HONDA Civic Hybrid Navigation 2012 User Manual

Using the navigation system while driving can take your attention away from the road, causing a crash in which you could be seriously injured or killed.

Only operate system controls when the conditions permit you to safely do so.

WARNING

2012 Civic Hybrid Navigation Online Reference Manual

2012 Civic Hybrid Navigation

QRG

The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd., reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.

Accessories Precautions

The GPS antenna is located in the dashboard. Metallic front or side window tinting can seriously degrade or obstruct GPS reception.

Signal noise from devices such as radar detectors, vehicle tracking devices, remote starters, and additional amplifiers can disrupt the navigation system. If you install any such item, install it away from the navigation display and antenna.

Important Safety Information

Avoid focusing on the screen or manually operating the system controls while driving.

Certain on-screen controls are disabled when driving, but most of the audible instructions and voice commands continue to function. Pull to the side of the road if you need to devote more attention and time to look at the screen or access additional menus.

Route guidance may conflict with street closures, road construction, detours, and out-of-date map data.

The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey traffic laws.

Index

Home

System Limitations P. 182

NOTICE

This vehicle’s navigation display, if so equipped, includes mercury-containing components. Upon removal, please reuse, recycle, or dispose of as hazardous waste.

Clean the screen with a soft, damp cloth. You may use a mild cleaner intended for use on navigation screens.

2012 Civic Hybrid Navigation Online Reference Manual

QRG

Index

2 System Setup P. 17

Start-up 18 Voice Control System 19 Interface Settings 21 Personal Information 29 Routing & Guidance 39 Clock Adjustment 46 Vehicle 49 Data Reset 52

2 Navigation P. 55

Entering a Destination 56 Calculating the Route 77 Driving to Your Destination 80 Map Menu 85 Changing Your Route 101 Changing Your Destination 108 Resuming Your Trip 112

2 Audio P. 113

Audio System 114 Playing FM/AM Radio 116 Playing XM® Radio 121 Playing a Disc 125 Playing an iPod® 129 Playing a USB Flash Drive 133 Playing Bluetooth®

Audio Remote Controls 141

Audio 137

Adjusting the Sound 140

2 Bluetooth® HandsFreeLink® P. 143

Bluetooth® HandsFreeLink® 144

Phone Setup 155 Making a Call 156 Receiving a Call 159 HFL Menus 160

Pairing a Phone 146 Setting Up Speed Dialing 151 Editing Phone

Information 154

2 Other Features P. 163

Trip Computer 164 Information Functions 165

2 Troubleshooting P. 167

Troubleshooting 168 Error Messages 174

2 Reference Information P. 179

System Initialization 180 System Limitations 182 Customer Assistance 184 Legal Information 187

2 Voice Commands P. 189

Voice Commands 190

Navigation Key

QRG

Quick Reference Guide

TOC

Chapter Table of Contents

Contents

Quick Reference Guide

System Setup

Navigation

Bluetooth

® HandsFreeLink®

Other Features

Troubleshooting

Reference Information

Voice Commands

Audio

Index

P.2

P.17

P.55

P.113

P.143

P.163

P.167

P.179

P.189

P.200

Home

Index

Home

Book Table of Contents

Voice Commands

Store home addresses (P35)

2 home addresses.

Store contacts (P30)

Store up to

200 contacts in 2 address books.

Enter destination (P56)

Select your destination using

11 methods.

Select route (P78)

Set route preferences and select one of

3 routes.

Track route (P80)

Follow your route in real-time with voice guidance.

FM Traffic (P99)

View and avoid congestion and traffic incidents.

Avoid certain areas (P102)

Set streets and areas to detour around.

Add waypoints (P103)

Add up to

4 “pit stops” along your route.

2012 Civic Hybrid Navigation

QRG

Overview—Functions at a Glance

Quick Reference Guide

Navigation

Index

Home

You can select any place/landmark as a destination by using voice control or the touch screen. The navigation system gives you turn-by-turn driving directions to your destination.

Audio

AM/FM Radio (P116) XM® Radio (P121) Compact Disc (P125)

iPod® (P129) USB Flash Drive (P133)

Bluetooth® Audio (P137)

Voice Control (P19)

Use voice commands to control the system while driving. You can operate all key functions of the navigation, audio, and climate control systems.

Bluetooth® HandsFreeLink® (P144)

Pair a compatible cell phone to receive incoming and make outgoing calls. You can operate the phone features without ever taking your hands off the wheel.

2012 Civic Hybrid Navigation

The advanced audio system provides clear, well-defined sound and makes the most of your music. Enjoy listening to a variety of audio sources, such as:

QRG

Quick Reference Guide

Index

Home

3 CD/XM Button (P121)

1 E (Eject) Button

2 FM/AM Button

(P116)

Navigation Screen (Touch Screen)

Audio

Navigation

Voice Control/ Bluetooth® HandsFreeLink®

6 Disc Slot (P6)

4 AUDIO Button (P6)

5 SEEK/SKIP Button (P116)

7 a (Display Mode)

Button

(P26)

lb DEST Button (P116)

9 PHONE Button (P144)

la MAP/GUIDE Button (P90)

le CANCEL Button

lc INFO Button

(P10)

ld ZOOM IN/OUT Button (P95)

lf Joystick/ENT Button

8 VOL 9 Knob

(P6)

Press ENTER

Selects map location or list item.

Move up Move Left Move down Move right

Scrolls map or list.

2012 Civic Hybrid Navigation

QRG

System Controls

Quick Reference Guide

Index

Home

lg Microphone

(P19)

lh ! (Display/Information)

Button

(P142)

li SOURCE Button (P141)

ma NB (Volume) Button

(P142)

md d (Talk) Button (P5)

mc J (Hang-Up/Back) Button

(P159)

mb h (Pick-Up) Button (P159)

lj bn (Channel) Button

(P142)

This illustration is for models without a moonroof.

d (Talk) Button

A helpful prompt asks what you would like to do. Press and release the d (Talk) button again to bypass this prompt.

2012 Civic Hybrid Navigation

Voice Control Operation

a Press and release the d (Talk) button.

QRG

Quick Reference Guide

 The icon is displayed and the system beeps when ready for a

command. Press the J (Hang-Up/Back) button to cancel.

 Available voice commands are highlighted on the screen.

b Say a voice command.

Voice Command (P189)

 The audio system is muted during voice control mode.

 Say “Help” to see all supported commands. A voice help

tutorial is also available.

Voice Help (P13)

 Carefully read the usage note for the voice control.

Voice Control System (P19)

Index

Home

Audio source

Track list

Open icon

Audio source

Displays selected source.

Music information

Close icon

Sound preferences

Folder/Track tab

Displays the list.

Repeat and random play

Play mode

Displays or hides the music information.

Audio control

2012 Civic Hybrid Navigation

QRG

Audio System

Quick Reference Guide

You can play music from a wide array of media sources. You can also control the audio system using voice commands.

Basic Operation

a Press the VOL 9 (Volume/Power) button to turn the audio

system on or off.

b Press the AUDIO button and select SOURCE on the screen.

c Select the audio source.

Or, press the FM/AM button or CD/XM button repeatedly to select the audio source.

Index

Home

d Rotate the VOL 9 (Volume/Power) knob to adjust

the volume.

Audio Control Display

Press the AUDIO button to display the audio system on the navigation screen.

Map Screen Legend

Map orientation (P97)

GPS signal strength

North up

Heading up

Best reception

Good reception

No icon: Poor/No reception

Traffic status indicator (P99)

Traffic information available

Flow or incident data not available

Traffic information not available

Traffic information off or map scale too large

Current map scale

Current street name/audio control (Select to switch the display.)

Map menu (P85)

Map scale (P95)

Current vehicle position

(P98)

Feature areas

Streets

Landmark icons (P92)

Park

Hospital Shopping Mall

Golf Course

Airport/Business

Water Area Cemetery

University

Freeways

State routes

Verified streets

Unverified streets One-way streets

Acura dealer Honda dealer

ATM

School

Parking lot

Parking garage Grocery store

Hotel/Lodging Gas station

Hospital

Post office

Restaurant

Freeway exit information

Traffic flow indicator (P99)

Heavy (approx.)

surface: 0 to 20 mph freeway: 0 to 25 mph

Moderate (approx.)

surface: 21 to 30 mph freeway: 25 to 52 mph

Congestion

Accident/Incident

Weather Construction

Road Closed

Traffic incident icons (P99)

2012 Civic Hybrid Navigation

QRG

Quick Reference Guide

Index

Home

Calculated route

(P80)

Destination direction indicator

Direction “as the crow flies.”

Guidance indicator

Distance to the next guidance point.

Distance to destination

Distance of the actual route.

Estimated time to destination

Waypoint (P103)

Destination icon

(P79)

Calculated route

(unverified roads)

(P82)

Street name of guidance point

Route guidance list scroll bar

Select R or U to scroll the list of guidance points.

Route progress bar

Distance to guidance point

No entry icon

Night mode

Day mode

Multi-information Display

Street name of next guidance point

Remaining distance

Next driving maneuver is approaching.

2012 Civic Hybrid Navigation

QRG

During Route Guidance

Quick Reference Guide

During route guidance, route information is displayed on the map/guidance screen and multi-information display. Press the MAP/GUIDE button to display the guidance screen.

Map Screen

Day or Night Mode

Press the a (Display mode) button to manually switch between day and night mode.

Guidance Screen

Index

Home

Turn-by-Turn Directions

The next guidance point appears on the multi-information display.

How to Enter Information

Number of Hits

On input search screens, the number of hits in the map database is displayed. Select List to display a list of possible entries.

NOTE

2012 Civic Hybrid Navigation

You can enter information (e.g., city names, street names, personal names, and business names comprising letters, numbers, and symbols) when prompted on input screens by two different methods.

QRG

Quick Reference Guide

Using Voice Control

When you see d in this manual, voice commands are available for that feature.

 Say the letter, number, or symbol (e.g., say d “A”).

 Use spelling assist (e.g., say d “Alpha” to enter the letter “A” or

d “Hyphen” to enter a hyphen).

 The system beeps if you say an unavailable (grayed out) letter or

number.

 If a voice command is not recognized, a list is displayed with

possible options.

On list screens:

 Say the number of the list item (e.g., say d “Five” to select

item 5).

 Say d “Up” or d “Previous” to scroll up one page.

 Say d “Down” or d “Next” to scroll down one page.

