Honda EB5000, EB6500, EU3000is, EU1000i, EU(2000)i Information

Honda Generators

Is a Honda generator for work? For play? Absolutely.

I

n the back of your pickup sit three

Honda generators.

Today they’re

going to the jobsite where they’ll

purr like kittens but work

like dogs. Funny, it was just last

weekend you took the smaller, lightweight

generator camping. Your wife used it for

margaritas and your kids used it to watch

TV. And the weekend before that, the mid-size

generator came in handy when a storm

unexpectedly knocked out the lights at home.

All of which makes you think, “So, are these

things made for work, or for play?”

After a moment, you’ve got the answer:

it doesn’t matter. Whenever you need

extra power, Honda’s got the generator

for you. Giving you the power you really need.

The power of choice.

Generators for Every Application

Wherever you need it, Honda has

the power to keep you going.

When the lights go out, it’s more than just an inconvenience.
Power outages can also result in financial loss due to spoiled
food, lost work time, broken pipes and even water damage
to buildings and furniture. A quiet, reliable Honda generator
can easily keep your family safe and secure through
power-related emergencies. It can also be used to charge
your 12-volt car battery.

*

Why are Honda generators number one on the job? Easy.
Reliability and durability. On construction sites, time is
money; crews can’t afford to be idle due to a lack of on-site
power. In the construction and rental industry, Honda has
consistently been named “most preferred” in reader
surveys by leading trade publications. Minimal downtime
plus minimal maintenance equals happy customers.

* Model-specific feature. Requires optional charging cord.

For work

For home

For camping and RV power, Honda portable power is the
perfect way to enjoy the great outdoors with all the comforts
of home. Portable generators are also ideal for outdoor
events like concerts, races, parties, tailgating and more.
That’s why Honda is the official generator of the Talladega
Superspeedway, the EAA AirVenture Oshkosh and Official
Supplier to INDYCAR to name a few.

For play

All Honda Generators feature either our
Honda GX or iGX commercial grade engines.
These four-stroke engines are recognized as
the industry leader in providing reliable, quiet
and fuel-efficient power. In fact, they run about
30% more fuel efficiently than comparable
side-valve engines.

Features include

overhead valves for smooth, consistent

power, and a

cast iron cylinder sleeve

*

for “commercial
grade” quality and durability. Many offer a dual element air cleaner for increased
engine life. All Honda generators are equipped with Oil Alert®which protects the
engine by shutting it down if the oil pressure level reaches an unsafe level.

And we’re proud to point out that the next generation of GX Engines, models
GX120 – GX390, bring even more to the table. Like noise reduction levels ranging
from 2.5 to 8dBA, 10% lower fuel consumption, plus, they already meet or beat
EPA Phase 3 emission regulations without a catalyst. The GX240 – GX390
model engines offer up to 6% more power over the original models. The
increase in power is achieved through several innovative improvements. First,
the new GX series now employs a digital CDI ignition system to dramatically
improve ignition timing. Second, the compression ratio has been increased
and finally, combustion air flow has been enhanced through a more efficient
air cleaner design that reduces air flow restriction.

Honda iGX Engines
take intelligence to

a whole new level.

Honda’s innovative iGX Series, a new generation
of intelligent computer-controlled engines, are on

select Honda EM and EB series generators.

The iGX models now employ a digital CDI ignition
system to dramatically improve ignition timing.
They also feature an integrated electronic control
unit (ECU) that communicates with a self-tuning
regulator (STR) governor system which allows the

engine to communicate with the machine it is powering. As the engine becomes
intelligent, operation is automated and control becomes surer, faster and easier.
Thus delivering exactly what you’ve always wanted; optimal performance.

W

hether you’re

a camper or a

contractor, an RVer or a

dirt biker, whether you

work in a shed out back

or at home in your office,

extra power with a

Honda Generator means

you’ll never go without.

2

* Except for EU1000.

Powered by world-famous

Honda Engines

facebook.com/
HondaGenerators

And be sure to become

our fan on Facebook.

And now, you don’t

even have to go out

your door to look for a

Honda. You can see our

entire line of reliable

generators and shop

online at gen.honda.com.

How cool is that?

Quiet

Thanks to the use of
inherently quiet four-stroke
engines and superior
technology, Honda
generators boast incredibly
low decibel levels.

Portable

Honda generators are
made for true portability,
from lightweight, easy-to­carry models to those with
wheeled transport kits.

Fuel Efficient

Honda’s superior
technology, with features
such as Eco-Throttle™and
Auto Throttle®, means
increased fuel efficiency
and longer run times.

Reliable

Honda has an unmatched
reputation for reliable
generators that offer
dependable starts and
keep on running year
after year.

Clean Power

Consistent delivery of clean
power is possible with
technologies such as
Inverter, CycloConverter™,
DAVR and iAVR voltage
regulating systems.

3

The Honda Advantage

EM Series generators with

electric start range from

4,000 to 6,500 watts and

offer a wide variety of

enhanced functions

for home backup and

general purpose situations.

EU Series generators represent

the leading edge of portable

power technology. Ranging from 1,000

to 6,500 watts, these totally enclosed,

super quiet generators are ideal

for recreational and home

backup applications.

EB Series generators range from

3,000 to 10,000 watts of industrial

strength power. These generators are

consistently ranked #1 by the

construction and rental industries.

Economy

series

Super Quiet

series

Industrial

series

EG Series generators are ideal

for residential and commercial use

and range from 4,000 to 6,500 watts,

offering legendary Honda reliability with

a no-frills approach to your basic power needs.

Deluxe

series

Features & Benefits

4

Honda Inverter Technology means stable, clean power in a smaller, lighter package.

You can even operate the most sensitive electronics without fear of interruption. Inverter technology is available on eight

Honda generators; look for an “i” after the model number.

Computers and power-sensitive testing equipment require what is referred to as “clean power.” Clean power is
electrical current that is consistent and has a stable “sine wave” or signal. If the lights or other basic appliances
in your home were being powered by a generator and there was a fluctuation in the AC power, you’d probably
see the lights flicker – no problem! However, if your computer was being powered by a
generator and the voltage fluctuated, chances are the computer would either shut down
or at least interrupt the program you were working in.

While all Honda Generators provide stable power, Honda engineers developed a
revolutionary form of inverter technology. This process takes the raw power produced
by the generator and passes it through a special microprocessor. This means you can
operate a computer or other sensitive equipment from a remote location with even less
possibility of interrupted service or damage to the equipment.

Using inverter technology, Honda engineers have integrated parts from
the engine and generator set, such as the combination flywheel/alternator.
This results in a more compact and lighter product that is purpose-built to
make clean, reliable power.

Honda offers consistent delivery

of clean power.

EU Series

Conventional

5

Inverter technology
is available on eight
Honda generators,
designated by an “i”
after the model number.

EU1000i – Super Quiet Series

EU2000i – Super Quiet Series

EU2000

i

Camo –Super Quiet Series

EU3000is – Super Quiet Series

EM5000is– i-Deluxe Series

EU6500is – Super Quiet Series

EU2000i Companion

–

Super Quiet Series

Handi EU3000i – Super Quiet Series

Eco-Throttle™System

Fuel economy, quiet operation and low emission levels.

Honda’s Eco-Throttle™system automatically adjusts engine speed to the optimum level,
given the usage load, through a load-dependent speed control-type governor. This not
only results in excellent fuel economy, but also makes a quiet generator even quieter.
Eco-Throttle

™

is standard on all inverter models.

