Honeywell 5380, 5180, 5080 User Manual

5X80 Series

Software Development Kit (SDK) for 5080, 5180, and 5380 Decoded Miniature Image Scan Engines

User’s Guide

Disclaimer

Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII.

Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies and are the property of their respective owners.

Web Address: www.honeywellaidc.com

Table of Contents

Chapter 1 - Introduction

Features of the 5X00 Series ................................................................................................1-1

Target Operating Systems for the 5X00 Series ...................................................................1-1

Interface Diagram ................................................................................................................1-2

5X00 Series Library Files.....................................................................................................1-2

5X00 Series API Library Summary ......................................................................................1-3

Data Types, Structures, and Enumerated Types.................................................................1-5

Chapter 2 - API Function Descriptions

hhpAcquireImage ..........................................................................................................2-1

hhpAcquireIntelligentImage ...........................................................................................2-1

hhpCancelIo ..................................................................................................................2-2

hhpCaptureBarcode ......................................................................................................2-2

hhpCaptureRawBarcode ...............................................................................................2-2

hhpConnect ...................................................................................................................2-3

hhpDisconnect ..............................................................................................................2-3

hhpEnableDisableSymbology .......................................................................................2-3

hhpEngineConnected ....................................................................................................2-4

hhpGetAsyncResult ......................................................................................................2-4

hhpGetErrorMessage ....................................................................................................2-4

hhpGetLastImage ..........................................................................................................2-4

hhpNamedConnect .......................................................................................................2-5

hhpRawAcquireIntelligentImage ...................................................................................2-5

hhpReadConfigItem ......................................................................................................2-6

hhpReadConfigStream ..................................................................................................2-7

hhpReadEngineInfo ......................................................................................................2-8

hhpReadImagerCapabilities ..........................................................................................2-8

hhpReadSymbologyConfig ...........................................................................................2-8

hhpReadSymbologyRangeMaxMin ...............................................................................2-9

hhpSendActionCommand .............................................................................................2-9

hhpSendMessage .........................................................................................................2-9

hhpSetAsyncMethods .................................................................................................2-10

hhpSetBarcodeDataCodePage ...................................................................................2-10

hhpSetConfigItemToDefaults ......................................................................................2-10

hhpSetHardwareLineDllFileName ...............................................................................2-11

hhpSetSymbologyDefaults ..........................................................................................2-11

hhpUpgradeFirmware .................................................................................................2-11

hhpWriteConfigItem ....................................................................................................2-12

hhpWriteConfigStream ................................................................................................2-13

hhpWriteSymbologyConfig ..........................................................................................2-14

Symbology Identifiers.........................................................................................................2-14

Chapter 3 - Enumerated Types and Definitions

Error Codes ...................................................................................................................3-1

Setup Type Enumerated Type.......................................................................................3-2

Symbology ID Enumeration........................................................................................... 3-2

Supported OCR Fonts ................................................................................................... 3-3

Image Formats............................................................................................................... 3-3

Compression Mode Formats .........................................................................................3-4

Capture Illumination Duty Cycle ....................................................................................3-4

Auto Exposure Type ...................................................................................................... 3-4

Gain Values Enum.........................................................................................................3-4

Frame Rates Enum........................................................................................................ 3-4

Beeper Volume Enum.................................................................................................... 3-5

Decoder Mode Enum.....................................................................................................3-5

System (MPU) Clock Speeds ........................................................................................ 3-5

Configuration Structure Item Enum for hhpReadConfigItem() and hhpWriteConfigItem()3-5

Trigger Modes Enum ..................................................................................................... 3-6

Sequence Mode............................................................................................................. 3-6

Serial Port Baud Rates .................................................................................................. 3-6

Baud Rates that Require USB Serial or SIO950 Compatible Serial Port Driver............ 3-6

Serial Data Bits.............................................................................................................. 3-7

Parity.............................................................................................................................. 3-7

Stop Bits ........................................................................................................................3-7

Connection Types..........................................................................................................3-7

Decoder Symbology Support.........................................................................................3-8

HHP Action Commands.................................................................................................3-8

On/Off Enum..................................................................................................................3-8

Beep Execute Enum...................................................................................................... 3-8

Imager Type Enum ........................................................................................................ 3-8

Illumination Color Enum (5X10/5X80 engines only) ...................................................... 3-8

Chapter 4 - Structures and Mask Definitions

Symbology Structures and Defines ..................................................................................... 4-1

Imaging Structures and Defines .......................................................................................... 4-6

Other Imager Configuration Structures and Defines ........................................................... 4-9

Chapter 5 - OEM-Configurable SDK Functionality

OEM Supplied DLL.............................................................................................................. 5-1

ConfigureCommPort ..................................................................................................... 5-1

ImagerPoweredDown ................................................................................................... 5-1

ModifyCommPortDCB .................................................................................................. 5-1

SetCommDriverHandle ................................................................................................. 5-1

SetHardwareTrigger ..................................................................................................... 5-2

WakeUpImager ............................................................................................................. 5-2

Registry Entries ................................................................................................................... 5-2

Baud Rate...................................................................................................................... 5-2

ForceHmodem............................................................................................................... 5-2

Chapter 6 - Program Samples

Configuration Management ................................................................................................. 6-1

Barcode Capture .................................................................................................................6-2

Image Capture..................................................................................................................... 6-5

Chapter 7 - Customer Support

Product Service and Repair................................................................................................. 7-1

Online Product Service and Repair Assistance ............................................................. 7-1

Technical Assistance........................................................................................................... 7-2

Online Technical Assistance.......................................................................................... 7-2

iii

Introduction

The 5X10/5X80 Software Development Kit (5X00 Series) provides a set of libraries, tools, and sample source code to help software developers create an interface between their host system and a Honeywell miniature image scan engine. The 5X00 Series consists of:

• The API Definition and Documentation

• API Libraries

• Sample Code

Features of the 5X00 Series

• The 5X00 Series contains software libraries that interact with image/data capture engines using a documented API (Application Programming Interface). The API functions are defined on a higher level so they can be easily understood and integrated into your applications, so you don’t have to learn minute details of the engine interface protocol. You simply compile your code with the library header files and link in the library for your platform. Afterward, all engine functionality is at your disposal.

• The image/data capture engine is easily integrated into a variety of host platforms.

• The 5X00 Series captures images and returns them as unformatted data, or as one of the standard file formats (BMP, TIFF, and JPG). Captured images can then be saved to disk and easily imported into a variety of common tools and applications.

• A single API is used for all Honeywell decoding engines. The libraries for all engines are identical for a given host platform. There are different libraries for each platform, but the API interface is the same for all of them, so you only need to learn a single API.

• Libraries are available for the Microsoft operating system, Windows

• Sample code is included that demonstrate how to use specific aspects of the 5X00 Series, as well as the buildable source and executable code for a demo application.

• The communication driver library is separate from the main engine API library.

9x, and Windows NT® derivatives.

Windows® family of operating systems. This includes both the Windows® CE

Target Operating Systems for the 5X00 Series

The 5X00 Series is designed for use with the following operating systems:

•Windows processors:

Pocket PC 2000ARM, MIPS, SH3 PocketPC 2002ARM PocketPC 2003ARMV4 CE.Net Standard SDK ARMV4, ARMV4I, ARMV4T, SH3, SH4, X86

•Windows

CE versions WinCE 4.2, WinCE 5.0, Windows® Pocket PC 2000, and Pocket PC 2002 supporting the following

9x, Windows NT® 4.0, Windows® 2000 and Windows® XP

1 - 1

Interface Diagram

User Application

SDK Driver Interface Layer - hhpImgrSdk.dll

SDK API Interface Layer - commDrv.dll

OS Communications Driver

Physical Connection: RS-232, USB, etc.

Image Engine

SDK API Interface Layer - commDrv.dll

Physical Connection: RS-232, USB, etc.

The following diagram shows the interface between the 5X00 Series and the Image Engine:

5X00 Series Library Files

The SDK API and SDK communications layers are provided in the dynamic link libraries, hhpImgrSdk.dll and commDrv.dll, respectively. The library link file hhpImgrSdk.lib and the include files hhpImgrSdk.h, hhpSymCfg.h and hhpImgrCfg.h are also provided. In order to use the 5X00 Series, you must include hhpImgrSdk.h in any source files that call the SDK functions. The library include files must be in the include path for the application’s project. This means that the files must either be in the source file build directory, or in the developer’s Studio include path. Also, the library link file, hhpImgrSdk.lib, must be added to the application project link list and link path. Since the .dll and .lib files are operating system and processor type dependent, care must be taken to use the proper files for the chosen target environment.

SDK Library File

commDrv.dll

hhpImgrSdk.dll

hhpImgrSdk.lib Project Link Path

hhpSymCfg.h Project Include Path

hhpImgrCfg.h Project Include Path

hhpImgrSdk.h Project Include Path

OemDll.h Project Include Path

Where Resides Function

Target Device Windows Folder

1 - 2

Sends commands from API to the appropriate OS driver. Handles low level communications protocols.

Contains the exported SDK API. Formats requests into imager commands, then calls commDrv layer.

Library exports file. Allows your application to link without actually including the SDK code at link time.

Definitions, structures, and enumerated types related to symbology setup. Automatically included when hhpImgrSdk.h is included.

Definitions, structures, and enumerated types for imaging as well as all other imager configurations, except communications. Automatically included when hhpImgrSdk.h is included.

Include file that must be included in application code. Contains definitions, structures, and enumerated types for communication configuration, as well as the SDK error codes and SDK function API prototypes.

Only necessary if you create a helper dll for the SDK to provide access to the imager hardware sleep and trigger lines.

5X00 Series API Library Summary

The following is a summary of the API functions. The full description of each function is found on the page noted.

Core Functions

Core Function Summary

Page

Error Management Function

hhpGetErrorMessage Returns a descriptive text string for the specified SDK error code. 2-4

Connection Functions

These functions open, close, and verify a connection to an imager.

hhpConnect

hhpDisconnect Closes down the open imager connection. 2-3

hhpEngineConnected Checks if the connection to the imager is valid. 2-4

hhpNamedConnect

Establishes and initializes a connection to the imager at the specified port and connection settings.

Establishes and initializes a connection to the imager at the specified driver name and connection settings.

2-3

2-5

Asynchronous Notification and Control Functions

Image and barcode capture can be either blocking (synchronous) or non-blocking (asynchronous). In blocking (synchronous) mode, the SDK function call does not return until the barcode or image is received, the request times out, or an error occurs. In non-blocking (asynchronous) mode, the capture call returns immediately. Your application is notified of the completion when either a barcode or an image was received, the time-out for the call was reached, or an error was detected. You can specify which notification methods you wish to receive. Your application can subscribe to one or more of the following notification methods: Windows Event, Windows Message, and/or Callback Function. When notification is received, your application can call hhpGetAsyncResult (see page 2-4) to retrieve the return code as well as the image, barcode, or text data. The asynchronous interface is also the manor in which imager-initiated barcode capture data, such as from a hardware trigger, is returned. There is also a cancel function (see hhpCancelIo on page 2-2) that allows you to cancel any ongoing operation. You should be aware that when the callback function method is used, any processing done during the callback is run within the context of the SDK’s asynchronous read thread. This means that the SDK is unable to receive images or barcodes until the callback returns.

hhpCancelIo Cancels any synchronous or asynchronous I/O in process. 1-3

hhpGetAsyncResult

hhpSetAsyncMethods

Retrieves the results (image/barcode, etc.) of an asynchronous I/O event.

Allows the application to select how it wishes to be notified on completion of an asynchronous I/O event.

2-4

2-10

Imaging and General Configuration Functions

The imaging and configuration functions provide a simplified API for modifying the imager setup, image/barcode capture configuration, and symbology configuration. In order to limit the number of functions a developer must master, the design philosophy is to allow configuration control using only a small number of setup functions. The imager configuration is broken down into functional groups with structures containing the configurable items for each. Individual configuration items are specified within structures by use of a bit field mask. In this way, single configuration items can be read or written using minimal communication traffic. There are functions for reading and writing parts or all of the HHP_CONFIG imager configuration structure as well as writing the setup/configuration for individual symbologies. If the specified symbology is not available in the imager’s version of the symbol decoder, (e.g., Data Matrix in a linear and PDF417 decoder), the symbology functions return RESULT_ERR_UNSUPPORTED. Finally, to facilitate easy configuration management from device to device and application to application, the 5X00 Series also provides methods for retrieving and setting the whole imager configuration as a single stream so it can be saved to disk and restored at a later time.

hhpReadConfigItem

hhpReadConfigStream

Retrieves a single configuration group or whole imager configuration from the imager.

Retrieves the current whole imager configuration as a single buffer. This buffer can be saved to a file and later restored.

2-6

2-7

1 - 3

Core Functions (Continued)

Core Function Summary

hhpReadImagerCapabilities

hhpReadEngineInfo

hhpSetConfigItemToDefaults

hhpWriteConfigItem

hhpWriteConfigStream

Retrieves the imager settings (fixed) for image size, image bit depth, and maximum message length.

Reads information about the image engine contained in the image engine PSOC.

Sets a selected symbology, or all symbology configurations, to their default values.

Writes some or all of the configuration items for a single configuration group or for all configuration groups, with the exception of version and communication groups.

Writes an entire data stream of programmable parameters from a previous call to hhpReadConfigStream.

Page

2-8

2-10

2-12

2-13

Symbology Configuration Functions

These functions allow you to read and set the symbology configurations.

hhpEnableDisableSymbology Enables or disables a single symbology, or all symbologies. 2-3

hhpReadSymbologyConfig

hhpReadSymbologyRangeMaxMin Returns the specified symbology range maximum and minimum values. 2-9

hhpSetSymbologyDefaults Defaults a single symbology, or all symbologies. 2-11

hhpWriteSymbologyConfig

Retrieves the current or default symbology configuration for a specified symbology, or for all symbologies.

Writes some or all of a single symbology, or all symbologies’ configuration items.

2-8

2-14

Barcode Capture Functions

The 5X00 Series captures barcodes from imagers that have hardware triggers or some other non-SDK initiated barcode captures without having to poll the imager to see if there is any data to read. This allows the imager to be put into low power mode without having to wake up to answer the polling message. All barcode result strings are returned in TCHAR arrays, which, if running on a WinCE device or if using a Unicode Desktop build, are 2 bytes per character. You can specify a Unicode code page other than the default ANSI code page (CP_ACP).

Initiates a synchronous (wait for finish before returning from call) or

hhpCaptureBarcode

hhpSetBarcodeDataCodePage

hhpCaptureRawBarcode

asynchronous (return immediately) barcode capture. Decoded data returned is translated by code page and locale.

Specifies the code page used to convert the barcode characters to Windows text. The default is the ANSI code page.

Initiates a synchronous (wait for finish before returning from call) or asynchronous (return immediately) barcode capture. Decoded data returned is unmodified 8 bit (ASCII) data.

2-2

2-10

2-2

Image Capture Functions

The image capture functions provide both synchronous and asynchronous operation. A synchronous capture is specified by setting the bWait parameter of hhpAcquireImage or hhpGetLastImage to TRUE. For synchronous operation, the function will not return until an image has been captured and transferred (hhpAcquireImage), just transferred (hhpGetLastImage), or an error has occurred. Asynchronous captures are specified by setting bWait to FALSE. The function call returns immediately and the caller is notified on request completion as long as at least one of the event notification methods has been enabled. You can receive transfer progress updates by Windows messages or by providing a pointer to a DWORD. Both hhpAcquireImage and hhpGetLastImage allow the caller to override the current imager transfer configuration in the imager.

Initiates a synchronous (wait for finish before returning from call) or

hhpAcquireImage

asynchronous (return immediately) image capture. The image acquisition and transfer parameters can also be specified.

2-1

1 - 4

Core Functions (Continued)

Core Function Summary

Initiates transfer of the last image captured. (This includes images captured

hhpGetLastImage

during barcode scan.) The call can be made synchronously or asynchronously, and the transfer parameters can be specified.

Page

2-4

Intelligent Imaging (Signature Capture) Functions

Intelligent imaging is barcode capture combined with an image window capture. The image window is cut from the same image used to capture a barcode. This is how the SDK provides the ability to capture a signature associated with a barcode. In fact, a successful barcode capture is required before the intelligent image window is sent by the imager. You can specify whether the image is returned grayscale or black and white.

hhpAcquireIntelligentImage Barcode capture combined with an image window capture. 2-1

hhpRawAcquireIntelligentImage Captures portion of the image in which a barcode is decoded. 2-5

Miscellaneous Functions

hhpSendActionCommand

hhpSendMessage Sends menu commands to the imager. 2-9

hhpUpgradeFirmware Upgrades the current imager firmware with a new firmware file. 2-11

hhpSetHardwareLineDllFileName

Turns on illumination LEDs, Aimers, (and sound beeper for imagers that have one) outside the image or barcode capture.

Allows you to specify the name of an OEM dll file. This file can contain some or all of the OemDll exports that provide support for hardware trigger and low power mode hardware lines.

