QuickSpecs

Overview

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

WLAN antennas (3)

WWAN antennas

Dual-microphone array

Webcam LED indicator (with optional webcam)

Optional 720p HD webcam

HP Night Light on button

HP Night Light

Wireless on/off button with LED indicator

HP Web Browser button with LED indicator

10.

Volume mute button with LED indicator

11.

Pointstick

12.

Optional HP Fingerprint Sensor

13.

Pointstick pick buttons

14.

Touchpad on/off button with LED indicator

15.

Touchpad with scroll zone

16.

Display release latch

DA - 14304 North America — Version 16 — June 6, 2013

17.

Touchpad pick buttons

18.

Stereo speakers (see bottom view)

19.

Hard drive activity / HP 3D DriveGuard LED indicator

20.

Battery charging LED indicator

21.

Power/standby LED indicator

22.

Wireless on/off LED indicator

23.

ExpressCard/54 slot

24.

Upgrade Bay (optical drive, second hard drive or weight saver)

25.

Secure Digital slot

26.

(2) USB 3.0 ports

27.

1394a port

28.

Power connector

29.

Power button with LED indicator

30.

Volume down function key

31.

Volume up function key

32.

HP Power Assistant function key

Page 1

QuickSpecs

Overview

Stereo headphone/line out

Stereo microphone/line in

Integrated Smart Card reader

eSATA/USB 2.0 combo port

USB 2.0 charging port

DisplayPort

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Vents

Security lock slot

RJ-11/modem port (optional)

10.

VGA/external monitor connector

11.

RJ-45/Ethernet port

Battery release latch

Docking connector

Bottom cover release latch

SIM slot for WWAN (in battery bay; select models)

DA - 14304 North America — Version 16 — June 6, 2013

Secondary battery connector

Vents

Speakers

Bluetooth module compartment under bottom cover

Page 2

QuickSpecs

Overview

Battery bay

HP EliteBook 8570p Notebook PC

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

10.

Hard drive, memory, and wireless compartment under bottom cover

WLAN antennas (3)

WWAN antennas

Dual-microphone array

Webcam LED indicator (with optional webcam)

Optional 720p HD webcam

HP Night Light on button

HP Night Light

Wireless on/off button with LED indicator

HP Web Browser button with LED indicator

10.

Volume mute button with LED indicator

11.

Calculator button with LED indicator

12.

Numeric keypad

13.

Pointstick

14.

Optional HP Fingerprint Sensor

15.

Pointstick pick buttons

16.

Stereo speakers

DA - 14304 North America — Version 16 — June 6, 2013

19.

Touchpad with scroll zone

20.

Touchpad on/off light

21.

Hard drive activity / HP 3D DriveGuard LED indicator

22.

Battery charging LED indicator

23.

Power/standby LED indicator

24.

Power/standby LED indicator

25.

ExpressCard/54 slot

26.

Smart Card Reader

27.

VGA/external monitor connector

28.

eSATA/USB 2.0 combo port

29.

Vent

30.

1394a port

31.

Secure Digital slot

32.

(2) USB 2.0 ports*

33.

Power button with LED indicator

34.

Volume down function key

Page 3

QuickSpecs

Overview

17.

Display release latch

18.

Touchpad pick buttons

* USB 2.0 port on right is a charging port.

Stereo headphone/line out

Stereo microphone/line in

(2) USB 3.0 ports

Upgrade Bay (optical drive, second hard drive or weight saver)9.Power connector

RJ-45/Ethernet port

35.

Volume up function key

36.

HP Power Assistant function key

Security lock slot

RJ-11/modem port (optional)

Serial port

10.

DisplayPort

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Battery release latch

Docking connector

Vents

Bluetooth module compartment

DA - 14304 North America — Version 16 — June 6, 2013

Page 4

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Overview

Bottom cover release latch

SIM slot for WWAN (in battery bay; select models)

Battery bay

Hard drive, memory, and wireless compartments under bottom cover

Secondary battery connector

At A Glance

Windows 8 versions, Windows 7 versions or FreeDOS Aluminum display enclosure, magnesium-reinforced chassis, wear-resistant platinum-colored HP DuraFinish, HP DisplaySafe frame, precision aluminum-alloy hinges, cast titanium-alloy display latches, keyboard in full aluminum deck, and chemically strengthened glass touchpad; designed to meet the military standard Mil-Std-810G for vibration, dust, altitude, and high temperature operation Choice 3rd Generation Intel® Core™ i7 Quad-Core with Turbo Boost Technology; 3rd Generation Intel Core™ i7 and i5 Dual-Core with Turbo Boost Technology Intel Core i7 with vPro™ and Core i5 with vPro technology (optional) AMD Radeon™ HD 7570M discrete graphics with 1 GB dedicated GDDR5 video memory or integrated Intel® HD Graphics 4000 Widescreen LED-backlit display HP EliteBook 8470p: 14.0-inch diagonal HD or HD+ HP EliteBook 8570p: 15.6-inch diagonal HD or FHD wide viewing angle Easily hot dock with one of the optional HP docking stations DisplayPort for high resolution support SRS Premium Sound PRO optimized for high fidelity audio Choice of primary battery to optimize run-time or weight: 9-cell (100 WHr), 6-cell (62 WHr), or 6-cell (55 WHr) HP Long Life Battery Combine primary battery with optional secondary battery options Touchpad with scroll zone and pointstick; 8570p features a numeric keypad and calculator button Standard ExpressCard slot and integrated Smart Card Reader for strong security authentication Security features including HP Client Security (Windows 8 only) and HP ProtectTools, with central management across HP and non-HP client PCs " HP Peak Power Manager (web download) and HP Power Assistant (Windows 7 only) allow you to conserve power, stretch battery run-time, accurately monitor the energy usage of the PC and up to four select HP external monitors, and report workforce power consumption. Flexible wireless connectivity options:

Optional integrated HP hs2350 HSPA+ Mobile Broadband Module connects to both HSPA and HSPA+ (UMTS) networks and provides GPS functionality Optional integrated HP un2430 EV-DO/HSDPA Mobile Broadband Module (Gobi™ 3000) Integrated Intel Centrino® 802.11 a/b/g/n 3x3 and 2x2, Broadcom 802.11 a/b/g/n 2x2, or Atheros b/g/n 1x1 wireless LAN module

Bluetooth® v4.0+EDR Upgrade Bay for optical drive, optional second hard drive, or weight saver Choice of 7200 rpm user-removable hard drive (up to 750 GB) with HP 3D DriveGuard, 500 GB 7200 rpm Self Encrypting Drive (SED) (8570p only), 128 GB Solid State Drive (8570p only), 180 GB Solid State Drive (available starting June 2012), or 256 GB SED Solid State Drive (8570p only) Low Halogen*, ENERGY STAR qualified (with Microsoft OS) and EPEAT Gold registered in the U.S. (with Microsoft OS). EPEAT status varies by country- please see

epeat.net

* Meeting the industry definition of 'Low Halogen' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be Low Halogen. External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal component: ATT SIM card, are not Low Halogen.

DA - 14304 North America — Version 16 — June 6, 2013

Page 5

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Overview

OPERATING SYSTEM

Preinstalled

Supported

Certified

* Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality. See ** This system is preinstalled with Windows® 7 Pro software and also comes with a license and media for Windows 8 Pro software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data. *** Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. See

Windows 8 Pro 64* Windows 7 Professional (available through downgrade rights from Windows 8 Pro)** Windows 8 64* Windows 7 Professional 32*** Windows 7 Professional 64*** Windows 7 Home Premium 32*** (8470p, select countries) Windows 7 Home Premium 64*** (select countries) Windows 7 Home Basic 32*** (select countries) FreeDOS

Windows 8 Pro 32* Windows 8 32* Windows 8 Enterprise 32* Windows 8 Enterprise 64* Windows 7 Enterprise 32*** Windows 7 Enterprise 64*** Windows 7 Ultimate 32*** Windows 7 Ultimate 64*** Windows XP Professional 32

SUSE Linux Enterprise Desktop 11

http://www.microsoft.com

http://www.microsoft.com/windows/windows-7/

for details.

