Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Troubleshooting

This section covers troubleshooting information for Compaq Presario 1200 Series Portable Notebook Computers. The basic steps in troubleshooting include:
1. Preliminary Steps
2. The Power-On Self Test (POST)
3. The recommended actions described in the diagnostic tables in case you are unable to run POST, or if POST displays an error message.
When following the recommended actions in the Sections on Power-On Self Test (POST) and Diagnostic Error Codes
, perform the steps in the order listed above. Rerun POST after each recommended action until the problem is solved, and if no error message occurs. Once the problem is solved, do not continue with any recommended actions remaining.
Note: If the problem is intermittent, check your computer several times to verify that the problem is solved.

Preliminary Steps

Before running Power-On Self Test (POST), complete the following steps:
1. If a Power-on password is established, type the password and press the Enter key. If you do not know the password, clear the password (See Clearing the Power-On
Password).
2. Run Compaq Diagnostics
.
3. Turn off the computer and its external devices.
4. Disconnect any external devices that you do not want to test. Do not disconnect the printer if you want to test it or use it to log error messages.
Important: If the problem only occurs when an external device is connected to the computer, the problem may be related to the external device or its cable. Verify this by running POST with and without the external device connected.
5. Install loopback plugs in the serial and parallel connectors if you would like to test these ports.
6. Ensure that the hard drive is installed in the notebook.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
1
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
7. Ensure that the battery pack is inserted in the notebook and that it is connected to an external AC power source.
POST
When these preliminary steps are completed, you are ready to run
.

Clearing the Power-On Password

(Removing/Replacing the RTC Battery)
Note: Clearing the Power-on password also removes all notebook Setup attributes that are programmed in the CMOS.
If you do not know the password, clear it by performing the following steps:
1. Turn off the Notebook.
2. Disconnect the power cord.
3. Remove the battery pack
.
4. Remove the Palmrest cover with the TouchPad
5. Remove the Heatspreader
6. Remove the keyboard
.
.
Continued on the next page.
.
2 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
7. To clear the password, remove the RTC battery 1 for 30 seconds and replace it.
8. Reassemble the notebook.
9. Turn on the notebook to verify that the power-on password has been cleared. If it has not been cleared, repeat Steps 1 through 9.

Power-On Self Test (POST)

To run POST, complete these steps:
Turn off the notebook, then turn it on again. As soon as the Compaq logo appears press the ESC key to clear the logo and display the POST messages as they occur.
If the notebook does not beep, POST has successfully completed its test and detected no errors. POST then re-boots from the hard drive, or from a bootable diskette if one is installed in the diskette drive.
However, if POST detects errors, these are indicated by messages on the display screen and/or audible messages. A list of the POST error codes and what they mean is shown in the table below.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
3
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Note: If the system is not functioning well enough to run POST, or if the display is not
functioning well enough to show POST error messages, refer to the Troubleshooting
tables.
Power-On Self-Test Messages
102-System Board Failure
Probable Cause Recommended Action
DMA, timers, etc. Replace the system board.
162-System Options Not Set
Probable Cause Recommended Action
Incorrect configuration Run Computer Setup.
CMOS reflects an invalid configuration setting.
RAM failure
Memory test data error
XX000YZZ RAM failure Replace the system board.
Run Computer Setup.
1. Replace the memory modules.
2. Replace the system board.
1. Replace the memory modules.
2. Replace the system board.
4 T
ROUBLESHOOTING
XX000YZZ 201-Memory Error
Probable Cause Recommended Action
Keyboard failure
1. Ensure that no keys are depressed during POST.
2. Reconnect the keyboard with the
notebook
off.
3. Replace the keyboard.
301-Keyboard Error
Probable Cause Recommended Action
Keyboard failure
1. Ensure the keys are not depressed during POST.
2. Reconnect the keyboard with the
notebook
off.
3. Replace the keyboard.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
304-Keyboard or System Unit Error
Probable Cause Recommended Action
Keyboard or system board error
601-Diskette Controller Error
Probable Cause Recommended Action
Mismatch in drive type or failure in the diskette controller
605-Diskette Drive Error
Probable Cause Recommended Action
Mismatch in drive type Run Computer Setup.
1. Replace the keyboard.
2. Replace the TouchPad or mouse.
3. Replace the system board.
1. Run Computer Checkup (TEST).
2. Check or replace cables.
3. Replace the system board.
1780-Primary Hard Drive 0 Failure
Probable Cause Recommended Action
Disk 0 failed to respond
1. Run Computer Checkup (TEST).
2. Replace the hard drive.
Hard drive format error
1. Run Computer Checkup (TEST).
2. Replace the hard drive.
1782-Hard Drive Controller
Probable Cause Recommended Action
Hard drive controller failure
1. Run Computer Setup.
2. Replace the hard drive.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
5
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Compaq Diagnostics