2-9

2-11

Data Types, Structures, and Enumerated Types

The 5X00 Series API uses structures (see Structures and Mask Definitions beginning on page 4-1) and enumerated types (see

Enumerated Types and Definitions beginning on page 3-1) extensively . The definitions are in the include files in the 5X00

Series package. All 5X00 Series-specific structures have a dwStructSize member that must be set to sizeof( struct name ). This insures that the structure being passed to a given function is the structure type expected by the function and, if writing is done to the structure, that the structure size boundary is not exceeded. Furthermore, all imager configuration structures (except the all inclusive structure HHP_CONFIG) have a DWORD member dwMask. The mask allows you to specify only certain members within a structure. Set the mask value by ORing together the appropriate masks for the given structure for the particular items within the structure that should be read/written. Samples of programs that demonstrate this can be found in Program

Samples beginning on page 6-1. This technique is also used by Microsoft

dows

SDK structure CHARFORMAT).

The following Windows

Note: A “P” in front of a data type means a pointer to the type.

data types are included for clarity.

in their Windows® SDK (for example, see Win-

Windows Data Types

BOOL 32 bit signed integer used by most Microsoft SDK functions in place of a true Boolean.

BYTE 8 bit unsigned variable.

DWORD 32 bit unsigned integer variable.

HANDLE

HWND A Windows handle to an application window.

PVOID 32 bit unsigned integer that points to void data type (generic pointer).

TCHAR OS-dependent character variable. 16 bit for Unicode systems, otherwise 8 bits.

WORD 16 bit unsigned integer variable.

A Windows WIN32 handle type. Returned from opening files, creating events, semaphores, or mutexes.

1 - 5

Windows Data Types (Continued)

HHP_EVENT_CALLBACK

Pointer to a callback function (see hhpImgrSdk.h) called in response to the completion of an asynchronous 5X00 Series function call or event. (See example on page 6-4.)

SDK Enumerated Types

Beep Options Enumeration (not an enumerated type) that can be used with an hhpSendActionCommand.

Compression_t

ConfigItems_t

DECODE_METHOD Enumerated type of decode methods available to decode symbols.

DECODER_TYPE Enumeration of types of decoders and, by extension, what symbologies can be decoded.

EngineType_t Describes the connection, the imager, and the type of engine.

FileFormat_t Enumerated type for specifying the format of the data returned in the HHP_IMAGE structure.

HP_ACTION

HHP_AIMER_MODES Enumerated type to specify the aimer mode.

HHP_AUTOEXPOSURE

HHP_BAUD_RATE

HHP_BEEPER_VOLUME

HHP_CONNECT_TYPE

HHP_DATA_BITS Enumerated type for number of serial data bits.

HHP_DUTY_CYCLE

HHP_EVENT_TYPE Enumerated type that describes the type of asynchronous event being reported.

HHP_FRAME_RATE

HHP_GAIN

HHP_PARITY Enumerated type for serial parity.

HHP_SEQ_MODES Enumerated type to specify the sequence acquisition mode.

HHP_STOP_BITS Enumerated type for number of serial stop bits.

HHP_SYS_SPEED

HHP_TRIG_MODES Enumerated type to specify the trigger mode.

OCRDirection_t Enumerated type for setting the text direction for OCR decoding.

OCRMode_t Enumerated type for setting the font for OCR symbology decoding.

On Off Enumeration (not an enumerated type) that can be used with hhpSendActionCommand.

Result_t

SetupType_t

Symbology ID enumeration

Enumerated type for specifying the form of compression (if any) to use when transferring an image from the imager to the SDK. See Compression Mode Formats on page 3-4.

Enumerated type to specify that the configuration structure is being sent to the Read/Write config item functions.

Enumerated type whose items describe which imager command functionality (beeper, aimers, lights) is to be acted upon.

Enumerated type to specify whether the imager tries to auto adjust the image exposure and, if so, how.

Enumerated type of the supported baud rates for serial devices.

Note: A special driver is required if a baud rate greater than 115200 is selected.

Enumerated type to select the imager beeper volume when sounding the beeper. This structure is ignored for products that do not have a beeper.

Enumerated type used in hhpConnect to specify the connection type and connection port where the imager is connected.

Enumerated type to specify the behavior of the illumination and aimer LEDs during image capture.

Enumerated type to select the image capture frame rate. Only valid when no auto exposure is selected.

Enumerated type to select the image capture gain. This type is only valid when no auto exposure is selected.

Enumerated type to specify the rate (in Mhz) at which all components other than the CPU are to be clocked.

Enumerates the function result codes returned by the SDK functions. See Error Codes on page 3-1.

Enumerated type for specifying whether a read configuration item call should return the current settings or the imager default setting.

Enumerates all the available symbologies supported in the imager decoder. Non-data type used in the symbology configuration functions.

1 - 6

SDK Structure Types

A full description of the SDK structure types can be found in Enumerated Types and Definitions beginning on page 3-1.

Note: Important: Make sure to set the structure members dwStructSize and dwMask.

Individual Symbology Structures

All symbologies, except OCR, use either SymFlagsOnly_t or SymFlagsRange_t for configuration. There is a define for each symbology (except OCR) that points to one of these two structures.

SymFlagsOnly_t Structure for symbologies that don’t have minimum and maximum data lengths.

SymFlagsRange_t Structure for symbologies that have minimum and maximum data lengths.

SymCodeOCR_t or OCR_T Structure to configure OCR symbology.

Configuration Structures

HHP_BEEPER

HHP_CONFIG Super structure whose members are all the other configuration structures.

HHP_DECODE_MSG Returns decoded, code page and locale-translated data output from the SDK.

HHP_DECODER_CONFIG Configures decoding behavior other than symbology setup.

HHP_ENGINE_INFO

HHP_IMAGE

HHP_IMAGE_ACQUISITION

HHP_IMAGE_TRANSFER

HHP_IMAGER_CAPS

HHP_INTEL_IMG

HHP_POWER_SETTINGS Configures the power management options of the imager.

HHP_RAW_DECODE_MSG Returns raw (8 bit ASCII) decoded data output from the SDK.

HHP_SERIAL_PORT_CONFIG Specifies serial port configuration for serial imagers.

HHP_SEQUENCE Specifies how the sequence acquisition mode is configured.

HHP_SYM_CONFIG Contains a list of all the structures for all the symbologies.

HHP_TEXT_MSG

HHP_TRIGGER Configures the trigger mode of the imager.

HHP_VERSION_INFO Queries imager and SDK software revisions.

Configures whether the beeper sounds on power up, decode, or command processing. This is ignored if the imager does not have a beeper.

Structure used by the hhpReadEngineInfo (page 2-8) call that returns information about the image engine. (5X80 engines with PSOC only.)

Returns image data from the SDK. It also specifies the format in which the image data is returned.

Specifies how images are captured by the imager. This includes gain, exposure, frame rates, and illumination.

Specifies how images are shipped from the imager to the SDK. This includes image processing items such as cropping, subsampling, histogram stretching, and transfer compression.

Retrieves the fixed characteristics of the imager: full image size, capture bits per pixel, and maximum text/barcode message size (sent from imager). Structure in which

hhpReadImagerCapabilities returns requested capabilities information.

Specifies the location and size of the image returned as part of an intelligent image capture. The location information is specified in minimum bar widths of the barcode portion of the intelligent image.

Returns non-decoded data output from the SDK. The data is translated by code page and locale.

1 - 7

1 - 8

API Function Descriptions

The following is an alphabetic listing of each API function with its complete description and a prototype for each function. All API functions (with the exception of hhpEngineConnected (page 2-4) return a result code of type Result_t. See Error Codes on page 3-1 for the result code values.

hhpAcquireImage

This function causes the imager to capture an image and transfer it to the host. Values to be used from the structures are specified by setting the appropriate bit mask for each item in the structure’s mask member.

hhpAcquireImage( PHHP_IMAGE pImg, PHHP_IMAGE_TRANSFER pImgTrans, PHHP_IMAGE_ACQUISITION pImgAcqu,

BOOL bWait

)

Parameter Description

pImg Pointer to an HHP_IMAGE structure if bWait is TRUE. If bWait is FALSE, the parameter

is ignored and should be NULL.

pImgTrans Optional pointer to an HHP_IMAGE_TRANSFER structure. This structure overrides (just

for this call) the current imager configuration, and specifies the pixel subsample, cropping rectangle, transfer compression type, compression factor (for JPEG lossy transfer), and progress notification method. If this parameter is NULL, the current imager configuration settings are used except for the progress notification methods that must be specified for each call if notification is desired.

pImgAcqu Optional pointer to an HHP_IMAGE_ACQUISITION structure. This structure overrides

(just for this call) the current imager configuration, to specify and configure the image capture method (type of autoexposure control or manual mode). If this parameter is NULL, the current imager configuration settings are used.

bWait If TRUE, do not return until the image is received or an error occurs. If FALSE, return

immediately. One of the event notification methods must be enabled to receive notification on completion. (See hhpSetAsyncMethods on page 2-10.)

hhpAcquireIntelligentImage

The location of the window of interest must be provided in units of minimum barcode widths. This allows the imager to grab the same physical window, no matter how far the imager is from the page. The resultant image window is always squared with the X and Y axis of the returned image, so even if the barcode page is rotated relative to the imager, the resultant image appears square to the image edges.

There is only one intelligent image call that supports both synchronous and asynchronous capture. If synchronous capture is used, all members of this structure must be valid. If asynchronous capture is used, you will receive HHP_INTELIMG_BARCODE_EVENT for the barcode data, and HHP_INTELIMG_IMAGE_EVENT for the image data. The barcode data is returned in a normal barcode structure (HHP_DECODE_MSG), while the intelligent image data is returned in an HPP_IMAGE structure.

Note: Since the HHP_INTEL_IMG structure requires that image offsets and size be specified in barcode units, the

HHP_INTEL_IMG structure has a size member that allows you to specify (in pixels) the maximum allowable width and height for the returned image.

hhpAcquireIntelligentImage( PHHP_INTEL_IMG pIntelImg, PHHP_DECODE_MSG pDecodeMsg,

DWORD dwTimeout,

PHHP_IMAGE pImg,

BOOL bWait

)

2 - 1

Parameter Description

pIntelImg Pointer to an HHP_INTEL_IMG structure that contains the setup parameters describing

the location of the intelligent image relative to the barcode.

pDecodeMsg Pointer to an HHP_DECODE_MSG structure if bWait is TRUE. If bWait is FALSE, the

parameter is ignored and should be NULL. The intelligent image barcode information is

returned here. dwTimeout Maximum time (in milliseconds) to attempt to decode before declaring a no decode. pImg Pointer to an HHP_IMAGE structure if bWait is TRUE. If bWait is FALSE, the parameter

is ignored and should be NULL. bWait If TRUE, do not return until the image is received or an error occurs. If FALSE, return

immediately. One of the event notification methods must be enabled to receive notification

on completion. (See hhpSetAsyncMethods on page 2-10.)

hhpCancelIo

Cancels the current barcode or image capture.

hhpCancelIo( void )

hhpCaptureBarcode

This function causes the imager to capture images and attempt to decode them. Decoded data returned is translated by code page and locale. Barcode capture can be synchronous or asynchronous. Synchronous capture is specified by setting the bWait parameter hhpCaptureBarcode to TRUE. In this case, the function will not return until a barcode is read, an error occurs, or the decode timeout is reached. Asynchronous capture is specified by setting the bWait parameter hhpCaptureBarcode to FALSE, or whenever a barcode capture is initiated other than by the 5X00 Series (e.g., from a hardware trigger). In order to be notified of an asynchronous transfer, you must enable at least one of the notification methods (see hhpSetAsyncMethods on page 2-10).

hhpCaptureBarcode( PHHP_DECODE_MSG pDecodeMsg,

DWORD dwTimeout, BOOL bWait

)

Parameter Description

pDecodeMsg Pointer to an HHP_DECODE_MSG structure if bWait is TRUE.

If bWait is FALSE, the parameter is ignored and should be NULL. (HHP_DECODE_MSG

will be passed to hhpGetAsyncMethods() call instead.) The function returns immediately,

and you are notified when symbols are decoded, an error occurs, or decoding times out

(no barcode) using the specified event notification method(s). dwTimeout Maximum time (in milliseconds) to attempt to decode before declaring a no decode. A

value of CURRENT_DECODE_TIMEOUT specifies that the timeout is whatever is

currently set on the imager. A value of 0 indicates no timeout. bWait If TRUE, wait for capture to complete before returning. If FALSE, one of the event

notification methods must be enabled to receive notification upon completion.

hhpCaptureRawBarcode

This function causes the imager to capture images and attempt to decode them. Decoded data returned is unmodified 8 bit ASCII data. Barcode capture can be synchronous or asynchronous. Synchronous capture is specified by setting the bWait parameter hhpCaptureRawBarcode to TRUE. In this case, the function will not return until a barcode is read, an error occurs, or the decode timeout is reached. Asynchronous capture is specified by setting the bWait parameter hhpCaptureRawBarcode to FALSE, or whenever a barcode capture is initiated other than by the 5X00 Series (e.g., from a hardware trigger). In order to be notified of an asynchronous transfer, you must enable at least one of the notification methods (see hhpSetAsyncMethods on page 2-10).

2 - 2

hhpCaptureBarcode( PHHP_RAW_DECODE_MSG pDecodeMsg,

DWORD dwTimeout, BOOL bWait

)

Parameter Description

pDecodeMsg Pointer to an HHP_RAW_DECODE_MSG structure if bWait is TRUE.

If bWait is FALSE, the parameter is ignored and should be NULL. (HHP_DECODE_MSG

will be passed to hhpGetAsyncMethods() call instead.) The function returns immediately,

and you are notified when symbols are decoded, an error occurs, or decoding times out

(no barcode) using the specified event notification method(s). dwTimeout Maximum time (in milliseconds) to attempt to decode before declaring a no decode. A

value of CURRENT_DECODE_TIMEOUT specifies that the timeout is whatever is

currently set on the imager. A value of 0 indicates no timeout. bWait If TRUE, wait for capture to complete before returning. If FALSE, one of the event

notification methods must be enabled to receive notification upon completion.

hhpConnect

This function opens a connection to an imager. The connection must be closed by calling hhpDisconnect(). The caller can verify that the imager is connected by calling hhpEngineConnected().

Opens the selected communications port and establishes connection with the imager and starts the read data thread.

hhpConnect(

HHP_CONNECT_TYPE connectType, PVOID pStruct

)

Parameter Description

connectType Describes the type of connection and hardware port, e.g., HHP_COM1, HHP_COM2,

HHP_COM3. pStruct An optional structure that contains setup information for the hardware port, or NULL.

PHHP_SERIAL_PORT_CONFIG is used to configure a serial port connection.

hhpDisconnect

Closes the communications port and stops the read data thread.

hhpDisconnect( void )

hhpEnableDisableSymbology

Enables/disables an individual symbology or all symbologies.

hhpEnableDisableSymbology( int nSymId,

BOOL bEnable

)

Parameter Description

nSymId One of the symbology enumerated types, e.g., SYM_CODE39, SYM_OCR, or SYM_ALL

to enable/disable all symbologies. bEnable TRUE to enable symbology, FALSE to disable symbology.

2 - 3

hhpEngineConnected

This function determines whether the imager is connected. This function checks to to see if the imager has lost power (due to the host going into a suspended state), or if the imager has been removed.

hhpEngineConnected( void )

hhpGetAsyncResult

Retrieves the data from the last signal event (image/barcode capture). This function can be called with pResultStruct set to NULL to obtain the event type. This is useful when the notification method is a Windows event.