Using the Touch Screen

Touch a character or icon on the screen to select it.

 Select Delete to remove the last entered character.

 Select Shift to display accented and upper/lower case characters.

 Select Space to enter a space character.

 Select More to display symbols.

You can also use the joystick to enter information.

2 System Controls P. 4

Index

Home

2012 Civic Hybrid Navigation

QRG

Navigation—Home Addresses and Going Home

Quick Reference Guide

The “Home” feature automatically routes you to your home address from any location simply by selecting Go Home 1 or 2, or saying d “Go Home.” You can store two home addresses as Home Address 1 and Home Address 2. (P35)

Index

Home

Storing Your Home Address

a Press the INFO button.

b Select Setup.

c Select Personal Information. d Select Home Address 1.

e Select Edit Name.

f Enter a name and select OK.

g Select Edit Address. h Select Address. i Enter an address. j Select Edit Phone No.

k Enter a phone number and select OK.

l Select OK.

Going Home

a Press the DEST button.

b Select Go Home 1.

Alternatively, you can say d “Go Home” from any screen. Your home

address is displayed on the Calculate Route screen.

c Select Set as Dest.

 The following voice commands are

available: say d “Go Home,” d “Go Home 1,” d “Go Home 2.”

 If you have two home addresses stored,

saying d “Go Home” will select Home

Address 1.

Navigation—Entering a Destination

2012 Civic Hybrid Navigation

Enter your destination using one of several methods, then follow route guidance on the map or guidance screen to your destination. You can also perform these steps using d voice control.

QRG

Quick Reference Guide

a Press the DEST button.

b Select Address.

c Select Street.

d Enter the name of your destination

street and select List if necessary.

e Select your destination street from

the list.

f Enter the street number. Select OK

when finished.

g If there is more than one city with the

specified street, a list of cities is displayed. Select the desired city from the list.

h Select Set as Dest.

Route guidance to the destination begins.

 View Routes: Choose one of three

routes.

 Route Pref.: Choose MAX or MIN for

the three settings.

Index

Home

2012 Civic Hybrid Navigation

QRG

Navigation—Changing Route or Destination

Quick Reference Guide

You can alter your route by adding waypoints to visit, adding streets to avoid, or changing your destination during route guidance.

Index

Home

Adding a Waypoint (“Pit Stop”)

You can add up to four waypoints along your route. (P103)

a Press the DEST button. b Select Waypoint.

c Select search method.

When you select Places Around the Waypoint, select the desired waypoint.

d Select the icon category and location

to add to the destination list when prompted.

Changing Your Destination

There are four methods you can use to specify a new destination during route guidance.

 Say d “Find Nearest…” (P108)

Searches for the nearest place/landmark on the map screen (e.g., d “Find nearest gas station”).

 Say d “Go Home” (P10)

Routes to your home address.

 Selecting an icon on the map (P109)

Scroll the map to position the cursor over a place/landmark icon or a new area on the map. Press the Enter button twice.

 Entering a new destination (P110)

Press the DEST button. Select DEST

Menu1/2 and enter a new destination.

Canceling Your Route

a Press the DEST button.

b Select Cancel Route.

From the map screen:

a Select MAP MENU.

b Select Cancel Route.

Voice Help

2012 Civic Hybrid Navigation

This navigation system comes with voice help information, which tells you how to use the voice command functions. Go to Voice Info for tips when using the voice command functions.

Getting Started Tutorial

a Press the INFO button.

b Select Voice Info.

c Select Getting started.

You can also view the available command list for each system. See Command Help on this page.

d Select Using the talk button.

e Select Read to hear the tutorial read

aloud.

Select Stop to stop the tutorial.

Command Help

For “Command Help” menu items, all voice commands that are available for that system are listed.

Select Read to hear the commands in the list read aloud.

Voice Commands (P189)

QRG

Quick Reference Guide

Index

Home

2012 Civic Hybrid Navigation

QRG

Troubleshooting For more Information (P167)

Quick Reference Guide

Why does the vehicle position icon on the map “lag” a short distance behind my actual position, especially at intersections?

This is normal. The navigation system is unaware of the width of intersections. Large differences in vehicle position can indicate a temporary loss of the GPS signal.

Why does the “time to destination” display sometimes increase even though I am getting closer to my destination?

The “time to destination” is based on the posted road speed signs and your actual road speed to give you a better estimate of arrival time.

Why does my clock frequently change the time forward and backward by one hour?

The clock setting is automatically updated based on your GPS location. If you normally drive between two time zones, the clock may keep adjusting the time. You can turn this feature off.

Clock Adjustment P. 46

Index

Home

How do I specify a destination when an entered city or street could not be found?

Try entering the street first. Some cities are lumped in with a major metro area. In rural “unverified” areas or new subdivisions, streets may be missing or only partially numbered.

How do I turn on the navigation system voice guidance?

1. Press the INFO button. Select Setup. Check that Volume is not set to Off.

2. Select Other, then Basic Settings. Set Voice Recognition Tutor to On if you want the system to

provide confirmations and system prompts.

My battery was disconnected or went dead, and the navigation system is asking for a code. Where do I find it?

In most cases, you do not need to enter a code. Simply press and hold the VOL 9 (Volume/Power) button for two seconds; the system should reactivate.

System Initialization P. 180

How to Use This Manual

Contents

Searching the Table of Contents

(P1)

Two types of Tables of Contents help you find your desired information.

First, find the general chapter related to what you are looking for (e.g., entering a destination from the Address Book). Then, go to that chapter to view a more specific table of contents.

Searching the Index (P200)

Menu items displayed on the navigation screen (e.g., Address Book) can be found individually in the Index.

This more detailed table of contents shows you exactly what information is listed by section and title.

The Index consists of main terms and subentries. The sub-entries help you get to the desired page depending on what you are looking for.

Table of Contents Chapter Contents

Navigation Screen

Index

2012 Civic Hybrid Navigation

This section explains different methods on how you can easily find information in this manual.

More Detailed

Contents

QRG

Quick Reference Guide

Go to the Next Page

Index

Home

Menu Tree

The menu tree helps guide you through the system’s menu options. To get to your desired function, follow the menu tree in order of the steps shown.

NOTE:

All menu options can also be activated with voice commands.

Press the hard button on the system control panel.

Press the DEST button.

Select the menu option.

Select Address Book.

After following the menu tree, step-by-step instructions explain how to achieve the desired result.

Sample pages and images in this section may differ from the actual ones.

2012 Civic Hybrid Navigation

QRG

Quick Reference Guide

DEST button

Index

Home

2012 Civic Hybrid Navigation

QRG

System Setup

This section describes the start-up procedure and the navigation and

setup functions.

Start-up ................................................... 18

Voice Control System ............................. 19

Command Input .................................... 19

Voice Recognition .................................. 20

Interface Settings ................................... 21

Display and Volume Settings.................. 21

Guidance Prompts.................................. 22

Basic Settings......................................... 23

Color ..................................................... 24

Language............................................... 28

Index

Home

Personal Information .............................. 29

Address Book......................................... 30

Home Addresses .................................... 35

PIN Numbers.......................................... 36

User Name..............................................37

Previous Destinations ..............................38

Routing & Guidance ................................39

Rerouting................................................40

Unverified Area Routing..........................41

Edit Avoid Area.......................................43

Edit Waypoint Search Area......................45

Clock Adjustment ....................................46

Adjust Time ............................................47

Resetting the Clock Settings....................47

Setting the Clock Type............................48

Vehicle ......................................................49

Off-road Tracking ...................................50

Correct Vehicle Position ..........................51

Data Reset ............................................... 52

Reset Factory Default Settings ................ 52

Clear All Speed Dial................................ 53

System Setup

Start-up

1 Start-up

If the navigation system loses power at any time, you may need to press and hold the VOL 9 (Volume/Power) button for more than two seconds, or you may be prompted for the 5-digit security code.

2 System Initialization P. 180

You can change the system language at any time.

2 Language P. 28

“OK” on the Confirmation screen cannot be selected by using a voice command. If you do not select OK within 30 seconds, the screen turns dark. Press any navigation or voice control button to continue.

2 Clock Adjustment P. 46 2 Setting the Clock Type P. 48

2012 Civic Hybrid Navigation

QRG

The navigation system starts automatically when you turn the ignition to

TOC

ACCESSORY (I) or ON (II). At start-up, the following Confirmation screen is displayed.

Index

Home

1. Select Change Language.



If you do not need to change the system language, proceed to step 3.

2. Select the system language.

3. Select OK.



Your current position is displayed on the map screen.

System Setup

Voice Control System

1 d (Talk) Button

When you press the d (Talk) button, a helpful prompt asks what you would like to do. Press and release the d (Talk) button again to bypass this prompt and give a command.

* Climate voice control: Civic Hybrid model only.

1 Command Input

The audio system is muted while using the voice control system.

2012 Civic Hybrid Navigation

QRG

Your vehicle has a voice control system that allows hands-free operation of most of the navigation system functions. You can also control the audio and climate control system*, and make and receive phone calls using Bluetooth® HandsFreeLink®.

The voice control system uses the d (Talk) and J (Hang-Up/Back) buttons on the steering wheel and a microphone near the map lights on the ceiling.

A “Voice Info” feature provides a tutorial that explains how to use the voice control system.

2 Voice Help P. 13

Command Input

If the system does not understand a command or you wait too long to give a command, it responds with “Pardon,” “Please repeat,” or “Would you say again.”

When you give a command, the system generally either repeats the command as a confirmation or asks you for further information. If you do not wish to hear this feedback, you can turn it off. However, listening to the feedback will help familiarize you with the way the system expects commands to be phrased.

2 Basic Settings P. 23

If the system cannot perform a command or the command is not appropriate for the screen you are on, the system beeps.

If the system responds with prompts such as “Please use the touch screen to…” or “Please use the joystick to…,” the system is asking for input that cannot be performed using the voice control system.

On character input screens, a list of possible characters is displayed if the system does not recognize your command.

You can find out which voice commands are available for a particular screen using the d Help command. The system will display and read the list of available commands to you.

TOC

Index

Home



System Setup

2012 Civic Hybrid Navigation

Voice Control SystemVoice Recognition

QRG

Voice Recognition

To achieve optimum voice recognition when using either the navigation voice

TOC

control system or Bluetooth® HandsFreeLink®:

• Make sure the correct screen is displayed for the voice command that you are using.

2 Voice Commands P. 190

• Close the windows and moonroof.