Compaq Diagnostics is installed on the hard drive of the notebook. Run the Diagnostic utilities when you want to view or test system information and if you have installed or connected devices. If you run Compaq Diagnostics from a diskette, ensure that the diagnostic program is version 10.11 or later.
The Diagnostics menu includes the following utilities:
Computer Checkup (TEST)
View System Information (INSPECT)
Diagnostic Error Codes
Troubleshooting without Diagnostics
Before Replacing Parts
Solving Minor Problems
Solving Hard Drive Problems
Solving Hardware Installation Problems
Solving Keyboard/Numeric Keypad Problems
Solving Memory Problems
Solving PC Card Problems
Solving Power Problems
Solving Printer Problems
Solving TouchPad/Pointing Device Problems
Contacting Compaq Support
If you have a problem you cannot solve, run the Diagnostics utilities before calling for support. Run Computer Checkup and select to save the device list to a file and to print or to save the log of errors. Run the View System Information (INSPECT) utility and select to print or to save that information. Have the files or the printed information available when you call for support.
6 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Computer Checkup (TEST)

Computer Checkup (TEST) determines if the various computer components and devices are recognized by the system and are functioning properly. You can display, print, or save the information generated by Computer Checkup.
Follow these steps to run Computer Checkup:
1. Plug the notebook into an external power source. (A low battery condition could interrupt the program.)
2. Turn on the external devices that you want to test. Connect the printer if you want to print a log of error messages.
3. Insert the Compaq Diagnostics diskette in drive A.
4. Turn on or restart the notebook. The notebook starts from drive A, and the Diagnostics Welcome screen is displayed.
5. Press Enter to continue. The Diagnostics menu is displayed.
6. Select Computer Checkup from the Diagnostics menu. A Test Option menu is displayed.
7. Select View the Device List from the Test Option menu. A list of the installed Compaq devices is displayed.
8. If the list of installed devices is correct, select OK. The Test Option menu is displayed.
Note: If the list is incorrect, ensure that any new devices are installed properly.
Select one of the following from the Test Option menu:
Quick Check Diagnostics. Runs a quick, general test on each device with a
minimal number of prompts. If errors occur, they display when the testing is complete. You cannot print or save the error messages.
Automatic Diagnostics. Runs unattended, maximum testing of each device with
minimal prompts. You can choose how many times to run the tests, to stop on errors, or to print or save a log of errors.
Prompted Diagnostics. Allows maximum control over testing the devices. You
can choose attended or unattended testing, decide to stop on errors, or choose to print or save a log of errors.
9. Follow the instructions on the screen as the devices are tested. When testing is complete, the Test Option menu is displayed.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
7
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
10. Exit the Test Option menu and the Diagnostics menu.

View System Information (INSPECT)

The View System Information (INSPECT) utility provides information about the notebook and installed or connected devices. You can display, print, or save the information.
Follow these steps to run View System Information (INSPECT) from the Compaq Diagnostics diskette:
1. Turn on the external devices that you want to test. Connect the printer if you want to print the information.
2. Insert the Compaq Diagnostics diskette in drive A.
3. Turn on or restart the computer. The computer starts from drive A, and the Diagnostics Welcome screen is displayed.
4. Press Enter to continue. The Diagnostics menu is displayed.
5. Select View System Information (INSPECT) from the Diagnostics menu.
6. Select the item you want to view from the following list:
System Memory
ROM Audio
Keyboard Operating system
System ports System files
System storage Windows files
Graphics
7. Follow the on-screen instructions to cycle through the screens, return to the list and choose another item, or print the information.

