HP 6735B User Manual

HP Compaq 6735b Notebook PC and HP Compaq 6730b Notebook PC

Maintenance and Service Guide

AMD Athlon, AMD Sempron, and AMD Turion are trademarks of Advanced Micro Devices, Inc. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Core are trademarks of Intel Corporation in the U.S. and other countries. Microsoft, Windows, and Windows Vista are U.S. registered trademarks of Microsoft Corporation. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: July 2008

Document Part Number: 463946-001

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description

2 External component identification

Top components ................................................................................................................................... 9

Top components .................................................................................................................. 9

Buttons, switches, and fingerprint reader .......................................................................... 10

Keys ................................................................................................................................... 12

TouchPad .......................................................................................................................... 13

Front components .............................................................................................................................. 14

Right-side components ....................................................................................................................... 15

Left-side components ......................................................................................................................... 16

Rear components ............................................................................................................................... 17

Bottom components ........................................................................................................................... 18

3 Illustrated parts catalog

Service tag ......................................................................................................................................... 19

Computer major components ............................................................................................................. 20

Plastics Kit .......................................................................................................................................... 27

Cable Kit ............................................................................................................................................. 28

Mass storage devices ......................................................................................................................... 29

Miscellaneous parts ............................................................................................................................ 30

Sequential part number listing ............................................................................................................ 31

4 Removal and replacement procedures

Preliminary replacement requirements ............................................................................................... 38

Tools required .................................................................................................................... 38

Service considerations ....................................................................................................... 38

Plastic parts ....................................................................................................... 38

Cables and connectors ..................................................................................... 39

Drive handling ................................................................................................... 39

Grounding guidelines ......................................................................................................... 40

Electrostatic discharge damage ........................................................................ 40

Packaging and transporting guidelines ............................................. 41

Workstation guidelines ..................................................................... 41

Equipment guidelines ....................................................................... 42

Unknown user password ................................................................................................... 43

Component replacement procedures ................................................................................................. 44

Service tag ......................................................................................................................... 44

Computer feet .................................................................................................................... 45

Battery ............................................................................................................................... 46

SIM .................................................................................................................................... 47

Display inverter .................................................................................................................. 48

Bluetooth module ............................................................................................................... 50

Hard drive .......................................................................................................................... 52

RTC battery ....................................................................................................................... 54

Optical drive ....................................................................................................................... 55

Expansion memory module ............................................................................................... 56

WLAN module .................................................................................................................... 58

Keyboard ........................................................................................................................... 60

Primary memory module .................................................................................................... 63

WWAN module .................................................................................................................. 64

Switch cover ...................................................................................................................... 65

Power button board ........................................................................................................... 66

Fan ..................................................................................................................................... 67

Heat sink ............................................................................................................................ 68

Processor ........................................................................................................................... 72

Display assembly ............................................................................................................... 74

Top cover ........................................................................................................................... 80

TouchPad assembly .......................................................................................................... 82

ExpressCard board ............................................................................................................ 83

Audio board ....................................................................................................................... 84

Modem module .................................................................................................................. 86

Speaker ............................................................................................................................. 87

USB/digital media board .................................................................................................... 89

Bluetooth module cable ..................................................................................................... 90

Rear cover ......................................................................................................................... 91

SIM connector board ......................................................................................................... 93

Modem module cable ........................................................................................................ 94

Serial connector and cable ................................................................................................ 95

System board ..................................................................................................................... 96

Optical drive connector board .......................................................................................... 100

5 Computer Setup

Starting Computer Setup .................................................................................................................. 102

Using Computer Setup ..................................................................................................................... 102

Navigating and selecting in Computer Setup ................................................................... 102

Restoring factory settings in Computer Setup ................................................................. 103

Computer Setup Menus ................................................................................................................... 104

6 Specifications

Computer specifications ................................................................................................................... 108

15.4-inch, WSXGA display specifications ........................................................................................ 109

15.4-inch, WXGA display specifications ........................................................................................... 110

Hard drive specifications .................................................................................................................. 111

DVD±RW and CD-RW Double-Layer Combo Drive specifications .................................................. 112

DVD/CD-RW Combo Drive specifications ........................................................................................ 113

DVD-ROM Drive ............................................................................................................................... 114

System DMA specifications .............................................................................................................. 115

System interrupt specifications ......................................................................................................... 116

System I/O address specifications ................................................................................................... 117

System memory map specifications ................................................................................................. 119

File menu ......................................................................................................................... 104

Security menu .................................................................................................................. 104

Diagnostics menu ............................................................................................................ 105

System Configuration menu ............................................................................................ 105

7 Screw listing

Phillips PM2.0×5.0 captive screw ..................................................................................................... 121

Phillips PM2.5×10.0 captive screw ................................................................................................... 122

Phillips PM3.0×4.0 screw ................................................................................................................. 123

Phillips PM2.5×9.0 captive screw ..................................................................................................... 124

Phillips PM2.0×3.0 screw ................................................................................................................. 125

Phillips PM2.5×4.0 screw ................................................................................................................. 126

Phillips PM2.0×5.0 screw ................................................................................................................. 127

Phillips PM2.5×7.0 captive screw ..................................................................................................... 128

Phillips PM2.0×4.0 captive screw ..................................................................................................... 129

Torx8 T8M2.5×9.0 screw ................................................................................................................. 130

Torx8 T8M2.5×4.0 screw ................................................................................................................. 132

Phillips PM2.5×3.0 screw ................................................................................................................. 133

Phillips PM2.5×3.0 broad-head screw .............................................................................................. 134

Phillips PM2.5×5.0 screw ................................................................................................................. 136

Hex HM5.0×9.0 screw lock .............................................................................................................. 139

Torx8 T8M2.5×6.0 screw ................................................................................................................. 140

8 Backup and recovery

Overview .......................................................................................................................................... 141

Backing up ........................................................................................................................................ 142

Backup tips ...................................................................................................................... 142

Backing up your information ............................................................................................ 142

Performing a recovery ...................................................................................................................... 143

vii

Recovering the hard drive using f11 ................................................................................................. 143

Recovering information using a Windows Vista operating system DVD (purchased

separately) ........................................................................................................................................ 144

9 Connector pin assignments

1394 ................................................................................................................................................. 145

Audio-in (microphone) ...................................................................................................................... 146

Audio-out (headphone) ..................................................................................................................... 146

External monitor ............................................................................................................................... 147

RJ-11 (modem) ................................................................................................................................ 148

RJ-45 (network) ................................................................................................................................ 149

S-Video-out ...................................................................................................................................... 150

Serial port ......................................................................................................................................... 151

Universal Serial Bus ......................................................................................................................... 151

10 Power cord set requirements

Requirements for all countries and regions ...................................................................................... 152

Requirements for specific countries and regions ............................................................................. 153

11 Recycling

Battery .............................................................................................................................................. 154

Display .............................................................................................................................................. 154

Index ................................................................................................................................................................. 160

viii

1 Product description

Category Description HP Compaq

6730b Notebook PC with WWAN

Product Name HP Compaq 6730b

HP Compaq 6735b

Processors

Notebook PC

Intel® Core™ 2 Duo

●

T9600 2.80-GHz processor, 35W, 6MB L2 cache, 800MHz front side bus (FSB)

Intel Core 2 Duo

●

P9500 2.53-GHz processor, 25W, 6MB L2 cache, 800MHz FSB

Intel Core 2 Duo

●

T9400 2.53-GHz processor, 35W, 3MB L2 cache, 800MHz FSB

√ √

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Intel Core 2 Duo

●

P8600 2.40-GHz processor, 25W, 3MB L2 cache, 800MHz FSB

Intel Core 2 Duo

●

P8400 2.26-GHz processor, 25W, 3MB L2 cache, 800MHz FSB

AMD Turion™ X2

●

Ultra Dual Core ZM-86 2.40-GHz processor, 35W, 2MB L2 cache

AMD Turion X2 Ultra

●

Dual Core ZM-82

2.20-GHz processor, 35W, 2-MB L2 cache

√ √

√√

Category Description HP Compaq

6730b Notebook PC with WWAN

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Chipset

Graphics Mobile Intel® Graphics

AMD Turion X2 Ultra

●

Dual Core ZM-80

2.10-GHz processor, 35W 2-MB L2 cache

AMD Turion X2 Dual

●

Core RM-70 2.00GHz processor, 35W, 1-MB L2 cache

AMD Athlon™ X2

●

QL-60 1.90-GHz processor, 35W, 1MB L2 cache

AMD Sempron™

●

SI-40 2.00-GHz processor, 25W, 512-KB L2 cache

Northbridge: GE45

●

Southbridge: ICH9M

●

Northbridge: M780G

●

Southbridge: SB700

●

Media Accelerator 4500MHD

√ √

Intel Universal Memory

Architecture (UMA) graphics subsystem integrated with shared video memory (dynamically allocated)

ATI Radeon HD 3200

UMA graphics subsystem

Panels All display assemblies

Memory 2 customer-accessible/

Graphics

integrated with shared video memory (dynamically allocated)

include 2 wireless local area network (WLAN) antennae

15.4-inch WXGA

●

BrightView

15.4-inch WXGA+

●

15.4-inch WXGA

●

upgradable memory module slots

√ √

√ √ √ √

√√√√

2 Chapter 1 Product description

Category Description HP Compaq

6730b Notebook PC with WWAN

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Supports dual-channel

memory

Supports up to 4 GB of

system RAM

PC2-6400, 800-MHz,

DDR2

Supports the following

configurations:

8192-MB total

●

system memory (4096 × 2, dualchannel)

4096-MB total

●

system memory (4096 × 1)

4096-MB total

●

system memory (2048 × 2, dualchannel)

3072-MB total

●

system memory (2048 + 1024, dualchannel)

√ √ √ √

2560-MB total

●

system memory (2048 + 512, dualchannel)

2048-MB total

●

system memory (2048 × 1)

2048-MB total

●

system memory (1024 × 2, dualchannel)

1536-MB total

●

system memory (1024 + 512, dualchannel)

1024-MB total

●

system memory (1024 × 1)

Hard drives Supports 9.5-mm, 2.5-

inch hard drives

Customer-accessible √ √ √ √

Serial ATA √√√√

√ √ √ √

Category Description HP Compaq

6730b Notebook PC with WWAN

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Supports the following

drives:

250-GB, 5400-rpm

●

160-GB, 5400-rpm

●

120-GB, 7200-rpm

●

120-GB, 5400-rpm

●

Optical drives Fixed (loosening of 1

Customer-accessible √ √ √ √

Parallel ATA √ √ √ √

12.7-mm tray load √ √ √ √

Supports the following

screw required)

drives:

DVD±RW and CD-

●

RW SuperMulti Double-Layer Combo Drive with LightScribe

DVD/CD-RW

●

Combo Drive

√ √ √ √

DVD-ROM Drive

●

Diskette drive Supports external USB

diskette drive only

Supports boot from

external USB diskette drive

Supports 3-mode diskette

drive

Audio High-definition audio

1984A - HD

Integrated stereo

microphone

Integrated dual array

microphone with camera only

Integrated VGA camera √ √ √ √

Stereo speakers (2) √ √ √ √

Modem No-modem option

available in Japan only

√ √ √ √

√√√√

4 Chapter 1 Product description

Category Description HP Compaq

6730b Notebook PC with WWAN

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

56K V.92 1.5-inch data/

fax modem with digital line guard

Ethernet Low-cost 10/100/1000

Ethernet network interface card (NIC)

NIC Power Down

Technology

S4/S5 wake on local area

Power Down Technology

Wireless Integrated WLAN options by way of wireless module:

Intel 802.11a/b/g/n (not

Intel 802.11a/b/g √ √

Intel 802.11b/g √ √

network (LAN) on AC power

S4/S5 wake on LAN (on/ AC)

Support for no WLAN option

available with Linux operating system)

√ √ √ √

√

Integrated WLAN options by way of wireless module:

Subscriber identity

Integrated personal area network (PAN) options by way of Bluetooth® module:

Broadcom Bluetooth 2.0

External media card

Media Card Reader

Wireless wide area network (WWAN) module

module (SIM) useraccessible inside the battery bay

No-WPAN option available

+EDR

One ExpressCard/54 slot √ √ √ √

supporting Memory Stick, Memory Stick Pro, MultiMediaCard, MultiMediaCard Plus, Secure Digital (SD) Memory Card, SD High Capacity Memory Card, xD-Picture Card, xD-

√

√ √

√√√√

Category Description HP Compaq

6730b Notebook PC with WWAN

Picture Card Type H, and xD-Picture Card Type M

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Ports

Audio-in (stereo

●

microphone)

Audio-out (stereo

●

headphone)

Docking

●

RJ-11 (modem)

●

RJ-45 (Ethernet,

●

includes link and activity lights)

Serial

●

S-Video-out (7 pin)

●

Travel battery

●

USB (4)

●

VGA (Dsub 15-pin)

●

supporting 1600 × 1200 external resolution at 75-GHz (hot plug/unplug with auto-detect)

1394a

●

√ √ √ √

3-pin HP Smart AC

●

Adapter

Docking Support for HP 3-in-1 NAS

Keyboard/ pointing devices

TouchPad only, with 2

Touch-sensitive controls √ √ √ √

Spill-resistant √ √ √ √

Power requirements

Docking Station, HP Advanced Docking Station, and HP Docking Station

31.20-mm (12.28-inch) keyboard with embedded numeric keypad

TouchPad buttons and vertical scrolling (taps enabled as default)

90-W HP Smart AC Adapter with localized cable plug support (2-wire plug with ground pin, supports 2-pin DC

√ √ √ √

√√√√

6 Chapter 1 Product description

Category Description HP Compaq

6730b Notebook PC with WWAN

connector) and HP Fast Charge Technology

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

6-cell, 55-Wh Li-ion battery

6-cell, 47-Wh Li-ion

battery

Support for 8-cell Li-ion

Extended Life Battery and 12-cell Ultra Capacity Battery

Security Supports Kensington

security lock

Trusted platform module

(TPM) v. 1.2

Enhanced Drive Lock √ √ √ √

Fingerprint reader √ √ √ √

Integrated smart card

reader

Operating system

Preinstalled:

Windows Vista® 32

●

Home Basic

Windows Vista

●

Business 32

√ √ √ √

Windows Vista

●

Business 32 (with Windows® XP Pro images)

FreeDOS

●

Red Flag Linux

●

Restore media:

Windows Vista 32

●

Home Basic

Windows Vista

●

Business 32

Windows Vista

●

Business 64

Windows Vista

●

Ultimate

Windows XP Pro,

●

Service Pack 2

√√√√

Category Description HP Compaq

6730b Notebook PC with WWAN

Windows Vista

●

(DRDVD)

Windows XP Pro

●

(DRDVD)

HP Compaq 6730b Notebook PC without WWAN

HP Compaq 6735b Notebook PC with WWAN

HP Compaq 6735b Notebook PC without WWAN

Certified:

Microsoft WHQL

●

SuSE Linux

●

Web support:

Windows XP Pro

●

Windows Vista

●

Enterprise

Serviceability End-user replaceable

parts:

AC adapter

●

Battery (system)

●

Hard drive

●

Memory modules

●

(expansion and primary)

Optical drive

●

SIM

●

WLAN module

●

√ √ √ √

√√√√

WWAN module

●

8 Chapter 1 Product description

2 External component identification

Top components

Item Component Function

(1) WLAN antenna locations Send and receive signals from one or more WLAN devices.

These antennae are not visible from the outside of the computer.

(2) Internal microphones (2) (select models only) Record sound.

NOTE: Some models have one internal microphone.

(3) WWAN antenna locations (select models only) Send and receive signals from one or more WWAN devices.

These antennae are not visible from the outside of the computer.

Top components 9

Item Component Function

(4) Webcam light (select models only) On: The integrated camera is in use.

(5) HP Webcam (select models only) Records audio and video and captures still photographs.

Buttons, switches, and fingerprint reader

Item Component Function

(1) Power button

(2) Internal display switch Turns off the display if the display is closed while the power is

When the computer is off, press the button to turn on the

●

computer.

When the computer is on, press the button to initiate

●

Hibernation.

When the computer is in Hibernation, press the button

●

briefly to exit Hibernation.

When the computer is in the Sleep state, press the button

●

briefly to exit Sleep.

If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button for at least 5 seconds to turn off the computer.

To learn more about your power settings, select Start >

Control Panel > System and Maintenance > Power Options.

on.

10 Chapter 2 External component identification

Item Component Function

(3) Info button Launches Info Center, which provides shortcuts, such as the

following:

HP 3D DriveGuard—Controls settings for software that

●

protects the hard drive by parking the drive when the computer is dropped or moved.

HP Software Setup—Installs preloaded applications to

●

make them accessible to the user.

HP Wireless Assistant—Turns wireless devices on or

●

off.

NOTE: If a wireless device is disabled in Computer

Setup, it must first be reenabled in Computer Setup before it can be turned on or off using Wireless Assistant.

System Information—Describes the memory, processor

●

speed, BIOS (basic input-output system) and other essential information about your computer system.

NOTE: Click the Advanced button to see more

information about your system.

User Guides—Provide specific details about the

●

computer, including your components, power, drives, multimedia, security, and wireless features.

NOTE: After you configure QuickLook 2, you can open this

feature by pressing the info button when the computer is off or in Hibernation.

(4) Presentation button Opens the Presentation Options window, where you can start

a frequently used presentation, file, program, or Web site. You can also adjust display settings for optimum viewing.

(5) Wireless button Turns the wireless feature on or off but does not establish a

(6) Volume mute button Mutes and restores speaker sound.

(7) Volume scroll zone Adjusts speaker volume. Slide your finger to the left to decrease

(8) Fingerprint reader (select models only) Allows a fingerprint logon to Windows, instead of a password

wireless connection.

NOTE: You must set up or access a wireless network to

establish a wireless connection.

volume and to the right to increase volume. You can also press and hold the minus (-) sign to decrease volume, or press and hold the plus (+) sign to increase volume.

logon.

Top components 11

Keys

Item Component Function

(1) esc key Displays system information when pressed in combination with

the fn key.

(2) fn key Executes frequently used system functions when pressed in

(3) Windows logo key Displays the Windows Start menu.

(4) Windows applications key Displays a shortcut menu for items beneath the pointer.

(5) Embedded numeric keypad keys Can be used like the keys on an external numeric keypad.

(6) Function keys Execute frequently used system functions when pressed in

combination with a function key or the esc key.

combination with the fn key.

12 Chapter 2 External component identification

TouchPad

Item Component Function

(1) TouchPad* Moves the pointer and selects or activates items on the screen.

(2) Left TouchPad button* Functions like the left button on an external mouse.

(3) Fingerprint reader (select models only) Allows a fingerprint logon to Windows, instead of a password

logon.

(4) Right TouchPad button* Functions like the right button on an external mouse.

(5) TouchPad scroll zone Functions like the right button on an external mouse.

*This table describes factory settings. To view or change pointing device preferences, select Start > Control Panel > Hardware and Sound > Mouse.

Top components 13

Front components

Item Component Function

(1) Wireless light

(2) Power light

(3) Battery light

(4) Drive light

Blue: An integrated wireless device, such as a wireless

●

local area network (WLAN) device, an HP Broadband Wireless Module, and/or a Bluetooth device, is on.

Amber: All wireless devices are off.

●

On: The computer is on.

●

Blinking: The computer is in the Sleep state.

●

Blinking rapidly: An AC adapter with a higher power rating

●

should be connected.

Off: The computer is off or in Hibernation.

●

Amber: A battery is charging.

●

Turquoise: A battery is close to full charge capacity.

●

Blinking amber: A battery that is the only available power

●

source has reached a low battery level. When the battery reaches a critical battery level, the battery light begins blinking rapidly.

Off: If the computer is plugged into an external power

●

source, the light turns off when all batteries in the computer are fully charged. If the computer is not plugged into an external power source, the light stays off until the battery reaches a low battery level.

Blinking: The hard drive or optical drive is being accessed.

●

(5) Display release latch Opens the computer.

(6) Speakers (2) Produce sound.

(7) Audio-out (headphone) jack Produces sound when connected to optional powered stereo

(8) Audio-in (microphone) jack Connects an optional computer headset microphone, stereo

14 Chapter 2 External component identification

Amber (select models only): HP 3D DriveGuard has

●

temporarily parked the hard drive.

speakers, headphones, ear buds, a headset, or television audio.

NOTE: When a device is connected to the headphone jack,

the computer speakers are disabled.

array microphone, or monaural microphone.

Right-side components

NOTE: Refer to the illustration that most closely matches your computer.

Item Component Function

(1) Media Card Reader (select models only) Supports the following optional digital card formats:

Memory Stick

●

Memory Stick Pro

●

MultiMediaCard

●

MultiMediaCard Plus

●

Secure Digital Memory Card

●

Secure Digital High Capacity Memory Card

●

xD-Picture Card

●

xD-Picture Card Type H

●

xD-Picture Card Type M

●

(2) USB ports (2) (select models only) Connect optional USB devices.

(3) Optical drive Reads an optical disc.

(4) Serial port Connects an optional device, such as a modem, mouse, or

Item Component Function

printer.

