Page 1
FHB 51 IX/HA S EH 51 I X/HA EHS 51 I X/HA EHS 51 KX/HA
Italiano
FORNO
Sommario
Istruzioni per l’uso,1 Avvertenze,2 Assistenza,3 Descrizione dell’apparecchio,4 Descrizione dell’apparecchio,5 Installazione,6 Avvio e utilizzo,8 Programmi,9 Precauzioni e consigli,11 Manutenzione e cura,11
English
Operating Instructions
OVEN
Contents
Operating Instructions,1 Warnings,2 Assistance,3 Description of the appliance,4 Description of the appliance,5 Installation,13 Start-up and use,15 Cooking modes,16 Precautions and tips,18 Maintenance and care,18
Page 2
Avvertenze
Warnings
ATTENZIONE: Questo apparecchio e le sue parti accessibili diventano molto caldi durante l’uso. Bisogna fare attenzione ed evitare di toccare gli elementi riscaldanti. Tenere lontani i bambini inferiori agli 8 anni se non continuamente sorvegliati. Il presente apparecchio può essere utilizzato dai bambini a partire dagli 8 anni e da persone con ridotte capacità
siche, sensoriali o mentali oppure con
mancanza di esperienza e di conoscenza se si trovano sotto adeguata sorveglianza oppure se sono stati istruiti circa l’uso dell’apparecchio in modo sicuro e se si rendono conto dei pericoli correlati. I bambini non devono giocare con l’apparecchio. Le operazioni di pulizia e di manutenzione non devono essere effettuate dai bambini senza sorveglianza.
Non utilizzare prodotti abrasivi né spatole di metallo taglienti per pulire lo sportello in vetro del forno in quanto potrebbero
grafare la supercie, provocando, così,
la frantumazione del vetro.
WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
Never use steam cleaners or pressure cleaners on the appliance.
Non utilizzare mai pulitori a vapore o ad alta pressione per la pulizia dell’apparecchio.
ATTENZIONE: Assicurarsi che l’apparecchio sia spento prima di sostituire la lampada per evitare la possibilità di scosse elettriche.
! Quando si inserisce la griglia assicurarsi che il fermo sia rivolto verso l’alto e nella parte posteriore della cavità.
2
WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.
! When you place the rack inside, make sure that the stop is directed upwards and in the back of the cavity.
Page 3
Assistenza
Assistance
! Non ricorrere mai a tecnici non autorizzati.
Comunicare:
• Il tipo di anomalia;
• Il modello della macchina (Mod.)
• Il numero di serie (S/N)
Queste ultime informazioni si trovano sulla targhetta caratteristiche posta sull’apparecchio
Assistenza Attiva 7 giorni su 7
Se nasce il bisogno di assistenza o manutenzione basta chiamare il Numero Unico Nazionale 199.199.199* per essere messi subito in contatto con il Centro Assistenza Tecnica più vicino al luogo da cui si chiama. È attivo 7 giorni su 7, sabato e domenica compresi, e non lascia mai inascoltata una richiesta.
! Never use the services of an unauthorised technician.
Please have the following information to hand:
• The type of problem encountered.
• The appliance model (Mod.).
• The serial number (S/N).
The latter two pieces of information can be found on the data plate located on the appliance.
Estensione di garanzia Airbag
Airbag è il servizio esclusivo creato da Ariston che integra e prolunga nel tempo i contenuti della garanzia standard: con una modica cifra protegge il cliente da ogni imprevisto riguardante l’assistenza e la manutenzione dell’elettrodomestico. Per i 5 anni successivi alla data di acquisto il cliente che aderisce al programma Airbag avrà diritto gratuitamente a:
• l’intervento entro 48 ore dalla chiamata;
• il contributo per spese di trasferta del Tecnico (diritto di chiamata);
• la manodopera;
• le parti di ricambio originali;
• il trasporto dell’elettrodomestico non riparabile in loco.
Inoltre, qualora l’elettrodomestico non sia riparabile la
garanzia prevede la sostituzione a prezzo agevolato in funzione dell’anzianità del prodotto.
* Al costo di 14,25 centesimi di Euro al minuto (iva inclusa)
dal Lun. al Ven. dalle 08:00 alle 18:30, il Sab. dalle 08:00
alle 13:00 e di 5,58 centesimi di Euro al minuto (iva inclusa)
dal Lun. al Ven. dalle 18:30 alle 08:00, il Sab. dalle 13:00
alle 08:00 e i giorni festivi, per chi chiama dal telefono sso.
Per chi chiama da radiomobile le tariffe sono legate al piano tariffario dell’operatore telefonico utilizzato. Le suddette tariffe potrebbero essere soggette a variazione
da parte dell’operatore telefonico; per maggiori informazioni
consultare il sito www.indesit.com.
3
Page 4
Descrizione dell’apparecchio
7
1
3
4
5
Vista d’insieme
1 POSIZIONE 1 2 POSIZIONE 2 3 POSIZIONE 3 4 POSIZIONE 4 5 POSIZIONE 5 6 GUIDE di scorrimento dei ripiani 7 Ripiano LECCARDA 8 Ripiano GRIGLIA 9 Pannello di controllo
Description of the appliance
Overall view
1 POSITION 1 2 POSITION 2 3 POSITION 3 4 POSITION 4 5 POSITION 5 6 GUIDES for the sliding racks 7 DRIPPING PAN 8 GRILL 9 Control panel
9 6
8
2
4
Page 5
Descrizione dell’apparecchio
1
2
1
2
5
Pannello di controllo
1 Spia TERMOSTATO 2 Manopola TERMOSTATO 3 Manopola TIMER * 4 Manopola PROGRAMMI 5 Manopola TIMER RUSTICO *
* Presente solo in alcuni modelli.
