HP 6720t User Manual

HP Compaq 6720t Mobile Thin Client

Maintenance and Service Guide

© Copyright 2008 Hewlett-Packard
Development Company, L.P.

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel and Celeron
are trademarks or registered trademarks of
Intel Corporation or its subsidiaries in the U.S.
and other countries. Microsoft, Windows,
and Windows Vista are either trademarks or
registered trademarks of Microsoft
Corporation in the United States and/or other
countries.

The information contained herein is subject to
change without notice. The only warranties
for HP products and services are set forth in
the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.

First Edition: January 2008

Document Part Number: 466357-001

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a
hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact
the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC
adapter comply with the user-accessible surface temperature limits defined by the International Standard
for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description

2 External component identification

Top components ...................................................................................................................... 3

Display .................................................................................................................... 3

Lights ....................................................................................................................... 4

Buttons and speakers ................................................................................................. 5

Keys ........................................................................................................................ 6

TouchPad ................................................................................................................. 7

Front components ..................................................................................................................... 8

Right-side components .............................................................................................................. 9

Left-side components ................................................................................................................. 9

Rear components ................................................................................................................... 10

Bottom components ................................................................................................................ 10

3 Illustrated parts catalog

Serial number location ............................................................................................................ 11

Computer major components ................................................................................................... 12

Plastics Kit ............................................................................................................................. 16

Miscellaneous parts ................................................................................................................ 17

Sequential part number listing .................................................................................................. 18

4 Removal and replacement procedures

Preliminary replacement requirements ....................................................................................... 21

Tools required ......................................................................................................... 21

Service considerations ............................................................................................. 21

Plastic parts ............................................................................................. 21

Cables and connectors ............................................................................. 22

Drive handling ......................................................................................... 22

Grounding guidelines .............................................................................................. 23

Electrostatic discharge damage .................................................................. 23

Packaging and transporting guidelines ........................................ 24

Workstation guidelines .............................................................. 24

v

Equipment guidelines ................................................................. 25

Unknown user password .......................................................................................... 26

Component replacement procedures ........................................................................................ 27

Serial number ......................................................................................................... 27

Computer feet ......................................................................................................... 28

Battery ................................................................................................................... 29

Flash drive ............................................................................................................. 30

Memory module ...................................................................................................... 31

Optical drive .......................................................................................................... 33

Keyboard ............................................................................................................... 35

RTC battery ............................................................................................................ 38

Heat sink ............................................................................................................... 39

WLAN module ........................................................................................................ 41

Switch cover ........................................................................................................... 43

Display assembly .................................................................................................... 45

Top cover ............................................................................................................... 49

Modem module ...................................................................................................... 51

System board and system board frame ...................................................................... 52

PC Card assembly ................................................................................................... 55

Modem module cable .............................................................................................. 57

Audio/USB board ................................................................................................... 58

5 Computer Setup

Starting Computer Setup ......................................................................................................... 60

Using Computer Setup ............................................................................................................ 61

Computer Setup menus ........................................................................................................... 62

6 Specifications

Computer specifications .......................................................................................................... 64

15.4-inch, WXGA display specifications ................................................................................... 65

8X Max DVD-ROM Drive specifications .................................................................................... 66

System DMA specifications ...................................................................................................... 67

System interrupt specifications ................................................................................................. 68

System I/O address specifications ............................................................................................ 69

System memory map specifications .......................................................................................... 71

Navigating and selecting in Computer Setup .............................................................. 61

Restoring factory settings in Computer Setup ............................................................... 61

File menu ............................................................................................................... 62

Security menu ......................................................................................................... 62

Diagnostics menu .................................................................................................... 63

System Configuration menu ...................................................................................... 63

7 Screw listing

vi

Phillips PM2.0×6.0 captive screw ............................................................................................ 73

Torx T8M2.5×9.0 screw ......................................................................................................... 74

Silver Phillips PM2.0×4.0 screw .............................................................................................. 76

Phillips PM2.0×3.0 screw ....................................................................................................... 77

Phillips PM2.5×3.0 screw ....................................................................................................... 78

Phillips PM2.0×2.0 broad-head screw ...................................................................................... 79

Torx T8M2.5×5.0 screw ......................................................................................................... 81

Torx T8M2.5×7.0 screw ......................................................................................................... 83

Black Phillips PM2.0×4.0 screw ............................................................................................... 84

Torx T8M2.5×4.0 screw ......................................................................................................... 86

Phillips PM2.5×4.0 screw ....................................................................................................... 87

Torx T8M2.5×6.0 screw ......................................................................................................... 88

Hex HM5.0×11.0 screw lock .................................................................................................. 89

8 Connector pin assignments

Audio-out (headphone) ........................................................................................................... 90

Audio-in (microphone) ............................................................................................................ 90

External monitor ..................................................................................................................... 91

RJ-11 (modem) ....................................................................................................................... 92

RJ-45 (network) ...................................................................................................................... 93

Universal Serial Bus ................................................................................................................ 93

9 Power cord set requirements

Requirements for all countries and regions ................................................................................. 94

Requirements for specific countries and regions ......................................................................... 95

10 Recycling

Battery .................................................................................................................................. 96

Display ................................................................................................................................. 96

Index ............................................................................................................................... 102

vii

viii

1

Product description

Category Description

Product Name

Processors

Chipset

Southbridge: Intel ICH-7M

Graphics

Panel

Memory

Flash drive

Customer-accessible

Parallel ATA (PATA)

Optical drives

Customer-accessible

PATA

12.7-mm tray load

Diskette drive

HP Compaq 6720t Mobile Thin Client

Intel® Celeron® M423 1.06-GHz processor 1-MB L2 cache, 533-MHz front side bus (FSB)

Northbridge: Mobile Intel 945GM Express chipset with up to 800-MHz FSB

Intel unified memory architecture (UMA) graphics subsystem with up to 224-MB shared
graphics subsystem memory

15.4-inch WXGA AntiGlare display assembly with 2 wireless local area network (WLAN)
antennae

One customer-accessible/upgradable memory module slot, support for up to 1 GB of
PC2-5300, 667-MHz, DDR2 system RAM

Support for one 1-GB solid-state flash module

Fixed (removal of 1 screw required) DVD-ROM Drive

Supports external USB diskette drive only

Supports boot from external USB diskette drive

Audio

Single speaker

Modem

Ethernet

Wireless Integrated WLAN options by way of wireless module:

2 dual-band WLAN antennae built into display assembly

Support for Broadcom 802.11a/b/g WLAN module

External media card

Ports

HD audio - ADI1981

56K V.92 1.5-inch data/fax modem with digital line guard

Integrated 10/100 NIC

One Type I/II PC Card slot (16-bit PCMCIA and 32-bit Cardbus)

Audio-in (stereo microphone)

1

Category Description

Audio-out (stereo headphone)

Docking

RJ-11 (modem)

RJ-45 (Ethernet)

USB (3)

VGA (Dsub 15-pin) supporting 1600 × 1200 external resolution at 75-GHz (hot plug/unplug

3-pin HP Smart Adapter AC power

Keyboard/pointing devices

TouchPad only, with 2 TouchPad buttons and vertical scrolling

Power requirements

6-cell, 47-Wh Li-ion battery

Support for optional 12- or 8-cell accessory battery

Security

Operating system Preinstalled: Microsoft® Windows® XPe

Serviceability End-user replaceable parts:

AC adapter

Battery (system)

Memory module

Optical drive

RTC battery

with auto-detect)

Full-sized, spill-resistant keyboard with embedded numeric keypad

65-W HP Smart Adapter with localized cable plug support (3-wire plug with ground pin,
supports 3-pin DC connector)

Supports Kensington security lock

WLAN module

2Chapter 1 Product description

2

External component identification

Top components

Display

Item Component Function

(1)

(2)

Wireless antennae (2) Send and receive signals from one or more wireless

devices. These antennae are not visible from the outside of
the computer.

