Honeywell 7900BUP, 7900LUP, 7900LU0, 7900BU0 User Guide

Dolphin® 7900 Series
Mobile Computer
Microsoft® Windows Mobile™ 2003
Second Edition Software for Pocket PCs
User’s Guide-
Prelim. Rev (c)
4/11/05
Disclaimer
Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Hand Held Products to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Hand Held Products.
Hand Held Products shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hand Held Products.
© 2005 Hand Held Products, Inc. All rights reserved. Web Address: www.handheld.com
Trademarks
Dolphin, HomeBase, Mobile Base, and QuadCharger are trademarks or registered trademarks of Hand Held Products, Inc. Windows Mobile, Windows, Windows NT, Windows 2000, Windows ME, Windows XP, ActiveSync, Outlook, and the Windows
logo are trademarks or registered trademarks of Microsoft Corporation. Intel is a registered trademark of Intel Corporation. Chapter 9 (pages 9-1–9-11) contains copyrighted information from SyChip, Inc. Chapter 9 (pages 9-12–9-39) contains copyrighted information from Meetinghouse Corporation. Meetinghouse, the
Meetinghouse logo, and all other Meetinghouse trademarks/service marks contained herein are trademarks or registered trademarks of Meetinghouse.
Chapter 10 is copyrighted information used by permission from Bluetooth SIG, Inc. The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Hand Held Products.
Chapter 11 contains information with permission from INTRYNSIC Software, Inc. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and
are hereby acknowledged.
Table of Contents
Chapter 1 - Introduction
Ergonomics...................................................................................................................................1-1
Rugged Design ............................................................................................................................. 1-1
Mobile Computing Features......................................................................................................... 1-1
Additional Features....................................................................................................................... 1-1
Application Development Tools...................................................................................................1-1
This User’s Guide.........................................................................................................................1-1
Required Safety Labels.......................................................................................................................1-2
Location........................................................................................................................................ 1-2
Laser Safety Label........................................................................................................................ 1-2
Regulatory and Safety Approvals for all Dolphin 7900 Series Terminals
Dolphin 7900 Series WLAN (802.11b) or WPAN (Bluetooth) Radio......................................... 1-4
Dolphin 7900 Series WWAN Radio - GSM MC-45 & MC-46...................................................1-5
FCC Compliance.................................................................................................................................1-6
Dolphin 7900 Series Batch Terminal ........................................................................................... 1-6
Dolphin 7900 Series RF Terminal with an 802.11b, Bluetooth, and/or
GSM MC-45 or MC-46 Radio...................................................................................................... 1-6
Canadian Compliance for Dolphin 7900 Series RF Terminals with an 802.11b, Bluetooth,
and/or GSM MC-45 or MC-46 Radio .......................................................................................... 1-6
RF, Regulatory, and Safety Agency Approvals for 802.11b and Bluetooth ...............................1-7
RF, Regulatory, and Safety Agency Approvals for GSM MC-45 ............................................... 1-7
RF, Regulatory, and Safety Agency Approvals for GSM MC-46................................................ 1-7
Dolphin 7900 Series 802.11b, Bluetooth, and/or GSM MC-45 or MC-46
R&TTE Compliance Statement....................................................................................................1-7
Pacemakers, Hearing Aids and Other Electrically Powered Devices ..........................................1-7
Microwaves .................................................................................................................................. 1-8
Care and Cleaning of the Dolphin Terminal.......................................................................................1-8
.........................................1-3
Chapter 2 - Getting Started
Overview............................................................................................................................................. 2-1
Dolphin 7900 Radio Configuration Options....................................................................................... 2-2
Standard Configurations............................................................................................................... 2-2
Custom Configurations.................................................................................................................2-2
Dolphin 7900 Series Peripherals.........................................................................................................2-3
Dolphin 7900 Accessories................................................................................................................... 2-4
Using the Dolphin 7900 for the First Time.........................................................................................2-5
Charging with Dolphin Peripherals.............................................................................................. 2-7
Resetting the Terminal...................................................................................................................... 2-11
Soft Reset (Warm Boot).............................................................................................................2-11
Hard Reset (Cold Boot).............................................................................................................. 2-11
Suspend Mode...................................................................................................................................2-11
Chapter 3 - Hardware Overview
System Features ..................................................................................................................................3-1
Front Panel Features............................................................................................................................ 3-2
Back Panel Features............................................................................................................................ 3-4
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 iii
Side Panel Features..............................................................................................................................3-6
Opening the Access Door .............................................................................................................3-6
Replacing the Access Door...........................................................................................................3-8
Bottom Panel Features.........................................................................................................................3-9
Mechanical Connector ..................................................................................................................3-9
Battery Power ....................................................................................................................................3-10
Main Battery Pack.......................................................................................................................3-10
Internal Backup Battery ..............................................................................................................3-10
Managing Battery Power ............................................................................................................3-11
Default Low and Critical Battery Points.....................................................................................3-11
Checking Battery Power .............................................................................................................3-12
Guidelines for Battery Use and Disposal....................................................................................3-12
Dolphin 7900 Technical Specifications.............................................................................................3-13
Chapter 4 - Using the Dolphin 7900 Terminal
Overview .............................................................................................................................................4-1
Today Screen.......................................................................................................................................4-2
Navigation Bar.....................................................................................................................................4-2
Selecting Programs..............................................................................................................................4-3
Pop-Up Menus.....................................................................................................................................4-3
Adjusting the Backlight.......................................................................................................................4-4
Communication Options......................................................................................................................4-5
Radio Options......................................................................................................................................4-6
Radio Combinations......................................................................................................................4-6
Radio Manager..............................................................................................................................4-6
Using the Soft Input Panel (SIP) .........................................................................................................4-8
Writing on the Screen........................................................................................................................4-10
Drawing on the Screen ......................................................................................................................4-10
Status Icons........................................................................................................................................4-11
Notifications ......................................................................................................................................4-11
Finding and Organizing Information.................................................................................................4-12
Chapter 5 - Using the Image Engine
Overview .............................................................................................................................................5-1
Image Engine Options .........................................................................................................................5-1
Bar Code Symbologies Supported.......................................................................................................5-2
Activating the Engine..........................................................................................................................5-3
Decoding..............................................................................................................................................5-3
Omni-Directional Scanning Position Options...............................................................................5-4
Capturing Images.................................................................................................................................5-5
Chapter 6 - Using the Keyboards
Overview .............................................................................................................................................6-1
Using the Function Keys .....................................................................................................................6-1
Using the Navigation Keys..................................................................................................................6-2
Using the Modifier Keys .....................................................................................................................6-3
iv Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
25-Key Numeric Keyboard .................................................................................................................6-4
Alpha Mode...................................................................................................................................6-4
Caps Lock Key in Alpha Mode.....................................................................................................6-4
Blue Key Combinations................................................................................................................6-5
Red Key Combinations.................................................................................................................6-5
36-Key Alpha Keyboard......................................................................................................................6-7
NUM Lock Key ............................................................................................................................6-7
