OWNER’S MANUAL
QUICK HEAT™ CERAMIC HEATER
Model HZ-315, HZ-316, HZ-315C and HZ-316C
The Honeywell trademark is used by Kaz, Inc. under license from Honeywell Intellectual Properties, Inc.
SUPER
OFF
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surface.
If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids
and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater to authorized service facility for examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is rated at 1500W, 120 VAC. It is intended for use on tabletops, desktops
and floors. It is not to be used in wet or moist locations, such as bathrooms and laundry areas. If an extension cord must be used, it must be 14 gauge or larger and rated no less than 1875 watts.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or the
like. Arrange cord away from traffic areas where it will not be tripped over.
9. This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of shock, this plug is intended to fit only one way in a polarized outlet. If the plug does not fit securely in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT attempt to defeat this safety feature.
10. This heater draws 12.5 amps during operation. To prevent overloading a circuit, do
not plug the heater into a circuit that already has other appliances working.
11. It is normal for the plug to feel warm to the touch; however, a loose fit between the
AC outlet (receptacle) and plug may cause overheating and distortion of the plug. Contact a qualified electrician to replace loose or worn outlet.
12. To disconnect the heater, first turn controls to the OFF position, then grip the plug and
pull it from the wall outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as
this may cause an electric shock or fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not
use on soft surface, like a bed, where openings may become blocked.
15. A heater has hot and arcing or sparking parts inside. Do not use it in the areas where
gasoline, paint, or flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
17. The output of this heater may vary and its temperature may become intense enough to
IMPORTANT SAFETY INSTRUCTIONS
burn exposed skin. Use of this heater is not recommended for persons with reduced sensitivity to heat or an inability to react to avoid burns.
18.
SAVE THESE INSTRUCTIONS
SAFETY FEATURES
This heater is equipped with several devices and features for added protection.
• A high temperature safety control prevents overheating (HI limit).
• A back-up thermal circuit breaker.
• This heater is also equipped with a motor thermal fuse that will shut down the motor should it operate at a higher than normal temperature.
• This heater was created using a high quality safety plastic.
TROUBLESHOOTING
If your heater shuts off unexpectedly or fails to operate, one of the above-mentioned safety features may have been activated to prevent overheating.
Be sure the power cord is plugged into a working electrical outlet.
• Check your Thermostat setting. The unit may simply be off because you have reached your desired heat setting.
Check for any obstructions. If you find an obstruction, turn the heater OFF and unplug it.
Allow the heater to cool completely, then remove the obstruction. Wait at least 10 minutes, then re-plug in the heater and follow the OPERATING INSTRUCTIONS for your unit.
OPERATING INSTRUCTIONS
Your Honeywell®Quick Heat™ heater is designed to heat you warmer, faster!*
Plug in unit.
Turn the Thermostat fully clockwise to the SUPER setting (Fig. 1).
When the room reaches a comfortable temperature, slowly turn the Thermostat counter-clockwise until the heater goes off. This is the point at which the Thermostat setting equals the room temperature. At this setting, the Thermostat will automatically turn the heater on and off to maintain this selected temperature.
UNPLUG the unit to turn the power OFF. The plug light will go off.
Fig. 1
SUPER
OFF
CLEANING AND STORAGE
We recommend that the heater be cleaned at least once a month and before off-season storage.
Turn the heater OFF and unplug it. Allow it to cool.
Use a dry cloth only to clean the external surfaces of the heater.
DO NOT USE WATER, WAX, POLISH OR ANY CHEMICAL SOLUTION.
Clean your heater using the above - mentioned steps, then pack the heater in its
original container and store it in a cool, dry place.
This heater does not disassemble.
ELECTRICAL RATING
This product is rated 12.5 Amps (1500 Watts) at 120 VAC, 60 Hz.
TROUBLESHOOTING (continued)
NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE RETURN THE HEATER TO THE PLACE OF ORIGINAL PURCHASE OR SEE YOUR WARRANTY. DO NOT ATTEMPT TO OPEN THE HEATER YOURSELF. DOING SO MAY VOID YOUR WARRANTY AND CAUSE DAMAGE TO THE HEATER OR PERSONAL INJURY. IF YOU HAVE ANY QUESTIONS REGARDING THIS HEATER, PLEASE CALL OR WRITE:
Mail questions and comments to: Kaz Home Environment
Consumer Relations Department 250 Turnpike Road Southborough, MA 01772
Toll Free #: 1-800-332-1110 E-mail us at: consumerrelations@kaz.com
Please be sure to specify model number.
Visit our website at www.kaz.com
*Based on Honeywell test #SM-0102 Note: Product may differ slightly from illustrations.
5 YEAR LIMITED WARRANTY
©2003 Kaz, Inc. All rights reserved. P/N 035-00431-000, Rev 1 Artwork 043-50189-000
You should first read all instructions before attempting to use this product.
Register your product on-line at www.kaz.com or complete and return the Consumer Response Card within 7 days.
A. This 5 year limited warranty applies to
repair or replacement of product found to be defective in material or workmanship. This warranty does not apply to damage resulting from commercial, abusive, unreasonable use or supplemental damage. Defects that are the result of normal wear and tear will not be considered manufacturing defects under this warranty.
KAZ IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you also may have other rights which vary from jurisdiction to jurisdiction. This warranty applies only to the original purchaser of this product from the original date of purchase.
B. At its option, Kaz will repair or replace this product if it is found to be defective in material or workmanship. Defective product should be returned to the place of purchase in accordance with store policy. Thereafter, while within the warranty period defective product may be returned to Kaz.
C.
This warranty does not cover damage resulting from any unauthorized attempts to repair or from any use not in accordance with the instruction manual.
D. Return defective product to Kaz Home Environment with a brief description of the problem. Include proof of purchase and a $10 US/$15.50 CAN check or money order for handling, return packing and shipping charges. Please include your name, address and a daytime phone number. You must prepay shipping charges.
Send to:
In U.S.A:
Kaz Home Environment Attn: Returns Department 4755 Southpoint Drive Memphis, TN 38118 USA
In Canada:
Kaz Home Environment Attn: Returns Department 510 Bronte Street South Milton, ON L9T 2X6 Canada
