Honeywell 70ELGN, 70ELG0, 70EL00 User Guide

Text here indicates

Icons here indicate the

the active program.

status of various system

functions.

Preliminary Draft 5/26/13, Not for Release

Dolphin™ 70e Black

with Windows® Embedded Handheld 6.5

User’s Guide

Preliminary Draft 5/26/13, Not for Release

Disclaimer

Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII.

Web Address: www.honeywellaidc.com

Trademarks

Dolphin is a trademark or registered trademark of Hand Held Products, Inc. in the United States and/or other countries.

Microsoft, Windows, Windows Mobile, Windows Phone, Windows Embedded Handheld, Windows CE, Windows 98 Second Edition, Windows NT, Windows 2000, Windows ME, Windows XP, Windows 7, Windows Vista, ActiveSync, Outlook, and the Windows logo are trademarks or registered trademarks of Microsoft Corporation.

The Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Honeywell.

Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are the property of their respective owners.

Patents

For patent information, please refer to www.honeywellaidc.com/patents.

Preliminary Draft 5/26/13, Not for Release

Table of Contents

Chapter 1 - Dolphin 70e Black Terminal Agency Information

Label Locations ....................................................................................................................	1-1
Model Number, Serial Number and IMEI Labels............................................................	1-1
LED Safety ...........................................................................................................................	1-1
LED Safety Statement....................................................................................................	1-1
UL and C-UL Statement.......................................................................................................	1-2
Approvals by Country...........................................................................................................	1-2
R&TTE Compliance Statement—802.11a/b/g/n, Bluetooth, and/or GSM............................	1-2
FCC Requirements ..............................................................................................................	1-3
Dolphin RF Terminal—802.11a/b/g/n, Bluetooth, and/or GSM ......................................	1-3
Canadian Compliance..........................................................................................................	1-3
Conformité à la règlementation canadienne ..................................................................	1-4
RF Exposure Information (SAR) ..........................................................................................	1-4
For European Community Users .........................................................................................	1-5
Waste Electrical and Electronic Equipment Information ......................................................	1-5
China RoHS .........................................................................................................................	1-5
Pacemakers, Hearing Aids and Other Electrically Powered Devices ..................................	1-6
Hearing Aid Compatibility (HAC)..........................................................................................	1-6
Microwaves ..........................................................................................................................	1-6
Chapter 2 - Getting Started
Out of the Box ......................................................................................................................	2-1
Initial Setup for Dolphin 70e Black Terminals ......................................................................	2-1
Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT) ..........	2-2
The Home Screen ................................................................................................................	2-4
Title Bar..........................................................................................................................	2-4
Icons in the Title Bar ......................................................................................................	2-5
Horizontal Scroll .............................................................................................................	2-7
Tile Bar...........................................................................................................................	2-7
Virtual Keyboard.............................................................................................................	2-8
The Start Menu ....................................................................................................................	2-9
Navigating the Start Menu..............................................................................................	2-9
Pop-Up Menus .....................................................................................................................	2-9
File Explorer .......................................................................................................................	2-10
File Provisioning on the Dolphin 70e Black........................................................................	2-11
Search................................................................................................................................	2-11
Turning Power On/Off ........................................................................................................	2-12
Suspend Mode .............................................................................................................	2-12
Replacing the Main Battery ................................................................................................	2-12
Resetting the Terminal .......................................................................................................	2-13
Chapter 3 - Hardware Overview
Standard Configurations for the Dolphin 70e Black .............................................................	3-1
Peripherals for the Dolphin 70e Black..................................................................................	3-2
Accessories for the Dolphin 70e Black ................................................................................	3-3

iii

Preliminary Draft 5/26/13, Not for Release

Features of the Dolphin 70e Black ......................................................................................	3-4
Front, Bottom, and Right Panels....................................................................................	3-4
Feature Descriptions: Front, Bottom, and Right Panels ................................................	3-5
Back, Top, and Left Panels............................................................................................	3-7
Feature Descriptions: Back, Top, and Left Panels ........................................................	3-8
The I/O Connector .............................................................................................................	3-10
Batteries ............................................................................................................................	3-10
Charging Options.........................................................................................................	3-11
Charging Time .............................................................................................................	3-11
Important Charging Guidelines ....................................................................................	3-11
Battery Error Notification..............................................................................................	3-12
Storing Batteries ..........................................................................................................	3-13
Guidelines for Battery Pack Use and Disposal ............................................................	3-13
Managing Battery Power .............................................................................................	3-14
Checking Battery Power ..............................................................................................	3-14
System Resets ..................................................................................................................	3-15
Hardware Maintenance .....................................................................................................	3-15
When needed, clean the image engine window and the touch screen with a clean, non-abra-
sive, lint-free cloth. The terminal can be cleaned with a damp cloth. .....................	3-15
Installing a SIM Card and/or Memory Card .......................................................................	3-15
Chapter 4 - Using the Scan Image Engine
Overview..............................................................................................................................	4-1
LED Safety ..........................................................................................................................	4-1
Image Engine Specifications ...............................................................................................	4-1
Field of View ..................................................................................................................	4-1
Depth of Field ................................................................................................................	4-1
Supported Bar Code Symbologies .....................................................................................	4-2
Decoding .............................................................................................................................	4-3
Using the Scan Demo to Decode a Bar Code ...............................................................	4-3
The Aiming Beam ..........................................................................................................	4-3
Capturing Images Using the Imaging Demo........................................................................	4-4
Taking an Image ............................................................................................................	4-5
Uploading Images..........................................................................................................	4-5
Chapter 5 - Using the Color Camera
Overview..............................................................................................................................	5-1
Taking a picture using the Camera Demo tool ....................................................................	5-1
Taking a picture using the Windows Embedded Handheld 6.5 Camera tool ......................	5-4
Recording Video ..................................................................................................................	5-6
Uploading Pictures and Videos ...........................................................................................	5-6
Chapter 6 - System Settings
Overview..............................................................................................................................	6-1
Clock & Alarms ....................................................................................................................	6-2
Lock .....................................................................................................................................	6-3

