Honda Civic Hybrid with Navigation Technical Reference Guide

T E C H N O L O G Y

R E F E R E N C E

G U I D E

2013 H on da C iv ic Hybr id w ith N av ig atio n 31 TR 2B 10 T ec hn ology R ef eren ce G uide 00 X3 1- TR 2-B1 00 © 2012 Amer ican Ho nda Motor Co., I nc. — A ll Rights Reserv ed Pr int ed i n U.S. A.

o w n e r s . h o n d a . c o m

2013 Civic Hybrid

with Navigation

TE C HNO LOG Y R EFE REN CE GUI DE

INSTRUMENT PANEL p.4

The Technology Reference Guide is designed to help you get

acquainted with your new Honda and provide basic

instructions on some of its technology and convenience

features. This guide covers the Civic Hybrid with

Navigation.

This guide is not intended to be a substitute for the

Owner’s Manual. For more detailed information on vehicle

controls and operation, please refer to the respective

sections in the Owner’s Manual or Navigation Manual.

BLUETOOTH

HANDSFREELINK®p.28

ECO ASSISTTMp.8

NAVIGATION p.24

p.28

i-MID p.6

Auto Door Locks .....................................................................................................2

Instrument Panel Indicators ...................................................................................4

Intelligent Multi-Information Display (i-MID).....................................................6

Eco Assist

Tire Pre ssure Monitoring System (TPMS) ........................................................12

One-Touch Turn Signal...........................................................................................13

Auto Headlights with Wiper Integration...........................................................13

Forward Collision Warning (FCW)....................................................................14

Lane Departure Warning (LDW)........................................................................15

Multi-View Rear Camera ......................................................................................16

................................................................................................................8

iPod®or USB Flash Drive .....................................................................................17

Bluetooth

Pandora

Voice Recognition...................................................................................................20

Navigation.................................................................................................................24

Bluetooth

SMS Text Messaging................................................................................................32

Owner Link..............................................................................................................34

Safety Reminder......................................................................................................34

Fuel Recommendation...........................................................................................35

Audio......................................................................................................18

...................................................................................................................19

HandsFreeLink®(HFL)........................................................................28

AUTO DOOR LOCKS

Program how and when the vehicle doors automatically lock and unlock.

Door Locks

D e f a u l t Lo c k S e t t i n g

The doors are preset to lock when your vehicle reaches about 10 mph.

D e f a u l t Un l o c k S e t t in g

Only the driver’s door is preset to unlock when you shift into Park (P).

Programming the Auto Door Unlock Setting

Press the (+/-) buttons on the steering wheel to scroll through the menu options. Press SOURCE to select an option. See pages 6-7 for more information on the

i-MID and its controls.

1. Press MENU.

2. Select Customize Settings.

3. Select Door Setup.

4 . SelectAuto Door Unlock.

5. Select All Doors with Shift to P.

6. Press MENU to exit.

Programmable Auto Door Lock/Unlock Settings

Below are the options you can choose. See Auto Door Locking/Unlocking in your Owner’s Manual for instructions on programming these settings.

AUTO DOOR LOCK

AUTO DOOR UNLOCK

Auto Lock

Turn off

Auto Lock

When you

reach 10 mph

Operate manually

When you shift

out of Park

Auto Unlock

(all doors)

Auto Unlock (only driver’s

door)

Turn off

Auto Unlock

When you turn

the ignition OFF

When you turn

the ignition OFF

Operate manually

When you shift

out of Park

When you shift

out of Park

2 3

INSTRUMENT PANEL INDICATORS

PASSENGER

AIRBAG

OFF

Briefly appear with each engine start. Red and amber indicators are most critical. Blue and green indicators are used for general information. See your Owner’s Manual for more information.

If an indicator remains on, there may be a problem; see your dealer

Charging system

Low brake fluid, Brake system

Low oil pressure

Transmission (blinking)

Brake system

IMA system

ABS (anti-lock brake system)

EPS (electric power steering)

Malfunction indicator lamp

(check engine light)

VSA

(vehicle stability assist)SRS (supplemental restraint system)

TPMS (blinks and stays on)

(tire pressure monitoring system)

FCW

(forward collision warning

system)

LDW (lane departure warning

system)

Low engine temperature

Condition Indicators

Action is needed by driver

Malfunction Indicators

Parking brake on:

Release

Seat belt reminder:

Fasten seat belt(s)

Door/Trunk open:

Close door(s) / trunk

Low fuel:

Refill

Low tire pressure:

Add air

On/Off Indicators

PASSENGER AIRBAG OFF

(next to i-MID)

VSA OFF

FCW off

CRUISE MAIN on

CRUISE CONTROL on

High temperature:

Drive slowly or pull over

Message indicator:

See i-MID

Immobilizer

(blinks):

Use other vehicle key

Auto idle stop on

ECON mode on

Exterior lights on

Turn signals/hazards on

High beams on

4 5

INTELLIGENT MULTI-INFORMATION DISPLAY (i-MID)

Consists of several displays that provide you with useful information.

Accessing the MID

Press the INFO button to change main displays.

Main Displays

Main display Power flow

monitor

Sub-displays

Press the SEL/RESET button to change sub-displays.

Steering Wheel Controls

Outside

temperature

Odometer

Trip A Trip B

Clock

(or wallpaper)

Audio display

(or Phone

display during

call)

A warning or indicator message may appear as necessary. Press the INFO button to clear it.

Ecological

Drive

Display

Trip

computer

(+) Button:

Press to scroll upward.

(t) Button:

Press to go back to the previous display.

(-) Button:

Press to scroll downward.

Display/Information Button:

Change main displays.

SOURCE Button:

Press to enter your selection.

(u) Button:

Press to go to the next display.

MENU Button:

Press to go to Vehicle Menu for customization and other settings.

6 7

ECO ASSIST SYSTEM

mph

Provides various ways to monitor your fuel efficiency and driving style.

Turning the ECON Mode On/Off

Driver Feedback

Deceleration Acceleration

1. Press ECON.

2. The ECON mode indicator comes on.

3. Check the i-MID for the system status.

4. Press ECON again to turn the system off.

Note: When turned on, the vehicle’s engine performance, transmission, cruise control, and air conditioning system are adjusted to maximize fuel efficiency.

Ambient Meter

Indicates instant fuel efficiency using color-coded bars.

High fuel efficiency Moderate fuel efficiency Low fuel efficiency

Driving Style

Smooth, steady acceleration

high fuel efficiency

Smooth, steady deceleration

high fuel efficiency

Moderate acceleration

Moderate deceleration

Rapid acceleration

low fuel efficiency

Rapid deceleration

low fuel efficiency

Inefficient

Braking Zone

Real-time Fuel Efficiency Coach

Eco Drive Bar

(on the i-MID)

Ambient Meter

Background Color

Changes

Efficient

Zones

Inefficient

Driving Zone

Fuel Efficiency

High

Low

Goals:

• Keep the Eco Drive bar near the center.

• Keep the Ambient Meter at GREEN.

• Develop a driving style that maximizes fuel efficiency.

8 9
