Holux GR-271 User Manual

GR-271

CF GPS Receiver

User’s Guide

Aug 17, 2006

2

TABLE OF CONTENTS

1. Introduction

1.1 Overview

1.2 Features

2. Brief Information

2.1 Hardware Interface

2.2 Software Interface

3. Functional Test

4. Trouble Shooting

5. Specifications

6. Warranty

………………………………………………………………………………………..

……………………………………………………………………………………..
……………………………………………………………………………………..

……………………………………………………………….…………………

……………………………………………………………………………
……………………………………………………………………………

………………………………………………………………………….……

…………………………………………………………………………….…

……………………………………………………………………………………….

………………………………………………………………………………………………

3
3
3

5
5
6

9

12

13

14

1. Introduction

1.1 Overview

1.2 Features

The GR-271 provides a host of features that make it easy for integration and use.

z 20 parallel satellite-tracking channels for fast acquisition and reacquisition

z Built-in hardware tracking loop processor WAAS/EGNOS demodulator

z Low power consumption with starШ chipset

z Built-in rechargeable battery for memory and RTC backup and for fast time to first fix(TTFF)

z Support NMEA0183 v2.2 data protocol and SiRF binary code

z Enhanced algorithms-SnapLock and SnapStart provide superior navigation performance in urban,

canyon and foliage environments

z Support CF card type I connector suitable PDA, Hand Held PC or PC device

2