Preliminary Draft 5/26/13, Not for Release

Personal Menu ....................................................................................................................	6-4
Buttons...........................................................................................................................	6-5
Voice Command ............................................................................................................	6-8
System Menu.......................................................................................................................	6-9
About ...........................................................................................................................	6-11
Audio Panel .................................................................................................................	6-11
Backlight ......................................................................................................................	6-12
Battery .........................................................................................................................	6-14
Certificates...................................................................................................................	6-16
Encryption....................................................................................................................	6-16
Error Reporting ............................................................................................................	6-17
External GPS ...............................................................................................................	6-17
HSM SystemInfo..........................................................................................................	6-17
SIP Config....................................................................................................................	6-18
Smart Sensor...............................................................................................................	6-19
Proximity Sensor Settings............................................................................................	6-21
Managed Programs .....................................................................................................	6-22
Memory........................................................................................................................	6-22
Power...........................................................................................................................	6-23
Regional Settings.........................................................................................................	6-24
Remove Programs.......................................................................................................	6-25
RIL ...............................................................................................................................	6-26
Screen .........................................................................................................................	6-26
Task Manager..............................................................................................................	6-27
Chapter 7 - Communication
Connections Menu...............................................................................................................	7-1
Connections Manager .........................................................................................................	7-2
Dolphin Wireless Manager ..................................................................................................	7-5
Dolphin Wireless Manager Window...............................................................................	7-5
Enabling the Radios.......................................................................................................	7-6
Accessing Radio Configuration Utilities .........................................................................	7-7
USB to PC ...........................................................................................................................	7-8
Network Cards.....................................................................................................................	7-8
Connecting and Synchronizing the Terminal and Workstation ............................................	7-9
Installing Additional Software ............................................................................................	7-11
Adding Programs Using ActiveSync or Windows Mobile Device Center.....................	7-11
Connecting the Terminal to a Wireless Network..........................................................	7-12
Adding Programs Using the Internet............................................................................	7-12
Software Upgrades............................................................................................................	7-13
Dolphin 70e Black COM Port Assignment Table ...............................................................	7-13

Preliminary Draft 5/26/13, Not for Release

Chapter 8 - Working with Wireless Wide Area Networking (WWAN)

Overview..............................................................................................................................	8-1
Requirements ................................................................................................................	8-1
Antenna Band ................................................................................................................	8-1
Signal Strength ..............................................................................................................	8-2
Voice and Data Communication ....................................................................................	8-2
Enabling the WWAN Radio .................................................................................................	8-3
Voice Communication, Using the Dolphin as a Phone ........................................................	8-4
Audio Modes..................................................................................................................	8-4
Volume Control ..............................................................................................................	8-4
Accessing the Dialer Window ........................................................................................	8-5
Dialing............................................................................................................................	8-5
Sending Calls.................................................................................................................	8-5
Ending Calls...................................................................................................................	8-6
Accessing Voice Mail.....................................................................................................	8-6
View Options..................................................................................................................	8-6
Phone Setup Options.....................................................................................................	8-6
Data Communication ...........................................................................................................	8-8
System Requirements ...................................................................................................	8-8
Information Requirements .............................................................................................	8-8
Establishing Data Communication.................................................................................	8-8
Manual Network Selection ...........................................................................................	8-10
Data Communication GSM/CDMA ....................................................................................	8-11
Dolphin Connection Manager ......................................................................................	8-11
Establishing Data Communication...............................................................................	8-14
Chapter 9 - Working with the Bluetooth Radio
Enabling the Bluetooth Radio ..............................................................................................	9-1
Pairing and Trusted Devices ...............................................................................................	9-2
Connecting to Other Bluetooth Devices ..............................................................................	9-2
Transferring Files using Beam File ......................................................................................	9-5
Making the Terminal Discoverable ......................................................................................	9-6
Enabling the Terminal to Receive Incoming Beams ............................................................	9-6
Selecting COM Ports ...........................................................................................................	9-6
Chapter 10 - Working with GPS
Overview............................................................................................................................	10-1
Assisted GPS Support.......................................................................................................	10-1
Powering the GPS Module ................................................................................................	10-1
Communication Ports ........................................................................................................	10-1
COM7 ..........................................................................................................................	10-1
GPS Intermediate Driver..............................................................................................	10-2
GPS Demo ........................................................................................................................	10-2

Preliminary Draft 5/26/13, Not for Release

Chapter 11 - Dolphin 70e Black HomeBase Device (Model 70e-HB)

