206391AA and 206273AA
Replacement Battery Doors
For T8131 and T8132 Thermosatats
APPLICATION
The 206391AA and 206273AA Replacement Battery
Doors are used with the T8131 and T8132 Thermostats.
INSTALLATION INSTRUCTIONS
INSTALLATION
Use the 206391AA Replacement Battery Door on the
Premier White® color T8131 and T8132 Thermostats.
Use the 206273AA Replacement Battery Door on the
taupe color T8131 and T8132 Thermostats.
To installl your new battery door:
1. Use a coin to remove the current battery. See
Fig. 1.
2. Engage the door on the tab at the top of the
thermostat and press the lower edge of the door.
See Fig. 2.
REMOVING
BATTERY
M1719C
Fig. 1. Removing the battery door.
DOOR
ENGAGE
TAB
Fig. 2. Installing the battery door.
LOWER
DOOR
AND SNAP
IN PLACE
M9936
