HP 5406-48G zl Switch
1
Power and Fault LEDs
6
LED Mode Select button and indicator LEDs
2
Locator LED
7
Console Port
3
Reset and Clear buttons
8
Auxiliary Port
4
Self Test LED
9
Module Link and Mode LEDs
5
Status LEDs for the Fans, Power Supplies, and Switch Modules
10
Switch Modules and slots with Link and Mode LEDs for each
port located on each module
HP 5406-48G zl Switch Rear View
1
Grounding lug mounting holes
3
AC power connector
2
Power and Fault LEDs
4
Slot for installing optional redundant power supply
5
External PoE power connectors
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 1
Page 2
HP 5412-92G zl Switch
1
Power and Fault LEDs
6
LED Mode Select button and indicator LEDs
2
Locator LED
7
Console Port
3
Reset and Clear buttons
8
Auxiliary Port
4
Self Test LED
9
Module Link and Mode LEDs
5
Status LEDs for the Fans, Power Supplies, and Switch Modules
10
Switch Modules and slots with Link and Mode LEDs for each
port located on each module
HP 5412-92G zl Switch Rear View
1
Grounding lug mounting holes
3
Slot for installing optional redundant power supply
2
Power and Fault LEDs
4
AC power connector
5
External PoE power connectors
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 2
Page 3
Models
HP 5406 zl Switch with Premium Software
J9642A
HP 5412 zl Switch with Premium Software
J9643A
HP 5406-44G-PoE+-2XG v2 zl Switch with Premium Software
J9533A
HP 5412-92G-PoE+-2XG v2 zl Switch with Premium Software
J9532A
HP 5406-44G-PoE+-4G-SFP v2 zl Switch with Premium Software
J9539A
HP 5412-92G-PoE+-4G v2 zl Switch with Premium Software
J9540A
HP 5406 8p 10GBASE-T 8p 10GbE SFP+ v2 zl Switch with Premium Software
J9866A
Key Features
Advanced access layer, distribution, and core
Integrated L2 to L4 intelligent edge feature set
Enterprise-class performance and security
HP AllianceOne integrated
Scalable 10/100/1000 and 10GbE connectivity
Product overview
The HP 5400 zl Switch Series consists of advanced intelligent switches in the HP modular chassis product line, which includes 6-slot
and 12-slot chassis and associated zl modules and bundles. The foundation for the switch series is a purpose-built, programmable
ProVision ASIC that allows the most demanding networking features, such as Quality of Service (QoS) and security, to be implemented
in a scalable yet granular fashion. With 10/100, Gigabit Ethernet, and 10 Gigabit Ethernet interfaces; choice of PoE+ and non-PoE;
integrated Layer 3 features; and HP AllianceOne solutions, the 5400 zl switch series offers excellent investment protection, flexibility,
and scalability, as well as ease of deployment, operation, and maintenance.
Features and Benefits
Software-defined networking
OpenFlow
supports OpenFlow 1.0 and 1.3 specifications to enable SDN by allowing separation of the data (packet forwarding) and control
(routing decision) paths
Quality of Service
(QoS)
Advanced classifier-based QoS
classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority
level and rate limit to selected traffic on a per-port or per-VLAN basis
Layer 4 prioritization
enables prioritization based on TCP/UDP port numbers
Traffic prioritization
allows real-time traffic classification into eight priority levels mapped to eight queues
Bandwidth shaping
Port-based rate limiting
provides per-port ingress-/egress-enforced increased bandwidth
Classifier-based rate limiting
uses an access control list (ACL) to enforce increased bandwidth for ingress traffic on each port
Guaranteed minimum
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 3
Page 4
provides per-port, per-queue egress-based reduced bandwidth
Class of Service
(CoS)
sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number, source
port, and DiffServ
Management
Remote intelligent mirroring
mirrors selected ingress/egress traffic based on ACL, port, MAC address, or VLAN to a local or remote HP 8200 zl, 6600, 6200 yl,
5400 zl, or 3500 Switch located anywhere on the network
RMON, XRMON, and sFlow v5
provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from adjacent devices on a network, facilitating easy mapping by network
management applications
Uni-Directional Link Detection (UDLD)
monitors a cable between two switches and shuts down the ports on both ends if the cable is broken, turning the bidirectional
link into a unidirectional one; this prevents network problems such as loops
Management simplicity
provides common software features and CLI implementation across all HP ProVision-based switches (including the zl and yl
switches)
Command authorization
leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login; an audit trail documents
activity
Friendly port names
allow assignment of descriptive names to ports
Dual flash images
provide independent primary and secondary operating system files for backup while upgrading
Multiple configuration files
can be stored to the flash image
NEW
Comware CLI
Comware-compatible CLI
bridges the experience of Comware CLI users who are using the ProVision software CLI
Display and fundamental Comware CLI commands
are embedded in the switch CLI as native commands; display output formatted as on Comware-based switches;
fundamental commands provide a Comware-familiar initial switch setup
Configuration Comware CLI commands
entered Comware CLI configuration commands elicit CLI help formulating the correct ProVision software CLI command
Connectivity
IEEE 802.3az Energy Efficient Ethernet
lowers power consumption in periods of low link usage (supported on v2 zl 10/100/1000 and 10/100 modules)
IEEE 802.3af Power over Ethernet (PoE)
provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such as IP phones, wireless access points, and
security cameras
IEEE 802.3at Power over Ethernet Plus
provides up to 30 W per port to IEEE 802.3 for PoE- and PoE+-powered devices, such as video IP phones, IEEE 802.11n wireless
access points, and advanced pan/zoom/tilt security cameras
Prestandard PoE support
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 4
Page 5
detects and provides power to prestandard PoE devices; see the list of supported devices in the product FAQ at
www.hp.com/networking
High-density port connectivity
provides up to 12 interface module slots and up to 288 wire-speed 10/100/1000 PoE-enabled ports or 96 10-GbE ports per
system
Jumbo frames
on Gigabit Ethernet and 10-Gigabit Ethernet ports, jumbo frames allow high-performance remote backup and disaster-recovery
services
Auto-MDIX
automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports
IPv6
IPv6 host
enables switches to be managed in an IPv6 network
Dual stack (IPv4 and IPv6)
transitions from IPv4 to IPv6, supporting connectivity for both
protocols
MLD snooping
forwards IPv6 multicast traffic to the appropriate interface
IPv6 ACL/QoS
supports ACL and QoS for IPv6 network traffic
IPv6 routing
supports static and OSPFv3 routing protocols
6in4 tunneling
supports encapsulation of IPv6 traffic in IPv4 packets
Performance
High-speed, high-capacity architecture
1 Tbps crossbar switching fabric provides intra-module and inter-module switching with 585.6 million pps throughput on the
purpose-built ProVision ASICs
Selectable queue configurations
allows for increased performance by selecting the number of queues and associated memory buffering that best meet the
requirements of the network applications
Resiliency and high availability
NEW Virtual Router Redundancy Protocol (VRRP)
allows groups of two routers to dynamically back each other up to create highly available routed environments for IPv4 and IPv6
networks
IEEE 802.1s Multiple Spanning Tree Protocol
provides high link availability in multiple VLAN environments by allowing multiple spanning trees; encompasses IEEE 802.1D
Spanning Tree Protocol and IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.3ad Link Aggregation Control Protocol (LACP) and HP
port trunking
support up to 144 trunks, each with up to eight links (ports) per trunk
Distributed trunking
enables loop-free and redundant network topology without using Spanning Tree Protocol; allows a server or switch to connect
to two switches using one logical trunk for redundancy and load sharing
Optional redundant power supply (HP 5400 series)
provides uninterrupted power and allows hot-swapping of the redundant power supplies when installed
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 5
Page 6
Hot-swappable modules (5400 zl series)
permits modules, mini-GBICs, and power supplies in a redundant power supply configuration to be added or swapped without
interrupting the network
Sparing simplicity
HP zl-common accessories (interface modules and power supplies)
Uplink Failure Detection
provides active-standby network path redundancy for servers that are configured for active-standby NIC teaming
NEW SmartLink
provides easy-to-configure link redundancy of active and standby links
Layer 2 switching
VLAN support and tagging
supports the IEEE 802.1Q standard and 2,048 VLANs simultaneously
IEEE 802.1v protocol VLANs
isolate select non-IPv4 protocols automatically into their own VLANs
GARP VLAN Registration Protocol
allows automatic learning and dynamic assignment of VLANs
IEEE 802.1ad Q-in-Q
increases the scalability of an Ethernet network by providing a hierarchical structure; connects multiple LANs on a high-speed
campus or metro network
MAC-based VLAN
provides granular control and security; uses RADIUS to map a MAC
address/user to specific VLANs (requires v2 modules)
Rapid Per-VLAN Spanning Tree (RPVST+)
allows each VLAN to build a separate spanning tree to improve link bandwidth usage; is compatible with PVST+
HP switch meshing
dynamically load balances across multiple active redundant links to increase available aggregate bandwidth; allows concurrent
Layer 3 routing with v2 modules
Layer 3 services
User Datagram Protocol (UDP) helper function
allows UDP broadcasts to be directed across router interfaces to specific IP unicast or subnet broadcast addresses and prevents
server spoofing for UDP services such as DHCP
Loopback interface address
defines an address in Routing Information Protocol (RIP) and Open Standard Path First (OSPF), improving diagnostic capability
Route maps
provide more control during route redistribution; allow filtering and altering of route metrics
Layer 3 routing
Static IP routing
provides manually configured routing for both IPv4 and IPv6 networks
Routing Information Protocol (RIP)
provides RIPv1 and RIPv2 routing
OSPF
provides OSPFv2 for IPv4 routing and OSPFv3 for IPv6 routing
Policy-based routing
uses a classifier to select traffic that can be forwarded based on policy set by the network administrator (requires v2 modules)
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 6
Page 7
Border Gateway Protocol (BGP)
provides IPv4 Border Gateway Protocol routing, which is scalable, robust, and flexible
Security
Access control lists (ACLs)
provide filtering based on the IP field, source/destination IP address/subnet, and source/destination TCP/UDP port number on
per-VLAN or per-port basis
Multiple user authentication methods
IEEE 802.1X users per port
provides authentication of multiple IEEE 802.1X users per port
Web-based authentication
authenticates from a Web browser for clients that do not support IEEE 802.1X supplicant
MAC-based authentication
client is authenticated with the RADIUS server based on the client's MAC address
Concurrent IEEE 802.1X, Web, and MAC authentication schemes per port
switch port accepts up to 32 sessions of IEEE 802.1X, Web, and MAC authentications
Virus throttling
detects traffic patterns typical of worm-type viruses and either throttles or entirely prevents the virus from spreading across the
routed VLANs or bridged interfaces without requiring external appliances
DHCP protection
blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks
Secure management access
securely encrypts all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3
USB Secure Autorun (requires HP PCM+)
deploys, diagnoses, and updates a switch using a USB flash drive; works with a secure credential to prevent tampering
Switch CPU protection
provides automatic protection against malicious network traffic trying to shut down the switch
ICMP throttling
defeats ICMP denial-of-service attacks by enabling any switch port to automatically throttle ICMP traffic
Identity-driven ACL
enables implementation of a highly granular and flexible access security policy and VLAN assignment specific to each
authenticated network user
STP BPDU port protection
blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks
Dynamic IP lockdown
works with DHCP protection to block traffic from unauthorized hosts, preventing IP source address spoofing
Dynamic ARP protection
blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data
STP Root Guard
protects the root bridge from malicious attacks or configuration mistakes
Detection of malicious attacks
monitors 10 types of network traffic and sends a warning when an anomaly that potentially can be caused by malicious attacks
is detected
Port security
allows access only to specified MAC addresses, which can be learned or specified by the administrator
MAC address lockout
prevents particular configured MAC addresses from connecting to the network
Source-port filtering
allows only specified ports to communicate with each other
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 7
Page 8
RADIUS/TACACS+
eases switch management security administration by using a password authentication server
Secure Shell
encrypts all transmitted data for secure remote CLI access over IP networks
Secure Sockets Layer (SSL)
encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch
Secure FTP
allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a switch
configuration file
Management Interface Wizard
helps secure management interfaces such as SNMP, telnet, SSH, SSL, Web, and USB at the desired level
Switch management logon security
can require either RADIUS or TACACS+ authentication for secure switch CLI logon
Security banner
displays a customized security policy when users log in to the switch
Convergence
IP multicast routing
includes PIM Sparse and Dense modes to route IP multicast traffic
IP multicast snooping
(data-driven IGMP)
automatically prevents flooding of IP multicast traffic
LLDP-MED (Media Endpoint Discovery)
is a standard extension of LLDP that stores values for parameters such as QoS and VLAN to automatically configure network
devices such as IP phones
PoE allocations
support multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user specified) to allocate PoE power for more efficient
energy savings
NEW
Auto VLAN configuration for voice
RADIUS VLAN: uses a standard RADIUS attribute and LLDP-MED to automatically configure a VLAN for IP phones
CDPv2: uses CDPv2 to configure legacy IP phones
NEW Local MAC Authentication
assigns attributes such as VLAN and QoS using locally configured profile that can be a list of MAC prefixes
Warranty and support
Lifetime Warranty 2.0
advance hardware replacement for as long as you own the product with next-business-day delivery (available in most countries)†
Electronic and telephone support (for Lifetime Warranty 2.0)
limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone
support is available from HP for the entire warranty period; to reach our support centers, refer to
www.hp.com/networking/contact-support
; for details on the duration of support provided with your product purchase, refer to
www.hp.com/networking/warrantysummary
Software releases
to find software for your product, refer to
www.hp.com/networking/support
; for details on the software releases available with
your product purchase, refer to
www.hp.com/networking/warrantysummary
†HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 8
Page 9
the Software license and hardware warranty statements at:
www.hp.com/networking/warranty
.