• Adjust the dashboard and side vents so air does not blow onto the microphone on

the ceiling.

• Speak clearly in a clear, natural speaking voice without pausing between words.

• Reduce any background noise if possible. The system may misinterpret your

command if more than one person is speaking at the same time.

• Refer to the Voice Info tutorial.

2 Voice Help P. 13

Index

Home

System Setup

Interface Settings

1 Display and Volume Settings

You can set separate daytime and nighttime settings for Brightness, Contrast, and Black Level. Adjust each setting when the display is in either daytime or nighttime mode.

You can set the display and volume settings using voice commands.

2 Main Setup Screen Commands P. 195

Volume

If you set Volume to Off, you will not hear route guidance or voice command confirmations. If you then select VOICE on the map screen, you will hear route guidance at the default volume.

2012 Civic Hybrid Navigation

Display and Volume Settings

H INFO button  Setup Use the Main Setup screen to adjust the display and volume.

The following items are available:

• Brightness: Adjusts the screen’s brightness.

• Contrast: Adjusts the screen’s contrast.

• Black Level: Adjusts the screen’s black level.

• Volume: Adjusts the navigation system volume level.

QRG

TOC

Select b or n to adjust the desired item.

Index

Home



System Setup

1 Guidance Prompts

To replay voice guidance, select VOICE on the map screen.

2 Listening to Voice Guidance P. 84

You can turn voice guidance off if you prefer.

2 Display and Volume Settings P. 21

2012 Civic Hybrid Navigation

Interface SettingsGuidance Prompts

QRG

Guidance Prompts

H INFO button  Setup

TOC

Set the number of guidance prompts before you get to the guidance point.

Select an option.

The following options are available:

Items

MIN Yes

NORMAL

(factory default)

MAX Yes Yes Yes

Index

Home

About 1/2 mile About 1/4 mile Just before

Distance from Guidance Point

Yes Yes

System Setup

2012 Civic Hybrid Navigation

Basic Settings

H INFO button  Setup  Other  Basic Settings Set the map units to either miles or kilometers, and control the voice feedback from

the navigation system.

Select an item.

The following items are available:

• Keyboard Layout: Sets the type of keyboard screen to either Alphabet (factory default) or QWERTY.

• Units: Sets the map units to either miles (factory default) or kilometers.

• Voice Recognition Tutor: Turns the voice feedback feature on or off.

On (factory default): Provides voice control system confirmation or prompts. Off: Disables the feature.

• Display Voice Command Tips: Alerts you when manual control of the system is

disabled to prevent distraction while driving. Only voice commands are available.

On (factory default): Displays a message. Off: Disables the message, but some options may be grayed out on the screen.



Interface SettingsBasic Settings

QRG

TOC

Index

Continued

Home



System Setup

2012 Civic Hybrid Navigation

Interface SettingsColor

QRG

• Verbal Reminder: Turns the verbal reminders on or off.

TOC

On (factory default): Provides warning voice messages when:

– Driving with the parking brake on – Driving without wearing the driver and/or passenger seat belt

Off: Disables the feature.

Color

H INFO button  Setup  Other  Color Choose the color of the navigation map and system menus.

The following items are available:

• Map: Sets the color of the map screen.

2 Map Color P. 25

• Menu: Sets the color of the menu screens.

2 Menu Color P. 25

Select an item.

Index

Home



System Setup

1 Map Color

For Day mode

Set to White (factory default is Beige) to obtain the best daytime display contrast.

For Night mode

Set to Black (factory default) to obtain the best nighttime display contrast.

1 Menu Color

For Day mode

Set to Black (factory default is Blue*) to obtain the best daytime display contrast.

For Night mode

Set to Black (factory default is Blue*) to obtain the best nighttime display contrast.

* Factory default is Red for Si models.

2012 Civic Hybrid Navigation

Interface SettingsColor

QRG

■ Map Color

H INFO button  Setup  Other  Color  Map Set separate map colors for Day and Night modes.

■ Menu Color



H INFO button Set separate menu colors for Day and Night modes.

Setup  Other  Color  Menu

TOC

Select a color for the map screen.

Select a color for the menu screens.

Index

Home



System Setup

1 Switching Display Mode Manually

A visual guide helps you see the difference between Day and Night modes.

2 Day or Night Mode P. 8

Recommended Settings

• Select mid-range for the dash illumination.

• Select White for the map Day display and

Black for the map Night display.

2012 Civic Hybrid Navigation

Interface SettingsColor

QRG

■ Switching Display Mode Manually

TOC

Set the screen brightness separately for Day and Night modes. Press the a (Display mode) button to cycle through the display modes (Day to Night to Off).

Index

Home

1. Press the a button.



The Brightness bar is displayed for a few seconds.

2. Press the a button again.



Repeat the procedure to switch the display modes.



Select b or n to adjust the brightness.



System Setup

1 Illumination Control

* Not available on all models.

2012 Civic Hybrid Navigation

Interface SettingsColor

QRG

Illumination

control

a button 1 Selects Day, Night, or Off display mode. This button has

Sunlight sensor* (see your Owner’s Manual for location)

Dash illumination adjustment buttons (see your Owner’s Manual for location)

Headlights (Auto*/On/Off)

Screen color choice

Priority Operation

the highest priority and overrides all other display control adjustments listed below. Remember: Once you press this button, you assume full manual control of the display mode until the ignition is turned off.

2 If the sunlight sensor detects daylight and the headlights

are turned on, the system automatically overrides the Night display and displays the Day display mode. Remember: If desired, use the a button to override this automatic choice.

3 When the headlights are turned on, and you wish to have

the Day display mode, adjust the illumination to full brightness (beeps). Remember: Adjust the dash brightness back to mid-range to allow auto switching by sensing the headlights are on or off.

4 When turned on, the display changes to Night display

mode. The previous three controls listed above can “cancel” this function. Remember: Use the a button, or adjust the dash illumination to full brightness, to set the display to your desired choice.

N/A The user can select the color of the screen that will be

displayed for the Day and Night display modes described above. Remember: For best contrast, ensure that the map color is white for Day and black for Night.

TOC

Index

Home



System Setup

1 Language

Voice confirmation of cities and streets only occurs when English is the system language.

When Français or Español is selected, some messages continue to be displayed in English.

2012 Civic Hybrid Navigation

Interface SettingsLanguage

QRG

Language

H INFO button  Setup  Other  Language

TOC

Set the system language used on all screens. You can choose from three languages: English, Français (French), Español (Spanish).

Select the system language.

Index

Home

System Setup

Personal Information

1 Personal Information

Personal information cannot be backed up or moved to another navigation system.

2012 Civic Hybrid Navigation

QRG

H INFO button  Setup  Personal Information Use the personal information menu to select and set your address books, home

addresses, and PINs. You can also delete unwanted destinations from the list of previously routed destinations.

The following items are available:

• Address Book: Stores new addresses or edits your address book.

2 Address Book P. 30

• Home Address 1: Sets or edits your home address.

2 Home Addresses P. 35

• Home Address 2: Sets or edits another home address.

2 Home Addresses P. 35

• PIN Number: Sets or changes your PIN.

2 PIN Numbers P. 36

• User Name: Sets or changes your user name.

2 User Name P. 37

• Previous Destinations: Deletes the destination history.

2 Previous Destinations P. 38

TOC

Select an item.

Index

Home



System Setup

1 Address Book

The number of addresses is shared by the two address books. For example, if User 1 has 150 addresses, User 2 can only have 50.

If you have PIN-protected your address book, enter your PIN when prompted. Select OK. PINs are optional.

2 PIN Numbers P. 36

Any address book categories you create are also displayed on the Select an Address screen.

2 Selecting an Address Book Category P. 33

2012 Civic Hybrid Navigation

Personal InformationAddress Book

QRG

Address Book

H INFO button  Setup  Personal Information  Address Book

TOC

Store up to 200 address entries in two address books (User 1 and User 2). You can add, edit, and delete information in the address books.

Index

Home

Select the user name to edit the user address book.

Displays the address book.



Select the user name to change the user address book.



Select the category tab to display only the address in the selected category.



System Setup

1 Adding an Address Book Entry

If you do not give the address a name, one is automatically assigned (e.g., Address 001). You can re-enter, edit, or make changes to any entry. “Address” is the only required field.

2012 Civic Hybrid Navigation

Personal InformationAddress Book

QRG

■ Adding an Address Book Entry

H INFO button  Setup  Personal Information  Address Book This section explains how to enter the name and address.

The following items are available:

• Edit Name: Edits the name of the entry.

• Edit Address: Edits the address of the entry.

• Edit Phone No.: Edits the phone number of the entry.

• Edit Category: Specifies the category of the entry.

• Delete: Deletes the entry.

1. Select New Address.

2. Select an item.

Continued

TOC

Index

Home

System Setup

1 Adding an Address Book Entry

When you use Place Name or Place Category, the phone number is automatically entered.

2012 Civic Hybrid Navigation

QRG



Personal InformationAddress Book

TOC

The following items are available:

• Current Position: Select your current location.

• Address: Enter an address on the character input screen when prompted.

2 Address P. 58

• Previous Destinations: Select a previous destination.

2 Previous Destinations P. 64

• Place Name: Enter the name of a place/landmark.

2 Place Name P. 65

• Place Category: Select a category to search for a place/landmark (e.g., Banking, Lodging).

2 Place Category P. 67

• Place Phone Number: Enter the phone number of a place/landmark.

2 Place Phone Number P. 72

Index

Home

3. Select Edit Name.

4. Enter a name or title. Select OK.

5. Select Edit Address.

6. Select an item for specifying the

address.



System Setup

1 Editing an Address Book Entry

The entered contents are displayed on the Edit address screen.

1 Selecting an Address Book Category

You can have up to 100 categories (including “UNFILED”). These categories can be shared with User 1 and User 2. For example, if User 1 creates some categories, User 2 can also use them.

If you delete a category that is used by other addresses, the category type for those addresses changes to “UNFILED.”

Category Icons

The following icons can be selected for a category:

2012 Civic Hybrid Navigation

Personal InformationAddress Book

QRG

■ Editing an Address Book Entry

H INFO button  Setup  Personal Information  Address Book

■ Selecting an Address Book Category

H INFO button



Setup  Personal Information  Address Book

1. Select the address to edit.

2. Enter the name, address, phone

number, and category fields.