Overview............................................................................................................................	11-1
Unpacking the HomeBase ...........................................................................................	11-1
Charging Overview ......................................................................................................	11-1
Communications ..........................................................................................................	11-1
Convenient Storage .....................................................................................................	11-2
Capacity.......................................................................................................................	11-2
Dimensions ..................................................................................................................	11-2
Weight..........................................................................................................................	11-2
Parts and Functions...........................................................................................................	11-3
Front Panel .................................................................................................................	11-3
Back Panel ..................................................................................................................	11-4
Bottom Panel ...............................................................................................................	11-5
Power ................................................................................................................................	11-5
Connecting Power to the HomeBase...........................................................................	11-5
Charging the Main Battery.................................................................................................	11-6
To Power a Terminal and Charge its Main Battery......................................................	11-6
Charging a Spare Battery in the Auxiliary Battery Well ...............................................	11-6
Communication..................................................................................................................	11-7
Requirements ..............................................................................................................	11-7
Setting Up and Connecting the Dolphin Terminal to the HomeBase...........................	11-7
Mounting the HomeBase ...................................................................................................	11-7
Desk Mounting.............................................................................................................	11-7
Chapter 12 - Dolphin 70e Black Mobile Base Device (Model 70e-MB)
Overview............................................................................................................................	12-1
Charging Overview ......................................................................................................	12-1
Convenient Storage .....................................................................................................	12-1
Dimensions ..................................................................................................................	12-1
Weight..........................................................................................................................	12-1
Mobile Base Components ................................................................................................	12-2
Mounting the Mobile Base .................................................................................................	12-3
Safety Precautions.......................................................................................................	12-3
Installation....................................................................................................................	12-3
Charging the Main Battery.................................................................................................	12-4
To Power a Terminal and Charge its Main Battery......................................................	12-5
Removing the Cable ....................................................................................................	12-5
Chapter 13 - Dolphin 70e Black ChargeBase Device (Model 70e-CB)
Overview............................................................................................................................	13-1
Unpacking the ChargeBase.........................................................................................	13-1
Charging Overview ......................................................................................................	13-1
Convenient Storage .....................................................................................................	13-1
Capacity.......................................................................................................................	13-1
Dimensions ..................................................................................................................	13-2
Weight..........................................................................................................................	13-2

vii

Preliminary Draft 5/26/13, Not for Release

Parts and Functions...........................................................................................................	13-2
Front Panel ..................................................................................................................	13-2
Back Panel...................................................................................................................	13-3
Bottom Panel ...............................................................................................................	13-3
Power ................................................................................................................................	13-3
Connecting Power to the ChargeBase .......................................................................	13-4
Charging the Main Battery.................................................................................................	13-4
To Power a Terminal and Charge its Main Battery......................................................	13-4
Mounting the ChargeBase.................................................................................................	13-5
Chapter 14 - Customer Support
Product Service and Repair...............................................................................................	14-1
Technical Assistance.........................................................................................................	14-1
Warranty Disclaimer: Proper Use of a Touch Screen Mobile Device ................................	14-1
Limited Warranty ...............................................................................................................	14-1
How to Extend Your Warranty .....................................................................................	14-3

viii

Preliminary Draft 5/26/13, Not for Release

Dolphin 70e Black Terminal Agency Information

Dolphin 70e Black mobile computers meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Read these guidelines carefully before using your Dolphin terminal.

This documentation is relevant for the following Dolphin models: 70eL00, 70eLGN, 70eLG0, 70eLW0 and 70eLWN.

!markings on the battery, charging peripheral, or device using the battery before attempting to install, use, or

charge the battery. Risk of fire and burns if improperly handled. Do not open, crush, heat above 60°C (140°F), or incinerate.CAUTION - Read the Guidelines for Battery Pack Use and Disposal on page 3-13 and all cautionary

Label Locations

Back Panel of the terminal

Compliance Labels and Marks

with the battery door and

battery removed.

Model Number, Serial Number and IMEI Labels

The model (item) number, serial number, and international mobile equipment identity (IMEI) number for the terminal are located on labels affixed to the bottom of the battery well.

Warning! To prevent possible hearing damage, do not listen at high volume levels for long periods.

LED Safety

LED Safety Statement

LEDs have been tested and classified as “EXEMPT RISK GROUP” to the Standard: IEC 62471:2006.

!Caution! Do not view directly with optical instruments.

1 - 1

Preliminary Draft 5/26/13, Not for Release

UL and C-UL Statement

UL and C-UL listed: UL60950-1 2nd Edition, and CSA C22.2 No. 60950-1-07 2nd Edition.

Underwriters Laboratories Inc. (UL) has not tested the performance or reliability of the global positioning system (GPS) hardware, GPS operating software or other GPS-related aspects of this product. UL has only tested for the explosion, fire, shock, and casualty hazards required by the applicable hazardous locations standards. UL certification does not cover the performance or reliability of the GPS hardware, GPS operating software, or other GPS-related aspects of this product. UL makes no representations, warranties, or certifications whatsoever regarding the performance or reliability of any GPS-related functions of this product.

Approvals by Country

Country	EMC, Radio, & SAR	Safety


U.S.A.	FCC Part 15, Subpart B	UL60950-1, 2nd Edition
	FCC Part 15, Subpart C, 15.247
	FCC Part 15, Subpart E
	FCC Part 22H, FCC Part 24E
	FCC SAR OET 65 Supplement C

Canada	ICES-003 (Class B), RSS 132, RSS 133, RSS 210	CSA C22.2 No. 60950-1-07, 2nd Edition

European	EN 302 291-1&2: V1.1.1,	EN 60950-1: 2006/A11:2009+A1:2010+A12:2011
Community/CE	EN 301 489-1: V1.9.2, EN 301 489-3: V1.4.1,	EN 60825-1: 2007 (2nd Edition)
	EN 301 489-7: V1.3.1, EN 301 489-17: V2.2.1,
	EN 301 489-24: V1.5.1,	2006/95/EC - Low Voltage Directive
	EN 301 511: V9.0.2,
	EN 301 893: V1.6.1,	2011/65/EU-RoHS (recast)
	EN 301 908-1&2: V5.2.1,
	EN 300 440-1: V1.6., EN 300 440-2: V1.4.1,
	EN 300 328: V1.7.1, EN 300 330-1: V1.7.1,
	EN 300 330-2: V1.5.1
	EN 50360: 2001, EN 50360: 2001/AC:2006
	EN 50364: 2010,
	EN 62209-1: 2010, IEC 62209-2: 2010

International		IEC 60950-1 2nd Edition
		IEC 60825-1 2nd Edition
		IEC 62471

R&TTE Compliance Statement—802.11a/b/g/n, Bluetooth, and/or GSM

Dolphin RF terminals are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC).