Caps Lock Functionality...............................................................................................................6-7
Blue Key Combinations ...............................................................................................................6-8
Red Key Combinations ................................................................................................................6-8
NUM Key Combinations ..............................................................................................................6-8
Numeric Shift in Numeric Mode ..................................................................................................6-9
Chapter 7 - Settings
Overview .............................................................................................................................................7-1
Personal Tab ........................................................................................................................................7-2
Buttons ..........................................................................................................................................7-3
Headset Control.............................................................................................................................7-5
Adding a Program to the Start Menu ............................................................................................7-6
System Tab ..........................................................................................................................................7-8
About.............................................................................................................................................7-8
Backlight.......................................................................................................................................7-8
Certificates ....................................................................................................................................7-9
ClearType Tuner ...........................................................................................................................7-9
Clock & Alarms ............................................................................................................................7-9
CPU Speed....................................................................................................................................7-9
Memory.......................................................................................................................................7-10
Power ..........................................................................................................................................7-13
Regional Settings ........................................................................................................................7-14
Remove Programs.......................................................................................................................7-15
Screen..........................................................................................................................................7-16
Connections Tab................................................................................................................................7-19
Server-Assigned IP Addresses....................................................................................................7-19
Zero-Config Wi-Fi......................................................................................................................7-19
Com Port Assignment Table.......................................................................................................7-20
Opening the Connections Manager.............................................................................................7-20
Creating an External Modem Connection to an ISP...................................................................7-21
Creating an External Modem Connection to Your Work ...........................................................7-25
Establishing Dialing Rules..........................................................................................................7-30
Creating a Wireless Network Connection...................................................................................7-31
Network Cards ............................................................................................................................7-32
Chapter 8 - Communications
Overview .............................................................................................................................................8-1
Help on Connecting ......................................................................................................................8-1
Installing Additional Software......................................................................................................8-1
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 v
Using ActiveSync................................................................................................................................8-2
Synchronizing from Your Desktop Computer..............................................................................8-2
Synchronizing from the Terminal.................................................................................................8-3
Exploring the Terminal from the Desktop Computer...................................................................8-3
Adding Programs to the Terminal Using ActiveSync ..................................................................8-4
Using Infrared......................................................................................................................................8-5
Verify That the IrDA Port is Enabled...........................................................................................8-5
IrDA Port Location on the Terminal.............................................................................................8-5
Troubleshooting ............................................................................................................................8-7
Using an ISP........................................................................................................................................8-8
Chapter 9 - Wireless LAN Communications with 802.11b
Overview .............................................................................................................................................9-1
Enabling the 802.11b Radio Driver ..............................................................................................9-1
Configuration Utilities ..................................................................................................................9-1
802.11b Settings ..................................................................................................................................9-2
Icons..............................................................................................................................................9-2
Status Tab......................................................................................................................................9-3
Config Tab ....................................................................................................................................9-5
Advanced Tab ...............................................................................................................................9-9
About Tab ...................................................................................................................................9-10
Using the Status Icon .................................................................................................................9-11
802.11b Wireless Security Supplement.............................................................................................9-12
Required Network Configuration Information Worksheets........................................................9-12
Opening the Client ......................................................................................................................9-16
Main Screen ................................................................................................................................9-17
Configuring the Client ................................................................................................................9-20
Logging.......................................................................................................................................9-31
Installing Certificates with CertAdd ...........................................................................................9-32
Advice and Workarounds............................................................................................................9-33
How 802.1X Works...........................................................................................................................9-35
Benefits of 802.1X.............................................................................................................................9-36
Chapter 10 - Wireless PAN Communications with Bluetooth
Overview ...........................................................................................................................................10-1
Enabling the Bluetooth Radio Driver..........................................................................................10-1
Setting Up Your Bluetooth Card.................................................................................................10-1
Assign COM Ports.............................................................................................................................10-2
Discover Bluetooth Device(s) ...........................................................................................................10-2
Turn Radio Transmitter ON/OFF......................................................................................................10-7
Bluetooth ActiveSync........................................................................................................................10-8
Bluetooth LAN Access....................................................................................................................10-10
OBEX ..............................................................................................................................................10-12
Enable File Sharing...................................................................................................................10-22
Using the Dialer...............................................................................................................................10-22
Get Connected Wizard.....................................................................................................................10-23
Dial Up to Your Network................................................................................................................10-26
vi Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Chapter 11 - Wireless WAN Communications with GSM/GPRS
Overview ...........................................................................................................................................11-1
Enabling the GSM/GPRS Radio Driver......................................................................................11-1
Frequencies .................................................................................................................................11-1
Tri-Band Antenna .......................................................................................................................11-1
Requirements ..............................................................................................................................11-1
Capabilities..................................................................................................................................11-1
SIM Card ...........................................................................................................................................11-2
SIM Card Requirements..............................................................................................................11-2
Using uPhone.....................................................................................................................................11-3
Accessing uPhone .......................................................................................................................11-3
Navigation Bar............................................................................................................................11-3
Using the Dialler................................................................................................................................11-5
Making a Call..............................................................................................................................11-6
Receiving a Call..........................................................................................................................11-7
Ending a Call...............................................................................................................................11-7
Keyboard Combinations for Calls...............................................................................................11-8
Call Waiting................................................................................................................................11-8
Making Conference Calls............................................................................................................11-8
Touchtones..................................................................................................................................11-9
Volume Control...........................................................................................................................11-9