Automatic Voltage Regulation

Consistent delivery of power under different loads.

Many Honda generators feature a new DAVR (Digital Automatic Voltage Regulator)
designed to hold the voltage stability within a +/- 1% change during operation to which the
U.S. standard is 60hZ. The DAVR adjustments are driven off the main winding versus a
sensor winding in conventional AVR systems. Additionally, the DAVR is protected from
overheating by a thermistor.

Some EM and EB Series now offer a proprietary new Honda

technology, iAVR (Intelligent Automatic Voltage Regulator).

This consists of a digital capacitive discharge ignition, a self

tuning regulator governor, a current transformer applied to

the auto throttle and the new DAVR control unit. iAVR
lets the generator operate well above its maximum rating for up to 10 seconds to start high
initial amp draw situations. This ensures a consistent flow of power regardless of the load,
which translates into protection for sensitive equipment and reliable power for you.

Model The iAVR Advantage

EM4000/EB4000 5000 watts for up to 10 seconds
EM5000/EB5000 7000 watts for up to 10 seconds
EM6500/EB6500 7000 watts for up to 10 seconds

Honda CycloConverter™Technology

Heavyweight power in a lighter weight unit.

Honda’s CycloConverter™generator model offers power that is
equal in quality to AVR (Automatic Voltage Regulator) generators
but is dramatically lighter than other units producing the same
amount of power. This lighter weight is achieved by reducing the
number of traditional parts with a CPU (Central Processing Unit)
that conditions the raw power produced by the generator and
eliminates the need for a bulky alternator. Honda CycloConverter™technology offers the
best power-to-weight ratio available anywhere. This is found on the EB3000c model only.

CycloConverter™sine wave

W

hile portable power is ideally distributed

through a professionally installed transfer

switch, homeowners can easily and safely

use a smaller output portable generator to power

essential home appliances.

Power management tips

During power outages, the first priority is to

provide sufficient light for the safety of

your family. If power is out for several

hours, you will want to power your refrigerator

and freezer to ensure that no food spoilage occurs.

Remember that it is not necessary to continually

power these appliances if your generator has a

small power output. Power management will

allow you to utilize a small generator to power

several appliances safely.

Portable generators over 1000 watts can be used to

power microwave ovens, as well as toaster ovens and

other electrical cooking devices, for meal preparation.

The Honda EU3000is or Handi EU3000i inverter

generators are ideal for customers who do not have

240-volt requirements.

The Honda EU6500is is a great choice for homeowners

with larger power requirements such as deep well water

pumps. This generator is also the top model offered with

the HP

2

S (Honda Portable Power Systems), that includes

a programmable Universal Transfer Switch that

automatically directs power to priority circuits

in your home. A qualified electrician should

professionally install any home backup system

utilizing a portable generator and manual

or automatic transfer switch. Never run a

generator in a closed or even partly closed area.

*

Contact your nearest Honda dealer or qualified

electrician to help determine the best backup power

options for your home.

Once you master the art of “power management,”

you will discover that a smaller portable generator can

safely provide many of the conveniences you count on

every day. And when the power comes back on,

you will be able to take and use your generator

at the park, at the lake, on the boat and tailgating

before the big game, as well as many other applications

around the home.

6 Home Backup

Safe use of portable generators for

* Never run a generator in a closed, or even partly closed area where people may be present. Generator exhaust contains poisonous carbon monoxide gas that can cause unconsciousness or death.

Keep the generator at least 10 Feet (3.05 Meters) away from any building or other equipment during operation.

Transfer Switch

What is a Transfer Switch?

A transfer switch installs near your breaker box and
provides a safe way to connect and use a generator with
selected circuits inside your home or building. It’s also
essential to prevent power from energizing lines outside
your home where power company workers might be
performing service.

Honda offers two types of transfer switches, manual and
“smart.” Both work with a single, heavy-duty cable to
connect the generator to the house or building. Manual types
can transfer power with a large, single master breaker,
and other versions use individual breakers. The “smart”
switch or UTS (Universal Transfer Switch) is a digitally­controlled and programmable system. After being connected

to the generator, the UTS is fully automatic. Its key feature
is automatic load shedding, which lets you set which circuits
have priority. For additional information on UTS transfer
switches and the Honda HP

2

S home backup systems,

visit our website at www.honda.com.

Why a Transfer Switch?

Often required by local electrical codes, a transfer switch
provides a safe and convenient method of connecting an
outdoor generator to a home or building. A transfer switch
completely isolates the generator’s power to selected circuits.
This prevents the generator’s power from going outside the
house or building, which could damage property and
possibly injure or kill power company workers servicing
nearby lines.

home power backup.

How Much Power Do You Need? 7

NOTE: Check your equipment or applicance for actual wattage requirements.

HOUSEHOLD/RV

Air Conditioner

Window Unit, 10,000 BTU. . . . . . . . . . . . . . . 2200 . . . . . . . . . . . 1500

RV, 13,500 BTU . . . . . . . . . . . . . . . . . . . . . . . 2800 . . . . . . . . . . . 1800

Automatic Clothes Washer . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . 1200

Box Fan or Table Fan, 20" . . . . . . . . . . . . . . . . . . . 180 . . . . . . . . . . . . 120

Clothes Dryer

Electric. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6750 . . . . . . . . . . . 5400

Natural Gas. . . . . . . . . . . . . . . . . . . . . . . . . . . 2000 . . . . . . . . . . . . 720

Coffee Maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600 . . . . . . . . . . . . 600

Dishwasher (Cool Dry) . . . . . . . . . . . . . . . . . . . . . . 540. . . . . . . . . . . . . 216

Electric Blanket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 . . . . . . . . . . . . 150

Electric Fry Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500 . . . . . . . . . . . 1500

Electric Range

6-inch element . . . . . . . . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . 1200

8-inch element . . . . . . . . . . . . . . . . . . . . . . . . 2100 . . . . . . . . . . . 2100

Furnace Fan, gas or fuel oil

1 ⁄ 8 Horsepower . . . . . . . . . . . . . . . . . . . . . . . 500 . . . . . . . . . . . . 300

1 ⁄ 6 Horsepower. . . . . . . . . . . . . . . . . . . . . . . . 750 . . . . . . . . . . . . 500

1 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1000 . . . . . . . . . . . . 600

1 ⁄ 3 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1400 . . . . . . . . . . . . 700

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . 2350 . . . . . . . . . . . . 875

Incandescent Lights . . . . . . . . . . . . . .

as indicated on bulb . . . as indicated on bulb

Microwave Oven

650 watts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . 1000

800 watts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1400 . . . . . . . . . . . 1300

1000 watts . . . . . . . . . . . . . . . . . . . . . . . . . . . 1750 . . . . . . . . . . . 1500

Radiant Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . 1300 . . . . . . . . . . . 1300

Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 to 200 . . . . . . . 50 to 200

Refrigerator or Freezer (Energy Star) . . . . . . . . . . 1200 . . . . . . . . 132-192

Sump Pump

1 ⁄ 3 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1300 . . . . . . . . . . . . 800

1⁄2 Horsepower. . . . . . . . . . . . . . . . . . . . . . . 2150 . . . . . . . . . . . 1050

Television. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 . . . . . . . . . . . . 300

Toaster. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500 . . . . . . . . . . . 1500

CONTRACTOR

Air Compressor

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1600 . . . . . . . . . . . . 975

1 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 4500 . . . . . . . . . . . 1600

Bench Grinder, 8 inches . . . . . . . . . . . . . . . . . . . 2500 . . . . . . . . . . . 1400