(1) Media Card Reader (select models only) Supports the following optional digital card formats:

Memory Stick

●

Memory Stick Pro

●

Right-side components 15

Item Component Function

MultiMediaCard

●

MultiMediaCard Plus

●

Secure Digital Memory Card

●

Secure Digital High Capacity Memory Card

●

xD-Picture Card

●

xD-Picture Card Type H

●

xD-Picture Card Type M

●

(2) USB ports (2) (select models only) Connect optional USB devices.

(3) Optical drive Connect optional USB devices.

(4) RJ-11 (modem) jack Connects a modem cable.

(5) Security cable slot Attaches an optional security cable to the computer.

NOTE: The security cable is designed to act as a deterrent,

but it may not prevent the computer from being mishandled or stolen.

Left-side components

Item Component Function

(1) Power connector Connects an AC adapter.

(2) Vent Enables airflow to cool internal components.

(3) USB ports (2) Connect optional USB devices.

(4) 1394 port (select models only) Connects an optional IEEE 1394 or 1394a device, such as a

(5) ExpressCard slot Supports optional ExpressCards.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

camcorder.

16 Chapter 2 External component identification

Rear components

NOTE: Refer to the illustration that most closely matches your computer.

Item Component Function

(1) Security cable slot Attaches an optional security cable to the computer.

(2) RJ-11 (modem) jack Connects a modem cable.

(3) RJ-45 (network) jack Connects a network cable.

(4) External monitor port Connects an external VGA monitor or projector.

(5) S-Video-out jack Connects an optional S-Video device such as a television,

NOTE: The security cable is designed to act as a deterrent,

but it may not prevent the computer from being mishandled or stolen.

VCR, camcorder, overhead projector, or video capture card.

Item Component Function

(1) RJ-45 (network) jack Connects a network cable.

(2) External monitor port Connects an external VGA monitor or projector.

(3) S-Video-out jack Connects an optional S-Video device such as a television,

VCR, camcorder, overhead projector, or video capture card.

Rear components 17

Bottom components

Item Component Function

(1) Battery bay Holds the battery.

(2) Battery release latch Releases the battery from the battery bay.

(3) SIM slot (select models only) Contains a WWAN SIM. The SIM slot is located inside the

battery bay.

(4) Accessory battery connector Connects an optional accessory battery.

(5) Vents (5) Enable airflow to cool internal components.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

(6) Expansion memory module compartment Contains the expansion memory module slot and the WLAN

module.

CAUTION: To prevent an unresponsive system, replace the

wireless module only with a wireless module authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region. If you replace the module and then receive a warning message, remove the module to restore computer functionality, and then contact technical support through Help and Support.

(7) Bluetooth module compartment (select models

only)

(8) Hard drive bay Holds the hard drive.

(9) Docking connector (select models only) Connects an optional docking device.

Contains a Bluetooth device.

18 Chapter 2 External component identification

3 Illustrated parts catalog

Service tag

The service tag, affixed to the bottom of the computer, provides information that may be needed when troubleshooting system problems. The service tag provides the following information:

(1) Product name: This is the product name affixed to the front of the computer.

(2) Serial number (s/n): This is an alphanumeric identifier that is unique to each product.

(3) Part number/Product number (p/n): This number provides specific information about the product's

hardware components. The part number helps a service technician to determine what components and parts are needed.

(4) Model description: This is the number used to locate documents, drivers, and support for the computer.

(5) Warranty period: Describes the duration of the warranty period for the computer.

When ordering parts or requesting information, provide the computer serial number and model description provided on the service tag.

Service tag 19

Computer major components

Item Description Spare part number

(1) 15.4-inch display assemblies (include 2 WLAN antenna transceivers and cables)

20 Chapter 3 Illustrated parts catalog

Item Description Spare part number

For use only with HP Compaq 6735b computer models equipped with both WLAN and WWAN modules:

For use only with HP Compaq 6735b computer models equipped with a WLAN module but not a WWAN

For use only with HP Compaq 6730b computer models equipped with both WLAN and WWAN modules:

SXGA+ display assembly with 2 microphones and webcam

●

SXGA+ display assembly with 1 microphone

●

WXGA BrightView display assembly with 2 microphones and webcam

●

WXGA BrightView display assembly with 1 microphone

●

WXGA display assembly with 2 microphones and webcam

●

WXGA display assembly with 1 microphone

●

module:

SXGA+ display assembly with 2 microphones and webcam

●

SXGA+ display assembly with 1 microphone

●

WXGA Brightview display assembly with 2 microphones and webcam

●

WXGA BrightView display assembly with 1 microphone

●

WXGA display assembly with 2 microphones and webcam

●

WXGA display assembly with 1 microphone

●

SXGA+ display assembly with 2 microphones and webcam

●

SXGA+ display assembly with 1 microphone

●

492177-001

492178-001

492181-001

492182-001

492173-001

492174-001

492179-001

492180-001

492183-001

492184-001

492175-001

492176-001

487126-001

487127-001

For use only with HP Compaq 6730b computer models equipped with a WLAN module but not a WWAN

Display internal components (not illustrated):

Display bezels:

For use only with computer models not equipped with a webcam 487338-001

Display hinge covers (includes left and right hinge covers) 487144-001

WXGA BrightView display assembly with 2 microphones and webcam

●

WXGA BrightView display assembly with 1 microphone

●

WXGA display assembly with 2 microphones and webcam

●

WXGA display assembly with 1 microphone

●

module:

SXGA+ display assembly with 2 microphones and webcam

●

SXGA+ display assembly with 1 microphone

●

WXGA BrightView display assembly with 2 microphones and webcam

●

WXGA BrightView display assembly with 1 microphone

●

WXGA display assembly with 2 microphones and webcam

●

WXGA display assembly with 1 microphone

●

For use only with computer models equipped with a webcam 487336-001

487130-001

487131-001

487122-001

487123-001

487128-001

487129-001

487132-001

487133-001

487124-001

487125-001

Computer major components 21

Item Description Spare part number

Display hinges 487337-001

Display inverters:

For use only with HP Compaq 6730b computer models 486773-001

Display panel cable 488021-001

Display Logo Kit 486290-001

Display Rubber Kit 486775-001

Display Screw Kit 487751-001

(2) Switch cover (includes LED board and cable) 487139-001

(3) Power button board (includes cable) 487118-001

(4) Keyboards (include keyboard)

For use in Brazil 487136-201

For use in the Czech Republic 487136-221

For use in Denmark 487136-081

For use in France 487136-051

For use in French Canada 487136-121

For use in Germany 487136-041

For use only with HP Compaq 6735b computer models 495086-001

For use in Belgium 487136-181

For use in Greece 487136-DJ1

For use in Hungary 487136-211

For use in Iceland 487136-DD1

For use in Israel 487136-BB1

For use in Italy 487136-061

For use in Japan 487136-291

For use in Latin America 487136-161

For use in the Netherlands 487136-B31

For use in Norway 487136-091

For use in Portugal 487136-131

For use in Russia 487136-251

For use in Saudi Arabia 487136-171

For use in Slovakia 487136-231

For use in Slovenia 487136-BA1

For use in South Korea 487136-AD1

For use in Spain 487136-071

22 Chapter 3 Illustrated parts catalog

Item Description Spare part number

For use in Sweden and Finland 487136-B71

For use in Switzerland 487136-BG1

For use in Taiwan 487136-AB1

For use in Thailand 487136-281

For use in Turkey 487136-141

For use in the United Kingdom 487136-031

For use in the United States 487136-001

Memory modules (PC2-6400, 667-MHz, DDR2)

(5a) Primary memory module (located under keyboard)

(5b) Expansion memory module (located under memory/WLAN module compartment cover)

1024-MB 483193-001

Plastics Kit (see Plastics Kit on page 27 for more Plastics Kit spare part

(6a) ExpressCard slot bezel

(6b) Hard drive bay cover

(6c) Memory/WLAN module compartment cover

(6d) Bluetooth module compartment cover

(7) TouchPad assemblies (include the components listed below):

Fingerprint reader board and cable (included only in spare part kit 487134-001)

TouchPad board and cable

TouchPad board bracket

For use only with computer models not equipped with a fingerprint reader 487135-001

Cable Kit (see Cable Kit on page 28 for more Cable Kit spare part information): 487138-001

(8a) Microphone extension cable

2048-MB 483194-001

486292-001

information):

For use only with computer models equipped with a fingerprint reader (includes a fingerprint reader board and cable)

487134-001

(8b) Modem module cable

(8c) Serial connector and cable

(8d) Bluetooth module cable

(9)

(10) Heat sinks (include heat sink clip and replacement thermal material)

For use only with HP Compaq 6730b computer models 486289-001

(11) Processors (include replacement thermal material)

Fan 486288-001

For use only with HP Compaq 6735b computer models 488315-001

Computer major components 23

Item Description Spare part number

AMD processors for use only with HP Compaq 6735b computer models:

Intel Core 2 Duo processors for use only with HP Compaq 6730b computer models:

(12) HSDPA EVDO WWAN module 483377-001

(13) Top cover 487140-001

(14) Rear cover 487143-001

(15) ExpressCard board (includes RTC battery) 487119-001

(16) Audio board (includes cable) 486250-001

Turion 64 ZM-86 2.40-GHz processor

●

Turion 64 ZM-82 2.20-GHz processor

●

Turion 64 ZM-80 2.10-GHz processor

●

Turion 64 RM-70 2.00-GHz processor

●

Sempron SI-40 2.00-GHz processor

●

Athlon QL-60 1.90-GHz processor

●

T9600 2.80-GHz (6-MB L2 cache, 800-MHz FSB)

●

T9400 2.53-GHz (6-MB L2 cache, 800-MHz FSB)

●

T8600 2.40-GHz (3-MB L2 cache, 800-MHz FSB)

●

T8400 2.26-GHz (3-MB L2 cache, 800-MHz FSB)

●

488198-001

488196-001

488195-001

488199-001

488197-001

488200-001

486257-001

486256-001

486255-001

486254-001

(17) Modem modules:

NOTE: The modem module spare part kits do not include a modem module cable. The modem module cable is

included in the Cable Kit, spare part number 487138-001.