Display release latch Opens the computer.

Top components 3

Lights

Item Component Function

(1)

(2)

(3)

(4)

(5)

Wireless lights* (2)

Power lights† (2)

Battery light

Drive light Blinking: The flash drive or optional optical drive is being

Caps lock light On: Caps lock is on.

Blue: An integrated wireless device, such as a wireless

●

local area network (WLAN) device, is on.

Off: All wireless devices are off.

●

On: The computer is on.

●

Blinking: The computer is in Standby.

●

Off: The computer is off.

●

Amber: A battery is charging.

●

Blue: A battery is close to full charge capacity.

●

Blinking amber: A battery that is the only available

●

power source has reached a low battery level. When
the battery reaches a critical battery level, the battery
light begins blinking

Off: If the computer is plugged into an external power

●

source, the light turns off when all batteries in the
computer are fully charged. If the computer is not
plugged into an external power source, the light stays
off until the battery reaches a low battery level.

accessed.

(6)

(7)

Numeric lock light On: Numeric lock is on.

Volume mute light On: Computer sound is turned off.

4Chapter 2 External component identification

Item Component Function

*The 2 wireless lights display the same information. The light on the wireless button is visible only when the computer is open.
The wireless light on the front of the computer is visible whether the computer is open or closed.

†The 2 power lights display the same information. The light on the power button is visible only when the computer is open. The
power light on the front of the computer is visible whether the computer is open or closed.

Buttons and speakers

Item Component Function

(1)

(2)

(3)

(4)

(5)

(6)

Speakers (2) Produce sound.

Power button

Internal display switch Turns off the display if the display is closed while the power

Wireless button Turns the wireless feature on or off but does not establish a

Volume mute button Mutes and restores speaker sound.

Volume down button Decreases speaker volume.

When the computer is off, press the button to turn on

●

the computer.

When the computer is in Standby, press the button

●

briefly to exit Standby.

If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the
power button for at least 5 seconds to turn off the computer.

To learn more about your power settings, right-click the
Power Meter icon in the notification area, and then
click Adjust Power Properties.

is on.

wireless connection.

NOTE: A wireless network must be set up in order to

establish a wireless connection.

(7)

Volume up button Increases speaker volume.

Top components 5

Keys

Item Component Function

(1)

(2)

(3)

(4)

(5)

(6)

esc key Displays system information when pressed in combination

with the fn key.

fn key Executes frequently used system functions when pressed in

combination with a function key or the esc key.

Windows logo key Displays the Windows Start menu.

Windows applications key Displays a shortcut menu for items beneath the pointer.

Numeric keypad keys Can be used like the keys on an external numeric keypad.

Function keys Execute frequently used system functions when pressed in

combination with the fn key.

6Chapter 2 External component identification

TouchPad

Item Component Function

(1)

(2)

(3)

(4)

*This table describes factory settings. To view or change pointing device preferences, select Start > Control Panel > Printers
and Other Hardware > Mouse.

TouchPad* Moves the pointer and selects or activates items on the

screen.

Left TouchPad button* Functions like the left button on an external mouse.

Right TouchPad button* Functions like the right button on an external mouse.

TouchPad scroll zone Scrolls up or down.

Top components 7

Front components

Item Component Function

(1)

(2)

(3)

(4)

(5)

Wireless light

Power light

Battery light

Drive light Blinking: The flash drive or optional optical drive is being

Display release latch Opens the computer.

On: An integrated wireless device, such as a wireless

●

local area network (WLAN) device, is on.

● Off: All wireless devices are off.

On: The computer is on.

●

Blinking: The computer is in Standby.

●

Off: The computer is off.

●

Amber: A battery is charging.

●

Blue: A battery is close to full charge capacity.

●

Blinking amber: A battery that is the only available

●

power source has reached a low battery level. When
the battery reaches a critical battery level, the battery
light begins blinking rapidly.

Off: If the computer is plugged into an external power

●

source, the light turns off when all batteries in the
computer are fully charged. If the computer is not
plugged into an external power source, the light stays
off until the battery reaches a low battery level.

accessed.

8Chapter 2 External component identification

Right-side components

Item Component Function

(1)

(2)

(3)

(4)

Audio-out (headphone) jack Produces sound when connected to optional powered

Audio-in (microphone) jack Connects an optional computer headset microphone,

USB ports (2) Connect optional USB devices.

Optical drive (select models only) Reads an optical disc.

Left-side components

Item Component Function

(1)

Security cable slot Attaches an optional security cable to the computer.

stereo speakers, headphones, ear buds, a headset, or
television audio.

stereo array microphone, or monaural microphone.

NOTE: The security cable is designed to act as a

deterrent, but it may not prevent the computer from being
mishandled or stolen.

(2)

(3)

(4)

(5)

(6)

RJ-45 (network) jack Connects a network cable.

RJ-11 (modem) jack Connects a modem cable.

Vent Enables airflow to cool internal components.

USB port Connects an optional USB device.

PC Card slot Supports optional Type I and Type II 32-bit (CardBus) or 16-

bit PC Cards.

Right-side components 9

Rear components

Item Component Description

(1)

(2)

Power connector Connects an AC adapter.

External monitor port Connects an external VGA monitor or projector.

Bottom components

Item Component Function

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

Battery bay Holds the battery.

Battery release latches (2) Release the battery from the battery bay.

Accessory battery connector Connects an optional accessory battery.

Business card holder Holds a standard-size business card.

Memory module compartment Contains the memory module slot.

Flash drive bay Holds the flash drive.

Vent Enables airflow to cool internal components.

Docking connector Connects an optional docking device.

10 Chapter 2 External component identification

3

Illustrated parts catalog

Serial number location

When ordering parts or requesting information, provide the computer serial number and model number
located on the bottom of the computer.

Serial number location 11

Computer major components

Item Description Spare part

(1) 15.4-inch, WXGA, antiglare display assembly (includes display panel cable and 2

Display bezel

wireless antenna transceivers and cables)

Display internal components:

12 Chapter 3 Illustrated parts catalog

number

467783-001

466164-001

Item Description Spare part

number

Display hinges (includes left and right hinges) 466166-001

Display inverter 466167-001

(2) Switch cover (includes LED board and cable)

(3) Keyboards

For use in the Czech Republic 481424-221

For use in Denmark 481424-081

For use in France 481424-041

For use in French Canada 481424-121

For use in Germany 481424-041

For use in Greece 481424-DJ1

For use in Hungary 481424-211

For use in Iceland 481424-DD1

For use in Israel 481424-BB1

For use in Italy 481424-061

For use in Japan 481424-291

For use in the Netherlands 481424-B31

For use in Norway 481424-091

For use in Belgium 481424-181

417520-001

For use in Portugal 481424-131

For use in Russia 481424-251

For use in Saudi Arabia 481424-171

For use in Slovakia 481424-231

For use in Slovenia 481424-BA1

For use in South Korea 481424-AD1

For use in Spain 481424-071

For use in Sweden and Finland 481424-B71

For use in Switzerland 481424-BG1

For use in Taiwan 481424-AB1

For use in Turkey 481424-141

For use in the United Kingdom 481424-031

For use in the United States 481424-001

(4) Heat sink (includes replacement thermal material)

(5) Broadcom 802.11a/b/g WLAN modules:

468102-001

Computer major components 13

Item Description Spare part

number

● For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda,

For use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the

●

United States

Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain,

Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia

and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina

Faso, Burundi, Cameroon, Cape Verde, the Central African Republic, Chad, Chile, the

People's Republic of China, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus,

the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor,

Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland,

France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece,

Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras,

Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica,

Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia,

Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the

Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico,

Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru,

Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria,

Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru,

the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda,

Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia,

the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands,

Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia,

St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan,

Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan,

Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay,

Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

For use in Japan

●

441075-001

441075-002

441075-291

(6) Top cover (includes TouchPad board and cable, TouchPad button board and cable, speakers

and cable)

(7) Modem module

NOTE: The modem module spare part kit does not include a modem module cable. The

modem module cable is included with the system board frame, spare part number 480894-001.

