Honeywell HXMT9, HXMT9X User Manual
9-Channel
Black&White Multiplexer
HXMT9 / HXMT9X
Installation Manual
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION
GRILLS.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols
ENGLISH
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the product.
iii
Safety Precautions
Should any liquid or solid object fall into the cabinet, unplug the unit and
have it checked by qualified personnel before operating it any further.
Unplug the unit from the wall outlet if it is not going to be used for several
days or more. To disconnect the cord, pull it out by the plug. Never pull
the cord itself.
Allow adequate air circulation to prevent internal heat build-up. Do not
place the unit on soft surfaces (rugs, carpets, sofas, etc.) or near
materials (curtains, draperies) that may block the ventilation holes.
Height and vertical linearity controls located on the rear panel are for
special adjustments by qualified personnel only.
iv
IMPORTANT SAFEGUARDS
ENGLISH
1. READ INSTRUCTIONS –
operating the unit.
2. RETAIN INSTRUCTIONS
future reference.
3. CLEANING
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. ATTACHMENTS
manufacturer as they may result in the risk of fire, electric shock or injury.
5. WATER AND MOISTURE
bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
6. ACCESSORIES
or table. The unit or equipment may fall, causing serious injury and serious
damage to the equipment. Wall or shelf mounting should follow the
manufacturer’s instructions, and should use a mounting kit approved by the
manufacturer.
8. VENTILATION
are provided for ventilation, to ensure reliable operation of the video
equipment and to protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked by placing the
unit on a bed, sofa, rug or other similar surface. The unit should never be
placed near or over a radiator or heat register. The unit should not be placed
in a built-in installation such as a bookcase unless proper ventilation is
provided.
9. POWER SOURCES
power source indicated on the marking label. If you are not certain of the
type of power supply you have, consult your video equipment dealer or local
power company.
10. GROUNDING OR POLARIZATION – This unit may be equipped with a
polarized alternating-current line plug (a plug with one blade wider than the
other). This plug will fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the outlet, try reversing
the plug. If the plug still fails to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. If
your unit is equipped with a three-wire grounding-type plug (a plug having a
third grounding pin), this plug will only fit into a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the grounding-type plug.
– Unplug unit from the wall outlet before cleaning. Do not use
– Do not use attachments not approved by the
– Do not place unit or equipment on an unstable cart, stand
7. CARTS
be moved with care. Quick stops, excessive force and
uneven surfaces may cause the equipment and cart
combination to overturn.
– Slots and openings in the cabinet and the back or bottom
Read the safety and operating instructions before
– Retain the safety and operating instructions for
– Do not use unit near water; for example, near a
– Video equipment and cart combinations should
– The unit should be operated only from the type of
v
11. POWER CORDS
locate unit or equipment where the cord can be damaged by persons
walking on it.
12. HEED WARNINGS
13. LIGHTNING
unattended and unused for long periods, unplug the unit and associated
equipment from the wall outlet. This will prevent damage to the video
equipment caused by lightning and power-line surges.
14. OVERLOADING
can result in a risk of fire or electric shock.
15. OBJECT AND LIQUID ENTRY
unit through openings as they may touch dangerous voltage points or short
out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
16. SERVICING
covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
17. DAMAGE REQUIRING SERVICE
wall outlet and refer servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid has spilled, or objects have fallen into the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally when following the operating
instructions, adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualified technician to restore the unit to its normal operation.
E. If the unit has been dropped or the cabinet damaged.
F. When the unit exhibits a distinct change in performance, this indicates
a need for service.
18. REPLACEMENT PARTS
the service technician uses replacement parts specified by the
manufacturer or that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other
hazards.
19. SAFETY CHECK
ask the service technician to perform safety checks to determine that the
video product is in proper operating condition.
20. FIELD INSTALLATION
service person and should conform to all local codes.
– Do not allow anything to rest on the power cord. Do not
– Follow all instructions marked on the unit.
– During lightning storms or when the unit will be left
– Do not overload wall outlets and extension cords as this
– Never push objects of any kind into the
– Do not attempt to service the unit as opening or removing
– Unplug the unit and equipment from the
– When replacement parts are required, be sure
– Upon completion of any service or repairs to the unit,
– Installation should be performed by a qualified
vi
FCC COMPLIANCE STATEMENT
FCC INFORMATION : THIS EQUIPMENTHASBEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR ACLASS A DIGITAL DEVICE, PURSUANT TO PART
15 OFTHE FCCRULES. THESELIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES,
USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED
AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS
EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THEUSER WILL BEREQUIRED TO CORRECTTHE
INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY
THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME
NMB-003 DU CANADA.
