Chapter 1 Introduction

This chapter introduces the Hotwire® 6212 ADSL Router. It includes a product overview, a

description of the product’s features and applications, and an explanation of the functions of

the Front panel LED indictors.

1.1 Product Overview

The Hotwire 6212 ADSL Router is an ADSL router integrated with a USB and an Ethernet

Interface. The USB and four Ethernet ports can be used simultaneously, allowing a total of five

PCs to be connected to the Hotwire 6212 and access the ADSL line. In addition, the Hotwire

6212 can be configured to operate in bridge mode or router mode.

The auto configuration/auto upgrade function allows multiple ADSL routers to be upgraded

over the LAN in one operation.

The Hotwire 6212 protects all of your networked computers with advanced security

technologies such as virtual private networks (VPNs) with PPTP passthrough, L2TP

passthrough, and IPSec passthrough.

6212-A2-GB20-00 May 2004 9

1.2 Features

The ADSL Router is a compact and high performance standalone unit that provides:



Four Ethernet ports and one USB port for LAN connection



One console port for local management



Stateful packet inspection and filtering



Denial of Service protection



IGMP Proxy



G.dmt, G.lite, and T1.413



Remote configuration and upgrade



Auto-negotiation rate adaptation



AAL5 for ATM over ADSL



UBR, CBR, VBR-real-time, VBR-non-realtime ATM services



VC-based and LLC multiplexing



Up to 8 VCs



Embedded SNMP agent



Configuration backup and restoration



OAM F4/F5



Static route/RIP/RIP v2 routing functions



NAT/PAT



On-demand PPPoE



PVC can support multiple PPPoE sessions



DHCP Server/Relay



DNS Proxy



FTP Server



TFTP Client



IEEE 802.1d compliant

10 May 2004 6212-A2-GB20-00

1.3 Application

The figure below shows a possible application of the router.

6212-A2-GB20-00 May 2004 11

1.4 Front Panel LED Indicators

LED Indicator Color Mode Function

Green On Power is supplied Power

Off Power is not supplied

LAN 1x – 4x Green

ADSL Link Green

On An Ethernet link is established

Off An Ethernet link is not established

Flash Activity over the Ethernet link

On A USB link is connected USB Green

Off A USB link is not connected

Flash The ADSL Link is training

On The ADSL Link is established

Off The ADSL link is not connected

Flash Packets transmitted or received on the ADSL link ADSL TX/RX Green

Off No packets on the ADSL link

12 May 2004 6212-A2-GB20-00

Chapter 2 Hardware Installation

2.1 Installation

The Hardware installation procedure is explained below.

Caution: Always disconnect all telephone lines from the telephone wall outlet before

servicing or disassembling this device.

1. Verify that the On/Off switch on the rear panel is in the Off position.

2. Connect the power adapter to the Power jack of the device, and then plug the power adapter into the wall outlet.

3. Connect the USB port to a PC with a standard USB cable.

4. Connect the LAN ports to PCs or a hub using RJ45 cables. The LAN ports automatically sense whether the connection requires a crossover, so either straight-through or crossover cables may be used.

5. Connect the LINE port t o y o u r t e l e ph o n e j a c k wi t h a n R J 1 1 con n e ct o r c a b le.

6. Turn the On/Off switch on the rear panel to the On position.

Note If the device fails to power on, or it malfunctions, first verify that the power supply

is correctly connected, and then power it on again.

6212-A2-GB20-00 May 2004 13

2.2 Installing the USB Driver

Before you connect your router’s USB cable to your PC, you must load the ADSL USB drivers

and configure the device via the LAN port using Web management. There are two ways to

install the USB driver:

• Auto-installation: Install the driver by inserting the CD in the CD drive of your PC and

letting the installation automatically start.

• Manual installation: Install the driver with the Windows Hardware Wizard. When using the

USB port the LAN port must be vacant.

14 May 2004 6212-A2-GB20-00

2.2.1 Auto Installation

STEP 1: Insert the CD-ROM disc for the ADSL USB router.

STEP 2:

continue. (If the screen doesn’t appear, browse the CD-ROM and double-click on

INSTALL.EXE.)

The CD-ROM will auto-play and you will see the following screen. Click on Next to

6212-A2-GB20-00 May 2004 15

STEP 3: When prompted by the message shown below, connect your router to a USB port of

your PC. Then click on OK.

STEP 4:

A completion message appears when the installation is complete. Click on Finish.

16 May 2004 6212-A2-GB20-00

2.2.2 Manual Installation

To connect the router to a PC using the USB interface, you need to use a standard USB cable

and install the USB interface software. Follow the steps below.

STEP 1

cable into a USB port on your PC, and plugging the square connector into the router. The Found

New Hardware screen appears:

STEP 2

: Connect the USB router to the PC by plugging the flat connector of a standard USB

: When the screen appears as below, click on the Next button.