Result_t hhpGetAsyncResult( hhpEventType_t *pEventType,

PVOID pResultStruct

)

Parameter Description

hEventType Type of data causing the event notification. The valid values are:

HHP_BARCODE_EVENT

HHP_IMAGE_EVENT

HHP_TEXT_ MSG_EVENT

HHP_INTELIMG_BARCODE_EVENT

HHP_INTELIMG_IMAGE_EVENT pResultStruct An HHP_DECODE_MSG, HHP_IMAGE, or HHP_TEXT_MSG structure pointer,

depending on the value of hEventType. This parameter can be NULL if just the event type

is desired. This is of use when the Event Handle notification is used.

hhpGetErrorMessage

This function returns a text message describing the meaning of a Result_t error code. See Error Codes on page 3-1 for complete descriptions.

hhpGetErrorMessage(

Result_t nErrorCode,

PTCHAR ptcErrorMsg, int nMaxChars )

Parameter Description

nErrorCode Error code returned from one of the other 5X00 Series functions. ptcErrMsg TCHAR buffer to hold error message string. nMaxChars Maximum number of characters that can fit in ptcErrorMsg including NULL.

hhpGetLastImage

This function causes the imager to transfer the last image captured to the host. If bWait is TRUE, the function will not return until the image is fully received or an error occurs. If bWait is FALSE, the function returns immediately and you are notified when image transfer has completed or an error has occurred. pImgTrans is an optional parameter and can be NULL. Setting the appropriate bit mask for each item specifies active members of this structure. This function can be used to obtain the image from the last barcode capture attempt as well as the last image from an image capture attempt.

hhpGetLastImage( PHHP_IMAGE pImg, PHHP_IMAGE_TRANSFER pImgTrans,

BOOL bWait

)

2 - 4

Parameter Description

pImg Pointer to an HHP_IMAGE structure if bWait is TRUE. If bWait is FALSE, the parameter

is ignored and should be NULL. pImgTrans Optional pointer to an HHP_IMAGE_TRANSFER structure. This structure overrides (just

for this call) the current imager configuration, and specifies the pixel subsample, cropping

rectangle, transfer compression type, compression factor (for JPEG lossy transfer), and

progress notification method. If this parameter is NULL, the current imager configuration

settings are used except for the progress notification methods that must be specified for

each call if notification is desired. bWait If TRUE, do not return until the image is received or an error occurs. If FALSE, return

immediately. One of the event notification methods must be enabled to receive notification

on completion.

hhpNamedConnect

This function opens a connection to an imager. The connection must be closed by calling hhpDisconnect (page 2-3). The caller can verify that the imager is connected by calling hhpEngineConnected (page 2-4).

hhpNamedConnect( PTCHAR ptcConnectName,

PVOID pStruct

)

Parameter Description

ptcConnectName The name of driver for the hardware port, e.g., "COM1:" or "\\.\COM12." pStruct An optional structure that contains setup information for the hardware port, or NULL.

HHP_SERIAL_PORT_CONFIG is used to configure a serial port connection.

hhpRawAcquireIntelligentImage

Captures a portion of the image in which a barcode is decoded. The position of the image is specified relative to the center of the barcode. This function differs from hhpAcquireIntelligentImage (page 2-1) in that the barcode data is returned as a raw (untranslated) byte data array.

Note: Since the HHP_INTEL_IMG structure requires that image offsets and size be specified in barcode units, the

HHP_INTEL_IMG structure has a size member that allows you to specify (in pixels) the maximum allowable width and height for the returned image.

hhpRawAcquireIntelligentImage( PHHP_INTEL_IMG pIntelImg, PHHP_RAW_DECODE_MSG pRawDecodeMsg,

DWORD dwTimeout,

PHHP_IMAGE pImg,

BOOL bWait

)

Parameter Description

pIntelImg Pointer to an HHP_INTEL_IMG structure that contains the setup parameters describing

the location of the intelligent image relative to the barcode. pRawDecodeMsg Pointer to an HHP_RAW_DECODE_MSG structure if bWait is TRUE. If bWait is FALSE,

the parameter is ignored and should be NULL. The intelligent barcode raw data

(untranslated) is returned here. dwTimeout Maximum time (in milliseconds) to attempt to decode before declaring a no decode. pImg Pointer to an HHP_IMAGE structure if bWait is TRUE. If FALSE, the parameter is ignored

and should be NULL. bWait If TRUE, do not return until the image is received, the decode timeout is reached, or an

error occurs. If FALSE, return immediately. One of the event notification methods must

be enabled to receive notification of completion (see hhpSetAsyncMethods on page 2-10).

2 - 5

hhpReadConfigItem

Reads the configuration items for one or all of the configuration structures found in the main 5X00 Series configuration structure HHP_CONFIG.

hhpReadConfigItem(

SetupType_t cfgType,

ConfigItems_t item,

PVOID pStruct

)

2 - 6

Parameter Description

cfgType Use SETUP_TYPE_CURRENT for the current settings, or SETUP_TYPE_DEFAULT for

the customer default settings. item One of the members of the enumerated type ConfigItems_t. The valid values are:

BEEPER_CONFIG Returns beeper control settings for devices with audible

beepers. The settings include volume, beep on decode, and beep on reset.

TRIGGER_CONFIG Returns values for all trigger timeouts and current

trigger mode.

DECODER_CONFIG Returns the decoder setup. This includes single

decode, multiple decodes, print weight, centered decode, and aimer.

POWER_CONFIG Contains low power configuration settings: trigger

mode, low power timeout, low power imaging, LED brightness, aimer LED settings, and system clock speed.

VERSION_INFO Returns the SDK, imager firmware, and imager boot

code versions.

SYMBOLOGY_CONFIG Returns the enable and setup parameters for all

symbologies. Individual symbologies can be read by calling hhpReadSymbologyConfig.

SERIAL_PORT_CONFIG If using a serial connection imager, this returns the

serial port setup parameters of the imager.

IMAGE_ACQUISITION Returns the current imager settings for capture mode,

manual exposure, manual gain, manual frame rate, target white value, target window, aimer and illumination duty cycle, and triggering mode (hardware trigger dependent).

IMAGE_TRANSFER Returns the current image transfer protocols, such as

cropping window, pixel subsample, and transfer compression.

SEQUENCE_CONFIG Returns the sequence mode enable/disable state and

the data sequence command string.

ALL_CONFIG All of the above except serial port config. pStruct Pointer to the appropriate structure based on parameter “item:”

HHP_BEEPER

HHP_TRIGGER

HHP_DECODER_CONFIG

HHP_POWER_SETTINGS

HHP_VERSION_INFO

HHP_SYM_CONFIG

HHP_SERIAL_PORT_CONFIG

HP_IMAGE_ACQUISITION

HHP_IMAGE_TRANSFER

HHP_SEQUENCE

HHP_CONFIG

hhpReadConfigStream

Reads the full imager configuration as a single stream of data into a buffer. The buffer contains all the configuration items in an ASCII stream so that it can be written to a disk for storage. No interpretation is done on the data stream, therefore, the data stream contains both read only, and read/write data.

2 - 7

hhpReadConfigStream( PBYTE puchCfgStream, int nMaxLen, PINT pnBytesReturned )

Parameter Description

puchCfgStream Buffer to hold the raw imager configuration stream. nMaxLen Maximum number of bytes that fit in buffer puchCfgStream. pnBytesReturned Pointer to an integer where the number of bytes returned in puchCfgStream is placed.

hhpReadEngineInfo

Reads information about the image engine contained in the image engine PSOC. This call is only valid for imagers that have a PSOC. If the attached imager is not an 5X80 image engine, or the engine does not have a PSOC, the function returns the error code RESULT_ERR_UNSUPPORTED.

hhpReadEngineInfo( PHHP_ENGINE_INFO pEngInfo )

Parameter Description

pEngInfo Pointer to an engine information structure in which the engine information is returned. The

dwStructSize member must be set to size (HHP_ENGINE_INFO) before making the call.

hhpReadImagerCapabilities

Returns the fixed imager capabilities, such as imager bits per pixel or image capture width and height.

Note: As with all other HHP structures, the dwStructSize member of the structure must be set before calling this function. (Set

to sizeof (HHP_IMAGER_CAPS).)

hhpReadImagerCapabilities(

HHP_IMAGER_CAPS pImgrCaps

)

Parameter Description

pImgrCaps Pointer to the HHP_IMAGER_CAPS structure.

hhpReadSymbologyConfig

Reads configuration items for a single symbology or for all symbologies. Individual items to be read are specified by adding the appropriate mask bit (OR it) to the mask member of the structure to which it belongs. Only items whose bits are set are read; all other items are ignored.

hhpReadSymbologyConfig(

SetupType_t cfgType,

int nSymbol,

PVOID pvSymStruct

)

Parameter Description

cfgType Use SETUP_TYPE_CURRENT for the current settings, or SETUP_TYPE_DEFAULT for

the customer default settings. nSymbol One of the symbology enumerated types, e.g., SYM_CODE39, SYM_OCR, or SYM_ALL

to read all symbologies. pStruct Pointer to the appropriate structure based on nSymbol, e.g., CODE39_T, OCR_T, or

HHP_SYM_CONFIG if all symbologies.

2 - 8

hhpReadSymbologyRangeMaxMin

Returns the specified symbology range maximum and minimum values. If a symbology has no range values, the function returns

-1 for the minimum and maximum values.

hhpReadSymbologyRangeMaxMin( int symbol, PLONG pnRangeMin, PLONG pnRangeMax )

Parameter Description

int The enumerated symbology types, eg., SYM_CODE39, SYM_PDF417, or SYM_ALL to

read the max/min range for all symbologies. pnRangeMin A LONG pointer to hold the minimum range value for single symbologies, or a LONG array

of size NUM_SYMBOLOGIES if SYM_ALL specified. The min value will be -1 if the

symbology does not support a minimum length value. pnRangeMax A LONG pointer to hold the maximum range value for single symbologies, or a LONG array

of size NUM_SYMBOLOGIES if SYM_ALL specified. The max value will be -1 if the

symbology does not support a maximum length value.

hhpSendActionCommand

This command allows the application to modify some of the imager hardware states. The items that can be modified include turning the illumination LEDs on/off, turning the aimer LEDs on/off, or causing the device’s beeper to beep/double beep.

hhpSendActionCommand( HHP_ACTION actionCmd, int nVal )

Parameter Description

actionCmd One of the values of enum HHP_ACTION (HHP_AIMER_CMD,

HHP_ILLUMINATION_CMD, or HHP_BEEP_CMD). nVal HHP_ON/HHP_OFF for illumination or aimers

HHP_SINGLE_BEEP/HHP_DOUBLE_BEEP for beeper.

hhpSendMessage

The SDK API provides access to almost all of the imager command set. hhpSendMessage allows applications to send menu (imager) commands directly to the imager (both wrapped and unwrapped) and to receive the actual uninterpreted imager response. This command allows a developer to send debug commands to the imager.

hhpSendMessage( PBYTE puchMsg, int nLen,

BOOL bSendRaw,

PBYTE puchReply, int nLenToRead, PINT pnRetLen )

2 - 9

Parameter Description

puchMsg Command sent to the imager with or without command wrapper. If no wrapper, set

bSendRaw to TRUE. nLen Number of bytes to send (in puchMsg). bSendRaw If TRUE, the SYN M CR command wrapper is NOT added to the command before sending

it to the imager. If FALSE, the command is sent withSYN M CR command wrapper. puchReply Buffer to hold imager response. Can be NULL if no response required. nLenToRead Number of bytes to read from imager in response. 0 if no response. pnRetLen Pointer to number of bytes returned in pnRetLen. NULL if no response required.

hhpSetAsyncMethods

hhpSetAsyncMethods sets the methods by which the caller wishes to be notified upon receipt of a barcode or image.

hhpSetAsyncMethods(

HANDLE hEventHandle,

HWND hWndHandle,

HHP_EVENT_CALLBACK EventCallback

)

Parameter Description

hEventHandle Handle to a Windows Event. The event should specify manual reset. hWndHandle Handle to the application window that should receive the SDK defined message

WM_HHP_EVENT_HWND_MSG. The message parameters are:

WPARAM The event type (hhpEventType_t)

LPARAM The number of bytes received EventCallback Callback function of type HHPEVENTCALLBACK, which is BOOL CALLBACK name (

EventType_t,DWORD ).

hhpSetBarcodeDataCodePage

This function changes the code page used when translating the decoded data from a string of bytes to Unicode. The default value is CP_ACP (ANSI code page). There is no error checking on the values sent to this function, so you must determine whether or not a code page is valid on the given system.

hhpSetBarcodeDataCodePage(

DWORD dwCodePage

)

Parameter Description

dwCodePage Code page to use when converting from BYTE string to Unicode. The only 2 code pages

that are valid are CP_ACP and CP_OEMCP.

hhpSetConfigItemToDefaults

Defaults a configuration group or individual group structure items.

hhpSetConfigItemToDefaults( ConfigItems_t item )

2 - 10

Parameter Description

item One of the members of the enumerated type ConfigItems_t. The valid values are:

BEEPER_CONFIG Resets HHP_BEEPER structure settings to their

defaults.

TRIGGER_CONFIG Resets HHP_TRIGGER structure settings to their

defaults.

DECODER_CONFIG Resets HHP_DECODER structure settings to their

defaults.

POWER_CONFIG Resets HHP_POWER_SETTINGS structure settings to

their defaults.

SYMBOLOGY_CONFIG Resets HHP_SYM_CONFIG structure settings to their

defaults.

SERIAL_PORT_CONFIG Resets HHP_SERIAL_PORT_CONFIG structure

settings to their defaults. Connection to the imager is maintained.

IMAGE_ACQUISITION Resets HHP_IMAGE_ACQUISITION structure settings

to their defaults.

IMAGE_TRANSFER Resets HHP_IMAGE_TRANSFER structure settings to

their defaults (not progress notification methods).

ALL_CONFIG Resets all of the above.

hhpSetHardwareLineDllFileName

The SDK API provides the ability to provide OEM device-dependent extensions to support the imager hardware sleep lines, and hardware trigger and/or special COM port driver configuration/initialization. The definitions and function prototype are located in the header file OemDll.h. Also see OEM-Configurable SDK Functionality on page 5-1.

hhpSetHardwareLineDllFileName( PTCHAR ptcHwrFilename )

Parameter Description

ptcHwrFilename Name of DLL provided by OEM containing some or all of the function exports described in

the header file OemDll.h

hhpSetSymbologyDefaults

Resets an individual symbology or all symbologies to their default values.

hhpSetSymbologyDefaults( int nSymId )

Parameter Description

nSymId One of the symbology enumerated types, e.g., SYM_CODE39, SYM_OCR, or SYM_ALL

to default all symbologies.

hhpUpgradeFirmware

The 5X00 Series provides the ability to update the firmware application running on the imager. hhpUpgradeFirmware checks the file contents to verify that it is a firmware application file before the file is downloaded to the imager. The firmware file is transferred to the imager compressed (lossless) unless the SDK has determined that the imager is running in bootstrap code instead of the current firmware application. In this case, the file is transferred uncompressed. This function only supports synchronous operation, so it does not return until the firmware file has been transferred to the imager and the imager has burned the new code into flash memory. When this function returns, the connection (host COM port) is connected at the default baud rate of 115200.

2 - 11

hhpUpgradeFirmware( const PTCHARptcFirmwareFilename, PDWORD DpdwTransferPercent,

HWND hTransferNotifyHwnd

)

Parameter Description

ptcFirmwareFilename String containing the fully qualified filename of the file that contains the code to be sent to the

imager. The file extension is usually .bin or .axf. The file is sent using an Hmodem, which is a derivative of Xmodem 1K.

pdwTransferPercent Pointer to a DWORD that contains the current percent transferred value(0 to 100). If

pdwTransferPercent is valid, the transfer completion percent is written to it. This is updated after each packet is sent.

hTransferNotifyHwnd Handle to the window that is to receive the transfer update messages. The message is sent

when the percentage changes by more than 1%. The window associated with the handle should hook the WM_HHP_PROGRESS_HWND_MSG message.

After file transfer is complete and while the imager is storing the new code in flash, the message WM_HHP_IMAGER_FLASHING is sent to the window HWND (if valid). The parameters are: WPARAM - Bytes transferred so far LPARAM - Bytes to be sent

The window should also hook the WM_HHP_IMAGER_FLASHING message. The parameters sent are: 1st Call wParam=1 lParam=0 ransfer is done and flashing has begun Subsequent wParam=x lParam=1 Where x toggles between 0 and 1 every ½ second Final Call wParam=0 lParam=0 Flashing is complete

hhpWriteConfigItem

Writes the configuration items for one or all of the configuration structures found in the main 5X00 Series configuration structure HHP_CONFIG. Individual items can be specified by adding the appropriate mask bit by ORing it with the dwMask member of the structure. Only items whose bits are set are written; all other items are ignored.

hhpWriteConfigItem( ConfigItems_t item,

PVOID pStruct

)

2 - 12

Parameter Description

item One of the members of the enumerated type ConfigItems_t. The valid values are:

BEEPER_CONFIG Writes the HHP_BEEPER structure settings specified

by the dwMask value to the imager.

TRIGGER_CONFIG Writes the HHP_TRIGGER structure settings specified

by the dwMask value to the imager.

DECODER_CONFIG Writes the HHP_DECODER_CONFIG structure

settings specified by the dwMask value to the imager.

POWER_CONFIG Writes the HHP_POWER_SETTINGS structure

settings specified by the dwMask value to the imager.

VERSION_INFO Returns the SDK, imager firmware, and imager boot

code versions.

SYMBOLOGY_CONFIG Writes the HHP_SYM_CONFIG individual structure

symbology settings specified by each structure's dwMask value to the imager.

SERIAL_PORT_CONFIG Writes the HHP_SERIAL_PORT_CONFIG structure

settings specified by the dwMask value to the imager. Connection to the imager is maintaned.

IMAGE_ACQUISITION Writes the HHP_IMAGE_ACQUISITION structure

settings specified by the dwMask value to the imager.

IMAGE_TRANSFER Writes the HHP_IMAGE_TRANSFER structure

settings specified by the dwMask value to the imager (not progress notification methods).

SEQUENCE_CONFIG Returns the sequence mode enable/disable state and

the data sequence command string.

