Hoover HEDS 988 User Manual
HEDS 988
1
This manual contains sections of Safety
Instructions,Operating Instructions,
Installation Instructions and Troubleshooting
Tips etc. Carefully reading it before using the
dishwasher will help you to use and maintain
the dishwasher properly.
To review the section on TroubleshootingTips
will help you to solve some common problems
by yourself and not need to ask for the help of
professional technicians.
..................1
ControlPanel........................2
DishwasherFeatures................. 2
WashCycleTable.................... 3
WaterSoftener...................... 4
Detergent...........................5
RinseAid......................... 5,6
Loading the Dishwasher Rack . . . . . . . . 6,7
TurningOntheAppliance..............7
FilteringSystem..................... 8
CaringfortheDishwasher.......... 9...
The manufacturer, following a policy of constant
development and up-dating of the product, may
make modifications without giving prior notice.
AboutElectricityconnection . . . . . . . . . .10
AbouttheUnicouple.................10
WaterConnection...................11
Dimensions........................11
Beforecallingforservice.......... 12,13
........................13Error codes
This appliance must be grounded. In the event
of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a
path of least resistance of electric current. This
appliance is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate
outlet that is installed and grounded in accordance
with all local codes and ordinances.
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service representative if you
are in doubt whether the appliance is
properly grounded. Do not modify the plug
provided with the appliance ;If it is not fit
for the outlet .have a proper outlet installed
by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic
items not so marked, check the manufactures
recommendations.
Use only detergent and rinse additives designed
for an automatic dishwasher. Never use soap ,
laundry detergent, or hand washing detergent
in your dishwasher. Keep these products out of
children.
Keep child away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
The door should not be left in the open position
since this could present a tripping hazards.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
The applianceis not intended for use by young
children or infirm persons without supervision.
Dishwasher detergents are strongly alkaline,they
can be extremely dangerous if swallowed.Avoid
contactwithskinandeyesandkeepchildrenaway
from the dishwasher when the door is open.
Do not operate your dishwasher unless all
enclosure panels are properly inplace. Open the
door very carefully if the dishwasher is operating,
there is a risk of water squirting out.
Do not place any heavy objects of stand on the door
when it is open. The appliance could tip forward.
When loading itemsto be washed:
1) Locate sharp items so thatthey are not likely to
damage the door seal;
2) Load sharp kniv es with the han dles up t o reduce
the riskof cut-type injuries.
When using your dishwasher, you should prevent
plasticitem from contacting with heating element.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Young children should be supervised to ensure that
they do not play with the appliance.
Check that the detergent receptable is empty after
completion of the wash cycle.
1
To get the best performance from your dishwasher,read all operating instructions before using it for the
first time keep this booklet safe for future reference.
7
4
2 3
1
1
.Power supply indicator light:comes on when the power
is turned on.
2
.Power Switch: turn on/off the power supply.
.Display Window: program remaining time, delay time, and
3
faut codes.
4
.Delayed Start Button: press this button to set the delayed
hoursfor washing.
5
.Rinse Aid indicator light: comes on when there is not enough
rinse agent .(Certain model only)
5 6
8 9
6
.No Salt Indicator Light: comes on when there is not enough
salt in thesoftener .(Certainmodel only)
7
.Program indicator light
8
.Program Button: pressed to choose desired program,
whose program indicator light will comeon.
9
.Start/Reset Button: press this button to start or stop the
machine.
Upper Basket
14
Spray Arms
2
3
Lower Basket
Water Softener
5
Detergent Dispenser
6
CupShelf
7
8
Silverware BasketMain Filter
9
Coarse Filter
2
11
Rinse Aid Dispenser
10
Drain pipe connector
11
Inletpipe connector
12
12
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
Pre-wash
Pre-wash (45℃)
Wash (70℃)
Rinse (75℃)
Drying
8/24 gr.
(EN 502 42)
For normall y soiled loads,
such as , plates,glasses
and lightly soiled pans.
standard daily cycle.
For lightly soiledloads,such
as plates,glasses,bowls and
lightly soiled pans.
Daily wash in only 1 hour.
Suitable for normal soiled dishes
that are to be washed straight
after a meal (max 6 plate settings).
For lightlysoiledloads,
such as glasses, crystal and
fine china.
pots
A shorter wash for lightly
soiledloads(max4platesettings).
Pre-wash
Wash (55℃)
Rinse (65℃)
Drying
Pre-wash
Wash (45℃)
Rinse (65℃)
Drying
Pre-wash (30℃)
Wash (70℃)
Rinse (65℃)
Drying
Wash (45℃)
Rinse (65℃)
Drying
Wash (50℃)
Rinse (55℃)
Drying
5/22 gr.
4/20 gr.
20 gr.
20 gr.
15 gr.
To rinse dishes that you
plan to wash later that day.
Draw out the lower and upper bask et, load the dishes and push them
1
back. Itis commended that loading the lower basket first, then the
upper one. The expensive and finer chinaware should not be put in.
With a little force to ensure the door is properly closed.
2
: asoundof click could beheard when thedoor is closed
Note
perfectly.
Insert the plug into the socket.
3
The power supply is 230V 50HZ, the specification of the socket is
250V 10A.
According to the soil level to choose the desired program by
4
pressing program selection button.
5
Press the ON/OFF button
6
Pressthisbuttontostartautomaticwashing.
Press the ON/OFF button at the end of washing. Open the door of
7
dishwasherafter waiting 30 minutes.
Pre-wa sh
Press the Start/Pause button to stop washing.
Press the programme button to select the
programme.
Press the Start/Pause button to start washing.
At end of washing, the time display will flash for 8
seconds while the buzzersound. But at the end of
delayed washing, no sound of the buzzer, only
the flash of the time display.
