Honeywell FS10-R Operating Manual

Installation Guide and Operating Manual

Multi-Spectral Digita l Infrared
Electro-Optical Fire Detector

Unitized, Two Stage, Quick Response
FSC Model Nos. FS10-R & FS10-RN with Wide Band IR

FS System 10

TM

Digital Fire Detection/Process Control System

OPERATOR MANUAL // NOTICES AND TRADEMARKS

Notices and Trademarks

Copyright 2014 by Honeywell International Inc.
While this information is presented in good faith and believed to be

accurate, Honeywell disclaims the implied warranties of
merchantability and fitness for a particular purpose and makes no
express warranties except as may be stated in its written
agreement with and for its customers.

In no event is Honeywell liable to anyone for any indirect, special or
consequential damages. The information and specifications in this
document are subject to change without notice.

The detector must be installed only by qualified professional
personnel in accordance with local codes.

The protection provided by the gas detector may be impaired if it is
used in a manner not specified by Honeywell Analytics.

ACCTTL, ALERT-1, ALARM-2, ALERT-1: ALARM 2 , ALERT-1:
ALARM-2, ATAG, Clean Room Sentry, COP-i, Complete Optical
Path Integrity, CM1, CM1-A, DartLogic, FireLogic, Honeywell
Analytics VSD-8 Honeywell Analytics VSD-8 Vis ual Smoke
Detection System, VSD-4, VSD-8, Fire Signature Analysis,
FireBusI, FireBusII, FirePic, FirePicII, FirePicIII, FirePix,
FirePicture, FSC, Honeywell Analy tics, Honeywell Analytics, FSX,
All FSX Nomenclature Variations (such as: FS2, FS2X, FS3,
FS3X, FS4, FS4X, FS5, FS5X, FS6, FS6X, FS7, FS7X, FS8,
FS8X, FS9, FS9X, FS10X, FS10X, FS11, FS11X, FS12, FS12X,
FS14, FS14X, FS15, FS15X, FS16, FS16X, FS17, FS17X FS18,
FS18X, FS19, FS19X, FS20, FS20X, FS24, FS24X, FS24XN,
FS26, FS26X, FS26XN), FS7-2173-2RP, FS System 7, FS System
10, FS7-2173, FS7-2173-RP, FS2000, FS System 2000, High
Speed Flame & Surveillance Detector, Multi-Spectrum QuadBand
Triple IR, Multi-Spectrum TriBand, Multi-Spectrum Tri-Band, Near
Band Infrared, Near Band IR, NearBand IR, QuadBand IR, Room
Sentry, RS, RS2, SM2, SM3, SS, SS2, SS2X, SS2-A, SS3, SS3-A,
SS3X, SS4, SS4-A, SS4X, SnapShot, SLR-BIT, SuperBus,
SuperSentry, System 2000, Tri-Mode Plot, QuadBand Triple IR
Plus, TriBand, Tri-Band, “FS & FSC triangle logo’s”, W BIR, Wide
Band Infrared, WideBand IR, Wide Band IRare registered
trademarks of Honeywell
International Inc.

HONEYWELL 2

OPERATOR MANUAL // NOTICES AND TRADEMARKS

Other brand or product names are trademarks of their
respective owners.

Honeywell Analytics

HONEYWELL 3

OPERATOR MANUAL // ABOUT THIS DOCUMENT

About This Document

Read and understand this manual before installing or
operating equipment.

No part of this document may be copied or reproduced without the
express written permission of Honeywell Analytics.

This manual is subject to change without notice.

HONEYWELL 4

OPERATOR MANUAL // SYMBOL DEFINITIONS

Symbol Definitions

The following table lists those symbols used in this document to
denote certain conditions.

Symbol Definition

ATTENTION: Identifies information that

requires special consideration.

TIP: Identifies advice or hints for the user,

often in terms of performing a task.

REFERENCE-EXTERNAL: Identifies an

additional source of information outside of
this booklet.

REFERENCE-INTERNAL: Identifies an

additional source of information within this
booklet.

Indicates a situation which, if not avoided,

may result in equipment or work (data) on
the system being damaged or lost, or may
result in the inability to properly operate the
process.

CAUTION: Indicates a potentially

hazardous situation which, if not avoided,
may result in minor or moderate injury. It
may also be used to alert against unsafe
practices.
CAUTION: Symbol on the equipment refers
the user to the product manual for
additional information. The symbol appears
next to required information in the manual.