ALL_CONFIG Writes the members specified in each of the structures

of HHP_CONFIG. This includes all of the above except SERIAL_PORT_CONFIG.

pStruct Pointer to the appropriate structure based on item:

HHP_BEEPER

HHP_TRIGGER

HHP_DECODER_CONFIG

HHP_POWER_SETTINGS

HHP_SYM_CONFIG

HHP_IMAGE_ACQUISITION

HHP_IMAGE_TRANSFER

HHP_SEQUENCE

HHP_CONFIG

hhpWriteConfigStream

Writes an entire data stream of programmable parameters to the device.

hhpWriteConfigStream( PBYTE puchCfgStream, int nLen )

Parameter Description

puchCfgStream Buffer to hold the raw imager configuration stream. nMaxLen Maximum number of bytes that fit in buffer puchCfgStream.

2 - 13

hhpWriteSymbologyConfig

Writes configuration items for a single symbology or for all symbologies. Individual items to be written are specified by adding the appropriate mask bit (OR it) to the mask member of the structure to which it belongs. Only items whose bits are set are written; all other items are ignored.

hhpWriteSymbologyConfig( int nSymId,

PVOID pvSymStruct

)

Parameter Description

nSymId One of the symbology enumerated types, e.g., SYM_CODE39, SYM_OCR, or SYM_ALL

to write all symbologies. pStruct Pointer to the appropriate structure based on nSymbol, e.g., CODE39_T, OCR_T, or

HHP_SYM_CONFIG if all symbologies.

Symbology Identifiers

Note: Please consult the appropriate symbology specification for discussion of AIM symbology IDs and modifiers.

Symbology Enumeration AIM ID

Australian Post SYM_AUSPOST, ] X0 A (0x41)

Aztec Code SYM_AZTEC = 0, ] z

Aztec Mesa SYM_MESA, ] z

British Post SYM_BPO, ] X0 B (0x42)

Canadian Post SYM_CANPOST, ] X0 C (0x43)

China Post SYM_CHINAPOST ] X0 Q (0x51)

Codabar SYM_CODABAR, ] F

Codablock F SYM_CODABLOCK, ] O

Code 11 SYM_CODE11, ] H3 h (0x68)

Code 16K SYM_CODE16K ] K

Code 128 SYM_CODE128, ] C

Code 32 Pharmaceutical (PARAF)

Code 39 SYM_CODE39, ] A

Code 49 SYM_CODE49, ] T

Code 4CB (4 State Customer Barcode)

Code 93 SYM_CODE93, ] G

Data Matrix SYM_DATAMATRIX, ] d

EAN-8 SYM_EAN8, ] E4 D (0x44)

EAN-13 SYM_EAN13, ] E0 d (0x64)

EAN•UCC Composite SYM_COMPOSITE, ] e

Interleaved 2 of 5 SYM_INT25, ] I

ISBT 128 SYM_ISBT, ] C4 j (0x6A)

Japanese Post SYM_JAPOST, ] X0 J (0x4A)

SYM_CODE32, ] X0 < (0x3C)

SYM_CODE4CB ] X0 M (0x4D)

Code ID

z (0x7A)

Z (0x5A)

a (0x61)

q (0x71)

o (0x6F)

j (0x6A)

b (0x62)

l (0x6C)

i (0x69)

w (0x77)

y (0x79)

e (0x65)

(hex)

2 - 14

Symbology Enumeration AIM ID

KIX (Netherlands) Post SYM_DUTCHPOST, ] X0 K (0x4B)

Korea Post SYM_KORPOST,] X0? (0x3F)

Matrix 2 of 5 SYM_MATRIX25, ] X0 m (0x6D)

MaxiCode SYM_MAXICODE, ] U

MicroPDF417 SYM_MICROPDF, ] L

MSI SYM_MSI, ] M

PDF417 SYM_PDF417, ] L

Planet Code SYM_PLANET, ] X0 L (0x4C)

Plessey Code SYM_PLESSEY ] P0 n (0x6E)

PosiCode SYM_POSICODE ] p

Postnet SYM_POSTNET, ] X0 P (0x50)

OCR US Money Font SYM_OCR, ] o3 O (0x4F)

QR Code SYM_QR, ] Q

Reduced Space Symbology SYM_RSS, ] e

Straight 2 of 5 Industrial SYM_STRT25 ] S0 f (0x66)

Straight 2 of 5 IATA SYM_IATA25, ] R

TCIF Linked Code 39 (TLC39) SYM_TLCODE39, ] L2 T (0x54)

Telepen SYM_TELEPEN ] B

Trioptic Code SYM_TRIOPTIC ] X0 = (0x3D)

UPC-A SYM_UPCA, ] E0 c (0x63)

UPC-A with Extended Coupon Code

UPC-E SYM_UPCE0, ] E0 E (0x45)

UPC-E1 SYM_UPCE1, ] X0 E (0x45)

UPU 4 State ID Tag SYM_UPUIDTAG ] X0 N (0x4E)

SYM_COUPONCODE ] E3 c (0x63)

Code ID

x (0x78)

R (0x52)

g (0x67)

r (0x72)

W(0x57)

s (0x73)

y (0x79)

f (0x66)

t(0x74)

(hex)

2 - 15

2 - 16

Enumerated Types and Definitions

Error Codes

RESULT_INTIALIZE = -1 Initial error code value.

RESULT_SUCCESS = 0 Operation was successful.

RESULT_EOT = 256 Undefined error.

RESULT_ERR_BADFILENAME Bad file name.

RESULT_ERR_BADINTELIMAGE Part of image window outside barcode image boundaries.

RESULT_ERR_BADPORT Invalid connection specified.

RESULT_ERR_BADREGION Invalid image window.

RESULT_ERR_BADSMARTIMAGE The device did not capture a valid image for intelligent imaging.

RESULT_ERR_BAUD_TOO_HIGH Requested baud rate not supported by host port.

RESULT_ERR_BUFFER_TOO_SMALL Buffer passed in to small for output.

RESULT_ERR_CAPTURE_IMAGE_FAILED Imager failed to capture the image.

RESULT_ERR_COMPRESSION_FAILED Error compressing image data.

RESULT_ERR_CONNECT_BOOT_CODE Imager connected but is running in boot code.

RESULT_ERR_DECOMPRESSION_FAILED Error decompressing image data.

RESULT_ERR_DLL_FILE Dll file specified to SetHardwareDllFileName not found.

RESULT_ERR_DRIVER Communication error/no response.

RESULT_ERR_ENGINEBUSY The scan engine temporarily busy.

RESULT_ERR_FILE Error occurred during a file operation.

RESULT_ERR_FILEINCOMPATIBLE The selected file is incompatible with the imager.

RESULT_ERR_FILEINVALID The selected file is invalid or corrupt.

RESULT_ERR_INTERNAL_ERROR Generic internal failure.

RESULT_ERR_INVALID_COMM_PARAMS Invalid RS-232 parameters specified.

RESULT_ERR_MEMORY Out of memory/memory allocation failed.

RESULT_ERR_MENUDECODE Symbol decoded is a menu symbol.

RESULT_ERR_NAK Received a NAK on response.

RESULT_ERR_NODECODE No decode: timed out or no more trigger.

RESULT_ERR_NODRIVER Communication initialization failed.

RESULT_ERR_NOIMAGE hhpGetLastImage called but no image available.

RESULT_ERR_NOINTELBARCODE No decode during intelligent image capture.

RESULT_ERR_NOINTELIMAGE Error on retrieve intelligent image from imager.

RESULT_ERR_NORESPONSE Imager did not acknowledge request.

RESULT_ERR_NOTCONNECTED Imager not yet connected.

RESULT_ERR_NOTRIGGER During wait for decode, checks that trigger return is released.

RESULT_ERR_PARAMETER One of the function parameters was invalid.

RESULT_ERR_POLLEVENT Error configuring transfer thread.

RESULT_ERR_READTHREAD_START Error starting asynchronous transfer thread.

RESULT_ERR_READTHREAD_STOP Error stopping asynchronous transfer thread.

RESULT_ERR_REFLASH Engine firmware is corrupt.

3 - 1

Error Codes (Continued)

RESULT_ERR_SHIP_IMAGE_FAILED Imager failed to ship captured image.

RESULT_ERR_SMARTIMAGETOOLARGE The captured image is too large to perform intelligent imaging.

RESULT_ERR_SYMBOLOGY_HAS_NO_RANGE The symbology has no range maximum/minimum values.

RESULT_ERR_UNICODE_UNSUPPORTED Attempted to set Code Page, but SDK is not UNICODE.

RESULT_ERR_UNSUPPORTED The operation was not supported by the engine.

RESULT_ERR_UPGRADE Upgrade of imager firmware failed.

RESULT_ERR_USER_CANCEL User called hhpCancelIo to abort operation.

RESULT_ERR_WRONGRESULTSTRUCT Wrong structure passed in for the type specified.

Setup Type Enumerated Type

SETUP_TYPE_CURRENT, The current value in flash.

SETUP_TYPE_DEFAULT = 0,

Hard coded Value. Set to current when imager “Reset To Defaults.”

Symbology ID Enumeration

NUM_SYMBOLOGIES

SYM_ALL=100 All active symbologies All Decoders

SYM_AUSPOST, Australian Post 2D Decoder only

SYM_AZTEC = 0, Aztec Code 2D Decoder only

SYM_BPO, British Post 2D Decoder only

SYM_CANPOST, Canadian Post 2D Decoder only

SYM_CHINAPOST China Post All Decoders

SYM_CODABAR, Codabar All Decoders

SYM_CODABLOCK, Codablock 2D Decoder only

SYM_CODE11, Code 11 All Decoders

SYM_CODE16K Code 16K All Decoders

SYM_CODE128, Code 128 All Decoders

SYM_CODE32 Code 32 Pharmaceutical (PARAF) All Decoders

SYM_CODE39, Code 39 All Decoders

SYM_CODE49, Code 49 All Decoders

SYM_CODE4CB 4 State Customer Barcode 2D Decoder only

SYM_CODE93, Code 93 All Decoders

SYM_COMPOSITE, Composite Code 2D and PDF Decoders only

SYM_COUPONCODE UPC-A with Extended Coupon Code All Decoders

SYM_DATAMATRIX, Data Matrix 2D Decoder only

SYM_DUTCHPOST, KIX (Netherlands) Post 2D Decoder only

SYM_EAN13, EAN-13 All Decoders

SYM_EAN8, EAN-8 All Decoders

SYM_IATA25, Straight 2 of 5 IATA All Decoders

Total number of supported symbologies

All Decoders

3 - 2

Symbology ID Enumeration (Continued)

SYM_INT25, Interleaved 2 of 5 All Decoders

SYM_ISBT, ISBT All Decoders

SYM_JAPOST, Japanese Post 2D Decoder only

SYM_KORPOST Korean Post All Decoders

SYM_MATRIX25, Matrix 2 of 5 All Decoders

SYM_MAXICODE, MaxiCode 2D Decoder only

SYM_MESA, Aztec Mesas 2D Decoder only

SYM_MICROPDF, MicroPDF417 2D and PDF Decoders

SYM_MSI, MSI Code All Decoders

SYM_OCR,

SYM_PDF417, PDF417 2D and PDF Decoders

SYM_PLANET, Planet Code 2D Decoder only

SYM_PLESSEY Plessey Code All Decoders

SYM_POSICODE PosiCode All Decoders

SYM_POSTNET, Postnet 2D Decoder only

SYM_QR, QR Code 2D Decoder only

SYM_RSS, Reduced Space Symbology (RSS) All Decoders

SYM_STRT25 Straight 2 of 5 Industrial All Decoders

SYM_TELEPEN Telepen All Decoders

SYM_TLCODE39, TCIF Linked Code 39 (TLC39) All Decoders

SYM_TRIOPTIC Trioptic Code All Decoders

SYM_UPCA, UPC-A All Decoders

SYM_UPCE0, UPC-E All Decoders

SYM_UPCE1, UPC-E1 (not truly standard) All Decoders

SYM_UPUIDTAG ID tag (UPU 4-State) 2D Decoder only

OCR (OCR-A, OCR-B, OCR US Money Font, MICR)

2D Decoder only

Supported OCR Fonts

These are mutually exclusive. Only one font can be enabled at one time.

OCR_DISABLED = 0, Disable OCR Codes.

OCR_A, Enable OCR-A Font Decoding.

OCR_B, Enable OCR-B Font Decoding.

OCR_MONEY, Enable Money Font Decoding.

OCR_MICR_UNSUPPORTED, Not supported.

Image Formats

FF_RAW_BINARY = 0, 1 bit per pixel – Each row padded out to byte boundary.

FF_RAW_GRAY, 8 bits per pixel.

FF_TIFF_BINARY, TIFF bilevel uncompressed.

FF_TIFF_BINARY_PACKBITS, TIFF bilevel packbits compressed.

3 - 3

Image Formats (Continued)

FF_TIFF_GRAY, TIFF 8 bits per pixel uncompressed.

FF_JPEG_GRAY, JPEG lossy compression.

FF_BMP_GRAY Windows BMP file uncompressed.

Compression Mode Formats

COMPRESSION_NONE=0, No compression.

COMPRESSION_LOSSLESS, Huffman lossless compression.

COMPRESSION_LOSSY JPEG lossy compression.

Capture Illumination Duty Cycle

HHP_DUTY_CYCLE_OFF =0, Keep off during image capture.

HHP_DUTY_CYCLE_ON Turn on for image capture.

#define HHP_CAPTURE_ALWAYS_OFF HHP_DUTY_CYCLE_OFF

#define HHP_CAPTURE_ALWAYS_ON HHP_DUTY_CYCLE_ON

Auto Exposure Type

HHP_AUTOEXPOSURE_BARCODE=0, Autoexposure for decode image (darker with less noise).

HHP_AUTOEXPOSURE_PHOTO, Autoexposure for pictures. (lighter, more pleasing image).

HHP_AUTOEXPOSURE_MANUAL

#define HHP_AUTOEXPOSURE_NONE HHP_AUTOEXPOSURE_MANUAL;

#define HHP_AUTOEXPOSURE_FIXED HHP_AUTOEXPOSURE_NONE;

No Autoexposure. User should supply Exposure, Gain, and Frame Rate Values.

Gain Values Enum

Only used when in manual capture mode.

HHP_GAIN_1x=1, HHP_GAIN_2x, HHP_GAIN_4x=4,

Frame Rates Enum

Only used when in manual capture mode.

HHP_1_FRAMES_PER_SEC=1, HHP_2_FRAMES_PER_SEC, HHP_3_FRAMES_PER_SEC, HHP_4_FRAMES_PER_SEC, HHP_5_FRAMES_PER_SEC, HHP_6_FRAMES_PER_SEC, HHP_10_FRAMES_PER_SEC=10, HHP_12_FRAMES_PER_SEC=12, HHP_15_FRAMES_PER_SEC=15, HHP_20_FRAMES_PER_SEC=20,

3 - 4

HHP_30_FRAMES_PER_SEC=30

Beeper Volume Enum

BEEP_OFF=0, Don’t sound beeper – no volume.

BEEP_LOW=1, Low volume.

BEEP_MEDIUM=2, Medium volume.

BEEP_HIGH=3 Loudest volume.

Decoder Mode Enum

DECODE_METHOD_STANDARD=0, Normal decode mode (default).

DECODE_METHOD_QUICK_OMNI Fast omni directional decoder .

DECODE_METHOD_NONOMNI_ALD Non-omni advanced linear decoder.

DECODE_METHOD_OMNI_LINEAR Omni-directional linear decoder.

System (MPU) Clock Speeds

Note: CPU clock speed must always be greater than system clock speed.

POWER_SYS_SPEED_96MHZ=0, POWER_SYS_SPEED_48MHZ, POWER_SYS_SPEED_32MHZ

Configuration Structure Item Enum for hhpReadConfigItem() and hhpWriteConfigItem()

BEEPER_CONFIG=0, Read/Write HHP_BEEPER items.

TRIGGER_CONFIG, Read/Write HHP_TRIGGER_CONFIG items.

DECODER_CONFIG, Read/Write HHP_DECODER_CONFIG items.

POWER_CONFIG, Read/Write HHP_POWER_SETTINGS items.

VERSION_INFO, Read/Write HHP_VERSION_INFO items.

Read/Write HHP_SYM_CONFIG items. If specified in

SYMBOLOGY_CONFIG,

SERIAL_PORT_CONFIG, Read/Write HHP_SERIAL_PORT_CONFIG items.

IMAGE_ACQUISITION, Read/Write HHP_IMAGE_ACQUISITION items.

IMAGE_TRANSFER, Read/Write HHP_IMAGE_TRANSFER items.

SEQUENCE_CONFIG Read/Write SEQUENCE_CONFIG items.

ALL_CONFIG

hhpReadConfigItem(), all the symbology config items for all the symbologies will be retrieved. Use hhpReadSymbologyConfig() to specify individual symbology structures.

Read/Write HHP_CONFIG items from structure memory in all HHP configuration member structures.

3 - 5

Trigger Modes Enum

HHP_MANUAL_SERIAL = 0,

UNUSED, Unused.