This product is marked with according to article 12 of the R&TTE Directive. In addition, this product complies to 2006/95/EC Low Voltage Directive when supplied with the recommended power supply. Honeywell shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

The equipment is intended for use throughout the European Community; PAN European Frequency Range: 2.400–2.4835 GHz.

5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.350 GHz) is restricted to indoor use only. Any other use will make the operation of the device illegal.

1 - 2

Preliminary Draft 5/26/13, Not for Release

High power radars are the primary users of 5250-5350 MHz and 5650-6850 MHZ bands. This may cause interference to Wireless Local Area Network devices.

European Contact:

Hand Held Products Europe B.V.

Nijverheidsweg 9-13

5627 BT Eindhoven

The Netherlands

FCC Requirements

Dolphin RF Terminal—802.11a/b/g/n, Bluetooth, and/or GSM

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Our company is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by our company. The correction is the responsibility of the user. Use only shielded data cables with this system.

5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.250 GHz) is restricted to indoor use only. Any other use will make the operation of the device illegal.

Caution! - Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment.

Canadian Compliance

This Class B digital apparatus complies with Canadian ICES-003 and RSS210. Operation is subject to the following two conditions:

1.This device may not cause harmful interference.

2.This device must accept any interference received, including interference that may cause undesired operation.

1 - 3

Preliminary Draft 5/26/13, Not for Release

5Ghz band: UNII (Unlicensed National Information Infrastructure) or band1 (5.150 to 5.250 GHz) is restricted to indoor use only. Any other use will make the operation of the device illegal.

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with the following body worn accessory: Holster-1. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

Caution! - Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment.

Conformité à la règlementation canadienne

Cet appareil numérique de la Classe B est conforme à la norme NMB-003 et RSS210 du Canada. Son fonctionnement est assujetti aux conditions suivantes:

1.Cet appareil ne doit pas causer de brouillage préjudiciable.

2.Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un fonctionnement indésirable.

Bande 5 Ghz: UNII (Infrastructure Nationale d'Information Sans Permis) ou Bande1 (5.150 à 5.250 GHz) est limitée à l'usage intérieur seulement. Toute autre utilisation rendra l'opération de l'appareil illégal.

For body worn operation, ce téléphone a été testé et respecte les directives d'exposition RF de la FCC pour une utilisation avec l'accessoire body worn: Holster-1. L'utilisation de d'autres accessoires risque de ne pas assurer la conformité avec les directives d'exposition RF de la FCC.

Mise en garde! - Tout changement ou modification non expressément approuvées par le bénéficiaire de cet appareil peut annuler l'autorisation d'utiliser l'équipement.

RF Exposure Information (SAR)

This mobile phone meets the government's requirements for exposure to radio waves. This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/Kg and for Europe 2W/Kg. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

The highest reported SAR values for head, body-worn accessory and simultaneous transmission use conditions are: 0.45 W/kg (1g), 0.96 W/kg (1g) and 1.33 W/kg (1g).

The highest reported CE SAR values for head, body-worn accessory and simultaneous transmission use conditions are: 0.59 W/kg (10g), 1.0 W/kg (10g), 1.15 W/kg (10g).

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: HD570eLGN, HD570eLG0 and HD570eL00.

1 - 4

Preliminary Draft 5/26/13, Not for Release

For European Community Users

Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).

Waste Electrical and Electronic Equipment Information

This product has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment, if not properly disposed.

In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way.

The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration. You may also contact your supplier for more information on the environmental performances of this product.

China RoHS

(Names and Content of Hazardous Substances or Elements)

Parts Name)	(Toxic and Hazardous Substances or Elements)

	(Pb)	(Hg)	(Cd)	(Cr6+)	(PBB)	(PBDE)
!" (Imager)	o	o	o	o	o	o

#$%&' (PCB)	o	o	o	o	o	o

()*+,-. Housing)	o	o	o	o	o	o

/0 Cables)	o	o	o	o	o	o

1234" LCD)	o	o	o	o	o	o

1234"56 (LCD Frame)	o	o	o	o	o	o

7)89 (Camera)	o	o	o	o	o	o

:; Key)	o	o	o	o	o	o

%< Battery)	o	o	o	o	o	o

%=>?" Power Adapter)	o	o	o	o	o	o

o: @4A BA C D EFGHIJDB KLMNHOJPQRS (Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in China’s SJ/T11363-2006.)

x: @4A TUBA HVWD EFGHIJXY SJ/T11363-2006 KLMNHOJPQ (Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials for this part is above the limit requirement in China’s SJ/T11363-2006. )

1 - 5

Preliminary Draft 5/26/13, Not for Release

Pacemakers, Hearing Aids and Other Electrically Powered Devices

Most manufacturers of medical devices adhere to the IEC 601-1-2 standard. This standard requires devices to operate properly in an EM Field with a strength of 3V/m over a frequency range of 26 to 1000MHz. The maximum allowable field strength emitted by the Dolphin terminal is 0.3V/m according to Subpart B of Part 1 of the FCC rules. Therefore, the RF from the Dolphin terminal has no effect on medical devices that meet the IEC specification.