QuickSpecs
HP 5400 zl Switch Series
Overview
DA - 12436 North America — Version 34 — December 9, 2014
Page 9
Page 10
Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP 5406 zl Switch with Premium Software
J9642A
1 Power Supply required
4U - Height
See Configuration
Note:4
HP 5406-44G-PoE+-2XG v2 zl Swch w Pm SW
J9533A
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included (min=0 \ max=2 SFP+
Transceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note:1, 5, 9
PDU CABLE NA/MEX/TW/JP
J9533A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9533A#B2C
C15 PDU Jumper Cord (ROW)C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power CordHigh Volt Switch to Wall Power Cord
J9533A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406 8p10GT 8p10GE Swch and Psw
J9866A
8 RJ-45 10GbE ports
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9546A HP 8-port 10GBASE-T v2 zl Module included
1 - J9538A HP 8-port 10GbE SFP+ v2 zl Module included (min=0 \ max=8 SFP+ Transceivers)
4U - Height
See Configuration
Note:1, 3, 5, 9
PDU CABLE NA/MEX/TW/JP
J9866A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9866A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9866A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406-44G-PoE+-4G v2 zl Swch w Prm SW
J9539A
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port GT PoE+/4-port SFP v2 zl Mod included (min=0 \ max=4 SFP Transceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note:2, 5, 9
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 10
Page 11
PDU CABLE NA/MEX/TW/JP
J9539A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9539A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9539A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406 8p10GT 8p10GE Swch and Psw
J9866A
8 RJ-45 10GbE ports
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9546A HP 8-port 10GBASE-T v2 zl Module included
1 - J9538A HP 8-port 10GbE SFP+ v2 zl Module included (min=0 \ max=8 SFP+ Transceivers)
4U - Height
See Configuration
Note:1, 5, 9
PDU CABLE NA/MEX/TW/JP
J9866A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9866A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9866A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5412 zl Switch with Premium Software
J9643A
2 Power Supplies required
7U - Height
See Configuration
Note:4
HP 5412-92G-PoE+-2XG v2 zl Swch w Pm SW
J9532A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included(min=0 \ max=2 SFP+
Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:1, 5, 9
PDU CABLE NA/MEX/TW/JP
J9532A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9532A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9532A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 11
Page 12
HP 5412-92G-PoE+-4G v2 zl Swch w Prm SW
J9540A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module included (min=0 \ max=4 SFP Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:2, 5, 9
PDU CABLE NA/MEX/TW/JP
J9540A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9540A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9540A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
Configuration Rules:
Note 1
The following Transceivers install into this Chassis :
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable
J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable
J9302A
HP X242 SFP+ 10m DAC Cable
J9286B
HP X242 SFP+ 15m DAC Cable
J9287B
Note 2
The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 12
Page 13
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X111 100M SFP LC FX Transceiver
J9054C
Note 4
If Switch is ordered in a Rack, Then #B2B, or #B2C is defaulted on the Power Supply's. (Optional when Switch is not
Racked. See Drop down remark in "Power Supplies" section.)
Note 5
If #B2E is selected Then replace Localized option with #B2E for power supply and with #B2E for switch . (Offered
only in North America, Mexico Taiwan, and Japan)
Note 9
Localization required on orders without #B2B, #B2C, #B2D or #B2E options.
Box Level Integration CTO Models
CTO Solution Sku
HP 54xx CTO Switch Solution
J9809A
SSP trigger sku
See Configuration
Note:7
CTO Switch Chassis
HP 5406 zl Switch with Premium Software
J9642A
1 Power Supply required
4U - Height
See Configuration
Note:4, 10
HP 5406-44G-PoE+-2XG v2 zl Swch w Pm SW
J9533A
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included (min=0 \ max=2 SFP+
Transceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note:1 , 4, 8, 10,
12
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406-44G-PoE+-4G v2 zl Swch w Prm SW
J9539A
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 13
Page 14
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port GT PoE+/4-port SFP v2 zl Mod included (min=0 \ max=4 SFP Transceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note: 2, 4, 8, 10,
12
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406 8p10GT 8p10GE Swch and Psw
J9866A
8 RJ-45 10GbE ports
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9546A HP 8-port 10GBASE-T v2 zl Module included
1 - J9538A HP 8-port 10GbE SFP+ v2 zl Module included (min=0 \ max=8 SFP+ Transceivers)
4U - Height
See Configuration
Note:1, 4, 8, 10,
12
PDU CABLE NA/MEX/TW/JP
J9866A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9866A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9866A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5412 zl Switch with Premium Software
J9643A
2 Power Supplies required
7U - Height
See Configuration
Note:4
HP 5412-92G-PoE+-2XG v2 zl Swch w Pm SW
J9532A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included(min=0 \ max=2 SFP+
Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:1, 4, 8, 10,
12
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 14
Page 15
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5412-92G-PoE+-4G v2 zl Swch w Prm SW
J9540A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module included (min=0 \ max=4 SFP Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:2, 4, 8, 10,
12
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
Configuration Rules:
Note 1
The following Transceivers install into this Chassis : (Use #0D1 if switch is CTO) - if applicable
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable
J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable
J9302A
HP X242 SFP+ 10m DAC Cable
J9286B
HP X242 SFP+ 15m DAC Cable
J9287B
Note 2
The following Transceivers install into this Chassis : (Use #0D1 if switch is CTO) - if applicable
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 15
Page 16
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X111 100M SFP LC FX Transceiver
J9054C
Note 4
Localization required on orders without #B2B, #B2C, #B2D or #B2E options.
Note 8
If #B2E is selected Then replace Localized option with #B2E for power supply and with #B2E for switch . (Offered
only in North America, Mexico Taiwan, and Japan)
Note 10
If the Switch Chassis is to be Factory Integrated (CTO), Then the #0D1 is required on the Switch Chassis and
integrated to the J9809A - HP 5400 CTO Enablement. (Min 1/Max 1 Switch per SSP)
Note 12
If this Switch is selected, Then a Minimum of 1 factory integrated accessory must be ordered and integrated to CTO
chassis. See Menu below, option must have a #0D1 to be integrated to the CTO Chassis.
Rack Level Integration CTO Models
CTO Switch Chassis
HP 5406 zl Switch with Premium Software
J9642A
1 Power Supply required
4U - Height
See Configuration
Note:11
HP 5406-44G-PoE+-2XG v2 zl Swch w Pm SW
J9533A
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included (min=0 \ max=2 SFP+
ransceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note:1, 4, 11
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406-44G-PoE+-4G v2 zl Swch w Prm SW
J9539A
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 16
Page 17
44 autosensing 10/100/1000 port
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port GT PoE+/4-port SFP v2 zl Mod included (min=0 \ max=4 SFP Transceivers)
1 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
4U - Height
See Configuration
Note:2, 4, 11
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5406 8p10GT 8p10GE Swch and Psw
J9866A
8 RJ-45 10GbE ports
1 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9546A HP 8-port 10GBASE-T v2 zl Module included
1 - J9538A HP 8-port 10GbE SFP+ v2 zl Module included (min=0 \ max=8 SFP+ Transceivers)
4U - Height
See Configuration
Note:1, 4, 11
PDU CABLE NA/MEX/TW/JP
J9866A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9866A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9866A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5412 zl Switch with Premium Software
J9643A
2 Power Supplies required
7U - Height
See Configuration
Note:11
HP 5412-92G-PoE+-2XG v2 zl Swch w Pm SW
J9532A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9536A HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module included(min=0 \ max=2 SFP+
Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:1, 4, 11
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 17
Page 18
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 5412-92G-PoE+-4G v2 zl Swch w Prm SW
J9540A
92 autosensing 10/100/1000 port
2 - J9306A HP 1500 W PoE+ zl Power Supply included
1 - J9535A HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module included (min=0 \ max=4 SFP Transceivers)
3 - J9534A HP 24-port Gig-T PoE+ v2 zl Module included
7U - Height
See Configuration
Note:2, 4, 5, 8
PDU CABLE NA/MEX/TW/JP
#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
Configuration Rules:
Note 1
The following Transceivers install into this Chassis : (Use #0D1 if switch is CTO) - if applicable
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable
J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable
J9302A
HP X242 SFP+ 10m DAC Cable
J9286B
HP X242 SFP+ 15m DAC Cable
J9287B
Note 2
The following Transceivers install into this Chassis : (Use #0D1 if switch is CTO) - if applicable
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 18
Page 19
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X111 100M SFP LC FX Transceiver
J9054C
Note 4
Localization required on orders without #B2B, #B2C, #B2D or #B2E options.
Note 6
If the CTO Base Model is ordered #0D1, Then #B2B, or #B2C is Required on the Power Supply's. (Optional when
Switch is not Factory Racked. See Drop down remark in "Power Supplies" section.)
Note 11
If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate (with #0D1) to the HP
Rack.
Internal Power Supplies
J9642Ax System (std 0 // max 2) User Selection (min 1 / max 2)
J9533Ax, J9866A and J9539Ax System (std 1 // max 2) User Selection (min 0 / max 1)
J9643Ax System (std 0 // max 4) User Selection (min 2 / max 4)
J9532Ax and J9540x System (std 2 // max 4) User Selection (min 0 / max 2)
HP 1500 W PoE+ zl Power Supply
J9306A
C15 Outlet
See Configuration
Note:1, 2, 6
PDU CABLE NA/MEX/TW/JP
J9306A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU CABLE ROW
J9306A#B2C
C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
J9306A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 875W zl Power Supply
J8712A
C15 Outlet
See Configuration
Note:1, 2, 5, 6
PDU CABLE NA/MEX/TW/JP
J8712A#B2B
C15 PDU Jumper Cord (NA/MEX/TW/JP)
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 19
Page 20
High Volt Switch to Wall Power Cord
J8712A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
HP 1500 W zl Power Supply
J8713A
C20 Outlet
See Configuration
Note:1, 2, 5, 6
C19 PDU WW
J8713A#B2D
C19 to C20 Jumper Cord
High Volt Switch to Wall Power Cord
J8713A#B2E
NEMA L6-20P Cord (NA/MEX/JP/TW)
Configuration Rules
:
Note 1
Power Supplies cannot be mixed for a switch enclosure
Note 2
Localization required on orders without #B2B, #B2C or #B2E options.
Note 5
This power supply is not supported on the J9533Ax, J9539Ax, J9532Ax, J9866A and J9540x switches.
Note 6
If #B2E is selected Then replace Localized option with #B2E for power supply and with #B2E for switch . (Offered
only in NA, Mexico,, Taiwan, and Japan)
Remarks:
"Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C ROW.
(Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and Box Level CTO)
High Volt Switch/Router/Power Supply to Wall Power Cord - #B2E Option. (Offered only in North America, Mexico,
Taiwan, and Japan)"
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Modules
J9642x only - System (std 0 // max=6) User Selection (min 0 / max=6) per Chassis
J9643x only - System (std 0 // max=12) User Selection (min 0 / max=12) per Chassis
J9533x, J9539x, J8699x, J9447x, J9866A only - System (std 2 // max=6) User Selection (min 0 / max=4) per Chassis
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 20
Page 21
J8700x, J9532x, J9448x, J9450x only - System (std 4 // max=12) User Selection (min 0 / max=8) per Chassis
HP 20-port GT PoE+/4-port SFP v2 zl Mod
J9535A
min=0 \ max=4 SFP Transceivers
See Configuration
Note:1
HP 24-port SFP v2 zl Module
J9537A
min=0 \ max=24 SFP Transceivers
See Configuration
Note:1
HP 12p Gig-T PoE+/12p SFP v2 zl Mod
J9637A
min=0 \ max=12 SFP Transceivers
See Configuration
Note:1
HP 20-port Gig-T / 4-port SFP v2 zl Mod
J9549A
min=0 \ max=20 SFP Transceivers
See Configuration
Note:1
HP 4-port 10GbE SFP+ zl Module
J9309A
min=0 \ max=4 SFP+ Transceivers
See Configuration
Note:2
HP 8-port 10 GbE SFP+ v2 zl Module
J9538A
min=0 \ max=8 SFP+ Transceivers
See Configuration
Note:5
HP 20p GT PoE+ / 2p SFP+ v2 zl Module
J9536A
min=0 \ max=2 SFP+ Transceivers
See Configuration
Note:5
HP 20-port Gig-T / 2-port SFP+ v2 zl Mod
J9548A
min=0 \ max=2 SFP+ Transceivers
See Configuration
Note:5
HP 4-Port 10 GbE X2 zl Module
J8707A
min=0 \ max=2 X2 Transceivers
See Configuration
Note:3
HP 4-Port 10 GbE CX4 zl Module
J8708A
min=0 \ max=2 CX4 Media Converter
HP 8-port 10GBase-T v2 zl Module
J9546A
No Transceivers
HP 24-Port 10/100/1000 PoE zl Module
J8702A
No Transceivers
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 21
Page 22
HP 20p 10/100/1000 PoE+/4p MGBIC zl Mod
J9308A
No Transceivers
See Configuration
Note:1
HP 20-Port Gig-T/4-Port Mini-GBIC zl Module
J8705A
No Transceivers
See Configuration
Note:12
HP 24-Port Mini-GBIC zl Module
J8706A
No Transceivers
See Configuration
Note:12
HP 24-Port 10/100/1000 PoE+ zl Module
J9307A
No Transceivers
HP 24-port Gig-T PoE+ v2 zl Module
J9534A
No Transceivers
HP 24-Port 10/100 PoE+ zl Module
J9478A
No Transceivers
HP 24-port 10/100 PoE+ v2 zl Module
J9547A
No Transceivers
HP 24-port Gig-T v2 zl Module
J9550A
No Transceivers
HP MSM765 zl Mobility Controller
J9370A
No Transceivers
HP MSM775 zl Premium Controller Module
J9840A
No Transceivers
See Configuration
Note:10
HP Surv Brch Com zl Mod pwrby Msft Lync
J9485A
No Transceivers. Double Height Module, takes up 2 Vertical slots*
See Configuration
Note:4, 6, 7, 8, 9
HP Svc zlMod f/AvayaSBC pwrby AcmePacket
J9486A
No Transceivers. Double Height Module, takes up 2 Vertical slots*
See Configuration
Note:6, 7, 8, 9
HP Advanced Services v2 zl Module w/ HDD
J9857A
No Transceivers
See Configuration
Note:11
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 22
Page 23
HP Advanced Services v2 zl Module w/ SSD
J9858A
No Transceivers
See Configuration
Note:11
HP Adv Srvs zl Mod w/XenServer Platform
J9747A
No Transceivers
See Configuration
Note:6, 7, 8
HP Adv Srvs zl Mod w/vSphere Platform
J9748A
No Transceivers
See Configuration
Note:6, 7, 8
Configuration Rules:
Note 1
The following Transceivers install into this Module: (Use #0D1 if switch is CTO) - if applicable
HP X111 100M SFP LC FX Transceiver
J9054C
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X121 1G SFP RJ45 T Transceiver
J8177C
Note 2
The following Transceivers install into this Module: (Use #0D1 if switch is CTO) - if applicable
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable
J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable
J9302A
HP X242 SFP+ 10m DAC Cable
J9286B
HP X242 SFP+ 15m DAC Cable
J9287B
Note 3
The following Transceivers install into this Module: (Use #0D1 if switch is CTO) - if applicable
HP X131 10G X2 SC SR Transceiver
J8436A
HP X131 10G X2 SC LR Transceiver
J8437A
HP X131 10G X2 SC ER Transceiver
J8438A
HP X131 10G X2 SC LRM Transceiver
J9144A
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 23
Page 24
Note 4
The following Upgrades install into this Module:
Sangoma 2-port T1/E1/J1 Telephony Card
J9488A
Sangoma 4-port T1/E1/J1 Telephony Card
J9489A
Sangoma 4-port FXO Telephony Card
J9516A
Sangoma 4-port FXS Telephony Card
J9482A
Sangoma 2-port FXO / 2-port FXS Telephony Card
J9518A
Sangoma 1-port T1/E1/J1 Telephony Card
J9487A
Note 5
The following Transceivers install into this Module: (Use #0D1 if switch is CTO) - if applicable
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 SFP+ SFP+ 1m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable
J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable
J9302A
Note 6
For Switches: J9643A, J9532A, J9540A; If this module is selected, Then Max = 4 Modules of any combination or
pairing of the following modules: J9517A, J9485A, J9486A, J9289A, J9483A, J9666A, J9747A, J9748A. Double Height
Modules occupy 2 vertical slots.