HONEYWELL 5

OPERATOR MANUAL // TABLE OF CONTENTS

Table of Contents

Notices and Trademarks
About This Document

................................................................. 2

..................................................................... 4

Symbol Definitions ........................................................................ 5

Table of Contents .......................................................................... 6

SECTION 1: INTRODUCTION ........................................................ 8

1.1 Application ....................................................................................... 8

1.2 Responses ....................................................................................... 8

1.3 Input Power Requirements .............................................................. 8

1.4 FirePicTM .......................................................................................... 8

1.5 No Silicone Used ............................................................................. 9

1.6 FS10-R, -RN Unitized Flame Detectors .......................................... 9

1.6.1 Alert / Early Warning Relay Output ............................... 10

1.6.2 Alarm Relay Output ....................................................... 10

1.6.3 Fault Relay Output ......................................................... 10

1.6.4 Physical Description ...................................................... 11

1.6.5 Field of View .................................................................. 11

1.6.6 Environment Range ....................................................... 11

1.6.7 Location ......................................................................... 11

1.6.8 Self-Test ........................................................................ 11

1.6.9 Warranty ........................................................................ 11

SECTION 2: INSTALLATION ....................................................... 12

2.1 Detector Views .............................................................................. 12

2.2 Conduit Installation ........................................................................ 13

2.3 Power Supply Considerations ....................................................... 14

2.4 Mounting the Flame Detectors ...................................................... 14

SECTION 3: OPERATING MODES .............................................. 15

3.1 Normal Operation .......................................................................... 15

3.2 Alert / Fire Early Warning .............................................................. 15

3.3 Alarm Condition ............................................................................. 15

3.4 Fault Condition .............................................................................. 15

3.5 Automatic Detector Test ................................................................ 16

3.6 Manual Detector Test .................................................................... 16

3.7 Advanced System Diagnostics ...................................................... 16

SECTION 4: MAINTENANCE AND REPLACEMENT .................. 17

4.1 Detector Faults .............................................................................. 17

4.2 Cleaning Detectors Housing Windows .......................................... 17

4.3 Detector Module Replacement ...................................................... 18

SECTION 5: PINOUT DATA......................................................... 19

SECTION 6: ACCESSORIES ....................................................... 22

6.1 Detector Heavy Duty Swivel Mount (Part No. SM2) ...................... 22

6.2 Test Lamp (Part No. FS-846) ........................................................ 23

6.3 Disposable Protective Covers for Detectors (Part No. DPC-12) .. 23

6.4 Extension Pole for Disposable Covers (Part No. E X PL-1) ............ 23

6.5 Air Shield for Dirty Applications (Part No. DASA1-P) ................... 23

6.6 PC Interface Kit (Part No. FS10-IK) .............................................. 24

HONEYWELL 6

OPERATOR MANUAL // TABLE OF CONTENTS

Index ............................................................................................. 25

Limited Warranty ......................................................................... 26

Contact Honeywell Analytics ..................................................... 27

Americas ................................................................................................. 27

Europe ................................................................................................... 27

Asia Pacific .............................................................................................. 27

Internet
Telephone

................................................................................................... 27

................................................................................................ 27

HONEYWELL 7

OPERATOR MANUAL // SECTION 1: INTRODUCTION

SECTION 1: INTRODUCTION

1.1 Application

The Honeywell Analytics Models FS10-R (relay output) are
unitized (stand-alone) Flame Detectors designed specifically for
detecting and alarming to fires in electrostatic powder or paint spray
booths and paint spray lines in industrial and automotive
applications. These multi-spectral, digital, electro-optical, pat ent ed
Flame Detectors are housed in explosion proof enclosures and
feature automatic "through-the-lens" self-test. The Detectors may
be ordered with dry contact relays for interfacing to approved
control panels, and either latching or non-latching outputs. FS10-R
Detectors each contain a built-in controller and are unitized
versions of the proven, large installed base FS10 Flame Detectors
with Card Controllers and FS10 Flame Detectors with Wall­Mounted Controllers.