PROCESSOR

3rd Generation Intel® Core™ i7-3740QM (2.70 GHz, 6 MB L3 cache, 45W, 4 cores)* Up to 3.70 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i7-3720QM (2.60 GHz, 6 MB L3 cache, 45W, 4 cores)* (8570p only) Up to 3.60 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i7-3630QM (2.40 GHz, 6 MB L3 cache, 45W, 4 cores)*† Up to 3.40 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i7-3610QM (2.30 GHz, 6 MB L3 cache, 45W, 4 cores)* (8570p only)† Up to 3.30 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i7-3520M (2.90 GHz, 4 MB L3 cache, 35W, 2 cores)* Up to 3.60 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i5-3360M (2.80 GHz, 3 MB L3 cache, 35W, 2 cores)* Up to 3.50 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i5-3320M (2.60 GHz, 3 MB L3 cache, 35W, 2 cores)* Up to 3.30 GHz with Intel Turbo Boost Technology 3rd Generation Intel® Core™ i5-3210M (2.50 GHz, 3 MB L3 cache, 35W, 2 cores)* (8570p only)† Up to 3.10 GHz with Intel Turbo Boost Technology

* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will

DA - 14304 North America — Version 16 — June 6, 2013

Page 6

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. Intel's numbering is not a measurement of higher performance.

NOTE:

Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.

† Not available with vPro

CHIPSET

Mobile Intel QM77 Express (vPro support)

INTEL CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE

Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with select processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a preinstalled Windows operating system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel Active Management Technology 8.0 (iAMT) offers built-in manageability and proactive security for networked notebook PCs, even when they are powered off* or when the operating system is inoperable. It can help identify threats before they reach the network, isolate infected systems, and update PCs regardless of their power state.

*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.

NOTE:

Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active Management technology and Intel Virtualization technology, requires additional third- party software in order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7 with vPro technology is dependent on third- party software providers. Compatibility with future "virtual appliances" is yet to be determined.

GRAPHICS

Integrated

Intel HD Graphics 4000 Microsoft® DirectX®, OpenGL 3.1, OpenCL 1.1, and CUI 4.0

Discrete

AMD Radeon™ HD 7570M, with 1 GB dedicated GDDR5 video memory Microsoft® DirectX® 11 with Shader Model 5.0 and support for OpenGL 4.1.

DA - 14304 North America — Version 16 — June 6, 2013

Page 7

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

DISPLAY

HP EliteBook 8470p: Internal

14.0" diagonal LED-backlit HD 16:9 widescreen anti-glare (1366 x 768)

14.0" diagonal LED-backlit HD+ 16:9 widescreen anti-glare (1600 x 900) HP Privacy Filter support

External

Up to 32-bit per pixel color depth

DisplayPort

Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz

VGA

Port supports resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz

DVI-D (single link)

Video signal available through DVI port in optional HP Docking Station (sold separately) supports resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking

HP EliteBook 8570p: Internal

15.6" diagonal LED-backlit HD 16:9 anti-glare (1366 x 768)

15.6" diagonal LED-backlit FHD WVA anti-glare (1920 x 1080) HP Privacy Filter support

External

Up to 32-bit per pixel color depth

DisplayPort

Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz

VGA

Port supports resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz

DVI-D (single link)

Video signal available through DVI port in optional HP Docking Station (sold separately) supports resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking

NOTE:

Resolutions are dependent upon monitor capability, and resolution and color depth settings.

DA - 14304 North America — Version 16 — June 6, 2013

Page 8

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

STORAGE AND DRIVES

Primary Storage Bay

Hard Drives 320/500/750 GB 7200 rpm SMART SATA II 500 GB 7200 rpm SMART SATA II Self Encrypting Drive (8570p only) HP 3D DriveGuard (Windows only) The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive. Solid State Drive SATA 6 Gb/s 128 GB Solid State (8570p only) SATA 6 Gb/s 180 GB Solid State (Available starting June 2012)* SATA 6 Gb/s 256 GB SED Solid State

* Not offered in Brazil.

NOTE:

For hard drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 16GB (for Windows 7) of

system and up to 30 GB (for Windows 8) disk is reserved for system recovery software.

OPTICAL DRIVES

Fixed 12.7 mm SATA optical drive

Blu-ray ROM DVD+/-RW SuperMulti DL Drive (8570p only) DVD+/-RW SuperMulti DL Drive DVD-ROM Drive

Second hard drive

500 GB 7200 rpm SMART SATA II Hard Drive

Weight saver

MEMORY

Standard

DDR3 PC3-12800 SDRAM (1600 MHz) Two SODIMM slots supporting dual-channel memory Standard memory up to 8192 MB (2 GB, 4 GB, and 8 GB SODIMMs)

Maximum

16384 MB

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows Starter 32bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

DA - 14304 North America — Version 16 — June 6, 2013

Page 9

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

NETWORKING/COMMUNICATIONS

Wireless

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries. Wireless LAN and integrated Bluetooth are also available (both are factory configurable only) and can be combined with any of the supported wireless WAN options.

Broadband Wireless (WWAN) (Win 8 WWAN support will not be available at Win 8 introduction)

HP hs2350 HSPA+ Mobile Broadband Module HP un2430 EV-DO/HSDPA Mobile Broadband Module (Gobi™ 3000)

HP lt2522 LTE/EV-DO Mobile Broadband Module – U.S. only* (no Win 8 support) HP lt2523 LTE/HSPA+Mobile Broadband Module – U.S. only* (no Win 8 support)

Integrated wireless LAN options

Intel Centrino Ultimate-N 6300 802.11a/b/g/n (3x3) Intel Centrino Advanced-N 6205 802.11a/b/g/n (2x2)

802.11 a/b/g/n WiFi Adapter (2x2)

802.11 b/g/n WiFi Adapter (1x1) (8570p only) HP Integrated Module with Bluetooth 4.0+ EDR Wireless Technology

Communications

Integrated Intel 82579LM Gigabit** Network Connection (vPro configurations) 56K V.92 modem***

* Wireless use requires separately purchased service contract. Check with your local vendor for coverage area and availability in your area. Connection and speeds will vary due to location, environment, network conditions, and other factors. 4G compatibility with HSPA+ and LTE. 4G LTE is only available in the United States and requires Windows 7. ** The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required. *** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

AUDIO/MULTIMEDIA

Audio

SRS Premium Sound PRO™ Integrated stereo speakers Integrated dual-microphone array Button for volume mute; function keys for volume up and down Stereo headphone port Stereo microphone port

Webcam

Optional 720p HD webcam

HD format (widescreen) Supports videoconferencing and still image capture High quality fixed focus lens Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps M-JPEG compression supports higher frame rates for video capture and videoconferencing Improved low light sensitivity

DA - 14304 North America — Version 16 — June 6, 2013

Page 10

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

Improved dynamic range

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

Keyboard

The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as the isolated invertedT cursor control keys, editing keys, both left and right control and alt keys, 12 function keys, and 19.05 x 19.05 mm key pitch (center-to-center spacing). U.S. and International key layouts are available. Other features include hot keys for instant access to power conservation and brightness. The HP EliteBook 8570p includes a separate numeric keypad.

Pointing Devices

Touchpad with on/off button, two-way scroll, gestures, two pick buttons Pointstick with two additional pointstick buttons (for a total of four)

Buttons and Function Keys

Discrete buttons provide easy access to the following features: wireless on/off, Web browser, and volume mute. The HP EliteBook 8570p also features a calculator button. Function keys provide control of the following features: standby mode, external display, volume down, volume up, HP Power Assistant (Windows 7 only), and display brightness.