Description of the appliance
Control panel
1 THERMOSTAT indicator light 2 THERMOSTAT knob 3 TIMER knob * 4 SELECTOR knob 5 COUNTRY STYLE TIMER knob *
* Only available in certain models.
4
3
4
5
Page 6
Installazione
595 mm.
25 mm.
IT
! È importante conservare questo libretto per poterlo consultare in ogni momento. In caso di vendita, di cessione o di trasloco, assicurarsi che resti insieme all’apparecchio per informare il nuovo proprietario sul funzionamento e sui relativi avvertimenti.
45 mm.
560 mm.
! Leggere attentamente le istruzioni: ci sono importanti informazioni sull’installazione, sull’uso e sulla sicurezza.
Posizionamento
! Gli imballaggi non sono giocattoli per bambini e vanno
eliminati secondo le norme per la raccolta differenziata (vedi Precauzioni e consigli).
! L’installazione va effettuata secondo queste istruzioni e
da personale professionalmente qualicato. Una errata
installazione può causare danni a persone, animali o cose.
Incasso
Per garantire un buon funzionamento dell’apparecchio è necessario che il mobile abbia le caratteristiche adatte:
• i pannelli adiacenti il forno devono essere di materiale resistente al calore;
• nel caso di mobili in legno impiallacciato, le colle devono essere resistenti alla temperatura di 100°C;
• per l’incasso del forno, sia nel caso di inserimento
sottotavolo (vedi gura) che a colonna, il mobile deve avere le seguenti dimensioni:
547 mm. min.
23 mm.
5 mm.
595 mm.
545 mm.
45 mm.
558 mm.
575-585 mm.
567 mm.
Centraggio e ssaggio
Per ssare l’apparecchio al mobile: aprire la porta del
forno e avvitare 4 viti a legno nei 4 fori posti sulla cornice perimetrale.
! Tutte le parti che assicurano la protezione debbono essere
ssate in modo tale da non poter essere tolte senza l’aiuto
di qualche utensile.
Collegamento elettrico
I forni dotati di cavo di alimentazione tripolare, sono predisposti per il funzionamento con corrente alternata alla tensione e frequenza di alimentazione indicate nella targhetta
caratteristiche posta sull’apparecchio (vedi sotto).
Montaggio del cavo di alimentazione
1. Aprire la morsettiera facendo leva con un cacciavite sulle linguette laterali del coperchio: tirare
e aprire il coperchio (vedi gura).
! Una volta incassato l’apparecchio non debbono essere possibili contatti con le parti elettriche. Le dichiarazioni di consumo indicate in targhetta caratteristiche sono state misurate con questo tipo di installazione.
Aerazione
Per garantire una buona aerazione è necessario eliminare la parete posteriore del vano. È preferibile installare il forno in modo che appoggi su due listelli in legno oppure su un piano continuo che abbia un’apertura di almeno 45 x 560
mm (vedi gure).
6
N
2. Mettere in opera il cavo di alimentazione: svitare la vite del serracavo e le tre viti dei
contatti L-N- e poi ssare
L
i cavetti sotto le teste delle viti rispettando i colori Blu
(N) Marrone (L) Giallo-Verde
(vedi gura).
3. Fissare il cavo nell’apposito fermacavo.
4. Chiudere il coperchio della morsettiera.
Page 7
Allacciamento del cavo di alimentazione alla rete
** Solo per modelli con guide in filo.
Tensione) e successive modificazioni
Montare sul cavo una spina normalizzata per il carico
indicato nella targhetta caratteristiche (vedi a anco).
In caso di collegamento diretto alla rete è necessario interporre tra l’apparecchio e la rete un interruttore onnipolare con apertura minima fra i contatti di 3 mm dimensionato al carico e rispondente alle norme in vigore
(il lo di terra non deve essere interrotto dall’interruttore). Il
cavo di alimentazione deve essere posizionato in modo tale che in nessun punto superi di 50°C la temperatura ambiente
(per esempio lo schienale del forno).
! L’installatore è responsabile del corretto collegamento elettrico e dell’osservanza delle norme di sicurezza.
TARGHETTA CARATTERISTICHE
larghezza cm 43,5
Dimensioni*
Volume*
Dimensioni**
Volume**
Collegamenti elettrici
altezza cm 32,4 profondità cm 41,5
lt. 59
larghezza cm 45,5 altezza cm 32,4 profondità cm 41,5
lt. 62
tensione a 220-240V~ 50/60Hz o 50Hz (vedi targhetta caratteristiche) potenza massima assorbita 2250W
IT
Prima di effettuare l’allacciamento accertarsi che:
• la presa abbia la messa a terra e sia a norma di legge;
• la presa sia in grado di sopportare il carico massimo
di potenza della macchina, indicato nella targhetta
caratteristiche (vedi sotto);
• la tensione di alimentazione sia compresa nei valori nella targhetta caratteristiche (vedi sotto);
• la presa sia compatibile con la spina dell’apparecchio. In caso contrario sostituire la presa o la spina; non usare
prolunghe e multiple.
! Ad apparecchio installato, il cavo elettrico e la presa della corrente devono essere facilmente raggiungibili.
! Il cavo non deve subire piegature o compressioni.
! Il cavo deve essere controllato periodicamente e sostituito
solo da tecnici autorizzati (vedi Assistenza).
! L’azienda declina ogni responsabilità qualora queste norme non vengano rispettate.
Direttiva 2002/40/CE sull’etichetta dei forni elettrici. Norma EN 50304
Consumo energia convezione
ENERGY LABEL
* Solo per modelli con guide imbutite.
Naturale – funzione di riscaldamento: Tradizionale;
Consumo energia dichiarazione Classe convezione Forzata ­funzione di riscaldamento: Multicottura.
Questa apparecchiatura è conforme alle seguenti Direttive Comunitarie:
- 2006/95/CEE del 12/12/06 (Bassa
- 2004/108/CEE del15/12/04 (Compatibilità Elettromagnetica) e successive modificazioni
- 93/68/CEE del 22/07/93 e successive modificazioni.