Phonebook...................................................................................................................................11-9
Tools Menu ...............................................................................................................................11-10
Settings Menu ...........................................................................................................................11-11
Audio Modes ...................................................................................................................................11-12
Handset......................................................................................................................................11-12
Headset......................................................................................................................................11-12
Speakerphone............................................................................................................................11-12
Ringtone Configuration...................................................................................................................11-13
Accessing Ringtone Configuration...........................................................................................11-13
WAV Files ................................................................................................................................11-13
Previewing Tones......................................................................................................................11-13
Call Log...........................................................................................................................................11-14
Call Log Options.......................................................................................................................11-14
Opening the Call Log................................................................................................................11-14
Tools Menu ...............................................................................................................................11-15
SMS Manager..................................................................................................................................11-16
Opening the SMS Manager.......................................................................................................11-16
Folders.......................................................................................................................................11-16
Sending an SMS Message.........................................................................................................11-17
Icons at the Top of the Message Screen....................................................................................11-18
Edit Menu......................................................................................................................
Online Help......................................................................................................................................11-19
............11-19
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 vii
uPhone Configuration......................................................................................................................11-20
Accessing ..................................................................................................................................11-20
Requirements ............................................................................................................................11-20
Tab Windows............................................................................................................................11-20
General Tab...............................................................................................................................11-21
Network Tab .............................................................................................................................11-22
Divert Tab .................................................................................................................................11-23
Bar Tab......................................................................................................................................11-24
Messaging Tab..........................................................................................................................11-25
Other Tab ..................................................................................................................................11-25
GPRS Settings .................................................................................................................................11-26
To Select the Pre-Configured GPRS Settings...........................................................................11-26
To Add a GPRS Setting ............................................................................................................11-27
GPRS Connection .....................................................................................................................11-27
Chapter 12 - Applications
Calendar.............................................................................................................................................12-1
Contacts .............................................................................................................................................12-3
Tasks .................................................................................................................................................12-6
Notes..................................................................................................................................................12-7
Messaging..........................................................................................................................................12-8
Pocket Internet Explorer..................................................................................................................12-11
Pocket Word ....................................................................................................................................12-14
Pocket Excel ....................................................................................................................................12-16
Windows Media Player for Pocket PC............................................................................................12-18
MSN Messenger ..............................................................................................................................12-19
Pictures ............................................................................................................................................12-20
Chapter 13 - Dolphin 7900 HomeBase
Overview ...........................................................................................................................................13-1
Dolphin 7900 HomeBase Parts and Functions..................................................................................13-2
Front Panel .................................................................................................................................13-2
Back Panel ..................................................................................................................................13-3
Powering the HomeBase ...................................................................................................................13-4
HomeBase Serial Connector..............................................................................................................13-4
Charging the Main Battery ................................................................................................................13-5
Communications................................................................................................................................13-6
Mounting the HomeBase.................................................................................................................13-10
Desk Mounting..........................................................................................................................13-11
Wall Mounting..........................................................................................................................13-11
Chapter 14 - Dolphin 7900 Mobile Base
Overview ...........................................................................................................................................14-1
viii Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Dolphin Mobile Base Hardware Overview .......................................................................................14-2
Front Panel..................................................................................................................................14-2
Bottom Panel...............................................................................................................................14-3
Back Panel...................................................................................................................................14-5
Mounting the Dolphin Mobile Base............................................................................................14-6
Powering the Dolphin Terminal ........................................................................................................14-7
Charging the Dolphin Terminal.........................................................................................................14-7
Setting Up the Mobile Base for Communications.............................................................................14-7
Chapter 15 - Dolphin 7900 ChargeBase
Overview ...........................................................................................................................................15-1
Dolphin ChargeBase Parts and Functions .........................................................................................15-1
Front Panel .................................................................................................................................15-1
Back Panel...................................................................................................................................15-2
Power Supply..............................................................................................................................15-2
Supplying Power to the ChargeBase .................................................................................................15-2
Inserting and Removing Terminals ...................................................................................................15-3
Charging Terminals in the ChargeBase.............................................................................................15-3
Mounting the Dolphin ChargeBase...................................................................................................15-3
Using the Mounting Brackets .....................................................................................................15-5
Chapter 16 - Dolphin 7900 QuadCharger
Overview ...........................................................................................................................................16-1
Dolphin QuadCharger Parts and Functions.......................................................................................16-1
Front Panel .................................................................................................................................16-1
Rear Panel ...................................................................................................................................16-2
Supplying Power to the QuadCharger...............................................................................................16-3
Inserting and Removing Battery Packs .............................................................................................16-3
Recommendations for Storing Batteries............................................................................................16-3
Charging Batteries in the QuadCharger.............................................................................................16-3
Using the Battery Analyzer ...............................................................................................................16-4
Mounting the QuadCharger...............................................................................................................16-5
Troubleshooting.................................................................................................................................16-6
Chapter 17 - Customer Support
Product Service and Repair ...............................................................................................................17-1
Online Product Service and Repair Assistance...........................................................................17-1
Technical Assistance .........................................................................................................................17-2
Online Technical Assistance.......................................................................................................17-2
Limited Warranty ..............................................................................................................................17-3
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 ix
x Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
1
Introduction
Congratulations on the purchase of the Dolphin 7900 mobile computer! You have made a wise choice in selecting the Dolphin, a device known worldwide for its ergonomic form factor, light-weight, rugged design and single-handed data collection capabilities.