2 Adding an Address Book Entry

P. 31

3. Select OK.

1. Select an address.

2. Select Edit Category.

3. Select BUSINESS, PERSONAL, or a

category you created.

Continued

TOC

Index

Home



System Setup

1 Deleting an Address Book Entry

When you transfer the vehicle to a third party, delete all address book entries.

2012 Civic Hybrid Navigation

Personal InformationAddress Book

QRG

■ Creating a New Category

TOC

1. Select New Category.

2. Enter a name and select an icon when prompted. Select OK.



The created category is displayed in the list of categories.

■ Deleting or Editing a Category

1. Select Edit Category.

2. Select Edit Category or Delete.

3. Delete an existing category, or change the name and icon.

■ Deleting an Address Book Entry

H INFO button



Setup  Personal Information  Address Book

1. Select the address to delete.

2. Select Delete.

3. Select Yes.

Index

Home

System Setup

Home Addresses

1 Home Addresses

If you have PIN-protected your home addresses, enter your PIN when prompted. Select OK. PINs are optional.

2 PIN Numbers P. 36

If your home street is not in the system database, park on the nearest verified street to your home. When entering the “Address” field, select Current Position to use your current location as the home address.

You can delete a home address if necessary. Select Delete. Select Yes.

When you transfer the vehicle to a third party, delete all home addresses.

The home icon is shown on the map screen in 1/20 and 1/8 mile scales.

2012 Civic Hybrid Navigation

H INFO button  Setup  Personal Information  Home Address 1 or Home

Address 2

Set two home addresses that you frequently use.

1. Edit the name, address, and phone number the same way as an address in the address book.

2 Adding an Address Book Entry

P. 31

2. Select OK.



Personal InformationHome Addresses

QRG

TOC

Index

Home



System Setup

1 PIN Numbers

Personal Identification Number (PIN) is a password used to access some personal data.

PINs are optional. If you choose to use a PIN, keep a note of the number in a secure location. If you forget your PIN, your dealer will have to reset the navigation system and all of your stored information will be erased. The factory default is no PIN.

Go Home PIN

Go Home PINs are shared with User 1 and User

2. If either User 1 or User 2 sets a Go Home PIN, both of them need to enter the PIN when:

• selecting Go Home for a destination

• selecting Home Address for editing

If you want to stop using a PIN, select Do not use PIN.

2012 Civic Hybrid Navigation

Personal InformationPIN Numbers

QRG

PIN Numbers

H INFO button  Setup  Personal Information  PIN Number

TOC

Set a 4-digit PIN for protecting personal addresses and your home addresses. Once you set a PIN, you are prompted to enter it whenever you access a personal address or a home address.

1. Select the PIN to create.

2. Select the user name (when

selecting Address Book PIN).

Index

Home

3. Enter a 4-digit PIN.

4. Re-enter the new PIN when

prompted to confirm the number you just entered.



If you do not enter the same number both times, an “INCORRECT PIN” message is displayed. Enter your PIN again.

System Setup

2012 Civic Hybrid Navigation

User Name

H INFO button  Setup  Personal Information  User Name Change the user name (“User 1” or “User 2”) to your desired name.

1. Select the name to change.

2. Enter a name. Select OK.



Personal InformationUser Name

QRG

TOC

Index

Home



System Setup

1 Previous Destinations

Up to 50 destinations can be stored.

The list of previous destinations is shared with User 1 and User 2. For example, if User 1 deletes some previous destinations, they are deleted for User 2 as well.

To cancel the selection of a previous destination, select the destination again.

Selecting Delete All allows you to delete all destinations.

Trash icon

2012 Civic Hybrid Navigation

Personal InformationPrevious Destinations

QRG

Previous Destinations

H INFO button  Setup  Personal Information  Previous Destinations

TOC

The navigation system maintains a list of your previously routed destinations as a shortcut for entering the same destination in the future. You can delete some or all of your previous destinations from the list.

1. Select the destination to delete.



Repeat the procedure as necessary.



Items to be deleted are indicated with a trash icon.

Index

Home

2. Select OK to delete the selected destinations.

System Setup

Routing & Guidance

2012 Civic Hybrid Navigation

QRG

H INFO button  Setup  Other  Routing & Guidance Choose various settings that determine the navigation system functionality during

route guidance.

Select an item.

The following items are available:

• Rerouting: Sets the route recalculation to automatic or manual mode.

2 Rerouting P. 40

• Unverified Area Routing: Sets whether you use the route guidance in unverified areas.

2 Unverified Area Routing P. 41

• Edit Avoid Area: Specifies areas to avoid when calculating a route.

2 Edit Avoid Area P. 43

• Edit Waypoint Search Area: Sets the distance from the route to find waypoints.

2 Edit Waypoint Search Area P. 45

• Guidance Mode: Sets whether to display only the map screen or a split map- guidance screen.

2 Guidance Mode P. 90

TOC

Index

Home



System Setup

1 Rerouting

If you live in an area with poor mapping, you may wish to set Rerouting to Manual to avoid constant recalculation. You will need to select Recalc. manually to make the system recalculate your new route.

2012 Civic Hybrid Navigation

Routing & GuidanceRerouting

QRG

Rerouting

H INFO button  Setup  Other  Routing & Guidance

TOC

Set whether route recalculation occurs automatically or manually during route guidance.

The following options are available:

• Automatic (factory default): The system calculates a new route automatically when you deviate from the route. It is strongly recommended that you leave the system set to Automatic.

• Manual: Disables route recalculation. The system beeps and “Off Route” is displayed when you deviate from the route.

Select an option.

Index

Home

System Setup

Unverified Area Routing

1 Unverified Area Routing

Unverified roads are found in rural areas, and typically include residential streets away from the center of a town. They may not be accurate, and can contain errors in location, naming, and address range.

Unverified roads are shown only when viewing the map in the 1/20, 1/8, 1/4 mile map scales.

Vector line (dotted)

Blue-pink route line

2012 Civic Hybrid Navigation

H INFO button  Setup  Other  Routing & Guidance Receive turn-by-turn map and voice guidance in unverified areas.

Differences Off (factory default) On

On or Off? The driver wishes to manually

Route calculation

Route line A blue dotted vector line is displayed

Cautionary messages

navigate using the navigation map and choose the streets that lead to the destination.

Route is usually longer, using verified roads whenever possible.

on the map that continually points to your destination.

Cautionary pop-up screens and voice announcements remind you to obey all traffic restrictions.

Select On or Off.

The driver chooses to let the navigation system suggest possible routing, knowing that the guidance may not be accurate.

Route is shorter, but uses unverified (purple) streets that may not be accurate.

A blue-pink dashed route line highlights suggested unverified streets on the map while traveling to your destination.

Cautionary pop-up screens and voice announcements remind you to exercise additional caution and obey all traffic restrictions.

Continued



Routing & GuidanceUnverified Area Routing

QRG

TOC

Index

Home

System Setup

2012 Civic Hybrid Navigation

QRG



Routing & GuidanceUnverified Area Routing

TOC

Index

Home

Differences Off (factory default) On

Guidance (map/voice)

My Destination (Direction list)

There is no turn-by-turn map or voice guidance.

A direction list is typically not available. However, depending on your route, directions are provided to help you reach the first available

Voice guidance commands end with the phrase “if possible” to remind you to verify all traffic restrictions.

A direction list is provided showing unverified street names in blue boxes and turn symbols in pink.

verified road.

System Setup

Edit Avoid Area

1 Edit Avoid Area

The avoid areas are shared with User 1 and User 2. For example, if User 1 specifies some avoid areas, User 2 can also use them for setting a route.

The maximum size of an “avoid area” is 1/2 square mile.

If your selected area contains a freeway, you are asked “Do you want to avoid freeways?” Answering “No” allows you to use a route through an avoid area on a freeway without any pop-up messages.

You can select areas to avoid, however you cannot select roads or areas that you want the system to use for routing.

You can enter up to 25 characters for the name.

2012 Civic Hybrid Navigation

H INFO button  Setup  Other  Routing & Guidance  Edit Avoid Area

“Edit”

Specify up to five areas to avoid (e.g., road construction, closures), if possible, when the system calculates routes to your destination.

The following items are available (after an area is set):

• View Area Map: Displays the selected avoid area on the map.

• Delete: Deletes the selected avoid area.

1. Select New Area or an existing area to edit.

2. Select Edit Name to label the area to avoid.

3. Enter a name or title. Select OK

4. Select Edit Area to define the area to avoid.

Continued



Routing & GuidanceEdit Avoid Area

QRG

TOC

Index

Home

System Setup

Cursor

Avoid area

2012 Civic Hybrid Navigation

QRG



Routing & GuidanceEdit Avoid Area

TOC

The following items are available:

• Address: Specify the general area by entering an address.

2 Address P. 58

• Map Input: Specify the general area by map input.

2 Map Input P. 75

Index

Home

5. Select a method for specifying the area.

6. Scroll the map to position the cursor over your desired start point, adjusting the map scale as necessary. Press the ENTER button to mark the start point.



To redo the area selection, press the CANCEL button.

7. Scroll the map to “draw” the area. Press the ENTER button to mark the end point.

8. Select OK.



The area you specify is displayed in the list of areas to avoid.

System Setup

1 Edit Waypoint Search Area

The search distance does not affect the search range used for the Find Nearest voice commands (e.g., say

d “Find nearest gas station”).

2012 Civic Hybrid Navigation

Edit Waypoint Search Area

H INFO button  Setup  Other  Routing & Guidance  Edit Waypoint

Search Area “Edit”

Select the distance from your highlighted route line (on either side of your route) that the system will search for a waypoint.

2 Adding Waypoints P. 103

You can specify a different search distance for freeways and surface streets.

1. Select a search distance.

2. Select OK

The following options are available:

• On Freeways: 1, 2, 5, or 10 miles can be set. Factory default is 2 miles.

• On Surface Street: 1/2, 1, 2, or 5 miles can be set. Factory default is 1/2 mile.



Routing & GuidanceEdit Waypoint Search Area

QRG

TOC

Index

Home

System Setup

Clock Adjustment

1 Clock Adjustment

You can check the time and date from any screen using voice commands.

2 Global Commands P. 190

Auto Daylight

This function is not activated in areas that have not adopted daylight saving time, even if you have set Auto Daylight to On.

Auto Time Zone

If you live and work in two different time zones, you may want to turn Auto Time Zone to Off. When driving near a time zone boundary, the displayed time zone may fluctuate between the two zone times.