(8a) PC Card slot bezel

(8b) Memory module compartment cover (includes one captive screw, secured by a C-clip)

(8c) Flash drive bay cover (includes 2 captive screws, secured by C-clips)

(9a)

(9b) 1-GB flash drive (includes flash drive bracket)

(10) PC Card assembly

(11) System board (includes RTC battery and replacement thermal material)

(12) RTC battery

(13) System board frame (includes modem module cable)

(14) Base enclosure (includes 8 rubber feet)

Plastics Kit (see Plastics Kit on page 16 for more Plastics Kit spare part information):

Flash drive bracket (included with flash drive)

Rubber Feet Kit (not illustrated)

466423-001

441074-001

417527-001

465619-001

480829-001

466424-001

449137-001

480894-001

466422-001

480830-001

(15) Audio/USB board (includes audio board cable and USB board cable)

14 Chapter 3 Illustrated parts catalog

480828-001

Item Description Spare part

number

(16) 1024-MB, PC2-5300, 667-MHz, DDR2 memory module

(17) 6-cell, 47-Wh Li-ion battery

(18) 8X Max DVD-ROM Drive (includes bezel and bracket)

414046-001

467784-001

467782-001

Computer major components 15

Plastics Kit

Item Description Spare part number

(1)

(2)

(3)

Plastics Kit:

Flash drive bay cover (includes 2 captive screws, secured by C-clips)

PC Card slot bezel

Memory module compartment cover (includes one captive screw, secured by a C-clip)

417527-001

16 Chapter 3 Illustrated parts catalog

Miscellaneous parts

Description Spare part number

65-W HP Smart Adapter

Power cords:

For use in Australia and New Zealand

For use in Brazil 246959-201

For use in Japan 246959-291

For use in South Korea 246959-AD1

For use the United States 246959-001

Screw Kit

● Hex HM5.0×11.0 screw lock

Phillips PM2.5×4.0 screw

●

Phillips PM2.5×3.0 screw

●

Phillips PM2.0×6.0 captive screw

●

Black Phillips PM2.0×4.0 screw

●

Silver Phillips PM2.0×4.0 screw

●

Phillips PM2.0×3.0 screw

●

Phillips PM2.0×2.0 broad-head screw

●

391172-001

246959-011

417526-001

Torx T8M2.5×9.0 screw

●

Torx T8M2.5×7.0 screw

●

Torx T8M2.5×6.0 screw

●

Torx T8M2.5×5.0 screw

●

Torx T8M2.5×4.0 screw

●

Miscellaneous parts 17

Sequential part number listing

Spare part
number

246959-001 Power cord for use in the United States

246959-011 Power cord for use in Australia and New Zealand

246959-201 Power cord for use in Brazil

246959-291 Power cord for use in Japan

246959-AD1 Power cord for use in South Korea

391172-001 65-W HP Smart Adapter

414046-001 1024-MB, PC2-5300, 667-MHz, DDR2 memory module

417520-001 Switch cover (includes LED board and cable)

417526-001 Screw Kit

417527-001 Plastics Kit (see Plastics Kit on page 16 for more Plastics Kit spare part information)

441074-001 Modem module

441075-001 Broadcom 802.11a/b/g WLAN module for use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin

Description

NOTE: The modem module spare part kit does not include a modem module cable. The modem module cable

is included with the system board frame, spare part number 480894-001.

Islands, and the United States

441075-002 Broadcom 802.11a/b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua

441075-291 Broadcom 802.11a/b/g WLAN module for use in Japan

449137-001 RTC battery

465619-001 1-GB flash drive (includes flash drive bracket)

466164-001 Display bezel

and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh,
Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana,
Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central
African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica,
Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor,
Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana,
Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea,
Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory
Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia,
Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta,
the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro,
Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand,
Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru,
the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino,
Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia,
Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St.
Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan,
Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the
United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire,
Zambia, and Zimbabwe

466166-001 Display hinges (includes left and right hinges)

466167-001 Display inverter

18 Chapter 3 Illustrated parts catalog

Spare part
number

466422-001 Base enclosure (includes 8 rubber feet)

466423-001 Top cover (includes TouchPad board and cable, TouchPad button board and cable, speakers and cable)

466424-001 System board (includes RTC battery and replacement thermal material)

467782-001 8X Max DVD-ROM Drive (includes bezel and bracket)

467783-001 15.4-inch, WXGA, antiglare display assembly (includes display panel cable and 2 wireless antenna transceivers

467784-001 6-cell, 47-Wh Li-ion battery

468102-001 Heat sink (includes replacement thermal material)

480828-001 Audio/USB board (includes audio board cable and USB board cable)

480829-001 PC Card assembly

480830-001 Rubber Feet Kit

480894-001 System board frame (includes modem module cable)

481424-001 Keyboard for use in the United States

481424-031 Keyboard for use in the United Kingdom

481424-041 Keyboard for use in Germany

Description

and cables)

481424-051 Keyboard for use in France

481424-061 Keyboard for use in Italy

481424-071 Keyboard for use in Spain

481424-081 Keyboard for use in Denmark

481424-091 Keyboard for use in Norway

481424-121 Keyboard for use in French Canada

481424-131 Keyboard for use in Portugal

481424-141 Keyboard for use in Turkey

481424-171 Keyboard for use in Saudi Arabia

481424-181 Keyboard for use in Belgium

481424-211 Keyboard for use in Hungary

481424-221 Keyboard for use in the Czech Republic

481424-231 Keyboard for use in Slovakia

481424-251 Keyboard for use in Russia

481424-291 Keyboard for use in Japan

417025-AB1 Keyboard for use in Taiwan

481424-AD1 Keyboard for use in South Korea

481424-BA1 For use in the Netherlands

481424-BB1 For use in Sweden and Finland

Sequential part number listing 19

Spare part
number

481424-BG1 For use in Slovenia

481424-B31 For use in Israel

481424-B71 For use in Switzerland

481424-DD1 For use in Iceland

481424-DJ1 For use in Greece

Description

20 Chapter 3 Illustrated parts catalog

4

Removal and replacement procedures

Preliminary replacement requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

Flat-bladed screwdriver

●

Magnetic screwdriver

●

Phillips P0 and P1 screwdrivers

●

Torx T8 screwdriver

●

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly
and assembly procedures.

NOTE: As you remove each subassembly from the computer, place the subassembly (and all

accompanying screws) away from the work area to prevent damage.

Plastic parts

Using excessive force during disassembly and reassembly can damage plastic parts. Use care when
handling the plastic parts. Apply pressure only at the points designated in the maintenance instructions.

Preliminary replacement requirements 21

Cables and connectors

CAUTION: When servicing the computer, be sure that cables are placed in their proper locations

during the reassembly process. Improper cable placement can damage the computer.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat
or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In
all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that
they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with extreme
care; these cables tear easily.

Drive handling

CAUTION: Drives are fragile components that must be handled with care. To prevent damage to the

computer, damage to a drive, or loss of information, observe these precautions:

Before removing or inserting a flash drive, shut down the computer. If you are unsure whether the computer
is off, turn the computer on, and then shut it down through the operating system.

Before handling a drive, be sure that you are discharged of static electricity. While handling a drive,
avoid touching the connector.

Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be
sure that the optical drive tray is closed.

Handle drives on surfaces covered with at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a flash drive, an optical drive, or a diskette drive, place it in a static-proof bag.

Avoid exposing a flash drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”

22 Chapter 4 Removal and replacement procedures

Grounding guidelines

Electrostatic discharge damage

Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some protection,
but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.

An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a
normal cycle. Or the device may function normally for a while, then degrade in the internal layers,
reducing its life expectancy.