For use only in Australia and New Zealand 491575-011

(18) USB/digital media board (includes cable) 486249-001

(19) SIM connector board 486252-001

(20) Speaker 487137-001

(21) System board bracket 486291-001

(22) System boards (include replacement thermal material)

For use only with HP Compaq 6735b computer models equipped with a WLAN module

For use only with HP Compaq 6730b computer models equipped with both WLAN and

For use only with HP Compaq 6730b computer models equipped with a WLAN module

For use in all countries and regions except Australia and New Zealand 491575-001

For use only with HP Compaq 6735b computer models equipped with both WLAN and WWAN modules

but not a WWAN module

WWAN modules

but not a WWAN module

488193-001

488194-001

486247-001

486248-001

(23) Optical drive connector board 487121-001

24 Chapter 3 Illustrated parts catalog

Item Description Spare part number

(24) Base enclosures

For use only with computer models equipped with a WLAN module but not a WWAN

Rubber Kit (not illustrated, includes 8 rubber feet and 2 rubber screw covers) 487145-001

(25) Batteries

6-cell, 47-Wh 486295-001

(26) Optical drives (include bezel and bracket)

DVD/CD-RW Combo Drive 486263-001

DVD-ROM Drive 486264-001

(27) RTC battery 449137-001

(28) Hard drives: (include hard drive bracket)

160-GB, 5400-rpm 486260-001

120-GB, 7200-rpm 486259-001

120-GB, 5400-rpm 486782-001

For use only with computer models equipped with both WLAN and WWAN modules 487142-001

487141-001

module

6-cell, 55-Wh 486296-001

DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive 486262-001

250-GB, 5400-rpm 486261-001

(29) WLAN modules

Broadcom WLAN modules for use only with HP Compaq 6735b computer models:

Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda,

●

Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

Broadcom 4322 802.11a/b/g/n WLAN module for use in Afghanistan, Albania,

●

Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles,

487330-001

487330-002

Computer major components 25

Item Description Spare part number

Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

Broadcom BCM4312 802.11b/g WLAN module for use in Antigua and Barbuda,

●

Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

Broadcom BCM4312 802.11b/g WLAN module for use in Afghanistan, Albania,

●

490811-001

490811-002

Intel WLAN modules for use only with HP Compaq 6730b computer models:

Intel Wi-Fi Link 5100 802.11a/b/g WLAN module for use in all countries and

(30) Bluetooth module (does not include Bluetooth module cable)

Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module for use in all countries and regions

regions

NOTE: The Bluetooth module spare part kit does not include a Bluetooth module

cable. The Bluetooth module cable is included in the Cable Kit, spare part number 487138-001

26 Chapter 3 Illustrated parts catalog

480985-001

482957-001

490809-001

Plastics Kit

Item Description Spare part number

Plastics Kit: 486292-001

(1) ExpressCard slot bezel

(2) Hard drive bay cover (includes 2 captive screws, secured by C-clips)

(3) Memory/WLAN module compartment cover (includes one captive screw, secured by a C-clip)

(4) Bluetooth module compartment cover (includes one captive screw, secured by a C-clip)

Plastics Kit 27

Cable Kit

Item Description Spare part number

Cable Kit: 487138-001

(1) Microphone extension cable, illustrated

(2) Modem module cable (includes RJ-11 connector)

(3) Bluetooth module cable

(4) Serial connector and cable

28 Chapter 3 Illustrated parts catalog

Mass storage devices

Item Description Spare part number

(1) Hard drives (include bracket)

160-GB, 5400-rpm 486260-001

120-GB, 7200-rpm 486259-001

120-GB, 5400-rpm 486782-001

(2) Optical drives (include bezel and bracket)

DVD/CD-RW Combo Drive 486263-001

DVD-ROM Drive 486264-001

250-GB, 5400-rpm 486261-001

DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive 486262-001

Mass storage devices 29

Miscellaneous parts

Description Spare part number

90-W HP Smart AC adapters

For use in all countries and regions except India

For use only in India 463956-001

Nylon carrying case 325814-001

USB 1.1 diskette drive 359118-001

Power cords:

For use in Australia

For use in Brazil 246959-201

For use in Denmark 246959-081

For use in Europe, the Middle East, and Africa 246959-021

For use in Israel 246959-BB1

For use in Italy 246959-061

For use in Japan 246959-291

For use in South Korea 246959-AD1

For use in Switzerland 246959-AG1

For use in the United Kingdom 246959-031

For use the United States 246959-001

463955-001

246959-011

Screw Kit

Hex HM5.0×9.0 screw lock

●

Phillips PM3.0×4.0 screw

●

Phillips PM2.5×10.0 captive screw

●

Phillips PM2.5×9.0 captive screw

●

Phillips PM2.5×7.0 captive screw

●

Phillips PM2.5×5.0 screw

●

Phillips PM2.5×4.0 screw

●

Phillips PM2.5×3.0 screw

●

Phillips PM2.5×3.0 broad-head screw

●

Phillips PM2.0×5.0 screw

●

Phillips PM2.0×5.0 captive screw

●

Phillips PM2.0×4.0 captive screw

●

Phillips PM2.0×3.0 screw

●

Torx T8M2.5×9.0 screw

●

487146-001

30 Chapter 3 Illustrated parts catalog

Description Spare part number

Torx T8M2.5×6.0 screw

●

Torx T8M2.5×4.0 screw

●

Sequential part number listing

Spare part number

246959-001 Power cord for use in the United States

246959-011 Power cord for use in Australia and New Zealand

246959-021 Power cord for use in Europe, the Middle East, and Africa

246959-031 Power cord for use in the United Kingdom

246959-061 Power cord for use in Italy

246959-081 Power cord for use in Denmark

246959-201 Power cord for use in Brazil

246959-291 Power cord for use in Japan

246959-AD1 Power cord for use in South Korea

246959-AG1 Power cord for use in Switzerland

246959-BB1 Power cord for use in Israel

449137-001 RTC battery

463955-001 90-W HP Smart AC adapter for use in all countries and regions except India

463956-001 90-W HP Smart AC adapter for use only in India

480985-001 Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module for use only with HP Compaq 6730b computer models in

Description

all countries and regions

482957-001 Intel Wi-Fi Link 5100 802.11a/b/g WLAN module for use only with HP Compaq 6730b computer models in all

483193-001 1024-MB memory module (PC2-6400, 667-MHz, DDR2)

483194-001 2048-MB memory module (PC2-6400, 667-MHz, DDR2)

483377-001 HSDPA EVDO WWAN module

486247-001 System board for use only with HP Compaq 6730b computer models equipped with both WLAN and WWAN

486248-001 System board for use only with HP Compaq 6730b computer models equipped with a WLAN module but not

486249-001 USB/digital media board (includes cable)

486250-001 Audio board (includes cable)

486252-001 SIM connector board

486254-001 Intel Core 2 Duo T8400 2.26-GHz processor for use only with HP Compaq 6730b computer models (3-MB

countries and regions

modules (includes replacement thermal material)

a WWAN module (includes replacement thermal material)

L2 cache, 800-MHz FSB, includes replacement thermal material)

Sequential part number listing 31

Spare part number

Description

486255-001 Intel Core 2 Duo T8600 2.40-GHz processor for use only with HP Compaq 6730b computer models (3-MB

486256-001 Intel Core 2 Duo T9400 2.53-GHz processor for use only with HP Compaq 6730b computer models (6-MB

486257-001 Intel Core 2 Duo T9600 2.80-GHz processor for use only with HP Compaq 6730b computer models (6-MB

486259-001 120-GB, 7200-rpm hard drive (includes hard drive bracket)

486260-001 160-GB, 5400-rpm hard drive (includes hard drive bracket)

486261-001 250-GB, 5400-rpm hard drive (includes hard drive bracket)

486262-001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive

486263-001 DVD/CD-RW Combo Drive

486264-001 DVD-ROM Drive

486288-001 Fan

486289-001 Heat sink for use only with HP Compaq 6730b computer models (includes heat sink clip and replacement

486290-001 Display Logo Kit

486291-001 System board bracket

486292-001 Plastics Kit (see Plastics Kit on page 27 for more Plastics Kit spare part information):

L2 cache, 800-MHz FSB, includes replacement thermal material)

thermal material)

486295-001 6-cell, 47-Wh battery

486296-001 6-cell, 55-Wh battery

486773-001 Display inverter for use only with HP Compaq 6730b computer models

486775-001 Display Rubber Kit

486782-001 120-GB, 5400-rpm hard drive (includes hard drive bracket)

487118-001 Power button board (includes cable)

487119-001 ExpressCard board (includes RTC battery)

487121-001 Optical drive connector board

487122-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6730b

487123-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6730b computer models

487124-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6730b

487125-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6730b computer models

487126-001 15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6730b

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

32 Chapter 3 Illustrated parts catalog

Spare part number

Description

487127-001 15.4-inch SXGA+ display assembly with 1 microphone for use only with HP Compaq 6730b computer models

487128-001 15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6730b

487129-001 15.4-inch SXGA+ display assembly with 1 microphone for use only with HP Compaq 6730b computer models

487130-001 15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only with

487131-001 15.4-inch WXGA BrightView display assembly with 1 microphone for use only with HP Compaq 6730b

487132-001 15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only with

487133-001 15.4-inch WXGA BrightView display assembly with 1 microphone for use only with HP Compaq 6730b

487134-001 TouchPad assembly for use only with computer models equipped with a fingerprint reader (includes a

487135-001 TouchPad assembly for use only with computer models not equipped with a fingerprint reader

equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

HP Compaq 6730b computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

HP Compaq 6730b computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

fingerprint reader board and cable)

487136-001 Keyboard for use in the United States

487136-031 Keyboard for use in the United Kingdom

487136-041 Keyboard for use in Germany

487136-051 Keyboard for use in France

487136-061 Keyboard for use in Italy

487136-071 Keyboard for use in Spain

487136-081 Keyboard for use in Denmark

487136-091 Keyboard for use in Norway

487136-121 Keyboard for use in French Canada

487136-131 Keyboard for use in Portugal

487136-141 Keyboard for use in Turkey

487136-161 Keyboard for use in Latin America

487136-171 Keyboard for use in Saudi Arabia

487136-181 Keyboard for use in Belgium

487136-201 Keyboard for use in Brazil

487136-211 Keyboard for use in Hungary

487136-221 Keyboard for use in the Czech Republic

487136-231 Keyboard for use in Slovakia

Sequential part number listing 33

Spare part number

487136-251 Keyboard for use in Russia

487136-281 Keyboard for use in Thailand

487136-291 Keyboard for use in Japan

487136-AB1 Keyboard for use in Taiwan

487136-AD1 Keyboard for use in South Korea

487136-B31 Keyboard for use in the Netherlands

487136-B71 Keyboard for use in Sweden and Finland

487136-BA1 Keyboard for use in Slovenia

487136-BB1 Keyboard for use in Israel

487136-BG1 Keyboard for use in Switzerland

487136-DD1 Keyboard for use in Iceland

487136-DJ1 Keyboard for use in Greece

487137-001 Speaker

487138-001 Cable Kit (see Cable Kit on page 28 for more Cable Kit spare part information):