Ergonomics
The patented shape of the Dolphin 7900 fits into either hand comfortably with major function keys that are easy to access. The adjustable hand strap on the back panel ensures a secure grip on the terminal for solid one-handed operation in mobile environments.
Rugged Design
Dolphin 7900 terminals are the most durable mobile computers on the market. Their rugged design can withstand repeated five­foot drops onto a concrete floor, extreme temperatures, as well as high humidity, moisture, and dust conditions. The terminals are independently tested to meet IP64 specifications.
Mobile Computing Features
• A low-power, high-resolution digital image engine for omni-directional and auto-discrimination decoding of most bar code symbologies
• An Intel
• Optional Wireless Full Area Networking anywhere
• Microsoft Windows Mobile 2003 Second Edition Software for Pocket PCs
• 64MB RAM (optional 128MB) and 64MB synchronous Flash memory configuration for ample and secure data storage
• A mini-Secure Digital (SD) memory interface that enables memory expansion
• Adaptus Imaging Technology for advanced point-and-shoot bar code decoding and image capture
®
X-Scale 400MHz RISC microprocessor for fast processing
(WFAN) configuration for real-time data and voice communications anytime,
Additional Features
• Long-lasting Lithium Ion (Li-ion) batteries
• 3.8”, easy-to-read 1/4 VGA (240 x 320) backlit TFT color display with industrial touch screen
• Two keyboard options: 25-key numeric and 36-key alpha
• Industrial-grade mechanical connector that supports serial and USB communications, as well as power in and out
• Full suite of compatible peripheral devices
• Decoding of stacked linear and matrix codes with Optical Character Recognition (OCR) functionality
• Buttons on both side panels that can activate the image engine for easy one-hand scanning with either hand
• Digital picture capability
• Audio jack for headset use
• Speaker and microphone on the front panel
Application Development Tools
• Dolphin SDK Add-on for Pocket PC 2003 - supports Embedded Visual C++ 4.0
• Dolphin .NET SDK for Pocket PC 2002 and 2003 - supports Visual Studio.NET 2003 (VB.NET and C#.NET)
• Dolphin GSM/GPRS SDK Add-on for Pocket PC 2003 - supports Embedded Visual C++ 4.0 and Visual Studio.NET 2003
This User’s Guide
The Dolphin 7900 Series Mobile Computer User’s Guide provides you with the information you need to make the most of your Dolphin terminal.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 1 - 1
Required Safety Labels
Dolphin 7900 mobile computers meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your Dolphin mobile computer.
Location
Laser safety label
Safety and radio label
Laser Safety Label
Dolphin 7900 terminals with the IMAGETEAM™ 4300 (IT4300) image engine contain a laser aimer that projects from the imager. Therefore, Dolphin 7900 terminals with the IT4300 have the following label on the back panel:
/$6(5/,*+7'212767$5(,172%($0 &/$66/$6(5352'8&7
P:0$;287387WRQ0 (1$$ &RPSOLHVZLWK&)5DQG H[FHSWIRUGHYLDWLRQVSXUVXDQWWR/DVHU 1RWLFH1RGDWHG-XO\
Note: The actual label is much smaller than the above graphic.
Use of controls or adjustment or performance of procedures other than those specified herein may result in hazardous radiation exposure.
!
1 - 2 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05
Regulatory and Safety Approvals for all Dolphin 7900 Series Terminals
Parameter Specification
U.S.A Canada European Community
The CE Mark on the product indicates that the system has been tested to and conforms with the provisions noted within the 89/336/EEC Electromagnetic Compatibility Directive and the 73/23/EEC Low Voltage Directive.
For further information, please contact: Hand Held Products, Inc.
Nijverheidsweg 9 5627 BT Eindhoven The Netherlands
Hand Held Products, Inc. shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
FCC Part 15, Class B ICES-003 EN 55022 (CISPR 22) Class B EN60950 EN60825-1 EN55024:1998
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 1 - 3
Dolphin 7900 Series WLAN (802.11b) or WPAN (Bluetooth) Radio
Dolphin 7900 RF terminals are designed to comply with the most current applicable standards on safe levels of RF energy developed by the Institute of Electrical and Electronics Engineers (IEEE) and the American National Standards Institute (ANSI) and has been recommended for adoption by the Federal Communications Commission (FCC).
802.11b
The required safety label that appears on the back of Dolphin 7900 terminals equipped with an 802.11b radio is as follows:
FOR HOME OR OFFICE USE
Tested to Comply With FCC Standards This Class B Digital apparatus complies with
Canadian ICES-003. Cet appariel numerique de la
Classe B est conforme a la norme NMB-003 du Canada.
