Hotpoint PC 604 X User Manual

Operating Instructions

HOB

Contents

GB

Warnings, 2

GB

FR

ES

Installation, 3-4

English, 1

Français, 8

Espanol, 13

Positioning

Electrical connections

PT

AR

Description of the appliance, 5

Overall view

Portuges, 19

Precautions and tips, 6

General safety

Disposal

Practical Advice on Using the Electric Hot Plates

Maintenance and care, 7

Switching the appliance off

Cleaning the appliance

PC 604

Technical data

PC 604 X

Assistance

1

Warnings

GB

WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

WARNING: Danger of fire: do not store items on the cooking surfaces.

Never use steam cleaners or pressure cleaners on the appliance.

The appliance is not intended to be operated by means of an external timer or separate remote control system.

2

Installation

!Before operating your new appliance please read this instruction booklet carefully. It contains important information for safe use, installation and care of the appliance.

!Please keep these operating instructions for future reference. Pass them on to possible new owners of the appliance.

Positioning

!Keep packaging material out of the reach of children. It can become a choking or suffocation hazard (see Precautions and tips).

!The appliance must be installed by a qualified professional according to the instructions provided. Incorrect installation may cause harm to people and animals or may damage property.

Fitting the appliance

It is possible to instal them next to furniture which is higher than the working board. For a correct installation of the cooking top the following precautions must be followed:

•Kitchen cabinets adjacent to the appliance and taller than the top of the hob must be at least 600 mm from the edge of the hob.

•Hoods must be installed according to their relative installation instruction manuals and at a minimum distance of 650 mm from the hob.

	600mm min.
700mmmin.	600mmmin.

•Place the wall cabinets adjacent to the hood at a minimum height of 420 mm from the hob (see figure).

•If the hob is installed beneath a wall cabinet, the latter must be situated at a minimum of 700 mm above the hob (see figure).

•The installation cavity should have the dimensions indicated in the figure.

Fastening hooks are provided, allowing you to fasten the hob to tops that are between 20 and 40 mm thick. To ensure the hob is securely fastened to the top, we recommend you use all the hooks provided.

555 mm

GB

mm

55

475

mm

Hook fastening diagram

20	30
Hooking position	Hooking position
for top H=20 mm	for top H=30 mm
	Front

	40
Hooking position	Back
for top H=40 mm

! Use the hooks contained in the “accessory pack”

•Where the hob is not installed over a built-in oven, a wooden panel must be installed as insulation. This must be placed at a minimum distance of 20 mm from the lower part of the hob.

Ventilation

To ensure adequate ventilation, the back panel of the cabinet must be removed. It is advisable to install the oven so that it rests on two strips of wood, or on a completely flat surface with an opening of at least 45 x 560 mm (see diagrams).

3

GB
.	45	m	m
m				.
m
560

Where a hob is installed above an oven without a forced ventilation cooling system, adequate ventilation must be provided inside the cabinet by means of air holes through which air can pass (see figure).

Electrical connection

The electric hobs are supplied without power supply cable since the cable must be sized according to the type of electrical connection used (see attached connection diagram). Follow these steps to connect the cable:

•Open the terminal box by removing the screws "V" and opening the cover (see figure).

•Connect the wires as shown in the diagram.

•Fix the cable using the cable clamp "F", replace the cover and fasten it using the screws "V" (see figure).

V

1	2	3	4	5
				F

380-400V 3N~		1			2				3			4			5
H05RR-F 5x1.5 CEI-UNEL 35363	R					S				T							N
	1														5
380-400V 2N~					2			3				4
H05RR-F 4x1.5 CEI-UNEL 35363							R			S N
	1			2								4
220-230V 1N~								3							5
H05RR-F 3x2.5 CEI-UNEL 35363											R						N

Connecting the supply cable to the mains

Install a standardised plug corresponding to the load indicated on the data plate.

The appliance must be directly connected to the mains using an omnipolar circuit-breaker with a minimum contact opening of 3 mm installed between the appliance and the mains. The circuit-breaker must be suitable for the charge indicated and must comply with current electrical regulations (the earthing wire must not be interrupted by the circuit-breaker). The supply cable must not come into contact with surfaces with temperatures higher than 50°C.

!The installer must ensure that the correct electrical connection has been made and that it is compliant with safety regulations.

Before connecting to the power supply, make sure that:

•The appliance is earthed and the plug is compliant with the law.

•The socket can withstand the maximum power of the appliance, which is indicated on the data plate.