ENGLISH
CE COMPLIANCE STATEMENT
WARNING : THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT
THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
vii
Table Of Contents Pages
Chapter 1 Introduction
Features 1
Technical Overview 3
Chapter 2 Installation
Required Tools 5
Connecting Cameras 5
Connecting Monitors 6
Connecting VCRs 6
Connection a Mouse 7
Daisy-Chaining and Remote Control Connections 7
Alarms and Other Connections 8
Initial Setup 8
Accessing the Main Menu 8
Main Menu Settings 10
Time, Date Setup 11
Camera Access Setup 13
Camera Title Setup 14
Camera Sequence Setup 15
Alarm Setup 16
Alarm I/O Setup 18
Alarm Action Setup (1) 19
Alarm Action Setup (2) 20
Associated Camera Setup 22
Motion Action Setup (1) 23
Motion Action Setup (2) 24
Video Loss Action Setup 25
Manual Alarm Action Setup (1) 27
Manual Alarm Action Setup (2) 29
Macro Link Setup 30
Alarm History 31
Motion Detection Setup 32
1
5
viii
Motion Detection Index Setup 33
Motion Detection Index List 34
Motion Detection Schedule Setup 35
Motion Detection Sensor Setup 36
Motion Detection Sensor Setup (Normal) 38
Testing Motion Detection Sensor Setup 39
Motion Detection Sensor Setup (Vector) 40
Playback & Recording Setup 40
VCR System Setup 41
Recording Index Setup 42
Camera Picture Adjustment 43
Macro Setup 45
Macro Record Setup 46
Macro Schedule Setup 47
Unit Setup 48
Password Setup 50
Assigning Passwords 51
ENGLISH
Chapter 3 Operation
Buttons and Their Functions 53
Menu Operation 56
Top Menu 56
Bottom Menu 56
Live Screen 57
Pop Up Menu 58
Live Camera Change 59
VCR Camera Change 60
Zoom 61
Full 62
Priority On 62
Histogram Equalizer 62
Panic Record On 63
Freeze On 63
Sequence 63
Utilities 64
ix
53
User Scrn Chg… 64
OSD Change… 66
Screen Protect… 67
Manual Alarm… 67
Alarm Reset 67
Spot Output… 68
Macro 68
User Change… 68
Alarm List… 69
Playback Format… 70
PB Picture Adjust… 70
Appendix A Troubleshooting
Appendix B Connector Pin Outs
Appendix C Remote Control
71
72
74
Remote Control for Daisychained Multiplexers 74
Remote Command Set 75
Functional remote commands 76
Appendix D Specifications
77
Operating Defaults 77
Factory Defaults 77
Video Format 80
Video Level 80
Main Output Display Formats (live and playback) 80
Resolution (pixels x lines) 80
Sampling Standard 81
Video Memory 81
Refresh Rate (fields/sec.) 81
Display Options 81
Motion Detection 82
VCR Playback 82
Alarm Operation 82
x
On-Screen Display (Main) 83
On-Screen Display (Spot) 83
Other Features (Internal) 83
Other Features (External Interface) 84
Remote Control 84
Rear Panel Connectors 84
Front Panel Controls 85
Power Requirements 85
Power Adapter 85
Dimensions 86
Weight 86
Operating Environment 86
ENGLISH
xi
List of Illustraions
Figure 1 — Typical multiplexer system configuration 1
Figure 2 — connections 5
Figure 3 — Connecting one VCR to the 6
Figure 4 — Connecting two VCRs to the 7
Figure 5 — Top menu bar 8
Figure 6 — Supervisor Password screen 9
Figure 7 — Main Menu screen 10
Figure 8 — Time, Date Setup, first screen 10
Figure 9 — Time, Date Setup, second screen 12
Figure 10 — Camera Access Setup screen 13
Figure 11 — Camera Title Setup screen 14
Figure 12 — Camera Sequence Setup screen 15
Figure 13 — Alarm Setup screen 16
Figure 14 — Alarm I/O Setup screen 18
Figure 15 — Alarm Action Setup (1) screen 19
Figure 16 — Alarm Action Setup (2) screen 20
Figure 17 — Associated Camera Setup submenu 22
Figure 18 — Motion Action Setup (1) screen 23
Figure 19 — Motion Action Setup (2) screen 24
Figure 20 — Video Loss Action Setup screen 25
Figure 21 — Manual Alarm Action Setup (1) screen 27
Figure 22 — Manual Alarm Action Setup (2) screen 29
Figure 23 — Macro Link Setup screen 30
Figure 24 — Alarm History List screen 31
Figure 25 — Motion Detection Setup screen 32
Figure 26 — Motion Detection Index Setup screen 33
Figure 27 — Motion Detection Index List screen 34
Figure 28 — Motion Detection Schedule Setup schedule 35
Figure 29 — Motion Detection Sensor Setup screen 36