0682
FCC ID: HD57900L00 Canada: IC1693B79L00
Hand Held Products, Inc. www.handheld.com
Bluetooth
The required safety label that appears on the back of Dolphin 7900 terminals equipped with a Bluetooth radio is as follows:
FOR HOME OR OFFICE USE
Testedto Comply With FCC Standards This Class B Digital apparatus complies with Canadian
ICES-003. Cet appariel numerique de la Classe B est conforme a la
norme NMB-003 du Canada.
Contains Socket Radio FCC ID: LUBBTM-1
Canada: IC1693B79B0P
No user serviceable parts.
Opening Voids Warranty.
N10410
No user serviceable parts.
Opening Voids Warranty.
!
Made in USA of US & imported parts.
N10410
Made in USA of US & imported parts.
0682
Hand Held Products, Inc.
www.handheld.com
802.11b and Bluetooth
The required safety label that appears on the back of Dolphin 7900 terminals equipped with an 802.11b and a Bluetooth radio combination is as follows:
FOR HOME OR OFFICE USE
Testedto Comply With FCC Standards This Class B Digital apparatus complies with
Canadian ICES-003. Cet appariel numerique de la
Classe B est conforme a la norme NMB-003 du Canada.
N10410
www.handheld.com
Hand Held Products, Inc.
0682
FCC ID: HD57900L0P
Canada: IC1693B79L0P
Made in USA of US & imported parts.
Opening Voids Warranty.
No user serviceable parts.
!
1 - 4 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05
Dolphin 7900 Series WWAN Radio - GSM MC-45 & MC-46
Dolphin 7900 Series RF terminals are designed to comply with the most current applicable standards on safe levels of RF energy developed by the Institute of Electrical and Electronics Engineers (IEEE) and the American National Standards Institute (ANSI) and has been recommended for adoption by the Federal Communications Commission (FCC).
GSM MC-45 GSM MC-46
GSM
res
N
2860
01401N
H
rPdleHdna
resuo
O
UniedaM
i
ww.cnI,stcudo
h.w
.strapelbaeciv
.ytnarraWsdioVgninep
&SU
foAS .strapdetropm
moc.dlehdna
GSM
UECIFFOROEMOHROF
ES
sdradnatSCCFhtiWylpmoCotdetseT
.300-SECInaidanaC aledeuqiremunleirappateC
noctseBessalC
rof
.strapelbaeciv
resresuoN
sdioVg
pO
nine
H
.ytnarraW
&SUfoASUniedaM
.strapdetropmi
rPdleHdna
MNemronalaem
CF
ww.cnI,stcudo
h.w
htiwseilpmocsutarappalatigiDBssalCsihT
.adanaCud300-B
UB00975DH:DIC
0
0UB97B3961CI:adanaC
moc.dlehdna
GSM and 802.11b
2860
,stcudorPdleHdnaH
GSM and Bluetooth
2860
01401N
H
rPdleHdna
GSM, 802.11b, and Bluetooth
2860
401N
,stcudorPdleHdnaH
GSM and 802.11b
OF
etse
T
ivres
uoN
res
!
.strapelbaec
rraWsdioVgninepO
.ytna
&SUfoASUniedaM
.strapdetropmi
ssa
lC
resuo
N
nepO
01401N
moc.dlehdn
ah.www.cnI
.300-SECInaidanaC aledeuqiremunleirappateC
rof
noctseBe
.strapelbaecivres
.ytnar
dioVgni
raWs
&SUfoASUniedaM
.stra
pdetropmi
cudorPdleHdnaH
ESUECIFFOROEMOHR
atSCCFhtiWy
lpmoCotd
CF
sdradn
htiwseilpmocsutarappalatigiDBssalCsihT
.adanaCud300-BMNemronalaem
0UL00975DH:DIC
0UL97B3961CI:adanaC
m
oc.dlehdnah.www.cnI,st
GSM and Bluetooth
EMOHROF
res
N
resuo
O
UniedaM
i
ww.cnI,stcudo
h.w
.strapelbaeciv
.ytnarraWsdioVgninep
&SU
foAS .strapdetropm
moc.dlehdna
.300-SECInaidanaC aledeuqiremunleirappat
n
aH
d
ESUECIFFORO
a
sdr
dnatSCCFhtiWylpmoCotdetseT
utarappalatigiDBssalCsihT
e
C
mronalaemrofnoctseBessalC
moc.dlehdnah.
www
.cnI,stcudorPdleH
ASUniedaM
&SUf
o
.s
apdetropmi
tr
htiwseilpmocs
oVgninepO
sdi
.ytnarraW
.adanaCud300-BMNe
resuoN
elbaecivres
.strap
PUB00975DH:DICCF
PUB97B3961CI:adanaC
GSM, 802.11b, and Bluetooth
O
EMOHROF
ivres
uoN
res
!
.strapelbaec
rraWsdioVgninepO
.ytna
&SUfoASUniedaM
.strapdetropmi
.300-SECInaidanaC aledeuqiremunleirappat
01
moc.dlehdn
ah.www.cnI
ESUECIFFOR
sdra
dnatSCCFhtiWylpmoCotdetseT
utarappalatigiDBssalCsihT
eC
mronalaemrofnoctseBessalC
naH
moc.dlehdnah.www
nI
H
d
.c
,stcudorPdle
H:D
ICCF
CI:adanaC
B3961
ASUniedaM
&SUfo
.s
trapdetropmi
htiwseilpmocs
sdioVgninepO
.ytnarraW
.adanaCud300-BMNe
resuoN
elbaecivres
.strap
P
UL00975D
PUL97
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 1 - 5
FCC Compliance
Dolphin mobile computers meet or exceed all applicable standards and have been manufactured to the highest level of quality.