487139-001 Switch cover (includes LED board and cable)

Description

487140-001 Top cover

487141-001 Base enclosure for use only with computer models equipped with a WLAN module but not a WWAN module

(includes 7 rubber feet)

487142-001 Base enclosure for use only with computer models equipped with both WLAN and WWAN modules (includes

7 rubber feet)

487143-001 Rear cover

487144-001 Display hinge covers (includes left and right hinge covers)

487145-001 Rubber Kit (includes 8 rubber feet and 2 rubber screw covers)

487146-001 Screw Kit

487330-001 Broadcom 4322 802.11a/b/g/n WLAN module for use only with HP Compaq 6735b computer models in

Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

447330-002 Broadcom 4322 802.11a/b/g/n WLAN module for use only with HP Compaq 6735b computer models in

Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, GuineaBissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru,

34 Chapter 3 Illustrated parts catalog

Spare part number

487336-001 Display bezel for use only with computer models equipped with a webcam

487337-001 Display hinges

487338-001 Display bezel for use only with computer models not equipped with a webcam

487751-001 Display Screw Kit

488021-001 Display panel cable

488193-001 System board for use only with HP Compaq 6735b computer models equipped with both WLAN and WWAN

Description

the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

modules (includes replacement thermal material)

488194-001 System board for use only with HP Compaq 6735b computer models equipped with a WLAN module but not

488195-001 AMD Turion 64 ZM-80 2.10-GHz processor for use only with HP Compaq 6735b computer models (includes

488196-001 AMD Turion 64 ZM-82 2.20-GHz processor for use only with HP Compaq 6735b computer models (includes

488197-001 AMD Sempron SI-40 2.00-GHz processor for use only with HP Compaq 6735b computer models (includes

488198-001 AMD Turion 64 ZM-86 2.40-GHz processor for use only with HP Compaq 6735b computer models (includes

488199-001 AMD Turion 64 RM-70 2.00-GHz processor for use only with HP Compaq 6735b computer models (includes

488200-001 AMD Athlon QL-60 1.90-GHz processor for use only with HP Compaq 6735b computer models (includes

488315-001 Heat sink for use only with HP Compaq 6735b computer models (includes heat sink clip and replacement

490809-001 Bluetooth module (does not include Bluetooth module cable)

490811-001 Broadcom BCM4312 802.11b/g WLAN module for use only with HP Compaq 6735b computer models in

a WWAN module (includes replacement thermal material)

replacement thermal material)

thermal material)

NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth

module cable is included in the Cable Kit, spare part number 487138-001

Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

490811-002 Broadcom BCM4312 802.11b/g WLAN module for use only with HP Compaq 6735b computer models in

Sequential part number listing 35

Spare part number

491575-001 Modem module for use in all countries and regions except Australia and New Zealand

491575-011 Modem module for use only in Australia and New Zealand

492173-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6735b

Description

Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

NOTE: The modem module spare part kits do not include a modem module cable. The modem module

cable is included in the Cable Kit, spare part number 487138-001.

NOTE: The modem module spare part kits do not include a modem module cable. The modem module

cable is included in the Cable Kit, spare part number 487138-001.

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

492174-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6735b computer models

equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

492175-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6735b

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

492176-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6735b computer models

equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

492177-001 15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6735b

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

492178-001 15.4-inch SXGA+ display assembly with 1 microphone for use only with HP Compaq 6735b computer models

492179-001 15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6735b

492180-001 15.4-inch SXGA+ display assembly with 1 microphone for use only with HP Compaq 6735b computer models

492181-001 15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only with

492182-001 15.4-inch WXGA BrightView display assembly with 1 microphone for use only with HP Compaq 6735b

equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

HP Compaq 6735b computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)

492183-001 15.4-inch WXGA Brightview display assembly with 2 microphones and webcam for use only with

HP Compaq 6735b computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

36 Chapter 3 Illustrated parts catalog

Spare part number

Description

492184-001 15.4-inch WXGA BrightView display assembly with 1 microphone for use only with HP Compaq 6735b

495086-001 Display inverter for use only with HP Compaq 6735b computer models

computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)

Sequential part number listing 37

4 Removal and replacement procedures

Preliminary replacement requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

Flat-bladed screwdriver

●

Magnetic screwdriver

●

Phillips P0 and P1 screwdrivers

●

Torx T8 screwdriver

●

5.0-mm nut driver

●

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

NOTE: As you remove each subassembly from the computer, place the subassembly (and all

accompanying screws) away from the work area to prevent damage.

Plastic parts

Using excessive force during disassembly and reassembly can damage plastic parts. Use care when handling the plastic parts. Apply pressure only at the points designated in the maintenance instructions.

38 Chapter 4 Removal and replacement procedures

Cables and connectors

CAUTION: When servicing the computer, be sure that cables are placed in their proper locations

during the reassembly process. Improper cable placement can damage the computer.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables tear easily.

Drive handling

CAUTION: Drives are fragile components that must be handled with care. To prevent damage to the

computer, damage to a drive, or loss of information, observe these precautions:

Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

Before handling a drive, be sure that you are discharged of static electricity. While handling a drive, avoid touching the connector.

Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be sure that the optical drive tray is closed.

Handle drives on surfaces covered with at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.

Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective packaging and label the package “FRAGILE.”

Preliminary replacement requirements 39

Grounding guidelines

Electrostatic discharge damage

Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.

An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a normal cycle. Or the device may function normally for a while, then degrade in the internal layers, reducing its life expectancy.

CAUTION: To prevent damage to the computer when you are removing or installing internal

components, observe these precautions:

Keep components in their electrostatic-safe containers until you are ready to install them.

Before touching an electronic component, discharge static electricity by using the guidelines described in this section.

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

If you remove a component, place it in an electrostatic-safe container.

The following table shows how humidity affects the electrostatic voltage levels generated by different activities.

CAUTION: A product can be degraded by as little as 700 V.

Typical electrostatic voltage levels

Relative humidity

Event 10% 40% 55%

Walking across carpet 35,000 V 15,000 V 7,500 V

Walking across vinyl floor 12,000 V 5,000 V 3,000 V

Motions of bench worker 6,000 V 800 V 400 V

Removing DIPS from plastic tube 2,000 V 700 V 400 V

Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V

Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V

Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V

Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V

40 Chapter 4 Removal and replacement procedures

Packaging and transporting guidelines

Follow these grounding guidelines when packaging and transporting equipment:

To avoid hand contact, transport products in static-safe tubes, bags, or boxes.

●

Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.

●

Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

●

Place items on a grounded surface before removing items from their containers.

●

Always be properly grounded when touching a component or assembly.

●

Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive

●

foam.

Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that

●

mechanized equipment used for moving materials is wired to ground and that proper materials are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate electric charges.

Workstation guidelines

Follow these grounding workstation guidelines:

Cover the workstation with approved static-shielding material.

●

Use a wrist strap connected to a properly grounded work surface and use properly grounded tools

●

and equipment.

Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

●

When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe

●

materials.

Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and

●

Styrofoam.

Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle

●

these items only at static-free workstations.

Avoid contact with pins, leads, or circuitry.

●

Turn off power and input signals before inserting or removing connectors or test equipment.

●

Preliminary replacement requirements 41

Equipment guidelines

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps

●

with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times. On grounded mats with banana-plug connectors, use alligator clips to connect a wrist strap.

When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps)

●

can be used at standing workstations and are compatible with most types of shoes or boots. On conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm resistance between the operator and ground. To be effective, the conductive strips must be worn in contact with the skin.

The following grounding equipment is recommended to prevent electrostatic damage:

Antistatic tape

●

Antistatic smocks, aprons, and sleeve protectors

●

Conductive bins and other assembly or soldering aids

●

Nonconductive foam

●

Conductive tabletop workstations with ground cords of one megohm resistance

●

Static-dissipative tables or floor mats with hard ties to the ground

●

Field service kits

●

Static awareness labels

●

Material-handling packages

●

Nonconductive plastic bags, tubes, or boxes

●

Metal tote boxes

●

Electrostatic voltage levels and protective materials

●

The following table lists the shielding protection provided by antistatic bags and floor mats.

Material Use Voltage protection level

Antistatic plastic Bags 1,500 V

Carbon-loaded plastic Floor mats 7,500 V

Metallized laminate Floor mats 5,000 V

42 Chapter 4 Removal and replacement procedures

Unknown user password

If the computer you are servicing has an unknown user password, follow these steps to clear the password:

NOTE: These steps also clear CMOS.

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the real-time clock (RTC) battery (see

6. Wait approximately 5 minutes.

7. Replace the RTC battery and reassemble the computer.

8. Connect AC power to the computer. Do not reinsert any batteries at this time.

9. Turn on the computer.

All passwords and all CMOS settings have been cleared.

Battery on page 46).

RTC battery on page 54).

Preliminary replacement requirements 43

Component replacement procedures

This chapter provides removal and replacement procedures.

There are as many as 96 screws and screw locks, in 16 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw and screw lock size and location during removal and replacement.

Service tag

The service tag, affixed to the bottom of the computer, provides information that may be needed when troubleshooting system problems. The service tag provides the following information:

(1) Product name: This is the product name affixed to the front of the computer.

(2) Serial number (s/n): This is an alphanumeric identifier that is unique to each product.

(3) Part number/Product number (p/n): This number provides specific information about the product's

hardware components. The part number helps a service technician to determine what components and parts are needed.

(4) Model description: This is the number used to locate documents, drivers, and support for the computer.

(5) Warranty period: Describes the duration of the warranty period for the computer.

44 Chapter 4 Removal and replacement procedures

Computer feet

The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 487145-001. There are 8 rubber feet that attach to the base enclosure in the locations illustrated below.

Component replacement procedures 45

Battery

Description Spare part number

6-cell, 55-Wh battery 486296-001

6-cell, 47-Wh battery 486295-001

Before disassembling the computer, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

Remove the battery:

1. Turn the computer upside down on a flat surface, with the battery bay toward you.

2. Slide the battery release latch (1) to release the battery.

3. Remove the battery (2) from the computer.

Install the battery by inserting it into the battery bay until you hear a click.

46 Chapter 4 Removal and replacement procedures

SIM

NOTE: This section applies only to computer models with WWAN capability. If there is a SIM inserted

in the SIM slot, it should be removed before disassembling the computer. Be sure the SIM is reinserted in the SIM slot after reassembling the computer.

Before removing the SIM, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Remove the SIM:

1. Press in on the SIM (1). (The module is partially ejected from the SIM slot.)

2. Remove the SIM (2) from the SIM slot.

Reverse this procedure to install the SIM.

Battery on page 46).

