The information contained in this document is sub ject to change without notice.
Agilent Te chnologies makes no warranty of any kind with regard to this material, including but not
limited to, the implied warranties of merchantability and fitness for a particular purpose. Agilent
Technologies shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
Where to Find the Latest Information
Documentation is updated periodically.
• For the latest information about Agilent Technologies PSA Spectrum Analyzers, including
firmware upgrades and application information, please visit the following Internet URL:
http://www.agilent.com/find/psa
• For the latest information about Agilent Technologies ESA Spectrum Analyzers, including
firmware upgrades and application information, please visit the following Internet URL:
This book, Volume 2, provides the user and programming information for the one-button
power measurement functions. For the core sp ectrum analyzer functionality refer to
Volume 1, Core Spectrum Analyzer Functions User’s and Programmer’s Reference.
Using This Document
23
Using This Document
About the User’s and Programmer’s Information
About the User’s and Programmer’s
Information
Your user’s and programmer’s informat io n is organized in two volumes, Volume 1, Core
Spectrum Analyzer Functions User’s and Programmer’s Reference and Volume 2,
One-Button Power Measurements User’s and Programmer’s Reference.
This document is Volume 2 and provides user and programmer information for the
one-button power measurement functions only. For information about the core spectrum
analyzer functionality and program ming fund amentals refer to Volume 1, Core Spectrum Analyzer Functions User’s and Programmer’s Reference.
NOTEThe front- and rear-panel features, along with the numeric keypad and
alpha-numeric softkey fundamentals are illustrated and described, in
your Getting Started guide.
Using This Document
What is in This Book
• Using This Document- describes the organization of this book.
• One-Button Measurement Functions - provides key descriptions and programming
information for each key associated with the measurements available when you press
the front-pa n el
NOTEThe core spectrum analyzer functions and programming information is
• Menu Maps - illustrates the menu structure of the front-panel and lower-level keys
associated with the one-button measurem ents. Refer to this chapter to identify the
lower-level softkeys associated with the front-panel keys.
Measure key.
provided in its own manual; if you are unable to locate the information
you need in this book, try Volume 1, Core Spectrum Analyzer Funct ions User’s and Programmer’s Reference.
24Chapter 1
Using This Document
About the User’s and Programmer’s Information
Terms Used in This Book
There are many terms used throu ghout t his boo k, f or example “active function block,” that
are explained in detail in the Getting Started guide. It is recommended that you read the
Getting Started guide first.
The following terms are us ed to des cri be eac h k ey. Note that a k ey desc rip tion ma y not use
all the ter m s.
State Saved: Indicates what happens to a particular function when the instrument
state is saved (either to floppy disk or the internal c:\ drive). It also
indicates wh e th er the curre n t se tt i ngs of the funct i on are maintai ned if
the instrument is powered on or preset using
Preset
.
Dependencies/
Couplings: Describes dependencies or interactions to ot her functions or s ettings in the
analyzer.
Power On Last State or User
Factory Preset: Describes the function settings after a
Factory Preset.
Default
Terminator: Indicates the units that will be attached to the numerical value that you
have entered. This default will be used from the front panel, when you
terminate your entry by pressing the
Enter key, rather then selecting a
units key. This default will be used remotely when you send the command
without specifying any units after your value(s).
Range:Describes the range of the smallest to largest values to which the function
can be set. If you try to set a value below the minimum value, the analyzer
defaults to the minimum value. If you try to set a value above the
maximum value, the analyzer defaults to the maximum value.
History:Describes the firmware revision history. Only applies after first fir mware
release.
Remote
Command: Shows the syntax requirements for each SCPI command.
Example: Provides command examples using the indicated remote command syntax.
Using This Document
Chapter 125
Using This Document
About the User’s and Programmer’s Information
Using This Document
26Chapter 1
2One-Button Measurement
Functions
This chapter provides you with functional descriptions, and remote program ming
commands for all measurements available to you when you press the front-panel
key (Spectrum Analysis mode is selected).
One-Button Measurement Functions
Measure
27
One-Button Measurement Functions
One - Button Measurement Functions
One - Button Measurement Functions
This section provides key descriptions and programming information for each key
associated with the measurements available when you press the front-panel
Note that the information for keys com mon to all measurements (
Mode Setup) is presented first and the information unique to each measurement is
and
Measure, Meas Control,
grouped by measurement type. Use the table below to locate the key descriptions and
remote commands for the measurement of interest.
Measure key.
Key Function
Measure 47
Mode Setup 31
ACP Measurement
Meas Setup
Trace/View
Burst Power Measurement
Meas Setup
Trace/View
CCDF Measurement (Power Stat)
Meas Setup
Display
Span X Scale
Marker
Location
81
97
101
107
109
113
123
117
Page
Channel Power Measurement
Meas Setup
Trace/View
Harmonic Distortion Measurement
Meas Setup
Trace/View
Intermod (TOI) Measurement
Meas Setup
Mult-Carrier Power Measurement
Meas Setup
One-Button Measurement Functions
125
131
133
145
147
151
28Chapter 2
One-Button Measurement Functions
One - Button Measurement Functions
Key Function
Trace/View
Occupied BW Measurement
Meas Setup
Spectrum Emission Mask Measurement
Meas Setup
Trace/View
Display
Span X Scale
Marker
Spurious Emissions Measurement
Meas Setup
Page
Location
169
171
177
201
195
199
197
203
Chapter 229
One-Button Measurement Functions
One-Button Measurement Functions
One - Button Measurement Functions
One-Button Measurement Functions
30Chapter 2
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1Mode Setup (Sp ec trum Analysis Mode)
Enables you to change measurement settings common to all measurements in the
MEASURE menu. In Spectrum Analysis mode, there are several built-in power
measurements. Parameters that you set in the Mode Setup menu affect all of these
measurements.
Key Path: Front-panel key
2.1.1Radio Std
Accesses the radio standards key menu to enable you to select a radio standar d. Selecting a
radio standard modifies spectrum analyzer settings for the measurement activated under
MEASURE menu.
the
NOTEMeasurements that are not relevant to the se lected radio standard are not
supported, and the me ssage Measurement does not support the current
radio standard. will be displayed when such a combination is encountered.
Updated with PSA firmware revision A.04.00
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Radio Std, None is selected when a measurement is running,
all measurement parameters are returned to their default values. Analyzer parameters
outside the
MEASURE or Meas Setup key menus are not affected.
One-Button Measurement Functions
Chapter 231
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN NONE
2.1.1.2IS-95A
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) app ropriate for industry st andard IS-95A. The
Spectrum Emissions Mask, Harmonic Distortion, and Spurious Emissions measurements
are not available when this radio standard is selected.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN IS95
2.1.1.3J-STD-008
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appropriate for ind ust ry stand ard J-S TD-008.
The Spectrum Emissions Mask, Harmonic Distortion, MCP, and Spurious Emissions
measurements are not available when this radio st andard is selected.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
One-Button Measurement Functions
32Chapter 2
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN JSTD
2.1.1.4IS-95C
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appro priate for ind ustry stand ard IS-95C . The
IS-95C radio standard is only available when selecting the Channel Power, Occupied
Bandwidth, Adjacent Channel Power, and CCDF one-button measurements.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.10.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN IS95C
2.1.1.5GSM/EDGE
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key de s cr i pt i on) appropriate fo r i n du s tr y stan dard
GSM/EDGE. Power Stat CCDF and Burst P ower are the only measurements available for
this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
One-Button Measurement Functions
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Chapter 233
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN GSM
2.1.1.63GPP W-CDMA
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appropriate for industry standard W-CDMA.
All measurements except Harmonic Distortion and Spurious Emissions are available for
this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN W3GPP
2.1.1.7cdma2000 MC-1X
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key de s cr i pt i on) appropriate fo r i n du s tr y stan dard
cdma2000-MC-1X. All measurements except Harmonic Distortion, Spurious Emissions,
and Spectrum Emission Mask are available for this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN C2000MC1
One-Button Measurement Functions
34Chapter 2
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.8cdma2000 MC-3X
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key de s cr i pt i on) appropriate fo r i n du s tr y stan dard
cdma2000:MC-3X. All measurements except Multi-Carrier Power, Harmonic Distortion,
Spurious Emissions and Spectrum Emission Mask are available for this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN C2000MC3
2.1.1.9cdma2000 DS
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key de s cr i pt i on) appropriate fo r i n du s tr y stan dard
cdma2000:DS. All measurements excep t Multi-Carrier Power, Harmonic Distortion,
Spurious Emissions and Spectrum Emission Mask are available for this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN C2000DS
Chapter 235
One-Button Measurement Functions
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.10NADC
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appropriate for industry standard NADC.
Channel Power and Intermod TOI measurements are not a vai lable when
Device (MS) is
selected. All other measurements are available when this radio standard is selected
except: Spectrum Emissions Mask, Harmonic Distortion, Spurious Emissions, and
Multi-Carrier Po we r.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN NADC
2.1.1.11PDC
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appropriate for industry standard PDC. The
Burst Power measurement is not available when
Power and Intermod TOI measurements are not available when
Device (BTS) is selected. The Channel
Device (MS) is selected. All
other measurements except Multi-Carrier Power, Harmonic Distortion, Spurio us
Emissions and Spectrum Emission Mask measurements are available for this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN PDC
One-Button Measurement Functions
36Chapter 2
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.12Bluetooth™
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key de s cr i pt i on) appropriate fo r i n du s tr y stan dard
Bluetooth™. Power St at CCDF and Burst Power are the only measurements available for
this standard.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN BLUE
2.1.1.13FCC Part 15 Subpart F
PSA Only: Sets the specific parameters for the selected measurement (located under the
“MEASURE (Spectrum Analysis Mode)” key description) appropriate for unlicensed
devices.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN FCC15
Chapter 237
One-Button Measurement Functions
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.14TETRA
Sets the specific parameters for the selected measuremen t (located under the “MEASURE
(Spectrum Analysis Mode)” key description) appropriate for industry standard TETRA.