Diagnostic Error Codes

Diagnostic error codes are displayed if the system recognizes a problem while running the Compaq Diagnostic program. These error codes help identify subassemblies with possible damage or defects.
8 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
The following tables list error codes, a description of the error condition, and the action required to resolve the error condition.
Important: Retest the system after completing each step. If the problem is resolved, do not proceed with the remaining steps.
For the removal and replacement of a particular subassembly, see Removal and
Replacement Procedures.
Select error codes by number or type:
101 through 114 (pg 10) Processor Test
200 through 215 (pg 10
300 through 304 (pg 11
401 through 403 (pg 11
501 through 516 (pg 14
600 through 699 (pg 12
1101 (pg 12
) Serial Test
)Memory Test
) Keyboard Test
) Parallel Printer Test
)Video Test
) Diskette Drive Test
1701 through 1736 (pg 13
2402 through 2456 (pg 15
2419 through 2456 (pg 16
2458 through 2480 (pg 16
3206 (pg 17
)Audio Test
3301 through 6623 (pg 17
8601 through 8602 (pg 17
)Hard Drive Test
)Video Test
)Video Test
)Video Test
)DVD or CD Test
) TouchPad Pointing Device Test
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
9
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Processor Test Error Codes
Error Code Description Recommended Action
101-xx CPU test failed Replace the processor and retest.
102-xx Coprocessor or Weitek Error
103-xx DMA page registers test failed Replace the system board and retest.
104-xx Interrupt controller master test
failed
105-xx Port 61 error
106-xx Keyboard controller self-test
failed
107-xx CMOS RAM test failed
108-xx CMOS interrupt test failed
109-xx CMOS clock test failed
110-xx Programmable timer load data
test failed
113-xx Protected mode test failed
114-01 Speaker test failed
1. Run the Configuration and Diagnostics Utilities.
2. Replace the processor board and retest.
1. Check system configuration.
2. Verify cable connections to speaker.
3. Replace the system board and retest.
Memory Test Error Codes
Error Code Description Recommended Action
200-xx Memory machine ID test failed
202-xx Memory system ROM checksum
1. Flash the system ROM and retest.
2. Replace the system board and retest.
failed
203-xx Write/Read test failed
204-xx Address test failed
211-xx Random pattern test failed
1. Remove the memory module and retest.
2. Install a new memory module and retest.
214-xx Noise test failed
215-xx Random address test failed
10 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Keyboard Test Error Codes
Error Code Description Recommended Action
300-xx Failed ID Test
301-xx Failed Self Test/Interface Test
302-xx Failed Individual Key Test
304-xx Failed Keyboard Repeat Test
Parallel Printer Test Error Codes
Error Code Description Recommended Action
401-xx Printer failed or not connected
402-xx Failed Port Test
403-xx Printer pattern test failed
1. Check the keyboard connection. If
disconnected, turn off the computer and reconnect the keyboard.
2. Replace the keyboard and retest.
3. Replace the system board and retest.
1. Connect the printer.
2. Check power to the printer.
3. Install the loop-back connector and
retest.
4. Check port and IRQ configuration.
5. Replace the system board and retest.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
11
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Diskette Drive Test Error Codes
Error Code Description Recommended Action
600-xx Diskette ID drive types test
failed
601-xx Diskette format failed
602-xx Diskette read test failed
603-xx Diskette write, read, compare
test failed
604-xx Diskette random read test failed
605-xx Diskette ID media failed
606-xx Diskette speed test failed
609-xx Diskette reset controller test
failed
610-xx Diskette change line test
697-xx Diskette type error
698-xx Diskette drive speed not within
limits
699-xx Diskette drive/media ID error
1. Replace the diskette media and retest.
2. Check and/or replace the diskette power and signal cables and retest.
3. Replace the diskette and retest.
4. Replace the system board and retest.
1. Replace media.
2. Run the Configuration and Diagnostics Utilities.
Serial Test Error Codes
Error Code Description Recommended Action
1101-xx Serial port test failed
1. Check port configuration.
2. Replace the system board and retest.
12 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Hard Drive Test Error Codes
Error Code Description Recommended Action
1701-xx Hard drive format test failed
1702-xx Hard drive read test failed
1703-xx Hard drive write/read/compare
test failed
1704-xx Hard drive random seek test
failed
1705-xx Hard drive controller test failed
1706-xx Hard drive ready test failed
1707-xx Hard drive recalibration test
failed
1708-xx Hard drive format bad track test
failed
1709-xx Hard drive reset controller test
failed
1710-xx Hard drive park head test failed
1715-xx Hard drive head select test failed
1716-xx Hard drive conditional format
test failed
1717-xx Hard drive ECC* test failed
1719-xx Hard drive power mode test
failed
1724-xx Network preparation test failed
1736-xx Drive monitoring test failed
1. Run the Configuration and Diagnostics
Utilities and verify drive type.
2. Verify that all secondary drives have
secondary drive capability.
3. Replace the hard drive and retest.
4. Replace the system board and retest.
*ECC = Error Correction Code
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
13
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Video Test Error Codes
Error Code Description Recommended Action
501-xx Video controller test failed The following steps apply to error codes
502-xx Video memory test failed
503-xx Video attribute test failed
504-xx Video character set test failed
505-xx Video 80 x 25 mode 9 x 14
character cell test failed
506-xx Video 80 x 25 mode 8 x 8
character cell test failed
507-xx Video 40 x 25 mode test failed
508-xx Video 320 x 200 mode color set
0 test failed
509-xx Video 320 x 200 mode color set
1 test failed
510-xx Video 640 x 200 mode test
failed
511-xx Video screen memory page test
failed
512-xx Video gray scale test failed
514-xx Video white screen test failed
516-xx Video noise pattern test failed
501-xx through 516-xx:
1. Disconnect external monitor and test with internal LCD display.
2. Replace the display assembly and retest.
3. Replace the system board and retest.
14 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Video Test Error Codes (Continued)
Error Code Description Recommended Action
2402-xx Video memory test failed The following steps apply to error codes
2403-xx Video attribute test failed
2404-xx Video character set test failed
2405-xx Video 80 x 25 mode 9 x 14
character cell test failed
2406-xx Video 80 x 25 mode 8 x 8
character cell test failed
2408-xx Video 320 x 200 mode color set
0 test failed
2409-xx Video 320 x 200 mode color set
1 test failed
2410-xx Video 640 x 200 mode test
failed
2411-xx Video screen memory page test
failed
2412-xx Video gray scale test failed
2414-xx Video white screen test failed
2416-xx Video noise pattern test failed
2418-xx ECG/VGC memory test failed
2402-xx through 2456-xx:
1. Run the Configuration and Diagnostics
Utilities.
2. Replace the display assembly and
retest.
3. Replace the system board and retest.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
15
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Video Test Error Codes (Continued)
Error Code Description Recommended Action
2419-xx ECG/VGC ROM checksum test
failed
2421-xx ECG/VGC 640 x 200 graphics
mode test failed
2422-xx ECG/VGC 640 x 350 16 color set
test failed
2423-xx ECG/VGC 640 x 350 64 color set
test failed
2424-xx ECG/VGC monochrome text
mode test failed
2425-xx ECG/VGC monochrome graphics
mode test failed
2431-xx 640 x 480 graphics test failure
2432-xx 320 x 200 graphics (256 color
mode) test failure
2448-xx Advanced VGA Controller test
failed
2451-xx 132-column Advanced VGA test
failed
2456-xx Advanced VGA 256 Color test
failed
1. Run the Configuration and Diagnostics Utilities.
2. Disconnect external monitor and test with internal LCD display.
3. Replace the display assembly and retest.
4. Replace the system board and retest.
Video Test Error Codes (Continued)
Error Code Description Recommended Action
2458-xx Advanced VGA BitBLT test failed The following applies to error codes
2468-xx Advanced VGA DAC test failed
2477-xx Advanced VGA data path test
failed
2458-xx through 2480-xx:
Replace the system board and retest.
2478-xx Advanced VGA BitBLT test failed
2480-xx Advanced VGA LineDraw test
failed
16 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Audio Test Error Codes
Error Code Description Recommended Action
3206-xx Audio System Internal Error Replace the system board and retest.
TouchPad/Pointing Device Interface Test Error Codes
Error Code Description Recommended Action
8601-xx Mouse test failed
8602-xx Interface test failed
DVD or CD Drive Test Error Codes
Error Code Description Recommended Action
3301-xx DVD or CD drive read test failed
3305-xx DVD or CD drive seek test failed
6600-xx ID test failed
6605-xx Read test failed
6608-xx Controller test failed
6623-xx Random read test failed
1. Replace the TouchPad and retest.
2. Replace the system board and retest.
1. Replace the DVD or CD and retest.
2. Verify that the speakers are
connected.
3. Verify that drivers are loaded and
properly installed.
4. Replace the DVD or CD drive and
retest.
5. Replace the system board and retest.