Component replacement procedures 47

Display inverter

Description Spare part number

For use only with HP Compaq 6735b computer models 495086-001

For use only with HP Compaq 6730b computer models 486773-001

Before removing the display inverter, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

Remove the display inverter:

1. Turn the computer right-side up, with the front toward you.

2. Open the computer as far as it will open.

3. Remove the two rubber screw covers (1) on the bottom edge of the display bezel. The rubber screw

covers are available in the Display Rubber Kit, spare part number 486775-001.

4. Remove the two Torx8 T8M2.5×6.0 screws (2) that secure the bottom edge of the display bezel to

the display enclosure.

5. Flex the hinge cover areas (1) and the bottom edge (2) of the display bezel until the bezel

disengages from the display enclosure.

48 Chapter 4 Removal and replacement procedures

6. Release the bottom edge of the display bezel (3) from the display assembly.

7. Release the inverter (1) from the display enclosure as far as the display panel cable and backlight

cable allow.

8. Disconnect the display panel cable (2) and the backlight cable (3) from the display inverter.

9. Remove the display inverter.

Reverse this procedure to install the display inverter.

Component replacement procedures 49

Bluetooth module

NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth

module cable is included in the Cable Kit, spare part number 487138-001. See for more Cable Kit spare part number information.

Description Spare part number

Bluetooth module 490809-001

Before removing the Bluetooth module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

Cable Kit on page 28

4. Remove the battery (see

Battery on page 46).

Remove the Bluetooth module:

1. Position the computer with the front toward you.

2. Loosen the Phillips PM2.0×5.0 captive screw (1) that secures the Bluetooth module compartment

cover to the base enclosure.

3. Lift the rear edge of the Bluetooth module compartment cover (2), swing it forward, and remove

the cover. The Bluetooth module compartment cover is available in the Plastics Kit, spare part number 486292-001.

4. Release the Bluetooth module (1) from the Bluetooth module compartment as far as the Bluetooth

module cable allows.

50 Chapter 4 Removal and replacement procedures

5. Disconnect the Bluetooth module cable (2) from the Bluetooth module.

6. Remove the Bluetooth module.

Reverse this procedure to install the Bluetooth module.

Component replacement procedures 51

Hard drive

NOTE: All hard drive spare part kits include a hard drive bracket.

Description Spare part number

250-GB, 5400-rpm 486261-001

160-GB, 5400-rpm 486260-001

120-GB, 7200-rpm 486259-001

120-GB, 5400-rpm 486782-001

Before removing the hard drive, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

Remove the hard drive:

1. Position the computer with the front toward you.

2. Loosen the two Phillips PM2.0×5.0 captive screws (1) that secure the hard drive bay cover to the

computer.

3. Lift the left side of the hard drive bay cover (2), swing it to the right, and remove the cover. The

hard drive bay cover is included in the Plastics Kit, spare part number 486292-001.

4. Loosen the Phillips PM2.5×10.0 captive screw (1) that secures the hard drive to the computer.

52 Chapter 4 Removal and replacement procedures

5. Grasp the Mylar tab (2) on the hard drive and slide the hard drive (3) to the right to disconnect it

from the system board.

6. Remove the hard drive (4) from the hard drive bay.

7. If it is necessary to replace the hard drive bracket, remove the two Phillips PM3.0×4.0 hard drive

bracket screws (1) from each side of the hard drive.

8. Lift the bracket (2) straight up to remove it from the hard drive.

Reverse this procedure to reassemble and install the hard drive.

Component replacement procedures 53

RTC battery

NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all

passwords and CMOS settings to be cleared.

Description Spare part number

RTC battery 449137-001

Before removing the RTC battery, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the hard drive (see

Battery on page 46).

Hard drive on page 52).

Remove the RTC battery:

Remove the RTC battery from the socket on the system board.



Reverse this procedure to install the RTC battery. When installing the RTC battery, make sure the “+” sign faces up.

54 Chapter 4 Removal and replacement procedures

Optical drive

NOTE: All optical drive spare part kits include an optical drive bezel.

Description Spare part number

DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive 486262-001

DVD/CD-RW Combo Drive 486263-001

DVD-ROM Drive 486264-001

Before removing the optical drive, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

Remove the optical drive:

1. Position the computer with the right side toward you.

2. Loosen the Phillips PM2.5×9.0 captive screw (1) that secures the optical drive to the computer.

3. Insert a flat-bladed screwdriver or similar tool into the optical drive tab access (2) and press the

tab to the left to release the optical drive from the computer.

4. Remove the optical drive (3) from the computer.

5. If it is necessary to replace the optical drive bracket, position the optical drive with the rear toward

you.

6. Remove the two Phillips PM2.0×3.0 screws (1) that secure the optical drive bracket to the optical

drive.

Component replacement procedures 55

7. Remove the optical drive bracket (2).

Reverse this procedure to reassemble and install an optical drive.

Expansion memory module

Description Spare part number

2048-MB memory module (PC2-6400, 667-MHz, DDR2) 483194-001

1024-MB memory module (PC2-6400, 667-MHz, DDR2) 483193-001

Before removing the expansion memory module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

Remove the expansion memory module:

1. Loosen the Phillips PM2.0×5.0 captive screw (1) that secures the memory/WLAN module

compartment cover to the computer.

2. Lift the front edge of the memory/WLAN module compartment cover (2), swing it back, and remove

the cover. The memory/WLAN module compartment cover is included in the Plastics Kit, spare part number 486292-001.

3. Spread the retaining tabs (1) on each side of the memory module slot to release the expansion

memory module. (The edge of the module opposite the slot rises away from the computer.)

56 Chapter 4 Removal and replacement procedures

4. Remove the expansion memory module (2) by pulling the module away from the slot at an angle.

NOTE: Memory modules are designed with a notch (3) to prevent incorrect insertion into the

memory module slot.

Reverse this procedure to install the expansion memory module.

Component replacement procedures 57

WLAN module

Description Spare part number

Broadcom WLAN modules for use only with HP Compaq 6735b computer models:

Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda, Barbados,

●

Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

Broadcom 4322 802.11a/b/g/n WLAN module for use in Afghanistan, Albania, Algeria,

●

Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

487330-001

487330-002

Broadcom BCM4312 802.11b/g WLAN module for use in Antigua and Barbuda, Barbados,

●

Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

Broadcom BCM4312 802.11b/g WLAN module for use in Afghanistan, Albania, Algeria,

●

490811-001

490811-002

58 Chapter 4 Removal and replacement procedures

Description Spare part number

the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

Intel WLAN modules for use only with HP Compaq 6730b computer models:

Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module for use only with HP Compaq 6730b

●

computer models in all countries and regions

Intel Wi-Fi Link 5100 802.11a/b/g WLAN module for use only with HP Compaq 6730b

●

computer models in all countries and regions

480985-001

482957-001

Before removing the WLAN module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the memory/WLAN module compartment cover (see

Battery on page 46).

Expansion memory module

on page 56).

Remove the WLAN module:

1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.

NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The

white WLAN antenna cable is connected to the WLAN module “Aux” terminal.

2. Remove the two Phillips PM2.5×4.0 screws (2) that secure the WLAN module to the computer.

(The edge of the module opposite the slot rises away from the computer.)

Component replacement procedures 59

3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.

Reverse this procedure to install the WLAN module.

Keyboard

NOTE: WLAN modules are designed with a notch (4) to prevent incorrect insertion into the WLAN

module slot.

Country or region Spare part number Country or region Spare part number

Belgium 487136-181 Norway 487136-091

Brazil 487136-201 Portugal 487136-131

The Czech Republic 487136-221 Russia 487136-251

Denmark 487136-081 Saudi Arabia 487136-171

France 487136-051 Slovakia 487136-231

French Canada 487136-121 Slovenia 487136-BA1

Germany 487136-041 South Korea 487136-AD1

Hungary 487136-211 Spain 487136-071

Iceland 487136-DD1 Sweden and Finland 487136-B71

Israel 487136-BB1 Switzerland 487136-BG1

Italy 487136-061 Taiwan 487136-AB1

Japan 487136-291 Thailand 487136-281

Latin America 487136-161 The United Kingdom 487136-031

The Netherlands 487136-B31 The United States 487136-001

60 Chapter 4 Removal and replacement procedures

Before removing the keyboard, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

Remove the keyboard:

1. Loosen the three Phillips PM2.5×9.0 captive screws that secure the keyboard to the computer.

2. Turn the computer display-side up, with the front toward you.

3. Open the computer as far as possible.

4. Slide the four keyboard retention tabs (1) toward you. The tabs are located between the esc and

f1 keys, between the f4 and f5 keys, between the f8 and f9 keys, and between the f12 and scroll

keys.

Component replacement procedures 61

5. Lift the rear edge of the keyboard (2) until it rests at an angle, and slide it back (3) until it rests on

the display assembly and switch cover.

6. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and

disconnect the keyboard cable (2) from the system board.

7. Remove the keyboard.

Reverse this procedure to install the keyboard.

62 Chapter 4 Removal and replacement procedures

Primary memory module

Description Spare part number

2048-MB memory module (PC2-6400, 667-MHz, DDR2) 483194-001

1024-MB memory module (PC2-6400, 667-MHz, DDR2) 483193-001

Before removing the primary memory module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the keyboard (see

Battery on page 46).

Keyboard on page 60).

Remove the primary memory module:

1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory

module. (The edge of the module opposite the slot rises away from the computer.)

2. Remove the memory module (2) by pulling the module away from the slot at an angle.

NOTE: Memory modules are designed with a notch (3) to prevent incorrect insertion into the

memory module slot.

3. Remove the memory module.

Reverse this procedure to install the primary memory module.

Component replacement procedures 63

WWAN module

Description Spare part number

HSDPA EVDO WWAN module 483377-001

Before removing the WWAN module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the keyboard (see

Battery on page 46).

Keyboard on page 60).

Remove the WWAN module:

1. Disconnect the WWAN antenna cables (1) from the terminals on the WWAN module.

NOTE: The red WWAN antenna cable is connected to the WWAN module “Main” terminal. The

blue WWAN antenna cable is connected to the WWAN module “Aux” terminal.

2. Remove the two Phillips PM2.5×4.0 screws (2) that secure the WWAN module to the computer.

(The edge of the module opposite the slot rises away from the computer.)

3. Remove the WWAN module (3) by pulling the module away from the slot at an angle.

NOTE: WWAN modules are designed with a notch (4) to prevent incorrect insertion into the

WWAN module slot.

4. Remove the WWAN module.

Reverse this procedure to install the WWAN module.

64 Chapter 4 Removal and replacement procedures

Switch cover

Description Spare part number

Switch cover (includes LED board and cable) 487139-001

Before removing the switch cover, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the keyboard (see

Battery on page 46).

