QuickSpecs

Overview

HP Compaq 6720s Notebook PC

HP recommends Windows Vista

Business

Dual-band Wireless LAN Antennas*

Wireless On/Off Button with LED*

Power Button with LED

Speaker

Kensington Lock Slot

Battery Charging LED

ExpressCard/54 slot

Three USB 2.0 ports

RJ-45/Ethernet port

10.

5. 6

Optical Drive Touchpad with Scroll Zone Secure Digital (SD) slot Microphone Jack Headphone Jack

Power Connector VGA/external monitor connector RJ-11/modem port

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 1

QuickSpecs

HP Compaq 6720s Notebook PC

Overview

At A Glance

Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic 32, FreeDOS, or Red Flag Linux (PRC only) Thin, lightweight design starting at 5.5 lb/2.49 kg and 1.27-inch/32.3 mm thin at front Widescreen 15.4-inch diagonal display with optional BrightView Flexible wireless connectivity options:

Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module

Bluetooth® Intel® Core™2 Duo processor or Intel Celeron® processor Device Access Manager for HP ProtectTools Integrated optical drive Up to 160-GB 5400 rpm user-removable hard drive with HP DriveGuard protection Secure Digital (SD) slot Up to 4 GB of 533-MHz or 667-MHz DDR2 SDRAM, dual channel memory support Mobile Intel Graphics Media Accelerator X3100, with up to 384-MB shared system memory Intel 10/100 Ethernet Controller Touchpad with scroll zone

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 2

QuickSpecs

Standard Features

HP Compaq 6720s Notebook PC

Processors

Operating System

Intel Core 2 Duo Processor T7700 (2.40-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7500 (2.20-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7300 (2.00-GHz, 800-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7100 (1.80-GHz, 800-MHz FSB, 2-MB L2 cache)*

Intel Core 2 Duo Processor T5550 (1.83-GHz, 800-MHz FSB, 2-MB L2 cache)*

Intel Core 2 Duo Processor T5470 (1.60-GHz, 800-MHz FSB, 2-MB L2 cache)* (select models)

Intel Core 2 Duo Processor T5450 (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)* (select models)

Intel Celeron Processor 540 (1.86-GHz, 533-MHz FSB, 1-MB L2 cache)*

* Intel's numbering is not a measurement of higher performance.

NOTE:

speeds in battery optimization mode.

Preinstalled

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx http://www.microsoft.com/windowsvista/getready/capable.mspx

Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit

Processor speed denotes maximum performance mode; processors will run at lower

Genuine Windows Vista Business 32* Genuine Windows Vista Home Basic 32* FreeDOS RedFlag Linux (PRC only)

Certain Windows Vista product features require advanced or additional hardware. See

and

for details. Windows Vista

http://www.windowsvista.com/upgradeadvisor

Chipset

Graphics

Display

Memory

Mobile Intel GM965 or GL960

Mobile Intel Graphics Media Accelerator X3100, up to 384-MB shared system memory Microsoft DirectX 9 capable

Internal

External

Standard

Dual-channel

*with Mobile Intel GM965 chipset only

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

15.4-inch diagonal WXGA anti-glare (1280 x 800 resolution)

15.4-inch diagonal WXGA BrightView (1280 x 800 resolution)

Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower

resolutions at up to 100 Hz

NOTE:

resolution and color depth settings.

512-MB, 1024-MB, 2048-MB, or 4096-MB* 533-MHz or 667-MHz DDR2 SDRAM total memory; two SODIMM slots supporting dual channel memory

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

Resolutions are dependent upon monitor capability, and

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 3

QuickSpecs

Standard Features

HP Compaq 6720s Notebook PC

Communications

Wireless Devices

Intel Fast Ethernet Integrated Controller (10/100 NIC)

56K V.92 modem*

* Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

Support for a broad range of secure, integrated wireless LAN options featuring support for the latest industry standards. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the supported wireless LAN options.

All 802.11a/b/g integrated wireless LAN options

Intel Wireless WiFi Link 4965AGN*

Intel Wireless WiFi Link 4965AG*

Intel PRO/Wireless 3945ABG Network Connection*

Intel PRO/Wireless 3945BG Network Connection*

Broadcom 4311AG

802.11a/b/g WiFi Adapter

Broadcom 4311BG

802.11b/g WiFi Adapter

HP Integrated Module with Bluetooth Wireless Technology

* Requires Intel Core 2 Duo processor

Wi-Fi certified Cisco Compatible Extensions support (Version 4.0) with Microsoft Windows XP Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAPGTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support WiFi certified for WPA2, WMM Dual antennas integrated in the display enclosure

Integrated support for 802.11a, b, g, and draft-n Up to 243-mbps data rate

Integrated support for 802.11 a, b and g Up to 54-mbps data rate

Integrated support for 802.11 b and g Up to 54-mbps data rate

Integrated support for 802.11 a, b and g Up to 54-mbps data rate

Integrated support for 802.11 b and g Up to 54-mbps data rate

Bluetooth Specification v2.0 compliant Works with a wide range of Bluetooth devices

Keyboard

Pointing device

The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. US and International key layouts are available. Other features include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, and comfort-dished keycaps.

Touchpad with scroll zone, two pick buttons

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 4

QuickSpecs

Standard Features

HP Compaq 6720s Notebook PC

Expansion card slots

Storage

Interfaces

ExpressCard/54 slot

Secure Digital slot

Hard drives

NOTE:

cycles. Up to 10 GB is reserved for the system recovery software.

