Hoover WDXOC575AC-AUS User Manual

WDXOC 575AC-AUS

Thank-you for choosing a Hoover washing machine. We are proud to always offer new, innovative and technologically advanced products, with a complete range of home appliances to ensure true assistance in your daily routine.

Carefully read this manual for correct and safe appliance use and for helpful tips on efficient maintenance.

Only use the washing machine after carefully reading these instructions. We recommend you always keep this manual on hand and in good condition for any future owners.

Please check that the appliance is delivered with this instruction manual, warranty certificate, water and energy efficiency label. Also check that plugs, curve for drain hose and liquid detergent or bleach tray (only on some models) are included. We recommend you keep all these components.

Each product is identified by a unique 16character code, also called the “serial number”, printed on the sticker affixed to the appliance (porthole area) or in the document envelope found inside the product.

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

WEEE contains both polluting substances (which can cause negative consequences for the environment) and basic components (which can be re-used). It is important to have WEEE subjected to specific treatments, in order to remove and dispose properly all pollutants, and recover and recycle all materials. Individuals can play an important role in ensuring that WEEE does not become an environmental issue; it is essential to follow some basic rules:

! WEEE should not be treated as household

waste;

! WEEE should be handed over to the relevant

collection points managed by the municipality or by registered companies. In many countries, for large WEEE, home collection could be present.

In many countries, when you buy a new appliance, the old one may be returned to the retailer who has to collect it free of charge on a one-to-one basis, as long as the equipment is of equivalent type and has the same functions as the supplied equipment.

1. GENERAL SAFETY RULES

2. INSTALLATION

3. PRACTICAL TIPS

4. MAINTENANCE AND CLEANING

5. QUICK USER GUIDE

6. CONTROLS AND PROGRAMS

7. DRYING CYCLE

8. AUTOMATIC WASHING/DRYING CYCLE

THROUBLESHOOTING AND WARRANTY

Environmental conditions

Contents

1. GENERAL SAFETY RULES

! This appliances is intended to

be used in household and similar applications such as:

- Staff kitchen areas in shops, offices and other working environments;

- Farm houses;

- By clients in hotels, motels and other residential type environments;

- Bed and breakfast type environments.

A different use of this appliance from household environment or from typical housekeeping functions, as commercial use by expert or trained users, is excluded even in the above applications. If the appliance is used in a manner inconsistent with this it may reduce the life of the appliance and may void the manufacturer’s warranty. Any damage to the appliance or other damage or loss arising through use that is not consistent with domestic or household use (even if located in a domestic or household environment) shall not be accepted by the manufacturer to the fullest extent permitted by law.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of

the appliance by a person responsible for their safety. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

! Children should be supervised

to ensure that they do not play with the appliance.

! Children of less than 3 years

should be kept away unless continuously supervised.

! If the supply cord is damaged, it

must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

! Only use the hose-sets

supplied with the appliance for the water supply connection (do not reuse old hose-sets).

! Water pressure must be between

0,05 MPa and 0,8 MPa.

! Make sure that carpet does not

obstruct the base of the machine and ventilation openings.

! The OFF condition is reached

placing the reference mark on the programmes control/knob in the vertical position. Any other different position of such control sets the machine in ON condition (only for models with programmes knob).

! The final part of a washer dryer

cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures that the items will not be damaged.

! After installation, the appliance

must be positioned so that the plug is accessible.

! The appliance must not be

installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the washer dryer, in such way that a full opening of the washer dryer door is restricted.

! The maximum load capacity for

washing dry clothes is 7kg. The maximum load capacity for Tumble drying is 5kg. Hence the maximum load capacity for Automatic washing and drying is 5kg (5+5).

! The appliance is not to be used

if industrial chemicals have been used for cleaning.

! Do not dry unwashed items in

the washer dryer.

! Items that have been soiled with

substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the washer dryer.

! Items such as foam rubber (latex

foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the washer dryer.

! Fabric softeners, or similar

products, should be used as specified by the fabric softener instructions.

Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as a washer dryer. The items become warm, causing an oxidation reaction in the oil, Oxidation creates heat. If the heat cannot escape, items can become hot enough to catch fire. Piling, stacking or storing oil-effected items can prevent heat from escaping and so create a fire hazard.

! If it is unavoidable that fabrics

contain vegetable or cooking oil or have been contaminated by hair care products be placed in a washer dryer they should first be washed in hot water with extra detergent - this will reduce, but not eliminate, the hazard.

WARNING:

never stop a washer dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.

! Remove all objects from pockets

such as lighters and matches.

! The technical details (supply

voltage and power input) are indicated on the product rating plate

! Make sure that the electrical

system is grounded, complies with all applicable law and that the (electricity) socket is compatible with the plug of the appliance. Otherwise, seek qualified professional assistance.

! The use of converters, multiple

sockets or extension cords is strongly advised against.

! Before cleaning or maintaining

the washing machine, unplug the appliance and turn off the water faucet.

! Do not pull on the power cord

or appliance to unplug the machine.

! Make sure there is no water in

the drum before opening the porthole.

! Do not expose the washing

machine to rain, direct sunlight or other weather elements. Protect from possible freezing.

! When moving, do not lift the

washing machine by the knobs or detergent drawer; during transport, never rest the porthole on the trolley. We recommend two people lift the washing machine.

! In the event of fault and/or

malfunction, turn off the washing machine, close the water faucet and do not tamper with the appliance. Immediately contact the Customer Service Centre and only use original spare parts. Failure to observe these instruction may jeopardise appliance safety.

! Lint must not be allowed to

accumulate around the tumble dryer.

Electrical connections and safety instructions

WARNING:

water may reach very high temperatures during the wash cycle.

2. INSTALLATION

! Unscrew the 2 or 4 transit

screws (A) on the back and remove the 2 or 4 washers (B) as illustrated in figure 1.