Note 7
If this module is selected, Then show following message:
For better airflow, This module must be located on left side only in the following Switches: J9642A, J9533A, J9539A,
J9866A.
For better airflow, It is preferred, but not required, that This module be located on left side only in the following
Switches: J9643A, J9532A, J9540A.
Note 8
For Switches J9642A, J9533A, J9539A, J9866A; If this module is selected, Then Max = 3 SLOTS on left side of chassis
only, of any combination or pairing of the following modules: J9517A, J9485A, J9486A, J9289A, J9483A, J9666A,
J9747A, J9748A. Double Height Modules occupy 2 vertical slots.
Note 9
This module occupies 2 Vertical Slots.
Note 10
Maximum of this Module per Chassis:
J9642A min=0\max=5 per Chassis
J9533A, J9539A, J9866A min=0\max=4 per Chassis
J9643A, J9532A, J9540A min=0\max=6 per Chassis
There are no restrictions on which slots these modules may go in.
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 24
Page 25
Note 11
Maximum of this Module per Chassis:
J9642A, J9533A, J9539A, J9866A min=0\max=4 per Chassis
J9643A, J9532A, J9540A min=0\max=6 per Chassis
There are no restrictions on which slots these modules may go in.
Transceivers
SFP Transceivers
HP X111 100M SFP LC FX Transceiver
J9054C
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP LC SX Transceiver
J4858C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X121 1G SFP RJ45 T Transceiver
J8177C
SFP+ Transceivers
HP X132 10G SFP+ LC ER Transceiver
J9153A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X242 10G SFP+ SFP+ 1m DAC Cable
J9281B
HP X242 10G SFP+ SFP+ 3m DAC Cable
J9283B
HP X242 10G SFP+ SFP+ 7m DAC Cable
J9285B
HP X242 10G SFP+ 10m DAC Cable
J9286B
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 25
Page 26
HP X242 10G SFP+ 15m DAC Cable
J9287B
HP X244 10G XFP SFP+ 1m DAC Cable
J9300A
HP X244 10G XFP SFP+ 3m DAC Cable
J9301A
HP X244 10G XFP SFP+ 5m DAC Cable
J9302A
X2 Transceivers
HP X131 10G X2 SC ER Transceiver
J8438A
HP X131 10G X2 SC LR Transceiver
J8437A
HP X131 10G X2 SC LRM Transceiver
J9144A
HP X131 10G X2 SC SR Transceiver
J8436A
Cables
Multi-Mode Cables
HP .5m Multi-mode OM3 LC/LC FC Cable
AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable
AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable
AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable
AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable
AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable
AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable
AJ839A
HP Premier Flex LC/LC OM4 2f 1m Cbl
QK732A
HP Premier Flex LC/LC OM4 2f 2m Cbl
QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl
QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl
QK735A
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 26
Page 27
HP Premier Flex LC/LC OM4 2f 30m Cbl
QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl
QK737A
Switch Enclosure Options
External Redundant Power Supplies
HP zl Power Supply Shelf
J8714A
Height = 3U
Cofiguration Rules:
Note 1
This shelf allows the addition of 2 extra J9306A - HP 1500 W PoE+ zl Power Supply in order to increase the number
of POE+ ports.
Remarks:
Cables included: includes two 2 m PoE (EPS) cables; cables can be used to carry PoE power to the connected switch;
no extra cables are needed for a complete solution. Flexible mounting: the power shelf can be mounted forward or
rear facing in a rack; in a four-post rack, two power shelves can be mounted front to front, requiring only 3U of rack
space.
License
HP MSM760/765 Additional 40 AP License
J9371A
Remarks:
The License is an option to the J9370A.
Survivable Branch Communication Upgrades
Sangoma 2-port T1/E1/J1 Telephony Card
J9488A
Sangoma 4-port T1/E1/J1 Telephony Card
J9489A
Sangoma 4-port FXO Telephony Card
J9516A
Sangoma 4-port FXS Telephony Card
J9482A
Sangoma 2-port FXO / 2-port FXS Telephony Card
J9518A
Sangoma 1-port T1/E1/J1 Telephony Card
J9487A
Remarks:
The Sangoma Telephony Cards are accessories to the J9485A.
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 27
Page 28
US Federal Government certifications
HP zl Chassis FIPS 10K Rack Mounting Kit
J9708A
See Configuration
Note:1
HP 16mm x 32mm Tmpr-Evidence (20) Labels
J9740A
See Configuration
Note:1
HP 16mm x 32mm Tmpr-Evidence (120) Label
J9709A
See Configuration
Note:1
HP 5406 zl FIPS Opacity Shield Kit
J9710A
See Configuration
Note:1
HP 5412 zl FIPS Opacity Shield Kit
J9711A
See Configuration
Note:1
HP 5406 zl High Performance Fan Tray
J9721A
See Configuration
Note:1
HP 5412 zl High Performance Fan Tray
J9722A
See Configuration
Note:1
Cofiguration Rules:
Note 1
Do not display in Watson.
QuickSpecs
HP 5400 zl Switch Series
Configuration
DA - 12436 North America — Version 34 — December 9, 2014
Page 28
Page 29
HP 5406 zl Switch with
Premium Software
(J9642A)
I/O ports and slots
6 open module slots
Supports a maximum of 48 10-GbE ports or 144 autosensing 10/100/1000
ports or 144 mini-GBICs, or a combination
Power supplies
2 power supply slots
1 minimum power supply required (ordered separately)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 6.9(h) in (44.45 x 45.09 x
17.53 cm) (4U height)
Weight
23.55 lb (10.68 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash,
128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 282.1 million pps
Routing/Switching
capacity
379.2 Gbps
Switch fabric speed
379.2 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Achieved Miercom Certified Green Award
Description
Chassis ships without power supplies. Two power
supply slots are available; three different power
supplies are available. See power supply products
for additional specifications.
Maximum heat
dissipation
2450 BTU/hr (2584 kJ/hr), (max. non-PoE); 3700
BTU/hr (3903 kJ/hr) (max. using PoE)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 29
Page 30
Voltage
100-127/200-240 VAC
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY909E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY910E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY911E)
3-year, 24x7 SW phone support, software updates (UY912E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW452E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW453E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW454E)
4-year, 24x7 SW phone support, software updates (UW455E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW473E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW474E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW475E)
5-year, 24x7 SW phone support, software updates (UY938E)
3 Yr 6 hr Call-to-Repair Onsite (UY913E)
4 Yr 6 hr Call-to-Repair Onsite (UW456E)
5 Yr 6 hr Call-to-Repair Onsite (UY939E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR599E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR600E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR603E)
1-year, 24x7 software phone support, software updates (HR602E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR601E)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 30
Page 31
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS738E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS739E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS740E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS741E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS742E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS743E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS744E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS745E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5412 zl Switch with
Premium Software
(J9643A)
I/O ports and slots
12 open module slots
Supports a maximum of 96 10-GbE ports or 288 autosensing 10/100/1000
ports or 288 mini-GBICs, or a combination
Power supplies
4 power supply slots
2 minimum power supplies required (ordered separately)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 12.1(h) in (44.45 x 45.09 x
30.73 cm) (7U height)
Weight
34.94 lb (15.85 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash
Mb, 128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 564.2 million pps
Routing/Switching
capacity
758.4 Gbps
Switch fabric speed
758.4 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 31
Page 32
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
Chassis ships without power supplies. Four power
supply slots are available; three different power
supplies are available. See power supply products
for additional specifications.
Maximum heat
dissipation
4900 BTU/hr (5169 kJ/hr), (max. non-PoE); 7400
BTU/hr (7,807 kJ/hr) (max. using PoE)
Voltage
100-127/200-240 VAC
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY914E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY915E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY916E)
3-year, 24x7 SW phone support, software updates (UW440E)
Installation with minimum configuration, system-based pricing (U4828E)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 32
Page 33
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW457E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW458E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW459E)
4-year, 24x7 SW phone support, software updates (UW460E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UY940E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UY917E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UY918E)
5-year, 24x7 SW phone support, software updates (UY919E)
3 Yr 6 hr Call-to-Repair Onsite (UW441E)
4 Yr 6 hr Call-to-Repair Onsite (UW461E)
5 Yr 6 hr Call-to-Repair Onsite (UY920E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR604E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR605E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR608E)
1-year, 24x7 software phone support, software updates (HR607E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR606E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS746E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS747E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS749E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS750E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS751E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS752E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS753E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5406-44G-PoE+-2XG
v2 zl Switch with Premium
Software
(J9533A)
Included accessories
1 HP 20-port Gig-T PoE+ / 2-port 10GbE SFP+ v2 zl Module (J9536A)
1 HP 1500W PoE+ zl Power Supply (J9306A)
1 HP 24-port Gig-T PoE+ v2 zl Module (J9534A)
Ports
44 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 33
Page 34
1000BASE-T: full only
2 open 10-GbE SFP+ transceiver slots
4 open module slots
Supports a maximum of 16 10-GbE ports or 140 autosensing 10/100/1000
ports or 100 mini-GBICs, or a combination
Power supplies
2 power supply slots
1 minimum power supply required
includes: 1 x J9306A (HP 1500W PoE+ zl Power Supply)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 6.9(h) in (44.45 x 45.09 x
17.53 cm) (4U height)
Weight
46.08 lb (20.9 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash,
128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 282.1 million pps
Routing/Switching
capacity
379.2 Gbps
Switch fabric speed
379.2 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
One J9306A installed. One open power supply slot
is available; three different power supplies are
available. See power supply products for
additional specifications.
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 34
Page 35
Maximum heat
dissipation
2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE);
3700 BTU/hr (3903 kJ/hr) (max. using PoE)
Voltage
100-127/200-240 VAC
Idle power
215 W
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY909E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY910E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY911E)
3-year, 24x7 SW phone support, software updates (UY912E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW452E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW453E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW454E)
4-year, 24x7 SW phone support, software updates (UW455E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW473E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW474E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW475E)
5-year, 24x7 SW phone support, software updates (UY938E)
3 Yr 6 hr Call-to-Repair Onsite (UY913E)
4 Yr 6 hr Call-to-Repair Onsite (UW456E)
5 Yr 6 hr Call-to-Repair Onsite (UY939E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR599E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR600E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR603E)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 35
Page 36
1-year, 24x7 software phone support, software updates (HR602E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR601E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS738E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS739E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS740E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS741E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS742E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS743E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS744E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS745E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5412-92G-PoE+-2XG
v2 zl Switch with Premium
Software
(J9532A)
Included accessories
3 HP 24-port Gig-T PoE+ v2 zl Module (J9534A)
1 HP 20-port Gig-T PoE+ / 2-port 10GbE SFP+ v2 zl Module (J9536A)
2 HP 1500W PoE+ zl Power Supply (J9306A)
I/O ports and slots
92 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
2 open 10-GbE SFP+ transceiver slots
8 open module slots
Supports a maximum of 32 10-GbE ports or 284 autosensing 10/100/1000
ports or 196 mini-GBICs, or a combination
Power supplies
4 power supply slots
2 minimum power supplies required
includes: 2 x J9306A (HP 1500W PoE+ zl Power Supply)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 12.1(h) in (44.45 x 45.09 x
30.73 cm) (7U height)
Weight
75.36 lb (34.18 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash
Mb, 128 MB compact flash, 256 MB DDR SDRAM
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 36
Page 37
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 564.2 million pps
Routing/Switching
capacity
758.4 Gbps
Switch fabric speed
758.4 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
Two J9306A installed. Two open power supply
slots are available; three different power supplies
are available. See power supply products for
additional specifications.