This standard is only available for the Channel Power and ACP measurements.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.03.00
Added with ESA firmware revision A.09.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN TETR
2.1.1.15W-LAN
Accesses the W-LAN radio standards key menu to enable you to select a W-LAN standard.
Selecting a radio standard modifies spectrum analyzer settings for the CHP or CCDF
measurem e nt activated under the
MEASURE menu.
2.1.1.15.1802.11a Sets the specific parameters for the selec ted measurement (located
under the “MEASURE (Spectrum Analysis Mode)” key description) appropriate for
industry standard 802.11a. This standard is only available for the Spectrum Emission
Mask (SEM) measurement.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.03.00
Added with ESA firmware revision A.09.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN WL802DOT11A
One-Button Measurement Functions
38Chapter 2
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.15.2802.11b Sets the specific parameters for th e selected measurement (located
under the “MEASURE (Spectrum Analysis Mode)” key description) appropriate for
industry standard 802.11b. Th is st andard is only available for the Spectrum Emission
Mask (SEM) measurement.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.03.00
Added with ESA firmware revision A.09.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN WL802DOT11B
2.1.1.15.3802.11g Sets the specific parameters for the selected measurement (located
under the “MEASURE (Spectrum Analysis Mode)” key description) appropriate for
industry standard 802.11g. This standard is only available for the Spectrum Emission
Mask (SEM) measurement.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.04.00
Added with ESA firmware revision A.10.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN WL802DOT11G
Chapter 239
One-Button Measurement Functions
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.15.4Hiper LAN/2 Sets the specific parameters for the selected measurement
(located under the “MEASURE (Spectrum Analysis Mode)” key description) appropriate
for industry standard Hiper LAN2. This standard is only available for the Spectrum
Emission Mask (SEM) measurement.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.03.00
Added with ESA firmware revision A.09.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
Example: RAD:STAN HIPERLAN2
2.1.1.16DVB-T
Accesses the DVB-T key menu to enable you to select a DVB-T mask filtering standard.
Selecting a DVB-T filtering standard modifies spectrum analyzer settings for the CHP or
CCDF measu rement act i v a te d under the
MEASURE menu.
2.1.1.16.1L/SECAM/NICAM
Pressing
L/SECAM/NICAM selects the filtering masks for the L/SECAM/NICAM analog
television system.
Key P ath:
Mode Setup, DVB-T
History: Added with PSA firmware revision A.04.00
Added with ESA firmware revision A.10.00
2.1.1.16.2G/PAL/NICAM
Pressing
G/PAL/NICAM selects the filtering masks for the G/PAL/NICAM analog television
system.
Key P ath:
Mode Setup, DVB-T
History: Added with PSA firmware revision A.04.00
Added with ESA firmware revision A.10.00
One-Button Measurement Functions
40Chapter 2
2.1.1.16.3I/PAL/NICAM
Pressing
I/PAL/NICAM selects the filtering masks for the I/PAL/NICAM analog television
system.
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
Key P ath:
Mode Setup, DVB-T
History: Added with PSA firmware revision A.04.00
Added with ESA firmware revision A.10.00
2.1.1.17S-DMB
Accesses the S-DMB radio standards key menu to enable you to select a S-DMB standard .
Selecting a radio standard modif ies spectrum a nalyzer settings for t he Spurious Emiss ions
measurem e nt activated under the
MEASURE menu.
Key Type: 1 of N menu
Key P ath: Mode Setup, Radio Std
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
2.1.1.17.1System E PSA Only: Sets the specific parameters for the selected
measurement (located under the “MEASURE (Spectrum Analysis Mode)” key description)
appropriate for industry standa rd System E. This standard is only available for the
Spurious Emissions measurements .
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
One-Button Measurement Functions
Chapter 241
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.1.18UWB
Accesses the UWB radio standards key menu to enable you to sele ct a UWB standard.
Selecting a radio standard modifies spectrum analyzer settings for the channel power
measurem e nt activated under the
MEASURE menu.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
2.1.1.18.1UWB Indoor Sets the specific parameters for the selec ted measurement
(located under the “MEASURE (Spectrum Analysis Mode)” key description) appropriate
for UWB Indoor standard. This standard is only available for the Channel Power
measurements.
Key Type: 1 of N menu
Key P ath:
Mode Setup, Radio Std
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:RADio:STANdard[:SELect]See “Radio Std” on page 31.
2.1.2Std Setup
Accesses the key menu for selecting the device, packet type, or signal bandwidth to be
measured.
Key P ath:
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Remote Command:
There is no equivalent remote command.
One-Button Measurement Functions
Mode Setup
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
42Chapter 2
2.1.2.1Signal BW
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
Allows you to se t th e m e a s u r ement bandw i d th w h e n
Radio Std (None) is selected. This
function is available only when you select None as the standard.
Key P ath:
Mode Setup, Std Setup
Factory Preset: 3.0 MHz
Default Terminator: Hz
Range: The non-zero span range of the analyzer
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
This function is only available when you have selecte d the standard: IS-95, J-STD-008,
cdma2000, W-CDMA, NADC, PDC, TETRA, or GSM. It enables you to select either the
base transmitter station (BTS) setup defaults or the mobile station (MS) defaults for the
standard that you have selected. This key is unavailable when you select Bluetooth™.
Key P ath:
Mode Setup, Std Setup
Factory Preset: BTS
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
[:SENSe]:RADio:STANdard:DEVice BTS|MS
[:SENSe]:RADio:STANdard:DEVice?
Example: RAD:STAN:DEV MS
One-Button Measurement Functions
Chapter 243
One-Button Measurement Functions
Mode Setup (Spectrum Analysis Mode)
2.1.2.3Packet Type
This function is only available when the standard you have selected is Bluetooth™. It
enables you to set the instrument settings for testing DH1, DH3, or DH5 packet type.
Key P ath:
Mode Setup, Std Setup
Factory Preset: DH1
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Enables you to retain the base-instrum ent parameter settings used by individual
measurements that are typically lost when switching between measurements.
When
Retain Params is set to Off, the values of the fully configurable parameters are not
saved and recalled during a measurement change.
When
recalled during a measurement change , along with
Avg/VBW Type, Points, and if applicable, Spectrum/Bar/Combined and Graticule On/Off.
NOTEWhen Radio Std or Radio Std Setup is changed, Retain P arams is set to Off. Once
Retain Params is set to On, the fully configurable parameters will be saved and
Span, Ref Level, Single/Cont, Detector,
Retain Params has been set to Off, parameters will no longer be retained and
any settings you may have entered will be lost.
Key P ath:
Mode Setup
Factory Preset: Off
History: Added with PSA firmware revision A.04.00
Added with PSA firmware revision A.10.00
Remote Command:
[:SENSe]:RADio:STANdard:RPARams[:STATe]ON|Off|1|0
[:SENSe]:RADio:STANdard:RPARams[:STATe]?
Example: RAD:STAN:RPAR Off
2.1.4Enable All Measurements
Allows you to specify whether all measurements and radio standards are enabled (set to
Yes) or not (Set to No).
NOTEEnable All Measurements will be disabled (greyed out) if a measurement is
entered when
entered does not support the currently selected Radio Std. The message:
“Select a valid radio standard/measurement combination to enable.” will be
displayed.
Key P ath:
Mode Setup
Factory Preset: No
History: Added with PSA firmware revision A.04.00
Added with ESA firmware revision A.10.00
Enable All Measurements is set to Yes and the measurement
2.1.5Autorange of Power Setting (Remote command only)
This command is the remote version of the Optimize Ref Level k ey. If this function is
applicable to the currently selected measurement, this command sets the reference level
and attenuator to optimum values based on the signal present at the input.
NOTEThere is always a minimum of 5 dB for ESA or 6 dB for PSA of attenuation
set to protect the analyzer input.
History: Modified with P SA fi r m wa re revision A.04 . 0 0
Added with PSA firmware revision A.02.00
Modified w i th E SA fi rmware revision A.08.00
Added with ESA firmware revision A.07.00
Remote Command:
[:SENSe]:POWer[:RF]:RANGe:AUTO ONCE
Example: POW:RANG:AUTO ONCE
One-Button Measurement Functions
46Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2MEASURE (Spectrum Analysis Mode)
In the Spectrum Analysis mode (see the Mode key), this key displays a menu that lets you
to make tran sm i t te r power measurements such a s a djacent chann e l power, occupi ed
bandwidth, and harmonic dis tortion measur ements. If other modes are available and have
been selected, the measurements for that particular mode will be displa yed. Some common
settings can be made for these measurements using the function under the
For example, you may select one of several radio standards available by pressing
, Radio Std.
