HP AF416A, AF426A Specification
The most dense, most power packed UPS available - offering HP customers more watts per U than any other UPS - allowing for more
valuable rack space to be utilized by all your server, storage and networking equipment.
The leading edge HP UPS R5500 Uninterruptible Power System features a slim 3U rack-mount design, offering up to 4500 Watts of
true power (5400 watts international). This new rack-space saving design allows more support for critical rack mountable
equipment. This product brings unprecedented power density and innovative features to the proven HP family of rack-mountable UPS
products.
The UPS R5500 is a high power density solution, designed for customers who want to provide power protection in space-constrained
rack enterprise environments. In addition, this new UPS R5500 has the capability to be connected to an optional Extended Runtime
Module (ERM). Customers can further increase the run-time on their UPS R5500 by using this ERM. The HP UPS "" models denote
"Extended Runtime Capable" UPS models.
1.
REPO port
7.
Load segment 2 (two IEC-320-C19 receptacles and two IEC320-C13 receptacles)
2.
Ground bonding screw
8.
Battery circuit breaker
3.
Communications port/option slot
9.
Cord retention clip attach. locations
4.
Load segment 1 circuit breaker
10.
ERM connector
5.
Load segment 1 (two IEC-320-C19 receptacles and two IEC320-C13 receptacles)
11.
PDU output NEMA L6-30 receptacle (NA/JPN) or 32 A IEC309 receptacle (INTL) associated with load segment 1
6.
Load segment 2 circuit breaker
12.
Power cord with NEMA L6-30 plug (NA/JPN) or 32 A IEC309 plug (INTL)
Models
ModelsModels
Models
NOTE:
NOTE:NOTE:
NOTE:
#0D1 will appear after the part number on the sales order if HP factory integration is indicated.
HP R5500 6000VA INTL 3U Rackmount Uninterruptible Power System
AF416A
HP R5500 5000kVA NA/JP 3U Rackmount Uninterruptible Power System
AF426A
QuickSpecs
HP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPSHP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPS
Overview
DA - 11871 Worldwide — Version 21 — January 9, 2012
Page 1
Key Features
Key FeaturesKey Features
Key Features
Increased power density with up to 5500VA / 4500 Watts of power packed in just 3U rack space
(5400 watts international)
Greater system uptime with support for Extended Runtime Modules (ERM)
Easy configuration through enhanced front panel display
Enterprise-wide intelligent manageability with bundled power management software
Support for the HP UPS Management Module that extends the power management capabilities of
the UPS
More efficient voltage regulation with revolutionary technology
Ultimate long-term battery reliability with HP Enhanced Battery Management
Enhanced system flexibility with two independently controlled load segments
Support for Remote Emergency Power Off (REPO) circuitry
Easy serviceability through modular design
Hot-Swappable Battery and Electronics Modules
Backed by a three year warranty with the first year including parts and labor. HP's Pre-Failure
warranty, and a $250,000 load protection guarantee*. (Certain restrictions and exclusions apply;
*Load protection guarantee available in North America only.
)
Optional upgrades include:
Extended Runtime Modules (ERMs)
Management Cards
HP R5500 UPS Tower Conversion Kit
3U Power Packed Design
3U Power Packed Design3U Power Packed Design
3U Power Packed Design
Rated near unity at 5500VA / 4500W (5400W international), the HP UPS R5500 packs more power in
space-conserving rack-mount design, allowing you to support more critical equipment in your rack.
Increase System Uptime
Increase System UptimeIncrease System Uptime
Increase System Uptime
with Extended Runtime
with Extended Runtimewith Extended Runtime
with Extended Runtime
Modules
ModulesModules
Modules
The Extended Runtime Modules are rack mounted battery modules that occupy 3U (5.25 inches) of rack
space. The HP UPS R5500 supports up to four Extended Runtime Modules (ERM), which extend your
overall battery runtime.
Lower Cost of Ownership
Lower Cost of OwnershipLower Cost of Ownership
Lower Cost of Ownership
with Innovative
with Innovativewith Innovative
with Innovative
Technology
TechnologyTechnology
Technology
The HP UPS R5500 utilizes a new industry-leading technology that continually conditions and regulates
power without using the battery, thereby increasing the life of the battery. The output voltage is
automatically regulated, based on the connected load and the input voltage.
Investment Protection with
Investment Protection withInvestment Protection with
Investment Protection with
HP Enhanced Battery
HP Enhanced BatteryHP Enhanced Battery
HP Enhanced Battery
Management
ManagementManagement
Management
HP UPS R5500 incorporates Enhanced Battery Management: an exclusive, patented technology that
doubles battery service life, optimizes battery recharge time, and provides advance notice of pending
battery failure. With Enhanced Battery Management, you have a lower total cost of ownership and
receive the best in the industry protection for your critical equipment.