CAUTION: To prevent damage to the computer when you are removing or installing internal

components, observe these precautions:

Keep components in their electrostatic-safe containers until you area ready to install them.

Use nonmagnetic tools.

Before touching an electronic component, discharge static electricity by using the guidelines described in
this section.

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

If you remove a component, place it in an electrostatic-safe container.

The following table shows how humidity affects the electrostatic voltage levels generated by different
activities.

CAUTION: A product can be degraded by as little as 700 V.

Typical electrostatic voltage levels

Relative humidity

Event 10% 40% 55%

Walking across carpet 35,000 V 15,000 V 7,500 V

Walking across vinyl floor 12,000 V 5,000 V 3,000 V

Motions of bench worker 6,000 V 800 V 400 V

Removing DIPS from plastic tube 2,000 V 700 V 400 V

Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V

Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V

Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V

Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V

Preliminary replacement requirements 23

Packaging and transporting guidelines

Follow these grounding guidelines when packaging and transporting equipment:

To avoid hand contact, transport products in static-safe tubes, bags, or boxes.

●

Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.

●

Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

●

Place items on a grounded surface before removing items from their containers.

●

Always be properly grounded when touching a component or assembly.

●

Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive foam.

●

Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that mechanized

●

equipment used for moving materials is wired to ground and that proper materials are selected to
avoid static charging. When grounding is not possible, use an ionizer to dissipate electric charges.

Workstation guidelines

Follow these grounding workstation guidelines:

Cover the workstation with approved static-shielding material.

●

Use a wrist strap connected to a properly grounded work surface and use properly grounded tools

●

and equipment.

Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

●

When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe

●

materials.

Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and

●

Styrofoam.

Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these

●

items only at static-free workstations.

Avoid contact with pins, leads, or circuitry.

●

Turn off power and input signals before inserting or removing connectors or test equipment.

●

24 Chapter 4 Removal and replacement procedures

Equipment guidelines

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps

●

with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground,
wear a strap snugly against the skin at all times. On grounded mats with banana-plug connectors,
use alligator clips to connect a wrist strap.

When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps) can

●

be used at standing workstations and are compatible with most types of shoes or boots. On
conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm
resistance between the operator and ground. To be effective, the conductive strips must be worn in
contact with the skin.

The following grounding equipment is recommended to prevent electrostatic damage:

Antistatic tape

●

Antistatic smocks, aprons, and sleeve protectors

●

Conductive bins and other assembly or soldering aids

●

Nonconductive foam

●

Conductive tabletop workstations with ground cords of one megohm resistance

●

Static-dissipative tables or floor mats with hard ties to the ground

●

Field service kits

●

Static awareness labels

●

Material-handling packages

●

Nonconductive plastic bags, tubes, or boxes

●

Metal tote boxes

●

Electrostatic voltage levels and protective materials

●

The following table lists the shielding protection provided by antistatic bags and floor mats.

Material Use Voltage protection level

Antistatic plastic Bags 1,500 V

Carbon-loaded plastic Floor mats 7,500 V

Metallized laminate Floor mats 5,000 V

Preliminary replacement requirements 25

Unknown user password

If the computer you are servicing has an unknown user password, follow these steps to clear the password:

NOTE: These steps also clear CMOS.

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the real-time clock (RTC) battery (see

5.

on page 52).

Wait approximately 5 minutes.

6.

Replace the RTC battery and reassemble the computer.

7.

Connect AC power to the computer. Do not reinsert any batteries at this time.

8.

Turn on the computer.

9.

All passwords and all CMOS settings have been cleared.

Battery on page 29).

System board and system board frame

26 Chapter 4 Removal and replacement procedures

Component replacement procedures

This chapter provides removal and replacement procedures.

There are as many as 81 screws and screw locks, in 13 different sizes, that must be removed, replaced,
or loosened when servicing the computer. Make special note of each screw size and screw lock location
during removal and replacement.

Serial number

Report the computer serial number to HP when requesting information or ordering spare parts. The serial
number is located on the bottom of the computer.

Component replacement procedures 27

Computer feet

The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part
number 480830-001. There are four oblong rubber feet (1) and four square rubber feet (2), that attach
to the base enclosure in the locations illustrated below.

28 Chapter 4 Removal and replacement procedures

Battery

Description Spare part number

6-cell, 47-Wh Li-ion battery 467784-001

Before disassembling the computer, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery:

Turn the computer upside down on a flat surface, with the battery bay toward you.

1.

2. Slide the battery release latches (1) to release the battery.

3. Remove the battery (2) from the computer.

Install the battery by sliding it into the battery bay until you hear a click.

Component replacement procedures 29

Flash drive

Description Spare part number

1-GB flash drive (includes flash drive bracket) 465619-001

Before removing the flash drive, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Battery on page 29).

Remove the flash drive:

Position the computer with the front toward you.

1.

2. Loosen the two Phillips PM2.0×6.0 captive screws (1) that secure the flash drive bay cover to the

computer.

3. Lift the right side of the flash drive bay cover (2), swing it to left, and remove the cover. The flash

drive bay cover is included in the Plastics Kit, spare part number 417527-001.

4. Grasp the Mylar tab (1) on the flash drive and pull the module (2) to the left to disconnect it from

the system board.

30 Chapter 4 Removal and replacement procedures

5. Remove the flash drive (3) from the flash drive bay.

If it is necessary to replace the flash drive bracket, slide the module out of the bracket.

6.

Reverse this procedure to reassemble and install the flash drive.

Memory module

Description Spare part number

1024-MB (PC2-5300, 667-MHz, DDR2) 414046-001

Before removing the memory module, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the memory module:

1. Loosen the Phillips PM2.0×6.0 captive screw (1) that secures the memory module compartment cover

to the computer.

Battery on page 29).

Component replacement procedures 31

2. Lift the right edge of the cover (2), swing it up and to the left, and remove the cover. The memory

module compartment cover is included in the Plastics Kit, spare part number 417527-001.

3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.

(The edge of the module opposite the slot rises away from the computer.)

4. Remove the memory module (2) by pulling the module away from the slot at an angle.

NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the

memory module slot.

Reverse this procedure to install a memory module.

32 Chapter 4 Removal and replacement procedures

Optical drive

NOTE: All optical drive spare part kits include an optical drive bezel.

Description Spare part number

8X Max DVD-ROM Drive 467782-001

Before removing the optical drive, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Battery on page 29).

Remove the optical drive:

Position the computer with the left side toward you.

1.

2. Remove the Torx T8M2.5×9.0 screw (1) that secures the optical drive to the computer.

3. Insert a flat-bladed screwdriver or similar tool into the optical drive tab access (2), and press the tab

to the left to release the optical drive from the computer.

4. Remove the optical drive (3) from the computer.

If it is necessary to replace the optical drive bracket, position the optical drive with the back edge

5.

toward you.

6. Remove the two Phillips PM2.0×4.0 screws (1) that secure the bracket to the optical drive.

Component replacement procedures 33

7. Remove the optical drive bracket (2).

Reverse this procedure to reassemble and install an optical drive.

34 Chapter 4 Removal and replacement procedures

Keyboard

Description Spare part number

Keyboards for use in the following countries or regions:

Belgium

The Czech Republic 481424-221 Russia 481424-251

Denmark 481424-081 Saudi Arabia 481424-171

France 481424-051 Slovakia 481424-231

French Canada 481424-121 Slovenia 481424-BA1

Germany 481424-041 South Korea 481424-AD1

Greece 481424-DJ1 Spain 481424-071

Hungary 481424-211 Sweden and Finland 481424-B71

Iceland 481424-DD1 Switzerland 481424-BG1

Israel 481424-BB1 Taiwan 481424-AB1

Italy 481424-061 Turkey 481424-141

Japan 481424-291 The United Kingdom 481424-031

The Netherlands 481424-B31 The United States 481424-001

Norway 481424-091

481424-181 Portugal 481424-131

Before removing the switch cover and keyboard, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Battery on page 29).