- 2012/19/CE e successive modificazioni.
1275/2008 standby/off mode
-
7
Page 8
Avvio e utilizzo
Manopola
IMPOSTAZIONE TEMPI
Icona
CONTAMINUTI
Icona
OROLOGIO
IT
3. Il timer è un contaminuti: a tempo scaduto emette un segnale acustico.
ATTENZIONE ! Il forno è dotato di un sistema di arresto griglie che consente di estrarle senza che queste
fuoriescano dal forno. (1)
Per estrarre completamente le griglie è sufficiente, come indicato sul disegno, alzarle, prendendole dalla
parte anteriore e tirarle. (2)
! Alla prima accensione fare funzionare il forno a vuoto per almeno un’ora con il termostato al massimo e a porta chiusa. Poi spegnere, aprire la porta del forno e aerare il locale. L’odore che si avverte è dovuto all’evaporazione delle sostanze usate per proteggere il forno.
Avviare il forno
1. Selezionare il programma di cottura desiderato ruotando la manopola PROGRAMMI.
2. Scegliere la temperatura ruotando la manopola TERMOSTATO. Una lista con le cotture e le relative temperature consigliate è consultabile nella Tabella cottura
(vedi Programmi).
3. La spia TERMOSTATO accesa indica la fase di
riscaldamento no alla temperatura impostata.
4. Durante la cottura è sempre possibile:
- modicare il programma di cottura agendo sulla manopola PROGRAMMI;
- modificare la temperatura agendo sulla manopola
TERMOSTATO;
- interrompere la cottura riportando la manopola PROGRAMMI in posizione “0”.
! Non appoggiare mai oggetti sul fondo del forno perché si rischiano danni allo smalto. ! Porre sempre i recipienti di cottura sulla griglia in dotazione.
Ventilazione di raffreddamento
Per ottenere una riduzione delle temperature esterne, alcuni modelli sono dotati di una ventola di raffreddamento. Questa genera un getto d’aria che esce tra il pannello di controllo e la porta del forno.
! A ne cottura la ventola rimane attiva nché il forno non è sufcientemente freddo.
Luce del forno
Si accende selezionando con la manopola PROGRAMMI. Rimane accesa quando si seleziona un programma di
cottura .
Utilizzare il timer di ne cottura*
1. Occorre anzitutto caricare la suoneria, ruotando la manopola TIMER di un giro quasi completo in senso orario.
2. Tornando indietro in senso antiorario, impostare il tempo desiderato facendo coincidere i minuti indicati sulla manopola
TIMER con il riferimento sso sul pannello di controllo.
! Il timer non controlla l’accensione e lo spegnimento del forno.
Orologio con contaminuti Rustico *
! Tutte le impostazioni sono possibili solo se il forno è collegato all’impianto elettrico. In caso di mancanza di corrente, per più di 10 secondi, il programmatore si ferma: al ripristino della corrente l’icona OROLOGIO lampeggia per indicare che c’è stato un black-out e che è necessario regolare nuovamente l’ora.
Impostare l’ora
Per regolare l’ora indicata dalle lancette premere
brevemente la manopola IMPOSTAZIONE TEMPI no ad
ottenere il lampeggio dell’icona OROLOGIO. Quindi per incrementare o decrementare l’orario visualizzato a passi di 1 minuto, ruotare la manopola in senso orario o antiorario e la lancetta dei minuti si muove a passi di 1 minuto in senso orario o antiorario. Trascorsi 10 secondi dall’ultimo aggiustamento il programmatore esce automaticamente dalla modalità di regolazione.
Impostare il contaminuti
! Questa funzione non interrompe la cottura e prescinde
dall’utilizzo del forno; permette solo di azionare il segnale
acustico allo scadere dei minuti impostati. Per attivare il contaminuti, premere brevemente la manopola IMPOSTAZIONE TEMPI fino ad ottenere il lampeggio dell’icona CONTAMINUTI. Per incrementare o decrementare il tempo del contaminuti, ruotare la manopola IMPOSTAZIONE TEMPI in senso orario o antiorario, la lancetta dei minuti si muove a passi di 1 minuto. Il lampeggio dell’icona CONTAMINUTI continua per 10 secondi dall’ultima rotazione. L’impostazione può essere confermata premendo la manopola IMPOSTAZIONE TEMPI o lasciando scadere i 10 secondi, purché sia stato programmato almeno 1 minuto di cottura. L’icona CONTAMINUTI accesa indica l’avvenuta impostazione e il conteggio del tempo inizierà immediatamente. Selezionare il programma di cottura desiderato con la manopola PROGRAMMI. Per visualizzare il tempo impostato premere brevemente e
rilasciare la manopola IMPOSTAZIONE TEMPI; le lancette
visualizzano i minuti rimanenti.
* Presente solo in alcuni modelli.
8
Page 9
Al termine del tempo impostato l’icona CONTAMINUTI lampeggia e l’allarme emette segnali acustici per 1 minuto
(per disattivarlo premere brevemente la manopola).
Portare la manopola PROGRAMMI in posizione “0”. ! Per annullare l’impostazione, premere la manopola IMPOSTAZIONE TEMPI per 3 secondi: la programmazione sarà annullata e l’icona CONTAMINUTI si spegne.
Consigli pratici di cottura
! Nelle cotture ventilate non utilizzare le posizioni dei ripiani 1 e 5: sono investite direttamente dall’aria calda, che potrebbe provocare bruciature sui cibi delicati.
! Nelle cotture GRILL e GRATIN, disporre la leccarda in posizione 1 per raccogliere i residui
di cottura (sughi e/o grassi).
IT
Programmi
! Per tutti i programmi è impostabile una temperatura tra 60°C e MAX, tranne:
• GRILL (si consiglia di impostare solo su MAX);
• GRATIN (si consiglia di non superare la temperatura di 200°C).