•The voltage is in the range between the values indicated on the data plate.

•The socket is compatible with the plug of the appliance. If the socket is incompatible with the plug, ask an authorised technician to replace it. Do not use extension cords or multiple sockets.

!Once the appliance has been installed, the power supply cable and the electrical socket must be easily accessible.

!The cable must not be bent or compressed.

!The cable must be checked regularly and replaced by authorised technicians only (see Assistance).

!The manufacturer declines any liability should these safety measures not be observed.

!If the appliance is to be installed above a built-in electric oven, the electrical connection of the hob and the oven must be carried out separately, both for electrical safety purposes and to make extracting the oven easier.

4

Description of the appliance

Overall view

GB

ELECTRIC PLATE

Control knobs for the cook-top		Pilot lamp of the
ELECTRIC PLATE		ELECTRIC PLATE

•The ELECTRIC PLATE vary in diameter and power: "normal" and "fast". The latter can be identified by a red boss in the center of the hot plate itself.

! The position of the corresponding electric hot plate is indicated on each control knob.

•The ELECTRIC PLATE ON indicator light switches on whenever the knob is moved from the 'off' position.

•The ELECTRIC PLATE control knob is a device used to regulate power.

The knob may be turned clockwise or anticlockwise and set to six different positions:

Setting	Normal or Fast Plate
0	Off
1	Low
2 - 5	Medium
6	High

! Please refer to the "Practical advice on using the appliance" section for a list of the relative positions and their recommended uses.

5

Precautions and tips

! This appliance has been designed and

GB manufactured in compliance with international safety standards. The following warnings are provided for safety reasons and must be read carefully.

General safety

•This manual is for a class 3 built-in cooktop.

•These instructions are only valid for the countries the symbols for which appear on the manual and the serial plate.

•This appliance is designed for non-professional use in the home.

•This appliance was designed for domestic use inside the home and is not intended for commercial or industrial use.

•Do not touch the appliance with bare feet or with wet or damp hands and feet.

•The appliance must be used by adults only for the preparation of food, in accordance with the instructions outlined in this booklet. Any other use of the appliance (e.g. for heating the room) constitutes improper use and is dangerous.

The manufacturer may not be held liable for any damage resulting from improper, incorrect and unreasonable use of the appliance.

•Ensure that power supply cables of other electrical appliances do not come into contact with the hot parts of the hob.

•The openings and slots used for ventilation and heat dispersion must never be covered.

•Make sure the knobs are in the “•”/” ” position when the appliance is not in use.

•When unplugging the appliance always pull the plug from the mains socket, do not pull on the cable.

•Never carry out any cleaning or maintenance work without having unplugged the plug from the mains.

•In the case of a malfunction, under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or further malfunctioning of the appliance. Contact a Service Centre (see Assistance).

•Always make sure pan handles are turned towards the centre of the hob in order to avoid accidental burns.

•Do not leave the electric plate switched on without a pan placed on it.

•Do not use cookware with uneven or deformed bottoms.

•The appliance should not be operated by people (including children) with reduced physical, sensory or mental capacities, by inexperienced individuals or by anyone who is not familiar with the product. These individuals should, at the very least, be supervised by someone who assumes

responsibility for their safety or receive preliminary instructions relating to the operation of the appliance.

•Do not let children play with the appliance.

•The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Disposal

•When disposing of packaging material: observe local legislation so that the packaging may be reused.

•The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

Practical Advice on Using the Electric Hot Plates

In order to avoid heat loss and damage to the hot plate, use cookware with a flat bottom the diameter of which is not less than that of the hot plate.

Setting	Setting
0	Off
1	Cooking vegetables, fish
2	Cooking patatoes (using steam) soups,
	chickpeas, beans.
3	Continuing the cooking of large quantities of
	food, minestrone.
4	For roasting (average)
5	For roasting (above average)
	---------
6	For browning and reaching a boil in a short
	time

! Before using the hot plates for the first time, you should heat them at maximum temperature for approximately 4 minutes, without any pans. During this initial stage, their protective coating hardens and reaches its maximum resistance.

6

Maintenance and care

Switching the appliance off

Disconnect your appliance from the electricity supply before carrying out any work on it.

Cleaning the appliance

!Do not use abrasive or corrosive detergents, stain removers, anti-rust products, powder detergents or sponges with abrasive surfaces: these may scratch the surface.

!Never use steam cleaners or pressure cleaners on the appliance.

•It is usually enough to wash the hob with a damp sponge and dry it with absorbent kitchen roll.