Hearing Aid Compatibility (HAC)

Dolphin 70e Black models 70eLGN and 70eLG0 have been tested for hearing aid compatibility. These devices have an M4 and T4 rating. For additional HAC information, including the HAC rating for this product, please refer to www.honeywellaidc.com.

When some wireless devices are used near some hearing devices such as hearing aids and implants, users may detect a buzzing or humming noise. Some hearing devices are more immune than others to this interference noise. Wireless devices may also vary in the amount of interference they generate.

The ratings for compatibility of digital wireless devices with hearing aids are described in the American National Standards Institute (ANSI) C63.19 standard:

M-Rating: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference with hearing devices than phones that are not labeled. M4 is the superior/higher of the two ratings.

T-Rating: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with hearing devices' telecoil than unrated phones. T4 is the superior/higher of the two ratings.

The more immune the hearing aid device is, the less likely one is to experience interference noise from the wireless phone. Hearing aid devices may also be rated. Adding the ratings of the hearing aid and the phone would determine probable usability:

•Any combined rating equal to or greater than six offers the best use.

•Any combined rating equal to five is considered normal use.

The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use this device successfully. Trying out this device with your hearing device is the best way to evaluate it for your personal needs.

This device has been tested and rated for use with hearing aids for some of the wireless technologies that it utilizes. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult your service provider or the manufacturer of this phone for information on hearing aid compatibility.

Microwaves

The radio in the Dolphin RF terminal operates on the same frequency band as a microwave oven. Therefore, if you use a microwave within range of the Dolphin RF terminal you may notice performance degradation in your wireless network. However, both your microwave and your wireless network will continue to function.

1 - 6

Preliminary Draft 5/26/13, Not for Release

Getting Started

Out of the Box

Verify that the carton contains the following items:

•Dolphin 70e Black mobile computer (terminal)

•3.7V Li-ion rechargeable battery

•USB charge/communication cable

•Power adapter with regional plug adapters

•Quick start guide

•Compliance Regulatory Sheet

If you ordered accessories for your terminals, verify that they are also included with the order. Be sure to keep the original packaging in the event that the Dolphin terminal should need to be returned for service.

Note: Your Dolphin model may differ from the model illustrated in this guide; however, the features noted are standard for all Dolphin 70e Black models with Windows® Embedded Handheld unless otherwise indicated.

Initial Setup for Dolphin 70e Black Terminals

Step 1. Install the Battery

Note: Before installing the main battery, read the Guidelines for Battery Pack Use and Disposal on page 3-13.

Dolphin 70e Black model terminals are designed for use with battery part numbers BAT-STANDARD-01 (Li-ion 3.7V, 6.179 watt hour) and BAT-EXTENDED-01 (Li-ion 3.7V, 12.358 watt hour) manufactured for Honeywell International Inc.

The terminal is shipped with the battery packaged separate from the unit. Perform the steps illustrated below to install the battery. For information on how to remove the battery, see Replacing the Main Battery on page 2-12.

!Ensure all components are dry prior to placing the battery in the terminal. Mating wet components may cause damage not covered by the warranty.

1
2	5	3
4	5	3

2 - 1

Preliminary Draft 5/26/13, Not for Release

Step 2. Charge the Battery

The power source for the Dolphin terminal is the 3.7V Li-ion rechargeable battery located under the battery door on the back panel of the device. See Batteries on page 3-10 for additional information on battery storage, use, and disposal.

Important: Removing the battery from the terminal erases all non-persistent memory. Always power off the terminal before removing the battery. For information on how to remove the battery from the terminal, see Replacing the Main Battery on page 2-12.

Before Initial Use

Dolphin terminals ship with the battery significantly discharged of power. After installing the battery in the terminal, charge the battery with a Dolphin 70e Black charging peripheral for a minimum of 4 hours for the standard battery pack or 6 hours for the extended battery pack.

Note: Inadequate source current may interfere with effective battery charging; see Important Charging Guidelines on page 3-11 for additional information.

! We recommend use of Honeywell peripherals, power cables, and power adapters. Use of any non-Honeywell peripherals, cables, or power adapters may cause damage not covered by the warranty.

Dolphin 70e Black model terminals are designed for use with the following charging devices and cables: 70e-HB, 70e-CB, 70e-MB, 70e-MC, and 70e-USB ADAPTERKIT. See pages 3-2 and 3-3 for additional information on Dolphin 70e Black peripherals and accessories.

!Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty.

Using the USB Charge/Communication Cable (Model 70e-USB ADAPTERKIT)

Dolphin 70e Black terminals ship with a USB Charge/Communication Cable and a power adapter with regional plug adapters. The USB Charge/Communication cable provides two options for charging the terminal. Use the cable in conjunction with the provided power supply adapter and plug adapter to charge the terminal from a power outlet or connect the cable to a high-power USB port to charge from a host device.

! Warning - The terminal shall only be connected to CTIA certified adapters, products that bear the USBIF logo or products that have completed the USB-IF compliance program when using the micro USB port as a charging source.

2 - 2

Preliminary Draft 5/26/13, Not for Release

Option 1: Charging from a power outlet

Use only a UL Listed power supply, which has been qualified by Honeywell with an output rated at 5VDC and 1A with the device.