SOFTWARE AND SECURITY

Preinstalled Software with Windows Operating System

HP Connection Manager (Windows 7 only) HP Hotkey Support HP Peak Power Manager (web download)* HP Power Assistant (Windows 7 only) HP ProtectTools for Central Management HP ProtectTools Security Manager HP Recovery Manager HP Support Assistant HP Webcam Software (select models) HP Wireless Hotspot (Windows 8 only, web download) Adobe Flash Player (Windows 7 only) Buy Office Cyberlink Media Suite Microsoft Defender (now includes MS Security Essentials) Microsoft Security Essentials (Windows 7 only) PDF Complete Corporate Edition Skype-ready** WinZip Basic (Windows 7 only)

NOTE:

HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important system files are accidentally deleted. Up to 16GB (for Windows 7) of system and up to 30 GB (for Windows 8) disk is reserved for system recovery software. Support in Windows Operating System only.

* HP Peak Power Manager replaces HP Power Assistant for both Win7 and Win8. HP Peak Power Manager will be available on the web for download for existing product owners. ** Skype-ready. Skype is not offered in China.

Security

DA - 14304 North America — Version 16 — June 6, 2013

Page 11

QuickSpecs

Features

Standard

HP Client Security Dashboard (Windows 8 only) HP ProtectTools HP Spare Key (requires initial user setup) Central Management for HP ProtectTools Credential Manager for HP ProtectTools Drive Encryption (will be web-only ready at Win8 GA date) Enhanced Pre-Boot Security Face Recognition File Sanitizer for HP ProtectTools (Windows 7 only) Microsoft Defender (now includes MS Security Essentials) Microsoft Security Essentials(Windows 7 only) TPM Embedded Security Chip 1.2 Smart Card Reader Security lock slot

Optional

Computrace (requires a subscription) Intel Anti-Theft Technology (requires a Computrace subscription) HP Fingerprint Sensor HP Privacy Filter

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

NOTE:

The Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S.

For more information on HP security solutions refer to:

http://www.hp.com/go/security

POWER

Power Supply

Models with discrete graphics and models with integrated graphics with quad-core processor: External 90W HP Smart AC Adapter Models with integrated graphics with dual-core processor: External 65W HP Smart AC Adapter Power cord included is 6-foot (1.8 meter). Total length including external AC adapter is 12 feet (3.66 meter). HP Fast Charge (not supported on 9-cell primary or secondary batteries)

Primary Battery

HP 9-cell Lithium-Ion Battery (100 WHr) HP 6-cell Lithium-Ion Battery (62 WHr) HP 6-cell HP Long Life Lithium-Ion Battery (55 WHr)

Secondary Battery

HP Extended Life Notebook Battery (9-cell /73 WHr) HP Ultra Extended Life Notebook Battery (9-cell /100 WHr)

Battery Life*

HP EliteBook 8470p**

9-cell (100 WHr)

6-cell (62 WHr)

Up to 14 hours and 15 minutes

Up to 9 hours and 15 minutes

DA - 14304 North America — Version 16 — June 6, 2013

Page 12

QuickSpecs

Features

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

with optional

HP ST09 Extended Life

Notebook Battery

with optional

HP BB09 Ultra Extended

Life Notebook Battery

HP EliteBook 8570p**

9-cell (100 WHr)

6-cell (62 WHr)

with optional

HP ST09 Extended Life

Notebook Battery

with optional

HP BB09 Ultra Extended

Life Notebook Battery

System Standby Time

Up to 30 days

*Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See MobileMark07 battery benchmark ** Configurations with integrated graphics. NOTE: Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. Please note that 9-cell batteries do not support Fast Charge.

Up to 20 hours and 30 minutes

Up to 24 hours and 15 minutes

Up to 13 hours and 30 minutes

Up to 8 hours and 15 minutes

Up to 18 hours and 45 minutes

Up to 22 hours and 15 minutes

http://www.bapco.com/products/mobilemark2007

for additional details.

Power Conservation

AMD PowerPlay technology (models with discrete graphics) Hibernation Standby ACPI compliance

ENVIRONMENTAL

ENERGY STAR qualified (with Microsoft OS) IT ECO Declaration EPEAT Gold where HP registers commercial notebook products. See

NOTE:

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks.

http://www.epeat.net

for registration status in your country.

DA - 14304 North America — Version 16 — June 6, 2013

Page 13

QuickSpecs

Features

WEIGHTS & DIMENSIONS

8470p

Weight

Starting at 4.56 lb (2.07 kg) without optical drive Starting at 4.95 lb (2.25 kg) with DVD-ROM drive

Dimensions

13.31 x 9.11 x 1.25 in (at front)

33.8 x 23.1 x 3.4 cm (at front)

8570p

Weight

Starting at 5.75 lb/2.61 kg (3-cell with weight saver) Starting at 5.97 lb/2.71 kg (3-cell with optical drive)

Dimensions

14.72 x 9.86 x 1.34 in (at front)

37.4 x 25.1 x 3.4 cm (at front)

NOTE:

components.

(w x d x h)

Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

PORTS/SLOTS

Ports

8470p

VGA – One DisplayPort – One (UMA: v1.1a; discrete: v1.2) Stereo microphone port – One Stereo headphone port – One Power Connector – One Secondary Battery Connector – One Docking Connector – One RJ-45 (Ethernet) – One RJ-11 (Modem) – One 1394a – One USB 3.0 – Two USB 2.0 charging port – One eSATA/USB 2.0 combo port – One

8570p

DA - 14304 North America — Version 16 — June 6, 2013

Page 14

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Features

USB 2.0 – One USB 2.0 charging port – One eSATA/USB 2.0 combo port – One Serial port – One

Digital Media Slots

1 ExpressCard/54 slot 1 SD slot (supported media include: SD, SDHC, SDXC)

SERVICE AND SUPPORT

HP Services offers limited 3 year and 1 year warranty options depending on country; 1-year limited warranty on primary battery; 3-year limited warranty on HP Long Life Battery (only available with 3-year platform warranty). On-site service and warranty upgrades are also available. HP Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool http://www.hp.com/services/carepack

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

. Additional HP Care Pack Services information by product is available at:

DA - 14304 North America — Version 16 — June 6, 2013

Page 15

QuickSpecs

Technical Specifications

SYSTEM UNIT

Stand-Alone Power Requirements

Temperature

Relative Humidity

Shock

Random Vibration

Altitude

Planned Industry Standard Certifications

(AC Power)

(unpressurized)

Nominal Operating Voltage

Average Operating Power

Max Operating Power

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

CSA

FCC Compliance

ENERGY STAR®

EPEAT

ICES

Australia / NZ A-Tick Compliance

CCC

Japan VCCI Compliance

BSMI

CE Marking Compliance

BNCI or BELUS

CIT

GOST

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

18.5 V

HP EliteBook 8570p

Integrated graphics Discrete graphics

HP EliteBook 8470p

Integrated graphics

Discrete graphics

< 65 W or < 90 W

32° to 95° F (0° to 35° C) (not writing optical) 41° to 95° F (5° to 35° C) (writing optical)

-4° to 140° F (-20° to 60° C)

10% to 90%, non-condensing

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

40 G, 2 ms, half-sine

200 G, 2 ms, half-sine

0.75 grms

1.50 grms

-50 to 10,000 ft (-15.24 to 3,048 m)

-50 to 40,000 ft (-15.24 to 12,192 m)

Yes

Select models*

Registered Gold in United States**

Yes

Windows 7 (32-bit) Windows 7 (64-bit)

10.23 W 10.42 W

13.5 W

9.14 W 9.07 W

13.62 W 13.31 W

13.88 W

DA - 14304 North America — Version 16 — June 6, 2013

Page 16

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Saudi Arabian Compliance (ICCP)

SABS

UKRSERTCOMPUTER

* Configurations of the HP EliteBook 8470p and HP EliteBook 8570p that are ENERGY STAR qualified are identified as HP 8470p ENERGY STAR and HP 8570p ENERGY STAR on HP websites and on ** EPEAT registration varies by country. See EPEAT status listed above applies to U.S.