Troubleshooting without Diagnostics

This section provides information about how to identify and correct some common hardware, memory, and software problems. It also explains several types of common messages that may be displayed on the screen. The following pages contain troubleshooting information on:
Audio
Battery PC Card
CD or DVD Drive Power
Diskette Drive Printer
Display TouchPad
Hard Drive Keyboard/Numeric Keypad
Hardware Installation
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
Memory
1200XL S
ERIES
T
ROUBLESHOOTING
17
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Since symptoms can appear to be similar, carefully match the symptoms of the computer malfunction against the problem description in the tables to avoid a misdiagnosis.
WARNING: To avoid a potential shock hazard during troubleshooting procedures,
Å
disconnect all power sources before removing the keyboard cover or the display bezel.

Before Replacing Parts

Verify that cables are connected properly to the suspected defective parts.
Run Computer Setup after connecting external devices.
Verify that all required device drivers are installed.
Verify that all required changes have been made to the CONFIG.SYS file.
Verify that all required changes have been made to the AUTOEXEC.BAT file.
Verify that all printer drivers have been installed for each application.

Solving Minor Problems

Some minor problems and possible solutions are outlined in the following tables. If the problem appears related to a software application, check the documentation provided with the software.

Solving Audio Problems

Some common audio problems and solutions are listed in the following table.
Solving Audio Problems
Problem Probable Cause Solution
Computer does not beep after the Power­On Self-Test (POST).
This is typical; it indicates successful completion of the Power-On Self-Test (POST).
No action is required.
18 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Solving Battery Pack/Gauge Problems

Some common causes and solutions for battery pack problems are listed in the following table. The "Solving Power Problems" section in this chapter may also be applicable.
Solving Battery Pack/Gauge Problems
Problem Probable Cause Solution(s)
Computer won’t turn on when battery pack is inserted and power cord is unplugged.
Notebook is beeping and battery icon is blinking.
Battery icon on the front of the unit blinks to indicate low battery condition, but computer does not beep.
Battery icon doesn’t light and battery pack won’t fast charge.
Battery pack is discharged. Connect the computer to an
external power source and charge the battery pack.
OR
Replace the battery pack with a
fully charged battery pack.
Check the battery connectors on the system board to verify they are evenly spaced and that they are not bent or broken.
Battery charge is low. Immediately save any open
file(s). Then complete one of the following:
Connect the notebook to an
external power source to charge the battery pack.
Turn off the notebook or initiate
Hibernation until you can find another power source or charge the battery pack.
Volume is turned down too
Adjust the volume.
low.
Battery pack is already
No action is necessary.
charged.
Battery pack was exposed to temperature extremes.
Battery pack is at end of its
Allow time for the battery pack to return to room temperature.
Replace the battery pack.
life.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
19
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Battery Pack/Gauge Problems
Problem Probable Cause Solution(s)
You have to set the date and time every time you turn on the notebook.
Battery charge does not last as long as expected.
Battery pack is warm to the touch after charging.
Battery pack operating time is far less than the documented average operating time.
RTC battery is dead. Replace the RTC battery.
Battery is being exposed to high temperatures or extremely cold temperatures.
Keep the battery pack within the recommended temperature range for operation or storage.
Operating Range: 50°F to
104°F (10°C to 40°C)
Storage Range: -4°F to 86°F
(-20°C to 30°C)
Recharge the battery pack.
Battery has partially self­discharged.
Recharge the battery. Discharge the battery completely and then recharge it.
Power management is disabled.
An external device or PC Card is draining the battery.
Normal warming has occurred
Set a power management level in Computer Setup.
Turn off or disconnect external devices when not in use.
No action is required.
due to charging.
Power management is turned off or disabled.
Enable power management in Computer Setup and in Windows Power Properties.
An external device or PC Card is draining the battery.
Turn off or disconnect external devices when not in use.
20 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Battery Pack/Gauge Problems
Problem Probable Cause Solution(s)
Battery pack has partially self-discharged.
Battery pack is being exposed to high temperatures or extremely cold temperatures.
Condition the battery pack by fully charging, fully discharging, then fully recharging it.
To maintain the charge, leave battery packs in the computer when it is connected to external power.
If the notebook is disconnected from external power for more than two weeks, remove battery packs from the notebook to reduce the discharge rate.
Keep the battery pack within the recommended temperature range for operation or storage.
Operating Range: 50°F to
104°F (10°C to 40°C)
Storage Range: -4°F to 86°F
(-20°C to 30°C)
Recharge the battery pack.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
21
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Solving CD and DVD Drive Problems