Maximum heat
dissipation
4900 BTU/hr (5169.5 kJ/hr), (max. non-PoE);
7400 BTU/hr (7807 kJ/hr) (max. using PoE)
Voltage
110-127/200-240 VAC
Idle power
312 W
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 37
Page 38
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY914E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY915E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY916E)
3-year, 24x7 SW phone support, software updates (UW440E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW457E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW458E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW459E)
4-year, 24x7 SW phone support, software updates (UW460E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UY940E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UY917E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UY918E)
5-year, 24x7 SW phone support, software updates (UY919E)
3 Yr 6 hr Call-to-Repair Onsite (UW441E)
4 Yr 6 hr Call-to-Repair Onsite (UW461E)
5 Yr 6 hr Call-to-Repair Onsite (UY920E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR604E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR605E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR608E)
1-year, 24x7 software phone support, software updates (HR607E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR606E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS746E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS747E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS749E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS750E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS751E)
5-year, 24x7 software phone support, software updates + Next Business Day
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 38
Page 39
Hardware Exchange (HS752E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS753E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5406-44G-PoE+-4GSFP v2 zl Switch with
Premium Software
(J9539A)
Included accessories
1 HP 24-port Gig-T PoE+ v2 zl Module (J9534A)
1 HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module (J9535A)
1 HP 1500W PoE+ zl Power Supply (J9306A)
Ports
44 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 open mini-GBIC slots
4 open module slots
Supports a maximum of 16 10-GbE ports or 140 autosensing 10/100/1000
ports or 100 mini-GBICs, or a combination
Power supplies
2 power supply slots
1 minimum power supply required
includes: 1 x J9306A (HP 1500W PoE+ zl Power Supply)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 6.9(h) in (44.45 x 45.09 x
17.53 cm) (4U height)
Weight
45.58 lb (20.68 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash,
128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 282.1 million pps
Routing/Switching
capacity
379.2 Gbps
Switch fabric speed
379.2 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 39
Page 40
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
One J9306A installed. One open power supply slot
is available; three different power supplies are
available. See power supply products for
additional specifications.
Maximum heat
dissipation
2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE);
3700 BTU/hr (3903 kJ/hr) (max. using PoE)
Voltage
110-127/200-240 VAC
Idle power
215 W
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY909E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY910E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY911E)
3-year, 24x7 SW phone support, software updates (UY912E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW452E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW453E)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 40
Page 41
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW454E)
4-year, 24x7 SW phone support, software updates (UW455E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW473E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW474E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW475E)
5-year, 24x7 SW phone support, software updates (UY938E)
3 Yr 6 hr Call-to-Repair Onsite (UY913E)
4 Yr 6 hr Call-to-Repair Onsite (UW456E)
5 Yr 6 hr Call-to-Repair Onsite (UY939E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR599E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR600E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR603E)
1-year, 24x7 software phone support, software updates (HR602E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR601E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS738E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS739E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS740E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS741E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS742E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS743E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS744E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS745E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5412-92G-PoE+-4G v2
zl Switch with Premium
Software
(J9540A)
Included accessories
HP 24-port Gig-T PoE+ v2 zl Module (J9534A)
1 HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module (J9535A)
2 HP 1500W PoE+ zl Power Supply (J9306A)
Ports
92 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
4 open mini-GBIC slots
8 open module slots
Supports a maximum of 32 10-GbE ports or 284 autosensing 10/100/1000
ports or 196 mini-GBICs, or a combination
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 41
Page 42
Power supplies
4 power supply slots
2 minimum power supplies required
includes: 2 x J9306A (HP 1500W PoE+ zl Power Supply)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 12.1(h) in (44.45 x 45.09 x
30.73 cm) (7U height)
Weight
74.86 lb (33.96 kg)
Memory and processor
Gigabit Module
ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR
SDRAM
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash
Mb, 128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 564.2 million pps
Routing/Switching
capacity
758.4 Gbps
Switch fabric speed
758.4 Gbps
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
Two J9306A installed. Two open power supply
slots are available; three different power supplies
are available. See power supply products for
additional specifications.
Maximum heat
dissipation
4900 BTU/hr (5169.5 kJ/hr), (max. non-PoE);
7400 BTU/hr (7807 kJ/hr) (max. using PoE)
Voltage
110-127/200-240 VAC
Idle power
312 W
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 42
Page 43
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY914E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY915E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UY916E)
3-year, 24x7 SW phone support, software updates (UW440E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW457E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW458E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW459E)
4-year, 24x7 SW phone support, software updates (UW460E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UY940E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UY917E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UY918E)
5-year, 24x7 SW phone support, software updates (UY919E)
3 Yr 6 hr Call-to-Repair Onsite (UW441E)
4 Yr 6 hr Call-to-Repair Onsite (UW461E)
5 Yr 6 hr Call-to-Repair Onsite (UY920E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR604E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR605E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR608E)
1-year, 24x7 software phone support, software updates (HR607E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR606E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS746E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 43
Page 44
exchange (HS747E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS748E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS749E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS750E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS751E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS752E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS753E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5406 8p 10GBASE-T 8p
10GbE SFP+ v2 zl Switch
with Premium Software
(J9866A)
Included accessories
1 HP 8-port 10GbE SFP+ v2 zl Module (J9538A)
1 HP 1500W PoE+ zl Power Supply (J9306A)
1 HP 8-port 10GBASE-T v2 zl Module (J9546A)
Ports
8 RJ-45 10GbE ports (IEEE 802.3an-2006 Type 10GBASE-T)
8 open 10GbE SFP+ transceiver slots
4 open module slots
Supports a maximum of 32 10GbE ports or 96 autosensing 10/100/1000 ports
or 96 mini-GBICs, or a combination
Power supplies
2 power supply slots
1 minimum power supply required
includes: 1 x J9306A (HP 1500W PoE+ zl Power Supply)
Physical characteristics
Dimensions
17.5(w) x 17.75(d) x 6.9(h) in (44.45 x 45.09 x
17.53 cm) (4U height)
Weight
46.08 lb (20.9 kg)
Memory and processor
10G module
ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR
SDRAM
Management Module
Freescale PowerPC 8540 @ 666 MHz, 4 MB flash,
128 MB compact flash, 256 MB DDR SDRAM
Mounting
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware
included); horizontal surface mounting only
Performance
1000 Mb Latency
< 3.7 µs (FIFO 64-byte packets)
10 Gbps Latency
< 2.1 µs (FIFO 64-byte packets)
Throughput
up to 282.1 Mpps
Routing/Switching
capacity
379.2 Gb/s
Switch fabric speed
379.2 Gb/s
Routing table size
10000 entries (IPv4), 5000 entries (IPv6)
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 44
Page 45
MAC address table size
64000 entries
Environment
Operating temperature
32°F to 131°F (0°C to 55°C); 0°C to 40°C with
J8706A or J8707A modules installed
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO
9296
Electrical characteristics
Frequency
50/60 Hz
Description
One J9306A product is installed. One open power
supply slot is available; three different power
supplies are available. See power supply products
for additional specifications.
Maximum heat
dissipation
2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE);
3700 BTU/hr (3903 kJ/hr) (max. using PoE)
Voltage
110-127/200-240 VAC
Idle power
215 W
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; >95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
HP PCM+; HP PCM (included); command-line interface; Web browser;
configuration menu; out-of-band management (serial RS-232C)
Notes
Supported 1G SFP transceivers are revision "B" or later (product number ends
with the letter "B" or later; for example, J9142B, J8177C).
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY909E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY910E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 45
Page 46
and SW updates (UY911E)
3-year, 24x7 SW phone support, software updates (UY912E)
Installation with minimum configuration, system-based pricing (U4828E)
Installation with HP-provided configuration, system-based pricing (U4832E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW452E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW453E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW454E)
4-year, 24x7 SW phone support, software updates (UW455E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW473E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW474E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UW475E)
5-year, 24x7 SW phone support, software updates (UY938E)
3 Yr 6 hr Call-to-Repair Onsite (UY913E)
4 Yr 6 hr Call-to-Repair Onsite (UW456E)
5 Yr 6 hr Call-to-Repair Onsite (UY939E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR599E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR600E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR603E)
1-year, 24x7 software phone support, software updates (HR602E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR601E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS738E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS739E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS740E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS741E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS742E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS743E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS744E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS745E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
Standards and protocols
BGP
RFC 1997 BGP Communities Attribute
RFC 2918 Route Refresh Capability
RFC 4271 A Border Gateway Protocol 4 (BGP-4)
RFC 4456 BGP Route Reflection: An Alternative to
Full Mesh Internal BGP (IBGP)
RFC 5492 Capabilities Advertisement with BGP-4
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 46
Page 47
Device Management
RFC 1591 DNS (client)
HTML and telnet management
General Protocols
IEEE 802.1ad Q-in-Q
IEEE 802.1AX-2008 Link Aggregation
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1v VLAN classification by Protocol and
Port
IEEE 802.1w Rapid Reconfiguration of Spanning
Tree
IEEE 802.3ad Link Aggregation Control Protocol
(LACP)
IEEE 802.3af Power over Ethernet
IEEE 802.3x Flow Control
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 868 Time Protocol
RFC 951 BOOTP
RFC 1058 RIPv1
RFC 1350 TFTP Protocol (revision 2)
RFC 1519 CIDR
RFC 1542 BOOTP Extensions
RFC 2030 Simple Network Time Protocol (SNTP)
v4
RFC 2131 DHCP
RFC 2453 RIPv2
RFC 2548 (MS-RAS-Vendor only)
RFC 3046 DHCP Relay Agent Information Option
RFC 3576 Ext to RADIUS (CoA only)
RFC 3768 VRRP
RFC 4675 RADIUS VLAN & Priority
UDLD (Uni-directional Link Detection)
IP Multicast
RFC 3376 IGMPv3 (host joins only)
RFC 3973 PIM Dense Mode
RFC 4601 PIM Sparse Mode
IPv6
RFC 1981 IPv6 Path MTU Discovery
RFC 2375 IPv6 Multicast Address Assignments
RFC 2460 IPv6 Specification
RFC 2464 Transmission of IPv6 over Ethernet
Networks
RFC 2710 Multicast Listener Discovery (MLD) for
IPv6
RFC 2925 Definitions of Managed Objects for
Remote Ping, Traceroute, and Lookup Operations
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 47
Page 48
(Ping only)
RFC 3019 MLDv1 MIB
RFC 3315 DHCPv6 (client and relay)
RFC 3484 Default Address Selection for IPv6
RFC 3587 IPv6 Global Unicast Address Format
RFC 3596 DNS Extension for IPv6
RFC 3810 MLDv2 for IPv6
RFC 4022 MIB for TCP
RFC 4087 IP Tunnel MIB
RFC 4113 MIB for UDP
RFC 4213 Basic Transition Mechanisms for IPv6
Hosts and Routers
RFC 4251 SSHv6 Architecture
RFC 4252 SSHv6 Authentication
RFC 4253 SSHv6 Transport Layer
RFC 4254 SSHv6 Connection
RFC 4291 IP Version 6 Addressing Architecture
RFC 4293 MIB for IP
RFC 4294 IPv6 Node Requirements
RFC 4419 Key Exchange for SSH
RFC 4443 ICMPv6
RFC 4541 IGMP & MLD Snooping Switch
RFC 4861 IPv6 Neighbor Discovery
RFC 4862 IPv6 Stateless Address Autoconfiguration
RFC 5095 Deprecation of Type 0 Routing Headers
in IPv6
RFC 5340 OSPFv3 for IPv6
RFC 5453 Reserved IPv6 Interface Identifiers
RFC 5519 Multicast Group Membership Discovery
MIB (MLDv2 only)
RFC 5722 Handling of Overlapping IPv6
Fragments
MIBs
IEEE 802.1ap (MSTP and STP MIB's only)
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 1724 RIPv2 MIB
RFC 1850 OSPFv2 MIB
RFC 2021 RMONv2 MIB
RFC 2096 IP Forwarding Table MIB
RFC 2613 SMON MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2668 802.3 MAU MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2737 Entity MIB (Version 2)
RFC 2787 VRRP MIB
RFC 2863 The Interfaces Group MIB
RFC 2925 Ping MIB
RFC 2933 IGMP MIB
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 48
Page 49
Network Management
IEEE 802.1AB Link Layer Discovery Protocol
(LLDP)
RFC 2819 Four groups of RMON: 1 (statistics), 2