Figure 30 — Motion Detection Sensor Setup (Normal) screen 38
Figure 31 — Motion Detection Sensor Setup test screen 39
Figure 32 — Playback & Recording Setup screen 40
multiplexer
multiplexer
multiplexer
xii
Figure 33 — VCR System Setup screen 41
—Figure 34 Recording Index Setup screen 42
Figure 35 — Camera Picture Adjustment screen 43
Figure 36 — Macro Setup screen 45
Figure 37 — Macro Recor Setup screen 46
Figure 38 — Live screen with M01 REC on the screen 47
Figure 39 — Macro Schedule Setup screen 47
Figure 40 — Unit Setup screen 48
Figure 41 — Passwords Setup screen 50
Figure 42 — Password entry screen 51
Figure 43 — Front Panel 53
Figure 44 — Top Menu 56
Figure 45 — Bottom Menu 56
Figure 46 — 3x3 Live Screen 57
Figure 47 — Pop Up menu 58
Figure 48 — Live Cam Change menu 59
Figure 49 — VCR Cam Change menu 60
Figure 50 — Zoom Screen 61
Figure 51 — Histogram Equalizer menu bar 62
Figure 52 — Sequence menu 63
Figure 53 — Utilities Pop Up menu 64
Figure 54 — User Screen Change menu bar 64
Figure 55 — Select a Screen menu 65
Figure 56 — OSD Setup screen 66
Figure 57 — Spot output change screen 68
Figure 58 — User Change menu 68
Figure 59 — Alarm History List 69
Figure 60 — Select Format menu 70
Figure 61 — Connetor Sub-Board 72
Figure 62 — RS-485 Connector 73
ENGLISH
Table 1 — Re-Address Commands 74
Table 2 — Front key emulation commands 75
Table 3 — Remote commands 76
xiii
xiv
Chapter 1
Introduction
< Figure 1 > Typical system configuration.multiplexer
ENGLISH
Features
• Compatible with standard Black&White cameras and other standard
Video sources
• Switchable between EIA and CCIR
• Able to decode tapes from many other brands of multiplexers
• Many user-selectable display formats, Cameras can be assigned to
any display format
• Multiple monitor outputs (1 Main, 4 Auxiliary) allow simultaneous
multi-camera and full-screen viewing
• Multilingual setup menus include English, French, Italian, German,
Polish and Spanish
• On-screen display includes date, time, alarm status, video loss,
camera number and 24-character camera titles
• Programmable day and night motion-detection schedules
1
• Each camera has a programmable 256-target (16 x 16) motion-
detection grid
• Programmable vector-based motion detection in any direction
• Nonvolatile program memory saves all user settings and protects
them against power outages
• One TTL/CMOS contact closure alarm for each camera
• Up to 4 cameras can be associated with a single contact closure
alarm
• Alarm input polarity is user selectable
• VCR switch pulse input for synchronization with VCRs having switch
pulse feature
• Full triplex operation allows simultaneous recording, playback and live
viewing
• 256-event alarm history log
• Linear Zoom in and out up to 32 times
2
Technical Overview
9 Camera Multiplexing with Motion Detection, Alarm Association and
Multilingual Setup Menus
The has revolutionary features not available in most
multiplexer
multiplexers. The has a sophisticated motion detection
system that can sense motion vectors in any direction. Motion detection
sensitivity can be adjusted and the user can set day and night motion
detection schedules. A motion tracking box gives visual indications for
easy setup.
The has composite BNC input and output for VCR. The
multiplexer
main monitor can be connected to either a composite BNC. There are
four BNC auxiliary outputs that can be used for “spot” monitors or as
sources of video for other devices.
The has a large selection of user selectable display formats.
multiplexer
It also has digital zooming from 1 to 32 times.
The multilingual menu options allow for easy setup. The
multiplexer
user’s configuration is stored in nonvolatile memory so that it will not be
lost during power outages.
The can play back videotapes recorded with many other
multiplexer
multiplexers. These include, but are not limited to; Dedicated Micros,
ULTRAK Legacy Color, ULTRAK Legacy B/W, Robot, Kalatel and Pelco.