Dolphin 7900 Series Batch Terminal
Dolphin 7900 Series Batch terminals comply with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Dolphin 7900 Series RF Terminal with an 802.11b, Bluetooth, and/or GSM MC-45 or MC-46 Radio
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user
may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Our company is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by our company. The correction is the responsibility of the user. Use only shielded data cables with this system.
In accordance with FCC 15.21, changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. To maintain compliance with FCC RF exposure guidelines for body-worn operation, do not use accessories that contain metallic components other than specified by the manufacturer.
!
Canadian Compliance for Dolphin 7900 Series RF Terminals with an 802.11b, Bluetooth, and/or GSM MC-45 or MC-46 Radio
This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
1 - 6 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05
RF, Regulatory, and Safety Agency Approvals for 802.11b and Bluetooth
Parameter Specification
RF Approvals U.S.A Canada
FCC Part 15.247 RSS 210
RF, Regulatory, and Safety Agency Approvals for GSM MC-45
Parameter Specification
RF Approvals U.S.A Canada
FCC Part 24 RSS 133
RF, Regulatory, and Safety Agency Approvals for GSM MC-46
Parameter Specification
RF Approvals U.S.A FCC Part 24
Dolphin 7900 Series 802.11b, Bluetooth, and/or GSM MC-45 or MC-46 R&TTE Compliance Statement
Dolphin 7900 RF terminals are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC). This equipment has been assessed to the following standards:
Parameter Specification
R&TTE EN 300 328-2:2000
EN 301 489-1 (2002-08) EN 301 489-17 (2002-08) EN 60950: 2000 EN 50361: 2001
This product is marked with in accordance with the Class II product requirements specified in the R&TTE Directive, 1999/5/EC.
The equipment is intended for use throughout the European Community. Its authorization for use in France is restricted as follows:
PAN European Frequency Range: 2.402 - 2.480 GHz Restrictions in France are as follows:
• Indoor use - Maximum power (EIRP*) of 100 mW for the entire 2400-2483.5 MHz
• Outdoor use - Maximum power (EIRP*) of 100 mW for the 2400-2454 MHz band and maximum power (EIRP*) of 10 mW for the 2454-2483 MHz band
00682
Pacemakers, Hearing Aids and Other Electrically Powered Devices
Most manufacturers of medical devices adhere to the IEC 601-1-2 standard. This standard requires devices to operate properly in an EM Field with a strength of 3V/m over a frequency range of 26 to 1000MHz.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 1 - 7
The maximum allowable field strength emitted by the Dolphin is 0.3V/m according to Subpart B of Part 1 of the FCC rules. Therefore, the Dolphin RF has no effect on medical devices that meet the IEC specification.
Microwaves
The radio in the Dolphin RF terminal operates on the same frequency band as a microwave oven. Therefore, if you use a microwave within range of the Dolphin RF terminal you may notice performance degradation in your wireless network. However, both your microwave and your wireless network will continue to function.
The Dolphin Batch terminal does not contain a radio, and therefore, is not affected by microwave ovens.
Care and Cleaning of the Dolphin Terminal
When needed, clean the image engine window and the LCD display with a clean, non-abrasive, lint-free cloth. The terminal can be cleaned with a damp cloth.
1 - 8 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05
2
Getting Started
Overview
The Dolphin 7900 terminal comprises one element of an enterprise data collection system that includes various models, peripherals, and accessories that you can combine to suit your exact needs. The Dolphin 7900 terminal itself combines the latest in multi-functional wireless data and voice communications technology with a unique, compact form factor, which makes it an ideal solution for today’s in-transit applications.
Data Input
The Dolphin 7900 mobile computer features a PDA design with a larger display and smaller recessed keyboards. The display area is 3.8 inches with a 240 X 320 VGA display in TFT color that is backlit for maximum viewability, then covered with an industrial touch screen for maximum durability. There are two keyboard options: 25-key numeric-alpha and 36-key alpha­numeric.
Imaging
The Dolphin 7900 contains an integrated imager that can take digital images of damaged packages and recipient signatures in addition to decoding standard 1D and 2D symbologies. For the greatest ease-of-use when operating the imager, both side panels feature a scan button that initiates a scan with the touch of a thumb or forefinger.
Memory
The Dolphin 7900 is a Windows Mobile computer with 64 MB RAM and 64 MB non-volatile synchronous Flash memory.
Communications
Communications via the industrial, mechanical connector supports 115 Kbps using serial RS-232 and 12 Mbps using USB.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 1
Dolphin 7900 Radio Configuration Options
Standard Configurations
Dolphin 7900 WLAN and WPAN (802.11b and Bluetooth)
This terminal features co-located 802.11b and Bluetooth radios, which means that your terminal contains the capabilities of both radios. You can operate the radios simultaneously or switch between them.
Dolphin 7900 WWAN and WLAN (GSM/GPRS and 802.11b)
This terminal features the functionality of both GSM/GPRS and 802.11b radio and network technologies.
Dolphin 7900 WWAN and WPAN (GSM/GPRS and Bluetooth)
This terminal features the functionality of both GSM/GPRS and Bluetooth radio and network technologies.
Dolphin 7900 WWAN, WLAN, and WPAN (GSM/GPRS, 802.11b, and Bluetooth)
This terminal features the functionality of GSM/GPRS, 802.11b, and Bluetooth radio and network technologies.
Custom Configurations
Please refer to the Dolphin 7900 pricing configuration guide or contact your Customer Account Representative (CAR) for details.