Component replacement procedures 35

Remove the keyboard:

Remove the two Torx T8M2.5×9.0 screws that secure the keyboard to the computer.

1.

Turn the computer display-side up, with the front toward you.

2.

Open the computer as far as possible.

3.

4. Slide the four keyboard retention tabs (1) toward you. The tabs are located between the esc and

f1 keys, between the f4 and f5 keys, between the f8 and f9 keys, and between the f12 and delete

keys.

5. Lift the rear edge of the keyboard (2) until it rests at an angle.

6. Slide the keyboard back (3) until it rests against the display.

36 Chapter 4 Removal and replacement procedures

7. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and

disconnect the keyboard cable (2) from the system board.

Remove the keyboard.

8.

Reverse this procedure to install the keyboard.

Component replacement procedures 37

RTC battery

NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all passwords

and CMOS settings to be cleared.

Description Spare part number

RTC battery 449137-001

Before removing the RTC battery, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the keyboard (see

5.

Battery on page 29).

Keyboard on page 35).

Remove the RTC battery:

Use a non-conductive tool to remove the RTC battery from the socket on the system board.

▲

Reverse this procedure to install the RTC battery.

38 Chapter 4 Removal and replacement procedures

Heat sink

Description Spare part number

Heat sink (includes replacement thermal material) 468102-001

Before removing the heat sink, follow these steps:

1.

2.

3.

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then
shut it down through the operating system.

Disconnect all external devices connected to the computer.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the keyboard (see

5.

Battery on page 29).

Keyboard on page 35).

Remove the heat sink:

In the 1, 2, 3, 4, 5, 6, 7, 8 sequence stamped into the heat sink, remove the following screws:

1.

(1) Four Phillips PM2.5×3.0 screws

(2) Four Phillips PM2.0×3.0 screws

NOTE: When removing and replacing the heat sink, inspect the thermal pads (3) for damage. If

the pads are damaged, replace them.

2. Remove the heat sink (4) by sliding it to the right until it clears the top cover.

NOTE: The thermal material must be thoroughly cleaned from the processor and Northbridge chip

(1) and the locations on the bottom of the heat sink (2) each time the heat sink is removed. Thermal

material is included with all heat sink and system board spare part kits.

Component replacement procedures 39

Reverse this procedure to install the heat sink.

40 Chapter 4 Removal and replacement procedures

WLAN module

Description Spare part number

Broadcom 802.11a/b/g WLAN modules:

For use in Canada, Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United

●

States

For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina,

●

Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados,
Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana,
Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape
Verde, the Central African Republic, Chad, Chile, the People's Republic of China, Colombia,
Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti,
Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea,
Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia,
Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea­Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the
Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon,
Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi,
Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius,
Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia,
Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria,
Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines,
Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao
Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore,
Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka,
St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden,
Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey,
Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom,
Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

For use in Japan 441075-291

●

441075-001

441075-002

Before removing the WLAN module, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the keyboard (see

5.

Remove the heat sink (see

6.

Battery on page 29).

Keyboard on page 35).

Heat sink on page 39).

Remove the WLAN module:

1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.

NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The

white WLAN antenna cable is connected to the WLAN module “Aux” terminal.

2. Remove the two Phillips PM2.0×3.0 screws (2) that secure the WLAN module to the computer. (The

edge of the module opposite the slot rises away from the computer.)

Component replacement procedures 41

3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.

NOTE: WLAN modules are designed with a notch (4) to prevent incorrect installation.

Reverse this procedure to install the WLAN module.

42 Chapter 4 Removal and replacement procedures

Switch cover

Description Spare part number

Switch cover (includes LED board and cable) 417520-001

Before removing the switch cover, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the keyboard (see

5.

Battery on page 29).

Keyboard on page 35).

Remove the switch cover:

Close the computer.

1.

Turn the computer upside down, with the rear toward you.

2.

3. Remove the three Phillips PM2.0×2.0 broad-head screws that secure the switch cover to the computer.

Turn the computer display-side up, with the front toward you.

4.

Open the computer as far as possible.

5.

6. Disconnect the LED board cable (1) from the system board.

Component replacement procedures 43

7. Remove the switch cover (2) by lifting it straight up.

Reverse this procedure to install the switch cover.

44 Chapter 4 Removal and replacement procedures

Display assembly

NOTE: All display assembly spare part kits include 2 WLAN antenna transceivers and cables.

Description Spare part number

15.4-inch, WXGA, antiglare display assembly (includes display panel cable and 2 wireless antenna
transceivers and cables)

467783-001

Before removing the display assembly, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Disconnect the wireless antenna cables from the WLAN module (see

5.

Remove the keyboard (see

6.

Remove the switch cover (see

7.

Battery on page 29).

WLAN module on page 41).

Keyboard on page 35).

Switch cover on page 43).

Remove the display assembly:

1. Disconnect the display panel cable (1) from the system board.

2. Remove the wireless antenna cables (2) from the clips and routing channels built into the top cover.

3. Remove the two Phillips PM2.0×2.0 broad-head screws (3) that secure the right display hinge to the

computer.

Position the computer with the rear panel toward you.

4.

Component replacement procedures 45

5. Remove the six Torx T8M2.5×9.0 screws (1) that secure the display assembly to the computer.

6. Lift the display assembly (2) straight up and remove it.

If it is necessary to replace the display bezel, display inverter, or display hinges, remove the rubber

7.

screw covers and screws listed below.

(1) Four rubber screw covers on the display bezel top edge.

(2) Two rubber screw covers on the display bezel bottom edge.

(3) Four Torx T8M2.5×5.0 screws on the display bezel top edge.

(4) Two Torx T8M2.5×7.0 screws on the display bezel bottom edge.

8. Flex the inside edges of the top (1) edge, left and right sides (2), and the bottom edge (3) of the

display bezel until the bezel disengages from the display enclosure.

46 Chapter 4 Removal and replacement procedures

9. Remove the display bezel (4). The display bezel is available using spare part number

466164-001.

10. If it is necessary to replace the display inverter, disconnect the display panel cable (1) and the

backlight cable (2) from the display inverter.

11. Remove the six Torx T8M2.5×5.0 screws (1) that secure the display panel to the display

enclosure.

12. Remove the display panel (2).

Component replacement procedures 47

13. Remove the display inverter (3). The display inverter is available using spare part number

466167-001.

14. If it is necessary to replace the display hinges, remove the four Phillips PM2.0×4.0 screws (1) that

secure each display hinge to the display panel.

15. Remove the display hinges (2). The left and right display hinges are available using spare part

number 466166-001.

Reverse this procedure to reassemble and install the display assembly.

48 Chapter 4 Removal and replacement procedures

Top cover

Description Spare part number

Top cover (includes TouchPad board and cable, TouchPad button board and cable, speakers and
cable)

466423-001

Before removing the top cover, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the following components:

5.

Optical drive (see

a.

Keyboard (see

b.

Switch cover (see

c.

Display assembly (see

d.

Battery on page 29).

Optical drive on page 33)

Keyboard on page 35)

Switch cover on page 43)

Display assembly on page 45)

Remove the top cover:

Turn the computer upside down, with the front toward you.

1.

Remove the following:

2.

(1) Two rubber screw covers

(2) Ten Torx T8M2.5×9.0 screws

Turn the computer right-side up, with the front toward you.

3.

Component replacement procedures 49

4. Disconnect the speaker cable (1) from the system board.

5. Remove the four Torx T8M2.5×5.0 screws (2) that secure the top cover to the computer.

6. Lift the rear edge of the top cover (1) and swing it up and forward until it rests at an angle.

7. Lift up on the outside edges of the top cover left and right sides (2) until the top cover disengages

from the base enclosure.