(history), 3 (alarm) and 9 (events)
RFC 3176 sFlow
ANSI/TIA-1057 LLDP Media Endpoint Discovery
(LLDP-MED)
SNMPv1/v2c/v3
XRMON
OSPF
RFC 2328 OSPFv2
RFC 3101 OSPF NSSA
RFC 5340 OSPFv3 for IPv6
QoS/CoS
RFC 2474 DiffServ Precedence, including 8
queues/port
RFC 2597 DiffServ Assured Forwarding (AF)
RFC 2598 DiffServ Expedited Forwarding (EF)
Security
IEEE 802.1X Port Based Network Access Control
RFC 1492 TACACS+
RFC 2865 RADIUS (client only)
RFC 2866 RADIUS Accounting
RFC 3579 RADIUS Support For Extensible
Authentication Protocol (EAP)
Secure Sockets Layer (SSL)
SSHv2 Secure Shell
QuickSpecs
HP 5400 zl Switch Series
Technical Specifications
DA - 12436 North America — Version 34 — December 9, 2014
Page 49
Page 50
HP 5400 zl Switch Series
accessories
Modules
HP 8-port 10GBase-T v2 zl Module
J9546A
HP 4-Port 10 GbE CX4 zl Module
J8708A
HP 4-Port 10 GbE X2 zl Module
J8707A
HP 4-Port 10 GbE SFP+ zl Module
J9309A
HP 8-port 10 GbE SFP+ v2 zl Module
J9538A
HP 20-port Gig-T PoE+/2-port 10-GbE SFP+ v2 zl Module
J9536A
HP 20-port Gig-T PoE+/4-port SFP v2 zl Module
J9535A
HP 24-port SFP v2 zl Module
J9537A
HP 12-port Gig-T PoE+/12-port SFP v2 zl Module
J9637A
HP 24-Port 10/100/1000 PoE zl Module
J8702A
HP 20-Port 10/100/1000 PoE+/4-Port Mini-GBIC zl Module
J9308A
HP 20-Port Gig-T/4-Port Mini-GBIC zl Module
J8705A
HP 24-Port Mini-GBIC zl Module
J8706A
HP 24-Port 10/100/1000 PoE+ zl Module
J9307A
HP 24-port Gig-T PoE+ v2 zl Module
J9534A
HP 24-Port 10/100 PoE+ zl Module
J9478A
HP 24-port 10/100 PoE+ v2 zl Module
J9547A
HP 24-port Gig-T v2 zl Module
J9550A
HP 20-port Gig-T/4-port SFP v2 zl Module
J9549A
HP 20-port Gig-T/2-port 10-GbE SFP+ v2 zl Module
J9548A
HP Extended Services zl Module with Riverbed Steelhead RiOS™ Application
J9517A
HP Survivable Branch Communication zl Module powered by Microsoft® Lync
J9485A
HP Services zl Module for Avaya Aura Session Border Controller powered by Acme
Packet
J9486A
NEW
HP Advanced Services v2 zl Module with HDD
J9857A
HP Advanced Services v2 zl Module with SSD
J9858A
Transceivers
HP X131 10G X2 SC ER Transceiver
J8438A
HP X130 CX4 Optical Media Converter
J8439A
HP X131 10G X2 SC SR Transceiver
J8436A
HP X131 10G X2 CX4 Transceiver
J8440C
HP X111 100M SFP LC FX Transceiver
J9054B
HP X131 10G X2 SC LR Transceiver
J8437A
HP X131 10G X2 SC LRM Transceiver
J9144A
HP X112 100M SFP LC BX-D Transceiver
J9099B
HP X112 100M SFP LC BX-U Transceiver
J9100B
HP X132 10G SFP+ LC SR Transceiver
J9150A
HP X132 10G SFP+ LC LR Transceiver
J9151A
HP X132 10G SFP+ LC LRM Transceiver
J9152A
QuickSpecs
HP 5400 zl Switch Series
Accessories
DA - 12436 North America — Version 34 — December 9, 2014
Page 50
Page 51
HP X121 1G SFP LC LH Transceiver
J4860C
HP X121 1G SFP LC SX Transceiver
J4858C
HP X121 1G SFP LC LX Transceiver
J4859C
HP X121 1G SFP RJ45 T Transceiver
J8177C
HP X122 1G SFP LC BX-D Transceiver
J9142B
HP X122 1G SFP LC BX-U Transceiver
J9143B
HP X132 10G SFP+ LC ER Transceiver
J9153A
Cables
HP X242 SFP+ SFP+ 1 m Direct Attach Cable
J9281B
HP X242 SFP+ SFP+ 3 m Direct Attach Cable
J9283B
HP X242 SFP+ SFP+ 7 m Direct Attach Cable
J9285B
HP X242 SFP+ to SFP+ 10m Direct Attach Copper Cable
J9286B
HP X242 SFP+ to SFP+ 15m Direct Attach Copper Cable
J9287B
HP X244 XFP SFP+ 1 m Direct Attach Cable
J9300A
HP X244 XFP SFP+ 3 m Direct Attach Cable
J9301A
HP X244 XFP SFP+ 5 m Direct Attach Cable
J9302A
HP 0.5 m Multimode OM3 LC/LC Optical Cable
AJ833A
HP 1 m Multimode OM3 LC/LC Optical Cable
AJ834A
HP 2 m Multimode OM3 LC/LC Optical Cable
AJ835A
HP 5 m Multimode OM3 LC/LC Optical Cable
AJ836A
HP 15 m Multimode OM3 LC/LC Optical Cable
AJ837A
HP 30 m Multimode OM3 LC/LC Optical Cable
AJ838A
HP 50 m Multimode OM3 LC/LC Optical Cable
AJ839A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
QK732A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable
QK733A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable
QK734A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable
QK735A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable
QK736A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable
QK737A
HP X242 10G SFP+ to SFP+ 10m Direct Attach Copper Cable
J9286B
HP X242 10G SFP+ to SFP+ 15m Direct Attach Copper Cable
J9287B
Power Supply
HP 1500 W PoE+ zl Power Supply
J9306A
HP 1500 W zl Power Supply
J8713A
HP 875 W zl Power Supply
J8712A
EPS/RPS
HP zl Power Supply Shelf
J8714A
License
HP MSM760/765 40-Access Point License
J9371A
HP 5400 zl Switch Premium License
J8994A
WLAN
QuickSpecs
HP 5400 zl Switch Series
Accessories
DA - 12436 North America — Version 34 — December 9, 2014
Page 51
Page 52
NEW
HP MSM775 zl Premium Controller Module
J9840A
HP MSM765zl Mobility Controller
J9370A
QuickSpecs
HP 5400 zl Switch Series
Accessories
DA - 12436 North America — Version 34 — December 9, 2014
Page 52
Page 53
NOTE:
Details are not available for all accessories. The following specifications were available at the time of publication.
HP 8-port 10GBase-T v2 zl
Module
(J9546A)
Ports
8 RJ-45 10-GbE ports; Duplex: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Full configuration weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Fiber type
Single Mode
Notes
Max Distance upto 100m with qualified 10Gbase-T Cat7(Shielded), Cat6a
(Shielded/Unshielded) and Cat6 (Shielded, tested to 350Mhz TIA/EIA TSB155A) cables. Max Distance upto 55m with Cat6 (unshielded, tested to 350Mhz
TIA/EIA TSB-155A)
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 4-Port 10 GbE CX4 zl
Module (J8708A)
Ports
4 CX4 10-GbE ports (IEEE 802.3ak Type 10GBASE-CX4); Duplex: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
1.74 lb. (0.79 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Cabling
Maximum distance:
• 15 m using CX4 cable
• 300 m using optical media converters and multimode fiber cable
Notes
Use CX4 10-GbE cable (0.5 m-15 m) or HP ProCurve 10-GbE CX4 Media
Converter (J8439A).
No CX4 cables are included with this module.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 53
Page 54
HP 4-Port 10 GbE X2 zl
Module
(J8707A)
Ports
4 open 10-GbE X2 transceiver slots
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
1.74 lb. (0.79 kg)
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Notes
When installed in a zl chassis, the J8707A module limits the operating
temperature range of the chassis to 32°F to 104°F (0°C to 40°C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 4-Port 10 GbE SFP+ zl
Module
(J9309A)
Ports
4 open 10-GbE SFP+ transceiver slots
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
1.64 lb. (0.74 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 113°F (45°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Notes
When installed in a zl chassis, the J9309A module limits the operating
temperature range of the chassis to 32F to 113F (0C to 45C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 8-port 10 GbE SFP+ v2
zl Module
(J9538A)
Ports
8 open 10-GbE SFP+ transceiver slots
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.09 lb (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 54
Page 55
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9538A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 20-port Gig-T PoE+/2port 10-GbE SFP+ v2 zl
Module
(J9536A)
Ports
2 open 10-GbE SFP+ transceiver slots
20 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9308A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 55
Page 56
HP 20-port Gig-T PoE+/4port SFP v2 zl Module
(J9535A)
Ports
4 open mini-GBIC (SFP) slots
20 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9308A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 24-port SFP v2 zl
Module
(J9537A)
Ports
24 open mini-GBIC (SFP) slots
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.01 lb. (0.91 kg)
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When installed in a zl chassis, the J8706A module limits the operating
temperature range of the chassis to 32°F to 104°F (0°C to 40°C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 56
Page 57
HP 12-port Gig-T
PoE+/12-port SFP v2 zl
Module
(J9637A)
Ports
12 open mini-GBIC (SFP) slots
12 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9308A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 24-port 10/100/1000
PoE zl Module
(J8702A)
Ports
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.16 lb. (0.98 kg)
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 57
Page 58
HP 20-Port 10/100/1000
PoE+/4-Port Mini-GBIC zl
Module (J9308A)
Ports
4 open mini-GBIC (SFP) slots
20 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9308A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 20-port Gig-T / 4-port
Mini-GBIC zl Module
(J8705A)
Ports
4 open mini-GBIC (SFP) slots
20 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.2 lb. (1 kg)
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J8705A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 58
Page 59
HP 24-port Mini-GBIC zl
Module
(J8706A)
Ports
24 open mini-GBIC (SFP) slots
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.01 lb. (0.91 kg)
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When installed in a zl chassis, the J8706A module limits the operating
temperature range of the chassis to 32°F to 104°F (0°C to 40°C).
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 24-Port 10/100/1000
PoE+ zl Module (J9307A)
Ports
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.0 lb. (0.98 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (-40°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 59
Page 60
HP 24-port Gig-T PoE+ v2
zl Module (J9534A)
Ports
24 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.0 lb. (0.98 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (-40°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 24-Port 10/100 PoE+ zl
Module
(J9478A)
Ports
24 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX); Media Type: Auto-MDIX; Duplex: half or full
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.0 lb. (0.98 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
100BASE-TX: Category 5 (or better), 100 O unshielded twisted pair (UTP) or
shielded twisted pair (STP), complying with IEEE 802.3u 100BASE-TX;
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 60
Page 61
HP 24-port 10/100 PoE+
v2 zl Module
(J9547A)
Ports
24 RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3at PoE+); Media Type: Auto-MDIX;
Duplex: half or full
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.0 lb. (0.98 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
100BASE-TX: Category 5 (or better), 100 O differential unshielded twisted pair
(UTP) or shielded twisted pair (STP), complying with IEEE 802.3u 100BASE-TX;
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 24-port Gig-T v2 zl
Module
(J9550A)
Ports
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.0 lb. (0.98 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (-40°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 61
Page 62
HP 20-port Gig-T/4-port
SFP v2 zl Module
(J9549A)
Ports
4 open mini-GBIC (SFP) slots
20 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9549A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 20-port Gig-T/2-port
10-GbE SFP+ v2 zl Module
(J9548A)
Ports
2 open 10-GbE SFP+ transceiver slots
20 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x
4.45 cm)
Weight
2.1 lb. (0.95 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 O differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 62
Page 63
Notes
When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, e.g., J4858B, J4859C) are
required.
When mini-GBICs are inserted in any mini-GBIC slot of a J9308A, this limits the
operating temperature range of the chassis to 32F to 104F (0C to 40C).
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP Extended Services zl
Module with Riverbed
Steelhead
RiOS™ Application
(J9517A)
Physical characteristics
Dimensions
9.75(d) x 8.13(w) x 3.5(h) in. (24.77 x 20.65 x 8.89
cm)
Weight
4.5 lb. (2.04 kg)
Environment
Operating temperature
32ºF to 122ºF (0ºC to 50ºC);
Important
: See
NOTE
for 50°C temperature spec rules
Operating relative
humidity
15% to 90% @ 122ºF (50ºC), non-condensing
Non-operating/
Storage temperature
14ºF to 149ºF (-10ºC to 65ºC)
Non-operating/
Storage relative humidity
15% to 95% @ 149ºF (65ºC), non-condensing
Alitude
up to 10,000 ft. (3 km)
Notes
5400 series switches operating temperature specifications apply to when the
services module is installed; 40°C when any services module is installed in the
right side of the chassis, and 50°C when all services modules are installed in
the left side.
Up to four services modules can be installed in a 5412zl/8212zl chassis
simultaneously.
When the services module is installed, the maximum relative humidity for the
switch drops from 95% to 90%.
This product does not support Riverbed Services Platform (RSP) functionality.
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UZ154E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UZ155E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UZ156E)
3-year, 24x7 SW phone support, software updates (UZ157E)
3 Yr 6 hr Call-to-Repair Onsite (UZ158E)
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 63
Page 64
HP Survivable Branch Communication zl Module powered by Microsoft® Lync
(J9485A)
Ports
1 USB 2.0
Physical characteristics
Dimensions
9.75(d) x 8.13(w) x 3.5(h) in. (24.77 x 20.65 x 8.89 cm)
Weight
4.5 lb. (2.04 kg)
Environment
Operating temperature
32°F to 122°F (0°C to 50°C); Important: See note for 50°C temperature spec
rules
Operating relative
humidity
15% to 90% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
14°F to 149°F (-10°C to 65°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Notes
HP 5400 zl chassis operating temperature specifications when the services module is installed: 45°C when
any services module is installed in the right side of the chassis, 50°C when all services modules are
installed in the left side of the chassis.
Up to four services modules can be installed in an HP 5412 zl/8212 zl Switch chassis simultaneously. Up to
two services modules can be installed in an HP 5406 zl/8206 zl Switch chassis simultaneously.
When the services module is installed, the maximum relative humidity for the switch drops from 95% to
90%.
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY932E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY933E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support and SW updates (UY934E)
3-year, 24x7 SW phone support, software updates (UY935E)
3 Yr 6 hr Call-to-Repair Onsite (UY936E)
Refer to the HP website at:
www.hp.com/networking/services
for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP Services zl Module for Avaya Aura Session Border Controller powered by Acme Packet
(J9486A)
Physical characteristics
Dimensions
9.75(d) x 8.13(w) x 3.5(h) in. (24.77 x 20.65 x 8.89 cm)
Weight
4.5 lb. (2.04 kg)
Environment
Operating temperature
32°F to 122°F (0°C to 50°C); Important: See note for 50°C temperature spec
rules
Operating relative
humidity
15% to 90% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
14°F to 149°F (-10°C to 65°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Notes
HP 5400zl chassis operating temperature specifications when the services module is installed: 45°C when
any services module is installed in the right side of the chassis, 50°C when all services modules are
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 64
Page 65
installed in the left side of the chassis.