Circular Saw, Heavy Duty, 7 1 ⁄ 4 inches . . . . . . . 2300 . . . . . . . . . . . 1400

Concrete Vibrator

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . . 840 . . . . . . . . . . . . 840

1 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 1080 . . . . . . . . . . . 1080

2 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 1560 . . . . . . . . . . . 1560

3 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 2400 . . . . . . . . . . . 2400

Demolition Hammer. . . . . . . . . . . . . . . . . . . . . . . 1260 . . . . . . . . . . . 1260

Drain Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 . . . . . . . . . . . . 250

Drills

3 ⁄ 8 inch, 4 amps. . . . . . . . . . . . . . . . . . . . . . . 600 . . . . . . . . . . . . 440

1 ⁄ 2 inch, 5.4 amps . . . . . . . . . . . . . . . . . . . . . 900 . . . . . . . . . . . . 600

Hand Drill, 1 ⁄ 2 inch. . . . . . . . . . . . . . . . . . . . . 900 . . . . . . . . . . . . 600

Electric Chain Saw, 14 inches, 2 hp . . . . . . . . . . 1100 . . . . . . . . . . . 1100

High-Pressure Washer, 1 Horsepower . . . . . . . . 3600 . . . . . . . . . . . 1200

Rotary Hammer . . . . . . . . . . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . 1200

Table Saw, 10 inches . . . . . . . . . . . . . . . . . . . . . . 4500 . . . . . . . . . . . 1800

INDUSTRIAL MOTORS

Capacitor Start Capacitor Run

1 ⁄ 8 Horsepower . . . . . . . . . . . . . . . . . . . . . . . 850 . . . . . . . . . . . . 275

1 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1050 . . . . . . . . . . . . 400

1 ⁄ 3 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1350 . . . . . . . . . . . . 450

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1800 . . . . . . . . . . . . 600

3 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . 2600 . . . . . . . . . . . . 850

1 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 3000 . . . . . . . . . . . 1000

1 1 ⁄ 2 Horsepower. . . . . . . . . . . . . . . . . . . . . 4200 . . . . . . . . . . . 1600

2 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 5100 . . . . . . . . . . . 2000

3 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 6800 . . . . . . . . . . . 3000

4 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 9800 . . . . . . . . . . . 4800

Capacitor Start Induction Run

1 ⁄ 8 Horsepower . . . . . . . . . . . . . . . . . . . . . . . 600 . . . . . . . . . . . . 275

1 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . . 850 . . . . . . . . . . . . 400

1 ⁄ 3 Horsepower. . . . . . . . . . . . . . . . . . . . . . . . 975 . . . . . . . . . . . . 450

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1300 . . . . . . . . . . . . 600

3 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1900 . . . . . . . . . . . . 850

1 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 2300 . . . . . . . . . . . 1000

1 1 ⁄ 2 Horsepower. . . . . . . . . . . . . . . . . . . . . 3200 . . . . . . . . . . . 1600

2 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 3900 . . . . . . . . . . . 2000

3 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 5200 . . . . . . . . . . . 3000

4 Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . 7500 . . . . . . . . . . . 4800

Fan Duty, 1 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . . 650

Split Phase

1 ⁄ 8 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1200 . . . . . . . . . . . . 275

1 ⁄ 4 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1700 . . . . . . . . . . . . 400

1 ⁄ 3 Horsepower . . . . . . . . . . . . . . . . . . . . . . 1950 . . . . . . . . . . . . 450

1 ⁄ 2 Horsepower . . . . . . . . . . . . . . . . . . . . . . 2600 . . . . . . . . . . . . 600

FARM EQUIPMENT

Battery Charger

15 amp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380 . . . . . . . . . . . . 380

60 amp with 250-amp boost . . . . . . 1500/5750 . . . . . 1500/5750

100 amp with 300-amp boost . . . . . 2400/7800 . . . . . 2400/7800

Electric Fence, 25 miles . . . . . . . . . . . . . . . . . . . . . 250 . . . . . . . . . . . . 250

Electric Welder

200 amp AC . . . . . . . . . . . . . . . . . . . . . . . . . . 9000 . . . . . . . . . . . 9000

230 amp AC, at 100 amp . . . . . . . . . . . . . . . 7800 . . . . . . . . . . . 7800

Milk Cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1800 . . . . . . . . . . . 1100

Milker (vacuum pump), 2 Horsepower . . . . . . . . 2300 . . . . . . . . . . . 1000

Portable Heater (kerosene, diesel fuel)

50,000 BTU . . . . . . . . . . . . . . . . . . . . . . . . . . . 600 . . . . . . . . . . . . 400

90,000 BTU . . . . . . . . . . . . . . . . . . . . . . . . . . . 725 . . . . . . . . . . . . 500

150,000 BTU . . . . . . . . . . . . . . . . . . . . . . . . . 1000 . . . . . . . . . . . . 625

OFFICE

Desktop Computer . . . . . . . . . . . . . . . . . . . 600 to 800 . . . . . . 600 to 800

Fax Machine. . . . . . . . . . . . . . . . . . . . . . . . 600 to 800 . . . . . . 600 to 800

Laptop Computer . . . . . . . . . . . . . . . . . . . . 200 to 250 . . . . . . 200 to 250

Monitor

CRT style . . . . . . . . . . . . . . . . . . . . . . . . 200 to 250 . . . . . . 200 to 250

LCD style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30. . . . . . . . . . . . . . 30

Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 to 600 . . . . . . 400 to 600

Ask your Honda Dealer to help you
select the most efficient model for
your power needs.

Amps x Volts = Watts

APPROXIMATE

WATTAGE REQUIRED

FOR STARTING

APPROXIMATE

RUNNING WATTAGE

REQUIREMENTS

APPROXIMATE

WATTAGE REQUIRED

FOR STARTING

APPROXIMATE

RUNNING WATTAGE

REQUIREMENTS

SUPER QUIET

8 Super Quiet Series

O

ur Super Quiet Series generators
feature a totally enclosed body

that results in noticeably quieter
performance. Designed for the ultimate
in quality, portability and convenience,
these models are perfect for any trip to
the great outdoors. All of the Super Quiet
generators have ultra-low noise, making
them ideal for camping, RVing, home backup,
public events or any situation where quiet
operation is critical.

Honda’s advanced inverter technology makes
the EU model generators extremely lightweight
and portable. EU models also boast great fuel

efficiency thanks to the Eco-Throttle

™

System,
which enables the engine to run only as fast as
needed for any given load.

With 3000 watts of super-quiet power and at
only 18 lbs. tow weight, the recently developed

Handi EU3000i is a portable power source

that’s handy to take along almost anywhere.

The top-of-the-line EU series model is the
powerful

EU6500is. Features include Inverter

Technology, Eco-Throttle

™

and a triple chamber
design for super-quiet operation. This EU
generator is our most powerful, versatile and
technologically advanced generator yet.

Super Quiet Series 9

Features & Benefits

Double your power

*

Two identical wattage EU
generators can be linked
in parallel to increase
available wattage through
the generator outlets.

**

*N/A for EU6500is.
**Requires optional cable kit.

Fuel efficient

Honda’s superior
technology, such as
Eco-Throttle,

™

results in

increased fuel efficiency.

Lightweight

EU models are incredibly
lightweight and portable,
thanks to inverter
technology.