Programma FORNO TRADIZIONALE
Si attivano i due elementi riscaldanti inferiore e superiore. Con questa cottura tradizionale è meglio utilizzare un solo ripiano: con più ripiani si ha una cattiva distribuzione della temperatura.
Programma MULTICOTTURA
Si attivano tutti gli elementi riscaldanti (superiore e inferiore) ed
entra in funzione la ventola. Poiché il calore è costante in tutto il forno, l’aria cuoce e rosola il cibo in modo uniforme. È possibile
utilizzare no a un massimo di due ripiani contemporaneamente.
Programma FORNO SOPRA
Si accende l’elemento riscaldante superiore. Questa funzione può essere utilizzata per ritocchi di cottura.
MULTICOTTURA
• Utilizzare le posizioni dei ripiani 2 e 4, mettendo alla 2 i
cibi che richiedono maggior calore.
• Disporre la leccarda in basso e la griglia in alto.
GRILL
• Inserire la griglia in posizione 3 o 4, disponendo gli
alimenti al centro della griglia.
• Si consiglia di impostare il livello di energia al massimo.
Non allarmarsi se la resistenza superiore non resta costantemente accesa: il suo funzionamento è controllato da un termostato.
PIZZA
• Per una buona cottura della pizza ultilizzate il programma
MULTICOTTURA.
• Utilizzare una teglia in alluminio leggero, appoggiandola
sulla griglia in dotazione.
Con la leccarda si allungano i tempi di cottura e
difcilmente si ottiene una pizza croccante.
• Nel caso di pizze molto farcite è consigliabile inserire la
mozzarella a metà cottura.
Programma GRILL
Si accende l’elemento riscaldante superiore. La temperatura assai elevata e diretta del grill consente la immediata rosolatura superficiale dei cibi che, ostacolando la fuoriuscita dei liquidi, li mantiene più teneri internamente. La cottura al grill è particolarmente consigliata per quei
piatti che necessitano di elevata temperatura superciale: bistecche di vitello e manzo, entrecôte, letto, hamburger
etc... Alcuni esempi di utilizzo sono riportati al paragrafo “Consigli pratici per la cottura”. Effettuare le cotture con la porta del forno chiusa.
Programma GRATIN
Si attiva l’elemento riscaldante superiore ed entra in funzione la ventola. Unisce all’irradiazione termica unidirezionale, la circolazione forzata dell’aria all’interno del
forno. Ciò impedisce la bruciatura superciale degli alimenti
aumentando il potere di penetrazione del calore. Effettuare le cotture con la porta del forno chiusa.
9
Page 10
IT
ProgrammiAlimenti
Peso
(Kg)
Posizione dei ripiani
Preriscaldamento
(minuti)
Temperatura
consigliata
Durata
cottura
(minuti)
Forno
Tradizionale
Anatra
Arrosto di vitello o manzo Arrosto di maiale Biscotti (di frolla) Crostate
1 1 1
­1
3 3 3 3 3
15 15 15 15 15
200 200 200 180 180
65-75 70-75 70-80 15-20 30-35
Multicottura
Pizza (su 2 ripiani) Lasagne Agnello Pollo arrosto + patate Sgombro Plum-cake Bignè (su 2 ripiani) Biscotti(su 2 ripiani) Pan di spagna (su 1 ripiano) Pan di spagna (su 2 ripiani) Torte salate
1 1 1
1+1
1 1
0.5
0.5
0.5 1
1.5
2 e 4
3 2
2 e 4
2
2 2 e 4 2 e 4
2 2 e 4
3
15 10 10 15 10 10 10 10 10 10 15
230 180 180 200 180 170 190 180 170 170 200
15-20 30-35 40-45 60-70 30-35 40-50 20-25 10-15 15-20 20-25 25-30
Forno Sopra
Ritocchi di cottura -3/4 15 220 -
Grill
Sogliole e seppie Spiedini di calamari e gamberi Filetto di merluzzo Verdure alla griglia Bistecca di vitello Cotolette Hamburger Sgombri Toast
1 1 1 1 1 1 1 1
n.° 4
4
4
4
3/4
4
4
4
4
4
5 5 5 5 5 5 5 5 5
Max Max Max Max Max Max Max Max Max
8-10
6-8
10 10-15 15-20 15-20
7-10
15-20
2-3
Gratin
Pollo alla griglia Seppie
1.5
1.5
2 2
5 5
200 200
55-60 30-35
Tabella cottura
10
Page 11
Precauzioni e consigli
! L’apparecchio è stato progettato e costruito in conformità alle norme internazionali di sicurezza. Queste avvertenze sono fornite per ragioni di sicurezza e devono essere lette attentamente.
Sicurezza generale
• L’apparecchio è stato concepito per un uso di tipo non
professionale all’interno dell’abitazione.
• L’apparecchio non va installato all’aperto, nemmeno se
lo spazio è riparato, perché è molto pericoloso lasciarlo esposto a pioggia e temporali.
• Per movimentare l’apparecchio servirsi sempre delle apposite maniglie poste sui anchi del forno.
• Non toccare l’apparecchio a piedi nudi o le mani o i piedi
bagnati o umidi.
L’apparecchio deve essere usato per cuocere alimenti, solo da persone adulte e secondo le istruzioni riportate in questo libretto. Ogni altro uso (ad esempio: riscaldamento di ambienti) è da considerarsi improprio e quindi pericoloso. Il costruttore non può essere considerato responsabile per eventuali danni derivanti da usi impropri, erronei ed irragionevoli.
Durante l’uso dell’apparecchio gli elementi riscaldanti e alcune parti della porta forno diventano molto calde. Fare attenzione a non toccarle e tenere i bambimi a distanza.