Up to 9 multiplexers can be “daisy chained” and addressed and
controlled by a single control panel. The multiplexer can also be
addressed by a computer using either an RS-232 or RS-485 connection.
multiplexer
ENGLISH
3
4
Chapter 2
Installation
Required Tools
Although no special tools are required to install the multiplexer, it is only
one part of a complex system. Refer to the Installation manuals for the
other components in your particular installation for special tool
requirements.
Up to 9
Cameras
Up to 9
Sensors or
Contacts
ENGLISH
< Figure 2 > connections.multiplexer
Connecting Cameras
You can connect up to 9 cameras to the . Connect the
camera BNCs to the IN BNC connectors (top row). The loop-through
connectors (OUT) are auto-terminated, so terminating resisters are not
needed if you do not loop video out to another device.
NOTE : Connecting a cable to the loop-through connector switches off
the termination. Do NOT connect a cable to the loop-through BNC
connectors unless it is connected to the input of another video device.
multiplexer
5
Connecting Monitors
Your main monitor should be connected to the MAIN output.
Up to four auxiliary monitors can be connected to the multiplexer. You
can use these as spot monitors or to view live video while playing tapes
back through the main monitor. The auxiliary monitors should be
connected to the AUX BNC connectors.
Connecting VCRs
There are BNC connectors for the VCRs.
< Figure 3 > Connecting one VCR to the .multiplexer
6
< Figure 4 > Connecting two VCRs to the .multiplexer
You can connect one VCR to the multiplexer and use it for both
recording and playback. However, the can handle recording
and playback at the same time, so it is possible to connect two VCRs.
One VCR is used to record while the other is used to play back. (See
the illustrations.)
multiplexer
Connecting a Mouse
The multiplexer menus can be controlled by either buttons on the front
panel or by a mouse. If you plan to use a mouse, connect it to the miniDIN connector labeled MOUSE.
The multiplexer is not compatible with all mouse available in the market.
Please note that users are recommended to use "Recommended
mouse" only described in the manual.
Logitech mouse (Ball mouse only)
ENGLISH
NOTE : Compatible mouse can be added without prior notice for better
performance.
Daisy- Chaining and Remote Control Connections
The can be daisy-chained to other multiplexers or controlled
multiplexer
by a remote keyboard. To add another multiplexer to your system,
connect the RS-485 OUT connector of the additional unit to the IN RS485 connector. (See Setup Menu section to set multiplexer address.)
The remote keyboard should be connected to the OUT connector on the
multiplexer.
7
Alarms and Other Connections
The 50-pin ALARM IN/OUT connector has 9 alarm inputs, 9 alarm
outputs, RS-232 connectors, VCR trigger pulse and various alarm
settings. See Appendix B — Connector Pin Outs for further details on
how to make these connections.
Initial Setup
Setting up for EIA or CCIR Operation
NOTE : When changing the multiplexer to EIA or CCIR all other settings
are returned to the factory defaults.
The multiplexer can be used with either EIA or CCIR systems.
To set it up for EIA operation:
1) Turn off the power
2) Press and hold the and {M} buttons.
3) Turn on the power
To set up the multiplexer for CCIR operation:
1) Turn off the power
2) Press and hold the and buttons.
3) Turn on the power
Accessing the Main Menu
NOTE : To access the Main Menu you must have a Supervisor
Password. The last item of the Main Menu is the Password Setup.
Keep the passwords you create in a safe place. The new passwords will
be the only way to access certain features of the multiplexer once you
have changed from the factory default passwords.
< Figure 5 > Top menu bar.
8
To access the Main Menu of the setup screens, move the cursor to the
top of the screen. The top menu bar appears. Select Setup.
< Figure 6 > Supervisor Password screen.
Enter the password by moving the cursor over the desired number and
clicking on it. As you enter each digit, the circles beside “Supervisor
Password” fill in and move to the right. Once you have entered all four
digits, click on OK. If you have entered the correct four-digit number, the
Main Menu will appear. If you have entered an incorrect number,
Incorrect Password displays for ten seconds and then the unit returns to
a live display.
ENGLISH
The factory default passwords are listed in the Technical Specifications.
Click on Cancel to exit the Supervisor Password screen and return to live
display.
9
Main Menu Settings
< Figure 7 > Main Menu screen.
< Figure 8 > Time, Date Setup, first screen.
10
Time, Date Setup
In addition to setting the multiplexer’s time and date, these screens can
be used to set the format and select daylight saving time. You can use
the arrow buttons on the multiplexer or mouse to select the menu item.