Up to four services modules can be installed in an HP 5412zl/8212zl Switch chassis simultaneously.
Up to two services modules can be installed in an HP 5406zl/8206zl Switch chassis simultaneously.
When the services module is installed, the maximum relative humidity for the switch drops from 95% to
90%.
The SBC software and licenses are procured from Avaya or Avaya authorized resellers.
This product does not support Avaya Aura SBC HA functionality.
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UY492E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UY493E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support and SW updates (UY494E)
3-year, 24x7 SW phone support, software updates (UY496E)
3 Yr 6 hr Call-to-Repair Onsite (UY495E)
Refer to the HP website at:
www.hp.com/networking/services
for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP Advanced Services v2 zl Module with HDD (J9857A)
Physical characteristics
Dimensions
8.13(w) x 9.75(d) x 1.75(h) in (20.65 x 24.77 x 4.45 cm) (1U height)
Weight
3.00 lb (1.36 kg)
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Electrical characteristics
Maximum heat
dissipation
133/287 BTU/hr (140.32/302.78 kJ/hr)
Idle power
84 W
Maximum power rating
39 W
Management
command-line interface
Notes
The services module can be used with VMware certified applications.
• The HDD has a maximum operational wet bulb temperature of 28°C
• The HDD has a maximum non-operational wet bulb temperature of 28°C
• Up to four services modules can be installed in a 5406 zl chassis. There are no restrictions on where the
modules can go in the chassis
• Up to three services modules can be installed in an 8206 zl chassis. There are no restrictions on where
the modules can go in the chassis
• Up to six services modules can be installed in a 5412 or 8212 zl chassis. There are no restrictions on
where the modules can go in the chassis
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the service-level
descriptions and product numbers. For details about services and response times
in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 65
Page 66
HP Advanced Services v2 zl Module with SSD (J9858A)
Physical characteristics
Dimensions
8.13(w) x 9.75(d) x 1.75(h) in (20.65 x 24.77 x 4.45 cm) (1U height)
Weight
2.75 lb (1.36 kg)
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km)
Electrical characteristics
Maximum heat
dissipation
133/290 BTU/hr (140.32/280.63 kJ/hr)
Idle power
85 W
Maximum power rating
37 W
Management
command-line interface
Notes
The services module can be used with VMware certified applications.
• The SSD has a maximum operational wet bulb temperature of 28°C
• The SSD has a maximum non-operational wet bulb temperature of 28°C
• Up to four services modules can be installed in a 5406 zl chassis. There are no restrictions on where the
modules can go in the chassis
• Up to three services modules can be installed in an 8206 zl chassis. There are no restrictions on where
the modules can go in the chassis
• Up to six services modules can be installed in a 5412 or 8212 zl chassis. There are no restrictions on
where the modules can go in the chassis
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the service-level
descriptions and product numbers. For details about services and response times
in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 66
Page 67
HP X131 10G X2 SC ER
Transceiver (J8438A)
HP X131 10G X2 SC ER
Transceiver: An X2 format
10-gigabit transceiver with
SC connectors using ER
technology.
Ports
1 SC 10-GbE port (IEEE 802.3ae Type 10GBASE-ER); Duplex: full only
Connectivity
Connector type
SC
Wavelength
1550 nm
Physical characteristics
Dimensions
3.48(d) x 1.42(w) x 0.43(h) in. (8.84 x 3.61 x 1.09
cm)
Weight
0.35 lb. (0.16 kg)
Transceiver form factor
X2
Environment
Operating temperature
32ºF to 104ºF (0ºC to 40ºC)
Operating relative
humidity
15% to 95%, noncondensing
Electrical characteristics
Power consumption
typical
3 W
Power consumption
maximum
4.5 W
Cabling
Cable type::
Low metal content, single-mode fiber-optic, complying with ITU-T G.652 and
ISO/IEC 793-2 Type B1;
Cable length
2m to 30km (max 40km on engineered links)
Fiber type
Single Mode
Notes
Conditioning patch cord cables are not supported
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X130 CX4 Optical
Media Converter (J8439A)
An optical media converter
that connects to CX4 ports,
providing 10-Gigabit
connectivity up to 300 m
on multimode fiber.
Physical characteristics
Dimensions: 2.83(d) x 0.98(w) x 0.59(h) in. (7.19 x 2.49 x 1.5 cm)
Weight: 0.06 lb. (0.03 kg)
Cabling
Maximum distance:
62.5 µm multimode cable @ 150 MHz*km = 1-50 meters
50 µm multimode cable @ 500 MHz*km = 1-100 meters
50 µm multimode cable @ 2000 MHz*km = 1-300 meters
Notes
Duplex: full
The CX4 Media Converter connects directly to the CX4 port, and a 12-strand
multimode ribbon cable is used between CX4 Media Converters.
The 12-strand multimode ribbon cable can have either 62.5 or 50 micron core
diameters, terminated by standard Multiple Terminations Push-pull Latch
(MTP) connectors in a crossover configuration. The ribbon cables are known as
Multi-fiber Push (MPO).
Users should specify a "crossover" (often called "key up/key up")
configuration for the ribbon cable. Also, specify female-female cables to
connect to HP 10-GbE CX4 Media Converters.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 67
Page 68
For a suggested vendor of MPO ribbon cables, please see the "Cabling"
answers on the "HP 10-GbE Transceivers
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X131 10G X2 SC SR
Transceiver
(J8436A)
HP X131 10G X2 SC SR
Transceiver: An X2 format
10-gigabit transceiver with
SC connectors using SR
technology.
Ports
1 SC 10-GbE port (IEEE 802.3ae Type 10GBASE-SR); Duplex: full only
Connectivity
Connector type
SC
Wavelength
850 nm
Physical characteristics
Dimensions
3.48(d) x 1.42(w) x 0.43(h) in. (8.84 x 3.61 x 1.09
cm)
Weight
0.35 lb. (0.16 kg)
Transceiver form factor
X2
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Nonoperating/Storage
relative humidity
0% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
1.7 W
Power consumption
maximum
2.4 W
Cabling
Cable type::
62.5/125 µm or 50/125 µm (core/cladding) graded-index, low metal content,
multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2 Type
A1b or A1a, respectively;
Maximum distance:
2-26m with 62.5 µm multimode cable @ 160 MHz*km
2-33m with 62.5 µm multimode cable @ 200 MHz*km
2-66m with 50 µm multimode cable @ 400 MHz*km
2-82m with 50 µm multimode cable @ 500 MHz*km
2-300m with 50 µm multimode cable @ 2000 MHz*km
Cable length
2-300m
Fiber type
Multi Mode
Notes
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 68
Page 69
HP X131 10G X2 CX4
Transceiver (J8440C)
HP X131 10G X2 CX4
Transceiver: An X2 format
10-gigabit CX4 transceiver.
Ports
1 CX4 10-GbE port (IEEE 802.3ak Type 10GBASE-CX4); Duplex: full only
Connectivity
Connector type
CX4
Physical characteristics
Dimensions
3.54(d) x 1.42(w) x 0.53(h) in. (8.99 x 3.61 x 1.35
cm)
Weight
0.18 lb. (0.08 kg)
Environment
Operating temperature
32ºF to 131ºF (0ºC to 55ºC)
Operating relative
humidity
15% to 95% @ 149ºF (65ºC), non-condensing
Cabling
Maximum distance:
15 m using CX4 cables
300 m using optical media converters and multimode fiber cable
Notes
Use CX4 10-GbE cable (0.5-15 m) or ProCurve 10-GbE CX4 Media Converter
(J8439A).
Includes a single 0.5 m cable.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X111 100M SFP LC FX
Transceiver
(J9054B)
HP X111 100M SFP LC FX
Transceiver: An SFP format
100-megabit transceiver
with LC connectors using
FX technology.
Ports
1 LC 100BASE-FX port (IEEE 802.3u Type 100BASE-FX); Duplex: half or full
Physical characteristics
Dimensions: 2.7(d) x 0.54(w) x 0.48(h) in. (6.86 x 1.38 x 1.22 cm)
Weight: 0.06 lb. (0.03 kg)
Environment
Operating temperature: 32ºF to 158ºF (0ºC to 70ºC)
Operating relative humidity: 5% to 95%
Nonoperating/Storage temperature: -40ºF to 185ºF (-40ºC to 85ºC)
Nonoperating/Storage relative humidity: 5% to 85%
Altitude: up to 10,000 ft. (3 km)
Cabling
Type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low
metal content, multimode fiber optic, complying with ITU-T G.651 and
ISO/IEC 793-2 Type A1b or A1a, respectively;
Maximum distance:
2 km (full duplex) or 412 m (half duplex)
Notes
Transmitter wavelength: 1310nm
Power consumption is 1.1 watt maximum.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the J9054B 100-FX SFP-LC
Transceiver" on the "HP Mini-GBICs and SFPs" Manuals Web page.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services and
response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 69
Page 70
HP X131 10G X2 SC LR
Transceiver
(J8437A)
An X2 form-factor
transceiver that supports
the 10-Gigabit LR standard,
providing 10-Gigabit
connectivity up to 10 km
on single-mode fiber.
Ports
1 SC 10-GbE port (IEEE 802.3ae Type 10GBASE-LR); Duplex: full only
Connectivity
Connector type
SC
Wavelength
1310 nm
Physical characteristics
Dimensions
3.48(d) x 1.42(w) x 0.43(h) in. (8.84 x 3.61 x 1.09
cm)
Weight
0.35 lb. (0.16 kg)
Transceiver form factor
X2
Environment
Operating temperature
32ºF to 104ºF (0ºC to 40ºC)
Operating relative
humidity
15% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
2 W
Power consumption
maximum
3 W
Cabling
Cable type::
Low metal content, single-mode fiber-optic, complying with ITU-T G.652 and
ISO/IEC 793-2 Type B1;
Maximum distance:
10 km
Cable length
2m to 10km with 9/125 ìm single-mode cable
Fiber type
Single Mode
Notes
Conditioning patch cord cables are not supported
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 70
Page 71
HP X131 10G X2 SC LRM
Transceiver
(J9144A)
An X2 form-factor
transceiver that supports
the 10-Gigabit LRM
standard, providing 10Gigabit connectivity up to
220 m on legacy
multimode fiber.
Ports
1 SC 10-GbE port (IEEE 802.3aq Type 10GBASE-LRM); Duplex: full only
Physical characteristics
Dimensions
3.54(d) x 1.59(w) x 0.7(h) in. (9.0 x 4.05 x 1.78 cm)
Weight
0.35 lb. (0.16 kg)
Transceiver form factor
X2
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
3.2 W
Power consumption
maximum
4.2 W
Cabling
Cable type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low metal
content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2
Type A1b or A1a, respectively (a mode conditioning patch cord may be needed
in some multimode fiber installations);
Maximum distance:
• 0.5-220m with 62.5 µm multimode cable @ 160/500 MHz*km
• 0.5-220m with 62.5 µm multimode cable @ 200/500 MHz*km
• 0.5-100m with 50 µm multimode cable @ 400/400 MHz*km
• 0.5-220m with 50 µm multimode cable @ 500/500 MHz*km
• 0.5-220m with 50 µm multimode cable @ 1500/500 MHz*km
Cable length
.5m to 220m
Fiber type
Multi Mode
Notes
Wavelength: 1310nm
For OM3 cable (50 ìm multimode @ 1500/500 MHz*km), a mode-conditioning
patch cord is not required. Other multimode cables may require modeconditioning patch cords to achieve the maximum distances listed above.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the J9144A 10-GbE X2-SC LRM
Optic" on the "HP 10-GbE Transceivers" Manuals Web page.
Power Consumption: 4W Max
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 71
Page 72
HP X112 100M SFP LC BX-D
Transceiver
(J9099B)
A small form-factor
pluggable (SFP) 100Megabit BX (bi-directional)
"downstream" transceiver
that provides 100 Mbps
full-duplex connectivity up
to 10 km on one strand of
singlemode fiber. The
J9099B connects to the
J9100B "upstream"
transceiver, or to any IEEEstandard 100BASE-BX10-U
("upstream") device.
Ports
1 LC 100BASE-BX10 port (IEEE 802.3ah Type 100BASE-BX10-D); Duplex: full
only
Physical characteristics
Dimensions
2.7(d) x 0.55(w) x 0.48(h) in. (6.86 x 1.39 x 1.22
cm)
Weight
0.04 lb. (0.03 kg)
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Cabling
Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
0.5-10,000 m (single-mode fiber)
Notes
Transmit wavelength: 1550 nm. Receive wavelength: 1310 nm.
Power consumption is 1.1 watt maximum.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the HP BX Transceivers" on the
"HP Mini-GBICs and SFPs" Manuals Web page.
The J9099B connects to the J9100B "upstream" transceiver, or to any IEEEstandard 100BASE-BX10-U ("upstream") device. (A 100-BX-D transceiver can
only connect to a 100-BX-U product. You cannot connect two 100-BX-D
transceivers together.)
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X112 100M SFP LC BX-U
Transceiver
(J9100B)
A small form-factor
pluggable (SFP) 100Megabit BX (bi-directional)
"upstream" transceiver
that provides 100 Mbps
full-duplex connectivity up
to 10 km on one strand of
singlemode fiber. The
J9100B connects to the
J9099B "downstream"
transceiver, or to any IEEEstandard 100BASE-BX10-D
("downstream")
device.
Ports
1 LC 100BASE-BX10 port (IEEE 802.3ah Type 100BASE-BX10-U); Duplex: full
only
Physical characteristics
Dimensions
2.7(d) x 0.55(w) x 0.48(h) in. (6.86 x 1.39 x 1.22
cm)
Weight
0.07 lb. (.03 kg)
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Cabling
Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 72
Page 73
0.5-10,000 m (single-mode fiber)
Notes
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the HP BX Transceivers" on the
"HP Mini-GBICs and SFPs" Manuals Web page.