The FS10 line of Detectors is designed primarily for indoor
fire detection applications where combustible materials exist.
Typical applications include:

-Automotive Paint Lines -Aerosol Filling

-Paint Kitchens -General Finishing

-Curing Ovens -Paint Mixing Rooms

-Powder Coating Booths -Warehouse Storage

-Compressor Modules -Liquid Paint Spray Lines

-Diesel Generators -Internal Storage Tanks

1.2 Responses

The FS10-R type Detectors contain Alert / Fire Early Warning,
Fire Alarm and Fault signal relays. The Alert/Fire Early Warning

and Alarm relays are de-energized
during normal operation. If a fire occurs, a Fire Alarm is declared
in less than 5.0 seconds.

1.3 Input Power Requirements FS10-R

TM

: The total electrical input power requirement during
normal operation for the Flame Detector is 85 milli-Amps (0.085
Amps) at 24 Volt DC (+/-15%). The maximum current required
during Alarm is 120 milli-Amps.

, and the Fault relay is energized

1.4 FirePicTM

FirePic stores the sensor data of the last six fire events in the
Detector’s non-volatile digital memory. FirePic provides the

HONEYWELL 8

OPERATOR MANUAL // SECTION 1: INTRODUCTION

numerical spectral evidence to postulate the cause of a fire. The
Detector records the time and date for each FirePic. The FirePic
data includes a graphical display of the relative spectral intensities
versus time preceding and during the fire.

Note

: A PC computer is required to access FirePic.

1.5 No Silicone Used

NO

silicone based sealant or silicone greases are used in the

Flame Detector.

1.6 FS10-R, -RN Unitized Flame Detectors

The multi-spectral digital infrared Flame Detector, spanning the
Wide Band IRTM, Near Band IRTM, and Visible BandTM spectra, has
intelligent, smart computer processing to tell the difference between
a real fire and false alarm radiant energy sources. The Detector
simultaneously

examines these three spectral radiant energy bands

that are real-time signal processed by an on-board microprocess or .
The Detector is factory set for Alert / Fire Early Warning and Fire

Alarm detection range of 15 feet (FS10-R15, -RN15) and 30 feet
(FS10-R30, -RN30) to a one square foot Heptane reference pan
fire. The Alert response time is factory set to 0.3 second, the Fire
Early Warning response time is factory set to 1.0 second, and The
Fire Alarm response time is factory set to less than 5.0 seconds.
The Detectors are factory set for either latching (FS10-R15, -R30)
or non-latching (FS10-RN15, -RN30) as the standard setting.

The Alert / Fire Early Warning response is NOT available
with either the FS10-R45, or FS10-RN45 versions (45 foot
detection range).

The Detector features real-world time and date stamped “Event
History” files that are stored in non-volatile solid-state memory.

HONEYWELL 9

OPERATOR MANUAL // SECTION 1: INTRODUCTION

The Detector performs the following output functions (relay contact
closure or analog current source depending on model utilized):

• Indicates a Fault if trouble occurs.

• Energizes Alert / Fire Early Warning and Fire Alarm if a fire

occurs.

• Turns on the Detector’s LED to indicate Normal Operation, Fire

Alarm, or Fault conditions.

• Communicates externally to a PC desktop or laptop computer

through the built-in RS-485 communication channel, using the
optional “windows” PC Interface Kit (refer to Section 6.6).

1.6.1 Alert / Early Warning Relay Output

The Detector contains one Alert / Fire Early Warning relay with a
contact rating of 1 Amp @ 24 VDC. During Normal Operation the
relay is de-energized with open contacts

. When an Alert or Fire
Early Warning condition occurs, the relay is energized with closed
contacts.

1.6.2 Alarm Relay Output

The Detector contains one Fire Alarm relay with a contact rating of
1 Amp @ 24 VDC. The relay is de-energized with open contacts
during Normal Operation. During a Fire Alarm condition, the relay
is energized with closed contacts.

Note:

The Fire Relay may be ordered configured in a Latching or
Non-Latching mode. If Latching mode is configured, the Fire Relay
will remain energized until the Detector is reset (Powered down and
up). When Non-Latching is configured, the Fire Relay will reset
automatically after 5 seconds. This option is software configured
and must be set in the factory prior to shipment. The standard
factory setting is latching, if an RN version of the Detector is not
ordered.

1.6.3 Fault Relay Output

The Detector contains one Fault relay with a contact rating of 1
Amp @ 24 VDC. The relay is energized during Normal Operation
with closed contacts. When a Fault condition occurs, the relay is
de-energized with opened contacts. Examples of Fault conditions
include loss of power to the Detector or failure of the Self-Test
feature.