6212-A2-GB20-00 May 2004 17

STEP 3

Next button.

: When the screen appears as below, select Search for a suitable driver and click the

18 May 2004 6212-A2-GB20-00

STEP 4: Select Specify a location and click on the Next button. If you are installing the

software from a disk, insert the disk.

STEP 5

: Select the location of the file using the Browse button.

6212-A2-GB20-00 May 2004 19

STEP 6: Enter the correct file for your operating system, select the ADIRNDIS.INF file, and

click on the Open button.

STEP 7

: When the screen below appears, click on the OK button.

20 May 2004 6212-A2-GB20-00

STEP 8: When the screen below appears, click on the NEXT button.

6212-A2-GB20-00 May 2004 21

STEP 9: Click the Finish button when prompted.

Installation is complete.

22 May 2004 6212-A2-GB20-00

2.3 Uninstalling the USB Driver

2.3.1 Auto-Uninstallation

If the software was installed with the auto-play driver, uninstall it by completing the following

steps:

STEP 1:

Click on the Windows Start button and go to Programs>CT-562. Click on Uninstall.

STEP 2:

Click on OK when you are prompted to confirm the removal of the software.

6212-A2-GB20-00 May 2004 23

STEP 3: When prompted by the message shown below, disconnect the USB cable from your PC

and click on the OK button.

STEP 4: When the driver is removed, a completion message appears. Click on Finish to close

the window.

24 May 2004 6212-A2-GB20-00

2.3.2 Manual Removal of the Driver

If the driver was manually installed, it must be uninstalled manually. To do that, go to the

Windows Device manager, choose ADI USB Remote NDIS Network Device, and delete it.

6212-A2-GB20-00 May 2004 25

Chapter 3 Login Via the Web Browser

This section describes how to manage the router via a web browser from the remote end. You

can use a web browser such as Microsoft Internet Explorer, or Netscape Navigator. It is best to

set your display resolution to 1024 x 768. To change the resolution, go to the Microsoft

Windows control panel and click on the Display icon, then change the display settings. Access

to the management functions of the USB router from the LAN side is restricted. A unique

default user account is assigned with user name Admin with an empty password. User can

change the default password later when logging to the device.

3.1 IP Address

To log on to the device using a web browser, your workstation and the device should both be on

the same network segment. The default IP address is 192.168.1.1. You can modify the IP

address of your PC by modifying its TCP/IP properties. Follow the steps below:

STEP 1:

Enter the TCP/IP screen and change the IP address to the domain of 192.168.1.x/24.

26 May 2004 6212-A2-GB20-00

STEP 2:

Click on OK to submit the settings. Restart the computer when requested.

STEP 3:

Start your Internet browser with the default IP address 192.168.1.1.

3.2 Login Procedure

To log on to the system from the Web browser, follow the steps below:

STEP1:

STEP 2:

STEP 3:

STEP 4:

Start your Internet browser.

Type the IP address for the router in the browser’s location field. For example, if the

IP address is 192.168.1.1, type http://192.168.1.1

You are prompted to enter your user name and password. The user name is ignored.

Type your password, or if the password has not been changed, type the default

password. The default password is 12345. The password is case-sensitive.

After successfully logging in, the main menu appears.

6212-A2-GB20-00 May 2004 27

Chapter 4 Basic Configuration

From the Basic menu bar you can change passwords, configure the WAN/LAN interfaces, set

up routing, save settings, reboot the router, and retrieve the factory default settings.

4.1 Software Version Information

Click on Version Information from the Basic menu bar. The screen shows the device name,

software version, and build time. The software version and build time on the screen are for

reference only. The information displayed on this screen may change when a new software file

is upgraded.

28 May 2004 6212-A2-GB20-00

4.2 Change the Password

To modify the password, click on Change Password from the menu bar. Type the old

password and type the new password twice. Click on Apply to submit the settings.

If you change the password, make sure you keep a record of it in a safe place, as you will

require it next time you log in.

6212-A2-GB20-00 May 2004 29

4.3 ADSL Link Status

To view the ADSL link status, click on Link Status from the menu bar. The page includes the

following information:

ADSL Line Status Shows the current status of the ADSL line

ADSL Mode Shows the ADSL standard that is currently configured. The

standards are:

Upstream Upstream data rate negotiated by DSL link (kbs)

Downstream Downstream data rate negotiated by DSL link (kbs)

Attenuation Current attenuation (dB) of both near end and far end.

SNR Margin Current SNR margin (dB)

HEC Count Number of ATM cells received with errors, since start of link.

Firmware The version number of the firmware

15 min ES Counter Number of errored seconds for the current 15-minute period

CRC Errors Number of errors per second since training

1 day ES Counter Number of errored seconds for the current day

MULTI, T1.413, G.DMT, and G.LITE.

30 May 2004 6212-A2-GB20-00

+ 71 hidden pages