Keyboard on page 60).

Remove the switch cover and keyboard:

1. Release the ZIF connector to which the LED board cable (1) is attached, and disconnect the LED

board cable from the system board.

2. Lift the left and right sides of the switch cover (2) until it detaches from the computer.

3. Release the switch cover (3) as far as the power button board cable allows.

4. Disconnect the power button board cable (4) from the system board.

5. Remove the switch cover.

Reverse this procedure to install the switch cover.

Component replacement procedures 65

Power button board

Description Spare part number

Power button board (includes cable) 487118-001

Before removing the power button board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the keyboard (see

6. Remove the switch cover (see

Battery on page 46).

Keyboard on page 60).

Switch cover on page 65).

Remove the power button board:

1. Turn the switch cover upside down, with the front toward you.

2. Remove the three Phillips PM2.0×5.0 screws (1) that secure the power button board to the switch

cover.

3. Remove the power button board (2) from the switch cover.

Reverse this procedure to install the power button board.

66 Chapter 4 Removal and replacement procedures

Fan

Description Spare part number

Fan 486288-001

Before removing the fan, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the keyboard (see

6. Remove the switch cover (see

Battery on page 46).

Keyboard on page 60).

Switch cover on page 65).

Remove the fan:

1. Disconnect the fan cable (1) from the system board.

2. Loosen the two Phillips PM2.5×7.0 screws (2) that secure the fan to the base enclosure.

3. Remove the fan (3) from the base enclosure.

Reverse this procedure to install the fan.

NOTE: To properly ventilate the computer, allow at least a 7.6-cm (3-inch) clearance on the left side

of the computer.

The computer uses an electric fan for ventilation. The fan is controlled by a temperature sensor and is designed to turn on automatically when high temperature conditions exist. These conditions are affected by high external temperatures, system power consumption, power management/battery conservation configurations, battery fast charging, and software requirements. Exhaust air is displaced through the ventilation grill located on the left side of the computer.

Component replacement procedures 67

Heat sink

NOTE: The heat sink spare part kits include replacement thermal material.

Description Spare part number

For use only with HP Compaq 6735b computer models 488315-001

For use only with HP Compaq 6730b computer models 486289-001

Before removing the heat sink, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following components:

a. Keyboard (see

b. Switch cover (see

c. Fan (see

Keyboard on page 60)

Switch cover on page 65)

Fan on page 67)

Remove the heat sink:

NOTE: Steps 1 through 4 apply only to HP Compaq 6730b computer models. See steps 5 through 8

for removing the heat sink on HP Compaq 6735b computer models.

1. Loosen the two Phillips PM2.0×4.0 captive screws (1) that secure the heat sink clip to the heat

sink.

2. Remove the heat sink clip (2) by sliding it to the right, and then lifting it up.

68 Chapter 4 Removal and replacement procedures

3. Lift the right side of the heat sink (1) until it releases from the system board components.

NOTE: Due to the adhesive quality of the thermal material located between the heat sink and

system board components, it may be necessary to move the heat sink from side to side to detach it.

4. Remove the heat sink (2) by sliding it to the right.

NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and

the system board components each time the heat sink is removed. Thermal pads are used on the Northbridge chip (1) and the section of the heat sink (1) that services it. Thermal paste is used on the processor (2) and the section of the heat sink (2) that services it. Replacement thermal material is included with all heat sink, system board, and processor spare part kits.

NOTE: Steps 5 through 8 apply only to HP Compaq 6735b computer models. See steps 1 through

4 for removing the heat sink on HP Compaq 6730b computer models.

5. Remove the two Phillips PM2.0×4.0 screws (1) that secure the heat sink clips to the heat sink.

Component replacement procedures 69

6. Remove the heat sink clips (2) by sliding them to left, and then lifting them up.

7. Lift the right side of the heat sink (1) until it releases from the system board components.

NOTE: Due to the adhesive quality of the thermal material located between the heat sink and

system board components, it may be necessary to move the heat sink from side to side to detach it.

70 Chapter 4 Removal and replacement procedures

8. Remove the heat sink (2) by sliding it to the right.

NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and

the system board components each time the heat sink is removed. Thermal paste is used on the processor (1) and the section of the heat sink (1) that services it. Thermal pads are used on the Northbridge chip (2) and the section of the heat sink (2) that services it. Replacement thermal material is included with all heat sink, system board, and processor spare part kits.

Reverse this procedure to install the heat sink.

Component replacement procedures 71

Processor

NOTE: All processor spare part kits include replacement thermal material.

Description Spare part number

AMD processors for use only with HP Compaq 6735b computer models:

AMD Turion 64 ZM-86 2.40-GHz processor

●

AMD Turion 64 ZM-82 2.20-GHz processor

●

AMD Turion 64 ZM-80 2.10-GHz processor

●

AMD Turion 64 RM-70 2.00-GHz processor

●

AMD Sempron SI-40 2.00-GHz processor

●

AMD Athlon QL-60 1.90-GHz processor

●

Intel processors for use only with HP Compaq 6730b computer models:

Intel Core 2 Duo T9600 2.80-GHz processor (6-MB L2 cache, 800-MHz FSB)

●

Intel Core 2 Duo T9400 2.53-GHz processor (6-MB L2 cache, 800-MHz FSB)

●

Intel Core 2 Duo T8600 2.40-GHz processor (3-MB L2 cache, 800-MHz FSB)

●

Intel Core 2 Duo T8400 2.26-GHz processor (3-MB L2 cache, 800-MHz FSB) 486254-001

●

488198-001

488196-001

488195-001

488199-001

488197-001

488200-001

486257-001

486256-001

486255-001

Before removing the processor, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following components:

a. Keyboard (see

b. Switch cover (see

c. Fan (see

d. Heat sink (see

Switch cover on page 65)

Fan on page 67)

Heat sink on page 68)

Remove the processor:

NOTE: Steps 1 and 2 apply only to HP Compaq 6730b computer models. See steps 3 and 4 for

removing the processor on HP Compaq 6735b computer models.

1. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn counterclockwise

until you hear a click.

72 Chapter 4 Removal and replacement procedures

2. Lift the processor (2) straight up and remove it.

NOTE: When you install the processor, the gold triangle (3) on the processor must be aligned

with the triangle (4) embossed on the processor socket.

NOTE: Steps 3 and 4 apply only to HP Compaq 6735b computer models. See steps 1 and 2 for

removing the processor on HP Compaq 6730b computer models.

3. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn counterclockwise

until you hear a click.

4. Lift the processor (2) straight up and remove it.

NOTE: When you install the processor, the gold triangle (3) on the processor must be aligned

with the triangle (4) embossed on the processor socket.

Reverse this procedure to install the processor.

Component replacement procedures 73

Display assembly

NOTE: All display assembly spare part kits include 2 WLAN antenna transceivers and cables.

Description Spare part number

Display assemblies for use only with HP Compaq 6735b computer models:

15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with

●

computer models equipped with both WLAN and WWAN modules

15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models

●

equipped with both WLAN and WWAN modules

15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with

●

computer models equipped with a WLAN module but not a WWAN module

15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models

●

equipped with a WLAN module but not a WWAN module

15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only

●

with computer models equipped with both WLAN and WWAN modules

15.4-inch WXGA BrightView display assembly with 1 microphone for use only with computer

●

models equipped with both WLAN and WWAN modules

15.4-inch WXGA Brightview display assembly with 2 microphones and webcam for use only

●

with computer models equipped with a WLAN module but not a WWAN module

15.4-inch WXGA Brightview display assembly with 1 microphone for use only with computer

●

models equipped with a WLAN module but not a WWAN module

15.4-inch WXGA display assembly with 2 microphones and webcam for use only with

●

computer models equipped with both WLAN and WWAN modules

15.4-inch WXGA display assembly with 1 microphone for use only with computer models

●

equipped with both WLAN and WWAN modules

15.4-inch WXGA display assembly with 2 microphones and webcam for use only with

●

computer models equipped with a WLAN module but not a WWAN module

492177-001

492178-001

492179-001

492180-001

492181-001

492182-001

492183-001

492184-001

492173-001

492174-001

492175-001

15.4-inch WXGA display assembly with 1 microphone for use only with computer models

●

equipped with a WLAN module but not a WWAN module

Display assemblies for use only with HP Compaq 6730b computer models:

15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with

●

computer models equipped with both WLAN and WWAN modules

15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models

●

equipped with both WLAN and WWAN modules

15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with

●

computer models equipped with a WLAN module but not a WWAN module

15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models

●

equipped with a WLAN module but not a WWAN module

15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only

●

with computer models equipped with both WLAN and WWAN modules

15.4-inch WXGA BrightView display assembly with 1 microphone for use only with computer

●

models equipped with both WLAN and WWAN modules

15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only

●

with computer models equipped with a WLAN module but not a WWAN module

74 Chapter 4 Removal and replacement procedures

492176-001

487126-001

487127-001

487128-001

487129-001

487130-001

487131-001

487132-001

Description Spare part number

15.4-inch WXGA BrightView display assembly with 1 microphone for use only with computer

●

models equipped with a WLAN module but not a WWAN module

15.4-inch WXGA display assembly with 2 microphones and webcam for use only with

●

computer models equipped with both WLAN and WWAN modules

15.4-inch WXGA display assembly with 1 microphone for use only with computer models

●

equipped with both WLAN and WWAN modules

15.4-inch WXGA display assembly with 2 microphones and webcam for use only with

●

computer models equipped with a WLAN module but not a WWAN module

15.4-inch WXGA display assembly with 1 microphone for use only with computer models

●

equipped with a WLAN module but not a WWAN module

487133-001

487122-001

487123-001

487124-001

487125-001

Before removing the display assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Disconnect the wireless antenna cables from the WLAN module (see

6. Disconnect the wireless antenna cables from the WWAN module (see

WLAN module on page 58).

WWAN module

on page 64).

7. Remove the fan (see

8. Remove the switch cover (see

Fan on page 67).

Switch cover on page 65).

Remove the display assembly:

1. Close the computer and position it with the rear panel toward you.

2. Remove the four Torx T8M2.5×9.0 screws that secure the display assembly to the computer.

3. Position the computer with the front toward you.

Component replacement procedures 75

4. Open the computer as far as possible.

5. Disconnect the display panel cable (1) from the system board.

6. Disconnect the microphone cable (2) from the microphone extension cable.

7. Remove the Torx8 T8M2.5×4.0 screw (3) that secures the left display hinge cover to the computer.

8. Remove the left display hinge cover (4).

NOTE: The left and right hinge covers are available using spare part number 487144-001.