5	Right Side Panel of Dolphin 70e Black
	Right Side Panel of Dolphin 70e Black
	1
USB Door	Micro USB Port

Power

Adapter

Plug Adapter

3	USB Charging/
	Communication Cable

Option 2: Charging from a high power USB port on a host device (PC)

Charging the battery through a USB port takes more time than direct charging using the provided power supply. Inadequate source current may lengthen the charge time or prevent the battery from charging if the terminal is drawing more current than supplied by the USB port. See Important Charging Guidelines on page 3-11 for additional information.

USB Door 1

Right Side Panel of Dolphin 70e Black

Micro USB

Port

USB Port on Host Device

USB Charge/

Communication Cable

Touch > Settings > System > Power to view the battery charge status.

To access detailed information on the battery, touch > Settings > System > Battery.

2 - 3

Preliminary Draft 5/26/13, Not for Release

Step 3. Boot the Terminal and Access the Home Screen

The terminal begins booting as soon as power is applied. Do not press any keys or interrupt the boot process. When the boot process is complete, the Home screen appears depending on your Dolphin model.

Note: During the initial charging stage, the terminal display may dim to conserve battery power due to inactivity. Touch the display to turn on the backlight.

The Home Screen

After the Dolphin terminal initializes, the Home screen appears.

Title Bar (page 2-5)

Touch a menu item to access additional screens.

Swipe up or down with your finger or stylus to scroll through the menu items.

Touch

to access

Tile Bar (page 2-7)

the Start menu.

Touch to access the

Touch to access the Clock &

Contacts screen.

Alarms settings screen.

2 - 4

Preliminary Draft 5/26/13, Not for Release

Title Bar

The Title bar, located at the top of the screen, displays the active program, the status of various system functions, and the current time. Touching on the title bar provides access to the Horizontal Scroll. The scroll provides access to additional programs and application screens. For additional information, see Horizontal Scroll on page 2-7.

Icons in the Title Bar

Indicator Meaning

Synchronizing data

The terminal could not synchronize data with the workstation via ActiveSync.

New e-mail

New text message

New voicemail

New instant message

Vibrate on

Ringer off

Speaker phone on

Voice call in progress

Calls are forwarded

Call on hold

Missed call

Data call in progress

A battery error has occurred. Replace the main battery with a Honeywell Li-ion battery pack.

Battery is has a full charge

2 - 5

Honeywell 70ELGN, 70ELG0, 70EL00 User Guide

Preliminary Draft 5/26/13, Not for Release

Icons in the Title Bar

Indicator Meaning

Battery has a high charge

Battery has a medium charge

Battery has a low charge

Battery has a very low charge and requires charging

Terminal is running on external power. If a battery pack is installed, the battery is charging in the background.

The terminal is not connected to external power. A battery is installed, but is defective; specifically, its charge level cannot be measured.

No SIM card is installed

Active network connection

No active network connection

GPRS available

GPRS connecting

GPRS in use

HSDPA available

HSDPA connecting

HSDPA in use

EDGE available

EDGE connecting

EDGE in use

UMTS available

UMTS connecting

UMTS in use

2 - 6

Preliminary Draft 5/26/13, Not for Release

Icons in the Title Bar

Indicator Meaning

Radio is off

The radio is not connected to a network.

The radio is connected. The bars indicate the signal strength.

No radio signal

The terminal is searching for a signal.

Wi-Fi is on, but device is not connected

Wi-Fi data call

Pending alarm

Bluetooth

Horizontal Scroll

The Horizontal Scroll, located at the top of most application windows, provides access to additional application screens. You can swipe left or right on the scroll or touch each label on the scroll, until you get to the desired screen. Touching a label to the left or right of the center item brings new labels into view.

Note: Touch the Title bar to access the horizontal scroll if it is not visible on the screen.

The content of the Horizontal scroll changes according to the open application.

Tile Bar

The Tile Bar is located at the bottom of an application window.

Touch

to access the

The Tile Bar displays icons you

Start menu (page 2-9).

use to open and close screens,

menus, and features.

The icons change according to the open application.

2 - 7

Preliminary Draft 5/26/13, Not for Release

Virtual Keyboard

The virtual keyboard appears when you open an application or select a field that requires text or numerical input. You can also touch the keyboard icon on the tile bar to toggle the keyboard on or off.

Touch the keyboard icon to toggle the virtual keyboard on or off.

When you touch an hold the keyboard icon, a pop-up menu allows you switch between the default enhanced Honeywell virtual keyboard, which is fully customizable or the standard Windows Embedded Handheld virtual keyboard.

The Enhanced Honeywell Virtual Keyboard

During text input, you may need to switch between keyboard modes to access additional character sets (e.g., function keys, symbols, and numbers). Each keyboard mode, includes navigation keys, which allow you to quickly switch between modes. Touch the ABC key to switch to the Qwerty Mode, the 123 key to switch to the Numeric Mode, and the #@& key to switch to the Function & Symbols Mode.

Note: The content of the keyboard and the mode initially displayed may vary depending on the application in use and the input field requirements.

Alternate Keys

Some keys include a second symbol in red. In order to use the alternate symbol, press and hold the key until the alternate symbol appears, then release the key to type the symbol.

Honeywell Virtual Keypad Creator

The default enhanced Honeywell virtual keyboard is fully customizable using the Honeywell Virtual Keypad Creator software available for download at www.honeywellaidc.com. The user-friendly utility allows you to personalize multiple keyboard features including key position, size, quantity, color, and the keyboard skin. In addition, you can make language changes, create alternate or function keys for special character sets, and add application launch keys to streamline common business tasks.

There are two software components required for customizing the enhanced Honeywell Virtual keyboard.