Some common causes and solutions for CD and DVD drive problems are listed in the following table.
Solving CD or DVD Drive Problems
Problem Probable Cause Solution(s)
CD or DVD drive cannot read a Compact Disc or Digital
Disc is upside down or is improperly inserted in the CD or DVD drive.
Versatile Disc.
CD is CD Plus or Pregap/Track 0 type.

Solving Diskette Drive Problems

Some common causes and solutions for diskette drive problems are listed in the following table.
Open the loading tray, lay the compact disc in it (label side up), then close the tray.
Cannot read these type CDs in 24x. Remove the CD.
Solving Diskette Drive Problems
Problem Probable Cause Solution(s)
Diskette drive cannot write to a diskette.
Diskette is write-protected. Disable the diskette’s write-
protect feature or use a diskette that is not write-protected.
Computer is writing to the wrong drive.
Not enough space is left on
Check the drive letter in the path statement.
Use another diskette.
the diskette.
Drive error has occured. Run Computer Checkup from the
Compaq Diagnostics diskette.
Diskette is not formatted. Format the diskette. At the
system prompt, enter: FORMAT A:
Diskette drive cannot read a diskette.
Diskette drive cannot read a diskette.
Use the type of diskette required by the drive.
Diskette has a bad sector. Copy files to hard drive or another
diskette. Reformat bad floppy.
Drive error has occurred. Run Computer Checkup from the
Compaq Diagnostics diskette.
22 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Diskette Drive Problems
Problem Probable Cause Solution(s)
(Continued) Diskette drive cannot
read a diskette.
Cannot boot from diskette.

Solving Display Problems

This section lists some common causes and solutions for computer display and external monitor problems.
You can perform a monitor self-text on an external VGA color or monochrome monitor by disconnecting the monitor from the notebook, then completing the following steps:
Diskette is not formatted. Format the diskette. At the
system prompt, enter FORMAT A:
Bootable diskette is not in drive A.
Diskette Boot has incorrect setting in Computer Setup.
Put the bootable diskette in drive A.
Run Computer Setup and set diskette as first to boot.
1. Turn off the monitor.
2. Turn off the notebook.
3. Disconnect the monitor signal cable from the notebook.
4. Turn on the monitor and allow it to warm up for one minute.
The display should be white. A narrow black border may also appear on the left and right sides of the display. Either of these displays indicates that the monitor is working properly.
Solving Display Problems
Problem Probable Cause Solution(s)
Screen is dim. Control for brightness (if
applicable) is not set properly.
Computer screen is in direct light.
Screen is blank. Screen save was initiated by
Power Management due to lack of user activity.
Adjust the Brightness of the display by using Fn+F7 or Fn+F8.
Tilt display or move computer.
Press any key or touch the TouchPad.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
23
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Display Problems
Problem Probable Cause Solution(s)
Display has overheated. If the notebook is in direct
sunlight, move it and allow it to cool off.
Display is blank and the Suspend icon is flashing.
Internal display is blank and the screen on an external monitor displays information.
Internal display flashes or has garbled characters when notebook is connected to external monitor.
The light tubes on the edge of the display panel do no light up at all and the Power-On Self-Test (POST) completes when the unit is powered up.**
The light tubes on the edge of the display panel do not light up at all and Power-On Self-Test (POST) does not complete when the unit is powered up.**
Backlight (brightness) cannot be adjusted with Fn+F7 or Fn+F8.
System is in Suspend mode. Press any key or touch the
TouchPad.
Display function was switched to the external monitor.
Using 1024 x 768 or higher
Use Fn+F3 to switch between LCD or CRT.
Restart the notebook. resolution on external monitor and have toggled back to internal display, which supports up to 800 x 600.
Improper backlight or display
Replace the display assembly. cable connections
Defective inverter board. Replace the display assembly.
Defective display cable. Replace the display assembly.
Defective display panel. Replace the display assembly.
Defective system board. Replace the system board.
Defective system board. Replace the system board.
Improper display cable connections.
1. Reseat the display cable to the system board.
2. Replace the display assembly.
24 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Display Problems
Problem Probable Cause Solution(s)
(Continued) Defective inverter board. Replace the display assembly.
Defective display cable. Replace the display assembly.
Defective system board. Replace the system board.
**This problem indicates that the backlight or its power circuitry has failed. If the backlight is not functioning, the POST result cannot be observed. Connect the unit to an external monitor before powering up the unit. If an external monitor is not available verify that POST is complete by opening and closing the display, listening for the single or double beep, and watching for the icons to turn on at the front of the notebook.
Solving Display Problems Continued
Problem Probable Cause Solution(s)
This display panel has a continuous pattern across it (e.g., “jailbars” pattern), has a single color on it, or has garbled graphics across the entire panel. This failure is for patterns across the entire panel (not just on one section).
A single line, small group of lines, or block appears on the display panel. This failure occurs in only a section of the display panel.
Improper display cable connections
Defective display cable. Replace the display assembly.
Defective inverter board. Replace the display assembly.
Defective system board. Replace the system board.
Defective display panel. Replace the display assembly.
Reseat the display cable to the following until the problem is solved:
1. System board
2. Display assembly
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
25
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Note: When you perform a "self-test" on an external VGA color or monochrome monitor,
the screen should be white. A narrow black border may also appear on the left and right sides of the display. Either of these displays indicates that the monitor is working properly.