HHP_MANUAL_LOW_POWER,

HHP_PRESENTATION,

HHP_SCANSTAND,

HHP_HOST_NOTIFY

HHP_SNAP_AND_SHIP

Requires trigger to scan (either software or hardware). No Low Power Mode.

Requires trigger to scan (either software or hardware). Image enters low power mode based on low power mode timeouts.

The imager uses ambient light to detect barcodes. For further information please see the 5X80 Integration Manual.

Constantly looks for the scan stand barcode. When the imager detects a barcode that is different from than the scan stand barcode, it initiates a full trigger. For further information please see the 5X80 Integration Manual.

Captures and sends an image when triggered (instead of scanning for barcodes).

Sequence Mode

HHP_SEQ_DISABLED = 0, Sequence mode disabled.

HHP_SEQ_ENABLED, Sequence mode enabled but not required.

HHP_SEQ_REQUIRED Sequence mode enabled and required.

Serial Port Baud Rates

SERIAL_BAUD_300 = 300, 300 BPS

SERIAL_BAUD_600 = 600, 600 BPS

SERIAL_BAUD_1200 = 1200, 1200 BPS

SERIAL_BAUD_2400 = 2400, 2400 BPS

SERIAL_BAUD_4800 = 4800, 4800 BPS

SERIAL_BAUD_9600 = 9600, 9600 BPS

SERIAL_BAUD_19200 = 19200, 19200 BPS

SERIAL_BAUD_38400 = 38400, 38400 BPS

SERIAL_BAUD_57600 = 57600, 57600 BPS

SERIAL_BAUD_115200 = 115200, 115200 BPS

// Baud Rates that Require USB Serial or SIO950 Compatible Serial Port Driver

SERIAL_BAUD_230400 = 230400, 230400 BPS

SERIAL_BAUD_460800 = 460800, 460800 BPS

SERIAL_BAUD_921600 = 921600, 921600 BPS

Baud Rates that Require USB Serial or SIO950 Compatible Serial Port Driver

SERIAL_BAUD_230400 = 230400, 230400 BPS

SERIAL_BAUD_460800 = 460800, 460800 BPS

SERIAL_BAUD_921600 = 921600 921600 BPS

3 - 6

Serial Data Bits

SERIAL_DATA_BITS_7 = 7, 7 bit data

SERIAL_DATA_BITS_8 8 bit data

Parity

SERIAL_PARITY_NONE = ‘N’, No parity

SERIAL_PARITY_ODD = ‘O’, Odd parity

SERIAL_PARITY_EVEN = ‘E’, Even parity

SERIAL_PARITY_MARK = ‘M’, Mark parity

SERIAL_PARITY_SPACE = ‘S’ Space parity

Stop Bits

SERIAL_ONE_STOPBITS = 1, 1 stop bit

SERIAL_TWO_STOPBITS, 2 stop bits

Connection Types

Currently limited to serial ports.

HHP_COM1=0, COM1

HHP_COM2, COM2

HHP_COM3, COM3

HHP_COM4, COM4

HHP_COM5, COM5

HHP_COM6, COM6

HHP_COM7, COM7

HHP_COM8, COM8

HHP_COM9, COM9

HHP_COM10, COM10

HHP_COM11, COM11

HHP_COM12, COM12

HHP_COM13, COM13

HHP_COM14, COM14

HHP_COM15, COM15

HHP_COM16, COM16

HHP_COM17, COM17

HHP_COM18, COM18

HHP_COM19, COM19

HHP_LAST_COMM_PORT=255 Last valid comm port.

3 - 7

Decoder Symbology Support

HHP_1D_CODES_ONLY=0, 1D Linear and stacked linear codes only.

HHP_1D_AND_PDF_CODES, Same as above plus PDF417 and MicroPDF417.

HHP_1D_AND_2D_CODES All symbologies.

HHP Action Commands

HHP_AIMER_CMD=0, Aimer command (turn aimers on/off).

HHP_ILLUMINATION_CMD, No longer supported by imagers.

HHP_BEEP_CMD Beeper command (sound a single or double beep).

On/Off Enum

HHP_OFF=0, Turn Off (HHP_AIMER_CMD and HHP_ILLUMINATION_CMD).

HHP_ON=1 Turn On (HHP_AIMER_CMD and HHP_ILLUMINATION_CMD).

Beep Execute Enum

HHP_SINGLE_BEEP=0, Single Beep (HHP_BEEP_CMD).

HHP_DOUBLE_BEEP=1 Double Beep (HHP_BEEP_CMD).

Imager Type Enum

HHP_UNKNOWN_IMAGER Unable to determine engine type.

HHP_DECODED_IMAGER_4080 Serial (RS-232) 4080 imager with internal decoder.

HHP_DECODED_IMAGER_4080_USB USB serial 4080 imager with internal decoder.

HHP_DECODED_IMAGER_5080VGA Serial (RS-232) 5080 VGA imager with internal decoder.

HHP_DECODED_IMAGER_5080VGA_USB USB serial 5080 VGA imager with internal decoder.

HHP_DECODED_IMAGER_5080VGA_PSOC

HHP_DECODED_IMAGER_5080VGA_PSOC_USB USB serial 5080 VGA imager with internal decoder and PSOC.

HHP_DECODED_IMAGER_5080 Serial (RS-232) 5080 imager with internal decoder.

HHP_DECODED_IMAGER_5080_USB USB serial 5080 imager with internal decoder.

HHP_DECODED_IMAGER_5080_PSOC Serial (RS-232) 5080 imager with internal decoder and PSOC.

HHP_DECODED_IMAGER_5080_PSOC_USB USB serial 5080 imager with internal decoder and PSOC.

Serial (RS-232) 5080 VGA imager with internal decoder and PSOC.

Illumination Color Enum (5X10/5X80 engines only)

SECONDARY_LEDS Alternate illumination color (if supported by engine).

PRIMARY_LEDS Primary illumination color.

3 - 8

Structures and Mask Definitions

Important: All structures have a dwStructSize member that MUST BE SET before calling any of the 5X00 Series API functions.

Most structures have a dwMask member. This specifies which structure members are active (to be read or written). Select structure items by ORing the individual structure masks for each of the items you wish to be active together.

This insures that the proper structure has been passed to the function being called.

Symbology Structures and Defines

All symbology structures are 1 of 3 possibilities.

Important: Symbology configuration definitions for each symbology are ORed together in the dwFlags member of the symbology

#define SYMBOLOGY_ENABLE 0x00000001 Enable Symbology bit. #define SYMBOLOGY_CHECK_ENABLE 0x00000002 Enable usage of check character. #define SYMBOLOGY_CHECK_TRANSMIT 0x00000004 Send check character. #define SYMBOLOGY_START_STOP_XMIT 0x00000008 Include the start and stop characters in the

#define SYMBOLOGY_ENABLE_APPEND_MODE 0x00000010 Code39 append mode. #define SYMBOLOGY_ENABLE_FULLASCII 0x00000020 Enable Code39 Full ASCII. #define SYMBOLOGY_NUM_SYS_TRANSMIT 0x00000040 UPC-A/UPC-E Send Num Sys. #define SYMBOLOGY_2_DIGIT_ADDENDA 0x00000080 Enable 2 digit Addenda (UPC and EAN). #define SYMBOLOGY_5_DIGIT_ADDENDA 0x00000100 Enable 5 digit Addenda (UPC and EAN). #define SYMBOLOGY_ADDENDA_REQUIRED 0x00000200 Only allow codes with addenda (UPC and

#define SYMBOLOGY_ADDENDA_SEPARATOR 0x00000400 Include Addenda separator space in

#define SYMBOLOGY_EXPANDED_UPCE 0x00000800 Extended UPC-E. #define SYMBOLOGY_UPCE1_ENABLE 0x00001000 UPC-E1 enable (use

#define SYMBOLOGY_COMPOSITE_UPC 0x00002000 Enable UPC Composite codes. #define SYMBOLOGY_AZTEC_RUNE 0x00004000 Enable Aztec Code Run. #define SYMBOLOGY_AUSTRALIAN_BAR_WIDTH 0x00010000 Include Australian postal bar data in string. #define SYMBOLOGY_AUS_CUST_FIELD_NUM 0x00020000 Customer fields as numeric data using the

#define SYMBOLOGY_AUS_CUST_FIELD_AlPHA 0x00040000 Customer fields as alphanumeric data

Flags for Aztec Mesas are reused, since Aztec Mesas have no addenda, extended UPC-E, or UPC-E1 enable flags.

#define SYMBOLOGY_ENABLE_MESA_IMS 0x00020000 Mesa IMS enable. #define SYMBOLOGY_ENABLE_MESA_1MS 0x00040000 Mesa 1MS enable. #define SYMBOLOGY_ENABLE_MESA_3MS 0x00080000 Mesa 3MS enable. #define SYMBOLOGY_ENABLE_MESA_9MS 0x00100000 Mesa 9MS enable. #define SYMBOLOGY_ENABLE_MESA_UMS 0x00200000 Mesa UMS enable. #define SYMBOLOGY_ENABLE_MESA_EMS 0x00400000 Mesa EMS enable. #define SYMBOLOGY_ENABLE_MESA_MASK 0x007E0000 Enable all Mesa.

There is only one symbology ID for RSE, RSL, and RSS, so 3 flags are used for enable.

#define SYMBOLOGY_RSE_ENABLE 0x00800000 Enable RSE Symbology bit. #define SYMBOLOGY_RSL_ENABLE 0x01000000 Enable RSL Symbology bit. #define SYMBOLOGY_RSS_ENABLE 0x02000000 Enable RSS Symbology bit. #define SYMBOLOGY_RSX_ENABLE_MASK 0x03800000 RSS enable all.

Telepen and PosiCode

#define SYMBOLOGY_TELEPEN_OLD_STYLE 0x04000000 Telepen Old Style mode. #define SYMBOLOGY_POSICODE_LIMITED_1 0x08000000 PosiCode Limited of 1

structure. The applicable flags are dependent on symbology. For example, Aztec Code accepts only SYMBOLOGY_ENABLE, while Postnet accepts SYMBOLOGY_ENABLE and SYMBOLOGY_CHECK_TRANSMIT.

decoded result string.

EAN).

returned string.

SYMBOLOGY_ENABLE for UPC-E0).

N Table.

using the C Table.

4 - 1

#define SYMBOLOGY_POSICODE_LIMITED_2 0x10000000 PosiCode Limited of 2 #define SYMBOLOGY_CODABAR_CONCATENATE 0x20000000 Codabar concatenate.

Flags for OCR are reused, since none of the other flags apply to OCR.

#define SYMBOLOGY_ENABLE_OCR_A 0x00000001 OCR-A enable. #define SYMBOLOGY_ENABLE_OCR_B 0x00000002 OCR-B enable. #define SYMBOLOGY_ENABLE_OCR_MONEY 0x00000004 OCR-Money enable. #define SYMBOLOGY_ENABLE_OCR_MICR 0x00000008 OCR-Micr enable.

Symbology structure sets masks to specify which items of config structure are to be set or read.

#define SYM_MASK_FLAGS 0x00000001 Flags are valid. #define SYM_MASK_MIN_LEN 0x00000002 Min Length valid. #define SYM_MASK_MAX_LEN 0x00000004 Max Length valid. #define SYM_MASK_OCR_MODE 0x00000008 OCR mode valid. #define SYM_MASK_DIRECTION 0x00000010 OCR direction valid. #define SYM_MASK_TEMPLATE 0x00000020 OCR template valid. #define SYM_MASK_GROUP_H 0x00000040 OCR group H valid. #define SYM_MASK_GROUP_G 0x00000080 OCR group H valid. #define SYM_MASK_CHECK_CHAR 0x00000100 OCR check char valid. #define SYM_MASK_ALL 0xffffffff Generic all mask.

Structure for symbologies with no specified minimum or maximum length:

typedef struct _tagSymFlagsOnly {

DWORD dwStructSize; Set to sizeof( SymFlagsOnly_t ); DWORD dwMask; Mask which can only be 0 or SYM_MASK_FLAGS. DWORD dwFlags; OR of valid flags for the given symbology.

} SymFlagsOnly_t, *PSymFlagsOnly_t;

4 - 2

Min/Max barcode lengths for symbologies that have length settings:

Code Min Max Aztec 1 3750 China Post 2 80 Codabar 2 60 Codablock F 1 2048 Code 11 1 80 Code 16K 1 160 Code 128 0 80 Code 2 of 5 1 48 Code 39 0 48 Code 49 1 81 Code 93 0 80 DataMatrix 1 1500 EAN•UCC Composite 1 2435 IATA Code 2 of 5 1 48 Interleaved 2 of 5 2 80 Korean Post 2 80 Matrix 2 of 5 1 80 MaxiCode 1 150 MicroPDF417 1 366 MSI 4 48 PDF417 1 2750 Plessey Code 4 48 PosiCode 2 80 QR Code 1 3500 Reduced Space Symbology (RSS) 4 74 Telepen 1 60

Structure for symbologies with minimum and maximum length:

typedef struct _tagSymFlagsRange {

DWORD dwStructSize; Set to sizeof( SymFlagsRange_t ); DWORD dwMask; Item Masks – SYM_MASK_FLAGS,MIN_LEN,MAX_LEN. DWORD dwFlags; OR of valid flags for the given symbology. DWORD dwMinLen; Minimum length for valid barcode string for this symbology. DWORD dwMaxLen; Maximum length for valid barcode string for this symbology.

} SymFlagsRange_t, *PSymFlagsRange_t;

Structure for unusual OCR:

#define MAX_TEMPLATE_LEN 256 #define MAX_GROUP_H_LEN 256 #define MAX_GROUP_G_LEN 256 #define MAX_CHECK_CHAR_LEN 64 typedef struct _tagSymCodeOCR {

DWORD dwStructSize; Set to size of ( SymCodeOcr_t ); DWORD dwMask; Item masks. OCRMode_t ocrMode; OCR Enable/Mode structure. OCRDirection_t ocrDirection; OCR direction structure. Not supported. TCHAR tcTemplate[ MAX_TEMPLATE_LEN ]; Template for decoded data (‘d’ - decimal,

TCHAR tcGroupG[ MAX_GROUP_H_LEN ]; Group G character string.

‘a’ - ASCII, ‘l’ - letter, ‘e’ - extended).

4 - 3

TCHAR tcGroupH[ MAX_GROUP_G_LEN ]; Group H character string. TCHAR tcCheckChar[ MAX_CHECK_CHAR_LEN ]; Check character string.

} SymCodeOCR_t, *PSymCodeOCR_t;

Structure of all Symbology Structures

There is one structure for each symbology. This info is stored in imager config.

Define aliases for each symbology structure:

#define AZTEC_T SymFlagsRange_t Aztec Code has max and min length values. #define MESA_T SymFlagsOnly_t Aztec Mesa has flags only. #define CODABAR_T SymFlagsRange_t Codabar has max and min length values. #define CODE11_T SymFlagsRange_t Code 11 has max and min length values. #define CODE128_T SymFlagsRange_t Code 128 has max and min length values. #define CODE39_T SymFlagsRange_t Code 39 has max and min length values. #define CODE49_T SymFlagsRange_t Code 49 has max and min length values. #define CODE93_T SymFlagsRange_t Code 93 has max and min length values. #define COMPOSITE_T SymFlagsRange_t Composite code has max and min length values. #define DATAMATRIX_T SymFlagsRange_t Data Matrix has max and min length values. #define EAN8_T SymFlagsOnly_t EAN-8 has flags only. #define EAN13_T SymFlagsOnly_t EAN-13 has flags only. #define INT25_T SymFlagsRange_t Interleaved 2 of 5 has max and min length values. #define MAXICODE_T SymFlagsRange_t MaxiCode has max and min length values. #define MICROPDF_T SymFlagsRange_t MicroPDF417 has max and min length values. #define OCR_T SymCodeOCR_t OCR has its own structure. #define PDF417_T SymFlagsRange_t PDF417 has max and min length values. #define POSTNET_T SymFlagsOnly_t Postnet has flags only. #define QR_T SymFlagsRange_t QR Code has max and min length values. #define RSS_T SymFlagsRange_t RSS Codes have max and min length values. #define UPCA_T SymFlagsOnly_t UPC-A has flags only. #define UPCE_T SymFlagsOnly_t UPC-E has flags only. #define ISBT_T SymFlagsOnly_t ISBT Code has flags only. #define BPO_T SymFlagsOnly_t British Post has flags only. #define CANPOST_T SymFlagsOnly_t Canadian Post has flags only. #define AUSPOST_T SymFlagsOnly_t Australian Post has flags only. #define IATA25_T SymFlagsRange_t IATA 2 of 5 has max and min length values. #define CODABLOCK_T SymFlagsRange_t Codablock has max and min length values. #define JAPOST_T SymFlagsOnly_t Japanese Post has flags only. #define PLANET_T SymFlagsOnly_t Planet Code has flags only. #define DUTCHPOST_T SymFlagsOnly_t KIX Post has flags only. #define MSI_T SymFlagsRange_t MSI Code has max and min length values. #define TLCODE39_T SymFlagsOnly_t TLCode 39 has flags only. #define MATRIX25_T SymFlagsRange_t Matrix 2 of 5 Code has max & min length values. #define KORPOST_T SymFlagsOnly_t Korea Post only has enable. #define TRIOPTIC_T SymFlagsOnly_t Trioptic Code has flags only. #define CODE32_T SymFlagsOnly_t Code 32 has flags only. #define CODE25_T SymFlagsRange_t Code 2 of 5 has min and max length values. #define PLESSEY_T SymFlagsRange_t Plessey Code has min and max length values. #define CHINAPOST_T SymFlagsRange_t China Post has min and max length values. #define TELEPEN_T SymFlagsRange_t Telepen Code has min and max length values. #define CODE16K_T SymFlagsRange_t Code 16K has min and max length values. #define POSICODE_T SymFlagsRange_t PosiCode has min and max length values. #define COUPONCODE_T SymFlagsOnly_t UPC Coupon code has flags only. #define CODE4CB_T SymFlagsOnly_t 4 State Customer Barcode. #define UPUIDTAG_T SymFlagsOnly_t ID tag (UPU 4-State) has flags only.