• Evitare che il cavo di alimentazione di altri elettrodomestici
entri in contatto con parti calde del forno.
• Non ostruire le aperture di ventilazione e di smaltimento
di calore.
• Impugnare la maniglia di apertura della porta al centro:
ai lati potrebbe essere calda.
• Utilizzare sempre guanti da forno per inserire o estrarre
recipienti.
• Non rivestire il fondo del forno con fogli di alluminio.
• Non riporre materiale infiammabile nel forno: se
l’apparecchio viene messo inavvertitamente in funzione potrebbe incendiarsi.
• Assicurarsi sempre che le manopole siano nella posizione “●”/“” quando l’apparecchio non è utilizzato.
• Non staccare la spina dalla presa della corrente tirando il cavo, bensì afferrando la spina.
• Non fare pulizia o manutenzione senza aver prima
staccato la spina dalla rete elettrica.
• In caso di guasto, in nessun caso accedere ai
meccanismi interni per tentare una riparazione.
Contattare l’Assistenza (vedi Assistenza).
• Non appoggiare oggetti sulla porta del forno aperta.
• Evitare che i bambini giochino con l’apparecchio.
• Non è previsto che l’apparecchio venga utilizzato da persone (bambini compresi) con ridotte capacità siche, sensoriali o mentali, da persone inesperte o
che non abbiano familiarità con il prodotto, a meno che non vengano sorvegliate da una persona responsabile della loro sicurezza o non abbiano ricevuto istruzioni preliminari sull’uso dell’apparecchio.
L’apparecchio non è destinato a essere messo in funzione per mezzo di un temporizzatore esterno oppure di un sistema di comando a distanza separato.
Smaltimento
• Smaltimento del materiale di imballaggio: attenersi alle norme locali, così gli imballaggi potranno essere
riutilizzati.
• La direttiva Europea 2012/19/CE sui rifiuti di apparecchiature elettriche ed elettroniche (RAEE),
prevede che gli elettrodomestici non debbano essere smaltiti nel normale flusso dei rifiuti solidi urbani. Gli apparecchi dismessi devono essere raccolti separatamente per ottimizzare il tasso di recupero e riciclaggio dei materiali che li compongono ed impedire potenziali danni per la salute e l’ambiente. Il simbolo del cestino barrato è riportato su tutti i prodotti per ricordare gli obblighi di raccolta separata. Per ulteriori informazioni, sulla corretta dismissione degli elettrodomestici, i detentori potranno rivolgersi al servizio pubblico preposto o ai rivenditori.
Risparmiare e rispettare l’ambiente
• Azionando il forno negli orari che vanno dal tardo pomeriggio no alle prime ore del mattino si collabora a
ridurre il carico di assorbimento delle aziende elettriche. Le opzioni di programmazione dei programmi, in
particolar modo la “cottura ritardata” (vedi Programmi),
permettono di organizzarsi in tal senso.
• Si raccomanda di effettuare sempre le cotture al GRILL e
GRATIN a porta chiusa: sia per ottenere migliori risultati
che per un sensibile risparmio di energia (10% circa).
• Mantenere efcienti e pulite le guarnizioni, in modo che
aderiscano bene alla porta e non procurino dispersioni di calore.
Manutenzione e cura
Escludere la corrente elettrica
Prima di ogni operazione isolare l’apparecchio dalla rete di alimentazione elettrica.
Pulire l’apparecchio
• Le parti esterne smaltate o inox e le guarnizioni in gomma
possono essere pulite con una spugnetta imbevuta di acqua tiepida, e sapone neutro. Se le macchie sono
difcili da asportare usare prodotti specici. Si consiglia
di sciacquare abbondantemente e di asciugare dopo la pulizia. Non usare polveri abrasive o sostanze corrosive.
• L’interno del forno va pulito preferibilmente ogni volta
dopo l’uso, quando è ancora tiepido. Usare acqua calda e detersivo, risciaquare e asciugare con un panno morbido. Evitare gli abrasivi.
• Gli accessori possono essere lavati come normali
stoviglie, anche in lavastoviglie ad eccezione delle guide scorrevoli.
! Non utilizzare mai pulitori a vapore o ad alta pressione per la pulizia dell’apparecchio.
IT
11
Page 12
Pulire la porta
IT
Pulire il vetro della porta con spugne e prodotti non abrasivi
e asciugare con un panno morbido; non usare materiali ruvidi abrasivi o raschietti metallici aflati che possono grafare la supercie e causare la frantumazione del vetro.
Per una pulizia più accurata è possibile smontare la porta del forno:
1. aprire completamente la porta (vedi gura);
2. alzare e ruotare le levette poste sulle due cerniere
(vedi gura);
F
3 (con controporta in vetro).
afferrare la porta ai due lati esterni, richiudendola lentamente ma non del tutto. Premere i fermi F, poi tirare la porta verso di sé estraendola
F
dalle cerniere (vedi gura).
Rimontare la porta seguendo il procedimento in senso contrario.
Controllare le guarnizioni
Controllare periodicamente lo stato della guarnizione attorno alla porta del forno. In caso risulti danneggiata rivolgersi
al Centro Assistenza più vicino (vedi Assistenza). È consigliabile non usare il forno no all’avvenuta riparazione.
Sostituire la lampadina
Per sostituire la lampadina di illuminazione del forno
1. Svitare il coperchio in vetro del portalampada.
2. Svitare la lampadina e sostituirla con una analoga: potenza 25 W, attacco E 14.
3. Rimontare il coperchio
(vedi gura)
! Non utilizzare la lampada forno per e come illuminazione di ambienti.
12
Page 13
Installation
595 mm.
25 mm.
! Please keep this instruction booklet in a safe place for future reference. If the appliance is sold, given away or moved, please make sure the booklet is also passed on to
the new owners so that they may benet from the advice
contained within it.
! Please read this instruction manual carefully: it contains important information concerning the safe operation, installation and maintenance of the appliance.