Dolphin 7900 WLAN (802.11b)
These terminals integrate the basic functionality of the Batch terminals with an integrated, IEEE 802.11b direct sequence radio that enable communication with a host computer through a wireless local area network (WLAN).
Dolphin 7900 WPAN (Bluetooth)
This terminal allows Bluetooth communications to Bluetooth enabled devices such as printers, mobile phones, Access Points (APs), Bluetooth-enabled PCs, etc.
Dolphin 7900 WWAN (GSM/GPRS)
This terminal features all the benefits of the Dolphin 7900 with the additional capabilities of GSM/GPRS technology.
2 - 2 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Dolphin 7900 Series Peripherals
Each of the following items is sold separately to enhance your Dolphin 7900 terminal’s capabilities.
Dolphin HomeBase
The Dolphin HomeBase charging and communication cradle supports both RS-232 and USB communications, which enable it to interface with the majority of PC-based enterprise systems. When a terminal is seated in the HomeBase, its main battery pack charges in less than four hours. In addition, the HomeBase contains an auxiliary battery well that charges a spare Li-ion battery.
For more information, see Dolphin 7900 HomeBase on page 13-1.
Dolphin Mobile Base™
The Dolphin Mobile Base charging and communication cradle is designed specifically for in-premise and in-transit data collection applications. It features a flexible mounting bracket, a cigarette lighter adapter or power cable to adapt it to your environment.
When a terminal is seated in the Mobile Base, its main battery pack charges in less than four hours. The serial connector supports RS-232 communication and power out to peripheral devices, such as hand held scanners.
For more information, see Dolphin 7900 Mobile Base on page 14-1.
Dolphin QuadCharger™
The Dolphin QuadCharger is a four-slot charging station for Dolphin Li-ion battery packs that can charge each battery in less than four hours. The fourth slot features a battery analyzer that completely resets and re-calibrates a battery, then displays remaining capacity.
For more information, see Dolphin 7900 QuadCharger on page 16-1.
Dolphin ChargeBase
The Dolphin ChargeBase is a four-slot charging cradle that holds, powers, and charges a terminal in each slot. For more information, see Dolphin 7900 ChargeBase on page 15-1.
Dolphin Net Base
The Dolphin Net Base is a four-slot charging/communication cradle that holds, powers, charges, and communicates with the terminal in each slot. Ethernet communication occurs via statically and dynamically-assigned IP addresses.
For more information about the Dolphin Net Base, please consult the Dolphin 7900 Net Base Quick Start Guide.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 3
Dolphin 7900 Accessories
Each of the following items is sold separately to enhance your Dolphin 7900 terminal’s capabilities.
Dolphin Cable Kits
USB and serial cables connect the Dolphin 7900 terminal directly to both a peripheral device for communication and a power source for charging.
Dolphin Mobile Charger
This charging cable plugs the terminal directly into a vehicle cigarette lighter/power port to power the terminal and charge the battery pack. This accessory converts the 12 Volts from the vehicle outlet to the 9 Volts required by the terminal.
Protective Enclosure
This enclosure wraps around the terminal to protect it from wear and tear.
Protective Holster
The protective holster holds the terminal for mobile use.
Dolphin Mobile Mount
The Dolphin Mobile Mount solution secures Dolphin 7900 in the cab of any vehicle. Used in conjunction with the Mobile Charger, Dolphin terminals can be adapted to almost any in-transit environment.
Li-ion Battery Pack
The 7.4v, 14.8 watt hour Li-ion rechargeable battery pack provides the main power supply for Dolphin 7900 terminals.
2 - 4 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Using the Dolphin 7900 for the First Time
1. Unpack the Carton and Verify its Contents, page 2-5.
2. Install the Main Battery Pack, page 2-5.
3. Charge the Main and Backup Batteries, page 2-6.
4. Initialize the Mobile Computer, page 2-7.
5. Align the Screen, page 2-8.
6. Complete the Opening Screens, page 2-8.
7. Set the Time Zone, page 2-9.
8. Let Autoinstall Run, page 2-9.
9. Verify Operations with Demos, page 2-10.
Step 1. Unpack the Carton and Verify its Contents
Verify that the carton contains the following items:
• Dolphin 7900 mobile computer (the terminal)
• Main battery pack (7.4v Li-ion)
• Microsoft Companion CD
• Dolphin 7900 Quick Start Guide
Be sure to keep the original packaging in the event that the Dolphin terminal should need to be returned for service. For details, see Limited Warranty on page 17-3.
If you ordered peripherals or accessories, verify that they are included with the order.
Note: You may have also received the Dolphin Software Development Kit and User’s Guide CD.
Step 2. Install the Main Battery Pack
The Dolphin 7900 ships with the handstrap installed and fastened with a clip on the top panel. To install the battery pack, you must detach the hand strap.
To detach the hand strap, push the clip up and away from the terminal. To re-attach the hand strap, slide the clip back into place.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 5
Installing the Main Battery Pack
Use only the Li-ion battery packs provided by Hand Held Products. The use of any battery pack not sold/manufactured by Hand Held Products in a Dolphin terminal will void your warranty and may result in damage to the Dolphin terminal
!
or battery.
1. Unpack the Li-ion battery pack.
2. Hold the terminal with the front panel (keyboard) facing down and detach the handstrap.
3. Take the battery and insert the end without the locking tab into the top of the battery well and push down with a hinging
motion until the locking tab snaps.
4. Re-attach the handstrap.
To Remove the Main Battery Pack
Put the terminal in Suspend mode before removing the battery; Suspend Mode, page 2-11.