•The first is the Honeywell Virtual Keypad Creator, which resides on your PC and is used to design, save, and download custom keyboard layouts to your Dolphin terminal.

•The second is the enhanced Honeywell virtual keyboard CAB file (i.e., HoneywellVK-Ver1.x.x.CAB), which is located in the \IPSM\Honeywell\AutoInstall folder on your Dolphin terminal. This keyboard file is what displays on the terminal screen when the enhanced Honeywell virtual keyboard is selected as the default virtual keyboard.

The customization process is easy. Simply download and install the Virtual Keypad Creator software onto your PC, open and modify the provided standard template, then download the customized keyboard to your terminal via a USB connection and the built in software sync command. Touch OK on the terminal to verify you want the current enhanced Honeywell virtual keyboard replaced with the new customized keyboard.

2 - 8

Preliminary Draft 5/26/13, Not for Release

The Start Menu

To see the programs loaded on your terminal, touch to access the Start menu.

Navigating the Start Menu

•Swipe up or down with your finger or stylus to scroll through the menu icons.

•To open a program, touch once on the program icon.

•To reposition an icon on the Start menu, touch and hold the stylus on the icon, then drag the icon to the desired position.

Pop-Up Menus

With pop-up menus, you can quickly choose an action for a selected item. To access a pop-up menu, touch and hold on the item name of the action you want to perform. When the menu appears, touch the action you want to perform.

Touch anywhere outside the menu to close the menu without performing an action.

2 - 9

Preliminary Draft 5/26/13, Not for Release

File Explorer

You can use the File Explorer to find files and organize files into folders.

Touch

> File Explorer

Touch on the name to open a file or folder.

Touch to toggle the virtual keyboard display on or off.

Touch and hold to access a pop-up menu of keyboard options.

Touch to return to the Start menu.

Touch to access additional Menu options.

Touch to close

File Explorer.

Touch to move Up one level in the directory.

To move or copy files between folders using File Explorer:

1.Touch and hold on the item you want to move, then touch Cut or Copy on the popup menu.

2.Navigate to the folder you want to move or copy the file to, then touch and hold a blank area of the window.

3.Touch Paste on the pop-up menu.

Note: If there is no blank space available in the window, touch Menu on the tile bar, navigate to the end of the menu using the down arrow, then touch Edit > Paste.

2 - 10

Preliminary Draft 5/26/13, Not for Release

File Provisioning on the Dolphin 70e Black

\IPSM\Honeywell

The IPSM folder is the only partition on the terminal that persists across a kernel upgrade (*.UPG file extension). During a kernel upgrade, files are automatically copied from the \IPSM\Honeywell folder and then installed in the \Honeywell (root file system) folder as part of the upgrade process.

\IPSM\Honeywell\AutoInstall

The files in the IPSM\Honeywell\AutoInstall folder are only installed when a factory reset or kernel upgrade occurs. Once the files are installed, they persist through hard and soft resets. If a file is added to the folder and a hard or soft reset is performed, it will have no effect. If a program is manually removed using the Remove Programs application (see page 6-25), then the program is not automatically re-installed on a hard or soft reset.

\Honeywell

The Honeywell partition or root file system partition is persistent over a hard reset, soft reset, and the removal of the battery pack or the removal of AC power. However, during a kernel upgrade the root file system is reformatted so all data in the folder is deleted and replaced by any files in the \IPSM\Honeywell folder as part of the upgrade process.

!To prevent data loss, back up all user data to an SD card or external memory device before performing an upgrade.

\Honeywell\AutoInstall

If you run a CAB file from within the \Honeywell\AutoInstall (user store) folder, after the program has been installed, the CAB file will be deleted from the User Store. However, the program remains installed through all successive Hard and Soft resets.

If you want the program to be part of the Autoinstall that occurs after a factory reset or software upgrade, paste the program file(s) in both the \IPSM\Honeywell\Autoinstall folder and the

\Honeywell\Autoinstall.

Contact a Honeywell technical support representative for information on how to perform a factory reset or for information on available software upgrades for your Dolphin terminal. For contact information, see Technical Assistance on page 14-1.

!To prevent data loss, back up all user data to an SD card or external memory device before performing an upgrade.

The Search feature helps you quickly locate information. Touch > Search Phone .

Enter the text you want to find, select a data type, and then touch Search. Select Larger than 64 KB in the Type drop-down field to quickly find information that is taking up storage space.

2 - 11

Preliminary Draft 5/26/13, Not for Release

Turning Power On/Off

To turn the terminal On, press the Power button .

To turn the terminal Off:

1.Press and hold the Power button for approximately 4 seconds until the options menu displays.

2.Touch Power off.

Note: You should always turn the terminal Off before removing the battery. For information on removing the battery, see Replacing the Main Battery on page 2-12.

Suspend Mode

Suspend mode differs from Power off mode. Power off mode is the equivalent to having no battery or external power source connected to the device. The terminal does not receive incoming calls when power is off since the device completely shuts down. In Suspend mode, the device enters a low power state to conserve battery power. The radio associated with the phone maintains enough power to wake the terminal for incoming phone calls.

Suspend mode automatically turns the touch screen off to save battery power when the terminal is inactive for a programmed period of time. The automatic timeout limits are adjustable from the Advance tab located under Settings > System > Power (see page 6-23).

Press and release the Power button to toggle the terminal in or out of Suspend mode.

Replacing the Main Battery

Note: Before replacing the main battery, read the Guidelines for Battery Pack Use and Disposal on page 3-13.

!Ensure all components are dry prior to mating terminals/batteries with peripheral devices. Mating wet components may cause damage not covered by the warranty.