HONEYWELL 10

OPERATOR MANUAL // SECTION 1: INTRODUCTION

1.6.4 Physical Description

The Detector’s electronics and sensors are mounted inside a
module which is housed in a water-tight and explosion-proof
enclosure with the following ratings: Class I Div. 1, 2, Groups B, C,
D; Class II, Div. 1 & 2, Groups E, F, G and Class III; NEMA 3 & 4;
tamper-resistant with integral dual 3/4 inch NPT conduit openings;
copper-free aluminum (less than 0.4%) with a red powder-coated
epoxy finish and a reflector assembly. The Detector’s housing “O”
ring material is Dupont Viton that is not affected by paint solvents.
The Detector weighs approximately 3.5 pounds. For dimensions,
see Figures 1 and 2.

1.6.5 Field of View

The Detector’s field-of-view is ninety (90) degrees (+ 45 º horizontal
and vertical).

1.6.6 Environment Range

The Detector humidity range is 10% to 90% (RH), non-condensing.
The operating and storage temperature range of the Detector is –

40 oF to +185 oF (-40 oC to +85 oC).

1.6.7 Location

For proper installation, each Detector should be located within the
detection distance ordered from the factory (i.e., 15 feet for the
FS10-R15, -RN15, -A15, -AN15; 30 feet for the FS10-R30, -RN30, ­A30, -AN30, and 45 feet for the FS10-R45, -RN45, -A45, -AN45) of
the fire threat area and have a clear view of the area being
monitored.

1.6.8 Self-Test

The Detector activates an ACCTTLTM (Automatic Computer
Controlled Through The Lens Test) for checking the Detector’s
window lens for contamination. If the Detector’s lens needs
cleaning, the Detector’s LED blinks three times in a burst, every 10
seconds.

1.6.9 Warranty

Honeywell Analytics warrants the Flame Detector against any
defects in material and workmanship for a period of two (2) years
from shipment date.

HONEYWELL 11

OPERATOR MANUAL // SECTION 2: INSTALLATION

2.09

4.66

1.10

0.67

4.38

2.40

¾ NPT

1.50

SECTION 2: INSTALLATION

2.1 Detector Views

The Detector may be mounted directly on the wall, or with the
optional SM2 swivel mounting assembly or SM4 Stainless Steel
Swivel Mount (refer to Section 6.1 for details).

Figure 3: Fire Detector Housing - Side View

HONEYWELL 12

OPERATOR MANUAL // SECTION 2: INSTALLATION

Figure 4: Detector Housing - Rear View

BE SURE and DOUBLE CHECK that the external AC voltage
electrical power is TURNED OFF.
With OPTION 1S-GF-120: Connect 120 Volts AC LAST
With OPTION 1S-GF-240: Connect 240 Volts AC LAST

2.2 Conduit Installation

Detectors should be located to cover the specific “fire threat” areas.
When planning the conduit, observe the following
recommendations.

1. If only one of the two ¾ inch NPT conduit openings of the

Detector enclosure is used, appropriately seal the unused
opening with a threaded, tapered plug.

2. In areas where m oisture may accumulate, install an approved

conduit trap or drain.

HONEYWELL 13

OPERATOR MANUAL // SECTION 2: INSTALLATION

2.3 Power Supply Considerations

Note: Apply ONLY 24 Volt DC to the Detectors Electrical Input
Power Connections.

Refer to Section 1.3 for specific input power requirements and
Table 2 and 3 for the appropriate pin assignments for the FS10-R
and –RN Detector. Make certain the panel’s power supply can
handle the load current of the total number Detectors connected to
it. For example, if ten (10) Model FS10-R Detectors are used on
one panel’s power supply, the panel’s power supply must be able to
handle at least 1.20 Amps. This load current must also be
considered when calculating the panel requirements for 24-hour
backup.

2.4 Mounting the Flame Detectors

The Flame Detectors have the ability to see a one square foot
heptane pan fire at half of the Detector’s sensitivity off axis out to
45 degrees for a 90 degree Field-of-view (viewing angle). It is
recommended the Flame Detectors be positioned with the primary
fire threat location aimed in the center of the Detector’s Field-of­View. Since Flame Detectors must “see” the fire in order to detect
it, mount the Detectors in locations such as room corners and
ceilings to avoid line-of-sight blockage.