Solving Hard Drive Problems

Some common causes and solutions for hard drive problems are listed in the following table.
CAUTION:
Ä
of your hard drive at all times, in case of errors or failures.
Problem Probable Cause Solution(s)
Reading hard drive takes an unusually long time after restarting the notebook.
Hard drive error occurs.
Hard drive does not work.
To prevent loss of information, always maintain an up-to-date backup
Solving Hard Drive Problems
System entered Hibernation due to low battery condition and is now exiting from it.
Hard drive has bad sectors or has failed.
Hard drive is not seated properly.
Give the system time to restore the previously saved data to its exact state before Hibernation.
Run Computer Checkup.
Turn off and unplug the notebook, remove the battery pack, and remove and then reinstall the hard drive.
26 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Solving Hardware Installation Problems

Some common causes and solutions for hardware installation problems are listed in the following table.
Solving Hardware Installation Problems
Problem Probable Cause Solution(s)
A new device is not recognized as part of the computer system.
Cable(s) of new external device are loose or power
Ensure that all cables are proplerly and securely connected.
cables are unplugged.
Power switch of new external device is not turned on.
Turn off the notebook, turn on the external device, then turn on the notebook to integrate the device with the computer system.
Device is not seated properly. Turn off the notebook and reinsert
the device.

Solving Keyboard/Numeric Keypad Problems

Some common causes and solutions for keyboard/numeric keypad problems are listed in the following table.
Solving Keyboard/Numeric Keypad Problems
Problem Probable Cause Solution(s)
Embedded numberic keypad on notebook keyboard is disabled.
Embedded numeric keypad is disabled and Num Lock function is on.
Num Lock function is not enabled.
External numeric keypad is connected to the notebook.
Press the Shift+NumLk keys to enable the Num Lock function and embedded numberic keypad. The Num Lock light on the notebook turns on.
Disconnect the external numeric keypad from the notebook.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
27
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Solving Memory Problems

Some common causes and solutions for memory problems are listed in the following table.
Solving Memory Problems
Problem Probable Cause Solution(s)
Memory count during Power-On Self-Test (POST) is incorrect.
“Out of Memory” message is displayed on the screen or insufficient memory error occurs during operation.
Optional memory expansion card is installed incorrectly, is incompatible with the computer, or is defective.
System ran out of memory for the application.
Too many TSR (terminate­and-stay-resident) applications are running.
Ensure that the optional memory expansion card is installed correctly.
Check the application documentation for memory requirements.
If necessary, Install additional memory.
Remove from memory any TSR applications that you do not need.

Solving PC Card Problems

The following table lists some common causes and solutions for PC Card problems.
Solving PC Card Problems
Problem Probable Cause Solution(s)
When turned on, the computer does not beep when a PC Card is inserted.
Card is not inserted properly. Ensure that the card is inserted in
the correct orientation.
PC Card beeps are disabled. Double-click the PC Card icon in
the Control Panel, click the Global Settings tab, the enable PC Card sound effects.
Speaker is turned off or volume is turned down.
Press Volume buttons to turn the speaker on, then increase the volume.
28 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving PC Card Problems
Problem Probable Cause Solution(s)
PC Card modem, fax, or network card does not work.
PC Card modem or fax card does not work.
Modem netword PC Card does not work.
PC Card drivers are not installed.
Card or card driver is not supported.
Card is not fully inserted into the slot or is not inserted properly.
Telephone cord is not plugged in all the way.
Necessary drivers are not installed (turned on).
You are trying to access the card using the wrong COM port.
The card conflicts with a serial device.
The card is not supported. Use supported cards only.
Network driver is not installed or is not set up properly.
Telephone cord is not properly connected.
Double-click the Add New Hardware icon in the Control Panel for installation instructions.
If PC Card or drivers are not compatible with Windows, install drivers and use the PC Card in MS-DOS mode.
Contact a Compaq authorized service provider for a list of PC Cards tested sucessfully in Compaq PC Card platforms.
Ensure that the card is inserted in the correct orientation.
Check and secure telephone connection.
Install drivers.
See Specifications port.
See Specifications to verify address.
Install driver.
Verify telephone connection.
to verify COM
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
29
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving PC Card Problems
Problem Probable Cause Solution(s)
Memory or storage card does not work.
SRAM and flash memory
Install driver. cards require the memory card driver to be loaded (turned on).
Flash memory cards require the Microsoft FlashFile System to be loaded.
Hard drives on flash mass storage cards require the PC Card ATA driver to be loaded.
You are trying to access the hard drive card using the wrong drive letter.
Double-click My Computer to
verify the drive letter assigned to
the card.
The card is not supported. Contact a Compaq authorized
service provider for a list of PC
Cards tested successfully in
Compaq PC Card platforms.