Setup
Meas Contr ol to pause and resume the currently selected measurement and to select
Use
between continuous or single measurements. For information about
Meas Control, see
Volume 1, Core Spectrum Analyzer Functions User’s and Programmer’s Reference.
NOTEThe measurements described in this book are available in SA mode (see Mode
key). Other measurements are available in other modes if an optio n al
personality is installed, use the appropriat e user ’s guide for information
about those modes.
Mode Setup key.
Mode
Chapter 247
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Command Interactions: MEASure, CONF igure,
FETCh, INITiate and READ
Each one-button measurement has a group of commands that work together to make the
measurement fast, but flexible.
Figure 1 Measurement Group of Commands
One-Button Measurement Functions
48Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measure Commands:
:MEASure:<measurement>[n]?
This is a fast single-command way to make a measurement using the factory default
instrument settings. These are the settings and units that conform to the Mode Setup
settings (e.g. radio standard) that you have currently selected.
• Stops the current measurement (if any) and sets up the instrument for the specified
measurement using the factory default s
• Initiates the data acquisition for the measurement
• Blocks other SCPI communication, waiting until the measurement is complete before
returning results.
• If the function does averaging, it is turned on and the number of averages is set to 10.
• After the data is valid it returns the scalar results, or the trace data, for the specified
measurement. The type of data returned may be defined by an [n] value that is sent with the
command.
The scalar measurement results will be returned if the optional [n] value is not included, or is
set to 1. If the [n] value is set to a value other than 1, the selected trace data results will be
returned. See each command for details of what types of scalar results or trace data results
are available.
ASCII is the default format for the data output. Older versions of Spectrum Analysis and
Phase Noise mode measurements only use ASCII.) The binary data formats should be used
for handling large blocks of data since they are smaller and faster than the ASCII format.
Refer to the FORMat:DATA command for more information.
If you need to change some of the measurement param e ters from the factory default
settings you can set up the measurement with the CONFigure command. Use the
commands in the SENSe:<measurement> and CALCulate: <measurement> subsystems
to change the settings. Then you can use the READ? command to initiate the
measurement and query the results. See
Figure 1.
If you need to repeatedly make a given measurement with sett ing s other than the
factory defaults, you can use the commands in the SENSe:<measurement> and
CALCulate:<measure m e n t > subsystem s to s e t u p the measure ment. Then use th e
READ? command to initiate the measurement and query results.
Measurement settings persist i f you initiate a different measure ment and then ret urn to
a previous one. Use READ:<measurement>? if you want to use those persistent settings .
If you want to go back to the default settings , use MEASure:<measurement>?.
One-Button Measurement Functions
Chapter 249
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Configure Commands:
:CONFigure :<mea sur emen t>
This command stops the current measurement (if any) and sets up the instrument for the
specified measurement using the factory default instrument settings. It sets the instrument to
single measurement mode but should not initiate the taking of measurement data unless
INIT:CONTinuous is ON. After you change any measurement settings, the READ command can
be used to initiate a measurement without changing the settings back to their defaults. In
Spectrum Anal ysis mode th e CONF ig ure co mman d al so t urns t he a ve ragin g fu ncti on o n and set s
the number of averages to 10 for all measurements.
In instruments with firmware older then A.05.00 CONFigure initiates the taking of data. The
data should be ignored. Other SCPI commands can be processed immediately after sending
CONFigure. You do not need to wait for the CONF command to complete this ’false’ data
acquisition.
The CONFigure? query returns the current measurement name.
Fetch Commands:
:FETCh:<measurement>[n]?
This command puts selected data from the most recent measurement into the output buffer. Use
FETCh if you have already made a good measurement and you want to return several types of
data (different [n] values, e.g. both scalars and trace data) from a single measurement. FETCh
saves you the time of re-making the mea surement. You can only FETCh results from the
measurement that is currently active, it will not change to a different measurement. An error is
reported if a measurement other than the current one, is specified.
If you need to get new measurement data, use the READ command, which is equivalent to an
INITiate followed by a FETCh.
The scalar measurement results will be returned if the optional [n] value is not included, or is set
to 1. If the [n] value is set to a value other than 1, the selected trace data results will be returned.
See each command for details of what types of scalar results or trace data results are available.
The binary data formats should be used for handling large blocks of data since they are smaller
and transfer faster then the ASCII format. (FORMat:DATA)
FETCh may be used to return results other than tho se specified wit h the original READ
or MEASure command that you sent.
One-Button Measurement Functions
50Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
INITiate Commands:
:INITiate:< measur ement>
This command is not available for measurements in all the instrument modes:
• Initiates a trigger cycle for the specified measurement, but does not output any data. You
must then use the FETCh<meas> command to return data. If a measurement other than the
current one is specified, the instrument will switch to that measurement and then initiate it.
For example, suppose you have previously initi at ed the ACP measurement, but now you are
running the channel power measurement. If you send INIT:ACP? it will change from channel
power to ACP and will initiate an ACP measurement.
• Does not change any of the mea surement setti ngs. For example, if you have previ ously start ed
the ACP measurement and you send INIT:ACP? it will initiate a new ACP measurement
using the same instrument settings as the last time ACP was run.
• If your selected measurement is currently active (in the idle st ate) it triggers the
measurement, assuming the t rigger condit ions are met. The n it complete s one trigger
cycle. Depending upon the measurement and the number of averages, there may be
multiple data acquisitions, with multiple trigger events, for one full trigger cycle. It
also holds off additional commands on GPIB until the acquisition is complete.
READ Commands:
:READ:<measurement>[n]?
• Does not preset the measurement to the factory default settings. For example, if you have
previously initiated the ACP measurement and you send READ:ACP? it will initiate a new
measurement using the same instrument settings.
• Initiates the measurement and puts valid da ta int o the output buffer. If a measurement other
than the current one is specified, the instrument will switch to that measurement befor e it
initiates the mea sur e men t and re tur ns re s ults.
For example, suppose you have previously initi at ed the ACP measurement, but now you are
running the channel power measurement. Then you send READ:ACP? It will change from
channel power back to ACP and, using the previous ACP settings, will initiate the
measurement and return results.
• Blocks other SCPI communication, waiting until the measurement is complete before
returning the results
If the optional [n] value is not included, or is set to 1, the scalar meas urement resu lts
will be returned. If the [n] va lue is s et to a value o ther than 1, the selec ted trace d ata
results will be returned. See each command f or detail s of what types of scalar res ults
or trace data results are available. The binary data formats should be used when
handling large blocks of data since they are smaller and faster then the ASCII
format. (FORMat:DATA)
This command returns the name of the measurement that is currently running.
Remote Command:
:CONFigure?
Example: CONF?
2.2.2Test Current Results Against all Limits (Remote Command
Only)
Queries the status of the c urrent measure ment l imit tes ting . It returns a 0 if the measured
results pass when compared with the current limits. It returns a 1 if the measured results
fail any limit tests.
Remote Command:
:CALCulate:CLIMits:FAIL?
Example: CALC:CLIM:FAIL?
One-Button Measurement Functions
52Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.3Channel Power
Channel Power measures the power and power spectral density in the channel bandwidth
that you specify. One marker pair on the display indicates the edges of the channel
bandwidth. The center frequency, reference level, and channel bandwidth must be set by
the user. For more information see “Meas Setup (Channel Power—CHP)” on page 125.
You can configure measurement settings by pressing
. You can make a measurement in single or continuous sweep mode. Pressing Meas
Power
Control
single measurement. To set
enables you to pause or restart a measurement, or toggle between continuous and
Ref Level automatically, use Optimize Ref Level.
Meas Setup after selecting Channel
The power calculation method used to determine the channel power is a traditional
method known as the integration bandwidth (IBW) met hod. A swept spectrum is used as
the basis for this calculation. Therefore, it is important to set the resolution bandwidth
correctly before making this measurement using the following formula:
RBWk span()n⁄=
Where k is a value between 1.2 and 4.0 and n is the number of trace points.
NOTEBecause of the noise-like nature of the signals being measured, the video
bandwidth should be ≥ 10 times the resolution bandwidth.
Figure 2-1ESA Channel Power Measurement Results
Chapter 253
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Figure 2-2PSA Channel Power Measurement Results
NOTEThe displayed trace is the current trace, not the averaged trace.
Pressing
measurement setup menu. Pressing
Meas Setup after Channel Power has been selected will access the channel power
Radio Standard after Mode Setup has been selected will
access all the Radio Standards available for which this measurement can be applied.
Pressing
Meas Control after Channel Power has been selected will access the channel power
measurement control menu which allows you to pause or restart your measurement, or
toggle between continuous and single measurement.
When a DVB-T radio standard is selected, this measurement will also compare the input
signal against a pre-defined spectrum mask. The mask amplitudes defined in the DVB-T
specification (ETSI EN 300 744 V1.4.1) range from 0 dB to 100 dB. This is for power
measured in a 4kHz bandwidth therefore an adjustment to these values will need to be
made as the measurement is made in a 7.61MHz bandwidth.
The measurement makes two sweeps, one in a 4kHz bandwidth and one in a 7.61MHz
bandwidth, then computes the difference between the two. This value will be used to
adjust the mask settings. As this value is calculated as part of the measurement setup, it is
expected that the DVB-T signal to be measured will be p resent prior to the standar d being
selected. The m a sk w i l l b e positioned re l a ti v e to th e power meas u r e d in th e 7.61MHz
bandwidth. The pass/fail indicat or will be us ed to deter mine if the inp ut signal exceed s the
mask or not.