HONEYWELL 14

OPERATOR MANUAL // SECTION 3: OPERATING MODES

SECTION 3: OPERATING MODES

3.1 Normal Operation

Apply only EXTERNAL 24 volt DC regulated electrical power.
At this time, turn the external power ON and check that the Detector
is operating correctly. Verify during initialization that the red LED
continuously blinks ON for about 10 seconds and then blink once
every 10 seconds during Normal Operation.

In Normal Operation, the Detector is ready to detect fires, report
Faults, should any occur, and will have the red LED blinking ON
every 10 seconds. The Analog type Detector will indicate a 4 mA
output current during Normal Operation.

3.2 Alert / Fire Early Warning

During an Alert or Fire Early Warning condition, the Detector will:

• rapidly blink the red LED continuously.

• energize the Alert/Early Warning (energize the relay or indicate

a 12 mA output current).

• record FirePic in non-volatile memory.

• record the event in the Event History file in non-volatile memory.

3.3 Alarm Condition

During a Fire Alarm condition, the Detector will:

• turn ON the red LED continuously.

• Energize the Fire Alarm (energize the relay).

• record FirePic in non-volatile memory.

• record the event in the Event History file in non-volatile memory.

3.4 Fault Condition

During a Fault condition, the Detector will:

• blink the red LED as indicated in Table 1,

• indicate a fault (de-energize the Fault relay).

• record the event in the Event History file.

Faults generally occur for the following reasons:

• a problem has been encountered, such as a dirty Detector

window.

• failure in the wiring such as a severed cable, loose terminations.

• the Detector’s internal self-checking reported a hardware failure.

• power loss at the Detector.

HONEYWELL 15

OPERATOR MANUAL // SECTION 3: OPERATING MODES

Note

: The Fault condition is self-resetting; i.e. if the action causing

the Fault is remedied, then the Detector will stop reporting a
Fault.

3.5 Automatic Detector Test

The Detector performs ACCTTL (Automatic Computer Controlled
Through the Lens) tests every 10 minutes (factory set) to check the
operation of the Flame Detector. During a fault condition, the
Detector will blink the green LED as defined in Table 1 “Detector
Fault Codes”. If the Flame Detector detects an inadequate signal
reflected back through the viewing window; this may indicate a
Detector dirty window lens, which requires cleaning, or a missing or
dirty reflector lens guard, such as the Detector’s front cover is not
installed.

Note

: While ACCTTL tests are occurring, the system is still

functional and able to alarm to a fire.

3.6 Manual Detector Test

WARNING: Responses to the FS10-R Detector relay output
must be isolated mechanically (not solely by programming the
control panel using software or firmware). This will avoid
external alarms and/or suppression discharge when
performing the following manual Detector test with a Portable
Test Lamp, such as the Honeywell Analytics Model FS-846-B.

Test the system “end-to-end” by activating each Detector
separately.

Note

: It is recommended that the Honeywell Analytics Model FS-

846-B Portable Test Lamp is used to activate the Detectors
individually.

3.7 Advanced System Diagnostics

The Detector’s FireBusTM connections allow interfacing to a desktop
or laptop PC computer, which requires the optional PC “Windows”
Interface Kit (Refer to Section 6.6, PC Interface Kit).

HONEYWELL 16

OPERATOR MANUAL // SECTION 4: MAINTENANCE AND REPLACEMENT

Event

Action

SECTION 4: MAINTENANCE AND REPLACEMENT

4.1 Detector Faults

WARNING: Serious injury or death may result if personnel fail
to observe safety precautions.

If a Detector Fault is observed, the Detector will blink ON the
internal red LED every 10 seconds with one of the following Fault
Codes. Should remedial action fail to clear a Fault condition,
contact FSC Customer Service.

History File

Fault CONDITION (1)
No LED illumination

Fault CONDITION (3)
LED blinks 3 times

Fault CONDITION (5)
LED blinks 5 times

Fault CONDITION (4)
LED blinks 4 times

Fault CONDITION (6)
LED blinks 6 times

Table 1: Detector and Detector Faults

No power is available at the Detect or . Check
wiring for broken or crimped cables or l oose
terminations.