Positioning
! Do not let children play with the packaging material; it
should be disposed of in accordance with local separated
waste collection standards (see Precautions and tips).
! The appliance must be installed by a qualied professional in
accordance with the instructions provided. Incorrect installation may damage property or cause harm to people or animals.
Built-in appliances
Use an appropriate cabinet to ensure that the appliance operates properly:
• The panels adjacent to the oven must be made of heat-
resistant material.
• Cabinets with a veneer exterior must be assembled with
glues which can withstand temperatures of up to 100°C.
• To install the oven under the counter (see diagram) or
in a kitchen unit, the cabinet must have the following dimensions:
547 mm. min.
23 mm.
5 mm.
595 mm.
545 mm.
45 mm.
558 mm.
575-585 mm.
567 mm.
GB
45 mm.
560 mm.
Centring and xing
Secure the appliance to the cabinet by opening the oven door and inserting 4 screws into the 4 holes on the outer frame.
! All parts which ensure the safe operation of the appliance must not be removable without the aid of a tool.
Electrical connection
Ovens equipped with a three-pole power supply cable are designed to operate with alternating current at the voltage and frequency indicated on the data plate located on the
appliance (see below).
Fitting the power supply cable
1. Open the terminal board by inserting a screwdriver into the side tabs of the cover. Use the screwdriver as a lever by pushing it
down to open the cover (see diagram).
* Stainless steel models only
! The appliance must not come into contact with electrical parts once it has been installed. The indications for consumption given on the data plate have been calculated for this type of installation.
Ventilation
To ensure adequate ventilation, the back panel of the cabinet must be removed. It is advisable to install the oven so that it rests on two strips of wood, or on a completely
at surface with an opening of at least 45 x 560 mm (see diagrams).
N
2. Install the power supply cable by loosening the cable clamp screw and the three wire contact screws
L
L-N- . Connect the wires to the corresponding terminals: the Blue wire to the terminal
marked (N), the Brown wire to the terminal marked (L) and the Yellow/Green wire
to the terminal marked
(see diagram).
13
Page 14
3. Secure the cable by fastening the clamp screw.
APPLIANCE SPECIFICATIONS
Dimensions*
width 43.5 cm height 32,4 cm depth 41.5 cm
Volume*
59 l
Dimensions**
width 45.5 cm height 32,4 cm depth 41.5 cm
Volume**
62 l
Electrical connections
voltage: 220-240V~ 50/60 Hz or 50Hz (see data plate) maximum power absorbed 2250 W
* Only for models with drawn rails. ** Only for models with wire rails.
ENERGY LABEL
Directive 2002/40/EC on the label of electric ovens. Standard EN 50304
Energy consumption for Natural convection – heating mode: Traditional mode
Declared energy consumption for Forced convection Class – heating mode: Fan assisted.
This appliance conforms to the following European Economic Community directives:
- 2006/95/EEC dated 12/12/06 (Low Voltage) and subsequent amendments.
- 2004/108/EEC dated 03/05/89 (Electromagnetic Compatibility) and subsequent amendments.
- 93/68/EEC dated 22/07/93 and subsequent amendments.
- 2012/19/EC and subsequent amendments.
- 1275/2008 standby/off mode.
GB
4. Close the cover of the terminal board.
Connecting the supply cable to the mains
Install a standardised plug corresponding to the load
indicated on the data plate (see table).
The appliance must be directly connected to the mains using an omnipolar switch with a minimum contact opening of 3 mm installed between the appliance and the mains. The switch must be suitable for the charge indicated and must
comply with current electrical regulations (the earthing wire must not be interrupted by the switch). The supply cable
must be positioned so that it does not come into contact
with temperatures higher than 50°C at any point (the back panel of the oven, for example).
! The installer must ensure that the correct electrical connection has been performed and that it is fully compliant with safety regulations.
Before connecting the appliance to the power supply, make sure that
• The appliance is earthed and the plug is compliant with
the law.
• The socket can withstand the maximum power of the
appliance, which is indicated on the data plate.
• The voltage is in the range between the values indicated
on the data plate.
• The socket is compatible with the plug of the appliance.
If the socket is incompatible with the plug, ask an authorised technician to replace it. Do not use extension cords or multiple sockets.
! Once the appliance has been installed, the power supply cable and the electrical socket must be easily accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced by
authorised technicians only (see Assistance).
! The manufacturer declines any liability should these safety measures not be observed.
14
Page 15
Start-up and use
TIMER knob
TIMER
icon
CLOCK
icon
3. The timer operates in minutes: when the selected time
has elapsed, a buzzer will sound.
GB
WARNING! The oven is provided with a stop system to extract the racks and prevent them from coming
out of the oven (1).
As shown in the drawing, to extract them completely, simply lift the racks, holding them on the front part, and
pull (2).
! The rst time you use your appliance, heat the empty
oven with its door closed at its maximum temperature for at least half an hour. Ensure that the room is well ventilated before switching the oven off and opening the oven door. The appliance may emit a slightly unpleasant odour caused by protective substances used during the manufacturing process burning away.
Starting the oven
1. Select the desired cooking mode by turning the SELECTOR knob.
2. Select the desired temperature with the THERMOSTAT knob. See the Cooking advice table for cooking modes and
the suggested cooking temperatures (see Cooking Modes).
3. When lit, the THERMOSTAT indicator light indicates that the oven is heating up to the temperature set.
4. You may do the following during cooking:
- change the cooking mode by turning the SELECTOR knob.
- change the temperature by turning the THERMOSTAT knob.
- stop cooking by turning the SELECTOR knob to the “0” position.
! Never put objects directly on the bottom of the oven; this
will avoid the enamel coating being damaged.
! Always place cookware on the rack(s) provided.
Cooling ventilation
In order to cool down the external temperature of the oven,
some models are tted with a cooling fan that blows out air
between the control panel and the oven door.