Solving Power Problems

Also see Solving Battery Pack/Gauge Problems in this section.
Solving Power Problems
Problem Probable Cause Solution(s)
Notebook will not turn on and the battery pack is not inserted.
Notebook is not connected to a power source.
Power cords to the external power source are unplugged.
Power adapter is defective. Replace AC Adapter and restart.
Insert battery or connect an
external power source.
Ensure that power cords
connecting the computer and the
external power source are
plugged in properly.
30 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Power Problems
Problem Probable Cause Solution(s)
Notebook turned off
System board is defective. Replace the system board.
while it was left unattended and the power icon is off.
System initiated Hibernation due to a critical low-battery condition.
Replace the battery pack with a fully charged battery pack or connect the notebook to an external power source. Then turn on the notebook.
System initiated Hibernation
Turn on the notebook.
after a preset timeout.

Solving Printer Problems

If you experience problems printing, run a printer self-test. Refer to the documentation provided with your printer for instructions. If the self-test fails, it is a printer-specific problem. Also refer to the printing section of your application documentation.
Solving Printer Problems
Problem Probable Cause Solution(s)
Printer will not turn on. The signal cable may not be
connected properly, or the printer is unplugged.
Ensure that the signal cable is properly connected and that the power cord is connected to the electrical outlet.
Printer will not print. Printer is not turned on or is
offline.
The device drivers for the application is not installed.
Turn the printer on and set it to online.
Refer to the printer documentation to install the correct printer driver.
Printer that is set up for a network is not connected to
Connect the printer to the network.
the network.
Printer cable is too long,
Replace the cable.
unshielded, or defective.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
31
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving Printer Problems
Problem Probable Cause Solution(s)
Paper tray is empty. Fill the paper tray with paper and
set the printer to online.
Printer prints garbled information.
Correct printer drivers are not installed.
Refer to the printer
documentation to install the
correct printer driver.
Cable is not connected properly.
Ensure that the printer signal
cable is properly connected to the
notebook.
Cable is defective. Replace the printer cable and
retest.

Solving TouchPad/Pointing Device Problems

The following table lists some common causes and solutions for TouchPad/pointing device problems.
Solving TouchPad/Pointing Device Problems
Problem Probable Cause Solution(s)
TouchPad or mouse does not work.
Incorrect or no device driver is installed.
Install the device driver and add
to the AUTOEXEC.BAT file or
CONFIG.SYS file.
External mouse does not work.
The device driver is not installed in Windows.
Mouse is not securely connected or is connected to an incorrect external
Install the TouchPad/mouse driver
in Windows.
Ensure that the mouse is securely
connected to the appropriate
external connector. connector.
TouchPad or mouse does not work even though the device is enabled in Windows.
Mouse is not enabled. Enter MOUSE at the system
prompt to activate the mouse
device driver.
Add a line in the AUTOEXEC.BAT
file to automatically activate the
mouse driver each time the
computer is turned on or
restarted.
32 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Solving TouchPad/Pointing Device Problems
Problem Probable Cause Solution(s)
Cable is not properly seated
Reseat cable.
in TouchPad board.
Defective TouchPad board. Replace the TouchPad board.
Defective system board. Replace system board.
Cursor skips or moves abnormally when using the TouchPad.
Device driver is not correclty installed in Windows.
The TouchPad needs to be cleaned.
Install the appropriate device driver in Windows.
Clean the TouchPad with a cloth dampened with alcohol or an ammonia-based glass cleaner. Wipe up liquid with a dry cloth.

Contacting Compaq Support

Obtain the following information before contacting Compaq Reseller Support:
Product name
Product serial number
Purchase date
Conditions under which the problem occurred
Any error messages that have occurred
Hardware configuration
Type of printer connected
Hardware/software installed
Printed result of Computer Checkup (TEST)
Printed copies of CONFIG.SYS and AUTOEXEC.BAT files, if possible.
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
33
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127

Shipping Preparation

To ship the notebook, complete the following steps:
1. Back up the critical hard drive files. Ensure that backup tapes/diskette are not exposed to electrical or magnetic fields while stored or in transit.
2. Turn off the notebook and external devices.
3. Disconnect the external devices from their power sources, then from the notebook.
Important: Ensure that there is no diskette in the diskette drive and that there are no PC Cards in the PC slots.
4. Close the display and all exterior doors of the notebook.
5. Pack the notebook with sufficient packing material to protect it. Use the original packing box or similar packaging.