4 - 4

typedef struct _tagSymCfg {

DWORD dwStructSize; Set to sizeof( SymCfg_t );

Linear Codes - Flags supported for this code:

CODABAR_T codabar; Enable,Check,CheckSend,StartStop,Concatenate CODE32_T code32; Enable COUPONCODE_T couponCode; Enable TRIOPTIC_T triopticCode; Enable CODE11_T code11; Enable,Check,CheckSend CODE128_T code128; Enable CODE39_T code39; Enable,Check,CheckSend,StartStop,Append,FullAscii CODE49_T code49; Enable CODE93_T code93; Enable COMPOSITE_T composite; Enable,CompositeUPC EAN8_T ean8; Enable, Check, Addenda2, Addenda5, AddendaReq, Adden-

EAN13_T ean13; Enable, Check, Addenda2, Addenda5, AddendaReq, Adden-

IATA25_T iata25; Enable INT25_T int2of5; Enable,Check,CheckSend ISBT_T isbt; Enable MATRIX25_T matrix25; Enable MSI_T msi; Enable,Check UPCA_T upcA; Enable, check, NumSysTrans, Addenda2, Addenda5,

UPCE_T upcE; Enable, Check, NumSysTrans, Addenda2, Addenda5,

Postal Codes

AUSPOST_T australiaPost; Enable,AustralianBar BPO_T britishPost; Enable CANPOST_T canadaPost; Enable DUTCHPOST_T dutchPost; Enable JAPOST_T japanPost; Enable KORPOST_T koreaPost Enable PLANET_T usPlanet; Enable,Check POSTNET_T usPostnet; Enable,Check CHINAPOST_T chinaPost; Enable UPUIDTAG_T upuIdTag; Enable CODE4CB_T code4CB; Enable

2D Codes

AZTEC_T aztec; Enable,AztecRun MESA_T aztecMesa; EnableIMS, Enable1MS, Enable3MS, Enable9MS, Enable-

CODABLOCK_T codablock; Enable DATAMATRIX_T datamatrix; Enable MAXICODE_T maxicode; Enable,SCMOnly MICROPDF_T microPDF; Enable PDF417_T pdf417; Enable QR_T qr; Enable RSS_T rss; Enable TLCODE39_T tlCode39; Enable CODE25_T code2of5; Enable PLESSEY_T plesseyCode; Enable TELEPEN_T telepen; Enable,Old Style Mode CODE16K_T code16k; Enable

daSep

AddendaReq, AddendaSep

AddendaReq, AddendaSep, ExpandedE, EnableE1

UMS, EnableEMS

4 - 5

POSICODE_T posiCode; Enable,Limited 1, Limited 2

Special OCR “code”

OCR_T ocr; None (See SymCodeOCR_t)

} SymCfg_t, HHP_SYM_CONFIG, *PSymCfg_t, *PHHP_SYM_CONFIG;

Data structures for decoded barcode message: hhpCaptureBarcode() and hhpGetAsyncResults(). Not stored in imager.

#define MAX_MESAGE_LENGTH 4096

typedef struct _tagHHP_DECODE_MSG {

DWORD dwStructSize; Size of decode structure. TCHAR pchMessage[ MAX_MESAGE_LENGTH ]; decoded message data TCHAR chCodeID; AIM Id of symbology TCHAR chSymLetter; Hand Held Products Id of symbology TCHAR chSymModifier; Modifier characters DWORD nLength; length of the decoded message

} HHP_DECODE_MSG, DecodeMsg_t, *PHHP_DECODE_MSG;

typedef struct _tagHHP_RAW_DECODE_MSG {

WORD wStructSize; Size of decode structure BYTE chMessage[ MAX_MESAGE_LENGTH ]; Decoded message data BYTE hCodeID; AIM ID of symbology BYTE hSymLetter; HHP ID of symbology BYTE hSymModifier; Modifier characters DWORD Length; Length of the decoded message

} HHP_RAW_DECODE_MSG, RawDecodeMsg_t, *PHHP_RAW_DECODE_MSG;

Imaging Structures and Defines

Image Acquisition bit mask:

The following are also configuration items:

#define WHITE_VALUE_MASK 0x00001 Target value (0-255) for the “white” pixel. #define WHITE_WINDOW_MASK 0x00002 Acceptable delta from target white. #define MAX_CAPTURE_RETRIES_MASK 0x00004 Max # of frames to try to get white value. #define ILLUMINATION_DUTY_CYCLE_MASK 0x00008 How LEDs behave during image capture. #define LIGHTS_DUTY_CYCLE_MASK 0x00008 Duplicate of above mask. #define AIMER_DUTY_CYCLE_MASK 0x00010 How aimers behave during image capture. #define FIXED_GAIN_MASK 0x00020 If manual mode, gain value to use. #define FIXED_EXPOSURE_MASK 0x00040 If manual mode, exposure value to use. #define FRAME_RATE_MASK 0x00080 If manual mode, frame rate to use. #define AUTOEXPOSURE_MODE_MASK 0x00100 Barcode, Photo, or manual AGC mode. #define IMAGE_CAPTURE_MODE_MASK 0x00100 Same as above mask.

Following 2 items are not config items and are only used in hhpAcquireImage():

#define WAIT_FOR_TRIGGER_MASK 0x00200 Wait for trigger before capture. #define PREVIEW_MODE_IMAGE_MASK 0x00400 Capture a preview image (214x160x8 JPEG).

Grouped masks:

#define CAPTURE_MASK_CONFIG_ALL 0x001ff Mask for all configuration items. #define CAPTURE_MASK_FIXED_AGC 0x00180 Mask for all manual exposure mode items. #define CAPTURE_MASK_ALL 0x007ff Mask for all structure members.

4 - 6

Image Acquisition structure:

typedef struct _tagHHP_IMAGE_ACQUISITION {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items.

Config items

DWORD dwWhiteValue; Target “white pixel” value. DWORD dwWhiteWindow; Acceptable delta from white value. DWORD dwMaxNumExposures; Max frame capture tries for white value. HHP_DUTY_CYCLE illuminatCycle; Illumination duty cycle (never on, on during imag-

ing). HHP_DUTY_CYCLE aimerCycle; Aimer duty cycle (never on, on during imaging). HHP_GAIN fixedGain; If manual capture mode, gain value for capture. DWORD dwFixedExposure; If manual capture mode, exposure time for cap-

ture. HHP_FRAME_RATE frameRate; If manual capture mode, frame rate for capture. HHP_AUTOEXPOSURE captureMode; Autoexposure (AGC) Capture mode: barcode,

photo or manual.

Capture time only, not real config items:

BOOL bWaitForTrigger; Wait for hardware or software trigger before cap-

turing image.

BOOL bPreviewImage; Capture a preview image. These are subsample

3, full window, JPEG transfer images.

} HHP_IMAGE_ACQUISITION, *PHHP_IMAGE_ACQUISITION;

Image Transfer bit masks:

#define BITS_PER_PIXEL_MASK 0x00001 Number of bits per pixel transferred (1 or 8). #define SUBSAMPLE_VALUE 0x00002 Subsample value (1-10). #define SUBSAMPLE_VALUE_MASK 0x00002 Subsample value (1-10). #define BOUNDING_RECTANGLE_MASK 0x00004 Rectangular region within image to send. #define COMPRESSION_MODE_MASK 0x00008 No Compression, Lossless or Lossy. #define HISTOGRAM_STRETCH_MASK 0x00010 Range -> 0 - 255. #define COMPRESSION_FACTOR_MASK 0x00020 If lossy compression, image quality percent. #define EDGE_ENHANCEMENT_MASK 0x00100 Edge sharpening filter. #define GAMMA_CORRECTION_MASK 0x00200 Gamma correction. #define TEXT_ENHANCEMENT_MASK 0x00400 Text sharpening filter. #define INFINITY_FILTER_MASK 0x00800 Sharpening for image beyond normal focus. #define FLIP_IMAGE_MASK 0x01000 Rotate the image 180 degrees. #define NOISE_FILTER_MASK 0x02000 Smoothing (fly spec) filter. #define TRANSFER_UPDATE_HWND 0x00040 Transfer progress message window. #define TRANSFER_UPDATE_DWORD 0x00080 Pointer to DWORD for percent of transfer complete. #define TRANSFER_MASK_ALL 0x03fff Mask to select all configuration items in structure. #define TRANSFER_MASK_ALL_NO_NOTIFY 0x03f3f Mask to select all structure members.

Image Transfer structure:

typedef struct _tagHHP_IMAGE_TRANSFER {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items.

Config items:

DWORD dwBitsPerPixel; Bits per pixel for transferred image (1 or 8 bits

only).

DWORD dwSubSample; Subsample value. This means take every dwSub-

Sample pixels of every dwSubSample row. The

default is 1.

4 - 7

RECT boundingRect; Rectangle describing a window within the image.

All pixels outside this rectangle are omitted from

the transferred image.

BOOL bHistogramStretch; Scaled frequency of total image pixels. Compression_t compressionMode; How image is compressed on transfer. Compres-

sion reduces the amount of data to transfer but

can reduce image quality (Lossy compression)

and does take a finite length of time.

DWORD dwCompressionFactor; Lossy compression is JPEG lossy. If lossy com-

pression, this value specifies the image quality

percentage from 100 (virtually no loss) to 1 (very

poor). Image size drops with decrease in image

quality.

DWORD dwEdgeEhancement; A sharpening filter used to sharpen light/dark

edges within the image. The valid range of values

is 0 (no edge enhancement) to 23 (maximum edge

enhancement).

DWORD dwGammaCorrection; Applies gamma correction to the image. The valid

range is 0 (no gamma correction) to 1000 (maxi-

mum correction).

DWORD dwTextEnhancement; This filter is an edge sharpening filter optimized for

text. The valid range is 0 (no text enhancement) to

255 (maximum enhancement).

BOOL bInfinityFilter; This is a boolean flag (TRUE or FALSE) that

applies a filter to the image that sharpens objects

beyond the normal focal distance of the imager.

BOOL bFlipImage; This is a boolean flag (TRUE or FALSE) that flips

the image 180°

BOOL bNoiseFilter; This is a boolean flag (TRUE or FALSE) that

enables or disables the imager smoothing filter.

Transfer time only, not stored in imager:

HWND hTransferNotifyHwnd; The user-defined window message.

WM_HHP_PROGRESS_HWND_MSG (wParam

is bytes so far, lParam is bytes to send) will be

sent if this member mask specified and its value is

a valid windows handle.

PDWORD pdwTransferPercent; If non-NULL and specified in MASK, the percent

complete of the transfer is placed here. It is up to

the caller to check the value in a thread or timer

callback.

} HHP_IMAGE_TRANSFER, *PHHP_IMAGE_TRANSFER;

Data structure for captured image: hhpAcquireImage(), hhpGetLastImage() and hhpGetAsyncResult(). Not stored in imager.

typedef struct _tagHHP_IMAGE {

DWORD dwStructSize; Size of structure in bytes. PBYTE puchBuffer; Buffer for image. LONG nBufferSize; Size of buffer in bytes. FileFormat_t fileFormat; Format for returned data. DWORD dwJpegQFactor; JPEG Quality Factor. LONG nBytesReturned; Number of bytes returned. SIZE imgSize; Size of image returned. LONG nCapturedFrames; Number of frames captured prior to this image. LONG nGain; Gain value used to capture this image. LONG nExposureTime; Exposure time used to capture this image.

4 - 8

LONG nUnderexposedPixels; Number of underexposed pixels in image. LONG nOverexposedPixels; Number of overexposed pixels in image.

} HHP_IMAGE, *PHHP_IMAGE;

Other Imager Configuration Structures and Defines

Beeper member valid bitmasks:

#define BPMASK_ON_DECODE 0x00001 Beep on successful decode. #define BPMASK_SHORT_BEEP 0x00002 Beep on imager reset. #define BPMASK_MENU_CMD_BEEP 0x00004 Beep on receive menu command. #define BPMASK_BEEP_VOLUME 0x00008 Set the beeper volume. #define BPMASK_ALL 0x0000f Mask for all members valid.

Beeper structure:

typedef struct _tagHHP_BEEPER {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items. BOOL bBeepOnDecode; Sound beeper on successful decode. BOOL bShortBeep; Sound beeper whenever imager resets. BOOL bMenuCmdBeep; Sound beeper whenever a menu command is received. BEEPER_VOLUME beepVolume; Set the beeper volume.

} HHP_BEEPER, *PHHP_BEEPER;

Trigger timeout range:

#define MIN_TRIGGER_TIMEOUT_VAL 0 Infinite #define MAX_TRIGGER_TIMEOUT_VAL 300000 5 Minutes

Trigger structure masks:

#define TRGMASK_TRIG_MODE 0x00001 Enable/disable manual trigger mode. #define TRGMASK_TIMEOUT 0x00002 Sanity timeout on trigger event. #define TRGMASK_ALL 0x00003 All members valid mask.

Triggering control:

typedef struct _tagHHP_TRIGGER {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items. HHP_TRIG_MODES TriggerMode; Trigger mode. DWORD dwTriggerTimeout; 0->9999 (milliseconds).

} HHP_TRIGGER, *PHHP_TRIGGER;

Engine information structure defines:

#define MAX_SHORT_VERSION_LEN 32 #define MAX_SERIAL_NUMBER_LEN 16 #define MAX_CHECKSUM_LEN 8 #define ENGINE_ID_DIGITS 4

Engine information structure

typedef struct _tagHHP_ENGINE_INFO { DWORD dwStructSize; Structure size TCHAR tcEngId[ ENGINE_ID_DIGITS ]; 4 digit ASCII Hex. TCHAR tcHHPSerialNumber[ MAX_SERIAL_NUMBER_LEN ]; ASCII Decimal TCHAR tcCustomSerialNumber[ MAX_SERIAL_NUMBER_LEN ]; ASCII Decimal LONG nAimerX; Aimer X

4 - 9

LONG nAimerY; Aimer Y LONG nLaserPower; Laser power in mW TCHAR tcFirmwareChecksum[ MAX_CHECKSUM_LEN ]; Firmware Checksum (ASCII Hex) TCHAR tcFirmwareRev[ MAX_SHORT_VERSION_LEN ]; Firmware revision number.Number LONG nLedCtrlMode; How LEDs are controled. LONG nLedClr; LED color (red or green LEDs) LONG nPwmFreq; PWM base frequence. LONG nRedLedCurrent; Red LED current (mA). LONG nRedLedMaxCurrent; Red LED max current (mA). LONG nGreenLedCurrent; Green LED current (mA). LONG nGreenLedMaxCurrent; Green LED max current (mA). LONG nAimerCurrent; Aimer current (mA). LONG nAimerMaxCurrent; Aimer max current (mA). LONG nPixelClockFreq; Pixel clock frequency (MHz) TCHAR tcRegisterChecksum[ MAX_CHECKSUM_LEN ]; Register chcksum (ASCII hex)

} HHP_ENGINE_INFO, *PHHP_ENGINE_INFO;

Sequence structure defines:

#define MAX_SEQ_BARCODES 12 #define MAX_NUM_START_CHARS 32 #define SEQ_ALL_LENGTH 9999

Sequence structure masks:

#define SEQMASK_MODE 0x00001 sequenceMode #define SEQMASK_BARCODES 0x00002 dwNumBarCodes & seqBarCodes[] #define SEQMASK_ALL 0x00003 Everything

Individual sequence barcode structure:

typedef struct _tagSeqItem {

LONG nSymId; Symbology identifier SYM_xxxx LONG nLength; Match length or 9999 to match any length. TCHAR tcStartChars[ MAX_NUM_START_CHARS+1 ]; Matching string (from start)

} SeqBarCode_t, *PSeqBarCode_t;

Sequence structure:

typedef struct _tagHHP_SEQUENCE_MODE {

DWORD dwStructSize; Size of structure in bytes DWORD dwMask; Mask of active items HHP_SEQ_MODES sequenceMode; Disabled/Enabled/Enabled & Required DWORD dwNumBarCodes; This MUST be sent if sending seqBarCodes SeqBarCode_t seqBarCodes[ MAX_SEQ_BARCODES ]; Barcodes to sequence in order they are to be

sent

TCHAR tchSeqCmdBlk[ SIZE_OF_SEQUENCE_BLOCK ];

} HHP_SEQUENCE_MODE, *PHHP_SEQUENCE_MODE;

Decode method stucture masks:

#define DCMASK_MAX_MESSAGE_LENGTH 0x00001 Maximum length of decoded string. This item is Read Only. #define DCMASK_DECODE_MULTIPLE 0x00002 Look for and report all barcodes in captured frame. #define DCMASK_USE_AIMERS 0x00004 Use aimers when capturing barcodes. #define DCMASK_PRINT_WEIGHT 0x00008 Relative contrast between barcode and background (0-9). #define DCMASK_DECODE_METHOD 0x00010 Normal, linear codes only. Fastest (may miss codes at

edges of image).