HP DriveGuard

Fixed optical drives

ExpressCard/54

External monitor

Stereo microphone in

Stereo headphone/line out

Power connector

RJ-11/modem

RJ-45/Ethernet

USB 2.0

LED status indicators

These hard drives are customer removable and will withstand multiple insertion/removal

Supports ExpressCard/54 and ExpressCard/34

Supports SD (Secure Digital), MMC (MultiMedia Card)

80/120/160-GB 5400 rpm SMART SATA

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive.

DVD/CD-RW Combo Drive DVD+/-RW SuperMulti DL Drive DVD+/-RW SuperMulti DL LightScribe Drive

Supports ExpressCard/54 and ExpressCard/34

One – VGA

One

Three

Six

Audio

Software

High Definition Audio support Integrated mono speaker Stereo headphone/line out Stereo microphone in

Preinstalled software with Windows Vista

Additional software available from the web

PDF Complete HP Backup and Recovery Manager HP Help and Support Center HP Universal Print Driver HP ProtectTools Security Manager: Device Access Manager for HP ProtectTools HP Wireless Assistant Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition (select models) Roxio Creator 9 (for optional DVD+/-RW and DVD/CDRW drives) Synaptics Touchpad Driver Symantec Norton Internet Security with complimentary 60-day live update Intervideo WinDVD – DVD Player

HP Client Manager Java Card Security for HP ProtectTools

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 5

QuickSpecs

Standard Features

HP Compaq 6720s Notebook PC

HP Backup and Recovery Manager

SMBIOS Version 2.4

Security

Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide data and system file protection for HP business PCs to enable fast recovery if the system becomes corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can perform scheduled or manual backups of the entire drive or individual files and folders. Up to 10 GB of the hard drive is reserved for the system recovery software. HP Backup and Recovery Manager can also create software recovery CDs or DVDs (requires optional hardware).

System Management BIOS, previously known as DMI BIOS, is used to store system management information.

Standard Features

For more information on HP security solutions refer to

Device Access Manager for HP ProtectTools Configuration Control Hardware Memory Change Alert Ownership Tag Setup Password Power-On Password HP DriveGuard Kensington Lock Slot Support for Computrace / LoJack for Laptops (must be purchased separately)

http://www.hp.com/go/security

Power Supply

Battery

Battery Life

System Standby Time

Power Conservation

External 65-watt AC adapter, 6-foot (1.8-meter) power cord included. Total length including external AC adapter is 12 feet (3.66 meter).

Primary battery

NOTE:

Vista. Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.

Up to 1 week

Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo processors (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)

Intel Display Power Saving technology

Hibernation

Standby

ACPI compliance

The listed battery life measurements were taken on models running Microsoft Windows

6-cell (47 WHr) Lithium-Ion battery

TBD

Service and Support

HP Services offers limited 1-year warranty. On-site service and warranty upgrades are also available. For HP Care Pack services see

NOTE:

details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

http://www.hp.com/go/lookuptool

Page 6

QuickSpecs

Options

HP Compaq 6720s Notebook PC

Memory

Other Storage

Power

Carrying Cases

Security

Input/Output Devices

HP 512-MB (DDR2 667 MHz) SODIMM

HP 1-GB (DDR2 667 MHz) SODIMM

HP 2-GB (DDR2 667 MHz) SODIMM

HP Notebooks USB Diskette Drive

HP 65W Smart AC Adapter

HP 65W AC/Auto/Air Combo Smart Adapter

HP Value Nylon Case

HP Universal Nylon Case

HP Executive Leather Case

HP Deluxe Nylon Backpack

HP Deluxe Roller Case

HP/Kensington MicroSaver Security Lock

HP PS/2 Keyboard & Mouse Bundle

HP USB Optical Travel Mouse

EM993AA

EM994AA

EM995AA

DC361B

ED494AA#xxx

ED993AA#xxx

RR314AA

RR315AA

RR316AA

RR317AA

GD405AA

PC766A

RC464AA#xxx

RH304AA

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 7

QuickSpecs

Memory

Up to 4096 MB* of 533-MHz or 667-MHz DDR2 SDRAM Two DIMM slots DIMM sizes supported: 512 MB, 1024 MB, and 2048 MB

Standard Memory

512 MB (512 MB x 1) 1024 MB (1024 MB x 1 or 512 MB x 2) 2048 MB (2048 MB x 1 or 1024 MB x 2)

HP Compaq 6720s Notebook PC

Optional Memory Upgrades

Both memory slots are user accessible. Please refer to the Hardware and Software Guide for installation procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

Up to

1024 MB 1024 MB 1024 MB 1536 MB 1024 MB 2048 MB 1024 MB 1024 MB

4096 MB*

NOTE:

third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

*with Mobile Intel GM965 chipset only

Memory Upgrades

This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some

HP 512-MB (DDR2 667 MHz) SODIMM

HP 1024-MB (DDR2 667 MHz) SODIMM

HP 2048-MB (DDR2 667 MHz) SODIMM

Slot 1 Slot 2

Empty

512 MB 512 MB

512 MB

2048 MB 2048 MB

EM993AA

EM994AA

EM995AA

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 8

QuickSpecs

Storage

Removable Media Drive Support

HP Compaq 6720s Notebook PC

DVD/CD-RW Combo Drive

DVD+/-RW SuperMulti DL Drive

DVD+/-RW SuperMulti DL LightScribe Drive

Hard Drive Support

Primary Hard Drives

160-GB 5400 rpm SMART SATA Hard Drive

120-GB 5400 rpm SMART SATA Hard Drive

80-GB 5400 rpm SMART SATA Hard Drive

Quantity Supported

One

Quantity Supported

One

Drive Bay

Fixed optical drive bay

Drive Bay

Dedicated hard drive bay

DA - 12759 Worldwide QuickSpecs — Version 2 — 9.5.2007

Page 9