•The electric hobs should be cleaned using a damp cloth and then rubbed with oil while still warm.

•Stainless steel may become marked if it comes into contact with very hard water or harsh detergents (containing phosphorous) for long periods of time. After cleaning, it is advisable to rinse thoroughly and dry. It is also recommended that drops of water be dried.

Assistance

GB

! Never use the services of an unauthorised technician.

Please have the following information to hand:

•The type of problem encountered.

•The appliance model (Mod.).

•The serial number (S/N).

This information can be found on the data plate located on the appliance and/or on the packaging.

Technical characteristic

DATA PLATE

voltage: 220-230V/380-400V 3N ~

Electrical section 50/60Hz

Max power 5600 W

This appliance conforms to the following European Economic Community directives:

- 2006/95/EEC of 12/12/06 (Low Voltage) and subsequent amendments;

- 2004/108/EEC of 15/12/04 (Electromagnetic Compatibility) and subsequent amendments;

- 93/68/EEC of 22/07/93 and subsequent amendments.

- 2002/96/EC and subsequent amendments.

7

Mode d’emploi

TABLE DE CUISSON

								Sommaire
FR
								Avertissements, 9
		GB		FR		ES
								Installation, 10-11
	English, 1			Français, 8		Español, 15		Positionnement
								Raccordement électrique
		PT		AR				Description de l’appareil, 12
								Vue d’ensemble
		Português, 22
								Précautions et conseils, 13
								Sécurité générale
								Mise au rebut
								Conseils pratiques pour l’utilisation des plaques électriques
								Nettoyage et entretien, 14

PC 604

PC 604 X

Mise hors tension Nettoyage de l’appareil Plaquette signalétique Assistance

8

Avertissements

ATTENTION : Cet appareil ainsi que ses parties accessibles deviennent très

FR

chauds pendant leur fonctionnement. Il faut faire attention à ne pas toucher les éléments chauffants. Ne pas faire approcher les enfants de moins de 8 ans à moins qu'ils ne soient sous surveillance constante. Le présent appareil peut être utilisé par des enfants de plus de 8 ans et par des personnes présentant des capacités physiques, sensorielles ou mentales réduites ou n'ayant pas l'expérience ou les connaissances indispensables, à condition qu'ils soient sous bonne surveillance ou qu'ils aient reçu les instructions nécessaires pour une utilisation de l'appareil en toute sécurité et à condition qu'ils se rendent compte des dangers encourus. Les enfants ne doivent pas jouer avec l'appareil. Les opérations de nettoyage et d'entretien ne doivent pas être effectuées par des enfants non surveillés.

ATTENTION : Laisser un récipient de cuisson avec de l'huile ou de la graisse sur un foyer est dangereux et risque d'entraîner un incendie. Il ne faut JAMAIS essayer d'éteindre une flamme ou un incendie avec de l'eau ! Il faut éteindre l'appareil et couvrir la flamme avec un couvercle, par exemple, ou avec une couverture anti-feu.

ATTENTION : Risque d'incendie : ne pas laisser d'objets sur les surfaces de cuisson.

Ne jamais nettoyer l'appareil avec des nettoyeurs vapeur ou haute pression.

Cet appareil ne peut pas être allumé au moyen d'un temporisateur extérieur ou d'un système de commande à distance séparé.

9

Installation

! Conservez ce mode d’emploi pour pouvoir le consulter FR à tout moment. En cas de vente, de cession ou de

déménagement, veillez à ce qu’il suive l’appareil pour informer le nouveau propriétaire sur son fonctionnement et lui fournir les conseils correspondants.

! Lisez attentivement les instructions : elles contiennent des conseils importants sur l’installation, l’utilisation et la sécurité de votre appareil.

Positionnement

!Les emballages ne sont pas des jouets pour enfants, il faut les mettre au rebut en respectant la réglementation sur le tri sélectif des déchets (voir Précautions et conseils).

!L’installation doit être effectuée par un professionnel du secteur conformément aux instructions du fabricant. Une mauvaise installation peut causer des dommages à des personnes, des animaux ou des biens.

Encastrement

On peut par conséquent les installer à côté de meubles dont la hauteur ne dépasse pas celle du plan de cuisson. Pour une installation correcte de la table de cuisson, il faut se conformer aux instructions suivantes :

•Les meubles jouxtant la table, dont la hauteur dépasse celle du plan de cuisson, doivent être placés

àau moins 600 mm du bord du plan.

•Les hottes doivent être installées conformément aux instructions reportées dans leur notice d’installation et

àau moins 650 mm de distance.