! Close the 2 or 4 holes using the

plugs included in the instruction envelope.

! In some models, 1 or more

washers will fall inside the machine: tilt the washing machine forward to remove them. Close the holes using the plugs found in the envelope. Keep the transit screws & parts for future use in case you move house.

! Place the polionda sheet on the

bottom as shown in figure 2 (according to the model, consider version A, B or C).

WARNING:

keep packaging materials away from children.

In some models this operation will not be necessary, because the corrugated plastic sheet will be already placed on the bottom of the appliance.

! Connect the water hose to the water

supply faucet (fig. 3) only using the hose supplied with the appliance (do not reuse old hose-sets).

! Some models may include one or more of

the following features:

! HOT&COLD (fig. 4):

water mains connection settings with hot and cold water for higher energy savings. Connect the grey hose to the cold water faucet and the red one to the hot water faucet. The machine can be connected to the cold water faucet only: in this case, some programs may start a few minutes later.

! AQUASTOP (fig. 5):

a device located on the supply hose that stops water flow if the tube deteriorates; in this case, a red mark will appear in the window “A” and the hose must be replaced. To unscrew the nut, press the one-way lock device "B".

! AQUAPROTECT – SUPPLY HOSE WITH

GUARD (fig. 6):

Should water leak from the primary internal hose "A", the transparent containment sheath "B" will contain water to permit the washing cycle to complete. At the end of the cycle, contact the Customer Service Centre to replace the supply hose.

! The washing machine should be installed

in its final position such that the water fill hose is not kinked or trapped. The corrugated drain hose should be inserted into a suitable drain pipe that is at a height between 50 cm and 85 cm above the floor using the curved drain hose support. If an under sink connection is used the drain hose must be routed above the sink overfill opening to prevent back siphoning. Care must be taken to avoid kinking or trapping the drain hose (fig. 7).

min 50 cm max 85 cm

+2,6 mt

max

max 100 cm

min 4 cm

Water connections

Setting

! Level the appliance using the feet as

illustrated in figure 8: a. turn the nut clockwise to release the

screw;

b. rotate the foot to raise or lower it until it

adheres to the floor;

c. lock the foot, screwing in the nut, until it

adheres to the bottom of the washing machine.

! Plug in the appliance.

The detergent draw is split into 3 compartments as illustrated in figure 9:

! compartment "1": for prewash detergent;

! compartment “ ”: for special additives,

softeners, starch fragrances, etc.;

! compartment "2": for washing detergent.

A liquid detergent cup is also included in SOME MODELS (fig. 10). To use it, place it

compartment "2". The cup can also be used for bleach when the “Rinse” program is selected.

WARNING:

contact the Customer Service Centre should the power cord need replacement.

Detergent drawer

WARNING:

Some liquid detergents are hard to dissolve. In this case we recommend diluting the detergent with warm water. We recommend you use only 20% of the recommended detergent quantities shown on the detergent pack.

WARNING:

installation faults are not covered by the manufacturers warranty.

3. PRACTICAL TIPS

WARNING: when sorting laundry,

make sure:

- there are NO foreign objects such as coins, hair clips, pins, keys etc, etc, from the wash load. Check all pockets. Serious damage to the machine can result which may not be covered by warranty.

- to have buttoned pillow cases, closed zips, tied loose belts and long robe ribbons;

- to have removed rollers from curtains;

- to have carefully read clothing washing labels;

- to have removed any persistent stains using specific detergents.

! When washing rugs, bedcovers or other

heavy clothing, we recommend you avoid spinning.

! To wash wool, make sure the item can be

machine washed. Check the fabric label.

A guide to environmentally friendly and economic use of your appliance.

Maximise The Load Size

! Achieve the best use of energy, water,

detergent and time by using the recommended maximum load size. Save up to 50% energy by washing a full load instead of 2 half loads.

Do you need to pre-wash?

! For heavily soiled laundry only!

SAVE detergent, time, water and between 5 to 15% energy consumption by NOT selecting Prewash for slight to normally soiled laundry.

Is a hot wash required?

! Pretreat stains with stain remover or soak

dried in stains in water before washing to reduce the necessity of a hot wash programme.

Save up to 50% energy by using a 60°C wash programme.

Before using a drying programme (WASHER-DRYERS)

! SAVE energy and time by selecting a

high spin speed to reduce the water content in laundry before using a drying programme.

Following is a quick guide with tips and recommendations on detergent use at the various temperatures. In any case, always read the instructions on the detergent for correct use and doses.

Load tips

Helpful suggestions for the user

When washing heavily soiled whites, we recommend using cotton programs of 60°C or above and a

normal washing powder (heavy duty) that contains bleaching agents that at medium/high temperatures provide excellent results.

For washes between 40°C and 60°C the type of detergent used needs to be appropriate for the type of fabric and level of soiling. Normal powders are suitable for “white” or colour fast fabrics with high soiling, while liquid detergents or “colour protecting” powders are suitable for coloured fabrics with light levels of soiling.

For washing at temperatures below 40°C we recommend the use of liquid

detergents or detergents specifically labeled as suitable for low temperature washing. Please note - dilute viscous liquid detergent with warm water if necessary.

For washing wool or silk, only use detergents specifically formulated for these fabrics.

4. MAINTENANCE AND CLEANING

To clean the washing machine exterior, use a damp cloth, avoiding abrasives, alcohol and/or solvents. The washing machine does not require any special care for ordinary cleaning: clean drawer compartments and the filter; some tips on how to move the machine or on long periods of disuse are provided below.

! We recommend you clean the drawer to

avoid accumulating detergent and additive residue.

! To do this, extract the drawer using slight

force, clean it with running water and reinsert it in its housing.