#define DCMASK_CENTER_ENABLE 0x00020 Only accept barcodes whose boundaries intersect center

window.

#define DCMASK_CENTER_WINDOW 0x00040 Rectangle about center of image for previous mask.

4 - 10

#define DCMASK_ILLUMINAT_LED_COLOR 0x00080 Illumination LED color to use. #define DCMASK_ALL 0x000ff All structure members are active.

Decoder functionality settings:

typedef struct _tagHHP_DECODER_CONFIG {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items. DWORD dwMaxMsgSize; Maximum length for any returned barcode string. This is a

read only value.

BOOL bDecodeMultiple; Decode and send all symbols decoded with first frame

where at least 1 symbol is found. BOOL bUseAimers; Turn on aimers during barcode capture. DWORD dwPrintWeight; How dark the barcode elements are relative to the back-

ground (1-7). DECODE_METHOD decodeMethod; Normal decoder, linear codes only, fast normal decoder,

which omits checking at the image margins as well as

some bad barcode correction. BOOL bCenterDecodeEnable; Does symbol have to intersect center decode window to be

valid. RECT centerWindow; Bounding coords of center window that decoded symbol

must intersect ILLUM_LED_COLOR illumLedColor; Illumination LED color to use.

} HHP_DECODER_CONFIG, *PHHP_DECODER_CONFIG;

Aimer Modes:

typedef enum {

AIMER_MODE_ALWAYS_OFF=0, No aimer LEDs. AIMER_MODE_ILLUM_AND_AIM, Aimer LEDs and illumination LEDs on simultaneously. AIMER_MODE_ALWAYS_ON Aimer LEDs always on.

} HHP_AIMER_MODES;

Power setting item masks:

#define PWRMASK_TRIGGER_MODE 0x00001 #define PWRMASK_SERIAL_TRIGGER_TIMEOUT 0x00002 #define PWRMASK_LOW_POWER_TIMEOUT 0x00004 #define PWRMASK_STOP_MODE_TIMEOUT 0x00004 #define PWRMASK_ILLUM_LED_INTENSITY 0x00008 #define PWRMASK_SYS_SPEED 0x00010 #define PWRMASK_AIMER_MODE 0x00020 #define PWRMASK_AIMER_DURATION 0x00040 #define PWRMASK_AIMER_DELAY 0x00080 #define PWRMASK_IMAGER_IDLE_TIMEOUT 0x00100 #define PWRMASK_ RS232_LOW_POWER_TIMEOUT 0x00200 #define PWRMASK_ SLEEP_MODE_TIMEOUT 0x00200 #define PWRMASK_POWER_OFF_HANDLE 0x00400 #define PWRMASK_POWER_OFF_HWND 0x00800 #define PWRMASK_ALL 0x00FFF

Matrix products power management structure:

typedef struct _tagHHP_POWER_SETTINGS {

DWORD dwStructSize; DWORD dwMask; HHP_TRIG_MODES TriggerMode;

4 - 11

DWORD dwTriggerTimeout; 0->300000 (milliseconds). DWORD dwLowPowerTimeout; 0 -> 300. DWORD dwLEDIntensityPercent; 0 -> 100%. HHP_SYS_SPEED systemClockSpeed; Clock speed for reset of system (except RS-232). HHP_AIMER_MODES AimerMode; Aimer always on, alternating between illumination

LEDs, or disabled. DWORD dwAimerDuration; 0 -> 240000 (milliseconds). DWORD dwAimerDelay; 0 -> 240000 (milliseconds). DWORD dwImagerIdleTimeout; 0 -> 999999 (milliseconds). DWORD dw RS232LowPwrTimeout; 0 -> 300 (seconds). RS-232 inactivity timeout

used to enter sleep mode.

These are used to notify on suspend (WinCE Suspend) – Not stored in imager:

HANDLE hPowerOffHandle; Handle for system suspend wakeup notification. HWND hPowerOffHwnd; Window HWND for system suspend wakeup noti-

fication message.

} HHP_POWER_SETTINGS, *PHHP_POWER_SETTINGS;

Version setting item masks – Items are read only:

#define VERMASK_SDK_API 0x00001 SDK version number. #define VERMASK_IMAGER_FIRMWARE 0x00002 Imager firmware version. #define VERMASK_IMAGER_PART_NUM 0x00004 Imager part number. #define VERMASK_IMAGER_BOOT_CODE 0x00008 Imager boot code version. #define VERMASK_IMAGER_DEVICE_TYPE 0x00010 Device type of which imager is part. #define VERMASK_ALL 0x0001f All version info mask.

Revision information:

#define MAX_VERSION_STRING_LEN64 #define MAX_DEVICE_TYPE_STRING_LEN16 typedef struct _tagHHP_VERSION_INFO {

DWORD dwStructSize; Size of structure in bytes. DWORD dwMask; Mask of active items. TCHAR tcAPIRev[ MAX_VERSION_STRING_LEN ]; SDK API version string. TCHAR tcFirmwareRev[ MAX_VERSION_STRING_LEN ]; Imager firmware version. TCHAR tcPartNumber[ MAX_VERSION_STRING_LEN ] ;Imager firmware part number. TCHAR tcBootCodeRev[ MAX_VERSION_STRING_LEN ] ;Imager boot code version. TCHAR tcDeviceType[ MAX_DEVICE_TYPE_STRING_LEN ] ;Imager device identifier.

} HHP_VERSION_INFO, *PHHP_VERSION_INFO;

Structure that includes all structures used to configure imager. See ConfigItems_t when specifying structure to call hhpReadConfigItem() and hhpWriteConfigItem().

typedef struct _tagHHP_CONFIG {

DWORD dwStructSize; Size of HHP_CONFIG structure in bytes. HHP_BEEPER beeperCfg; Beeper configuration structure. HHP_TRIGGER triggerCfg; Trigger configuration structure. HHP_DECODER_CONFIG decoderCfg; Decoder function configuration structure. HHP_POWER_SETTINGS powerCfg; Power modes configuration structure. HHP_VERSION_INFO versionInfo; Version information structure. HHP_SYM_CONFIG symbolCfg; Decoder symbology enables and configuration

structure. HHP_IMAGE_ACQUISITION imgAcqu; Image acquisition configuration structure. HHP_IMAGE_TRANSFER imgTrans; Image transfer configuration structure.

} HHP_CONFIG, *PHHP_CONFIG;

4 - 12

Intelligent Image Capture:

typedef struct {

DWORD dwStructSize; Size of HHP_INTEL_IMG structure in bytes. DWORD dwAspectRatio; Ratio of barcode height to minimum barcode element width. LONG nOffsetX; Offset from barcode center to the image window center in X

LONG nOffsetY; Offset from barcode center to the image window center in Y

DWORD dwWidth; Width of image in minimum barcode units. DWORD dwHeight; Height of image in minimum barcode units. SIZE maxImgSize; Maximum width and height for resulting intelligent image in pix-

BOOL bSendBinary; Have reader binarize data before transfer.

} IntellImgDesc_t, HHP_INTEL_IMG, *PHHP_INTEL_IMG;

Serial Port Config:

typedef struct _tagHHP_SERIAL_PORT_CONFIG {

DWORD dwStructSize; Size of HHP_SERIAL_PORT_CONFIG structure in bytes. HHP_BAUD_RATE baudRate; Baud rate for connection. NOTE: Reader always powers up at

HHP_DATA_BITS dataBits; Number of data bits. HHP_PARITY parity; Parity. HHP_STOP_BITS stopBits; Number of stop bits. BOOL bAutoBaud; Not supported in the IT4500.

direction, relative to barcode center in minimum barcode units.

els. Image size is guaranteed not to exceed either dimension.

115200. The 5X00 Series changes the baud rate to this value once it connects at 115200. Also, the SDK will not allow you to connect at bauds above 115200 for WinCE unless the port driver is sio950.dll (high speed driver for sio950 chipset).

} HHP_SERIAL_PORT_CONFIG, *PHHP_SERIAL_PORT_CONFIG;

Imager capabilities structure – Items are read only:

typedef struct _tagHHP_IMAGER_CAPS {

DWORD dwStructSize; Size of HHP_IMAGE_CAPS structure in bytes. SIZE fullImgSize; Size of image captured by imager before cropping and subsam-

pling. DWORD dwImgrBpp; Bits per pixel of image captured by imager. DECODER_TYPE decoderType; Level of symbology support in the imager’s decoder. IMAGER_TYPE imagerType; Decoded Out Serial, Decoded Out USB, Non-Decoded Out.

} HHP_IMAGER_CAPS, *PHHP_IMAGER_CAPS;

Imager Type (decoded out or non decoded out)

typedef enum { HHP_UNKNOWN_IMAGER Unable to determine engine type. HHP_DECODED_IMAGER_4080 Serial (RS-232) 4080 imager with internal decoder. HHP_DECODED_IMAGER_4080_USB USB serial 4080 imager with internal decoder HHP_NON_DECODED_IMAGER_4000 Incorporated 4000 imager. HHP_DECODED_IMAGER_5080VGA USB serial 5080 VGA imager with internal decoder. HHP_DECODED_IMAGER_5080VGA_USB Serial (RS-232) 5080 VGA imager with internal decoder and

PSOC.

HHP_NON_DECODED_IMAGER_5000VGA Incorporated 5000 VGA imager.

4 - 13

HHP_DECODED_IMAGER_5080VGA_PSOC Serial (RS-232) 5080 imager with internal decoder. HHP_DECODED_IMAGER_5080VGA_PSOC_USB USB serial 5080 imager with internal decoder. HHP_NON_DECODED_IMAGER_5000VGA_PSOC Incorporated 5000 VGA imager with PSOC. HHP_DECODED_IMAGER_5080 Serial (RS-232) 5080 imager with internal decoder. HHP_DECODED_IMAGER_5080_USB USB serial 5080 imager with internal decoder. HHP_NON_DECODED_IMAGER_5000 Incorporated 5000 imager. HHP_DECODED_IMAGER_5080_PSOC Serial (RS-232) 5080 imager with internal decoder and PSOC. HHP_DECODED_IMAGER_5080_PSOC_USB USB serial 5080 imager with internal decoder and PSOC. HHP_NON_DECODED_IMAGER_5000_PSOC Incorporated 5000 imager with PSOC.

} ImagerType_t, IMAGER_TYPE;

4 - 14

OEM-Configurable SDK Functionality

The 5X80 accommodates a variety of PDA/PDT, static mount, and "gun" type installations, so the 5X00 Series has included the flexibility to modify some SDK behaviors. You can provide a DLL that affords the SDK access to the hardware trigger, hardware sleep lines, and access to the open driver handle and registry entries, which can be used to specify high speed baud rates (greater than 115200). You can also specify whether to force a Y-modem communications protocol for image transfers.

OEM Supplied DLL

The OEM DLL interface is described in SDK header file OemDll.h. The DLL can export some or all of the available functionality. If the DLL is named ImgrHwrLines.dll and is located in the default library search path, it will be loaded automatically by the SDK. Otherwise, it can by loaded manually by calling the SDK function hhpSetHardwareLineDllFileName. The DLL exports are described in the following list:

ConfigureCommPort

ConfigureCommPort performs any special driver configuration that needs to be done to support the specified communication port settings. Configuring the communications driver requires the current driver handle, so you must also support SetCommDriverHandle(). The function is called by the SDK whenever you set/change the communication port settings. It is called after the SDK is finished processing pConfig, so any changes you make will not be overridden.

bool ConfigureCommPort( PCommPortConfig pConfig )

Parameter Description

pConfig The communication settings requested. The CommPortConfig structure contains:

Baud Rate, Data Bits, Parity, Stop Bits and RTS control.

ImagerPoweredDown

ImagerPoweredDown checks the imager powered down hardware line for the imager power state. The powered down hardware line is active high. ImagerPoweredDown returns true if the hardware line is high, false if it is low.

bool ImagerPoweredDown( void )

ModifyCommPortDCB

ModifyCommPortDCB receives the RS-232 configuration (DCB) structure just before it's sent to the serial driver. You can then modify the RTS/CTS and DTR/DTS settings if they are used for the imager’s power or trigger.

void ModifyCommPortDCB( LPDCB lpDCB )

Parameter Description

LPDCB lpDCB Structure used by windows to configure a serial port.

SetCommDriverHandle

SetCommDriverHandle receives the handle to the open communications port. The handle can then be used to access private driver ioctl calls.

void SetCommDriverHandle( HANDLE hDriver )

5 - 1

Parameter Description

hDriver The current handle to the open driver used to communicate with the imager.

SetHardwareTrigger

SetHardwareTrigger triggers the imager hardware trigger line, depending on bEnable. The hardware trigger line is active low.

void SetHardwareTrigger( bool bEnable )

Parameter Description

bEnable If true, set trigger line low to trigger imager. If false, set trigger line high to turn off trigger.

WakeUpImager

WakeUpImager toggles the imager hardware wakeup line from low to high, delay, (see Integration Manual for timing), then from high back to low.

void ImagerPoweredDown( void )

Registry Entries

There are two registry entries used to modify the SDK default behavior. The values are both located in the registry key HKEY_LOCAL_MACHINE\SOFTWARE\Hand Held Products\MatrixDemos.

Baud Rate

The SDK will not normally allow high speed serial connections (connections greater than 115200 baud) unless it recognizes the driver name in the registry. The first registry value, BaudRate, specifies the first baud rate at which the demos will attempt to connect. It also overrides the normal block that sets high speed baud rates. This lets you specify a baud rate greater than

115200.

ForceHmodem

The SDK does not normally use its Y-Modem variant, Hmodem, if a high speed serial connection is specified. However, if your driver does not support true hardware RTS flow control, there is a substantial risk of communication buffer overruns. These overruns can cause data loss, especially during image transfer. The registry value ForceHmodem lets you force the use of the communications protocol, preventing data buffer overflow.

5 - 2

Program Samples

Configuration Management

Sample 1 - Set code 39 defaults turning on Full ASCII

CODE39_Tcode39; // Structure for Code 39. TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_tnResult = RESULT_ERR_INTIALIZE; // Return code.

code39.dwStructSize = sizeof( CODE39_T ); // setup size parameter, used in

code39. dwMask = SYM_MASK_FLAGS; // you want all info. if( (nResult = hhpReadSymbologyConfig( SETUP_TYPE_DEFAULT,SYM_CODE39,&code39 )) ==

RESULT_SUCCESS ) {

code39.dwFlags |= SYMBOLOGY_ENABLE_FULLASCII;// OR flags with Enable Full ASCII

nResult = hhpWriteSymbologyConfig( SYM_CODE39,&code39 ); } hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Setup Code39 Returned: %s\n”),tcErrMsg;

Sample 2 - Set the capture mode to photo image

Note: This changes the imager configuration for the items selected. The imager uses these values if they are not overridden

at the time of image capture/transfer.

HHP_IMAGE_TRANSFER imgTrans; // Image transfer structure. TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code.

// Set the structure size and structure mask imgTrans.dwStructSize = sizeof( HHP_IMAGE_TRANSFER); imgTrans.dwMask = IMAGE_CAPTURE_MODE_MASK;

// Turn on photo image mode. ImgTrans.captureMode = HHP_AUTOEXPOSURE_PHOTO;

struct verification.

flag to turn on code 39.

// Call the write configuration function specifying the HHP_ACQUISITION_STRUCTURE. nResult = hhpWriteConfigItem( IMAGE_ACQUISITION,&imgTrans );

// Display error code (NOTE: RESULT_SUCCESS error code returns string SUCCESS. hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Change Imager Config To Photo Capture Mode: %s\n”),tcErrMsg;

6 - 1

Barcode Capture

Sample 3 - A synchronous barcode capture

HHP_DECODE_MSG decodeInfo; TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code.