If the current span setting is narrower than the mask width, the mask will not be
displayed and the message
10191 displayed. Increase the span to at least the mask width to
display the mask. When the mask is not displayed, the pass /fail functionality will not be
executed therefore no pass/fail flag will be displayed.
One-Button Measurement Functions
54Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
To ensure accuracy this measurement requires a specific minimum Swe ep Point to Span
ratio. This is calculate d using; Sweep Points = Span / (Closest Mask Breakpoint / 2), then
rounded off .
For DVB-T measurements using 24 MHz Span, the number of Sweep Points is 2001. If the
Sweep Point to Span ratio is changed to a value less than the value obtained using the
above algorithm, the message
10192 is then displayed, although the measurement is still
made using the new sweep point to span ratio.
Key P ath:
Returns two values that co rr esp on d to th e Chan n el
Power and Power Spectral Density.
Returns a single value that corresponds to the Channel
Power.
Returns a single value that corresponds to the Power
Spectral Density.
Remote Command Notes: The main channel power is returned in the current am plitude
units, and the density value is returned in current amplitude units/Hz
Example:
FETC:CHP? or MEAS:CHP? or READ:CHP? command returns scalar results of
main channel power and power density.
FETC:CHP:CHP? or MEAS:CHP:DENS? or READ:CHP:DENS? commands will
return the sin g l e sca l a r re sult specifi e d.
One-Button Measurement Functions
Chapter 255
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.4Occupied BW
Occupied Bandwidth integrates the power of the displayed spectrum and puts markers at
the frequencies between which a selected percentage of the power is contained. The
measurement de faults to 99% of the oc cupied bandwid th po we r. The power-bandwidth
routine first computes the combined power of all signal respons es contained in the trace.
For 99% occupied power bandwidth, markers are placed at the frequencies on either side of
99% of the power. 1% of the power is evenly distributed outsid e the mar kers. The
differenc e be tween the ma rker freque n cies is the 99% power band w i dth and is th e v a l u e
displayed. For more information see “Meas Setup (Occupied Bandwidth—OBW)” on
page 171.
The occupied bandwidth fun ction also ind icates the differenc e between t he analyze r center
frequency and the center frequency of the channel. This “Tra nsmit Freq Error” is defined
as the difference between the (f
Figure 2-3 on page 57.
The occupied bandwidth measurement can be made in single or continuous sweep mode.
The center frequency, reference level, and channel spacing must be set by the user.
+ f2)/2 and the tuned center frequency of the signal. See
1
To configure measurement settings, press
Radio Standard after Mode Setup has been selected will access all the Radio Standards
available for which this measurement can be applied. Pressing
Meas Setup after selecting Occupied BW. Pressing
Meas Control enables you to
pause or restart a measurement, or toggle between continuous and single measurement.
Key P ath:
MEASURE
Remote Command:
Measurement Results Available
CommandResults Returned
:CONFigure:OBW
:INITiate:OBW
:FETCh:OBW?
:MEASure:OBW?
:READ:OBW?
:FETCh:OBW:OBW idth?
:MEASure:OBW:OBW i dth?
:READ:OBW:OBW i dth?
Returns two values that correspond to the Occupied BW and
Transmit Frequency Error in Hertz.
Returns a single value that corresponds to the Occupied BW in
Hertz.
Returns a single value that corresponds to the Transmit
Frequency Error in Hertz.
:FETCh:OBW:XDB?
:MEASure:OBW:XDB?
:READ:OBW:XDB?
One-Button Measurement Functions
56Chapter 2
Returns a single value that corresponds to the x dB BW in
Hertz.
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Remote Command Notes: The results for both values are returned in Hz.
Example:
FETC:OBW? or MEAS:OBW? or READ:OBW? command returns scalar results
of occupied bandwidth and transmit frequency error.
FETC:OBW:OBW? or MEAS:OBW:FERR? or READ:OBW:FERR? commands will
return the sin g l e sca l a r re sult specifi e d.
Figure 2-3Occupied Bandwidth Measurement Results
f1
f2
2.2.5Adjacent Channel Power—ACP
Adjacent Channel Power (ACP) is a measur e of the power that leaks into adjacent
transmit channels. Depending on the radio standard selected from the Mode Setup menu,
this measurement can run in several differe nt mod es in or der t o measure differe nt ty pes of
signals. For more information see “Meas Setup (Adjacent Channel Power—ACP)” on
page 81.
ACP measures the power present in ad jacent transm it c hannels. The span is set according
to the six available offsets and their ass ociated integration bandwidths defined by you or
the selected radio standard (
the span and is only available for NADC, 3GPP W-CDMA, and TETRA radio standards.
•When Method is set to IBW, one sweep of the trace will be taken, and the band power for
each offset will be computed. Results will be displayed r elative to the total power or the
power spectral density, depending on your selection after pressing
You may view the re su l ts as the current trace, bar gra ph, or a comb in ation.
•When Method is set to RBW, the main channel and offsets will be measured in zero sp an
Chapter 257
Mode Setup, Radio Std). The root-raised cosine filter also affects
Meas Setup, Meas Type.
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
and the combi n e d re sults report e d according to the Meas Type selection.
•When Method is set to Fast, the five point ACLR measureme n t method is used for
improved speed of making ACP measurements.
Fast is only enabled for the 3GPP
W-CDMA radio standard only.
The measurement settings may be configured by pressing
selected. Pressing
Radio Standard after Mode Setup has been selected will access a ll th e Radi o
Standards available for whic h this measurement can be applied. Pressing
Meas Setup after ACP has been
Meas Control
allows you to pause or restart your measu rement, or toggle between c ontinuo us and s ingle
measurement mode.
Returns 3 comma-separated values that
correspond to:
main channel power,
lower-adjacent channel power (dBc), and
upper-adjacent channel power (dBc).
Returns 28 comma-separated values that
correspond in the following order:
1. Main Channel- relative power (dB)
2. Main Channel- absolute power (dBm)
3. Main Channel- relative power (dB)
4. Main Channel- absolute power (dBm)
5. Negative Offset Frequency (1)
- relative power (dB)
6. Negative Offset Frequency (1)
- absolute power (dBm)
7. Positive Offset Frequency (1)
- relative power (dB)
8. Positive Offset Frequency (1)
- absolute power (dBm)
...
1. Negative Offset Frequency (6)
- relative power (dB)
2. Negative Offset Frequency (6)
- absolute power (dBm)
3. Positive Offset Frequency (6)
- relative power (dB)
4. Positive Offset Frequency (6)
- absolute power (dBm)
Main channel relative power is relative to
the main channel absolute power, and
therefore is always equal to 0.00 dB.
One-Button Measurement Functions
Chapter 259
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measurement Results Available (Continued)
ConditionCommandResults Returned
Radio Std ≠ None
or
Radio Std = None and
more than one offset is
on
Meas Type = T ot al Pwr
Ref
Returns 28 values that correspond in the
following order:
1. Main Channel- relative power spectral
density (dB)
2. Main Channel- power spectral density
(dBm/Hz)
3. Main Channel- relative power spectral
density (dB)
4. Main Channel- power spectral density
(dBm/Hz)
5. Negative Offset Frequency (1) -
relative power spectral density (dB)
6. Negative Offset Frequency (1) -
power spectral density (dBm/Hz)
7. Positive Offset Frequency (1) -
relative power spectral density (dB)
8. Positive Offset Frequency (1) -
power spectral density (dBm/Hz)
...
1. Negative Offset Frequency (6)
- relative power (dB)
2. Negative Offset Frequency (6)
- absolute power (dBm)
3. Positive Offset Frequency (6)
- relative power (dB)
4. Positive Offset Frequency (6)
- absolute power (dBm)
Main channel relative power is relative to
the main channel power spectral density,
and therefore is always equal to 0.00 dB.
Remote Command Notes: The main channel power is returned in the current am plitude
units, and the lower and upper channel results are always returned in dB.
Example:
FETC:ACP? or MEAS:ACP? or READ:ACP? commands return the sca lar results
of main channel power, lower channel power (relative), and upper channel
power (relative) if only one off set is set to on and the Radi o St andard is set
to None. Otherwise, 28 values are returned. If
Meas Type is Total Power Ref,
these are the m a in ch a n n el power in dBm an d i n dBc from the ca rr i e r (0
dBc) each repeated, followe d by th e absolute and relative power levels for
each lower and upper offset if Meas Type is Total Power Ref. Otherwise
they are the main channel po w e r spectral den sity and rela ti v e power
spectral density (0 dB) each repeated. Then followed by the absolute and
relative spectral density values for each lower and upper offset.
One-Button Measurement Functions
60Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.6Multi-Carrier Power
Multi-Carrier P ower is the measure of the power that leaks into adjacent transmit
channels when two or more carriers are present. The results reported are identical to the
adjacent power measurement, but the setup is different to allow for two or more carriers.
For more information s e e “Meas Setup (Multi-Carrier Power—MCP)” on page 151.
The measurement settings may be configured by pressing
has been selected. Pressing Meas Control allows you to pause or restart your
Power
Meas Setup after Multi-Carrier
measurement, or toggle between continuous and single measurement mode.
Key P ath:
MEASURE
Remote Command:
Measurement Results Available
CommandnResults Returned
:CONFigure:MCPowerN/ANot Applicable
Chapter 261
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measurement Results Available (Continued)
CommandnResults Returned
:FETCh:MCP[n]?