2012 Civic Hybrid Navigation

QRG

H INFO button  Setup  Other  Clock Adjustment  Clock Adjustment

TOC

Set the automatic adjustment of the system clock for daylight saving and international time zones.

The following items are available:

• Auto Daylight: The navigation system automatically adjusts the clock (“spring ahead” or “fall back” by one hour) when a daylight saving time change occurs.

On (factory default): Adjusts the clock automatically. Off: Disables the feature.

Home

• Auto Time Zone: The navigation system automatically adjusts the clock when

Index

driving through different time zones.

On (factory default): Adjusts the clock automatically. Off: Disables the feature.

• Clock Format: Sets the time notation to either 12-hour clock (12H, factory default) or 24-hour clock (24H).

• Time Adjustment: Adjust the current time manually.

2 Adjust Time P. 47

• Reset: Reset the clock settings to the factory default.

2 Resetting the Clock Settings P. 47

Select an item.

System Setup

2012 Civic Hybrid Navigation

Adjust Time

H INFO button  Setup  Other  Clock Adjustment  Clock Adjustment Adjust the current time (hours and minutes).

1. Select B or N to adjust the value.

2. Select OK on the top right of the

screen.

Resetting the Clock Settings

H INFO button  Setup  Other  Clock Adjustment  Clock Adjustment Reset all clock settings to the factory defaults.

Select OK under Reset.



Clock AdjustmentAdjust Time

QRG

TOC

Index

Home



System Setup

2012 Civic Hybrid Navigation

Clock AdjustmentSetting the Clock Type

QRG

Setting the Clock Type

H INFO button  Setup  Other  Clock Adjustment  Clock Type

TOC

Set the design of the clock screen.

1. Select Clock Type or Background.

2. Select an option to change the

design.

3. Select OK.

Index

Home

System Setup

Vehicle

2012 Civic Hybrid Navigation

QRG

H INFO button  Setup  Other  Vehicle Set the off-road tracking feature and correct the vehicle position displayed on the

map.

Select an item.

The following items are available:

• Off-road Tracking: Set whether to display the tracking dots on the map.

2 Off-road Tracking P. 50

• Correct Vehicle Position: Adjust the position of the vehicle on the map.

2 Correct Vehicle Position P. 51

TOC

Index

Home



System Setup

1 Off-road Tracking

To clear existing breadcrumbs, set Off-road Tracking to Off, exit the Setup screen, and then set Off-road Tracking to On again.

2012 Civic Hybrid Navigation

VehicleOff-road Tracking

QRG

Off-road Tracking

H INFO button  Setup  Other  Vehicle

TOC

The navigation system can be set to display white off-road tracking dots (“breadcrumbs”) on the map screen whenever you drive into an area approximately 1/2 mile away from a mapped road.

The following options are available:

• On: The system displays the white tracking dots.

2 Driving Off-road P. 83

• Off (factory default): Disables the feature.

Select an option.

Index

Home

System Setup

Correct Vehicle Position

1 Correct Vehicle Position

An apparent position error can occur where buildings, tunnels, and other objects block or reflect the GPS signals, forcing the system to use “dead reckoning” to determine your location and direction.

Using this function to adjust vehicle position is not recommended. When the system reacquires a GPS signal, it will automatically place the vehicle in the correct location.

If you continually have to adjust the vehicle position, you may have problems with the GPS reception or there may be database errors.

2 System Limitations P. 182

2012 Civic Hybrid Navigation

H INFO button  Setup  Other  Vehicle Manually adjust the current position of the vehicle as displayed on the map screen if

the position appears to be incorrect.

1. Put the vehicle in Park.

2. Select ADJUST under Current

Vehicle Position.

3. Scroll the map to position the arrowhead at your correct position.

4. Select or to position the arrowhead in the correct direction the vehicle is facing.

5. Select OK.



VehicleCorrect Vehicle Position

QRG

TOC

Index

Home

System Setup

Data Reset

1 Reset Factory Default Settings

The following settings are reset:

• Brightness, Contrast, Black Level, Volume,

Guidance Prompts

• Basic Settings: Keyboard Layout, Units, Voice

Recognition Tutor, Verbal Reminder, Display Voice Commands Tips

• Routing & Guidance: Rerouting, Unverified

Area Routing, Edit Waypoint Search Area, Guidance Mode

• Clock Adjustment: Auto Daylight, Auto Time

Zone, Clock Format Time, Clock Type

• Vehicle: Off-road Tracking

• Color: Map Color, Menu Color

When you transfer the vehicle to a third party, reset all settings to default and delete all personal data.

2 Deleting an Address Book Entry P. 34 2 Home Addresses P. 35 2 PIN Numbers P. 36 2 User Name P. 37 2 Previous Destinations P. 38 2 Edit Avoid Area P. 43 2 Deleting a Paired Phone P. 149

2012 Civic Hybrid Navigation

QRG

Reset Factory Default Settings

H INFO button  Setup  Other  Reset Factory Default

TOC

Reset all the settings on the Setup screens to their factory defaults.

Index

Home

Select Yes.

System Setup

1 Clear All Speed Dial

You can also delete a speed dial individually.

2 Setting Up Speed Dialing P. 151

2012 Civic Hybrid Navigation

Clear All Speed Dial

H INFO button  Setup  Other  Clear All Speed Dial Delete all registered speed dials stored in Bluetooth® HandsFreeLink®.

Select Yes.



Data ResetClear All Speed Dial

QRG

TOC

Index

Home

2012 Civic Hybrid Navigation

QRG

Index

Home

2012 Civic Hybrid Navigation

QRG

Navigation

This section describes how to enter a destination, select a route to take,

and follow the route to your destination. It also describes how to change

your route or destination along the way.

Entering a Destination ........................... 56

Address ................................................. 58

Address Book......................................... 63

Previous Destinations ............................. 64

Place Name............................................ 65

Place Category....................................... 67

Place Phone Number.............................. 72

Coordinate ............................................ 73

Intersection............................................ 74

Map Input.............................................. 75

Index

Home

Calculating the Route..............................77

Changing the Route Preference ..............78

Viewing the Routes.................................78

Calculating the Route on the

Destination

Driving to Your Destination ...................80

Viewing the Route ..................................80

Listening to Voice Guidance....................84

Map Menu ................................................85

Displaying Map Menu .............................85

Guidance Menu ......................................87

Showing Icons on the Map .....................92

Map Legend ...........................................94

FM Traffic ...............................................99

Map...................................79

Changing Your Route........................... 101

Canceling the Route............................. 102

Taking a Detour ................................... 102

Avoiding Streets................................... 102

Adding Waypoints ............................... 103

Editing My Destination ......................... 107

Changing Your Destination ................. 108

Find Nearest Place ................................ 108

Selecting a Destination on the Map...... 109

Entering a New Destination .................. 110

Resuming Your Trip .............................. 112

Navigation

Entering a Destination

1 Entering a Destination

d “Display Menu”, d “Display Navigation”

If you press the DEST button when en route, the Route Menu screen is displayed.

2 Changing Your Route P. 101

Prior to departure, you can set areas along your route to avoid.

2 Avoiding Streets P. 102

2012 Civic Hybrid Navigation

QRG

H DEST button This section describes how to enter a destination for route guidance.

TOC

The following items are available:

• Address: Sets a destination by entering an address.

2 Address P. 58

Home

• Address Book: Sets a destination by selecting an address stored in your Address

Index

Book.

2 Address Book P. 63

• Previous Destinations: Sets a destination by selecting a previous destination.

2 Previous Destinations P. 64

Select an item.



Select DEST Menu 2 to display additional menu entries.

Navigation

• Place Name: Sets a destination by entering a place name.

2012 Civic Hybrid Navigation

2 Place Name P. 65



Entering a Destination



QRG

• Place Category: Sets a destination by selecting a place/landmark.

2 Place Category P. 67

• Place Phone Number: Sets a destination by entering the phone number of a place/landmark.

2 Place Phone Number P. 72

• Coordinate: Sets a destination by entering latitude and longitude.

2 Coordinate P. 73

• Intersection: Sets a destination (intersection) by entering two streets.

2 Intersection P. 74

• Map Input: Sets a destination by scrolling through the map.

2 Map Input P. 75

• Go Home 1 or 2: Sets your home address as a destination.

2 Going Home P. 10

TOC

Index

Home



Navigation

2012 Civic Hybrid Navigation

Entering a DestinationAddress

QRG

Address

H DEST button  Address Enter an address to use as the destination. The state or province you are currently in

is displayed (e.g., California).

TOC

The following items are available:

• City: Selects your destination city.

2 Selecting a City P. 60

• Street: Selects your destination street.

2 Selecting a Street P. 61

• Change State: Selects the state or province.

2 Selecting the State or Province P. 59

Select an item.

Index

Home

Navigation

2012 Civic Hybrid Navigation

■ Selecting the State or Province

H DEST button  Address  Change State

1. Enter a state name.



Select List to display a list of states.

2. Select a state from the list.



Entering a DestinationAddress

QRG

TOC

Index

Home



Navigation

1 Selecting a City by Name

Vehicle position may not be displayed when:

• The automobile is traveling off-road.

• The vehicle position data cannot be updated.

You do not need to enter spaces or symbols (e.g., &, -, %). Partial matches are supported (e.g., “ANGELES” to find “LOS ANGELES”).

Using Voice Command (English only)

Say d “City” on the Find address by screen, and the following screen is displayed:

Say d “Current City” to select your current location, or say the name of a different city.

2 Selecting a Street P. 61

If your city is not listed, it may be part of a larger metropolitan area. Try entering the street first.

Non-detailed area mark: Try entering the street first and then select the city.

2012 Civic Hybrid Navigation

Entering a DestinationAddress

QRG

■ Selecting a City

H DEST button  Address  City The name of the city where you are currently located is displayed.

TOC

1. Enter the name of a different city, or select List for the current city.



Select List to display a list of cities.

2. Select your destination city from the list.



A list of matching hits is automatically displayed after you enter several letters, with the closest match at the top of the list.



Next, you are prompted to enter a street name.

2 Selecting a Street P. 61

Index

Home

Navigation

■ Selecting a Street

1 Selecting a Street

When entering the names of major freeways, you can use the following abbreviations. For interstates, use an “I” (e.g., I-10). For U.S. freeways, use “US” (e.g., US-18). For state freeways, use the two-character state designation (e.g., CA-101). For county roads, use the appropriate designation (e.g., G-2).