1.Power off the terminal, see Turning Power On/Off.

2.Remove the battery door, pull back the battery latch, then remove the battery.

2 - 12

Preliminary Draft 5/26/13, Not for Release

3.Pull the battery latch back and insert the new battery. Attach the battery door.

Note: Do not attempt to use the terminal without the battery door installed.

4.The terminal begins booting as soon as power is applied.

!We recommend use of Honeywell Li-ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty.

Resetting the Terminal

There are three types of system resets: a Soft Reset, a Hard Reset, or a Factory Reset. The soft and hard resets preserve all data stored in the file system. Contact a Honeywell technical support representative for more information on how to perform a Factory Reset. For contact information, see Technical Assistance on page 14-1.

A Soft Reset (Warm Boot) re-boots the device and preserves any objects created in RAM. You would perform a soft reset when: the terminal fails to respond, after installing some software applications, or after making changes to certain system settings, such as network cards.

A Hard Reset (Cold Boot) re-boots the terminal and closes any open applications running in RAM at the time of the reset.

To perform a Soft Reset or Hard Reset:

1.Press and hold the Power button until the options menu appears.

2.Touch Soft Reset or Hard Reset on the menu.

3.When the reset is complete, the Home screen displays.

Note: To perform a Hard Reset if the touch screen has stopped responding, press and hold the Power button for approximately 8 seconds until the terminal starts to re-boot. When the reset is complete, the Home screen displays.

2 - 13

Preliminary Draft 5/26/13, Not for Release

2 - 14

Preliminary Draft 5/26/13, Not for Release

Hardware Overview

Standard Configurations for the Dolphin 70e Black

WLAN, WPAN & Camera

•Microsoft Windows Embedded Handheld 6.5 Professional

•TI OMAP3715 1.0GHz Processor

•512MB RAM X 1GB Flash

•3.7V Li-ion rechargeable standard or extended battery pack

•Dedicated imager capable of decoding standard 1D and 2D bar code symbologies

•5.0 megapixel auto focus camera

•802.11a/b/g/n and Bluetooth

WLAN, WPAN, WWAN, GPS & Camera

WLAN, WPAN, WWAN, NFC, GPS & Camera

•Microsoft Windows Embedded Handheld 6.5 Professional

•TI OMAP3715 1.0GHz Processor

•512MB RAM X 1GB Flash

•3.7V Li-ion rechargeable standard or extended battery pack

•Dedicated imager capable of decoding standard 1D and 2D bar code symbologies

•5.0 megapixel auto focus camera

•802.11a/b/g/n and Bluetooth,

•Voice and Data, GSM/CDMA/GPS (US bands) - SW Definable Radio

•Microsoft Windows Embedded Handheld 6.5 Professional

•TI OMAP3715 1.0GHz Processor

•512MB RAM X 1GB Flash

•3.7V Li-ion rechargeable standard or extended battery pack

•Dedicated imager capable of decoding standard 1D and 2D bar code symbologies

•5.0 megapixel auto focus camera

•802.11a/b/g/n and Bluetooth

•Voice and Data, GSM/CDMA/GPS (US bands) - SW Definable Radio

	•	NFC
WLAN, WPAN, WWAN, GPS & Camera	WLAN, WPAN, WWAN, NFC, GPS & Camera
• Microsoft Windows Embedded Handheld	•	Microsoft Windows Embedded Handheld
6.5 Professional		6.5 Professional
• TI OMAP3715 1.0GHz Processor	•	TI OMAP3715 1.0GHz Processor
• 512MB RAM X 1GB Flash	•	512MB RAM X 1GB Flash
• 3.7V Li-ion rechargeable standard or	•	3.7V Li-ion rechargeable standard or
extended battery pack		extended battery pack
• Dedicated imager capable of decoding	•	Dedicated imager capable of decoding
standard 1D and 2D bar code symbologies		standard 1D and 2D bar code symbologies
• 5.0 megapixel auto focus camera	•	5.0 megapixel auto focus camera
• 802.11a/b/g/n and Bluetooth	•	802.11a/b/g/n, and Bluetooth
• Voice and Data GSM/GPS (EU Bands)	•	Voice and Data, GSM/GPS (EU Bands)
	•	NFC

3 - 1

Preliminary Draft 5/26/13, Not for Release

Peripherals for the Dolphin 70e Black

Each of the following items is sold separately to enhance the capabilities of your Dolphin terminal.

Dolphin 70e Black HomeBase Device (Model 70e-HB)

The Dolphin 70e Black HomeBase device is a charging and communication cradle equipped with a USB host port that is Hi-Speed 2.0v compliant, which enables the terminal to interface with the majority of PCbased enterprise systems. This device also contains an auxiliary battery well that charges a spare Honeywell standard or extended battery pack.

For more information, see Dolphin 70e Black HomeBase Device (Model 70e-HB) on page 11-1.

Dolphin 70e Black Mobile Base Device (Model 70e-MB)

The Dolphin 70e Black Mobile Base is a charging cradle designed specifically for in-premise and intransit data collection applications. It features a flexible mounting bracket, an integrated speaker with volume control, and a cigarette lighter adapter to adapt it to your mobile environment.

For more information, see Dolphin 70e Black Mobile Base Device (Model 70e-MB) on page 12-1.

Dolphin 70e Black ChargeBase (Model 70e-CB)

The Dolphin 70e Black ChargeBase is a 4-slot charging cradle that holds, powers, and charges terminals.

For more information, see Dolphin 70e Black ChargeBase Device (Model 70e-CB) on page 13-1.

3 - 2