8. Lift up on the front edge of the top cover (3) until the TouchPad board cable is accessible.

9. Disconnect the TouchPad board cable (4) from the system board.

Remove the top cover.

10.

Reverse this procedure to install the top cover.

50 Chapter 4 Removal and replacement procedures

Modem module

NOTE: The modem module spare part kit does not include a modem module cable. The modem module

cable is included with the system board frame, spare part number 480894-001.

Description Spare part number

Modem module 441074-001

Before removing the modem module, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the following components:

5.

Optical drive (see

a.

Keyboard (see

b.

Switch cover (see

c.

Display assembly (see

d.

Top cover (see

e.

Battery on page 29).

Optical drive on page 33)

Keyboard on page 35)

Switch cover on page 43)

Display assembly on page 45)

Top cover on page 49)

Remove the modem module:

1. Remove the two Phillips PM2.5×4.0 screws (1) that secure the modem module to the system board.

2. Lift the modem module (2) straight up to disconnect it from the system board

Component replacement procedures 51

3. Disconnect the modem module cable (3) from the modem module.

Remove the modem module.

4.

Reverse this procedure to install the modem module.

System board and system board frame

Description Spare part number

System board (includes RTC battery and replacement thermal material) 466424-001

System board frame (includes modem module cable) 480894-001

Before removing the system board and system board frame, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the following components:

5.

Flash drive (see

a.

Optical drive (see

b.

Keyboard (see

c.

Battery on page 29).

Flash drive on page 30)

Optical drive on page 33)

Keyboard on page 35)

Switch cover (see

d.

Display assembly (see

e.

Top cover (see

f.

Switch cover on page 43)

Display assembly on page 45)

Top cover on page 49)

52 Chapter 4 Removal and replacement procedures

When replacing the system board, be sure that the following components are removed from the defective
system board and installed on the replacement system board:

Memory module (see

●

WLAN module (see

●

Memory module on page 31)

WLAN module on page 41)

Remove the system board and system board frame:

Turn the computer upside down, with the front toward you.

1.

Remove the two Torx T8M2.5×9.0 screws that secure the system board frame to the base enclosure.

2.

Turn the computer right-side up, with the front toward you.

3.

4. Remove the five Torx T8M2.5×6.0 screws (1) that secure the system board frame to the base

enclosure.

5. Disconnect the USB board cable (2) and audio board cable (3) from the system board.

Position the base enclosure with the rear toward you.

6.

7. Flex the base enclosure (1) above the USB connector until the connector is clear.

8. Use the optical drive connector (2) to release the system board frame and system board from the

base enclosure.

Component replacement procedures 53

9. Remove the system board frame and system board (3) from the base enclosure.

10. Release the modem module cable (1) from the two clips built into the system board.

11. Release the RJ-11 connector (2) from the clip built into the system board.

12. Remove the three Torx T8M2.5×4.0 screws (3) that secure the system board to the system board

frame.

13. Remove the two Hex HM5.0×11.0 screw locks (4) that secure the system board to the system board

frame.

14. Lift the front edge of the system board (1) until it rests at an angle.

54 Chapter 4 Removal and replacement procedures

15. Remove the system board (2) by pulling it away from the system board frame at an angle.

Reverse the preceding procedure to install the system board and system board frame.

PC Card assembly

Description Spare part number

PC Card assembly 480829-001

Before removing the PC Card assembly, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the following components:

5.

Flash drive (see

a.

Optical drive (see

b.

Keyboard (see

c.

Switch cover (see

d.

Display assembly (see

e.

Battery on page 29).

Flash drive on page 30)

Optical drive on page 33)

Keyboard on page 35)

Switch cover on page 43)

Display assembly on page 45)

Top cover (see

f.

System board (see

g.

Top cover on page 49)

System board and system board frame on page 52)

Component replacement procedures 55

Remove the PC Card assembly:

Turn the system board upside down, with the front toward you.

1.

Remove the two Phillips PM2.0×4.0 screws that secure the PC Card assembly to the system board.

2.

Turn the system board right side up, with the front toward you.

3.

4. Disengage the hook on the PC Card assembly from the tab (1) on the system board connector.

5. Remove the PC Card assembly (2).

Reverse the preceding procedure to install the PC Card assembly.

56 Chapter 4 Removal and replacement procedures

Modem module cable

NOTE: The modem module cable is included with the system board frame, spare part number

480894-001. See

Before removing the modem module cable, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

System board and system board frame on page 52 for system board frame information.

Remove the battery (see

4.

Remove the following components:

5.

Flash drive (see

a.

Optical drive (see

b.

Keyboard (see

c.

Switch cover (see

d.

Display assembly (see

e.

Top cover (see

f.

System board (see

g.

Remove the modem module cable:

Remove the modem module cable from the clips built into the system board frame.

▲

Battery on page 29).

Flash drive on page 30)

Optical drive on page 33)

Keyboard on page 35)

Switch cover on page 43)

Display assembly on page 45)

Top cover on page 49)

System board and system board frame on page 52)

Reverse this procedure to install the modem module cable.

Component replacement procedures 57

Audio/USB board

Description Spare part number

Audio/USB board (includes audio board cable and USB board cable) 480828-001

Before removing the audio/USB board, follow these steps:

Shut down the computer. If you are unsure whether the computer is off, turn the computer on, and then

1.

shut it down through the operating system.

Disconnect all external devices connected to the computer.

2.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

3.

then unplugging the AC adapter from the computer.

Remove the battery (see

4.

Remove the following components:

5.

Flash drive (see

a.

Optical drive (see

b.

Keyboard (see

c.

Switch cover (see

d.

Display assembly (see

e.

Top cover (see

f.

System board (see

g.

Battery on page 29).

Flash drive on page 30)

Optical drive on page 33)

Keyboard on page 35)

Switch cover on page 43)

Display assembly on page 45)

Top cover on page 49)

System board and system board frame on page 52)

Remove the audio/USB board:

1. Remove the two Torx T8M2.5×5.0 screws (1) that secure the audio/USB board to the base

enclosure.

58 Chapter 4 Removal and replacement procedures

2. Lift the rear edge of the audio/USB board (2) until the board is clear of the base enclosure.

Remove the audio/USB board from the base enclosure.

3.

Reverse this procedure to install the audio/USB board.

Component replacement procedures 59

5

Computer Setup

Starting Computer Setup

Computer Setup is a preinstalled ROM-based utility that can be used even when the operating system is
not working or will not load.

NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your

computer.

NOTE: Pointing devices are not supported in Computer Setup. You must use the keyboard to navigate

and make selections.

To start Computer Setup:

Turn on or restart the computer.

1.

Before Windows opens and while the “F10=ROM Based Setup” message is displayed in the lower-

2.

left corner of the screen, press f10.

60 Chapter 5 Computer Setup

Using Computer Setup

Navigating and selecting in Computer Setup

The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and
System Configuration menus.

Open Computer Setup by turning on or restarting the computer, and then pressing f10 while the

1.

"F10 = ROM Based Setup" message is displayed in the lower-left corner of the screen.

Because Computer Setup is not Windows-based, it does not support the TouchPad. Navigation and
selection are by keystroke:

To choose a menu or a menu item, use the arrow keys.

●

To select an item, press enter.

●

To close open dialog boxes and return to the main Computer Setup screen, press esc.

●

To view navigation information, press f1.

●

To change the language, press f2.

●

2. Select the File, Security, Diagnostics, or System Configuration menu.

To exit Computer Setup, choose one of the following methods:

3.

●

To exit Computer Setup without saving your preferences, use the arrow keys to select File >
Ignore changes and exit. Then follow the instructions on the screen.

●

To save your preferences and exit Computer Setup, use the arrow keys to select File > Save
changes and exit. Then follow the instructions on the screen.

Your preferences go into effect when the computer restarts.

