V5015A
FLANGED LINEAR VALVE PN6
SPECIFICATION DATA
GENERAL
These single seated valves are used for modulating control of
hot / chilled water or steam in heating, ventilating and air
conditioning systems. The valves can be operated by linear
actuators M6421B and M7421B or by pneumatic actuators
MP953.
FEATURES
• Cast iron body with flanged end connections
• Low seat leakage rate
• Metal to metal seating for long life span
• Self adjusting packing
• Accurate positioning to ensure state-of-the-art
temperature control
• Easy mounting of direct coupled electric and
pneumatic actuators
• Constant total flow throughout full plug travel
SPECIFICATIONS
Action Stem up to close port A-AB
Nominal pressure rating PN6
Flow characteristic Equal percentage port A-AB,
n
linear port B-AB
Rangeability 50:1
Leakage rate ≤ 0.1% of k
≤ 1% of k
Stroke 38 mm
Valve body
End connections Flanged per ISO 7005-2
Material Cast iron (GG25)
Dimensions See Fig. 1
Trim
Seat Body integrated
Stem Stainless steel
Plug Stainless steel, skirt guided
Packing Spring-loaded PTFE cone rings
Medium temperature
and pressure
Maximum temperature
differential in alternating
hot/cold water use 60 K
= 3.4
gl
port A-AB
VS
port B-AB
VS
2 ... 120 °C; max. 600 kPa
EN0B-0431GE02 R0607
V5015A FLANGED LINEAR VALVE PN6
SIZES AND FLOW CAPACITIES
order number valve size kVS
V5015A1151 DN100 140
V5015A1169 DN125 220
V5015A1177 DN150 310
INSTALLATION
• Water should meet VDI 2035 requirements.
• Do not install valve with stem below the horizontal.
• Fluid flow must correspond with the arrow direction on the
valve body.
• The installation of a strainer is strongly recommended.
ACTUATORS
Electric Actuators
actuator (1800 N) valve size
M6421B
M7421B
Pneumatic Actuators
actuator
model size
MP953A 13" x yes
MP953C 13"
valve size
DN100 -
DN150
DN100 - DN150
direct
acting
REPAIR PACKING KIT
Part No.: R 43 176 754 - 005
CLOSE OFF PRESSURE RATINGS in kPa
Electric Actuators
actuator valve size
model force DN100
M6421B, M7421B 1800 N 150 120 80
Pneumatic Actuators
(kVS 140)
DN125
(kVS 220)
DN150
positioner
x no
(kVS 310)
actuator model
MP953C; (13“)
MP953A,C; (13“)
actuator spring
range
14-48 kPa
(2-7 PSI)
14-48 kPa
(2-7 PSI)
air pressure in
actuator
0 kPa
115 kPa
closed valve
seat
upper
lower
valve size
DN100 DN125 DN150
110
150
150
150
70
150
150
150
45
150
100
120
EN0B-0431GE02 R0607 2
V5015A FLANGED LINEAR VALVE PN6
DIMENSIONS (mm)
Electric Actuators
Valve
STROKE
170.5
227
B
C
A
WITH STEM
EXTENSION FOR
MP953A,C 13”
Fig. 1. V5015A
valve size A B C
DN100 350 100 150
DN125 400 120 175
DN150 480 140 200
Pneumatic Actuators
178x (178)
64
Two knock-outs
are provided for
cable fitting:
21.2 (PG13.5) /
22.8 (PG16),
18.9 (PG11)
430
326
301
204
H
E
F
0
50
100
G
MP953A,C
Fig. 2. MP953A,C
model ∅E F G H
MP953A; 13“ 343 327 - 200
MP953C; 13“ 343 - 255 200
Fig. 3. M6421B/M7421B
3 EN0B-0431GE02 R0607
V5015A FLANGED LINEAR VALVE PN6
Honeywell
Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route du Bois 37, Switzerland by its Authorized Representative:
Automation and Control Solutions
Honeywell GmbH
Böblinger Straße 17
D-71101 Schönaich
Phone: (49) 7031 63701
Fax: (49) 7031 637493
http://europe.hbc.honeywell.com
Subject to change without notice. Printed in Germany Manufacturing location certified to
EN0B-0431GE02 R0607