Using Voice Command (English only)

Say d “Street” on the Find address by screen, and the following screen is displayed:

• Say the name of your destination street, and

say the street number as a string of individual numbers.

• Set the route to your destination.

2 Calculating the Route P. 77

2012 Civic Hybrid Navigation

H DEST button  Address  Street

1. Enter the name of your destination

street.



Do not enter the street type (e.g., street, road, avenue) or direction (e.g., north, south, east, west).



Select List to display a list of streets.

2. Select your destination street from the list.



A list of matching hits is automatically displayed after you enter several letters, with the closest match at the top of the list.



Entering a DestinationAddress

QRG

TOC

Continued

Index

Home



Navigation

1 Selecting a Street

If you did not select a city first and there is more than one city with the specified street, a list of cities is displayed.

Select the desired city from the list.

2012 Civic Hybrid Navigation

Entering a DestinationAddress

QRG

TOC

3. Enter the street number. Select OK.



Only valid street numbers can be entered.

4. Set the route to your destination.

2 Calculating the Route P. 77

Index

Home

Navigation

Address Book

1 Address Book

If you have PIN-protected your address book, enter your PIN when prompted. Select OK. PINs are optional.

2 PIN Numbers P. 36

You can select New Address on the Select an address screen to add an entry to the address book.

2 Adding an Address Book Entry P. 31

To switch the list between User 1 or User 2, select the user name on the top right of the screen.

2012 Civic Hybrid Navigation

H DEST button  Address Book Select an address stored in your address book to use as the destination.

1. Select your user name.

2. Select your destination from the

list.

3. Set the route to your destination.

2 Calculating the Route P. 77



Select C or X to display only the entries in a category: ALL, BUSINESS, PERSONAL, or other categories you have created.

2 Selecting an Address Book

Previous Destinations

H DEST button  Previous Destinations Select an address from a list of your 50 most recent destinations to use as the

destination. The list is displayed with the most recent destination at the top.

TOC

Index

Home

1. Select a destination from the list.

2. Set the route to your destination.

2 Calculating the Route P. 77

Navigation

Place Name

1 Place Name

This option is convenient if you know the exact name of a place.

Select More to enter symbols and accented letters, select Space to enter a space character, or select Delete to remove the last character.

Once a name is entered and selected, select SORT BY Name or SORT BY Distance. Matching letters are in yellow.

2012 Civic Hybrid Navigation

H DEST button  Place Name Enter the name of a place (e.g., business, hotel, restaurant) stored in the map

database to use as the destination.

1. Enter a place name.

2. Select List to display a list of

matching hits.

3. Select a place name from the list.



If the place name is in multiple categories, the categories are displayed when you select it.

2 Place Name in Multiple

1 Place Name in Multiple Categories

Select SORT BY Name or SORT BY Distance. Matching letters are in yellow.

2012 Civic Hybrid Navigation

Entering a DestinationPlace Name

QRG

■ Place Name in Multiple Categories

If the place name is in multiple categories in the map database, the following screen is displayed.

TOC

1. Select a place name.

2. Select a subcategory.

3. Set the route to your destination.

2 Calculating the Route P. 77

Index

Home

Navigation

Place Category

1 Place Category

This option is convenient if you do not know the exact name of a place or if you want to narrow down the number of matches returned for places with a common name.

You can store up to 30 favorite subcategories. Select Fav. Subcategory to access your favorites.

2 Favorite Subcategories P. 69

Advanced helps you to search the subcategory. When you enter a keyword and select List, the list of appropriate subcategories is displayed.

2012 Civic Hybrid Navigation

H DEST button  Place Category Select the category of a place (e.g., Banking, Lodging, Restaurant) stored in the map

database to search for the destination.

1. Select a category.

2. Select a subcategory.



Select b or n to change the main category.

2 List of Categories P. 199

Continued



Entering a DestinationPlace Category

QRG

TOC

Index

Home



Navigation

1 Place Category

Sort by Distance to Travel

For locations sorted by distance to travel, you can select More to increase the scope of the search. The number of locations increases to 100, 200, and up to 1000. When the number of locations is 100 or less, you can increase the scope to 500 miles, 1000 miles, or all of U.S.

2012 Civic Hybrid Navigation

Entering a DestinationPlace Category

QRG

TOC

The following items are available:

• Place Name: Searches for a place in the subcategory by name. Enter a city name when prompted.

• Sort by Distance to Travel: Displays all the places in the subcategory sorted by distance from your current location. The closest place is displayed at the top.

• City Vicinity: Searches for a place in the subcategory within a 20-mile radius of a specific city. Enter a city name and then a place name when prompted. Only the first 1,000 matching places/landmarks are displayed.

• Search by Keyword: Searches for a place by keyword when you do not know the exact category. Select Sort by Distance to Travel for locations near your current location, or select City Vicinity for locations in a specific city. Enter a keyword when prompted. Select List to view a list of possible locations if one is not found automatically.

3. Select an item.

Index

Home

Navigation

1 Place Category

The straight line distance (as the crow flies, not driving distance) and direction to the destination are shown for the highlighted place.

2012 Civic Hybrid Navigation

■ Favorite Subcategories



H DEST button Store up to 30 favorite subcategories.

Place Category  Fav. Subcategory

4. Select a place name from the list.

5. Set the route to your destination.

2 Calculating the Route P. 77



Entering a DestinationPlace Category

QRG

TOC

Continued

Index

Home



Navigation

1 Favorite Subcategories

Stored categories

A subcategory stored in Fav. Subcategory has a star at the end of the line.

2012 Civic Hybrid Navigation

Entering a DestinationPlace Category

QRG

■ To store a subcategory in favorites:

TOC

1. Select a category on the Category screen.

2. Select Add to Fav. Subcategory.

3. Select the favorite subcategories to

add. Select OK.

Index

Home

Navigation

1 Favorite Subcategories

Deleting categories

You can also delete a favorite subcategory on any Subcategory screen. Select R or U to select a favorite subcategory (which has a star at the end of line) and select Delete from Fav. Subcategory.

Trash icon

2012 Civic Hybrid Navigation

■ To delete a subcategory from favorites:

1. Select Delete on the Favorite Subcategory screen.

2. Select the subcategories to delete.



Repeat the procedure as necessary.



Items to be deleted are indicated with a trash icon.

3. Select OK.



Entering a DestinationPlace Category

QRG

TOC

Index

Home



Navigation

1 Place Phone Number

All 10 digits must be entered.

Phone numbers of private residences entered in your address book are not stored in the database and thus cannot be used to search for a destination.

A list is displayed if there are multiple locations in the database with the same phone number. Select a place from the list.

2012 Civic Hybrid Navigation

Entering a DestinationPlace Phone Number

QRG

Place Phone Number

H DEST button  DEST Menu 2  Place Phone Number Select a destination by phone number. Only phone numbers in the database are

recognized.

TOC

1. Enter the area code and phone number. Select OK.

Index

Home

2. Set the route to your destination.

2 Calculating the Route P. 77

Navigation

Coordinate

1 Coordinate

Latitude and longitude must be entered up to the seconds’ value.

A yellow box (shown at scales above 1/4 mile) denotes the area that can be viewed when you press the ENTER button on the current map.

Information icons are displayed at scales from 1 mile to 1/4 mile. Place/landmark icons are displayed at 1/8 mile or less. Roads are displayed at 1/4 mile or less.

If you select multiple icons within the cursor radius, you are prompted to select one of the items from a list.

2012 Civic Hybrid Navigation

H DEST button  DEST Menu 2  Coordinate Specify a location using latitude and longitude map coordinates.

1. Enter the latitude. Select OK.

2. Enter the longitude. Select OK.

3. Scroll the map to position the

cursor over your desired destination, adjusting the map scale as necessary. Press the ENTER button.



If the address is not the desired location, scroll to another location and try again.

4. Press the ENTER button again to display the route calculation menu.

2 Calculating the Route P. 77

5. Select Set as Dest.



Entering a DestinationCoordinate

QRG

TOC

Index

Home



Navigation

1 Intersection

It is usually easier to select Street to find the streets first. The city or cities that the streets are in will be displayed. If you select City and your city is not listed, it may be part of a larger metropolitan area. Try entering the street first.

If the intersection is outside the state you are currently in, select Change State.

2 Selecting the State or Province P. 59

If there is more than one intersection, you are prompted to select the intersection. If the two streets that you have selected do not intersect, no intersection is entered.

2012 Civic Hybrid Navigation

Entering a DestinationIntersection

QRG

Intersection

H DEST button  DEST Menu 2  Intersection Select the intersection of two streets as the destination. The state or province for

your current location is displayed at the top of the screen (e.g., California).

TOC

1. Select the intersection search method.

The following items are available:

• City: Selects the city where the intersection is located. You are prompted to enter the name of the two intersecting streets.

2 Selecting a City P. 60

• Street: Selects the two intersecting streets. The city or cities that the streets are located in are displayed.

Index

Home

2 Selecting a Street P. 61

• Change State: Selects the state or province.

2 Selecting the State or Province P. 59

2. Set the route to your destination.

2 Calculating the Route P. 77

Navigation

2012 Civic Hybrid Navigation

Map Input

H DEST button  DEST Menu 2  Map Input Use the joystick to manually select an icon or a location on the map screen as the

destination. You are prompted to define the map area to display.

1. Select an item.

The following items are available:

• Current Position: Your current location is centered on the map.

• City: You are prompted to select the city.

2 Selecting a City P. 60

• State: You are prompted to select the state.

2 Selecting the State or Province P. 59



Entering a DestinationMap Input

QRG

TOC

Continued

Index

Home



Navigation

1 Map Input

A yellow box (shown at scales above 1/4 mile) denotes the area that can be viewed when you press the ENTER button on the current map.

Information icons are displayed at scales from 1 mile to 1/4 mile. Place/landmark icons are displayed at 1/8 mile or less. Roads are displayed at 1/4 mile or less.

If you select multiple icons within the cursor radius, you are prompted to select one of the items from a list.

2 Selecting a Destination on the Map P. 109

2012 Civic Hybrid Navigation

Entering a DestinationMap Input

QRG

TOC

Index

Home

2. Scroll the map to position the cursor over your desired destination, adjusting the map scale as necessary. Press the ENTER button.



If the address is not the desired location, scroll the map to another location and try again.