:MEASure:MCP[n ]?
:READ:MCP[n]?
n=1 (or not
specified)
Returns 20 comma-separated scalar results, in the
following order.
1. 0.0
2. Total carrier power (dBm)
3. 0.0
4. Reference carrier power (dBm)
5. lower 5 MHz offset - relative power (dBc)
6. lower 5 MHz offset - absolute power (dBm)
7. upper 5 MHz offset - relative power (dBc)
8. upper 5 MHz offset - absolute power (dBm)
9. lower 10 MHz offset - relative power (dBc)
10. lower 10 MHz offset - absolute power (dBm)
11. upper 10 MHz offset - relative power (dBc)
12. upper 10 MHz offset - absolute power (dBm)
13. lower 15 MHz offset - relative power (dBc)
14. lower 15 MHz offset - absolute power (dBm)
15. upper 15 MHz offset - relative power (dBc)
:FETCh:MCPower?
:MEASure:MCPower?
:READ:MCPower?
16. upper 15 MHz offset - absolute power (dBm)
17. NaN returned
18. NaN returned
19. NaN returned
20. NaN returned
If the results are not available,
−999.0 is returned.
n=2...13Returns absolute and relative values for carrier n-1. If
results are not available
−999.0 is returned
One-Button Measurement Functions
62Chapter 2
Measurement Results Available (Continued)
CommandnResults Returned
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
:FETCh:MCPower?
:MEASure:MCPower?
:READ:MCPower?
n=14Returns 36 comma-separated scalar results, in the
following order.
1 to 24. All carriers absolute and relative values
25. lower offset A - relative power (dBc)
26. lower offset A - absolute power (dBm)
27. upper offset A - relative power (dBc)
28. upper offset A - absolute power (dBm)
29. lower offset B - relative power (dBc)
30. lower offset B - absolute power (dBm)
31. upper offset B - relative power (dBc)
32. upper offset B - absolute power (dBm)
33. lower offset C - relative power (dBc)
34. lower offset C - absolute power (dBm)
35. upper offset C - relative power (dBc)
36. upper offset C - absolute power (dBm)
If the results are not available,
−999.0 is returned.
Example: FETC:MCP? or MEA:MCP? or READ:MCP?
One-Button Measurement Functions
Chapter 263
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.7Power Stat CCDF
The CCDF measurement is a statistical measurement of a high-level signal or peak power.
It shows in both graphical and tabular form for what percentage of the time a signal
exceeds its average power, and by how much this average is exceeded. For more
information see “Meas Setup
(Complementary Cumulative Distribution Function—CCDF)” on page 109.
NOTEESA Only: CCDF measurement requires the installation of Option AYX (fast
time domain sweeps) or Option B7D (Digital Signal Processing with Fast
ADC).
For each single sweep of this measurement, the average power is defined by:
n
PavgV2Z0⁄()
∑
1
n⁄=
where V is the envelope voltage, Z
maximum).
Pavg is used as a guideline to def ine the probability of the samples , which is xdB above the
average power. The number of samples collected per sweep depends upon the sampling
rate and the setting of the measurement inte rv al. Multiple sweeps may be required if the
sample number exceeds the number of samples collected per sweep. The results and the
CCDF curve are updated after each sweep.
Results from a 2.17 GHz 3GPP W-CDMA input signal are shown below in Figure 2-4 .
NOTE It is important to set the correct center frequency befor e in itiating this
measurement.
0 is the characteristic impeda nce , and n is the number of samples (3 2k
One-Button Measurement Functions
64Chapter 2
MEASURE (Spectrum Analysis Mode)
Figure 2-4Power Stat CCDF Measurement Results
One-Button Measurement Functions
Pressing
Meas Setup after Power Stat CCDF has been selected will access the Power Stat
CCDF measurement setup menu. The factory defaults provide a good starting point for
this measurement. The settings are adjustable, however, to meet specific requirements.
Pressing
Standards available for which this measu rement can be app lied. Pressing
after
Radio Standard after Mode Setup has been selected will access all the Radio
Meas Control
Power Stat CCDF has been selected will acces s the Power Stat CCDF measurement
control menu which allows you to pause or restart your measurement, or toggle between
continuous and single measurement.
Returns 10 scalar results, in the following order.
1. Average input power (in dBm)
2. Probability at the average input power (in%)
3. Power level that has 10% of the power
4. Power level that has 1% of the power
5. Power level that has 0.1% of the power
6. Power level that has 0.01% of the power
7. Power level that has 0.001% of the power
8. Power level that has 0.0001% of the power
9. Peak power (in dB)
10. Count
n=2Returns a series of 501 floating point numbers (in
percent) that represent the current measured
power statistics trace. This is the probability at
specific power levels (average power), in the
following order:
1. Probability at 0 dB power
2. Probability at 0.1 dB power
3. Probability at 0.2 dB power
…
501. Probability at 50.0 dB power
n=3Returns a series of 501 floating point numbers (in
percent) that represent the Gaussian trace. This is
the probability at specific power levels (average
power), in the following order:
1. Probability at 0 dB power
2. Probability at 0.1 dB power
3. Probability at 0.2 dB power
…
501. Probability at 50.0 dB power
One-Button Measurement Functions
66Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measurement Results Available (Continued)
CommandnResults Returned
n=4Returns a series of 501 floating point numbers (in
percent) that represent the user-definable
reference trace. This is the probability that at
specific power levels (average power) will occur, as
follows:
1. Probability at 0 dB power
2. Probability at 0.1 dB power
3. Probability at 0.2 dB power
…
501. Probability at 50.0 dB power
Remote Command Notes: To save trace data use the fetch methods shown above.
Example:
FETC:PST? or MEAS:PST? or READ:PST?
FETC:PST2?
FETC:PST3?
or MEAS:PST2? or READ:PST2?
or MEAS:PST3? or READ:PST3?
2.2.8Harmonic Distortion
The range table state determines which harmonics are to be measured. If Range Table is set
Off, for each harmonic to be measured, the center frequency will be set to the
to
appropriate integer multiple of the fundamental frequency and a sweep taken. The
amplitude is calculated by a v eraging the power in the trace and is d isp layed in the results
table in the results window. The desired Res BW value for each harmonic is calculated by
multiplying the harmonic number with the Res BW of the fundament al. This r esults in the
smallest Res BW available being used that is greater than or equal to the computed value.
If a Res BW greater than the instrument maximum is calculated then the maxim um Res
BW of the instrument is used and an asterisk (*) is displayed after the amplitude result of
the harmonic to indicate that the desi red Res BW was not used. The span for each
harmonic is set to zero.
If Range Table is set to On, for each range enabled after the fundamental, the center
frequency will be set to the frequency of each range. If the current span is set to zero, the
amplitude is calculated by a v eraging the power in the trace and is d isp layed in the results
table in the results window. If the range has a non-zero span, the amplitude is calculated
by making a band-power measurement over the span and is displayed in the results table
in the result s w i n d o w.
One-Button Measurement Functions
After the specified number of harmonics have been measured and their amplitudes
displayed, the total har monic dis tortion is computed an d displa yed in the left-hand portio n
of the window (view is set to
Harmonics & THD). If the measurement is in si ngle mode, the
display will remain at the last harmonic setting and the analyzer sweep will be stopped . If
Chapter 267
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
the measurement is in continuous mode, the measurement will continually measure the
amplitude of the fundamental and harmonics.
For averaged measurements, you may specify the number of sweeps over whi ch the
amplitude of each harmonic is measured. This means t hat if the
Avg Number is set to 10, ten
sweeps will be taken and averaged for each harmonic to be measured. The total harmonic
distortion would then be calculated from these averaged amplitude readings. Note that
averaging applies only to the amplitude of the harmonic, and does not aff ect the frequency
at which the amplitude is measured.
Refer to your measurement guide for examples of this me asurement and the calculati on of
Total Harmonic Distortion.
Key P ath:
MEASURE
Dependencies/
Couplings: This measurement is not available when using external mixing.
N/AReturns the amplitude val ues of t he f irst ten
harmonics. The first value (for the
fundamental) is measured in dBm. The
remaining harmonics are measured in dBm
from the fundamental. If fewer than ten
harmonics are measured, zero is returned for
any harmonic not measured.
n=1 to 10
(n=1 for n
not
specified)
Returns the amplitude of the specified
harmonic number n, where n=1 returns the
amplitude of the fundamental in units of
dBm.
For example, n = 9 returns the amplitude of
the ninth harmonic measured in dBc from
the fundamental.
harmonics, in Hz. The first harmonic is the
fundamental. If fewer than ten harmonics
are measured, zero is returned for any
harmonic not measured.
n=2 to 10
(n=1 for n
not
specified)
N/AReturns the frequency of the fundamental,
n=1 to 2
(n=1 for n
not
specified)
Returns the frequency of the specified
harmonic number N (in Hz).
measured in Hz.
These commands return the power of the
spurious emissions at the selected harmonic
frequencies of the current channe l freque ncy
using the selected resolution bandwidth
filter . You can set the number of harmonics
to be measured. For each harmonic, the
reference level is set 40 dB above the largest
amplitude limit with input attenuation held
constant. Th e attenuation is set to limit the
carrier (fundamental) power at the spectrum
analyzer input mixer to the val u e
determined by
Max Mixer Lvl.