For accessibility information on HP products, please visit:

www.epeat.net

Yes

www.energystar.gov

for registration status by country.

http://www.hp.com/accessibility

DISPLAY

14.0-inch LED HD (1366 x 768) anti-glare

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

(W x H)

12.74 x 7.56 in (32.4 x 19.2 cm)

14.0 in (35.6cm)

Anti-glare

300:1 (typical)

60 Hz

200 nit (typical)

Pitch

Format

Configuration

LED

112 ppi

±30° Horizontal, ±10° Vertical (minimum) 30/30/20/10 (Left/Right/Down/Up) (minimum) or 45/45/35/25 (Left/Right/Down/Up) (typical)

0.227 mm

1366 x 768

RGB Stripe

DA - 14304 North America — Version 16 — June 6, 2013

Page 17

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

14.0-inch LED HD+ (1600 x

900) anti-glare

15.6-inch LED HD (1366 x 768) anti-glare

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

(W x H)

12.74 x 7.56 in (32.4 cm x 19.2 cm)

14.0 in (35.6cm)

Anti-glare

300 (min)

60 Hz

200 nits (typical)

Pitch

Format

Configuration

LED

131 ppi

30/30/20/10 (Left/Right/Down/Up) (minimum)

13.54 x 7.59 in (34.4 x 19.4 cm)

15.6 in (39.6cm)

Anti-glare

300:1 (typical)

60 Hz

200 nit (typical)

Pitch

Format

Configuration

LED

100 ppi

±30° Horizontal, ±10° Vertical (minimum) 30/30/20/10 (Left/Right/Down/Up) (minimum) or 45/45/35/25 (Left/Right/Down/Up) (typical)

0.1935mm

1600 x 900

RGB Stripe

0.252 mm

1366 x 768

RGB Stripe

DA - 14304 North America — Version 16 — June 6, 2013

Page 18

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

15.6-inch LED FHD WVA (1920 x 1080) anti-glare

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

STORAGE AND DRIVES

Internal Storage

750 GB 7200 rpm SATA Hard Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Cache

Rotational Speed

Logical Blocks

Operating Temperature

Features

(W x H)

13.54 x 7.59 in (34.4 x 19.4 cm)

15.6 in (39.6 cm)

Anti-glare

300 :1 (min)

60 Hz

220 nits (Typ)

Pitch

Format

Configuration

White LED

142 ppi

±60° Horizontal, ± 50° Vertical (minimum) or ±70° Horizontal, ±60° Vertical (typical)

0.22 lb (101 g)

750 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

Single Track

Average

Maximum

16 MB

7200 rpm

1,465,149,168

32° to 140° F (0° to 60° C) [case temp]

ATA Security

(maximum)

0.179mm x 0.179mm

1920 x 1080

RGB Stripe

300 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

DA - 14304 North America — Version 16 — June 6, 2013

Page 19

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

500 GB 7200 rpm SATA Hard Drive

500 GB 7200 rpm SMART SATA II Self Encrypting Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Cache

Rotational Speed

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Cache

Rotational Speed

Logical Blocks

Operating Temperature

Features

0.25 lbs (115g)

500 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

Single Track

Average

Maximum

16 MB

7200 rpm

976,773,168

32° to 140° F (0° to 60° C) [case temp]

ATA Security

0.25 lbs (115g)

500 GB

0.37 in (9.5 mm)

2.50 in (63.5 mm)

ATA-8, SATA 2.6, 3.0 Gb/s

Synchronous

Single Track

Average

Maximum

16 MB

7200 rpm

976,773,168

32° to 140° F (0° to 60° C) [case temp]

ATA Security

(maximum)

300 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

300 MB/s (Drive Capability)

1 ms

12 ms

20 ms

DA - 14304 North America — Version 16 — June 6, 2013

Page 20

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

320 GB 7200 rpm SATA Hard Drive

SATA 6 Gb/s 256 GB, 2.5inch SATA SED Solid State Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Cache

Rotational Speed

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Performance

Logical Blocks

Operating Temperature

Features

0.25 lbs (115 g)

320 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

Single Track

Average

Maximum

16 MB

7200 rpm

625,142,448

32° to 140° F (0° to 60° C) [case temp]

ATA Security

73 Grams

256 GB

0.276 in (7 mm)

2.76 in (70 mm)

SATA 3 (6 Gb/s)

Maximum Sequential Read

Up to 460 MB/s Up to 260 MB/s 500,118,192

32° to 158°F (0° to 70°C) [case temp]

ATA Security; ATA-8 compliant; SATA 3.0; DIPM; TRIM

(maximum)

300 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

Maximum Sequential Write

DA - 14304 North America — Version 16 — June 6, 2013

Page 21

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

SATA 6 Gb/s 180 GB, 2.5inch Solid State Drive

SATA 6 Gb/s 128 GB, 2.5inch Solid State Drive

Drive Weight

Capacity

Height

Width

Interface

Performance

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Performance

Logical Blocks

Operating Temperature

Features

78 Grams

180 GB

0.276 in (7 mm)

2.76 in (70 mm)

SATA Gen 3 (6 Gb/s)

Maximum Sequential Read

550 MB/s 520 MB/s 351,651,888

32° to 158°F (0° to 70°C) [case temp]

ATA Security; ATA-8, SATA 3.0; DIPM; TRIM

73 Grams

128 GB

0.276 in (7 mm)

2.76 in (70 mm)

SATA 3 (6 Gb/s)

Maximum Sequential Read

415 MB/s 175 MB/s 250,069,680

32° to 158°F (0° to 70°C) [case temp]

ATA Security; ATA-8; SATA 3.0 DIPM; TRIM

Maximum Sequential Write

Optical Drives

DVD-ROM Drive

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

Transport

DA - 14304 North America — Version 16 — June 6, 2013

(read)

(write)

(read)

Random

24X CD-ROM 8X-DVD UDMA Mode 5

Gen 1 SATA

CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM

None

8.5GB

Tray Loading

< 140 ms CD (typical) < 160 ms DVD (typical)

Page 22

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

DVD+/-RW SuperMulti DL Drive

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(write)

Transport

(read)

(write)

(read)

Random

24X CD-ROM 8X DVD 24X CD-R 24X CD-RW 8X DVD+R 8X DVD+RW 8X DVD-R 6X DVD-RW 6X - DVD+R Dual Layer 6X - DVD-R Dual Layer 5X DVD-RAM UDMA Mode 5

Gen 1 SATA

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, DVD+R DL, DVD-R DL

8.5 GB

Tray Loading

<140ms CD (typical) < 160 ms DVD (typical)

Blu-ray ROM DVD+/-RW SuperMulti DL Drive

Access Times

Max Data Transfer Rate

DA - 14304 North America — Version 16 — June 6, 2013

Random

24X CD-ROM 8X DVD-ROM 24X CD-R 16X CD-RW 8X DVD+R 8X DVD+RW 8X DVD-R 6X DVD-RW 4X - DVD+R Dual Layer 4X - DVD-R Dual Layer 5X DVD-RAM 6X BD-ROM

<190 ms CD-ROM (typical) < 180ms DVD-ROM (typical) <230 ms BD-ROM (typical)

Page 23

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

SECURITY

HP Fingerprint Sensor

(optional)

Transfer Mode

Interface

Supported Media

Max Media Capacity

(write)

Transport

Mobile Voltage Operation

Operating Temperature

Current Consumption @

3.3V

High-Rate Image Capture

ESD Resistance

Detection Matrix

(read)

(write)

(read)

UDMA Mode 5

Gen 1 SATA

CD-DA, , CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW. DVD-RAM, BD-ROM, BD-R, BD-RE

CD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW, DVDRAM

50.0 GB

8.5GB

Tray Loading

3.0V-3.6V Single Supply

32° - 158°F (0° - 70°C)

Less than 70 mA peak imaging and scrolling Less than 25 mA hardware finger detection Advanced Power Management

Up to 240 image frames /sec

IEC 61000-4-2 Level 4 (±15KV)

192 x 16 Pixels

9.7 mm x 0.81 mm 500 ppi High-Resolution Images

NETWORKING/COMMUNICATIONS

DA - 14304 North America — Version 16 — June 6, 2013

Page 24

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Intel® 82579LM Gigabit Network Connection

Ethernet Features

Power Management

Performance Features

Manageability

Interface

NIC Device Driver Name

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023. Clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE(Energy Efficient Ethernet) Jumbo Frame 9K Auto MDI/MDIX Crossover cable detection

ACPI compliant - multiple power modes Energy Detect Low Power Mode(Green Ethernet)

TCP/IP/UDP Checksum Offload (configurable) Protocol Offload( ARP & NS) Large send offload and Giant send offload Receiving Side Scaling MACSec Offload (802.3ae) Intel vPro iSCSI Boot

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status

PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ.