Restoring factory settings in Computer Setup

To return all settings in Computer Setup to the values that were set at the factory, follow these steps:

Open Computer Setup by turning on or restarting the computer, and then pressing f10 while the

1.

"F10 = ROM Based Setup" message is displayed in the lower-left corner of the screen.

2. Use the arrow keys to select File > Restore defaults, and then press enter.

When the confirmation dialog box opens, press f10.

3.

4. To save your preferences and exit Computer Setup, use the arrow keys to select File > Save

changes and exit. Then follow the instructions on the screen.

Your preferences go into effect when the computer restarts.

NOTE: Your password settings and security settings are not changed when you restore the factory

settings.

Using Computer Setup 61

Computer Setup menus

The menu tables in this section provide an overview of Computer Setup options.

NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your

computer.

File menu

Select To do this

System information

Restore defaults Replace the configuration settings in Computer Setup with the original factory settings.

Ignore changes and exit Cancel any changes entered during the current session and exit Computer Setup.

Save changes and exit Save any changes entered during the current session and exit Computer Setup. Your

Security menu

NOTE: Some of the menu items listed in this section may not be supported by your computer.

Select To do this

Setup Password Enter, change, or delete a setup password.

Power-On Password Enter, change, or delete a power-on password.

Password Options

View identification information for the computer and the batteries in the system.

●

View specification information for the processor, cache and memory size, system

●

ROM, video revision, and keyboard controller version.

(Password settings and security settings are not changed when you restore the factory
settings.)

changes go into effect when the computer restarts.

Enable/disable stringent security.

●

Enable/disable the password requirement on computer restart.

●

Smart Card Security Enable/disable smart cards.

System IDs Enter a user-defined computer asset tracking number and ownership tag.

62 Chapter 5 Computer Setup

Diagnostics menu

Select To do this

Memory Check Run a comprehensive test on system memory.

System Configuration menu

NOTE: Some of the listed System Configuration options may not be supported by your computer.

Select To do this

Language (or press f2) Change the Computer Setup language.

Boot Options

Device Configurations

Built-In Device Options ● Enable/disable embedded WLAN Device Radio.

Set an f9, f10, and f12 delay when starting up.

●

Enable/disable CD-ROM boot.

●

Enable/disable floppy boot.

●

Enable/disable internal network adapter boot and set the boot mode (PXE).

●

Enable/disable MultiBoot, which sets a boot order that can include most boot

●

devices in the system.

Set the Express Boot Popup delay in seconds.

●

Set the boot order.

●

Swap the functions of the fn key and left ctrl key.

●

Enable/disable USB legacy support. When enabled, USB legacy support allows

●

the following:

Use of a USB keyboard in Computer Setup even when a Windows

◦

operating system is not running.

Startup from bootable USB devices, including a hard drive, diskette drive,

◦

or optical drive connected by a USB port to the computer.

Network Interface Controller (LAN).

●

LAN/WAN switching.

●

Port Options

Enable/disable Wake on LAN.

●

Enable/disable the optical disc drive.

●

Enable/disable the USB port.

●

Enable/disable the PC Card slot.

●

Computer Setup menus 63

6

Specifications

Computer specifications

Metric U.S.

Dimensions

Length

Width 35.7 cm 14.05 in

Height (front to rear) 3.0 to 3.6 cm 1.16 to 1.43 in

Weight (equipped with optical drive, flash drive, and battery)

Input power

Operating voltage

Operating current 4.74 A

Temperature

Operating (not writing to optical disc)

Operating (writing to optical disc) 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity

Operating

Nonoperating 5% to 95%

Maximum altitude (unpressurized)

Operating

26.0 cm 10.23 in

2.54 kg 5.6 lbs

19.0 V dc @ 4.74 A – 90 W

0°C to 35°C 32°F to 95°F

10% to 90%

-15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

Shock

Operating

Nonoperating 200 g, 2 ms, half-sine

Random vibration

Operating

64 Chapter 6 Specifications

125 g, 2 ms, half-sine

0.75 g zero-to-peak, 10 Hz to 500 Hz, 0.25 oct/min sweep
rate

Metric U.S.

Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate

NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this

range of temperatures.

15.4-inch, WXGA display specifications

Metric U.S.

Dimensions

Height

Width 33.1 cm 13.03 in

Diagonal 39.1 cm 15.39 in

Number of colors

Contrast ratio

Brightness

Pixel resolution

Pitch

Format 1366 × 768

Configuration RGB vertical stripe

Backlight

Character display

Total power consumption

Viewing angle

20.7 cm 8.15 in

Up to 16.8 million

200:1 (typical)

180 nits (typical)

0.197 × 0.197 mm

CCFT

80 × 25

7.0 W

+/-40° horizontal, +/-50° vertical (typical)

15.4-inch, WXGA display specifications 65

8X Max DVD-ROM Drive specifications

Applicable disc

Access time

Random < 100 ms < 125 ms

Cache buffer

Data transfer rate

CD-R (24X) 3600 KB/s (150 KB/s at 1X CD rate)

CD-RW (10X) 1500 KB/s (150 KB/s at 1X CD rate)

CD-ROM (24X) 3600 KB/s (150 KB/s at 1X CD rate)

DVD (8X) 10,800 KB/s (1,352 KB/s at 1X DVD rate)

Multiword DMA mode 2 16.6 MB/s

DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18, CD-ROM (Mode 1 and 2), CD Digital
Audio, CD-XA ready (Mode 2, Form 1 and Form 2), CD-I (Mode 2, Form 1 and Form 2),
CD-R, CD-RW, Photo CD (single and multisession), CD-Bridge

CD DVD

512 KB

66 Chapter 6 Specifications

System DMA specifications

Hardware DMA System function

DMA0 Not applicable

DMA1* Not applicable

DMA2* Not applicable

DMA3 Not applicable

DMA4 Direct memory access controller

DMA5* Available for ExpressCard

DMA6 Not assigned

DMA7 Not assigned

*ExpressCard controller can use DMA 1, 2, or 5.

System DMA specifications 67

System interrupt specifications

Hardware IRQ System function

IRQ0 System timer

IRQ1 Standard 101-/102-Key or Microsoft® Natural Keyboard

IRQ2 Cascaded

IRQ3 Intel 82801DB/DBM USB2 Enhanced Host Controller—24CD

IRQ4 COM1

IRQ5* Conexant AC—Link Audio Intel 82801DB/DBM SMBus Controller—24C3 Data Fax

Modem with SmartCP

IRQ6 Diskette drive

IRQ7* Parallel port

IRQ8 System CMOS/real-time clock

IRQ9* Microsoft ACPI-compliant system

IRQ10* Intel USB UHCI controller—24C2

Intel 82852/82855 GM/GME Graphic Controller

Realtek RTL8139 Family PCI Fast Ethernet Controller

IRQ11 Intel USB EHCI controller—24CD

Intel USB UHCI controller—24C4

Intel USB UHCI controller—24C7

Intel Pro/Wireless 2200BG

TI OHCI 1394 host controller

TI PCI1410 CardBus controller

IRQ12 Synaptics PS/2 TouchPad

IRQ13 Numeric data processor

IRQ14 Primary IDE channel

IRQ15 Secondary IDE channel

*Default configuration; audio possible configurations are IRQ5, IRQ7, IRQ9, IRQ10, or none.

NOTE: ExpressCards may assert IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, or IRQ15. Either the infrared or the serial

port may assert IRQ3 or IRQ4.