Example: FETC:HARM:AMPL:ALL?
MEAS:HARM:AMPL2?
returns the amplitude of the second harmonic
measured in dBc from the fundamental.
READ:HARM:FREQ10 returns the frequency of the tenth harmonic in Hz.
Chapter 269
not specified or n=1
Returns one value that corresponds to the
total harmonic distortion (RMS
voltage %).
n=2
Returns one value that corresponds to the
total harmonic distortion (dB).
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.9Burst Power
The burst power measurement i s an accurate method of deter mining the a verage power for
the specified burst. Bur s t power measures the avera g e po w er in zero-sp a n m o de for the
captured burst. This measurement is primarily for use with time domain modul ated
signals (Bluetooth™, GSM /Edge, and NADC). The burst width, if not user defined, is
determined by finding the pea k in the captured d ata, then searc hing for the firs t place that
the trace is higher than the threshold level. This is considered to be the start of the burst.
The stop of the burst is the first position in the trace that falls below the threshold level.
The mean carrier power is calculated based on the burst width and the threshold level.
Refer to the following figure for clarification of these parameters.
The burst power measurement acquires data from the “Measured Area” above when a
radio standard is chosen and when
When
Meas Setup, Meas Method, Above Threshold Lvl is selected, the “Measured A r ea” extends
the burst width delimiter lines to the start and stop points.
Meas Setup, Meas Method, Measured Burst Width is selected.
The mean carrier power is calculated by:
1. converting each trace point amplitude from dBm into linear power
2. Adding the above amplitudes to gether and dividing by th e number of p oints i nclude d i n
the average.
3. This value is then displayed in logarithmic form (dBm) .
One-Button Measurement Functions
70Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Pavg()1010
log=
m
∑
n
----------------------------
p
----- -
10
10
mn–
where Pav g = av erage p ower, n is the start trace point, m= the stop trace po int, and p= the
trace point amplitude power in dBm.
Figure 2-5 shows an example of the results obtained when measuring a Bluetooth™ signal
and with a user-defined burst width.
Figure 2-5Burst Power Measurement Results
NOTEThe analyzer defaults to zero-spa n m ode and the sweep time is set to capture
at least one b u rst. The swee p ti m e ca n be changed by pressing
Time.
Pressing
measurement setup menu. Pressing
displays the burst power control menu, where you can pause or restart a measurement, or
toggle between continuous and single measurement.
Key Access:
Meas Setup after Burst Power has been selected displays the burst power
Meas Control after Burst Power has been selected
MEASURE
Chapter 271
Sweep, Sweep
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
NOTEThe measurements described above are those available in SA mode (see Mode
key). Other measurements are available in other modes if an optio n al
personality is installed.
Returns 10 scalar results, in the following
order .
1. Sample time
2. Power (RMS of carrier power)
3. Power averaged
4. Number of sample s,
5. Amplitude threshold (relative)
6. Maximum trace point on the measured
part of the burst.
7. Minimum trace point on the measured part
of the burst.
8. Burst width (actual measured width, using
the threshold level)
9. Measured time
10. Measured points
n=2Returns the displayed RF envelope trace data
separated by commas. The number of data
values is determined by the setting of the trace
points parameter.
Example: FETC:BPOW? or MEAS:BPOW? or READ:BPOW?
2.2.10Intermod (TOI)
The third order intermodulation (TOI) measurement computes and disp lays the output
intercept po i n t (IP3), and plac e s m a rkers upon the tr a ce to in d ic a te the measur ed s i gn a l s
and third-order products. For more information see “Meas Setup (Inte r mo d (TOI))” on
page 147.
Key P ath:
One-Button Measurement Functions
MEASURE
72Chapter 2
Remote Command:
Measurement Results Available
CommandnResults Returned
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
:CONFigure:TOI
:INITiate:T OI
:FETCh:TOI?
:MEASure:TOI?
:READ:TOI?
:FETCh:TOI:IP2?
:MEASure:TOI:IP2?
:READ:TOI:IP2?
n/aNot Applicable
n=1 or
not
specified
Returns 6 scalar results, in the following
order.
1. The worst case Output Intercept
Power value in dBm.
2. The worst case Output Intermod Point
in Hz
3. The lower Output Intercept Power
value in dBm
4. The lower Output Intermod Point in
Hz
5. The upper Output Intercept Power
value in dBm
6. The upper Output Intermod Point in
Hz
n=2Returns 12 scal ar results , in the foll owing
order.
1. The worst case Output Intermod Point
value in Hz.
2. The worst case Output Intermod
Power value in dBm.
3. The worst case Output Intercept
Power value in dBm
4. The lower base frequency value in Hz
5. The lower base power value in dBm
6. Th e upp er bas e fre qu e n cy value in Hz
7. Th e up p er bas e po w e r va lu e in dBm
8. The lower Output Intermod Point in
Hz
9. The lower Output Intermod Power
value in dBm
10. The lower Ou tput Intercept Power
value in dBm
11. The upper Output Intermod Power
value in dBm
12. The upper Output Intermod Point in
Hz
13. The upper Output Intercept Power
value in dBm
One-Button Measurement Functions
:FETCh:TOI:IP3?
:MEASure:TOI:IP3?
:READ:TOI:IP3?
Chapter 273
n=1 or
not
specified
Returns the worst case Output Intercept
Power value in dBm.
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Example: FETC:TOIN? or MEAS:TOIN? or READ:TOI N?
FETC:TOIN:IP3? or MEAS:TOIN :IP3 ? or READ :T OIN: IP3?
2.2.11Spurious Emissions
The spurious emissions measurement identifies and determines the power level of
spurious emissions in certain frequency bands. For more information see “Meas Setup
Returns a variable-length list of values containi ng detailed spur
information. The total number of data values returned is (1 + 6x spurs),
where x is the number of spurs identified. You can have up to 121 data
entries if you have the maximum 20 spurs identified. The values returned
are in the foll owing order:
1. Number of spurs in items 2 through 6 in this list
[Repeat the following for each spur]
2. Spur number
3. Range number in which spur was located (integer)
4. Frequency of spur (Hz)
5. Amplitude of spur (dBm)
6. Absolute limit (d Bm)
7. Pass or Fail (1|0)
n=2 through 21Returns trace data values for the selected frequency range (where range
number = n
returned for each non-active trace data element.
n=22Returns the number of spurs found.
− 1). If the selected range is not active, then 9.91E37 is
Example: MEAS:SPUR?
One-Button Measurement Functions
74Chapter 2
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
2.2.12Spectrum Emission Mask
Spectrum Emission Mask measurement includes the in-band and out-of-band spurious
emissions. As it applies to W-CDMA (3GPP), this is the power contained in a specified
frequency bandwidth at certain offsets relative to the total carrier power. It may also be
expressed as a ratio of power spect ral densiti es betwee n the carr ier and the s pecifi ed offse t
frequency band. For WLAN, the reference power is taken as the peak PSD in the signal,
and all offset results are also the peak PSD in that offset as opposed to the integrated
power.
Offsets that are turned off (inact ive) will return -999. 0 when their results are queried over
SCPI.
For more information s e e “Meas Setup (Spectru m Emissions Mask—SEM)” on page 177.
Key P ath:
Returns 60 scalar results, in the following order:
1. Reserved for the future use, returns –999.0
2. Absolute power at the center frequency
(reference) area (dBm)
3. Reserved for the future use, returns –999.0
4. Reserved for the future use, returns –999.0
5. Reserved for the future use, returns –999.0
6. Reserved for the future use, returns –999.0
7. Reserved for the future use, returns –999.0
8. Reserved for the future use, returns –999.0
9. Reserved for the future use, returns –999.0
10.Reserved for the future use, returns -999.0.
11.Relative power on the negative offset A (dBc)
12.Absolute power on t he negative offset A (dBm)
13.Relative peak power on the negative offset A
(dBc)
14.Absolute peak power on the negative offset A
(dBm)
15.Peak frequency in the negative offset A (Hz)
16.Relative power on the positive offset A (dBc)
17.Absolute power on the positive offset A (dBm)
18.Relative peak power on the positive offset A
(dBc)
19.Absolute peak power on the positive offset A
(dBm)
20.Peak frequency in the positive offset A (Hz)
21.Relative power on the negative offset B (dBc)
…
59.Absolute peak power on the positive offset E
(dBm)
60.Peak frequency in the positive offset E (Hz)
One-Button Measurement Functions
76Chapter 2
Measurement Results Available (Continued)
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Command /
Condition
Using Power Spect r a l
Density Reference
nResults Returned
(Continued)
n=1 (or not
specified)
Returns 60 scalar results, in the following order:
1. Reserved for the future use, returns –999.0
2. Absolute power at the center frequency
(reference) area (dBm)
3. Reserved for the future use, returns –999.0
4. Reserved for the future use, returns –999.0
5. Peak frequency in the center frequency
(reference) area (Hz)
6. Reserved for the future use, returns –999.0
7. Reserved for the future use, returns –999.0
8. Reserved for the future use, returns –999.0
9. Reserved for the future use, returns –999.0
10.Reserved for the future use, returns -999.0.