The J9100B connects to the J9099B "downstream" transceiver, or to any IEEEstandard 100BASE-BX10- D ("downstream") device. (A 100-BX-U transceiver
can only connect to a 100-BX-D product. You cannot connect two 100-BX-U
transceivers together.)
Transmit wavelength: 1310 nm. Receive wavelength: 1550 nm.
Power consumption is 1.1 watts maximum.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X132 10G SFP+ LC SR
Transceiver
(J9150A)
A 10-Gigabit transceiver in
SFP+ form-factor that
supports the 10-Gigabit SR
standard, providing 10Gigabit connectivity up to
300 m on multimode fiber.
Ports
1 LC 10-GbE port (IEEE 802.3ae Type 10Gbase-SR); Duplex: full only
Connectivity
Connector type
LC
Wavelength
850 nm
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.47(h) in. (5.57 x 1.38 x 1.19
cm)
Weight
0.04 lb. (0.02 kg)
Transceiver form factor
SFP+
Environment
Operating temperature
32°F to 158°F (0°C to 70°C)
Operating relative
humidity
0% to 85%, noncondensing
Nonoperating/Storage
temperature
-40°F to 185°F (-40°C to 85°C)
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
0.6 W
Power consumption
maximum
0.8 W
Cabling
Cable type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low metal
content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2
Type A1b or A1a, respectively;
Maximum distance:
2-26m with 62.5 µm multimode cable @ 160 MHz*km
2-33m with 62.5 µm multimode cable @ 200 MHz*km
2-66m with 50 µm multimode cable @ 400 MHz*km
2-82m with 50 µm multimode cable @ 500 MHz*km
2-300m with 50 µm multimode cable @ 2000 MHz*km
Cable length
2-300m
Fiber type
Multi Mode
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 73
Page 74
Notes
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended.
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X132 10G SFP+ LC LR
Transceiver
(J9151A)
A 10-Gigabit transceiver in
SFP+ form-factor that
supports the 10-Gigabit LR
standard, providing 10Gigabit connectivity up to
10 km on single-mode
fiber.
Ports
1 LC 10-GbE port (IEEE 802.3ae Type 10Gbase-LR); Duplex: full only
Connectivity
Connector type
LC
Wavelength
1310 nm
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.47(h) in. (5.57 x 1.38 x 1.19
cm)
Weight
0.04 lb. (.02 kg)
Transceiver form factor
SFP+
Environment
Operating temperature
32°F to 158°F (0°C to 70°C)
Operating relative
humidity
0% to 85%, noncondensing
Nonoperating/Storage
temperature
-40°F to 185°F (-40°C to 85°C)
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
0.9 W
Power consumption
maximum
1 W
Cabling
Cable type:
Low metal content, single-mode fiber-optic, complying with ITU-T G.652 and
ISO/IEC 793-2 Type B1;
Maximum distance:
2m-10km with 9/125 µm single-mode cable
Cable length
2m to 10km
Fiber type
Single Mode
Notes
Conditioning patch cord cables are not supported.
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended.
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 74
Page 75
HP X132 10G SFP+ LC LRM
Transceiver (J9152A)
A 10-Gigabit transceiver in
SFP+ form-factor that
supports the 10-Gigabit
LRM standard, for 10Gigabit connectivity up to
220 m on legacy
multimode fiber.
Ports
1 LC 10-GbE port (IEEE 802.3aq Type 10Gbase-LRM); Duplex: full only
Connectivity
Connector type
LC
Wavelength
1310 nm
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.47(h) in. (5.57 x 1.38 x 1.19
cm)
Weight
0.04 lb. (.02 kg)
Transceiver form factor
SFP+
Environment
Operating temperature
32°F to 158°F (0°C to 70°C)
Operating relative
humidity
0% to 85%, noncondensing
Nonoperating/Storage
temperature
-40°F to 185°F (-40°C to 85°C)
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
0.7 W
Power consumption
maximum
1 W
Cabling
Cable type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low metal
content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2
Type A1b or A1a, respectively (a mode conditioning patch cord may be needed
in some multimode fiber installations);
Maximum distance:
0.5-220m with 62.5 µm multimode cable @ 160/500 MHz*km
0.5-220m with 62.5 µm multimode cable @ 200/500 MHz*km
0.5-100m with 50 µm multimode cable @ 400/400 MHz*km
0.5-220m with 50 µm multimode cable @ 500/500 MHz*km
0.5-220m with 50 µm multimode cable @ 1500/500 MHz*km
Cable length
0.5m to 220m
Fiber type
Multi Mode
Notes
For OM3 cable (50 µm multimode @ 1500/500 MHz*km), a mode-conditioning
patch cord is not required. Other multimode cables may require modeconditioning patch cords to achieve the maximum distances listed above.
For fiber patch cords, use Ultra Physical Contact (UPC) surface
termination/polish. Angled Physical Contact (APC) is not recommended.
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 75
Page 76
HP X121 1G SFP LC LH
Transceiver
(J4860C)
A small form-factor
pluggable (SFP) Gigabit LH
transceiver that provides a
full-duplex Gigabit solution
up to 70 km on singlemode fiber.
Ports
1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics); Duplex:
full only
Physical characteristics
Dimensions: 2.17(d) x 0.60(w) x 0.46(h) in. (5.5 x 1.53 x 1.18 cm)
Weight: 0.04 lb. (0.02 kg)
Environment
Operating temperature: -40°F to 185°F (-40°C to 85°C)
Operating relative humidity: 0% to 95% @ 77°F (25°C), noncondensing
Nonoperating/Storage temperature: -40°F to 185°F (-40°C to 85°C)
Altitude: up to 10,000 ft. (3 km)
Cabling
Cable type:
Low metal content, single-mode fiber-optic, complying with ITU-T
G.652 and ISO/IEC 793-2 Type B1;
Maximum distance:
10-70,000 m (single-mode fiber)
Notes
Power consumption is 0.8 watts typical with 1 watt maximum at 100%
utilization.
For distances less than 20 km, a 10 dB attenuator must be used.
For distances between 20 km and 40 km, a 5 dB attenuator must be used.
Attenuators can be purchased from most cable vendors.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services and
response times in your area, please contact your local HP sales office.
HP X121 1G SFP LC SX
Transceiver
(J4858C)
A small form-factor
pluggable (SFP) Gigabit SX
transceiver that provides a
full-duplex Gigabit solution
up to 550 m on multimode
fiber.
Ports
1 LC 1000BASE-SX port; Duplex: full only
Physical characteristics
Dimensions: 2.24(d) x 0.54(w) x 0.48(h) in. (5.69 x 1.37 x 1.22 cm)
Weight: 0.04 lb. (0.02 kg)
Transceiver form factor: SFP
Environment
Operating temperature: 32°F to 158°F (0°C to 70°C)
Operating relative humidity: 5% to 85%, noncondensing
Nonoperating/Storage temperature: -40°F to 203°F (-40°C to 85°C)
Altitude: up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption typical: 0.4 W
Power consumption maximum: 0.7 W
Cabling
Type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low
metal content, multimode fiber optic, complying with ITU-T G.651 and
ISO/IEC 793-2 Type A1b or A1a, respectively;
Maximum distance:
2-220 m (62.5 µm core diameter, 160 MHz*km bandwidth
2-275 m (62.5 µm core diameter, 200 MHz*km bandwidth
2-500 m (50 µm core diameter, 400 MHz*km bandwidth)
2-550 m (50 µm core diameter, 500 MHz*km bandwidth)
Cable length: 2-550m
Fiber type: Multi Mode
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 76
Page 77
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services and
response times in your area, please contact your local HP sales office.
HP X121 1G SFP LC LX
Transceiver (J4859C)
HP X121 1G SFP LC LX
Transceiver: An SFP format
gigabit transceiver with LC
connectors using LX
technology.
Ports
1 LC 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX); Duplex: full only
Physical characteristics
Dimensions: 2.24(d) x 0.54(w) x 0.486(h) in. (5.69 x 1.37 x 1.23 cm)
Weight:0.04 lb. (0.02 kg)
Environment
Operating temperature: 32°F to 158°F (0°C to 70°C)
Operating relative humidity: 0% to 85%, noncondensing
Nonoperating/Storage temperature: -40°F to 212°F (-40°C to 100°C)
Altitude: up to 10,000 ft. (3 km)
Cabling
Type:
Either single mode or multimode; 62.5/125 µm or 50/125 µm
(core/cladding) diameter, graded-index, low metal content, multimode
fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2 Type A1b or
A1a, respectively; Low metal content, single-mode fiber-optic,
complying with ITU-T G.652 and ISO/IEC 793-2 Type B1;
Maximum distance:
2-550 m (multimode 62.5 µm core diameter, 500 MHz*km bandwidth)
2-550 m (multimode 50 µm core diameter, 400 MHz*km bandwidth)
2-550 m (multimode 50 µm core diameter, 500 MHz*km bandwidth)
2-10,000 m (single-mode fiber)
Notes
A mode conditioning patch cord may be needed in some multimode fiber
installations.
Wavelength: 1310nm
Power Consumption: < 500mW Typical
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services and
response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 77
Page 78
HP X121 1G SFP RJ45 T
Transceiver
(J8177C)
HP X121 1G SFP RJ45 T
Transceiver: An SFP format
gigabit transceiver with
RJ45 connectors using
1000BaseT technology.
Ports
1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T); Duplex: full only
Physical characteristics
Dimensions: 2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)
Weight: 0.06 lb. (0.03 kg)
Environment
Operating temperature: 32°F to 158°F (0°C to 70°C); with 100 LFM airflow over
the SFP module
Operating relative humidity: 0% to 95% @ 75°F (25°C), noncondensing
Nonoperating/Storage temperature: -40°F to 185°F (-40°C to 85°C)
Nonoperating/Storage relative humidity: 0% to 95% @ 77°F (25°C),
noncondensing
Altitude: up to 10,000 ft. (3000 km)
Cabling
Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced,
complying with IEEE 802.3ab 1000BASE-T;
Maximum distance:
100 m
Notes
Power consumption is nominally 1 watt.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the J8177C 1000Base-T MiniGBIC" on the "HP Mini-GBICs and SFPs" Manuals Web page.
The J8177C Gigabit copper mini-GBIC is not supported on dual-personality
ports.
The J8177C is capable of 100 Mb operation. This is supported on only the HP
8200zl, 5400zl, and HP 6200-24G-mGBIC yl Switches using software version
K.12.21 or later. Use the "auto-100" port setting to enable 100 Mb operation.
Important: The earlier J8177B does not support 100 Mb operation. When used
in the Switch gl 20-Port 10/100/1000 Module (J4908A), the J8177C mini-GBIC
can be installed in either the upper or lower mini-GBIC
port, but will block access to the other port.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 78
Page 79
HP X122 1G SFP LC BX-D
Transceiver
(J9142B)
A small form-factor
pluggable (SFP) Gigabit-BX
(bi-directional)
"downstream" transceiver
that provides a full-duplex
Gigabit solution up to 10
km on one strand of
single-mode fiber. The
J9142B connects to the
J9143B "upstream"
transceiver, or to any IEEEstandard 1000BASE-BX10U ("upstream") device.
Ports
1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-D); Duplex:
full only
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.46(h) in. (5.57 x 1.37 x 1.18
cm)
Weight
0.04 lb. (0.02 kg)
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, non-condensing
Non-operating/
Storage temperature
–40ºF to 185ºF –40ºC to 85ºC)
Cabling
Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
0.5-10,000 m (single-mode fiber)
Notes
Transmit wavelength: 1490 nm. Receive wavelength: 1310 nm.
Power consumption is 1 watt maximum.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the HP BX Transceivers" on the
"HP Mini-GBICs and SFPs" Manuals Web page.
The J9142B connects to the J9143B "upstream" transceiver, or to any IEEEstandard 1000BASE-BX10-U ("upstream") device. (A 1000-BX-D transceiver
can only connect to a 1000-BX-U product. You cannot connect two 1000-BX-D
transceivers together.)
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X122 1G SFP LC BX-U
Transceiver (J9143B)
A small form-factor
pluggable (SFP) Gigabit-BX
(bi-directional) "upstream"
transceiver that provides a
full-duplex Gigabit solution
up to 10 km on one strand
of single-mode fiber. The
J9143B connects to the
J9142B "downstream"
transceiver, or to any IEEEstandard 1000BASE-BX10D ("downstream")
device.
Ports
1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U); Duplex:
full only
Physical characteristics
Dimensions
2.19(d) x 0.54(w) x 0.46(h) in. (5.57 x 1.37 x 1.18
cm)
Weight
0.04 lb. (0.02 kg)
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, non-condensing
Non-operating/
Storage temperature
–40ºF to 185ºF –40ºC to 85ºC)
Cabling
Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
0.5-10,000 m (single-mode fiber)
Notes
Transmit wavelength: 1310 nm. Receive wavelength: 1490 nm.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 79
Page 80
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the HP BX Transceivers" on the
"HP Mini-GBICs and SFPs" Manuals Web page.
The J9143B connects to the J9142B "downstream" transceiver, or to any IEEEstandard 1000BASE-BX10-D ("downstream") device. (A 1000-BX-U
transceiver can only connect to a 1000-BX-D product. You cannot connect two
1000-BX-U transceivers together.)
Power consumption is 1 watt maximum.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X132 10G SFP+ LC ER
Transceiver
(J9153A)
Ports
1 LC 10-GbE port (IEEE 802.3ae Type 10GBASE-ER); Duplex: full only
Connectivity
Connector type
LC
Wavelength
1550 nm
Physical characteristics
Dimensions
2.22(d) x 0.55(w) x 0.47(h) in. (5.65 x 1.39 x 1.19
cm)
Weight
.04 lb., Fully loaded
Transceiver form factor
SFP+
Environment
Operating temperature
32°F to 158°F (0°C to 70°C)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
-40°F to 185°F (-40°C to 85°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Power consumption
typical
1.3 W
Power consumption
maximum
1.5 W
Cabling
Cable type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
40km
Fiber type
Single Mode
Notes
Check switch release notes for minimum version of software required to
support this transceiver.
