC)

NOTE:

This mPDU (252663-B21), 40A model has a hardwired input.

NOTE:NOTE: NOTE:

NOTE:

Please see the following Modular Power Distribution Unit (Zero-U/1U

NOTE:NOTE: Modular PDUs) QuickSpecs for additional options including shorter jumper cables and country specific power cords:

http://h18000.www1.hp.com/products/quickspecs/11041_na/11041_na.HTML

Third Party PDU Mounting Kit

NOTE:

This kit allows you to mount the Modular PDUs in racks other than the

NOTE:NOTE: 9000/10000 Series racks (any racks using the standard 19" rail). For more details please refer the Modular PDU QuickSpecs.

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

252663-B24

252663-D72 252663-D71

252663-B21

310777-B21

Enterprise Configurator

Enterprise ConfiguratorEnterprise Configurator

HP Rack 10000 Series

HP Rack 10000 SeriesHP Rack 10000 Series (Graphite Metallic)

Please see the CO for configuration assistance at:

S10614 (14U) Rack Cabinet – Shock Pallet HP Rack 10647 (47U) – Pallet HP Rack 10647 (47U) – Crated HP Rack 10642 (42U) – Pallet HP Rack 10642 (42U) – Shock Pallet HP Rack 10642 (42U) – Crated HP Rack 10636 (36U) – Pallet HP Rack 10636 (36U) – Shock Pallet HP Rack 10636 (36U) – Crated HP Rack 10622 (22U) – Pallet HP Rack 10622 (22U) – Shock Pallet HP Rack 10622 (22U) – Crated HP Rack 10842 (42U) – 800 mm wide – Pallet HP Rack 10842 (42U) – Crated

NOTE:

-B21 (pallet) used to ship empty racks shipped on a truck

NOTE:NOTE:

-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels)

-B23 (crated) used for air shipments of empty racks NOTE:

NOTE:

Not all HP equipment is qualified to be shipped in the Rack 10000 series.

NOTE:NOTE: NOTE:

NOTE:

Please see the Rack 10000 QuickSpecs for Technical Specifications such as

NOTE:NOTE: height, width, depth, weight, and color:

http://h18000.www1.hp.com/products/quickspecs/10995_na/10995_na.HTML

For additional information regarding Rack Cabinets, please see the following URL:

http://h18000.www1.hp.com/products/servers/proliantstorage/racks/index.html

http://www.hp.com/products/configurator

.

....

292302-B22 245160-B21 245160-B23 245161-B21 245161-B22 245161-B23 245162-B21 245162-B22 245162-B23 245163-B21 245163-B22 245163-B23 257415-B21 257415-B22

DA - 11903 North America — Version 5 — May 20, 2005

Page 10

QuickSpecs

Options

Rack Options for HP Rack

Rack Options for HP RackRack Options for HP Rack 10000 Series

10000 Series

10000 Series10000 Series

Rack Blanking Panels – Graphite (Multi)

NOTE:

Contains one each of 1U, 2U, 4U and 8U.

NOTE:NOTE:

Rack Blanking Panels – Graphite (1U)

NOTE:

The Rack Blanking Panels Kit contains 10 each of (1U).

NOTE:NOTE:

Rack Blanking Panels – Graphite (2U)

NOTE:

The Rack Blanking Panels Kit contains 10 each of (2U).

NOTE:NOTE:

Rack Blanking Panels – Graphite (3U)

NOTE:

The Rack Blanking Panels Kit contains 10 each of (3U).

NOTE:NOTE:

Rack Blanking Panels – Graphite (4U)

NOTE:

The Rack Blanking Panels Kit contains 10 each of (4U).

NOTE:NOTE:

Rack Blanking Panels – Graphite (5U)

NOTE:

The Rack Blanking Panels Kit contains 10 each of (5U).

NOTE:NOTE:

600mm Stabilizer Kit – Graphite Baying Kit for Rack 10000 series (Carbon) 42U Side Panel – Graphite Metallic 110V Fan Kit (Graphite)

NOTE:

Roof Mount Includes power cord with IEC320-C13 to Nema 5-15P.