! Once cooking has been completed, the cooling fan continues
to operate until the oven has cooled down sufciently.
Oven light
It goes on when selecting with the SELECTOR knob. It stays on when a cooking mode is selected.
How to use the timer*
1. To set the buzzer, turn the TIMER knob clockwise almost one complete revolution.
2. Turn the knob anticlockwise to set the desired time: align the minutes shown on the knob with the indicator on the control panel.
! The timer does not turn the oven on or off.
Clock with Country Style timer *
! All settings can only be entered if the oven is connected to the mains electricity. In case of blackouts lasting over 10 seconds, the programmer stops: when current is restored,
the CLOCK icon ashes to indicate that a blackout has
occurred and that the time must be set again.
Setting the time
To adjust the time indicated by the hands, briey press the TIME SETTING knob until the CLOCK icon starts ashing.
Then, to increase or decrease the displayed time setting in
1-minute steps, turn the knob clockwise or anti-clockwise;
the minutes hand moves clockwise or anticlockwise accordingly, in 1-minute steps. Once 10 seconds have elapsed since the most recent
adjustment, the programmer automatically exits the adjustment mode.
Setting the minute minder
! This function does not interrupt cooking nor does it affect
the oven’s operation; it is simply used to activate the buzzer
when the set duration has elapsed. To activate the minute minder, briefly press the TIME SETTING knob until the MINUTE MINDER icon starts
ashing.
To increase or decrease the set duration, turn the TIME
SETTING knob clockwise or anti-clockwise; the minutes
hand will move in 1-minute steps.
The MINUTE MINDER icon ashes continuously for 10
seconds after the most recent rotation. The setting can be
conrmed by pressing the TIME SETTING knob or letting
10 seconds elapse, provided that a cooking time of at least 1 minute has been programmed. The switched-on MINUTE MINDER icon indicates that the
duration has been set; the countdown will start immediately.
Select the desired cooking mode using the PROGRAMMES knob.
To view the set duration, briey press and release the TIME SETTING knob; the hands and icons will display the
remaining minutes. At the end of the set time, the MINUTE MINDER icon
ashes and the buzzer sounds for 1 minute (to silence it, briey press the knob).
Turn the PROGRAMMES knob to position “0”.
* Only available in certain models.
15
Page 16
! To cancel the setting, press the TIME SETTING knob
GB
for 3 seconds: the programming will be cancelled and the MINUTE MINDER icon will switch off.
Practical cooking advice
! Do not place racks in position 1 and 5 during fan-assisted cooking. Excessive direct heat can burn temperature sensitive foods.
Cooking modes
! A temperature value can be set for all cooking modes between 60°C and Max, except for
• GRILL (recommended: set only to MAX power level);
• GRATIN (recommended: do not exceed 200°C).
TRADITIONAL OVEN mode Both the top and bottom heating elements will come on. With this traditional cooking mode, it is best to use one
cooking rack only; if more than one rack is used, the heat
will be distributed unevenly.
MULTI-COOKING mode
All the heating elements (top and bottom), as well as the fan,
will come on. Since the heat remains constant throughout the oven, the air cooks and browns food uniformly. A maximum of two racks may be used at the same time.
TOP OVEN mode The top heating element comes on. This mode can be used to brown food at the end of cooking.
GRILL mode The top heating element comes on. The extremely high and direct temperature of the grill makes it possible to brown
the surface of meats and roasts while locking in the juices
to keep them tender. The grill is also highly recommended for dishes that require a high temperature on the surface:
such as beef steaks, veal, rib steak, lets, hamburgers
etc... Some grilling examples are included in the “Practical Cooking Advice” paragraph. Always cook in this mode with the oven door closed.
! In the GRILL and GRATIN cooking modes, place the dripping
pan in position 1 to collect cooking residues (fat and/or grease).
MULTI-COOKING
• Use position 2 and 4, placing the food that requires more
heat on 2.
• Place the dripping pan on the bottom and the rack on
top.
GRILL
• Insert the rack in position 3 or 4. Place the food in the
centre of the rack.
• We recommend that you set the maximum power level.
The top heating element is regulated by a thermostat and may not always be on.
PIZZA
• For best results when cooking pizza, use the MULTI-
COOKING mode.
• Use a light aluminium pizza pan. Place it on the rack
provided.
For a crispy crust, do not use the dripping pan (prevents
crust from forming by extending cooking time).
• If the pizza has a lot of toppings, we recommend adding
the mozzarella cheese on top of the pizza halfway through the cooking process.
GRATIN mode The top heating element, as well as the fan, will come on. This combination of features increases the effectiveness of the unidirectional thermal radiation of the heating elements through forced circulation of the air throughout the oven. This helps prevent food from burning on the surface, allowing the heat to penetrate right into the food. Always cook in this mode with the oven door closed.
16
Page 17
GB
Cooking
modes
Foods
Weight (in kg)
Rack position
Pre-heating time (min)
Recommended temperature
Cooking time (minutes)
Convection Oven
Duck Roast veal or beef Pork roast Biscuits (short pastry) Tarts
1 1 1
-
1
3 3 3 3 3
15 15 15 15 15
200 200 200 180 180
65-75 70-75 70-80 15-20 30-35
Multi-cooking
Pizza (on 2 racks) Lasagne Lamb Roast chicken + potatoes Mackerel Plum cake Cream puffs (on 2 racks)
Biscuits (on 2 racks) Sponge cake (on 1 rack) Sponge cake (on 2 racks) Savoury pies
1 1 1 1+1 1 1
0.5
0.5
0.5 1
1.5
2 and 4 3 2 2 and 4 2 2 2 and 4 2 and 4 2 2 and 4 3
15 10 10 15 10 10 10 10 10 10 15
230 180 180 200 180 170 190 180 170 170 200
15-20 30-35 40-45 60-70 30-35 40-50 20-25 10-15 15-20 20-25 25-30
Top oven
Browning food to perfect cooking - 3/4 15 220 -
Grill
Soles and cuttlefish Squid and prawn kebabs Cod filet Grilled vegetables Veal steak Cutlets Hamburgers Mackerels Toasts
1 1 1 1 1 1 1 1 4
4 4 4 3 or 4 4 4 4 4 4
5 5 5 5 5 5 5 5 5
Max Max Max Max Max Max Max Max Max
8-10 6-8 10 10-15 15-20 15-20 7-10 15-20 2-3
Gratin
Grilled chicken Cuttlefish
1.5
1.5 2 2 5 5
200 200
55-60 30-35
Cooking advice table
17
Page 18
Precautions and tips
GB
! This appliance has been designed and manufactured in compliance with international safety standards. The following warnings are provided for safety reasons and must be read carefully.