! The washing machine comes with a

special filter able to trap large residue, such as buttons or coins, which could clog the drain.

! ONLY AVAILABLE ON CERTAIN MODELS:

pull out the corrugated hose, remove the stopper and drain the water into a container.

! Before unscrewing the filter, we

recommend you place an absorbent cloth under it to keep the floor dry.

! Turn the filter counter-clockwise.

! Remove and clean the filter; when

finished, replace it turning it clockwise.

! Repeat the previous steps in reverse

order to reassemble all parts.

! If the washing machine will not be used

for an extended amount of time and will be store in a cold area ensure all water is drained from the hoses to prevent freezing.

! Unplug the washing machine.

! Detach the hose from the strap and lower

it, fully draining water into a bowl.

! Secure the drain hose with the strap

when finished.

Drawer cleaning

Filter cleaning

Suggestions for moves or prolonged disuse

WARNING:

unplug the machine prior to cleaning.

5. QUICK USER GUIDE

This washing machine automatically adjusts the level of the water to the type and quantity of washing. This system gives a reduction in energy consumption and a saving in washing times.

! Turn on the washing machine and select

the required program.

! Adjust the washing temperature if

necessary and press the required "option" buttons.

! Press the START/PAUSE button to start

washing.

Should power go out when the washing machine is running, a special memory saves the settings and, when power returns, the machine resumes the cycle from where it left off.

! At the end of the programme, the

message "End" will appear on the display or, on some models, all wash stage indicator lights will turn on.

! Turn off the washing machine.

For any type of wash, see the program table and follow the operating sequence as indicated.

Water pressure:

min 0.05 Mpa / max 0.8 Mpa (0.05 MPa dispenses approximately 1 litre of water in 10 seconds)

Spin r.p.m.: See rating plate.

Power input / Power current fuse amp / Supply voltage: See rating plate.

6. CONTROLS AND PROGRAMS

DCEFG

LHI

PO MN

Programme selector with OFF position

START/PAUSE button

DELAY START button

DRYING SELECTION / STEAM FUNCTION button

RAPID / STAIN / SOIL LEVEL button

TEMPERATURE SELECTION button

SPIN SPEED button

F+G

KEY LOCK

Digital display

DRYING SELECTION indicator lights

DOOR LOCKED indicator light

KG MODE indicator light

KEY LOCK indicator light

TEMPERATURE SELECTION indicator lights

SPIN SPEED indicator lights

ONE TOUCH area

Program selection

Wait until the DOOR LOCKED light has gone out before opening the door.

Technical data

! Press the START/PAUSE button to start

the selected cycle.

Once a programme is selected the programme selector remains stationary on the selected programme until the cycle ends.

! "End" will appear in the display at the

end of the program and the DOOR LOCKED light will go off, it is now possible to open the door.

! Switch off the washing machine by

turning the selector to OFF.

! Press to start the selected cycle.

ADD OR REMOVE ITEMS AFTER THE PROGRAMMES HAS STARTED (PAUSE)

! Press and hold the START/PAUSE

button for about 2 seconds (some indicator lights and the time remaining indicator will flash, showing that the machine has been paused).

! Wait until the DOOR LOCKED light has

gone out before opening the door.

! After you have added or removed items,

close the door and press the START/PAUSE button (the programme will start from where it left off).

CANCELLING THE PROGRAMME

! To cancel the programme, set the

selector to the OFF position.

! Wait 2 minutes until the safety device

unlocks the door.

! This button allows you to pre-programme

the wash cycle and delay the start of the cycle for up to 24 hours.

! To delay the start use the following

procedure:

- Select the required programme.

PROGRAMME selector with OFF position

When the programme selector is turned the display lights up to show the settings for the programme selected. For energy saving, at the end of the cycle or with an inactivity period, the display level contrast will decrease.

N.B.: To switch the machine off, turn the programme selector to the OFF position.

The programme selector must be returned to the OFF position at the end of each cycle or when starting a subsequent wash cycle prior to the next programme being selected and started.

START/PAUSE button

Close the door BEFORE selecting the button START/PAUSE.

When the START/PAUSE button has been pressed, the appliance can take few seconds before it starts working.

Before you open the door, please check the water level is below the door opening to avoid flooding.

DELAY START button

- Press the delay start button once to activate it (h00 appears on the display) and then press it again to set a 1 hour delay (h01 appears on the display). The pre-set delay increases by 1 hour each time the button is pressed, until h24 appears on the display, at which point pressing the button again will reset the delay start to zero.

- Confirm by pressing the START/PAUSE button. The delay countdown will begin and when it has finished the programme will start automatically.

! It is possible to cancel the delay start by

turning the programme selector to OFF.

If there is any break in the power supply while the machine is operating, a special memory stores the selected programme and, when the power is restored, it continues where it left OFF.

This button allows you to choose between two different options:

- DRYING SELECTION

! For automatic washing/drying cycle:

after the selection of washing programme according to laundry type, select a degree of dryness by pressing this button. At the end of the washing programme, the selected drying cycle will start automatically.

If a washing programme is not compatible with automatic drying selected, this function will not be activated.

! If you want delete the selection before

the programme starts, please press

repeatedly the button until the lights go off or reposition the programme selector to the OFF position.

! Drying only cycle:

select via the knob the desired drying programme in conjunction with your fabrics, by pressing this button it is possible to select a degree of dryness that is different to the default one (except for the wool drying programme).

! To cancel the cycle during the drying

phase, please press the button for about 3 seconds.

! "End" will appear in the display at the

end of the program and the DOOR LOCKED light will go off, it is now possible to open the door.

The option buttons should be selected before pressing the START/PAUSE button. If an option is selected that is not compatible with the selected programme then the option indicator light first flashes and then goes off.