POST Routine Description

Note: The following routines are sorted by their test point numbers assigned in the BIOS code. Their actual orders, as executed during POST, can be quite different.
Code Beeps POST Routine Description
02h Verify Real Mode
03h Disable Non-Maskable Interrupt (NM)
04h Get CPU type
06h Initialize system hardware
08h Initialize chipset with Initial POST values
09h Set IN POST flag
0Ah Initialize CPU registers
0Bh Enable CPU cache
0Ch Initialize caches to initial POST values
0Eh Initialize I/O component
0Fh Initialize the local bus IDE
10h Initialize Power Management
11h Load alternate registers with initial POST values
34 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Code Beeps POST Routine Description
12h Restore CPU control word during warm boost
13h Initialize PCI Bus Mastering devices
14h Initialize keyboard controller
16h 1-2-2-3 BIOS ROM Checksum
17h Initialize cache before memory autosize
18h 8254 timer initialization
1Ah 8237 DMA controller initialization
1Ch Reset Programmable Interrupt Controller
20h Te s t D RA M r ef re s h
22h Test 8742 Keyboard Controller
24h Set ES segment register to 4 GB
26h Enable A20 line
28h Autosize DRAM
29h Initialize POST Memory Manager
2Ah Clear 512 KB base RAM
2Ch RAM failure on address line xxxx*RAM failure on data
bits xxxx* of low byte of memory bus
2Eh Enable cache before system BIOS shadow
2Fh RAM failure on data bits xxxx*of high byte memory bus
30th Test CPU bus-clock frequency
32h Initialize Phoenix Dispatch Manager
33h Warm start shut down
36h Shadow system BIOS ROM
38h Autosize cache
3Ah Advanced configuration of chipset registers
3Ch Load alternate registers with CMOS values
3Dh Initialize interrupt vectors
42h POST device initialization
45h Check ROM copyright notice
46h Check Video configuration against CMOS
48h Initialize PCI bus and devices
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
35
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Code Beeps POST Routine Description
49h Initialize all video adapters in system
4Ah QuietBoot start (optional)
4Bh Shadow video BIOS ROM
4Ch Display BIOS copyright notice
4Eh Display CPU type and speed
50Eh Initialize EISA board
51h Te s t k ey bo a rd
52h Set key click if enabled
54h Test for unexpected interrupts
58h Initialize POST display service
59h Display prompt "Press F2 to enter SetUP"
5Ah Disable CPU cache
5Bh Test RAM between 512 and 640 KB
5Ch Test extended memory
60h Test extended memory address lines
62h Jump to UserPatchI
64h Configure advanced cache registers
66h Initialize Multi Processor APIC
67h Enable external and CPU cache
68h Setup System Management Mode (SMM) area
69h Display external L2 cache size
6Ah Load custom defaults (optional)
6Bh Display shadow-area message
6Ch Display possible high address for UMB recovery
6Eh Display error messages
70h Check for configuration errors
72h Check for keyboard errors
76h Set up hardware interrupt vectors
7Ch Initialize coprocessor if present
7Eh Disable onboard Super I/O ports and IRQs
80h Late POST device initialization
36 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Code Beeps POST Routine Description
81h Detect and install external RS232 ports
82h Configure non-MCD IDE controllers
83h Detect and install external parallel ports
84h Initialize PC-compatible PnP ISA devices
85h Reinitialize onboard I/O ports
86h Configure Motherboard Configurable Devices (optional)
87h Initialize BIOS Data Area
88h Enable Non-Maskable Interrupts (NMIs)
89h Initialize Extended BIOS Data Area
8Ah Test and initialize PS/2 mouse
8Bh Initialize floppy controller
8Ch Determine number of ATA drives (optional)
81h Initialize hard disk controllers
90h Initialize local-bus hard disk controllers
91h Jump to UserPatch2
92h Build MPTABLE for multi-processor boards
93h Install CD ROM or DVD Drive for boot
95h Clear huge ES segment register
96h Fixup Multi Processor table
97h Search for option ROMs. One long, two short beeps on
checksum failure
98h Check for SMART drive (optional)
99h Shadow option ROMs
9Ah Set up Power Management
9Ch Initialize security engine (optional)
9Dh Enable hardware interrupts
9Eh Determine number of ATA and SCSI drives
9Fh Set time of day
A0h Check key lock
A2h Initialize Typematic rate
A4h Erase F2 prompt
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
T
ROUBLESHOOTING
37
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Code Beeps POST Routine Description
A8h Scan for F2 key stroke
AAh Enter Setup
Clear Boot flag
Check for errors
POST done - prepare to boot operating system
One shot beep before boot
Terminate QuietBoot (optional)
Check password (optional)
Prepare Boot
Initialize DMI Parameters
Initialize PnP Option ROMs
Clear parity checkers
Display MultiBoot menu
Clear screen (optional)
check virus and back up reminders
Try to boot with INT 19
Initialize POST Error Manager (PEM)
Initialize error logging
Initialize error display function
Initialize system error handler
PnPnd dual CMOS (optional)
Initialize notebook docking (optional)
Initialize notebook docking late
Force check (optional)
Extended checksum (optional)
Unknown interrupts
38 T
ROUBLESHOOTING
RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE
1200XL S
ERIES
Loading...