68 Chapter 6 Specifications

System I/O address specifications

I/O address (hex) System function (shipping configuration)

000 - 00F DMA controller no. 1

010 - 01F Unused

020 - 021 Interrupt controller no. 1

022 - 024 Opti chipset configuration registers

025 - 03F Unused

02E - 02F 87334 “Super I/O” configuration for CPU

040 - 05F Counter/timer registers

044 - 05F Unused

060 Keyboard controller

061 Port B

062 - 063 Unused

064 Keyboard controller

065 - 06F Unused

070 - 071 NMI enable/RTC

072 - 07F Unused

080 - 08F DMA page registers

090 - 091 Unused

092 Port A

093 - 09F Unused

0A0 - 0A1 Interrupt controller no. 2

I/O Address (hex) System function (shipping configuration)

0A2 - 0BF Unused

0C0 - 0DF DMA controller no. 2

0E0 - 0EF Unused

0F0 - 0F1 Coprocessor busy clear/reset

0F2 - 0FF Unused

100 - 16F Unused

170 - 177 Secondary fixed disk controller

178 - 1EF Unused

1F0 - 1F7 Primary fixed disk controller

1F8 - 200 Unused

201 JoyStick (decoded in ESS1688)

202 - 21F Unused

System I/O address specifications 69

I/O address (hex) System function (shipping configuration)

220 - 22F Entertainment audio

230 - 26D Unused

26E - 26 Unused

278 - 27F Unused

280 - 2AB Unused

2A0 - 2A7 Unused

2A8 - 2E7 Unused

2E8 - 2EF Reserved serial port

2F0 - 2F7 Unused

2F8 - 2FF Infrared port

300 - 31F Unused

320 - 36F Unused

370 - 377 Secondary diskette drive controller

378 - 37F Parallel port (LPT1/default)

380 - 387 Unused

388 - 38B FM synthesizer—OPL3

38C - 3AF Unused

3B0 - 3BB VGA

3BC - 3BF Reserved (parallel port/no EPP support)

3C0 - 3DF VGA

3E0 - 3E1 ExpressCard controller in CPU

3E2 - 3E3 Unused

3E8 - 3EF Internal modem

3F0 - 3F7 “A” diskette controller

3F8 - 3FF Serial port (COM1/default)

CF8 - CFB PCI configuration index register (PCIDIVO-1)

CFC - CFF PCI configuration data register (PCIDIVO-1)

70 Chapter 6 Specifications

System memory map specifications

Size Memory address System function

640 KB 00000000-0009FFFF Base memory

128 KB 000A0000-000BFFFF Video memory

48 KB 000C0000-000CBFFF Video BIOS

160 KB 000C8000-000E7FFF Unused

64 KB 000E8000-000FFFFF System BIOS

15 MB 00100000-00FFFFFF Extended memory

58 MB 04800000-07FFFFFF Super extended memory

58 MB 04800000-07FFFFFF Unused

2 MB 08000000-080FFFFF Video memory (direct access)

4 GB 08200000-FFFEFFFF Unused

64 KB FFFF0000-FFFFFFFF System BIOS

System memory map specifications 71

7

Screw listing

This section provides specification and reference information for the screws and screw locks used in the
computer. All screws listed in this section are available in the Screw Kit, spare part number 417526-001.

72 Chapter 7 Screw listing

Phillips PM2.0×6.0 captive screw

Color Quantity Length Thread Head diameter

Black 3 6.0 mm 2.0 mm 5.0 mm

Where used:

(1) Two captive screws that secure the flash drive bay cover to the computer (screws are captured on the

cover by C-clips)

(2) One captive screw that secures the memory module compartment cover to the computer (screw is
captured on the cover by a C-clip)

Phillips PM2.0×6.0 captive screw 73

Torx T8M2.5×9.0 screw

Color Quantity Length Thread Head diameter

Black 21 9.0 mm 2.5 mm 5.0 mm

Where used:

(1) One screw that secures the optical drive to the computer

(2) Two screws that secure the keyboard to the computer

74 Chapter 7 Screw listing

Where used: 6 screws that secure the display assembly to the computer

Where used: 10 screws that secure the top cover to the computer

Where used: 2 screws that secure the system board frame to the base enclosure

Torx T8M2.5×9.0 screw 75

Silver Phillips PM2.0×4.0 screw

Color Quantity Length Thread Head diameter

Silver 2 4.0 mm 2.0 mm 4.5 mm

Where used: 2 screws that secure the optical drive bracket to the optical drive

76 Chapter 7 Screw listing

Phillips PM2.0×3.0 screw

Color Quantity Length Thread Head diameter

Silver 6 3.0 mm 2.0 mm 4.5 mm

Where used: 2 screws that secure the WLAN module to the system board

Phillips PM2.0×3.0 screw 77

Where used: 4 screws that secure the heat sink to the computer

Phillips PM2.5×3.0 screw

Color Quantity Length Thread Head diameter

Black 4 3.0 mm 2.5 mm 5.0 mm

Where used: 4 screws that secure the heat sink to the computer

78 Chapter 7 Screw listing

Phillips PM2.0×2.0 broad-head screw

Color Quantity Length Thread Head diameter

Black 5 2.0 mm 2.0 mm 7.0 mm

Where used: 3 screws that secure the switch cover to the computer

Phillips PM2.0×2.0 broad-head screw 79

Where used: 2 screws that secure the display assembly right hinge to the computer

80 Chapter 7 Screw listing

Torx T8M2.5×5.0 screw

Color Quantity Length Thread Head diameter

Black 14 5.0 mm 2.5 mm 5.0 mm

Where used: 4 screws that secure the display bezel top edge to the display assembly

Where used: 6 screws that secure the display panel to the display enclosure

Torx T8M2.5×5.0 screw 81

Where used: 4 screws that secure the top cover to the base enclosure

82 Chapter 7 Screw listing

Torx T8M2.5×7.0 screw

Color Quantity Length Thread Head diameter

Black 2 9.0 mm 2.5 mm 5.0 mm

Where used: 2 screws that secure the display bezel bottom edge to the display assembly

Torx T8M2.5×7.0 screw 83

Black Phillips PM2.0×4.0 screw

Color Quantity Length Thread Head diameter

Black 10 4.0 mm 2.0 mm 4.5 mm

Where used: 8 screws that secure the display hinges to the display panel

84 Chapter 7 Screw listing

Where used: 2 screws that secure the PC Card assembly to the system board

Black Phillips PM2.0×4.0 screw 85

Torx T8M2.5×4.0 screw

Color Quantity Length Thread Heat width

Black 5 4.0 mm 2.5 mm 5.0 mm

Where used: 3 screws that secure the system board to the system board frame

Where used: 2 screws that secure the audio/USB board to the base enclosure

86 Chapter 7 Screw listing

Phillips PM2.5×4.0 screw

Color Quantity Length Thread Head diameter

Black 2 4.0 mm 2.5 mm 5.0 mm

Where used: 2 screws that secure the modem module to the system board

Phillips PM2.5×4.0 screw 87

Torx T8M2.5×6.0 screw

Color Quantity Length Thread Head diameter

Black 5 6.0 mm 2.5 mm 5.0 mm

Where used: 5 screws that secure the system board frame to the base enclosure

88 Chapter 7 Screw listing

Hex HM5.0×11.0 screw lock

Color Quantity Length Thread Head diameter

Silver 2 11.0 mm 2.5 mm 5.0 mm

Where used: 2 screw locks that secure the system board to the system board frame

Hex HM5.0×11.0 screw lock 89

8

Connector pin assignments

Audio-out (headphone)

Pin Signal

1 Audio out, left channel

2 Audio out, right channel

3Ground

Audio-in (microphone)

Pin Signal

1 Audio signal in

2 Audio signal in

3Ground

90 Chapter 8 Connector pin assignments

External monitor

Pin Signal

1 Red analog

2 Green analog

3 Blue analog

4 Not connected

5 Ground

6 Ground analog

7 Ground analog

8 Ground analog

9 +5 VDC

10 Ground

11 Monitor detect

12 DDC 2B data

13 Horizontal sync

14 Vertical sync

15 DDC 2B clock

External monitor 91

RJ-11 (modem)

Pin Signal

1 Unused

2 Tip

3 Ring

4 Unused

5 Unused

6 Unused

92 Chapter 8 Connector pin assignments