11.Relative power on the negative offset A (dB)
12.Absolute power on the negative offset A
(dBm/Hz)
13.Relative peak power on the negative offset A
(dB)
14.Absolute peak power on the negative offset A
(dBm/Hz)
15.Peak frequency in the negative offset A (Hz)
16.Relative power on the positive offset A (dB)
17.Absolute power on th e posit ive offse t A (d Bm/Hz)
18.Relative peak power on the positive offset A (dB)
19.Absolute peak power on the positive offset A
(dBm/Hz)
20.Peak frequency in the positive offset A (Hz)
21.Relative power on the negative offset B (dB)
…
59.Absolute peak power on the positive offset E
(dBm/Hz)
60.Peak frequency in the positive offset E (Hz)
n=2Returns the displayed frequency domain spectrum
trace data separated by comma. The number of data
points is determined by the setting of the trace points
parameter.
n=3Returns the displayed frequency domain absolute limit
trace data separated by comma. The number of data
points is determined by the setting of the trace points
parameter.
n=4Returns the displayed frequency domain relative limit
trace data separated by comma. The number of data
points is determined by the setting of the trace points
parameter.
Chapter 277
One-Button Measurement Functions
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measurement Results Available (Continued)
Command /
Condition
Using Total Power
Reference
Using Power Spect r a l
Density Reference
nResults Returned
n=5Total Power Reference
Returns 12 scalar values (in dBm) of the absolute
power of the segment frequencies:
1. Total power reference (dBm)
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=5Power Spectral Density Reference
Returns 12 scalar values (in dBm/Hz) of the absolute
power of the segment frequencies:
1. Total power reference (dBm/Hz)
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
Using Total Power
Reference
Using Power Spect r a l
Density Reference
n=6Total Power Reference
Returns 12 scalar values (in dBc) of the power relative
to the carrier at the segment frequencies:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=6Power Spectral Density Reference
Returns 12 scalar values (in dBc/Hz) of the power
relative to the carrier at the segment frequencies:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
One-Button Measurement Functions
78Chapter 2
Measurement Results Available (Continued)
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Command /
Condition
nResults Returned
n=7Returns 12 pass/fail test results (0 = passed, or
1 = failed) determined by te sting the absolut e power in
each offset against the specif ied o ffset’s absolute power
limits:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=8Returns 12 scalar values of the pass/fail (0 = passed, or
1 = failed) results determined by testing the relative
power in each offset against the specified offset’s
relative power limits:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=9Returns 12 scala r values of frequency (in Hz ) that have
peak power in each offset:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=10Returns 12 scalar values (in dBm) of the absolute peak
power of the segment frequencies:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
One-Button Measurement Functions
Chapter 279
One-Button Measurement Functions
MEASURE (Spectrum Analysis Mode)
Measurement Results Available (Continued)
Command /
Condition
nResults Returned
n=11Returns 12 scalar values (in dBc) of the peak power
relative to the carrier at the segment frequencies:
1. Reserved for the future use, returns –999.0
2. Reserved for the future use, returns –999.0
3. Negative offset frequency (A)
4. Positive offset frequency (A)
…
11.Negative offset frequency (E)
12.Positive offset frequency (E).
n=12Returns the band power result when in WLAN
standard. If not in WLAN standard the value returne d
will be .999.0
Example: FETC:SEM? or MEA:SEM? or READ:SEM?
One-Button Measurement Functions
80Chapter 2
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3Meas Setup (Adjacent Channel Power—ACP)
If the adjacent channel power (ACP) measurement has been selected in the Measure menu
of the spectrum analysis mode, this key displays the ACP measurement setup menu.
The adjacent channel power measurement measures the power that leaks into adjacent
transmit channels. Depending on the radio standard chosen from the Mode Setup menu,
this measurement can run in several differe nt mod es in or der t o measure differe nt ty pes of
signals.
Pressing Avg Number to On enables you to specify the number of measurements that will be
averaged when calculating the measurement result. The average will be displayed at the
end of each sweep.Se tting
Key P ath:
Meas Setup
State Saved: Saved in in strument sta te.
Factory Preset: 10 / Off
Range: 1 to 1000
History: Added with PSA firmware revision A.02.00.
[:SENSe]:ACPower:AVERage[:STATe] OFF|ON|0|1 tur n s th e averaging on o r off.
[:SENSe]:ACPower:AVERage[:STATe]?
Avg Number to Off disables the measurement averaging.
One-Button Measurement Functions
Example: ACP:AVER:COUN 10
ACP:AVER:COUN?
ACP:AVER OFF
ACP:AVER?
Chapter 281
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3.2Avg Mode
Press Avg Mode to select the type of termination control used for the aver aging function as
either
measurements (average count) is reached.
• EXP (Exponential Averaging mode)—When you set Avg Mode to Exp, each successive
• Repeat—When you set Avg Mode to Repeat, after reaching the average count, all
Exp or Repeat. This determines the averaging action after the specified number of
data acquisition after the avera ge count is reached is exponentially weighted and
combined with the existing average. Exponential averaging weights new data more
than old data, which facilitates tracking of slow-changing signals. The average will be
displayed at the end of each sweep.
previous result data is cleared and the average count is set back to 1.
Key P ath:
Meas Setup
State Saved: Saved in in strument sta te.
Factory Preset: EXPonential
History: Added with PSA firmware revision A.02.00.
Press Chan Integ BW to speci fy the range of integr ation use d in calc ulating the power in th e
main channel.
Key P ath:
Meas Setup
Key Notes: If RRC Filter is on, the actual integration bandwidth used is the displayed
integration bandwidth multiplied by (1 + Filter Alpha).
State Saved: Saved in in strument sta te.
Factory Preset: 2.0 MHz or as defined by the selected radio standard.
Default Terminator: Hz
Knob Increment: Span/50 if non-zero span.
RBW/100 if zero span.
Step Key
One-Button Measurement Functions
82Chapter 2
Meas Setup (Adjacent Channel Power—ACP)
Increment: RBW if CF Step is set to Auto with zero span.
One-Button Measurement Functions
Span/10 if
CF Step if
CF Step is set to Auto with non-zero span.
CF Step is set to Manual.
Range: 3 Hz to 20 MHz. Depends on the adjacent-channel settings and the
minimum and maximum analyzer span.
History: Added with PSA firmware revision A.02.00.
Accesses menu keys that allow you to configure the offsets for the ACP measurement.
Key P ath:
Meas Setup
2.3.4.1Offset
Selects the offset the menu keys will affect. Press
Offset until the le tter of the desired offs et
is underlined.
Key P ath:
Meas Setup, Offset Setup
State Saved: Saved in in strument sta te.
Factory Preset: A
History: Added with PSA firmware revision A.02.00.
Remote Command:
There is no remote command for this function.
2.3.4.2Offset Freq or Edge Freq
Enables you to set the frequency difference from the center of the main channel to the
center of the offset for a maximum of 6 offsets (labeled A-F). It also allows you to turn
on/off the offsets that you want to measure.
One-Button Measurement Functions
Chapter 283
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
NOTEThis key label changes to Edge Freq when IS-95C, cdma2000 MC-1X, cdma2000
MC-3X, and cdma2000 DS is selected.
Key P ath:
Meas Setup, Offset Setup
State Saved: Saved in in strument sta te.
Factory Preset: The following table shows the default array if no radio standard (
and [:SENSe]:ACPower:OFFSe t:LIST:STATe, are used to set the
parameters for all of the offsets, up to six. The following table shows the
values of these parameters if no radio standard (
Example: Sending fewer than six parameters to one of these commands will leave
the values of the unspecified offsets unchanged. If you don’t send settings
for all 6 offsets, it will set all the offsets that you specified, then it will set
any remaining offsets to the same setting as the last off set that you sent.
For example, after the above command is sent, sending the command with
only four paramenters (ACP:OFFS:LIST:STAT ON,ON,ON,OFF) will result
in the fifth and sixth offset remaining the same as the previous setting
(OFF).
2.3.4.3Ref BW
Sets the reference bandwidth (integrat i on bandwidth) for each offset.
Key P ath:
Meas Setup, Offset Setup
State Saved: Saved in in strument sta te.
Factory Preset: 2 MHz, if no radio standard (
None) is selecte d.
If a radio standa rd is selected, the default v a lue is defined by the selected
standard. This command, along with commands
[:SENSe]:ACP ower:OFFSet:LIST[:FREQuency] and
[:SENSe]:ACPower:OFFSet:LIST:STATe are used to set an entire array of
values. The following table shows the default array if no radio standard
Enables you to set the upper limit for the upper segment of the specified offset pair.
Key P ath: Meas Setup, Offset Setup
State Saved: Saved in in strument sta te.
Factory Preset: 0.00 dB
Default Terminator: dB
Range: –200 dB to 200 dB
History: Added with PSA firmware revision A.02.00.
Enables you to set the upper limit for the lower segment of the specified offset pair.
Key P ath:
Meas Setup, Offset Setup
State Saved: Saved in in strument sta te.
Factory Preset: 0.00 dB
Default Terminator: dB
Range: –200 dB to 200 dB
History: Added with PSA firmware revision A.02.00.
Sets the inpu t a tt enuator and r eference lev el to optimize the ro b u st n ess of the
measurement, in which it is free from errors due to input compression and log amp range
limitations. The input attenuator setting will not necessarily give the optimum dynamic
range, nor the optimum accuracy. No single setting can optimize both, and the optimum
setting often de pends on the sign a l cha r a ct e ri stics.
NOTEThere will always be a minimum of 2 dB for PSA or 5 dB for ESA of
attenuation set to protect the analyz er input.