EU2000i / EU2000i Camo

Honda’s advanced inverter technology provides
2000 watts of extremely quiet, lightweight and
fuel-efficient power. This popular model can
operate a wide variety of appliances, making it
perfect for portable use at home or while camping.
It’s also available with a Natural Gear™camo
exterior. Can run 4.0 to 9.6 hours on a single
tank, depending on load. Ideal for microwaves,
coffee pots, hair dryers and refrigerators.

EU1000i

Honda’s advanced inverter technology
offers 1000 watts of super-quiet power to
run a wide variety of small appliances,
including computers and other sensitive
electronic devices. Can run 4.0 to 8.3
hours on a single tank, depending on load.
Perfect for lights, fans, TVs and small
power tools.

DC Charging

*

These units have a
DC outlet for use when
charging 12-volt
automotive type batteries.

**

*N/A for EU6500is and EU2000

Companion.

**Requires optional charging cord.

EU2000i Companion

The EU2000i Companion offers one
30A receptacle for RV applications
(requires optional adaptor) and one 20A
receptacle. The 30A receptacle allows two
EU2000i models to be run in parallel by
way of a simple parallel cable.

EU3000is

Honda’s advanced inverter technology
provides 3000 watts of super-quiet power
capable of running many types of appliances,
including computers and other sensitive
equipment. Can run from 7.2 to 20.0 hours
on a single tank, depending on load. An
excellent source of power for most 13,500
BTU RV A/C units and basic home backup.

Handi EU3000i

The Handi EU3000i is the lightest and most
portable 3000 watt inverter generator we’ve
ever made. With its convenient flip-up handle
and sturdy transport wheels, it’s easy to pack
and perfect for camping, tailgating, working
outdoors and, of course, home backup. Comes
complete with a closable fuel vent for safer
transporting and a recessed convenience light.

EU6500is

Honda’s advanced inverter technology offers
6500 watts of super quiet, fuel-efficient
power. Can run from 4.7 to 14 hours on a
single tank of fuel, depending on load. Ideal
for home backup power, RV use, outdoor
events, special projects, job sites and more.

Portable

The Honda Handi

™

EU3000i is designed with
a unique folding handle
and recessed transport
wheels for greater mobility.

DELUXE

10 Deluxe Series

* Never run a generator in a closed, or even partly closed area where people may be present. Generator exhaust contains poisonous carbon monoxide gas that can cause

unconsciousness or death. Keep the generator at least 10 Feet (3.05 Meters) away from any building or other equipment during operation.

H

onda Deluxe Series generators
offer the right features for
convenient, reliable backup power

during outages and brownouts.

*

Features include a heavy-duty full frame
for added protection, voltage regulation
for continuous stable power, wide handles
for easy transporting, multiple front panel
outlets for easy power connections and
electric start.

The

EM4000, EM5000 and EM6500

generators feature simultaneous AC/DC use,
fuel gauges and large 6.2-gallon fuel tanks
for hours of continuous operation.

All of them are powered by the new,
technologically-advanced commercial-grade
iGX Engines and include the all-new iAVR
power feature which minimizes voltage
fluctuations and allows for increased wattage
above the maximum rating for up to 10
seconds to start high amp load applications.
Adding up to quiet, durable and efficient
power like you’ve never experienced.

The

EM5000is model adds Honda’s

advanced Inverter Technology to the mix –
providing quieter operation with clean power
in a smaller, lighter-weight package.

EM5000SX

Deluxe electric start, 5000-watt model
with Honda iGX commercial engine with
Oil Alert

®

, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, 120/240V
selector switch, iAVR for 7000 watts up to
10 seconds and Auto Throttle

®

.

EM4000SX

Deluxe electric start, 4000-watt model
with Honda iGX commercial engine with
Oil Alert

®

, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, 120/240V
selector switch, iAVR for 5000 watts up to
10 seconds and Auto Throttle®.

EM6500SX

Deluxe electric start, 6500-watt model
with Honda iGX commercial engine with
Oil Alert®, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, 120/240V
selector switch, iAVR for 7000 watts up to
10 seconds and Auto Throttle

®

.

Deluxe Series 11

AC/DC

Deluxe series generators
feature simultaneous
AC/DC output.

120/240 Volt
Selector Switch

This enables full generator
wattage for short durations
through the 120 volt
outlets to power high
initial start-up wattage
requirements.

Long run time

Eco-Throttle

™

on inverter

models and Auto Throttle

®

on conventional models
deliver increased fuel
efficiency, resulting in
longer run times.

Features & Benefits

The EM5000is gives you
the advantage of quieter
operation while providing
clean, stable power for the
best possible performance.
And it’s more compact and
lighter than comparable
conventional generators.
Eco-Throttle

™

means the
engine runs only as fast as it
needs to for any given load –
so it runs quieter and is up to
40% more fuel efficient.

i-Monitor

™

The EM5000is and EU6500is
generators feature an i-Monitor

™

on the front panel. The i-Monitor
provides information for hours of
operation, wattage and engine
speed, as well as diagnostics for
convenient dealer servicing.

The i -Deluxe Advantage

EM5000is

i-Deluxe Inverter Model

Deluxe 5000-watt inverter generator with electric starting,
Eco-Throttle,

™

i-Monitor™, Honda GX commercial engine, extended
run time, two-wheel transport kit, folding handles and 120/240V
selector switch.

Regulated Power

The all-new iAVR power
feature minimizes voltage
fluctuations and allows for
increased wattage above the
maximum rating for up to
10 seconds to start high
amp load applications.

Folding handles

All EM models come with
folding handles that offer
a smaller overall footprint
for convenient transport
and storage. The EM4000,
EM5000 and EM6500
feature a unique push button
system for ease of use.

12 Industrial Series

INDUSTRIAL

NOTE: EB4000, EB5000, and EB6500 can only be used with a transfer or isolation switch by removing the neutral bond, which means the generator no longer complies

with OSHA requirements. See your dealer for details.

H

onda’s legendary industrial generators
have earned a reputation in the

construction and rental industries
for their incredibly rugged reliability. A recent
Independent Survey of Construction and
Industrial Users rated Honda #1.

All EB Series Honda generators have full
generator GFCI circuit protection for OSHA­regulated jobsites. The

EB3000c model features

Honda’s CycloConverter

™

technology, which
makes it dramatically lighter than competitive
units producing the same amount of power.

The recently upgraded

EB4000, EB5000 and

EB6500 models are powered by the new,

technologically-advanced commercial-grade
iGX engines for an even higher standard of
performance. And they include the all-new iAVR
power feature which minimizes voltage
fluctuations and allows for increased wattage
above the maximum rating for up to 10 seconds
to start high amp load applications.

Of course, they’re all backed by Honda’s 3-year
commercial use warranty and legendary reputation
for performance, durability and reliability.

CycloConverter™Model

Industrial Series 13

EB3000c

3000 watts of commercial power. Compact
and lightweight (71 lbs) thanks to Honda
CycloConverter™Technology. Powered by
a Honda GX commercial engine.
Full generator GFCI OSHA compliant,
fuel gauge and Oil Alert

®

.

Features & Benefits

Regulated Power

The all-new iAVR power
feature minimizes voltage
fluctuations and allows for
increased wattage above the
maximum rating for up to
10 seconds to start high
amp load applications.

EB6500X

Industrial, 6500-watt model with Honda
iGX commercial engine with Oil Alert

®

,
full GFCI, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, lift hook
standard, 120/240V selector switch,
iAVR for 7000 watts up to 10 seconds
and Auto Throttle

®

.