NOTE:NOTE:

220V Fan Kit (Graphite)

NOTE:

Roof Mount Includes power cord with IEC320-C13 to Nema 6-15P.

NOTE:NOTE:

36U Side Panel – Graphite Metallic 47U Side Panel – Graphite Metallic 9000/10000 Series Offset Baying Kit (42U)

NOTE:

This kit can be used to connect 9000 and 10000 series racks of the same U

NOTE:NOTE: height together. Kit contents include hardware for connecting racks and a panel to cover the 100mm gap at the rear of the two racks.

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

253214-B26

253214-B21

253214-B22

253214-B23

253214-B24

253214-B25

246107-B21 248929-B21 246099-B21 257413-B21

257414-B21

246102-B21 255486-B21 248931-B21

Cable Management

Cable ManagementCable Management

Rack Options for Rack

Rack Options for RackRack Options for Rack 10000 Series

10000 Series

10000 Series10000 Series

FC Cable Routing Spool – box of 12 Rail-to-Rail FC Cable Routing Side Rail FC Routing – box of 6 Compaq Networking Cable Management Kit Cable Management D-Rings Kit

Monitor Utility Shelf Ballast Option Kit 100kg Sliding Shelf Rack Rail Adapter Kit (25" depth) 9000/10000 Grounding Kit 100-kg Shelf Kit

NOTE:

This 100Kg Shelf Kit (PN 234672-B21) supports the Rack 10000 and 9000

NOTE:NOTE: series only.

DA - 11903 North America — Version 5 — May 20, 2005

293357-B21 293358-B21 293359-B21 292407-B21 168233-B21

303606-B21 120672-B21 234672-B21 120675-B21 260457-B21 234672-B21

Page 11

QuickSpecs

Options

Rack Options for HP,

Rack Options for HP,Rack Options for HP, Third Party and Telco

Third Party and Telco

Third Party and TelcoThird Party and Telco racks

racks

racksracks

Telco rack-mounting hardware kit for HP e-Class Blade PC Enclosure Enclosure Shipping Bracket Kit

NOTE:

When shipping an enclosure in a rack shipping brackets must be installed to

NOTE:NOTE: the rack.

NOTE:

For more information on rack and rack options, please visit the following url:

NOTE:NOTE:

http://h18000.www1.hp.com/products/servers/proliantstorage/rackoptions/index.html

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

266076-B21 293119-B21

.

DA - 11903 North America — Version 5 — May 20, 2005

Page 12

QuickSpecs

Memory

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC Standard Memory

Standard Memory

Standard MemoryStandard Memory

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

512-MB 333-MHz DDR SDRAM (1x512 MB SODIMM) installed. (NOTE:

Standard Memory Plus Optional Memory

Standard Memory Plus Optional MemoryStandard Memory Plus Optional Memory

Up to 1024 MB of DDR SDRAM is available with the installation of optional DDR SDRAM memory expansion kits (sold separately).

Memory

MemoryMemory

1111 2222

Standard

StandardStandard Maximum

Maximum

MaximumMaximum

512 MB

512 MB512 MB 1024 MB

1024 MB

1024 MB1024 MB

NOTE:

32 MB of system RAM is reserved for processor usage.)

NOTE:NOTE:

Slot

SlotSlot

Empty

EmptyEmpty

512 MB

512 MB 512 MB

512 MB512 MB

512 MB

512 MB512 MB 512 MB

512 MB512 MB

DA - 11903 North America — Version 5 — May 20, 2005

Page 13

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Technical Specifications

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

NOTE 1:

NOTE 1:NOTE 1: maximum humidity of 95% is based on a maximum temperature of 112° F (45° C). Minimum pressure for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Storage

Dimensions

DimensionsDimensions

Weight

WeightWeight Temperature

Temperature

TemperatureTemperature

Relative humidity

Relative humidityRelative humidity (noncondensing)

LEDs

(Top to bottom)