Some switches have limits as to how many of this particular transceiver can
be installed. See the release notes of the switch software/firmware being
used for more details.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 80
Page 81
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X242 SFP+ SFP+ 1 m
Direct Attach Cable
(J9281B)
Connectivity
Length
3.28 ft. (1 m)
Physical characteristics
Weight
0.24 lb. (0.11 kg) the cable with an SFP+
transceiver at each end of the cable
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
14ºF to 185ºF (-10ºC to 85ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Notes
0.04 watts maximum per transceiver end
Notes
Electrical Properties
• Cable Characteristic Impedance: 100 ohms
• Crosstalk between pairs: 2% max
• Time delay: 1.31 nsec/ft
Physical Properties
• Cable Diameter: 0.180"
• Minimum Cable Bend Radius: 1.0"
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X242 SFP+ SFP+ 3 m
Direct Attach Cable
(J9283B)
Connectivity
Length
10 ft. (3 m)
Physical characteristics
Weight
.49 lb. (0.22 kg), Fully loaded the cable with an
SFP+ transceiver at each end of the cable
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
14ºF to 185ºF (-10ºC to 85ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Notes
0.04 watts maximum per transceiver end
Notes
Electrical Properties
• Cable Characteristic Impedance: 100 ohms
• Crosstalk between pairs: 2% max
• Time delay: 1.31 nsec/ft
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 81
Page 82
Physical Properties
• Cable Diameter: 0.180"
• Minimum Cable Bend Radius: 1.0"
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X242 SFP+ SFP+ 7 m
Direct Attach Cable
(J9285B)
Connectivity
Length
22.97 ft. (7 m)
Physical characteristics
Weight
1.02 lb., Fully loaded the cable with an SFP+
transceiver at each end of the cable
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
14ºF to 185ºF (-10ºC to 85ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Notes
0.04 watts maximum per transceiver end
Notes
Electrical Properties
• Cable Characteristic Impedance: 100 ohms
• Crosstalk between pairs: 2% max
• Time delay: 1.31 nsec/ft
Physical Properties
• Cable Diameter: 0.180"
• Minimum Cable Bend Radius: 1.0"
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 82
Page 83
HP X242 SFP+ to SFP+ 10m
Direct Attach Copper
Cable
(J9286B)
Connectivity
Length
32.82 ft. (10 m)
Physical characteristics
Dimensions
12(d) x 15(w) x 3(h) in. (30.48 x 38.1 x 7.62 cm)
Weight
0.99 lb. (0.45 kg), Fully loaded the cable with an
SFP+ transceiver at each end of the cable
Environment
Operating temperature
23°F to 185°F (-5°C to 85°C)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
14°F to 185°F (-10°C to 85°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Maximum power rating
1.2 W
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
0.6 watts maximum per transceiver end
Notes
Electrical Properties:
• Cable Characteristic Impedance: 100 ohms
Physical Properties:
• Cable Diameter: 0.185"
• Minimum Cable Bend Radius: .555"
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X242 SFP+ to SFP+ 15m
Direct Attach Copper
Cable (J9287B)
Connectivity
Length
49.20 ft. (15 m)
Physical characteristics
Dimensions
12(d) x 15(w) x 3(h) in. (30.48 x 38.1 x 7.62 cm)
Weight
1.74 lb. (0.79 kg), Fully loaded the cable with an
SFP+ transceiver at each end of the cable
Environment
Operating temperature
23°F to 185°F (-5°C to 85°C)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
14°F to 185°F (-10°C to 85°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Maximum power rating
1.2 W
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 83
Page 84
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
0.6 watts maximum per transceiver end
Notes
Electrical Properties:
• Cable Characteristic Impedance: 100 ohms
Physical Properties:
• Cable Diameter: 0.255"
• Minimum Cable Bend Radius: 0.765"
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X244 XFP SFP+ 1 m
Direct Attach Cable
(J9300A)
A 1m direct attach copper
cable with an XFP
connector attached on one
end and an SFP+ connector
attached on the other end.
This cable
provides a low price
connectivity option
between switches/servers/
storage to interconnect
XFP and SFP+ form factors.
Connectivity
Length
3.28 ft. (1 m)
Physical characteristics
Weight
.27 lb. (0.12 kg), Fully loaded cable with XFP
transcevier on one end and SFP+ on the other end
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
32ºF to 158ºF (0ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Notes
XFP end consumes 2 watts SFP+ end consumes 0.036 watts
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 84
Page 85
HP X244 XFP SFP+ 3 m
Direct Attach Cable
(J9301A)
A 3m direct attach copper
cable with an XFP
connector attached on one
end and an SFP+ connector
attached on the other end.
This cable provides a low
price connectivity option
between switches/servers/
storage to interconnect
XFP and SFP+ form factors.
Connectivity
Length
9.84 ft. (3 m)
Physical characteristics
Weight
.51 lb. (0.23 kg), Fully loaded cable with XFP
transcevier on one end and SFP+ on the other end
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
32ºF to 158ºF (0ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Cabling
Maximum distance:
• 3m Direct Attach Cable
Notes
XFP end consumes 2 watts SFP+ end consumes 0.036 watts
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP X244 XFP SFP+ 5 m
Direct Attach Cable
(J9302A)
A 5m direct attach copper
cable with an XFP
connector attached on one
end and an SFP+ connector
attached on the other end.
This cable provides a low
price connectivity option
between switches/servers/
storage to interconnect
XFP and SFP+ form factors.
Connectivity
Length
16.4 ft. (5 m)
Physical characteristics
Weight
.74 lb. (0.34 kg), Fully loaded cable with XFP
transcevier on one end and SFP+ on the other end
Environment
Operating temperature
32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
32ºF to 158ºF (0ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 10,000 ft. (3 km)
Notes
XFP end consumes 2 watts SFP+ end conumes 0.036 watts
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 85
Page 86
HP 0.5 m Multimode OM3
LC/LC Optical Cable
(AJ833A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km
@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm
for Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber and designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 86
Page 87
HP 1 m Multimode OM3
LC/LC Optical Cable
(AJ834A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 87
Page 88
HP 2 m Multimode OM3
LC/LC Optical Cable
(AJ835A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m;
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 88
Page 89
HP 5 m Multimode OM3
LC/LC Optical Cable
(AJ836A)
Cabling
Cable type
:
50/125 µm core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m;
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: This specification defines the detail requirements for a tight
buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and
Ethernet assembly with LC duplex connectors on one end and LC duplex
connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 89
Page 90
HP 15 m Multimode OM3
LC/LC Optical Cable
(AJ837A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m;
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 90
Page 91
HP 30 m Multimode OM3
LC/LC Optical Cable
(AJ838A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m;
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 91
Page 92
HP 50 m Multimode OM3
LC/LC Optical Cable
(AJ839A)
Cabling
Cable type
:
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m;
Maximum distance
:
10Gbps Transfer Rate (Ethernet): 300m
Notes
Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.
VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for
Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber. The cable is designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 92
Page 93
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
1m Cable (QK732A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
2m Cable (QK733A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 93
Page 94
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
5m Cable (QK734A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
15m Cable
(QK735A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 94
Page 95
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
30m Cable
(QK736A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
50m Cable
(QK737A)
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um
duplex cable and Ethernet assembly with LC duplex connectors on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type
OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white
stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added
for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @
23°C as tested in accordance with EIA 455-45
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 95
Page 96
HP 1500 W PoE+ zl Power
Supply
((J9306A)
Physical characteristics
Dimensions
6.05(d) x 7.45(w) x 5.1(h) in. (15.37 x 18.92 x
12.95 cm)
Weight
7.5 lb. (3.2 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Voltage
110-127/200-240 VAC
Current
13/10 A
Maximum power rating
1768 W
Frequency
50/60 Hz
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded
PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
The Maximum Power Rating at 120 volts is 1114
watts and at 240 volts is 1768 watts.
Notes
Each J9306A supplies 600 W chassis power, 300 W of PoE/PoE+ power at 110127 volts, and 900 W of PoE/PoE+ power at 200-240 volts.
One J9306A can power the J8697A chassis.
One J9306A can power the J9477A chassis.
Two J9306A supplies are required to power the J8698A chassis.
Two J9306A supplies are required to power the J8715A chassis.
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 96
Page 97
HP 1500 W zl Power
Supply
(J8713A)
Physical characteristics
Dimensions
6.05(d) x 7.45(w) x 5.1(h) in. (15.37 x 18.92 x
12.95 cm)
Weight
7.5 lb. (3.2 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Voltage
200-240 VAC
Current
10 A
Maximum power rating
1800 W
Frequency
50/60 Hz
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded
PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Notes
200–240 V only. Installation of the J8713A reduces the chassis altitude
specification to 10,000 ft. (3677m).
• J8713A supplies 600 W chassis power and 900 W PoE power.
See the Ordering Guide for more details on power supply selection for PoE
power.
Units shipped to North America include a NEMA L6-20P twist lock power cord.
Non-locking NEMA 6-20P optionally available - see the Ordering Guide for
more details.
When used in the J8714A power shelf, the following specs apply (at full load):
• Heat dissipation: 450 BTU/hr (475 kJ/hr) @ 220V
• Maximum current: 5.1 A @ 220 V
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 97
Page 98
HP 875 W zl Power Supply
(J8712A)
Physical characteristics
Dimensions
6.05(d) x 7.45(w) x 5.1(h) in. (15.37 x 18.92 x
12.95 cm)
Weight
7.05 lb. (3.2 kg)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 158°F (70°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Electrical characteristics
Voltage
100-127/200-240 VAC
Current
12/5.7 A
Maximum power rating
1050 W
Frequency
50/60 Hz
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Notes
J8712A supplies 600 W chassis power and 273 W PoE power.
One J8712A can power the J8697A chassis.
Two J8712A supplies are required to power the J8698A chassis.
Two J8712A supplies are required to power the J8715A chassis.
See the Ordering Guide for more details on power supply selection for PoE
power.
When used in the J8714A power shelf, the following specs apply (at full load):
• Heat dissipation: 250 BTU/hr (263 kJ/hr) @ 110 V, 210 BTU/hr (222 kJ/hr) @
220 V
• Maximum current: 3.2 A @ 110 V, 1.7 A @ 220 V
Services
Refer to the HP website at
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP zl Power Supply Shelf
(J8714A)
Ports
2 external power supply ports
Restrictions: PoE power available depends on power supplies installed.
Physical characteristics
Dimensions
9.73(d) x 17.44(w) x 5.2(h) in. (24.71 x 44.3 x 13.2
cm) (3U height)
Weight
9.26 lb. (4.2 kg) (no power supplies installed)
Environment
Operating temperature
32°F to 131°F (0°C to 55°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 98
Page 99
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 104°F (40°C), noncondensing
Altitude
up to 10,000 ft. (3 km)
Acoustic
Power: 52.9 dB Pressure: 42.9 dB
Electrical characteristics
Description
Power draw and heat dissipation for the power
shelf are dependent on the power supplies
installed.
Notes
For heat dissipation and power requirements of
the power shelf, find and add together these
figures for the 1 or 2 power supplies actually
installed.
Safety
CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950
Emissions
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
Immunity
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2; 4 kV CD, 8 kV AD
Radiated
IEC 61000-4-3; 3 V/m
EFT/Burst
IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal
line)
Surge
IEC 61000-4-5; 1 kV/2 kV AC
Conducted
IEC 61000-4-6; 3 V
Power frequency
magnetic field
IEC 61000-4-8; 1 A/m, 50 or 60 Hz
Voltage dips and
interruptions
IEC 61000-4-11; > 95% reduction, 0.5 period; 30%
reduction, 25 periods
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Notes
The HP ProCurve Switch zl Power Supply Shelf has two slots for zl power
supplies. It supplies PoE power only to zl switches. For yl switches, see the HP
ProCurve 620 Redundant/External Power Supply.
Power shelf depth includes 0.75 in. (1.9 cm) due to the power supply handles.
Power supplies not included.
Services
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 99
Page 100
HP 5400 zl Premium
License
(J8994A)
Services
3-Year, 9x5 SW phone support, software updates (UT481E)
3-year, 24x7 SW phone support, software updates (UT482E)
4-year, 24x7 SW phone support, software updates (UT458E)
5-year, 24x7 SW phone support, software updates (UT459E)
1-year, 24x7 software phone support, software updates (HS532E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP MSM765zl Mobility Controller
(J9370A)
Physical characteristics
Dimensions
10.3(d) x 8.13(w) x 1.75(h) in. (26.16 x 20.65 x 4.45 cm)
Weight
2.05 lb. (0.93 kg)
Mounting
Install the blade in any of the following chassis: HP 5406zl (J8697A), HP 5412zl (J8698A), and HP 8212zl
(J8715A)
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
15% to 95% @ 131°F (55°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95%, noncondensing
Electrical characteristics
Description
IEEE 802.3af PoE compliant or 48 VDC input from included AC power supply
Maximum heat
dissipation
272 BTU/hr (287 kJ/hr)
Voltage
100-240 VAC
Current
1.0/0.4 A
Maximum power rating
80 W
Frequency
50/60 Hz
Safety
UL 60950-1; CAN/CSA 22.2 No. 60950-1; IEC 60950-1; EN 60950-1
Emissions
FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003
Features
Supported
IEEE 802.11 n/a/b/g access points and/or access devices
40 to 200 (in increments of 40) access points and/or access devices
Unlimited simultaneous users
1000 simultaneous guest access users upgradable in increments of 250 per 40 license pack, up to a
maximum of 2000 supported users
Included services
WLAN management
Guest access
Captive portal
PCI DSS compliant for wireless PoS traffic
QuickSpecs
HP 5400 zl Switch Series
Accessory Product Details
DA - 12436 North America — Version 34 — December 9, 2014
Page 100
Loading...