DRYING SELECTION / STEAM FUNCTION

If you exceed the maximum dryable load of laundry indicated in the programme table, the laundry may not be dried satisfactory.

WARNING: After cancelling the drying programme, the cool down phase will begin and please wait for about 10/20 minutes before opening the door.

It is also possible to cancel the drying cycle by turning the programme selector to the OFF position. It is necessary to wait for the cooling phase’s end (10/20 minutes) and the DOOR LOCKED light to go off before opening the door.

- STEAM FUNCTION

After the selection of "ACTIVE STEAM" programme, select between three different intensity of steam treatments that are suitable for dry or wet clothes and according to fabric type:

- Active Steam Synthetics/Mixed

(default selection) P1 appears on the

display

This programme is suitable for synthetics and mixed clothes. In the case of wet clothes (i.e. after washing) If relax creases is selected after spin the dry clothes will reach the ideal moisture level for an easy ironing. Medium time.

- Active Steam Cotton

(only a button push) P2 appears on the

display

This programme is for cotton clothes. In the case of wet clothes (i.e. after washing) If relax creases is selected after spin the dry clothes will reach the ideal moisture level for an easy ironing. Medium time.

- Steam Refresh

(two button pushes) P3 appears on the

display

Thanks to the steam action, the cycle lets to refresh and relax clothes’ creases after use. This programme consists of a start phase in which the steam in introduced and the excess moisture is removed at the final stage to allow prompt use. This cycle is suitable for dry clothes.

The function is suitable for max up to 1,5 kg load.

This button allows you to choose between two different options, depending on the selected programme:

- RAPID

The button becomes active when you select the RAPID (14/30/44 Min.) programme on the knob and allows you to select one of three durations indicated.

- STAIN / SOIL LEVEL button

! Once the programme has been selected

the wash time set for that programme will be automatically shown.

! This option allows you to choose between

3 levels of wash intensity modifying the length of the programme, depending on how much the fabrics are soiled (can only be used on some programmes as shown in the table of programmes).

! This button allows you to change the

temperature of the wash cycles.

! It is not possible to raise the temperature

over the maximum allowed for the programme, in order to protect the fabrics.

! If you want carry out a cold wash all the

indicators must be off.

! By pressing this button, it is possible to

reduce the maximum speed, and if you wish, the spin cycle can be cancelled.

! If the label does not indicate specific

information, it is possible to use the maximum spin expected in the program.

RAPID / STAIN / SOIL LEVEL button

TEMPERATURE SELECTION button

SPIN SPEED button

! To reactivate the spin cycle press the

button until you reach the spin speed you would like to set.

! It is possible to modify the spin speed

without pausing the machine.

! Pressing simultaneously the buttons

TEMPERATURE SELECTION and SPIN SPEED for about 3 seconds, allows you

to lock the keys. This will prevent accidental or unwanted changes if a button on the display is pressed accidently during a cycle.

! The key lock can be simply cancelled by

pressing the two buttons simultaneously again or turning off the appliance.

The display’s indicator system allows you to be constantly informed about the status of the machine.

67 5

3124

DRYING SELECTION INDICATOR LIGHTS

The indicators display the degrees of dryness that can be selected by the relevant button:

EXTRA DRY

(suitable for towels, bathrobes and bulky loads).

IRON DRY

(that leaves the laundry ready for ironing).

CUPBOARD DRY

(for items that will be put away without ironing).

2) CYCLE DURATION

! When a programme is selected the

display automatically shows the typical cycle duration, which can vary, depending on the options selected.

! During the initial filling phase of the cycle

the machine calculates the actual cycle time needed based on the load size, content and options selected. The real time of the wash will then be displayed. This time can recaulculate during the wash depending on detergent levels and load balancing.

To prevent damage to the fabrics, it is not possible to increase the speed over the maximum allowed for the programme.

An over dosing of detergent can cause excessive foaming. If the appliance detects the presence of excessive foam, it may exclude the spinning phase or extend the duration of the program and increase water consumption.

The machine is fitted with a special electronic device, which prevents the spin cycle should the load be unbalanced. This reduces the noise and vibration in the machine and so prolongs the life of your machine.

KEY LOCK

Digital Display

3) DOOR LOCKED INDICATOR LIGHT

! The indicator light is illuminated when the

door is fully closed.

! When START/PAUSE is pressed on

the machine with the door closed, the indicator will flash momentarily and then illuminate.

! Wait until the DOOR LOCKED light has

gone out before opening the door.

4) Kg Mode INDICATOR LIGHT (function active only on certain programmes)

! During the first minutes of the cycle, the

"Kg Mode" indicator remains on while the intelligent sensor will weigh the laundry and adjust the cycle time, water and electricity consumption accordingly.

The "Kg MODE" displays information on the wash load. During the first couple of minutes, it will:

- adjusts the amount of water required;

- determines the length of the wash cycle;

- controls rinsing according to the type of fabric selected to be washed;

- adjusts the rhythm of drum rotation for the type of fabric being washed;

- recognises the presence of too much soap suds, and if necessary, adjust the amount of rinse water.

- adjusts the spin speed according to the load, thus avoiding any imbalance.

5) KEY LOCK INDICATOR LIGHT

The indicator light shows that the keys are locked.

6) WASH TEMPERATURE INDICATOR LIGHTS

This shows the washing temperature of the selected programme that can be changed (where allowed) by the relevant button. If you want carry out a cold wash all the indicators must be off.

7) SPIN SPEED INDICATOR LIGHTS

This displays the spin speed of the selected programme, that it can be reduced or omitted by the relevant button.

Close the door BEFORE selecting the START/PAUSE button.

If the door is not properly closed, the light will continue to flash for about 7 seconds, after which the start command will be automatically canceled. In this case, close the door in the proper way and press the START/PAUSE button.