Key P ath:
Meas Setup
State Saved: Not saved.
History: Added with PSA firmware revision A.02.00.
Remote Command:
[:SENSe]:POWer[:RF]:RANGe:AUTO ONCE
Example: POW:RANG:AUTO ONCE
One-Button Measurement Functions
88Chapter 2
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3.7Method
Enables you to set the measurement method .The resolution bandwidth method is most
useful for measuring cdmaOne and cdma2000 signals; the integration bandwidth method
is preferred for other signal s.
NOTEESA Only:
This key toggles to select either the i ntegration bandwidth method (IBW) or
the resolutio n b an d w i dth method (R B W ).
Key P ath:
Meas Setup
State Saved: Saved in in strument sta te.
Factory Preset: IBW
History: Added with PSA firmware revision A.02.00.
PSA Only: Sets the measurement control method to IBW.
Key Type: 1 of N menu
Key P ath:
Meas Setup, Method
History: Modified with P SA fi r m wa re revision A.06 . 0 0
Remote Command:
Use[:SENSe]:ACPower:METHod See “Method” on page 89.Example: ACP:METH IBW
Chapter 289
One-Button Measurement Functions
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3.7.2RBW
PSA Only: Sets the measurement control method to RBW.
Key Type: 1 of N menu
Key P ath:
Meas Setup, Method
History: Modified with P SA fi r m wa re revision A.06 . 0 0
Remote Command:
Use[:SENSe]:ACPower:METHod See “Method” on page 89.Example: ACP:METH RBW
2.3.7.3Fast
PSA Only: Sets the measurement control method to Fast. When
Fast method is selected,
the 5 point ACLR measurement method is used. The following parameters are configured
to allow the measurement to be made. This method is only available for the 3GPP
W-CDMA radio standard, this key will be disabled for all other radio standards.
NOTEThe current function values are not saved when fa st method is turned on.
Most functions are disabled when Fast is selected.
FunctionValue
Channel Integration BW3.84 MHz
Offset State On, On, Off, Off, Off, Off
Offset Frequency5 MHz, 10 MHz, 0 Hz, 0Hz, 0 Hz
Ref BW3.84 MHz
Meas TypeTotal Pwr Ref
Opt Ref LvlDisabled
RRC Filter StateOn
Filter Alpha0.22 (T fixed at 1/3.84 MHz)
Noise CorrectionOff
Radio Std
Sweep Time
Sweep Time Mode
GateOff
a
a, b
a
3 GPP W-CDMA
6.2 ms
Manual
One-Button Measurement Functions
90Chapter 2
FunctionValue
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
Sweep Points
TriggerFree Run
DetectorAverage
Res BW470 kHz
Res BW ModeManual
Video BW5 MHz
Video BW ModeAuto
Avg/VBW TypePower
Avg/VBW Type ModeAuto
Span23.84 MHz
Span ZoomNot Applicable
Full SpanNot Applicable
Zero SpanNot Applicable
Last SpanNot Applicable
Signal TrackNot Applicable
a
5
a. This function is not disabled when Fast is selected.
b. The maximum sweep time available is limited to 27 ms.
Key Type: 1 of N menu
Key P ath:
Meas Setup, Method
History: Added with PSA firmware revision A.06.00
Remote Command:
Use[:SENSe]:ACPower:METHod See “Method” on page 89.Example: ACP:METH FAST
One-Button Measurement Functions
Chapter 291
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3.8Total Pwr Ref
Enables you to set the adjacent channel power reference to automatic or manual when
Meas Type is set to Total Pwr Ref. When set to automatic, the carrier power result reflects
the measured power value in the carrier. When set to manual, the last measured value is
captured and held, or may be entered by the user. Relative values are displayed,
referenced to the total power measured in the main channel.
Key P ath:
Meas Setup
State Saved: Saved in in strument sta te.
Factory Preset: Auto, Measured carrier power value
Terminat ors: dBm
Default Terminator: dBm
Range: –200 dBm to 200 dBm
History: Added with PSA firmware revision A.02.00.
ESA Only: [:SENSe]:ACPower:CARRier[:POWer] <ampl>
ESA Only: [:SENSe]:ACPower:CARRier[:POWer]?
Example: ACP:CARR:AUTO 0
ACP:CARR:AUTO?
ESA Only: ACP:CARR -100
ESA Only: ACP:CARR?
One-Button Measurement Functions
92Chapter 2
One-Button Measurement Functions
Meas Setup (Adjacent Channel Power—ACP)
2.3.9PSD Ref
Enables you to set the power spectral density in the carrier (main channe l) that will be
used to compute the relative power spectral density values for the offsets when
is set to
PSD Ref. When the PSD Ref state is set to Auto, this will be set to the measured
Remote Command Notes: This function is only available when measurement type is set t o
PSD Ref, use the command [:SENS e]:ACPower:TYPE PSDRef to select the
measurement type.
Example: ACP:CARR:CPSD 5
2.3.10Limit Test
Pressing Limit Test turns the testing of the limit line on or off. When Limit Test is set to On,
each offset is compared to its upper and lower offset limit. In those cases where the power
exceeds the limit, a red “F” is placed next to the dBc result to indicat e a failure . If there are
any failures, the pass/fail indicator area show “FAIL” in red; if there are none, it shows
“PASS” in green. Any offsets that are in the off state (see “Offset Freq or Edge Freq” on
page 83) are not measured and their results will not be displayed on screen.
Key P ath:
State Saved: Saved in in strument sta te.
Factory Preset: Off
Meas Setup
One-Button Measurement Functions
History: Updated with PSA firmware revi sion A.03.00.
Added with PSA firmware revision A.02.00.
Updated with ESA firmware revision A.07.01.
Pressing Filter turns the Root Raised Cosine filter on or off. This filter is the type specified
in the NADC and 3GPP W-CDMA standards and is only available when
NADC, or Tetra is selected as the Radio Std from the Mode Setup me nu. If 3GPP W-CDMA is
selected, the rolloff value (alpha) for the filter will be initially set to 0.22. T is set to
1/RefBW (default 260 ns). If
to 1/RefBW (default 42
0.35. T is set to 1/RefBW (default 55.6
.
Alpha
NADC is selected, the rolloff will be initially set to 0.35. T is set
µs). If TETRA has been selected, the rolloff will be initially set to
µs). The rolloff value can be changed using Filter
3GPP W-CDMA,
The filter is unavailable when the measurement method is set to
Key P ath:
Meas Setup
State Saved: Saved in in strument sta te.
Factory Preset: Off
History: Added with PSA firmware revision A.03.00.
Pressing Noise Correction turns noise correction on or off. When you set NoiseCorr to On, a
calibration of the noise floor is performed and used to correct for analyzer noise floor
contribut i on to measurement levels, increasing dyn a mic range.
Noise Correction is unavailable if signal track ing is on, or when the radio standard is set to
NADC or PDC when the measurement method is set to RBW.
Key P ath:
State Saved: Saved in in strument sta te.
Factory Preset: Off
History: Added with PSA firmware revision A.02.00.
Remote Command Notes: The noise correction feature is not available when the radio
standard is set to NADC or PDC
Example: ACP:CORR:NOIS 1
ACP:CORR:NOIS?
One-Button Measurement Functions
96Chapter 2
One-Button Measurement Functions
Trace/View (ACP Measurement)
2.4Trace/View (ACP Measurement)
If ACP has been selected in the Measure menu of the Spectrum Analysis mode, this key
displays the appropr i ate
measurement.
Displays menu keys that enable you to set how trace information is stored and displayed.
Key Path: Front-panel key
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Remote Command:
There is no equivalent remote command for this funct ion.
Trace/View menu for the adjacent channel power (ACP)
2.4.1Spectrum
Pressing Spectrum selects the spectral display of the measurement.
NOTEPSA Only: Spectrum is disabled when using the Fast Method.
Key P ath:
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Remote Command:
There is no remote command for this function.
Trace/View
Added with ESA firmware revision A.07.00
One-Button Measurement Functions
Chapter 297
One-Button Measurement Functions
Trace/View (ACP Measurement)
2.4.2Bar Graph
Pressing Bars turns the graphic bar disp l ay on or off.
Key P ath:
Trace/View
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Added with ESA firmware revision A.07.00
Remote Command:
There is no remote command for this function.
2.4.3Combined
Pressing Combined selects the measurement to be displayed as a bar graph and spectrum
as shown below.
Key P ath:
Trace/View
Factory Preset: Spectrum
History: Added with PSA firmware revision A.02.00
Added with ESA firmware revision A.07.00
Remote Command:
There is no remote command for this function.
One-Button Measurement Functions
98Chapter 2
One-Button Measurement Functions
Trace/View (ACP Measurement)
2.4.4Combined View Units
Pressing Combined View Units selects the units (dBc or dBm) for the floating numeric
displays when
Combined is selected.
Key P ath:
Trace/View
Factory Preset: dBc
History: Added with PSA firmware revision A.02.00
Added with ESA firmware revision A.08.00
Remote Command:
There is no remote command for this function.
2.4.5Trace
One-button measurements do not change this function. See Volume 1, Core Spectrum
Analyzer Functions User’s and Programmer’s Reference guide for information about
and its lower-level functions.
Trace
Chapter 299
One-Button Measurement Functions
One-Button Measurement Functions
Trace/View (ACP Measurement)
One-Button Measurement Functions
100Chapter 2
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