9. Disconnect the camera cable (1) from the system board.

10. Remove the wireless antenna cables (2) from the clips (3) and routing channel built into the top

cover.

CAUTION: The display assembly will be unsupported when the following screws are removed.

To prevent damage to the display assembly, support it before removing the screws.

11. Remove the two T8M2.5×9.0 screws (1) that secure the display assembly to the computer.

NOTE: The screw on the left display assembly hinge secures a display panel cable ground loop.

76 Chapter 4 Removal and replacement procedures

12. Lift the display assembly (2) straight up and remove it.

13. If it is necessary to replace the display bezel or display hinges, remove the following:

(1) Four beveled rubber screw covers on the display bezel top edge. All rubber screw covers are

available in the Display Rubber Kit, spare part number 486775-001.

(2) Two flat rubber screw covers on the display bezel bottom edge. All rubber screw covers are available in the Display Rubber Kit, spare part number 486775-001.

(3) Six Torx T8M2.5×7.0 screws that secure the display bezel to the display assembly.

14. Flex the inside edges of the left and right sides (1) and the top and bottom sides (2) of the display

bezel until the bezel disengages from the display enclosure.

Component replacement procedures 77

15. Remove the display bezel (3). The display bezel is available using spare part numbers 487336-001

(for use with computer models equipped with a webcam) and 487338-001 (for use with computer models not equipped with a webcam).

16. If it is necessary to replace the display hinges, remove the two four T8M2.5×7.0 screws (1) that

secure the display panel to the display enclosure.

17. Remove the display panel (2).

18. Remove the four Phillips PM2.0×4.0 screws (1) that secure each display hinge to the display

panel.

78 Chapter 4 Removal and replacement procedures

19. Remove the display hinges (2). The left and right display hinges are available using spare part

number 487337-001.

Reverse this procedure to reassemble and install the display assembly.

Component replacement procedures 79

Top cover

Description Spare part number

Top cover 487140-001

Before removing the top cover, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following components:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

Remove the top cover:

1. Turn the computer upside down, with the front toward you.

2. Remove the two rubber screw covers (1) and the seven Torx8 T8M2.5×9.0 screws (2) that secure

top cover to the base enclosure.

NOTE: All rubber screw covers are included in the Rubber Kit, spare part number 487145-001.

80 Chapter 4 Removal and replacement procedures

3. Remove the three Phillips PM2.5×3.0 screws (1) and the two Phillips PM2.5×3.0 broad-head

screws (2) that secure the top cover to the computer.

4. Turn the computer right side up, with rear panel toward you.

5. Lift the rear edge of the top cover until it rests at an angle.

6. Release the ZIF connector to which the TouchPad cable (1) is attached, and disconnect the

TouchPad cable from the ExpressCard board.

NOTE: The fingerprint reader board is available only on select models.

Component replacement procedures 81

7. Disconnect the fingerprint reader board cable (2) from the ExpressCard board.

8. Remove the top cover.

Reverse this procedure to install the top cover.

TouchPad assembly

Description Spare part number

For use only with computer models equipped with a fingerprint reader (includes a fingerprint reader board and cable)

For use only with computer models not equipped with a fingerprint reader 487135-001

487134-001

Before removing the TouchPad assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

d. Switch cover (see

e. Display assembly (see

f. Top cover (see

Switch cover on page 65)

Display assembly on page 74)

Top cover on page 80)

82 Chapter 4 Removal and replacement procedures

Remove the TouchPad assembly:

1. Hold the top cover above the work surface.

2. Release the TouchPad assembly (1) by pushing up on the front edge of the assembly from

underneath the top cover.

3. Remove the TouchPad assembly (2) by sliding it up and forward at an angle

Reverse this procedure to install the TouchPad assembly.

ExpressCard board

Description Spare part number

ExpressCard board (includes RTC battery) 487119-001

Before removing the ExpressCard board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

Battery on page 46).

Hard drive on page 52)

Optical drive on page 55)

c. Keyboard (see

Keyboard on page 60)

d. Switch cover (see

Switch cover on page 65)

Component replacement procedures 83

e. Display assembly (see Display assembly on page 74)

f. Top cover (see

Top cover on page 80)

Remove the ExpressCard board:

1. Remove the two Phillips PM2.5×3.0 broad-head screws (1) that secure the ExpressCard board to

the computer.

2. Remove the ExpressCard board (2).

Reverse this procedure to install the ExpressCard board.

Audio board

Description Spare part number

Audio board (includes cable) 486250-001

Before removing the audio board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

Battery on page 46).

Hard drive on page 52)

Optical drive on page 55)

c. Keyboard (see

d. Switch cover (see

Keyboard on page 60)

Switch cover on page 65)

84 Chapter 4 Removal and replacement procedures

e. Display assembly (see Display assembly on page 74)

f. Top cover (see

g. ExpressCard board (see

Top cover on page 80)

ExpressCard board on page 83)

Remove the audio board:

1. Remove the three Phillips PM2.5×5.0 screws (1) that secure the audio board to the system board.

NOTE: The audio board cable ground loop (2) is secured by the audio board rear screw.

2. Disconnect the speaker cable (3) from the audio board.

3. Disconnect the audio board cable (4) from the system board.

4. Release the audio board (1) by sliding it up and away from the front edge of the base enclosure.

5. Disconnect the microphone cable (2) from the audio board.

Component replacement procedures 85

6. Disconnect the modem module cable (3) from the modem module.

7. Remove the audio board.

Reverse this procedure to install the audio board.

Modem module

NOTE: The modem module spare part kits do not include a modem module cable. The modem module

cable is included in the Cable Kit, spare part number 487138-001.

Description Spare part number

For use in all countries and regions except Australia and New Zealand 491575-001

For use only in Australia and New Zealand 491575-011

Before removing the modem module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

Hard drive on page 52)

Optical drive on page 55)

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

86 Chapter 4 Removal and replacement procedures

f. Top cover (see Top cover on page 80)

g. ExpressCard board (see

h. Audio board (see

Audio board on page 84)

ExpressCard board on page 83)

Remove the modem module:

1. Turn the audio board upside down, with the audio connectors toward you.

2. Remove the two Phillips PM2.5×3.0 screws (1) that secure the modem module to the audio board.

NOTE: The audio board cable ground loop (2) is secured by the modem module rear screw.

3. Lift the modem module (3) straight up to disconnect it from the audio board.

4. Remove the audio board.

Reverse this procedure to install the modem module.

Speaker

Before removing the speaker, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

Description Spare part number

Speaker 487137-001

computer on, and then shut it down through the operating system.

then unplugging the AC Adapter from the computer.

Component replacement procedures 87

4. Remove the battery (see Battery on page 46).

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

f. Top cover (see

g. ExpressCard board (see

h. Audio board (see

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

Top cover on page 80)

ExpressCard board on page 83)

Audio board on page 84)

Remove the speaker:

1. Remove the two Phillips PM2.5×5.0 screws (1) that secure the speaker to the base enclosure.

2. Remove the speaker (2).

Reverse this procedure to install the speaker.

88 Chapter 4 Removal and replacement procedures

USB/digital media board

Description Spare part number

USB/digital media board (includes cable) 486249-001

Before removing the USB/digital media board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

f. Top cover (see

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

Top cover on page 80)

Remove the USB/digital media board cable:

1. Disconnect the USB/digital media board cable (1) from the system board.

2. Remove the two Phillips PM2.5×5.0 screws (2) that secure the USB/digital media board to the base

enclosure.

3. Remove the USB/digital media board (3).

Component replacement procedures 89

Reverse this procedure to install the USB/digital media board.

Bluetooth module cable

NOTE: The Bluetooth module cable is included in the Cable Kit, spare part number 487138-001.

Before removing the Bluetooth module cable, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

f. Top cover (see

Remove the Bluetooth module cable:

1. Disconnect the Bluetooth module cable (1) from the system board.

2. Remove the Bluetooth module cable (2) from the opening built into the base enclosure.

Battery on page 46).

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

Top cover on page 80)

3. Remove the Bluetooth module cable.

Reverse this procedure to install the Bluetooth module cable.

90 Chapter 4 Removal and replacement procedures

Rear cover

Description Spare part number

Rear cover 487143-001

Before removing the rear cover, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

computer on, and then shut it down through the operating system.

then unplugging the AC Adapter from the computer.

4. Remove the battery (see

Battery on page 46).

5. Remove the following:

a. Hard drive (see

b. Optical drive (see

c. Keyboard (see

d. Switch cover (see

e. Display assembly (see

f. Top cover (see

Hard drive on page 52)

Optical drive on page 55)

Keyboard on page 60)

Switch cover on page 65)

Display assembly on page 74)

Top cover on page 80)

Remove the rear cover:

1. Turn the computer upside down, with the rear panel toward you.

2. Remove the four Torx8 T8M2.5×9.0 screws that secure the rear cover to the base enclosure.

3. Turn the computer right side up, with the front toward you.

Component replacement procedures 91

4. Remove the three Phillips PM2.5×3.0 broad-head screws (1) that secure the rear cover to the base

enclosure.

NOTE: The microphone extension cable ground loop (2) is secured the computer by the left-most

broad-head screw.

5. Remove the two Phillips PM2.5×5.0 screws (3) that secure the rear cover to the base enclosure.

6. Remove the microphone extension cable (4) from the clips and routing channel built into the rear

cover.

NOTE: The microphone extension cable is included in the Cable Kit, spare part number

487138-001.

7. Lift the rear edge of the rear cover (1) until it disengages from the base enclosure.

8. Remove the rear cover (2) by lifting it straight up.

Reverse this procedure to install the rear cover.

92 Chapter 4 Removal and replacement procedures

HP 6735B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Product description

2 External component identification

Top components

Top components

Buttons, switches, and fingerprint reader

Keys

TouchPad

Front components

Right-side components

Left-side components

Rear components

Bottom components

3 Illustrated parts catalog

Service tag

Computer major components

Plastics Kit

Cable Kit

Mass storage devices

Miscellaneous parts

Sequential part number listing

4 Removal and replacement procedures

Preliminary replacement requirements

Tools required

Service considerations

Plastic parts

Cables and connectors

Drive handling

Grounding guidelines

Electrostatic discharge damage

Packaging and transporting guidelines

Workstation guidelines

Equipment guidelines

Unknown user password

Component replacement procedures

Service tag

Computer feet

Battery

Display inverter

Bluetooth module

Hard drive

RTC battery

Optical drive

Expansion memory module

WLAN module

Keyboard

Primary memory module

WWAN module

Switch cover

Power button board

Heat sink

Processor

Display assembly

Top cover

TouchPad assembly

ExpressCard board

Audio board

Modem module

Speaker

USB/digital media board

Bluetooth module cable

Rear cover