NOTE:

Intel 82579 PCIe interface is not PCIe compliant. It operates at half of

PCIe specification V1.1 (2.5GT/S) speed.

Intel 82579LM/82579V Ethernet Network Connection

DA - 14304 North America — Version 16 — June 6, 2013

Page 25

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

V.92 56K Data/Fax Modem

Form Factor

Power Management Support

Approvals/ Certifications

Data Mode Capabilities

Fax Mode Capabilities

Command Set

MDC 1.5 Daughtercard

APM Revision 1.2, ACPI

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries

V.92 data V.8bis V.80 V44, V.42bis, MNP5 (Compression) V.42 (LAPM, MNP2-4) (Error Correction)

Optional symbol rates

2800, 3429 Asymmetric Symbol rates

Synchronous primary channel data signaling rates

3600, 31200 Automatic rate re-negotiation V.34 V.32bis V.32 V.23 V.22bis V.22 V.21 Bell 212A Bell 103J

TIA/EIA-578-B (Class 1) T.30, T.4 (Group 3) V.17 V.29 V.27ter V.21 Channel 2 T.31

V.250 (Partial) TIA-602 Identification: +GMI, +GMM, +GMR Port control: +IPR, +ICF, +IFC, +ILRR Modulation: +MS, +MR, +MA Error control: +ES, +ER, +EB, +ESR, +ETBM Data compression: +DS, +DR V.251

DA - 14304 North America — Version 16 — June 6, 2013

Page 26

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP un2430 EV-DO/HSDPA Mobile Broadband Module (Gobi™

3000)

Technology/Operating Bands

Wireless Protocol Standards

Wireless Parametric Standards

Maximum Data Rates

GPS

GPS Bands

Maximum Output Power

Maximum Power Consumption

Power Consumption, Idle Not Connected

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

(from TIA/EIA/IS-98-D)

Temperature, Nonoperating, 96 hours

MIL-STD 202 Method 108)

Humidity, Non-operating

Configuration Utilities

LED Activity

(Length x

(from

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz (PCS) UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz (UTRA FDD Band II), AWS (UTRA FDD Band IV), 900MHz(UTRA FDD Band VIII), 850MHz (UTRA FDD Band V) 1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell), 1900MHz (Band Class1-PCS)

GSM/GPRS/EDGE: Class A, Multi-slot class 10 operation, coding schemes CS1 CS4 and MSC1 - MSC9. UMTS/WCDMA: Release 99 and Release 6 CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-2000

Meets or exceeds TIA/EIA IS-98-D

UMTS (HSPA) - 14.4 Mbps (Download ), 5.76Mbps (Upload) CDMA (EVDO Release A) - 3.1 Mbps (Download), 1.8Mbps (Upload)

Standalone GPS enabled gpsOneXTRATM™

L1 - 1575.42 MHz

GSM/GPRS/EDGE: 32dBm (+/-1) WCDMA: 24dBm (+0.7/-2.3) CDMA: 24dBm (+0.7/-2)

2750mA (peak); 1100mA (average)

20 mA

USB selective suspend Integrated notebook wireless button

Dual high efficiency 5 band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard, USB 2.0 interface

11.5 g

2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)

3.3v +/- 10%

-22° to 158° F (-30° to 70° C) (full RF performance)

-22° to 167° F (-30° to 75° C) (reduced RF performance)

-40° to 185° F (-40° to 85° C)

95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

HP Connection Manager

LED Off - Radio Off; Solid LED On - Radio On

DA - 14304 North America — Version 16 — June 6, 2013

Page 27

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP hs2350 HSPA+ Mobile Broadband Module

Technology/Operating Bands

Wireless Protocol Standards

Wireless Parametric Standards

Maximum Data Rates

GPS

GPS Bands

Maximum Output Power

Maximum Power Consumption

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

Temperature, Nonoperating, 96 hours

MIL-STD 202 Method 108)

Humidity, Non-operating

Configuration Utilities

(Length x

(from

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz (PCS) UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900Mhz (UTRA FDD Band II), 900Mhz(UTRA FDD Band VIII), 850 MHz (UTRA FDD Band V)

GSM/GPRS/EDGE: Class B, Multi-slot class 10 operation, coding schemes CS1 CS4 and MSC1 - MSC9. UMTS/WCDMA: Release 99 and Release 7 Advanced Receiver Type 3i

Complies with 3GPP specifications

UMTS (HSPA) - 21 Mbps (Download ), 5.76Mbps (Upload)

Standalone, A-GPS (Internet- and Network assisted)

1575.42 MHz (± 1.023 MHz)

GSM/EDGE GSM850 & GSM900 bands GPRS: +33 dBm ± 2 dBm (class 4) EGPRS: +27 dBm ± 3 dBm (class E2)

DCS1800 & PCS1900 bands GPRS: +30 dBm ± 2 dBm (class 1) EGPRS: +26 dBm +4 / -3 dBm (class E2)

UMTS UTRA FDD Bands +24 dBm +4 / -3 dBm (class 3)

2000mA (peak); 600mA (average)

5 mA

USB selective suspend Integrated notebook wireless button

Dual high efficiency 5 band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard, USB 2.0 interface

< 12 g

2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)

3.3v +/- 9%

14° to 149° F (-10° to 65° C) (full RF performance) 14° to 167° F (-10° to 75° C) (reduced RF performance)

-22° to 185° F (-30° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

HP Connection Manager

DA - 14304 North America — Version 16 — June 6, 2013

Page 28

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP lt2522 LTE/EV-DO Mobile Broadband Module

LED Activity

Technology/Operating Bands

Mobile Operator

Wireless Protocol Standards

Wireless Parametric Standards

Maximum Data Rates

GPS

GPS Bands

Maximum Output Power

Maximum Power Consumption

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

Temperature, Nonoperating, 96 hours

MIL-STD 202 Method 108)

(Length x

(from

LED Off - Radio Off; Solid LED On - Radio On

CDMA/1xRTT/EvDO: 800MHz (Cell), 1900MHz (PCS) GSM/GPRS/EDGE: 850MHz (Cell), 900MHz (EGSM), 1800MHz (DCS), 1900MHz (PCS) UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz (UTRA FDD Band II), 900MHz (UTRA FDD Band VIII), 850 MHz (UTRA FDD Band V) LTE: 700 MHz (Verizon, Band XIII)

Verizon (US only)

GSM/GPRS/EDGE: Class B, Multi-slot class 10 operation, coding schemes CS1 CS4 and MSC1 - MSC9. CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-2000 UMTS/WCDMA: Release 99 and Release 7 LTE: Power Class III as per 3GPP TS 36.101

Complies with 3GPP specifications Release 8 for LTE

EvDO (Revision A) - 3.1 Mbps (Download), 1.8 Mbps (Upload) WCDMA (DC-HSPA+) - 42Mbps (Download) LTE (Category 3) - 100 Mbps (Download ), 50Mbps (Upload)