LEDsLEDs

1

Height

HeightHeight Width

Width

WidthWidth Depth

Depth

DepthDepth Maximum

Maximum

MaximumMaximum Operating

Operating

OperatingOperating Non-operating shipping

Non-operating shipping

Non-operating shippingNon-operating shipping Non-operating storage

Non-operating storage

Non-operating storageNon-operating storage

1

Operating

OperatingOperating Non-operating shipping

Non-operating shipping

Non-operating shippingNon-operating shipping Non-operating storage

Non-operating storage

Non-operating storageNon-operating storage Unit identification

Unit identification

Unit identificationUnit identification

Health

HealthHealth

NIC 1

NIC 1NIC 1

NIC 2

NIC 2NIC 2

Drive activity

Drive activityDrive activity

Power

PowerPower

4.7 in (11.94 cm)

0.8 in (2.03 cm)

15.5 in (39.37 cm)

2.2 lb (1.0 kg) 50° to 95° F (10° to 35° C)

-40° to 140° F (-40° to 60° C)

-4° to 140° F (-20° to 60° C) 10% to 90% 10% to 90% 10% to 95% Off = off Steady blue = blade identified Blinking blue = being accessed remotely Off = off Green = health good Amber = degraded or power up prohibited by

the Integrated Administrator Blinking or steady red = critical Off = off Green = linked to network Blinking green = Activity on network Off = off Green = linked to network Blinking green = activity on network Off = No drive activity Blinking green = drive activity Off = no AC power to blade or enclosure Amber = Enclosure on and in good health Green = blade power on

40-GB Ultra ATA/100

40-GB Ultra ATA/10040-GB Ultra ATA/100 Hard Drive

Hard Drive

Hard DriveHard Drive

Capacity

CapacityCapacity Interface

Interface

InterfaceInterface Transfer rate synchronous

Transfer rate synchronous

Transfer rate synchronousTransfer rate synchronous (maximum)

Seek time

Seek timeSeek time including settling)

Rotational speed

Rotational speedRotational speed

(typical reads,

DA - 11903 North America — Version 5 — May 20, 2005

40 GB Ultra ATA 100 100 MB/s

Single track

Single trackSingle track Average

Average

AverageAverage Maximum

Maximum

MaximumMaximum 5400 rpm

1.5 ms 12 ms 22 ms

Page 14

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Technical Specifications

Broadcom 5705F 10/100

Broadcom 5705F 10/100Broadcom 5705F 10/100 Integrated NIC

Integrated NIC

Integrated NICIntegrated NIC

Enclosure

EnclosureEnclosure

NOTE 1:

NOTE 1:NOTE 1: maximum humidity of 95% is based on a maximum temperature of 112° F (45° C). Minimum pressure for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Storage

Network interface

Network interfaceNetwork interface Compatibility

Compatibility

CompatibilityCompatibility Data transfer method

Data transfer method

Data transfer methodData transfer method Features

Features

FeaturesFeatures Network transfer rate

Network transfer rate

Network transfer rateNetwork transfer rate

Connector

ConnectorConnector Cable support

Cable support

Cable supportCable support

Dimensions

DimensionsDimensions

Weight

(with interconnect

WeightWeight tray)

Rated input

Rated inputRated input

BTUs

BTUsBTUs Temperature

Temperature

TemperatureTemperature

Relative humidity

Relative humidityRelative humidity (noncondensing)

Management

ManagementManagement

High availability

High availabilityHigh availability

(autosensing)

1

10Base-T/100Base-TX IEEE 802.3/802.3u compliant 32-bit bus-master PCI NIC 1 WOL enabled and PXE compliant 10Base-T (half-duplex) 10Base-T (full-duplex) 100Base-TX (half-duplex) 100Base-TX (full-duplex) Mates into enclosure center wall assembly 10Base-T 100Base-TX

Height

(3U)