This appliance is equipped with One Touch technology that allows you to interact, via the App, with smartphones based on Android operating system and equipped with NFC (Near Field Communication) function.

! Download on your smartphone the

Hoover Wizard App.

FUNCTIONS

The main functions available using the App are:

! Voice Coach – A guide to help you

choose the ideal cycle with only three voice inputs (clothes/fabrics, color, stain level).

! Programmes – To download and launch

new washing programmes.

! Clever Care – Clever Check-up and Auto-

Hygiene cycles and a troubleshooting guide.

! Reports – Washing statistics and tips for

a more efficient use of your machine.

HOW TO USE ONE TOUCH

FIRST TIME - Machine registration

! Enter the "Settings" menu of your

Android smartphone and activate the NFC function inside the "Wireless & Networks" menu.

! Turn the knob to the One Touch position

to enable the sensor on the dashboard.

! Open the App, create the user profile and

"Quick Guide" attached on the machine.

ONE TOUCH

The Hoover Wizardi App is available for devices running both Android and iOS, both for tablets and for smartphones. However, you can interact with the machine and take advantage of the potential offered by One Touch only with Android smartphones equipped with NFC technology, according to following functional scheme:

Android smartphone with NFC technology

Interaction with the machine + contents

Android smartphone without NFC technology

Contents only Android Tablet

Contents only

Apple iPhone

Contents only

Apple iPad

Contents only

Get all the details of the One Touch functions, browsing the App in DEMO mode or go to: www.hooveronetouch.com

Depending on the smartphone model and its Android OS version, the process of the NFC activation may be different. Refer to the smartphone manual for more details.

More information, F.A.Q. and the video for an easy registration are available on: www.hooveronetouch.com/how-to

NEXT TIME – Regular usage

! Every time you want to manage the

machine through the App, first you have to enable the One Touch mode by turning the knob to the One Touch indicator.

! Make sure you have unlocked your phone

(from stand-by mode) and you have activated the NFC function following the steps mentioned earlier.

! If you want to start a washing cycle, load

the laundry, the detergent and close the door.

! Select the desired function in the App

(e.g.: starting a programme, the Clever Check-up cycle, update statistics, etc…).

! Follow the instructions on the phone

display, KEEPING IT ON the One Touch logo on the machine dashboard, when requested to do so by the App.

NOTES:

Place your smartphone so that the NFC antenna on its back matches the position of the One Touch logo on the appliance (as illustred below).

If you do not know the position of your NFC antenna, slightly move the smartphone in a circular motion over the One Touch logo until the App confirms the connection. In order for the data transfer to be successful, it is essential TO KEEP THE SMARTPHONE ON THE DASHBOARD DURING THESE FEW SECONDS OF THE PROCEDURE; a message on the device will inform about the correct outcome of the operation and advise you when it is possible to move the smartphone away.

Thick cases or metallic stickers on your smartphone could affect or prevent the transmission of data between machine and telephone. If necessary, remove them.

The replacement of some components of the smartphone (e.g. back cover, battery, etc...) with non-original ones, could result in the NFC antenna removal, preventing the full use of the App.

The management and the control of the machine via App is only possible "by proximity": it is therefore not possible to perform remote operations (e.g.:

from

another room

; outside of the house).

PROGRAMME

(MAX.)

(see control panel)

(MAX.)

2 1

Active Steam

1,5

Mixed

All In One

3,5

40°

All Hygiene

4,5

60°

All In One

59 Min.

40°

14'

30°

Rapid

3) 4)

14-30-44 Min.

30'

2,5

30°

44'

3,5

40°

Cottons*

7 or 5

60°

Whites + Prewash

7 or 5

90°

Rinse

Drain & Spin

Delicates

2,5

40°

Wool & Silk

30°

Dry Wool

Low Heat

(drying)

3,5

High Heat

(drying)

Customizable setting that interacts with the App on your smartphone and to download the cycles (see the dedicated section). The factory sets the default programme Auto-Hygiene, which will sanitize the machine.

Table of programmes

Please read these notes:

(Only for models with liquid detergent compartment)

When only a limited number of articles have stains which require treatment with liquid bleaching agents, preliminary removal of stain can be carried out in the washing machine. Pour the bleach into the liquid bleach container, inserted into the compartment marked "2" in the detergent drawer, and set the special programme RINSE. When this phase has terminated, turn the programme selector to the OFF position, add the rest of the fabrics and proceed with a normal wash on the most suitable programme.

When a programme is selected, the display shows the recommended wash temperature, it can be reduced (where allowed) by the relevant button.

For the programmes shown you can adjust the duration and intensity of the wash using the STAIN / SOIL LEVEL button.

If the RAPID program is selected with the knob, the rapid programs 14', 30' and 44' will become available to select by using the RAPID button.

Programmes for automatic drying. The maximum load for auto wash/dry is 5 kg (5+5 Auto).

* Programme tested in accordance with AS/NZS 2040.2 with a temperature of 40°C and in accordance with AS/NZS 2442 for drying.

Programme also recommended for lowtemperature washes (lower than the max. shown).

The "Cottons" programme at 40 deg.C, 1500 RPM spin with "Max soil Level" setting is the program recommended for a normally soiled load at the rated capacity 7 kg.

Drying

First drying with 5 kg (a load consist:

pillowcases and hand-towels) selecting

the

cotton drying programme ( )

extra dry ( ).

Second drying with 2 kg (a load consist: sheets and hand towels) selecting the

cotton drying programme ( )

extra dry ( ).

To clean different types of fabrics and various levels of soil, the washing machine has specific programs to meet every need of washing (see table of programmes).

WASHING

Active Steam

This exclusive programme uses a steam treatment that allows you to reduce and relax the creases reaching the ideal moisture level easier ironing. Through a dedicated button it’s possible to select three different levels of intensity, customizing for dry or wet items, and accordingly on the type of fabric.