Flame Detector “through the lens” test failure.
Clean the lens and grill. It is import ant to clean
underneath the grill. See Section 3. 5.

Flame Detector temperature ratings have been
exceeded. This should clear when the unit is
brought back to a standard environm ent.

Internal Detector Fault, such as a broken relay coil.
If this persists, return the entire Detec tor to
Honeywell Analytics for service. See Section 4.3.

Internal Detector Fault, such as a memory failure.
If this persists, return the entire Detec tor to
Honeywell Analytics for service. See Section 4.3.

4.2 Cleaning Detectors Housing Windows

Clean the Detector’s windows and grills immediately; after handling
and installation, on a regular or periodic schedule, and whenever a
Fault occurs for which that is the recommended action. Use an air

HONEYWELL 17

OPERATOR MANUAL // SECTION 4: MAINTENANCE AND REPLACEMENT

blast and/or a clean cloth to clean the Detector’s windows. Utilize
Honeywell Analytics’ Disposable Protect ive Covers, Par t No. DPC­12, to keep the window lens and self-test grill clean.

4.3 Detector Module Replacement

To replace an improperly operating Flame Detector Module, do the
following:

1. Loosen the hex nut t hat s ecures the top windowed cover to the

Detector housing base.

2. Next, tur n the Detector top cover counter-clockwise until the top

cover is removed.

3. Using a screwdriver, tur n t he three captive screws counter-

clockwise, that secures the black Flame Detector Module to the
housing base, until the Module is free.

4. Gently lift the Flame Det ec t or Module out of the housing base;

take care not to touch the sensor windows.

5. Using a small screwdri v er , turn the two clamp screws counter-

clockwise, that secures the ten wire cable plug, so the plug may
be removed.

6. Handle the Flame Detec t or Module with care and do not touch

the sensor windows.

7. Carefully wr ap t he Module in static protection material (if none

available, use aluminum foil) and ship to Honeywell Analytics.

8. To install a Detect or Module, just reverse the removal steps

listed above.

THERE ARE NO USER SERVICEABLE PARTS IN A
DETECTOR’s MODULE. ANY EVIDENCE OF TAMPERING,
PRYING OPENING DETECTOR MODULE OR ATTE MPTED
REPAIRS OF ANY KIND BY NON-FACTORY PERSONNEL WILL
VOID ALL WARRANTIES

To return a Detector; it must be packaged in static protective
material. If this material is not available, carefully wrap the Detector
and harness within aluminum foil. Before shipping the Detector
back to the factory, contact Honeywell Analytics Customer Ser vice
for a required Return Material Authorization (RMA) for all returns.

HONEYWELL 18

OPERATOR MANUAL // SECTION 5: PINOUT DATA

SECTION 5: PINOUT DATA

PIN

1 DCRtn (Not Chassis Ground)
2 Data “A” (RS-485 COMM A)
3 Data “B” (RS-485 COMM B)
4 DC (+) Voltage
5

6

7 Alarm Relay Contact A (Normally OPEN)
8 Alarm Relay Contact B (Normally OPEN)
9

10

Fault Relay Contact A (Normally
energized CLOSED)

Fault Relay Contact B (Normally
energized CLOSED)

Alert / Early Warning Relay Contact A
(Normally OPEN)

Alert / Early Warning Relay Contact B
(Normally OPEN)

Description

Table 2: Flame Detector Connector Pin-outs for FS10-R type Detectors

J1 Connector: FIRE DETECTOR Module

HONEYWELL 19

OPERATOR MANUAL // SECTION 5: PINOUT DATA

PIN

1

2

3

4

5

6

7

8

9

Description

DCRtn (Not Chassis Ground)
Data “A” (RS-485 COMM A)
Data “B” (RS-485 COMM B)
DC (+) Voltage
Fault Relay Contact A

(Normally energized CLOSED)
Fault Relay Contact B

(Normally energized CLOSED)
Alarm Relay Contact A

(Normally OPEN)
Alarm Relay Contact B

(Normally OPEN)
Not used

10

Table 3: Flame Detector Connector Pin-outs for FS10-R45 type D etectors

Not Used

DO NOT CONNECT SHIELD AT THE FLAME DETECTOR.

Note: COMM as it is used in this document is an abbreviation

for Communications.

Detector relays are shown as they are during Normal

Operation, that is, there are no Fire Alarm conditions
or Faults.