EB5000X

Industrial, 5000-watt model with Honda
iGX commercial engine with Oil Alert

®

,
full GFCI, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, lift hook
standard, 120/240V selector switch,
iAVR for 7000 watts up to 10 seconds
and Auto Throttle

®

.

EB4000X

Industrial, 4000-watt model with Honda
iGX commercial engine with Oil Alert

®

,
full GFCI, 6.2 gallon fuel tank, two-wheel
transport kit, folding handles, lift hook
standard, 120/240V selector switch,
iAVR for 5000 watts up to 10 seconds
and Auto Throttle

®

.

EB10000

Industrial 10,000 watt model with Honda
electric start, a Honda GX630 engine with
Oil Alert

®

, 8.1 gallon fuel tank, two wheel
transport kit, folding handles and lift hook
standard. Provides 10,000 watts of 120/240
power with DAVR.

Folding handles

The EB4000, EB5000 and
EB6500 feature a unique
push button folding handle
system that offers a smaller
overall footprint for convenient
transport and storage.

Wheel Kit & Hanger Kit

All models (except the
EB3000C) come standard
with features like a Wheel
Kit for easy transport and
a Hanger Kit for lifting
units with cranes and
securing units left on job
sites overnight.

Full Frame Protection

These models are all
equipped with a full frame
for added protection and
durability.

GFCI and Neutral Bond

Honda EB industrial
generators are OSHA
compliant with neutral
bond and full generator
GFCI (Ground Fault
Circuit Interrupter) circuit
protection on all outlets.

14 Economy Series

ECONOMY

H

onda’s economy generators are

a reliable source of “no frills” power.

These models are all equipped

with Oil Alert

®

and a protective frame with

isolation mounts for added durability.

The

EG4000, EG5000 and EG6500 are new

models with features including the Honda

Digital Auto Voltage Regulator (DAVR) that

maintains voltage stability within a +/- 1% of

60hZ, thus protecting and optimizing the

equipment being powered, a convenient fuel

gauge and centralized controls for ease of use.

It’s a lineup that delivers the best of both

worlds, reliability and cost savings.

Economy Series 15

EG5000CL

5000 watts maximum of economical,
portable power including Honda GX
commercial-grade engine with Oil Alert,

®

Digital Automatic Voltage Regulator
(DAVR), AC circuit breaker/protectors and
120/240V operation.

EG6500CL

6500 watts maximum of economical,
portable power including Honda GX
commercial-grade engine with Oil Alert,

®

Digital Automatic Voltage Regulator
(DAVR), AC circuit breaker/protectors and
120/240V operation.

Features & Benefits

Oil Alert

®

This feature protects the
engine by shutting it
down if oil pressure level
reaches an unsafe level.

Circuit Protection

All circuits are protected
from overload.

Frame Protection

Economy models are all
equipped with a steel
frame for added protection
and durability.

120/240 Volt
Selector Switch

This enables full generator
wattage for short durations
through the 120 volt
outlets to power high
initial start-up wattage
requirements.

Large Fuel Tank

Experience a longer run time
with a new, larger fuel tank
(3x larger than previous
EG models).

Legendary Honda
Four-stroke OHV Engine

EG models feature Honda’s easy-starting overhead
valve commercial-grade GX engines, backed up by
world-renowned Honda technology. Smooth, quiet
and efficient, it delivers plenty of power with low
exhaust emissions. No need to mix oil and gas either;
it runs on regular gasoline.

Rugged and

reliable, the

economy series

generators

are easy to

take anywhere.

Just load ‘em up

and go.

EG4000CL

4000 watts maximum of economical,
portable power including Honda GX
commercial-grade engine with Oil Alert,

®

Digital Automatic Voltage Regulator
(DAVR), AC circuit breaker/protectors and
120/240V operation.

Private Office

Normal Speech

Vacuum Cleaner

Curbside on Busy Street

Rotary Mower

Heavy City Traffic

Chain Saw

Auto Horn at 3 Feet
or Rock & Roll Bar

Jet Plane at 50 Feet

Siren at 100 Feet

Threshold of Pain

Model Number

Noise Level

*

(in decibels)

Noise Level Comparisons

(in decibels)

Quiet

Loud

16 Decibel Chart

M

any of today’s applications for generators require quiet operation. Whether you’re using your generator
for home backup power or taking along one of our lightweight models for a camping trip, you can count

on Honda to provide one of the quietest sources of portable power around. Thanks to the use of inherently
quiet OHV engines and quality construction, Honda EU generators boast incredibly low sound levels. The chart
below compares the noise level of Honda generators to a variety of common sounds we’re exposed to every day.

count on Honda.

quiet counts,

When

50

60

70

80

90

10 0

110

120

13 0

14 0

50

60

70

80

90

10 0

110

120

13 0

14 0

* Noise levels at rated load to reflect maximum noise level possible, measured at 9 Feet (3 Meters) from the control panel side of the generator.
** LwA is an international noise level measurement that uses a weighting factor to reflect noise “tonality” in addition to the sound power (dBA) level.

EU3000is

EU1000i

EU2000i

EU6500is

EU3000i Handi

EM5000is

EB3000c

EM4000SX

EB4000X

EG4000CL

EM5000SX

EB5000X

EM6500SX

EB6500X

EG5000CL

EG6500CL

EB10000

49- 58 dBA

90 LwA

**

53-59 dBA

86 LwA

**

53- 59 dBA

89 LwA

**

53- 60 dBA

91 LwA

**

57-65 dBA

91 LwA

**

62- 68 dBA

98 LwA

**

68 dBA

97 LwA

**

71 dBA

97 LwA

**

71 dBA

97 LwA

**

72 dBA

97 LwA

**

72 dBA

99 LwA

**

72 dBA

99 LwA

**

73 dBA

100 LwA

**

73 dBA

100 LwA

**

73 dBA

100 LwA

**

74 dBA

101 LwA

**

76 dBA

104 LwA

**

gen.honda.com 17

Need more

information?

OR

Visit your nearest Honda

Generator Dealer.

Find the dealer

nearest you by using

our convenient

website locator

at gen.honda.com.

V

isit our website for the very latest on Honda

generators and accessories including product

information, video clips and the ability to shop

online for your new generator.

gen.honda.com

Shop online for your new Honda generators through

your local authorized Honda Generator Dealer.

Honda Power Choice dealers are “the best of the best”
when it comes to meeting and exceeding our standards
in a number of areas, including Sales, Service, Facility,
Training and Business Practices. As a Power Choice dealer,
this dealer is committed to offering you a superior Honda
sales & service experience!

Become our fan on Facebook

facebook.com/HondaGenerators

Look for this symbol.

SPECIFICA TIONS

Engine

Displacement

AC output

iAVR AC output

Receptacles

DC output

Starting system

Fuel tank capacity

Run time per tankful

Dimensions (L x W x H)

Noise level

Dry weight

FE A TU RES

Honda OHV engine

Electric start/Remote start option

Oil Alert

®

Auto Throttle

®

Eco-Throttle™(load dependent operation)

Electronic ignition

Simultaneous AC/DC use

Circuit breakers

Fuel gauge

i-Monitor

Wheel kit standard

iAVR

DAVR

CycloConverter

™

Inverter

One switch for engine/fuel valve on/off

Full tubing frame for protection

USDA-qualified spark arrester/muffler

Fully enclosed for quieter operation

120/240V selector switch

GFCI/neutral bond

Residential warranty

Commercial warranty

EU2000i /

EU2000i Companion

†

Honda GX100

Single cylinder,

overhead cam, air-cooled

98.5cc

120V 2000W max. (16.7A)

1600W rated (13.3A)

N/A

C / F, J

†

12V, 96W (8A)

Recoil

.95gal.