3. Press the ENTER button again to display the route calculation menu.

2 Calculating the Route P. 77

4. Select Set as Dest.

Navigation

1 Calculating the Route

The current route preferences are displayed as icons on the top right of the Calculate Route screen. The straight line distance (as the crow flies, not driving distance) and direction to the destination are shown.

You cannot use voice commands while the system is calculating the route.

Add to Address Book

You can add the destination address to the address book.

2 Adding an Address Book Entry P. 31

Add to My Dest.

You can add the address to the destination list.

2 Editing My Destination P. 107

Call

You can place a telephone call to the destination phone number.

2 Bluetooth® HandsFreeLink® P. 144

2012 Civic Hybrid Navigation

Calculating the Route

This section describes how to calculate your route.

1. Select Set as Dest.



The system calculates and displays the route line on the map screen.

2 Route Line P. 82

QRG

TOC

The following items are available:

• Route Pref.: Changes the route preferences (calculating method).

2 Changing the Route Preference P. 78

• View Routes: Displays three different routes.

2 Viewing the Routes P. 78

• Destination Map: Displays a map of the destination.

2 Calculating the Route on the Destination Map P. 79

2. Follow the route guidance to your

destination.

2 Driving to Your Destination P. 80



The system provides you with pop-up messages if your route passes through unverified areas, avoid areas, or areas with traffic restrictions.

Index

Home



Navigation

1 Changing the Route Preference

The calculated route may not be the route you would choose. For safety reasons, the system generally applies the following rules to your route:

• Shortcuts through residential areas are

avoided.

• Right turns are favored over left turns or U-

turns.

• Time-restricted turns (turns prohibited at

certain times of the day) are not used.

1 Viewing the Routes

It is not unusual for some calculated route options to be identical.

2012 Civic Hybrid Navigation

Calculating the RouteChanging the Route Preference

QRG

Changing the Route Preference

Change the route preference by selecting minimum or maximum driving methods.

TOC

Viewing the Routes

View three different routes to your destination.

Index

Home

1. Select MIN or MAX for each item.

2. Select OK

1. Select a route on the list.



The travel distance and estimated travel time is displayed for each route.



The system calculates and displays the route line on the map screen.

2 Route Line P. 82

2. Select OK.

Navigation

1 Calculating the Route on the Destination Map

d “Display Destination Map” (when en route)

2012 Civic Hybrid Navigation



Calculating the Route on the Destination Map

Calculate the route from the map of the destination address.

Select Calculate the Route.



The system calculates and displays the route line on the map screen.

2 Route Line P. 82

Calculating the RouteCalculating the Route on the Destination Map

QRG

TOC

Index

Home

Navigation

Driving to Your Destination

1 Viewing the Route

d “Display Map”

You can change the map scale using voice control commands (e.g., say d “Display 2 mile scale”).

2 Map Scale Commands P. 191

You can also change the map scale by using the ZOOM button.

You can control the icons displayed on the map screen using voice control commands (e.g., say d “Display post office”).

2 Map Display Commands P. 190

You can obtain information about the route using voice control commands (e.g., say d “How long to the destination?”).

2 Route Commands P. 192

You can display the next guidance point on the map screen by saying d “Display Map Guide” (when en route).

If you scroll the map while en route, the time and distance to destination indicators are replaced with an indicator showing distance from the current vehicle position.

The map screen can be viewed in single-screen or split-screen mode.

2 Guidance Mode P. 90

2012 Civic Hybrid Navigation

QRG

This section describes how to follow the route guidance to your destination, receive traffic information, and choose the icons displayed on the map screen.

Viewing the Route

TOC

Home

■ Map Screen

Index

After calculating the route to your destination, the route is displayed on the map screen.

2 Map Screen Legend P. 7

As you drive, the system tracks your position on the map in real time and provides guidance as you approach each guidance point on the route.

Navigation

■ Guidance Screen

1 Guidance Screen

A visual guide helps you check the guidance screen.

2 Guidance Screen P. 8

Turn-by-Turn Directions

The next guidance point appears on the multiinformation display.

2 Turn-by-Turn Directions P. 8

You can turn this feature on or off using the multi-information display. See the Owner’s Manual for instructions.

2012 Civic Hybrid Navigation

The guidance screen offers an alternative way to view your route.



In single-screen mode, press the MAP/GUIDE button to switch between the map and guidance screens.



In split-screen mode, press the MAP/GUIDE button to switch between the next guidance direction and a list of guidance directions.



Driving to Your DestinationViewing the Route

QRG

TOC

Continued

Index

Home



Navigation

1 Route Line

You can set Unverified Area Routing to Off to follow your own route to the destination. If Unverified Area Routing is On, be aware that unverified streets may not be displayed accurately.

2 Unverified Area Routing P. 41

You can always view the entire route by simply saying d “Display entire route.”

The route line may also consist of red or orange segments when your route line displays traffic information.

2 Map Screen Legend P. 7 2 FM Traffic P. 99

Vector line (dotted)

Blue-pink route line

2012 Civic Hybrid Navigation

Driving to Your DestinationViewing the Route

QRG

■ Route Line

When driving on verified streets, the route line is light blue. The route line display changes when driving on unverified streets:

TOC

Index

Home



If Unverified Area Routing is Off, the route line uses verified streets only (when possible). A dotted “vector line” pointing directly towards your destination is also displayed.



If Unverified Area Routing is On, the route line changes to a dashed blue-pink line to indicate that the route line uses unverified streets.

Navigation

■ Deviating From the Planned Route

1 Deviating From the Planned Route

If Rerouting is set to Manual and you go off route, the system waits for you to manually initiate recalculation. Select Recalc.

2 Rerouting P. 40

1 Driving Off-road

A message “Not on a digitized road” may appear when you drive half a mile away from a mapped road.

Breadcrumbs may occasionally be displayed in urban areas, such as large parking lots in shopping malls, in new subdivisions where the roads are not yet in the database, or in areas where a GPS signal is unavailable, such as in a parking garage.

Off-road tracking breadcrumbs are limited to approximately 150 miles. Breadcrumbs at the beginning of the trail are deleted if you exceed that distance.

Breadcrumbs are displayed only at 1/20, 1/8, 1/4, and 1/2 mile map scales.

2012 Civic Hybrid Navigation

If you leave the calculated route, the system automatically recalculates a route to the desired destination based on your current location and direction.

2 Rerouting P. 40

■ Driving Off-road

If you leave all mapped (digitized) roads, the system automatically starts displaying a series of dots (breadcrumbs) to track the path you are taking. If needed, you can follow the dots back to the mapped road you originally left.

2 Off-road Tracking P. 50



Driving to Your DestinationViewing the Route

QRG

TOC

Index

Home



Navigation

1 Listening to Voice Guidance

d “Voice” (on the map screen)

You can turn voice guidance off if you prefer.

2 Display and Volume Settings P. 21

When driving in unverified areas, the phrase “if possible” is inserted before each voice guidance prompt.

VOICE on the map screen may be grayed out if the vehicle is approaching or in an unverified area.

The timing of voice guidance varies depending on the type of road you are on and the distance to the next guidance point.

2012 Civic Hybrid Navigation

Driving to Your DestinationListening to Voice Guidance

QRG

Listening to Voice Guidance

H VOICE (on map) As you approach each guidance point, a pop-up window is displayed on the map

screen with instructions for you to follow. Voice guidance for each guidance point is also provided.

TOC

Typically, you hear three prompts:

• 1/2 mile from the guidance point

• 1/4 mile from the guidance point

• Just before the guidance point

To replay voice guidance, select VOICE on the map screen. If you select VOICE between guidance points, voice guidance for the next guidance

point is provided.

Index

Home

Navigation

1 Map Menu

If you scroll the map while en route, press the MAP/GUIDE (or CANCEL/BACK) button to return to the current position map screen, then select MAP MENU.

Traffic Incidents

You must be in or near a traffic-enabled city to receive coverage for that area. FM Traffic is available in the lower 48 states and Hawaii.

The incident icons are displayed on the 5 mile (8 km) or less map scale.

2 Map Scale and Functions P. 95

2012 Civic Hybrid Navigation

Map Menu

Displaying Map Menu

Use the Map Menu to control the icons displayed on the screen and to display traffic information. You can also use the Map Menu to find locations or to cancel the route.

1. On the map screen, select MAP MENU (if displayed).



The Map Menu is displayed on the map screen.

2. Select an item.

QRG

TOC

The following items are available:

• Cancel Route: Cancels your current route.

2 Canceling the Route P. 102

• Show Icon on Map: Selects the icons to display on the map.

2 Showing Icons on the Map P. 92

• Traffic Incidents: Displays a list of the traffic incidents around your current location or on your current route.

2 FM Traffic P. 99

Continued

Index

Home



Navigation

2012 Civic Hybrid Navigation

Map MenuDisplaying Map Menu

QRG

• Map Legend: Displays an overview of the map features.

2 Map Legend P. 94

• Guidance Menu: Allows you to set or confirm the guidance points and freeway

TOC

exits for your route.

2 Guidance Menu P. 87

• Find Nearest…: Allows you to find the nearest place/landmark (e.g., nearest gas station) by specifying a category. You can then add the location to the list of destinations, set as a waypoint, or set as your destination.

2 Changing Your Destination P. 108

• Exit Info: Displays a list of the freeway exits.

2 Freeway Exit Information P. 89

Index

Home

Navigation

2012 Civic Hybrid Navigation

Guidance Menu

H MAP MENU (on map)  Guidance Menu Display the guidance points and freeway exits for your route, and set the display

mode for the map and guidance screens.

Select an item.

The following items are available:

• Directions: Displays a list of the guidance points.

2 Directions P. 88

• Guidance Mode: Selects the guidance display mode.

2 Guidance Mode P. 90



Map MenuGuidance Menu

QRG

TOC

Index

Home



Navigation

1 Directions

Guidance points with exit information are indicated by a (freeway exit information) icon. Select Exit Information to display the exit information.

2 Freeway Exit Information P. 89

The route guidance information is automatically deleted when you reach your destination.

2012 Civic Hybrid Navigation

Map MenuGuidance Menu

QRG

■ Directions

H MAP MENU (on map)  Guidance Menu  Directions Display a list of the guidance points on your route for your confirmation.

TOC

Index

Home

Select R or U to scroll through the list.



Press the MAP/GUIDE button to return to the map screen.

Navigation

■ Freeway Exit Information

1 Freeway Exit Information

d “Display Freeway Exit Information”

You can scroll the map and select a (freeway exit information) icon on the map screen to display the freeway exit information. The icon is only displayed if there is exit information available.