HeightHeight Width

Width

WidthWidth Depth

Depth

DepthDepth No blade PCs

No blade PCs

No blade PCsNo blade PCs 20 blade PCs

20 blade PCs

20 blade PCs20 blade PCs Voltage

Voltage

VoltageVoltage

Frequency

FrequencyFrequency Current

Current

CurrentCurrent

Power

PowerPower Per hour

Per hour

Per hourPer hour Operating

Operating

OperatingOperating Shipping, 72 hours

Shipping, 72 hours

Shipping, 72 hoursShipping, 72 hours Operating

Operating

OperatingOperating Non-operating

Non-operating

Non-operatingNon-operating Enclosure self recovery

Health logs Redundant power supply utility Automatic System Recovery (ASR)

Redundant hot-plug power supplies Redundant hot-plug fans

10 Mb/s 20 Mb/s 100 Mb/s 200 Mb/s

Categories 3, 5, or 6 UTP; up to 328 ft (100 m) Category 5 or 6 UTP; up to 328 ft (100 m)

5.25 in (13.34 cm) 19 in (48.26 cm) 27 in (68.58 cm) 59 lb (26.76 kg) 103 lb (46.7 kg) Minimum: 90 VAC

Maximum: 264 VAC Nominal: 100 to 120 VAC or 200 to 240 VAC

47 to 63 Hz

11.7 A at 90 VAC

8.5 A at 120 VAC

4.3 A at 240 VAC 1000 W 3416 50° to 95° F (10° to 35° C)

-40° to 140° F (-40° to 60° C) 10% to 90% 10% to 95%

DA - 11903 North America — Version 5 — May 20, 2005

Page 15

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Technical Specifications

Enclosure Hot-Plug Power

Enclosure Hot-Plug PowerEnclosure Hot-Plug Power Supply

Supply

SupplySupply

NOTE 1:

NOTE 1:NOTE 1: maximum humidity of 95% is based on a maximum temperature of 112° F (45° C). Minimum pressure for storage is 70 KPa.

Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Storage

Dimensions

DimensionsDimensions

Weight

WeightWeight Rated input

Rated input

Rated inputRated input

Rated output

Rated outputRated output

Temperature

TemperatureTemperature

Relative humidity

Relative humidityRelative humidity (noncondensing)

Dieletric voltage

Dieletric voltageDieletric voltage withstand

withstand

withstandwithstand

1

Height

HeightHeight Depth

Depth

DepthDepth Width

Width

WidthWidth

6.5 lb (2.95 kg) Voltage

Voltage

VoltageVoltage Frequency

Frequency

FrequencyFrequency Current

Current

CurrentCurrent Power

Power

PowerPower Maximum peak power

Maximum peak power

Maximum peak powerMaximum peak power Voltage/current

Voltage/current

Voltage/currentVoltage/current

Power RMS

Power RMSPower RMS Maximum peak power

Maximum peak power

Maximum peak powerMaximum peak power Operating

Operating

OperatingOperating Non-operating, shipping

Non-operating, shipping

Non-operating, shippingNon-operating, shipping

1

Operating

OperatingOperating Non-operating

Non-operating

Non-operatingNon-operating Input to output

Input to output

Input to outputInput to output Input to ground

Input to ground

Input to groundInput to ground

(autosensing)

3.579 in (9.14 cm)

10.24 in (28.45 cm)

4.47 in (11.43 cm)

100 to 127 VAC (200 to 240 VAC) 47 to 63 Hz

8.5 A at 120 VAC (4.3 A at 240 VAC) 1000 W 1167 W

5.01 V - 0.5 A ~ 34 A

3.33 V - 0.5 A ~ 36 A

12.1 V - 0.5 A ~ 38 A 5 Vaux - 0.2 A ~ 8 A 600 W 700 W for 2 minutes 5° to 55° F (10° to 35° C)

-40° to 85° F (-40° to 60° C) 10% to 90% 10% to 95% 2000 VAC minimum 1500 VAC minimum