Standalone, Assisted, XTRA

1575.42 MHz (± 1.023 MHz)

GSM/GPRS/EDGE: 32dBm (+/-1) WCDMA: 24dBm (+0.7/-2.3) LTE: +23 dBm (+2.7 dBm/-1.7 dBm) 1xRTT/EvDO: +24 dBm (+0.5 dBm/-1.5 dBm)

2700mA (peak)

10 mA

USB selective suspend Integrated notebook wireless button

Dual high efficiency 6 band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard, USB 2.0 interface

< 10 g

2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)

3.3v +/- 9%

-4° to 149° F (-20° to 65° C)

-40° to 185° F (-40° to 85° C)

DA - 14304 North America — Version 16 — June 6, 2013

Page 29

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP lt2523 LTE/HSPA+ Mobile Broadband Module

Humidity, Non-operating

LED Activity

Technology/Operating Bands

Mobile Operator

Wireless Protocol Standards

Wireless Parametric Standards

Maximum Data Rates

GPS

GPS Bands

Maximum Output Power

Maximum Power Consumption

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

Temperature, Nonoperating, 96 hours

MIL-STD 202 Method 108)

Humidity, Non-operating

LED Activity

(Length x

(from

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

LED Off - Radio Off; Solid LED On - Radio On

GSM/GPRS/EDGE: 850MHz (Cell), 900MHz (EGSM), 1800MHz (DCS), 1900MHz (PCS) UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz (UTRA FDD Band II), 850 MHz (UTRA FDD Band V) LTE: AWS (Band IV) 700 MHz (AT&T, Band XVII)

AT&T (US only)

LTE: Power Class III as per 3GPP TS 36.101

Complies with 3GPP specifications Release 8 for LTE

WCDMA (DC-HSPA+) - 42Mbps (Download) LTE (Category 3) - 100 Mbps (Download ), 50Mbps (Upload)

Standalone, Assisted, XTRA

1575.42 MHz (± 1.023 MHz)

GSM/GPRS/EDGE: 32dBm (+/-1) WCDMA: 24dBm (+0.7/-2.3) LTE: +23 dBm (+2.7 dBm/-1.7 dBm) 1xRTT/EvDO: +24 dBm (+0.5 dBm/-1.5 dBm)

2700mA (peak)

10 mA

USB selective suspend Integrated notebook wireless button

Dual high efficiency 6 band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard, USB 2.0 interface

< 10 g

2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)

3.3v +/- 9%

-4° to 149° F (-20° to 65° C)

-40° to 185° F (-40° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

LED Off - Radio Off; Solid LED On - Radio On

DA - 14304 North America — Version 16 — June 6, 2013

Page 30

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Intel Centrino Advanced-N 6205 (2x2)

Wireless LAN Standards

Interoperability

Frequency Band

Antenna Structure

Data Rates

Modulation

Security

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n

Wi-Fi certified Cisco Compatible Extensions Program compliant with Microsoft Windows 7, Windows Vista and XP (details at:

2.4 GHz and 5GHz

2 transmit; 2 receive (2x2)

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: 66 possible data rates, ranging from 6 Mbps to 300 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Authentication: WPA and WPA2, 802.1x (EAP_TLS, TTLS, PEAP, LEAP, EAPFAST)

Authentication Protocols: PAP, CHAP, TLS, GTC, MS-CHAP, MS-CHAPv2

Encryption: 64 and 128-bit WEP, AES-CCMP, CKIP, TKIP

http://www.hp.com/go/notebooks/WLAN

)

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

OFDM)

Power Consumption

Power Management

Receiver Sensitivity

Antenna Connections

Form Factor

Weight

Dimensions

(for CCK and

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4) with Microsoft Windows Vista and XP only.

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between 2.4GHz band Access Points

17 dBm max

Transmit: 2.3 Watts (max, with two spatial streams) Receive: 1 Watt (max with two spatial streams) Idle mode3: 35 mW (average) Radio off: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode 54 Mbps: -76 dBm, 6 Mbps: -92 dBm

2 U.FL type connectors, 50 ohm nominal impedance

PCI-Express Half-MiniCard

0.0075 lb (3.4 g)

0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)

DA - 14304 North America — Version 16 — June 6, 2013

Page 31

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Intel Centrino Ultimate-N 6300

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. In Power Save Polling mode and on battery power.

4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

5. WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.

Wireless LAN Standards

Interoperability

Frequency Band

Antenna Structure

Data Rates

Modulation

Security

3.3V +/- 9%

Operating Non-operating

LED Off - Radio OFF; Solid LED On - Radio ON

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n

Wi-Fi certified Cisco Compatible Extensions Program compliant with Microsoft Windows 7, Windows Vista and XP (details at:

2.4 GHz and 5GHz

3 transmit; 3 receive (3x3)

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: many possible data rates, ranging from 6 Mbps to 450 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Authentication: WPA and WPA2, 802.1x (EAP_TLS, TTLS, PEAP, LEAP, EAPFAST)

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing)

5% to 90% (non-condensing) 0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

http://www.hp.com/go/notebooks/WLAN

)

Sub-channels

DA - 14304 North America — Version 16 — June 6, 2013

Authentication Protocols: PAP, CHAP, TLS, GTC, MS-CHAP, MS-CHAPv2

Encryption: 64 and 128-bit WEP, AES-CCMP, CKIP, TKIP

Multinational support with frequency bands and channels compliant to local regulations.

Page 32

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Media Access Protocol

Network Architecture Models

Roaming

Output Power

OFDM)

Power Consumption

Power Management

Receiver Sensitivity

Antenna Connections

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. In Power Save Polling mode and on battery power.

4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

(for CCK and

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between Access Points

17 dBm max

Transmit: 1.4 Watts (average, with one spatial streams) Receive: 1.3 Watts (average with two receive chains) Idle mode3: 30 mW (average) Radio off: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

54 Mbps: -76 dBm, 6 Mbps: -92 dBm

3 U.FL type connectors, 50 ohm nominal impedance

PCI-Express Half-MiniCard

0.0075 lb (3.4 g)

0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)

3.3V +/- 9%

Operating Non-operating

LED Off - Radio OFF; Solid LED On - Radio ON

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing)

5% to 90% (non-condensing) 0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

802.11 b/g/n WiFi Adapter (1x1)

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

DA - 14304 North America — Version 16 — June 6, 2013

IEEE 802.11b IEEE 802.11g IEEE 802.11n

Wi-Fi certified

2.4 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: many possible data rates, ranging from 6 Mbps to 300 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification

Page 33

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Modulation

Security

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output

Power Consumption

Power Management

Receiver Sensitivity

Antenna Connections

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

13.5 dBm, nominal

Transmit: 2.0 W (max) Receive: 1.6 W (max) Associated to Access Point, Idle: 250 mW nominal Wireless Button Off: 100 mW nominal Radio disabled: 75 mW nominal

ACPI compliant power management

802.11 compliant power saving mode

72.2 Mbps: -70 dbm, 54 Mbps: -74 dBm, 11 Mbps: -88 dBm , 1 Mbps: -95 dBm

High efficiency antenna with spatial diversity, mounted in the display enclosure

PCI-Express Half-MiniCard 1.2

0.013 lb (6 g)

0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)

3.3v +/- 9%

Operating Non-operating

LED Off - Radio OFF; Solid LED On - Radio ON

14° to 158° F (-10° to 70° C)

-40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing)

5% to 95% (non-condensing) 0 to 10,000 ft (3,048 m)

0 to 50,000 ft (15,240 m)

HP Integrated Module with Bluetooth 4.0+EDR Wireless Technology

Bluetooth Specification

Dimensions

Frequency Band

Number of Available Channels

DA - 14304 North America — Version 16 — June 6, 2013

4.0+EDR Compliant

1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)