4hrs. @ rated load,

9.6 hrs. @ 1/4 load

20.1" x 11.4 " x 16.7"

59 dB @ rated load

53 dB @ 1/4 load

89 LwA

††

46.3 lbs. / 45.9 lbs.

†

•

•

•

•

•

Electronic

OPT

•

•

•

•

3 Years

3 Years

EU6500is

Honda GX390

Single cylinder,

overhead valve, air-cooled

389cc

120/240V

6500W max. (54.1/27.1A)

5500W rated (45.8/22.9A)

N/A

C, F, H

N/A

Recoil, electric

4.5 gal.

4.7 hrs. @ rated load,

14.0 hrs. @ 1/4 load

33.5" x 26.4" x 27.5"

60 dB @ rated load

53 dB @ 1/4 load

91 LwA

††

253 lbs.

EU6500is

•

•

•

•

•

Electronic

•

•

•

•

•

•

•

3 Years

3 Years

EU3000is

Honda GX200

Single cylinder,

overhead valve, air-cooled

196cc

120V 3000W max. (25A)

2800W rated (23.3A)

N/A

C, F

12V, 144W (12A)

Recoil, electric

3.4 gal.

7.2 hrs. @ rated load,

20.0 hrs. @ 1/4 load

25.8" x 18.9" x 22.4"

58 dB @ rated load

49 dB @ 1/4 load

90 LwA

††

134 lbs.

EU3000is

•

•

•

•

•

•

Electronic

•

OPT

•

•

•

3 Years

3 Years

Handi EU3000i

Honda GX160

Single cylinder,

overhead valve, air-cooled

163cc

120V 3000W max. (25A)

2600W rated (21.7A)

N/A

C, F

12V, 100W (8.3A)

Recoil

1.56 gal.

3.6 hrs. @ rated load,

7.7 hrs. @ 1/4 load

24.5" x 14.9" x 19.3"

65 dB @ rated load

57 dB @ 1/4 load

91 LwA

††

78 lbs.

Handi EU3000i

•

•

•

•

•

Electronic

•

•

•

•

•

3 Years

3 Years

EU1000i

Honda GXH50

Single cylinder,

overhead valve, air-cooled

50cc

120V 1000W max. (8.3A)

900W rated (7.5A)

N/A

B

12V, 96W (8A)

Recoil

0.6 gal.

3.8 hrs. @ rated load,

8.3 hrs. @ 1/4 load

17.7" x 9.4" x 15.0"

59 dB @ rated load

53 dB @ 1/4 load

86 LwA

††

29 lbs.

EU1000i

•

•

•

•

•

Electronic

•

•

•

•

2 Years

1 Year

SUPER QUIET

RECEPTACLE DESCRIPTION PLUG #

B 15A 125V Duplex 5-15P
C 20A 125V Duplex 5-15P or 5-20P

RECEPTACLE DESCRIPTION PLUG #

D 20A 125V GFCI Duplex 5-20P
E 20A 125V Locking Plug L5-20P

Receptacle Key

† indicates a specification for EU2000iA Companion
model only.
††LwA is an international noise level measurement that
uses a weighting factor to reflect noise "tonality" in
addition to the sound power (dBA) level.

EU2000i /

EU2000i Companion

†

EM4000SX

Honda iGX270

Single cylinder, overhead valve,

air-cooled

270cc

120/240V

4000W max. (33.3/16.7A)

3600W rated (30/15A)

5000W (41.7/20.8A) for 10 sec.

C(2), F, G

12V, 100W (8.3A)

Recoil, electric

6.2 gal.

10.1 hrs.@ rated load,

16.0 hrs. @ 1/2 load

41.1" x 27.8" x 30.4"

71 dB @ Rated Load

97 LwA

††

201 lbs.

EM4000SX

•

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EM5000SX

Honda iGX390

Single cylinder,

overhead valve, air-cooled

389cc

120/240V

5000W max. (41.2/20.8A)

4500W rated (37.5/18.6A)

7000W (58.3/29.2A) for 10 sec.

C(2), F, H

12V, 100W (8.3A)

Recoil, electric

6.2 gal.

8.1 hrs. @ rated load,

11.2 hrs. @ 1/2 load

41.1" x 27.8" x 30.5"

72 dB @ rated load

99 LwA

††

232 lbs.

EM5000SX

•

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EM5000is

Honda GX340

Single cylinder,

overhead valve, air-cooled

337cc

120/240V
5000W max. (41.7/20.8A)
4500W rated (37.5/18.8A)

N/A

C, F, H

N/A

Recoil, electric

4.5 gal.

5.7 hrs.@ rated load,

15.2 hrs. @ 1/4 load

31.9" x 26.4" x 27.2"

68 dB(A) @ rated load,

62 dB(A) @ 1/4 load

98 LwA

††

217 lbs.

EM5000is

•

•

•

•

•

Electronic

•

•

•

•

•

•

3 Years

3 Years

EM6500SX

Honda iGX390

Single cylinder,

overhead valve, air-cooled

389cc

120/240V
6500W max. (54.2/27.1A)
5500W rated (45.8/22.9A)

7000W (58.3/29.2A) for 10 sec.

C(2), F, H

12V, 100W (8.3A)

Recoil, electric

6.2 gal.

6.9 hrs. @ rated load,

10.4 hrs. @ 1/2 load

41.1" x 27.8" x 30.6"

73 dB @ rated load

100 LwA

††

243 lbs.

EM6500SX

•

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

DELUXE

SPECIFICATIONS

Engine

Displacement

AC output

iAVR AC output

Receptacles

DC output

Starting system

Fuel tank capacity

Run time per tankful

Dimensions (L x W x H)

Noise level

Dry weight

FEATURES

Honda OHV engine

Electric start/Remote start option

Oil Alert

®

Auto Throttle

®

Eco-Throttle™(load dependent operation)

Electronic ignition

Simultaneous AC/DC use

Circuit breakers

Fuel gauge

i-Monitor

Wheel kit standard

iAVR

DAVR

CycloConverter

™

Inverter

One switch for engine/fuel valve on/off

Full tubing frame for protection

USDA-qualified spark arrester/muffler

Fully enclosed for quieter operation

120/240V selector switch

GFCI/neutral bond

Residential warranty

Commercial warranty

RECEPTACLE DESCRIPTION PLUG #

F 30A 125V Locking Plug L5-30P
G 20A 125/250V Locking Plug L14-20P

RECEPTACLE DESCRIPTION PLUG #

H 30A 125/250V Locking Plug L14-30P
I 50A 125/250V Locking Plug CS6365
J 20A 125V Single 5-20P

SPECIFICATIONS

Engine

Displacement

AC output

iAVR AC output

Receptacles

DC output

Starting system

Fuel tank capacity

Run time per tankful

Dimensions (L x W x H)

Noise level

Dry weight

FEATURES

Honda OHV engine

Electric start/Remote start option

Oil Alert

®

Auto Throttle

®

Eco-Throttle™(load dependent operation)

Electronic ignition

Simultaneous AC/DC use

Circuit breakers

Fuel gauge

i-Monitor

Wheel kit standard

iAVR

DAVR

CycloConverter

™

Inverter

One switch for engine/fuel valve on/off

Full tubing frame for protection

USDA-qualified spark arrester/muffler

Fully enclosed for quieter operation

120/240V selector switch

GFCI/neutral bond

Residential warranty

Commercial warranty

EB4000X

Honda iGX270

Single cylinder,
overhead valve,

air-cooled

270cc

120/240V

4000W max. (33.3/16.7A)

3600W rated (30/15A)

5000W (41.7/20.8A) for 10 sec.

