INNCOM PC-502.1 Datasheet
Overview
The INNCOM PC-502 wall mounted module can be used to expand the range of a network (IR or Layer-1 or Layer-2 RF) or to provide the protocol gateway from INNCOM S5-bus to Layer-1 or Layer-2 RF protocol.
In an IR network, the PC-502 module can be used to provide remote eye functionality or protocol gateway from INNCOM S5-bus to IR wireless protocols. The PC-502 adds functionality beyond the traditional remote eye because, as a smart 5-bus device, it can be powered from a standard 3-pin 5-bus connection.
In a Layer-1 RF network, the PC-502 provides S5-bus to RF protocol conversion, giving any INNCOM product participating in the INNCOM Integrated Room Automation System (IRAS) an RF transceiver for control of wireless products in the guestroom.
In the Deep Mesh 802.15.4 network, the PC-502 is designed to patch areas within the network where signal strength is lost due to distance limitations or interference. It
also serves to create multiple pathways, increasing the redundancy of the mesh communications to ensure maximum network reliability.
Features
Small wall mountable form factor
2.4Ghz IEEE 802.15.4 compliant RF transceiver (CC2430 radio core)
Medium and long range variants available
Industrial temperature ratings 0–65 degrees C
FCC Part 15b listed
Specification
Parameter |
PC-502.1 |
|
|
RF Data Rate |
250kbps |
Antenna Type |
SMT |
Indoor Range |
70ft |
Outdoor/ RF line-of-sight range |
540ft |
Transmit Power |
1mW (+0dBm) |
Receive Sensitivity |
-94.6dBm |
Frequency Band |
2.4Ghz |
Encryption |
AES-128 |
Protocol |
802.15.4 |
Frequency Channels |
11-26 |
Input Voltage |
12VDC |
Current Consumption |
50mA (Peak) |
Operating Ambient Temperature |
0°C |
INNCOM PC-502 Datasheet |
P a g e | 2 |
|
|
Network Topology
X 07 HVAC |
L 208 Lamp |
Controller |
Controller |
e527 |
PC502.IR |
S55 x Lamp |
|
Controller |
|||
|
|
||
|
S5bus |
|
|
|
D254. DIN |
|
Figure 2 PC-502.IR Topology
In this application, the PC-502 provides S5-bus to IR protocol conversion giving any INNCOM product participating in the INNCOM Integrated Room Automation System (IRAS) an IR transceiver for control of wireless products in the guestroom.
X07 HVAC |
L208 Lamp |
Controller |
Controller |
|
Layer-1 RF Network |
e527 |
PC-502.1 |
S55x Lamp |
|
Controller |
|||
|
|
||
|
S5bus |
|
|
|
D254.DIN |
|
Figure 3 PC-502 Layer-1 Topology
In this application, the PC-502 is providing S5-bus to RF protocol conversion, giving any INNCOM product participating in the INNCOM Integrated Room Automation System (IRAS) an RF transceiver for control of wireless products in the guestroom.