•Les éléments hauts jouxtant la hotte doivent être

											placés à au moins 420
											mm de distance du plan
											de travail (voir figure).
											• En cas d’installation de
	min.			600mm min.			min.
											la table de cuisson sous
	700mm						600mm
											un élément haut, ce
											dernier devra être monté
											à au moins 700 mm de
											distance du plan (voir
											figure).

•La découpe du meuble doit avoir les dimensions indiquées par la figure. Des crochets de fixation sont prévus pour fixer la table sur des plans de 20 à 40

mm d’épaisseur.

Pour bien fixer la table, utilisez tous les crochets fournis.

				555 mm
	mm
55				475					mm

Schéma de fixation des crochets

20

30

Position du crochet pour	Position du crochet pour
plan H=20mm	plan H=30mm
	Devant

	40
Position du crochet pour	Derrière
plan H=40mm

! Utilisez tous les crochets compris dans le “sachet accessoires”

•Si la table n’est pas installée au-dessus d’un four à encastrer, il faut monter un panneau d’isolation en bois. Il faut le monter à au moins 20 mm de distance du bord inférieur de la table.

Aération

Pour garantir une bonne aération, la cavité d’encastrement doit être dépourvue de paroi arrière. Il est conseillé d’installer le four de manière à ce qu’il repose sur deux cales en bois ou bien sur un plan d’appui continu qui ait une découpe d’au moins 45 x 560 mm (voir figures).

10

.	45	mm	.
mm
560

En cas d’installation au-dessus d’un four encastrable dépourvu de ventilation de refroidissement forcée, il faudra prévoir des prises d’air d’entrée et de sortie pour permettre une bonne aération à l’intérieur du meuble (voir figure).

Raccordement électrique

Les tables électriques ne sont pas équipées de câble d’alimentation électrique car ce dernier doit être dimensionné en fonction du type de raccordement électrique utilisé (voir schéma de connexion sous indiqué). Pour raccorder le câble, procédez comme suit

:

•Dévissez la vis “V” et soulevez le couvercle pour ouvrir le bornier (voir figure).

•Raccordez les fils comme illustré.

•Fixez le câble dans le pince-câble “F”, refermez et fixez le couvercle à l’aide de la vis “V” (voir figure).

V

1	2	3	4	5
				F

380-400V 3N~			1			2			3			4			5									FR
H05RR-F 5x1.5 CEI-UNEL 35363		R					S			T							N
		1													5
380-400V 2N~						2			3			4
H05RR-F 4x1.5 CEI-UNEL 35363								R		S N
		1			2							4
220-230V 1N~									3						5
H05RR-F 3x2.5 CEI-UNEL 35363											R						N

Branchement du câble d’alimentation au réseau électrique

Montez sur le câble une prise normalisée adaptée à la charge indiquée sur l’étiquette des caractéristiques. En cas de raccordement direct au réseau, il faut intercaler entre l’appareil et le réseau un interrupteur à

coupure omnipolaire ayant au moins 3 mm d’écartement entre les contacts, dimensionné à la charge et conforme aux normes en vigueur (le fil de terre ne doit pas être interrompu par l’interrupteur). Le câble d’alimentation ne doit atteindre, en aucun point, des températures dépassant de 50°C la température ambiante.

! L’installateur est responsable du bon raccordement électrique de l’appareil et du respect des normes de sécurité.

Avant de procéder au branchement, assurez-vous que :

•la prise est bien munie d’une terre conforme à la loi;

•la prise est bien apte à supporter la puissance maximale de l’appareil, indiquée sur la plaquette signalétique;

•la tension d’alimentation est bien comprise entre les valeurs indiquées sur la plaquette signalétique;

•la prise est bien compatible avec la fiche de l’appareil. Si ce n’est pas le cas, remplacez la prise ou la fiche, n’utilisez ni rallonges ni prises multiples.

!Après installation de l’appareil, le câble électrique et la prise de courant doivent être facilement accessibles

!Le câble ne doit être ni plié ni excessivement écrasé.

!Il doit être contrôlé périodiquement et ne peut être remplacé que par un technicien agréé (voir Assistance).

!Nous déclinons toute responsabilité en cas de non respect des normes énumérées ci-dessus.

!En cas d’installation au-dessus d’un four à encastrer, la connexion électrique de la table et celle du four doivent être effectuées séparément, pour des questions de sécurité électrique mais aussi pour simplifier, au besoin, l’extraction du four.

11