C(2), F, G

N/A

Recoil

6.2 gal.

10.1 hrs. @ rated load,

16.0 hrs. @ 1/2 load

41.9" x 27.2" x 29.2"

71 dB @ rated load

97 LwA

††

185 lbs.

EB4000X

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EB5000X

Honda iGX390

Single cylinder,

overhead valve,

air-cooled

389cc

120/240V

5000W max.

(41.7/20.8A)

4500W rated (37.5/18.8A)

7000W (58.3/29.2A) for 10 sec.

C(2), F, H

N/A

Recoil

6.2 gal.

8.1 hrs. @ rated load,

11.2 hrs. @ 1/2 load

41.9" x 27.2" x 29.2"

72 dB @ rated load

99 LwA

††

214 lbs.

EB5000X

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EB6500X

Honda iGX390

Single cylinder,

overhead valve,

air-cooled

389cc

120/240V

6500W max.

(54.1/27.1A)

5500W rated (45.8/22.9A)

7000W (58.3/29.2A) for 10 sec.

C(2), F, H

N/A

Recoil

6.2 gal.

6.9 hrs. @ rated load,

10.4 hrs. @ 1/2 load

41.9" x 27.2" x 29.2"

73 dB @ rated load

100 LwA

††

220 lbs.

EB6500X

•

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EB10000

Honda GX630

Twin cylinder,

overhead valve,

air-cooled

688cc

120/240V

10000W max. (83.8/41.6A)

9000W rated (75/37.5A)

N/A

C(2), F, H, I

N/A

Electric

8.1 gal.

4.6 @ rated load,

7.2 hrs @1/2 load

55.9" x 26.7" x 35.1"

76 dB @ rated load

104 LwA

††

403 lbs.

EB10000

•

•

•

•

•

•

•

•

•

•

•

•

3 Years

3 Years

EB3000c

Honda GX200

Single cylinder,
overhead valve,

air-cooled

196cc

120V
3000W max. (25.0A)
2600W rated (21.7A)

N/A

D, F

N/A

Recoil

2.6 gal.

6.1 hrs. @ rated load,

9.39 hrs. @ 1/2 load

17.5" x 15.8" x 18.9"

68 dB @ rated load

97 LwA

††

71 lbs.

EB3000c

•

•

•

•

•

•

•

•

•

3 Years

3 Years

RECEPTACLE DESCRIPTION PLUG #

B 15A 125V Duplex 5-15P
C 20A 125V Duplex 5-15P or 5-20P

RECEPTACLE DESCRIPTION PLUG #

D 20A 125V GFCI Duplex 5-20P
E 20A 125V Locking Plug L5-20P

INDUSTRIAL

Receptacle Key

††LwA is an international noise level measurement that uses
a weighting factor to reflect noise "tonality" in addition to the
sound power (dBA) level.

RECEPTACLE DESCRIPTION PLUG #

F 30A 125V Locking Plug L5-30P
G 20A 125/250V Locking Plug L14-20P

RECEPTACLE DESCRIPTION PLUG #

H 30A 125/250V Locking Plug L14-30P
I 50A 125/250V Locking Plug CS6365

ECONOMY

SPECIFICATIONS

Engine

Displacement

AC output

iAVR AC output

Receptacles

DC output

Starting system

Fuel tank capacity

Run time per tankful

Dimensions (L x W x H)

Noise level

Dry weight

FEATURES

Honda OHV engine

Electric start/Remote start option

Oil Alert

®

Auto Throttle

®

Eco-Throttle™(load dependent operation)

Electronic ignition

Simultaneous AC/DC use

Circuit breakers

Fuel gauge

i-Monitor

Wheel kit standard

iAVR

DAVR

CycloConverter

™

Inverter

One switch for engine/fuel valve on/off

Full tubing frame for protection

USDA-qualified spark arrester/muffler

Fully enclosed for quieter operation

120/240V selector switch

GFCI/neutral bond

Residential warranty

Commercial warranty

** with hanger

EG4000CL

Honda GX270

Single cylinder,
overhead valve,

air-cooled

270cc

120/240V
4000W max. (33.3/16.7A)
3500W rated (29.2/14.6A)

N/A

C, F, G

N/A

Recoil

6.3 gal.

15.7 hrs. @ 1/2 load

26.8" x 22.8" x 22.5"

72 dB @ rated load

97 LwA

††

155 lbs.

EG4000CL

•

•

•

•

•

OPT

•

•

•

•

3 Years

3 Years

EG5000CL

Honda GX390

Single cylinder,
overhead valve,

air-cooled

389cc

120/240V
5000W max. (41.2/20.8A)
4500W rated (37.5/18.6A)

N/A

C, F, H

N/A

Recoil

6.3 gal.

11 hrs. @ 1/2 load

26.8" x 22.8" x 22.6"

73 dB @ rated load

100 LwA

††

177 lbs.

EG5000CL

•

•

•

•

•

OPT

•

•

•

•

3 Years

3 Years

EG6500CL

Honda GX390

Single cylinder,
overhead valve,

air-cooled

389cc

120/240V

6500W max. (54.2/27.1A)

5500W rated (45.8/22.9A)

N/A

C, F, H

N/A

Recoil

6.3 gal.

10 hrs. @ 1/2 load

26.8" x 22.8" x 22.7"

74 dB @ rated load

101 LwA

††

182 lbs.

EG6500CL

•

•

•

•

•

OPT

•

•

•

•

3 Years

3 Years

EU Storage Cover Silver EU Storage Cover Camo EU Storage Cover Marine Silver EU Storage Cover Marine Blue

22 Accessories

DC Charging Cord

Parallel Cables

for connecting two identical EU series generators.

EU2000i Companion Parallel Kit

for combining an EU2000i to an EU2000i Companion

generator to double the power.

Accessories

Storage Cover

2-Wheel Kit

4-Wheel Kit

DC Charging Cord

Transfer Switch

Hanger Kit

Remote Control Kit

Parallel Cables

Parallel Kit

Super Quiet

EU1000i OPT OPT OPT

EU2000i OPT OPT OPT OPT OPT

EU3000is OPT OPT OPT OPT OPT OPT OPT

Handi 3000i OPT STD OPT OPT OPT OPT

EU6500is OPT STD OPT OPT OPT

Deluxe

EM4000SX OPT STD OPT OPT OPT OPT

EM5000SX OPT STD OPT OPT OPT OPT

EM6500SX OPT STD OPT OPT OPT OPT

i-Deluxe

EM5000is OPT STD OPT OPT OPT

Industrial

EB3000c OPT OPT OPT

EB4000X OPT STD OPT STD

EB5000X OPT STD OPT STD

EB6500X OPT STD OPT STD

EB10000 OPT STD STD

Economy

EG4000CL OPT OPT OPT OPT

EG5000CL OPT OPT OPT OPT

EG6500CL OPT OPT OPT OPT

STD = Standard

OPT = Optional

†

*

*

*

*

† Not available on EU2000i Companion. *Connection to transfer switch requires removal of neutral bond wire.

ENM Hour Meter

monitors usage time for proper

maintenance scheduling.

Battery Tender

keeps your electric start

generator’s battery charged.