2402 to 2480 MHz

79 (1 MHz) available channels

Page 34

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Data Rates and Throughput

Transmit Power

Receiver Sensitivity

Power Consumption

Antenna

Range

Electrical Interface

Bluetooth Software Supported

Link Topology

Security

Power Management

Certifications

Temperature

Humidity

Altitude

Bluetooth Profiles Supported

3 Mbps data rate; throughput up to 2.17 Mbps Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or

1306.9 kbps symmetric

-1.5 dBm to 4 dBm (Bluetooth Class II)

Better than -20 dBM at 0.1 % raw bit error rate

Peak (Tx) 264 mW Peak (Rx) 231 mW Sleep <1 mW Internally integrated within module

Up 33 ft (10 m)

USB 2.0 compliant Microsoft Windows Plug and Play compliant Broadcom Bluetooth for Windows Microsoft Windows Bluetooth Software Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Microsoft Windows ACPI, and USB Bus Support Self configurable to optimize power conservation in all operating modes,

including Standby, Hold, Park, and Sniff All necessary regulatory approvals for supported countries, including: FCC (47 CFR) Part 15C, Section 15.247 & 15.249 ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark Operating

Non-operating Operating

Non-operating Serial Port Profile (SPP) Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN) Generic Object Exchange Profile (GOEP) Object Push Profile (OPP) File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP) Personal Area Networking Profile (PAN) Human Interface Device Profile (HID)

-14° to 158° F (-10° to 70° C)

-40° to 212° F (-40° to 100° C) 0% to 90%

0% to 95% 15,000 ft (4,572 m)

40,000 ft (12,192 m)

1,2

DA - 14304 North America — Version 16 — June 6, 2013

Page 35

QuickSpecs

Technical Specifications

1. indicates the profile is supported by Microsoft Windows XP SP2

2. indicates the profile is part of Windows Vista

AUDIO/MULTIMEDIA

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

FAX Profile (FAX) Basic Imaging Profile (BIP) Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

Hardware

Audio Output Quality

Internal Stereo Speaker

Implementation

Function-Key Volume Controls

Full Duplex

Microphone In

Headphone/Line Out

Integrated Microphone

Frequency Response

Signal to Noise Ratio

Total Harmonic Distortion

Noise Floor

Play/Record Sampling Rate

(s)

DAC

ADC

Power Rating

Impedance

IDT 92HD87 High Definition CODEC

Volume up, volume down, and mute

Yes

Stereo

Yes, dual digital microphone array when equipped with optional webcam

20 Hz - 20 kHz

>85 dB

0.01%

-110 dB

8 kHz - 48kHz

16, 20 or 24-bit

16 or 20-bit

2 Watts

4 ohms

POWER

DA - 14304 North America — Version 16 — June 6, 2013

Page 36

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP 90W Smart AC Adapter (discrete configurations and configurations with integrated graphics with quad-core processor)

Dimensions

Weight

Input

Output

Connector

Environmental Design

EMI and Safety Certifications

5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)

0.82 lb (370 g)

100 to 240 VAC

Input Efficiency

Input frequency range

Input AC current

Output power

DC output

Hold-up time

Output current limit

3 pin/grounded, mates with interchangeable cords

Operating temperature

Non-operating (storage) temperature

Altitude

Humidity

Storage Humidity

CE Mark - full compliance with LVD and EMC directives; Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient condition.

87% min at 115 VAC

47 to 63 Hz

1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version

2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version 90W

19.0V

5 msec at 115 VAC input

<11A, Over voltage protection- 29V max automatic shutdown

32° to 104° F (0° to 40° C)

-4° to 149° F (-20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

HP 65W Smart AC Adapter (Configurations with integrated graphics with dual-core processor)

Dimensions

Weight

Input

Output

Connector

Environmental Design

DA - 14304 North America — Version 16 — June 6, 2013

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

0.62 lb (280 g)

100 to 240 VAC

Input Efficiency

Input frequency range

Input AC current

Output power

DC output

Hold-up time

Output current limit

3 pin/grounded, mates with interchangeable cords

Operating temperature

Non-operating (storage) temperature

87% min at 115 VAC

47 to 63 Hz

1.7 A at 90 VAC, 0.85 A at 180 VAC

65W

18.5V

5 msec at 115 VAC input

<11A, Over voltage protection- 29V max automatic shutdown

32° to 104° F (0° to 40° C)

-4° to 149° F (-20° to 65° C)

Page 37

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP 9-cell (100 WHr) Lithium-Ion Primary battery

EMI and Safety Certifications

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge LED

Warranty

Compatible with optional Travel Battery

(H x W x L)

(max)

Altitude

Humidity

Storage Humidity

0.8 x 2.4 x 8.1in (2 x 6.6 x 20.5cm)

1.1lb, (.488kg)

Lithium-Ion

Voltage

Amp-hour capacity

Watt-hour capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF or Standby Mode

System ON

1 year

Yes

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

11.25V

8.85Ah

100Wh

32° to 113° F (0° to 45° C)

14° to 122° F(-10° to 50° C)

-4° to 122° F (-20° to 50° C)

3.5 to 5 hours

4 to 7 hours

HP 6-cell (62 WHr) Lithium-Ion Primary battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Warranty

Compatible with optional Travel Battery

(H x W x L)

(max)

DA - 14304 North America — Version 16 — June 6, 2013

0.8 x 2.0 x 8.3 in (2.0 x 5.1 x 21.1 cm)

0.72 lb (0.325 kg)

6-cell Lithium-Ion

Watt-hour capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF or Standby Mode

1 year

Yes

62Wh

32° to 113° F (0° to 45° C)

14° to 140° F (-10° to 60° C)

-4° to 140° F (-20° to 60° C)

2.5 hours

Page 38

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

HP 6-cell (55 WHr) Long Life Primary Battery

Optional HP BB09 Ultra Extended Life Notebook Battery (secondary battery)

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge LED

Warranty

Compatible with optional Travel Battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge LED

Warranty

Compatible with optional Travel Battery

(H x W x L)

(max)

(H x W x L)

(max)

0.8 x 1.8 x 8.0in (2.0 x 4.7 x 20.5cm)

.72lb, (.323kg)

Lithium-Ion

Voltage

Amp-hour capacity

Watt-hour capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF or Standby Mode

System ON

3 years

Yes

1.2 x 5.9 x 11.4 in (3x15x29cm)

1.5lb, (.682kg)

Lithium-Ion

Voltage

Amp-hour capacity

Watt-hour capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF or Standby Mode

System ON

Yes

1 year

10.8V

5.1Ah

55Wh

32° to 113° F (0° to 45° C)

14° to 122° F(-10° to 50° C)

-4° to 122° F (-20° to 50° C)

2.5 hours

3 to 5 hours

11.25V

8.85Ah

100Wh

32° to 113° F (0° to 45° C)

14° to 122° F(-10° to 50° C)

-4° to 122° F (-20° to 50° C)

3.5 to 5 hours

4 to 7 hours

DA - 14304 North America — Version 16 — June 6, 2013

Page 39

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Optional HP ST09 Extended Life Notebook Battery ("Travel Battery") (secondary battery)

ENVIRONMENTAL

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge LED

Warranty

Compatible with optional Travel Battery

(H x W x L)

(max)

1.2 x 6.1 x 12 in (3x15.5x30.5cm)

1.2lb, (.550kg)

Lithium-Ion Polymer

Voltage

Amp-hour capacity

Watt-hour capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF or Standby Mode

System ON

Yes

1 year

Yes

11.1V

6.6Ah

73Wh

32° to 113° F (0° to 45° C)

14° to 122° F(-10° to 50° C)

-4° to 122° F (-20° to 50° C)

3.5 to 5 hours

4 to 7 hours

HP EliteBook 8470p Notebook PC

Environmental Data

Eco-Label Certifications

System Configuration

Energy Consumption

Normal Operation Sleep (Energy Star low

power mode) Off

Heat Dissipation

Normal Operation Sleep

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

US ENERGY STAR qualified (with Microsoft OS) IT ECO declaration EPEAT Gold with a Microsoft OS where HP registers commercial notebook products. See Federal Energy Management Program (FEMP)

The configuration used for the Energy Consumption and Declared Noise Emissions data is based on a "Typically Configured Notebook"

http://www.epeat.net

115 VAC 230 VAC 100 VAC

8.6 W

0.6 W 0.7 W 0.6 W

0.61 W 0.68 W 0.58 W

115 VAC 230 VAC 100 VAC

29.4 BTU/hr 31.7 BTU/hr 28.4 BTU/hr 2 BTU/hr

for registration status in your country. US

9.27 W 8.32 W

2.3 BTU/hr

2 BTU/hr

DA - 14304 North America — Version 16 — June 6, 2013

Page 40

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Off

* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

System Fan Off

Idle Fixed Disk

(random writes) System fan is usually off except when charging the battery

Batteries

Additional information

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

The battery type and chemistry used in the product is:

CR2032 (coin cell), Li-ion 6-cell high capacity Lithium-Ion battery (optional 8 cell available)

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC.