ALL IN ONE technology

This washing machine is equipped with an innovative system with an high pressure jet that sprays a mixture of water and detergent directly into the load. The special motor movement used in this machine manages the drum movement during the start up of each programme, in conjunction with the high pressure jet spraying the detergent mixture into the load, the cycle includes a set of spin actions that helps the detergent solution to penetrate into the fibers, helping dirt removal and ensuring the best available wash performance. The ALL IN ONE system is also used during the water load phases where the high pressure jet aids the complete removal of detergent residues trapped in the clothes.

Mixed All In One

This programme allows you to wash different type’s fabrics and different colours all together. The rotational movement of the drum and the water levels are optimized during the washing and rinsing phases. The accurate spin action, ensures a reduced formation of creases in the fabrics. Thanks to ALL IN ONE technology, a complete washing cycle optimization is possible.

IMPORTANT WASH PERFORMANCE ADVICE:

! New, coloured garments should be

washed separately for at least 5 or 6 washes.

! Certain large dark items such as jeans

and towels should always be washed separately.

! Never mix NON COLOURFAST fabrics.

All Hygiene

This programme ensures a deep cleaning, an effective sanitizing and anti-allergic action thanks to an optimized cycle in terms of temperature and rinse cycles, eliminating allergens and detergent residues. Ideal for people with sensitive skin. It is suitable for cotton garments, washed at 60°C temperature and is suggested for a reduced load.

All In One 59 Min.

This programme allows you to wash mixed fabrics such as cottons, synthetics and mixed fabrics in only 59 minutes, using the full load of the washing machine, at 40°C (or less) temperature. This programme is particularly suited to slightly soiled fabrics.

Rapid (14-30-44 Min.)

Washing cycle suggested for low loads and slightly soiled. With this program it is recommended to reduce the quantity of detergent normally used, in order to avoid unnecessary waste. Selecting the RAPID program and acting on the button you can choose one of three programs available.

Cottons

This program is suitable to clean normally soiled cotton laundry and it is the most efficient program in terms of combined energy and water consumptions for washing cotton laundry (when selected at 40°C, maximum stain/soil level, 1500 RPM spin speed).

Whites + Prewash

This programme has been designed to remove the stronger stains from cotton white clothes. The prewash guarantees the tough dirt removal. Add into compartment "1" a quantity of detergent equal to 20% of that used for main wash.

Programmes selection

Rinse

This program performs 3 rinses with an intermediate spin (which can be reduced or excluded by using the appropriate button) . It is used for rinsing any type of fabric, for example after a wash carried out by hand.

Drain & Spin

The program completes the drain and a maximum spin. It is possible to delete or reduce the spin with the SPIN SPEED button.

Delicates

This program has reduced periods of drum rotation during the cycle and is particularly suitable or washing delicate fabrics. The wash cycle and rinses are carried out with a high level of water to ensure the best performance.

Wool & Silk

This programme allows a delicate washing cycle, particularly suited to garments specified as "Machine-Washable" Wool fabrics and laundry items made from Silk or specified as "Wash as Silk" on the fabric label.

DRYING

The drum changes direction during the drying cycle to prevent the laundry from tangling and producing even more drying. Cool air is used during the last 10/20 minutes of the drying cycle to minimize creasing.

Dry Wool

Low temperature drying programme, ideal to dry woollen clothes with maximum care and softness, reducing rubbing of fabrics and avoid possible felting. It’s suggested to reverse clothing before drying. Timing is related to the amount of the washing and the spin speed selected for the wash. The cycle is suitable for small loads up to 1 kg (3 sweaters).

Mixed (Low Heat)

Low temperature drying programme recommended for synthetics and mixed fibres (always refer to the laundry care label).

Cottons (High Heat)

High temperature drying programme recommended for cottons and linen items (always refer to the laundry care label).

ONE TOUCH

Customizable setting of the knob that you have to select when you would like to transfer a command from the App to the machine and to download/start a cycle (see the dedicated section and the user manual of the App for more info). In the One Touch option the factory sets as a default the "Auto-Hygiene" cycle, made to clean the drum, remove bad smells and extend the life of the washing machine. Make sure there is no load in the drum before starting the "Auto-Hygiene" cycle, use a proprietary washing machine cleaning agent or powder detergent. Leave the door of the machine open at the end of the cycle to allow the drum to dry. Recommended every 50 washes.

WARNING: Dispensers used for concentrated powders and liquid detergents must be removed from the drum before commencing the tumble drying programmes.

The wool drying cycle of this machine has been approved by "The Woolmark Company" for the drying of machine washable wool products provided that the products are washed and dried according to the instructions on the garment label and those issued by the manufacturer of this machine. The Woolmark symbol is a Certification mark in many countries. M1715.

7. DRYING CYCLE

! Drying guidance advice is general, but

practical experience of using the product will help you to achieve the best drying results.

! We recommend setting a lower drying

time than indicated, when first using the appliance in order to establish the degree of dryness required.

! We recommend not drying fabrics that

fray easily, such as rugs or garments with a deep pile, in order to avoid air duct clogging.

! We recommend that you sort the laundry

by the following methods:

- By drying care symbols, which are displayed on the clothing labels

Suitable for tumble drying.

Tumble dry at high temperature.

Tumble dry at low temperature only.

DO NOT tumble dry.

- By size and thickness

Whenever the wash load is bigger than

the drying capacity, separate the clothes according to thickness (e.g. towels from thin underwear).

- By fabric type

Cottons/linen: towels, cotton jersey, bed

and table linen.

Synthetics: blouses, shirts, overalls, etc.

made of polyester or polyamide, as well as for cotton/synthetic mixes.

! Only dry pre-spun laundry.

! Open the door.