General safety
• The appliance was designed for domestic use inside the
home and is not intended for commercial or industrial use.
• The appliance must not be installed outdoors, even in
covered areas. It is extremely dangerous to leave the
appliance exposed to rain and storms.
• When moving or positioning the appliance, always use
the handles provided on the sides of the oven.
• Do not touch the appliance while barefoot or with wet or
damp hands and feet.
The appliance must be used by adults only for
the preparation of food, in accordance with the
instructions provided in this booklet. Any other
use of the appliance (e.g. for heating the room)
constitutes improper use and is dangerous. The
manufacturer may not be held responsible for any
damage caused as a result of improper, incorrect
and unreasonable use of the appliance.
Do not touch the heating elements or certain parts
of the oven door when the appliance is in use; these
parts become extremely hot. Keep children well away
from the appliance.
• Make sure that the power supply cables of other electrical
appliances do not come into contact with the hot parts of
the oven.
• The ventilation and heat dispersal openings must never
be obstructed.
• Always grip the oven door handle in the centre: the ends
may be hot.
• Always use oven gloves when placing cookware in the
oven or when removing it.
• Do not use aluminium foil to line the bottom of the oven.
• Do not place ammable materials in the oven: if the appliance
is switched on accidentally, the materials could catch re.
• Always make sure the knobs are in the “●”/“” position
when the appliance is not in use.
• When unplugging the appliance, always pull the plug
from the mains socket; do not pull on the cable.
• Do not perform any cleaning or maintenance work without
having disconnected the appliance from the electricity mains.
• If the event of malfunctions, under no circumstances
should you attempt to perform the repairs yourself.
Contact an authorised Service Centre (see Assistance).
• Do not rest objects on the open oven door.
• Do not let children play with the appliance.
• The appliance should not be operated by people (including
children) with reduced physical, sensory or mental
capacities, by inexperienced individuals or by anyone
who is not familiar with the product. These individuals
should, at the very least, be supervised by someone who
assumes responsibility for their safety or receive preliminary
instructions relating to the operation of the appliance.
• The appliance is not intended to be operated by means
of an external timer or separate remote-control system.
Disposal
• When disposing of packaging material: observe local
legislation so that the packaging may be reused.
• The European Directive 2012/19/EC on Waste Electrical and Electronic Equipment (WEEE), requires
that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer
for information concerning the correct disposal of their old appliance.
Respecting and conserving the environment
• You can help to reduce the peak load of the electricity
supply network companies by using the oven in the hours between late afternoon and the early hours of the morning. The cooking mode programming options,
the “delayed cooking” mode (see Cooking modes) and “delayed automatic cleaning” mode (see Care and Maintenance) in particular, enable the user to organise their time efciently.
• Always keep the oven door closed when using the GRILL
and GRATIN modes: This will achieve improved results
while saving energy (approximately 10%).
• Regularly check the door seals and wipe clean to ensure
they are free of debris so that they stick properly to the door and do not allow heat to disperse.
Maintenance and care
Switching the appliance off
Disconnect your appliance from the electricity supply before carrying out any work on it.
Cleaning the appliance
• The stainless steel or enamel-coated external parts and
the rubber seals may be cleaned using a sponge that has been soaked in lukewarm water and neutral soap. Use specialised products for the removal of stubborn stains. After cleaning, rinse and dry thoroughly. Do not use abrasive powders or corrosive substances.
• The inside of the oven should ideally be cleaned after
each use, while it is still lukewarm. Use hot water and detergent, then rinse well and dry with a soft cloth. Do not use abrasive products.
• All accessories - with the exception of the sliding racks
- can be washed like everyday crockery, and are even dishwasher safe.
! Never use steam cleaners or pressure cleaners on the appliance.
18
Page 19
Cleaning the oven door
Clean the glass part of the oven door using a sponge and a non-abrasive cleaning product, then dry thoroughly with a soft cloth. Do not use rough abrasive material or sharp metal scrapers as these could scratch the surface and cause the glass to crack. For more thorough cleaning purposes, the oven door may be removed:
1. Open the oven door fully (see diagram);
2. Lift up and turn the small levers located on the two hinges
(see diagram);
F
Grip the door on the two external sides and close it approximately half way. Unlock the door by pressing on the clamps F, then pull the door towards you lifting it
F
out of its seat (see diagram).
GB
To replace the door, reverse this sequence.
Inspecting the seals
Check the door seals around the oven regularly. If the seals are damaged, please contact your nearest Service Centre
(see Assistance). We recommend that the oven is not used
until the seals have been replaced.
Replacing the light bulb
To replace the oven light bulb:
1. Remove the glass cover of the lamp-holder.
2. Remove the light bulb and replace it with a similar one: Wattage 25 W, cap E 14.
3. Replace the glass cover
(see diagram).
! Do not use the oven lamp as/for ambient lighting.
19
Page 20
GB
195114217.00
05/2013 - XEROX FABRIANO
20
Loading...
