Hitachi UB 18DSL Technical Data And Service Manual

CORDLESS LANTERN

UB 18DSL

UB 18DSL

H805

Mar. 2008

U

CONTENTS

Page

1. PRODUCT NAME ----------------------------------------------------------------------------------------------------- 1

2. MARKETING OBJECTIVE ----------------------------------------------------------------------------------------- 1

3. APPLICA TIONS ------------------------------------------------------------------------------------------------------- 1

4. SELLING POINTS ---------------------------------------------------------------------------------------------------- 1

4-1. Selling Point Descriptions ---------------------------------------------------------------------------------------- 2

5. SPECIFICATIONS ---------------------------------------------------------------------------------------------------- 3

5-1. Specifications ---------------------------------------------------------------------------------------------------- 3
5-2. Specifications

Descriptions-------------------------------------------------------------------------------------- 4

6. PRECAUTIONS IN SALES PROMOTION (SAFETY INSTRUCTIONS)-------------------------------- 5

7. REPLACEMENT OF LAMP, LAMP CAP AND LAMP COVER ------------------------------------------- 6

7-1. Replacement of the Lamp---------------------------------------------------------------------------------------- 6

7-2.

Replacement of the Lamp Cover------------------------------------------------------------------------------- 6

7-3.

Replacement of the Lamp Cap------------------------------------------------------------------------------- 6

8. SPARE PARTS--------------------------------------------------------------------------------------------------------- 7

Assembly Diagram for UB 18DSL

-1-

1. PRODUCT NAME

Hitachi Cordless Lantern, Model UB 18DSL

2. MARKETING OBJECTIVE

The Model UB 18DSL is a fluorescent lantern that works on Hitachi BSL 14 series batteries.

3. APPLICATIONS

For construction work, outdoor use, etc.

4. SELLING POINTS

LED small light

Usable for 150 hours as an all-night
light (when using a 3-Ah battery).

Holes for attaching a strap

The handle has holes to attach a
user's strap.

Detachable reflector

For increased brightness and
prevention of backward glare

Automatic LED switching
function

It automatically switches lighting
from fluorescent lamp to LED
when the battery is discharged.
* When the battery remaining

power is nearly empty, the
overdischarge protection
circuit may prevent the LED
from lighting.

14.4-V slide-type lithium-ion
battery is attachable.

Rotary hooked handle

It can be hung on a single pipe 48.6
mm in diameter, and locked in eight
positions in increments of 45°. It is
also possible to lock the lantern
upside down.

NOTE: The battery is sold separately.

-2-

4-1. Selling Point Descriptions
4-1-1. Rotary hooked handle

The Model UB 18DSL has a hooked handle. It can be hung on a pipe up to 50 mm (2 inches) in
diameter and locked in eight positions in increments of 45°.
(Locking position: 0°, 45°, 90°, 135°, 180°, 225°, 270°, 315°)
NOTE: When hanging the Model UB 18DSL on a pipe 30 mm (1-3/16 inches) or more in diameter ,

turn the handle to any position other than the 0° position and then hang it on the pipe. It is
impossible to hang the Model UB 18DSL on a pipe 30 mm (1-3/16 inches) or more in
diameter when the handle is in the 0° position because the lamp cover contacts such a
pipe in the 0° position.

4-1-2. Detachable reflector

The Model UB 18DSL is equipped with the reflector to increase brightness and to prevent
backward glare. Use the Model UB 18DSL by detaching the reflector depending on applications.

4-1-3. Holes for attaching a strap

There are two holes for attaching a user's strap at both sides of the upper portion of the handle.

4-1-4. LED small light

The Model UB 18DSL has a white LED that can be operated for about 150 hours when using a
fully charged 3.0 Ah battery. The LED can be lit for a long time because it consumes low power
while it has high directivity. The Model UB 18DSL is convenient as an all-night light if so bright
light is not required.
* The LED will be dim by the

overdischarge protection circuit of the lithium-ion battery if the battery

is nearly discharged

.

4-1-5. Automatic LED switching function

The Model UB 18DSL automatically switches lighting from fluorescent lamp to LED when the
battery voltage is decreased to about 14 V to prevent from being extinguished suddenly.
* When switched automatically from fluorescent lamp to LED, please charge the battery
because the remaining battery level is low.