HONEYWELL 20

OPERATOR MANUAL // SECTION 5: PINOUT DATA

1 2 3 4 5 6 7 8 9 10

Figure 3: FS10-R, Detector Module, Connector Rear View

HONEYWELL 21

OPERATOR MANUAL // SECTION 6: ACCESSORIES

4.86

4.26

2.95

2.00

0.295
Dia.

4.7”
approx.

SECTION 6: ACCESSORIES

6.1 Detector Heavy Duty Swivel Mount (Part No. SM2)

Figure 4: Detector Swivel Mount

Figure 5: Model SM4 Stainless Steel Swivel Mount

HONEYWELL 22

OPERATOR MANUAL // SECTION 6: ACCESSORIES

6.2 Test Lamp (Part No. FS-846-B)

This portable, hand-held test lamp is battery-powered for remote
activation of the FS System 10 Flame Detectors. This device
allows the entire Fire Protection System to be tested during start-up
or routine maintenance. This test lamp simulates the radiant
energy emitted by an actual fire in order to test the Detectors
without the need for an open flame. Eight “D” sized replaceable
flashlight batteries are required to power the Test Lamp.

Note

: Refer to the SYSTEM TEST WARNING of Section 3.6.

6.3 Disposable Protective Covers for Detectors (Part No. DPC-12)

Honeywell Analytics’ Flame Detectors, with their unique wide
spectral bands, can “see through” factory supplied Disposable
Protective Covers with no reduction in Detector performance (for
end-users with a planned maintenance schedule). Should debris
collect, these specifically designed protective covers may be easily
replaced. The task of cleaning the Detector viewing windows for
proper operation is eliminated

, thus reducing maintenance
requirements. A regularly scheduled maintenance plan can
virtually eliminate the need to interrupt a production process in
order to clean a Detector’s dirty viewing window. Each package
contains twelve (12) Protective Covers.

6.4 Extension Pole for Disposable Covers (Part No. EXPL-1)

This extension is used to install or remove the FS System 10
Disposable Protective Covers in hard-to-reach areas. The pole
extends in three sections to a length of 11.0 feet.

6.5 Air Shield for Dirty Applications (Part No. DASA1-P)

The Detector Air Shield mounts to the Flame Detector housing for
installation in areas with high levels of airborne contaminants. The
Air line fitting accepts ¼” O.D. nylon tubing for an instrument grade
air supply of 5 to 15 psi @ 6 cubic ft. per minute.

HONEYWELL 23

OPERATOR MANUAL // SECTION 6: ACCESSORIES

6.6 PC Interface Kit (Part No. FS10-IK)

The PC Interface Kit electronically converts the Detector’s RS-485
digital output (FireBus) signal into a standard RS-232 signal for
interfacing to an IBM type PC computer. This optional

interface Kit
allows access to post event analysis (FirePic), as well as
monitoring the Detector’s operation (SnapShot). Post event
analysis includes the Detector’s time and date stamp of ALERT,
ALARM and FAULT histories (Event History).

The PC Interface Kit includes; a self-powered (internal
rechargeable battery) terminal box with two connecting cables, a
120 VAC wall transformer for recharging the battery, and User PC
software.

Note : The PC Interface Kit may also be used with a Detector that is
powered by an external 24 VDC source (a complete user
instruction is included with the Interface Kit).

HONEYWELL 24

OPERATOR MANUAL // INDEX

Index

Controller Fault ....................... 17

Detector

Cable ................................... 19

Cleaning .............................. 17

Input Power

Milliamps ................................ 8

Test Lamp ............................... 23

Through the Lens Fault ........... 17

HONEYWELL 25

OPERATOR MANUAL // LIMITED WARRANTY

Honeywell Analytics warrants its Product s against defects in material and workmanship un der normal