C-GbE Interconnect

C-GbE InterconnectC-GbE Interconnect Switch

Switch

SwitchSwitch

General

GeneralGeneral

Performance

PerformancePerformance

Forwarding mode

Forwarding modeForwarding mode MAC addresses

MAC addresses

MAC addressesMAC addresses

Memory

MemoryMemory

Two 24-port Managed Layer 2 Ethernet switches for network cable reduction; fully pre-configured for immediate operation

4.0 Gbps Switching bandwidth 12 million pps aggregate throughput (64-byte packets) Full-wire speed for all connections Store and forward 16,382; MAC address based filtering and MAC address packet priority

configuring 64 MB Main 12 MB Flash 32 MB Packet Buffer

DA - 11903 North America — Version 5 — May 20, 2005

Page 16

QuickSpecs

Technical Specifications

Ports

PortsPorts

Management

ManagementManagement

High availability

High availabilityHigh availability

Security

SecuritySecurity

IEEE standards

IEEE standardsIEEE standards compliance

compliance

compliancecompliance

Form factor

Form factorForm factor

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Four RJ-45 10/100/1000 T/TX/T Gigabit Ethernet uplink ports for customer use

Forty 10/100 T/TX fast Ethernet downlink ports dedicated to blade PC to interconnect switch network connections

Two 10/100 T/TX Fast Ethernet ports dedicated to inter-switch module communications

One RS-232 DB-9 port (console connector for Integrated Administrator) One 10/100 T/TX Fast Ethernet port (Network management connector for

Integrated Administrator) Auto-negotiation and auto-sensing with full-duplex Web-based interface with graphical user interface Console menu driven Interface via local RS-232 and Telnet Scriptable command line interface (CLI) SNMP v1 (RFC 1157) with scripting tool and example scripts RMON v1 (RFC 1757) groups 1, 2, 3, and 9 Telnet (RFC 854) MIB-II (RFC 1213), Bridge MIB (RFC 1493), Interface MIB (RFC 2233),

801.1Q MIB (RFC 2684), RMON1 MIB (RFC 1757) groups 1, 2, 3, and 9, Ethernet MIB (RFC1643) and HP-specific switch MIBs

XML human read/write configuration file TFTP client (RFC 783) for backup and remote download of configuration

and history log files IGMP (Internet Group Management Protocol) multicasting Uplink port speed and link activity LEDs Simple network time protocol (SNTP) Broadcast, multicast, and DA-unknown packet storm control BootP and DHCP client support Port mirroring HP Interconnect Switch Management System and Utilities Dual network communication paths using redundant, non-blocking layer 2

switch modules with redundant inter-module communication links Two redundant uplink ports per each interconnect switch module Spanning tree protocol for loop-free path redundancy Multilevel user names and passwords with configurable time out period

setting, IP address restriction IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Ethernet IEEE 802.3ab 1000Base-T Ethernet IEEE 802.1D Spanning Tree Protocol IEEE 802.1p Quality of Service (QoS) Packet Prioritization IEEE 802.3x Flow Control Removable interconnect tray that plugs into the rear of the server blade

enclosure

DA - 11903 North America — Version 5 — May 20, 2005

Page 17

QuickSpecs

HP bc1000 blade PC

HP bc1000 blade PCHP bc1000 blade PC

Technical Specifications

Network transfer rate

Network transfer rateNetwork transfer rate

Cable support

Cable supportCable support

The information contained herein is subject to change without notice.

Microsoft and Windows NT are US registered trademarks of Microsoft Corporation.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

10Base-T (half-duplex) 10Base-T (full-duplex) 100Base-TX (half-duplex) 100Base-TX (full-duplex) 1000Base-T (full-duplex,

uplink ports only) 10Base-T 100Base-TX 1000Base-T (uplink ports

only)

10 Mb/s 20 Mb/s 100 Mb/s 200 Mb/s 2000 Mb/s

Categories 3, 5, or 6 UTP; up to 328 ft (100 m) Category 5 or 6 UTP; up to 328 ft (100 m) Category 5 or 6 UTP; up to 328 ft (100 m)

DA - 11903 North America — Version 5 — May 20, 2005

Page 18

HP bc1000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Models

Options

Memory

Technical Specifications