Enhanced Flexibility
Enhanced FlexibilityEnhanced Flexibility
Enhanced Flexibility
The UPS R5500 models include four PDU Extension Bars. Each extension bar has seven C13 outlets for
powering equipment in the rack and attaches to the C19 outlets on the back of the UPS. The 6.5 foot (2
meter) cord allows the extension bars to mounted in many locations inside the rear of the rack.
QuickSpecs
HP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPSHP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPS
Standard Features
DA - 11871 Worldwide — Version 21 — January 9, 2012
Page 2
Remotely Monitor UPSs on
Remotely Monitor UPSs onRemotely Monitor UPSs on
Remotely Monitor UPSs on
the Network
the Networkthe Network
the Network
The optional HP UPS Management Module features the ability to perform simultaneous network and outof-band communications. It enables network administrators to remotely monitor UPSs and reboot
network devices. It provides SNMP functionality, including power event alerts, network power diagnostics,
and remote UPS reboot and testing. Used in conjunction with HP Systems Insight Manager or other
SNMP capable Network Management Software, power-related problems on the network are quickly
discovered and remedied.
Easy Configuration via
Easy Configuration viaEasy Configuration via
Easy Configuration via
Enhanced Front Panel
Enhanced Front PanelEnhanced Front Panel
Enhanced Front Panel
Display
DisplayDisplay
Display
LED and switch membrane integrated into the front panel with four button controls (three buttons for UPS
power control and one button under the front bezel for configuration)
1.
LED indicating Overload capacity
9.
STANDBY Button
2.
LED indicating 76% to 100% load capacity
10.
ON Button
3.
LED indicating 51% to 75% load capacity
11.
General Alarm
4.
LED indicating 26% to 50% load capacity
12.
On Battery
5.
LED indicating 0% to 25% load capacity
13.
Bad Battery/Low Battery
6.
Configure mode on LED
*
14.
Site Wiring Fault Indicator
7.
Configure Button
*
15.
Utility LED
8.
TEST/ALARM RESET Button
A.
Voltage Configuration Panel
*
*
Accessible only when the front bezel is removed
Intelligent Manageability
Intelligent ManageabilityIntelligent Manageability
Intelligent Manageability
Free HP Power Management Software, an integrated component of HP Systems Insight Manager, the
industry-leading hardware management platform, is included with the HP UPS R5500 models. The HP
Power Management Software enables you to monitor and control HP UPSs locally or remotely. This
software is a versatile, fully configurable, alert response tool that gives system administrators a full
overview of the network's conditions. It enables you to monitor system status and power conditions,
configure shut down timing, customize alert messages, and perform UPS diagnostic checks quickly and
easily.
QuickSpecs
HP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPSHP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPS
Standard Features
DA - 11871 Worldwide — Version 21 — January 9, 2012
Page 3
Independently
IndependentlyIndependently
Independently
Controllable Load
Controllable LoadControllable Load
Controllable Load
Segments
SegmentsSegments
Segments
With two load segments, you have the flexibility to configure scheduled startups and shutdowns, in
addition to independently control the separate load segments. Working in conjunction with HP Power
Management Software, the HP UPS R5500 can be configured to extend the runtime for more critical
devices.
Ease of Maintenance with
Ease of Maintenance withEase of Maintenance with
Ease of Maintenance with
Hot-Swappable Batteries
Hot-Swappable BatteriesHot-Swappable Batteries
Hot-Swappable Batteries
and Electronics Modules
and Electronics Modulesand Electronics Modules
and Electronics Modules
The UPS R5500 is modular in design, and both the battery and the electronics modules are hot
swappable. HP UPSs are designed with simple access through the front panel. Users can safely install
new batteries and even the electronics module without ever powering down connected server and server
options.
HP Quality
HP QualityHP Quality
HP Quality
HP's hardware qualification is the toughest in the industry. Extensive evaluation, testing, product
improvement, and an unsurpassed warranty guarantee the highest level of system protection, electrical
performance, product quality and compatibility.
Compatibility
CompatibilityCompatibility
Compatibility
Compatible with all HP servers, storage, racks, rack options, and other rack mountable HP equipment.
For PDU options please refer to the UPS/PDU compatibility matrix on
www.hp.com/products/ups
.
Warranty
WarrantyWarranty
Warranty
The HP UPS R5500 is covered by a three year warranty, with the first year including parts and labor.
Also, standard on all HP UPS units, is our exclusive Pre-Failure Warranty, which extends the advantage of
a HP three-year, limited warranty by applying it to the battery before it actually fails. This warranty is
offered worldwide. Specifically, the Pre-Failure Battery Warranty ensures that when customers receive
notification from HP Power Management Software that the battery may fail, the battery is replaced free of
charge under the warranty.
NOTE:
NOTE:NOTE:
NOTE:
$250,000 Computer/Load Protection Guarantee is also provided in NA, in addition to the HP
three year, limited warranty.
QuickSpecs
HP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPSHP Rack-Mountable R5500 UPS
HP Rack-Mountable R5500 UPS
Standard Features
DA - 11871 Worldwide — Version 21 — January 9, 2012
Page 4