2 BTU/hr

Sound Power

(LWAd, bels)

3 26

3.4

Mercury greater the 5ppm by weight Cadmium greater than 10ppm by weight

2.3 BTU/hr

2 BTU/hr

Sound Pressure

(LpAm, decibels)

This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC.

This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of 1986).

This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level, see

Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.

This product contains 0% post-consumer recycled plastic (by wt.)

This product is greater than 96.7% recycle-able when properly disposed of at end of life.

Packaging Materials

www.epeat.net

External:

PAPER/Corrugated 335.7 g

Internal:

PLASTIC/Polyethylene low density 13.8 g

DA - 14304 North America — Version 16 — June 6, 2013

Page 41

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

PLASTIC/EPE-Expanded Polyethylene 68.1 g

PLASTIC/Polyester 6.5 g The PAPER/Corrugated packaging material is made from 80% recycled content. The PLASTIC/Polyethylene low density packaging material is made from 60% recycled content. The PLASTIC/EPE-Expanded Polyethylene packaging material is made from 60% recycled content. The PLASTIC/Polyester packaging material is made from 60% recycled content.

HP follows these guidelines to decrease the environmental impact of product packaging:

Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

HP EliteBook 8570p Notebook PC

Environmental Data

Eco-Label Certifications

System Configuration

Energy Consumption

Normal Operation Sleep (Energy Star low

power mode) Off

Heat Dissipation

Normal Operation Sleep

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

US ENERGY STAR qualified (with Microsoft OS) IT ECO declaration EPEAT Gold with a Microsoft OS where HP registers commercial notebook products. See Federal Energy Management Program (FEMP)

The configuration used for the Energy Consumption and Declared Noise Emissions data is based on a "Typically Configured Notebook"

45.69 BTU/hr 46.68 BTU/hr 45.55 BTU/hr

http://www.epeat.net

115 VAC 230 VAC 100 VAC

13.36 W 13.65 W 13.32 W

1.22 W 1.35 W 1.21 W

0.685 W 0.800 W 0.677 W

115 VAC 230 VAC 100 VAC

4.2 BTU/hr 4.6 BTU/hr 4.1 BTU/hr

for registration status in your country. US

DA - 14304 North America — Version 16 — June 6, 2013

Page 42

QuickSpecs

Technical Specifications

HP EliteBook 8470p Notebook PC HP EliteBook 8570p Notebook PC

Off

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

System Fan Off

Idle Fixed Disk

(random writes) System fan is usually off except when charging the battery

Batteries

Additional information

2.3 BTU/hr 2.7 BTU/hr 2.3 BTU/hr

* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Sound Power

(LWAd, bels)

3.0

3.4

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight Cadmium greater than 10ppm by weight

The battery type and chemistry used in the product is:

CR2032 (coin cell), Li-ion 6-cell high capacity Lithium-Ion battery (optional 8 cell available)

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC.

Sound Pressure

(LpAm, decibels)

24 28

This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC.

This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of 1986).

This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level, see

Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.

This product contains 0% post-consumer recycled plastic (by wt.)

This product is greater than 95.7% recycle-able when properly disposed of at end of life.

Packaging Materials

www.epeat.net

External:

PAPER/Corrugated 361 g Internal:

PLASTIC/Polyethylene low density 36 g

DA - 14304 North America — Version 16 — June 6, 2013

Page 43

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Technical Specifications

PLASTIC/EPE-Expanded Polyethylene 28 g

OTHER/OTHER 20 g

PLASTIC/Polypropylene 15 g The PAPER/Corrugated packaging material is made from 74% recycled content. The PLASTIC/Polyethylene low density packaging material is made from 21.9% recycled content The PLASTIC/EPE-Expanded Polyethylene packaging material is made from 21.9% recycled content The OTHER/OTHER packaging material is made from 21.9% recycled content. The PLASTIC/Polypropylene packaging material is made from 21.9% recycled content

HP follows these guidelines to decrease the environmental impact of product packaging:

MATERIAL USAGE

This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment (

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html

Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs)

DA - 14304 North America — Version 16 — June 6, 2013

Page 44

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Technical Specifications

Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO) Nickel finishes that release greater than 0.5 µgrams/cm2/week, measured according to EN 1811:1998, are not used on any product surface designed to be frequently handled or touched by users.

END-OF-LIFE MANAGEMENT AND RECYCLING

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at:

http://www.hp.com/go/recyclers

customers who integrate and re-sell HP equipment.

HEWLETT-PACKARD CORPORATE ENVIRONMENTAL INFORMATION

For more information about HP's commitment to the environment:

http://www.hp.com/go/reuse-recycle

. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM

or contact your nearest HP sales office. Products returned to HP will be recycled,

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

DA - 14304 North America — Version 16 — June 6, 2013

Page 45

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Options and Accessories (sold separately and availability may vary by country)

Type

Memory

Cases

Docking

Input/Output - Mice

Adapters

Storage - External Storage

Batteries

Health and Education

Security

Description

HP 2 GB PC3-12800 (DDR3 1600 MHz) SODIMM

HP 4 GB PC3-12800 (DDR3 1600 MHz) SODIMM

HP 8 GB PC3-12800 (DDR3 1600 MHz) SODIMM

NOTE:

Full availability of 4 GB or more of memory requires Windows Vista Business 64bit or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

HP Deluxe 4 Wheel Roller

HP Display and Notebook Stand HP Dual Hinge Notebook Stand HP Adjustable Dual Display Stand HP 90W Docking Station HP 120W Advanced Docking Station

HP Wireless Mobile Mouse

HP 90W Slim Adapter

HP Mobile USB DVDRW SATA Upgrade Bay 500 GB 7200 rpm Hard Drive

HP CC06XL Long Life Notebook Battery HP CC09 Notebook Battery HP ST09 Extended Life Notebook Battery HP BB09 Ultra Extended Life Notebook Battery

HP 20-Notebook Managed Charging Cart HP 20-Notebook Charging Cart HP 30-Notebook Managed Charging Cart HP Pocket Whiteboard

HP Keyed Cable Lock HP Docking Station Cable Lock

H2P63AA#xxx

H2P64AA#xxx

H2P65AA#xxx

A7E32AA#xxx A7E36AA#xxx

BT796AA#xxx

Part #

XW576AA

AW662AA AW661AA AW664AA

H2L63AA

A2U57AA

LX733AA

QK642AA QK643AA QK639AA QK640AA

QL489AA QL488AA QL490AA A0X37AA

BV411AA AU656AA

DA - 14304 North America — Version 16 — June 6, 2013

Page 46

HP EliteBook 8470p Notebook PC

QuickSpecs

HP EliteBook 8570p Notebook PC

Options and Accessories (sold separately and availability may vary by country)

All rights reserved. All trademarks are the property of their respective owners. Intel, Core, and vPro are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 14304 North America — Version 16 — June 6, 2013

Page 47

HP 8570p User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Technical Specifications

Options and Accessories (sold separately and availability may vary by country)