Press SET or the left mouse button to decrease the number. Press ESC
or the right mouse button to increase the number.
ENGLISH
• Date format :
month and days are each two-digit numbers represented by MM and
DD. Years are four-digit numbers represented by YYYY. The U.S.
format is: MM-DD-YYYY. Europe’s format is: DD-MM-YYYY. Asia’s
format is: YYYY-MM-DD.
• Hour format :
hour (military) time. The second is AM/PM.
• Clock Source :
multiplexer is connected to a network, set the option to Network Clock
and the unit will receive the clock information from the master
multiplexer. If your multiplexer is not connected to a network, set the
option to Internal Clock.
• Year :
• Month :
• Date :
• Hour :
• Minute :
• Second :
Use the arrow or mouse buttons to change the year.
Use the arrow or mouse buttons to change the date.
Use the arrow or mouse buttons to change the hour.
There are three date formats to choose from. The
There are two hour formats to choose from. One is 24-
There are two choices for the clock source. If your
Use the arrow or mouse buttons to change the month.
Use the arrow or mouse buttons to change the minute.
Use the arrow or mouse buttons to change the second.
• Next > : Selecting this takes you to the second Daylight Saving
setup Screen.
11
< Figure 9 > Time, Date Setup, second screen.
• Daylight Saving :
If you are in an area that does not have Daylight
Saving (Summer) Time, set this option to Off. When you set this
selection to On, you must set the start and stop dates and times.
• Start :
Set the Month and Date that your area begins Daylight Saving
time. Unless there is an unusual situation, you will not need to set
From and To times.
• Stop :
Set the Month and Date that your area ends Daylight Saving
time. Unless there is there is an unusual situation, you will not need to
set From and To times.
• < Back :
Selecting this takes you back to the first Time, Date Setup
Screen.
• Exit :
Selecting this saves your settings and exits the Time, Date
Setup screens.
12
Camera Access Setup
< Figure 10 > Camera Access Setup screen.
The Camera Access Setup screen allows you to assign which cameras
different users will have access to and which cameras can be displayed
on the Spot (auxiliary) monitors. You can also designate whether a
camera can be recorded.
ENGLISH
•<<:
•<:
•>:
•>>:
•:
•O:
• Exit :
Goes to Camera 1
Goes back one camera
Goes forward one camera.
Goes to Camera 9
An next to an item activates the camera for that output.
An deactivates the camera.
Saves your changes and returns to the Main Menu.
O
13
Camera Title Setup
< Figure 11 > Camera Title Setup screen.
The Camera Title Setup screen allows you to enter titles for each
camera. Clicking on the letters and characters enters them in the
camera title. Each camera title can have a maximum of 24 characters.
•Top<:
• Top>:
• Middle << :
• Middle < :
• Middle > :
• Middle >> :
• Bottom < :
• Bottom > :
Moves the cursor left.
Moves the cursor right.
Goes to Camera 1.
Goes back one camera.
Goes forward one camera.
Goes to Camera 9.
Changes the keyboard characters to the previous set.
Changes the keyboard characters to the next set.
14
• Keyboard Character Set 1 :
A to Z (upper case)
ENGLISH
• Keyboard Character Set 2 :
• Keyboard Character Set 3 :
• Keyboard Character Set 4 :
• Keyboard Character Set 5 :
ЫЬЯабв
• Exit :
Saves your changes and returns to the Main Menu.
АБВДЗИЙКЛМНОПСТУФЦЩЪ
дзийклмнопстуфцщъыь• Keyboard Character Set 6 :
Camera Sequence Setup
a to z (lower case)
BLANK !"#$%&'()*+,-./0to9
:;<=>?[\]^_'{I}~
< Figure 12 > Camera Sequence Setup screen.
This screen allows you to set the order in which the cameras appear
when the multiplexer is in sequence mode. You can also set the how
long each camera will display from Off to 99 seconds.
15
Enter the camera number under the Camera column and the display
time under Dwell. You can also set the Stack Dwell Time, which is the
length of time each group of cameras will display.
Saves your changes and returns to the Main Menu.• Exit :
Alarm Setup
< Figure 13 > Alarm Setup screen.
The Alarm Setup screen allows you to enter six alarm submenus.
• Alarm Reset Button :
events using the front panel buttons or the Pop Up menu. Setting it to
Off requires the user to enter the Setup Menus to clear alarm events.
• Alarm Screen Format :
will use when an alarm occurs. There are four possible settings: Full,
2x2, 2x2 Associated and Unchanged.
Setting this to On allows users to clear alarm
This sets the display mode the multiplexer
16
Loading...