// Make sure to set the structure size! decodeInfo.dwStructSize = sizeof( HHP_DECODE_MSG ); // Call the SDK function to capture a barcode setting the bWait parameter to TRUE, 6

second timeout. if ( (nResult = hhpCaptureBarcode( &decodeInfo,6000,TRUE ) == RESULT_SUCCESS ) {

_tprintf( _T(“Barcode: %s\n”),decodeInfo.pchMessage ); _tprintf( _T(“Barcode Length: %d\n”),decodeInfo.nLength ); _tprintf( _T(“AIM Id : %cn”),decodeInfo.chCodeID ); _tprintf( _T(“HHP Id: %cn”),decodeInfo.chSymLetter );

_tprintf( _T(“Symbol Modifier: %c\n”),decodeInfo.chSymModifier ); } else {

hhpGetErrorMessage( nResult,tcErrMsg );

_tprintf( _T(“Capture Barcode Returned: %s\n”),tcErrMsg ); }

Sample 4 - An asynchronous barcode capture using an event

HHP_DECODE_MSG decodeInfo; // Returned decoded data message

hhpEventType_t eventType = HHP_BARCODE_EVENT; // Type of event that occurred. TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code.

structure.

// Verify the event is valid (or you won’t get any notification) If( hEvent != NULL ) {

// Register the event with the SDK. if ( (nResult = hhpSetAsyncMethods( hEvent,NULL,NULL ) == RESULT_SUCCESS ) {

// Call the SDK function to capture a barcode setting the bWait parameter to FALSE,

if ( (nResult = hhpCaptureBarcode( NULL,6000,FALSE ) == RESULT_SUCCESS )

{

} }

} if( nResult == RESULT_SUCCESS ) {

6 second timeout.

// Make sure to set the structure size! decodeInfo.dwStructSize = sizeof( HHP_DECODE_MSG ); // Wait on event being set by SDK then call SDK to get results. if( WaitForSingleObject( hEvent,7000 ) == WAIT_OBJECT_0 ) nResult = hhpGetAsyncResult( &event,&decodeInfo );

6 - 2

} else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Capture Barcode Returned: %s\n”),tcErrMsg );

}

Sample 5 - An asynchronous barcode capture message notification

Note: You must hook the message WM_HHP_EVENT_HWND_MSG in your message loop to receive a barcode event

notification. In this example, the message is hooked to call OnEventMsg.

TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code. HWND hWnd = GetSafeHwnd(); // The window to which message is to be

// Register the message window with the SDK. if ( (nResult = hhpSetAsyncMethods( NULL,hWnd,NULL ) == RESULT_SUCCESS ) {

// Call the SDK function to capture a barcode, 6 second timeout. Unless call fails, you

will get a message when command completes. if ( (nResult = hhpCaptureBarcode( NULL,6000,FALSE ) != RESULT_SUCCESS ) {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Capture Barcode Returned: %s\n”),tcErrMsg );

}

sent. (note: this example is MFC c++)

// Message Handler function LRESULT OnEventMsg( WPARAM wParam,LPARAM lParam ) {

hhpEventTye_t eventType = (hhpEventType_t)wParam; // Event type DWORD dwBytes = lParam; // Number of bytes in barcode.

HHP_DECODE_MSG decodeInfo; // Decode message structure. TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code.

// Verify the event type is barcode if( eventType == HHP_BARCODE_EVENT ) {

// Make sure to set the structure size! decodeInfo.dwStructSize = sizeof( HHP_DECODE_MSG ); if( (nResult = hhpGetAsyncResult( &eventType,&decodeInfo )) == RESULT_SUCCESS ) {

_tprintf( _T(“Symbol Modifier: %c\n”),decodeInfo.chSymModifier ); } else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Capture Barcode Returned: %s\n”),tcErrMsg );

}

You don’t actually use it here.

6 - 3

Sample 6 - An asynchronous barcode capture using Callback function

// Message Handler function BOOL CALLBACK EventCallback(HHP_EVENT_TYPE eventType,DWORD dwBytes ) {

HHP_DECODE_MSG decodeInfo; // Decode message structure. TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code.

// Verify the event type is barcode if( eventType == HHP_BARCODE_EVENT ) {

// Make sure to set the structure size! decodeInfo.dwStructSize = sizeof( HHP_DECODE_MSG ); // Retrieve the barcode event data. If( (nResult = hhpGetAsyncResult( &eventType,&decodeInfo )) == RESULT_SUCCESS ) {

_tprintf( _T(“Symbol Modifier: %c\n”),decodeInfo.chSymModifier ); } else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Capture Barcode Returned: %s\n”),tcErrMsg );

}

} } // Code snippet to capture barcode TCHARtcErrMsg[ 128 ]; // Error message buffer. Result_tnResult = RESULT_ERR_INTIALIZE; // Return code.

6 - 4

// Register the callback function with the SDK. if ( (nResult = hhpSetAsyncMethods( NULL,NULL,&EventCallback ) == RESULT_SUCCESS ) {

// Call the SDK function to capture a barcode, 6 second timeout. Unless call fails, we

will get a message when command completes. if ( (nResult = hhpCaptureBarcode( NULL,6000,FALSE ) != RESULT_SUCCESS ) {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T("Capture Barcode Returned: %s\n"),tcErrMsg );

}

Image Capture

Sample 7 - A synchronous image capture

// Capture image specifies: for capture - Photo Mode and Lights On During Frames. for Transfer - Subsample value of 1 and Lossless transfer.

Note: You don’t really have to pass anything except the HHP_IMAGE structure as long as you want the imager config settings for capture and transfer. Also, no progress feedback will be received.

HHP_IMAGE image; // Structure to hold captured image HHP_IMAGE_TRANSFER imgTrans; // Image transfer options (override

TCHAR tcErrMsg[ 128 ]; // Error message buffer Result_t nResult = RESULT_ERR_INTIALIZE; // Return code

// Make sure to set imgAcqu structure size! imgAcqu.dwStructSize = sizeof( HHP_IMAGE_ACQUISITION );

// Set the mask to activate captureMode and illuminatCycle (lights). ImgAcqu.dwMask = (ILLUMINATION_DUTY_CYCLE_MASK | IMAGE_CAPTURE_MODE_MASK);

// Set values ImgAcqu.captureMode = HHP_AUTOEXPOSURE_PHOTO; ImgAcqu. IlluminatCycle = HHP_DUTY_CYCLE_ON;

imager config)

// Image capture options (override

imager config)

// Make sure to set imgTrans structure size! imgTrans.dwStructSize = sizeof( HHP_IMAGE_TRANSFER );

// Set the subsample and compression masks. ImgTrans.dwMask = (SUBSAMPLE_VALUE_MASK | COMPRESSION_MODE_MASK);

// Set values imgTrans.dwSubSample = 1; imgTrans. compressionMode = COMPRESSION_LOSSLESS;

// Set the HHP_IMAGE structure size and allocate a buffer for the data, set the buffer size and how you want to receive the data in the buffer.

Image.dwStructSize = sizeof( HHP_IMAGE ); Image.puchBuffer = new BYTE[ 324000 ]; // Allocate a buffer big enough to hold

Image.nBufferSize = 324000; // SDK wants to know how big the buffer

Image.fileFormat = FF_RAW_GRAY; // 8 bit raw data.

// Call the SDK function to capture an image setting the bWait parameter to TRUE for blocking/synchronous behavior.

if ( (nResult = hhpAcquireImage( &image,&imgTrans, &imgAcqu,TRUE ) == RESULT_SUCCESS ) {

// Display the image. NOTE: you could specify FF_BMP_GRAY. The data would come as

a BMP file. } else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Image Capture Failed: %s\n”),tcErrMsg );

640x480x8 plus header (if BMP)

so no overflow.

6 - 5

} // Remember to delete your buffer. delete [ ] image.puchBuffer;

Sample 8 - An asynchronous image capture using Windows Messaging

Note: You must hook the message WM_HHP_PROGRESS_HWND_MSG in your message loop to receive a barcode event

notification. Here, assume the message is hooked to call OnEventMsg.

// Capture image specifies: for capture - none (use imager config settings) for transfer - subsample value of 2 and JPEG transfer, progress notification

HHP_IMAGE_TRANSFER imgTrans; // Image transfer options (override

TCHAR tcErrMsg[ 128 ]; // Error message buffer. Result_t nResult = RESULT_ERR_INTIALIZE; // Return code. extern DWORD g_dwPercentComplete = NULL; // Percent complete updated by SDK.

// Make sure to set imgTrans structure size! imgTrans.dwStructSize = sizeof( HHP_IMAGE_TRANSFER );

// Set the subsample, compression, and, since you’re specifying lossy compression (JPEG), add the compression factor masks. You are also asking to receive both a Windows message with progress information, as well as having the SDK update a DWORD with the percentage of transfer completion. For the latter, it is important the DWORD not lose scope or be deleted before the asynchronous call completes. You might have a thread or timer that looks at this value periodically before altering the user.

ImgTrans.dwMask =( SUBSAMPLE_VALUE_MASK | COMPRESSION_MODE_MASK | COMPRESSION_FACTOR_MASK

| TRANSFER_UPDATE_HWND | TRANSFER_UPDATE_DWORD); // Set values imgTrans.dwSubSample = 2; // Every other pixel and every other

imgTrans.compressionMode = COMPRESSION_LOSSY; // Image compression lossy which is

imgTrans.compressionFactor = 95; // Image compression factor (image

ImgTrans. hTransferNotifyHwnd = GetSafeHwnd(); // Set this to the window handle you

imgTrans.dwPercentComplete = &g_dwPercentComplete; //Tell SDK to update this DWORD as

imager config)

row.

mode 1 JPEG lossy.

quality) of 95%.

wish to receive the progress message.

data is received.

6 - 6

// Call the SDK function to capture an image setting the bWait parameter to FALSE for asynchronous behavior.

if ( (nResult = hhpAcquireImage( NULL,&imgTrans,NULL,FALSE ) == RESULT_SUCCESS ) {

// Display the image. NOTE: You could specify FF_BMP_GRAY. The data would come as

a BMP file. } else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Image Capture Failed: %s\n”),tcErrMsg );

}

// Message Handler for transfer progress message LRESULT OnProgressMsg( WPARAM wParam,LPARAM lParam ) {

DWORDdwBytesSoFar = wParam;// Number of bytes receive to this point. DWORDdwBytesToRead = lParam;// Total number of bytes expected.

return( 0 );

}

// Message Handler for image acquisition ended function (can be result of a failure as well)

LRESULT OnEventMsg( WPARAM wParam,LPARAM lParam ) {

hhpEventTye_t eventType = (hhpEventType_t)wParam;// Event type DWORD dwBytes = lParam; // Number of bytes in barcode. You

HHP_IMAGE Image; // Returned image structure. TCHAR tcErrMsg[ 128 ]; // Error message buffer Result_t nResult = RESULT_ERR_INTIALIZE; // Return code

// Verify the event type is barcode if( eventType == HHP_IMAGE_EVENT ) {

// Set the HHP_IMAGE structure size and allocate a buffer for the data, set the

buffer size and how we want to receive the data in the buffer. Image.dwStructSize = sizeof( HHP_IMAGE ); Image.puchBuffer = new BYTE[ 324000 ]; // Allocate a buffer big enough to

Image.nBufferSize = 324000; // SDK wants to know how big the

Image.fileFormat = FF_BMP_GRAY; // 8 bit bmp file format data

if( (nResult = hhpGetAsyncResult( &eventType,&Image )) == RESULT_SUCCESS ) {

// save image data to a bmp file and/or display it } else {

hhpGetErrorMessage( nResult,tcErrMsg ); _tprintf( _T(“Capture Image Failed: %s\n”),tcErrMsg );

}

} // Remember to delete your buffer delete [ ] image.puchBuffer;

don’t actually use it here.

hold 640x480x8 plus header (if BMP)

buffer is so there’s no overflow

return( 0 );

}

6 - 7

6 - 8

Customer Support

Product Service and Repair

Honeywell International Inc. provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.

North America

Telephone: (800) 782-4263

E-mail: hsmnaservice@honeywell.com

Latin America

Telephone: (803) 835-8000 Telephone: (800) 782-4263 Fax: (239) 263-9689

E-mail: laservice@honeywell.com

Brazil

Telephone: +55 (11) 5185-8222 Fax: +55 (11) 5185-8225

E-mail: brservice@honeywell.com

Mexico

Telephone: 01-800-HONEYWELL (01-800-466-3993) Fax: +52 (55) 5531-3672

E-mail: mxservice@honeywell.com

Europe, Middle East, and Africa

Telephone: +31 (0) 40 2901 633 Fax: +31 (0) 40 2901 631

E-mail: euroservice@honeywell.com

Hong Kong

Telephone: +852-29536436 Fax: +852-2511-3557

E-mail: apservice@honeywell.com

Singapore

Telephone: +65-6842-7155 Fax: +65-6842-7166

E-mail: apservice@honeywell.com

China

Telephone: +86 800 828 2803 Fax: +86-512-6762-2560

E-mail: apservice@honeywell.com

Japan

Telephone: +81-3-6730-7344 Fax: +81-3-6730-7222

E-mail: apservice@honeywell.com

Online Product Service and Repair Assistance

You can also access product service and repair assistance online at www.honeywellaidc.com.

7 - 1

Technical Assistance

If you need assistance installing or troubleshooting your device, please call your distributor or the nearest technical support office:

North America/Canada

Telephone: (800) 782-4263

E-mail: hsmnasupport@honeywell.com

Latin America

Telephone: (803) 835-8000 Telephone: (800) 782-4263

E-mail: hsmlasupport@honeywell.com

Brazil

Telephone: +55 (11) 5185-8222 Fax: +55 (11) 5185-8225

E-mail: brsuporte@honeywell.com

Mexico

Telephone: 01-800-HONEYWELL (01-800-466-3993)

E-mail: soporte.hsm@honeywell.com

Europe, Middle East, and Africa

Telephone: +31 (0) 40 7999 393 Fax: +31 (0) 40 2425 672

E-mail: hsmeurosupport@honeywell.com

Hong Kong

Telephone: +852-29536436 Fax: +852-2511-3557

E-mail: aptechsupport@honeywell.com

Singapore

Telephone: +65-6842-7155 Fax: +65-6842-7166

E-mail: aptechsupport@honeywell.com

China

Telephone: +86 800 828 2803 Fax: +86-512-6762-2560

E-mail: aptechsupport@honeywell.com

Japan

Telephone: +81-3-6730-7344 Fax: +81-3-6730-7222

E-mail: aptechsupport@honeywell.com

Online Technical Assistance

You can also access technical assistance online at www.honeywellaidc.com.

7 - 2

™

Honeywell Scanning & Mobility

9680 Old Bailes Road Fort Mill, SC 29707

www.honeywellaidc.com

5X10-80SDK-UG Rev D

4/11

Honeywell 5380, 5180, 5080 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Features of the 5X00 Series

Target Operating Systems for the 5X00 Series

Interface Diagram

5X00 Series Library Files

5X00 Series API Library Summary

Data Types, Structures, and Enumerated Types

API Function Descriptions

hhpAcquireImage

hhpAcquireIntelligentImage

hhpCancelIo

hhpCaptureBarcode

hhpCaptureRawBarcode

hhpConnect

hhpDisconnect

hhpEnableDisableSymbology

hhpEngineConnected

hhpGetAsyncResult

hhpGetErrorMessage

hhpGetLastImage

hhpNamedConnect

hhpRawAcquireIntelligentImage

hhpReadConfigItem

hhpReadConfigStream

hhpReadEngineInfo

hhpReadImagerCapabilities

hhpReadSymbologyConfig

hhpReadSymbologyRangeMaxMin

hhpSendActionCommand

hhpSendMessage

hhpSetAsyncMethods

hhpSetBarcodeDataCodePage

hhpSetConfigItemToDefaults

hhpSetHardwareLineDllFileName

hhpSetSymbologyDefaults

hhpUpgradeFirmware

hhpWriteConfigItem

hhpWriteConfigStream

hhpWriteSymbologyConfig

Symbology Identifiers

Enumerated Types and Definitions

Setup Type Enumerated Type

Supported OCR Fonts

Compression Mode Formats

Capture Illumination Duty Cycle

Auto Exposure Type

Gain Values Enum

Frame Rates Enum

Beeper Volume Enum

Decoder Mode Enum

System (MPU) Clock Speeds

Configuration Structure Item Enum for hhpReadConfigItem() and hhpWriteConfigItem()

Trigger Modes Enum

Sequence Mode

Serial Port Baud Rates

Baud Rates that Require USB Serial or SIO950 Compatible Serial Port Driver

Serial Data Bits

Parity

Stop Bits

Connection Types

Decoder Symbology Support

HHP Action Commands

On/Off Enum

Beep Execute Enum

Imager Type Enum

Illumination Color Enum (5X10/5X80 engines only)

Structures and Mask Definitions

Symbology Structures and Defines

Imaging Structures and Defines

Other Imager Configuration Structures and Defines

OEM-Configurable SDK Functionality

OEM Supplied DLL

ConfigureCommPort

ImagerPoweredDown

ModifyCommPortDCB

SetCommDriverHandle