Icons are displayed only at 1/4, 1/2, or 1 mile scale.

2 Showing Icons on the Map P. 92

The route guidance information is automatically deleted when you reach your destination.

2012 Civic Hybrid Navigation

H MAP MENU (on map)  Exit Info. Display a list of the freeway exits for the route. You can view freeway exit

information (whether the exit is near gas stations, restaurants, ATMs, etc.) and add new destinations or waypoints to the calculated route.

1. Select an exit from the list.

2. Select a list item.



Select C or X to display information for different exits.



The location is displayed on the Calculate Route screen.

2 Calculating the Route P. 77



Map MenuGuidance Menu

QRG

TOC

Index

Home



Navigation

1 Guidance Mode

The guidance mode can also be selected from the System Setup menu.

2 Routing & Guidance P. 39

Map screen

Press the MAP/GUIDE button

Guidance screen

Press the MAP/GUIDE button

Directions list screen

2012 Civic Hybrid Navigation

Map MenuGuidance Menu

QRG

■ Guidance Mode

H MAP MENU (on map)  Guidance Menu  Guidance Mode Select the display mode during route guidance: single-screen mode (default) or split-

TOC

screen mode.

Select an option.

The following options are available:

• Single Screen: Displays the map and guidance screens on separate screens.

Index

Home

Navigation

• Split Screen: Displays the map and guidance information simultaneously on the

1 Guidance Mode

Next guidance point

The next guidance point (the pop-up window) is displayed on the map screen as you approach a guidance point in the single-screen mode.

The next guidance point is also displayed on the multi-information display.

2 Turn-by-Turn Directions P. 8

Next guidance point

Press the MAP/GUIDE button

Guidance direction list

Press the MAP/GUIDE button

Directions list screen

2012 Civic Hybrid Navigation

map screen.



Map MenuGuidance Menu

QRG

TOC

Index

Home



Navigation

1 Showing Icons on the Map

You can display or hide the icons using voice commands on the map screen (e.g., say d “Display hospital”).

2 Map Display Commands P. 190

2012 Civic Hybrid Navigation

Map MenuShowing Icons on the Map

QRG

Showing Icons on the Map

H MAP MENU (on map)  Show Icon on Map The icon bar along the bottom of the screen allows you to select the icons that are

displayed on the map.

TOC

The following options are available:

• Icon check boxes: Displays or hides the traffic and landmark icons.

2 Map Screen Legend P. 7 2 FM Traffic P. 99

• ALL OFF: Hides all icons.

• Icon Options: Fine-tunes the icon display.

2 Fine-tuning the Icons P. 93

Select an icon in the icon bar.



Selecting toggles the icon display on or off.



Repeat the procedure as necessary.

Index

Home

Navigation

1 Fine-tuning the Icons

To display the “Other Icons,” be sure to turn on OTHER ICON in the icon bar.

2012 Civic Hybrid Navigation

■ Fine-tuning the Icons

H MAP MENU (on map)  Show Icon on Map  Icon Options Icons in some categories can be fine-tuned to display or hide.

1. Select an icon category from the list (e.g., Other Icons).

2. Select the icons to display on the map.



Selecting toggles the icon display on or off.



Repeat the procedure as necessary.

3. Select OK.



Map MenuShowing Icons on the Map

QRG

TOC

Index

Home



Navigation

1 Map Legend

A visual guide helps you see the map legend.

2 Map Screen Legend P. 7 2 FM Traffic P. 99

2012 Civic Hybrid Navigation

Map MenuMap Legend

QRG

Map Legend

H MAP MENU (on map)  Map Legend See an overview of the map lines, areas, routes, traffic information, and navigation

icons.

TOC

Select an item.



The system displays the map legend.

Index

Home

Navigation

■ Map Scale and Functions

1 Map Scale & Functions

You can change the map scale using voice commands on the map screen (e.g., say d “Display 2 mile scale”).

2 Map Scale Commands P. 191

You can change between miles or kilometers.

2 Basic Settings P. 23

2012 Civic Hybrid Navigation

The functions that are available from the map screen depend on the map scale.

Function page

Icon display

Landmark icon 7 ✔ ✔

Exit info. 7 ✔ ✔ ✔

One-way traffic 7 ✔

Waypoint “flag”

Traffic incident 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔

Map orientation

Heading-up 97 ✔ ✔ ✔ ✔ ✔

North-up 97 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔

Others

Off-road tracking dots

Unverified road 7 ✔ ✔ ✔

Map features 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔

Avoid areas 43 ✔ ✔ ✔

Traffic speed 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔

1/20 1/8 1/4 1/2 1 2 5 15 50 150 350 1000

80 200 400 800 1.6 3 8 24 80 240 560 1600

8 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔

83 ✔ ✔ ✔ ✔

Map Scale (top: mile, bottom: metric)



Map MenuMap Legend

QRG

TOC

Index

Home



Navigation

1 Map Icons & Functions

You can display or hide the icons using voice commands on the map screen (e.g., say d “Display hospital”).

2 Map Display Commands P. 190

Some icons, like police stations, are not shown, but you can still locate the nearest one with the Find Nearest voice command (e.g., say d “Find nearest police station”).

2 Find Place Commands P. 191

Icon display control

Icons that can be displayed or hidden.

Icon selectable

Icons that can be selected as a destination using the joystick.

Icon searchable

Icons that can be searched using the d Find Nearest voice command.

2012 Civic Hybrid Navigation

Map MenuMap Legend

QRG

■ Map Icons and Functions

Display or hide all icons on the map screen, with the exception of Honda/Acura Dealer icons which are always shown.

TOC

■ Landmark icon

Honda/Acura dealer Always on Yes Yes Hospital Yes Yes Yes School Yes Yes Yes ATM Yes Yes Yes Gas station Yes Yes Yes Restaurants Yes Yes Yes Post office Yes Yes Yes Grocery store Yes Yes Yes Hotel/Lodging Yes Yes Yes Police station No icon No Yes Shopping, Tourist attraction, Bank No icon No Yes Parking garage Yes Yes Yes

Index

Home

Parking lot Yes Yes Yes Freeway exit info. Yes Yes No

Type

Icon display

control

Icon

selectable

Icon

searchable

Navigation

■ Traffic icon

1 Traffic Incident

When you use the joystick to position the cursor (round red circle) over the traffic incident icon, you can view the summary of the incident.

When you press the ENTER button to select the traffic incident icon, you can view a pop-up message describing the incident in detail.

1 Map Orientation

d “Display Heading-up” (from map screen), d “Display North-up” (from map screen)

The red arrow in the symbol always points North. On scales greater than 1 mile, North-up mode is always used.

Map orientation icon

North-up: Displays the map with North always pointing up.

Map orientation icon

Heading-up: Displays the map so that the direction you are traveling is always pointing up.

Select

2012 Civic Hybrid Navigation



Map MenuMap Legend

QRG

Type

Traffic speed Yes No No Traffic incident Yes No Yes

■ Map Orientation

Select the map orientation icon to change the map orientation.

Icon display

control

Icon

selectable

Icon

searchable

TOC

Index

Home



Navigation

1 Current Location

d “Display Current Location” (on map screen)

You can also save the current location by saying d “Register the Current Location”.

If you have PIN-protected your address book, enter your PIN when prompted. Select OK. PINs are optional.

2 PIN Numbers P. 36

The elevation is not displayed if the system is receiving insufficient GPS information. When elevation is displayed, it may differ with roadside elevation signs by ±100 feet or more.

Saving your current location does not change or cancel your current route.

2012 Civic Hybrid Navigation

Map MenuMap Legend

QRG

■ Current Location

Display and save your current location for future use as a destination. The address, latitude, longitude, and elevation of your current location are displayed.

TOC

■ To save your current location in the address book:

1. Select the vehicle icon on the map.

2. Select Save.

Index

Home

3. Edit the name, phone number, and category.

2 Address Book P. 30

4. Select OK.

Navigation

FM Traffic

1 FM Traffic

You must be in or near a traffic-enabled city to receive coverage for that area. FM Traffic is available in the lower 48 states and Hawaii.

Automatic traffic rerouting may not provide a detour route depending on circumstances.

d “Display traffic incidents”, d “Display traffic list”

You can also display the traffic incidents from the INFO screen.

You can display traffic incidents and related information on the map screen using voice commands.

2 Map Display Commands P. 190

2012 Civic Hybrid Navigation

H MAP MENU (on map)  Traffic Incidents View and avoid specific incidents and/or congestion on your route:

1. Select On Route.

2. Select an incident from the list.



The system displays the map screen and the incident location.

3. Select Traffic Detail.

Continued



Map MenuFM Traffic

QRG

TOC

Index

Home

HONDA Civic Hybrid Navigation 2012 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Quick Reference Guide

System Setup

Start-up

Voice Control System

Command Input

Voice Recognition

Interface Settings

Display and Volume Settings

Guidance Prompts

Basic Settings

Color

1 Map Color

1 Menu Color

1 Switching Display Mode Manually

Language

Personal Information

Address Book

1 Adding an Address Book Entry

1 Editing an Address Book Entry

1 Selecting an Address Book Category

1 Deleting an Address Book Entry

Home Addresses

PIN Numbers

User Name

Previous Destinations

Routing & Guidance

Rerouting

Unverified Area Routing

Edit Avoid Area

Edit Waypoint Search Area

Clock Adjustment

Adjust Time

Resetting the Clock Settings

Setting the Clock Type

Vehicle

Off-road Tracking

Correct Vehicle Position

Data Reset

Clear All Speed Dial

Navigation

Entering a Destination

Address

■ Selecting the State or Province

■ Selecting a City

■ Selecting a Street

Address Book

Previous Destinations

Place Name

1 Place Name in Multiple Categories

Place Category

■ Favorite Subcategories

Place Phone Number

Coordinate

Intersection

Map Input

Calculating the Route

Changing the Route Preference

Viewing the Routes

Calculating the Route on the Destination Map

Driving to Your Destination

Viewing the Route

■ Guidance Screen

1 Route Line

■ Deviating From the Planned Route

1 Driving Off-road

Listening to Voice Guidance

Map Menu

Displaying Map Menu

Guidance Menu

1 Directions

■ Freeway Exit Information

1 Guidance Mode

Showing Icons on the Map

1 Fine-tuning the Icons

Map Legend

■ Map Scale and Functions