EG Series Wheel Kit (Hanger Kit Extra)

Wireless Remote Kit

for convenient remote start/stop.

Accessories 23

Hanger Kit

EU2000i Generator Skin Kits

Collegiate, NFL and NASCAR skins available. See your Honda dealer for details.

Tele-Lite Kit

Lightweight folding halogen light is designed

specifically for the EU1000i and EU2000i.

RV Adapter Plug

Universal Folding Handle CoverEU2000i Cart

Adds wheels to your EU2000i. Includes a

transportation strap to secure your generator.

EU3000is Telescoping 2-Wheel Kit

EU2000i Theft Deterrent Bracket

Steel bracket with tamper-proof bolts deters thieves from

cutting the plastic handle and removing a cable lock.

No Spill Gas Can

Transfer Switches

Transfer switches allow a safe connection from a generator to a household/commercial electrical system.
The transfer switch isolates the generator, so it can’t accidentally electrify external power wires.

TRANSFER SWITCHES

Style Description Max. Watts Part Number

A 15 Amp 1 Circuit Furnace Transfer Switch (5-15) 1875 32314-TF151W

C 20 Amp 6 Circuit Indoor Transfer Switch (L14-20) 5000 32311-189EF

C 30 Amp 6 Circuit Indoor Manual Transfer Switch (L14-30) 7500 32311-189008

C 30 Amp 125 Volt 6-Circuit Manual Indoor Transfer (L5-30) 3750 32311-189018

C 30 Amp 10 Circuit Indoor Manual Transfer Switch (L14-30) 7500 32311-189006

C 50 Amp 12 Circuit Indoor Manual Transfer Switch 12500 32311-18950A

D 20 Amp 6 Circuit Automatic/Programmable UTS Switch 14400 32315-UTS6BI

D 30 Amp 6 Circuit Automatic/Programmable UTS Switch (L5-30/EU3) 3750 32316-UTS6H

D 30 Amp 10 Circuit Automatic/Programmable UTS Switch 24000 32315-UTS10BI

E 10- CIR PANEL/LINK®X, 30A (for EB series generators) 7500 32316-XRC1003AH

COMBINATION TRANSFER SWITCH KITS
HARDWIRE/PLUG-IN WITH 25' CORD SET AND INLET BOX

Kit Description Max. Watts Part Number

Kit C 30 Amp 10 Circuit Indoor Transfer Switch Kit 7500 32312-101025KT

(includes a power inlet box & 25 Ft cord set)

Kit D 30 Amp 8 Circuit Indoor Transfer Switch Kit 7500 32313-30408-BHK25

(includes a power inlet box & 25 Ft cord set)

Kit E 30 Amp 10 Circuit Indoor Transfer Switch Kit 7500 32313-Q310-CHK25

(includes a power inlet box & 25 Ft cord set)

Note: Kits D & E permit relocating the flanged 30A inlet from the power inlet box to the transfer switch for direct cord­connection to the transfer switch.

Transfer switches and inlet boxes must be installed by a qualified electrician and the connection must comply with all
applicable laws and electric codes.

Appliance Load Tester

A hand-held ammeter/wattmeter for measuring loads on cord-connected tools,
appliances or lighting. A slide switch on the side of the unit allows you to choose
amps or watts to appear on the liquid crystal display. UL listed.

Description Part Number

APPLIANCE LOAD TESTER (15A, 1875W) 32660-893-THP103

Style C

Kit C

Kit D

Kit E

24 Accessories

Style A Style B

Style D Style E

Cord Sets

Cord sets provide easy and safe connections to an inlet box or transfer switch.

Standard 125/250V Cord Sets (Twist-Lock)

Description: Standard Cord Set Part Number

12 gauge 4-wire, 20 Amp, 5 Ft (L1420) female end only 06580-124-005AH

12 gauge 4-wire, 20 Amp, 10 Ft (L1420) male & female ends 06580-124-010AH

12 gauge 4-wire, 20 Amp, 25 Ft (L1420) male & female ends 06580-124-025AH

12 gauge 4-wire, 20 Amp, 50 Ft (L1420) male & female ends 06580-124-050AH

10 gauge 4-wire, 30 Amp, 5 Ft (L1430) female end only 06580-104-005AH

10 gauge 4-wire, 30 Amp, 10 Ft (L1430) male & female ends 06580-104-010AH

10 gauge 4-wire, 30 Amp, 25 Ft (L1430) male & female ends 06580-104-025AH

10 gauge 4-wire, 30 Amp, 50 Ft (L1430) male & female ends 06580-104-050AH

6 gauge 4-wire, 50 Amp, 5 Ft (L6364) female end only 06580-064-005AH

6 gauge 4-wire, 50 Amp, 10 Ft (L6365/L6364) male & female ends 06580-064-010AH

6 gauge 4-wire, 50 Amp, 25 Ft (L6365/L6364) male & female ends 06580-064-025AH

EU3000is Single Operation Cord Sets

EU3000is (single unit) 3-prong connector & plug cord sets

Cord sets for 30 Amp 125 Volt 6-Circuit L5-30 (EU3000i) Part Number

10 gauge 3-wire, 30 Amp, 5 Ft (L530) female end only 3-prong 06582-103-005AH

10 gauge 3-wire, 30 Amp 10 Ft (L530 female & male) ends 3-prong 06582-103-010AH

10 gauge 3-wire, 30 Amp 25 Ft (L530 female & male) ends 3-prong 06582-103-025AH

10 gauge 3-wire, 30 Amp 50 Ft (L530 female & male) ends 3-prong 06582-103-050AH

Power Inlet Boxes

Inlet boxes are mounted on the exterior of the house to avoid running a power cord through a door or window.

Power Inlet Boxes (Bottom Inlet)

Description Part Number

30 Amp Inlet Box L1430 (125/250V) - bottom inlet 32314-189-030AH

30 Amp Inlet Box L530 (125V “only”) - bottom inlet 32315-189-030AH

50 Amp Inlet Box CS6360N (125V “only”) - bottom inlet 32314-189-052AH

50 Amp Inlet Box CS6364N (125/250V) - bottom inlet 32314-189-055AH

Power Inlet Boxes (Front Inlet)

Description Part Number

20 Amp Inlet Box L1420 (125/250V) - front inlet/cover 32314-189-020AH

30 Amp Inlet Box L1430 (125/250V) - front inlet/cover 32316-189-PB30

30 Amp Inlet Box L530 (125V “only”) - front inlet/cover 32316-189-PB31

50 Amp Inlet Box CS6364N (125/250V) - front inlet/cover 32316-189-PB50

Accessories 25

Visit us at www.honda.com

Honda.

The Official Generator Of Good Times.

Please read the owner’s manual before operating your Honda Power Equipment and never use in a closed or partly enclosed area where you could be exposed to poisonous carbon monoxide.
Connection of a generator to house power requires a transfer device to avoid possible injury to power company personnel. Consult a qualified electrician. Specifications subject to change without notice.

All images contained herein are either owned by American Honda Motor Co., Inc., or used under a valid license. It is a violation of federal law to reproduce these images without express written permission
from American Honda Motor Co., Inc., or the individual copyright owner of such images. All rights reserved. HONDA, the HONDA GENERATORS logo, Honda generator model names and their trade dress are
trademarks of Honda Motor Co., Ltd. used under license by American Honda Motor Co., Inc. Many Honda engine, generator and vehicle model names, and associated trade dress may be seen at
www.honda.com. ©2012 American Honda Motor Co., Inc.

C0530

Official Supplier of

REV. 01
