Honeywell TS906 User Manual

HONEYWELL

REMOTE RAIN GAUGE

For Professional Weather Station TE923W

TS906

USER MANUAL

Table of Contents
Introduction 3
Standard Package Contents 3
Installation 3
Before you begin 3
Operation 6
Maintenance 7
Troubleshooting 8
PRECAUTIONS 8
Specifications 8
FCC STATEMENT 9
DECLARATION OF CONFORMITY 9

STANDARD WARRANTY INFORMATION 10

2

Introduction

Thank you for selecting the Honeywell remote rain gauge TS906.This product is a part of
the Professional Weather Station TE923W. It measures rainfall amount and transmits data
to a TE923WD (main display unit).
Note: In order to display the rainfall amount and related items, you must own a main
display unit (TE923WD) for the Professional Weather Station TE923W.
In this package you will find:
One Rain Gauge (remote rain sensor/transmitter) (TS906)
Mounting Hardware
One User Manual

Standard Package Contents

Picture Components

Rain Gauge consists of:

Funnel shaped top with battery

compartment

4 screws for securing rain gauge to the flat

surface

Rain Gauge bucket

Bucket see-saw mechanism

Protective screen

Mounting hardware

Installation

All data measured by the rain gauge is transmitted to the main unit wirelessly, with the
operating range up to 100 feet (30 meters) in the open area.
Remote rain gauge must be placed outdoors to measure precipitation.
Note: It is critical to power up and test communication between the remote rain gauge
and the main unit BEFORE permanently mounting it outside.

Before you begin

• We recommend using alkaline batteries for the remote rain gauge when

temperatures are above 32°F (0°C) and lithium batteries when temperatures are
below 32°F (0°C).

• Avoid using rechargeable batteries. (Rechargeable batteries cannot maintain

correct power requirements).

• Insert batteries before first use, matching the polarity in the battery compartment

• During an initial setup, place the main unit close to the remote rain gauge.

3