! Fill with the laundry, not exceeding the

maximum drying load indicated in the programme table. For large items (e.g. sheets) or very absorbent items (e.g. towels or jeans), it is a good idea to reduce the load.

! Close the door.

! Turn the programme dial to the more

suitable drying programme for your laundry.

! The washer dryer can perform the

following types of drying:

- Low temperature drying programme recommended for wool fabrics.

- Low temperature drying programme recommended for mixed fabrics (synthetics/cotton) synthetic fabrics.

- High temperature drying programme recommended for cotton, terry

toweling, linen, hemp fabrics, etc....

! Select the degree of dryness that you

require:

EXTRA DRY

(suitable for towels, bathrobes and bulky loads).

IRON DRY

(that leaves the laundry ready for ironing).

CUPBOARD DRY

(for items that will be put away without ironing).

If the fabric does not have a care label, you should assume that it is not suitable for drying.

The correct way to dry

! The washer dryer will calculate the time

needed for drying and the level of moisture remaining in the laundry, according to the load and drying type selected.

! Check that the tap is turned on and that

the discharge hose is positioned correctly.

! Press the START/PAUSE button (the

display will show the drying time remaining).

! When the programme is finished the word

"End" will appear on the display. After 5 minutes the appliance will go into

standby mode (on certain models, the display will show two lines).

! Switch off the machine by turning the

programme selector to the OFF position.

! Open the door and remove the laundry.

! Turn off the tap.

CANCELLING THE DRYING PROGRAMME

! To cancel the drying programme, press

and hold the DRYING SELECTION button for about 3 seconds.

In order to ensure the correct operation of the appliance, it is advisable not to interrupt the drying phase unless it is absolutely necessary.

By selecting the wool drying programme, it's not possible to select a degree of dryness different from the default one.

WARNING:

Do not dry articles with special padding (e.g. quilts, quilted anoraks, etc.) and very delicate fabrics. If garments are drip/dry, load less items to prevent creasing.

The appliance calculates the time to the end of the selected programme based upon a standard loading. During the cycle, the appliance corrects the time according to the size and composition of the load.

During the drying phase the drum will accelerate to a higher speed to distribute the load and to optimize the drying performance.

WARNING:

After cancelling the drying programme, the cool down phase will begin and you must wait for about 10/20 minutes before opening the door.

8. AUTOMATIC WASHING/DRYING CYCLE

- Washing

! Open the drawer and put in the correct

amount of detergent.

! Refer to the list of washing programmes

for the fabrics to be washed (e.g. very dirty cotton) and turn the selector knob to the required programme.

! Adjust the wash temperature if

necessary.

! Press the option buttons (if required).

! Check that the tap is turned on and that

the discharge hose is positioned correctly.

- Drying

! Select the degree of dryness that you

require:

EXTRA DRY

(suitable for towels, bathrobes and bulky loads).

IRON DRY

(that leaves the laundry ready for ironing).

CUPBOARD DRY

(for items that will be put away without ironing).

! Press the START/PAUSE button.

! At the end of the wash phase the display

will show the drying time remaining.

! When the programme is finished the word

"End" will appear on the display. After 5 minutes the appliance will go into

standby mode (on certain models, the display will show two lines).

! Switch off the machine by turning the

programme selector to the OFF position.

! Open the door and remove the laundry.

! Turn off the tap.

CANCELLING THE DRYING PROGRAMME

! To cancel the drying programme, press

and hold the DRYING SELECTION button for about 3 seconds.

In order to ensure the correct operation of the appliance, it is advisable not to interrupt the drying phase unless it is absolutely necessary.

You cannot exceed the maximum dryable load of laundry indicated in the programme table, otherwise the laundry will not be dried satisfactory (i.e. 5 kg Max for Auto wash/dry).

By selecting the wool programme, only the default degree of dryness is available.

WARNING:

After cancelling the drying programme, the cool down phase will begin and you must wait for about 10/20 minutes before opening the door.

9. THROUBLESHOOTING AND WARRANTY

If you believe the washing machine is not working correctly, consult the quick guide provided below which includes some practical tips on how to fix the most common problems.

ERROR CODE FORMAT

Error shown

Possible causes and practical solutions

E2 (with display) 2 flashes of the LEDs (without display)

The machine cannot load water.

Make sure the water supply tap is open.

Make sure the water supply hose isn’t bent, kinked or trapped.

Make sure the drain pipe is at the proper height (see installation section).

Close the water supply tap, unscrew the filler hose from the back of the washing machine and make sure the “anti-sand” filter is clean and not blocked.

E3 (with display) 3 flashes of the LEDs (without display)

The washing machine does not drain water.

Make sure the filter is not clogged.

Make sure the drain hose isn’t bent, kinked or trapped.

Make sure the home drainage system is not blocked and is allowing water to flow through without obstruction. Try to drain the water in the sink.

E4 (with display) 4 flashes of the LEDs (without display)

There is too much foam and/or water.

Ensure the correct amount of detergent is being used and the detergent is designed for use in a washing machine.

E7 (with display) 7 flashes of the LEDs (without display)

Door problem.

Make sure the door is correctly closed. Make sure the clothes inside the drum are not preventing the door from closing fully.

If the door is locked, turn off and unplug the washing machine from the electrical supply socket, wait 2-3 minutes and reopen the door.

Any other code

Turn off and unplug the washing machine, wait a minute. Turn on the machine and restart a program. If the error occurs again contact an Authorised Customer Service Centre directly.

FOR ONE TOUCH MODELS

The Hoover Wizard app has a Clever Check-up function that allows you to confirm the functionality and status of the product at any time. To use the Hoover Wizard app you will need an Android smartphone with NFC technology. More info can be found on the App. If the display of the machine is showing an error (by a code or blinking LEDs), you should turn on the App on your Android smartphone, with NFC on. Place your smart phone against the One Touch logo on the control panel. You should now be able to read the fault directory to solve the issue.