1. Detach the handstrap.
2. Press the locking tab on the battery pack and pull it away from the bottom panel.
3. Pull the battery pack up with a hinging motion.
Step 3. Charge the Main and Backup Batteries
The power supply consists of two types of battery power: the main battery pack and the backup battery located inside the terminal. The main battery powers the terminal and charges the internal backup battery. The internal backup battery maintains the application data stored in RAM and the system clock for up to 30 minutes when the main battery pack is completely discharged or removed.
Before initial use - Because the terminals are shipped with both batteries discharged of all power, charge the main battery pack for a minimum of four hours before initial use. When installed in the terminal, the battery pack can be charged in the HomeBase, Mobile Base, or with the appropriate charging cable. When not installed in the terminal, battery packs can be charged in the QuadCharger or the auxiliary well of the HomeBase.
Time to Charge - Four hours for the main battery pack, eight hours for the internal backup battery the first time. For more information, see Battery Power on page 3-10.
Use only Dolphin 7900 Series peripherals, power cables, and power adapters. Use of peripherals, cables, or power adapters not sold/manufactured by
!
Hand Held Products
will void the warranty and may damage the terminal.
2 - 6 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Charging with Dolphin Peripherals
When the battery is installed in the terminal, you can insert the terminal into any one of the following peripherals to charge the main battery pack:
Dolphin 7900 HomeBase (see page 13-1)
Dolphin 7900 Mobile Base (see page 14-1)
Dolphin 7900 ChargeBase (see page 15-1) or the Dolphin 7900 Net Base
To fully charge the Li-ion battery before installing it in the terminal, use the
Dolphin 7900 QuadCharger (see page 16-1)
Auxiliary Battery Well of the Dolphin HomeBase (see page 13-5)
Step 4. Initialize the Mobile Computer
1. Power on the terminal. The decode LED lights and the scan LED blinks for approximately three seconds. Do NOT press any
keys while the terminal is booting up.
2. The terminal initializes and the splash screen appears for a few seconds. The Build numbers indicate the software versions.
Build 8.XX 8.XX 8.XX
Bootloader
3. The system performs a hard reset. When the display activates again, follow the instructions that appear.
Kernel
Keyboard
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 7
Step 5. Align the Screen
You are prompted to align the screen by tapping the target five times. Use the stylus provided by Hand Held Products.
• Alignment should always be performed with a stylus designed for touch screen applications. The small point is required for accurate calibration.
• Press the stylus firmly into the center of the cross-hair target once and release. Do not “double-tap” the target.
• You can re-align the screen at any time by going to Start > Settings > System tab > Screen.
Step 6. Complete the Opening Screens
After aligning the screen, follow the directions on the screen which take you through a simple exercise showing how to use the stylus and pop-up menus.
Note: Hand Held Products recommends using screen protectors for Dolphin 7900 terminals; especially for those terminals used
within applications that require high-volume interaction with the touch screen. Screen protectors help prevent damage to the touch screen, are easily installed, and can be purchased at any major computer retail store or directly from Hand Held Products; contact Hand Held Products directly for part numbers and pricing.
2 - 8 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Step 7. Set the Time Zone
Use the drop-down list to select your time zone, and tap Next. This does not necessarily set the correct time; only the time zone. You set the time and date manually. For details, see Setting the Time and Date on page 2-9. After setting the time zone, you are finished with the initial setup. The system begins autoinstalling.
Step 8. Let Autoinstall Run
For each program that loads, a status bar indicates that the program is loading. Autoinstall occurs after each hard reset. Do NOT touch the keyboard or the screen while programs are loading.
All configurations of the Dolphin 7900 terminal install Demos and Utilities. If the terminal is configured with a wireless radio, the appropriate radio drivers and utilities for each radio install.
After Autoinstall is complete, the terminal performs a soft reset automatically. When it finishes booting up after the soft reset, the Today screen appears; see Today Screen on page 4-2.
Step 9. Setting the Time and Date
You need to re-set the time and date after every hard reset of the terminal. It is a good idea to set the time and date now before you begin using the device.
On the Today screen, tap the line that displays the time and date,
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 9
The Clock Settings screen appears.
Step 10. Verify Operations with Demos
For details, see Using the Image Engine on page 5-1.
2 - 10 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Resetting the Terminal
There are two ways to reset the Dolphin terminal: a soft and a hard reset.
Soft Reset (Warm Boot)
A soft reset re-boots the device without losing RAM data. You would perform a soft reset when
The terminal fails to respond
After installing some software applications
After making changes to certain system settings, such as network cards
1. Press and hold the Red + ESC keys for approximately five seconds.
2. The decode and scan LEDs flash for approximately three seconds as the terminal resets.
3. When the reset is complete, the Today screen displays.
Hard Reset (Cold Boot)
A hard reset resets the operating system, restores the terminal back to factory defaults, and resets the terminal after a bootloader, keyboard, and kernel upgrade.
A hard reset erases all of the data stored in RAM memory and all RAM installed applications.
!
1. Press and hold the Red + TAB keys for approximately five seconds.
2. The decode and scan LEDs light for approximately three seconds.
3. The terminal re-initializes; see Initialize the Mobile Computer on page 2-7.
Suspend Mode
To put the Dolphin terminal into suspend mode manually, press and hold Blue + Backlight keys. The terminal also goes into suspend mode automatically when the terminal is inactive for a programmed period of time. For more information, see Power on page 7-13. To wake the Dolphin terminal from suspend mode, press the SCAN key.
Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim. Rev (c) 4/11/05 2 - 11
2 - 12 Dolphin® 7900 Series Mobile Computer User’s Guide-Prelim.
Rev (c) 4/11/05
Loading...
+ 102 hidden pages