Limited Warranty

use and service for a period of two (2) years from the date of shipment as described herein. Honeywell
Analytics, at its option, will repair or replace, at no charge, such products found to be defectiv e during
the warranty period provided that they are returned in accordance with the terms of this wa rranty.
Replaced parts or boards are warranted for t he balance of the original applicable warranty peri od. All
Replaced parts of Products shall become the property of Honeywell Analytics. This express limited
warranty is extended by Honeywell Analyti cs to the original purchaser only and is not assignable or
transferable to any other party. This is the complete warranty for the Products manufactured by
Honeywell Analytics. Honeywell Analyti cs assumes no obligations or liability for additions or
modifications to this warranty unless made i n writing and signed by an officer of Honeywell A nalytics.
Honeywell Analytics does not warrant the i nst all ation, maintenance or service of its Products. Honeywell
Analytics is not responsible in any way for ancillary equipment not furnished by Honeywell Anal ytics,
which is attached to or used in connection with its Product(s), or for operation of the Product (s) with
ancillary equipment and all such equipment if expressly excluded from this warranty. This war ranty sets
forth the full extent of Honeywell Analytics’ responsibility regarding the Products’ repai r or replacement
at Honeywell Analytics’ options, is the exclusive remedy.

This Warranty is given in lieu of all other Expres s Warranties, Implied Warranties, including without
limitation, Implied Warranties of Merchantability and fitness for a particular purpo se, are li m i ted to the
duration of this Limited Warranty. In no other ev ent shall Honeywell Analytics be liable for dama ges i n
excess of the purchased price of the product(s ), for any loss of use, loss of time, inconvenienc e,
commercial loss, lost profits or savings or ot her incidental, special or consequential damage s arising out
of or in connection with the use or inability t o use su ch product, to the full extent such may be
disclaimed by law.

THIS WARRANTY DOES NOT COVER:

1. Defects or damage resulting from use of the P roduct(s) in other than its normal and customary
manner.

2. Defects or damage from misuse, accident, or neglect.

3. Defects or damage from improper testing, operation, maintenance, installation, alt erat i on,
modification or adjustment.

4. Product(s) subject to unauthorized Product modifications, disassemblies or repair s (including, without
limitation, the audition of the product of non-Honeywell Analytics supplied equipment) which
adversely affect performance of the Product(s ) to interfere with Honeywell Analytics’ norm al war rant y
inspection and testing of the Product(s) to verify any warranty claim.

5. Product(s) that have had the serial number removed or made illegible.

6. Freight cost to the repair facility.

7. A Product which due to illegal or unauthorized alteration of the software/firmware in the Product, does
not function in accordance with Honeywell Analytics’ specifications.

8. Scratches or other cosmetic damage to Product surfaces that do not affect the operation of the
Product.

9. Normal and customary wear and tear.

Laws in the United States and other countries preserve for Honeywell Analytics certain exclu sive rights
for copyrighted Honeywell Analytics software/firmware, such as the exclusive rights to reproduce in
copies and distribute copies of such Honeywell A nal ytics software/firmware. Honeywell Anal ytics
software/firmware may be used only in the Product(s) in which the software/firmware was originally
embodied and such software/firmware in suc h Product(s) may not be replaced, copied, distributed,
modified in any way, or used to produce any derivative thereof. No other use including, without
limitation, alteration, modification, repr oduction, distribution, or reverse engineeri ng of such Honeywell
Analytics software/firmware or exercise or rights in such Honeywell Analytics software/firmware is
permitted. No license is granted by implication, estoppel or otherwise under Honeywell Analytics patent
rights or copyrights.

HONEYWELL 26

OPERATOR MANUAL // CONTACT HONEYWELL ANALYTICS

Honeywell Organization

URL

Organization

Phone Number

Contact Honeywell Analytics

Americas

Honeywell Analytics Inc.
405 Barclay Blvd.
Lincolnshire, Illinois
USA 60069
Email: [e-mail]

Europe

Life Safety Distribution AG
Javastrasse 2
8604 Hegnau
Switzerland
Email: [e-mail]

Asia Pacific

Honeywell Analytics Asia Pacific Co., Ltd.
#701 Kolon Science Valley (1)
43 Digital-Ro 34-Gil, Guro-Gu
Seoul, 152-729
Korea
Email: [e-mail]

Internet

Telephone

These Honeywell websites may be of interest to Industry Solution customers.

Corporate www.honeywell.com
Honeywell Analytics www.honeywellanalytics.com

Contact us by telephone at these numbers.

Americas Honeywell Analytics Inc.

Europe

Asia Pacific

Life Safety Distribution AG

Honeywell Analytics Asia Pacific Co., Ltd.

1-800-538-0363
1-800-321-6320

{32-2} 728-2711

[phone]
VOIP: [phone]

HONEYWELL 27

© 2014 Honeywell International Inc.

1998M0950

Revision A

July 2014