! Models with a display: the error is shown by a number preceded by the letter “E”

(example: E2 = Error 2).

! Models without display: an error is shown by a sequence of flashes of every LED.

The error code is shown by the number of flashes followed by a pause of 5 seconds (example: two flashes – pause 5 seconds – two flashes – repeating = Error 2).

OTHER ANOMALIES

Problem

Possible causes and practical solutions

The washing machine does not work / start

Make sure the product is plugged into a working supply socket.

Make sure power is on.

Make sure the wall socket is working, testing it with another appliance such as a lamp.

The door may not be correctly closed: open and close it again.

Check whether the required program was correctly selected and the start button pressed.

Make sure the washing machine is not in pause or time delay mode.

Water leaked on the floor near the washing machine

This may be due to a leak from the seal between the tap, supply hose and fill valve; in this case, replace it and tighten the hose connections correctly.

Make sure the front filter is correctly closed.

The washing machine does not spin

The machine is fitted with a detection system that protects the load and product from damage if the load is not balanced before spinning. This may result in:-

• The machine attempts to balance the load, increasing the time of spin.

• Reduction of the speed of spin to decrease vibrations and noise.

• The spin cycle aborting to protect the machine and load.

If this is experienced remove the load de-tangle it, reload it and restart the spin program.

This could be due to the fact that water has not been completely drained: wait a few minutes. If the problem persists, see Error 3 section.

Some models include a "no spin" function: make sure it is not selected.

Check which options are selected and their effect on the spin cycle.

Excessive detergent can impede the spin cycle, ensure the correct amount of detergent is being used.

Strong vibrations / noises are heard during the spin cycle

The washing machine may not be fully levelled: if necessary, adjust the feet as indicated in the specific section.

Make sure transport screws, rubber bungs and spacer tubes were removed.

Make sure there are no foreign objects inside the drum (coins, hinges, buttons, etc…).

The standard manufacturer warranty covers faults caused by electrical or mechanical faults in the product due to an act or omission of the manufacturer. If a fault is found to be caused by factors outside the product supplied, misuse or as a result of the instructions on use not being followed, a charge may be applied.

The use of ecological detergents without

: This effect is tied to the suspended zeolites which do not have negative effects on rinse

white powder (zeolites) on laundry at

: this is normal, the

powder is not absorbed by fabric and

move the zeolites, select a rinse

programme. In the future consider using

: this does not necessary indicate poor rinsing. Consider using less detergent in future

often due to the anionic surfactants found in the detergents which are hard to eliminate

rinse to eliminate

We suggest conducting a maintenance

If the problem persists or if you suspect a malfunction, immediately contact an

It is always recommended to use original spare parts, that are available at our

responsibility for any printing errors in the booklet included with this product. Moreover, it also reserves the right to make any changes deemed useful to its products without changing their essential

The product is guaranteed under the terms and conditions stated on the certificate included with the product. Proof of purchase must be made available at the time of any warranty

If the problem persists or if you suspect a malfunction, immediately contact an

It is always recommended to use original spare parts, that are available at our

The manufacturer declines all responsibility for any printing errors in the booklet included with this product. Moreover, it also reserves the right to make any changes deemed useful to its products without changing their essential

Warranty

The product is guaranteed under the terms and conditions stated on the certificate included with the product. Proof of purchase must be made available at the time of any warranty

phosphates may cause the following effects:

- cloudier rinse drain water

efficiency.

the end of the wash

does not change its colour. To re

slightly less detergent.

- foam in the water at last rinse

washes.

- abundant foam: This is

from laundry.

In this case, do not re-

these effects: it will not help at all.

wash using a proprietary cleaner.

If the problem persists or if you suspect a malfunction, immediately contact an Authorised Customer Service Centre.

Authorised Customer Service Centre.

It is always recommended to use original spare parts, that are available at our Authorised Customer Service Centres.

Authorised Customer Service Centres.

Warranty

The manufacturer declines all

related repair.

characteristics.

WIRELESS PARAMETERS

(for model with Wi-Fi function)

Parameter

Specifications

Wireless Standard

802.11 b/g/n

Frequency range

2.412 GHz. - 2.484 GHz.

Max Trasmit Power

802.11b (11Mbps) +18,5 ± 2 dBm

802.11g (54Mbps) +16 ± 2 dBm

802.11n (HT20, MCS7)

+14 ± 2 dBm

Minimum Receiving Sensitivity

802.11b (11Mbps)

-93 dBm

802.11g (54Mbps)

-85 dBm

802.11n (HT20, MCS7)

-82 dBm

With this the Candy Hoover Group Srl, declares that this appliance marked with

complies with the essential requirements of the Directive 2014/53/EU. To receive a copy of the declaration of conformity, please contact the manufacturer at: www.candy-group.com

WIRELESS PARAMETERS

(for model with NFC function)

Parameter

Specifications

Wireless Standard

ISO/IEC 14443 Type A and NFC Forum Type 4

Frequency band

13.553-13.567 MHz (centre frequency

13.560 MHz)

Magnetic field limit

< 42dBµA/m (at 10 meters)

With this the Candy Hoover Group Srl, declares that this appliance marked with

complies with the essential requirements of the Directive 2014/53/EU. To receive a copy of the declaration of conformity, please contact the manufacturer at: www.candy-group.com

 hldsk

1300 769 522

customercare@hooverappliances.com.au

www.hooverappliances.com.au

. - 43011512 I

1300 769 522

customercare@hooverappliances.com.au

www.hooverappliances.com.au

- WDXOC - A (7+5) -

19.03 - 43020629.B - Canon Italia - Business Services Channel

Hoover WDXOC575AC-AUS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
